S T 4 0 I N S T RU M E N T S

ST40 INSTRUMENTS

Depth Compass Wind

Compact yet powerful, ST40 instruments feature extra large characters and razor sharp displays for outstanding visibility in all light conditions. Fully compatible with

Raymarine SeaTalk® networking ST40 integrates seamlessly with Raymarine autopilots and multifunction navigation displays.

ST40 BIdATA

ST40 Bidata offers all the features of the ST40 speed and ST40 depth units in a single display. Available as a system with transducers or as a repeater display.

Display features: 200Khz frequency, digital depth display of minimum depth, shallow and deep anchor alarms. Current, max and average speed display.

Log, trip and sea water temperature indicator.

ST40 WINd

ST40 Wind instrument features wind speed and direction in both apparent and true. Wind angle can be locked manually or automatically. Display features: Deviation and course-to-steer to achieve locked wind angle. System supplied with rotavecta type wind transducer.

ST40 SPEEd

The ST40 Speed instrument is available as a system with a transducer or as a repeater display. Display features: current, max and average speed in either knots (kts), miles per hour, (mph) or kilometers per hour (kph). Log and trip, and sea water temperature indicator.

ST40 dEPTh

The ST40 Depth instrument is available as a system with a transducer or as a repeater display. Display features: 200Khz frequency, digital depth display of minimum depth, shallow and deep anchor alarms.

Depth can be displayed in feet (ft), meters (m) or fathoms (fa).

ST40 COMPASS

The ST40 compass instrument is available as a system with a compass transducer or as a repeater display for Raymarine autopilot systems. Display features:

Analog compass display with true or magnetic mode.

S T 6 0 P L U S I N S T RU M E N T S

ST60 PLUS INSTRUMENTS

ST60 Plus instruments combine maximum performance and versatility with bold, easy-to-read displays that set the standard for instrument systems. Based on the award winning ST60 instruments, ST60 Plus feature a new bezel design that compliments

Raymarine’s multifunction navigation displays. SeaTalk networking enables each instrument to receive 12 volt power and data from a single easy-to-install cable.

Plug and play compatibility with Raymarine Autopilots and Multifunction Displays.

SPEEd

ST60 Plus with optional low profile mounting bezel

The ST60 Plus speed provides accurate speed through water. Calibration is easy using SOG data from SeaTalk

(GPS required). Available as a system with transducer or as a repeater display. Display features: Speed (0 – 60 in kts, mph or kph), max/average speed, cumulative log, trip log with reset, 1/100 knot resolution, sea temp, stop watch/lap time, 10 and 5 minute race start timer, and VMG (Velocity

Made Good).

dEPTh

The ST60 Plus delivers reliable depth performance and accuracy. Available as a system with 200 KHz transducer or as a repeater display. Display features: Depth performance from

2.6’ to 600’ (0.8 – 180 m), maximum and minimum depth display, depth trend indicator, adjustable display response, transducer, keel or waterline offset.

WINd

The ST60 Plus wind display and systems offer reliable and accurate performance. ST60 Plus Wind offers a choice of vane or rotavecta wind transducers. Add the ST60 Plus

Close Hauled repeater for precise wind measurements between 20° and 60°. Display features: Apparent wind speed and direction, true wind speed and direction (relative), max wind speed, max wind speed alarm, beaufort scale, adjustable display and pointer response, and heading on opposite tack

gRAPhIC

*Visit www.raymarine.com for a complete list of compatible

NMEA 0183 sentences

A versatile repeater of SeaTalk data from compatible

Raymarine instruments, autopilots, GPS, and multifunction displays. The ST60 Graphic is also NMEA 0183 compatible* for integration with other brands of marine electronics.

Display features: Easy-to-use chapter and page control, depth, speed, SOG, sea temp, VMG, log and trip, true and apparent wind speed & direction (relative), beaufort scale, cardinal point, GPS Lat/Lon, COG, cross track error, bearing to waypoint/ distance to waypoint, pilot rudder angle, heading, autopilot status indicator, battery voltage/battery and voltage alarm.

TRIdATA

The versatile Tridata combines the functions of the ST60

Plus Speed and Depth instruments into a single display.

Choose a Tridata system with transducers or a Tridata repeater display. Display features: Depth performance:

2.6’ – 600’ (0.8 – 180 m), max and min depth with trend indicator, transducer keel or waterline offset, speed with max/average display with 1/100 knot resolution, cumulative log, trip log with reset, sea temperature, stopwatch/lap timer, VMG (Velocity Made Good), SOG (requires data on

SeaTalk).

COMPASS ANd RUddER

Compass and rudder displays are available as systems with transducers or as repeaters for Raymarine autopilot systems.

The Compass display can also repeat GPS course over ground (COG) data from SeaTalk.

S T 7 0 C O L O R M U LT I F U N C T I O N I N S T RU M E N T S

ST70 COLOR MULTIfUNCTION INSTRUMENTS

ST70 multifunction instruments offer a brand new way of visualizing instrumentation.

Featuring a graphical user interface and high resolution color displays, ST70 provides unmatched versatility and ease of use. Designed for simple setup and extensive customization, ST70 delivers an array of intuitive digital, graphical and historical display options.

ST70 APPLICATIONS

The ideal companion instrument system for Raymarine MFDs, creating a full color helm solution

• Choose multiple ST70 instruments and transducers for a full featured,

information rich instrument system

• Utilize ST70 as a navigation data repeater with a Raymarine multifunction display

TECh TIP: ST60 PLUS INTEgRATION

• Add color to your ST60 instrument system with an ST70 multifunction instrument

• Each ST70 instrument is supplied with a first generation SeaTalk adapter cable for

plug and play connectivity with ST60/ST60 Plus instruments

• ST70 intelligently converts first generation SeaTalk data to SeaTalk

ng

ST70 fEATURES INCLUdE:

• 3.5” Sunlight viewable display

• Eight user defined data pages with 16 screen layout options for each data page

• Easy-to-use menu and icon driven interface

• Fast SeaTalk

ng

next generation data bus interface for creating an ST70

instrument network

• NMEA2000 compatible for engine instrument integration

• Simple start up wizard configures every ST70 display on the SeaTalk

ng

data bus

• Combine with SeaTalk

ng

transducers for depth, speed and wind data

• Compatible with Raymarine SeaTalk and SeaTalk2 instrument systems as well as

Raymarine autopilots and multifunction displays

Intuitive graphical displays for visualizing data

Customize the display with analog, digital, bar graphs and historical data displays

GPS and Waypoint

Navigation display

Engine instrumentation using NMEA2000

S T 7 0 P L U S I N S T RU M E N T & AU TO P I L OT S YS T E M

ST70 PLUS INSTRUMENT & AUTOPILOT SYSTEM

The ST70 Plus system is an innovative instrumentation and autopilot display and control system engineered for premium power and sailing yachts. ST70 Plus is the perfect partner for Raymarine E-Series and G-Series navigation systems. The ultra bright 6.5” color display is ideal for installations where information is viewed at a distance. An ergonomic remote instrument keypad provides complete control of the intuitive menu and icon user interface, plus multiple ST70 Plus displays can be controlled from a single instrument keypad. ST70 Plus is fully customizable with high quality graphics, multiple color palettes and 17 unique screen layout options.

Combine an ST70 Plus display with either the Sail or Power pilot keypad and enjoy full function autopilot control of any SmartPilot X-Series autopilot system.

kEY fEATURES

• 6.5” Ultra bright sunlight viewable display

• Superior visibility with high quality graphics and a wide viewing angle

• Night mode and inverse text mode enhance visibility at night or from a distance

• Create a system with SeaTalk

ng

sensors for wind, speed, depth

and NMEA2000 compatible engine systems

• User defined instrument pages

• 17 screen layout options with analog, digital, and historical displays

• Configure as either an instrument or autopilot display

S T 7 0 P L U S I N S T RU M E N T & AU TO P I L OT S YS T E M

INSTRUMENT kEYPAd

The instrument keypad controls all the instrument functions via a series of push buttons and a rotary ‘Unicontrol’ interface.

SAIL PILOT kEYPAd

Designed for sail boats, the sail pilot keypad consists of dedicated buttons to engage and disengage the autopilot, perform a dodge maneuver and track to a waypoint. Course adjustment and auto tack functions are made using the port and starboard -1, +1, -10 and +10 keys.

POWER PILOT kEYPAd

The power pilot keypad is designed specifically for powerboats.

Dedicated buttons are used to engage and disengage the pilot and the rotary control provides simple course changes.

W I R E L E S S

WIRELESS SMARTCONTROLLER

Take control of your Raymarine SeaTalk network with the powerful SmartController wireless handheld remote. Access instrument data from ST40, and ST60 Plus in the palm of your hand. Plus SmartController is a full function autopilot remote control.

The bright display and ergonomic keypad offer straightforward operation with access to up to eight user defined SeaTalk instrument data pages.

SmartController Ordering Information

Part # Description

E15023 SmartController with base station

W I R E L E S S S T 4 0 N E T W O R K D I AG R A M

SeaTalk

3 Way SeaTalk

Junction Box

12 Volt

Power Supply

SeaTalk

3 Way SeaTalk

Junction Box

SeaTalk SeaTalk

ST40 Depth Display

ST40 Speed Display

ST40 Wind Display

Depth Transducer

Speed Transducer

Typical ST40 Depth, Speed and Wind System

ST40 ORdERINg INfORMATION

Part # Description

E22037

E22038

E22041

E22039

ST40 Speed Display

ST40 Depth Display

ST40 Wind Display

ST40 Bidata Display

E22042 ST40 Compass Display

ST40 Systems

E22047 ST40 Wind System

E22045

E22054

E22053

E22044

ST40 Bidata System (Thru Hull)

ST40 Bidata System (Transom Mount)

ST40 Depth System (Transom Mount)

ST40 Depth System (Thru Hull)

E22052

E22043

E22048

ST40 Speed System (Transom Mount)

ST40 Speed System (Thru Hull)

ST40 Compass System

Wind Transducer

S T 6 0 P L U S N E T W O R K D I AG R A M

12 Volt

Power Supply

SeaTalk

SeaTalk

SeaTalk

ST60 Plus Depth

Display

ST60 Plus Speed

Display

ST60 Plus Wind

Display

Depth Transducer

Speed Transducer

Wind Transducer

Typical ST60 Plus Depth, Speed and Wind System

ST60 PLUS ORdERINg INfORMATION

Part #

A22004-P

A22013-P

A22002-P

A22010-P

A22001-P

A22009-P

A22005-P

A22011-P

A22012-P

E22049-P

A22016-P

E22075-P

A22006-P

A22017-P

A22007-P

A22014-P

A22008-P

A22015-P

T22050-P

T22052 -P

A25003-P

E25009

Description

ST60 Plus Tridata Display

ST60 Plus Tridata System

ST60 Plus Depth Display

ST60 Plus Depth System

ST60 Plus Speed Display

ST60 Plus Speed System

ST60 Plus Wind Display (Analog)

ST60 Plus Wind System Analog Rotavecta

ST60 Plus Wind System Analog Vane

ST60 Plus Clubhouse Wind Display

ST60 Plus Clubhouse Wind Analog System

ST60 Plus Graphic Display

ST60 Plus CH/VMG Display

ST60 Plus Tridata Repeater

ST60 Plus Compass Display

ST60 Plus Compass System

ST60 Plus Rudder Angle Indicator Display

ST60 Plus Rudder Angle Indicator System

ST60 Plus Tridata w/Speed & Retractable Depth Transducer

ST60 Plus Wind System Analog Vane w/50M Cable

ST60 Plus Flush Mount Kit

ST60 Plus Bracket Mount Kit

S T 7 0 N E T W O R K D I AG R A M

ST70 instruments

Transducer pod

Wind transducer

SeaTalk

ng

backbone

Terminator

Transducer pod

Power Supply

12V dc

SeaTalk

ng

backbone

Transducer pod

Depth transducer

Speed transducer

ST70 ORdERINg INfORMATION

PART # dESCRIPTION

E22105 ST70 3.5” Color Instrument Display

E22106 ST70 Depth Transducer Pod

E22107 ST70 Speed Transducer Pod

E22108 ST70 Wind Transducer Pod

A22111 Smart Depth, Speed and Temperature transducer

A22112 Smart Depth and Temperature transducer with 12 degree tilted element depth sensor

S T 7 0 P L U S N E T W O R K D I AG R A M

ST70+ Instrument displays

ST70+ Pilot Controller display

12V dc

Fuse Fuse Fuse

Power Supply for

ST70+ displays

12V dc 12V dc

ST70+ Pilot

Controller keypad

SeaTalk

ng

backbone

SeaTalk

ng

Power Supply

Terminator

5-Way Connector

12V dc

SeaTalk

ng

backbone

Wind transducer

ST70+

Instrument keypad

Transducer pod

DST800

Smart transducer

X-10 Course

Computer

ST70 PLUS ORdERINg INfORMATION

PART #

E22115

E22116

E22117

E22118

E22119

E22121

E22122

E22123

dESCRIPTION

ST70 Plus Display

ST70 Plus Instrument Keypad

ST70 Plus Sail Key Pad

ST70 Plus Power Key Pad

Analog Close Hauled Wind/VMG repeater

Analog Compass repeater

Analog Rudder Reference indicator

Analog Wind repeater

S T 7 0 P L U S N E T W O R K D I AG R A M

SEATALk

ng

NExT gENERATION dATA BUS

A fast CAN based network, SeaTalk

ng

enables the simple interconnection of multiple

ST70 instruments, transducers and NMEA2000 compatible devices. Small diameter cables and color coded connectors make SeaTalk

ng

networks easy and straightforward to install. In addition to networking, ST70 displays and transducer pods receive power from the SeaTalk

ng

bus, eliminating the need for additional power cables and simplifying installation.

SEATALk

ng

fEATURES INCLUdE:

• Color coded and keyed connectors for foolproof installation of backbones and spurs

• Very small diameter connectors (11.0mm) for passing through bulkheads and in

areas with limited access

• Rugged and waterproof (IP67) with positive locking connectors

• Quick and easy to install (including blind and limited access conditions)

• NMEA2000 compatible using optional SeaTalk

ng

to DeviceNet adapter cables

SEATALk

ng

TRANSdUCER OPTIONS

SeaTalk

ng

transducer pods for use with depth, speed and wind transducers (pods and transducers are sold individually) Smart™ transducers do not require a pod and connect directly to the SeaTalk

ng

databus.

200 kHz Depth transducer and SeaTalk

ng

depth pod

Speed transducer and

SeaTalk

ng

speed pod

Wind sensor and

SeaTalk

ng

wind pod

235 kHz Depth and Temperature

Smart™ Transducer with 12 degree tilted element

235 kHz Depth, Temperature and Speed Smart™ Transducer

S T 7 0 N E T W O R K D I AG R A M

SEATALkng CABLES ANd CONNECTORS

Backbone Cables

PART # dESCRIPTION

A06033 1 ft 3 in (400mm) Backbone Cable

A06034 3 ft 3 in (1m) Backbone Cable

A06035 9 ft 10 in (3m) Backbone Cable

A06036 16 ft 4 in (5m) Backbone Cable

A06037 65 ft 7 in (20m) Backbone Cable

A25062

Backbone kit- Comprises: Two terminators, one 65 ft 7 in (20m) backbone cable, two 16 ft 4 in (5m)

Backbone cables, four T-Piece connectors, one power cable, one SeaTalk

ng

Reference Manual

Spur Cables

PART # dESCRIPTION

A06038 1 ft 3 in (400mm) Spur Cable

A06039 3 ft 3 in (1m) Spur Cable

A06040 9 ft 10 in (3m) Spur Cable

A06041 16 ft 4 in (5m) Spur Cable

A06042 1 ft 3 in (400mm) Elbow Spur Cable - For spurs in confined spaces

A06049 Power Cable- Connects SeaTalk

ng

12 V dc supply

A06043 1m Stripped end spur cable - Connects products which do not have plug in connectors ( e.g. transducer pods)

A06044 3m Stripped end spur cable - Connects products which do not have plug in connectors ( e.g. transducer pods)

Adapters, T Pieces & Connectors

PART # dESCRIPTION

A06028 T Piece- Connects one spur to backbone

A06064 5-Way Connector- Connects three spurs to backbone

A06030 Backbone Extender- Connects two backbone cables

A06031 Terminator- Fitted at each end of backbone

A06032 Blanking Plug- Inserted into unused spur connector positions in 5-way connector & T Piece

A06047 SeaTalk Adapter Cable- Connects SeaTalk

ng

products to SeaTalk(1)

A06048 Seatalk2 Adapter Cable- Connects SeaTalk

ng

products to SeaTalk2

A06045 DeviceNet Female Adapter Cable- Connects SeaTalk

ng

products to NMEA2000

A06046 DeviceNet Male Adapter Cable- Connects SeaTalk

ng

products to NMEA2000

A06061 E-Series Adapter Cable- Connects SeaTalk

ng

products to Raymarine E-Series Displays

ST70 Plus Display ST70 Plus Power Pilot/Instrument

& ST70 Plus Sail Pilot Keypads

7.44”(189mm) .26”

(6.5mm)

1.67”

(42.3mm)

ST70 Display

Surface

Mount

Flush

Mount

3.62”(92mm) .26”

(6.5mm)

1.38”

(35mm)

Transducer Pod

4.33"(110mm) 0.95"

(24 mm)

0.95"

(24 mm)

ST60 Plus Surface Mount

2.6” (66 mm)

1.42”

(36 mm)

ST60 Plus Flush Mount

4.33 in (110mm)

1.54 in

(39mm)

.94 in

(24mm)

ST60 Plus Speed

and Depth Transducer

2” (51mm) 2” (51mm)

4.90 in (124 mm)

0.25” 1.4”

(6.50 mm) (35 mm)

ST40 Display

2.95” (75mm) 2.95” (75mm)

ST40 Speed and Depth Transducer

2.01”

(51mm)

2.01”

(51mm)

2.95”(75mm) 2.95”(75mm)

Wind Transducer

10.71”(272mm)

2.44”(68mm)

21.20”(538.5mm) 1.50”(38mm)

4.96”(126mm) .83”

(21mm)

.67”

(17mm)

Rotavecta Wind Transducer

2.64”

(67mm)

SmartController

5.82” (148 mm)

ExPLORE RAYMARINE PROdUCTS ONLINE

WWW.RAYMARINE.COM

• Extensive product information and video tutorials

• Expert technical advice and FAQs

• Connect with authorized Raymarine dealers

• Stay connected with the latest Raymarine news on our Insider Blog

Raymarine Inc.

21 Manchester Street

Merrimack, NH 03054

USA

Tel: 603.881.5200

Fax: 603.864.4756 www.raymarine.com

Raymarine plc.

Marine House, 5 Harbourgate,

Southampton Road, Portsmouth,

Hampshire PO6 4BQ, UK.

Tel: +44(0)23 9269 3611

Fax: +44(0)23 9269 4642 www.raymarine.co.uk

Additional information, specifications and interactive product tours available online at www.raymarine.com

Product specifications subject to change without notice

LIT82304 - 0909

Learn about all our new products. Go to www.raymarine.com

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
