BP7304021

EN

OVEN USER MANUAL

EURO Appliances - euappliances.info

2

FOR PERFECT RESULTS

Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.

ACCESSORIES AND CONSUMABLES

In the AEG webshop, you’ll find everything you need to keep all your AEG appliances looking spotless and working perfectly. Along with a wide range of accessories designed and built to the high quality standards you would expect, from specialist cookware to cutlery baskets, from bottle holders to delicate laundry bags…

Visit the webshop at: www.aeg.com/shop

EURO Appliances - euappliances.info

CONTENTS

Contents 3

4 Safety information

7 Product description

9 Before first use

10 Control panel

12 Daily use

14 Clock functions

16 Automatic programmes

17 Using the accessories

20 Additional functions

22 Care and cleaning

26 What to do if…

27 Environment concerns

28 GREAT BRITAIN & IRELAND -

Guarantee/Customer Service

EURO Appliances - euappliances.info

The following symbols are used in this user manual:

Important information concerning your personal safety and information on how to avoid damaging the appliance.

General information and tips

Environmental information

Subject to change without notice

4 Safety information

Before the installation and use, read this manual carefully:

• For your personal safety and the safety of your property

• For the respect of the environment

• For the correct operation of the appliance.

Always keep these instructions with the appliance also if you move or sell it.

The manufacturer is not responsible if incorrect installation or use results in damage.

Children and vulnerable people safety

• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in safe way and understand the hazards involved. Children shall not play with the appliance.

• Keep all packaging away from children. There is the risk of suffocation or physical injury.

• WARNING: Keep children and animals away from the appliance when the door is open or the appliance is in the operation, because it becomes hot. There is the risk of injury or other permanent disability.

• If the appliance has Child Lock or Key Lock (Control Lock) function, use it. It prevents children and animals from accidental operation of the appliance.

General safety

• Do not change the specifications of this appliance. There is the risk of injury and damage to the appliance.

• Do not let the appliance stay unattended during operation.

• Switch off the appliance after each use.

Installation

• Only an approved electrician can install and connect the appliance. Contact an approved service centre. This is to prevent the risks of structural damage or physical injury.

• Make sure that the appliance is not damaged because of transport. Do not connect a damaged appliance. If necessary, contact the supplier.

• Remove all packaging, stickers and layers from the appliance before first use. Do not remove the rating plate. It can invalidate the guarantee.

• Make sure that the appliance is disconnected from the power supply during the installation.

• Be careful when you move the appliance. The appliance is heavy. Always use safety gloves. Do not lift the appliance by the handle.

• The electrical installation must have an isolation device which lets you disconnect the appliance from the mains at all poles. The isolation device must have a contact opening width of minimum 3 mm.

• You must have correct isolation devices: line protecting cut-outs, fuses (screw type fuses removed from the holder), earth leakage trips and contactors.

EURO Appliances - euappliances.info

Safety information 5

• Before the installation, make sure that the kitchen cabinet has the recess dimensions applicable.

• Make sure that the appliance is installed below and adjacent safe structures.

• Keep the minimum distances to the other appliances and units.

• The appliance cannot be positioned on a base.

• Built in ovens and built in cooking surfaces are attached with special connection system.

To prevent damage to the appliance, only use an appliance with the appliances from the same manufacturer.

Electrical connection

• The appliance must be earthed.

• Make sure that the electrical data on the rating plate agree with your domestic power supply.

• Information on the voltage is on the rating plate.

• Always use a correctly installed shockproof socket.

• Do not use multi-way plugs, connectors and extension cables. There is the risk of fire.

• Do not replace or change the mains cable. Contact the service centre.

• Make sure not to squash or cause damage to the mains plug (if applicable) and cable behind the appliance.

• Do not pull the mains cable to disconnect the appliance. Always pull the mains plug – if applicable.

Use

• The appliance is only for domestic use. Do not use the appliance for commercial and industrial use.

• Only use the appliance for domestic cooking tasks. This is to prevent physical injury to persons or prevent damage to property.

• Do not use the appliance as a work surface or storage surface.

• The interior of the appliance becomes hot during use. There is the risk of burns. Do not touch the heating elements in the appliance. Use gloves when you insert or remove the accessories or pots.

• Be careful when you remove or install the accessories to prevent damage to the oven enamel.

• Always stay away from the appliance when you open the door while the appliance is in operation. Hot steam can release. There is the risk of skin burns.

• To prevent damage or discoloration to the enamel:

– do not put any objects directly on the appliance floor and do not cover it with aluminium foil;

– do not put hot water directly into the appliance;

– do not keep moist dishes and food in the appliance after you finish the cooking.

• Discoloration of the enamel has no effect on the performance of the appliance so it is not a defect in the sense of the warranty law.

• Do not apply pressure on the open door.

EURO Appliances - euappliances.info

6 Safety information

• Always close the appliance door when you cook, even while grilling.

Care and cleaning

• Before maintenance, switch off the appliance and disconnect the appliance from the power supply.

• Before maintenance, make sure that the appliance is cold. There is the risk of burns.

There is the risk that the glass panels can break.

• Keep the appliance clean at all times. A build-up of fats or other foodstuff can result in a fire.

• Regular cleaning prevents the surface material from deteriorating

• Use a deep baking tray for very moist cakes to prevent that fruit juices cause stains that can be permanent.

• For your personal safety and the safety of your property, only clean the appliance with water and a soap. Do not use flammable products or products that can cause corrosion.

• Do not clean the appliance with steam cleaners, high-pressure cleaners, sharp objects, abrasive cleaning agents, abrasive sponges and stain removers

• If you use an oven spray, follow the instructions from the manufacturer.

• Do not clean the glass door with abrasive cleaning agents or metal scraper. Heat resistant surface of the inner glass can break and shatter.

• When the door glass panels are damaged they become weak and can break. You must replace them. Contact the service centre.

• Be careful when you remove the door from the appliance. The door is heavy!

• Do not clean catalytic enamel (if applicable).

Risk of fire

• Open the door carefully. The use of ingredients with alcohol can cause a mixture of alcohol and air. There is the risk of fire.

• Do not let sparks or open flames come near the appliance when you open the door.

• Do not put flammable products or items that are wet with flammable products, and/or fusible objects (made of plastic or aluminium) in, near or on the appliance.

Pyrolytic cleaning

• Do not leave the appliance unattended during Pyrolytic cleaning.

• Do not try to open the door and do not cut the power supply during Pyrolytic cleaning.

• Keep children away during pyrolytic cleaning. The appliance becomes very hot. There is the risk of burns.

• During pyrolytic cleaning, stubborn dirt can cause discoloration to the enamel. Discoloration to the enamel has no effect on the performance of the appliance

Oven lamp

• Bulb lamps used in this appliance are special lamps selected for household appliances use only. They cannot be used for the full or partial illumination of a household room.

• If it becomes necessary to replace the lamp use one of the same power and specifically designed for household appliances only.

EURO Appliances - euappliances.info

Product description 7

• Disconnect the appliance from the power supply before the replacement of the oven lamp. There is the risk of electrical shock.

Service centre

• Only an approved engineer can repair or work on the appliance. Contact an approved service centre.

• Use only original spare parts.

Disposal of the appliance

• To prevent the risk of physical injury or damage

– Disconnect the appliance from the power supply.

– Cut off the mains cable and discard it.

– Discard the door catch. This prevents children or small animals from being closed inside of the appliance. There is the risk of suffocation.

PRODUCT DESCRIPTION

General overview

2

1

3

4

5

10

5

2

1

4

3

6

7

8

9

1 Control panel

2 Electronic programmer

3 Socket for the core temperature sensor

4 Heating element

EURO Appliances - euappliances.info

8 Product description

5 Oven lamp

6 Fan

7 Rear wall heating element

8 Bottom heat

9 Shelf support, removable

10 Shelf positions

Accessories

• Nonstick wire shelf

For cookware, cake tins, roasts.

• Baking tray

For cakes and biscuits.

• Deep grill / roasting pan

To bake and roast or as pan to collect fat.

• Trivet

For roasting and grilling.

Use the trivet only with the grill/roasting pan.

EURO Appliances - euappliances.info

Before first use 9

• Core Temperature Sensor

To measure how far the food is cooked.

BEFORE FIRST USE

WARNING!

Refer to "Safety information" chapter.

Initial Cleaning

• Remove all parts from the appliance.

• Clean the appliance before first use.

Refer to chapter "Care and Cleaning".

First connection to the mains

After first connection to the mains all symbols in the display are on for some seconds. For the subsequent few seconds the display shows software version.

First setting the time of day

After the software version goes off, the display shows "h" and "12:00".

Setting the time of day:

1.

Touch or to set hours.

2.

Touch or .

3.

Touch or to set minutes.

4.

Touch or .

The Temperature/Time display shows new time.

Changing the time of day

You can change the time of day only if the appliance is off.

Touch . flashes in the display. To set new time of day use the above procedure.

EURO Appliances - euappliances.info

10 Control panel

CONTROL PANEL

Electronic programmer

1

9

10

7

8

2 3 4 5 6 7 8 9 10

Use the sensor fields to operate the appliance.

Sensor Field Function

1

2

DISPLAY

ON/OFF

Description

Shows the current settings of the appliance.

To activate and deactivate the appliance.

3

4

5

6

OPTIONS

MY FAVOURITE PRO-

GRAMME

TEMPERATURE / FAST

HEAT UP

UP, DOWN

To set an oven function or programme.

Straight access to the oven function when the appliance is off.

You can store your favourite programme. Use it to access your favourite programme directly, also when the appliance is off.

To set and examine cavity temperature or core temperature sensor temperature. If you press it and hold for three seconds, it turns Fast heat up function ON and OFF.

Straight access to the temperature setting of the first oven function when the appliance is off.

To choose an oven function, clock function and to set the minute minder, temperature or time of day.

OK

OVEN LIGHT

CLOCK

MINUTE MINDER

To confirms the selection or setting.

To set the oven lamp on or off.

To set the clock function.

To set the minute minder.

EURO Appliances - euappliances.info

Display

1 2

Control panel 11

3

7 6 5

1 Oven function symbol

2 Temperature/Time display

3 Clock/Residual heat display (also Minute minder and Time of day)

4 Residual heat indicator

5 Indicators for the clock functions (refer to the table "Clock functions")

6 Heat up indicator

7 Number of oven function/programme

Other indicators of display

Symbols Name

Function

Description

You can choose an oven function.

/

/

4

Automatic programme

My favourite programme

You can choose an oven programme.

The favourite programme operates.

kgr/gr h/min

An oven programme with weight input operates.

A clock function operates.

Temperature / fast heat up The function operates.

Temperature

Core temperature sensor

Door lock

Oven light

You can examine or change the temperature.

The core temperature sensor is in the core temperature sensor socket.

The door lock function operates.

The oven light is off.

Minute minder The minute minder function operates.

Heat up indicator

If you set an oven function, the bars in the display come on one by one. The bars show that the temperature in the appliance increases or decreases.

When the appliance is at the set temperature Heat up indicator goes off the display.

EURO Appliances - euappliances.info

12 Daily use

8

9

10

6

7

4

5

DAILY USE

WARNING!

Refer to "Safety information" chapter.

To operate the appliance you can use:

• manual mode -to set an oven function, the temperature and the cooking time manually.

• automatic programmes -to prepare a dish when you do not have a knowledge or experience in cooking.

Setting the oven function

1.

Touch .

The display shows a preset temperature, symbol and number of the oven function. flashes in the display.

2.

Touch or to set an oven function.

3.

Touch or the appliance starts automatically after five seconds.

If you activate the appliance with or and do not set any oven function or programme the appliance will deactivate automatically after 20 seconds.

1

2

3

Oven function

Pizza Setting

Application

True Fan Cooking To bake maximum on three shelf positions at the same time.

Decrease the oven temperatures (20-40 °C) compared with

Conventional. And to dry food.

To bake on one shelf position food with a more intensive browning and a crispy base. Decrease the oven temperatures

(20-40 °C) compared with Conventional cooking.

Slow Cook To prepare very lean, tender roasted food.

Conventional

Cooking

Frozen Foods

To bake and roast food on one shelf position.

Turbo Grilling

Fast Grilling

Grilling

Keep Warm

Defrost

To make your convenience food like e.g. French Fries, Wedges, spring rolls crispy.

To roast larger meat joints or poultry with bones on one shelf position. Also to gratinate and to brown.

To grill flat food in large quantities. To toast bread.

To grill flat food in the middle of the grill. To toast bread.

To keep food warm.

To defrost frozen food.

EURO Appliances - euappliances.info

Daily use 13

11

Oven function

Bottom Heat

Application

To bake cakes with a crispy base, and to preserve food.

12

13

ECO Roasting

Pyro Cleaning

ECO functions let you to optimize the energy consumption during cooking. Thus it is necessary to set the cooking time first. To get more information about the recommended settings, refer to the cooking tables with the equivalent usual oven function.

For automatic pyrolytic cleaning of the oven. The oven temperature is at approximately 500° C. It burns off residual dirt in the oven. This can then be removed with a cloth when the oven is cold.

Changing the oven temperature

Touch / to change the temperature in steps of 5 °C.

When the appliance is at the set temperature, an acoustic signal operates three times and the Heat up indicator goes off.

Examining the oven temperature

You can examine the temperature in the appliance when the function or programme operates.

1.

Touch .

The Temperature/Time display shows the temperature in the appliance.

If you want to change the oven temperature, touch one more time and use or .

2.

Touch to go back to the set temperature or the display will show it automatically after five seconds.

Fast heat up function

The fast heat up function decreases the heat up time.

Do not put food in the oven when the fast heat up function operates.

Activating the fast heat up function: Touch and hold for more then three seconds.

If you activate the fast heat up function, the bars on the display flash one by one to show that the function operates.

The fast heat up is not available with every oven function. An acoustic signal operates if the fast heat up is not available for set function.

EURO Appliances - euappliances.info

14 Clock functions

Energy saving

The appliance has some features that help you save energy during everyday cooking:

• Residual heat:

– the oven function or programme operates: the heating elements are deactivated 10% time earlier (the lamp and fan continue to operate). The condition: the cooking time is longer then 30 minutes or you use the clock functions (Duration, End, Time delay).

– the oven is off: you can use the heat to keep the food warm. The indication: the clock/

Residual heat display shows the remaining temperature, the bars show the decreasing temperature.

• Oven lamp off - touch to deactivate the oven lamp during cooking;

• Display off - if necessary, deactivate the appliance. Touch and at the same time until the display goes out (or on).

• Eco functions - refer to "Oven function".

CLOCK FUNCTIONS

SYMBOL FUNCTION

COUNT UP TIMER

TIME OF DAY

DURATION

DESCRIPTION

To set count up. It shows how long the appliance operates.

This function has no effect on the operation of the appliance.

To examine the time of day. For changing the time of day refer to 'Setting the time of day'.

To set how long the appliance operates.

END

SET+GO

To set when the appliance deactivates. You can use Duration and End at the same time (Time delay), if the appliance is to be activate and deactivate automatically later.

To start the appliance with necessary settings with only one touch of the sensor field, any time later.

Count Up Timer

Use the Count Up Timer to monitor how long the appliance operates. It is on immediately when the appliance starts to heat.

Reset the Count Up Timer: touch again and again until flashes in the display. Touch

until the display shows "00:00" and the Count Up Timer starts to count up again.

You can not use Count Up Timer when Duration or End is set.

Setting the DURATION

1.

Activate the appliance and set an oven function and temperature.

EURO Appliances - euappliances.info

Clock functions 15

2.

Touch again and again until the display shows .

flashes in the display.

3.

Use or to set minutes for DURA-

TION.

4.

Touch to confirm

5.

Use or to set hours for DURATION.

If you touch or during setting hours for DURATION, the appliance goes to setting of the END function.

6.

When the set time ends, an acoustic signal operates for two minutes.

symbol and time setting flash in the display. The appliance deactivates.

Touch any sensor field or open the oven door to stop an acoustic signal.

7.

Deactivate the appliance.

Setting the END

1.

Activate the appliance and set an oven function and temperature.

2.

Touch again and again until the display shows .

flashes in the display.

3.

Use or to set END (first you set minutes and then hours) and or to confirm.

4.

When the set time ends, an acoustic signal operates for two minutes.

symbol and time setting flash in the display. The appliance deactivates.

5.

Touch any sensor field or open the oven door to stop an acoustic signal.

6.

Deactivate the appliance.

Setting the SET+GO

To start of the appliance with necessary settings with only one touch of the sensor field, any time later.

1.

Set an oven function (or programme) and temperature (refer to "Setting the oven function" and "Changing the oven temperature").

2.

Set DURATION (refer to "Setting the DURATION").

3.

Touch again and again until will flash in the display.

4.

Touch to set the SET+GO function.

The display shows and with a dot. This dot shows which clock function is activated.

5.

Touch any sensor field (apart from ON/OFF) to start the SET+GO function.

You can use SET+GO function only if DURATION is set.

Check result (selected models only)

If you set END or DURATION function, 2 minutes before end of cooking an acoustic signal sounds and lamp activates. The appliance goes to the setting of the END or DURATION

EURO Appliances - euappliances.info

16 Automatic programmes function. During these two minutes you can examine the cooking results and, if necessary, add END or DURATION time.

Setting the Time delay function

DURATION and END can be used at the same time, if the oven is to be switched on and off automatically later. In this case first set DURATION and then END function

(refer to "Setting the DURATION" and "Setting the END ").

When the Time delay function is activated the display shows static symbol of the oven function, with a dot and . The dot shows which clock function is on in the Clock/

Residual heat display.

Setting the MINUTE MINDER

Use the MINUTE MINDER to set a countdown (maximum 23 h 59 min). This function has no effect on the operation of the oven. You can set the MINUTE MINDER any time, also if the appliance is off.

1.

Touch .

and "00" flash in the display.

2.

Use or to set MINUTE MINDER.

First you set seconds and then minutes and hours.

3.

Touch or the MINUTE MINDER starts automatically after five seconds.

4.

When set time ends, an acoustic signal operates for two minutes and "00:00" and flash in the display.

5.

Touch any sensor field or open the oven door to stop an acoustic signal.

AUTOMATIC PROGRAMMES

WARNING!

Refer to "Safety information" chapter.

There are 20 automatic programmes and recipes. Use an automatic programme or recipe when you do not have a knowledge or experience how to prepare a dish. You can find the recipes for the automatic programmes in the "Recipe book".

There are three types of automatic programmes:

• Automatic recipes;

• Automatic programmes with weight input;

• Automatic programmes with core temperature sensor;

Automatic recipes

Setting an automatic recipe:

1.

Touch two times until the display shows .

The display shows symbol and number of the automatic programme.

EURO Appliances - euappliances.info

Using the accessories 17

2.

Touch or to choose the automatic recipes.

3.

Touch or the automatic recipe activates automatically after five seconds.

4.

When set time ends, an acoustic signal operates for two minutes. Symbol flashes.

The appliance deactivates.

5.

Touch any sensor field or open the oven door to stop an acoustic signal.

Automatic programmes with weight input

If you set the weight of the meat, the appliance calculates the roasting time.

1.

Touch again and again until the display shows .

2.

Touch or to set the weight programme (refer to "Recipe book").

The display shows: cooking time, duration symbol , a default weight, a unit of measurement (kg, g).

3.

Touch or the settings save automatically after five seconds.

4.

The appliance starts. A symbol of the weight unit flashes in the display. During this time you can change the default weight value with or . Touch .

5.

When set time ends, an acoustic signal operates for two minutes. flashes.

The appliance deactivates.

6.

Touch any sensor field or open the oven door to stop an acoustic signal.

Automatic programmes with core temperature sensor

The core temperature of the food is default and fixed in programmes with core temperature sensor. The programme ends when the appliance is at the set core temperature.

1.

Touch again and again until the display shows .

2.

Install the core temperature sensor (refer to "The core temperature sensor").

3.

Touch or to set the core temperature sensor programme.

When a core temperature sensor programme is set, the display shows the cooking time, and .

4.

Touch or the settings save automatically after five seconds.

5.

When set time ends, an acoustic signal operates for two minutes. flashes.

The appliance deactivates.

6.

Touch any sensor field or open the oven door to stop an acoustic signal.

USING THE ACCESSORIES

WARNING!

Refer to "Safety information" chapter.

The core temperature sensor

The core temperature sensor measures the core temperature of the meat. When the meat is at the set temperature, the appliance deactivates.

There are two temperatures to set:

• The oven temperature: refer to the table for roasting in the recipe book.

EURO Appliances - euappliances.info

18 Using the accessories

• The core temperature: refer to the table for the core temperature sensor in the recipe book.

Only use the core temperature sensor supplied or original replacement parts.

1.

Activate the appliance.

2.

Put the point of the core temperature sensor (with the symbol on the handle) into the centre of the meat.

3.

Put the plug of the core temperature sensor into the socket at the front of the appliance.

The display shows a flashing symbol

and the default set core temperature. The temperature is 60 °C during the first use, and the last set value during each subsequent use.

4.

Touch or to set the core temperature.

5.

Touch or the settings save automatically after 5 seconds.

You can set the core temperature only when the symbol flashes. If the display shows a static symbol before you set the core temperature, use and or to set a new value.

6.

Set the oven function and, if necessary, the oven temperature.

The display shows the current core temperature and (which shows the relation between the set oven temperature and the current oven temperature).

The core temperature sensor must stay in the meat and in the socket during the cooking.

While the appliance calculates the approximate duration time, the value of the Count Up

Timer function shows in the Timer/Residual heat display. When the first calculation ends, the Timer/Residual heat display shows -, and then the approximate duration of the cooking.

The appliance continues to calculate the duration during the cooking. The display updates at intervals with the new duration value.

7.

When the meat is at the set core temperature, the core temperature and flash. An acoustic signal sounds for two minutes.

Touch a sensor field to deactivate the acoustic signal.

8.

Remove the core temperature sensor from the socket and remove the meat from the appliance.

WARNING!

Be careful when you remove the core temperature sensor. It is hot. There is a risk of burns.

9.

Deactivate the appliance.

EURO Appliances - euappliances.info

Using the accessories 19

When you put the core temperature sensor into the socket, you cancel the settings for the clock functions.

When you cook with the core temperature sensor, you can change the temperature shown in the Temperature/Time display. After you put the core temperature sensor in the socket and set an oven function and temperature, the display shows the current core temperature.

Touch again and again to see three other temperatures:

• The current core temperature

• The oven set temperature

• The current oven temperature.

The set core temperature changes into current core temperature and current oven temperature changes into set oven temperature.

Installing the Oven Accessories

The deep pan and the wire shelf have side edges.

These edges and the shape of the guide-bars causes the anti-tilt safety for the oven accessories.

Installing the wire shelf and the deep pan together

Put the wire shelf on the deep pan. Push the deep pan between the guide-bars of one of the oven levels.

Trivet and grill/roasting pan

WARNING!

Risk of burns when removing the accessories from a hot oven.

EURO Appliances - euappliances.info

20 Additional functions

You can use the trivet to roast larger pieces of meat or poultry on one level:

• Put the trivet inside the deep pan so that the supports of the oven shelf point up.

• Put the deep pan in the oven at the necessary level.

You can use the trivet to grill flat dishes in large quantities and to toast:

• Put the trivet inside the deep pan so that the supports of the oven shelf point downwards.

• Put the deep pan in the oven at the necessary level.

ADDITIONAL FUNCTIONS

My Favourite Programme function

Use this function to save your favourite settings of temperature and time for an oven function or programme.

1.

Set the temperature and time for an oven function or programme.

2.

Touch and hold for more than three seconds.

An acoustic signal sounds.

3.

Deactivate the appliance.

Using My Favourite Programme function:

• To activate the function touch . The appliance activates your favourite programme.

• To deactivate the function touch . The appliance deactivates your favourite programme.

When the function operates, you can change the time and temperature.

Child Lock

The Child Lock prevents an accidental operation of the appliance.

EURO Appliances - euappliances.info

Additional functions 21

Activating and deactivating the Child Lock function:

1.

Deactivate the appliance with . Do not set an oven function.

2.

Touch and hold and at the same time for 2 seconds. An acoustic signal sounds.

SAFE comes on/goes out in the display.

If the oven has Pyro Cleaning function, the door is locked.

SAFE comes on in the display when you touch a sensor field.

Control lock

You can activate the function only when the appliance operates. The Control Lock prevents an accidental change of the oven function.

Activating/deactivating the control lock function:

1.

Activate the appliance.

2.

Activate an oven function or setting.

3.

Touch and hold and at the same time for 2 seconds. An acoustic signal sounds.

Loc comes on/goes out in the display.

You can deactivate the appliance when the control lock is on. When you deactivate the appliance, the control lock deactivates.

If the oven has the Pyro cleaning function, the door is locked.

Loc comes on in the display when you touch a sensor field.

Settings menu

The settings menu lets you to add or remove functions from the main menu (for example: you can set on or off the Residual heat indicator). Settings menu has maximum eight settings (from SET1 to SET8). The number of the settings is different for different models. Look into the table below to see the possible value of each setting.

Settings menu

Indicator of the setting menu Description Value to set

SET1 SET+GO ON/OFF

SET2

SET3

SET4

SET5

SET6

SET7

SET8

1)

1) Selected models only

RESIDUAL HEAT INDICATOR

CLEANING REMINDER

KEY TONE

FAULTY TONE

SERVICE MENU

RESTORE SETTINGS

TIME EXTENSION

You can set the settings menu only when the appliance is off.

ON/OFF

ON/OFF

CLIC/BEEP/OFF

ON/OFF

---

YES/NO

ON/OFF

Activate the Settings menu:

1.

If necessary, deactivate the appliance .

EURO Appliances - euappliances.info

22 Care and cleaning

2.

Touch and hold for three seconds.

The display shows "SET1" and "1" flashes.

3.

Touch / to set the setting.

4.

Touch .

5.

Touch / to change the value of the setting.

6.

Touch .

Automatic switch-off

For safety reasons the appliance deactivates automatically after some time:

• if an oven function operates.

• if you do not change the oven temperature.

Oven temperature Switch-off time

30 °C -120 °C

120 °C - 200 °C

200 °C -250 °C

12.5 h.

8.5 h.

5.5 h.

250 °C -maximum °C 3.0 h.

After an automatic switch-off, touch a sensor field to operate the appliance again.

The Automatic switch-off works with all oven functions, apart from Light, Low temperature cooking, core temperature sensor, Duration, End, Time delay.

Brightness of the display

There are two modes of display's brightness:

• Night brightness - when the appliance is off, the brightness of the display is lower between 22:00 and 06:00;

• Day brightness:

– when the appliance is on;

– if you touch any of the sensor fields during night brightness (apart from ON/OFF), the display goes back to day brightness mode for next 10 seconds;

– if the appliance is off and you set the minute minder. When the minute minder function ends, the display goes back to night brightness;

Cooling fan

When the appliance operates, the cooling fan activates automatically to keep the surfaces of the appliance cool. If you deactivate the appliance, the cooling fan can continue to operate until the appliance cools down.

CARE AND CLEANING

WARNING!

Refer to "Safety information" chapter.

EURO Appliances - euappliances.info

Care and cleaning 23

Notes on cleaning:

• Clean the front of the appliance with a soft cloth with warm water and cleaning agent.

• To clean metal surfaces use a usual cleaning agent.

• Clean the appliance interior after each use. Then you can remove dirt more easily and it does not burn on.

• Clean stubborn dirt with a special oven cleaner.

• Clean all accessories (with a soft cloth with warm water and cleaning agent) after each use and let them dry.

• If you have nonstick accessories, do not clean them using an aggressive agents, sharp edged objects or dishwasher. It can cause a damage to the nonstick coating.

Pyrolytic cleaning

1.

Remove all parts from the appliance.

The pyrolytic cleaning procedure cannot start:

– If you do not remove the shelf support or telescopic runners (if present), the display shows "C1"

– If you do not remove the core temperature sensor plug from the socket, the display shows „C2“

– If you do not close the oven door correctly, the display shows „C3“.

2.

Remove the worst of the residual dirt manually.

3.

Set the Pyrolytic cleaning function (refer to "Oven functions").

4.

Touch to activate the Pyro cleaning function.

5.

Touch or to set the duration of the cleaning procedure:

– P1 1:00 for a low degree of dirt

– P2 1:30 for a usual degree of dirt

– P3 2:30 for a high degree of dirt.

Touch to confirm.

You can use the End function to delay start of the cleaning process.

During the Pyro cleaning the door is locked. The symbol and the bars of the heat indicator come up, until the door unlocks again.

The door unlocks when temperature inside the oven is under safety condition and Pyro cleaning is finished.

During pyrolytic cleaning the lamp is off.

Cleaning reminder

To remind you that the pyrolytic cleaning is necessary the cleaning reminder symbol flashes in the display after every deactivating the appliance for the next 10 seconds.

The cleaning reminder goes off from the display:

• After end of the pyrolytic cleaning function

• When you deactivate it in the Basic settings (refer to "Basic settings")

EURO Appliances - euappliances.info

24 Care and cleaning

Shelf support

You can remove the shelf support to clean the side walls.

Removing the shelf support

1.

Pull the front of the shelf support away from the side wall.

2.

Pull the shelf support from the back of the side wall to remove it.

To install the shelf support follow the procedure in reverse.

Valid with telescopic runners:

The retaining pins on the telescopic shelf runners must point to the front!

1

2

Oven lamp

WARNING!

There is a risk of electrical shock.

The oven lamp and the lamp glass cover can be hot.

Before you change the oven lamp:

• Deactivate the appliance.

• Remove the fuses from the fuse box or deactivate the circuit breaker.

CAUTION!

Put a cloth on the bottom of the interior of the appliance. It prevents damage to the lamp glass cover and the cavity.

Replacing the oven lamp:

1.

You can find the lamp glass cover at the cavity ceiling.

Turn the lamp glass cover counterclockwise to remove it.

2.

Clean the glass cover.

3.

If necessary, replace the oven lamp with applicable 300°C heat-resistant oven lamp.

Use the same oven lamp type.

EURO Appliances - euappliances.info

Care and cleaning 25

4.

Install the glass cover.

Replacing the lamp:

1.

You can find the lamp glass cover at the left side of the cavity.

Remove the left shelf rail.

2.

Use a narrow, blunt object (for example a teaspoon) to remove the glass cover.

Clean the glass cover.

3.

If necessary, replace the lamp with applicable 300°C heat-resistant lamp.

Use the same lamp type.

4.

Install the glass cover.

5.

Install the left shelf rail.

Door and glass panels

To clean the door, remove it.

CAUTION!

Be careful when you remove the door from the appliance. The door is heavy!

Removing the door

1.

Open the door as far as it goes.

2.

Fully press clamping levers (A) on the two door hinges.

3.

Close the door until the first position

(angle approximately 70°).

4.

Hold of the door with one hand on each side and pull it away from the at an up angle.

To install the door follow the procedure in reverse.

The number of glass panels if different for the different models.

A

A

CAUTION!

Put the door with the outer side down on a soft and level surface to prevent scratches.

Removing and cleaning the door glass panels

1.

Remove the door.

EURO Appliances - euappliances.info

26 What to do if…

2.

Hold the door trim (B) on the top edge of the door at the two sides and push inwards to release the clip seal.

3.

Pull the door trim to the front to remove it.

B

4.

Hold the door glass panels on their top edge one by one and pull them up out of the guide

5.

Clean the door glass panels.

To install panels follow the procedure in reverse. Install the smaller panel first, then the larger.

WHAT TO DO IF…

WARNING!

Refer to "Safety information" chapter.

Problem

The oven does not heat up

The oven does not heat up

The oven does not heat up

The oven does not heat up

The oven does not heat up

Possible cause

The appliance is deactivated

The time of day is not set

The necessary settings are not set

The automatic switch-off is activated

The fuse is released

The oven lamp is defective

Solution

Activate the appliance

Set the clock. Refer to "First setting the time of day"

Make sure, the settings are correct

Refer to „Automatic switchoff“

Make sure, if the fuse is the cause for the malfunction. If the fuse releases again and again, refer to an authorized electrician

Replace the oven lamp.

The oven lamp does not operate

The display shows C1 You want to start the pyrolytic cleaning but you did not remove the shelf support (or telescopic runners).

Remove the shelf support (or telescopic runners) from the oven.

EURO Appliances - euappliances.info

Environment concerns 27

Problem

The display shows C2

The display shows C3

Possible cause

You want to start the pyrolytic cleaning, keep warm or defrost function but you did not remove core temperature sensor plug from the socket.

You want to start pyrolytic cleaning but you did not close the oven door correctly.

The door lock is defect

Solution

Remove the core temperature sensor plug from the socket.

Close the door correctly.

The display shows F102

The display shows an error code that is not in this list

There is an electronic fault

• Close the door correctly

• Deactivate the appliance with the house fuse or the safety switch in the fuse box and activate it again

• If the display shows F102 again, refer to the Customer

Care Department

• Deactivate the appliance with the house fuse or the safety switch in the fuse box and activate it again

• If the display shows the error code again, refer to the

Customer Care Department

If you cannot find a solution to the problem yourself, contact your dealer or the service centre.

The necessary data for the service centre is on the rating plate. The rating plate is on the front frame of the appliance cavity.

We recommend that you write the data here:

Model (MOD.)

Product number (PNC)

Serial number (S.N.)

.........................................

.........................................

.........................................

ENVIRONMENT CONCERNS

The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it should be taken to the appropriate collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local council, your household waste disposal service or the shop where you purchased the product.

EURO Appliances - euappliances.info

28 GREAT BRITAIN & IRELAND - Guarantee/Customer Service

Packaging material

The packaging material is environmentally-friendly and recyclable. Plastic parts are marked with international abbreviations such as PE, PS, etc. Dispose of the packaging material in the containers provided for this purpose at your local waste management facility.

GB IE

GREAT BRITAIN & IRELAND - GUARANTEE/CUSTOMER

SERVICE

Standard guarantee conditions: We, Electrolux, undertake that if within 12 months of the date of the purchase this Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that:

• Appliance has been correctly installed and used only on the electricity supply stated on the rating plate.

• Appliance has been used for normal domestic purposes only, in accordance with manufacturer's instructions.

• Appliance hasn't been serviced, maintained, repaired, taken apart or tampered with by person not authorised by us.

• Electrolux Service Force Centre must undertake all service work under this guarantee

• Any appliance or defective part replaced shall become the Company's property.

• This guarantee is in addition to your statutory and other legal rights.

Exclusions

• Damage, calls resulting from transport, improper use, neglect, light bulbs, removable parts of glass, plastic.

• Costs for calls to put right appliance which is improperly installed, calls to appliances outside United Kingdom.

• Appliances found to be in use within a commercial environment, plus those which are subject to rental agreements.

• Products of Electrolux manufacturer that are not marketed by Electrolux

Service and Spare Parts.Please contact your local Service Force Centre: 08445 616

616(Call will be routed to Service Force Centre covering your postcode area). For address of local Service Force Centre and further information, please visit: www.serviceforce.co.uk

Before calling out an engineer, please ensure you have read the details under the heading

"What to do if...". When you contact the Service Force Centre you will need to give the following details: Your name, address and postcode, your telephone number, clear concise details of the fault, model and serial number of the appliance (found on the rating plate), the purchase date. Please note a valid purchase receipt or guarantee documentation is required for in guarantee service calls.

Customer Care.Please contact our Customer Care Department: Electrolux Major Appliances,

Addington Way, Luton, Bedfordshire, LU4 9QQ or visit our website at www.electrolux.co.uk

EURO Appliances - euappliances.info

29

Customer Care Department,

Electrolux

AEG-Electrolux

Zanussi-Electrolux

Tel: (Calls may be recorded for training purposes)

08445 613 613

08445 611 611

08445 612 612

For Customer Service in The Republic of Ireland please contact us at the address below:

Electrolux Group (Irl) Ltd, Long Mile Road, Dublin 12, Republic of Ireland

Tel: +353 (0)1 4090751, Email: [email protected]

GB

European Guarantee: This appliance is guaranteed by Electrolux in each of the countries listed at the back of this user manual, for the period specified in the appliance guarantee or otherwise by law. If you move from one of these countries to another of the countries listed, the appliance guarantee will move with you subject to the following qualifications:-

• The appliance guarantee starts from the date you first purchased the appliance which will be evidenced by production of a valid purchase document issued by the seller of the appliance.

• The appliance guarantee is for the same period and to the same extent for labour and parts as exists in your new country of residence for this particular model or range of appliances.

• The appliance guarantee is personal to the original purchaser of the appliance and cannot be transferred to another user.

• The appliance is installed and used in accordance with instructions issued by Electrolux and is only used within the home, i.e. is not used for commercial purposes.

• The appliance is installed in accordance with all relevant regulations in force within your new country of residence.

The provisions of this European Guarantee do not affect any of the rights granted to you by law.

WWW.ELECTROLUX.COM

Albania

Belgique/België/Belgien

Česká republika

Danmark

Deutschland

Eesti

España

+35 5 4 261 450

++32-2-7162444

+420 261 302 261

+45 70 11 74 00

+49 180 32 26 622

+37 2 66 50 030

+34 902 11 63 88

EURO Appliances - euappliances.info

Rr. Pjeter Bogdani Nr. 7 Tirane

Raketstraat 40, 1130 Brussel/Bruxelles

Budějovická 3, Praha 4, 140 21

Strevelinsvej 38-40, 7000 Fredericia

Fürther Str. 246, 90429 Nürnberg

Pärnu mnt. 153, 11624 Tallinn

Carretera M-300, Km. 29,900 Alcalá de

Henares Madrid

30

Suomi

Sverige

Türkiye

Россия

Україна

France

Great Britain

Hellas

Hrvatska

Ireland

Italia

Latvija

Lietuva

Luxembourg

Magyarország

Nederland

Norge

Österreich

Polska

Portugal

Romania +40 21 451 20 30

Schweiz - Suisse - Svizzera +41 62 88 99 111

Slovenija +38 61 24 25 731

Slovensko +421 2 32 14 13 34-5

08 44 62 26 53

+44 8445 616 616

+30 23 10 56 19 70

+385 1 63 23 338

+353 1 40 90 753

+39 (0) 434 558500

+371 67313626

+370 5 278 06 03

+352 42 431 301

+36 1 252 1773

+31 17 24 68 300

+47 81 5 30 222

+43 18 66 400

+48 22 43 47 300

+35 12 14 40 39 39 www.electrolux.fi

+46 (0)771 76 76 76

+90 21 22 93 10 25

8-800-200-3589

+380 44 586 20 60 www.electrolux.fr

Addington Way, Luton, Bedfordshire LU4

9QQ

4, Limnou Str., 54627 Thessaloniki

Slavonska avenija 3, 10000 Zagreb

Long Mile Road Dublin 12

C.so Lino Zanussi, 26 - 33080 Porcia (PN)

Kr. Barona iela 130/2, LV-1012, Riga

Ozo 10a, LT-08200 Vilnius

Rue de Bitbourg, 7, L-1273 Hamm

H-1142 Budapest XIV, Erzsébet királyné

útja 87

Vennootsweg 1, 2404 CG - Alphen aan den Rijn

Risløkkvn. 2 , 0508 Oslo

Herziggasse 9, 1230 Wien ul. Kolejowa 5/7, Warszawa

Quinta da Fonte - Edificio Gonçalves Zarco - Q 35 -2774-518 Paço de Arcos

Str. Garii Progresului 2, S4, 040671 RO

Industriestrasse 10, CH-5506 Mägenwil

Gerbičeva ulica 110, 1000 Ljubljana

Electrolux Slovakia s.r.o., Electrolux Domáce spotrebiče SK, Galvaniho 17/B,

821 04 Bratislava

Electrolux Service, S:t Göransgatan 143,

S-105 45 Stockholm

Tarlabaşı caddesi no : 35 Taksim İstanbul

129090 Москва, Олимпийский проспект, 16, БЦ "Олимпик"

04074 Київ, вул.Автозаводська, 2а, БЦ

"Алкон"

EURO Appliances - euappliances.info

EURO Appliances - euappliances.info

31

www.aeg.com/shop 892945719-B-232011

EURO Appliances - euappliances.info

Powered by TCPDF (www.tcpdf.org)

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
