(ACRC500 series) model. This user’s guide describes the features of the ACRC500series cooling units. The ACRC500-series models are the width of a standard enclosure, and can be placed in a data-center row. The InRow RC provides full management capabilities over a network using Telnet, Secure Shell (SSH), HTTP,

HTTPS, FTP, Secure Copy (SCP), Modbus, and SNMP. The InRow RC provides the following features:

• Group control

• Temperature monitoring

• Remote shutdown

• Output contact monitoring

• Event log accessible by Telnet, FTP, SSH, SCP, serial connection, the display interface, or a Web browser

• SNMP traps and e-mail notifications sent in response to events

• Syslog events sent to configured Syslog servers

• Security protocols for authentication and encryption

Initial setup

You must define the following three TCP/IP settings for the InRow RC before it can operate on the network:

• IP address of the InRow RC

• Subnet mask

• IP address of the default gateway

Never use the loopback address (127.0.0.1) as the default gateway address for the InRow RC. Doing so will disable the unit and will require you to reset TCP/IP settings to their defaults using a local serial login.

To use a DHCP server to configure the TCP/IP settings for an InRow

RC, see

TCP/IP settings

To configure the TCP/IP settings, see the InRow RC Installation and

Quick Start Manual, provided in printed form and in PDF on either the

Utility CD or on the APC Web site,

www.apc.com

Internal Management Features

Overview

You can manage the InRow RC through the Web interface, display interface, control console, Modbus, or SNMP. SNMP requires the PowerNet

MIB, available on the

Utility CD or from the APC Web site,

www.apc.com

For more information about the menu-driven interfaces of the InRow RC, see

Web Interface and

Control Console .

For more information about the display interface, see the InRow RC

Operation and Maintenance manual, available on the Utility CD or on the APC Web site,

www.apc.com.

To download the latest version of the Modbus register map, go to the

APC Web site,

www.apc.com

, search by part number, and click the link to the register map in the list of documentation. Check the publication date at the start of the file.

For more information about Modbus, see the Modbus Standard Library at

www.modbus.org

To use the PowerNet MIB with an SNMP browser, see the PowerNet

SNMP Management Information Base (MIB) Reference Guide, provided on the APC Network Management Card utility CD.

Log on control

Only one user at a time can log on to the InRow RC to use its internal user interface features. The priority for access is as follows:

• Local access to the control console from a computer with a direct serial connection to the InRow RC always has the highest priority.

• Telnet or Secure SHell (SSH) access to the control console from a remote computer has the next highest priority.

• Web access, either directly or through InfraStruXure Central or InfraStruXure

Manager, has the lowest priority.

For information on how to control SNMP access to the Management

Card, see SNMP .

Types of user accounts

The InRow RC has three levels of access (Administrator, Device-Only User, and Read-

Only User), all of which are protected by user name and password requirements.

• An Administrator can use all of the management menus available in the control console and the Web interface. The Administrator’s default user name and password are both

apc

• A Device-Only User (Device Manager in the control console) can access only the

Log

option in the

Events

menu and use the

Group

Unit

, and

Alarms

menus. The

Device-Only User’s default user name is

device

, and the default password is

apc

• A Read-Only User has the following restricted access:

– Access through the Web interface only.

– Access to the same menus as a Device-Only User, but without the capability to change configurations, control devices, or delete data. Links to configuration options may be visible but are disabled, and the event log displays no

Clear Log

button.

The Read-Only User’s default user name is

readonly

, and the default password is

apc

To set

User Name

and

Password

values for the Administrator,

Device-Only User, and Read-Only User accounts, see

Setting user access . You must use the Web interface to configure values for the

Read-Only User.

How to Recover from a Lost Password

Use a local computer, a computer that connects to the Management Card through the serial port, to access the control console.

1. Select a serial port at the local computer and disable any service that uses that port.

2. Connect the APC null-modem cable (APC part number 940-0024 or 940-1524) to the selected port on the computer and to the serial port at the InRow RC (use the DB-9 connector on the front of the electrical panel).

Do not touch components on the electrical panel, other than the service port.

3. Run a terminal program (such as HyperTerminal) and configure the selected port as follows:

•9600 bps

•8 data bits

•no parity

•1 stop bit

•no flow control

4. Press

NTER

on the computer, repeatedly if necessary, to display the

User

Name

prompt.

If you are unable to display the

User Name

prompt, verify the following:

•The serial port is not in use by another application.

•The terminal settings are correct as specified in step 3.

•The correct cable is being used as specified in step 2.

5. Switch the main breaker to

. Wait one second. Switch the main breaker to

If you wait too long to return power to the InRow RC, you must repeat step

6. Press

NTER

as many times as necessary to redisplay the

User Name

prompt, then use the default,

apc,

for the user name and password. (If you take longer than 30 seconds to log on after the

User Name

prompt is redisplayed, you must repeat step 5 and log on again.)

7. From the

Control Console

menu, select

System

, then

User Manager

8. Select

Administrator

, and change the

User Name

and

Password

settings, both of which are now defined as

apc

. Select

Accept Changes

to store the new user name and password values.

9. Press

TRL

, log off, reconnect any serial cable you disconnected, and restart any service you disabled.

Display Interface LEDs

Status

This LED indicates the status of the InRow RC.

Condition

Off

Solid Green

Flashing Green

Description

The InRow RC has no power.

The InRow RC is receiving power.

The InRow RC is receiving a firmware upgrade.

Check log

When yellow, this LED indicates that at least one new critical alarm, warning alarm, or event has occurred since the last time the event log was viewed from the display interface.

Warning alarm

When yellow, this LED indicates that a warning alarm condition exists and may require your attention to prevent it from deteriorating into a critical state. A new alarm will cause a beep every 30 seconds until you silence the alarm by pressing any function key.

Critical alarm

When red, this LED indicates that a critical alarm condition exists and requires your immediate attention. An audible alarm beeps every 30 seconds. Press any function key to silence the audible alarm.

Watchdog Features

Overview

To detect internal problems and recover from unanticipated inputs, the InRow RC uses internal, system-wide watchdog mechanisms. When it reboots to recover from an internal problem, a

System: Warmstart

event is recorded in the event log.

Network interface watchdog mechanism

The InRow RC implements internal watchdog mechanisms to protect itself from becoming inaccessible over the network. For example, if the InRow RC does not receive any network traffic for 9.5 minutes (either direct traffic, such as SNMP, or broadcast traffic, such as an Address Resolution Protocol [ARP] request), it assumes that there is a problem with its network interface and restarts.

Resetting the network timer

To ensure that the InRow RC does not restart if the network is quiet for 9.5 minutes, the

InRow RC attempts to contact the Default Gateway every 4.5 minutes. If the gateway is present, it responds to the InRow RC, and that response restarts the 9.5-minute timer.

If your application does not require or have a gateway, specify the IP address of a computer that is running on the network most of the time and is on the same subnet.

The network traffic of that computer will reset the 9.5-minute timer frequently enough to prevent the InRow RC from restarting.

Control Console

How to Log On

Overview

You can use either a local (serial) connection, or a remote (Telnet or SSH) connection to access the control console.

Use case-sensitive user name and password entries to log on (by default,

apc

and

apc

for an Administrator, or

device

and

apc

for a Device-Only User). A Read-Only User cannot access the control console.

If you cannot remember your user name or password, s ee

How to

Recover from a Lost Password .

Remote access to the control console

You can access the control console through Telnet or Secure SHell (SSH), depending on which is enabled. (An Administrator can enable these access methods through the

Telnet/SSH

option of the

Network

menu.) By default, Telnet is enabled. Enabling SSH automatically disables Telnet.

Telnet for basic access.

Telnet provides the basic security of authentication by user name and password, but not the high-security benefits of encryption. To use Telnet to access the control console from any computer on the same subnet:

1. At a command prompt, type telnet and the System IP address for the InRow

RC (when the InRow RC uses the default Telnet port of 23), and press

NTER

For example: telnet 139.225.6.133

If the InRow RC uses a non-default port number (between 5000 and 32768), you need to include a colon or a space (depending on your Telnet client) between the IP address and the port number.

2. Enter the user name and password (by default,

apc

and

apc

for an

Administrator, or

device

and

apc

for a Device-Only User).

SSH for high-security access.

If you use the high security of SSL for the Web interface, use Secure SHell (SSH) for access to the control console. SSH encrypts user names, passwords,and transmitted data.

The interface, user accounts, and user access rights are the same whether you access the control console through SSH or Telnet, but to use SSH, you must first configure

SSH and have a SSH client program installed on your computer.

Local access to the control console

You can use a local computer that connects to the InRow RC through the serial port on the controller board that is on the electrical panel (connector J2) of the unit.

To access the serial port, remove the front panel and lower air filter of the InRow RC.

1. Select a serial port at the local computer and disable any service that uses that port.

2. Use the supplied RS-232 configuration cable (APC part number 940-0103A) to connect the selected port to the serial port at the InRow RC (use the DB-9 connector on the front of the electrical panel).

3. Run a terminal program (such as HyperTerminal) and configure the selected port for 9600 bps, 8 data bits, no parity, 1 stop bit, and no flow control. Save the changes.

4. Enter the user name and password for the access desired (Administrator or

Device-Only User).

Main Screen

Example main screen

The following is an example of the screen that appears when you log on to the control console at the InRow RC.

User Name : apc

Password : ***

American Power Conversion Netowrk Management Card AOS vx.x.x

-------------------------------------------------------------------------------

Name : InRow RC Date : 10/29/2008

Contact : Bill Cooper Time : 10:16:58

Location : Testing Lab User : Administrator

Up Time : 0 Days 0 Hours 43 Minutes Stat : P+ N+ A+

Cooling Group Status : None

Cooling Unit Status : None

------- Control Console -------------------------------------------------------

1- Device Manager

2- Network

3- System

4- Logout

<ESC>- Main Menu, <ENTER>- Refresh, <CTRL-L>- Event Log

Information and status fields

Main screen information fields.

• Two fields identify the APC operating system (AOS) and application (APP) firmware versions. The application firmware name identifies the type of device that connects to the network. On the example main screen, the application firmware for the InRow RC is displayed.

Network Management Card AOS

InRow RC APP vx.x.x vx.x.x

• Three fields identify the system

Name

Contact

, and

Location

values.

Name

Contact

Location

: InRow RC

: Bill Cooper

: Testing Lab

To set the

Name

Contact

, and

Location

values, see

Identification

• An

Up Time

field reports how long the management interface has been running since it was last reset or since power was applied.

Up Time : 0 Days 0 Hours 43 Minutes

• Two fields identify the date and time at which the screen most recently refreshed.

Date : 10/29/2008

Time : 10:16:58

• A

User

field identifies whether you logged on as Administrator or Device-Only User.

User : Administrator or

User : Device Manager

Main screen status fields.

• A

Stat

field reports the status of the InRow RC.

Stat : P+ N+ A+

P+

The APC operating system (AOS) is functioning properly.

N+

The network is functioning properly.

A BOOTP or DHCP request cycle is in progress.

N–

The InRow RC failed to connect to the network.

Another device is using the IP address of the InRow RC.

A+

The application is functioning properly.

A–

The application has a bad checksum.

The application is initializing.

The application is not compatible with the AOS.

If the AOS status is not P+, contact APC Worldwide Customer

Support , even if you can still access the InRow RC.

InRow RC status field.

The

Status

field displays the status of the Cooling Units. Under normal operation this field will read:

Cooling Group Status : None

Cooling Unit Status : None

None

will be replaced with Warning or Critical if an alarm condition exists.

Control Console Menus

Menu structure

The menus in the control console list options by number and name. To use an option, type the option’s number and press

NTER

, then follow any on-screen instructions.

For menus that allow you to change a setting you must use the

Accept Changes

option to save the changes you made. Some changes may only take effect after you log off.

While in a menu, you can also do the following:

• Type ? and press

NTER

to access brief menu option descriptions (if the menu has help available).

• Press

NTER

to refresh the menu.

• Press

to return to the menu from which you accessed the current menu.

• Press

TRL

to return to the main (control console) menu.

• Press

TRL

to access the event log.

For more information about the event log, see Events

Main menu

The main control console menu has options that provide access to the management features of the control console.

1- Device User

(equivalent to Device-Only User in the Web interface)

2- Network

3- System

4- Logout

When you log on as Device User, you do not have access to the

Network

System

menus.

Device Manager option

This option accesses the

Device Manager

menu, which displays information about the unit and the group. Select the components you want to manage. For example:

1- View Active Alarms

2- Cooling Group

3- Cooling Unit

Network option

Use this option to perform any of the following tasks:

• Configure the InRow RC’s TCP/IP settings.

• Configure the settings for the type of server (DHCP or BOOTP) used to provide the

TCP/IP settings to the InRow RC.

• Use the Ping utility.

• Define settings that affect the FTP, Telnet/SSH, Web/SSL/TLS, SNMP, Syslog, Serial

Modbus, E-mail, and DNS features of the InRow RC.

System option

Use this option to perform any of the following tasks:

• Control

Administrator

and

Device Manager

access.

• Define the System

Name

Contact

, and

Location

values.

• Set the date and time used by the InRow RC.

• Restart the InRow RC management interface.

• Reset control console settings to their default values.

• Define RADIUS access and set primary and secondary servers.

Logout option

Use this option to log out of the Control Console.

Web Interface

How to Log On

Overview

You can use the DNS name or System IP address of the InRow RC for the URL address of the Web interface. Use your case-sensitive

User Name

and

Password

settings to log on. The default user name differs by account type:

•

apc

for an Administrator

•

device

for a Device-Only User

•

readonly

for a Read-Only User

The default password is

apc

for all three account types.

If you are using HTTPS as your access protocol, your login credentials are compared with information in a server certificate. If the certificate was created with the APC Security Wizard, and an IP address was specified as the common name in the certificate, you must use an IP address to log on to the InRow RC. If a DNS name was specified as the common name on the certificate, you must use a DNS name to log on.

For information about the Web page that appears when you log on to the Web interface, see

Summary Page

Supported Web browsers

You can use Microsoft

Internet Explorer 5.5 and higher (on Windows operating systems only), Firefox, version 1.x and higher, by Mozilla Corporation (on all operating systems), or Netscape

7.x and higher (on all operating systems) to access the InRow

RC through its Web interface. Other commonly available browsers also may work but have not been fully tested by APC.

For optimal functioning of the Web interface, enable JavaScript

® for your Web browser.

In addition, the InRow RC management interface cannot work with a proxy server.

Therefore, before you can use a Web browser to access the InRow RC Web interface, you must do one of the following:

• Configure the Web browser to disable the use of a proxy server for the InRow RC.

• Configure the proxy server so that it does not proxy the specific IP address of the

InRow RC.

URL address formats

Type the DNS name or IP address of the InRow RC in the Web browser’s URL address field, and press E

NTER

. When you specify a non-default Web server port in Internet

Explorer, you must include http:// or https:// in the URL.

Common browser error messages at login.

Cause of the

Error

Someone else is logged on.

Web access is disabled, or the

URL was not correct

Browser

Internet Explorer,

Netscape, Firefox

Netscape

Internet Explorer

Firefox

Error Message

“You are not authorized to view this page” or “Someone is currently logged in...”

“The connection was refused...”

“This page cannot be displayed.”

“Unable to connect.”

• For a DNS name of Web1, the entry would be one of the following:

– http://Web1 if HTTP is your access mode

– https://Web1 if HTTPS is your access mode

• For a System IP address of 139.225.6.133, when the InRow RC uses the default port

(80) at the Web server, the entry would be one of the following:

– http://139.225.6.133 if HTTP is your access mode

– https://139.225.6.133 if HTTPS is your access mode

• For a System IP address of 139.225.6.133, when the InRow RC uses a non-default port (5000, in this example) at the Web server, the entry would be one of the following:

– http://139.225.6.133:5000 if HTTP is your access mode

– https://139.225.6.133:5000 if HTTPS is your access mode

Summary Page

When you log on to the Web interface at the InRow RC, navigation tabs are displayed at the top of the screen. Below the navigation tabs, a top menu bar lists options related to the selected tab. The status field displays information about the selected tab or top menu bar option.

Navigation tabs

Five tabs are displayed at the top of the screen:

•

Home

—View any active alarm or warning conditions and clear active alarms; this tab is displayed at login.

•

Group

—View and configure group settings.

•

Unit

—View and configure cooling settings, unit properties, identification information, view or reset run hours, and configure service intervals.

•

Logs—

View and configure the event and data logs, and configure Syslog settings.

•

Administration—

Configure security, network connection, notification, and device settings.

Quick status

The quick status tab is displayed in the upper right of every screen in the Web interface. The tab displays a warning of any alarms.

Click the green “device operating normally” icon to return to the status screen where the status of the InRow RC is displayed.

Click the “attention required” icon to return to the status screen where active warnings and alarms are displayed.

Click the “alarm detected” icon to return to the status screen where active alarms are displayed.

Status

The Active Alarms field displays the states (No alarms present, Warning, or Critical) of both the Cooling Group and individual Cooling Units. The Recent Device Events table displays the five most recent device events, and the dates and times they took place.

Click

More Events

at the bottom of the Recent Device Events table to see the entire event log.

Help

Click

Help

, located in the upper right hand corner of the Web interface, to view context-sensitive information.

Select a tab to perform a task

To do the following, see Home :

• View and clear alarms.

To do the following, see Group

• View the status of the group.

• Set the number of units in the group.

• Define the configuration type used by the group.

• Set the cool and supply air setpoints.

• Set the fan speed preference.

• Set the cool PIDs.

• Set the percentage of glycol in the group.

To do the following, see Unit :

• View the status and properties of each unit.

• Set unit delays.

• Change the unit identification values.

• Assign the type of alarm that will activate the output sensor.

• Set the normal state of the input and output.

• Reset the unit run hours alarms.

• Set alarm threshold values.

• Set service intervals.

To do the following, see Logs

• Access the event and data logs.

• Set the interval and rotation for the data log.

• Create data log graphs.

• Configure Syslog settings, add servers to the Syslog, and initiate Syslog server tests.

To do the following, see Administration: Security :

• Control Administrator, Device User, and Read-Only user access.

• Configure RADIUS access, servers, and server secret.

• Configure the minutes of inactivity required before Auto Log Off

To do the following, see

Administration: Network :

• Configure new TCP/IP settings for the InRow RC.

• Select the port speed.

• Identify the Domain Name System (DNS) Server and test the network connection to that server.

• Define settings for the FTP server, SNMPv1, SNMPv3, Control Console/SSH, and

Web/SSL.

To do the following, see

Administration: Notification :

• Configure the actions to be taken based on an event’s severity level.

• Configure and test SNMP Trap Receiver settings for sending event-based traps.

• Define who will receive e-mail notifications of events.

• Test e-mail settings.

To do the following, see Administration: General :

• Define the System name, contact, and location values.

• Set the date and time used by the InRow RC.

• Select the temperature scale used by the InRow RC.

• Restart the user interface of the InRow RC.

• Reset network interface settings to their default settings.

• Upload a user configuration file.

• Configure Modbus settings.

• View information about the InRow RC.

• Define the URL addresses of the user links in the Web interface.

InRow RC Operation

Home

Overview

View a summary of the following:

• Active alarms

• Group status

• Unit status

• Recent device events

Alarm status

View the following alarm information:

• Group alarm status showing alarm descriptions and severity level

• Unit alarm status showing alarm descriptions and severity level

You can also choose to clear active alarms.

Group

Overview

View the following properties that are group-level or common to each unit in the group:

• Cool setpoint—in degrees Celsius (C) or Fahrenheit (F)

• Air flow—in cubic feet per minute (CFM) or liters per second (L/s)

• Maximum rack inlet temperature

• Minimum rack inlet temperature

• Cool output—in kilowatts (kW)

• Cool demand—in kW

Setpoints

Assign the group setpoints and then click

Apply

Assign Fan Speed Preference and then click

Apply

. Options are:

• Low

• Medium-Low

• Medium

• Medium-High

• High

Configuration

Number of units in group.

Enter the number of units in the group, then click

Apply

Up to twelve units can be configured to work as a group.

Configuration type.

Select the configuration type, which is the air flow control strategy the group uses, then click

Apply

•

RACS

—Rack Air Containment System. Air flow in the enclosure is controlled by a ducting system fitted to the enclosure. This is not a sealed system.

•

HACS

—Hot Aisle Containment System. Air flow in the room is controlled by enclosing the hot air aisle. The loads share an enclosed common hot aisle. This is not a sealed system.

•

In-Row

—Air flow is horizontal to allow in-row operation of the cooling group. The loads share a common open cold aisle.

Percent glycol.

Enter the percentage of glycol the group uses to cool the environment. This information is used to calculate the amount of energy (in kW) required by the unit.

Only a qualified service technician should change the amount of glycol in the group.

PID control settings.

The Proportional + Integral + Derivative (PID) control loop is used to control the output of the group. Enter the settings for the Cool PIDs, then click

Apply

The loops must be tuned after the room load is in place, and then tuned periodically if the room load changes. Only a qualified service technician should perform PID tuning.

For more information about PID tuning, see the InRow RC

Operation and Maintenance manual, available on the Utility CD or on the APC Web site,

www.apc.com.

Unit

Overview

View information for the various components of each unit in the group, including the following:

• Operating mode—On, Standby, or Idle

• Rack Inlet Temperature—in degrees F or C

• Supply and Return Air Temperatures—in degrees F or C

• Air flow—in CFM or L/s

• Fan speed—the average RPM of all fans, given as a percentage of the maximum fan speed.

• Cool output and demand—in kW

Detailed status

View information for the components of the units in the group:

• Input and output contact states—open or closed.

• Active power source—the power source supplying power to the unit, A or B.

• Filter differential pressure—the difference in pressure on either side of the air filter.

• Rack temperature 1, 2, and 3—three remote temperature sensors that display the temperature of the rack in degrees Fahrenheit or Celsius.

• Supply humidity—relative humidity (RH) of the unit’s supply air, displayed as a percentage.

Identification

The

Unit

tab’s left navigation menu option

Identification

displays the following read-only information about each unit:

• Model Number

• Serial Number

• Controller Firmware

• Hardware Revision

• Date of Manufacture

You can also configure the following identification information:

•

Unit ID

—Assign the unit a number from 1 to 12. The

Unit ID

may be unique for each

InRow RC within the cooling group, but the same

Unit ID

can be assigned to multiple units.

•

Name

—Enter a name (up to 20 alphanumeric characters) for the unit.

•

Location

—Enter the location (up to 20 alphanumeric characters) of the unit.

Click

Apply

to save your changes.

Run hours

View the run hours of the unit components. To reset the run hours, select the unit components to reset to zero and click

Apply

Service intervals

Set the service intervals for the

Air Filter, Condensate Pump,

and

Fans,

in weeks.

The default service interval for the

Air Filter

is 13 weeks, and the default service intervals for the

Condensate Pump

and

Fans

are 52 weeks.

Enable or disable alarm generation for the service interval, then click

Apply

to save your changes.

Thresholds

Configure high temperature thresholds for the rack inlet, supply air, return air, and entering fluid temperature sensors. If the respective temperature rises above the threshold, an alarm is activated. Click

Apply

to save your changes.

Configuration

Configure the following unit settings, then click

Apply

to save your changes:

•

Startup Delay

—The delay, in seconds, that begins when power is applied. The unit starts when the delay period ends. This allows you to create a staged restart after a power loss.

•

Cool Capacity

—The setting used to determine chilled water flow to the unit. Use

Automatic

to have the InRow RC automatically control its output under normal

(default) conditions. Use

Maximum

to run the InRow RC at full capacity.

•

Idle on Leak Detect

—When enabled, this setting causes the unit to idle when a leak is detected; the default setting is disabled.

•

Input Normal State

—The normal state for the input contact, open or closed. When the input is not in its normal state, the unit will stop cooling.

•

Output Normal State

—The normal state for the output relay, open or closed.

•

Output Source

—The type of alarm that will activate the output relay: any alarm, or only critical alarms.

•

Display Units

—The units (metric or US) displayed for each InRow RC.

•

Bypass Valve

—The setting must match the physical setting of the actual bypass valve, On or Off. This setting affects the cooling power calculation.

•

Fluid Calibration Mode

—When set to On, the chilled water valve stays 100% open; this assists in balancing the fluid flow across multiple units piped to the same chilled water loop. Only PowerView supports changing this mode to On or Off. An alarm is generated if this mode is set to On.

Logs

Events

Log

Use this option to view or delete the contents of the event log. The event log displays all events recorded since the log was last deleted or since the log reached its maximum capacity and the older half was deleted automatically. Events are in reverse chronological order. By default, all events are logged:

• You can view the event log as a page of the Web interface (the default view) or click

Launch Log in New Window

from that page to display a full-screen view of the log, enabling you to see more of the listed events without scrolling.

If your browser is Microsoft Internet Explorer, JavaScript must be enabled for you to use the

Launch Log in New Window

button.

Alternatively, you can use FTP or Secure CoPy (SCP) to view the

event log. See How to use FTP or SCP to retrieve the log files .

• To delete all events recorded in the log, click

Clear Event Log

on the Web page that displays the log. Deleted events cannot be retrieved.

To disable the logging of events based on their assigned severity level or their event category, configure event actions by group.

See Configuring by group

To access lists of all configurable events and how they are currently configured, select the

Administration

tab,

Notification

on the top menu bar, and

by event

under

Event

Actions

on the left navigation menu; then click, in turn, on each major category of event.

See

Configuring by event .

Reverse lookup

Reverse lookup is disabled by default. Enable this feature unless you have no DNS server configured or have poor network performance because of heavy network traffic.

With reverse lookup enabled, when a network-related event occurs, both the IP address and the domain name for the networked device associated with the event are logged in the event log. If no domain name entry exists for the device, only its IP address is logged with the event. Since domain names generally change much less frequently than IP addresses, enabling reverse lookup can improve the ability to identify addresses of networked devices that are causing events to occur.

Data

Log

Use this option to access a log that periodically records InRow RC data. Each entry is listed by the date and time the data was recorded and provides the data in a column format.

To view the data log through the Web interface, click

log

Click

Launch Log in New Window

to launch the data log in a new browser window that provides a full-screen view.

If your browser is Microsoft Internet Explorer, JavaScript must be enabled for you to use the

Launch Log in New Window

button.

Alternatively, you can use FTP or Secure CoPy (SCP) to view the

data log. See How to use FTP or SCP to retrieve the log files

Click

Clear Data Log

to delete all data recorded in the log. Deleted data cannot be retrieved.

Graphing

Use this option to create an interactive data graph. Select a maximum of four data parameters from the

Graph Data

drop-down list. Choose a time frame from the

Graph

Time

drop-down list or enter a date range in the

From

and

To

fields. Click

Apply

to generate the graph.

Click

Launch Graph in New Window

to launch the graph in a new browser window that provides a full-screen view.

Use the zoom tool above the graph to magnify the data shown on the screen. You can also click on any point in the graph to center and magnify that point on the screen. Use the left or right arrow bar to navigate through the data displayed in the magnified graph.

Hover over any horizontal line in the graph to view the date, time, and Y-axis value for that data record.

Interval

Use this option to define, in the

Data Log Interval

setting, how frequently data is sampled and stored in the data log. This Web interface page also reports how many days of data the log can store, based on the interval you selected.

When the log is full, the older half of the log is deleted and the newer half is retained. To avoid automatic deletion of older data, enable and configure data log rotation as described in the next section.

Rotation

Use this option to set up a password-protected data log repository on a specified FTP server. Enabling rotation causes a copy of any previously unsaved entries in the data log to be appended to the file you specify by name and location. Updates to this file occur either at the upload interval that you specify, in hours, or when the data log has reached its maximum size (if the maximum size is reached before the upload interval expires).

Parameter Description

Last Upload

Result

Data Log Rotation Enable or disable (the default) data log rotation.

FTP Server The location (IP address or host name) of the FTP server where the data repository file is stored.

User Name

Indicates whether the last upload of the data file to the FTP server succeeded or failed, or displays "None Available."

The user name required to send data to the repository file. This user must also be configured to have read and write access to the data repository file and the directory (folder) in which it is stored.

Password

File Path

File Name

Delay hours between Uploads

Upon failure, try uploading every

minutes

The password required to send data to the repository file.

The path to the repository file.

The name of the repository ASCII text file.

The number of hours between uploads of data to the specified file.

The time that the system waits before retrying an upload after a failed attempt. You can specify that the upload will be retried repeatedly until it succeeds or you can limit the number of retries. If you specify a limited number of retries and the upload has been retried unsuccessfully the specified number of times (

Number of

Retries

), the scheduled upload is skipped, and the system waits the number of hours specified as

Delay hours between Uploads

To initiate the initial upload of data to the repository file immediately, click

Upload Now!

Syslog

By default, the InRow RC can send messages to up to four Syslog servers whenever events occur. The Syslog servers, which must be specifically identified by their IP addresses or host names, record the events that occur at network devices in a log that provides a centralized record of events.

This user’s guide does not describe Syslog or its configuration values in detail. For more information about Syslog, see

RFC3164, at

www.ietf.org/rfc/rfc3164.txt?number=3164

Servers

Use this option to identify one or more Syslog servers that will receive Syslog messages and to specify a port for each. Select the server address to edit existing server configurations or select

Add Server

to configure additional servers.

Setting

Syslog Server

Port

Definition

Uses specific IP addresses or host names to identify up to four servers that will receive Syslog messages sent by the InRow RC.

OTE

To use the Syslog feature,

Syslog Server

must be defined for at least one server.

Identifies the user datagram protocol (UDP) port that the InRow RC will use to send Syslog messages. The default is

514

, the number of the UDP port assigned to Syslog.

Settings

Leave the Syslog settings, except the

Server IP

settings, set to their defaults unless otherwise specified by the Syslog network or system administrator.

Setting

Message

Generation

Facility

Code

Severity

Mapping

Definition

Enables (by default) or disables the Syslog feature.

Selects the facility code assigned to the InRow RC’s Syslog messages

(

User

, by default).

OTE

: User

is the selection that best defines the Syslog messages sent by the InRow RC. Do not change this selection unless advised to do so by the Syslog network or system administrator.

Maps each of the severity levels assigned to InRow RC events to the available Syslog priorities. You should not need to change the default mappings.

The following definitions are from RFC3164:

•

Emergency

: The system is unusable

•

Alert

: Action must be taken immediately

•

Critical

: Critical conditions

•

Error

: Error conditions

•

Warning

: Warning conditions

•

Notice

: Normal but significant conditions

•

Info

: Informational messages

•

Debug

: Debug-level messages

Following are the default settings for the four

Local Priority

settings:

•

Critical

is mapped to

Critical

•

Warning

is mapped to

Warning

•

Informational

is mapped to

Info

OTE

To disable sending Syslog messages for

Critical

Warning

, or

Informational

events, see Configuring event actions .

Test

Use this option to send a test message to the Syslog servers configured through the

servers

option:

1. Select a severity to assign to the test message.

2. Define the test message, using any text that is formatted according to the required test message field. For example, APC: Test Syslog, meets the formatting requirements.

How to use FTP or SCP to retrieve the log files

If you are an Administrator or Device-Only User, you can use FTP or SCP to retrieve a tab-delineated event log file (event.txt) or data log file (data.txt) that you can import into a spreadsheet application.

• The file reports all of the events recorded since the log was last deleted.

• The file includes information that the event log does not display.

– The version of the file format (first field)

– The date and time the file was retrieved

– The

Name

Contact

Location

values, and IP address of the InRow RC

– The unique

Event Code

for each recorded event (event log only)

The InRow RC uses a four-digit year for log entries. You may need to select a four-digit date format in your spreadsheet application to display all four digits of the year.

If you are using the encryption-based security protocols for your system, use Secure

CoPy (SCP) to retrieve the log file. (You should have FTP disabled.)

If you are using unencrypted authentication methods for the security of your system, use FTP to retrieve the log file.

See the Security Handbook, available on the APC InRow RC utility CD and on the APC Web site (

www.apc.com

) for information on the available protocols and methods for setting up the type of security appropriate for your needs.

To use SCP to retrieve the file.

To use SCP to retrieve the event.txt file, use the following command:

scp

username@hostname_or_ip_address:event.txt ./event.

txt

To use SCP to retrieve the data.txt file, use the following command:

scp

username@hostname_or_ip_address:data.txt ./data.

txt

To use FTP to retrieve the file.

To use FTP to retrieve the event.txt or data.txt file:

1. At a command prompt, type ftp and the InRow RC’s IP address, and press

NTER

. If the

Port

setting for the

FTP Server

option (which you select on the

Network

menu of the

Administration

tab) has been changed from its default value (

), you must use the non-default value in the FTP command. For

Windows FTP clients, use the following command, including spaces. (For some

FTP clients, you must use a colon instead of a space between the IP address and the port number.) ftp>open ip_address port_number

To set a non-default port value to enhance security for the FTP Server, see

FTP server . You can specify any port from 5001 to 32768.

2. Use the case-sensitive

User Name

and

Password

for either an Administrator or a Device-Only User to log on.

• For Administrator,

apc

is the default for

User Name

and

Password

• For the Device-Only User,

device

is the default for

User Name

, and

apc

is the default for

Password

3. Use the

get

command to transmit the text-version of the event log or data log to your local drive.

ftp>get event.txt

or ftp>get data.txt

4. You can use the

del

command to clear the contents of the event log or data log.

ftp>del event.txt or ftp>del data.txt

You will not be asked to confirm the deletion. If you clear the event log, a new

event.txt file is created to record the event.

5. Type

quit

at the

ftp>

prompt to exit from FTP.

Queries (Modbus requests and SNMP GETs)

See

About for information on configuring and using the request/

response structure of building management systems using the Modbus protocol, and see

access control

, under SNMP

for a description of

SNMP access types that enable an NMS to perform informational queries. Configuring the most restrictive SNMPv1 access type, READ, enables informational queries without the risk of allowing remote configuration changes.

Administration: Security

Local Users

Permission levels

Before you configure user access, be sure you understand the capabilities of each account type (Administrator, Device-Only User, and Read-Only User) to use menus, view information, and change settings.

For information on user permission levels for each account type

(Administrator, Device-Only User, and Read-Only User), see

Types of user accounts .

Setting user access

You set the user name and password for each of the account types in the same manner.

User name.

The case-sensitive user name (maximum of 10 characters) is used by

Administrators and Device-Only Users to log on at the control console, display interface, or Web interface and by the Read-Only User to log on at the Web interface.

Default values are

apc

for Administrator,

device

for Device-Only Users, and

readonly

for the Read-Only User.

Password.

The case-sensitive password (maximum of 10 characters) is used to log on to the Web interface, (except for the Read-Only User) the control console, or the display interface. The default setting for

Password

apc

for Administrators, Device-

Only Users, and Read-Only Users.

Remote Users

Authentication

Use this option to select how to administer remote access to the InRow RC:

For information about local authentication (authentication that can be administered without the centralized authentication provided by a

RADIUS server), see the Security Handbook provided on the Utility CD and available on the APC Web site at

www.apc.com

APC supports the authentication and authorization functions of RADIUS

(Remote Authentication Dial-In User Service).

• When a user accesses the InRow RC or another network-enabled device that has RADIUS enabled, an authentication request is sent to the RADIUS server to determine the user’s permission level.

• RADIUS user names used with the InRow RC are limited to 32 characters.

Select one of the following:

•

Local Authentication Only

: RADIUS is disabled. Local authentication is enabled.

•

RADIUS, then Local Authentication

: RADIUS is enabled, and local authentication is enabled. Authentication is requested from the RADIUS server first; local authentication is used only if the RADIUS server is not available

•

RADIUS Only

: RADIUS is enabled. Local authentication is disabled.

RADIUS Only

is selected, the only way to recover if the RADIUS server is unavailable, improperly identified, or improperly configured is to use a serial connection to the control console and change the

Authentication Method

setting to

Local Authentication Only

RADIUS, then Local Authentication

. See

Local access to the control console

for information about how to access the serial port.

RADIUS

Use this option to do the following:

• Display a list of RADIUS servers identified as being available to the InRow RC and the time-out period for each server (the number of seconds the InRow RC will wait for a reply from the server before the request fails).

• Add a server to the list of identified RADIUS servers. Click

Add Server

, and configure the following parameters for authentication by the new server:

RADIUS Setting Definition

RADIUS Server

Secret

The server name or IP address of the RADIUS server.

OTE

RADIUS servers use port 1812 by default to authenticate users. To use a different port, add a colon followed by the new port number to the end of the

RADIUS server name or IP address.

The shared secret between the RADIUS server and the

InRow RC.

Reply Timeout

Test Settings

The time in seconds that the InRow RC waits for a response from the RADIUS server.

Enter the Administrator user name and password to test the RADIUS server path that you have configured.

Skip Test and Apply

Do not test the RADIUS server path.

Configuring the RADIUS Server

You must configure your RADIUS server to work with the InRow RC. The following procedure summarizes the steps to perform.

For examples of the file entries needed to configure a RADIUS server for use with an InRow RC, see the Security Handbook, available on the Utility CD or from the APC Web site,

www.apc.com

Summary of the configuration procedure

1. Add the IP address of the InRow RC to the RADIUS server client list (file).

RADIUS servers use port 1812 by default to authenticate users.

To use a different port, add a colon followed by the new port number to the end of the RADIUS server name or IP address.

2. The users must be configured with Service-Type attributes unless Vendor

Specific Attributes (VSAs) are defined instead. If no Service-Type attribute is configured, the user will have read-only access to the Web interface only.

See your RADIUS server documentation for information about the RADIUS users file, and see the APC Security Handbook for an example.

3. VSAs can be used instead of the Service-Type attributes provided by your

RADIUS server. This method requires a dictionary entry and a RADIUS users file. In the dictionary file, you can define the names for the ATTRIBUTE and

VALUE keywords, but not the numeric values. If you change the numeric values, RADIUS authentication and authorization will not work correctly. VSAs take precedence over standard RADIUS attributes.

For examples of the RADIUS users file with VSAs and an example of an entry in the dictionary file on the RADIUS server, see the APC Security Handbook.

Configuring a RADIUS server on UNIX

®

, with shadow passwords

If UNIX shadow password files are used (/etc/passwd) in conjunction with the RADIUS dictionary files, the following two methods can be used to authenticate users:

• If all UNIX users have administrative privileges, add the following to the RADIUS

“user” file.

DEFAULT Auth-Type = System

APC-Service-Type = Admin

To allow only Device-Only Users, change the value for APC-Service-Type to

Device

• Add user names and attributes to the RADIUS “user” file and verify passwords against /etc/passwd. The following example is for users bconners and thawk:

bconners Auth-Type = System

APC-Service-Type = Admin thawk Auth-Type = System

APC-Service-Type = Device

Supported RADIUS servers

APC supports FreeRADIUS and Microsoft IAS 2003. Other commonly available

RADIUS applications may work but have not been fully tested by APC.

Auto Log Off

Use the

Auto Log Off

option to configure the time (3 minutes by default) that the system waits before logging off an inactive user.

Administration: Network

TCP/IP and Communication Settings

TCP/IP settings

The

TCP/IP

option on the left navigation menu, selected by default when you choose

Network

on the top menu bar, displays the current TCP/IP settings of the InRow RC (its

IP address, subnet mask, default gateway) and the MAC address.

On the same page,

TCP/IP Configuration

provides the following options for how the

TCP/IP settings will be configured when the InRow RC turns on, resets, or restarts:

Manual

BOOTP

DHCP

, and

DHCP & BOOTP

For information on DHCP and DHCP options, see

RFC2131

and

RFC2132

TCP/IP

Setting

Description

Manual The IP address, subnet mask, and default gateway must be configured manually. (The MAC address is not configurable.) Click

Next>>

and enter the new values.

BOOTP A BOOTP server provides the TCP/IP settings. At 32-second intervals, the

InRow RC requests network assignment from any BOOTP server:

• If it receives a valid response, it starts the network services.

• If it finds a BOOTP server, but the request to that server fails or times out, the InRow RC stops requesting network settings until it is restarted.

• By default, If previously configured network settings exist, and it receives no valid response to five requests (the original and four retries), it uses the previously configured settings so that it remains accessible if a BOOTP server is no longer available.

Click

Next>>

to access the BOOTP Configuration page to change the number of retries or the action to take if all retries fail to find a BOOTP server:

•

Maximum retries

: Enter the number of retries that will occur when no valid response is received, or zero (0) for an unlimited number of retries.

•

If retries fail

: Select either

Use prior settings

(the default) or

Stop

BOOTP request

1 The default values for these three settings on the configuration pages generally do not need to be changed:

•

Vendor Class

: APC

•

Client ID

: The MAC address of the InRow RC, which uniquely identifies it on the local area network (LAN)

•

User Class

: The name of the application firmware module

TCP/IP

Setting

DHCP

Description

At 32-second intervals, the InRow RC requests network assignment from any DHCP server: By default, the number of retries is unlimited.

• If the InRow RC receives a valid response, by default it requires the APC cookie from the DHCP server in order to accept the lease and start the network services.

• If the InRow RC finds a DHCP server, but the request to that server fails or times out, the InRow RC stops requesting network settings until it is restarted.

• If a DHCP server responds with an invalid offer (for example, the offer does not contain the APC Cookie), the InRow RC accepts the lease from that server on the last request of the sequence and then immediately releases that lease. This prevents the DHCP server from reserving the IP address associated with its invalid offer.

For more information on what a valid response requires, see

DHCP response options

To specify values other than the defaults, click

Next>>

to access the

DHCP

Configuration

page:

•

Require vendor specific cookie to accept DHCP Address

: To disable the requirement that the DHCP server provide the APC cookie, unmark this check-box.

•

Maximum retries

: Enter the number of retries that will occur when no valid response is received, or zero (0) for an unlimited number of retries.

1 The default values for these three settings on the configuration pages generally do not need to be changed:

•

Vendor Class

: APC

•

Client ID

: The MAC address of the InRow RC, which uniquely identifies it on the local area network (LAN)

•

User Class

: The name of the application firmware module

TCP/IP

Setting

Description

DHCP and

BOOTP

The default setting. The InRow RC tries to obtain its TCP/IP settings from a

BOOTP server first, and then, if it cannot discover a BOOTP server, from a

DHCP server. If it obtains its TCP/IP settings from either server, it switches this setting from the default to

BOOTP

DHCP

, depending on the type of server that supplied the TCP/IP settings to the InRow RC.

Click

Next>>

to access and configure the same settings that are available on the

BOOTP Configuration

and

DHCP Configuration

pages

and to specify that the

DHCP and BOOTP

setting be retained after either type of server provides the TCP/IP values.

1 The default values for these three settings on the configuration pages generally do not need to be changed:

•

Vendor Class

: APC

•

Client ID

: The MAC address of the InRow RC, which uniquely identifies it on the local area network (LAN)

•

User Class

: The name of the application firmware module

DHCP response options

Each valid DHCP response contains options that provide the TCP/IP settings that the

InRow RC needs to operate on a network, and other information that affects the InRow

RC’s operation.

Vendor specific information (option 43).

The InRow RC uses this option in a DHCP response to determine whether the DHCP response is valid. This option contains up to two APC-specific options in a TAG/LEN/DATA format: the APC Cookie and the Boot

Mode Transition.

• APC cookie. Tag 1, Len 4, Data “1APC”

Option 43 communicates to the InRow RC that a DHCP server is configured to service APC devices. By default, this DHCP response option must contain the APC

Cookie for the InRow RC to accept the lease.

To disable the requirement of an APC cookie, see

DHCP

Following, in hexadecimal format, is an example of a Vendor Specific Information option that contains the APC cookie:

Option 43 = 0x01 0x04 0x31 0x41 0x50 0x43

• Boot mode transition. Tag 2, Len 1, Data 1/2

This option 43 setting enables or disables

Remain in DHCP & BOOTP mode after accepting TCP/IP settings

, which, by default, is disabled.

– A data value of 1 enables

Remain in DHCP & BOOTP mode after accepting

TCP/IP settings

. Whenever the InRow RC reboots, it will request its network assignment first from a BOOTP server, and then, if necessary, from a DHCP server.

– A data value of 2 disables the

Remain in DHCP & BOOTP mode after accepting

TCP/IP settings

The

TCP/IP Configuration

setting switches to

DHCP

when the

InRow RC accepts the DHCP response. Whenever the InRow RC reboots, it will request its network assignment from a DHCP server only.

Following, in hexadecimal format, is an example of a Vendor Specific Information option that contains the APC cookie and the Disable Boot Mode Transition setting:

Option 43 = 0x01 0x04 0x31 0x41 0x50 0x43 0x02 0x01 0x01

TCP/IP options.

The InRow RC uses the following options within a valid DHCP response to define its TCP/IP settings. All of these options except the first are described in

RFC2132

•

IP Address

(from the

yiaddr

field of the DHCP response, described in

RFC2131)

The IP address that the DHCP server is leasing to the InRow RC.

•

Subnet Mask

(option 1): The Subnet Mask value that the InRow RC needs to operate on the network.

•

Default Gateway

(option 3): The default gateway address that the InRow RC needs to operate on the network.

•

IP Address Lease Time

(option 51): The time duration for the lease of the IP

Address to the InRow RC.

•

Renewal Time, T1

(option 58): The time that the InRow RC must wait after an IP address lease is assigned before it can request a renewal of that lease.

•

Rebinding Time, T2

(option 59): The time that the InRow RC must wait after an IP address lease is assigned before it can seek to rebind that lease.

Other options.

The InRow RC also uses the following options within a valid DHCP response. All of these options except the last are described in

RFC2132

•

Network Time Protocol Servers

(option 42): Up to two NTP servers (primary and secondary) that the InRow RC can use.

•

Time Offset

(option 2): The offset of the InRow RC's subnet, in seconds, from

Coordinated Universal Time (UTC).

•

Domain Name Server

(option 6): Up to two Domain Name System (DNS) servers

(primary and secondary) that the InRow RC can use.

•

Host Name

(option 12): The host name that the InRow RC will use (32-character maximum length).

•

Domain Name

(option 15): The domain name that the InRow RC will use

(64-character maximum length).

•

Boot File Name

(from the

file

field of the DHCP response, described in

RFC2131

The fully qualified directory-path to an APC user configuration file (.ini file) to download. The

siaddr

field of the DHCP response specifies the IP address of the server from which the InRow RC will download the .ini file. After the download, the

InRow RC uses the .ini file as a boot file to reconfigure its settings.

Port speed

The

Port Speed

setting defines the communication speed of the TCP/IP port.

• For

Auto-negotiation

(the default), Ethernet devices negotiate to transmit at the highest possible speed, but if the supported speeds of two devices are unmatched, the slower speed is used.

• Alternatively, you can choose either 10 Mbps or 100 Mbps, each with the option of half-duplex (for communication in only one direction at a time) or full-duplex (for communication simultaneously in both directions on the same channel).

DNS (Adminstration>Network>DNS>servers)

Use the options under

DNS

on the left navigation menu to configure and test the

Domain Name System (DNS):

• Select

servers

to specify the IP addresses of the primary and optional secondary

Domain Name System server. The InRow RC cannot send any e-mail messages unless at least the IP address of the primary DNS server is defined.

– The InRow RC waits a maximum of 15 seconds for a response from the primary

DNS server or the secondary DNS server (if a secondary DNS server is specified).

If the InRow RC does not receive a response within that time, e-mail cannot be sent. Therefore, use DNS servers on the same segment as the InRow RC or on a nearby segment (but not across a wide-area network [WAN]).

– After you define the IP addresses of the DNS servers, verify that DNS is working correctly by entering the DNS name of a computer on your network to look up the

IP address for that computer.

• Select

naming

to define the host name and domain name of the InRow RC:

–

Host Name

: When an Administrator configures a host name here and a domain name in the

Domain Name

field, users can then enter a host name in any field in the InRow RC interface (except e-mail addresses) that accepts a domain name as input.

–

Domain Name

: An Administrator must configure the domain name here only. In all other fields in the InRow RC interface (except e-mail addresses) that accept domain names, the InRow RC adds this domain name when only a host name is entered.

• To override all instances of the expansion of a specified host name by the addition of the domain name, set the domain name field to its default, example.com

, or to 0.0.0.0.

• To override the expansion of a specific host name entry—for example when defining a trap receiver—include a trailing period. The InRow RC recognizes a host name with a trailing period (such as mySnmpServer.) as if it were a fully qualified domain name and does not append the domain name.

• Select

test

to send a DNS query that tests the setup of your DNS servers:

– As

Query Type

, select the method to use for the DNS query:

•

by Host

: the URL name of the server

•

by FQDN

: the fully qualified domain name

•

by IP

: the IP address of the server

•

by MX

: the Mail Exchange used by the server

– In the

Query Question

field, identify the value to be used for the selected query type:

Query Type Selected Query Question to Use

by Host by FQDN by IP by MX the URL the fully qualified domain name, formatted as

my_server.my_domain.com

the IP address the Mail Exchange address

– View the result of the test DNS request in the

Last Query Response

field.

Web

Use the options under

Web

on the left navigation menu to configure the following:

Option

access

Description

To activate changes to any of the following access selections, log off from and back on to the InRow RC:

•

Disable

: Disables all access to the Web interface. (You must use the control console to re-enable access to the Web interface. Select

Network

and

Web/

SSL/TLS

. Then for HTTP access, select

Access

and

Enabled

, and for HTTPS access, also select

Web/SSL

and

Enabled

•

Enable HTTP

(the default): Enables Hypertext Transfer Protocol (HTTP), which provides Web access by user name and password, but does not encrypt user names, passwords, and data during transmission.

•

Enable HTTPS

: Enables Hypertext Transfer Protocol over Secure Sockets

Layer (HTTPS) to provide Web access. Secure Sockets Layer (SSL) encrypts user names, passwords, and data during transmission, and provides authentication of the InRow RC by digital certificate.

See “Creating and Installing Digital Certificates” in the Security Handbook on the

Utility CD to choose among the several methods for using digital certificates.

When HTTPS is enabled, your browser displays a lock icon, usually at the bottom of the screen:

HTTP Port

: Identifies the TCP/IP port used for communication by

HTTP with the InRow RC. The default is 80.

HTTPS Port

: Identifies the TCP/IP port used for communication by HTTPS with the InRow RC. The default is 443.

You can change either port setting to the number of any unused port from 5000 to

32768 to enhance the protection provided by User Name and Password settings.

You must then use a colon (:) in the address field of the browser to specify the non-default port number. For example, for port 5000 and the InRow RC IP address of 152.214.12.114, you would use one of these Web addresses: http://152.214.12.114:5000 https://152.214.12.114:5000

Option

ssl cipher suites ssl certificate

Description

Enable or disable any of the SSL encryption ciphers and hash algorithms:

•

DES

: A block cipher that provides authentication by Secure Hash Algorithm.

•

RC4_MD5

(enabled by default): A stream cipher, providing authentication by

MD5 hash algorithm.

•

RC4_SHA

(enabled by default): A stream cipher that provides authentication by

Secure Hash Algorithm.

•

3DES

: A block cipher that provides authentication by Secure Hash Algorithm.

Add, replace, or remove a security certificate.

Status

•

Not installed

: A certificate is not installed, or a certificate was installed by FTP or SCP to an incorrect location. Using

Add or Replace Certificate File

installs the certificate to the correct location,

/sec

on the InRow RC.

•

Generating

: The InRow RC is generating a certificate because no valid certificate was found.

•

Loading

: A certificate is being activated on the InRow RC.

•

Valid certificate

: A valid certificate was installed or was generated by the InRow

RC. Click on this link to view the certificate’s contents.

If you install an invalid certificate, or if no certificate is loaded when you enable SSL, the InRow RC generates a default certificate, a process which delays access to the interface for up to five minutes.

You can use the default certificate for basic encryption-based security, but a security alert message displays whenever you log on.

Add or Replace Certificate File

: Enter or browse to the certificate file created with the Security Wizard.

See “Creating and Installing Digital Certificates” in the Security Handbook on the

Utility CD to choose a method for using digital certificates, including certificates created by the Security Wizard or generated by the InRow RC.

Remove

: Delete the current certificate.

Console

Use the options under

Console

on the left navigation menu to configure the following:

Option

access

Description

Choose one of the following:

•

Disable

: Disables all access to the control console.

•

Enable Telnet

(the default setting): Telnet transmits user names, passwords, and data without encryption.

•

Enable SSH v1 and v2

: Do not enable both versions 1 and 2 of Secure

SHell (SSH) unless you require that both be activated at the same time.

(Security protocols use extensive processing power.)

•

Enable SSH v1 only

: Secure SHell (SSH) version 1 transmits user names, passwords, and data in encrypted form. There is little or no delay as you log on.

•

Enable SSH v2 only

: Secure SHell (SSH) version 2 transmits user names, passwords, and data in encrypted form with somewhat more protection than version 1 from attempts to intercept, forge, or alter data during transmission. There is a noticeable delay as you log on.

Identify the TCP/IP port used for communications with the Network

Management Card of the InRow RC by Telnet and Secure SHell (SSH).

•

Telnet Port

: The default is 23.

•

SSH Port

: The default is 22.

You can change the Port setting to the number of any unused port from

5000 to 32768 to enhance the protection provided by User Name and

Password settings.

• For Telnet, you must use either a colon (:) or a space in the command line, according to the requirements of your Telnet client program, to specify the non-default port number. For example, for a port number of

5000 and the InRow RC IP address of 152.214.12.114, your Telnet client requires one of the following commands: telnet 152.214.12.114:5000 telnet 152.214.12.114 5000

• For SSH, see the documentation for your SSH client for the command line format required to specify a non-default port when starting SSH.

Option

ssh encryption

Description

Enable or disable encryption algorithms (block ciphers) compatible with

SSH version 1 or version 2 clients:

SSH v1 algorithms:

•

DES

•

Blowfish

: If your SSH v1 client cannot use Blowfish, which is always enabled, you must also enable DES.

SSH v2 algorithms:

•

3DES

: (enabled by default)

•

Blowfish

: (enabled by default)

•

AES 128

•

AES 256

Your SSH v2 client selects the enabled algorithm that provides the highest security. If your SSH client cannot use the default algorithms, you must enable an AES algorithm that it can use.

Option

ssh host key

Description

Status

indicates the status of the host key (private key):

•

SSH Disabled: No host key in use:

SSH is disabled and is not using a host key even if one is loaded.

•

Generating

: The InRow RC is creating a host key because no valid host key was found.

•

Loading

: A host key is being activated on the InRow RC.

•

Valid

: One of the following valid host keys is in the

/sec

directory (the required location on the InRow RC:

• A 1024-bit host key created by the APC Security Wizard.

• A 768-bit RSA host key generated by the InRow RC

Add or Replace

: Upload a host key file created by the APC Security

Wizard to the

/sec

directory:

1. Click

Browse

2. Locate the file.

3. Click

Apply

If you use FTP or Secure CoPy (SCP) instead to transfer the host key file, you must specify the

/sec

directory as the target location in the command.

To use the APC Security Wizard, see the Security Handbook on the Utility

CD.

OTE

To reduce the time required to enable SSH, create and upload a host key in advance.

If you enable SSH with no host key loaded, the

InRow RC takes up to 5 minutes to create a host key, and the SSH server is not accessible during that time.

Remove

: Remove the current host key.

To use SSH, you must have a SSH client installed. Most Linux and other UNIX

® platforms include a SSH client, but Microsoft Windows operating systems do not. SSH clients are available from various vendors.

SNMP

SNMPv1.

All user names, passwords, and community names for SNMP are transferred over the network as plain text. If your network requires the high security of encryption, disable SNMP access or set the access for each community to Read. (A community with Read access can receive status information and use SNMP traps.)

When using InfraStruXure Central or InfraStruXure Manager to manage an InRow RC on the public network of an InfraStruXure system, you must have SNMP enabled in the

InRow RC. Read access will allow InfraStruXure Central or InfraStruXure Manager to receive traps from the InRow RC, but Write access is required while you use the interface of the InRow RC to set InfraStruXure Central or InfraStruXure Manager as a trap receiver.

For detailed information on enhancing and managing the security of your system, see the Security Handbook, available on the Utility CD or from the APC Web site,

www.apc.com

Use the options under

SNMP

on the left navigation menu to configure the following:

Option Description

access

Enable SNMPv1 Access:

Enables SNMP version 1 as a method of communication with this device.

access control

You can configure up to four access control entries to specify which Network

Management Systems (NMS) have access to this device. The opening page for access control, by default, assigns one entry to each of the four available

SNMPv1 communities, but you can edit these settings to apply more than one entry to any community to grant access by several specific IP addresses, host names, or IP address masks. To edit the access control settings for a community, click its community name.

• If you leave the default access control entry unchanged for a community, that community has access to this device from any location on the network.

• If you configure multiple access control entries for one community name, the limit of four entries requires that one or more of the other communities must have no access control entry. If no access control entry is listed for a community, that community has no access to this device.

Community Name:

The name that a NMS must use to access the community.

The maximum length is 15 ASCII characters, and the default community names for the four communities are "public," "private," "public2," and "private2."

NMS IP/Host Name:

The IP address, IP address mask, or host name that controls access by NMSs. A host name or a specific IP address (such as

149.225.12.1) allows access only by the NMS at that location. IP addresses that contain 255 restrict access as follows:

• 149.225.12.255: Access only by a NMS on the 149.225.12 segment.

• 149.225.255.255: Access only by a NMS on the 149.225 segment.

• 149.255.255.255: Access only by a NMS on the 149 segment.

• 0.0.0.0 (the default setting) which can also be expressed as 255.255.255.255:

Access by any NMS on any segment.

Access Type

: The actions an NMS can perform through the community.

•

Read

: GETS only, at any time.

•

Write

: GETS at any time, and SETS when no user is logged onto the Web interface or Control Console.

•

Write+

: GETS and SETS at any time.

•

Disabled

: No GETS or SETS at any time.

SNMPv3.

For SNMP GETs, SETs, and trap receivers, SNMPv3 uses a system of user profiles to identify users. An SNMPv3 user must have a user profile assigned in the

MIB software program to perform GETs and SETs, browse the MIB, and receive traps.

To use SNMPv3, you must have a MIB program that supports SNMPv3.

The InRow RC supports only MD5 authentication and DES encryption.

Option Description

access

SNMPv3 Access:

Enables SNMPv3 as a method of communication with this device. user profiles

By default, lists the settings of four user profiles, configured with the user names "apc snmp profile1" through "apc snmp profile 4," and no authentication and no privacy (no encryption of data). To edit the following settings for a user profile, click a user name in the list.

User Name:

The identifier of the user profile. SNMP version 3 maps GETs, SETs, and traps to a user profile by matching the user name of the profile to the user name in the data packet being transmitted. A user name can have up to 32 ASCII characters.

Authentication Passphrase:

A phrase of 15 to 32 ASCII characters that verifies that the NMS communicating with this device through SNMPv3 is the NMS it claims to be, that the message has not been changed during transmission, and that the message was communicated in a timely manner, indicating that it was not delayed and that it was not copied and sent again later at an inappropriate time.

Privacy Passphrase:

A phrase of 15 to 32 ASCII characters that ensures the privacy of the data (by means of encryption) that a NMS is sending to this device or receiving from this device through SNMP v3.

Authentication Protocol

: The APC implementation of SNMPv3 supports MD5 authentication. Authentication will not occur unless MD5 is selected here.

Privacy Protocol:

The APC implementation of SNMPv3 supports DES as the protocol for encrypting and decrypting data. Privacy of transmitted data requires that

DES is selected here.

Note:

You cannot select the privacy protocol if no authentication protocol is selected.

Option Description

access control

You can configure up to four access control entries to specify which NMSs have access to this device. The opening page for access control, by default, assigns one entry to each of the four user profiles, but you can edit these settings to apply more than one entry to any user profile to grant access by several specific IP addresses, host names, or IP address masks.

• If you leave the default access control entry unchanged for a user profile, all NMSs that use that profile have access to this device.

• If you configure multiple access entries for one user profile, the limit of four entries requires that one or more of the other user profiles must have no access control entry. If no access control entry is listed for a user profile, no NMS that uses that profile has any access to this device.

To edit the access control settings for a user profile, click its user name.

Access:

Mark the Enable checkbox to activate the access control specified by the parameters in this access control entry.

User Name:

Select from the drop-down list the user profile to which this access control entry will apply. The choices available are the four user names that you configure through the

user profiles

option on the left navigation menu.

NMS IP/Host Name:

The IP address, IP address mask, or host name that controls access by the NMS. A host name or a specific IP address (such as 149.225.12.1) allows access only by the NMS at that location. An IP address mask that contains 255 restricts access as follows:

• 149.225.12.255: Access only by a NMS on the 149.225.12 segment.

• 149.225.255.255: Access only by a NMS on the 149.225 segment.

• 149.255.255.255: Access only by a NMS on the 149 segment.

• 0.0.0.0 (the default setting) which can also be expressed as 255.255.255.255:

Access by any NMS on any segment.

FTP server

The

FTP server

settings enable (by default) or disable access to the FTP server and specify the TCP/IP port (21 by default) that the FTP server uses for communication with the InRow RC. The FTP server uses both the specified port and the port one number lower than the specified port.

You can change the

Port

setting to the number of any unused port from 5001 to 32767 to enhance the protection provided by User Name and Password settings. You must then use a colon (:) in the command line to specify the non-default port number. For example, for a port number of 5001 and the InRow RC IP address of 152.214.12.114, you would use this command: ftp 152.214.12.114:5001

FTP transfers files without encryption. For higher security, disable the

FTP server, and transfer files with Secure CoPy (SCP). Selecting and configuring Secure SHell (SSH) enables SCP automatically.

At any time that you want the InRow RC to be accessible for management by InfraStruXure Central or InfraStruXure Manager, FTP

Server must be enabled in the InRow RC interface.

Administration: Notification

Event Actions

Types of notification

You can configure event actions to occur in response to an event or a group of events.

These actions notify users of the event in any of several ways:

• Active, automatic notification. The specified users or monitoring devices are contacted directly.

– E-mail notification

– SNMP traps

– Syslog notification

To set up additional methods of active notification that are not included in the

Event Action

options, see Configuration

for information on configuring the output contact.

• Indirect notification through the event log. If none of the direct notification methods are configured, users must check the log to determine which events have occurred.

Another method of indirect notification, not included in the

Event

Action

options, is the use of informational queries. See access control

, under

SNMP

, for a description of SNMP access types that enable a Network Management System (NMS) to perform informational queries. Configuring the most restrictive SNMP access type, READ, or using Serial Modbus enables informational queries without the risk of allowing remote configuration changes.

Configuring event actions

You can configure event actions for individual events or for predefined groups of events.

Configuring by event.

To define event actions for an individual event:

1. Select the

Administration

tab,

Notification

on the top menu bar, and

by event

under

Event Actions

on the left navigation menu.

2. Follow the on-screen instructions to list events by severity, either by main category or sub-category.

3. In the list of events, check the marked columns to see whether the action you want is already configured for the event. (By default, logging is configured for all events.)

4. For details of the current configuration, such as the recipients to be notified by e-mail or the Network Management Systems (NMSs) to be notified by SNMP traps, click on the event name.

5. Add to or change the event configuration.

A Syslog server must be configured before you can display or use the Syslog option, and at least one e-mail recipient or trap receiver must be configured before you can display or use the detailed e-mail and trap notification options.

–Mark the checkboxes to enable (or unmark them to disable) event logging or

Syslog for this event.

–Click on any e-mail recipient or trap receiver, and specify any value up to three digits to configure the following detailed options:

•How long, in seconds or minutes, the InRow RC waits after the event occurs before sending e-mail to the selected e-mail recipient or a trap to the selected trap receiver. If the event clears during this delay period, no notification is sent.

To configure a delay longer than 999 seconds (16 minutes, 39 seconds), use minutes.

•How frequently to send e-mail to the selected e-mail recipient or a trap to the selected trap receiver. E-mail or a trap repeats at the time interval specified here in seconds, minutes, or hours, unless the event has cleared.

•The number of times to send e-mail to the selected e-mail recipient or a trap to the selected trap receiver. Choose to send e-mail or a trap a specified number of times or to repeat the notification an unlimited number of times. In either case, notification stops if the event clears.

When configuring events, you can enable or disable notification to configured e-mail recipients, Syslog servers, or trap receivers, but you cannot add or remove any recipients, receivers, or Syslog servers. To

add or remove recipients, receivers, or servers, see Syslog ,

Recipients

, and

Trap receivers.

Configuring by group.

To configure a group of events simultaneously:

1. Select the

Administration

tab,

Notification

on the top menu bar, and

by group

under

Event Actions

on the left navigation menu.

2. Choose how you want events to be grouped for configuration and select

• If you choose

Events by severity

, you can then select all events of one or more severity types.

When configuring events by severity, you must use their existing severity. You cannot change the severity of an event.

• If you choose

Events by category

, you can then select all events in one or more predefined categories.

3. Select event actions for all events in the group.

A Syslog server must be configured in order to display or use the

Syslog option, and at least one e-mail recipient (for e-mail notification) or at least one trap receiver (for notification by

SNMP traps) must be configured in order to display the detailed e-mail and trap receiver notification options.

– Click the

Logging

button to choose logging for all events in the group. Click

Next>>

, and then mark the checkboxes to enable (or unmark them to disable) event logging or Syslog for these events.

– Click the

E-mail Recipients

Trap Receivers

button, click

Next>>

, and select an e-mail recipient or trap receiver. Then specify any value up to three digits to configure the following detailed options:

• How long, in seconds or minutes, the InRow RC waits after one of these events occurs before sending e-mail to the selected e-mail recipient or a trap to the selected trap receiver. If the event clears during this delay period, no notification is sent. To configure a delay longer than 999 seconds (16 minutes,

39 seconds), use minutes.

• How frequently to send e-mail to the selected e-mail recipient or a trap to the selected trap receiver. E-mail or a trap repeats at the time interval specified here in seconds, minutes, or hours, unless the event has cleared.

• The number of times to send e-mail to the selected e-mail recipient or a trap to the selected trap receiver. Choose to send e-mail or a trap a specified number of times or to repeat the notification an unlimited number of times. In either case, notification stops if the event clears.

To add or remove recipients or receivers, see Recipients

Trap receivers.

4. Click

Next>>

, and then click

Apply

to confirm the displayed selections.

5. Click

Finish

to return to the

by group

page, or select

Configure Additional

Actions

to keep the selected event group and to configure the remaining

Logging

E-mail Recipients

, or

Trap Receivers

actions for this group.

Active, Automatic, Direct Notification

E-mail

Overview of setup.

Use the Simple Mail Transfer Protocol (SMTP) to send e-mail to up to four recipients when an event occurs.

To use the e-mail feature, you must define the following settings:

• The IP addresses of the primary and, optionally, of the secondary Domain Name

System (DNS) servers

See DNS (Adminstration>Network>DNS>servers)

• The IP address or DNS name for

SMTP Server

and the

From Address

setting for

SMTP

See SMTP (Administration>Notification>E-mail>server) .

• The e-mail addresses for a maximum of four recipients

To configure recipients, see Recipients

You can use the

To Address

setting of the

recipients

option to send e-mail to a text-based pager.

SMTP (Administration>Notification>E-mail>server).

Use this option to define the following settings:

Setting Description

Local

SMTP

Server

From

Address

The IP address (or if DNS is configured, the DNS name) of the local SMTP server.

OTE

This definition is required only when

SMTP Server

is set to

Local

when e-mail recipients are being configured. See

Recipients .

The contents of the

From

field in the format user@ [IP_address] (if an IP address is specified as

Local SMTP Server

) or user@domain.com (if DNS is configured and the DNS name is specified as

Local SMTP Server

) in the e-mail messages sent by the InRow RC.

OTE

The local SMTP server’s configuration may require that you use a valid user account on the server for this setting. See the server’s documentation for more information.

Recipients.

Use this option to identify up to four e-mail recipients. Click a recipient

To

Address

to edit that configuration. Select

Add Recipient

to add a new recipient.

Setting Description

To Address Defines the user and domain names of the recipient. To use e-mail for paging, use the e-mail address for that recipient’s pager gateway account

(for example,

[email protected]

). The pager gateway will generate the page.

You can bypass the DNS lookup of the mail server’s IP address by using the IP address in brackets instead of the e-mail domain name. For example, use jsmith@[xxx.xxx.x.xxx] instead of [email protected].

This is useful when DNS lookups are not working correctly.

OTE

The recipient’s pager must be able to use text-based messaging.

E-mail

Generation

Enables (by default) or disables sending e-mail to the recipient.

Setting Description

SMTP

Server

Format

Selects one of the following methods for routing e-mail:

•

Local

: Through the SMTP server of the InRow RC (the recommended setting). This option ensures that the e-mail is sent before the InRow

RC’s 20-second time-out, and, if necessary, is retried several times.

Also do one of the following:

• Enable forwarding at the InRow RC’s SMTP server so that it can route e-mail to external SMTP servers. Typically, SMTP servers are not configured to forward e-mail. Always check with the administrator of your SMTP server before changing its configuration to allow forwarding.

• Set up a special e-mail account for the InRow RC to forward e-mail to an external mail account.

•

Recipient

: Directly to the recipient’s SMTP server. On a busy remote

SMTP server, the time-out may prevent some e-mail from being sent because, with this option, the InRow RC tries to send the e-mail only once.

When the recipient uses the InRow RC’s SMTP server, this setting has no effect.

Select

Long

Short

. The

Long

format contains Name, Location,

Contact, IP address, serial number of the device, date, time, event code, and event description. The

Short

format provides only the event description.

Test.

Use this option to send a test message to a configured recipient.

SNMP traps

Trap receivers.

This option lists, by NMS IP/Host Name, up to the maximum number

(six) of trap receivers allowed.

• To open the page for configuring a new trap receiver, click

Add Trap Receiver

• To modify or delete a trap receiver, first click its IP address or host name to access its settings. (If you delete a trap receiver, all notification settings configured under Event

Actions for the deleted trap receiver are set to their default values.)

• To specify the trap type for a trap receiver, select either the SNMPv1 or SNMPv3 radio button. For an NMS to receive both types of traps, you must configure two trap receivers for that NMS, one for each trap type.

Item

Trap Generation

NMS IP/Host

Name

Definition

Enable (the default) or disable trap generation for this trap receiver.

The IP address or host name of this trap receiver. The default, 0.0.0.0, leaves the trap receiver undefined.

SNMPv1 option.

Community Name The name ("public" by default) used as an identifier when SNMPv1 traps are sent to this trap receiver.

Authenticate

Traps

When this option is enabled (the default), the NMS identified by the NMS

IP/Host Name setting will receive authentication traps (traps generated by invalid attempts to log on to this device). To disable that ability, unmark the checkbox.

SNMPv3 option.

Select the identifier of the user profile for this trap receiver. (To view the settings of the user profiles identified by the user names selectable here, choose

Network

on the top menu bar and

user profiles

under

SNMPv3

on the left navigation menu.)

Test.

Use this option to test the sending of a trap to a configured trap receiver.

Last test result

—The result of the most recent SNMP trap test. A successful SNMP trap test verifies only that a trap was sent; it does not verify that the trap was received by the selected trap receiver. A trap test succeeds if all of the following are true:

• The SNMP version (SNMPv1 or SNMPv3) configured for the selected trap receiver is enabled on this device.

• The trap receiver is enabled.

• If a host name is selected for the

To

address, that host name can be mapped to a valid IP address.

To

—Select the IP address or host name to which a test SNMP trap will be sent. If no trap receiver was ever configured, a link to the

Trap Receiver

configuration page is displayed. (If a trap receiver was deleted, or was reset to its default values by this or any other management application, the default values for its trap type are listed.)

Administration: General

Information about the InRow RC

Identification

Use this option to define the System

Name

Contact

, and

Location

values used to identify the InRow RC. For example, you might configure

Name

as Test Lab,

Contact

(whom to contact about the device) as Donald Adams, and

Location

as Building 3.

Date and time

Mode.

Use this option to set the time and date used by the InRow RC. The option displays the current settings, and allows you to change those settings manually, or through a Network Time Protocol (NTP) Server.

•

Manual

: Use this selection to do one of the following:

– Enter the date and time for the InRow RC.

– Mark the checkbox

Apply Local Computer Time

to match the date and time settings of the computer you are using, and click

Apply

•

Synchronize with NTP Server

: Use this selection to have an NTP Server define the date and time for the InRow RC.

Setting Definition

Primary NTP

Server

Secondary

NTP Server

Time Zone

Enter the IP address or domain name of the primary NTP server.

Enter the IP address or domain name of the secondary NTP server, when a secondary server is available.

Select a time zone. The number of hours preceding each time zone in the list is the offset from UTC (Coordinated Universal

Time, Temps Universel Coordonné, formerly Greenwich Mean

Time), the international time standard.

Update Interval Define how often, in hours, the InRow RC accesses the NTP

Server for an update. The minimum is 1 hour; the maximum is

8760 hours (1 year).

Update Using

NTP Now

Mark this checkbox and click

Apply

to initiate an immediate update of the date and time by the NTP Server.

Daylight Saving.

Use this option to enable either traditional United States Daylight

Saving Time (DST) or to enable and configure a customized daylight saving time, with starting and ending dates and time that you specify to match how Daylight Saving Time is implemented in your local area. DST is disabled by default.

When customizing Daylight Saving Time:

• If the local Daylight Saving Time always starts or ends on the 4th occurrence of a specific weekday of a month (for example, the 4th Sunday), choose Fourth/Last. If a

5th Sunday occurs in that month in a subsequent year, the time setting will still change to or from Daylight Saving Time on the 4th Sunday.

• If the local Daylight Saving Time always starts or ends on the last occurrence of a specific weekday of a month, such as the last Sunday of that month, regardless of whether that last Sunday is the 4th or the 5th Sunday, choose Fifth/Last.

Date format.

Select the numerical format in which to display all dates in this User

Interface. In the selections, each letter m (for month), d (for day), and y (for year) represents one digit. Single-digit days and months are displayed with a leading zero.

User configuration file (ini)

As an Administrator, you can retrieve a dynamically generated .ini file of the current configuration of the InRow RC and export that file to another InRow RC or to multiple

InRow RCs.

Use the

Browse

button to upload an .ini file.

For further detail, see How to Export Configuration Settings

Unit preference

Select the temperature scale (Fahrenheit or Celsius) in which to display all temperature measurements in this user interface.

Changing the temperature scale will also change other unit settings between Metric and English. Settings that will be affected include flow rates and pressure measurements.

Reset/reboot

Use this option to perform any of the following actions:

Action

Reboot Management

Interface

Definition

Restarts the management interface of the device without turning off and restarting the device itself.

Action

Reset All

Reset Only

Definition

Resets Security, Network, Notification, General, and Logs configuration settings. It does not reset Cooling Group and

Cooling Unit configuration settings.

Mark the

Include TCP/IP

checkbox to include the setting that determines how this device must obtain its TCP/IP settings. That setting will be reset to its default, DHCP & BOOTP.

OTE

To reset all device settings except the TCP/IP settings, leave the

Include TCP/IP

checkbox unchecked.

You can choose one or more of the following options by marking their checkboxes:

TCP/IP

: Resets only the setting that determines how this device must obtain its TCP/IP settings. That setting will be reset to its default, DHCP & BOOTP.

Event Configuration

: Resets only events to their default configuration. Any configuration changes, by event or by group, will revert to their default settings.

Serial Modbus

To configure Modbus, select the

Administration

tab,

General

on the top menu bar, and

Serial Modbus

on the left navigation menu. You can enable or disable Modbus, choose a baud rate, and specify a unique identifier.

Modbus defines a request/response message structure for a client/server environment.

The APC implementation of Modbus uses Remote Terminal Unit (RTU) mode. You can use Modbus to view the InRow RC through your building management system interface. It is read-only.

• The Modbus interface supports 2-wire RS-485.

• Modbus runs at 9600 or 19200 bps.

The Modbus register map for the InRow RC defines the data (type, location, and valid responses) available through Modbus. To download the latest Modbus register map, go to the APC Web site (

www.apc.com

), search for your product, and click the link to the register map in the list of documentation. Check the publication date at the start of the file.

For more information on Modbus, see the Modbus Standard

Library at

www.modbus.org

Quick links

Select the

Administration

tab, the

General

option on the top menu bar, and the

Quick

Links

option on the left navigation menu to view the three URL links displayed at the bottom left of each page of the interface.

By default, these links access the following Web pages:

•

APC’s Web Site

: The APC home page.

•

Testdrive Demo

: A demonstration page where you can use samples of APC

Web-enabled products.

•

APC Monitoring

: The home page of the APC Remote Monitoring Service.

To reconfigure a link, click on that link in the

Display

column, and change any of the following:

•

Display

: The short link name displayed on each interface page.

•

Name

: A name that fully identifies the target or purpose of the link.

•

Address

: Any URL — for example, the URL of another device and server.

About

The hardware information is especially useful to APC Customer Support in helping to troubleshoot problems with your InRow RC. The serial number and MAC address accessible through the

About

menu option are also available on the InRow RC itself.

Management Uptime shows the time that has elapsed since the last reset or reboot.

Firmware information, listed under Application Module and APC OS (AOS), indicates the name, firmware version number, and the date and time each firmware module was created. This information may also be useful in troubleshooting and enables you to determine quickly if updated firmware is available to download from the APC Web site.

APC Device IP Configuration Wizard

Purpose and Requirements

Purpose: configure basic TCP/IP settings

You can use the APC Device IP Configuration Wizard to configure the basic TCP/IP settings (IP address, subnet mask, and default gateway) of the following:

• Network Management Cards

• Network-enabled devices (devices that contain embedded Network Management

Cards)

Using the Wizard, you can configure the basic TCP/IP settings of installed or embedded Network Management Cards in either of the following ways:

• Automatically discover and configure unconfigured Network Management Cards or network-enabled devices remotely over your TCP/IP network.

• Configure or reconfigure a Network Management Card or network-enabled device through a direct connection from the serial port of your computer to the device that contains the card.

The Wizard can discover and configure Network Management Cards or devices only if they are on the same network segment as the computer that is running the Wizard.

System requirements

The Wizard runs on Windows 2000, Windows 2003, and Windows XP workstations.

Install the Wizard

To install the Wizard from the Utility CD:

1. If autorun is enabled, the user interface of the CD starts when you insert the

CD. Otherwise, open the file

contents.htm

on the CD.

2. Click

Device IP Configuration Wizard

and follow the instructions.

To install the Wizard from a downloaded executable file:

1. Go to

www.apc.com/tools/download

2. Download the Device IP Configuration Wizard.

3. Run the executable file in the folder to which you downloaded it.

Use the Wizard

Launch the Wizard

The installation creates a shortcut link in the

Start

menu that you can use to launch the

Wizard.

Configure the basic TCP/IP settings remotely

Prepare to configure the settings.

Before you run the Wizard, be sure that you have the information you will need during the configuration procedure:

1. Contact your network administrator to obtain valid TCP/IP settings.

2. If you are configuring multiple unconfigured Network Management Cards or network-enabled devices, obtain the MAC address of each one so that you can identify each Network Management Card or device that the Wizard discovers.

(The Wizard displays the MAC address for a discovered card or device on the same screen on which you then enter the TCP/IP settings.)

• For Network Management Cards that you install, the MAC address is on a label on the bottom of the card.

– For a network-enabled device (with an embedded Network Management Card), the MAC address is on a label on the device — for example, usually on the side of a device that you mount in a rack.

You can also obtain the MAC address from the Quality Assurance slip that came with the Network Management Card or device.

Run the Wizard to perform the configuration.

To discover and configure, over the network, Network Management Cards or network-enabled devices that are not configured:

1. From the

Start

menu, launch the Wizard. The Wizard automatically detects the first Network Management Card or network-enabled device that is not configured.

2. Select

Remotely (over the network)

, and click

Next >

3. Enter the TCP/IP settings (

System IP

Subnet Mask

, and

Default Gateway

) for the unconfigured Network Management Card or network-enabled device identified by the MAC address at the top of the screen. Then click

Next >

. On the

Transmit Current Settings Remotely

screen, if you check-mark

Start a

Web browser when finished

, the default Web browser connects to the

Network Management Card or device after you transmit the settings.

4. Click

Finish

to transmit the TCP/IP settings. If the IP address you entered is in use on the network, the Wizard prompts you to enter an IP address that is not in use. Enter a correct IP address, and click

Finish

5. The Wizard searches for another unconfigured Network Management Card or device. If it finds one, it displays the screen with data entry boxes for the TCP/IP settings of that card or device.

• To skip configuring the Network Management Card or device whose MAC address is currently displayed, click

Cancel

• To configure the TCP/IP settings of the next card, repeat this procedure beginning at step 3.

Configure or reconfigure the TCP/IP settings locally

To configure a single Network Management Card or network-enabled device through a serial connection:

1. Contact your network administrator to obtain valid TCP/IP settings.

2. Remove the lower air filter and rear panel.

3. Connect the RS-232 configuration cable that came with the Network

Management Card or device.

a. Connect one end to an available communications port on your computer. Make sure no other application is using the port.

b. Connect the other end to the serial port of the card or device.

4. From the

Start

menu, launch the Wizard application.

• If the Network Management Card or network-enabled device is not configured, wait for the Wizard to detect it.

• If you are assigning basic TCP/IP settings serially to a Network Management

Card or device, click

Next>

5. Select

Locally (through the serial port)

, and click

Next >

6. Enter the TCP/IP settings (

System IP

Subnet Mask

, and

Default Gateway

) for the Network Management Card or device. Then click

Next >

7. On the

Transmit Current Settings Locally

screen, if you check-mark

Start a

Web browser when finished

, the default Web browser connects to the

Network Management Card or device after you transmit the settings.

8. Switch the main breaker on the front of the electrical panel to

. Wait one second. Switch the main breaker to

If you wait too long to return power to the Cooling Unit, you must repeat step 7.

If the IP address you entered is in use on the network, the Wizard prompts you to enter an IP address that is not in use. Enter a correct IP address, and click

Finish

9. If you selected

Start a Web browser when finished

in step 6, you can now configure other parameters through the Web interface of the card or device.

10. Reinstall the lower air filter, and replace the rear panel

How to Export Configuration Settings

Retrieving and Exporting the .ini File

Summary of the procedure

As an Administrator, you can retrieve a dynamically generated .ini file of the current configuration of the InRow RC and export that file to another InRow RC or to multiple

InRow RCs.

1. Configure the InRow RC to have the settings you want to export.

2. Retrieve the .ini file from that InRow RC.

3. Customize the .ini file (to change at least the TCP/IP settings) and make a copy to export.

4. Use any of the file transfer protocols supported by the InRow RC to transfer the copied file to one or more additional InRow RCs. (To transfer the file to multiple

InRow RCs simultaneously, write an FTP or SCP script that repeats the steps for transferring the file to a single InRow RC.)

5. Each receiving InRow RC stores the file temporarily in its flash memory, uses it to reconfigure its own settings, and then deletes the file.

To create batch files and use an APC utility to retrieve configuration settings from multiple InRow RCs and export them to other InRow

RCs, see Release Notes: ini File Utility, version 1.0 on the Utility CD.

Contents of the .ini file

The config.ini file that you retrieve from the InRow RC contains the following:

• Section headings, which are category names enclosed in brackets ([ ]), and under each section heading, keywords, which are labels describing specific InRow RC settings.

Only section headings and keywords supported for the specific device (in this case the InRow RC) from which you retrieve the file are included.

• Each keyword is followed by an equals sign and the current value for that parameter’s setting, either the default value (if the value has not been specifically configured) or the configured value.

– The Override keyword, with its default value, prevents one or more keywords and their device-specific values from being exported. For example, in the

[NetworkTCP/IP]

section, the default value for Override (the MAC address of the InRow RC) blocks the exporting of the values for the keywords SystemIP,

SubnetMask

, DefaultGateway, and BootMode.

– You must edit the section [SystemDate/Time] to set the system date and time of a receiving InRow RC or cause that InRow RC to use an NTP Server to set its date and time.

See Customizing for configuration guidelines for date and

time settings.

Detailed procedures

Use the following procedures to retrieve the settings of one InRow RC and export them to one or more InRow RCs.

Retrieving.

To set up and retrieve an .ini file to export:

1. Configure the InRow RC with the settings you want to export.

To avoid errors, configure the InRow RC by using its user interface whenever possible. Directly editing the .ini file risks introducing errors.

2. Use FTP to retrieve the file config.ini from the InRow RC you configured: a. Open a connection to the InRow RC, using its IP address. For example: ftp> open 158.165.2.132

b. Log on, using the Administrator user name and password configured for the

InRow RC.

c. Retrieve the config.ini file containing the InRow RC’s current settings: ftp> get config.ini

The file is written to the folder from which you launched FTP.

To create batch files and use an APC utility to retrieve configuration settings from multiple InRow RCs and export them to other InRow

RCs, see Release Notes: ini File Utility, version 1.0 on the Utility CD.

Customizing.

You must customize the file to change at least the TCP/IP settings before you export it. Use a text editor to customize the file.

– Section headings, keywords, and pre-defined values are not case-sensitive, but string values that you define are case-sensitive.

– Use adjacent quotation marks to indicate no value. For example, LinkURL1="" indicates that the URL is intentionally undefined.

– To define values, opening and closing quotation marks are optional, except to enclose values that contain leading or trailing spaces or values which are already

enclosed in quotation marks. (Leading or trailing spaces not within the opening and closing quotation marks are ignored.)

– To export a specific system date and time or any scheduled events, you must configure the values directly in the .ini file.

• To export a specific system time, export only the configured [SystemDate/

Time]

section as a separate .ini file. (The time necessary to export a large file would cause the configured time to be significantly inaccurate.)

• For greater accuracy, if the InRow RCs receiving the file can access a Network

Time Protocol (NTP) Server, set the value for the NTPEnable keyword as follows:

NTPEnable=enabled

– Add comments about changes that you made. The first printable character of a comment line must be a semicolon (;).

– Copy the customized file to another file name in the same folder:

– The copy, which you will export to other InRow RCs, can have any file name up to

64 characters and must have the .ini file suffix.

– Retain the original customized file for future use.

The file that you retain is the only record of your comments.

They are removed automatically from the file that you export.

Transferring the file to a single InRow RC.

To transfer the .ini file to one other

InRow RC, do either of the following:

• From the Web interface of the receiving InRow RC, select the

Administration

tab,

General

on the top menu bar, and

User Config File

on the left navigation menu.

Enter the full path of the .ini file to transfer or use the

Browse

button to identify the location of the .ini file.

• Use any of the file transfer protocols supported by InRow RCs (including FTP, FTP

Client, SCP, and TFTP). The following example uses FTP: a. From the folder containing the customized .ini file and its copy, use FTP to log in to the InRow RC to which you are exporting the .ini file. For example: ftp> open 158.165.4.135

b. Export the copy of the customized .ini file. The receiving InRow RC accepts any file name that has the .ini suffix, is no more than 64 characters in length, and is exported to its root directory.

ftp> put filename.ini

Exporting the file to multiple InRow RCs.

To export the .ini file to multiple InRow

RCs:

• Use FTP or SCP, but write a script that incorporates and repeats the steps used for exporting the file to a single InRow RC.

• Use a batch processing file and the APC .ini file utility.

To create the batch file and use the utility, see Release Notes: ini

File Utility, version 1.0 on the Utility CD.

The Upload Event and Error Messages

The event and its error messages

The following event occurs when the receiving InRow RC completes using the .ini file to update its settings.

Configuration file upload complete, with number valid values

If a keyword, section name, or value is invalid, the event text is extended to include notification of the following errors.

The export to and the subsequent upload by the receiving InRow RC succeeds even if there are errors.

Event text

Configuration file warning: Invalid keyword on line number.

Configuration file warning: Invalid value on line number.

Configuration file warning: Invalid section on line number.

Configuration file warning:

Keyword found outside of a section on line number.

Configuration file warning:

Configuration file exceeds maximum size.

Description

A line with an invalid keyword or value is ignored.

If a section name is invalid, all keyword/value pairs in that section are ignored.

A keyword entered at the beginning of the file (i.e., before any section headings) is ignored.

If the file is too large, the InRow RC stores and processes what it can, but ignores what it cannot.

Reduce the size of the file, or divide it into two files, and try uploading again.

Errors generated by overridden values

The Override keyword and its value will generate error messages in the event log when it blocks the exporting of values.

See

Contents of the .ini file

for information about which values are overridden.

The overridden values are device-specific and not appropriate to export to other InRow

RCs. Therefore, you can ignore these error messages. To prevent these error messages from occurring, you can delete the lines that contain the Override keyword and the lines that contain the values that they override. Do not delete or change the line containing the section heading.

Using the APC Device IP Configuration Wizard

On Windows operating systems, instead of using the preceding procedure for transferring .ini files, you can choose to update the basic TCP/IP settings of InRow RCs by using the APC Device IP Configuration Wizard.

See

APC Device IP Configuration Wizard for a detailed description of

how to discover and configure the basic TCP/IP settings of unconfigured InRow RCs remotely over your TCP/IP network. This section will also tell you how to configure or reconfigure one InRow RC through a direct connection from the serial port of your computer to the

InRow RC.

File Transfers

Overview

The InRow RC automatically recognizes binary firmware files. Each of these files contains a header and one or more Cyclical Redundancy Checks (CRCs) to ensure that the data contained in the file is not corrupted before or during the transfer operation.

When new firmware is transmitted to the InRow RC, the program code is updated and new features become available.

This chapter describes how to transfer firmware files to the InRow RC.

To verify a file transfer, see

Verifying Upgrades and Updates .

Upgrading Firmware

Benefits of upgrading firmware

Upgrading the firmware on the InRow RC has the following benefits:

• New firmware has the latest bug fixes and performance improvements.

• New features become available for immediate use.

• Keeping the firmware versions consistent across your network ensures that all InRow

RCs support the same features in the same manner.

Firmware files (InRow RC)

A firmware version consists of two modules: An APC Operating System (AOS) module and an application module.

The APC Operating System (AOS) and application module files used with the InRow

RC share the same basic format: apc_hardware-version_type_firmware-version.bin

–

apc

: Indicates that this is an APC file.

– hardware-version: hw0x identifies the version of the hardware on which you can use this binary file.

– type: aos if the file is the APC Operating System (AOS) module, or acrp if the file is the application module for the InRow RC.

– version: The version number of the application file.

– bin: Indicates that this is a binary file.

Obtain the latest firmware version

Automated upgrade tool for Microsoft Windows systems.

An automated self-extracting executable tool combines the firmware modules that you need to automate your upgrades on any supported Windows operating system. You can obtain the latest firmware version of the tool at no cost. At the support section of the APC web site

www.apc.com/tools/download

, find the latest firmware release for your APC product (in this case, your InRow RC) and download the automated tool.

Each upgrade tool is specific to an APC product type. If you use a version of the tool from the APC Web site, make sure that you use the upgrade tool that corresponds with your APC product type.

Manual upgrades, primarily for Linux systems.

If all computers on your network are running Linux, you must upgrade the firmware of the InRow RCs manually, i.e., by using the separate APC firmware modules (AOS module and application module).

If you have a networked computer running a supported Microsoft

Windows operating system on your network, you can use the tool

described in Automated upgrade tool for Microsoft Windows systems

to upgrade the firmware of the InRow RC automatically over the network. This tool automates the entire upgrade process.

You can obtain the individual firmware modules you need for a manual firmware upgrade by extracting them from the automated tool.

Firmware file transfer methods

To upgrade the firmware of the InRow RC:

• From a networked computer running a Microsoft Windows operating system, you can use the automated firmware upgrade tool on your CD or downloaded from the APC

Web site.

• From a networked computer on any supported operating system, you can use FTP or

SCP to transfer the individual AOS and application firmware modules.

• For the InRow RC that is not on your network, you can use XMODEM through a serial connection to transfer the individual AOS and application firmware modules from your computer to the InRow RC.

When you transfer individual firmware modules and do not use the automated firmware upgrade tool to upgrade the firmware for the

InRow RC, you must transfer the AOS module to the InRow RC before you transfer the application module.

For more information about the firmware modules, see Firmware files (InRow RC) .

Use FTP or SCP to upgrade one InRow RC

Instructions for using FTP.

For you to be able to use FTP to upgrade a single InRow

RC over the network:

• The InRow RC must be connected to the network.

• The FTP server must be enabled at the InRow RC.

• The InRow RC must have its TCP/IP settings (

System IP

Subnet Mask

, and

Default Gateway

addresses) configured.

To use FTP to upgrade the InRow RC:

1. Open an MS-DOS command prompt window on a computer that is connected to the network. Go to the directory that contains the firmware upgrade files, and list the files. For the directory C:\apc, the commands would be those shown in

bold

C:\>

cd \apc

C:\apc>

dir

Files listed for the InRow RC, for example, might be the following (with xxx representing the version number of each file):

–apc_hw03_aos_

xxx

.bin

–apc_hw03_acrc_

xxx

.bin

2. Open an FTP client session:

C:\apc>

ftp

3. Type open and the InRow RC’s IP address, and press

NTER

. If the

port

setting for the FTP Server (accessible through the

Administration

tab,

Network

on the top menu bar, and

FTP Server

on the left navigation menu) has changed from its default of

21

, you must use the non-default value in the

FTP command.

a. For some FTP clients, use a colon to add the port number to the end of the IP address.

b. For Windows FTP clients, separate the port number from the IP address by a space. For example, if the InRow RC’s

FTP Server Port

setting has been changed from its default of

21

, such as to

21000

, you would use the following command for a Windows FTP client transferring a file to the InRow RC with an

IP address of 150.250.6.10.

ftp>

open 150.250.6.10 21000

4. Log on using the Administrator user name and password. (

apc

is the default for both.)

5. Upgrade the AOS. (In the put command in the following example, xxx is the firmware version number, with no periods separating the digits:) ftp>

bin

ftp>

put apc_hw03_aos_xxx.bin

6. When FTP confirms the transfer, type

quit

to close the session.

7. Wait 20 seconds, and then repeat step 2 through step 5, but in step 5, use the application module file name instead of the AOS module.

Instructions for using SCP.

To use Secure CoPy (SCP) to upgrade the firmware for one InRow RC:

1. Identify and locate the firmware modules described in the preceding instructions for FTP.

2. Use an SCP command line to transfer the AOS firmware module to the InRow

RC. The following example assumes an InRow RC IP address of

158.205.6.185, and an AOS module of

apc_hw03_aos_xxx.bin

. (with xxx representing the version number of the AOS module, with no periods separating the digits).

scp apc_hw03_aos_xxx.bin [email protected]:apc_hw03_aos_xxx.bin

3. Use a similar SCP command line, with the name of the application module instead of the AOS module, to transfer the application module to the InRow RC.

Upgrade multiple InRow RCs

Export configuration settings.

You can create batch files and use an APC utility to retrieve configuration settings from multiple InRow RCs and export them to other

InRow RCs.

See Release Notes: ini File Utility, version 1.0 on the Utility CD.

Use FTP or SCP to upgrade multiple InRow RCs.

To upgrade multiple InRow RCs using an FTP client or using SCP, write a script which automatically performs the procedure. For FTP, use the steps in

Use FTP or SCP to upgrade one InRow RC in the

script.

Use XMODEM to upgrade one InRow RC

To use XMODEM to upgrade the firmware for a single InRow RC that is not on the network:

1. Obtain the individual firmware modules (the AOS module and the application module) from

www.apc.com/tools/download

2. Select a serial port at the local computer and disable any service which uses that port.

3. Connect the RS-232 configuration cable (APC part number 940-0103A) that came with the InRow RC to the selected port and to the serial port at the InRow

RC.

4. Run a terminal program (such as HyperTerminal), and configure the selected port for 9600 bps, 8 data bits, no parity, 1 stop bit, no flow control, and save the changes.

5. Press

NTER

twice to display the

User Name

prompt.

6. Enter the Administrator user name and password (

apc

by default for both).

7. From the

Control Console

menu, select

System

, then

Tools

, then

File

Transfer

, then

XMODEM

; and type Yes at the prompt to continue.

8. At the prompt for the baud rate, enter an appropriate baud rate for the terminal program to use for the transfer. A higher baud rate causes faster firmware upgrades.

Allowed values are 2400, 9600, 19200, and 38400. To choose a baud rate different from your current connection, disconnect from the terminal session. Configure the selected port for the desired baud rate and reconnect the terminal session.

Press

NTER

. The screen displays uppercase C, indicating transfer mode.

9. From the terminal program’s menu, select the binary AOS file to transfer via

XMODEM-CRC. After the XMODEM transfer is complete, set the baud rate to

9600 (if you selected a different rate in step 8). The InRow RC automatically restarts.

10. Repeat step 4 through step 9 to install the application module. In step 9, use the application module file name, not the AOS module file name.

For information about the file name format used for application modules, see

Firmware files (InRow RC)

Verifying Upgrades and Updates

Overview

To verify that the firmware upgrade was successful, see the

Last Transfer Result

message, available through the

FTP Server

option of the

Network

menu (in the control console only), or use an SNMP GET to the

mfiletransferStatusLastTransferResult

object identifier (OID).

Last transfer result codes

Code Description

Successful

Result not available

Failure unknown

Server inaccessible

The file transfer was successful.

There are no recorded file transfers.

The last file transfer failed for an unknown reason.

The TFTP or FTP server could not be found on the network.

Server access denied The TFTP or FTP server denied access.

File not found The TFTP or FTP server could not locate the requested file.

File type unknown

File corrupt

The file was downloaded but the contents were not recognized.

The file was downloaded but at least one Cyclical Redundancy

Check (CRC) failed.

Use the Web interface to verify the versions of the upgraded AOS and application modules by selecting the

Administration

tab,

General

on the top menu bar, and

Factory Info

on the left navigation menu, or use an SNMP GET to the MIB II

sysDescr

OID.

Product Information

One-Year Factory Warranty

The limited warranty provided by American Power Conversion Corporation (APC

) in this Statement of Limited Factory Warranty applies only to Products you purchase for your commercial or industrial use in the ordinary course of your business.

Terms of warranty

American Power Conversion warrants its products to be free from defects in materials and workmanship for a period of one year from the date of purchase. The obligation of

APC under this warranty is limited to repairing or replacing, at its sole discretion, any such defective products. This warranty does not apply to equipment that has been damaged by accident, negligence or misapplication or has been altered or modified in any way. Repair or replacement of a defective product or part thereof does not extend the original warranty period. Any parts furnished under this warranty may be new or factory-remanufactured.

Non-transferable warranty

This warranty extends only to the original purchaser who must have properly registered the product. The product may be registered at the APC Web site, www.apc.com.

Exclusions

APC shall not be liable under the Warranty if its testing and examination discloses that the alleged defect in the product does not exist or was caused by your or any third person’s misuse, negligence, improper installation or testing, unauthorized attempts to repair or modify, or any other cause beyond the range of the intended use, or by accident, fire, lightning or other hazard.

T

HERE ARE NO WARRANTIES

,

EXPRESSED OR IMPLIED

,

BY OPERATION OF LAW

OR OTHERWISE

,

OF PRODUCTS SOLD

,

SERVICED OR FURNISHED UNDER THIS

AGREEMENT OR IN CONNECTION HEREWITH

. APC

DISCLAIMS ALL IMPLIED

WARRANTIES OF MERCHANTABILITY

,

SATISFACTION AND FITNESS FOR A

PARTICULAR PURPOSE

. T

APC

EXPRESS WARRANTIES WILL NOT BE

ENLARGED

,

DIMINISHED

,

OR AFFECTED BY AND NO OBLIGATION OR LIABILITY

WILL ARISE OUT OF

APC

RENDERING TECHNICAL OR OTHER ADVICE OR SERVICE

IN CONNECTION WITH THE PRODUCTS

. T

HE FOREGOING WARRANTIES AND

REMEDIES ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES AND

REMEDIES

. T

HE WARRANTIES SET FORTH ABOVE

,

CONSTITUTE SOLE LIABILITY

APC

AND YOUR EXCLUSIVE REMEDY FOR ANY BREACH OF SUCH

WARRANTIES

. THE

WARRANTIES

EXTEND

ONLY TO YOU AND ARE NOT

EXTENDED TO ANY THIRD PARTIES

.

I

N NO EVENT SHALL

APC,

ITS OFFICERS

,

DIRECTORS

,

AFFILIATES OR EMPLOYEES

BE LIABLE FOR ANY FORM O

F

INDIRECT

,

SPECIAL

,

CONSEQUENTIAL OR PUNITIVE

DAMAGES ARISING OUT OF THE USE

,

SERVICE OR INSTALLATION OF THE

PRODUCTS

,

WHETHER SUCH DAMAGES ARISE IN CONTRACT OR TORT

,

IRRESPECTIVE OF FAULT

,

NEGLIGENCE OR STRICT LIABILITY OR WHETHER

APC

HAS BEEN ADVISED IN ADVANCE OF THE POSSIBILITY OF SUCH DAMAGE

.

Warranty Claims

Customers with warranty claims issues may access the APC customer support network through the Support page of the APC Web site, www.apc.com/support. Select your country from the country selection pull-down menu at the top of the Web page. Select the Support tab to obtain contact information for customer support in your region.

To determine which factory warranty applies to the APC product you purchased, consult the factory warranties located on the APC website, www.apc.com.

APC Worldwide Customer Support

Customer support for this or any other APC product is available at no charge in any of the following ways:

• Visit the APC Web site to access documents in the APC Knowledge Base and to submit customer support requests.

–

www.apc.com

(Corporate Headquarters)

Connect to localized APC Web sites for specific countries, each of which provides customer support information.

–

www.apc.com/support/

Global support searching APC Knowledge Base and using e-support.

• Contact the

APC

Customer Support Center by telephone or e-mail.

– Local, country-specific centers: go to

www.apc.com/support/contact

for contact information.

For information on how to obtain local customer support, contact the APC representative or other distributors from whom you purchased your APC product.

Copyright

Entire contents copyright 2008 American Power Conversion Corporation. All rights reserved. Reproduction in whole or in part without permission is prohibited. APC, the APC logo, InfraStruXure, and InRow are trademarks of

American Power Conversion Corporation. All other trademarks, product names, and corporate names are the property of their respective owners and are used for informational purposes only.

990-3408

9/2008

Thank you for your participation!

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project

Schneider Electric 操作和維護 InRow® RD 氣冷式 ACRD100 ACRD101 ユーザーガイド

Schneider Electric 运行与维护 InRow® RD 液冷 ACRD200 ACRD201 ユーザーガイド

Schneider Electric 操作和維護 InRow® RD 液冷式產品 ACRD200 ACRD201 ユーザーガイド

Schneider Electric InRow RD 100-Series and InRow RD 200-Series Users Guide

APC ACRC500 Power Supply User Manual

InRow RC中文操作手册

Schneider Electric 操作和維護 InfraStruXure® InRow SC ユーザーガイド

Schneider Electric InRow RC ACRC500 Series ユーザーガイド
