2016 MOUNTING EqUIpMENT CATALOG

2016 MOUNTING EqUIpMENT CATALOG

MOUNTING EqUIpMENT

3001 Borham Ave.

Stevens Point, WI 54481

Phone toll-free: 800.741.4530

Fax: 715.344.5209

Fax toll-free: 800.934.3577

email: [email protected]

www.gamberjohnson.com

Your Local Gamber-Johnson Reseller:

Follow us on:

An ISO 9001:2008 Certified Company

CATALOG pMENT 2016 MOUNTING EqUI

GRIP

2016 MOUNTING EqUIpMENT CATALOG

ExCEpTIONAL ENGINEErING | rOCk sOLId | ExTENsIvE TEsTING

CATALOG pMENT 2016 MOUNTING EqUI

TABLE OF CONTENTS

An ISO 9001:2008

CERTIFIED COmpAny.

GAMBER-JOHNSON MOUNTING SYSTEMS

Gamber-Johnson is a global market leader of rugged docking stations and vehicle mounts, and a member of the Leggett & Platt Commercial

Vehicle Products (CVP) Group. Our extensive line of modular products can be mixed and matched to create a safe and comfortable mobile office for just about any fleet vehicle. Gamber-Johnson makes specific computer mounts and docking stations for Panasonic, Getac,

Motorola, Dell and Samsung.

TABLE OF CONTENTS

Guide to Gamber-Johnson

Hole Patterns RoHS/WEEE

Mounting Systems Air Bag Safety

Markets

Vehicle Bases

2-7

8-23

Vehicle Base Reference Guide 10-11

Poles

Complete Poles

Upper Poles

Accessories

Motion Attachments

Lower Tubes

24-27

Low Profile Brackets

28-33

Mission Control System (MCS Series) 34-59

Vehicle Leg Kits Console Boxes

Top Plates Accessories

Trunk Mounting Shelves Faceplate Guide

Mobile Workstations 60-61

Material Handling 62-69

Keyboard/Printer Mounts 70-73

Cradle and Docking Stations 74-97

Universal Computer Mounts Panasonic

Accessories Motorola

Dell

Getac

Power Distribution & Wiring Harnesses 98-106

MAX

3

Index

107-109

110-112

COMMITMENT TO QUALITY

It is the Quality Policy of Gamber-Johnson LLC to provide products and services that meet or exceed our customer’s expectations. This commitment is achieved through compliance to our quality program, pursuit of continual improvement and quality stewardship among all associates.

Our quality in product integrity is forged through our focus on developing the best mounting systems and docking stations for efficient use in a mobile workforce environment. We design products that reflect the changing trends and market demands. The result is leading innovation and long-lasting, dependable products.

Gamber-Johnson has teamed with partners, resellers and installers in multiple markets to further extend our service to you. Through them we can provide customers instant access to Gamber-Johnson products, expert knowledge and quality installation no matter where you are located. Visit our website for a complete list of our authorized resellers.

STAY SOCIAL: JOIN THE CONVERSATION

Connect with us for the latest information and news by liking us on Facebook, watching us on YouTube or following us on Twitter and LinkedIn. Thank you for being a part of our social community.

This catalog, including images, may not be reproduced partly or fully without the expressed written consent of Gamber-Johnson’s marketing department.

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

1

2

LIMITED LIFETIME WARRANTY

Gamber-Johnson warrants to the reseller and the original end user of any Gamber-Johnson product that it will be free from defects in materials and workmanship for the warranty time period.

The remedies for a defect in material or workmanship are limited to repair or replacement of any nonconforming product. Gamber-

Johnson will repair or replace, without charge, any Gamber-Johnson product that does not conform to its warranty only if a reseller or an original end user gives us notice of a defect in material or workmanship within the warranty time period stated below:

Mounting Systems (non-electronic products) – All non-electronic products purchased after Dec. 31st, 2009 are protected by Gamber-

Johnson's limited lifetime warranty. For any warranty related issues of products purchased prior to Dec. 31st 2009, please contact your

Gamber-Johnson authorized reseller. All MAX3 products come with a standard one year product warranty.

Mobile Docking Stations & Electronic Products – Warranty time period (from date of original factory shipment) may vary. Please see individual specifications on these products for further warranty information.

Specific 3rd Party Supplied Products – For all products purchased through Gamber-Johnson that are supplied from a 3rd party company

(i.e. iKey, Brother, Lind, MNSTAR, etc.) are warranted by the specific manufacturer of that product. Please see individual specifications on these products for further warranty information.

To obtain specific warranty time periods please visit our online Warranty page found on under the Product Support tab.

Any failure of any Gamber‐Johnson product that is due to damage or misuse, such as excessive force, improper installation, cosmetic wear or application of power in excess of specified ratings is not covered by this warranty. The warranty is void on electronic products if the warranty label is removed or altered.

GAMBER‐JOHNSON WILL NOT BE RESPONSIBLE FOR ANY

INCIDENTIAL, CONSEQUENTIAL (INCLUDING LOSS OF BUSINESS

OR PROFITS) OR PUNITIVE DAMAGES DUE TO FAILURE OF A

GAMBER‐JOHNSON PRODUCT. INCIDENTAL, CONSEQUENTIAL

AND PUNITIVE DAMAGES ARE EXCLUDED FROM THIS LIMITED

WARRANTY. THE FOREGOING WARRANTY IS A LIMITED WARRANTY.

THERE ARE NO OTHER WARRANTIES, EXPRESS OR IMPLIED,

WHICH EXTEND BEYOND THE DESCRIPTION OF THE WARRANTIES

ON THE FACE HEREOF INCLUDING BUT NOT LIMITED TO THE

IMPLIED WARRANTIES OF FITNESS AND MERCHANTABILITY.

For warranty concerns or questions, please contact Gamber-Johnson at 800-456-6868.

Return Materials Authorization (RMA)/Return Policy

Return for Repair (RFR) - An RMA number must be obtained from

Gamber-Johnson prior to the return of any product for Warranty and

Non-Warranty repairs. For non-warranty repairs, a diagnostic fee will be charged per docking station. The fee will be included in the quoted cost for repair. If the customer decides not to repair the unit, only the diagnostic fee will be billed to the customer. Customer approval and payment arrangements for repairs must be received within 60 days of quotation of all non-warranty products. If approval and/or payment arrangement is not provided to Gamber-Johnson, the unrepaired product(s) will be shipped back to the customer at their expense.

Warranty Claim Returns – In order to return a product covered under the Gamber-Johnson Limited Lifetime Warranty an RMA number must be obtained from Gamber-Johnson. The Gamber-Johnson Receiving

Department cannot accept returns without an RMA number. If a return arrives to Gamber-Johnson without a RMA number, the package(s) will be refused and shipped back at the customer’s expense. Please package the product with a note detailing the failure and indicate where and when the unit was purchased.

Upon receiving the equipment, Gamber-Johnson will perform diagnostics to determine the cause of product failure. If the unit is covered under warranty, the unit will be repaired and returned to you.

If it is determined that the repairs are not covered under warranty,

Gamber-Johnson will notify you with the findings and cost to perform the repairs. If we do not receive a payment arrangement or a response from you within 60 days of the issuance of the quote, Gamber-Johnson will return the product unrepaired at the customer’s expense.

To obtain an RMA number, please visit our online RMA submission form found on under the Product Support tab.

Repair Warranty

Repairs completed by Gamber-Johnson are warranted for a period of 90 days from completion of repair (unless otherwise specifically stated) or the balance of the warranty remaining on the product; whichever is longer. All other terms and conditions remain the same as set forth in the warranty above.

GAMBER-JOHNSON HOLE PATTERNS

4.09”

2.0”

Gamber-Johnson Hole Pattern

The Gamber-Johnson Hole Pattern is a 2x4 pattern specific to Gamber-

Johnson products.

Where Used: You will find the Gamber-Johnson Hole Pattern on newer

Gamber-Johnson docking station, cradles and motion attachments. It is used to mount the motion attachment to the docking station or cradle.

100 mm

75 mm

VESA 75mm & 100mm Hole Pattern

The VESA 75mm and 100mm Hole Pattern is part of a family of standards as defined by the Video Electronics Standards Association for mounting flat panel monitors, TVs, and other displays to stands or wall mounts. VESA

Pattern consists of four screws arranged in a square, with the horizontal and vertical distance between the screw centers.

Where Used: You will find VESA 75mm Hole Pattern on newer Gamber-

Johnson docking stations (Panasonic GI, M1, Getac F110, T800, on MAX3

VESA Device Mounting plate) and on certain motion attachments used to mount displays (i.e. any Clam Shell for Material Handling or on the Universal

Adapter Plate).

30mm

38mm

Gamber-Johnson

“Smiley Faced” Hole Pattern

The Gamber-Johnson “Smiley Faced”

Hole pattern is a specific pattern to

Gamber-Johnson products that allows for swivel.

Where Used: You will find the Gamber-

Johnson “Smiley Faced” Hole Pattern on most upper poles (i.e. DS-UPPER,

QADJ-UPPER-M, etc…) and a few console boxes (i.e. Dodge Charger

Specific Consoles, Low Profile Ergonomic

Console, MCS-COMBRKT, etc…). It is used to mount a motion attachment to the upper pole or console box and allow for swivel capabilities.

AMPS Hole Pattern

Most electronics manufacturers have adopted a common hole pattern for mounting their devices. This pattern is often called an AMPS hole pattern. This is a rectangular pattern measuring 30 X 38mm.

Where Used: You will find the AMPS

Hole Pattern on certain Gamber-

Johnson docking stations (Panasonic

X1/E1), on MAX3 Round Mounting plates, and on certain motion attachments used to mount displays

(i.e. any Clam Shell for Material

Handling or on Clevis models like

7160-0162).

40mm

NEC Triangle Hole Pattern

Electronics manufacturers have adopted a common hole pattern for mounting their devices. This pattern is often called a NEC

Triangle hole pattern. This is a triangle pattern measuring 40mm on each side.

Most often the NEC and AMPS pattern are found on the same mounting device.

Where Used: You will find the NEC Hole

Pattern on certain Gamber-Johnson docking stations (Panasonic X1/E1), on MAX3 Round Mounting plates, and on certain motion attachments used to mount displays (i.e. any Clam Shell for

Material Handling or on Clevis models like

7160-0162).

3

GUIDE TO GAMBER- JOHNSON

MOUNTING SYSTEMS

For years, Gamber-Johnson has been known for the modular design of our mounting systems. Unlike other competitive models, our components easily mix-and-match to fit your needs. In fact, Gamber-Johnson has the widest variety of stocked products, accessories and options in the industry to make configuring your mounting system that much easier and faster. Our system proves to be especially helpful in future years when your vehicle or computer/communications mounting needs may change.

STANDARD MOUNTING SYSTEMS

Together, products from the categories listed below combine to make our standard mounting systems.

Vehicle Bases

The vehicle base secures the entire mounting system to the vehicle. All of our bases are constructed of heavy-duty steel for long-lasting use. Some vehicle bases require drilling while some do not. If a lower tube is not already welded to the vehicle base, you will need to order it separately.

OR

Mission Control System (MCS Series)

The MCS mounting system is generally used in the public safety industry.

It is primarily favored for mounting multiple radios and equipment low and out of the air bag zone. You can also easily integrate computer mounts on these bases by attaching a pole assembly.

OR

Mobile Workstations

Mobile Workstations are generally used in the utility industry. They consist of a center console system with a computer platform and/or a locking storage space for devices and supplies. You can easily integrate computer mounts on the computer platform by attaching any motion attachment.

Poles

Together the lower tubes and upper poles offer varying height and distance of the computer system. There are also several accessories that solve problems from quick-release to vibration.

Motion Attachments

Motion Attachments join the Upper Pole and Cradle or Docking Stations to provide tilting, swiveling, sliding and extending capability.

Cradle and Docking Stations

The NotePad™ universal computer mount is the preferred solution for safely securing laptop computers in vehicles. It adjusts to fit the width, depth and thickness dimensions of virtually any laptop, sub-notebook or pen computer available. Products that provide regulated voltage and additional ports can be combined with the NotePad™ universal computer mount to provide greater computing capabilities while on the road.

Specific rugged mobile computer solutions and docking stations for

Panasonic, Getac, Motorola, Samsung and Dell are full-featured and designed specifically for in-vehicle use.

Keyboard/Printer Mounts

Offering several peripheral mounts to complete your mounting system.

INSTALLATION

Gamber-Johnson designs our vehicle bases to be attached two different ways. Most of our vehicle bases install using the existing seat studs in the vehicle. This design allows for a clean and secure installation and eliminates the need for drilling holes. Some other bases require drilling holes into the mounting surface to secure the bases. Please check the specifications of each base before ordering to determine if drilling is required or not.

AIR BAG SAFETY

Gamber-Johnson strongly recommends that all Gamber-Johnson product, and the computers and/or equipment mounted on them, be installed safely out of a vehicle’s Air Bag Zone. Our products are “Air

Bag Safe” if, and only if, the installation provider installs the products in conformance with the instructions and vehicle manufacturer’s specifications for after-market equipment installation. If these products are not installed properly, they may interfere with the deployment of an air bag thereby preventing the air bag from operating properly and/ or causing injury. Gamber-Johnson advises that you consult with your installation provider in advance and specifically state the location where you want your mounting system installed.

THINKING GREEN: ROHS, WEEE,

AND OTHER ENVIRONMENTAL PROGRAMS

Gamber-Johnson is committed to protecting and preserving the environment and being a responsible global corporate citizen. We are dedicated to complying with the requirements of all applicable environmental legislation and regulations wherever our products are marketed or sold including initiatives adapted by the

European Union, known as RoHS and WEEE.

4

Example 1 Example 2 Example 3

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

MARkETS: PUBLIC SAFET y

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

5

MARkETS: ENTERPRISE / UTILIT y

6

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

MARkETS: MATERIAL HANDLING

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

7

VEHICLE BASES

8

7160-0510

Page 20

INSTALLED IN A CHEVROLET

SILVERADO/TAHOE

Recommended Solution

DS-LOWER-9 (pg. 25)

Center Upper Pole

(7160-0178) (pg. 25)

9" Locking Slide Arm – Mongoose

(7160-0220) (pg. 28)

Support Brace (7160-0230) (pg. 27)

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

VEHICLE BASES

7160-0281

INSTALLED IN A FORD

F-250 TO F-750 SUPER DUTY

Recommended Solution

DS-LOWER-9 (pg. 25)

Center Upper Pole (7160-0178) (pg. 25)

9" Locking Slide Arm – Mongoose

(7160-0220) (pg. 28)

Support Brace (7160-0230) (pg. 27) pAgE 20 pAgE 21

7160-0350

INSTALLED IN A FORD SEDAN/UTILITY

POLICE INTERCEPTOR

Recommended Solution

DS-LOWER-9 (pg. 25)

Center Upper Pole (7160-0178) (pg. 25)

9" Locking Slide Arm – Mongoose

(7160-0220) (pg. 28)

Support Brace (7160-0230) (pg. 27) pAgE 23

7160-0537

INSTALLED IN A FORD TRANSIT

Recommended Solution

DS-LOWER-9 (pg. 25)

Center Upper Pole (7160-0178) (pg. 25)

6" Locking Slide Arm (7160-0500) (pg. 28)

Support Brace (7160-0230) (pg. 27)

7160-0510

INSTALLED IN A CHEVROLET

SILVERADO/TAHOE

Recommended Solution

DS-LOWER-9 (pg. 25)

Center Upper Pole (7160-0178) (pg. 25)

9" Locking Slide Arm – Mongoose

(7160-0220) (pg. 28)

Support Brace (7160-0230) (pg. 27) pAgE 22 pAgE 21

7160-0329

INSTALLED IN A DODGE CHARGER

Recommended Solution

DS-LOWER-13 (pg. 25)

Center Upper Pole (7160-0178) (pg. 25)

9" Locking Slide Arm – Mongoose

(7160-0220) (pg. 28)

Support Brace (7160-0230) (pg. 27) pAgE 22

7160-0527

pAgE 23

INSTALLED IN A RAM PROMASTER

Recommended Solution

DS-LOWER-7 (pg. 25)

Center Upper Pole (7160-0178) (pg. 25)

6" Locking Slide Arm (7160-0500) (pg. 28)

Support Brace (7160-0231) (pg. 27)

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

9

10

VEHICLE BASE REFERENCE GUIDE

The Vehicle Base Reference Guide makes it easy to identify which vehicle base is compatible with your vehicle.

If there is not a vehicle base listed or if you can’t find a particular make, model or year on the chart, please contact our sales department at

1-800-456-6868 or at [email protected] For the most up-to-date product information, visit our website at

www.gamberjohnson.com

.

Make

Chrysler

Dodge

Freightliner

Ford

Model

Chevrolet

1500 C/K - 4WD-SELECTOR ON HUMP ONLY

1500/2500/3500 C/K

1500/2500/3500 C/K

AVALANCHE

AVALANCHE

CAPRICE

CAPRICE

CITY EXPRESS VAN

COLORADO

COLORADO

EQUINOX

EQUINOX

EXPRESS VAN

EXPRESS VAN

G-SERIES VAN

G-SERIES VAN

IMPALA

IMPALA (CIVILAN MODEL)

MALIBU

MALIBU

SILVERADO

SILVERADO

SILVERADO (1500 Models)

SILVERADO 2500/3500/HD

SUBURBAN

SUBURBAN

SUBURBAN

TAHOE

TAHOE

TAHOE

UPLANDER

ASPEN

TOWN & COUNTRY

AVENGER

CARAVAN

RAM C/V

CHARGER

CHARGER

CHARGER

DAKOTA

DAKOTA

DURANGO

DURANGO

MAGNUM

MAGNUM

NITRO

PROMASTER

RAM 1500

RAM 1500

RAM 2500/3500

RAM 2500/3500

RAM 4500/5500

RAM 4500/5500

SPRINTER

SPRINTER (w/ bucket seats)

M2 106

M2 112

UNIVERSAL

CROWN VICTORIA/POLICE INTERCEPTOR

POLICE INTERCEPTOR- SEDAN

POLICE INTERCEPTOR- UTILITY

ESCAPE

ESCAPE

E-SERIES VAN

E-SERIES VAN

E-SERIES - CUT AWAYS

EXCURSION

EXCURSION LIMITED

EXPEDITION

EXPEDITION

Year

No Drilling

Required

(1994-1999)

(1999-2006 & 2007 Classic Body Style) DS-122

(2007 -2009)

(2002-2006)

(2007-2013)

DS-144

DS-122

DS-144

(2011-2013)

(2014-2016)

(2015-2016)

(2004-2012)

(2015-2016)

(2007-2009)

(2010-2016)

(1995-2009)

(2010-2016)

(1995-2009)

(2010-2016)

7160-0381

7160-0532

7160-0557

7160-0114

7160-0556

7160-0572

7160-0133

7160-0248

7160-0133

7160-0248

(2006-2013 & 2015-2016 PPV Only) 7160-0055

(2014-2015)

(2006-2012)

(2013-2016)

7160-0520

7160-0222

7160-0520

(1999-2006 & 2007Classic Body Style) DS-122

(2007 New Body Style-2014)

(2014-2016)

(2015)

DS-144

7160-0510

7160-0510

(2000-2006)

(2007 New Body Style-2014)

(2015-2016)

(2000-2006)

(2007 New Body Style-2014)

(2015-2016)

(2005-2009)

(2007-2009)

DS-122

DS-144

7160-0510

DS-122

DS-144

7160-0510

(2008-2014)

(2008-2015)

(2008-2016)

(2012-2016)

(2006)

(2007-2010)

(2011-2016)

(1997-2004 & 2007-2011)

(2005)

(2011-2016)

(1997-2003)

(2006)

(2007-2008)

(2007-2011)

(2014-2016)

(2002-2016)

(2011-2016)

(2003-2016)

(2011-2016)

(2007-2016)

(2011-2016)

(2004-2009)

(2004-2016)

(2012-2016)

(2012-2016)

ALL YEARS

(1991-2011)

(2012-2016)

(2012-2016)

(2002-2012)

(2013-2016)

(1995-2005)

(2006-2014)

(2006-2016)

(2000-2005)

(2000-2005)

(1997-2006)

(2007-2016)

DS-132

7160-0116

7160-0256

7160-0116

7160-0116

7160-0008

7160-0329

7160-0013

7160-0323

7160-0013

7160-0008

DS-148

7160-0527

7160-0182

7160-0182

7160-0182

7160-0036

7160-0036

7160-0544

7160-0544

7160-0234

7160-0350

7160-0350

DS-140

7160-0451

7160-0133

7160-0090

7160-0090

7160-0045

DS-112

7160-0046

Page

W

14

20

20

16

21

W

21

23

16

18

16

18

W

14

20

W

14

20

W

16

W

16

16

W

21

23

W

W

14

W

14

22

W

19

W

19

W

W

W

21

17

17

17

18

20

20

W

20

16

16

16

15

15

15

22

22

W

15

Drilling

Required

DS-55

7160-0185

7160-0185

7160-0185

7160-0185

7160-0185

DS-146

7160-0185

Page

12

17

17

17

17

17

14

17

Vehicle Legs

(MCS)

7110-0350

7160-0160

7160-0160

7160-0160

7160-0160

7160-0249

7110-0350

7110-0350

7110-0350

7110-0350

7110-0350

7160-0121

7110-0350

7160-0160

7160-0509

7160-0509

7160-0160

7160-0160

7160-0509

7160-0160

7160-0160

7160-0509

7110-0350

7110-0350

7110-0350

7110-0350

7110-0350

7160-0088

7160-0088

7160-0088

7110-0350

7110-0350

7110-0350

7160-0088

7160-0088

7160-0422

7160-0422

7160-0422

7110-0350

7110-0350

7160-0545

7160-0545

7110-0350

7160-0117

7160-0413

7160-0413

7110-0350

7110-0350

7110-0350

7160-0350

7160-0054

7160-0054

7110-0350

7160-0084

Page

42

42

42

42

42

W

42

42

42

42

42

42

42

42

42

W

W

42

42

42

42

42

61

61

42

W

42

42

42

42

42

42

42

42

42

42

42

42

42

42

42

42

42

42

42

42

42

42

42

42

42

42

42

42

W = Web Listing Only

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

VEHICLE BASE REFERENCE GUIDE

Make Model

EXPLORER

EXPLORER

EXPLORER

EXPLORER SPORT TRACK

F-150

F-150 HERITAGE

F-150 (New Body Style)

F-150 (Aluminum Body)

F-150

F-150

Year

(1995-2001)

(2002-2010)

(2011-2016)

(2007)

(1997-2003)

(2004)

(2004-2014)

(2015-2016)

(2004-2008)

(2009-2014)

No Drilling

Required

DS-118

DS-114

7160-0350

DS-114

DS-112

DS-112

DS-124

7160-0554

F-250 LIGHT DUTY (1997-2004) DS-112

F-250, F-350, F-450, F-550, F-750 SUPER DUTY (1999-2010 AUTOMATICS ONLY) 7160-0045

F-250, F-350, F-450, F-550, F-750 SUPER DUTY

FIVE HUNDRED

(2011-2016)

(2005-2007)

7160-0281

7160-0009

FLEX

FOCUS

FREESTYLE

FUSION/LINCOLN MKZ

FUSION

RANGER

(2009 -2016)

(2007)

(2005-2007)

(2007-2012)

(2013-2016)

(1993-2011)

7160-0009

7160-0244

7160-0260

DS-118

TAURUS (2000-2007)

GMC

TAURUS/TAURUS-X

TRANSIT CONNECT

TRANSIT CONNECT

TRANSIT

1500/2500/3500 C/K

1500/2500/3500 C/K

CANYON

CANYON

G-SERIES VAN

G-SERIES VAN

SAVANA

SAVANA

International

Jeep

SIERRA

SIERRA

SIERRA 1500

SIERRA 2500/3500/HD

TERRAIN

YUKON/YUKON XL

YUKON/YUKON XL

YUKON/YUKON XL

UNIVERSAL

DURASTAR 4300 / 7300 Series Trucks

COMMANDER

COMPASS

GRAND CHEROKEE

GRAND CHEROKEE

LIBERTY

PARTRIOT

Mazda

Mercedes

Mercury

Nissan

Semi-Truck

/ Class 8

TRIBUTE

SPRINTER

MARINER

MILAN

SABLE

PATHFINDER

TITAN

NV Van

NV200 Van

INTERNATIONAL

FREIGHTLINER

PETERBILT

KENWORTH

VOLVO

MACK

STERLING

WESTERN STAR DAY CAB

Class 6/7

FREIGHTLINER M2 BUSINESS CLASS

Sterling

BULLET 4500-5500

UNVERSAL

Toyota

Volkswagon

TACOMA

TUNDRA

HIGHLANDER

JETTA / PASSAT

Page

W

15

19

W

W

W

18

W

(2008-2016) 7160-0350

(2011-2013)

(2014-2016)

7160-0245

7160-0536

(2015-2016) 7160-0537

(1999-2006 & 2007 Classic Body Style) DS-122

(2007 - 2009)

(2004-2012)

(2015-2016)

(1995-2009)

(2010-2016)

(1995-2009)

(2010-2016)

DS-144

7160-0114

7160-0556

7160-0133

7160-0248

7160-0133

7160-0248

(2000-2006 & 2007 Classic Body Style) DS-122

(2007 New Body Style-2014)

(2014-2016)

(2015-2016)

DS-144

7160-0510

7160-0510

(2010-2016)

(2007 New Body Style-2014)

(2000-2006)

(2015-2016)

ALL YEARS

2002-2016

(2007)

(2007-2016)

7160-0572

DS-144

DS-122

7160-0510

7160-0198

(2007-2010)

(2011-2016)

(2002-2012)

(2007-2016)

(2002-2012)

(2004-2016)

(2002-2012)

(2007-2012)

(2008-2012)

(2009-2016)

(2009-2016)

(2011-2016)

(2010-2016)

(2005-2016)

(2005-2016)

(2005-2016)

(2005-2016)

(2005-2016)

(2005-2016)

(2005-2010)

(2005-2016)

(2010-2016)

2008

ALL YEARS

(2005-2016)

(2007-2016)

(2007-2013)

(2008-2016)

7160-0323

DS-148

DS-140

7160-0036

DS-140

7160-0244

7160-0260

7160-0342

7160-0198

7160-0198

7160-0198

7160-0198

7160-0198

7160-0198

7160-0198

7160-0198

7160-0544

7160-0182

DS-150

7160-0062

DS-150

7160-0417

17

19

W

W

7160-0557 23

17

17

17

17

17

17

17

17

22

17

14

W

14

W

W

15

W

W

18

14

W

23

16

18

16

18

20

W

21

22

W

23

14

W

20

W

14

20

20

W

W

20

W

W

W

13

22

W = Web Listing Only

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Drilling

Required

7160-0185

DS-146

7160-0185

7160-0185

7160-0185

7160-0185

7160-0185

7160-0185

DS-146

Page

Vehicle Legs

(MCS)

7110-0350

7110-0350

Page

42

42

7110-0350

7110-0054

7160-0185

7160-0185

DS-55

7160-0185/

DS-55

7160-0076

7160-0164

7110-0054

7160-0054

7160-0301

7110-0350

17

17

12 7110-0350

7110-0350

7110-0350

7110-0350

17/12 7110-0350

7110-0350

17

14

17

17

17

17

17

17

14

7160-0552

7160-0160

7160-0160

7160-0249

7110-0350

7160-0575

7110-0350

7110-0350

7160-0160

7160-0160

7160-0509

7160-0509

7160-0160

7160-0160

7160-0509

7110-0350

7160-0403

7110-0350

7110-0350

7110-0350

7110-0350

7110-0350

7110-0350

7110-0350

7110-0350

7160-0549

7110-0350

7110-0350

7110-0350

42

W

W

42

W

W

42

42

42

42

42

42

61

42

42

42

42

42

42

42

42

42

42

42

42

42

42

W

42

42

42

42

42

42

42

42

42

42

42

42

42

42

W

11

12

Vehicle Bases

Shown: DS-52

Shown: 7160-0190

Shown: DS-53

Shown: DS-55

Item No. Placement

Seat

Configuration

Drilling

Required

Pole

DS-52

Flat Floor All

Yes - any vehicle with a flat floor

Lower Tube

included with base

Upper Pole

ordered separately (pg. 26)

Features

- Solution for vehicle with high seats - vans, stepvans and trucks

Height Adjustability Weight Height Width Depth

Yes - overall

18.5" - 23.5"

(depending on

Upper Pole

selected)

8.1 lbs. 18.25" 8.0" 8.0"

Item No.

Placement

Seat

Configuration

Drilling

Required

Weight Height Width Depth

7160-0190

Under the vehicle in conjunction with the

DS-52 and DS-57 Vehicle Bases only

All

Yes

4.91 lbs. 0.52" 8.0"

Features

- Underbody support plate provides stability to the DS-52 and DS-57 and distributes the clamping load across the

vehicle body

- Underbody support plate can be installed in two configurations:

- Bolts with threads up (plate will remain fixed position if the vehicle base is removed)

- Bolts with threads down (plate will disengage when the vehicle base is removed)

- Pem studs are used in order to reduce installation time and can be installed by a single individual

- Holes in center of plate allows installer to thread twine or wire and pull plate up to the underbody

Note:

Before drilling holes through a vehicle floor pan, inspect the drill locations for wiring, exhaust pipes, drive train components, fuel lines and hydraulic lines.

8.0"

Item No. Placement

Seat

Configuration

Drilling

Required

Pole Height Adjustability Weight Height Width Depth

DS-53

Flat, vertical surface

All

Yes

Lower Tube

included with base

Upper Pole

ordered separately (pg. 26)

Yes - overall

13.25" - 18.25"

(depending on

Upper Pole

selected)

Features

- Can be mounted to engine covers, consoles and “dog houses”

- Two back-up mounting strips included

4.2 lbs. 13.0" 2.0" 8.0"

Item No.

Placement

Seat

Configuration

Drilling Required

DS-55

Offset transmission hump passenger side

All

Yes - any vehicle with a transmission hump

Features

- Wide footprint to make unit stable for heavier or larger equipment

Pole

Ordered separately

(pg. 25-27)

Weight Height Width Depth

7.8 lbs.

5.3" to

8.1"

9.5" to

11.25"

9.0"

Item No.

Placement

Seat

Configuration

Drilling

Required

Pole Weight Height Width Depth

DS-56

Flat, horizontal surface

All

Yes

N/A - attaches to

Motion

Attachment

(pg. 29-33) 2.0 lbs.

Features

- Solution for any vehicle where mounting floor space is limited

- Provides low rise for mounting on storage boxes or engine covers

0.75" 6.0" 6.0"

Shown: DS-56

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Vehicle Bases

Item No. Placement

Seat

Configuration

Drilling

Required

Pole Height Adjustability Weight Height Width Depth

DS-57

Flat Floor All

Yes - any vehicle with a flat floor

Lower Tube

included with base

Upper Pole

ordered separately (pg. 26)

Yes - overall

14.25" - 19.25"

(depending on

Upper Pole

selected)

Features

- Solution for vehicle with high seats - vans, stepvans and trucks

5.35 lbs.

14.0" 8.0" 8.0"

Item No. Placement

Seat

Configuration

Drilling

Required

Pole Height Adjustability Weight Height Diameter

DS-100

Flat

Floor

All

Yes - any vehicle with a flat floor

Lower Tube

included with base

Upper Pole

ordered separately (pg. 26)

Yes - overall

18.63" - 22.63"

(depending on

Upper Pole

selected)

10.2 lbs. 18.38" 8.0"

Features

- Design is protected by Patent Number D421,708

- Allows entire mounting system to be quickly installed and removed by removing securing pin and simply twisting the

post clockwise

- Solution for vehicle with high seats - vans, stepvans and trucks

- Multiple base plates maybe ordered for switching entire mounting system from one vehicle to another

Item No.

Placement

Seat

Configuration

Drilling Required Weight Height Diameter

DS-100-PLATE

Flat Floor All Yes - any vehicle with a flat floor 4.5 lbs.

0.5"

Features

- For use with

Vehicle Base

(Item No. DS-100) when entire mounting systems needs to be quickly switched to

another vehicle

- Low profile circular base plate (1/2" thick)

8.0"

Item No.

Placement

DS-124

7170-0135

Seat

Configuration Drilling Required

Recommended Pole Solution Weight Height Width Depth

Passenger side on the floor, under seat

Bucket/

Bench

No - attaches to seat studs:

Ford F-150

(New Body

Style 2004-2014)

Lower Tube: DS-LOWER-9

Upper Pole: 7160-0178

Support Brace: 7160-0230

Poles ordered separately (pg. 25-27) 9.0 lbs. 4.0" 19.25" 8.0"

Motion Attachment: 7160-0220

Motion Attachment ordered separately (pg. 29-33)

Vehicle Kit includes vehicle base and the recommended pole solution as stated above.

No substitutions. For more detailed information please visit our website.

Features

- Angled step moves pole away from passenger leg space

- Will not interfere with levers or factory installed consoles

- One Offset Universal Mounting Step (Item No. DS-STEP) is already included with this vehicle base. However,

additional

Offset Universal Mounting Steps

can be ordered to stack on top of each other if needed (pg. 29).

Item No.

Placement

DS-138

Flat, vertical surface

Seat

Configuration

All

Drilling

Required

Yes - backing plate provided to system strength

Pole

Lower Tube

included with base

Upper Pole

ordered separately (pg. 26)

Height Adjustability Weight Height Width Depth

Yes - overall

7.75" - 12.75"

(depending on

Upper Pole

selected)

Features

- Ideal for mounting communication equipment to engine cover, consoles and “dog houses”

2.4 lbs. 7.5" 3.0" 1.25"

Shown: DS-57

Shown: DS-100

Shown: DS-100-PLATE

Shown: DS-124

Shown: DS-138

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

13

14

Vehicle Bases

Shown: DS-144

Shown: DS-146

Shown: DS-150

Shown: 7160-0033

Item No.

Placement

DS-144

7170-0142

Seat

Configuration

Drilling Required

Recommended Pole

Solution

Weight Height Width Depth

Passenger side on the floor, under seat

Bucket/

Bench

No - attaches to seat studs:

Chevrolet:

1500/2500/3500/C/K

(2007-2009 New Body Style)

Avalanche (2007-2013)

Silverado 1500

(2007 New Body Style-2013)

Silverado 2500/3500/HD

(2007 New Body Style-2014)

Suburban

(2007 New Body Style-2014)

Tahoe

(2007 New Body Style-2014)

GMC:

Sierra 1500

(2007 New Body Style-2013)

Sierra 2500/3500/HD

(2007 New Body Style-2014)

Yukon/Yukon XL

(2007 New Body Style-2014)

Lower Tube:

DS-LOWER-9

Upper Pole:

7160-0178

Support Brace:

7160-0230

Poles ordered separately

(pg. 25-27)

Motion Attachment:

7160-0220

Motion Attachment ordered separately

(pg. 29-33)

7.5 lbs. 5.57" 20.18" 11.39"

Vehicle Kit includes vehicle base and the recommended pole solution as stated above.

No substitutions. For more detailed information please visit our website.

Features

- Angled step moves pole away from passenger leg space

Note:

1) An additional Offset Universal Mounting Step (pg.27) is recommended to position the computer mounting system away from the passenger

leg space and out of the air bag zone. This may require the factory installed console to be removed.

2) It is recommended that the passenger side air bag is deactivated if mounting system is placed in the air bag zone. Failure to comply may

lead to serious injury during sudden braking or accidents.

3) Will not work with Chevrolet 3500 with PTO, the recommended base is 7160-0185.

Item No.

Placement

Seat

Configuration

Drilling Required Pole Weight Height Width Depth

DS-146

Flat floor to the bench seat

Bench

Yes - attaches to seat frame and drilled into the vehicle floor of the

International, Freightliner or Sterling

Ordered separately

(pg. 25-27)

8.0 lbs.

11.0" to

15.23"

5.0"

Features

- Universal design can be used in International, Freightliner, Sterling and other large trucks with a bench style seat

- Several mounting holes on top of the vehicle base allows for flexible positioning of computer mounting system

13.39"

Item No. Placement

DS-150

Passenger side on the floor, under seat

Seat

Configuration

Bucket/

Bench

Drilling

Required

Recommended Pole Solution Weight Height Width Depth

No - attaches to seat studs:

Toyota Tacoma

(2005-2015)

Lower Tube: DS-LOWER-7

Upper Pole: QUADJ-UPPER-M

Support Brace: 7160-0230

Poles ordered separately (pg. 25-27)

Motion Attachment: 7160-0284

Motion Attachment ordered separately (pg. 29-33)

8.5 lbs. 4.2" 18.5" 7.0"

Features

- Will not interfere with levers or factory installed console

- Angled step moves pole away from passenger leg space

- One Offset Universal Mounting Step (Item No. DS-STEP) is already included with this vehicle base. However,

additional

Offset Universal Mounting Steps

can be ordered to stack on top of each other if needed (pg. 27).

Item No.

7160-0033

Placement

On passenger seat

Seat

Configuration

All

Drilling

Required

No

Weight

5.7 lbs.

Height

5.0"

Width

14.0"

Depth

16.0"

Features

- Light-weight aluminum for reduced overall weight

- Uses the passenger seat to firmly secure the base into the vehicle

- Design can easily be used with any vehicle

- Can be used with any

Motion Attachment

and

Computer Cradle

to make a universal computer mounting solution

- Provides a platform to mount portable equipment (computers, printers, scanners, etc...)

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Vehicle Bases

Item No.

Placement

Seat

Configuration

Drilling Required Recommended Pole Solution Weight Height Width Depth

7160-0036

Secured between the passenger seat base and seat bolts

Bucket

No - attaches between seat base and seat studs:

Dodge Sprinter

(2004-2009)

Freightliner Sprinter

(2004-2015)

Mercedes Sprinter

(2004-2016)

Lower Tube: DS-LOWER-5

Upper Pole: QADJ-UPPER-M5

Support Brace: 7160-0231

Poles ordered separately (pg. 25-27)

Motion Attachment: 7160-0284

Motion Attachment ordered separately (pg. 29-33)

10.13 lbs. 5.88" 24.12" 7.0"

7170-0501

Vehicle Kit includes vehicle base and the recommended pole solution as stated above.

No substitutions. For more detailed information please visit our website.

Features

- For extra stability a Support Brace (Item No. 7160-0231) is recommended (pg. 27)

Shown: 7160-0036

Item No.

Placement

Seat

Configuration

Drilling Required Recommended Pole Solution Weight Height Width Depth

7160-0045

Passenger side on the floor, under seat

Bucket/

Bench

No - attaches to seat studs:

Ford Excursion

(2000-2005)

Ford F-250 to

F-750 Super Duty

Automatics Only

(1999-2010)

Lower Tube: DS-LOWER-9

Upper Pole: DS-UPPER-M

Support Brace: 7160-0230

Poles ordered separately

(pg. 25-27)

Motion Attachment: 7160-0750

Motion Attachment ordered separately (pg. 29-33)

9.4 lbs. 6.0" 21.0" 5.5"

Features

- Won’t interfere with levers or factory installed consoles located on transmission hump

- Won’t interfere with passenger leg space

- For extra stability a Support Brace (Item No. 7160-0230) is recommended (pg. 27)

Note:

- In some cases of a bench seat, the seat bolt that the vehicle base mounts to on the inboard seat bolt the installer might need to tap threads

into the hole under the mat.

- F-450 to F-750 with floor manual shifter will have modify base to fit around shifter base.

- Vehicle Base will work with 4x4 floor shifter.

Shown: 7160-0045

Item No.

7160-0046

Placement

Passenger side on the floor, under seat

Seat

Configuration

Bucket/

Bench

Drilling

Required

Recommended Pole Solution Weight Height Width Depth

No - attaches to seat studs:

Ford

Expedition

(2007-2016)

Lower Tube: DS-LOWER-9

Upper Pole: 7160-0178

Support Brace: 7160-0230

Poles ordered separately (pg. 25-27)

Motion Attachment: 7160-0220

Motion Attachment ordered separately (pg. 29-33)

9.8 lbs.

6.7" 12.75" 6.0"

7170-0129

Vehicle Kit includes vehicle base and the recommended pole solution as stated above.

No substitutions. For more detailed information please visit our website.

Features

- Angled step moves pole away from passenger leg space

- Will not interfere with levers or factory installed consoles

- One Offset Universal Mounting Step (Item No. DS-STEP) is already included with this vehicle base. However, additional

Offset can be ordered to stack on top of each other if needed (pg. 27).

- For extra stability a Support Brace (Item No. 7160-0230) is recommended (pg. 27)

Note:

Will not work wit the MCS Leg Kit (Item No. 7160-0084) pg. 42

Shown: 7160-0046

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

15

16

Vehicle Bases

Shown: 7160-0055

Shown: 7160-0090

Shown: 7160-0116

Shown: 7160-0133

Item No.

Placement

7160-0055

7170-0144

Seat

Configuration

Drilling

Required

Recommended Pole Solution Weight Height Width Depth

Passenger side on the floor, under seat

Bucket/

Bench

Yes - drilling is recommended but not required:

Chevrolet

Impala PPV

(2006-2016)

Lower Tube: DS-LOWER-7

Upper Pole: 7160-0178

Support Brace: 7160-0230

Poles ordered separately (pg. 25-27)

Motion Attachment: 7160-0220

Motion Attachment ordered separately (pg. 29-33)

11.0 lbs. 6.68" 20.7" 10.92"

Vehicle Kit includes vehicle base and the recommended pole solution as stated above.

No substitutions. For more detailed information please visit our website.

Features

- The base uses the weight and pressure of the seat and the mechanical counter balance of the base design to secure

it under the seat. Due to not being secured using the seat bolts, we strongly recommend you fasten the base by using

the four holes located on the base and drill into the floor.

- One Offset Universal Mounting Step (Item No. DS-STEP) is already included with this vehicle base. However, additional

Offset

Universal Mounting Steps

can be ordered to stack on top of each other if needed (pg. 27).

- The

Offset Universal Mounting Step

should be pointed towards the passenger seat to move the mounting system away

from the dash

- For extra stability a Support Brace (Item No. 7160-0230) is recommended (pg. 27)

Item No.

Placement

Seat

Configuration

Drilling

Required

Recommended Pole Solution Weight Height Width Depth

7160-0090

Passenger side inner front and back seat studs

Bucket

No - attaches to seat studs:

Ford E-Series

Van

(2006-2014)

Lower Tube:

included with base

Upper Pole: 7160-0178

Poles ordered separately (pg. 25-27)

Motion Attachment: 7160-0220

Motion Attachment ordered separately (pg. 29-33)

9.5 lbs. 19.25" 16.75" 8.3"

7170-0130

Vehicle Kit includes vehicle base and the recommended pole solution as stated above.

No substitutions. For more detailed information please visit our website.

Features

- Won’t interfere with passenger leg space

- Bracket mounted to pole gusset allows for additional attachment to seat frame

- Base works with most existing work boxes

Note:

Works with the 2015 model year cutaway versions

Item No.

Placement

Seat

Configuration

Drilling Required Recommended Pole Solution Weight Height Width Depth

7160-0116

Passenger side on the floor, under seat

Bucket

No - attaches to seat studs:

Dodge Caravan

(2008-2016)

Ram CV (2012-2016)

Lower Tube: included with base

Upper Pole: QAD-UPPER-M

Poles ordered separately (pg. 25-27)

Motion Attachment: 7160-0750

Motion Attachment ordered separately (pg. 29-33)

8.0 lbs. 9.75" 21.0" 5.0"

Features

- Vehicle base will work with both the Stow & Go and Swivel & Go Dodge Caravan models

- Won’t interfere with passenger leg space

- For extra stability a Support Brace (Item No. 7160-0230) is recommended (pg. 27)

Note:

On the Stow & Go Dodge Caravan models, the front seat will have limited travel due to the install of the base and this may cause the rear passenger seat not to stow properly.

Item No. Placement

Seat

Configuration

Drilling Required Pole

Height

Adjustability

7160-0133

Passenger side inner front and back seat studs

Bucket

No - attaches to seat studs:

Ford E-Series Van

(1995-2005)

Chevrolet/GMC

G-Series Van (1995-2009)

Chevrolet Express Van

(1995-2009)

Chevrolet Kodiak

(2001-2009

Bucket Seat Only

)

GMC Savana Van

(1995-2009)

GMC Topkick

(2001-2009

Bucket Seat Only

)

Lower Tube included with base

Upper Pole ordered separately

(pg. 26)

Features

- Won’t interfere with passenger leg space

- Bracket mounted to pole gusset allows for additional attachment to seat frame

- Base works with most existing work boxes

Weight Height Width Depth

Yes - overall

19.13" - 24.13"

(depending on Upper Pole selected)

10.5 lbs. 18.88" 16.75" 7.30"

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Vehicle Bases

Item No.

Placement

7160-0182

7170-0136

Seat

Configuration

Drilling Required Recommended Pole Solution Weight Height Width Depth

Passenger side on the floor, under seat

Bucket/

Bench

No - attaches to seat studs:

Dodge Ram

1500-5500

(2002-2016)

Sterling Bullet

4500-5500 (2008)

Lower Tube: DS-LOWER-7

Upper Pole: 7160-0178

Support Brace: 7160-0230

Poles ordered separately (pg. 25-27)

Motion Attachment: 7160-0220

Motion Attachment ordered separately (pg. 29-33)

4.1 lbs. 3.58" 18.25" 5.08"

Vehicle Kit includes vehicle base and the recommended pole solution as stated above.

No substitutions. For more detailed information please visit our website.

Features

- Will not interfere with levers or factory installed consoles

- An

Offset Universal Mounting Step (Item No. DS-STEP)

maybe ordered separately to move the pole away from

passenger leg space (pg. 27)

- For extra stability a

Support Brace (Item No. 7160-0230)

is recommended (pg. 27)

Note:

1) If your Dodge Ram has a factory installed console and/or manual shift on the floor, the recommended pole solution is DS-LOWER-13,

QADJ-UPPER-M, 7160-0230 and 7160-0284 . That solution is not available in a kit.

2) If your Sterling Bullet has a factory installed console and/or manual shift on the floor, the recommended pole solution is DS-LOWER-9,

QADJ-UPPER-L, 7160-0230 and 7160-0750 (CLEVIS) . That solution is not available in a kit.

Item No.

Placement

Seat

Configuration

Drilling Required Pole Weight Height Width Depth

7160-0185

Passenger side on the floor

Bucket/

Bench

Yes:

Chevrolet:

Equinox (2007-2009)

Uplander (2005-2009)

GMC Yukon/Yukon XL (2000-2006)

Ford:

Excursion Limited (2000-2005)

Focus (2007)

Flex (2009-2015)

Jeep:

Commander (2007)

Compass (2007-2016)

Grand Cherokee (2007-2010)

Patriot (2007-2016)

Nissan:

Pathfinder (2009-2016)

Titan (2009-2016)

Dodge Dakota (2005)

Ordered separately

(pg. 25-27)

7.5 lbs. 5.75"

Features

- Won’t interfere with levers or factory installed 1/2 consoles located on transmission hump

- Will not work with full factory installed console or 4WD lever on transmission hump

- Won’t interfere with passenger leg space

22.88" 5.25"

Item No. Placement

Seat

Configuration

Drilling Required Pole Weight Height Width Depth

7160-0198

Passenger side floor

Bucket

No - attaches to seat studs:

International (2005-2016)

Freightliner (2005-2016)

Peterbilt (2005-2016)

Kenworth (2005-2016)

Volvo (2005-2016)

Mack (2005-2016)

Sterling (2005-2010)

Western Star Day Cab

(2005-2016)

Lower Tube:

included with base

Upper Pole: QADJ-UPPER-L

Support Brace: 7160-0231

Poles ordered separately

(pg. 25-27)

Motion Attachment: 7160-0750

Motion Attachment ordered separately (pg. 29-33)

25.5 lbs. 19.09" 18.75" 26.3"

Features

- Compatible with most Class 8 International, Freightliner, Peterbilt, Kenworth, Volvo, Mack, Sterling and Western Star

Day Cab and Over the Road Sleeper Cab Semi-Tractors

- Compatible with all bucket standard and air ride seats including National Seat Company, Sears Seating Inc., and

Bostrom Seats

- Four positions of linear adjustability (can be adjusted based on standard floor shift and automatic models)

- Pole can be rotated in four positions in order to adjust to cab configurations and driver ergonomics

- Vehicle base standoff is designed to accommodate different floor mat thicknesses

- Vehicle base can be adjusted for driver or passenger use

- Allows egress to the back of the sleeper cab

- Won’t interfere with standard floor shift

- A Support Brace (Item No. 7160-0231) is highly recommended and can be bolted directly to the vehicle base

Note:

This base will not work with International trucks with an integrated air conditioning system under the seat.

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Shown: 7160-0182

Shown: 7160-0185

Shown: 7160-0198

17

18

Vehicle Bases

Shown: 7160-0234

Item No.

Placement

Seat

Configuration

Drilling

Required

Pole Weight Height Width Depth

7160-0234

Passenger side on the floor, under the seat

Bucket/

Bench/

60-40 split

No - attaches to seat studs:

Ford Crown

Victoria Police

Interceptor

(1991-2011)

Lower Tube: DS-LOWER-7

Upper Pole: 7160-0177

Support Brace: 7160-0230

Poles ordered separately (pg. 25-27) 11.0 lbs. 5.7" 18.5" 10.9"

Motion Attachment: 7160-0220

Motion Attachment ordered separately (pg. 29-33)

Features

- Angled step moves pole away from passenger leg space

- Will not interfere with levers or factory installed consoles

- One Offset Universal Mounting Step (Item No. DS-STEP) is already included with this vehicle base. However,

additional

Offset Universal Mounting Steps

can be ordered to stack on top of each other if needed (pg. 27).

- Multiple mounting slots allow for flexible positioning of the Offset Universal Mounting Step

- Larger base footprint and reinforced flanges provide added stability

- For extra stability a Support Brace (Item No. 7160-0230) is recommended (pg. 27)

Shown: 7160-0248

Shown: 7160-0260

Item No.

Placement

7160-0248

7170-0140

Passenger side inner front and back seat studs

Seat

Configuration Drilling Required

Bucket

No - attaches to seat studs:

Chevrolet/GMC

G-Series Van

(2010-2016)

Chevrolet Express

Van (2010-2016)

GMC Savana

Van (2010-2016)

Recommended Pole Solution

Lower Tube:

included with base

Upper Pole: 7160-0178

Poles ordered separately

(pg. 25-27)

Motion Attachment: 7160-0220

Motion Attachment ordered separately (pg. 29-33)

Weight Height Width Depth

8.1 lbs. 19.85" 15.0" 9.31"

Vehicle Kit includes vehicle base and the recommended pole solution as stated above.

No substitutions. For more detailed information please visit our website.

Features

- Won’t interfere with passenger leg space

- Bracket mounted to pole gusset allows for additional attachment to seat frame

- Base works with most existing work boxes

Item No.

7160-0260

Placement

Attaches to inboard and outboard passenger side seat studs

Seat

Configuration

Bucket

Drilling

Required

Pole Weight Height Width Depth

No - attaches to seat studs:

Ford Fusion

(2013-2016)

Lower Tube: DS-LOWER-9

Upper Pole: 7160-0178

Support Brace: 7160-0230

Poles ordered separately (pg. 25-27)

Motion Attachment: 7160-0500

Motion Attachment ordered separately (pg. 29-33)

6.9 lbs. 5.43" 19.0" 4.36"

7170-0234

Vehicle Kit includes vehicle base and the recommended pole solution as stated above.

No substitutions. For more detailed information please visit our website.

Features

- Angled step moves pole away from passenger leg space

- Can be used with factory installed console

- One Offset Universal Mounting Step (Item No. DS-STEP) is already included with this vehicle base. However,

additional can be ordered to stack on top of each other if needed (pg. 27).

- For extra stability a Support Brace (Item No. 7160-0230) is recommended (pg. 27)

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Vehicle Bases

Item No.

Placement

7160-0281

Passenger side on the floor, under seat

Seat

Configuration

Bucket/

Bench

Drilling

Required

Recommended Pole Solution Weight Height Width Depth

No - attaches to seat studs:

Ford F-250

to F-750

Super Duty

(2011-2016)

Lower Tube: DS-LOWER-9

Upper Pole: 7160-0178

Support Brace: 7160-0230

Poles ordered separately (pg. 25-27) 9.5 lbs. 7.5" 19.5" 9.5"

Motion Attachment: 7160-0220

Motion Attachment ordered separately (pg. 29-33)

7170-0133

Vehicle Kit includes vehicle base and the recommended pole solution as stated above.

No substitutions. For more detailed information please visit our website.

Features

- Angled step moves pole away from passenger leg space

- Will not interfere with levers or factory installed consoles

- One Offset Universal Mounting Step (Item No. DS-STEP) is already included with this vehicle base. However,

additional

Offset Universal Mounting Steps

can be ordered to stack on top of each other if needed (pg. 27).

- For extra stability a Support Brace (Item No. 7160-0230) is recommended (pg. 27)

Note:

- In some cases of a bench seat, the seat bolt that the vehicle base mounts to on the inboard seat bolt the installer might need to tap threads

into the hole under the mat.

- Vehicle Base will work with 4x4 floor shifter.

Item No.

Placement

7160-0323

Attaches to inboard and outboard passenger side seat studs

Seat

Configuration

Bucket

Drilling

Required

No - attaches to seat studs:

Dodge Durango

(2011-2016)

Jeep Grand

Cherokee

(2011-2016)

Pole Weight Height Width Depth

Lower Tube: DS-LOWER-9

Upper Pole: 7160-0178

Support Brace: 7160-0230

Poles ordered separately (pg. 25-27) 9.11 lbs. 5.87" 18.85" 9.22"

Motion Attachment: 7160-0220

Motion Attachment ordered separately (pg. 29-33)

Features

- Angled step moves pole away from passenger leg space

- Will not interfere with levers or factory installed consoles

- One Offset Universal Mounting Step (Item No. DS-STEP) is already included with this vehicle base. However,

additional

Offset Universal Mounting Steps

can be ordered to stack on top of each other if needed (pg. 27).

- For extra stability a Support Brace (Item No. 7160-0230) is recommended (pg. 27)

Item No.

Placement

7160-0329

Attaches to inboard and outboard passenger side seat studs

Seat

Configuration

Bucket

Drilling

Required

Recommended Pole Solution

No - attaches to seat studs:

Dodge

Charger

(2011-2016)

Lower Tube: DS-LOWER-13

Upper Pole: 7160-0178

Support Brace: 7160-0230

Poles ordered separately (pg. 25-27)

Motion Attachment: 7160-0220

Motion Attachment ordered separately (pg. 29-33)

Weight Height Width Depth

10.5 lbs.

3.2" 20.3"

7170-0138

Vehicle Kit includes vehicle base and the recommended pole solution as stated above.

No substitutions. For more detailed information please visit our website.

Features

- Base works with both the Police and Street model Dodge Charger

- Can be used with factory installed console

- For extra stability a Support Brace (Item No. 7160-0230) is recommended (pg. 27)

9.6"

Item No.

Placement

Seat

Configuration

Drilling

Required

Recommended Pole Solution Weight Height Width Depth

7160-0342

Passenger side on the floor, under seat rails

Bucket

No - attaches to seat studs:

Nissan NV

(2011-2016)

Lower Tube: DS-LOWER-13

Upper Pole: 7160-0178

Support Brace: 7160-0230

Poles ordered separately (pg. 25-27)

Motion Attachment: 7160-0220

Motion Attachment ordered separately (pg. 29-33)

6.6 lbs.

4.0" 20.8"

7170-0502

Vehicle Kit includes vehicle base and the recommended pole solution as stated above.

No substitutions. For more detailed information please visit our website.

Features

- Can be used with factory installed console

- For extra stability a Support Brace (Item No. 7160-0230) is recommended (pg. 27)

10.0"

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Shown: 7160-0281

Shown: 7160-0323

Shown: 7160-0329

Shown: 7160-0342

19

20

Vehicle Bases

Shown: 7160-0350

Shown: 7160-0451

Shown: 7160-0510

Item No.

Placement

7160-0350

7170-0148

Seat

Configuration

Drilling Required Recommended Pole Solution Weight Height Width Depth

Attaches to inboard and outboard passenger side seat studs

Bucket

No - attaches to seat studs:

Ford Explorer

(2011-2016)

Ford Sedan/Utility

Police Interceptor

(2012-2016)

Lower Tube: DS-LOWER-9

Upper Pole: 7160-0178

Support Brace: 7160-0230

Motion Attachment: 7160-0220

Motion Attachment ordered separately (pg. 29-33)

Poles ordered separately (pg. 25-27) 10.4 lbs. 8.12" 19.0" 8.93"

Vehicle Kit includes vehicle base and the recommended pole solution as stated above.

No substitutions. For more detailed information please visit our website.

Features

- Angled step moves pole away from passenger leg space

- Won’t interfere with passenger leg space

- One Offset Universal Mounting Step (Item No. DS-STEP) is already included with this vehicle base. However,

additional

Offset Universal Mounting Steps

can be ordered to stack on top of each other if needed (pg. 27).

- For extra stability a Support Brace (Item No. 7160-0230) is recommended (pg. 27)

Item No.

Placement

7160-0451

7170-0233

Seat

Configuration

Drilling Required Pole Weight Height Width Depth

Attaches to inboard and outboard passenger side seat studs

Bucket

No- drilling is recommended but not required:

Ford Escape

(2013-2016)

Dodge Caliber

(2007-2012)

Dodge Journey

(2015-2016)

Jeep Patriot

(2007-2016)

Jeep Compass

(2007-2016)

Lower Tube:

DS-LOWER-13

Upper Pole: 7160-0178

Support Brace:

7160-0230

Poles ordered separately

(pg. 25-27)

Motion Attachment:

7160-0500

Motion Attachment ordered separately

(pg. 29-33)

5.0 lbs. 1.68" 17.0"

Vehicle Kit includes vehicle base and the recommended pole solution as stated above.

No substitutions. For more detailed information please visit our website.

7.5"

Features

- Won’t interfere with passenger leg space

- For extra stability a Support Brace (Item No. 7160-0230) is recommended (pg. 27)

Note:

This base will not work with the Offset Universal Mounting Step (Item No. DS-STEP)

Item No.

Placement

7160-0510

7170-0214

Attaches to inboard and outboard passenger side seat hooks

Seat

Configuration

Bucket/

Split Bench

Drilling Required

No - attaches to seat hooks:

Chevrolet Silverado 1500

(2014-2016)

Chevrolet Silverado

2500/3500/HD (2016)

Chevrolet Tahoe (2016)

GMC Sierra 1500 (2014-2016)

GMC Sierra 2500/3500/HD

(2016)

GMC Yukon/Yukon XL (2016)

Recommended Pole

Solution

Lower Tube: DS-LOWER-9

Upper Pole: 7160-0178

Support Brace: 7160-0230

Poles ordered separately (pg. 25-27)

Motion Attachment:

7160-0220

Motion Attachment ordered separately

(pg. 29-33)

Weight Height Width Depth

13.5 lbs.

7.2" 20.7" 15.4"

Vehicle Kit includes vehicle base and the recommended pole solution as stated above.

No substitutions. For more detailed information please visit our website.

Features

- Will not interfere with levers or factory installed console

- One Offset Universal Mounting Step (Item No. DS-STEP) is already included with this vehicle base. However,

Offset Universal Mounting Steps

can be ordered to stack on top of each other if needed (pg. 27)

- For extra stability, a Support Brace (Item No. 7160-0230) is recommended (pg. 27)

Note:

- Rearward travel of the passenger seat is not affected, however there is limited forward seat travel

- Will not work with Chevrolet 3500 with PTO, the recommended base is 7160-0185

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Vehicle Bases

Item No.

Placement

Seat

Configuration

Drilling Required Recommended Pole Solution Weight Height Width Depth

7160-0520

Attaches to inboard and outboard passenger side seat hooks

Bucket/

Split Bench

No - attaches to seat hooks:

Chevrolet Malibu

(2013-2016)

Chevrolet Impala -

Civilian Model

Only (2014-2016)

Lower Tube: DS-LOWER-9

Upper Pole: QUADJ-UPPER-M

Support Brace: 7160-0230

Poles ordered separately (pg. 25-27)

Motion Attachment: 7160-0285

Motion Attachment ordered separately (pg. 29-33)

10.95 lbs.

5.74" 19.9" 12.84"

Features

- Will not interfere with levers or factory installed console

- One Offset Universal Mounting Step (Item No. DS-STEP) is already included with this vehicle base. However,

Offset Universal Mounting Steps

can be ordered to stack on top of each other if needed (pg. 27)

- For extra stability, a Support Brace (Item No. 7160-0230) is recommended (pg. 27)

Note:

Rearward travel of the passenger seat is not affected, however forward seat travel is slightly affected

Item No.

Placement

Seat

Configuration

Drilling

Required

Recommended Pole Solution Weight Height Width Depth

7160-0527

Attaches to inboard and outboard passenger side seat studs

Bucket/

Split Bench

No - attaches to seat studs:

Ram

ProMaster

(2014-2016)

Lower Tube: DS-LOWER-7

Upper Pole: 7160-0178

Support Brace: 7160-0231

Poles ordered separately (pg. 25-27)

Motion Attachment: 7160-0500

Motion Attachment ordered separately (pg. 29-33)

7.1 lbs. 5.1" 22.5" 4.8"

7170-0239

Vehicle Kit includes vehicle base and the recommended pole solution as stated above.

No substitutions. For more detailed information please visit our website.

Features

- One

Offset Universal Mounting Step (Item No. DS-STEP)

is already included with this vehicle base. However,

additional can be ordered to stack on top of each other if needed (pg. 27)

- For extra stability, a

Support Brace (Item No. 7160-0231)

is recommended (pg. 27)

Item No.

Placement

7160-0532

7170-0220

Seat

Configuration

Drilling

Required

Recommended Pole Solution Weight Height Width Depth

Attaches to inboard and outboard passenger side seat hooks

Bucket/Split

Bench

No - attaches to seat hooks:

Chevrolet

Caprice PPV

(2014-2016)

Lower Tube: DS-LOWER-9

Upper Pole: 7160-0178

Support Brace: 7160-0230

Poles ordered separately (pg. 25-27)

Motion Attachment: 7160-0220

Motion Attachment ordered separately (pg. 29-33)

10.65 lbs.

5.87" 18.4" 13.51"

Vehicle Kit includes vehicle base and the recommended pole solution as stated above.

No substitutions. For more detailed information please visit our website.

Features

- One Offset Universal Mounting Step (Item No. DS-STEP) is already included with this vehicle base. However,

additional can be ordered to stack on top of each other if needed (pg. 27)

- For extra stability, a Support Brace (Item No. 7160-0230) is recommended (pg. 27)

Item No.

Placement

7160-0536

7170-0238

Seat

Configuration

Drilling

Required

Recommended Pole Solution Weight Height Width Depth

Passenger side on the floor, under seat

Bucket

No - attaches to seat hooks:

Ford Transit

Connect

(2014-2016)

Lower Tube: DS-LOWER-9

Upper Pole: 7160-0178

Support Brace: 7160-0230

Poles ordered separately (pg. 25-27)

Motion Attachment: 7160-0500

Motion Attachment ordered separately (pg. 29-33)

3.35 lbs.

4.46" 5.81" 4.30"

Vehicle Kit includes vehicle base and the recommended pole solution as stated above.

No substitutions. For more detailed information please visit our website.

Features

- For extra stability, a Support Brace (Item No. 7160-0230) is recommended (pg. 27)

Shown: 7160-0520

Shown: 7160-0527

Shown: 7160-0532

Shown: 7160-0536

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

21

22

Vehicle Bases

Item No.

7160-0537

7170-0226

Placement

Seat

Configuration

Drilling

Required

Recommended Pole Solution Weight Height Width Depth

Attaches to inboard and outboard passenger side seat studs

Bucket/

Split Bench

No - attaches to seat studs:

Ford Transit

(2015-2016)

Lower Tube: DS-LOWER-9

Upper Pole: 7160-0178

Support Brace: 7160-0231

Poles ordered separately (pg. 25-27)

Motion Attachment: 7160-0500

Motion Attachment ordered separately (pg. 29-33)

4.75 lbs. 1.18" 23.0" 4.21"

Vehicle Kit includes vehicle base and the recommended pole solution as stated above.

No substitutions. For more detailed information please visit our website.

Features

- For extra stability, a Support Brace (Item No. 7160-0230) is recommended (pg. 27)

Shown: 7160-0537

Shown: 7160-0544

Item No.

Placement

Seat

Configuration Drilling Required

Recommended Pole Solution Weight Height Width Depth

7160-0544

Attaches to inboard and outboard passenger side seat studs

Bucket

No - attaches to seat studs:

Freightliner M2 106

(2012-2015)

Freightliner M2 112

(2012-2016)

Lower Tube: DS-LOWER-9

Upper Pole: 7160-0178

Support Brace: 7160-0230

Poles ordered separately (pg. 25-27)

Motion Attachment: 7160-0220

Motion Attachment ordered separately (pg. 29-33)

9.6 lbs. 9.49" 20.27" 11.27"

Features

- For extra stability, a Support Brace (Item No. 7160-0230) is recommended (pg. 27)

Shown: 7160-0553

Item No.

Placement

7160-0553

Attaches to inboard and outboard passenger side seat studs

Seat

Configuration

Bucket

Drilling

Required

Recommended Pole Solution Weight Height Width Depth

No - attaches seat studs:

Ram

ProMaster

City

(2015-2016)

Lower Tube: DS-LOWER-9

Upper Pole: 7160-0178

Support Brace: 7160-0230

Poles ordered separately (pg. 25-27)

Motion Attachment: 7160-0500

Motion Attachment ordered separately (pg. 29-33)

11.2 lbs. 8.18" 19.0" 10.55"

7170-0500

Vehicle Kit includes vehicle base and the recommended pole solution as stated above.

No substitutions. For more detailed information please visit our website.

Features

- Installs in minutes with no drilling required

- Angled step moves pole away from passenger leg space

- Will not interfere with levers or factory installed consoles

- One Offset Universal Mounting Step (Item No. DS-STEP) is already included with this vehicle base. However,

additional

Offset Universal Mounting Steps

can be ordered to stack on top of each other if needed (pg. 27)

- Multiple mounting slots allow for flexible positioning of the

Offset Universal Mounting Step

Shown: 7160-0554

Item No.

Placement

7160-0554

Passenger side on the floor, under the seat

Seat

Configuration

All

Drilling

Required

Recommended Pole Solution

No - attaches seat studs:

Ford F-150

Aluminum

Body

(2015-2016)

Lower Tube: DS-LOWER-9

Upper Pole: 7160-0178

Support Brace: 7160-0230

Poles ordered separately (pg. 25-27)

Motion Attachment: 7160-0220

Motion Attachment ordered separately (pg. 29-33)

Weight Height Width Depth

6.7 lbs. 6.48" 17.68" 7.27"

7170-0236

Vehicle Kit includes vehicle base and the recommended pole solution as stated above.

No substitutions. For more detailed information please visit our website.

Features

- Installs in minutes with no drilling required

- Angled step moves pole away from passenger leg space

- Will not interfere with levers or factory installed consoles

- One Offset Universal Mounting Step (Item No. DS-STEP) is already included with this vehicle base. However, additional

Offset Universal Mounting Steps

can be ordered to stack on top of each other if needed (pg. 27)

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

VEHICLE BASES

Item No.

Placement

Seat

Configuration

Drilling

Required

Recommended Pole Solution Weight Height Width Depth

7160-0556

Attaches to inboard and outboard passenger side seat hooks

Bucket

No - attaches seat hooks:

Chevrolet

Colorado

(2015-2016)

GMC Canyon

(2015-2016)

Lower Tube: DS-LOWER-9

Upper Pole: 7160-0178

Support Brace: 7160-0230

Poles ordered separately (pg. 25-27)

Motion Attachment: 7160-0500

Motion Attachment ordered separately (pg. 29-33)

12.68 lbs.

6.88" 18.44" 13.66"

Features

- Installs in minutes with no drilling required

- Angled step moves pole away from passenger leg space

- Will not interfere with levers or factory installed consoles

- One Offset Universal Mounting Step (Item No. DS-STEP) is already included with this vehicle base. However, additional

Offset Universal Mounting Steps

can be ordered to stack on top of each other if needed (pg. 27)

Item No.

Placement

7160-0557

Attaches to inboard and outboard passenger side seat studs

Seat

Configuration

Bucket/

Split Bench

Drilling

Required

No - attaches to seat studs:

Chevrolet

City Express

(2015)

Chevrolet Volt

(2010-2016)

Nissan NV200

(2010-2016)

Recommended Pole Solution

Lower Tube: DS-LOWER-13

Upper Pole: 7160-0178

Support Brace: 7160-0230

Poles ordered separately

(pg. 25-27)

Motion Attachment: 7160-0500

Motion Attachment ordered separately (pg. 29-33)

Weight Height Width Depth

7.15 lbs. 4.48" 18.14" 7.15"

7170-0503

Vehicle Kit includes vehicle base and the recommended pole solution as stated above.

No substitutions. For more detailed information please visit our website.

Features

- Can be used with factory installed console

- For extra stability, a Support Brace (Item No. 7160-0230) is recommended (pg. 27)

Note:

Rearward travel of the passenger seat is not affected, however there is limited forward seat travel

Item No.

Placement

Seat

Configuration Drilling Required

Recommended Pole Solution Weight Height Width Depth

7160-0572

Passenger side on the floor, under seat rails

Bucket

Yes - drilling is recommended but not required:

Chevrolet Equinox

(2010-2016)

GMC Terrain

(2010-2016)

Lower Tube: DS-LOWER-9

Upper Pole: 7160-0178

Support Brace: 7160-0230

Poles ordered separately (pg. 25-27)

Motion Attachment: 7160-0500

Motion Attachment ordered separately (pg. 29-33)

5.74 lbs.

4.8" 19.83" 6.68"

Features

- Can be used with factory installed console

- Due to inboard seat rail only having one pre-drilled hole, we strongly recommend drilling another hole due to

the weight of the equipment is on that rail, for more information visit our website.

- For extra stability, a Support Brace (Item No. 7160-0230) is recommended (pg. 27)

Note:

Rearward travel of the passenger seat is not affected, however there is limited forward seat travel

Item No.

Placement

Seat

Configuration

Drilling

Required

Recommended Pole Solution Weight Height Width Depth

7160-0590

Attaches to inboard and outboard passenger side seat studs

Bucket/

Split Bench

No - drilling is recommended but not required:

Toyota Prius

(2009-2016)

Lower Tube: DS-LOWER-13

Upper Pole: 7160-0178

Support Brace: 7160-0230

Poles ordered separately (pg. 25-27)

Motion Attachment: 7160-0500

Motion Attachment ordered separately (pg. 29-33)

7.35 lbs. 5.68" 18.75" 8.73"

7170-0235

Vehicle Kit includes vehicle base and the recommended pole solution as stated above.

No substitutions. For more detailed information please visit our website.

Features

- Installs in minutes with no drilling required

- Angled step moves pole away from passenger leg space

- Will not interfere with levers or factory installed consoles

- One Offset Universal Mounting Step (Item No. DS-STEP) is already included with this vehicle base. However, additional

Offset Universal Mounting Steps

can be ordered to stack on top of each other if needed (pg. 27)

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Shown: 7160-0556

Shown: 7160-0557

Shown: 7160-0572

Shown: 7160-0590

23

POLES

Center Upper poles

Page 25

Features/Benefits

- Allows for closer mounting to the dash

- Weight is centered on the pole

- Available in two heights: 7.22" and 10.22"

- Is recommended for use with the Mongoose or Locking Arms Motion Attachments

24

Page 25

lower tUbes

Features/Benefits

- Helps to clear the vehicle console or

transmission hump

- Available in four heights: 5.0", 7.0", 9.0"

and 13.0"

Page 25

Page 26 Page 27

QUiCk AdjUst Upper poles

Features/Benefits

- Quick adjust lever for left/right rotation

positions the equipment towards the

passenger or driver

- Set-collar stabilizes height while rotational

adjustments are made

- Available in three different depths (5.8", 8.0"

and 12.0") which extends the computer

away from the pole

sUpport brACes

Features/Benefits

- Telescoping design allows for precise length

adjustment without drilling into the pole

- Increases the mounting system rigidity in

rugged driving environments

- Available in two lengths

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

POLES

3" Center-Mounted Complete Poles

Item No.

Placement Height Adjustability Weight Height Width Depth

DS-POLE-CTR

Any

MCS Top Plate

or

Vehicle Base

without a welded pole No - welded pole 3 lbs. 4.65" 3.0" 3.0"

Features

- Specifically designed for low profile computer mounting in the Dodge Charger/Magnum police vehicle

- A Low Profile Motion Attachment (Item No. LOWSWIVEL) is recommended for use in the Dodge Charger/Magnum

police vehicle (pg. 33)

- Hardware for attaching to

MCS Top Plates

included (pg. 43)

- Is not compatible with the following Vehicle Bases (Item No. DS-52, DS-53, DS-56, DS-57, DS-100, DS-138, 7160-0090,

7160-0116, 7160-0133, 7160-0198, or 7160-0248)

Key Dimension - Affects Overall Height of Equipment

Shown: DS-POLE-CTR

Lower Tubes

Item No.

Placement Height Adjustability Weight Height Width Depth

DS-LOWER-5

DS-LOWER-7

Any

MCS Top Plate

or

Vehicle

Base

without a welded pole

Yes - from 5.0" - 7.0" adjustment includes upper pole 1.5 lbs.

Any

MCS Top Plate

or

Vehicle

Base

without a welded pole

Yes - from 7.0" - 9.0" adjustment includes upper pole 1.8 lbs.

5.0"

7.0"

3.0"

3.0"

3.0"

3.0"

DS-LOWER-9

Any

MCS Top Plate

or

Vehicle

Base

without a welded pole

Yes - from 9.0" - 14.25" adjustment includes upper pole 2.1 lbs.

9.0" 3.0" 3.0"

DS-LOWER-13

Any

MCS Top Plate

or

Vehicle

Base

without a welded pole

Yes - from 13.0" - 18.25" adjustment includes upper pole 2.65 lbs.

13.0" 3.0" 3.0"

Features

- Hardware for attaching to

MCS Top Plates

included (pg. 43)

- Is not compatible with the following

Vehicle Bases

(Item No. DS-52, DS-53, DS-56, DS-57, DS-100, DS-138, 7160-0090,

7160-0116, 7160-0133, 7160-0198, or 7160-0248)

Key Dimension - Affects Overall Height of Equipment

Shown: DS-LOWER-9

Center Upper Tubes

Item No.

Placement Height Adjustability Weight Height Width Depth

7160-0177

7160-0178

Inserts into:

- Any Gamber-Johnson

Lower Tube

-

Vehicle Base

that has a welded lower tube

Inserts into:

- 9" Lower Tube (Item No. DS-LOWER-9)

- (Item No. DS-LOWER-13)

-

Vehicle Base

that has a welded lower tube

Allows 0.38" to 2.76" adjustment above lip of

Lower Tube

Allows 0.38" to 5.76" adjustment above lip of

Lower Tube

Features

- Allows for closer mounting to the dash when off-set adjustability is not needed

- Less stress on the vehicle mounting equipment as weight is centered on the pole

- Wrench is needed for loosening, tightening and height adjustment

2.8 lbs. 7.22" 4.31" 3.0"

3.2 lbs. 10.22" 4.31" 3.0"

Shown: 7160-0178

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

25

26

POLES

Shown: DS-UPPER-M

Standard-Adjustable Upper Poles

Item No.

Placement Height Adjustability

DS-UPPER

DS-UPPER-5

DS-UPPER-M

Inserts into:

- 7" Lower Tube (Item No. DS-LOWER-7)

- 9" Lower Tube (Item No. DS-LOWER-9)

- 13" Lower Tube (Item No. DS-LOWER-13)

-

Vehicle Base

that has a welded lower tube

Inserts into:

- Any Gamber-Johnson

Lower Tube

-

Vehicle Base

that has a welded lower tube

Inserts into:

- 7" Lower Tube (Item No. DS-LOWER-7)

- 9" Lower Tube (Item No. DS-LOWER-9)

- 13" Lower Tube (Item No. DS-LOWER-13)

-

Vehicle Base

that has a welded lower tube

Inserts into:

- Any Gamber-Johnson

Lower Tube

-

Vehicle Base

that has a welded lower tube

Allows 0.38" - 5.76" adjustment above lip of of

Lower Tube

Allows 0.38" - 2.76" adjustment above lip

Lower Tube

Allows 2.18" - 5.76" adjustment above lip of

Lower Tube

DS-UPPER-M5

Allows 2.18" - 2.76" adjustment above lip of

Lower Tube

DS-UPPER-L

Inserts into:

- 7" Lower Tube (Item No. DS-LOWER-7)

- 9" Lower Tube (Item No. DS-LOWER-9)

- 13" Lower Tube (Item No. DS-LOWER-13)

-

Vehicle Base

that has a welded lower tube

Allows 2.18" - 5.76" adjustment above lip of

Lower Tube

Features

- Any

Motion Attachment

can be mounted on top of these

Upper Poles

.

- Wrench is needed for left/right rotational adjustments and height adjustments.

Key Dimension - Determines How Far Equipment Extends Away From Pole

Weight Height Width Depth

2.6 lbs. 8.00" 3.5" 5.8"

2.2 lbs. 5.00" 3.5" 5.8"

3.3 lbs. 8.00" 3.5" 8.0"

2.9 lbs. 5.00" 3.5" 8.0"

4.1 lbs. 8.00" 3.5" 12.0"

Shown: QADJ-UPPER-M

Quick-Adjustable Upper Poles

Item No.

Placement Height Adjustability Weight Height Width Depth

QADJ-UPPER-S

QADJ-UPPER-S5

QADJ-UPPER-M

QADJ-UPPER-M5

QADJ-UPPER-L

QADJ-UPPER-L5

Inserts into:

- 7" Lower Tube (Item No. DS-LOWER-7)

- 9" Lower Tube (Item No. DS-LOWER-9)

- 13" Lower Tube (Item No. DS-LOWER-13)

-

Vehicle Base

that has a welded lower tube

Inserts into:

- Any Gamber-Johnson

Lower Tube

-

Vehicle Base

that has a welded lower tube

Inserts into:

- 7" Lower Tube (Item No. DS-LOWER-7)

- 9" Lower Tube (Item No. DS-LOWER-9)

- 13" Lower Tube (Item No. DS-LOWER-13)

-

Vehicle Base

that has a welded lower tube

Inserts into:

- Any Gamber-Johnson

Lower Tube

-

Vehicle Base

that has a welded lower tube

Inserts into:

- 7" Lower Tube (Item No. DS-LOWER-7)

-

9" Lower Tube (Item No. DS-LOWER-9)

- 13" Lower Tube (Item No. DS-LOWER-13)

-

Vehicle Base

that has a welded lower tube

Inserts into:

- Any Gamber-Johnson

-

Vehicle Base

Lower Tube

that has a welded lower tube

Allows 0.38" - 5.76" adjustment above lip of lip of

Lower Tube

Allows 0.38" - 2.76" adjustment above lip of

Allows 2.18" - 5.76" adjustment above lip of

Lower Tube

Lower Tube

Allows 2.18" - 2.76" adjustment above

Lower Tube

Allows 2.18" - 5.76" adjustment above lip of

Lower Tube

Allows 2.18" - 2.76" adjustment above lip of

Lower Tube

3.1 lbs. 8.25"

2.2 lbs. 5.25"

3.3 lbs. 8.25"

2.9 lbs. 5.25"

4.1 lbs. 8.25"

4.4 lbs. 5.25"

3.5"

3.5"

3.5"

3.5"

3.5"

3.5"

5.8"

5.8"

8.0"

8.0"

12.0"

12.0"

Features

- Any

Motion Attachment

can be mounted on top of these

Upper Poles

.

- Convenient lever controls left/right rotational adjustments and height adjustments. Wrench is not needed for adjustments.

- Set-collar can be used to stabilize height while rotational adjustments are made.

Key Dimension - Determines How Far Equipment Extends Away From Pole

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

POLES

Low Profile Bracket

Item No.

Placement Weight Height Width Depth

ABF-KIT

Any

Vehicle Base

without a welded pole 0.8 lbs.

1.5" 3.0" 6.6"

Features

- Positions equipment low to the floor

- Hardware for attaching to

MCS Top Plates

included (pg. 43)

- Is not compatible with the following

Vehicle Bases

(Item No. DS-52, DS-53, DS-56, DS-57, DS-100, DS-138, 7160-0090,

7160-0116, 7160-0133, 7160-0198, or 7160-0248)

Shown: ABF-KIT

Offset Universal Mounting Step

Item No.

Placement Drilling Required Pole Weight Height Width Depth

DS-STEP

Any

MCS Top Plate

or

Vehicle Base

without a welded pole or directly to the vehicle floor

No-When mounting onto a

Vehicle

Base

or

MCS Top Plate

Yes-Drilling is required when mounting directly to the vehicle floor

Order

Lower and Upper Pole

separately

(pg. 25-27)

3.0 lbs.

4.0" 3.6" 3.5"

Features

- Offset design moves mounting system away from passenger leg space towards driver

- Will not interfere with levers or factory-installed console

- The

Offset Universal Mounting Step

is already included in the following

Vehicle Bases

(Item No. DS-112, DS-118,

DS-124, DS-144, DS-150, 7160-0036, 7160-0046, 7160-0055, 7160-0234, 7160-0256, 7160-0260, 7160-0262,

7160-0281, 7160-0323, 7160-0342, 7160-0350, 7160-0510, 7160-0520, 7160-0527, 7160-0532, 7160-0537, 7160-0544,

7160-0553, 7160-0554, 7160-0556, 7160-0557 or 7160-0572) however, additional

Offset Universal Mounting Steps

can

be ordered to stack on top of each other if needed.

- Is not compatible with the following

Vehicle Bases

(Item No. DS-52, DS-53, DS-56, DS-57, DS-100, DS-138,

7160-0090, 7160-0116, 7160-0133, 7160-0198, 7160-0248, or 7160-0451)

Rack-To-Post Platforms

Item No.

Placement Weight Height Width Depth

DS-74

Secures to any

Lower Tube

1.9 lbs.

4.0" 3.0" 6.0"

DS-74-L

Secures to any

Lower Tube

2.6 lbs.

3.56" 3.0" 9.38"

Features

- Provides additional mounting surface for radios, printers and other equipment

- Two muffler clamps are included for securing to pole

- Pre-drilled holes for use with the following Printer Mounts (Item No. 7160-0126, 7160-0392 or 7160-0507) (pg. 72-73)

Shown: DS-STEP

Shown: DS-74

Shown: DS-74-L

Support Braces

Item No.

Placement Weight

7160-0230

7160-0231

Pole clamp attaches to the

Lower Tube

, flattened surface on opposite end secures to vehicle floor, console or dash

Pole clamp attaches to the

Lower Tube

, flattened surface on opposite end secures to vehicle floor, console or dash

1.1 lbs.

1.5 lbs.

Features

- Designed for ease of installation

- Telescoping design allows for precise length adjustment without drilling into the pole

- Includes durable aluminum pole clamp that prevents catch points

- Increases the mounting system rigidity in rugged driving environments

Width

2.3"

2.3"

Depth

10.3" to 16.3"

10.3" to 35.3"

Shown: 7160-0230

Shown: 7160-0231

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

27

MOTION AT TACHMENTS

9" loCking slide Arm – mongoose

(7160-0220)

Page 32

Features/Benefits

- Locking slide arm can telescope 9.0" to 13.0" from center of the pole

- Uses a slam and lock technology that automatically locks the device in the retracted position when closing

- The entire arm can rotate around 360° with locking points every 15°

- Motion Attachment can rotate 360° allowing for maximum flexibility

28

Page 31

6" loCking slide Arm

(7160-0500)

Features/Benefits

- Locking slide arm can slide up to 5.5"

- The entire arm can rotate around 360° with

locking points every 15°

- Motion Attachment can rotate 360° for

maximum flexibility

Page 33

12" loCking slide Arm

(7160-0053)

Features/Benefits

- The entire arm can rotate around 360° with locking points every 15°

- Motion Attachment can rotate 360° allowing

for maximum flexibility

- 12” locking arm has 6 locking points 1.81" apart

Page 29

Clevis

(7160-0750)

Features/Benefits

- Built in swivel function allows mounting on

any flat, rigid surface as well as the traditional

application on a “smiley face” pattern

- Tilt capabilities allows the device to be used

with a traditional laptop or a tablet

- Open throat design and fixed mounting stud

make for easier installation

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

MOTION AT TACHMENTS

VESA 75mm & Gamber-Johnson Hole Pattern Clevis Motion Attachments

Item No. Description Placement Tilt Swivel Weight Height Width Depth

7160-0750

7160-0775

Standard

Short

Any Upper Pole, Compatible Pole,

Center Pole, Low Profile Bracket or directly to any flat surface

Yes - up to

90° fore/26° aft Yes - 360° 2.20 lbs. 2.17" 8.18" 4.40"

Any Upper Pole, Compatible Pole,

Center Pole, Low Profile Bracket or directly to any flat surface

Yes - up to

45° fore

Yes - 360° 2.20 lbs. 1.47" 7.23" 4.05"

7160-0776

Tall

Any Upper Pole, Compatible Pole,

Center Pole, Low Profile Bracket or directly to any flat surface

Yes - up to

90° fore/30° aft Yes - 360° 3.0 lbs. 5.71" 7.23" 4.40"

Features

- Clevis works with the following hole patterns (see pg. 3 for hole pattern definitions):

- VESA 75mm

- Gamber-Johnson 2x4

- NEC

- AMPS

- Does not require smiley face pattern (see pg. 3 for hole pattern definitions) for mounting. Built in swivel function allows

Clevis to be mounted on any flat, rigid surface. When mounted to a smiley face pattern the built in swivel function gives

the user more flexibility of the Clevis positioning during installation.

- Easier installation:

- Fixed mounting studs

- Rear fastening stud allows the Clevis to be locked in a fixed position

- Lever provides a secure clamping force when tilted

Shown: 7160-0750

Shown: 7160-0775

Shown: 7160-0776

3/8" Hole with VESA 75mm & Gamber-Johnson Hole Pattern Clevis Motion Attachment

Item No.

Placement Tilt Swivel Weight Height Width Depth

7110-1200

Any

Upper Pole, Compatible Pole, Center Pole, Low

Profile Bracket

. Has a 3/8" center hole for 360° rotation.

Is recommended to be used with

3/8" Stud Motion

Attachments (Item No. 7160-0427 or 7160-0514).

Yes - up to 90° fore/26° aft

Yes - 360° 2.20 lbs. 2.40" 8.18" 4.40"

Features

- Clevis works with the following hole patterns (see pg. 3 for hole pattern definitions):

- VESA 75mm

- Gamber-Johnson 2x4

- NEC

- AMPS

- Clevis can attach to any

Motion Attachment

that has a 3/8" Stud (Item No. 7160-0427 or 7160-0514)

- Rear fastening stud allows the Clevis to be locked in a fixed position

- Lever provides a secure clamping force when tilted

Shown: 7110-1200

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

29

30

MOTION AT TACHMENTS

Shown: LOWSWIVEL

Shown: 7160-0268

Shown: 7160-0436

Lowswivel VESA 75mm & Gamber-Johnson Hole Pattern Motion Attachments

Item No.

Placement Tilt Swivel Weight Height Width Depth

LOWSWIVEL

7160-0762

7160-0268

7160-0436

Any

Upper Pole, Compatible Pole, Center Pole,

Low Profile Bracket

Any

Upper Pole, Compatible Pole, Center Pole, Low

Profile Bracket

. Has a 3/8" center hole for 360° rotation.

Is recommended to be used with

3/8" Stud Motion

Attachments (Item No. 7160-0427 or 7160-0514).

No

No

Yes - 360° 1.4 lbs. 1.94" 5.25" 3.68"

Yes - 360° 0.35 lbs. 1.67" 5.25" 3.68"

Any

Upper Pole, Compatible Pole, Center Pole,

Low Profile Bracket

Any

Upper Pole, Compatible Pole, Center Pole, Low

Profile Bracket

. Has a 3/8" center hole for 360° rotation.

Is recommended to be used with

3/8" Stud Motion

Attachments (Item No. 7160-0427 or 7160-0514).

No - Motion

Attachment has a fixed angle of 10°

Yes - 360° 1.4 lbs. 2.52" 5.25" 3.65"

No - Motion

Attachment has a fixed angle of 10°

Yes - 360° 0.36 lbs. 2.52" 5.25" 3.65"

Features

- Clevis works with the following hole patterns (see pg. 3 for hole pattern definitions):

- VESA 75mm

- Gamber-Johnson 2x4

- NEC

- AMPS

- Provides a low profile for mounting equipment

Shown: 7160-0162

Mini-Clevis Motion Attachment

Item No.

Placement Tilt Swivel Weight Height Width Depth

7160-0162

Any

Upper Pole, Compatible Pole,

Center Pole, Low Profile Bracket

Yes - up to 72° fore/40° aft

Yes - up to 60° right/ 60° left

Features

- Clevis works with the following hole patterns (see pg. 3 for hole pattern definitions):

- NEC

- AMPS

- Designed to work with smaller handheld devices (rugged and non-rugged)

- Will hold devises up to 3.5 lbs.

- Ratching lever allows for easy tilting adjustment

1.04 lbs 2.62" 5.16" 3.13"

Shown: 7160-0497

6" Articulating Arm with VESA 75mm & Gamber-Johnson Hole Pattern Motion Attachment

Item No.

Placement Tilt Swivel Rotate Weight Height Width Depth

7160-0497

Any

Upper Pole, Compatible Pole, Center

Pole, Low Profile Bracket

or the

Universal

Portable Base (Item No. 7160-0033)

Yes - up to 90° fore/26° aft

Features

- Clevis works with the following hole patterns (see pg. 3 for hole pattern definitions):

- VESA 75mm

- Gamber-Johnson 2x4

- NEC

- AMPS

- Marine-grade aluminum to help prevent rusting

- Can tilt, swivel, pull-out and rotate equipment 360° to virtually any position for optimal computer placement

- Extends 6" bringing equipment close to the user

- Recommended for use with Universal Portable Base (Item No. 7160-0033) (pg. 14)

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

MOTION AT TACHMENTS

6" Locking Slide Arms with VESA 75mm & Gamber-Johnson Hole Pattern Motion Attachment

Item No.

Placement Tilt Rotate Slide Weight Height Width Depth

7160-0500

7160-0502

Any

Upper Pole,

Compatible Pole, Center

Pole, Low Profile Bracket

or directly to any flat surface

Yes - includes a

Standard

Clevis

Yes - up to

90° fore/26° aft

Motion Attachment

- 360°

Entire Arm - 360° can lock at every 15°

Yes - up to 5.5" fore/aft

4.9 lbs. 4.59" 7.23" 9.39"

Any

Upper Pole,

Compatible Pole, Center

Pole, Low Profile Bracket

or directly to any flat surface

Yes - includes a

Lowswivel

No - Motion

Attachment has a fixed angle of 10°

Motion Attachment

- 360°

Entire Arm - 360° can lock at every 15°

Yes - up to 5.5" fore/aft

4.7 lbs. 3.94" 5.25" 8.69"

Features

- Clevis works with the following hole patterns (see pg. 3 for hole pattern definitions):

- VESA 75mm

- Gamber-Johnson 2x4

- NEC

- AMPS

- The entire arm can rotate around 360° with locking points at every 15°

- To rotate the arm simply pull the front lever out, rotate to desired position and then release the lever

- Locking slide arm can slide up to 5.5" from the center of the pole

- Clevis Motion Attachment (7160-0500):

- Tilt capabilities:

- 90° forward allows for tablets to be easily mounted

- 26° aft movement

- Riveted design allows for smoother tilt movement

- Lowswivel Motion Attachment (7160-0502):

- Tilt capabilities:

- Fixed 10° angle for low profile mounting solution

Shown: 7160-0500

Shown: 7160-0502

6" Locking Slide Arm with 3/8" stud

Item No.

Placement

Motion Attachment

Included

Tilt Rotate Slide Weight Height Width Depth

7160-0514

Any

Upper Pole, Compatible

Pole, Center Pole, Low

Profile Bracket or directly to any flat surface

No - must use

Motion Attachment

(Item No. 7110-1200 or 7160-0436)

No

Entire arm -

360° can lock at every 15°

Yes - up to 5.5" fore/aft

3.63 lbs 2.43" 3.66" 8.74"

Features

- The entire arm can rotate around 360° with locking points at every 15°

- To rotate the arm simply pull the front lever out, rotate to desired position and then release the lever

- Locking slide arm can slide up to 5.5" from the center of the pole

- Designed to be used with the Gamber-Johnson

Clevis with a 3/8" hole (7110-1200) or Lowswivel with a 3/8" hole

(Item No. 7160-0436)

Shown: 7160-0514

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

31

32

MOTION AT TACHMENTS

Shown: 7160-0284

Quad-Motion Attachments with VESA 75mm & Gamber-Johnson Hole Pattern

Item No.

Placement Tilt Swivel Slide Weight Height Width Depth

7160-0284

7160-0285

Any

Upper Pole, Compatible

Pole, Center Pole, Low

Profile Bracket or directly to any flat surface

Any

Upper Pole, Compatible

Pole, Center Pole, Low

Profile Bracket or directly to any flat surface

Yes - up to 90° fore/26° aft

Motion Attachment

- 360°

Entire Arm - up to 60° right/60° left

Yes - up to

3.5" fore/aft 4.66 lbs 4.16" 7.23" 7.91"

Yes - up to 90° fore/26° aft

Motion Attachment

- 360°

Entire Arm - up to 60° right/60° left

Yes - up to

5.0" fore/aft 4.88 lbs 4.16" 7.23" 9.50"

Features

- Clevis works with the following hole patterns (see pg. 3 for hole pattern definitions):

- VESA 75mm

- Gamber-Johnson 2x4

- NEC

- AMPS

- Two separate pivot points allow for swiveling, sliding, swiveling again and tilting computer to ideal location

- Maximum range of motion allows for comfortable use by both driver and passenger

- Adjustments can be made easily by turning the quick adjustment knob and moving the equipment in the desired position

- Improved sliding plate for smoother forward and backward motion

Shown: 7160-0285

Shown: 7160-0220

Mongoose - 9" Locking Slide Arm with VESA 75mm & Gamber-Johnson Hole

Pattern Motion Attachment

Item No.

Placement Tilt Rotate Weight Height Width Depth

7160-0220

Any

Upper Pole, Compatible

Pole, Center Pole, Low

Profile Bracket or directly to any flat surface

Yes - includes a

Standard

Clevis

Yes - up to

90° fore/

26° aft

Motion Attachment - 360°

Entire arm - 360° can lock at every 15°

6.9 lbs 4.64" 7.23" 11.34"

Features

- Design is protected by US Patent Number 8,511,629

- Clevis works with the following hole patterns (see pg. 3 for hole pattern definitions):

- VESA 75mm

- Gamber-Johnson 2x4

- NEC

- AMPS

- The entire arm can rotate around 360° with locking points at every 15°

- To rotate the arm simply pull the front lever out, rotate to desired position and then release the lever

- Locking slide arm can telescope 9” to 13” from the center of the pole and allows you to simply push the computer back

to the retracted position and it automatically locks into place

- Heavy duty, spring loaded steel, side pin was tested to 50,000+ cycles

Shown: 7160-0427

Mongoose - 9" Locking Slide Arm with 3/8" stud

Item No.

Placement

Motion Attachment

Included

Tilt

7160-0427

Any

Upper Pole,

Compatible Pole, Center

Pole, Low Profile Bracket or directly to any flat surface

No - must use

Motion Attachment

(Item No. 7110-1200 or 7160-0436)

No

Rotate Weight Height Width Depth

Entire arm - 360° can lock at every 15°

5.2 lbs 4.0” 4.0” 12.0”

Features

- Design is protected by US Patent Number 8,511,629

- The entire arm can rotate around 360° with locking points at every 15°

- To rotate the arm simply pull the front lever out, rotate to desired position and then release the lever

- Locking slide arm can telescope 9" to 13" from the center of the pole and allows you to simply push the computer back

to the retracted position and it automatically locks into place

- Heavy duty, spring loaded steel, side pin was tested to 50,000+ cycles

- Designed to be used with the Gamber-Johnson Clevis with 3/8" Hole (Item No. 7110-1200) or Lowswivel with 3/8" Hole

(Item No. 7160-0436)

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

MOTION AT TACHMENTS

Locking Swing Arm with VESA 75mm & Gamber-Johnson Hole

Pattern Motion Attachment

Item No.

Placement

Motion Attachment

Included

Tilt Rotate Weight Height Width Depth

7160-0341

Any

Upper Pole, Compatible

Pole, Center Pole, Low

Profile Bracket or directly to any flat surface

Yes - includes a Standard

Clevis

Yes - up to

90°fore/

26° aft

Motion Attachment

- 360°

Entire arm - 360° can lock at every 15°

5.90 lbs. 3.59" 7.23" 14.50"

Features

- Clevis works with the following hole patterns (see pg. 3 for hole pattern definitions):

- VESA 75mm

- Gamber-Johnson 2x4

- NEC

- AMPS

- The entire arm can rotate around 360° with locking points at every 15°

- To rotate the arm simply pull the front lever out, rotate to desired position and then release the lever

- Ideal for work trucks and vans

Shown: 7160-0341

12" Locking Slide Arm with VESA 75mm & Gamber-Johnson Hole

Pattern Motion Attachment

Item No.

Placement

Motion Attachment

Included

Tilt Rotate Weight Height Width Depth

7160-0053

Any

Upper Pole, Compatible

Pole, Center Pole, Low

Profile Bracket or directly to any flat surface

Yes - includes a Standard

Clevis

Yes - up to

90°fore/

26° aft

Motion Attachment

- 360°

Entire arm - 360° can lock at every 22.5°

5.4 lbs. 5.04" 7.29" 16.81"

Features

- Clevis works with the following hole patterns (see pg. 3 for hole pattern definitions):

- VESA 75mm

- Gamber-Johnson 2x4

- NEC

- AMPS

- The entire arm can rotate around 360° with locking points at every 22.5°

- To rotate the arm simply pull the front lever out, rotate to desired position and then release the lever

- 12" locking arm has 6 locking points 1.81" apart

- Locking pin can be placed oneither side of the base giving the user easy access no matter where the arm is installed

- A backing plate is included with the arm

Shown: 7160-0053

Universal Adapter

Item No.

Placement Weight Height Width Depth

7160-0454

Between any Screen/Display or Docking Station with a VESA 75mm or 100mm, NEC,

AMPS, Havis, Jotto or PMT hole pattern and any Gamber-Johnson Motion Attachment 0.85 lbs. 0.97" 5.0" 5.0"

Features

- Compatible with screens/displays or Docking Station that utilize the VESA 75mm or 100mm, NEC, AMPS, Havis, Jotto

or PMT hole pattern and allows you to attach the Gamber-Johnson standard hole pattern (see pg. 3 for hole pattern

definitions)

- Adapter plate can be mounted to flat surfaces

- Built-in cable restraint tie for service loops

- Adapter plate includes pem’s for easy installation

Shown: 7160-0454

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

33

MISSION CONTROL SYSTEM (MCS)

Chevrolet tahoe/Silverado (2015)

Page 37

Recommended Solution:

9" Locking Slide Arm – Mongoose (7160-0220) (pg. 32)

Features/Benefits

- Vehicle specific console

- Vertical, angled section accommodates 7.5" of mounting space

- Horizontal, low profile section accommodates 7.0" of mounting

space (11.5" without an internal cupholder)

- USB/MP3/SD card from factory console can be relocated on

passenger side using knock-outs

- Available in four different configurations:

1. Console Box Only

2. Console Box, Armrest and Internal Cupholder

3. Console Box and Wiring Chase

4. Console Box, Armrest, Internal Cupholder and Wiring Chase

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

MISSION CONTROL SYSTEM (MCS)

Page 39 Page 39 Page 38

Ford utility poliCe interCeptor

Recommended Solution:

9” Locking Slide Arm – Mongoose (7160-0220) (pg. 32)

Features/Benefits

- Vehicle specific console

- Vertical angled section accommodates 7.5"

of mounting space

- Horizontal low profile section accommodates

7.0" of mounting space (11.5" without internal

cupholder)

- Available in two different configurations:

1. Console Box Only

2. Console Box, Armrest and Internal Cupholder

Ford Sedan poliCe interCeptor

Recommended Solution

Quad-Motion TS5 (7160-0285) (pg. 32)

Features/Benefits

- Vehicle specific console

- Vertical angled section accommodates 7.5"

of mounting space

- Horizontal low profile section accommodates

7.0" of mounting space (11.5" without internal

cupholder)

- Available in two different configurations:

1. Console Box Only

2. Console Box, Armrest and Internal Cupholder

dodge Charger

Recommended Solution

6" Locking Slide Arm (7160-0500) (pg. 31)

Features/Benefits

- Vehicle specific console

- Vertical, angled section accommodates 7.5" of

mounting

- Horizontal, low profile section accommodates

9.0" of mounting space (13.5" without internal

cupholder)

- Available in two different configurations:

1. Console Box Only

2. Console Box, Armrest and Internal Cupholder

Ford F-150 (2011-2015)

Recommended Solution:

Vehicle MCS Leg Kit (7160-0164) (pg. 42)

MCS Top Plate (7160-0085) (pg. 43)

MCS Epic 13" Console Box (MCS-EPIC13) (pg. 43)

Features/Benefits

- No drill vehicle leg kit

- Pole solution can be attached directly to the

top plate

- Solution can be customized to fit your radio/

device needs

Ford F-250 to F-750 Super duty

Recommended Solution:

Vehicle MCS Leg Kit (7160-0301) (pg. 42)

MCS Top Plate (7160-0085) (pg. 43)

MCS Epic 13" Console Box (MCS-EPIC13) (pg. 43)

Features/Benefits

- No drill vehicle leg kit

- Pole solution can be attached directly to the

vehicle leg kit using threaded PEMS

- Solution can be customized to fit your radio/

device needs

ram 1500-5500

Recommended Solution

Vehicle MCS Leg Kit (7160-0422) (pg. 42)

MCS Top Plate (7160-0085) (pg. 43)

MCS Epic 13" Console Box (MCS-EPIC13) (pg. 43)

Features/Benefits

- No drill vehicle leg kit

- Pole solution can be attached directly to the

top plate

- Solution can be customized to fit your radio/

device needs

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

35

MISSION CONTROL SYSTEM (MCS)

Shown: 7160-0521-00

2014-2016 Chevrolet Caprice (PPV) Solutions

Consoles

Item No.

Description Seat Configuration Weight Height Width Depth

7160-0521-00

Vehicle Specific Console only Bucket 22.0 lbs.

8.5" 9.75" 29.6"

7160-0521-01

Vehicle Specific Console with armrest and cupholder

Bucket 24.5 lbs.

8.5" 9.75" 29.6"

7170-0221

Vehicle Kit includes Console Box (7160-0521-01) and Motion Attachment (7160-0500).

No substitutions. For more detailed information please visit our website.

Features

- Low profile no-drill vehicle specific console for the Chevy Caprice Police Patrol Vehicle (PPV)

- Attaches directly to the Chevy Caprice PPV without the need to order a separate top plate, four fasteners for mounting

the console allows for easy installation

- Horizontal, low profile section:

- Accommodates 2 to 4 devices (14.5" of mounting space) without an internal cup holder or 1 to 2 devices (10.0" of

mounting space) with an internal cup holder

- Has a consistent mounting space height of 4.28"

- Designed to house remote or control head devices and accessories

- Vertical, angled section:

- Accommodates 1 full sized device (3" of mounting space)

- Box will ship fully assembled (except for accessories)

- Computer can be center mounted in two locations:

- Off -set towards the passenger on the “smiley face pattern”

- On the 3-bolt pattern closer to the driver for easy articulation access

- Fully welded construction for long term product life span

- 3 faceplates and 3 filler panels are included (pg. 49-59)

- For a list of armrests and accessories that work with this box see pg. 40

Shown: 7160-0521-01

Shown: 7160-0380 & 7160-0386

Caprice Trunk Shelf (2011-2016)

Item No.

Description Seat Configuration Weight Height

7160-0380

7160-0386

Trunk Shelf

Front rail for use with Trunk Shelf

Yes

No

43.0 lbs.

12.4"

3.8 lbs.

Features

- Full width trunk shelf for Chevy Caprice PPV (9C1 and 9C3)

- Push button activation for easy release

- Features magnetic stop when the trunk is extended (in the event of inclined parking)

- Access to batteries and the spare tire with the trunk is in the closed position

- Cable restraint holes included on the back of the tray

- Trunk Shelf is rated for 150 lbs.

- Has a hole pattern for mounting the Computer Mounting Platform (Item No. 7160-0398)

- Available mounting space 36.0" W x 20.0" D

4.1"

Width

43.0"

36.9"

Depth

24.8"

0.6"

36

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

MISSION CONTROL SYSTEM (MCS)

2007-2014 Chevrolet Tahoe (PPV and SSV) Solutions

Consoles

Item No.

Description

Seat

Configuration

7160-0434

Vehicle Specific Console with armrest and cupholder Bucket

Weight Height Width Depth

27.5 lbs.

14.8" 9.3" 33.6"

7160-0435

Vehicle Specific Console only Bucket 21.5 lbs.

12.4" 9.3" 33.6"

7170-0222

Vehicle Kit includes Console Box (7160-0434) and Motion Attachment (7160-0220).

No substitutions. For more detailed information please visit our website.

Features

- Low profile no-drill vehicle specific console for the Chevy Tahoe (PPV and SSV)

- Attaches directly to the Chevy Tahoe without the need to order a separate top plate, leg kit is provided with the console box

- Horizontal, low profile section:

- Accommodates 4 to 6 devices (11.5" of mounting space) without an internal cup holder or 2 to 4 devices (7.0" of

mounting space) with an internal cup holder

- Has a consistent mounting space height of 8.01"

- Designed to house full sized devices and accessories

- Vertical, angled section:

- Accommodates 1 to 2 full sized devices (6" of mounting space)

- Traction control can be relocated to the top of the console box with the included bracket

- Two 12 volt plug inserts (located on passenger side), one 12 volt cigarette adapter kit included with box

- Side wings and top mounting plate can be removed for easy access to wiring

- Box will ship fully assembled (except for accessories)

- Computer can be mounted in the off-set position on the “smiley face pattern” located on the top of the console

(accommodates any

Tablet Display Mount

or any Gamber-Johnson

Motion Attachment

, ordered separately)

- Fully welded construction for long term product life span

- 3 faceplates and 3 filler panels are included (pg. 49-59)

- For a list of armrests and accessories that work with this box see pg. 40

Note:

Does not require a top plate. A leg kit comes with the console box to attach to the vehicle.

Shown: 7160-0434

Shown: 7160-0435

2015-2016 Chevrolet Tahoe (PPV), 2015-2016 Chevrolet Silverado Solutions

Consoles

Item No.

Description

Seat

Configuration

Weight Height Width Depth

7170-0237-xx

Vehicle Kits include the Console Box (7160-0548) and the Leg Kit (7160-0509), plus the accessories listed below. No Substitutions. For more detailed information, please visit our website.

7170-0237-00

Vehicle Specific Console only Bucket 18.5 lbs. 14.82" 13.71" 24.92"

7170-0237-01

Vehicle Specific Console with armrest and cupholder Bucket 22.0 lbs. 16.41" 13.71" 26.67"

7170-0237-02

Vehicle Specific Console and wiring chase Bucket 23.3 lbs. 14.82" 13.71" 37.75"

7170-0237-03

7170-0237-04

Vehicle Specific Console with armrest, cupholder and wiring chase

Vehicle Specific Console with armrest, cupholder, wiring chase and motion attachment

Bucket

Bucket

26.8 lbs. 16.41" 13.71" 39.50"

33.7 lbs. 19.46" 13.71" 39.50"

Features

- Low profile, no-drill vehicle specific console for the Chevy Tahoe (2016), Chevy Silverado 1500 (2015-2016), and

Chevy Silverado 2500/3500/HD (2016)

- Attaches directly to the Chevy Tahoe and Silverado vehicles without the need to order a separate top plate, leg kit is

provided with the 7170-0237 kit numbers

- See Utility Specific Box (Item No. 7160-0548) on pg. 45 for more features

Shown: 7170-0237-00

Shown: 7170-0237-01

Shown: 7170-0237-02

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Shown: 7170-0237-03

37

38

MISSION CONTROL SYSTEM (MCS)

Shown: 7160-0326

Shown: 7160-0327

2011-2016 Dodge Charger Solutions

Consoles

Item No.

7160-0326

Description

Vehicle Specific Console only

Seat

Configuration

Bucket

Weight Height Width Depth

18.0 lbs. 10.10" 14.14" 35.66"

7160-0327

Vehicle Specific Console with armrest and cupholder Bucket 24.0 lbs. 10.58" 14.14" 40.21"

7170-0137

Vehicle Kit includes Console Box (7160-0327) and Motion Attachment (7160-0500).

No substitutions. For more detailed information please visit our website.

Features

- Low profile no-drill vehicle specific console for the Dodge Charger

- Attaches directly to the Dodge Charger without the need to order a separate top plate, five fasteners for mounting the

console allows for easy installation

- Horizontal, low profile section:

- Accommodates 4 to 6 devices (13.5" of mounting space) without an internal cup holder or 1 to 2 devices (9.0" of

mounting space) with an internal cup holder

- Has amounting space height range of 3.6" to 5.67"

- Designed to house remote or control head devices and accessories

- Vertical, angled section:

- Accommodates 1 to 3 full sized devices (7.5" of mounting space)

- A removable top plate and center plate for easy radio installation and wire routing

- Ships with molded dash filler panels that gives the box a sleek appearance that blends in with the car’s aesthetics

- Five, 12 Volt knock-outs (4 on the back and 1 on driver side)

- USB and MP3 knock-outs from stock console, relocated on passenger side

- Computer can be center mounted in two locations:

- Off -set towards the passenger on the “smiley face pattern”

- On the 3-bolt pattern closer to the driver for easy articulation access

- Box will ship fully assembled (molded dash panels must be installed on-site)

- Fully welded construction for long term product life span

- 3 faceplates and 3 filler panels are included (pg. 50-59)

- For a list of armrests and accessories that work with this box see pg. 40

- Console box is not compatible with legacy Dodge Chargers

Charger Trunk Shelf (2011-2016)

Item No.

Description Drilling Required Weight Height Width

7160-0336

Upper Shelf

No

18.0 lbs.

10.10" 14.01"

Features

- Strong, lightweight aluminum alloy

- Upper tray slides on heavy-duty ball bearing slides and can latch securely in the closed and open position

- Available mounting space 37.75" W x 18.5" D

Depth

35.66"

Shown: 7160-0336

Shown: 7160-0580-00

Shown: 7160-0580-01

2014-2016 Dodge Durango Solutions

Consoles

Item No.

7160-0580-00

Description

Vehicle Specific Console only

Seat

Configuration

Bucket

Weight Height Width Depth

20.0 lbs. 11.2" 9.0" 37.9"

7160-0580-01

Vehicle Specific Console with armrest and cupholder Bucket 24.0 lbs. 15.4" 9.0" 41.8"

Features

- Low profile no-drill vehicle specific console for the Dodge Durango

- Attaches directly to the Dodge Durango without the need to order a separate top plate, four fasteners for mounting the

console allows for easy installation

- Includes two faceplates:

- A shifter plate with cutout for the center console shifter

- A traction control/OEM plate (needed only if vehicle has a traction control module)

- Horizontal, low profile section:

- Accommodates 4 to 6 devices (12.0" of mounting space) without an internal cup holder and traction control,

1 to 2 devices (4.5" of mounting space) with an internal cup holder and traction control

- Has a consistent mounting space height of 6.8”

- Designed to house remote or control head devices and accessories

- Vertical, angled section:

- Accommodates 1 full sized device (6.0" of mounting space)

- Removable top plate and center brace can be removed for easy access to wiring

- Ships with dash filler panels that gives the box a sleek appearance that blends in with the car’s aesthetics

- Fully welded construction for long term product life span

- Threaded pems provided for mounting armrest to the console

- Two knockouts for 12 volt plug inserts (located on passenger side)

- Will ship fully assembled (except for wings and accessories)

- 3 faceplates and 3 filler panels are included (pg. 50-59)

- For a list of armrests and accessories that work with this box see pg. 40

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

MISSION CONTROL SYSTEM (MCS)

2012-2016 Ford Sedan Police Interceptor Solutions

Consoles

Item No.

Description

Seat

Configuration

Weight Height Width Depth

7160-0409

Vehicle Specific Console with armrest and cupholder Bucket 24.0 lbs. 11.5" 9.0" 30.8"

7160-0410

Vehicle Specific Console only Bucket 18.0 lbs. 11.5" 9.0" 27.0"

7170-0165

Vehicle Kit includes Console Box (7160-0409) and Motion Attachment (7160-0285).

No substitutions. For more detailed information please visit our website.

Features

- Low profile no-drill vehicle specific console for the Ford Sedan Police Interceptor (PI)

- Attaches directly to the Ford Sedan PI without the need to order a separate top plate, six fasteners for mounting the

console allows for easy installation

- Horizontal, low profile section:

- Accommodates 4 to 6 devices (11.5" of mounting space) without an internal cup holder or 1 to 2 devices (7.0" of

mounting space) with an internal cup holder

- Has amounting space height range of 4.13" to 6.56"

- Designed to house remote or control head devices and accessories

- Vertical, angled section:

- Accommodates 1 to 3 full sized devices (7.5" of mounting space)

- A removable top plate and center plate for easy radio installation and wire routing

- Ships with molded dash filler panels that gives the box a sleek appearance that blends in with the car’s aesthetics

- 12 volt plug insert (located on passenger side)

- Computer can be mounted in the off-set position on the “smiley face pattern” located on the top of the console

(accommodates any

Tablet Display Mount

or any Gamber-Johnson

Motion Attachment

, ordered separately)

- Box will ship fully assembled (except for accessories)

- Fully welded construction for long term product life span

- 3 faceplates and 3 filler panels are included (pg. 50-59)

- For a list of armrests and accessories that work with this box see pg. 40

Sedan Trunk Shelf (2012-2016)

Item No.

Description Drilling Required Weight Height

7160-0438

7160-0386

Trunk Shelf

Front rail for use with Trunk Shelf

Yes

No

47.0 lbs.

13.6"

3.8 lbs.

Features

- Push button activation for easy release

- Features magnetic stop when the trunk is extended (in the event of inclined parking)

- Access to batteries and the spare tire with the trunk is in the closed position

- Cable restraint holes included on the back of the tray

- Trunk Shelf is rated for 125 lbs.

- Has a hole pattern for mounting the Computer Mounting Platform (Item No. 7160-0398)

- Available mounting space 35.5" W x 20.25" D

4.1"

Width

41.9"

36.9"

Depth

24.6"

0.6"

2012-2016 Ford Utility Police Interceptor Solutions

Consoles

Item No.

Description

Seat

Configuration

7160-0411

Vehicle Specific Console with armrest and cupholder Bucket

Weight Height Width Depth

24.0 lbs. 11.5" 9.0" 30.8"

7160-0412

Vehicle Specific Console only Bucket 18.0 lbs. 11.5" 9.0" 27.0"

7170-0166

Vehicle Kit includes Console Box (7160-0411) and Motion Attachment (7160-0220).

No substitutions. For more detailed information please visit our website.

Features

- Low profile no-drill vehicle specific console for the Ford Utility Police Interceptor (PI)

- Attaches directly to the Ford Utility PI without the need to order a separate top plate, six fasteners for mounting the

console allows for easy installation

- Horizontal, low profile section:

- Accommodates 4 to 6 devices (11.5" of mounting space) without an internal cup holder or 1 to 2 devices (7.0" of

mounting space) with an internal cup holder

- Has amounting space height range of 6.15" to 8.46"

- Designed to house remote or control head devices and accessories

- Vertical, angled section:

- Accommodates 1 to 3 full sized devices (7.5" of mounting space)

- A removable top plate and center plate for easy radio installation and wire routing

- Ships with molded dash filler panels that gives the box a sleek appearance that blends in with the car’s aesthetics

- 12 volt plug insert (located on passenger side)

- Box will ship fully assembled (except for accessories)

- Computer can be center mounted in two locations:

- Off -set towards the passenger on the “smiley face pattern”

- On the 3-bolt pattern closer to the driver for easy articulation access

- Fully welded construction for long term product life span

- 3 faceplates and 3 filler panels are included (pg. 50-59)

- For a list of armrests and accessories that work with this box see pg. 40

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Shown: 7160-0409

Shown: 7160-0410

Shown: 7160-0438

Shown: 7160-0411

Shown: 7160-0412

39

40

MISSION CONTROL SYSTEM (MCS)

Shown: 14422

Shown: 7110-0998

Shown: 7110-1001

Shown: 7160-0429

Shown: 7160-0431

Shown: 7110-1201

Shown: 7110-1012

Shown: 7160-0430

Vehicle Specific Console Box Accessories

The table below shows the compatibility of the accessories that are designed to work with the vehicle specific console boxes. For more detailed information and images please visit our website

Item No.

13791

13792

14422

15250

7110-0998

7110-0999

Description

Lind Factory Set Shut

Down Timer

Lind Adjustable Shut

Down Timer

Charger USB/Phone

Jack/12 Volt Relocation

Filler Panel

Tahoe USB/MP3/SD

Card Reader/Factory

12 Volt Relocation Filler

Panel

Caprice Passenger Side

Armrest

Caprice Driver Side

Armrest

Chevrolet

Caprice

Console

(2014-2016)

Chevrolet

Tahoe

Console

(2007-2014)

Chevrolet

Tahoe/

Silverado

Console

(2015-2016)

Dodge

Charger

Console

(2011-2016)

Dodge

Durango

Console

(2014-2016)

Ford

Sedan PI

Console

(2012-

2016)

Ford

Utility PI

Console

(2012-

2016)

Yes

Yes

Yes

Yes

Yes

Yes

Utility

Specific

Box

Yes

Yes

Yes

Yes

Yes

7110-1001

7110-1012

7110-1013

Interior Armrest

Tahoe Passenger Side

Armrest

Tahoe Driver Side

Armrest

7110-1024

Tahoe Wiring Chase

Yes

Yes

Yes

Yes

Yes

Yes Yes Yes

Yes

Yes

7120-0579

Ford Utility USB/Audio

Relocation Cable Kit

7160-0110

Power Distribution Block

7160-0313

Power Distribution Block with Negative Bus

7160-0429

7160-0430

7160-0431

7160-0444

7160-0464

Exterior Armrest

Exterior Brother Printer

Armrest

Ford Utility USB/

Audio/12 Volt Relocation

Filler Panel and Cable

Kit

Ford Sedan/Utility Wiring

Cover

Tahoe Passenger Side

Accessory Mounting Box

7110-1201

7160-0524

MCS-

CUPHOLD2

Tahoe Side Panels

note: can’t be used with wiring chase packages

(Item No. 7160-0548-02 and 7160-0548-03)

Exterior Break Away

Armrest

Universal Heavy-Duty

Cupholder

note: can’t be used with

Exterior Armrests

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Shown: 7160-0464

Shown: 7160--0524

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

MISSION CONTROL SYSTEM (MCS)

MAX

3

Visor Camera Mount

Item No.

Description Drilling Required Weight Height Width Depth

7160-0325

Camera bracket mounted using the passenger side visor retainer

Yes - Attaches to the existing passenger side visor retainer, recommended to use self tapping screws for additional stability

1.3 lbs. 2.37" 2.56" 9.37"

Features

- Utilizes MAX

3

knuckles for X, Y, Z axis movement

- Will support cameras up to three pounds

- Passed shock and vibe testing to MIL STD 810 G

- 1 year limited warranty

Shown: 7160-0325

MCS Vehicle Kits:

Includes recommended MCS Leg Kit, Top Plate, Console Box, Pole Solution, Cupholder and Armrest.

Sold as a Kit, no substitutions. For more detailed information please visit our website.

Item No.

Drilling Required

7170-0128

7170-0132

7170-0134

7170-0143

No - attaches to inboard seat bolts of driver and passenger seat studs:

Ford Expedition (2007-2016)

No - attaches to inboard seat bolts of driver and passenger seat studs:

Ford F-250 to F-750 Super Duty Automatics Only

(2011-2016)

No - attaches to inboard seat bolts of driver and passenger seats:

Ford F-150 (2009-2014)

Yes - drilling is required for the rear only, front legs attach to seat studs:

Chevrolet Impala (2006-2016 PPV only)

Items in Kit

MCS Leg Kit: 7160-0084

Top Plate: 7160-0085

Console Box: MCS-ERGOBOX12

Pole Solution: DS-LOWER-9

7160-0178

Motion Attachment: 7160-0220

Armrest: MCS-ARMREST

Cupholder: MCS-CUPHOLD2

MCS Leg Kit: 7160-0301

Top Plate: 7160-0085

Console Box: MCS-EPIC13

Pole Solution: 7160-0106

DS-LOWER-9

7160-0178

7160-0230

Motion Attachment: 7160-0220

Armrest: MCS-ARMREST

Cupholder: MCS-CUPHOLD2

MCS Leg Kit: 7160-0164

Top Plate: 7160-0085

Console Box: MCS-EPIC13

Pole Solution: 7160-0106

DS-LOWER-9

7160-0178

7160-0230

Motion Attachment: 7160-0220

Armrest: MCS-ARMREST

Cupholder: MCS-CUPHOLD2

MCS Leg Kit: 7160-0121

Top Plate: 7160-0086

Console Box: 7160-0237

Pole Solution: MCS-COMBRKT

Motion Attachment: 7160-0285

Shown: 7170-0128

Shown: 7170-0132

Shown: 7170-0134

Shown: 7170-0143

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

41

42

MISSION CONTROL SYSTEM (MCS)

Step One

Step One:

Select the MCS Leg Kit for your type of vehicle.

Shown: 7160-0422

Shown:

7160-0413

Shown: 7160-0555

Shown: 7160-0301

Shown: 7160-0160

Shown: 7160-0509

Shown: 7160-0088

Shown: 7160-0589

Shown: 7160-0164

Shown: 7160-0084

Shown: 7160-0121

MCS Vehicle Leg Kits

Item No.

7160-0088

7160-0422

7160-0589

Placement

On top of the transmission hump

On top of the transmission hump

Attaches to the mounting points on the side of the transmission hump

Seat

Configuration

Bucket

Bucket

Bucket

Drilling Required

No - attaches to the mounting points on side of the transmission hump:

Ram ProMaster (2014-2016)

Weight

No - attaches to the existing studs on top of the transmission hump:

Dodge Charger (2006-2016)

Dodge Magnum (2006-2008)

No - attaches to the existing studs on top of the transmission hump:

Ram 1500-5500 Retail Models (2011-2016)

Ram 1500-5500 SSV Models (2012-2016)

4.6 lbs.

7.2 lbs.

6.92 lbs.

7160-0413

7160-0164

7160-0555

7160-0084

7160-0301

7160-0552

On top of the transmission hump

On top of the transmission hump

On top of the transmission hump

On both sides of the transmission hump

On top of transmission hump

Attaches to the mounting points on the side of the transmission hump

Bucket

Bucket

Bucket

Bucket

Bucket

Bucket

No - attaches to the existing studs on top of the transmission hump:

Ford Sedan Police Interceptor (2012-2016)

Ford Utility Police Interceptor (2012-2016)

No - Requires removal of the center seat and attaches to the seat mounting points:

Ford F-150 (2009-2014)

1.8 lbs.

4.0 lbs.

No - attaches to the existing studs on top of the transmission hump:

Ford F-150 Aluminum Body (2015-2016)

6.8 lbs.

No - attaches to the inboard seat bolts of the driver and passenger seat:

Ford Expedition (2007-2016)

No - attaches to inboard driver and passenger side seat studs:

Ford F-250 to F-750 Super Duty (2011-2016)

9.91 lbs.

12.0 lbs.

No - attaches to the mounting points on side of the transmission hump:

Ford Transit (2015-2016)

4.75 lbs.

7160-0121

7160-0160

7160-0509

7160-0575

7110-0350

On both sides of the transmission hump

On both sides of the transmission hump

On top of the transmission hump

Attaches to the mounting points on the side of the transmission hump

On both sides of the transmission hump

Bucket

Bucket

Bucket

Bucket

Bucket

Yes - drilling is required for the rear only, front legs attach to seat studs:

Chevrolet Impala (2006-2016 PPV only)

No - Requires removal of the center console & attaches to console mounting points:

Chevrolet 1500/2500/3500 C/K (2007-2009)

Chevrolet Avalanche (2007-2013)

Chevrolet Silverado 1500 (2007-2013)

Chevrolet Silverado 2500/3500 (2007-2014)

Chevrolet Suburban (2007-2014)

Chevrolet Tahoe (2007-2014)

GMC Sierra1500 (2007-2013)

GMC Sierra 2500/3500 (2007-2014)

GMC Yukon/Yukon XL (2007-2014)

4.5 lbs.

3.8 lbs.

No - attaches to the existing studs on top of the transmission hump:

Chevrolet Silverado 1500 (2014-2016)

Chevrolet Silverado 2500/3500 (2015-2016)

Chevrolet Tahoe (2015-2016)

GMC Sierra 1500 (2014-2016)

GMC Sierra 2500/3500 (2016)

GMC Yukon XL (2015-2016)

7.2 lbs.

No - attaches to the mounting points on side of the transmission hump:

Chevrolet Express Van (2010-2016)

GMC Savana (2010-2016)

Yes - drilling is required:

Universal - All Vehicles

15.1 lbs.

1.2 lbs.

Shown: 7110-0350

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

MISSION CONTROL SYSTEM (MCS)

Step Two:

Select the MCS Top Plate that best fits your equipment needs.

Keep in mind the number of radios you will need to mount and any accessories (armrest, cupholders, etc…).

MCS Top Plates

Item No.

Description Placement

Seat

Configuration

Drilling Required Weight Width Depth

7160-0086

Short MCS

Top Plate

Any

MCS

Vehicle Leg

Bucket

No -

MCS Vehicle Legs

holes alongside

attach to pre-drilled

MCS Top Plate

9.9 lbs. 8.0" 23.0"

7160-0085

Long MCS

Top Plate

Any

MCS

Vehicle Leg

Bucket

No -

MCS Vehicle Legs

holes alongside

attach to pre-drilled

MCS Top Plate

12.4 lbs. 8.0" 29.0"

Features:

- Wider design allows the console box to be offset towards the passenger for added space

- Wider plate adds additional space to mount additional accessories

- Provides three (3) options for computer mount placement (offset towards driver, center or offset towards passenger side)

- Fills up space between the seats giving a cleaner appearance

Step Two

Shown: 7160-0086

Step Three:

Select the MCS Console Box that best fits your equipment needs.

EPIC Console Boxes

Item No.

MCS-EPIC9

MCS-EPIC13

Placement

On any MCS Top Plate (Item

No. 7160-0086 or 7160-0085)

On any MCS Top Plate (Item

No. 7160-0086 or 7160-0085)

Seat

Configuration

Bucket

Bucket

Drilling

Required

No

No

No. of

Devices Weight

2 to 4 8.8 lbs.

Exterior

Height

7.5" to

11.5"

Exterior

Width

9.0"

9.0"

Exterior

Depth

9.0"

13.0"

Interior

Depth

7.0"

11.0"

MCS-EPIC17

On any MCS Top Plate (Item

No. 7160-0086 or 7160-0085)

Bucket

No

9.0" 17.0" 15.0"

Features

- Rounded-edges for sleek appearance and passenger safety

- Two-piece flexible design allows for 36 ht/angle combinations (18 ht/angle combination for Item No. MCS-EPIC9)

- 12 knockout panels and multiple cutouts for cigarette adapters (10 knockout panels in Item No. MCS-EPIC9)

- Cutout pattern for light mount on each side

- Large cutout holes in bottom and on both sides for wiring access

- Pre-drilled sidewall & bottom slots for convenient mounting; Mounting holes align with many competitive top plates

- 2 Faceplates and 2 filler panels are included with MCS-EPIC 9 (pg. 50-59)

- 3 Faceplates and 3 filler panels are included with MCS-EPIC 13 and MCS-EPIC 17 (pg. 49-59)

Step Three

Shown: MCS-EPIC13

Ergonomic Console Box

Item No.

MCS-ERGOBOX12

Placement

On any

MCS Top Plate

(Item No. 7160-0086 or

7160-0085)

Seat

Configuration

Bucket

Drilling

Required

No

No. of

Devices

3 to 5 (10" of mounting space)

10.0 lbs. 9.5" 9.0" 13.0" 10.91"

Features

- Rounded-edges for sleek appearance and passenger safety

- May be mounted towards the dash of any vehicle creating added space between the seats for other equipment or

easier passenger side exit

- Enclosed design enables communication equipment to be stored securely and safely

- Available Computer Mounting Bracket (Item No. MCS-COMBRKT) for added versatility

- Mounting holes align with many competitive top plates

- 3 Faceplates and 3 filler panels are included (pg. 50-59)

Shown: MCS-ERGOBOX12

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

43

44

MISSION CONTROL SYSTEM (MCS)

Shown: 7160-0237

Low Profile Ergonomic Console Box

Item No.

Placement

Seat

Configuration

Drilling

Required

No. of Devices Weight Height Width Depth Interior

7160-0237

On any MCS Top Plate (Item

No. 7160-0086 or 7160-0085)

Bucket

No

3 to 5 (10" of radio mounting space) 17.75 lbs 8.5" 8.75" 21.76" 10.98"

Features

- Ergonomically designed console box that provides two mounting positions for motion devices on the top of the console box

- Reduced height allows the console to be positioned closer to the dash

- Top plate can be removed during installation for better access to electronics

- Large cutout on top plate allows for easy access to wiring

- Two piece flexible design allows for many height and angle combinations

- 9 Knockout panels for cigarette adapters

- Large cutout holes on bottom for wiring access

- Pre-drilled sidewall & bottom slots for convenient mounting

- Pre-drilled holes for use with any Gamber-Johnson cup holder

- Rounded edges for sleek appearance

- 3 Faceplates and 3 filler panels are included (pg. 50-59)

Shown: 7160-0333

Shown: MCS-LOWBOX

Shown: 7160-0770

13" Low Profile Ergonomic Console Box

Item No.

7160-0333

Placement

On any

MCS Top Plate (Item

No. 7160-0086 or 7160-0085)

Seat

Configuration

Bucket

Drilling

Required

No

No. of

Devices Weight

3 to 5

17.75 lbs.

Height Width Depth

8.5" 9.06"

Interior

Depth

13.33" 10.66"

Features

- Ergonomically designed console box that provides two mounting positions for motion devices on the top of the console box

- Reduced height allows the console to be positioned closer to the dash

- Top plate can be removed during installation for better access to electronics

- Two piece flexible design allows for many height and angle combinations

- 9 Knockout panels for cigarette adapters

- Large cutout holes on bottom for wiring access

- Pre-drilled sidewall & bottom slots for convenient mounting

- Pre-drilled holes for use with any Gamber-Johnson cup holder

- Rounded edges for sleek appearance

- 3 Faceplates and 3 filler panels are included (pg. 50-59)

Low Profile Console Box

Item No.

MCS-LOWBOX

Placement

On any

MCS Top Plate

(Item No. 7160-0086 or 7160-0085)

Seat

Configuration

Bucket

Drilling

Required No. of Devices Weight

No

4 to 5 (12" of control head mounting space)

12 lbs.

Height

4" (low end) to

6" (high end)

9.0" 14.0" 12.1"

Features

- May be mounted towards the dash of any vehicle creating added space between the seats for other equipment

- Low-profile design sits flush or slightly below the seats allowing ample space for an emergency passenger side exit

- Enclosed design enables communication equipment to be stored securely and safely

- Available Computer Mounting Bracket (Item No. MCS-COMBRKT) for added versatility

- Mounting holes align with many competitive top plates

- 3 Faceplates and 3 filler panels are included (pg. 50-59)

25" Universal Console Box

Item No.

Placement

Seat

Configuration

Drilling

Required Weight

Height Width Depth

7160-0770

On any

MCS Leg Kits

(Item No. 7160-0086 or 7160-0085) Bucket

No

22.5 lbs. 8.36" to 11.36" 8.75" 8.75"

Features

- 24.5" of straight mounting space plus 0.5" of overlap space to allow faceplates to fit flush

- Designed to house full sized devices and accessories

- Height adjustable with no side gaps in the console, ranges from 8.36" to 11.36"

- Angle adjustable at any height, ranges from 0° to 9°

- Adjustable support bracket in the center to strengthen the console box, along with fixed gussets in the bottom

- Can accommodate a power distribution block or Lind shut-down timer on the Front Plate

- Can accommodate most console box accessories including armrests, exterior cup holder, side pocket, DS-138 etc.

For a list of armrests and accessories that work with this box see pg. 40

- Side pole mount ( DS-138 , Sold Separately) is angle adjustable to keep the pole vertical

- Rear armrest can be angle adjusted be using spacers on the bottom two bolts

- Three mounting locations on the side of the box for a mic clip or Adjustable Mic Clip (Item No. 7160-0826)

- Six 12V knockout panels for cigarette adapters

- Fully welded construction for long term product life span

- Box will ship fully assembled (except for accessories)

- 3 faceplates and 3 filler panels are included (pg. 50-59)

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

MISSION CONTROL SYSTEM (MCS)

Utility Specific Box

Item No.

Placement

Seat

Configuration

Drilling

Required

No. of

Devices Weight Height Width Depth

Interior

Depth

7160-0548

On most Vehicle Specific Leg Kits Bucket

No

5 to 8 18.5 lbs. 11.84" 8.99" 24.75" 11.75"

Features

- Low profile, no-drill vehicle specific console that works with the following Leg Kits:

Silverado/Tahoe/Sierra/Yukon (Item No. 7160-0509) , Ford F-150 (2015+) (Item No. 7160-0555) , Ram ProMaster Van

(Item No. 7160-0589) , Dodge Ram Truck (Item No. 7160-0422)

- Horizontal, low profile section:

- Has a consistent mounting space height of 8.0"

- Designed to house fill sized devices and accessories

- Vertical, angled sections:

- Accommodates 1 to 2 full sized devices (7.5" of mounting space)

- Two 12 volt plug inserts (located on passenger side)

- USB/MP3/SD card from factory console can be relocated on the passenger side using the provided knock-outs or

by purchasing separately a relocation faceplate (Item No. 15250)

- Front plate of console (underneath dash) has placement for a power distribution block or Lind shut-down timer

using pre-configured mounted holes

- Wiring Chase bolts onto the front of the console to cover/hide the wires for a finished look and is adjustable to fit

both the Tahoe and Silverado

- Box will ship fully assembled (except for accessories)

- Computer can be center mounted in two locations:

- Off -set towards the passenger on the “smiley face pattern”

- On the 3-bolt pattern closer to the driver for easy articulation access

- Fully welded construction for long term product life span

- 3 faceplates and 3 filler panels are included (pg. 50-59)

- For a list of armrests and accessories that work with this box see pg. 40

Note:

Does not require a top plate.

Step Four:

Select the MCS Accessories that fits your equipment needs.

MCS Filler Panels

Item No.

Description Placement Weight Height Width Depth

3130-0152

15130

3130-0153

3130-0154

1/2" Blank Filler Panel On top of any

MCS Console Box

0.10 lbs.

0.50"

3/4" Blank Filler Panel On top of any

MCS Console Box

0.15 lbs.

0.75"

1.0" Blank Filler Panel On top of any

MCS Console Box

0.20 lbs.

2.0" Blank Filler Panel On top of any

MCS Console Box

0.30 lbs.

1.0"

2.0"

3130-0155

3.0" Blank Filler Panel On top of any

MCS Console Box

0.40 lbs.

3130-0156

4.0" Blank Filler Panel On top of any

MCS Console Box

0.50 lbs.

Features

- Fills space in console boxes not occupied by equipment

3.0"

4.0"

8.7"

8.7"

8.7"

8.7"

8.7"

8.7"

0.075"

0.075"

0.075"

0.075"

0.075"

0.075"

Shown: 7160-0548

Step Four

Shown: 3130-0361

MCS Accessories - Cigarette Knockout Filler Panel

Item No.

Description Placement Weight Height Width

3130-0361

2.0" Cigarette Knockout Filler Panel On any

MCS Console Box

0.40 lbs.

2.0"

Features

- Three holes for mounting the Cigarette Receptacle (Item No. 7160-0063)

8.7"

Depth

0.075"

Shown: 3130-0361 & 7160-0063

MCS Accessories - Cigarette Lighter Adapter Kit

Item No.

Description Placement

7160-0063

Cigarette Lighter

Adapter Kit

On the side of any

MCS Console Box

or with 2.0"

Cigarette Knockout Filler Panel (Item No. 3130-0361)

Features

- Kit includes one (1) RoHS compliant 12 volt receptacle, wire kit and cap

Weight Height Diameter

0.05 lbs.

2.5" 1.12"

Shown: 7160-0063

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

45

46

MISSION CONTROL SYSTEM (MCS)

Shown: 15082

Shown: 15083

MCS Accessories - Rocker Switch/Dual USB Port Knockout Filler Panels

Item No.

Placement Placement Weight Height Width Depth

15082

3 Rocker Switch/Dual USB Port and 3 Cigarette

Knockout Panel

On any

MCS Console Box

0.36 lbs. 2.0" 8.7" 0.08"

15083

6 Rocker Switch/Dual USB Port Knockout Panel On any

MCS Console Box

0.36 lbs. 2.0" 8.7" 0.08"

Features

- Knockouts work with Rocker Switches (Item No. 7160-0516 or 7160-0517), Cigarette Receptacle (Item No. 7160-0063)

or Dual USB Port (Item No. 15371)

Shown: 7160-0516 and 15082

MCS Accessories - Rocker Switches

Item No.

Description Placement

7160-0516

7160-0517

7160-0540

Rocker Switch (ON/OFF/ON) -

4 contacts (Ground, Input, 2 Outputs)

Rocker Switch (ON/OFF) -

3 contacts (Ground, Input, Output)

Rocker Switch (Momentary ON/OFF) -

2 contacts (Input and Output)

With

Rocker Switch Filler Panels

(Item No. 15082 or 15083)

With

Rocker Switch Filler Panels

(Item No. 15082 or 15083)

With

Rocker Switch Filler Panels

(Item No. 15082 or 15083)

Features

- Red LED light is visible when switch is in the “ON” position

- Rated for 20 Amps

- Rated for 12 Volts DC

- RoHS compliant

Weight Height Width Depth

0.09 lbs. 2.05" 0.96" 1.93"

0.09 lbs. 2.05" 0.96" 1.93"

0.09 lbs. 2.05" 0.96" 1.93"

Shown: 7160-0516

Shown: 15371

MCS Accessories - Dual USB Port

Item No.

Description Placement Weight Height Width Depth

15371

Dual USB Port (two 2.1 Amp ports, one 1.0 Amp port)

With

Rocker Switch/Dual USB Port Filler

Panels (Item No. 15082 or 15083)

Features

- Quick and easy way to recharge electronic devices in a vehicle

- Output: 5 Vdc, 4.2 Amps total

- Input: 11-16 Vdc

0.25 lbs. 1.80" 1.0" 1.73"

Shown: MCS-ARMREST

Shown: MCS-ARMREST5

Shown: 7160-0525

MCS Accessories - Heavy-Duty Armrest

Item No.

MCS-ARMREST

MCS-ARMREST5

Placement

Regular Armrest with 9" Lower Tube

Regular Armrest with 5" Lower Tube

Height Adjustment

2.5" adjustment above the lip of

Lower Tube

1.6" adjustment above the lip of

Lower Tube

Weight Height Width Depth

6.10 lbs.

5.50 lbs.

11.5" 5.25" 10.0"

8.15" 5.25" 10.0"

7160-0525

7.00 lbs.

11.5" 5.25" 10.0"

Common Features

- Attaches to any MCS Top Plate, the MCS-ARMREST5 is recommended for the Dodge Charger vehicle

- Sturdy design for addition support

- Height adjustable

- Padded armrest flips up for convenience

Break Away Armrest Features

- Armrest pad slides forwards 2" for a comfortable armrest position

- Armrest swivels 100° from the driver to help minimize injury to the driver when in a side impact situation

- Both the slide and the swivel offer an adjustable tension feature

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

MISSION CONTROL SYSTEM (MCS)

Brother Armrest Printer Mount

Item No.

Placement Height Adjustment Weight Height

7160-0006

On top of any

MCS Top Plate

or any flat stable surface

1.6" adjustment above lip of

Lower Tube

11.25 lbs.

15.0"

(includes 5" pole)

Features

- Convenient flip-up armrest and printer mount all in one

- For use with the following Brother printers:

PocketJet 200 PocketJet 3 PocketJet 6 PocketJet 7

PocketJet II PocketJet 3 Plus PocketJet 6 Plus (NiMH battery only)

- Mount holds printer and paper roll in separate lockdown trays

- Paper roll is enclosed to protect from dirt and dust

- The cover latches shut and can be used with a padlock for extra security

- Indicator lights and on/off button are easy to see and accessible when the cover is closed

- Paper deflector prevents paper from curling up and jamming

- Cable strain relief protects connector interface on the printer engine from damage

- Printer can be easily removed from the mount for use outside of the vehicle

- Paper feeds out the side towards the driver (Paper and printer not included)

- The cover latches shut and can be used with a padlock for extra security

Width Depth

5.5" 11.6"

Shown: 7160-0006

MCS Accessories - Extended Panel Armrest

Item No.

Placement Weight

7160-0375

On top of most Gamber-Johnson

MCS Console

Boxes

and

Vehicle Specific Consoles Boxes

1.3 lbs.

Features

- Padded, height adjustable faceplate armrest

- Perfect for vehicle specific consoles or vehicles that have space constraints

Height

2.0"

Width

8.7"

Depth

4.75" to 5.5"

Shown: 7160-0375

MCS Accessories - Adjustable Cupholder (Single and Double)

Item No.

Placement Weight Height Width Depth

MCS-CUP

Attaches to pre-drilled holes on either end of any

MCS Console Box

2.4 lbs. 4.0" 9.75" 6.0"

MCS-CUP2

Attaches to pre-drilled holes on either end of any

MCS Console Box

2.4 lbs. 4.0" 9.75" 6.0"

Features

- Hold one (MCS-CUP) or two (MCS-CUP2) cups and compatible with most cup sizes

- No drilling is required

MCS Accessories - Universal Heavy-Duty Cupholder (Double)

Item No.

Placement Weight Height Width Depth

MCS-CUPHOLD2

Attaches to pre-drilled holes on either end of any

MCS Console Box

2.8 lbs. 3.2" 8.75" 4.5"

Features

- Holds two cups and compatible with most cup sizes

- No drilling is required

Shown: MCS-CUP2

Shown: MCS-CUPHOLD2

MCS Accessories - Internal Mounted Cupholder (Double)

Item No.

Placement Weight

MCS-INTCUP

Inserts into any

MCS Console Box

Features

- Holds two cups; Compatible with most cup sizes

- No drilling is required

0.5 lbs.

Height

4.5"

Width

8.63"

Depth

3.4"

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Shown: MCS-INTCUP

47

48

MISSION CONTROL SYSTEM (MCS)

MCS Accessories - Side-Mounted LED Task Light

Item No.

Placement Weight Height Width Depth

7160-0100

Attaches to pre-drilled holes on either end of any

MCS Console Box

0.80 lbs.

12.0" 3.0" 1.25"

Features

- Rugged construction for long-term durability

- Flexible design

- On/off switch allows you two (2) different LED color combinations: white or red

- Can be positioned either over or away from radios

- No drilling is required

Shown: 7160-0100

Shown: 7160-0110

Shown: 7160-0313

MCS Accessories - Power Distribution Block

Item No.

Description Placement

Drilling

Required

7160-0110

6 Circuit Power

Distribution Block

Can be positioned in any convenient location

Features

- 6 circuit block without a negative bus

- Clear insulating cover with label recesses that accepts Small Format Labels

- Tin-plated copper busses and fuse clips give 30 amperes rating per circuit

- Accepts ATO and ATC fast acting blade fuses

- Four thru holes for mounting

- Maximum Amperage per Circuit: 30 Amperes

- Maximum Amperage per Block: 100 Amperes

- Maximum Voltage Rating: 32 Volts DC

Yes

Weight Height Width Depth

0.42 lbs 1.5" 3.63" 3.30"

MCS Accessories - Power Distribution Block with Negative Bus

Item No.

Description Placement

Drilling

Required

Weight Height Width Depth

7160-0313

6 Circuit Power Distribution

Block with Negative Bus

Can be positioned in any convenient location

Yes

0.42 lbs 1.5"

Features

- 6 independent ground connections on to a ground bus and separate master ground bus connection

- Clear insulating cover with label recesses that accepts Small Format Labels

- Tin-plated copper busses and fuse clips give 30 amperes rating per circuit

- Accepts ATO and ATC fast acting blade fuses

- Four thru holes for mounting

- Maximum Amperage per Circuit: 30 Amperes

- Maximum Amperage per Block: 100 Amperes

- Maximum Voltage Rating: 32 Volts DC

3.63" 3.30"

MCS Accessories - Tall Interior Pocket

Item No.

Placement

MCS-POCKET3

Works with any Gamber-Johnson

Console Box

Features

- Ideal for holding pens, keys and other miscellaneous items

Weight

2.4 lbs.

Height

3.0"

Width

7.25"

Depth

6.06"

Shown: MCS-POCKET3

Shown: 7160-0332

MCS Accessories - Short Interior Pocket

Item No.

Placement

7160-0332

7160-0597

Works with any Gamber-Johnson

Console Box, Low Profile

Box (Item No. MCS-LOWBOX), or any Vehicle Specific Console Box

Works with any Gamber-Johnson

Console Box, Low Profile

Box (Item No. MCS-LOWBOX), or any Vehicle Specific Console Box

Features

- Ideal for holding pens, keys and other miscellaneous items

- Drain holes located in the bottom of the pocket

Weight Height Width Depth

1.85 lbs. 3.0" 8.60" 3.26"

2.8 lbs. 6.0" 8.60" 3.26"

Shown: 7160-0597

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

MISSION CONTROL SYSTEM (MCS)

MCS Accessories - Locking Interior Pocket

Item No.

Placement Weight Height Width Depth

7160-0388

Tall Locking Pocket works with any Gamber-Johnson

Console Box,

7160-0389

Short Locking Pocket fits any

MCS EPIC Console Box, Low Profile Box

(Item No. MCS-LOWBOX), or any Vehicle Specific Console Box

Features

- Locking lid with barrel key lock

- Ideal for weapons, keys and other miscellaneous items

3.1 lbs.

3.1"

3.9 lbs.

6.1"

8.6"

8.6"

6.3"

3.5"

Shown: 7160-0388

Shown: 7160-0389

MCS Accessories - Computer Mounting Bracket

Item No.

Placement Weight Height Width Depth

MCS-COMBRKT

Attaches to pre-drilled holes on each side of the

Ergonomic

Console Boxes (Item No. MCS-ERGOBOX12, 71600237, 7160-0333) or the Low Profile Box (Item No. MCS-LOWBOX)

Features

- Keeps computer low in vehicle and out of the air bag zone

- Computer can be mounted in the center or offset

3.5 lbs. 5.0" 9.61" 3.0"

Shown: MCS-COMBRKT

MCS Accessories - Side Extension Mounting Plate

Item No.

Description Placement Weight Height Width Depth

7160-0106

Side Extension

Mounting Plate

Attaches to pre-drilled holes along side of any new

MCS Top Plate (Item No. 7160-0085 or 7160-0086)

1.0 lb.

1.5"

Features

- Provides an offset mounting surface for any

Complete DS Pole Assembly or Lower Tube Assembly

5.0" 3.65"

Shown: 7160-0106

MCS Accessories - Microphone Clip Panel

Item No.

Placement

MCS-MICPLT

On top of any

MCS Console Box

Features

- Heavy gauge steel construction for long-term durability

- Black powdercoat finish for maximum corrosion resistance

- Can hold up to three microphone clips

- Spacer provided to raise clip for easier use

- Microphone clip sold separately (Item No. 9000-0053)

Weight

0.50 lb.

Height

2.25"

Width

8.7"

Depth

1.0"

Shown: MCS-MICPLT

MCS Accessories - Adjustable Mic Clip

Item No.

Placement Weight Height Width Depth

7160-0826

Attaches to pre-drilled holes on the 25” Universal Console Box or by drilling to any

MCS Console Box

1.00 lbs. 7.51"

Features

- Can be positioned either over or away from radios

- Heavy gauge steel construction for long-term durability

- Height adjustable, range of 2.5”

- No drilling is required for 25” Universal Console Box, Drilling is required for other MCS Console Boxes

1.45" 2.50"

MCS Accessories - Rail-Mounted Microphone Clip

Item No.

Placement Weight Height Width Depth

MCS-EPICMIC

Attaches to pre-drilled holes on either end of any

MCS Console Box

0.80 lbs. 2.25" 1.75" 1.50"

Features

- Can be positioned either over or away from radios

- No drilling is required

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Shown: 7160-0826

Shown: MCS-EPICMIC

49

50

MISSION CONTROL SYSTEM (MCS)

Shown: 7160-0337

MCS Accessories - Code 3 MasterCon Siren Full Faceplate

Item No.

Placement Weight Height Width Depth

7160-0337

Works with any Gamber-Johnson

Console Box

and the Code 3 MasterCon Siren 0.60 lb. 3.5" 8.62" 3.33"

Features

- Designed for use with the Code 3 MasterCom Siren control

- Full Faceplate secures the Code 3 MasterCom Siren control into any Gamber-Johnson

Console Box

- Interior mounting dimensions: 6.78"W x 2.78"H

Shown: 7160-0569

Shown: 11511

Shown: 7160-0406

Shown: 3130-0237

MCS Accessories - Code 3 Xcel Siren Box Full Faceplate

Item No.

Placement Weight Height Width Depth

7160-0569

Works with any Gamber-Johnson

Console Box

and the Code 3 Xcel Siren Box 0.45 lbs. 3.0"

8.60" 2.83"

Features

- Designed for use with the Code 3 Xcel Siren Box

- Full Faceplate secures the Code 3 Xcel Siren Box into any Gamber-Johnson

Console Box

- Interior mounting dimensions: 6.36" W x 2.70" H

MCS Accessories - Code 3 Z3 Series Full Faceplate

Item No.

Placement Weight Height Width Depth

11511

Works with any Gamber-Johnson

Console Box

and the Code 3 Z3 Series

0.67 lbs. 3.38" 8.63" 0.89"

Features

- Designed for use with the Code 3 Z3 Series

- Full Faceplate secures the Code 3 Z3 Series into any Gamber-Johnson

Console Box

MCS Accessories - EF Johnson 5300 ES Series Mobile Radio/

EF Johnson Lightning Control Head Full Faceplate

Item No.

Placement Weight Height Width Depth

7160-0406

Works with any Gamber-Johnson

Console Box

and the EF Johnson

5300 ES Series Mobile Radio/EF Johnson Lightning Control Head

0.50 lbs.

3.0"

Features

- Designed for use with the EF Johnson 5300 ES Series Mobile Radio/EF Johnson Lightning Control Head

8.62" 3.58"

- Full Faceplate secures the EF Johnson 5300 ES Series Mobile Radio/EF Johnson Lightning Control Head into any

Gamber-Johnson

- Interior mounting dimensions: 7.19"W x 2.11"H

MCS Accessories - Federal Signal e-Q2B/Premium Vision/SmartSiren Full Faceplate

Item No.

Placement Weight Height Width Depth

3130-0237

Works with any Gamber-Johnson

Console Box

and the Federal

Signal e-Q2B/Premium Vision/SmartSiren control

0.70 lbs.

3.25" 8.62" 0.88"

Features

- Designed for use with the Federal Signal e-Q2B/Premium Vision/SmartSiren control

- Full Faceplate secures theFederal Signal e-Q2B/Premium Vision/SmartSiren into any Gamber-Johnson

Console Box

MCS Accessories - Federal Signal Smart Siren/Platinum Full Faceplate

Item No.

Placement Weight Height Width Depth

7160-0338

Works with any Gamber-Johnson

Console Box

and the Federal Signal Smart Siren/Platinum 0.65 lbs. 4.25" 8.62" 1.2"

Features

- Designed for use with the Federal Signal Smart Siren/Platinum

- Full Faceplate secures the Federal Signal Smart Siren/Platinum into any Gamber-Johnson

Console Box

- Interior mounting dimensions: 6.86"W x 3.31"H

Shown: 7160-0338

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

MISSION CONTROL SYSTEM (MCS)

MCS Accessories - Harris M7300 Full Faceplate

Item No.

Placement Weight Height Width Depth

7160-0523

Works with any Gamber-Johnson

Console Box

and the Harris M7300 0.42 lb.

3.0" 8.62" 2.58"

Features

- Designed for use with the Harris M7300 Radio

- Full Faceplate secures the Harris M7300 Radio into any Gamber-Johnson

Console Box

- Interior mounting dimensions: 6.94"W x 2.4"H

Shown: 7160-0523

MCS Accessories - Harris Unity XG-100M Control Head Full Faceplate

Item No.

Placement Weight Height Width Depth

7160-0432

Works with any Gamber-Johnson

Console Box

and the Harris Unity XG-100M control head 0.40 lbs. 4.50" 8.62" 1.88"

Features

- Designed for use with the Harris Unity XG-100M control head

- Full Faceplate secures the Harris Unity XG-100M control head into any Gamber-Johnson

Console Box

- Interior mounting dimensions: 7.09"W x 3.44"H

MCS Accessories - ICOM ID-5100 Control Head Full Faceplate

Item No.

Placement Weight Height Width Depth

16082

Works with any Gamber-Johnson

Console Box

and the ICOM ID-5100 control head 0.44 lbs. 3.5" 8.62" 0.71"

Features

- Designed for use with the ICOM ID-5100 control head

- Full Faceplate secures the ICOM ID-5100 control head into any Gamber-Johnson

Console Box

- Allows use of magnet mounting from ICOM for ease of removing control head

- Interior mounting dimensions: 7.13"W x 3.19"H

Shown: 7160-0432

Shown: 16082

MCS Accessories - ICOM IC-2730 Control Head Full Faceplate

Item No.

Placement Weight Height Width Depth

16328

Works with any Gamber-Johnson

Console Box

and the ICOM IC-2730 control head 0.40 lbs. 3.0" 8.62" 0.5"

Features

- Designed for use with the ICOM ID-2730 Control Head

- Allows to be mounted with PEM’s on back side of control head

- Allows use of magnet mounting option from ICOM for ease of removing control head

- Interior mounting dimensions: 5.88" W X 2.00" H

MCS Accessories - Kenwood NX-700/NX-800/TK-7180/TK-8180/MPT Series Radio

Full Faceplate

Item No.

Placement Weight Height Width Depth

16030

Works with any Gamber-Johnson

Console Box

and the

Kenwood NX-700/NX-800/TK-7180/TK-8180/MPT Series Radio

0.36 lbs.

2.5" 8.62" 3.27"

Features

- Designed for use with the Kenwood NX-700/NX-800/TK-7180/TK-8180/MPT Series Radio

- Full Faceplate secures the Kenwood NX-700/NX-800/TK-7180/TK-8180/MPT Series Radio into any Gamber-Johnson

Console Box

- Interior mounting dimensions: 6.38” W x 1.75” H

Shown: 16328

Shown: 16030

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

51

52

MISSION CONTROL SYSTEM (MCS)

Shown: 7160-0466

MCS Accessories - Kenwood TK-790 Radio Full Faceplate

Item No.

Placement Weight Height Width Depth

7160-0466

Works with any Gamber-Johnson Console Box and the Kenwood TK-790 Radio 0.50 lbs. 3.0" 8.62" 3.25"

Features

- Designed for use with the Kenwood TK-790 Radio

- Full Faceplate secures the Kenwood TK-790 Radio into any Gamber-Johnson

Console Box

- Interior mounting dimensions: 7.32"W x 2.39"H

Shown: 7160-0465

MCS Accessories - Kenwood TK-980 and TK-981 Radio Full Faceplate

Item No.

Placement Weight Height Width Depth

7160-0465

Works with any Gamber-Johnson Console Box and the Kenwood TK-980 and TK-981 Radio 0.40 lbs. 2.0" 8.62" 2.72"

Features

- Designed for use with the Kenwood TK-980 and TK-981 Radios

- Full Faceplate secures the Kenwood TK-980 and TK-981 Radios into any Gamber-Johnson

Console Box

- Interior mounting dimensions: 5.53"W x 1.61"H

Shown: 7160-0522

Shown: 7160-0459

Shown: 7160-0462

Shown: 7160-0267

MCS Accessories - L3 Mobile-Vison Flashback3 Video Recorder Full Faceplate

Item No.

Placement Weight Height Width Depth

7160-0522

Works with any Gamber-Johnson

Console Box

and the L3 Communication Flashback3 0.38 lb. 3.0" 8.62" 2.43"

Features

- Designed for use with the L3 Communication Flashback3 In-Car Digital Video Recorder

- Full Faceplate secures the L3 Communication Flashback3 into any Gamber-Johnson

Console Box

- Interior mounting dimensions: 6.94" W x 2.44" H

MCS Accessories - Motorola 8 Button DEK Full Faceplate

Item No.

Placement Weight Height Width Depth

7160-0459

Works with any Gamber-Johnson

Console Box

and the Motorola 8 Button DEK (Single) 0.25 lbs. 2.0" 8.62" 1.75"

7160-0462

Works with any Gamber-Johnson

Console Box

and the Motorola 8 Button DEK (Dual) 0.50 lbs. 3.5" 8.62" 1.75"

Features

- Designed for use with the Motorola 8 Button DEK (Single or Dual)

- Full Faceplate secures the Motorola 8 Button DEK (Single or Dual) into any Gamber-Johnson

Console Box

- Interior mounting dimensions for Motorola 8 Button DEK (Single): 6.56"W x 1.28"H

- Interior mounting dimensions for Motorola 8 Button DEK (Dual): 6.56"W x 2.56"H

MCS Accessories - Motorola APX 09 Full Faceplate

Item No.

Placement Weight Height Width Depth

7160-0267

Works with any Gamber-Johnson

Console Box

and the Motorola APX 09 Integrated Control Head 0.80 lb. 8.0" 8.62" 1.68"

Features

- Designed for use with the Motorola APX 09 Integrated Control Head

- Full Faceplate secures the Motorola APX 09 into any Gamber-Johnson

Console Box

- Interior mounting dimensions: 7.53"W x 7.06"H

Shown: 7160-0467

MCS Accessories - Motorola CDM Series Radio Full Faceplate

Item No.

Placement Weight Height Width Depth

7160-0467

Works with any Gamber-Johnson

Console Box

and the Motorola CDM Series Radio 0.40 lbs. 3.0" 8.62" 3.60"

Features

- Designed for use with the Motorola CDM Series Radio

- Full Faceplate secures the Motorola CDM Series Radio into any Gamber-Johnson

Console Box

- Interior mounting dimensions: 6.96" W x 2.36" H

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

MISSION CONTROL SYSTEM (MCS)

MCS Accessories - Motorola PM1500 Series Radio Full Faceplate

Item No.

Placement Weight Height Width Depth

7160-0538

Works with any Gamber-Johnson

Console Box

and the Motorola PM1500 Series Radio 0.35 lbs. 3.0" 8.62" 1.79"

Features

- Designed for use with the Motorola PM1500 Series Radio

- Full Faceplate secures the Motorola PM1500 Series Radio into any Gamber-Johnson

Console Box

- Interior mounting dimensions: 7.26" W x 2.36" H

Shown: 7160-0538

MCS Accessories - Motorola XPR 5550/6550 Full Faceplate

Item No.

Placement Weight Height Width Depth

7160-0587

Works with any Gamber-Johnson

Console Box

and the Motorola

XPR 5550/6550 Control Head and Full Radio

0.32 lbs.

2.5" 8.62" 3.36"

Features

- Designed for use with the Motorola XPR 5550/6550 Control Head and Full Radio

- Full Faceplate secures the Motorola XPR 5550/6550 Control Head and Full Radio into any Gamber-Johnson

Console Box

- Interior mounting dimensions: 6.734" W x 2.10" H

Shown: 7160-0587

MCS Accessories - Motorola XTL 2500/5000 Full Faceplate

Item No.

Placement Weight Height Width Depth

7160-0321

Works with any Gamber-Johnson

Console Box

and the

Motorola XTL 2500/5000 Control Head Radio

0.35 lbs 3.0" 8.62" 1.51"

7160-0322

Works with any Gamber-Johnson

Console Box

and the

Motorola XTL 2500/5000 Full sized radio

0.50 lbs

Features

- Designed for use with the Motorola XTL 2500/5000 control head and full sized radio

- Full Faceplate secures the Motorola XTL 2500/5000 into any Gamber-Johnson

Console Box

- Interior mounting dimensions: 7.06"W x 2.08"H

3.0" 8.62" 3.58"

MCS Accessories - Panasonic Arbitrator MK3 VPU Full Faceplate

Item No.

Placement Weight Height Width Depth

16071

Works with any Gamber-Johnson

Console Box

and the Panasonic Arbitrator MK3 VPU 0.33 lbs. 4.0" 8.62" 1.00"

Features

- Designed for use with the Panasonic Arbitrator MK3 VPU

- Full Faceplate secures the Panasonic Arbitrator MK3 VPU into any Gamber-Johnson

Console Box

- Interior mounting dimensions: 7.0” W x 2.38” H

Shown: 7160-0321

Shown: 7160-0322

Shown: 16071

MCS Accessories - Relm BK KNG M Full Faceplate

Item No.

Placement Weight Height Width Depth Interior Dimensions

15344

Works with any Gamber-Johnson

Console Box

and the Relm BK KNG M Control Head

0.31 lbs.

3.0" 8.62" 1.33" 6.13" W x 2.25" H

15348

Works with any Gamber-Johnson

Console Box

and the Relm BK KNG M Full Radio

0.34 lbs.

3.0" 8.62" 2.83" 6.5" W x 2.42" H

Features

- Designed for use with the Relm BK KNG M Control Head and Full Sized Radio

- Full Faceplate secures the Relm BK KNG M Control Head and Full Sized Radio into any Gamber-Johnson

Console Box

Shown: 15344

Shown: 15348

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

53

MISSION CONTROL SYSTEM (MCS)

MCS Accessories - Sound Off Signal 380 Control Head Full Faceplate

Item No.

Placement Weight Height Width Depth

14619

Works with any Gamber-Johnson

Console Box

and the Sound Off Signal 380 control head 0.70 lbs. 3.50" 8.62" 0.88"

Features

- Designed for use with the Sound Off Signal 380 control head

- Full Faceplate secures the Sound Off Signal 380 control head into any Gamber-Johnson

Console Box

Shown: 14619

MCS Accessories - SoundOff Signal ETSP990 Switch Panel Full Faceplate

Item No.

Placement Weight Height Width Depth

16331

Works with any Gamber-Johnson

Console Box

and the SoundOff Signal ETSP990 Switch Panel 0.31 lbs. 3.0" 8.62" 0.50"

Features

- Designed for use with the SoundOff Signal Switch Panel

- Full Faceplate secures the SoundOff Signal ETSP990 Swtich Panel into any Gamber-Johnson Console Box

- Works with mounting points on back side of switch panel

- Interior mounting dimensions: 6.50" W x 2.63" H

Shown: 16331

Shown: 15343

MCS Accessories - Tait TM8100/8200 Series Full Faceplate

Item No.

Placement Weight Height Width Depth

15343

Works with any Gamber-Johnson

Console Box

and the Tait TM8100/8200 Series 0.48 lbs. 3.0" 8.62" 3.23"

Features

- Designed for use with the Tait TM8100/8200 Series

- Full Faceplate secures the Tait TM8100/8200 Serieso into any Gamber-Johnson

Console Box

- Interior mounting dimensions: 6.33" W x 2.13" H

Shown: 7160-0528

MCS Accessories - Uniden Mobile Scanners Full Faceplate

Item No.

Placement Weight Height Width Depth

7160-0528

Works with any Gamber-Johnson

Console Box

and the Uniden Mobile Scanners 0.46 lbs.

3.0" 8.62" 3.65"

Features

- Designed for use with the Uniden Mobile Scanners Models: BCT15 (X), BCD996 (T & XT), UBC800XLT and BCD536HP

- Full Faceplate secures the Uniden Mobile Scanners into any Gamber-Johnson

Console Box

- Interior mounting dimensions: 7.28" W x 2.25" H

54

Shown: 15377

MCS Accessories - Whelen 295SLSA1 Siren Full Faceplate

Item No.

Placement Weight Height Width Depth

15377

Works with any Gamber-Johnson

Console Box

and the Whelen 295SLSA1 Siren 0.3 lbs.

3.0" 8.62" 1.58"

Features

- Designed for use with the Whelen 295SLSA1 Siren

- Full Faceplate secures the Whelen 295SLSA1 Siren into any Gamber-Johnson

Console Box

- Interior mounting dimensions: 5.97" W x 2.40" H

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

MISSION CONTROL SYSTEM (MCS)

MCS Accessories - Whelen PCC8R 8 Button Light Controller Faceplate

Item No.

Placement Weight Height Width Depth

15087

Works with any Gamber-Johnson

Console Box

and the Whelen PCC8R 8 Button Light Controller 0.55 lbs. 3.0" 8.62" 0.08"

Features

- Designed for use with the Whelen PCC8R 8 Button Light Controller

- Faceplate secures the Whelen PCC8R 8 Button Light Controller into any Gamber-Johnson

Console Box

Shown: 15087

MCS Accessories - Whelen CenCom Gold/SoundOff 380 Light and Siren Full Faceplate

Item No.

Placement Weight Height Width Depth

7160-0339

Works with any Gamber-Johnson

Console Box

and the Whelen

CenCom Gold or SoundOff 380 Light/Siren controls

0.50 lbs.

4.0" 8.62" 1.33"

Features

- Designed for use with the Whelen CenCom Gold or SoundOff 380 Light/Siren controls

- Full Faceplate secures the Whelen CenCom Gold or SoundOff 380 Light/Siren controls into any Gamber-Johnson

Console Box

- Interior mounting dimensions: 6.66" W x 3.44" H

Shown: 7160-0339

MCS Accessories - Yaesu FT-7900 / FT-8800R / FT-8900R / FTM-100D / FTM-400D

Full Faceplate

Item No.

Placement Weight Height Width Depth

16327

Works with any Gamber-Johnson

Console Box

and Yaesu FT-7900 /

FT-8800R / FT-8900R / FTM-100D / FTM-400D Series Radio

0.30 lbs.

Features

- Designed for use with Yaesu FT-7900 / FT-8800R / FT-8900R / FTM-100D / FTM-400D-radio body

- Works with mounting points on the Radio

- Control Head has to be detached to put on faceplate on the Radio, then reattached

- Interior mounting dimensions: 5.63" W x 1.5" H

2.5" 8.62" 2.5"

MCS Accessories - Yaesu FTM-100DR Control Head Full Faceplate

Item No.

Placement Weight Height Width Depth

16329

Works with any Gamber-Johnson

Console Box

and Yaesu FTM-100DR Control Head 0.75 lbs. 4.0" 8.62" 1.25"

Features

- Designed for use with Yaesu FTM-100DR Control Head

- Works with mounting points on the Radio

- Work with GPS Receiver on top of Control Head

- Interior mounting dimensions: 5.5" W x 2.38" H (angled)

MCS Accessories - Yaesu FT-857 Radio Full Faceplate

Item No.

Placement Weight Height Width Depth

16330

Works with any Gamber-Johnson

Console Box

and Yaesu FT-857 Radio 0.35 lbs. 2.5" 8.62" 2.5"

Features

- Designed for use with Yaesu FT-857 Radio

- Works with mounting points on the Radio

- Control Head has to be detached to put on faceplate on the Radio, then reattached

- Interior mounting dimensions: 6.13" W x 1.75" H (angled)

Shown: 16327

Shown: 16329

Shown: 16330

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

55

MANUFACTURER ,

MODEL # ,

E

F

B

C

DIMENSIONS:

A

D

MISSION CONTROL SYSTEM (MCS)

HOLE DIAMETER - F

( SCREW SIZE )

Manufacturer _________________________

Model# ________________________________

E

B

Dimensions:

A _____________ D _____________

B _____________ E _____________

C _____________ F _____________

C

D

A

Note: Fill in all dimensions and include make and model for each control head or radio.

NOTE , FILL IN ALL DIMENSIONS

AND INCLUDE MAKE AND

MODEL FOR EACH CONTROL

HEAD OR RADIO

Fax to 1-800-934-3577. If you have any questions please call 1-800-456-6868.

Faceplate Ordering Instructions

(Every order number includes a pair of faceplates)

IF YOU HAVE ANY QUESTIONS

PLEASE CALL 1-800-456-6868

2. Use the part number listed in the Item No. column.

3. Should Gamber-Johnson’s dimensions not correspond with your equipment or you do not find your equipment listed, please make a copy of the

dimensions worksheet (above), fill it out and fax it to us at 1-800-934-3577. We will help you find a faceplate which will work with your equipment.

Can’t find your device? Visit our website at www.gamberjohnson.com for a full listing.

56

DESCRIPTIoN

Height

“B”

Width

“A”

Part

Number

911EP Orion DIRECTOR (ORITD4)

911EP Orion ELITE (ORIEL4)

911EP Orion STANDARD (ORISD4)

Able 2 05.5300

1.25

6.50 7140-0374

1.25

6.50 7140-0374

1.25

6.50 7140-0374

2.75

6.00 7140-0312

Able 2 05-6040 2.00

6.00 7140-0318

Able 2 Sho-Me 30-2100 / 30.2108 / 30-2200 SIRENS 2.25

6.00 7140-0316

Able 2 Sho-Me-05-600 siren

Able 2 Sho-Me-05-600 Switch Box

2.25

2.25

7.12 7140-0441

6.00 7140-0316

Able 2 Sho-Me-5-5540

Able2 Chameleon Traffic Director Control

ADI AR-146

Alinco DR-06T

Alinco DR-590

Applied Concepts Stacker Radar

Bee Doppler Radar Model 36 Series A

Bendix/King EMH5990A

2.25

1.25

1.62

1.62

2.00

1.75

2.38

2.12

6.00 7140-0316

6.00 7140-0322

5.50 7140-0271

5.50 7140-0271

6.00 7140-0318

5.50 7140-0271

6.00 7140-0315

6.00 7140-0317

Bendix/King EMV

Bendix/King GMH (RELM / BK Radio)

BK DMH5992X

Brooking BR960

Carson SA 400

Carson SC407 Siren Box 407A Siren

Carson SC-409

Cobra 148 GTL

2.12

6.00 7140-0317

2.12

6.00 7140-0317

2.12

6.00 7140-0317

2.00

6.25 7140-0343

2.50

6.12 7140-0314

2.88

6.12 7140-0312

2.75

6.13 7140-0312

2.38

7.88 7140-0440

Cobra 18 Ultra

Cobra 18 WX ST II

Cobra 25 LTD

Cobra 29 LTD Classic

Cobra 29 LX & 29 LX BT

2.12

6.12 7140-0442

1.88

6.50 7140-0369

2.13

6.25 7140-0342

2.25

7.28 7140-0441

2.25

7.25 7140-0441

DESCRIPTIoN

Cobra 29 WX NW BT

Cobra 29 WX NWST Mobile CB

Code 3 3892L6M / 3892L4H Siren / Light Control

(MasterCom B)

Height

“B”

Width

“A”

Part

Number

2.56

7.28 7140-0438

2.25

7.28 7140-0441

2.75

6.50 7140-0362

Code 3 3942M / 3942L4H / 3942L6H / 3944L4H

(MasterCom B)

2.75

6.50 7140-0362

Code 3 Model 430 6 Switchbox

Code 3 415 Series Rocker Swich Control Panels

Code 3 Arrowstick PSE (Model - NASLCH2)

Code 3 ArrowStik

2.18

6.06 7140-0316

2.50

6.50 7140-0364

1.25

6.50 7140-0374

2.00

6.50 7140-0368

Code 3 Mastercom B (3892 / 3892L6M / 3892L6) 2.75

6.50 7140-0362

Code 3 Narrowstick 1.53

6.56 7140-0371

Code 3 Stealth 518

Code 3 V-CON 3600 Series

1.50

2.25

6.00 7140-0322

6.50 7140-0864

Code 3 V-CON 3672L4

Code 3 V-CON 3692

Code 3 V-CON 3692L4

Code 3 V-CON 3696 series

CPI SV100

D & R RDS-RK

Eagle Radar

EF Johnson 242-7610

EF Johnson 53SL ES

Emtrac, Traffic Pre-Empron System

2.25

2.25

2.25

2.25

1.50

2.40

1.75

1.60

2.00

2.75

6.50 7140-0864

6.50 7140-0864

6.50 7140-0864

6.50 7140-0864

5.50 7140-0272

6.60 7140-0364

6.50 7140-0370

5.50 7140-0272

7.00 7140-0443

6.50 7140-0362

Ericsson EDACS Orion Scanner

Ericsson GE 34A4210P D

2.50

7.38 7140-0439

2.00

6.00 7140-0318

Ericsson M7100 (Orion) 2.40

6.90 7140-0439

Fedeeral Signal Light Control Model SMC5 (331105) 1.50

6.13 7140-0322

Federal FIRECOM 3000A 1.69

6.06 7140-0317

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

DESCRIPTIoN

Height

“B”

Width

“A”

Part

Number

Federal FIRECOM 3000C

Federal MS-4000

Federal PA - 200, PA-300, PA-400

Federal PA-15

Federal PA630 P640

Federal Signal SignalMaster SMC 5 Lightbar

Controller 331105

1.50

1.50

2.38

2.75

3.00

1.50

6.12 7140-0322

5.50 7140-0272

6.06 7140-0315

5.25 7140-0237

6.90 7140-0385

6.12 7140-0322

Federal Signal SS-700 Siren/PA

Federal Signal UTMD Delta

2.50

6.00 7140-0364

2.40

6.50 7140-0364

Federal SW-300, SW400SS, SW400SSJ, SW 400S&L 2.19

6.06 7140-0316

Feniex 4200 (control head) 3.50

6.80 7140-0881

Galls 5 Function Switch Panel SE080

Galls 6 Function Switch Panel SE081

Galls 6 Function Switch Panel SE082

Galls 6 Function Switch Panel SE103

2.00

2.13

2.00

2.00

6.25 7140-0343

6.25 7140-0342

6.25 7140-0342

5.00 7140-0218

Galls 9 Function Switch Panel SE104

Galls Siren Box SK053 (is Code 3 Mastercom)

Galls SK155

Galls Street Thunder 240

2.00

5.00 7140-0218

2.75

6.62 7140-0362

2.50

6.00 7140-0314

2.50

6.00 7140-0314

Galls Street Thunder Deluxe Full Feature Siren

SK125 / ST240

Galls Switch Box J-SE041

Galls XL 100 Street Thunder -- OLD

Galls XL 200 Switch Box

Galls XL 300 Street Thunder

Galls XL 400 Street Thunder

GE 344A4210P2

GE Ericsson Mrk Vehicle Charger

GE Ericsson (MA/Comm) KMC300

GE Ericsson M7100 (Orion)

GE FMD Radio/Recessed

GE Marc MDX, NPH-20

GE MDX Remote

GE MLS II

GE Monogram MGM-148

GE MPR Controller & Charger

GE MVS

GE Orion

GE Orion Mobile EDACS Scan Model

GE PAE 5610 or GE ORION REMOTE HEAD

GE Phoenix

GE PMH4SD

GE S-900 w/light

GE S-990 Remote Head

Genesis I Radar

HARRIS M5300 Series Radio & Control Head

HARRIS M7100 Series Radio & Control Head

Harris M7100 (Orion)

HARRIS M7200 Series Radio & Control Head

HARRIS M7300 Series CONTROL HEAD

Icom F420

Icom 207

Icom 521

Icom A-110

Icom F1020

Icom F-122

Icom F220

Icom F2721D

Icom F320

2.00

5.75 7140-0218

2.19

6.13 7140-0316

2.50

6.00 7140-0314

2.50

6.50 7140-0364

2.12

6.25 7140-0342

2.50

6.50 7140-0364

2.00

6.00 7140-0318

2.38

7.13 7140-0440

2.12

7.12 7140-0442

2.40

6.90 7140-0439

2.88

7.38 7140-0436

2.21

7.20 7140-0441

2.21

7.20 7140-0441

2.50

7.00 7140-0439

2.00

6.00 7140-0318

3.00

7.00 7140-0385

2.25

7.06 7140-0441

2.00

7.06 7140-0443

2.50

7.00 7140-0439

2.38

6.94 7140-0440

2.62

7.38 7140-0438

2.25

7.12 7140-0441

2.00

6.62 7140-0368

1.62

6.56 7140-0371

1.75

6.50 7140-0370

2.40

7.00 7140-0439

2.40

7.00 7140-0439

2.40

6.90 7140-0439

2.40

7.00 7140-0439

2.40

7.00 7140-0439

1.50

5.50 7140-0272

1.50

5.50 7140-0272

1.50

5.50 7140-0272

1.88

5.88 7140-0318

2.00

6.00 7140-0318

1.56

5.91 7140-0321

2.00

6.00 7140-0318

1.50

5.50 7140-0272

1.50

5.50 7140-0272

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

DESCRIPTIoN

Kenwood TK 6110

Kenwood TK5710

Kenwood TK5710

Kenwood TK5720/5820

Kenwood TK5810

Kenwood TK601

Kenwood TK690

Kenwood TK7102

Kenwood TK7150

Kenwood TK7160

Kenwood TK7160H

Kenwood TK7180

Kenwood TK730

Kenwood TK7360

Kenwood TK7360 HV

Kenwood TK760H

Kenwood TK780

Kenwood TK790

Kenwood TK8102

Kenwood TK8150

Kenwood TK8160

Kenwood TK8180

Kenwood TK830

Kenwood TK8360HU

Kenwood TK840

Kenwood TK840

Kenwood TK860

Kenwood TK863G

Icom F521

Icom F621

Icom IC-1010

Icom IC-1020

Icom IC-2300H Radio

Icom IC-2720

Icom IC-2800

Icom IC-F121 also IC-F221-A

Icom IC-F5061

Icom IC-F5220D

Icom IC-F606ID

Icom IC-F6220D

Icom IC-F65061

Icom IC-V800 Radio

Icom ID-880H

Icom IG R100

Icom V100

Johnson 8615B

Johnson 9755 Multi-N

Johnson Summit Trunk

Kenwood 7150

Kenwood 862

Kenwood KCH-4

Kenwood NX700

Kenwood NX800

Kenwood NX800K

Kenwood TK863G

Kenwood TK880

Kenwood TK890

Kenwood TK940

Kenwood TK980

MISSION CONTROL SYSTEM (MCS)

Height

“B”

Width

“A”

Part

Number

2.00

6.31 7140-0343

2.36

7.01 7140-0440

2.38

7.06 7140-0440

1.77

6.30 7140-0345

2.36

7.01 7140-0440

2.62

7.25 7140-0438

2.38

7.06 7140-0440

1.70

6.30 7140-0345

2.00

7.00 7140-0443

1.70

6.30 7140-0345

2.00

7.00 7140-0443

1.70

6.30 7140-0345

2.38

7.06 7140-0440

1.70

6.30 7140-0345

1.77

6.30 7140-0345

1.50

5.50 7140-0272

1.62

5.50 7140-0271

2.38

7.06 7140-0440

1.70

6.30 7140-0345

2.00

7.00 7140-0443

1.70

6.30 7140-0345

1.70

6.30 7140-0345

2.38

6.94 7140-0440

1.77

6.30 7140-0345

1.50

5.50 7140-0272

1.50

5.50 7140-0272

1.62

5.50 7140-0271

1.50

5.50 7140-0272

1.60

5.58 7140-0271

1.60

5.58 7140-0271

2.00

6.00 7140-0318

2.00

6.00 7140-0318

1.57

5.50 7140-0271

1.50

5.50 7140-0272

1.50

5.50 7140-0272

1.50

6.00 7140-0322

1.57

5.91 7140-0321

1.57

5.91 7140-0321

1.57

5.91 7140-0321

1.57

5.91 7140-0321

1.75

6.38 7140-0345

2.00

6.00 7140-0318

1.56

5.91 7140-0322

1.94

5.88 7140-0293

2.00

6.25 7140-0393

2.00

6.50 7140-0368

2.25

7.00 7140-0441

2.12

7.12 7140-0442

2.00

7.12 7140-0443

1.50

5.62 7140-0272

2.25

7.00 7140-0441

1.77

6.30 7140-0345

1.77

6.30 7140-0345

1.70

6.30 7140-0345

1.50

5.50 7140-0272

1.62

5.50 7140-0271

2.38

6.94 7140-0440

1.50

5.50 7140-0272

1.50

5.50 7140-0272

57

58

MISSION CONTROL SYSTEM (MCS)

DESCRIPTIoN

Kenwood TM-261

Kenwood TM-271

Kenwood TM-641A

Kenwood TM-741A

Kenwood TM-742A

Kenwood TM-942A

Kenwood TM-V7

Kenwood TM-V71A

Kustom Signal Eyewitness G3 (not the best solution but the only solution)

Height

“B”

Width

“A”

Part

Number

1.50

5.50 7140-0272

1.70

6.30 7140-0345

2.00

5.94 7140-0318

2.00

5.94 7140-0318

2.00

5.94 7140-0318

2.00

5.94 7140-0318

1.50

5.50 7140-0272

1.69

5.50 7140-0271

2.12

6.50 7140-0839

Kustom Signal Golden Eagle

Kustom Signal Pro 1000DS

L3 Mobile Vision FLASHBACK 2

L3 Mobile Vision FLASHBACK 3

Light Switch PNL

M/A Com D28LPX - M7100

M/A Com M7300 Radio

M/A Com Panther 500M

MA/Comm M7100 (Orion)

Maxon SM 4450SC

Midland 2 piece

Midland 70-0002

Midland 70-1394B

Midland 70-340B

Midland 77-116

Midland 77-155

Midland LMM4115D

Midland Syntech II (Dash)

Mixer, MFG unknown

Motorola 067W

Motorola 4009 CB

Motorola 800 MHZ GTX

Motorola AM300

Motorola APX 6500 (05 Control head) Full Radio

Motorola APX 7500 (05 Control head) Full Radio

Motorola Astro

Motorola Astro 800

Motorola Astro MHLN6432E

Motorola Astro Spectra W7 Control head

Motorola Astro Spectra W9 Control head

1.75

1.75

6.50 7140-0370

6.50 7140-0370

Motorola CDM 1250

Motorola CDM 1250

Motorola CDM 1550

Motorola CDM 1550

Motorola CDM 750

Motorola CDM 750

Motorola CM200

Motorola CM300

2.00

6.50 7140-0368

2.38

7.00 7140-0440

2.00

6.50 7140-0368

2.38

7.00 7140-0440

2.00

6.50 7140-0368

2.38

7.00 7140-0440

1.73

6.67 7140-0370

1.73

6.67 7140-0370

Motorola DEK / SIREN Control Box

Motorola E-4

Motorola GM300

Motorola Handi-Talkie Charger NTN8660A

1.25

6.50 7140-0374

2.00

7.00 7140-0443

2.00

7.00 7140-0443

3.50

3.50 7140-0556

Motorola HCN 1019A 2.00

6.75 7140-0393

Motorola HCN 1052B Maratrac Remote HD ADV. A-7 3.38

6.50 7140-1010

Motorola HCN 1089A Maratrac (Astro)

Motorola HLN 1241C, HLN 1241B, HLN333

3.44

1.25

6.50 7140-1010

6.50 7140-0374

Motorola HLN 1260

Motorola HLN 3333B

1.25

6.50 7140-0374

1.25

6.50 7140-0374

2.00

5.88 7140-1036

2.40

6.93 7140-0440

2.50

6.50 7140-0364

2.00

6.88 7140-0393

2.00

7.00 7140-0443

2.25

7.00 7140-0441

2.40

6.90 7140-0439

2.00

6.00 7140-0318

2.12

7.12 7140-0442

2.62

7.38 7140-0438

2.25

7.38 7140-0441

2.62

7.50 7140-0438

1.50

6.00 7140-0322

2.25

6.00 7140-0316

2.00

7.00 7140-0443

2.25

7.25 7140-0441

3.50

6.12 7140-0306

2.00

7.00 7140-0443

2.50

7.00 7140-0439

1.75

6.62 7140-0370

2.00

7.00 7140-0443

2.00

7.00 7140-1034

2.00

7.00 7140-1034

2.00

7.00 7140-0906

2.00

7.00 7140-0906

2.00

7.00 7140-0443

2.00

7.10 7140-1004

3.37

6.50 7140-1010

DESCRIPTIoN

Height

“B”

Width

“A”

Part

Number

Motorola LCS 2000

Motorola M1225

Motorola M1550

Motorola Maratrac A7 Head

Motorola Maratrac HCN 4034

Motorola Maratrac W-9

Motorola Maxar 80

Motorola Maxon SM4000

1.73

6.61 7140-0370

1.75

6.56 7140-0370

2.88

7.38 7140-0436

3.62

6.50 7140-1010

2.00

5.75 7140-0318

3.62

6.50 7140-1010

2.50

6.56 7140-0364

2.00

6.00 7140-0318

Motorola Maxtrac

Motorola MCS 2000 - Control Head MODEL I

2.00

7.00 7140-0443

2.35

7.33 7140-0440

Motorola MCS 2000 - Control Head MODEL II & III 2.38

5.00 7140-1031

Motorola MCS 2000 - MODEL I, II, & III 1.75

6.62 7140-0370

Motorola MCX 1000

Motorola MD1H Remote

Motorola NLN4368A

Motorola P200 Charger

2.00

2.25

3.00

3.00

6.94 7140-0443

7.25 7140-0441

7.25 7140-0435

7.25 7140-0435

Motorola PM1500

Motorola PM1500 Remote Head only

Motorola PM400

2.50

7.25 7140-0439

2.62

7.12 7140-0438

1.73

6.67 7140-0370

Motorola Radius / GM 300

Motorola SM120 / SM50 Radius

Motorola Spectra A-4 Remote (double bend) B7

Motorola Spectra A-5 Astro/ W7 W5 W4

Motorola Spectra C-7

Motorola Spectra C-9 HCN1073D

Motorola Spectra DA5KM

Motorola Spectra/W9

Motorola Syntor Radio

2.00

7.00 7140-0443

1.73

6.62 7140-0370

2.00

5.68 7140-1004

2.00

7.00 7140-0443

2.00

5.68 7140-1004

3.19

6.50 7140-1010

2.00

7.00 7140-0442

3.62

6.50 7140-1010

2.25

6.00 7140-0316

Motorola Syntor X9000 (same as spectra, astro-ctrl head only)

Motorola TLN 3042A

Motorola VRM 850

Motorola Wildcard

Motorola XPR 4500

Motorola XPR 5000 Series

Motorola XTL 1500

Motorola XTL 2500

Motorola XTL 5000

Opticom Model 2100 & 2101

Panasonic Arbitrator Camera Head

Power call Siren - 6 Adam

Public Safety Equip. Lite Switch Box

Pyramid SVR200 Series Vehicular Repeater

Radio Shack CCS

Radio Shack PRO 2046 & 2051

Radio Shack Pro 2066

Radio Shack PRO 2066

Radio Shack PRO 2067

Radio Shack Pro MD2 800

Radio Shack TRC-474

Radio Shack TRC-487

Radio Shack TRC-496

Radio Shack TRC519

Realistic HTX100

Realistic TRC-418 CB

Realistic TRC-423

Realistic TRC-435

Realistic TRC-482

3.38

6.50 7140-1010

1.25

6.25 7140-0374

1.85

6.61 7140-0370

1.25

6.00 7140-0374

2.00

7.00 7140-1034

2.00

7.00 7140-1034

2.00

7.00 7140-1034

2.00

7.00 7140-1034

2.00

7.00 7140-1034

1.63

5.44 7140-0271

2.00

7.00 7140-0443

2.50

6.40 7140-0364

2.12

6.25 7140-0342

1.12

5.28 7140-0249

2.00

7.00 7140-0443

2.00

7.12 7140-0443

2.12

7.12 7140-0442

2.00

7.38 7140-0443

2.00

6.75 7140-0393

2.12

7.12 7140-0442

1.50

5.50 7140-0272

1.50

5.62 7140-0272

2.00

7.25 7140-0443

1.62

5.56 7140-0271

2.50

7.38 7140-0439

1.62

5.44 7140-0271

2.00

5.88 7140-0318

1.50

5.50 7140-0272

2.00

5.88 7140-0318

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

DESCRIPTIoN

Height

“B”

Width

“A”

Part

Number

Regency Lo Band Radio

Regency R1600 Scanner

Regency RH2510

Regency WH2516

Relm MS2000

Relm RM800

Relm RMV50 & V50R

Roadmaster

2.50

6.50 7140-0364

1.75

6.31 7140-0345

2.75

6.50 7140-0362

2.12

6.00 7140-0317

2.12

6.00 7140-0317

2.00

6.75 7140-0443

1.75

6.50 7140-0370

2.50

6.12 7140-0314

Ronton LC1000

Signal Vehicle SB4020

Signal Vehicle SB4040

Signal Vehicle SS700

2.00

6.75 7140-0443

2.50

6.12 7140-0314

2.13

4.75 7140-0317

2.50

6.50 7140-0364

Sound Off 380 ML (Multi-Function) 2.38

6.40 7140-0439

Sound Off 400 Series Sirens (nERGY 400 Series) 2.62

7.10 7140-0438

Sound Off 700 Series

Sound Off Directional Arrowswitch

2.12

1.76

6.25 7140-0342

6.55 7140-0370

Sound Off ETSA481(2)CSP (400 Series - nERGY) 2.62

7.00 7140-0438

Sound Off ETSA481CSR (400 Series - nERGY) 2.62

7.00 7140-0438

Sound Off ETSP990 & ETSP993 2.62

7.00 7140-0438

Standard Vertex

Star Signal Warning Systems TD77-2

Star Signal Siren Model LCS770

Star Signal Siren Model SS650 - Economy

Star Signal Siren Model SS670

Star Signal Siren Model SS700

Star SignalSiren Model SS652

Steven R Jennings Siren

SVP SA-500

SVP SB4020

SVP SS-700

SVP Star SB4020

Tait T2020

Tait TM8255

Tele Tec

Tomar 940 & Tomar 940 amp

TSD Generation S1CMCI & S2GMC1

Uniden 780 XLT

Uniden BC350A

Uniden BC350C

Uniden BC355C

Uniden BC355N

Uniden BC700A

Uniden BCT7

Uniden BCT8

Uniden BCT8 scanner

Uniden Bearcat 400XLT

Uniden Bearcat Scan BCT15

Uniden Bearcat Scan BCT15X

Uniden CB Radio PC 76XL

Uniden FML 600C

Uniden HR-2510 & HR-2600

Uniden Mobile Scanner - BCD536 HP

Uniden Mobile Scanner - BCD996

Uniden PC68 Elite CB

Uniden PC78 Elite CB Radio

Uniden PRO 538W

Uniden PRO Series PC68XL

Uniden SMH5250T

Uniden SMR Base Station

2.20

2.12

2.50

2.50

2.19

2.19

2.12

2.19

2.00

2.12

2.16

2.50

7.20 7140-0441

7.25 7140-0442

7.25 7140-0439

7.38 7140-0439

7.25 7140-0442

7.25 7140-0442

6.25 7140-0342

7.25 7140-0441

6.75 7140-0443

7.12 7140-0442

6.00 7140-0317

6.00 7140-0314

1.75

6.38 7140-0345

1.50

6.00 7140-0322

2.88

6.00 7140-0312

2.00

6.00 7140-0318

2.00

6.00 7140-0318

2.38

6.00 7140-0315

2.00

6.00 7140-0318

3.50

6.12 7140-0306

2.12

6.12 7140-0317

2.25

6.12 7140-0316

2.50

6.50 7140-0364

2.50

6.50 7140-0364

2.00

6.20 7140-0393

2.80

7.20 7140-0436

3.00

7.31 7140-0435

3.60

7.00 7140-0435

1.62

6.12 7140-0321

2.38

6.94 7140-0440

2.00

5.00 7140-0218

2.00

5.00 7140-0218

2.00

5.00 7140-0218

2.00

5.00 7140-0218

2.38

6.94 7140-0440

1.62

5.50 7140-0271

2.00

6.94 7140-0443

2.44

7.06 7140-0439

2.75

5.38 7140-0237

2.20

7.20 7140-0441

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

MISSION CONTROL SYSTEM (MCS)

DESCRIPTIoN

Height

“B”

Width

“A”

Part

Number

Uniden SMU4525

Uniden UTMD Delta

Unitrol 480K w/switch pack

Unitrol Touchmaster (UTM4)

Vertex Standard (Yaesu) VX-2100

Vertex Standard (Yaesu) VX-2200

Vertex Standard (Yaesu) VX-4500

Vertex Standard (Yaesu) VX-4600

Watchgaurd DVR (4RE)

Whelen 295HFSA1

Whelen 295HFSA5

Whelen 295HFSA6

Whelen 295SDA Series

Whelen 295SL100

Whelen 295SLSA1

Whelen 295SLSA1 Siren

2.00

2.50

3.00

2.50

1.80

1.80

1.80

1.80

1.65

2.50

2.50

2.50

3.50

2.50

2.50

2.50

6.12 7140-0318

6.50 7140-0364

4.94 7140-0710

6.50 7140-1001

6.50 7140-0369

6.50 7140-0369

6.50 7140-0369

6.50 7140-0369

7.15 7140-0445

6.00 7140-0314

6.00 7140-0314

6.00 7140-0314

6.88 7140-0881

6.00 7140-0314

6.00 7140-0314

6.00 7140-0314

Whelen 295SLSC1 Siren 2.50

6.00 7140-0314

Whelen Cencom (head only) Sapphire (CCSRN36) 3.50

6.88 7140-0881

Whelen Cencom Gold (head only) Sapphire (CCSRN3) 3.50

6.88 7140-0881

Whelen Epsilon Siren EPSL259

Whelen HSF4

Whelen MGC032

Whelen MPC01

Whelen PCC10W

Whelen PCC6W

Whelen PCC9

Whelen PCCHD-2

Whelen PCCS9N1

Whelen PCCS9R

Whelen PCDS-9 and PCDS-9R Barlight Head

Whelen TACTRL12

Whelen Traffic Advisor

Whelen WS-2100

Whelen WS295HFS5

Whelen WS295HFS6

3.25

5.88 7140-0283

3.12

5.88 7140-0284

2.50

6.00 7140-0314

3.12

5.88 7140-0284

2.25

6.00 7140-0816

2.25

6.00 7140-0316

2.12

6.00 7140-0317

2.12

6.12 7140-0317

3.50

6.88 7140-0306

2.00

6.12 7140-0318

2.00

6.00 7140-0318

2.12

6.12 7140-0317

2.00

5.94 7140-0318

2.50

6.00 7140-0314

3.38

6.00 7140-0307

3.38

6.00 7140-0307

Whelen WS295HFSA6 3.38

6.00 7140-0307

Whelen WS-295-HF-Sinc Siren Head (295HFSA1) 2.50

6.00 7140-0314

Whelen WS295SLS6

Whelen WS295SLSA6

3.38

3.38

6.00 7140-0307

6.00 7140-0307

Yaesu FT-5100

Yaesu FT-7800R

Yaesu FT-7900R

Yaesu FT-8100

1.50

1.80

1.80

1.61

5.50 7140-0272

6.10 7140-0369

6.10 7140-0369

5.50 7140-0271

Yaesu Vertex

Yaesu Vertex VX 7200

Yaesu Vertex FTL 2011

Yaesu Vertex FTL-7011

1.50

5.62 7140-0272

2.38

7.00 7140-0440

2.00

6.25 7140-0343

2.00

6.25 7140-0343

Yaesu Vertex VX2100

Yaesu Vertex VX4000U - VX6000

Yaesu Vertex VX4200

Yaesu Vertex VX-7200-DO-50

Yeasu FT-100

Yeasu FT-100D

Yeasu High Band

Yeasu Vertex 4000

Yeasu Vertex VX 5500

1.69

6.50 7140-0370

2.38

7.00 7140-0440

2.38

7.00 7140-0440

1.69

6.50 7140-0370

2.00

6.50 7140-0368

2.12

6.29 7140-0342

1.62

5.50 7140-0271

2.40

7.70 7140-0439

2.40

7.00 7140-0440

Can’t find your device? Visit our website at www.gamberjohnson.com for a full listing.

59

Mobile Workstations

WORK TRUCK CONSOLE

Page 61

INSTaLLeD IN a ForD SuPer DuTy

Features/Benefits

- Contains locking storage for hanging standard file folders, supplies or other devices

- Armrest can be positioned closer to the driver or passenger

- 9.0" of mounting space with the internal cupholder and is designed to work with both full sized radios and radio control heads

- Can be used with any Vehicle Leg Kit (pg. 61)

60

Page 61

SMALL MOBILE WORKSTATION

INSTaLLeD IN a ForD SuPer DuTy

Features/Benefits

- Contains locking storage for hanging standard file folders,

supplies or other devices

- Includes attachable convenient clipboard holder

- Large handle for easy opening and closing of door

- Computer mounting platform has a built in sliding shelf unit for

mounting peripheral equipment like a printer

- Can be used with any Vehicle Leg Kit (pg. 61)

Page 61

LARGE MOBILE WORKSTATION

INSTaLLeD IN a ForD e-SerIeS VaN

Features/Benefits

- Contains locking storage for hanging standard file folders,

supplies or other devices

- Includes attachable convenient clipboard holder

- Large handle for easy opening and closing of door

- Computer mounting platform has a built in sliding shelf unit for

mounting peripheral equipment like a printer

- Can be used with any Vehicle Leg Kit (pg. 61)

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Mobile Workstations

Mobile Workstations

Item No.

Placement Description Weight Height Width Depth

7160-0079

Attaches to the floor, between the seats of most common vans & trucks

Small Mobile Workstation

7160-0102

7160-0103

Attaches to the floor, between the seats of most common vans & trucks

Complete Small Mobile Workstation with Computer Platform

Attaches to the floor, between the seats of most common vans & trucks

Complete Small Mobile Workstation with Vertical Surface Mount

11.5" 18.8"

11.5" 28.1"

11.5" 20.8"

7160-0082

Attaches to the floor, between the seats of most common vans & trucks

Large Mobile Workstation only 15.0" 16.1"

7160-0104

Attaches to the floor, between the seats of most common vans & trucks

Complete Large Mobile Workstation with Computer Platform

15.0" 24.6"

7160-0105

Attaches to the floor, between the seats of most common vans & trucks

Complete Large Mobile Workstation with Vertical Surface Mount

15.0" 18.1"

Workstation Features

- Includes attachable convenient clipboard holder and locking storage for supplies and devices

- Larger handle to allow easy opening or closing of door

- Box attaches separately to mounting legs which allows for easy installation and quick removal of the workstation from

the vehicle

- Attaches to leveling feet that will adjust to vehicle floor variations

- Can be used with any vehicle leg kit

MCS Vehicle Leg

(pg. 42) and

MCS Top Plate

(Item No. 7160-0085 or 7160-0086)

Computer Platform Features

- A computer can be mounted on top of the workstation by using any of the

Motion Attachment

listed below and any

Gamber-Johnson

Cradle or Docking Station

(sold separately)

-The Small Computer Mounting Platform (Item No. 7160-0080) has a built-in sliding shelf unit for mounting peripheral

equipment like a printer

Vertical Surface Mount

- A computer can be mounted on top of the workstation by using a Motion Attachment (7160-0776) , any

Upper Pole

(pg. 26) and any Gamber-Johnson

Cradle or Docking Station

(sold separately) (pg. 74-98)

Shown: 7160-0102

Shown: 7160-0103

Shown: 7160-0104

Vehicle Leg Kit

Item No.

Placement

Seat

Configuration

Drilling Required

No. of mounting locations

Weight Height Width Depth

7160-0403

Attaches to inboard driver and passenger side seat studs

Bucket

No - attaches to seat studs:

International 4300/7300

Work Truck (2011-2013)

3 24.0 lbs. 2.75" 63.5" 18.75"

7160-0545

Attaches to inboard driver and passenger side seat studs

Bucket

No - attaches to seat studs:

Freightliner M2 106

(2012-2016)

Freightliner M2 112

(2012-2016)

2 19.6 lbs. 7.11" 33.44" 19.30"

Features

- Vehicle Leg Kit allows workstations, storage or console boxes to be mounted between the seats of the vehicle

- Multiple mounting locations on the strut channel (see above for number) allows for various positions for mounting

equipment (center, off-center, etc...)

- Compatible with air ride seats

Shown: 7160-0105

Shown: 7160-0403

Shown: 7160-0545

Work Truck Console with File Box, Cupholder and Armrest

Item No.

Placement Weight Height Width Depth

7170-0125

On the 29" MCS Top Plate (Item No. 7160-0085) 37 lbs.

11.0" to 13.4" 9.23" 32.06"

Features

- Locking storage for hanging standard file folders, supplies or other devices

- Armrest that can be positioned closer to the driver or passenger during installation

- 9.0" of mounting space with the internal cupholder and is designed to work with both full sized radios and radio control heads

- Mounting holes on the right side of the console accommodates the Vertical Surface Mount (Item No. DS-138) for

computer mounting (sold separately pg. 13)

- Box attaches to

MCS Vehicle Legs

(sold separately pg. 42)

- This item is sold as a package and there are no substitutions, includes:

- Internal Cupholder, Break Away Armrest, MCS Top Plate

- 3 Faceplates and 3 filler panels are included (pg. 50-59)

Shown: 7170-0125

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

61

Material Handling

62

ToTal soluTion

Items shown

Roll Form Bracket (pg. 65)

Horizontal Extension Bar (pg. 67)

Dual Clam Shell with 3" Arm (pg. 65)

Barcode Scanner/Mobile Computer Mount (pg. 66)

Material Handling

Page 65 Page 67 Page 65

dual ClaM shell wiTh 3" arM and plaTe

(7160-0420/7160-0421)

Features/Benefits

- Dual Clam Shell features the following hole

patterns: AMPS, NEC, VESA 75mm and

Gamber-Johnson 2x4

- The Dual Clam Shell offers increased range of tilt,

swivel and rotation

- The 3" Arm allows the user to bring the device

closer to them and position it more ergonomically

- The Dual Clam Shell with 3" Arm can be

purchased with a Small Plate or a Large Plate

horizonTal exTension bar

(7160-0363)

Features/Benefits

- The arm allows the user to position the device

up to 15.34" horizontally from the inside of the

overhead guard leg

- Allows for multiple system configurations based

on style of forklift and computer configuration

- Can be mounted in conjunction with Clam Shell

with Small Plate (7160-0357), Forklift Dual Clam

Shell with Small Plate (7160-0366), or Forklift Dual

Clam Shell with 3" Arm and Small Plate (7160-0420)

overhead Guard MounT

(7160-0368)

Features/Benefits

- The Extended Overhead Guard mount allows users

to mount the device from the top of the forklift

- Dual Clam Shell features the following hole

patterns: AMPS, NEC, VESA 75mm and

Gamber-Johnson 2x4

- The arm extends down 8.0" from the top of the

forklift

- Tilts up to 90° fore or 26° aft and swivels 360°

Page 66 Page 66

Keyboard arM wiTh Mini Clevis

MoTion aTTaChMenT

(7160-0550)

Features/Benefits

- Designed to be used with any keyboard using the

AMPS or NEC pattern

- Articulating keyboard arm is designed for use with

any Gamber-Johnson Clam Shell

- Keyboard attaches directly to the keyboard arm

and can be tilted 72° fore/40° aft

handheld barCode sCanner/Mobile CoMpuTer

MounT

(7160-0499-01)

Features/Benefits

- Designed to be used with most handheld

barcodes scanners or mobile computers

- Forward restraint protect the IR Lens

- Design prevent the trigger from being

accidently activated

- Can be used with Roll Formed Pillar Brackets

or Tube Overhead Guard Leg Clamp

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Page 65

Tube overhead Guard leG

ClaMp

(7160-0561)

Features/Benefits

- Bracket allows system to be mounted on forklifts,

reach trucks or order pickers with either a

2", 2.5" or 3" diameter tube style overhead

guard leg

- Can be mounted to any Clam Shell or

Horizontal Extension

- Allows for multiple system configurations based

on style of forklift and computer configuration

63

64

Material Handling

Shown: 7160-0357

Clam Shells

Item No.

Description Placement Tilt Rotates Weight Height Width Depth

7160-0357

Clam Shell with

Small Plate

Attaches to rectangular overhead guard leg 1.5" to 2.5" wide

Yes - up to

160° total

No

3.97 lbs.

4.6" 6.26" 5.1"

7160-0370

Clam Shell with

Large Plate

Attaches to rectangular overhead guard leg 2.5" to 5.0" wide

Yes - up to

160° total

No

5.8 lbs.

4.6" 6.8" 5.28"

Features

-

Clam Shell

features the following hole patterns: AMPS, NEC & VESA 75mm (see pg. 3 for hole pattern definitions)

- To tilt the

Clam Shell

simply loosen the adjustable lever, tilt to desired position and then re-tighten the lever

- A secondary bolt is included to lock the clam shell into a permanent position

- Plate sandwiches the overhead guard leg and allows user to position the device at the desired height position

Shown: 7160-0370

Shown: 7160-0356

Clam Shell with 3" Arm

Item No.

Placement Tilt Rotates

7160-0356

Attaches to any Clam Shell (Item No.

7160-0357, 7160-0370, 7160-0371)

Yes - up to 90° fore/ 26° aft

Motion Attachment - 360°

Entire arm - 360°

Features

- Clam Shell works with the following hole patterns (see pg. 3 for hole pattern definitions):

- VESA 75mm

- Gamber-Johnson 2x4

- NEC

- AMPS

- The entire arm can rotate around 360° and the Motion Attachment can also rotate 360°

- Arm extends 3” bringing equipment closer to the user

- Arm can be tighten down to be locked into a permanent position

Weight Height Width Depth

4.23 lbs.

3.5" 8.18" 6.63"

Shown: 7160-0371

Shown:14463

Shown: 7160-0418

Shown: 7120-0647

Forklift Secondary Clam Shell

Item No.

Placement Tilt Rotates Weight Height Width Depth

7160-0371

Attaches to any

Clam Shell

(Item No. 7160-0357,

7160-0370) for additional articulation

Yes - up to

160° total

Motion Attachment

- 360°

1.72 lbs.

4.6" 5.97" 5.17"

Features

-

Clam Shell

features the following hole patterns: AMPS, NEC & VESA 75mm (see pg. 3 for hole pattern definitions)

- To tilt the Clam Shell simply loosen the adjustable lever, tilt to desired position and then re-tighten the lever

- A secondary bolt is included to lock the clam shell into a permanent position

- Can be mounted directly to the Clam Shell with Small Plate (Item No. 7160-0357) or Clam Shell with Large Plate

(Item No. 7160-0370) , when attached to plate device the clam shell can rotate 360°

Display Swivel

Item No.

Description Placement Weight Height Width Depth

14463

Display Swivel for mounting small devices with AMPS or NEC mounting pattrns

Use with any Gamber-Johnson Clam

Shell or Clevis mounting device

.2 lbs. 1.375" 2.625" 2.625"

Features

- Swivel mounts to any Gamber-Johnson clam shell or clevis motion attachment with 3/8" mounting hole

- Swivel has AMPS and NEC mounting patterns on swivel

- Counter sunk mounting holes for flat installation

Roll Formed Pillar Bracket

Item No.

Description Placement Weight Height Width Depth

7160-0418

Standard Roll Form Pillar Bracket Use with most forklift trucks with Roll Form Pillars 2.7 lbs. 4.72" 5.82" 2.25"

7160-0815

Linde Custom Roll Form Pillar Bracket Use with special Linde forklift models EV-30 and EV-40 2.7 lbs. 4.72" 6.82" 2.0"

7160-0814

Jungheinrich/CAT Custom Roll

Form Pillar Bracket

Use with special Jungheinrich models EFG 110K-

115; EFG 213K-220; EFG 316K-320; EFG 425K-S30;

EFG 535K-S50 or CAT models 2ET 2500-2ET 4000

2.7 lbs. 4.72" 5.82" 1.12"

7120-0647

Roll Form Bracket Spacer

Use with Gamber-Johnson Roll Formed Pillar Bracket

7160-0418 to create a tight fit on some roll form profiles .25 lbs. 4.0" 2.25" 1.0"

Features

- Bracket allows system to be mounted on forklift roll form overhead guard leg

- Can be mounted directly to any Clam Shell (Item No. 7160-0371) or Horizontal Extension (Item No. 7160-0363)

Note:

Use spacer (Item No. 7120-0647) when mounting to a vehicle with an oversized overhead guard leg.

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Tube Overhead Guard Leg Clamp - 2", 2.5" or 3"

Item No.

Placement Weight Height Width Depth

7160-0561

Attaches to any 2", 2.5" or 3" Tube Overhead Guard Leg on Forklifts, Reach

Trucks or Order Pickers

4.0 lbs.

4.0" 8.25" 3.75"

Features

- Bracket allows system to be mounted on forklifts, reach trucks or order pickers with either a 2", 2.5" or 3" tube overhead

guard leg

- Can be mounted directly to any Clam Shell (Item No. 7160-0371) or Horizontal Extension (Item No. 7160-0363)

Material Handling

Shown: 7160-0561

Forklift Combination Solutions

Item No.

7160-0366

7160-0367

7160-0420

7160-0421

Description

Dual Clam Shell with Small Plate

Dual Clam Shell with Large Plate

Dual Clam Shell

with 3" Arm and

Small Plate

Dual Clam Shell

with 3" Arm and

Large Plate

Placement Tilt Rotates Weight Height Width Depth

Attaches to rectangular forklift support braces

1.5" to 2.5" wide

Attaches to rectangular forklift support braces

2.5" to 5.0" wide

Attaches to rectangular forklift support braces

1.5" to 2.5" wide

Attaches to rectangular forklift support braces

2.5" to 5.0" wide

Yes - Clevis up to 90° fore/26° aft

Yes - Clam Shell up to 160°

Yes - Clevis up to 90° fore/26° aft

Yes - Clam Shell up to 160°

Yes - Clevis up to 90° fore/26° aft

Yes - Clam Shell up to 160°

Yes - Clevis up to 90° fore/26° aft

Yes - Clam Shell up to 160°

Motion

Attachment

- 360°

Motion

Attachment

- 360°

Motion

Attachment

- 360°

Motion

Attachment

- 360°

6.18 lbs. 9.77" 7.26" 6.96"

7.98 lbs. 9.77" 8.26" 7.14"

7.95 lbs. 10.08" 7.43" 9.96"

9.79 lbs. 10.08" 6.63" 10.14"

Shown: 7160-0366

Shown: 7160-0420

Overhead Guard Mount

Item No.

Description Placement Tilt Rotates Weight Height Width Depth

7160-0368

Extended Overhead Guard

Mount with 0-90 Clevis

Attaches directly to the top of the Overhead Guard

Yes - up to 90° forward/ 26° aft

Motion

Attachment - 360°

9.37 lbs. 13.15" 10.0" 5.6"

Features

- The Overhead Guard mount allows users to mount device from the top of the forklift cage and extends down 8.0"

- Recommended when device needs to be closer to the ceiling of the overhead guard and provides a reduced profile

solution for mounting peripherals such as radios or other electronics

-

Extended Overhead Guard Mount with 0-90 Clevis

features the following hold patterns; AMPS, NEC, VESA 75mm,

Gamber-Johnson 2" x 4.09" (see pg 3 for hole pattern definitions)

Shown: 7160-0367

Shown: 7160-0421

Shown: 7160-0368

Overhead Guard Mount - Vertical Extension Sleeve

Item No.

Placement Height Adjustability Weight Height Width Depth

7160-0598

Attaches to Overhead Guard Mount (Item No.7160-0368) Yes - 12.0" to 16.0" 2.8 lbs. 11.18" 2.84" 2.52"

Features

- The Extension Sleeve attaches to the Overhead Guard Mount and allows computer or tablets to be extended an

additional 4.0" when used with lift vehicles that have tall overhead guards or where extension is desired

- The sleeve extends the current 8.0" drop to an adjustable 12.0" to 16.0"

Shown: 7160-0598

Overhead Guard Mount - Horizontal Extension Sleeve

Item No.

Description Placement Weight Height Width Depth

7160-0805

Overhead Guard Mount - Horizontal

Extension Sleeve

Attaches to

Overhead Guard Mount

(Item No.7160-0368)

1.5 lbs.

3.75" 4.0" 8.0"

Features

- The Horizontal Extension attaches directly to the

Extended Overhead Guard Mount (7160-0368)

and allows saftey lights

and lasers to be properly positioned on forklifts with large counterweights

Shown: 7160-0805

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

65

Material Handling

Shown: 7160-0585 Shown: 7160-0586

Short Overhead Guard Mount

Item No.

Description Placement Tilt Rotates Weight Height Width Depth

7160-0585

7160-0586

Short Overhead Guard

Mount with Clam Shell

Short Overhead Guard

Mount with Dual Clam

Shell

Attaches directly to the Overhead Guard

Attaches directly to the Overhead Guard

Yes - up to 90° forward/ 26° aft

Motion

Attachment - 360° 5.6 lbs. 5.61" 10.0" 5.61"

Yes - each of the clevis tilt up to 90° forward/ 26° aft

Motion

Attachment - 360°

7.86 lbs.

7.47" 10.0" 10.77"

Features

- Recommended when device needs to be closer to the ceiling of the overhead guard

- Provides a reduced profile solution for mounting peripherals such as radios or other electronics

-

Short Overhead Guard Mount with Clam Shell

features the following hole patterns; AMPS, NEC, VESA 75mm,

Gamber-Johnson 2 x 4 (see pg. 3 for hole pattern definitions)

Intermec CV61 Interface Plate

Item No.

Description Placement Weight Height Width Depth

7160-0493

Interface plate for use with the

Intermec CV61 computer display

In between the Intermec CV61 and any

Gamber-Johnson

Clam Shell Forklift mount

2.0 lbs. 5.0" 12.32" 0.82"

Features

- Designed to be used with the Intermec CV61 Computer Display

- Attaches directly to any Gamber-Johnson Clam Shell (Item No. 7160-0366, 7160-0367, 7160-0368, 7160-0420 or 7160-0421)

- Interface plate attaches directly to the CV61 using the existing Intermec hole pattern

Shown: 7160-0493

Shown: 7160-0550

Keyboard Arm with Mini Clevis Motion Attachment

Item No.

Description Placement Weight Height Width Depth

7160-0550

Articulating Keyboard Bracket with Mini Clevis

Attaches to the underside of any

Clam

Shell

against the overhead guard leg

3.0 lbs. 3.75" 5.09" 14.03"

Features

- Designed to be used with any keyboard using the AMPS or NEC pattern (see pg. 3 for hole pattern definitions)

- Articulating keyboard arm is designed for use with any Gamber-Johnson

Clam Shell

- Mount underneath the clam shell to the bracket that is against the overhead guard leg

- Keyboard attaches directly to the keyboard arm and can be tilted 72° fore/40° aft

66

Shown: 7160-0499-01

Shown: 7160-0499

Handheld Barcode Scanner/Mobile Computer Mounts

Item No.

Description Placement Weight Height Width Depth

7160-0499

7160-0499-01

Upper and Lower mounting bracket for most handheld Barcode Scanner Guns and Mobile Computers

Upper only mounting bracket for most handheld Barcode Scanner Guns and

Mobile Computers

Attaches to rectangular overhead guard leg 1.5" to 5.0" wide

Attaches to rectangular overhead guard leg 1.5" to 5.0" wide

4.40 lbs. 8.34" 6.9" 9.2"

3.0 lbs. 8.34" 6.9" 6.66"

Features

- Designed to be used with most handheld barcode scanners and mobile computers

- The mount can work with wireless or wired devices

- Can be used with the Roll Formed Bracket (Item No. 7160-0418) if the overhead guard is Roll Formed

- On the combination scanner, the adjustable lever allows the lower section to be moved to a desired position or locked

into place and the device can be placed in either the lower or upper section depending on best ergonomic position

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Lind Warehousing Power Adapters

Item No.

Description Placement Weight Height Width Depth

15202

Lind Power

Adapter provides regulated power

(input 12-32 VDC) to the Panasonic

Toughbook CF18,

CF19, Toughpad

G1 and M1 computers

For use with the following

Panasonic Toughbook MK1-3 Docking

Stations (Item No. 7160-0207, 7160-0207-02), Panasonic

Toughbook 19 MK4-6 Docking Stations (Item No. 7160-0264-00,

7160-0264-02), Panasonic Toughbook 18/19 Cradle (Item No.

7160-0264-05), Panasonic Toughpad G1 Docking Stations (Item

No. 7160-0486-xx and 7160-0487-xx), Panasonic Toughpad G1

Cradles (Item No. 7160-0489-00 or 7160-0490-00), Panasonic

Toughpad M1 Docking Stations (Item No. 7160-0531-xx) and

Panasonic Toughpad M1 Cradle (Item No. 7160-0543-00)

1.56 lbs. 1.15" 9.3" 3.0"

15203

Lind Power

Adapter provides regulated power

(input 20-60 VDC) to the Panasonic

Toughbook CF18,

CF19, Toughpad

G1 and M1 computers

For use with the following

Panasonic Toughbook MK1-3 Docking

Stations (Item No. 7160-0207, 7160-0207-02), Panasonic

Toughbook 19 MK4-6 Docking Stations (Item No. 7160-0264-00,

7160-0264-02), Panasonic Toughbook 18/19 Cradle (Item No.

7160-0264-05), Panasonic Toughpad G1 Docking Stations (Item

No. 7160-0486-xx and 7160-0487-xx), Panasonic Toughpad G1

Cradles (Item No. 7160-0489-00 or 7160-0490-00), Panasonic

Toughpad M1 Docking Stations (Item No. 7160-0531-xx) and

Panasonic Toughpad M1 Cradle (Item No. 7160-0543-00)

1.56 lbs. 1.15" 9.3" 3.0"

16078

Lind Power Adapter provides regulated power (input 20-

60 VDC) to the

Getac F110, S400,

T800 and V110 computers

For use with the following Getac F110 Docking Stations (Item

No. 7160-0542-xx), Getac F110 Cradle (Item No. 7160-0576-00)

Getac S400 Docking Stations (Item No. 7160-0505-xx),

Getac S400 Cradle (Item No. 7160-0573-00), Getac T800

Docking Stations (7160-0565-xx), Getac T800 Cradle (Item No.

7160-0583-00), Getac V110 Docking Stations (Item No.

7160-0515-xx) and Getac V110 Cradle (Item No. 7160-0568-00)

1.56 lbs. 1.15" 9.3" 3.0"

16079

16411

16412

Lind Power Adapter provides regulated power (input 12-

32 VDC) to the

Getac F110, S400,

T800 and V110 computers

Lind Power Adapter provides regulated power (input 12-32

VDC)

Lind Power Adapter provides regulated power (input 20-60

VDC)

For use with the following Getac F110 Docking Stations (Item

No. 7160-0542-xx), Getac F110 Cradle (Item No. 7160-0576-00)

Getac S400 Docking Stations (Item No. 7160-0505-xx),

Getac S400 Cradle (Item No. 7160-0573-00), Getac T800

Docking Stations (7160-0565-xx), Getac T800 Cradle (Item No.

7160-0583-00), Getac V110 Docking Stations (Item No.

7160-0515-xx) and Getac V110 Cradle (Item No. 7160-0568-00)

For use with

(Item No. 7160-0773-00, 7160-0788-00) and Powered Cradles

(Item No. 7160-0818-04, 7160-0819-04)

For use with

Zebra ET50/55 Docking Stations

Zebra ET50/55 Docking Stations

(Item No. 7160-0773-00, 7160-0788-00) and Powered Cradles

(Item No. 7160-0818-04, 7160-0819-04)

1.56 lbs. 1.15" 9.3"

1.81 lbs. 1.15" 9.2"

1.81 lbs. 1.15" 9.2"

3.0"

3.0"

3.0"

Features

- Full continuous rated power output

- Sealed and potted in aluminum extrusions for the harshest operating environments

- Input Voltage: 12-32 VDC ( Item No. 15202, 16079, or 16411 ) or 20-60 VDC ( Item No. 15203, 16078, or 16412 )

- Output Voltage: 15.6 Vdc ( Item No. 15202 or 15203 ), 19 VDC ( Item No. 16078 or 16079 ), 12 VDC ( Item No. 16411 or 16412 )

- Output Current: 5.5 amps (max)

- Operating Temperature: -40 to 104° F ( Item No. 15202, 15203, 16078 or 16079 ), -4º to 104° F ( Item No. 16411 or 16412 )

Forklift Horizontal Extension Bar

Item No.

Placement Tilt Rotates Weight Height Width Depth

7160-0363

Attaches to rectangular overhead guard leg 1.5" to 5.0" wide

No No

6.77 lbs. 4.36" 19.0" 1.18"

Features

- The arm allows the user to position the device up to 15.34" horizontally from the inside of the overhead guard leg

- Allows for multiple system configurations based on style of forklift and computer configuration

- Can be mounted in conjunction with Clam Shell with Small Plate (Item No. 7160-0357), Forklift Dual Clam Shell with

Small Plate (Item No. 7160-0366) or Forklift Dual Clam Shell with 3" Arm and Small Plate (Item No. 7160-0420), Roll

Formed Bracket (Item No. 7160-0418) or Tube Overhead Guard Leg Clamp (Item No. 7160-0561)

Material Handling

Shown: 15203

Shown: 7160-0363

Quick Release Mount

Item No.

Placement Weight Height Width Depth

7160-0593

Attaches to the overhead guard leg 2.8 lbs.

1.45" 5.06" 7.79"

Features

- Allows computer or tablets mounted on Gamber-Johnson Clam Shells to be easily removed from the vehicle without tools

- Low profile quick release mount can be mounted in the horizontal or vertical orientation

- Features AMPS, NEC, VESA 75mm and 100mm and Gamber-Johnson hole patterns (see pg. 3 for hole pattern definitions)

- Includes backer plate and hardware for drill and no-drill solutions

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Shown: 7160-0593

67

68

Material Handling

Shown: 7160-0785

Shown: 7160-0795

Datamax O'Neil MP Compact 4 Mark II Printer Bracket

Item No.

Description Placement Weight Height Width Depth

7160-0785

Printer Bracket for the Datamax

O'Neil MP Compact 4 Mark II

Attaches to any Clam Shell (Item No.

7160-0357, 7160-0370, 7160-0371)

Features

- Printer bracket mounts to Gamber-Johnson Clam Shell using 75mm VESA hole pattern

- Bracket fastens to the printer using the PEM inserts on the printer

- Orients printer vertically or horizontally

- Bracket does not impede paper feed, printer ports or power connections

1.0 lbs. 0.50" 8.0" 4.0"

SATO MB410i-W2 Printer Bracket

Item No.

Description Placement Weight Height Width Depth

7160-0795

Printer Bracket for the SATO model MB410i-W2 printer.

Attaches to any

Clam Shell (Item No.

7160-0357, 7160-0370, 7160-0371)

Features

- Printer bracket mounts to Gamber-Johnson Clam Shell using 75mm VESA hole pattern

- Bracket fastens to the printer using the PEM inserts on the printer

- Orients printer vertically or horizontally

- Bracket does not impede paper feed, printer ports or power connections

1.0 lbs. 3.25" 7.0" 5.25"

Honeywell RL4 Quick Release Printer Bracket

Item No.

Description Placement

7160-0793

Printer Bracket for the

Honeywell RL4 printer.

Attaches to any Clam Shell (Item No.

7160-0357, 7160-0370, 7160-0371)

Features

- Printer bracket mounts to Gamber-Johnson Clam Shell using 75mm VESA hole pattern

- Bracket fastens to the printer using the PEM inserts on the printer

- Orients printer vertically or horizontally

- Bracket does not impede paper feed, printer ports or power connections

Weight Height Width Depth

.5 lb.

1.5" 6.25" 5.62"

Shown: 7160-0793

Zebra QLn420 Printer Bracket

Item No.

Description Placement

7160-0817

Printer Bracket for the Zebra

QLn420 printer

Attaches to any Clam Shell (Item No.

7160-0357, 7160-0370, 7160-0371)

Features

- Printer bracket mounts to Gamber-Johnson Clam Shell with 3/8" studs (included)

- Bracket fastens to the printer using the PEM inserts on the printer

- Orients printer vertically or horizontally

- Bracket does not impede paper feed, printer ports or power connections

Weight Height Width Depth

.5 lb.

1" 6.0" 4"

Shown: 16063

Shown: 16064

TYRI Safety Lights

Item No.

Light Color Placement Weight Height Width Depth

16063

Red

Attaches to any Light Bracket (Item No. 7160-0608,

7160-0609, 7160-0610, 7160-0611)

2.19 lbs. 5.31" 4.19" 3.24"

16064

Blue

Attaches to any Light Bracket (Item No. 7160-0608,

7160-0609, 7160-0610, 7160-0611)

2.19 lbs. 5.31" 4.19"

Features

- Increases safety and minimizes risk for accidents by displaying a concentrated bright beam pattern on the floor to

visually alert workers of an approaching vehicle

- Light pattern: Spot/Point

- Housing: Cast aluminum for long-term durability and vibration dampening in a rugged environment

- Lens: Impact Resistant Plastic

- Light Source: Light Emitting Diodes (LEDs)

- Input Voltage: 12V – 48V

- Operating Temperature: -40°F to 122°F (-40°C to 50°C)

- Amp Draw:

- 1.3 Amps @ 12V

- 0.6 Amps @ 24V

- 0.3 Amps @ 48V

- Life: 40,000 Hours

- Testing: EMC, IP 69K, Vibration, Salt Spray and UL compliant

- LED light warranted by TYRI for 4 years or 40,000 hours

3.24"

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Material Handling

Safety Light Brackets with Clam Shells

Item No.

Description Placement Tilt Swivel Weight Height Width Depth

7160-0608

Single light bracket

Attaches directly to the top of the

Overhead Guard

Yes - up to

160°

NA 5.50 lbs. 8.87" 6.40" 6.41"

7160-0609

Dual light bracket

Attaches directly to the top of the

Overhead Guard

Yes - up to

160°

Clam Shell -

360°

8.10 lbs. 9.39" 10.0" 7.41"

Features

- The light bracket attaches to the overhead guard and allows light to be mounted in multiple orientations

- The bracket can be used with overhead guard supports that are 2" to 5" wide

- The bracket provides for 4.75" of travel up and down

- The Clam Shell provides articulation that allows lights to be mounted in locations where the mounting surface is at an angle

Shown: 7160-0608

Shown: 7160-0609

Safety Light Brackets

Item No.

Description Placement Tilt Weight Height Width Depth

7160-0610

Single light bracket Attaches directly to the top of the Overhead Guard

No

3.80 lbs. 8.87" 6.40" 6.41"

7160-0611

Dual light bracket Attaches directly to the top of the Overhead Guard

No

4.10 lbs. 9.39" 10.0" 7.41"

Features

- The light bracket attaches to the overhead guard and allows light to be mounted in multiple orientations

- The bracket can be used with overhead guard supports that are 2" to 5" wide

- The bracket provides for 4.75" of travel up and down

- The bracket accommodates a light with hardware up to 3/8"

Shown: 7160-0610 Shown: 7160-0611

TRYI Safety Light and Bracket Solutions

Item No.

7170-0504

7170-0505

7170-0506

7170-0507

7170-0508

7170-0509

7170-0510

7170-0511

Description Placement

Light

Color

Tilt

Single light bracket with Clam

Shell (solution consists of

Item No. 7160-0608 and 16063 )

Single light bracket with Clam

Shell (solution consists of

Item No. 7160-0608 and 16064 )

Attaches directly to the top of the

Overhead Guard

Attaches directly to the top of the

Overhead Guard

Dual light bracket with Clam Shell

(solution consists of Item No.

7160-0609 and two 16064 )

Attaches directly to the top of the

Overhead Guard

Red

Blue

Yes - up to 160°

Yes - up to 160°

Dual light bracket with Clam Shell

(solution consists of Item No.

7160-0609, 16063 and 16064 )

Attaches directly to the top of the

Overhead Guard

Single light bracket

(solution consists of

Item No. 7160-0610 and 16063 )

Single light bracket

(solution consists of

Item No. 7160-0610 and 16064 )

Dual light bracket

(solution consists of Item No.

7160-0611 and two 16064 )

Attaches directly to the top of the

Overhead Guard

Attaches directly to the top of the

Overhead Guard

Attaches directly to the top of the

Overhead Guard

Red

Blue

No

No

Blue/Blue

No

Dual light bracket

(solution consists of Item No.

7160-0611, 16063 and 16064 )

Attaches directly to the top of the

Overhead Guard

Red/Blue

No

Swivel

NA

NA

Weight Height Width Depth

7.69 lbs. 14.0" 6.40" 6.41"

7.69 lbs. 14.0" 6.40" 6.41"

Clam Shell

- 360°

12.48 lbs. 14.7" 10.0" 7.41"

Clam Shell

- 360°

12.48 lbs. 14.7" 10.0" 7.41"

NA

NA

NA

NA

6.0 lbs. 12.7" 4.19" 4.80"

6.0 lbs. 12.7" 4.19" 4.80"

8.48 lbs. 12.7" 6.40" 3.97"

8.48 lbs. 12.7" 6.40" 3.97"

Shown: 7170-0504 Shown: 7170-0505

Shown: 7170-0506 Shown: 7170-0507

Shown: 7170-0509 Shown: 7170-0510

Shown: 7170-0511

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

69

Keyboard / printer Mounts

Shown: 7160-0810

Keyboard Arm

Item No.

Placement Width Adjustable Weight Height Width Depth

7160-0810

Attaches to any Gamber-Johnson Motion Attachment with 3/8" hole or KEYBOARD-BRKT

Yes - from 2.0" to 10.0" 1.6 lbs. 1.5"

Features

- Keyboard arm extends 10" positioning it close to the user; or moved away when not in use

- Attach Gamber-Johnson Clevis and Keyboard tray to one end of the keyboard arm

- Attach one end of the Arm to the KEYBOARD-BRKT to pole mount the keyboard arm

10.0" 2.0"

Shown: 7160-0757

Quick Release Keyboard Tray Assembly

Item No.

Placement Weight Height Width Depth

7160-0757

Attaches to any Gamber-Johnson

Motion Attachment

1.6 lbs.

1.73" 5.8" 7.26"

Features

- Patent Pending

- Keyboard tray features a “stationary mounting plate” that is mounted permanently to the mounting system, and a

“mobile” plate, used to mount the keyboard

- Stationary mounting plate provides 3 mounting patterns (VESA 75mm, Gamber-Johnson’s 2x4 pattern, and AMPS)

easily attaching to any Gamber-Johnson Motion Attachments

- The mobile plate offers a series of AMPS hole patterns offering additional versatility with your keyboard positioning

allowing it to be offset either towards the driver or passenger for optimal ergonomics

- Keyboard can be easily released by using the push button latch

- Keyboard can be comfortably placed on the operators lap for typing

- Mobile plate allows for easy attachment by aligning the front side of the trays and securing by applying light pressure

until you hear the click of the latch

- Key lock for theft deterrent

- Can be used with the

Tablet Display Mounts

- Constructed of light weight yet durable composite material

- SAE J1455 Crash tested

Shown: 7160-0498

Quick Release Keyboard Tray Assembly for use with Motion Attachment

Item No.

Placement Weight Height Width Depth

7160-0498

Attaches to Gamber-Johnson

Motion Attachment

(Item No. 7160-0419 and 7110-1008)

3.65 lbs.

1.40" 12.71"

Features

- Aluminum keyboard plate for reduced weight

- Keyboard plate features hole patterns: PDRC Keyboard, I-Key Keyboard, Man & Machine Keyboard and a

Standard AMPS pattern

- Keyboard can easily be removed using the latching lever in the back and allows for one-handed release

- Keyboard can be comfortably placed in the operators lap for typing

- When done keyboard snaps back onto the steel base plate with an audible click that indicates an engaged latch

- Any Gamber-Johnson Motion Attachment can be attached to the bottom of the keyboard tray

- Can be used with Tablet Display Mount (Item No. 7160-0494 or 7160-0529) (pg. 78)

7.10"

70

Shown: KEYBOARD-BRKT

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Keyboard / printer Mounts

iKey Keyboards

Item No.

Description Features Weight

7300-0028

7300-0029

7300-0030

7300-0031

7300-0032

7300-0033

7300-0034

7300-0035

7300-0036

7300-0037

7300-0038

Rechargeable Bluetooth

(BT-80-02)

®

Keyboard for Windows 8

Rechargeable Bluetooth

®

Keyboard for Windows/

Android (BT-80-03)

Bluetooth®-Compatible,

Wireless Industrial Keyboard with Touchpad (BT-87-TP)

Backlit Keyboard with

Integrated Touchpad

(FT-88-911-TP)

SkinnyBoard™ Mobile

Keyboard with Touchpad

(SB-87-TP-M)

SkinnyBoard™ Mobile

Keyboard (SB-87-TP)

Fully Sealed, IP68 Case, Bluetooth ®

Fully Sealed, IP65 Case, Bluetooth

wireless technology, Windows 8 integrated hot keys, VESA Mounting Pattern

®

wireless technology, Red LED

Backlit Keys, VESA Mounting Pattern

Rechargeable, 12 Function Keys, Built-In Mounting Holes, Class 2

Output Power, Integrated Touchpad, Up to a 30-foot Range,

Bluetooth

®

- compatible version 2.0

12 Function Keys, 88-Key Functionality, Integrated Backlighting,

Integrated Touchpad, Mobile Mounting Holes, One-Touch

Emergency Key

12 Function Keys, Red Backlit Keys, Integrated Touchpad, Silicone

Rubber, VESA Mounting Pattern, Ultra-Thin Design

1.2 lbs.

1.2 lbs.

2.0 lbs.

2.25 lbs.

1.4 lbs.

IP65 Case,12 Function Keys, Fully Sealed, Integrated Touchpad, Silicone

Rubber, Red LED Backlit Keys, USB Connectivity, Ultra-Thin Design

1.4 lbs.

Mountable Keyboard with

Touchpad (SL-86-911-TP)

OEM Keyboard for Public

Safety (SL-86-911-USB)

86-Key Functionality, Fn Key for Secondary Legend Flexibility,

Integrated Touchpad, Meets NEMA 4X (IP65) Specifications, One-

Touch Emergency Key, Red Backlit Keys

86-Key Functionality, Fn Key for Secondary Legend Flexibility,

Integrated Touchpad, Meets NEMA 4X (IP65) Specifications, One-

Touch Emergency Key, Red Backlit Keys

2.25 lbs.

2.0 lbs.

Mobile Backlit Keyboard with

HulaPoint II™ (SLK-79-M)

12 Function Keys, Integrated HulaPoint II™ Pointing Device, Mobile

Mounting Holes, Red Backlit Keys, USB and PS/2 configurations available 1.0 lb.

Bluetooth-Compatible keyboard with Touchpad

(BT-80-TP)

Full Travel Keyboard with

Attachment Versatility

(IK-TR-88)

Wireless industrial keyboard, Fully-sealed keyboard - meets NEMA 4X specifications, Silicone rubber keypad and ABS polycarbonate case,

Submersible and easy to clean with disinfectants, Compact design and internal Bluetooth® module, Red LED backlighting

1.2 lbs.

12 Function Keys, 88-Key Functionality, Integrated Backlighting,

Integrated Touchpad, Mobile Mounting Holes, One-Touch

Emergency Key

2.0 lbs.

Shown: 7300-0033

Shown: 7300-0037

Brother PocketJet 6 & PocketJet 6 Plus Printers

Item No.

Placement Interfaces

Printer

Resolution

Weight Height Width Depth

14327

14328

14329

Attaches to any Gamber-Johnson Brother PocketJet

Printer Mount (Item No. 7160-0006 and 7160-0126)

Attaches to any Gamber-Johnson Brother PocketJet

Printer Mount (Item No. 7160-0006 and 7160-0126)

Attaches to any Gamber-Johnson Brother PocketJet

Printer Mount (Item No. 7160-0006 and 7160-0126)

USB

USB

203 x 200 dpi 1.4 lbs. 1.18"

300 x 300 dpi 1.4 lbs. 1.18"

Bluetooth 203 x 200 dpi 1.4 lbs. 1.18"

10.04"

10.04"

10.04"

2.17"

2.17"

2.17"

14330

Attaches to any Gamber-Johnson Brother PocketJet

Printer Mount (Item No. 7160-0006 and 7160-0126)

Bluetooth 300 x 300 dpi 1.4 lbs. 1.18" 10.04" 2.17"

Features

- Prints on 8.5" wide thermal media - cut sheets for letter and legal size documents, continuous roll paper for

longer printouts and perforated roll and fanfold paper

- Fast mobile printing - up to 6 ppm

- USB and IrDA interfaces

- NiMH battery included with printer

- Low maintenance costs - no ink or ribbons to replace

- Compact size fits in places where space is limited

- Lightweight - less than 1.4 lbs. including NiMH battery

- Direct thermal technology is less susceptible to temperature and humidity extremes

- Operating Systems Supported: Windows XP/Vista/7; Mac OS TBD; Windows Mobile; BlackBerry OS

- 1 year limited warranty by Brother.

Shown: PocketJet 6

Shown: PocketJet 6 Plus

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

71

72

Keyboard / printer Mounts

Brother PocketJet 6 & PocketJet 6 Plus Printer Accessories

Item No.

Description

14331

14332

Power Car Adapter - wired 14 Foot for use with PocketJet 3, 3 Plus, 6, 6 Plus Printers

USB Cable - 4 Foot for use with PocketJet 3, 3 Plus, 6, 6 Plus Printers

Shown:14331

Shown:14332

Shown: 7160-0006

Brother Armrest Printer Mount

Item No.

Placement Drilling Required Weight Height Width Depth

7160-0006

On top of any

MCS Top Plate

or any flat stable surface

No - attaches to any

MCS Top Plate

(see pg 45) 11.25 lbs.

15.0"

(includes 5" pole) 5.5"

Features

- Convenient flip-up armrest and printer mount all in one

- For use with the following Brother printers:

PocketJet 200 PocketJet 3 PocketJet 6

PocketJet II PocketJet 3 Plus PocketJet 6 Plus (NiMH battery only)

- Mount holds printer and paper roll in separate lockdown tray

- Paper roll is enclosed to protect from dirt and dust

- The cover latches shut and can be used with a padlock for extra security

- Indicator lights and on/off button are easy to see and accessible when the cover is closed

- Paper deflector prevents paper from curling up and jamming

- Cable strain relief protects connector interface on the printer engine from damage

- Printer can be easily removed from the mount for use outside of the vehicle

- Paper feeds out the side towards the driver (Paper and printer not included)

- The cover latches shut and can be used with a padlock for extra security

11.6"

Shown: 7160-0126

Brother PocketJet Series Mount

Item No.

Placement Description Weight Height Width Depth Misc

7160-0126

Secures to the

Rack-to-Post

Platform (Item No. DS-74 or DS-74-L) , then secured to any

Lower Tube

,

Vehicle

Base

with a welded pole or onto any flat, stable surface

Printer/Paper

Roll Housing with optional bolt-on cable strain relief

2.34 lbs. 3.25” 12.25” 5.25”

Holds printer and paper roll in separate trays.

Cable strain relief protects connector interface on the printer engine from damage

Features

- For use with the following Brother printers:

PocketJet 200 PocketJet 3 PocketJet 6

PocketJet II PocketJet 3 Plus PocketJet 6 Plus (NiMH battery only)

- Mount holds printer and paper roll in separate lockdown tray

- New wire draw latch provides a secure fit to reduce vibration noise

- Bolt-on cable restraint provide cable management options if desired

- There is no drilling required if mounting to a Rack-to-Post (Item No. DS-74 or DS-74-L) , otherwise drilling is required for

most other applications

- Gamber-Johnson mounting hole pattern (see pg. 3 for hole pattern definitions)

- Roll paper is enclosed to protect from prolonged exposure to direct sunlight

- Paper roll cut-out allows for vertical orientation as well as horizontal orientation

- Printer can be easily removed from the mount for use outside of the vehicle

- Paper and printer not included

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Keyboard / printer Mounts

Brother RuggedJet Printer Mount

Item No.

Placement Weight Height Width Depth

7160-0425

Secures to the Rack-to-Post Platform (Item No. DS-74 or DS-74-L), any Lower Pole,

Vehicle Base

with a welded pole or onto any flat stable surface

2.15 lbs.

2.12" to

3.38"

12.5" to

14.62"

7.62" to

8.88"

Features

- Bracket allows the Brother RuggedJet™ RJ-4030 or RJ-4040 mobile printer to be mounted in a vertical or horizontal

orientation

- Optional removable cable restraint

- Allows installation of paper roll while mounted

- Works with Brother’s optional card reader

- This is not a quick release mount

Shown: 7160-0425

Canon i70/i80/i90/i100 and HP100/HP450/HP460/HP470 Printer Mount

Item No.

Placement Drilling Required Weight Height Width Depth

7160-0392

Attaches to pre-drilled holes on

Rack-to-Post Platform

(Item No. DS-74 or DS-74-L)

No - if using a

Rack-to-Post Platform

(Item No. DS-74 or DS-74-L)

2.15 lbs.

2.12" to

3.38"

12.5" to

14.62"

Features

- Universal printer mount designed to be used with Canon i70/i80/i90/i100 and HP100/450/460/470 printers

- Adjustable side brackets allows the printer to be firmly seated

- Printer mount can be used with or without the optional battery pack

- For extra protection against shock and vibration, an Isolator Plate (Item No. 7160-0351) is recommended

7.62" to

8.88"

Shown: 7160-0392

HP150 All-in-One Mobile Printer

Item No.

Placement Drilling Required Weight Height Width Depth

7160-0507

Attaches to pre-drilled holes on

Rack-to-Post Platform

(Item No. DS-74 or DS-74-L)

No - if using a

Rack-to-Post

Platform (Item No. DS-74 or DS-74-L)

2.2 lbs.

4.24” 14.56”

Features

- Printer mount designed to be used with HP150 All-in-One Printer

- For extra protection against shock and vibration, an Isolator Plate (Item No. 7160-0351) is recommended

8.80”

Shown: 7160-0507

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

73

NotePad™ V

(7160-0250)

Page 75

Features/Benefits

- Special flanged side clip design provides superior strength and can be easily adjusted

- Rear support brace is gusseted for added restraint

- 90° wing turn closure latch allows for quick computer insertion and removal

- Adjusts to fit computer widths from 11.75" to 18.25"

74

Page 76 Page 75

tabCruzer

®

MiNi – uNiVersal tablet Cradle

(7160-0774)

Features/Benefits

- TabCruzer® Mini – Universal Tablet Cradle is designed to hold consumer

tablet computers

- Reversible front and back supports adjust to accommodate varying

depths of computers

- 90 wing turn closure latch allows for quick computer insertion, removal

and adjustment

- Adjusts to fit computer widths from 7.12" to 11.5"

NotePad™ V tall CliPs

(7160-0250-01)

Features/Benefits

- Tall clips are designed to be used with rugged laptop computers

with thicker chassis

- 90° wing turn closure latch allows for quick computer insertion

and removal

- Clips adjust to fit computer thickness from 0.12" to 2.0"

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Universal Laptop Mount - NotePad™ V

Item No.

7160-0250

Description

Width

Adjustable

Depth

Adjustable

Thickness

Adjustable

For use with most computers

(Dell, HP, Sony, Toshiba,

Gateway, Samsung,

Compaq, Asus, etc…)

Yes - adjusts to computer widths from

10.62" - 16.5"

Yes - adjusts to computer depths from

9.0" - 12.38"

Yes - adjusts to computer thickness

(measured with screen open) from

0" - 1.5"

7160-0250-01

For use with Rugged

Computer Laptops that exceed 1.5” in thickness

(Panasonic Toughbook 30 and 31, Dell XFR, etc...)

Yes - adjusts to computer widths from

10.62" - 16.5"

Yes - adjusts to computer depths from

9.0" - 12.38"

Yes - adjusts to computer thickness

(measured with screen open) from

0.12" - 2.0"

6.5 lbs 1.62"

6.5 lbs 1.62"

Overall

Width

11.75"

to

18.25"

11.75"

to

18.25"

Overall

Depth

9.5"

9.5"

7160-0250-02

7160-0250-03

For use with computers where the keyboard extends to the left and right edge of the computer

Yes - adjusts to computer widths from

10.62" - 16.5"

Yes - adjusts to computer depths from

9.0" - 12.38"

Yes - adjusts to computer thickness

(measured with screen open) from

0" - 1.5"

6.5 lbs 1.62"

For use with most computers

(Dell, HP, Sony, Toshiba,

Gateway, Samsung,

Compaq, Asus, etc…), uses

Cam back clips

Yes - adjusts to computer widths from

10.62" - 16.5"

Yes - adjusts to computer depths from

6.63" - 8.0"

Yes - adjusts to computer thickness

(measured with screen open) from

0" - 1.5"

6.5 lbs. 1.62"

11.75"

to

18.25"

11.75" to

18.25"

9.5"

9.5"

7160-0402

For use with small computers (netbooks)

Yes - adjusts to computer widths from

8.2" - 11.8"

Yes - adjusts to computer depths from

7.58"-9.33"

Yes - adjusts to computer thickness

(measured with screen open) from

0" - 1.5"

5.5 lbs 1.62"

9.6"

to 13.2" 9.5"

7160-0402-03

For use with small computers

(netbooks and tablets), uses

Cam back clips

Yes - adjusts to computer widths from

8.2" - 11.8"

Yes - adjusts to computer depths from

6.63" - 8.0"

Yes - adjusts to computer thickness

(measured with screen open) from

0" - 1.5"

Features

- Special “flanged” side clip design provides superior strength and can be easily adjusted they:

- are “one-size-fits-all”, work with most computers

- feature T-molded polycarbonate covers that hold clips in place during installation for easy height adjustment

- Reversible front and back supports adjust to accommodate varying depths of computers

- Rear support brace is gusseted for added restraint

- 90° wing turn closure latch

- allows for fast initial size adjustment

- allows for quick computer insertion and removal

- * has built-in heavy duty key lock (keyed alike)

- Molded polycarbonate end caps ensure that the computer is level when in the cradle

- Multiple mounting holes allows the computer mount to be offset to avoid other equipment, if necessary

- Gamber-Johnson mounting hole pattern (see pg. 3 for hole pattern definitions)

- Passed 30 mph crash tested per SAE J1455 standard

- Can be used with optional accessories to further capabilities in the field

*Note

- The

NotePad™ V

side clips and key lock are designed to securely hold the laptop in the mount and to deter theft, not prevent it.

Gamber-Johnson recommends taking your laptop out of the vehicle when not in use.

9.5"

Shown: 7160-0250

Shown: 7160-0250-01

Shown: 7160-0250-02

Shown: 7160-0250-03

Shown: 7160-0402

Universal Laptop Mount - NotePad™ V Clip Packages

Item No.

7120-0519

7120-0587

Description Placement Weight

Tall Clip Package for use with Rugged Computer Laptops that exceed 1.5” in thickness (Panasonic Toughbook 30 and

31, Dell XFR, etc...)

Note:

buy this only if you already have a NotePad™ V Universal

Computer Mount (Item No. 7160-0250)

Replaces the clips on the

NotePad™ V Universal Computer

Mount (Item No. 7160-0250)

Cam Clip Packaget used with a smaller notebook, convertible tablet or tablet format

Note:

buy this only if you already have a NotePad™ V Universal

Computer Mount (Item No. 7160-0250) or the NotePad™ V-LT Universal

Computer Mount (Item No. 7160-0402)

Replaces the clips on the NotePad™

V Universal Computer Mount (Item

No. 7160-0250) or the

NotePad™

V-LT Universal Computer Mount (Item

No. 7160-0402)

0.25 lbs

0.30 lbs

Shown: 7160-0402-03

Shown: 7160-0251

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

75

76

Universal CompUter Cr adles

Shown: 7160-0252

Shown: 7160-0253

Universal Laptop Mount - NotePad™ V Accessories

Item No.

Description Placement

7160-0251

7160-0251-01

7160-0252

7160-0253

7160-0351

7160-0539

Screen Support for

NotePad™ V

with the standard clip package

Screen Support for

NotePad™ V

with the tall clip package

LED Light Assembly

Microphone Clip

Shock/Vibration Isolator Plate

Note: Computer and Cradle

combined should not exceed 30 lbs.

Lind Power Supply Mount

Attaches to the back right corner using pre-drilled slots on the NotePad™ V

Universal Computer Mount (Item No.

7160-0250, 7160-0250-02 or 7160-0402)

Attaches to the back right corner using pre-drilled slots on the NotePad™ V

Universal Computer Mount

(Item No. 7160-0250-01)

Attaches to any corner using pre-drilled slots on any NotePad™ V Universal

Computer Mount

Attaches to any corner using pre-drilled slots on any NotePad™ V

Universal Computer Mount

Positioned between any

Motion

Attachment

and any NotePad™ V

Universal Computer Mount

Attaches a Lind Power supply between a

Docking Station/Cradle

and the

Motion

Attachment

Weight Height Width Depth

0.50 lbs 8.75" 2.5" 1.5"

0.50 lbs 8.75" 2.5" 1.5"

0.50 lbs 17.0" 2.5" 1.56"

0.15 lbs 2.12" 1.5" 1.0"

2.43 lbs 0.85" 7.0" 6.5"

1.52 lbs. 5.0" 10.01" 1.27"

Shown: 7160-0351

Shown: 7160-0539

Shown: 7160-0774

Universal Tablet Computer - TabCruzer

®

Mini

Item No.

7160-0774

Description

Width

Adjustable

For use with most consumer tablet computers (Apple iPad,

Samsung Galaxy, Microsoft

Surface Pro, etc…)

Yes - adjusts to tablet widths from

6.9" to 11.2"

Depth

Adjustable

Yes - adjusts to tablet depths from

4.3" to 8.2""

Thickness

Adjustable

Yes - adjusts to tablet thickness from

0.2" to 0.7"

1.7 lbs. 2.25"

Features

- TabCruzer

®

Mini - Universal Tablet Cradle is designed to hold consumer tablet computers

- Can be used with Motion Attachments with the VESA 75mm hole pattern

- Slim form design provides low mounting capability

- Side clips are easily adjusted to the proper tablet height and work with most tablets

- Reversible front and back supports adjust to accommodate varying depths of computers

- Rear support brace is gusseted for added restraint

- 90° wing turn closure latch

- allows for fast initial size adjustment

- allows for quick computer insertion and removal

- has built-in heavy duty key lock (keyed alike)

- Engineered polycarbonate and steel design for long-term durability

- Limited lifetime warranty

Overall

Width

Overall

Depth

9.6" to

12.1"

8.4"

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

tablet displ ay moUnts

MoNgoose tablet disPlay MouNt Kit

(7170-0218)

Page 78

Display Kit Includes

Tablet Display Mount (Item No. 7160-0494)

Mongoose (Item No. 7160-0220)

Quick Release Keyboard Tray for use with

Motion Attachment (Item No. 7160-0498)

Features/Benefits

Can be mounted two different ways:

1. Mount the Display Mount on the back of the Mongoose and Quick Release Keyboard on the Clevis

- Quick Release Keyboard slides independently of the Display Mount up to 9" forward and locks into place when stowed.

2. Mount the Display Mount and Quick Release Keyboard on the Clevis

- Display Mount and keyboard travel together toward the driver and both swivel on top of the Locking Slide Arm.

Page 78

tablet disPlay MouNt

(7160-0494)

Features/Benefits

- Display Mount can be used with any tablet or tablet docking station that

has an AMPS, NEC, Gamber-Johnson or VESA 75 mm hole pattern

- The Display mount and be tilted downward 160° which helps provide easy

access to the controls on the instrument panel

- Display Mount can be swiveled 60° right/60° left for optimal viewing

positioning

Page 78

Quad-MotioN tablet disPlay MouNt Kit

(7170-0219)

Display Kit Includes

Tablet Display Mount (Item No. 7160-0494)

Quad Motion TS5 (Item No. 7160-0285)

Quick Release Keyboard Tray for use with Motion Attachment

(Item No. 7160-0498)

Features/Benefits

- Quick Release Keyboard slides independently of the Display Mount up to

5" forward and backward

- The Display Mount is in a fixed position but can be tilted for optimal viewing

- The Quad-Motion TS5 rotates up to 60° right or left; the Display Mount and

Keyboard also rotate 60° right or left for optimal viewing

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

77

tablet displ ay moUnts

Shown: 7160-0494

Shown: 7160-0529

Tablet Display Mount

Item No.

Tilt Swivel Weight Height Width Depth

7160-0494

Display can be tilted down

160° away from the dash

Display can be swiveled

60° right/60° left

3.85 lbs.

8.42" to 10.3" (entire mounting system will determine overall height) 5.5" 5.75"

7160-0529

Display can be tilted down

160° away from the dash

Display can be swiveled

60° right/60° left

4.0 lbs.

10.31" to 12.70" (entire mounting system will determine overall height) 5.5" 5.75"

Features

- The

Tablet Display Mount

can be placed on any Gamber-Johnson

Upper Pole

, the

Mongoose

(Item No. 7160-0220) or

“smiley face” pattern found on a

MCS Console System

(ordered separately) allowing flexibility in how you want to adapt

the tablet in a vehicle

- Display Mount can be used with any tablet or tablet docking station that has an AMPS, NEC, Gamber-Johnson or VESA

75mm hole pattern (see pg. 3 for hole pattern definitions)

- Display Mount can easily tilted down 160° away from the dashboard, providing easy access to the controls on the

instrument panel

- Display Mount can be swiveled 60° right/60° left for optimal viewing positioning

- Display Mount is height adjustable to accommodate the various sizes of tablet computers and docking stations

- Can be used with the Quick Release Keyboard Tray for Motion Attachment (Item No. 7160-0498) and one of the

following

Motion Attachments

to make a sliding keyboard:

- Quad-Motion TS3 (Item No. 7160-0284)

- Quad-Motion TS5 (Item No. 7160-0285)

- Mongoose (Item No. 7160-0220)

- 6" Locking Slide Arm (Item No. 7160-0514) with 3/8" stud

- Limited lifetime warranty

Shown: 7170-0218

Shown: 7170-0218-01

Shown: 7170-0219

Shown: 7170-0513

Shown: 7170-0219-01

Shown: 7170-0513-01

Tablet Display Mount Kits with Keyboard

Item No.

Description Weight Height Width Depth

7170-0218

7170-0218-01

7170-0219

7170-0219-01

Kit includes the

Tablet Display Mount (Item No.

7160-0494 ), Mongoose with 3/8" stud (Item No.

7160-0427) and the

Keyboard (Item No. 7160-0498)

Kit includes the Tall Tablet Display Mount (Item No.

7160-0529) , Mongoose with 3/8" stud (Item No.

7160-0427) and the Keyboard (Item No. 7160-0498)

Kit includes the Tablet Display Mount (Item No.

7160-0494 ), Quad-Motion TS5 (Item No. 7160-0285) and the Keyboard (Item No. 7160-0498)

Kit includes the Tall Tablet Display Mount (Item No.

7160-0529) , Quad-Motion TS5 (Item No. 7160-0285) and the Keyboard (Item No. 7160-0498)

14.5 lbs.

14.65 lbs.

12.0 lbs.

12.15 lbs.

9.88" to 11.75" (entire mounting system will determine overall height)

11.77" to 14.5" (entire mounting system will determine overall height)

8.38" to 10.25" (entire mounting system will determine overall height)

10.27" to 12.65" (entire mounting system will determine overall height)

7170-0513

Kit includes the Tablet Display Mount (Item No.

7160-0494 ), Quad-Motion TS5 (Item No. 7160-0285) and the Keyboard (Item No. 7160-0757)

9.38 lbs.

8.38" to 10.25" (entire mounting system will determine overall height)

7170-0513-01

7170-0514

Kit includes the Tall Tablet Display Mount (Item No.

7160-0529) ,

Quad-Motion TS5 (Item No. 7160-0285) and the Keyboard (Item No. 7160-0757)

Kit includes the

Tall Tablet Display Mount

(Item No. 7160-0758) , Mongoose 9" Locking Slide Arm

(Item No. 7160-0220) and the

Quick Release Keyboard

Tray (Item No. 7160-0757)

9.53 lbs.

15.0 lbs.

10.27" to 12.65" (entire mounting system will determine overall height)

16.02"

12.88" 13.62"

12.88" 13.62"

12.88" 11.18"

12.88" 11.18"

7.40"

7.40"

7.54"

13.27"

13.27"

14.41"

78

Shown: 7170-0514

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

panasoniC Cr adles & doCking stations

toughPad Fz-M1 doCKiNg statioN

Page 81

Features/Benefits

- This product has passed the appropriate tests to qualify for the Toughbook Certified status

- Push and Turn latching system with key lock

- Two port replication types: Full port replicator or Lite port replicator

- Two mounting hole pattern options: Gamber-Johnson 2x4 or VESA 75mm

Page 80

toughPad g1 doCKiNg statioN

Features/Benefits

- This product has passed the appropriate tests

to qualify for the Toughbook Certified status

- Designed to work with the Panasonic Toughpad

FZ-G1 tablet computer

- Two mounting hole pattern options:

Gamber-Johnson 2x4 or VESA 75mm

Page 88 Page 86

toughbooK 31 doCKiNg statioN

Features/Benefits

- This product has passed the appropriate tests

to qualify for the Toughbook Certified status

- Smaller footprint for easier tilt and rotation and an

unobstructed view of the radios or other instruments

- Two power options: Integrated Power or

External Power

toughbooK 54 doCKiNg statioN

Features/Benefits

- This product has passed the appropriate tests

to qualify for the Toughbook Certified status

- Small footprint is designed to maximize

available space inside of the vehicle

- Front push button latch docking mechanism –

with key lock

- Special access area for Smart Card reader

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

79

80

panasoniC Cr adles & doCking stations

Shown: 7160-0489-00

TabCruzer

®

for Panasonic Toughpad FZ-G1 Cradle

Item No.

Power Supply Weight Height

7160-0490-00

No - must use external Lind Auto Adapter (Item No. 11798) 2.5 lbs.

9.14"

Features

- Design works with the Toughpad FZ-G1 tablet computer

- Cradle can be mounted using the VESA 75MM mounting hole pattern or clevis 7160-0750

- Alignment tabs assist in proper placement when inserting the tablet

- Integrated key lock: locks are keyed the same

- Steel and Composite design for reduced overall weight

- Passed SAE Standard J1455 Crash Test

- 3 year limited warranty

Width

11.22"

Depth

3.8"

Shown: 7160-0487-00

TabCruzer

®

for Panasonic Toughpad FZ-G1 Docking Station

Item No.

Antenna

Pass-Through

Power Supply

7160-0487-00

NA

Weight Height Width Depth

No - must use external Lind Auto Adapter (Item No. 11798) 2.5 lbs. 9.14" 11.22" 3.8"

7160-0487-02

Dual RF (TNC) No - must use external Lind Auto Adapter (Item No. 11798) 2.5 lbs. 9.14" 11.22" 3.8"

Features

- Gamber-Johnson has worked with Panasonic to perform the appropriate tests needed to qualify a product as

Toughbook Certified

- Design works with the Toughpad FZ-G1 tablet computer

- Docking Station can be mounted using any Gamber-Johnson VESA 75mm Motion Attachment or clevis (Item No. 7160-0750)

- Alignment tabs prevent damage to the docking connector when docking the tablet

- Integrated key lock: locks are keyed the same

- Steel and Composite design for reduced overall weight

- Passed SAE Standard J1455 Crash Test

- 3 year limited warranty

Port Replicator

- Ethernet

- USB (2)

- Serial (1)

RJ45

9 pin

D-sub 9 pin

- Video (2)

- VGA

- HDMI

D-sub 15 pin

- RF Pass-through (Optional) TNC

- Power Supply Input

19 pin

DC

Shown: Ports Shown: RF Ports

Shown: 7160-0487-02

TabCruzer® for Panasonic Toughpad FZ-G1 Thin Docking Station

Item No.

Antenna

Pass-Through

Power Supply

7160-0595-00

NA

Weight Height Width Depth

No - must use external Lind Auto Adapter (Item No. 11798) 2.5 lbs. 9.33" 11.22" 2.56"

7160-0595-02

Dual RF (TNC) No - must use external Lind Auto Adapter (Item No. 11798) 2.5 lbs. 9.33" 11.22" 2.56"

Features

- Gamber-Johnson has worked with Panasonic to perform the appropriate tests needed to qualify a product as

Toughbook Certified

- Design works with Toughpad FZ-G1 tablet computer only

- Docking Station is designed to perfectly fit the G1 tablet without extra accessories, thus preserving the existing

cabin space within the vehicle

- Docking station can be mounted using any Gamber-Johnson VESA 75mm

Motion Attachment (Item No. 7160-0750)

- Alignment tabs prevent damage to the docking connector when docking the computer

- Steel and Composite design for reduced overall weight

- Rugged construction for long-term durability

- Passed SAE Standard J1455 Crash Test

- 3 year limited warranty

Port Replicator

- Ethernet

- Serial (1)

- Video (2)

- VGA

- HDMI

RJ45

- Fully Powered USB 3.0 (2) 9 pin

D-sub 9 pin

D-sub 15 pin

19 pin

- RF Pass-through (Optional) TNC

- Power Supply Input DC

Shown: Ports Shown: RF Ports

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

panasoniC Cr adles & doCking stations

TabCruzer

®

for Panasonic Toughpad FZ-G1 Cradle and Docking Station Accessories

Item No.

Description Placement Weight Height Width Depth

7160-0454

11798

Universal Adapter

Bracket

External Lind Automobile

Bare Wire Leads Power

Adapter (Toughpad FZ-G1)

Attaches between the back of the TabCruzer for

Panasonic Toughpad FZ-G1 Docking Stations or

Cradles and any Gamber-Johnson Motion Attachment

0.85 lbs. 0.97" 5.0" 5.0"

7160-0539

Station/Cradle

and the

Docking

Motion Attachment

11634

External Lind Automobile

Cigarette Power Adapter

(Toughpad FZ-G1)

For use with the following TabCruzer for Panasonic

1.52 lbs. 5.0" 10.01" 1.27"

Toughpad FZ-G1 Docking Stations and Cradles 0.85 lbs. 1.1"

5.4" 3.1"

For use with the following TabCruzer for Panasonic

Toughpad FZ-G1 Docking Stations and Cradles 1.22 lbs. 1.0"

5.0" 3.0"

Shown: 7160-0539

Shown: 11634

TabCruzer

®

for Panasonic Toughpad FZ-M1 Cradle

Item No.

Weight Height Width Depth

7160-0543-00

2.3 lbs.

8.1" 9.63" 3.57"

Features

- Gamber-Johnson has worked with Panasonic to perform the appropriate tests needed to qualify a product as

Toughbook Certified

- Designed using MIL-STD-810G test procedures

- Design works with the Toughpad FZ-M1 tablet computer

- Cradle can be mounted using either the Gamber-Johnson 2x4 pattern or the VESA 75mm mounting hole pattern, to

attach to a Gamber-Johnson system using VESA pattern use the Universal Adapter Bracket (Item No. 7160-0454)

(see pg. 3 for hole pattern definitions)

- Cradle design accommodates mag stripe reader and hand strap (sold separately by Panasonic)

- Composite/steel design for reduced overall weight and durability

- Limited lifetime warranty

TabCruzer

®

for Panasonic Toughpad FZ-M1/FZ-B2 Docking Station

Item No.

Computer

Antenna

Pass-Through

Port

Replication

Power Supply Weight Height Width Depth

7160-0531-00

FZ-M1 and FZ-B2 NA Lite

No - must use external

Lind

Auto Adapter (Item No. 11798)

2.48 lbs. 8.1" 9.63" 3.57"

7160-0531-02

7160-0531-03

FZ-M1 and FZ-B2 Dual RF (TNC)

FZ-M1 NA

Lite

Full

No - must use external

Lind

Auto Adapter (Item No. 11798)

No - must use external

Lind

Auto Adapter (Item No. 11798)

2.48 lbs. 8.1"

2.48 lbs. 8.1"

9.63" 3.57"

9.63" 3.57"

7160-0531-04

FZ-M1 Dual RF (TNC) Full

No - must use external

Lind

Auto Adapter (Item No. 11798)

2.48 lbs. 8.1" 9.63" 3.57"

Features

- Gamber-Johnson has worked with Panasonic to perform the appropriate tests needed to qualify a product as

Toughbook Certified

- Design works with the Toughpad FZ-M1 and FZ-B2 tablet computers

- Docking Station is available in a Full Port Replication or a Lite Port Replication version

- Docking Station can be mounted using any Gamber-Johnson VESA 75mm Motion Attachment (see pg. 3 for hole

pattern definitions) (Item No. 7160-0750)

- Downward facing I/O ports with cable strain relief system for easy cable management

- Docking Station design accommodates mag stripe reader and hand strap (sold separately by Panasonic)

- Push and Turn lock with key lock for theft deterrence

- Insert tablet then push down and turn lock to close and dock tablet

- Alignment tabs prevent damage to the docking connector when docking the computer

- Composite/steel design for reduced overall weight and durability

- Passed SAE Standard J1455 Crash Test

- 3 year limited warranty

Full Port Replicator

- Ethernet RJ45

- Fully Powered USB 3.0 (2) 9 pin

- Serial (1) D-sub 9 pin

- Video (2)

- VGA D-sub 15 pin

- HDMI 19 pin

- RF Pass-through (Optional) TNC

- Power Supply Input DC

Lite Port Replicator

- Ethernet RJ45

- Fully Powered USB 2.0 (2) 4 pin

- RF Pass-through (Optional) TNC

- Power Supply Input DC

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Shown: 7160-0543-00

Shown: 7160-0531-00

Shown: 7160-0531-04 ports

81

82

panasoniC Cr adles & doCking stations

TabCruzer

®

for Panasonic Toughpad FZ-M1/FZ-B2 Cradle and Docking Station Accessories

Item No.

Description Placement Weight Height Width Depth

7160-0539

Lind Power Supply Mount

11798

Attaches a Lind Power supply between a Docking

Station/Cradle

and the

Motion Attachment

External Lind Automobile

Bare Wire Leads Power

Adapter (Toughpad FZ-G1)

For use with the following

TabCruzer for Panasonic

Toughpad FZ-M1 Docking Stations and Cradles

1.52 lbs.

1.22 lbs.

5.0" 10.01" 1.27"

1.0" 5.0" 3.0"

Shown: 7160-0539

Shown: 7160-0564

TabCruzer

®

for Panasonic Toughpad FZ-X1 and FZ-E1 Powered Cradle

Item No.

Weight Height Width Depth

7160-0564

1.3 lbs.

8.0" 5.3" 3.6"

Features

- Gamber-Johnson has worked with Panasonic to perform the appropriate tests needed to qualify a product as

Toughbook Certified

- Design works with the Toughpad FZ-X1 and FZ-E1 5-inch handheld computers

- Access to all computer function buttons and ports while tablet is docked in computer

- AMPS, NEC and keyhole slot mounting patterns located on the back of the powered cradle (see pg. 3 for hole pattern

definitions)

- Cradle accommodates magnetic card reader and 2 different hand straps (sold separately by Panasonic)

- Front bracket and side channels align computer for proper docking connectivity

- Push button lock with key lock for theft deterrence

- Insert computer and push top down until lock engages - computer is docked

- Push button to release top and remove computer

- Composite design for reduced overall weight

- 3 year limited warranty

Shown: 7170-0156

TabCruzer

®

for Panasonic Toughpad FZ-X1 and FZ-E1 Powered Cradle Accessories

Item No.

Description Placement Tilt Swivel Weight Height Width Depth

7170-0156

MAX3 Mounting

Solution for TabCruzer

(includes part numbers 7160-0296 and two 14144 plates)

11798

External Lind

Automobile Bare Wire

Leads Power Adapter

(Toughpad FZ-X1 and

FZ-E1)

Attaches to the back of any

TabCruzer for Panasonic Toughpad

FZ-X1 & FZ-E1 Powered Cradle using the AMPS and NEC mounting pattern

For use with the

TabCruzer for

Panasonic Toughpad FZ-X1 & FZ-E1

Powered Cradle

Yes

NA

Yes

NA

1.05 lbs.

1.22 lbs.

1.0" 5.0" 3.0"

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

panasoniC Cr adles & doCking stations

Panasonic Toughbook 19 Cradle

Item No.

Port Replicator/Internal Power Supply Weight Height

7160-0264-05

NA 3.35 lbs.

3.04"

Features

- Designed using MIL-STD-810F test procedures

- Lightweight cradle can be positioned both vertically (Tablet PC) or horizontal (Notebook PC)

- Rounded edges to enhance personal safety

- New push button latching mechanism draws computer down

- Holes provided for cable strain relief (cable ties included)

- Use

Lind Auto Adapter (Item No. 11798)

- Gamber-Johnson mounting hole pattern (see pg. 3 for hole pattern definitions)

- Passed 30 mph Sled Impact Test per SAE Standard J1455

- Aluminum structure for reduced overall weight

- Limited lifetime warranty

Width

11.10"

Depth

11.67"

Shown: 7160-0264-05

Panasonic Toughbook 19 Cradle and Docking Station Accessories

Item No.

Description Placement Weight Height Width Depth

7160-0215

7160-0049

LED Light Assembly

Screen Support

Attaches to either side of the docking station or cradle 0.5 lbs 17.0" 3.0" 1.56"

Attaches to threaded holes on the back of either the docking station or cradle

0.5 lbs 10.0" 2.31" 0.25"

11798

Lind Automobile Power

Adapter (Toughbook 18/19)

Provides regulated power to the

Panasonic

Toughbook 19 Cradle or Docking Station

1.22 lbs 1.0" 5.0" 3.0"

7160-0073

7160-0398

Wedge and Hardware

Trunk Shelf

Mounting Plate

Wedge attaches to the bottom of docking station or cradle for use on a flat surface or trunk applications 1.70 lbs 2.0" 10.25" 8.75"

Used to raise any

Gamber-Johnson Panasonic

Toughbook 19 Cradle or Docking Station

to provide clearance for cables when mounting to a flat surface (usually trunk applications)

2.65 lbs 2.30" 10.25" 5.5"

7160-0539

Station/Cradle

and the

Docking

Motion Attachment

1.52 lbs. 5.0" 10.01" 1.27"

Shown: 7160-0215

Shown: 7160-0049

Shown: 7160-0073

Shown: 7160-0539

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

83

84

panasoniC Cr adles & doCking stations

Shown: 7160-0264-00

Shown: 7160-0264-03

Panasonic Toughbook 19 Docking Station - MK4/MK5/MK6

Item No.

Description Antenna Pass-Through Weight Height Width Depth

7160-0264-00

Docking Station only NA 4.15 lbs.

3.04" 11.10" 11.67"

7160-0264-02

Docking Station only

WAN & Wireless LAN

(TNC)

4.15 lbs.

3.04" 11.10" 11.67"

7160-0264-03

Docking Station and External Lind

Power Supply (11798)

NA 5.37 lbs.

3.04" 11.10" 11.67"

7160-0264-04

Docking Station and External Lind

Power Supply (11798)

WAN & Wireless LAN

(TNC)

5.37 lbs.

3.04" 11.10"

Features

- Gamber-Johnson’s docking station has passed the appropriate tests to qualify for the Toughbook Certified status

- Designed using MIL-STD-810F test procedures

- Universal design works with Toughbook 19 computers (MK4/MK5/MK6 versions)

- Can be positioned both vertically (Tablet) or horizontal (Notebook)

- Internal/protected circuit board protects against dirt and dust

- Brass locating pins for precise computer placement

- Front clips provide computer guidance

- Floating docking connector for reliable docking connection

- Four (4) USB ports; three (3) out the back and one (1) on the side

- Rounded edges to enhance personal safety

- Push button latching mechasnism draws the computer down for docking connection

- Key lock built-in to deter laptop theft

- Use

Lind Auto Adaptor (Item No. 11798)

for power supply

- 3 year limited warranty

- Gamber-Johnson mounting hole pattern (see pg. 3 for hole pattern definitions)

- Passed 30 mph Sled Impact Test per SAE Standard J1455

- Aluminum structure for reduced overall weight

11.67"

Port Replicator

- USB (4)

- Ethernet

- Serial (2)

- External video

- Headphones/speakers Mini-jack stereo

- Microphone

4 pin

RJ45

D-sub 9 pin

D-sub 15 pin

Mini-jack

Shown: 7160-0415

Panasonic Toughbook 53 Cradle

Item No.

Port Replicator/Internal Power Supply Weight Height Width Depth

7160-0415

NA 10.0 lbs.

2.9" 13.9" 11.9"

Features

- Secures the Toughbook 53 computer on all sides

- One-handed operation to engage and disengage computer from cradle:

- To secure computer, place in cradle and pull lever forward to latch

- To remove computer, push tubular key lock button to release back hooks from computer

- Key lock built-in to deter theft

- Gamber-Johnson mounting hole pattern (see pg. 3 for hole pattern definitions)

- Limited lifetime warranty

- Accessories: LED light (7160-0123), Screen Support (7160-0124), Shock/Vibration Isolator Plate (7160-0351), LIND

Power adapter (13786)

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

panasoniC Cr adles & doCking stations

Panasonic Toughbook 53 Docking Station

Item No.

Antenna Pass-Through Power Supply Weight Height Width Depth

7160-0393-00

NA No - must use external Lind Auto Adapter (Item No. 14650) 6.1 lbs 3.63" 13.48" 11.48"

7160-0393-02

Dual RF (TNC) No - must use external Lind Auto Adapter (Item No. 14650) 6.1 lbs 3.63" 13.48" 11.48"

7160-0393-04

NA Yes - 120W Internal Lind Power Supply 7.1 lbs 3.63" 13.48" 11.48"

7160-0393-06

Dual RF (TNC) Yes - 120W Internal Lind Power Supply 7.1 lbs 3.63" 13.48" 11.48"

Features

- Designed to MIL-STD 810G test procedures and complies with FCC Class A standards

- Dual pass-thru antenna for WAN and Wi-Fi connectivity inside your vehicle (optional)

- 120W Internal Lind Power Supply (optional)

- Small footprint - designed to maximize available space inside of vehicle

- Rear-facing l/O ports, integrated cable strain relief system, and convenient cable management system

- Front safety bracket and locator pins ensure proper alignment and docking connectivity

- Barrel Lock and key for theft deterrence –

- Push button key lock releases docking connector

- Insert computer and pull handle forward to dock computer

- Power Switch - allows for hot docking without having to power down the computer

- Rugged aluminum/steel construction with black powder coat finish for long-term durability

- Gamber-Johnson mounting hole pattern (see pg. 3 for hole pattern definitions)

- 3 year limited warranty

Port Replicator

- Ethernet (1)

- Fully -Powered

- USB 3.0 (1)

- USB 2.0 (3)

- Video (2)

- VGA

- HDMI

RJ45

USB (4)

4 pin

4 pin

D-Sub 15 pin

19 pin

- Serial D-Sub 9

- RF Pass-thru (Optional) TNC

120W Internal Power Supply (Optional)

- Operating Temperature: -20°C to 50°C (-4° F to 122° F)

- Non-operating (storage) Temperature: -40°C to 85°C (-40° F to 185° F)

- Power output to computer from dock = 120 watts (max)

- Input Voltage: 12V DC min to 32V DC max systems

- Output Voltage: 15.6V DC-16V No Load, 14.5V-15.5V Full Load

- Under voltage protection: 9.5V min to 10.5V max DC

- Over voltage protection: 33V min to 34V max DC

- Output voltage protection: 17V min to 18V max DC

- Automatic Temperature Reset

- Reverse Polarity Protection

- Auto Shutdown Circuit

- Output Current Limit

- Load Dump

- Input Fused

Shown: 7160-0393-00

Shown: 7160-0393-06

Shown: 7160-0101

Shown: 7160-0428

Panasonic Toughbook 53 Docking Station Accessories

Item No.

Description Placement Weight Height Width Depth

7160-0101

LED Light Assembly Attaches to either side of docking station 0.60 lbs. 17.0" 2.28" 2.0"

7160-0428

Screen Support Attaches to either side of docking station 0.65 lbs. 8.88" 2.31" 2.19"

7160-0539

Station/Cradle

and the

Docking

Motion Attachment

1.52 lbs. 5.0" 10.01" 1.27"

14650

Lind Automobile Power

Adapter provides regulated power to the Panasonic

Toughbook CF53

For use with the following

Panasonic Toughbook

53 Docking Stations (Item No. 7160-0393-00,

7160-0393-02, 7160-0393-04, 7160-0393-06) or

Cradle (Item No. 7160-0415)

1.1 lbs. 1.15" 5.0" 3.0"

Shown: 7160-0539

Shown: 14650

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

85

86

panasoniC Cr adles & doCking stations

Shown: 7160-0578-00

Panasonic Toughbook 54 Cradle

Item No.

Weight Height Width Depth

7160-0578-00

5.5 lbs.

3.5" 13.48" 11.85"

Features

- Gamber-Johnson has worked with Panasonic to perform the appropriate tests needed to qualify this product as

Toughbook Certified

- Designed to MIL-STD 810G test procedures

- Small footprint - designed to maximize available space inside of vehicle

- Front safety bracket and locator pins ensure proper alignment

- Cradle accommodates the Optional Expansion area of the CF-54 for Optical Disk Drive, PC Card, Smart Card Reader,

Second Battery and more

- Special access area for smart card reader makes it easy to insert and eject card

- Push button latch with keyed lock for theft deterrence:

- Push the latch to release

- Insert computer and push latch closed to secure computer

- Passed SAE standard J1455 Crash Test

- Can be mounted using any Gamber-Johnson VESA 75mm

Motion Attachment

(See pg. 3 for hole pattern definitions)

- 3 year limited warranty

Shown: 7160-0577-00

Shown: 7160-0577-02

Panasonic Toughbook 54 Docking Station

Item No.

Antenna Pass-

Through

Power Supply

7160-0577-00

NA

Weight Height Width Depth

No - must use external Lind Auto Adapter (Item No. 14103) 5.5 lbs. 3.5" 13.48" 11.85"

7160-0577-02

Dual RF (TNC) No - must use external Lind Auto Adapter (Item No. 14103) 5.5 lbs. 3.5" 13.48" 11.85"

7170-0250

NA Yes - 120W external Lind Auto Adpater included 8.5 lbs. 3.5" 13.48" 11.85"

7170-0251

Dual RF (TNC) Yes - 120W external Lind Auto Adpater included 8.5 lbs. 3.5" 13.48" 11.85"

Features

- Gamber-Johnson has worked with Panasonic to perform the appropriate tests needed to qualify this product as

Toughbook Certified

- Designed to MIL-STD 810G test procedures and complies with FCC Class A standards

- Small footprint - designed to maximize available space inside of vehicle

- Rear-facing l/O ports, integrated cable strain relief system, and convenient cable management system

- Front safety bracket and locator pins ensure proper alignment and docking connectivity

- Spring-loaded plate protects RF connector from damage when computer is not in the docking station. Plate draws back

into the docking station when the computer is docked

- Docking station accommodates the Optional Expansion area of the CF-54 for Optical Disk Drive, PC Card, Smart Card

Reader, Second Battery and more

- Special access area for smart card reader makes it easy to insert and eject card

- Push button latch with keyed lock for theft deterrence:

- Push the latch to release the docking connector

- Insert computer and push latch closed to dock computer

- Passed SAE standard J1455 Crash Test

- Can be mounted using any Gamber-Johnson VESA 75mm

Motion Attachment

(See pg. 3 for hole pattern definitions)

- 3 year limited warranty

Port Replicator

- Serial

- Ethernet

- USB 3.0 (2)

D-sub 9 pin

RJ45

9 pin

- Video (2)

- VGA

- HDMI

D-sub 15 pin

- RF Pass-through (Optional) TNC

- Power Supply Input

19 pin

DC

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

panasoniC Cr adles & doCking stations

Panasonic Toughbook 54 Cradle and Docking Station Accessories

Item No.

Description Antenna Pass-Through Weight Height Width Depth

7160-0096

7110-1023

14103

LED Light Assembly Attaches to the right side of docking station 0.5 lbs.

17.0" 3.0" 1.56"

Screen Support Attaches to the right side of docking station

External 120W Lind

Automobile Power Adapter

(Toughbook 54)

For use with any Gamber-Johnson Panasonic

Toughbook 54 Cradle or Docking Station

0.85 lbs.

1.1" 5.4" 3.1"

Shown: 7160-0096

Panasonic Toughbook 27/28/29/30/31 Cradle

Item No.

Port Replicator/Internal Power Supply Weight Height

NP-PAN-CRADLE

NA 7.1 lbs.

3.5" - 3.75"

Features

- Cradle adjusts to securely hold the Panasonic Toughbook 27/28/29/30/31 computers

- Hold-down clips don’t interfere with closing the screen

- 90° wing turn closure latch with built-in key lock that allows for quick computer insertion

- Can be used with any

Motion Attachment

(pg. 29-33)

- Limited lifetime warramty

Width

12.5"

Depth

10.0"

Shown: 7110-1023

Shown: NP-PAN-CRADLE

Panasonic Toughbook 27/28/29/30/31 Cradle Accessories

Item No.

Description Placement

7160-0095

LED Light Assembly

7110-0643

7160-0539

Screen Support

Lind Power Supply

Mount

Weight Height Width Depth

Attaches to either side of the cradle 0.5 lbs. 17.0" 2.28" 1.56"

Screen support attaches to either side of the cradle 0.4 lbs.

9.0" 5.0" 0.25"

Attaches a Lind Power supply between a

Docking

Station/Cradle

and the

Motion Attachment

1.52 lbs. 5.0" 10.01" 1.27"

Shown: 7160-0095

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Shown: 7110-0643

Shown: 7160-0539

87

88

panasoniC Cr adles & doCking stations

Panasonic Toughbook 30/31 Docking Station

Item No.

Antenna Pass-

Through

Power Supply

7160-0318-00

NA

No - must use external

120W Lind

Auto Adapter (Item No. 14103)

7160-0318-01

Single RF (TNC)

No - must use external

120W Lind

Auto Adapter (Item No. 14103)

7160-0318-02

Dual RF (TNC)

No - must use external

120W Lind

Auto Adapter (Item No. 14103)

7160-0318-04

NA

Weight Height Width Depth

5.1 lbs.

3.9" 12.4" 12.3"

5.1 lbs.

3.9" 12.4" 12.3"

5.1 lbs.

Yes* - Integrated 120W Lind Power Supply 6.0 lbs.

3.9"

3.9"

12.4" 12.3"

12.4" 12.3"

7160-0318-05

Single RF (TNC) Yes* - Integrated 120W Lind Power Supply 6.0 lbs.

3.9" 12.4" 12.3"

7160-0318-06

Dual RF (TNC) Yes* - Integrated 120W Lind Power Supply 6.0 lbs.

3.9" 12.4" 12.3"

Features

- Gamber-Johnson has worked with Panasonic to perform the appropriate tests needed to qualify a product as

Toughbook Certified

- 120W LIND integrated power supply has passed the appropriate tests to qualify for the Toughbook Certified status

- Designed using MIL-STD-810G test procedures and complies with FCC Class A standards

- 30 mph crash tested per SAEJ 1455 standard

- Design works with Toughbook 30 and 31 computers

- Smaller footprint allows for easier tilt and rotation of the docking station towards the driver as well as an

unobstructed view of the radios or other instruments

- Simple, one-handed, docking mechanism: - Pull side handle towards you to dock

- Push key lock button to release and undock computer

- Brass locating pins for precise computer placement

- Floating docking and connector for reliable docking connection

- Interlocking mechanism protects against connector damage and prevents engagements until properly mounted

- Side LED Indicator light can be used to troubleshoot in the field

- Green: All ports are ready to use

- Orange: USB and LAN ports not functioning or external power is not connected

- Red: PC is not supported or connection is not made

- Red (Blinking): Error has occurred in firmware, contact Panasonic Technical Support

- Not Lit: PC not docked or PC is Off, Standby or in Hibernation

- Gamber-Johnson mounting hole patterns (see pg. 3 for hole pattern definitions)

- Power Supply options:

- *Factory Integrated 120W Lind Power Supply - fits into dedicated pocket within the docking station for easier

installation and service

- External 120W Lind Auto Adapter (Item No. 14103), sold separately

- 3 year limited warranty

- Optional 4 and 5 year extended warranty available

- Composite/steel design creates a lightweight, yet rugged platform for long-term durability

Note:

Panasonic recommends that the CF30/31 computers should not be “hot docked” into any docking station.

Port Replicator

- Serial (2)

- Ethernet (2)

- USB Ethernet

- True Ethernet*

- USB (5)

- External video

- Headphones/speakers

D-sub 9 pin

RJ45

RJ45

4 pin

D-sub 15 pin

- Microphone

Stereo phono jack

Mono phono jack

- RF Pass-through (Optional) TNC

*

Note:

The True Ethernet will not work with a Toughbook 30 computer

120W Internal Lind Power Supply (Optional)

- Operating Temperature: -20°C to 50°C (-4° F to 122° F)

- Non-operating (storage) Temperature: -40°C to 85°C (-40° F to 185° F)

- Power Output to Computer from Dock = 120 watts (max)

- Input Voltage: 12V DC min to 32V DC max systems

- Output Voltage: 15.6V DC-16V No Load, 14.5V-15.5V Full Load

- Under Voltage Protection: 9.5V min to 10.5V max DC

- Over Voltage Protection: 33V min to 34V max DC

- Output Voltage Protection: 17V min to 18V max DC

- Automatic Temperature Reset

- Reverse Polarity Protection

- Auto Shutdown Circuit

- Output Current Limit

- Load Dump

- Input Fused

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Panasonic Toughbook 30/31 Docking Station

panasoniC Cr adles & doCking stations

Panasonic Toughbook 30/31 Docking Station Accessories

Item No.

Description Placement Weight Height Width Depth

7160-0096

LED Light Assembly Attaches to the right side of docking station 0.5 lbs. 17.0" 3.0" 1.56"

7160-0501

Screen Support

7160-0398

7160-0496

7160-0539

14103

Attaches to the right side of docking station 0.5 lbs. 9.66" 4.11" 1.8"

Trunk Shelf

Mounting Plate

Integrated 120W

Lind Power Supply

Kit

Lind Power Supply

Mount

External 120W Lind

Automobile Power

Adapter (Toughbook

30 and 31)

Used to raise the Panasonic 30/31 Docking Station to provide clearance for cables when mounting to a flat surface (usually trunk applications)

Inserts into the dedicated pocket on the underside of docking station, for use with the following

Panasonic Toughbook 30/31 Docking Stations

(Item No. 7160-0318-00, 7160-0318-01,

7160-0318-02, 7160-0318-07, 7160-0318-08,

7160-0318-09)

Attaches a Lind Power supply between a

Docking

Station/Cradle

and the

Motion Attachment

For use with the following Panasonic Toughbook

30/31 Docking Stations (Item No. 7160-0318-00,

7160-0318-01, 7160-0318-02, 7160-0318-07,

7160-0318-08, 7160-0318-09)

3.6 lbs. 2.30" 10.25" 5.5"

1.0 lbs.

1.0"

1.52 lbs.

5.0" 10.01" 1.27"

0.85 lbs. 1.1"

2.0"

5.4"

4.5"

3.1"

Shown: 7160-0096

Shown: 7160-0501

Shown: 7160-0398

Lind Automobile Power Adapters for Panasonic Toughbooks / Toughpads

Item No.

Description Placement Weight Height Width Depth

11634

11798

14103

14650

External 90W Lind

Automobile Cigarette

Power Adapter

(Toughbook CF18,

CF19 and Toughpad

FZ-G1, FZ-M1, FZ-X1 and FZ-E1)

For use with the following Panasonic Toughbook CF19

Docking Stations and Cradles (Item No.

7160-0264-00, 7160-0264-02, 7160-0264-05), TabCruzer for Panasonic Toughpad FZ-G1 Docking Stations and

Cradles (Item No. 7160-0486-00, 7160-0486-02, 7160-

0487-00, 7160-0487-02, 7160-0489-00, 7160-0490-00),

TabCruzer for Panasonic Toughpad FZ-M1 Docking

Stations and Cradles (Item No. 7160-0531-00, 7160-

0531-02, 7160-0531-03, 7160-0531-04, 7160-0543-00) and Panasonic Toughpad FZ-X1 & FZ-E1 Powered

Cradle (Item No. 7160-0564)

1.22 lbs.

1.15" 5.0" 3.0"

External 90W Lind

Automobile Bare Wire

Leads Power Adapter

(Toughbook CF18,

CF19 and Toughpad

FZ-G1, FZ-M1, FZ-X1 and FZ-E1)

For use with the following Panasonic Toughbook CF19

Docking Stations and Cradles (Item No. 7160-0264-00,

7160-0264-02, 7160-0264-05), TabCruzer for Panasonic

Toughpad FZ-G1 Docking Stations and Cradles (Item No.

7160-0486-00, 7160-0486-02, 7160-0487-00,

7160-0487-02, 7160-0489-00, 7160-0490-00),

TabCruzer for Panasonic Toughpad FZ-M1 Docking

Stations and Cradles (Item No. 7160-0531-00,

7160-0531-02, 7160-0531-03, 7160-0531-04,

7160-0543-00) and Panasonic Toughpad FZ-X1 & FZ-E1

Powered Cradle (Item No. 7160-0564)

1.0 lb. 1.15" 5.0" 3.0"

External 120W Lind

Automobile Power

Adapter (Toughbook

CF30, CF31 and

CF54)

For use with the following Panasonic Toughbook CF30/31

Docking Stations and Cradles (Item No. 7160-0318-00,

7160-0318-01, 7160-0318-02, 7160-0318-07, 7160-0318-

08, 7160-0318-09, NP-PAN-CRADLE) and Panasonic

Toughbook CF54 Docking Stations and Cradles

(Item No. 7160-0577-00, 7160-0577-02, 7160-0578

0.85 lbs.

External Lind

Automobile Cigarette

Power Adapter

(Toughbook CF53)

For use with the following Panasonic Toughbook CF53

Docking Stations and Cradles (Item No. 7160-0393-00,

7160-0393-02, 7160-0415)

1.1"

1.0 lb. 1.1"

5.4"

5.4"

3.1"

3.1"

Shown: 7160-0539

Shown: 11634

Shown: 11798

Shown: 14103

Shown: 14650

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

89

motorol a mW810 moUnting solUtions

Motorola MW800/MW810 Tilt & Swivel Folding Display & Keyboard Holder

Item No.

Tilt Swivel Weight Height Width Depth

7110-0913

Display can easily be tilted forward up to 90° or back toward the dash 45°

Both display and keyboard can be swiveled together up to 60° right/60° left 9.0 lbs. 13.9” 14.9” 10.1”

Features

- Can be mounted to any flat horizontal surface or most Gamber-Johnson

Motion Attachments

- The display can easily be tilted forward up to 90° or back toward the dash 45°

- Keyboard can be quickly removed and inserted

Shown: 7110-0913

90

dell Cr adles & doCking stations

Shown: 7160-0201

Shown: 7160-0203

Dell E-Series Docking Cradle

(for use with Dell E-Port or E-Port Plus Port Replicator)

Item No.

Description Weight Height Width Depth

7160-0201

Cradle wraps around the Dell E-Port or E-Port Plus Port Replicator to form a

Docking Cradle for the Dell E6400/E6410/E6420/E6430 Series

6.5 lbs 3.9" 14.1" 13.8"

7160-0202

Cradle wraps around the Dell E-Port or E-Port Plus Port Replicator to form a

Docking Cradle for the Dell E6500/E6510/E6520/E6530 Series

6.5 lbs 3.9" 14.7" 14.4"

Features

- The

Dell E-Series Docking Cradle

must attach to the E-Port or E-Port Plus Port Replicator (sold separately). The

E-Port or E-Port Plus Port Replicator can be purchased through Dell or any authorized Dell reseller

- Push button barrel lock, deters laptop theft and allows for easy computer placement and removal

- Rugged side, front and rear hold-down brackets secure computer and port replicator in cradle keeping

equipment and mobile workers safe

- Side brackets are easily adjustable to fit the height of the computer and won’t block critical ports or the CD/DVD bay

- Rear port replicator brackets can be adjusted to accommodate the E-Port or E-Port Plus Port Replicator and

allow access to all ports on the port replicator

- Vibration tested to MIL-STD-810G and shock tested to 40G, 11 millisecond (non-operational)

- The optional Shock/Vibration Isolator Plate (Item No. 7160-0351) is highly recommended for non-rugged laptop

computers

- 3 year limited warranty

- Gamber-Johnson mounting hole patterns (see pg. 3 for hole pattern definitions)

- Aluminum structure for reduced overall weight

Note:

- Docking cradle is not compatible with the Dell E6400 XFR fully ruggedized computer.

- The Dell port replicator used in the Dell E-Series Docking Cradle is not warranted by Gamber-Johnson, please refer to the warranty

provided by Dell for the port replicator

Shown: 7160-0095

Shown: 7160-0351

Dell E6400/E6400 ATG/E6500 Docking Cradle Accessories

Item No.

Description Placement Weight Height Width Depth

7160-0203

7160-0095

7160-0351

7120-0568

Screen Support

LED Light Assembly

Shock/Vibration Isolator Plate

Note:

Computer and Cradle combined should not exceed 30 lbs.

Attaches to either side of any

Dell E-Series Docking Cradle

(Item No. 7160-0201 or 7160-0202)

Attaches to either side of any

Dell E-Series Docking Cradle

(Item No. 7160-0201 or 7160-0202)

0.7 lbs 8.0"

0.5 lbs. 17.0"

2.0"

2.28"

2.0" to

2.4"

1.56"

Positioned between any

Motion Attachment

and any

NotePad™ V Universal Computer Mount

2.43 lbs 0.85" 7.0" 6.5"

Dell E6420 Clip package

Note:

buy this only if you already have a Dell

E-Series Docking Cradle (Item No. 7160-0201)

Replaces clips on the

Dell E-Series

Docking Cradle (Item No. 7160-0201)

0.3 lbs.

NA NA NA

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

getaC doCking stations

getaC F110 doCKiNg statioN

Page 92

Features/Benefits

- Push and Turn latching system with key lock

- Two mounting hole pattern options: Gamber-Johnson 2x4 or VESA 75mm

- Available in No-RF and Triple RF

Page 95

getaC b300 doCKiNg statioN

Features/Benefits

- Power switch on front of dock for power by-pass

capability

- Internal power supply standard with all docking

stations

- Available in No-RF and Dual RF

Page 96

getaC s400 doCKiNg statioN

Features/Benefits

- Front facing ports with integrated cable strain

relief system

- Screen support included with the docking station

- Available in No-RF and Dual RF

Page 97

getaC V110 doCKiNg statioN

Features/Benefits

- Docking Station can be mounted either in vertical

(tablet) or in horizontal (laptop) orientation

- Screen support included with the docking station

- Available in No-RF and Triple RF

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

91

getaC doCking stations

Shown: 7160-0576-00

Getac F110 Cradle

Item No.

Antenna

Pass-Through

7160-0576-00

NA

Power Supply Weight Height Width Depth

No - must use external Lind Auto Adapter (Item No. 15110) 2.3 lbs. 10.06" 8.81" 3.09"

7160-0576-03

Triple RF (SMA) No - must use external Lind Auto Adapter (Item No. 15110) 2.3 lbs. 10.06" 8.81" 3.09"

7170-0248

NA Yes - includes external Lind Power Supply 2.3 lbs. 10.06" 8.81" 3.09"

7170-0248

Triple RF (SMA) Yes - includes external Lind Power Supply 2.3 lbs. 10.06" 8.81" 3.09"

Features

- Compatible with Getac F110 11.6-inch rugged tablet

- Cradle design accommodates mag stripe reader and hand strap (sold separately)

- Can be mounted using the VESA 75mm or Gamber-Johnson mounting hole patterns (see pg. 3 for hole pattern definitions)

- Front bracket helps align computer for proper cradling

- Push and Turn lock with key for theft deterrence

- Insert computer then push down and turn lock to close and secure tablet

- Composite/aluminum design for reduced weight and durability

- Passed SAE Standard J1455 Crash Test

- 3 year limited warranty

92

Shown: 7160-0542-00

Getac F110 Docking Station

Item No.

Antenna

Pass-Through

7160-0542-00

NA

Power Supply Weight Height Width Depth

No - must use external Lind Auto Adapter (Item No. 15110) 2.6 lbs. 11.44" 8.81" 3.69"

7160-0542-03

Triple RF (SMA) No - must use external Lind Auto Adapter (Item No. 15110) 2.6 lbs. 11.44" 8.81" 3.69"

7170-0240

NA Yes - includes external Lind Power Supply 2.6 lbs. 11.44" 8.81" 3.69"

7170-0241

Triple RF (SMA) Yes - includes external Lind Power Supply 2.6 lbs. 11.44" 8.81" 3.69"

Features

- Compatible with Getac F110 11.6-inch tablet computer

- Downward-facing l/O ports, integrated cable strain relief system

- Docking Station design accommodates mag strip reader and hand strap (sold separately)

- Can be mounted using the VESA 75mm or Gamber-Johnson mounting hole patterns (see pg. 3 for hole pattern definitions)

- POGO pin style docking connector for easy docking activation

- Front bracket helps align computer for proper docking connectivity

- Push and Turn lock with key for theft deterrence

- Insert computer then push down and turn lock to close and dock computer

- Composite/aluminum design for reduced weight and durability

- Passed SAE Standard J1455 Crash Test

- 3 year limited warranty

Port Replicator

- Ethernet (1)

- USB (4)

- 2.0 (3)

- 3.0 (1)

- Serial (2)

- Video (2)

- VGA

- HDMI

- Headphones/Speakers

- Microphone

- RF Pass through (Optional)

- Power In

RJ45

4 pin

9 pin

D-sub 9 pin

D-sub 15 pin

19 pin

Stereo phono jack

Mono phono jack

SMA

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

getaC doCking stations

Getac F110 Cradle and Docking Station Accessories

Item No.

7160-0539

15110

Description Placement Weight Height Width Depth

Lind Power Supply Mount

External Lind Automobile Cigarette

Power Adapter (Getac F110)

Attaches a Lind Power supply between a

Docking Station/Cradle

and the

Motion Attachment

For use with the following

Getac F110

Docking Stations and Cradle

1.52 lbs. 5.0" 10.01" 1.27"

1.0 lb.

1.2" 2.5" 5.15"

Shown: 7160-0539

Shown: 15110

Getac RX10 Docking Station

Item No.

Antenna

Pass-Through

7160-0760-00

NA

Power Supply Weight Height Width Depth

No - must use external Lind Auto Adapter (Item No. 15110) 2.26 lbs. 10.25" 11.25" 2.5"

7160-0760-03

Triple RF (SMA) No - must use external Lind Auto Adapter (Item No. 15110) 3.8 lbs. 1.38" 11.6" 10.75"

7170-0792-00

NA Yes - includes external Lind Power Supply 4.8 lbs. 1.38" 11.6" 10.75"

7170-0792-03

Triple RF (SMA) Yes - includes external Lind Power Supply 4.8 lbs. 1.38" 11.6" 10.75"

Features

- Designed using MIL-STD-810G test procedures and complies with FCC Class A standards

- Designed for the Getac RX10 tablet computer

- Alignment tabs prevent damage to the docking connector when docking the computer

- POGO pin style docking connector for easy docking activation

- Docking station design accomodates barcode scanner, accessory cover, kickstand and extended battery

- Access to all computer function buttons, stylus and ports while tablet is docked

- Simple, one handed operation:

- Insert computer into docking station, push top of computer against latch button until latch engages

- To remove, push down on latch-button with palm of hand to disengage and pull computer out of docking station

- SAE Standard J1455 Crash Test

- Steel and Composite design for reduced overall weight

- Slim form factor accomodates applications where there is limited space

- Gamber-Johnson mounting hole pattern (see pg. 3 for hole pattern definitions)

- 3 year limited warranty

Port Replicator

- Ethernet (1)

- USB (2)

- Serial

RJ45

- Triple RF Pass through (Optional) SMA

- Power In

D-sub 9 pin

DC Shown: 7160-0760-00

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

93

94

Universal CompUter Cr adles

Shown: 7160-0583-00

Getac T800 Cradle

Item No.

Antenna

Pass-Through

7160-0583-00

NA

Power Supply Weight Height Width Depth

No - must use external Lind Auto Adapter (Item No. 15110) 2.4 lbs. 9.5" 8.4" 3.5"

7160-0583-03

Triple RF (SMA) No - must use external Lind Auto Adapter (Item No. 15110) 2.4 lbs. 9.5" 8.4" 3.5"

7170-0246

NA Yes - includes external Lind Power Supply 3.4 lbs. 9.5" 8.4" 3.5"

7170-0247

Triple RF (SMA) Yes - includes external Lind Power Supply 3.4 lbs. 9.5" 8.4" 3.5"

Features

- Designed for the Getac T800 8.1-inch rugged tablet

- Access to all computer function buttons and ports while tablet is docked

- Can be mounted using the VESA 75mm or Gamber-Johnson mounting hole patterns (see pg. 3 for hole pattern definitions)

- Alignment pins guide the tablet for easy cradling

- Cradle design accommodates SnapBack SmartCard & RFID reader and X-Hand Strap (sold separately)

- Push and Turn lock with key for theft deterrence

- Insert tablet then push down and turn lock to close and secure tablet

- Composite/aluminum design for reduced weight and durability

- Passed SAE Standard J1455 Crash Test

- 3 year limited warranty

Shown: 7160-0565-00

Getac T800 Docking Station

Item No.

Antenna

Pass-Through

7160-0565-00

NA

Power Supply Weight Height Width Depth

No - must use external Lind Auto Adapter (Item No. 15110) 2.4 lbs. 9.5" 8.4" 3.5"

7160-0565-03

Triple RF (SMA) No - must use external Lind Auto Adapter (Item No. 15110) 2.4 lbs. 9.5" 8.4" 3.5"

7170-0244

NA Yes - includes external Lind Power Supply 3.4 lbs. 9.5" 8.4" 3.5"

7170-0245

Triple RF (SMA) Yes - includes external Lind Power Supply 3.4 lbs. 9.5" 8.4" 3.5"

Features

- Designed for the Getac T800 8.1-inch rugged tablet

- Access to all computer function buttons and ports while tablet is docked

- Can be mounted using the VESA 75mm or Gamber-Johnson mounting hole patterns (see pg. 3 for hole pattern definitions)

- POGO pin style docking connector for easy docking activation

- Alignment pins guide the computer for easy docking and connectivity

- Downward-facing I/O ports; cable strain relief system for easy cable management

- Docking Station design accommodates SnapBack SmartCard & RFID reader and X-Hand Strap (sold separately)

- Push and Turn lock with key for theft deterrence

- Insert computer then push down and turn lock to close and dock computer

- Composite/aluminum design for reduced weight and durability

- Passed SAE Standard J1455 Crash Test

- 3 year limited warranty

Port Replicator

- Ethernet (1)

- Fully Powered USB 3.0 (2)

- Serial (2)

- RF Pass through (Optional)

- Power In

RJ45

9 pin

D-sub 9 pin

SMA

Shown: 7160-0539

Shown: 15110

Getac T800 Cradle and Docking Station Accessories

Item No.

7160-0539

15110

Description Placement Weight Height Width Depth

Lind Power Supply Mount

External Lind Automobile Cigarette

Power Adapter (Getac T800)

Attaches a Lind Power supply between a

Docking Station/Cradle

and the

Motion Attachment

1.52 lbs. 5.0" 10.01" 1.27"

For use with the following

Getac T800

Docking Stations and Cradle

1.0 lb.

1.2" 2.5" 5.15"

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Universal CompUter Cr adles

Getac B300 Docking Cradle

Item No.

Power Supply Weight Height Width Depth

7160-0570-00

No - must use external Lind Auto Adapter (Item No. 15110) 4.7 lbs.

3.9"

Features

- Design works with B300 Computer

- Simple, one-handed, docking mechanism:

- Pull side handle forward to dock

- Unlock the key button to release and undock computer

- Brass locating pins for precise computer placement

- Interlocking mechanism protects against damage & prevents engagement until properly mounted

- Gamber-Johnson mounting hole pattern

- Composite/steel design creates a lightweight, yet rugged platform for long-term durability

- Passed SAE Standard J1455 Crash Test

- 3 year limited warranty

12.4" 12.3"

Shown: 7160-0570-00

Getac B300 Docking Station

Item No.

7160-0526-00

Antenna

Pass-Through

NA

Power Supply Weight Height Width Depth

Yes - internal power supply

5.2 lbs. 4.9" 12.4" 12.3"

7160-0526-02

Dual RF (TNC)

Yes - internal power supply

5.2 lbs. 4.9" 12.4"

Features

- Designed using MIL-STD-810G test procedures and complies with FCC Class A standards

- Design works with B300 Computer

- Simple, one-handed, docking mechanism:

- Pull side handle forward to dock

- Unlock the key button to release and undock computer

- Brass locating pins for precise computer placement

- Floating docking connector for reliable docking connection

- Interlocking mechanism protects against connector damage & prevents engagement until properly mounted

- Forward facing ports for low mounting capability, minimal cable strain and minimal swivel resistance

- Power switch with LED light and optional by-pass capability:

- Green LED indicates power to the docking station

- Gamber-Johnson mounting hole pattern (see pg. 3 for hole pattern definitions)

- Composite/steel design creates a lightweight, yet rugged platform for long-term durability

- Passed SAE Standard J1455 Crash Test

- 3 year limited warranty

Port Replicator

- Ethernet (1) RJ45

- Fully Powered USB 3.0 (2) 9 pin

- Serial (2) D-sub 9 pin

- RF Pass through (Optional) TNC

- External Video D-sub 15 pin

- Headphones/speakers Stereo phono jack

- Microphone Mono phono jack

- Alternate DC Power Input

12.3"

Shown: 7160-0526-00

Getac B300 Docking Station/Cradle Accessories

Item No.

Description

7160-0096

LED Light Assembly

7160-0501

Screen Support

7160-0398

Trunk Shelf

Mounting Plate

Placement

Attaches to the right side of the docking station

Attaches to the right side of the docking station

Weight Height Width Depth

0.5 lbs 17.0” 3.0" 1.56”

0.5 lbs 9.66” 4.11” 1.8”

Used to raise the

Getac B300 Docking Station

to provide clearance for cables when mounting to a flat surface (usually trunk applications) 3.6 lbs. 2.30" 10.25" 5.5"

Shown: 7160-0096

Shown: 7160-0060

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

95

getaC doCking stations

Shown: 7160-0573-00

Getac S400 Cradle

Item No.

Power Supply Weight Height Width Depth

7160-0573-00

No - must use external Lind Auto Adapter (Item No. 15110) 7.75 lbs.

4.2"

Features

- Compatible with Getac S400 computer

- Rugged aluminum/steel construction with black powder coat finish for long-term durability

- Front safety bracket helps align computer for proper placement

- Push button latch with keyed lock for theft deterrence. Lock keyed alike.

- Push the latch to release

- Insert computer and push latch closed to secure the computer

- Screen support is included with the cradle

- Passed SAE Standard J1455 Crash Test

- Gamber-Johnson mounting hole pattern (see pg. 3 for hole pattern definitions)

- 3 year lifetime warranty

12.3" 12.2"

96

Shown: 7160-0505-00

Getac S400 Docking Station

Item No.

Antenna

Pass-Through

7160-0505-00

NA

Power Supply Weight Height Width Depth

No - must use external Lind Auto Adapter (Item No. 15110) 7.75 lbs.

4.2" 12.3" 12.2"

7160-0505-02

Dual RF (SMA) Yes - includes external Lind Power Supply 7.75 lbs.

4.2" 12.3" 12.2"

Features

- Designed using MIL-STD-810G test procedures and complies with FCC Class A standards

- Designed for the Getac S400 computer

- Front safety bracket helps align computer for proper docking connectivity

- Floating docking connector for reliable docking connection

- Front-facing I/O ports, integrated cable strain relief system

- Push button latch with keyed lock for theft deterrence:

- Push the latch to release the docking connector

- Insert computer and push latch closed to dock computer

- Screen support is included with the docking station

- Passed SAE Standard J1455 Crash Test

- Rugged aluminum/steel construction

- Gamber-Johnson mounting hole pattern (see pg. 3 for hole pattern definitions)

- 3 year limited warranty

Port Replicator

- Serial (2)

- USB (3)

- eSATA

- Ethernet

- Parallel

- VGA

- DVI

- Display Port

- Keyboard (PS2)

- Mouse (PS2)

- Headphones/speakers

- Microphone

- RF Pass-through (Optional)

Shown: 7160-0096

Shown: 7160-0539

Shown: 15110

Getac S400 Docking Station/Cradle Accessories

Item No.

Description Placement Weight Height Width Depth

7160-0096

7160-0539

15110

LED Light Assembly

Lind Power Supply Mount

External Lind Automobile Cigarette

Power Adapter (Getac S400)

Attaches to right side of the

Getac S400

Docking Station/Cradle

Attaches a Lind Power supply between a

Docking

Station/Cradle

and the

Motion Attachment

0.5 lbs. 17.0" 3.0" 1.56"

1.52 lbs. 5.0" 10.01" 1.27"

For use with Getac S400 Docking Station/Cradle 1.01 lbs. 1.2" 2.5" 5.15"

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

getaC doCking stations

Getac V110 Cradle

Item No.

Antenna

Pass-Through

7160-0568-00

NA

Power Supply Weight Height Width Depth

No - must use external

Lind Auto Adapter (Item No. 15110) 3.8 lbs. 1.38" 11.6" 10.75"

7160-0568-03

Triple RF (SMA) No - must use external Lind Auto Adapter (Item No. 15110) 3.8 lbs. 1.38" 11.6" 10.75"

4.8 lbs. 1.38" 11.6" 10.75"

7160-0568-04

NA Yes - includes external Lind Power Supply

7160-0568-05

Triple RF (SMA) Yes - includes external Lind Power Supply

Features

- Compatible with Getac V110 convertible computer

- Cradle can be used in tablet or laptop position

- Rugged aluminum construction with black powder coat finish for long-term durability

- Front safety bracket helps align computer

- Built-in stylus holder

- Push button latch with keyed lock for theft deterrence:

- Push the latch

- Insert computer and push latch closed to secure computer

- Screen support is included with the cradle

- Passed SAE Standard J1455 Crash Test

- 3 year limited warranty

4.8 lbs. 1.38" 11.6" 10.75"

Shown: 7160-0568-00

Getac V110 Docking Station

Item No.

Antenna

Pass-Through

7160-0515-00

NA

Power Supply Weight Height Width Depth

No - must use external Lind Auto Adapter (Item No. 15110) 3.8 lbs. 1.38" 11.6" 10.75"

7160-0515-03

Triple RF (SMA) No - must use external Lind Auto Adapter (Item No. 15110) 3.8 lbs. 1.38" 11.6" 10.75"

7170-0242

NA

Yes - includes external Lind Power Supply

4.8 lbs. 1.38" 11.6" 10.75"

7170-0243

Triple RF (SMA) Yes - includes external Lind Power Supply 4.8 lbs. 1.38" 11.6" 10.75"

Features

- Designed using MIL-STD-810G test procedures and complies with FCC Class A standards

- Designed for the Getac V110 convertible computer

- Front safety bracket helps align computer for proper docking connectivity

- POGO pin style docking connector for easy docking activation

- Front-facing I/O ports, integrated cable strain relief system

- Built-in stylus holder

- Push button latch with keyed lock for theft deterrence:

- Push the latch to release the docking connector

- Insert computer and push latch closed to dock computer

- Screen support is included with the docking station

- SAE Standard J1455 Crash Test

- Rugged aluminum construction

- Gamber-Johnson mounting hole pattern (see pg. 3 for hole pattern definitions)

- 3 year limited warranty

Port Replicator

- Ethernet (1)

- USB (4)

- 2.0 (3)

- 3.0 (1)

- Serial (2)

- Video (2)

- VGA

RJ45

4 pin

9 pin

D-sub 9 pin

- HDMI

D-sub 15 pin

19 pin

- Headphones/Speakers Stereo phono jack

- Microphone Mono phono jack

- RF Pass through (Optional) SMA

- Power In

Getac V110 Docking Station/Cradle Accessories

Item No.

Description Placement Weight Height Width Depth

7160-0539

15110

Lind Power Supply Mount

Attaches a Lind Power supply between a

Docking

Station/Cradle

and the

Motion Attachment

1.52 lbs. 5.0" 10.01" 1.27"

External Lind Automobile Cigarette

Power Adapter (Getac V110)

For use with the following

Getac V110 Docking

Stations (Item No. 7160-0515-00 and 7160-0515-03)

1.0 lbs. 1.2"

2.5" 5.15"

Shown: 7160-0515-00

Shown: 7160-0539

Shown: 15110

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

97

Power Distribution anD wiring harness

Shown: 13791

Lind Shutdown Timers

Item No.

Description Shut Down Delay AMP Load Weight Height Width Depth

13791

Lind Ruggedized Shut

Down Timer

Factory set at 2 hour

Up to

20 AMPS

0.30 lbs.

1.6" 3.0" 2.06"

13792

Lind Low Profile Shut

Down Timer

Adjustable - 5 seconds to

4 hours

Up to

30 AMPS

0.30 lbs.

1.2" 3.8" 4.3"

Features

- Shut Down Timer (SDT) protects the automobile battery from over discharge by shutting OFF at a preset time after

engine is shut down or battery discharged to a low voltage level

- SDT protects radio or computer equipment from damage due to low or high input voltage

- Low voltage shut down at 10.5 V DC

- High voltage shut down at 18 V DC with auto reset

- Automatic activation by sensing the battery voltage (battery not charging = timer ON)

- Optional activation by ignition switch connection (ignition OFF = timer ON)

- LED indicators

Shown: 13792

Shown: 16372

Kerr Power Distribution and Shutdown Timers

Item No.

Placement Weight Height

16372

Kerr Bit-13 Power Distribution and Shutdown Timer 1.05 lbs.

1.78"

Features

- Compact design

- Simplified aftermarket circuits

- 5 Battery Direct Circuits

- 5 Ignition Switched Circuits

- Panel Rated at 100 Amps overall

- 3 Timed Circuits each with its own timer

- 4 Different Time Settings per Timer for Automatic Shut-off (30 mins, 1 hr., 2hrs., 4 hrs.)

- Each circuit can carry a maximum load of 30 Amps

- 3 Year Warranty (by KERR)

Width

3.95"

Depth

7.72"

98

Shown: 7300-0039

Shown: 7300-0040

MOBILE MOUNTS Vehicle Power Distribution Units (VPDU)

Item No.

Description

Continuous

Power Circuits USB Ports Weight

7300-0039

Standard VPDU (MM-VPDU-1011) 1

Height Width Depth

No

1.03 lbs.

1.5" 4.25" 6.5"

7300-0040

VPDU with Dual USB Output (MM-VPDU-1014) 1 Yes - 2 1.05 lbs. 2.25" 4.25" 6.5"

7300-0041

Accessory Power Distribution Unit (MM-APDU) 7

No

2.06 lbs. 1.75" 7.25" 11.25"

Features

- Dip switch settable time delay from 15 seconds - 8 hours (constant ‘on’ is also available)

- Low voltage cutoff at 10.5 Volts

- High voltage cutoff at 18.0 Volts

- Loads up to 50 AMPS total

- LED display indicates the time delay and status

- Automatic activation by seeking battery voltage

- Optional activation by wiring to ignition sense point

- Four (4) circuits controlled by timer

- Over-ride switch for 15 minutes of on-demand operation

- LED lights show operative state of fuse positions

- Reverse polarity protected

- 3 year limited warranty by MOBLIE MOUNTS

Shown: 7300-0041

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Power Distribution anD wiring harness

MNSTAR Power Distribution Harnesses - Power Prep Series

Power Prep Harnesses provide Battery Hot, Ignition, Ground and in some configurations Timed fused outputs.

These products feature battery direct power and grounds to provide main power distribution for aftermarket equipment installations. Power Prep Harnesses can be broken down into three basic groups:

- Full Vehicle Power: The output wires are either long enough to reach throughout the vehicle or are braided to pre-determined

breakout locations throughout the vehicle

- Power To the Console: A main power feed and fuse panel at the battery with outputs circuits that reach to the center console

- Power In the Console: A main power feed from the battery to a console mounted fuse panel

MNSTAR Power Prep - Full Vehicle Power Distribution

Item No.

Description Continuous Power Circuits Weight

7300-0001

Installer Harness, Power Prep, 12 Fused

Outputs - Requires Battery Cable

(EDH120)

Provides Power Distribution to the Console and the

Trunk (Requires Battery Cable)

7300-0002

7300-0003

7300-0004

Installer Harness, Power Prep, 12 Fused

Outputs - Front Battery (EDH120-F)

Installer Harness, Power Prep, 12

Fused Outputs- Mid Ship Battery Cable

(EDH120-M)

Installer Harness, Power Prep, 12

Fused Outputs- Rear Battery Cable

(EDH120-R)

Provides Power Distribution to the Console and the Trunk (includes Front Battery Cable braided in harness)

Provides Power Distribution to the Console and the

Trunk (includes Mid Ship Battery Cable braided in harness)

Provides Power Distribution to the Console and the Trunk (Includes Rear Battery Cable braided in harness)

Features

- Trunk Mounted Fuse Panel provides Ignition and Battery Hot Circuits to the console and trunk

- Flexible Spare Circuits for integration of factory lighting options and pre-wire packages

- Available in Front, Mid-Ship, Rear or Dual Battery configurations

- Color-Coded and Labeled Wiring

- Detailed Color Schematics

- Direct to Battery Grounds

- Fabricated Wire Harness of High Quality TXL Copper Exceeds SAE Standard J-1128

- Heat Rated: Tested for Maximum Loads at -40°F to 221°F

- Fire Retardant Protective Loom

- Warranty terms/policy by MNSTAR:

- No warranty for Fuses and Solenoids

- 1 year limited warranty for Relays, Timers, Electronic Control Modules and Circuit Boards

- 3 year limited warranty for Wire Harnesses, Fuse Panels and Power Distribution Centers

9.0 lbs.

11.0 lbs.

10.07 lbs.

10.0 lbs.

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

99

Power Distribution anD wiring harness

Shown: 7300-0043

MNSTAR Truck Harness Power Prep - Full Vehicle Power Distribution

Item No.

Description Placement Circuits to Console Weight

7300-0042

Integrator Truck

Harness, 11 Circuits to

Console with Ignition

Relay - Requires

Relay or Timer (sold separrately) (TH45-0)

Underhood Fuse Panel, 125A Master

Fuse, Master Cutoff switch Power

Distribution Center and Wires that extend to the console and 107" further toward rear of vehicle

3 - Hot lines (30A, 20A, 20A)

8 - Ignition lines (10A each) 6.09 lbs.

7300-0043

Integrator Truck

Harness, 11 Circuits to

Console with DR40-VM

Voltage Sensing Timer

(TH45-VM)

Underhood Fuse Panel, 125A Master

Fuse, Master Cutoff switch Power

Distribution Center and Wires that extend to the console and 107" further toward rear of vehicle

3 - Hot lines (30A, 20A, 20A)

4 - Ignition lines (10A each)

4 - Timed Lines (10A each)

Features

- Power Prep Series is designed to work with Commercial Trucks, Police Vehicles and SUV’s

- Direct plug in of DR series timers eliminate the need for additional timers to be installed

- Flexible lines capable of reaching console and back of a crew cab or a trunk tray

- Color-Coded and Labeled Wiring

- Detailed Color Schematics

- Direct to Battery Grounds

- Fabricated Wire Harness of High Quality TXL Copper Exceeds SAE Standard J-1128

- Heat Rated: Tested for Maximum Loads at -40°F to 221°F

- Fire Retardant Protective Loom

- Circuits for Timed, Hot and Ignition power

- Warranty terms/policy by MNSTAR:

- No warranty for Fuses and Solenoids

- 1 year limited warranty for Relays, Timers, Electronic Control Modules and Circuit Boards

- 3 year limited warranty for Wire Harnesses, Fuse Panels and Power Distribution Centers

6.09 lbs.

100

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Power Distribution anD wiring harness

MNSTAR Integrator Utility Harness Power Prep - Power Distribution

To The Center Console

Item No.

Description Placement Circuits to Console Weight

7300-0005

Integrator Utility Harness, 4 Circuits to Console (EDH40-0), requires

Relay or Timer (sold separately)

7300-0007

Integrator Utility Harness, 4 Circuits to Console with DR40-VM Voltage

Sensing Programmable Timer

(EDH40-VM)

Underhood Fuse Panel, Power

Distribution Center with wires extending to the console

Underhood Fuse Panel, Power

Distribution Center with wires extending to the console

1 - Hot line (30A)

3 - Ignition lines (15A each) 3.0 lbs.

1 - Hot line (30A)

1 - Ignition lines (15A)

2 - Timed Lines (15A each)

3.0 lbs.

7300-0008

Integrator Utility Harness, 4 Circuits to

Console, with Lind Power Connector,

Requires Relay or Timer (sold separately) (EDH40-L)

Underhood Fuse Panel, Power

Distribution Center with wires extending to the console

1 - Hot line (30A)

2 - Ignition lines (15A)

1 - Line with Lind Barrel

Connector (15 A)

3.0 lbs.

7300-0010

7300-0011

7300-0013

Integrator Utility Harness, 4 Circuits to Console, with Lind Power

Connector, DR40-VM Voltage

Sensing Timer (EDH40-LVM)

Integrator Utility Harness, 11

Circuits to Console with Ignition

Relay (EDH45)

Underhood Fuse Panel, Power

Distribution Center with wires extending to the console

1 - Hot line (30A)

1 - Ignition lines (15A)

1 - Timed Lines (15A)

1 - Line with Lind Barrel

Connector (15 A)

3.0 lbs.

Underhood Fuse Panel, 125A

Master Fuse, Master Cutoff switch

Power Distribution Center, wires extend to the console

3 - Hot lines (30A, 20A, 20A)

8 - Ignition lines (10A each) 6.0 lbs.

Integrator Utility Harness, 11

Circuits to Console with DR40-VM

Voltage Sensing Timer (EDH45-VM)

Underhood Fuse Panel, 125A

Master Fuse, Master Cutoff switch Power Distribution Center, wires extend to the console

3 - Hot lines (30A, 20A, 20A)

4 - Ignition lines (10A each)

4 - Timed Lines (10A each)

6.0 lbs.

Features

- Power Prep Harness designed for Commercial Trucks, Pickups and Code Enforcement vehicles

- Battery, Ignition and Timed Circuits to support the aftermarket equipment installed in a vehicle

- Fuse panel mounts near the battery and extends the power circuits to the center console

- Provides a parallel electrical system that is isolated from the vehicle electronics and improving serviceability of both

the vehicle and aftermarket equipment

- Direct plug in of DR series timers eliminating need for additional timers to be installed

- Color-Coded and Labeled Wiring

- Detailed Color Schematics

- Direct to Battery Grounds

- Fabricated Wire Harness of High Quality TXL Copper Exceeds SAE Standard J-1128

- Heat Rated: Tested for Maximum Loads at -40°F to 221°F

- Fire Retardant Protective Loom

- Warranty terms/policy by MNSTAR:

- No warranty for Fuses and Solenoids

- 1 year limited warranty for Relays, Timers, Electronic Control Modules and Circuit Boards

- 3 year limited warranty for Wire Harnesses, Fuse Panels and Power Distribution Centers

Shown: 7300-0007

Shown: 7300-0013

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

101

102

Power Distribution anD wiring harness

Shown: 7300-0046

Shown: 7300-0048

MNSTAR Power Prep Console Harness - Power Distribution In The Center Console

Item No.

Description Placement Outputs Weight

7300-0044

7300-0045

7300-0046

7300-0047

7300-0048

7300-0049

7300-0050

7300-0051

7300-0052

Power Prep Console Harness, 4

Outputs, Mounts to 2" Console

Face Plate - Requires Relay or

Timer (sold separrately) (CH40-0)

Power Prep Console Harness,

4 Outputs, with DR40-VM Timer,

Lind Power Connector, Mounts to 2" Console Face Plate

(CH40-LVM)

Power Prep Console Harness,

4 Outputs, with DR40-VM Timer,

Mounts to 2" Console Face Plate

(CH40-VM)

Console Mounted Fuse Panel,

Power Distribution Center with wires extending to the console

Console Mounted Fuse Panel,

Power Distribution Center with wires extending to the console

Console Mounted Fuse Panel,

Power Distribution Center with wires extending to the console

Power Prep Console Harness,

11 Outputs, Mounts to 2" Console

Face Plate - Requires Relay or

Timer (sold separrately) (CH45-0)

Console Mounted Fuse Panel,

125A Master Fuse, Master Cutoff switch Power Distribution Center, wires extend to the console

Power Prep Console Harness,

11 Outputs, with DR40-VM Timer,

Mounts to 2" Console Face Plate

(CH45-VM)

Console Mounted Fuse Panel,

125A Master Fuse, Master Cutoff switch Power Distribution Center, wires extend to the console

Utility Harness, Battery Cable,

Console Mount Fuse Panel:

6 Relayed Circuits, 3 Ignition

Circuits, 3 Battery Hot - Requires

Relay or Timer (sold separrately)

(UH633-0)

Console Mounted Fuse Panel,

125A Master Fuse, Master Cutoff switch Power Distribution Center, wires extend to the console

1 - Hot line (30A)

3 - Ignition lines (15A each) 3.03 lbs.

1 - Hot line (30A)

1 - Ignition lines (15A)

1 - Timed Lines (15A)

1 - Line with Lind Barrel

Connector (15 A)

1- Hot line -30A

1 - Ignition lines (15A)

2 - Timed Lines (15A each)

3 - Hot lines (30A, 20A, 20A)

3 - Hot lines (30A, 20A, 20A)

4 - Ignition lines (10A each)

4 - Timed Lines (10A each)

3 - Hot lines (30A, 20A, 20A)

6 - Relayed lines (10A each)

3 - Ignition Lines (10A each)

3.05 lbs.

3.03 lbs.

8 - Ignition lines (10A each) 5.05 lbs.

5.05 lbs.

5.15 lbs.

Utility Harness, Battery Cable,

Console Mount Fuse Panel:

6 Relayed, 3 Ignition, 3 Battery

Hot Circuits, Lind Connector -

Requires Relay or Timer (sold separrately) (UH633-L)

Utility Harness, Battery Cable,

Console Mount Fuse Panel:

6 Timed, 3 Ignition, 3 Battery

Hot Circuits, DR40-VM Timer

(UH633-VM)

Console Mounted Fuse Panel,

125A Master Fuse, Master Cutoff switch Power Distribution Center, wires extend to the console, includes one quick disconnect designed for Docking Station

3 - Hot lines (30A, 30A, 20A)

4 - Relayed lines (10A)

2 - Relayed lines (5A)

3 - Ignition Lines (10A, 10A, 5A)

Console Mounted Fuse Panel,

125A Master Fuse, Master Cutoff switch Power Distribution Center, wires extend to the console, includes one quick disconnect designed for Docking Station

3 - Hot lines (30A, 30A, 20A)

4 - Relayed lines (10A)

2 - Relayed lines (5A)

3 - Ignition Lines (10A, 10A, 5A)

6.0 lbs.

6.0 lbs.

Utility Harness, Battery Cable,

Console Mount Fuse Panel:

6 Timed, 3 Ignition, 3 Battery Hot

Circuits, DR40-VM Timer, Lind

Connector (UH633-VML)

Console Mounted Fuse Panel,

125A Master Fuse, Master Cutoff switch Power Distribution Center, wires extend to the console, includes one quick disconnect designed for Docking Station

3 - Hot lines (30A, 30A, 20A)

4 - Relayed lines (10A)

2 - Relayed lines (5A)

3 - Ignition Lines (10A, 10A, 5A)

6.0 lbs.

Features

- Power Prep Harness designed for Commercial Trucks, Pickups and Code Enforcement vehicles

- Battery, Ignition and Timed Circuits to support the aftermarket equipment installed in a vehicle

- Fuse panel mounts on or near the center console

- Provides a parallel electrical system that is ideal for the computer and IT needs

- Direct plug in of DR series timers eliminating need for additional timers to be installed

- Color-Coded and Labeled Wiring

- Detailed Color Schematics

- Direct to Battery Grounds

- Fabricated Wire Harness of High Quality TXL Copper Exceeds SAE Standard J-1128

- Heat Rated: Tested for Maximum Loads at -40°F to 221°F

- Fire Retardant Protective Loom

- Warranty terms/policy by MNSTAR:

- No warranty for Fuses and Solenoids

- 1 year limited warranty for Relays, Timers, Electronic Control Modules and Circuit Boards

- 3 year limited warranty for Wire Harnesses, Fuse Panels and Power Distribution Centers

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Power Distribution anD wiring harness

MNSTAR Protector Series - Power Distribution Centers Fuse Panels

Item No.

Description Placement Outputs Weight

7300-0053

7300-0027

7300-0054

7300-0014

Protector Fuse Panel, 100

Amp, 6 Outputs, Screw

Term (PD-B6)

Protector Fuse Panel, 11

Outputs Split (PD-B11)

Protector Fuse Panel, 100

Amp, 12 Outputs, Screw

Term (PD-B12)

Protector Fuse Panel, 11

Outputs,16" Input, 60"

Outputs - Requires Relay or Timer (sold separrately)

(PRT11-0)

Trunk, Console or anyplace multiple fused circuits are needed

Trunk, Console or anyplace multiple fused hot, timed or ignition circuits are needed

Trunk, Console or anyplace multiple fused circuits are needed

The PRT11-0 provides Relayed, Battery

Hot, and Ignition Hot circuits in a compact power distribution center

6 (100 Amp)

6 (100 Amp)

5 (40 Amp)

12 (100Amp)

3 Battery

4 Ignition

4 Timed Requires Relay or Timer

0.08 lbs.

0.11 lbs.

0.11 lbs.

2.0 lbs.

7300-0016

Protector Fuse Panel,

11 Outputs, Timed with

DR40-VM Timer, 16" Input,

60" Outputs (PRT11-VM)

The PRT11-VM provides Timed, Battery

Hot, and Ignition Hot circuits in a compact power distribution center

3 Battery

4 Ignition

4 Timer

2.0 lbs.

Features

- Protector Series provides power distribution centers and fuse panels to be used as stand-alone products or augment

the Installer or Integrator Series Harnesses

- Provides Timed, Battery Hot and Ignition Hot circuits in a compact power distribution center

- Direct plug in of DR series timers

- Perfect Solution for Command Boxes

- Color-Coded and Labeled Wiring

- Detailed Color Schematics

- Fabricated Wire Harness of High Quality TXL Copper Exceeds SAE Standard J-1128

- Heat Rated: Tested for Maximum Loads at -40°F to 221°F

- Fire Retardant Protective Loom

- Protector Series doesn’t include grounds, lighting triggers or spare wires

- Warranty terms/policy by MNSTAR:

- No warranty for Fuses and Solenoids

- 1 year limited warranty for Relays, Timers, Electronic Control Modules and Circuit Boards

- 3 year limited warranty for Wire Harnesses, Fuse Panels and Power Distribution Centers

Shown: 7300-0014

Shown: 7300-0017

MNSTAR Protector Series - Delay Shut Down Timers and Accessories

Item No.

Description

7300-0026

7300-0017

7300-0018

7300-0023

7300-0055

7300-0056

Programmable, Voltage Sensing, 30 Amp Load, Diagnostic LED Indicators Plugin Timer used with the 00-1705 Pigtail or fuse panel (DR40-VM)

Kit (PK40VM): DR40-VM Timer, Voltage Sensing, 25 Amp Load, 00-1705 Pigtail

Kit (PK40VMR): DR40-VM Timer, 00-1705 Pigtail, 130/300 Amp Relay, Wiring

Pigtail and Connector for DR38 Series Timers (00-1705)

200 Amp Master Relay Kit (SK-1502)

75 Amp Relay with Relay Control Connector (SK-1550)

Weight

0.02 lbs.

0.1 lbs.

2.08 lbs.

0.1 lbs.

1.0 lb.

1.0 lb.

Shown: 7300-0026

Shown: 7300-0055

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Shown: 7300-0056

103

Power Distribution anD wiring harness

MNSTAR Installer Adaptable Harnesses

These products are designed to offer a wide array of configurations and options. Installer Harnesses are designed to be used with a Power Prep Harness.

Utilizing separate harnesses for the lighting installation allows the customer to scale the power distribution to their application.

104

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Power Distribution anD wiring harness

MNSTAR Installer Level 1 Harnesses: Light and Siren Control Wires for Trucks, Sedans and SUV’s

Item No.

Description Placement Weight

7300-0057

Installer Front Battery, Level 1, Base Harness (IFL1) Under hood and thru the main Cabin of the Vehicle 11.0 lbs.

7300-0058

Installer Front Battery, Level 1 with Sync, 2nd Speaker,

Low Frq Speaker, Front Marker, Mirror and Mid-ship

Lights and Dual Y Power Prep (IFL1-AS2LEMBYY)

Under hood and thru the main Cabin of the Vehicle 13.0 lbs.

Features

- Base Installer Front Battery Harness

- Add options from the Adaptable Design Array (below) to the base IFL1 to create custom harness

- Additionally several Radio Prep lines can be added to the main harness

- Color-Coded and Labeled Wiring

- Detailed Color Schematics

- Direct to Battery Grounds

- Fabricated Wire Harness of High Quality TXL Copper Exceeds SAE Standard J-1128

- Heat Rated: Tested for Maximum Loads at -40°F to 221°F

- Fire Retardant Protective Loom

- Flexible Spare Circuits

- Warranty terms/policy by MNSTAR:

- No warranty for Fuses and Solenoids

- 1 year limited warranty for Relays, Timers, Electronic Control Modules and Circuit Boards

- 3 year limited warranty for Wire Harnesses, Fuse Panels and Power Distribution Centers

Note:

MNSTAR recommends the use of a Power Prep Harness with all Level 1 Harnesses

MNSTAR Adaptable Design Array: Options that may be added to the

Base IFL1 Harness (may select none, one or all of the options)

Item No.

Description Placement

7300-0059

Vehicle Sense, Right Spot Light, & Rebroadcast (A) Right Spot Light

Weight

1.0 lb.

7300-0060

Sync Option, Provides Common Sync Wire at Each Lighthead (S) Sync wire provided for all lighting 1.0 lb.

7300-0061

2nd 100 Watt Siren Speaker, Wire Pair from Siren to Speaker (2) Under hood to Switchbox location 1.0 lb.

7300-0062

Low Frequency Siren, 3 Wires from Siren to Speakers (L)

7300-0063

Warning Lights at European/Front Marker Light Locations (E)

Under hood to Switchbox location 1.0 lb.

Driver & Passenger 1.0 lb.

7300-0064

7300-0065

7300-0066

7300-0067

7300-0068

7300-0069

Side Mirror Warning Lights (M)

Mid-Ship Lights at the B or C Pillar (B)

Radio Power, 20 Amp, 10 Gauge (X)

Radio Power, 20 Amp, 10 Gauge (Y)

Radio Power, 20 Amp, 10 Gauge (Z)

Radio Power, 20 Amp, 10 Gauge (W)

Driver & Passenger side

Driver & Passenger side

Front Battery to Console

Front Battery to Trunk Tray

Rear Battery to Console

1.0 lb.

1.0 lb.

1.0 lb.

1.0 lb.

1.0 lb.

Rear Battery to Trunk Tray - Braided 1.0 lb.

Shown: 7300-0066

Shown: 7300-0067

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

105

Power Distribution anD wiring harness

Shown: 7300-0074 / 7300-0075

MNSTAR Accessory Harnesses: Additional installation support to augment Level 1 products

Item No.

Description

7300-0070

Accessory Harness, Truck Rear Lights, 2 Rear Warning Lights (00-AH01)

7300-0071

7300-0072

7300-0073

7300-0074

7300-0075

Accessory Harness, Truck Rear Lights, 2 Rear Warning Lights with

Work Light 1 Near Cab (00-AH02)

Accessory Harness, Truck Rear Lights, 2 Rear Warning Lights With

Work Light 2 at Rear of Body (00-AH03)

Accessory Harness, Truck Rear Lights, 2 Rear Warning Lights with Work

Light 1 Near Cab & Work Light 2 at Rear of Body (00-AH04)

Accessory Harness, Lift Gate Harness, 2 Two Color-Warning Lights,

2 Red/White Interior Lights, & 2 Warning Lights (00-AH20)

Lift Gate Harness, 2 Two Color-Warning Lights, 2 Red/White Interior Lights,

2 Warning Lights & 2 Radio Speaker Pairs (00-AH21)

Placement Weight

Console to Rear 1.0 lb.

Rear 1.04 lbs.

Rear 1.09 lbs.

Rear

Lift Gate

Lift Gate

1.12 lbs.

3.0 lbs.

3.0 lbs.

MNSTAR Radio Power Harness

Item No.

Description Placement Weight

7300-0076

Installer Radio Prep Power,20 Amp, 10 Gauge, Braided (I-RFC) Front Battery to Console 2.13 lbs.

7300-0077

Installer Radio Prep Power, 20 Amp, 10 Gauge, Braided (I-RFT) Front Battery to Rear of Vehicle 3.1 lbs.

7300-0078

Installer Radio Prep Power, 20 Amp, 10 Gauge, Braided (I-RRC) Rear Battery to Console 2.13 lbs.

7300-0079

Installer Radio Prep Power, 20 Amp, 10 Gauge, Braided (I-RRT) Rear Battery to Trunk Tray 2.0 lbs.

Features

- Stand alone power and ground cables

- Direct to battery power and ground circuits reduce voltage drop and RFI interference for critical communication equipment

- The Braided pairs may be augmented by options W, X, Y, or Z, to additional ordered pairs to each braided harness.

- Warranty terms/policy by MNSTAR:

- No warranty for Fuses and Solenoids

- 1 year limited warranty for Relays, Timers, Electronic Control Modules and Circuit Boards

- 3 year limited warranty for Wire Harnesses, Fuse Panels and Power Distribution Centers

106

Shown: 16373

MNSTAR Distribution and Timer Block

Item No.

Description Placement Weight

16373

Power Distribution and Timer Block Can be positioned in any convenient location 1.3 lbs.

Features

- 60 Amp Total Load

- 8 Fused Outputs

- 30 Amps of load per Terminal Bank which equals 37.5 Amps of Fuses

- Maximum of 30 Amps for any single circuit

- Indicator LED’s for Simple Diagnostics

- Programmable Delay Settings in 15 Minute Increments

- 1 Minute to 225 Minutes

- 2 Distinct Timers in one body – Eac timer controls one Bank of 4 Outputs

- Voltage Sensing to Protect the Battery

- Under Voltage Cut0off at 10.5 VDC to Protect the Vehicle Battery from Parasitic Drain

- Over Voltage Cut-Off at 16.5 VDC to protect the IT and Communication Equipment

- Ignition Override: The Ignition Signal brings the Timer Live to ensure instant access to the Two-way Radio and IT Equipment

- Simulated Ignition Output – Setting the Timer to 1 Minute Delay Creates additional Ignition Controlled Outputs

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Ma x

3

Every gadget needs me.

MAX

3

is a mounting solution that gives you more.

MAXimum versatility, flexibility and durability.

BENEFITS:

• Holds a variety of devices

• Multi-configurable

• Withstands industry wear and tear

• Moves all-axis for convenient device use

• Available in three different sizes

Small (holds up to 1 lb.)

Medium (holds up to 3 lbs.)

Large (holds up to 7 lbs.)

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

107

108

Ma x

3

To configure your solution you must select a Kit, a Device Plate and a Base Plate

Item No.

7160-0292

7160-0293

7160-0294

Description

Kits (includes Knuckle, Extension and Thread Adapter)

Small Knuckle, 50mm Extension (holds up to 1 lb.) 0.35 lbs 5.50"

Small Knuckle, 100mm Extension (holds up to 1 lb.) 0.45 lbs 7.50"

Small Knuckle, 150mm Extension (holds up to 1 lb.)

7160-0295

Medium Knuckle, 50mm Extension (holds up to 3 lbs.)

7160-0296

Medium Knuckle, 100mm Extension (holds up to 3 lbs.)

7160-0297

Medium Knuckle, 150mm Extension (holds up to 3 lbs.)

Weight

0.50 lbs

0.55 lbs

0.65 lbs

0.70 lbs

Height

9.50"

5.88"

7.88"

9.88"

7160-0298

7160-0299

7160-0300

7.00"

9.00"

10.88"

14139

14140

14144

14144

14146

7160-0440

14649

Large Knuckle, 50mm Extension (holds up to 7 lbs.)

Large Knuckle, 100mm Extension (holds up to 7 lbs.)

1.05 lbs

1.15 lbs

Large Knuckle, 150mm Extension (holds up to 7 lbs.) 1.20 lbs

Device Mounting Plates

VESA 75mm plate 0.20 lbs

VESA 100mm plate

Round Plate

0.25 lbs

0.10 lbs

Base Plates

Round Plate

Quick Release Round Plate

0.10 lbs

0.30 lbs

Pole Mount

Suction Cup

0.50 lbs

0.80 lbs

0.88"

0.88"

0.88"

0.88"

1.25"

4.12"

2.0"

Width

3.75"

4.75"

NA

NA

NA

2.75"

NA

2.75"

2.75"

2.75"

3.38"

3.38"

3.38"

3.88"

3.88"

3.88"

Depth

1.26" diameter

1.26" diameter

1.26" diameter

1.54" diameter

1.54" diameter

1.54" diameter

2.05" diameter

2.05" diameter

2.05" diameter

3.75"

4.75"

2.38" diameter

2.38" diameter

2.50" diameter

1.87"

4.75" diameter

Shown: 7160-0296,

14139, 14144

With an all metal construction, all axes movement and the ability to hold a wide variety of devices, MAX3 is more versatile, more durable and more flexible.

Numerous mounting plates designed for device adaption – use with ultramobile PCs, handheld devices,

PDAs, cell phones and more

All metal construction (anodized aluminum) will not deform or degrade

MIL-810F tested

Quick adjust handle for easy adjustment to position the device at the desired angle

All axes range of motion in X axis (left/right), Y axis

(front/back) and Z axis (up/down)

Multi-Configurable – extension tubes of various lengths work to achieve desired reach

Encapsulated ball design offers theft deterrence

1 year limited warranty by Zirkona

www.mymax3.com

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Ma x

3

Max3 Individual Components

Item No.

7160-0286

7160-0287

7160-0288

14141

14142

14143

Description Weight

Knuckles

Small Knuckle (holds up to 1 lb.) 0.25 lbs

Medium Knuckle (holds up to 3 lbs.) 0.45 lbs

Large Knuckle (holds up to 7 lbs.) 0.95 lbs

Extensions

50mm Extension

100mm Extension

150mm Extension

0.05 lbs

0.15 lbs

0.20 lbs

Thread Adapter

14145

14139

14140

14144

14144

14146

7160-0440

14649

Thread Adapter to conntect extension to base plate

0.05 lbs

Device Mounting Plates

VESA 75mm plate 0.20 lbs

VESA 100mm plate 0.25 lbs

Round Plate (AMPS and NEC) 0.10 lbs

Base Plates

Round Plate (AMPS and NEC)

Quick Release Round Plate

0.10 lbs

0.30 lbs

Pole Mount

Suction Cup

0.50 lbs

0.80 lbs

Height

3.62"

4.00"

5.00"

2.00"

4.00"

6.00"

1.00"

0.88"

0.88"

0.88"

0.88"

1.25"

4.12"

2.0"

Width

2.75"

3.38"

3.88"

Depth

1.26" diameter

1.54" diameter

2.05" diameter

NA

NA

NA

1.00" diameter

1.00" diameter

1.00" diameter

NA 0.77" diameter

3.75"

4.75"

NA

NA

NA

2.75"

NA

3.75"

4.75"

2.38" diameter

2.38" diameter

2.50" diameter

1.87"

4.75" diameter

Shown: 14139

Shown: 14140

Shown: 14141

Shown: 14142

Shown: 14143

Shown: 14145

See page 3 for hole pattern definitionS

Shown: 14144

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

Shown: 14146

Shown: 7160-0440

Shown: 14649

109

110

Index

3130-0152 ..................................... 45

3130-0153 ..................................... 45

3130-0154 ..................................... 45

3130-0155 ..................................... 45

3130-0156 ..................................... 45

3130-0361 ..................................... 45

7110-0350 ...................................... 42

7110-0643 ...................................... 87

7110-0913 ...................................... 90

7110-0998 ...................................... 40

7110-0999 ...................................... 40

7110-1001 ...................................... 40

7110-1012 ...................................... 40

7110-1013 ...................................... 40

7110-1023 ...................................... 87

7110-1024 ...................................... 40

7110-1200 ...................................... 29

7110-1201 ...................................... 40

7120-0519 ..................................... 75

7120-0568 ..................................... 90

7120-0579 ..................................... 40

7120-0587 ..................................... 75

7120-0647 ..................................... 64

7160-0006 ............................... 47, 72

7160-0033 ..................................... 14

7160-0036 ..................................... 15

7160-0045 ..................................... 15

7160-0046 ..................................... 15

7160-0049 ..................................... 83

7160-0053 ..................................... 35

7160-0055 ..................................... 16

7160-0063 ..................................... 45

7160-0073 ..................................... 83

7160-0079 ..................................... 61

7160-0082 ..................................... 61

7160-0084 ..................................... 42

7160-0085 ..................................... 43

7160-0086 ..................................... 43

7160-0088 ..................................... 42

7160-0090 ..................................... 16

7160-0095 ............................... 87, 90

7160-0096 ................... 87, 89, 95, 96

7160-0100 ..................................... 48

7160-0101 ..................................... 85

7160-0102 ..................................... 61

7160-0103 ..................................... 61

7160-0104 ..................................... 61

7160-0105 ..................................... 61

7160-0106 ..................................... 49

7160-0110 ................................ 40, 48

7160-0116 ...................................... 16

7160-0121 ..................................... 42

7160-0126 ..................................... 72

7160-0133 ..................................... 16

7160-0160 ..................................... 42

7160-0162 ..................................... 30

7160-0164 ..................................... 42

7160-0177 ..................................... 25

7160-0178 ..................................... 25

7160-0182 ..................................... 17

7160-0185 ..................................... 17

7160-0190 ..................................... 12

7160-0198 ..................................... 17

7160-0201 ..................................... 90

7160-0202 ..................................... 90

7160-0203 ..................................... 90

7160-0215 ..................................... 83

7160-0220 ..................................... 34

7160-0230 ..................................... 27

7160-0231 ..................................... 27

7160-0234 ..................................... 18

7160-0237 ..................................... 44

7160-0248 ..................................... 18

7160-0250 ..................................... 75

7160-0250-01 ................................ 75

7160-0250-02 ................................ 75

7160-0250-03 ................................ 75

7160-0251 ..................................... 76

7160-0251-01 ................................ 76

7160-0252 ..................................... 76

7160-0253 ..................................... 76

7160-0260 ..................................... 18

7160-0264-00 ................................ 84

7160-0264-02 ................................ 84

7160-0264-03 ................................ 84

7160-0264-04 ................................ 84

7160-0264-05 ................................ 83

7160-0267 ..................................... 52

7160-0268 ..................................... 30

7160-0281 ..................................... 19

7160-0284 ..................................... 34

7160-0285 ..................................... 34

7160-0286 ................................... 109

7160-0287 ................................... 109

7160-0288 ................................... 109

7160-0292 ................................... 108

7160-0293 ................................... 108

7160-0294 ................................... 108

7160-0295 ................................... 108

7160-0296 ................................... 108

7160-0297 ................................... 108

7160-0298 ................................... 108

7160-0299 ................................... 108

7160-0300 ................................... 108

7160-0301 ..................................... 42

7160-0313 ............................... 40, 48

7160-0318-00 ................................ 88

7160-0318-01 ................................ 88

7160-0318-02 ................................ 88

7160-0318-04 ................................ 88

7160-0318-05 ................................ 88

7160-0318-06 ................................ 88

7160-0321 ..................................... 53

7160-0322 ..................................... 53

7160-0323 ..................................... 19

7160-0325 ..................................... 41

7160-0326 ..................................... 38

7160-0327 ..................................... 38

7160-0329 ..................................... 19

7160-0332 ..................................... 48

7160-0333 ..................................... 44

7160-0336 ..................................... 38

7160-0337 ..................................... 50

7160-0338 ..................................... 50

7160-0339 ..................................... 55

7160-0341 ..................................... 33

7160-0342 ..................................... 19

7160-0350 ..................................... 20

7160-0351 ..................................... 90

7160-0356 ..................................... 64

7160-0357 ..................................... 64

7160-0363 ..................................... 67

7160-0366 ..................................... 65

7160-0367 ..................................... 65

7160-0368 ..................................... 65

7160-0370 ..................................... 64

7160-0371 ..................................... 64

7160-0375 ..................................... 47

7160-0380 ..................................... 36

7160-0386 ............................... 36, 39

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

7160-0388 ..................................... 49

7160-0389 ..................................... 49

7160-0392 ..................................... 73

7160-0393-00 ................................ 85

7160-0393-02 ................................ 85

7160-0393-04 ................................ 85

7160-0393-06 ................................ 85

7160-0398 ......................... 83, 89, 95

7160-0402 ..................................... 75

7160-0402-03 ................................ 75

7160-0403 ..................................... 61

7160-0406 ..................................... 50

7160-0409 ..................................... 39

7160-0410 ..................................... 39

7160-0411 ...................................... 39

7160-0412 ..................................... 39

7160-0413 ..................................... 42

7160-0415 ..................................... 84

7160-0418 ..................................... 64

7160-0420 ..................................... 65

7160-0421 ..................................... 65

7160-0422 ..................................... 42

7160-0425 ..................................... 73

7160-0427 ..................................... 32

7160-0428 ..................................... 85

7160-0429 ..................................... 40

7160-0430 ..................................... 40

7160-0431 ..................................... 40

7160-0432 ..................................... 51

7160-0434 ..................................... 37

7160-0435 ..................................... 37

7160-0436 ..................................... 30

7160-0438 ..................................... 39

7160-0440 ........................... 108, 109

7160-0444 ..................................... 40

7160-0451 ..................................... 20

7160-0454 ..................................... 80

7160-0459 ..................................... 52

7160-0462 ..................................... 52

7160-0464 ..................................... 40

7160-0465 ..................................... 52

7160-0466 ..................................... 52

7160-0467 ..................................... 52

7160-0487-00 ................................ 80

7160-0487-02 ................................ 80

7160-0490-00 ................................ 80

7160-0493 ..................................... 66

7160-0494 ..................................... 78

7160-0496 ..................................... 89

7160-0497 ..................................... 30

7160-0498 ..................................... 70

7160-0499 ..................................... 66

7160-0499-01 ................................ 66

7160-0500 ..................................... 31

7160-0501 ..................................... 95

7160-0502 ..................................... 31

7160-0505-00 ................................ 96

7160-0505-02 ................................ 96

7160-0507 ..................................... 73

7160-0509 ..................................... 42

7160-0510 ..................................... 20

7160-0514 ..................................... 31

7160-0515-00 ................................ 97

7160-0515-03 ................................ 97

7160-0516 ..................................... 45

7160-0517 ..................................... 45

7160-0520 ..................................... 21

7160-0521-00 ................................ 36

7160-0521-01 ................................ 36

7160-0522 ..................................... 52

7160-0523 ..................................... 51

7160-0524 ..................................... 40

7160-0525 ..................................... 46

7160-0526-00 ................................ 95

7160-0526-02 ................................ 95

7160-0527 ..................................... 21

7160-0528 ..................................... 54

7160-0529 ..................................... 78

7160-0531-00 ................................ 81

7160-0531-02 ................................ 81

7160-0531-03 ................................ 81

7160-0531-04 ................................ 81

7160-0532 ..................................... 21

7160-0536 ..................................... 21

7160-0537 ..................................... 22

7160-0538 ..................................... 53

7160-0539 .................. 81, 82, 83, 85,

.................. 87, 89, 90, 93, 94, 96, 97

7160-0540 ..................................... 45

7160-0542-00 ................................ 92

7160-0542-03 ................................ 92

7160-0543-00 ................................ 81

7160-0544 ..................................... 22

7160-0545 ..................................... 61

7160-0548 ..................................... 45

7160-0550 ..................................... 66

7160-0552 ..................................... 42

7160-0553 ..................................... 22

7160-0554 ..................................... 22

7160-0555 ..................................... 42

7160-0556 ..................................... 23

7160-0557 ..................................... 23

7160-0561 ..................................... 65

7160-0564 ..................................... 82

7160-0565-00 ................................ 94

7160-0565-03 ................................ 94

7160-0568-00 ................................ 97

7160-0568-03 ................................ 97

7160-0568-04 ................................ 97

7160-0568-05 ................................ 97

7160-0569 ..................................... 50

7160-0570-00 ................................ 95

7160-0572 ..................................... 23

7160-0573-00 ................................ 96

7160-0575 ..................................... 42

7160-0576-00 ................................ 92

7160-0576-03 ................................ 92

7160-0577-00 ................................ 86

7160-0577-02 ................................ 86

7160-0578-00 ................................ 86

7160-0580-00 ................................ 38

7160-0580-01 ................................ 38

7160-0583-00 ................................ 94

7160-0583-03 ................................ 94

7160-0585 ..................................... 66

7160-0586 ..................................... 66

7160-0587 ..................................... 53

7160-0589 ..................................... 42

7160-0590 ..................................... 23

7160-0593 ..................................... 67

7160-0595-00 ................................ 80

7160-0595-02 ................................ 80

7160-0597 ..................................... 48

7160-0598 ..................................... 65

7160-0608 ..................................... 69

7160-0609 ..................................... 69

7160-0610 ..................................... 69

7160-0611 ...................................... 69

7160-0750 ..................................... 29

7160-0757 ..................................... 70

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

7160-0762 ..................................... 30

7160-0760-00 ................................ 93

7160-0760-03 ................................ 93

7160-0770 ..................................... 44

7160-0774 ..................................... 76

7160-0775 ..................................... 29

7160-0776 ..................................... 29

7160-0785 ..................................... 68

7160-0793 ..................................... 68

7160-0795 ..................................... 68

7160-0805 ..................................... 65

7160-0810 ..................................... 70

7160-0814 ..................................... 64

7160-0815 ..................................... 64

7160-0817 ..................................... 68

7160-0826 ..................................... 49

7170-0125 ..................................... 61

7170-0128 ..................................... 41

7170-0129 ..................................... 15

7170-0130 ..................................... 16

7170-0132 ..................................... 40

7170-0133 ..................................... 19

7170-0134 ..................................... 41

7170-0135 ..................................... 13

7170-0136 ..................................... 17

7170-0137 ..................................... 38

7170-0138 ..................................... 19

7170-0140 ..................................... 18

7170-0142 ..................................... 14

7170-0143 ..................................... 41

7170-0144 ..................................... 16

7170-0148 ..................................... 20

7170-0156 ..................................... 82

7170-0165 ..................................... 39

7170-0166 ..................................... 39

7170-0214 ..................................... 20

7170-0218 ..................................... 78

7170-0218-01 ................................ 78

7170-0219 ..................................... 78

7170-0219-01 ................................ 78

7170-0220 ..................................... 21

7170-0221 ..................................... 36

7170-0222 ..................................... 37

7170-0226 ..................................... 22

7170-0233 ..................................... 20

7170-0234 ..................................... 18

7170-0235 ..................................... 23

7170-0236 ..................................... 22

7170-0237 ..................................... 39

7170-0237-XX ............................... 37

7170-0237-00 ................................ 37

7170-0237-01 ................................ 37

7170-0237-02 ................................ 37

7170-0237-03 ................................ 37

7170-0237-04 ................................ 37

7170-0238 ..................................... 21

7170-0239 ..................................... 21

7170-0240 ..................................... 92

7170-0241 ..................................... 92

7170-0242 ..................................... 97

7170-0243 ..................................... 97

7170-0244 ..................................... 94

7170-0245 ..................................... 94

7170-0246 ..................................... 94

7170-0247 ..................................... 94

7170-0250 ..................................... 86

7170-0251 ..................................... 86

7170-0500 ..................................... 21

7170-0501 ..................................... 15

7170-0502 ..................................... 19

7170-0503 ..................................... 23

7170-0504 ..................................... 69

7170-0505 ..................................... 69

7170-0506 ..................................... 69

7170-0507 ..................................... 69

7170-0508 ..................................... 69

7170-0509 ..................................... 69

7170-0510 ..................................... 69

7170-0511 ...................................... 69

7170-0513 ..................................... 78

7170-0513-01 ................................ 78

7170-0514 ..................................... 78

7170-0792-00 ................................ 93

7170-0792-03 ................................ 93

7300-0001 ................................... 100

7300-0002 ................................... 100

7300-0003 ................................... 100

7300-0004 ................................... 100

7300-0005 ................................... 101

7300-0007 ................................... 101

7300-0008 ................................... 101

7300-0010 ................................... 101

7300-0011 .................................... 101

7300-0013 ................................... 101

7300-0014 ................................... 103

7300-0016 ................................... 103

7300-0017 ................................... 103

7300-0018 ................................... 103

7300-0023 ................................... 103

7300-0026 ................................... 103

7300-0027 ................................... 103

7300-0028 ..................................... 71

7300-0029 ..................................... 71

7300-0030 ..................................... 71

7300-0031 ..................................... 71

7300-0032 ..................................... 71

7300-0033 ..................................... 71

7300-0034 ..................................... 71

7300-0035 ..................................... 71

7300-0036 ..................................... 71

7300-0037 ..................................... 71

7300-0038 ..................................... 71

7300-0039 ..................................... 99

7300-0040 ..................................... 99

7300-0041 ..................................... 99

7300-0042 ................................... 100

7300-0043 ................................... 100

7300-0044 ................................... 102

7300-0045 ................................... 102

7300-0046 ................................... 102

7300-0047 ................................... 102

7300-0048 ................................... 102

7300-0049 ................................... 102

7300-0050 ................................... 102

7300-0051 ................................... 102

7300-0052 ................................... 102

7300-0053 ................................... 103

7300-0054 ................................... 103

7300-0055 ................................... 103

7300-0056 ................................... 103

7300-0057 ................................... 105

7300-0058 ................................... 105

7300-0059 ................................... 105

7300-0060 ................................... 105

7300-0061 ................................... 105

7300-0062 ................................... 105

7300-0063 ................................... 105

7300-0064 ................................... 105

7300-0065 ................................... 105

7300-0066 ................................... 105

Index

111

Index

7300-0067 ................................... 105

7300-0068 ................................... 105

7300-0069 ................................... 105

7300-0070 ................................... 106

7300-0071 ................................... 106

7300-0072 ................................... 106

7300-0073 ................................... 106

7300-0074 ................................... 106

7300-0075 ................................... 106

7300-0076 ................................... 106

7300-0077 ................................... 106

7300-0078 ................................... 106

7300-0079 ................................... 106

11634 ....................................... 81, 89

11798 ........................... 81, 82, 83, 89

11511 ............................................. 50

13791....................................... 40, 98

13792....................................... 40, 98

14103....................................... 87, 89

14139................................... 108, 109

14140................................... 108, 109

14141........................................... 109

14142........................................... 109

14143........................................... 109

14144................................... 108, 109

14145........................................... 109

14146................................... 108, 109

14327............................................. 71

14328............................................. 71

14329............................................. 71

14330............................................. 71

14331............................................. 72

14332............................................. 72

14422............................................. 40

14463............................................. 64

14619............................................. 54

14649................................... 108, 109

14650....................................... 85, 89

15082............................................. 45

15083............................................. 45

15087............................................. 55

15110 ........................... 93, 94, 96, 97

15130............................................. 45

15202............................................. 67

15203............................................. 67

15250............................................. 40

15343............................................. 54

15344............................................. 53

15348............................................. 53

15371............................................. 46

15377............................................. 54

16030............................................. 51

16063............................................. 68

16064............................................. 68

16071............................................. 53

16079............................................. 67

16082............................................. 51

16327............................................. 55

16330............................................. 55

16331............................................. 54

16372............................................. 98

16373........................................... 106

16411 ............................................. 67

16412............................................. 67

ABF-KIT ......................................... 27

DS-52 ............................................ 12

DS-53 ............................................ 12

DS-55 ............................................ 12

DS-56 ............................................ 12

DS-57 ............................................ 13

DS-74 ............................................ 27

DS-74-L ......................................... 27

DS-100 .......................................... 13

DS-100-PLATE .............................. 13

DS-124 .......................................... 13

DS-138 .......................................... 13

notes

DS-144 .......................................... 14

DS-146 .......................................... 14

DS-150 .......................................... 14

DS-LOWER-5 ................................ 25

DS-LOWER-7 ................................ 25

DS-LOWER-9 ................................ 25

DS-LOWER-13 .............................. 25

DS-POLE-CTR .............................. 25

DS-STEP ....................................... 27

DS-UPPER .................................... 26

DS-UPPER-5 ................................. 26

DS-UPPER-L ................................. 26

DS-UPPER-M ................................ 26

DS-UPPER-M5 .............................. 26

FACEPLATES ........................... 56-59

LOWSWIVEL ................................. 30

MCS-ARMREST ............................ 46

MCS-ARMREST5 .......................... 46

MCS-COMBRKT ........................... 49

MCS-CUP ...................................... 47

MCS-CUP2 .................................... 47

MCS-CUPHOLD2 .................... 40, 47

MCS-EPIC9 ................................... 43

MCS-EPIC13 ................................. 43

MCS-EPIC17 ................................. 43

MCS-EPICMIC .............................. 49

MCS-ERGOBOX12 ....................... 43

MCS-INTCUP ................................ 47

MCS-LOWBOX .............................. 44

MCS-MICPLT ................................ 49

MCS-POCKET3 ............................. 48

NP-PAN-CRADLE ......................... 87

QADJ-UPPER-L ............................ 26

QADJ-UPPER-L5 .......................... 26

QADJ-UPPER-M ........................... 26

QADJ-UPPER-M5 ......................... 26

QADJ-UPPER-S ............................ 26

QADJ-UPPER-S5 .......................... 26

112

View and customize mounting solutions for your vehicle @ www.gamberjohnson.com

MOUNTING EqUIpMENT

3001 Borham Ave.

Stevens Point, WI 54481

Phone toll-free: 800.741.4530

Fax: 715.344.5209

Fax toll-free: 800.934.3577

email: [email protected]

www.gamberjohnson.com

Your Local Gamber-Johnson Reseller:

Follow us on:

An ISO 9001:2008 Certified Company

CATALOG pMENT 2016 MOUNTING EqUI

GRIP

2016 MOUNTING EqUIpMENT CATALOG

ExCEpTIONAL ENGINEErING | rOCk sOLId | ExTENsIvE TEsTING

CATALOG pMENT 2016 MOUNTING EqUI

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
