DSC-S600

DSC-S600
DSC-S600
NEW
New
Cyber-shot® digital still camera
With superb 6.0 megapixel performance and top-quality Carl Zeiss® 3X Optical zoom lens with wide-angle shooting,
the compact Sony Cyber-shot® DSC-S600 provides excellent value for both first-time and step-up digital
photographers. Both powerful and affordable, the DSC-S600 also has high sensitivity, strong flash, 2.0” 2 LCD screen
and 32 MB1 Internal Memory for in-camera shooting.
6.0 Megapixel Super HAD™ CCD
More megapixels mean more detail and
definition in digital photos -- important when
you’ re making large prints or posting photos
on the Internet. Sony’ s advanced Super
HAD (Hole Accumulated Diode) CCD is
designed to allow more light to pass to each
pixel, to increase camera sensitivity and
reduce picture noise.
3X Optical/2X Digital Zoom
What’ s the difference between “ optical”
and “ digital” zoom? Optical zoom uses
moving lens elements; digital zoom relies on
digital enlargement. In the DSC-S600, 3X
Optical zoom helps you frame your shots for
better digital pictures; Sony’ s Precision
Digital zoom provides an additional 2X
Carl Zeiss® Lens Design
The Sony Cyber-shot® DSC-S600 uses a
precision Carl Zeiss® Vario-Tessar lens
design with excellent wide-angle shooting
capabilities, making it easier to take indoor
photos and capture group shots -- and its
sophisticated design enables quick autofocus and incorporates a wide optical zoom
range within compact dimensions.
Strong Flash
The DSC-S600 provides strong flash to
illuminate subjects more effectively -- up to
a range of 33 feet, significantly greater than
previous Sony models so you won’ t have to
stand so close to get great pictures indoors.
High Sensitivity
A first in an entry-level digital camera, the
high sensitivity (ISO 1000) shooting mode of
the DSC-S600 gets great shots even in lowlight conditions -- a plus when shooting to
capture the mood or in locations where
flash is not permitted.
13X Smart Zoom™ Feature
At VGA resolution4 , Sony’ s Smart Zoom
feature intelligently “ crops into” the central
portion of interest in your photo without
sacrificing the resolution of the full CCD -thus avoiding the image degradation of
other digital zooms.
Large 2.0” 2 LCD Screen
In addition to the optical viewfinder, the
DSC-S600 also has a built-in 2.0” LCD
screen that makes it easy to read menus,
frame shots and check results while you’ re
still on the scene.
Real Imaging Processor™ LSI
To capture the moment before it gets
away, Sony’ s DSC-S600 uses a Real
Imaging Processor™ LSI (Large Scale
Integrated Circuit) that not only improves
camera response time and decreases
shutter lag, but also improves picture quality
and clarity and increases battery stamina.
5 Area Multi-Point Auto Focus
By intelligently evaluating 5 separate focus
areas of the frame, Sony’ s Multi-Point AF
system can help you automatically maintain
focus on the subject -- not on distracting
elements in the background.
AF (Auto Focus) Illuminator
This simple feature briefly illuminates the
subject, to help establish a positive focus
lock in low -- or no -- light conditions.
32 MB1 Internal Memory
What if you forget your flash memory card?
No problem -- with the DSC-S600, you can
capture great memories in-camera with an
internal 32 MB1 memory -- then easily
transfer your shots to optional Memory Stick
Duo™ media.
Burst Mode
For capturing a child’ s first steps or a pet’ s
bests tricks, this Sony feature lets you
automatically record up to 7 shots at full 6.0
megapixel resolution or 100 shots at
standard VGA resolution.
Optional Memory Stick Duo™ Media
Sony’ s compact, high-capacity Memory
Stick Duo™ media options can hold all your
digital images and connect you to a wide
range of compatible hardware and software
applications.
MPEG Movie VX Fine Mode
In MPEG VX Fine Mode, the DSC-S600 can
capture VGA (640 x 480) audio/video clips
at high frame rate (up to 30 frames per
second) -- another rarity in entry-level
cameras, with length limited only by the
capacity of your media. Video mail mode
captures smaller files sizes suitable for email.
Stamina™ Battery Performance
With standard AA alkaline batteries, the
DSC-S600 can capture up to 160 shots3 -and when you use optional Sony NiMH
rechargeable batteries, you can capture up
to an amazing 460 shots3 . That’ s enough
shooting capacity for an entire vacation.
Cyber-shot Viewer Software
Sony’ s new software that makes it easy to
import images via camera or Memory
Stick® media -- then organize and browse
through photos on your PC with simple
scrolling through thumbnail images.
PictBridge™ Compatibility
The DSC-S600 connects easily to any
PictBridge™ compatible printer with the
supplied USB cable, so you can print
directly from your camera.6 You can view
images and make print selections right on
the camera’ s LCD screen -- with simple
menus for print quality, date and index print.
DSC-S600
Cyber-shot® digital still camera
Specifications
General
Megapixel: 6.0 MP
Imaging Device: 1/2.5" Super HAD™ CCD
Recording Media: 32MB1 internal Flash
Memory, optional Memory Stick® DUO
Media, optional Memory Stick DUO
PRO™ Media
Convenience
White Balance: Automatic, Cloudy,
Daylight, Fluorescent, Incandescent
Self Timer: Yes (10 Seconds)
Memory Stick PRO™ Media
Compatibility: Tested to support up to
2GB Memory Stick DUO PROTM media
capacity1 ; does not support Access
Control security function
Still Image Mode(s): Burst, JPEG
(Fine/Standard), Multi-Burst
Red-Eye Reduction: Yes (On/Off)
Movie Mode(s): MPEG VX Fine with Audio
(640x480 at 30fps) (MPEG VX Fine
requires Memory Stick DUO PRO™
media), MPEG VX Standard with Audio
(640x480 at 16fps), Video Mail with Audio
(160x112 at 8fps)
Burst Mode: 7 Shot at 1.25 fps (6MP JPEG
fine), 100 Shot VGA at 1.43 fps (JPEG
std.)
Power Save Mode: Yes (after approx. 3
min. of inactivity)
Erase/Protect: Yes/ Yes
Date/Time Stamp: No/ No
Media/Battery Indicator: Yes/ Yes
Picture Effect(s): Black & White, Sepia
Scene Mode(s): Beach, High Sensitivity,
Landscape, Snow, Soft Snap, Twilight,
Twilight Portrait
Inputs and Outputs
Accessory Terminal: N/A
Audio/Video Output(s): N/A
Input(s): N/A
USB Port(s): Yes (Supports USB 2.06 )
Aperture: f2.8-f6.3 (W), f5.1-f11 (T)
Aperture Range: Auto, (f2.8-f11)
Focal Distance: 4-3/4" (12 cm) (W), 19
3/4" (50cm) (T)
Focal Length: 5.1-15.3mm
Focus: 5 Area Multi-Point AF, Center AF
ISO: Auto, 80, 100, 200, 400, 800, 1000
Shutter Speed: 1/8-1/2000 sec. (Auto), 11/2000 sec. (Program Auto) , 1-1/2000
sec.
Filter Diameter: N/A
Macro Mode: Auto Macro
EV Compensation: ±2.0 EV, 1/3 EV Steps
Power
Battery Type: "AA" NiMH, "AA" Alkaline
Battery Capacity: N/A
Service and Warranty Information
Limited Warranty: 1 Year Parts & Labor
Software
Supplied Software: Cyber-shot® Viewer
Vers 1.0 + USB Driver, (Windows®)
Operating System Compatibility:
Microsoft® 2000 Professional, Me, XP
Home and Professional; Macintosh® OS
9.1/9.2/OS X (10.0-10.4)
Video
Hybrid Record Mode: N/A
Dimensions
Weight: 4.7 oz (133 g) Body; 6.4 oz. (181
g) including Battery and optional Memory
Stick® DUO Media
Measurements: 3 15/16" x 2" x 1
7/16" (99.9 x 52 x 36.8 mm)
Supplied Accessories
“ AA” Type One-use Alkaline Batteries (x2)
USB Cable
Wrist Strap
Software CD-ROM
NOTE: No Memory Stick® DUO media or
adapters are included.
Optional Accessories
Hardware
Total Zoom: 6X
Optical Zoom: 3X
Digital Zoom: 0-2.0X (Precision)
Smart Zoom® Technology: 0-13X4 (at
Cyber-shot® Starter Kit (ACC-CN3TR)
Rechargeable NiMH Batteries - 2pk (NHAA-2DB)
External Slave Flash w/ Bracket (HVLFSL1B)
Soft Carrying Case (LCS-WA, LCS-CSD,
LCS-CP2)
Memory Stick Duo™ Media (MSH-128A)
Memory Stick PRO Duo™ Media (MSX256S)
Memory Stick PRO Duo™ Media (MSX512S)
Memory Stick PRO Duo™ Media (MSX1GS)
Memory Stick PRO Duo™ Media (MSX1GN)
Memory Stick PRO Duo™ Media (MSX2GN)
Memory Stick PRO™ Media USB Adaptor
(MSAC-US30)
Multi-slot Memory Stick® Adaptor (MSACUSM1)
VGA Resolution)
35mm Equivalent: 31-93mm
Color: Silver
UPC Code: 027242678187
LCD: 2.0"2 (85K Pixels TFT LCD Screen)
Viewfinder: Optical
Lens Construction: 7 Elements in 6
Groups, 3 Aspheric Elements
Microphone/Speaker: Yes/Yes
Lens Type: Carl Zeiss® Vario-Tessar®
Docking Station: N/A
Operating Conditions
Flash Effective Range: ISO Auto: 6” to
23’ (0.2-7.0m)(W)
ISO 1000: 2’ 7” to 36’ (0.8-11.0m)(W)
Flash Mode(s): Auto, Forced, Off, Slow
Synchro
Optics
1: A portion of the memory is used for data management purposes; approx. 30 MB is available for image
recording.
2: Viewable area, measured diagonally.
3: Under average conditions; when fully charged, actual results may vary based on camera settings and
conditions of use.
4: Smart Zoom feature will not work at highest resolution setting.
5: Memory Stick DUO PRO™ Media compatibility: tested up to 2 GB media capacity; a portion of the memory is
used for data management purposes. Actual available memory for storage purposes is 1.85 GB.
6: Not all products with USB connectors may communicate with each other due to chip-set variations
Sony, Cyber-shot, Handycam, Memory Stick DUO, Memory Stick DUO PRO, Real Image Processor, Super
HAD, Stamina, Trinitron and Walkman are trademarks of Sony.
Please visit the Dealer Network for more information at
www.sony.com/dn
Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1-800-222-7669 • www.sony.com
Last Updated: 01/30/2006
