Volume 3 - BRK Electronics
Product Catalog
Electrical Distributor
Volume 3
SECURITY CAMERAS
CAMERA FEATURES
2
WHY FIRST ALERT SECURITY CAMERAS?
Over 50 Years of Safety and Security Experience
For more than half a century, BRK Brands, Inc. has made the home-safety and
security products that make your job easier. These products are marketed under
the First Alert and BRK brand names. Our products are built to the highest
standard which has earned the company a leadership role in the home-safety
and security product categories. We are committed to serving our customers,
from you, the professionals who install our products, to the families who count
on them.
First Alert/BRK has introduced a line of Security Cameras targeted towards the
small business owner and high-end residential market. Until now, your customer’s
options have been limited. Spend thousands on the design, installation and
maintenance of complicated security systems or sacrifice quality and features for
other entry level systems. First Alert Security Cameras have all of the important
features your customers need for their small to medium security monitoring
requirements.
First Alert Quality Features:
•
•
•
•
•
•
•
Complete packages - Easy to install kits
No installation or monthly maintenance fees
Indoor/outdoor cameras with night vision
DVR recording systems with large expandable storage capacities
Advanced features in the BRK-Series product line
Wired and wireless kits for added versatility
Internet/mobile phone ready on many systems
Perfect for:
High-end Residential - New or Remodel
Light Commercial
Small Business/Retail
Small Warehouse
How many locations do you need to protect?
First Alert Security Camera systems are available in systems that can accommodate
up to 16 cameras. For most residential and small business applications this is sufficient
for covering a front and rear entrance along with several inside locations like the
cash register, storage area, key warehouse locations or residential interior rooms.
Wired or Wireless?
Wired Systems: Wired systems provide the most secure camera monitoring and are
perfect for new construction or anywhere access to an open cable run is available.
In addition, the wired systems supply power to the cameras from the cable so no
electrical outlets are required near each camera.
Wireless Systems: First Alert wireless systems operate on a secure 2.4 GHz digital signal
using frequency hopping spread spectrum (FHSS) technology. This FHSS technology
is highly resistant to narrowband interference and is difficult to intercept. However,
as with any wireless transmission, it can be subject to interference, interception or
jamming under certain conditions. Wireless signals can be significantly reduced
depending on the structures the signal must go through. Concrete, copper and metal
pipes and heating ducts tend to reduce the signal length. In addition, the camera
needs to be plugged in to a 120V outlet near the camera. If no outlets are available
they will need to be installed first.
What is the maximum distance you need to cover?
Longer runs may require an upgrade to RG59 CCTV Coax cable. First Alert kits ship
with economical AV cable that is designed to work well up to the length of cable
provided, usually around 60 feet. If longer distances between camera and DVR are
required, you will need to upgrade to RG59 Coax cable. We provide several lengths
up to 300 feet. In addition, if you need to run cable for in-wall installations, then you
may require fire rated cable, FT-4/CMR UL approved for in-wall installations.
Do you need to monitor your system remotely?
All of our wired and some wireless systems have the capability of being monitored
using an internet connection. Remote access is available via your PC or Mac
computer or via a smart phone through software provided or downloaded from your
smartphone app store. Access ranges from all DVR functions to just remote viewing
of the live view feed depending on the model.
HOW TO CHOOSE
HOW TO CHOOSE YOUR CAMERA SYSTEM
Do you need audio surveillance?
Our wireless systems and some of our wired cameras have the capability of audio
surveillance and recording. Be aware that audio surveillance in some states is illegal
or requires permission from one or both parties to record someone’s voice. Laws are
also different from residential vs. commercial applications. Be sure to check with state
or local authorities in your area for laws that may affect your installation.
3
WIRED RECORDING KITS
WIRED RECORDING KITS
H.264 Digital 8 and 16 Channel
Color DVR Camera Systems
1.0TB
H.264
VIDEO
COMPRESSION
DIGITAL DVR
RECORDER
MOBILE PHONE/
WEB READY
DVR OPTIMIZED
SATA HDD
INDOOR/OUTDOOR
600 TVL CAMERAS
NIGHT
VISION
AUTO IR
CUT FILTER
COLD TEMP
PERFORMANCE
• Real hexaplex operation - simultaneous record, playback, mobile phone live view, backup, control, &
remote access
• 16 bit true color user friendly graphical interface
• Web-ready & mobile phone compatible
• Advanced H.264 video compression for maximum storage efficiency
• Large 1TB Hard Drive installed for extended data storage (can expand up to 2TB)
• Easy power connections with 9-way power splitter - eliminates need for individual camera power supplies
• Alarm and PTZ Inputs for added flexibility and control
• Cameras
• 600TVL Color CMOS Cameras included for clear resolution (SKU# PRO-CM600)
• Indoor/outdoor (IP66 rating) with 36 IR LED’s, 80’+ night vision
• Auto IR Cut Filter for truer daytime colors
• Cable Safe Bracket – Protects cable from vandalism
• Cold temp performance: -22°F to 122°F temp range • Monitor
• Display Size: 18.5” (16:9) LED SLIM
• Display Type: Active matrix TFT
• Dynamic Contrast Ratio: 5,000,000:1
• Pixel Pitch: 0.239
• Resolution: 1366 x 768 @ 60Hz
• Response Time: 2mS
Available Kits:
BRK Series
PRO-DC881060019
8 Channel System with 18.5” LED Display and 8 Cameras
Includes: PRO-D810 DVR System, 18.5” LED Display, 8 PRO-CM600 Cameras, remote control, USB mouse, 60 ft.
AV BNC/DC Power Cable per camera, Power Supplies (cameras, monitor and DVR), 9-way Power Splitter Cable, 6’
Ethernet cable, Camera Mounting Hardware, 2 Warning Decals, Quick Install Guide (English), Mini CD with English
and Spanish Manuals and Install Software.
4
PRO-DC8810-600
BRK Series
8 Channel System with 8 Cameras
Includes: PRO-D810 DVR System, 8 PROCM600 Cameras, remote control, USB mouse,
60 ft. AV BNC/DC Power Cable per camera,
Power Supply (cameras and DVR), 9-way Power
Splitter Cable, 6’ Ethernet cable, Camera
Mounting Hardware, 2 Warning Decals, Quick
Install Guide (English), Mini CD with English and
Spanish Manuals and Install Software.
PRO-DC8410-600
BRK Series
8 Channel System with 4 Cameras
Includes: PRO-D810 DVR System, 4 PRO-CM600
Cameras, remote control, USB mouse, 60 ft.
AV BNC/DC Power Cable per camera, Power
Supply (cameras and DVR), 9-way Power Splitter
Cable, 6’ Ethernet cable, Camera Mounting
Hardware, 2 Warning Decals, Quick Install
Guide (English), Mini CD with English and
Spanish Manuals and Install Software.
DVR’s only:
PRO-D810
8 Channel DVR System
BRK Series
PRO-D1610
16 Channel DVR System
DVR Only Kits Include: DVR System, remote control, USB
mouse, Power Supply, 6’ Ethernet cable, 2 Warning
Decals, Quick Install Guide (English), Mini CD with English
and Spanish Manuals and Install Software.
Back Panel Configurations:
PRO-D810 Back Panel Connections/Ports:
8 BNC in, 8 Audio in, 1 VGA out, 1 BNC Main
out, 1 audio out, LAN port, DC power in, PTZ/
Alarm Block: 8 Alarm in, 1 Alarm out (NO,
Common and Ground), RS485A & RS485B PTZ
connections, 2 additional ground and +12 power.
Note: 1 USB port, 1 USB Mouse on front panel.
PRO-D1610 Back Panel Connections/Ports:
16 BNC in, 2 Audio in, 1 audio out, 1 VGA out, 1
BNC Main out, LAN port, DC power in, PTZ/Alarm
Block: 4 Alarm in, 2 Alarm out (NO, Common), 2
RS485A & RS485B PTZ connections, 5 ground and
one +12 power. Note: 1 USB port, 1 USB Mouse
on front panel. Note: 1 USB port, 1 USB Mouse on
front panel.
WIRED RECORDING KITS
WIRED RECORDING KITS/DVR’s
5
WIRED SURVEILLANCE
6
WIRED SURVEILLANCE
PRO-CM600
600TVL Wired CMOS Color Camera
• Indoor/outdoor color camera (IP66 rating)
• 600 TV lines for clear resolution
• 36 IR LED’s for a minimum of 80’ Night Vision distance
• Metal Housing
• Auto IR Cut Filter for truer daytime colors
• Cable Safe Bracket – Protects cable from vandalism
• Cold temp performance: -22°F to 122°F temp range
• Dimensions: 3.25”H x 2.88”W x 6.25”D
Includes:
1 Camera, 60 ft. AV BNC/DC Power Cable, Power Supply, Camera Mounting Hardware,
Manual.
INDOOR/OUTDOOR
600 TVL CAMERA
NIGHT
VISION
AUTO IR
CUT FILTER
BRK Series
COLD TEMP
PERFORMANCE
PRO-CMD600
600TVL Dome Wired CMOS Color Camera
• Indoor color dome camera
• 600 TV lines for clear resolution
• 32 IR LED’s for a minimum of 80’+ Night Vision distance
• Plastic Housing
• 14°F to 122°F temp range
• Dimensions: 3.625 Dia x 2.69” H
Includes:
1 Camera, 60 ft. AV BNC/DC Power Cable, Power Supply, Camera Mounting Hardware,
Manual.
BRK Series
INDOOR
600 TVL CAMERA
NIGHT
VISION
AUTO IR
CUT FILTER
PRO-CM520
520TVL Wired CMOS Color Camera
• Indoor/outdoor color camera (IP65 rating)
• 520 TV lines for clear resolution
• 30 IR LED’s for a minimum of 80’ Night Vision distance
• Metal Housing
• Dimensions: 5.5”H x 3.68”W x 3.63”D
Includes:
1 Camera, 60 ft. AV BNC/DC Power Cable, Power Supply, Camera Mounting
Hardware, Manual.
BRK Series
INDOOR/OUTDOOR
520 TVL CAMERA
NIGHT
VISION
PRO-CMD520
520TVL Dome Wired CMOS Color Camera
• Indoor color dome camera
• 520 TV lines for clear resolution
• 32 IR LED’s for a minimum of 80’+ Night Vision distance
• Plastic Housing
• Dimensions: 3.625 Dia x 2.69” H
Includes:
1 Camera, 60 ft. AV BNC/DC Power Cable, Power Supply, Camera Mounting Hardware,
Manual.
BRK Series
INDOOR
520 TVL CAMERA
NIGHT
VISION
P-500
Mini Indoor Wired Analog Color Camera
• Discrete placement and surveillance
• Compact size can easily be positioned anywhere
• Indoor color camera with built-in microphone
• 380 TV lines
• Dimensions: 1.5”H x 1.2”W x 1.2”D
WIRED SURVEILLANCE
WIRED SURVEILLANCE
Includes:
1 Camera, 18 ft. AV/Power cable, Power Supply, Camera Mounting Hardware,
Manual.
Compact Size
1-1/2” high
DISCRETE PLACEMENT
& SURVEILLANCE
INDOOR
380 TVL CAMERA
AUDIO
SURVEILLANCE
7
WIRED SURVEILLANCE
WIRED SURVEILLANCE
PRO-CDH480
480TVL Heated CCD Color Camera
• 1/3” Sony Super HAD CCD image sensor
• Indoor/outdoor Heated Camera with Fan (IP65 rating)
• 480 TV lines for clear resolution
• 30 IR LED’s: 130’ Night Vision distance
• Dimensions: 11.50”H x 5.50”W x 13.50”D
Includes:
1 Camera, Power Supply, Camera Mounting Hardware, Manual.
(Note: Requires RG59 Coax Video/DC Power Cable, not included)
Special Order
INDOOR/OUTDOOR
480 TVL CAMERA
NIGHT
VISION
BRK Series
PRO-CDP480
Mini PTZ Wired CCD Color Camera
• 1/3” Sony Interline Transfer CCD image sensor
• Indoor/outdoor with shockproof and weatherproof cover, builtin fan and heater (IP65 Rating)
• Pan 360° Tilt 180° (Auto-Flip), Max 360°/sec
• Built-in 10*10X Zoom with invert image
• 480 TV lines for clear resolution
• Dimensions: 8.0”H x 6.0”W x 8.5”D
Includes:
1 Camera, Power Supply, Camera Mounting Hardware, Manual.
(Note: Requires RG59 Coax Video/DC Power Cable, not included)
INDOOR/OUTDOOR
480 TVL CAMERA
NIGHT
VISION
Special Order
BRK Series
PRO-CD550
550TVL Wired CCD Manual Zoom
Color Camera
• 1/3” Sony Super HAD CCD image sensor
• 4mm - 9mm Manual Zoom Lens
• Indoor/outdoor Camera (IP66 rating)
• 550 TV lines for clear resolution
• 42 IR LED’s: 100’ Night Vision distance
• Dimensions: 5.00”H x 4.00”W x 10.25”D
Includes:
1 Camera, Power Supply, Camera Mounting Hardware, Manual.
(Note: Requires RG59 Coax Video/DC Power Cable, not included)
Special Order
8
INDOOR/OUTDOOR
550 TVL CAMERA
NIGHT
VISION
BRK Series
PRO-DC2
Aluminum Box Decoy Camera
• Battery operated flashing LED light
• Indoor/outdoor (IP44 rating)
• Non-functioning video camera
• Requires 2 AA batteries (not included)
• Aluminum and ABS plastic (12.875”D x 4.25”W x 12.75”H)
Includes:
1 Camera with stand, Camera Mounting Hardware, Manual.
BRK Series
INDOOR/OUTDOOR
PRO-DC3
Dome Decoy Camera
• Motion activated flashing LED light
• Indoor/outdoor
• Non-functioning video camera
• Requires 2 AA batteries (not included)
• ABS plastic (4.63”Dia. x 2.88”H)
Includes:
1 Camera, Camera Mounting Hardware, Manual.
BRK Series
MOTION
ACTIVATED
INDOOR/OUTDOOR
PRO-DC4
Mini Dome Decoy Camera
• Battery operated flashing LED light
• Indoor/outdoor
• Non-functioning video camera
• Requires 2 AA batteries (not included)
• ABS plastic (3.74”Dia. x 2.75”H)
DECOY CAMERAS
DECOY CAMERAS
Includes:
1 Camera, Camera Mounting Hardware, Manual.
BRK Series
INDOOR/OUTDOOR
PRO-DC5
Barrel Decoy Camera
Tip:
Decoy Ca
m
deterren eras act as a gre
at
t if you d
on’t have
function
ing came
ras or th
can mak
ey
e your li
ve system
seem to
be more
extensive
.
• Low light activated flashing LED light
• Indoor/outdoor (IP44 rating)
• Non-functioning video camera
• Requires 2 AAA batteries (not included)
• Aluminum (5.64”D x 2.28”W x 3.22”H)
Includes:
1 Camera with stand, Camera Mounting Hardware, Manual.
BRK Series
LOW LIGHT
ACTIVATED
INDOOR/OUTDOOR
99
WIRELESS RECORDING KITS
10
WIRELESS RECORDING KITS
DWH-Series DVR
(DWH-471, DWH-472)
2.4 GHz Digital Wireless Color DVR with 7” LCD
Touch Screen & Internet Access via Smart Phone
• 4 channel H.264 recording system
• Internet access via Smart Phone
• 2.4 GHz secure digital signal using
frequency hopping spread spectrum
(FHSS) technology
• Indoor/outdoor night vision color camera (IP66 rating)
• Auto IR Cut Filter for truer daytime
colors
• Audio surveillance with Mute
• Wireless transmission up to 500 ft. line of sight
• 4GB SD card included, up to 32GB SD/SDHC compatible
• Expandable up to a total of four DWH-400 cameras
TOUCH
SCREEN
TOUCH
SCREEN
TÁCTI PORTÁTIL
Includes:
DWH-471: 1 camera, DWH-472: 2 Cameras,
2.4 GHz wireless DVR recording system with
7” LED Touch Screen, Docking Cradle, 4GB SD
card, RJ-45 Ethernet cable (6’), power supplies, camera stand & mounting hardware, 2
Window Warning Decals, English Manual, CD with English and Spanish manuals (pdf).
Internet access via Smart Phone
H.264
VIDEO
COMPRESSION
AUTO IR
CUT FILTER
7” LCD
TOUCH SCREEN
AUDIO
SURVEILLANCE
4GB
SD CARD
INCLUDED
MOBILE PHONE
READY
INDOOR/OUTDOOR
CAMERAS
NIGHT
VISION
Note:
legal or it
ates it is il
In some st
om one or
fr
mission
er
p
e’s
es
ir
u
req
rd someon
es to reco
h
it
w
both par ti
k
re to chec
voice. Be su authorities in your
l
ca
state or lo
ay affect
ws that m
area for la
llation
your insta
DWH-400
2.4 GHz Digital Wireless Color Camera
• Add-on Camera for DWH-Series DVR
• 2.4 GHz secure digital signal using frequency hopping spread spectrum
(FHSS) technology
• Indoor/outdoor color camera (IP66 rating)
• Auto IR Cut Filter for truer daytime colors
• 25 IR LED’s fpr 60’ night vision distance
• Audio surveillance
• Wireless transmission up to 500 ft. line of sight
• Dimensions: 8.0”H x 2.8”W x 4.8”D
Includes:
2.4 GHz wireless Color Camera, power supply, camera stand & mounting hardware, English Manual, CD
with English and Spanish manuals (pdf).
AUTO IR
CUT FILTER
INDOOR/OUTDOOR
AUDIO
CAMERA
SURVEILLANCE
NIGHT
VISION
DWS-Series DVR
(DWS-401, DWS-471 & DWS-472)
2.4 GHz Digital Wireless Color DVR with 7” LCD Screen
DWS-471 and DWS-472
• 4 channel MPEG-4 recording system
• 2.4 GHz secure digital
signal using frequency
hopping spread spectrum
(FHSS) technology
• Indoor/outdoor night vision
color camera (IP66 rating)
• Auto IR Cut Filter for truer daytime colors
• Audio surveillance with Mute
• Wireless transmission up to 500 ft. line of sight
• 4GB SD card included, up to 32GB SD/SDHC compatible
• Expandable up to a total of four DWC-400 cameras
DWS-401
Includes:
DWS-401: 1 DWC-400 camera, 2.4 GHz wireless DVR recording system (no LED display), 1 BNC to
RCA connector:
DWS-471: 1 DWC-400 camera, 2.4 GHz wireless DVR recording system with 7” LED display
DWS-472: 2 DWC-400 cameras, 2.4 GHz wireless DVR recording system with 7” LED display:
and 4GB SD card, AV cable, power supplies, camera stand & mounting hardware, 2 Window Warning Decals,
English Manual, CD with English and Spanish manuals (pdf).
MPEG-4
VIDEO
COMPRESSION
7” LCD
SCREEN
4GB
MICRO SD
CARD INCLUDED
AUDIO
SURVEILLANCE
INDOOR/OUTDOOR
CAMERAS
NIGHT
VISION
DWC-400
2.4 GHz Digital Wireless Color Camera
• Add-on Camera for DWS-Series DVR
• 2.4 GHz secure digital signal using frequency hopping spread spectrum
(FHSS) technology
• Indoor/outdoor color camera (IP66 rating)
• Auto IR Cut Filter for truer daytime colors
• 25 IR LED’s fpr 60’ night vision distance
• Audio surveillance
• Wireless transmission up to 500 ft. line of sight
• Dimensions: 8.5”H x 2.75”W x 6.2”
Includes:
2.4 GHz wireless Color Camera, power supply, camera stand & mounting hardware, English
Manual, CD with English and Spanish manuals (pdf).
INDOOR/OUTDOOR
AUDIO
CAMERA
SURVEILLANCE
NIGHT
VISION
WIRELESS RECORDING KITS
WIRELESS RECORDING KITS
11
WIRELESS RECORDING KITS
12
WIRELESS RECORDING KITS
DWB-740
Indoor 2.4GHz Digital Wireless Family
Surveillance Camera & 2.5” LCD Monitor
• 4-channel digital wireless recording system
• VOX voice activated recording
• 2.4 GHz secure digital signal using frequency hopping spread
spectrum (FHSS) technology
• Indoor night vision color camera with audio surveillance
• Wireless transmission up to 750 ft. line of sight
• 3 Musical Lullabies, Playing Time 5 - 7 Minutes Each
• 2GB SD card included, up to 32GB SD/SDHC compatible
• Expandable up to a total of four DWB-700 cameras
Includes:
2.5” Monitor/Receiver, 1 digital wireless camera, 2GB SD card, power supply, camera
stand & mounting hardware, manual.
2.5” LCD
SCREEN
INDOOR
CAMERA
2GB
MICRO SD
CARD INCLUDED
AUDIO
SURVEILLANCE
NIGHT
VISION
DWB-700
Indoor 2.4GHz Digital Wireless Camera
• 2.4 GHz secure digital signal using frequency hopping spread
spectrum (FHSS) technology
• Indoor night vision color camera with audio surveillance
• Wireless transmission up to 750 ft. line of sight
• Use with First Alert DWB-740 family surveillance kit
Includes:
1 digital wireless camera, power supply, camera stand & mounting hardware, manual.
INDOOR
CAMERA
AUDIO
SURVEILLANCE
NIGHT
VISION
Tip:
Perfect
f
Lightin or placement
g Show
in
rooms
at the
or
counte
r
impuls
e sales. area for
BNC-50, BNC-100, BNC-300
RG59 CCTV COAX VIDEO & DC POWER CABLES
• Combined video and DC power in one cable
• Solid copper conductor for less voltage drop and
better signal over longer distances - easier to
handle
• Double shielded with copper clad aluminum braiding
• BNC Male connections on video cable and
1 jack male, 1 plug female on DC power
cable (2.1mm I.D./5.5mm O.D.)
• Two adaptor plugs provided to extend
lengths
• 50’ (BNC-50), 100’ (BNC-100) and 300’
(BNC-300) lengths
Notes:
BNC-50: 50’ cable, BNC-100: 100’ cable, BNC-300: 300’ cable.
grade
s? Up able
n
u
r
Tip:
AX c
longer
Need 9 CCTV CO ver
o
5
l
to RG tter signa
e
b
a
ces
for
distan
longer
ACCESSORIES
ACCESSORIES
BNC-100F
RG59 FIRE RATED CCTV COAX VIDEO & DC POWER CABLE
Same features as above plus:
• FT-4/CMR UL approved for in-wall installations
• 100’ length
YS-1
FIRST ALERT SIGN
• Inform potential intruders your premises are under 24 hour surveillance with First Alert security cameras
• Indoor/outdoor use
• Includes sign, post and (4) anti-theft deterrent stickers
13
CAMERA KNOWLEDGE
CAMERA KNOWLEDGE
RECORDING TIME CAPACITIES (H.264)
Recording Times for NTSC Video Format @ 30 Frames/Second
For 1TB Hard Drive
Resolution
Video
Quality
Bit Rate
(Kbps)
Space Used
(MB/h)
# Hours/
Channel
# of Days/
Channel
# of Days
w/ 8
Channels
CIF
Low
384
172.8
5,787.0
241.1
30.1
Medium
512
230.4
4,340.3
180.8
22.6
High
768
345.6
2,893.5
120.6
15.1
Low
512
230.4
4,340.3
180.8
22.6
Medium
768
345.6
2,893.5
120.6
15.1
High
1,024
460.8
2,170.1
90.4
11.3
Low
896
403.2
2,480.2
103.4
12.9
Medium
1,024
460.8
2,170.1
90.4
11.3
High
1,280
576.0
1,736.1
72.4
9.0
HD1
D1
Total Recording Capacity = Used space per hour (MB/h) x Recording time (hour) x number of
channels
RECORDING TIME CAPACITIES (M-JPEG)
SD Card
Capacity
320 x 240
(QVGA)
640 x 480
(VGA)
1,280 x 720
(HD)
1GB
29 min 30 sec
10 min 40 sec
2 min
2GB
1h
21 min 40 sec
8 min 20 sec
8GB
4 h 1 min
1 h 27 min
33 min 33 sec
16GB
8 h 5 min
2 h 55 min
1 h 7 min
32GB
16 h 14 min
5 h 51 min
2 h 15 min
RECORDING TIME CAPACITIES (SD Card)
SD Card
Capacity
Single Camera
(480 x 272 )
Multiple Cameras
(320 x 240 QVGA)
1GB
200 Minutes (3.3 hours)
130 Minutes (2.2 hours)
2GB
400 Minutes (6.7 hours)
260 Minutes (4.3 hours)
8GB
1,600 Minutes (26.7 hours)
1,040 Minutes (17.3 hours)
16GB
3,200 Minutes (53.3 hours)
2,080 Minutes (34.7 hours)
32GB
6,400 Minutes (106.7 hours)
4,160 Minutes (69.3 hours)
Note: All numbers are approximate and are for estimating only. Many factors influence
actual storage capacities including size of data, quality, aspect ratio and compression used.
14
INGRESS PROTECTION (IP RATINGS)
The IP rating is used to specify the strength of the enclosure that surrounds electronic equipment and is
determined by specific tests. Each IP rating consists of using two separate measures. The first is protection
against solids; the second number is protection against liquids. So therefore an IP rating of 65 is totally
protected against dust and is protected against low pressure jets of water from all directions with limited ingress
permitted.
IP Ratings
Level of Protection against solid objects,
materials or dust
Level of Protection against water or liquids
0
No protection
0
No protection
1
Protected against solid objects down to
50 mm
1
Protection against vertically falling drops of water (e.g.
condensation)
2
Protected against solid objects down to
12 mm
2
Protection against direct sprays of water up to 15
degrees from vertical
3
Protected against solid objects down to
2.5 mm
3
Protection against direct sprays of water up to 60
degrees from vertical
4
Protected against solid objects down to
1 mm
4
Protection against water sprayed from all directions –
limited ingress permitted
5
Protected against dust, limited ingress
(no harmful deposit)
5
Protected against low pressure jets of water from all
directions – limited ingress permitted
6
Totally protected against dust
6
Protected against low pressure jets of water, limited
ingress permitted (e.g. ship deck)
7
Protected against the effect of immersion between
15cm and 1m
8
Protected against long periods of immersion under
pressure
MECHANICAL PROTECTION (IK RATINGS)
The IK rating is an international numeric classification (EN/IEC 62262) for the degrees of protection provided
by enclosures for electrical equipment against external mechanical impacts. For cameras this can be a measure
of vandal resistance of the housing. Not all cameras have an IK rating. This mechanical impact is identified by
the energy needed to qualify a specified resistance level, which is measured in joules (J).
IK Code
IK Code
Impact energy (joules)
Equivalent impact
00
Unprotected
01
0.15
Drop of 200 g object from 7.5 cm height
02
0.20
Drop of 200 g object from 10 cm height
03
0.35
Drop of 200 g object from 17.5 cm height
04
0.50
Drop of 200 g object from 25 cm height
05
0.70
Drop of 200 g object from 35 cm height
06
1.00
Drop of 500 g object from 20 cm height
07
2.00
Drop of 500 g object from 40 cm height
08
5.00
Drop of 1.7 kg object from 29.5 cm height
09
10.00
Drop of 5 kg object from 20 cm height
10
20.00
Drop of 5 kg object from 40 cm height
No test
CAMERA KNOWLEDGE
CAMERA KNOWLEDGE
15
CAMERA KNOWLEDGE
16
CAMERA KNOWLEDGE
CCTV COAX CABLE CONSTRUCTION
Not all coax cables are created equally. You do not want to use CATV RF coax video cable used for
standard cable TV installations for your CCTV installation. This CATV cable can cause video distortion
and excessive loss of video strength because of the copper-covered steel core and aluminum braiding.
First Alert’s RG59 CCTV Baseband/composite coax video and DC power cables use a solid copper
conductor for less voltage drop and better signal over longer distances. This also makes the cable easier
to handle versus other lower quality copper clad steel cables as it is less rigid and will not remain coiled.
In addition, the cables are double shielded with copper clad aluminum (CCA) braiding to help protect
the video signal from interference. This offers an economical alternative to a solid copper braiding
shield while still meeting industry standard requirements. Runs can be made up to 600ft without video
performance loss.
Each cable comes with BNC Male connections on each end of the video cable and 1 jack male, 1 plug
female on the ends of the DC power cable (2.1mm I.D./5.5mm O.D.). We also supply two adaptor
plugs for your convenience. One is a BNC female to BNC female adaptor to provide a way to connect
two lengths of cable together. The other is a BNC Female to RCA male connector to attach cable to a TV
RCA female (Yellow Video in) input. In addition, we offer cable that is fire rated FT-4/CMR UL approved
for in-wall installations. All of these features ensure your customers of the highest quality installation.
Jacket: Ø6.0 ± 0.1mm
60P white jacket PVC
Braid: 16/8/0.12mm CCA
Jacket: Ø5.0 x 3.4 ± 0.1mm
60P white jacket PVC
Wrap: 14mm Aluminum foil
PE Insulation: Ø1.8 mm± 0.05mm
red, black HDPE5502+LDPE N150
Froth PE: Ø3.8 ± 0.1mm
PE(HDPE+LDPE)
Conductor: 7/0.38mm CCA
Conductor: 1/0.78mm bare copper
INFRARED (IR) LIGHT AND ITS EFFECT ON
COLOR SECURITY CAMERAS
Color security cameras that feature night vision use IR LED’s to illuminate the area. The infrared region
of the color spectrum is not visible to the human eye, but is visible to night vision security cameras.
Many light sources including the sun emit infrared light. Unfortunately, infrared light in the daylight
to a security camera sometimes results in strange colors. The color spectrum to the naked eye can
seem to shift, causing for example, the grass to look white or pink. To get around this problem some
cameras contain a special component which filters out infrared light. This gives a high quality image
with truer daytime colors. This component is called an IR cut filter. However, having a permanent filter
in the camera renders it useless if we want to monitor in the dark using infrared light. Therefore, some
cameras feature an automatic IR cut filter to move over or away from the lens when appropriate.
No IR cut filter during daylight
IR cut filter added during daylight
CONNECTING FIRST ALERT WIRELESS
CAMERAS TO WIRED DVR SYSTEMS
Connecting First Alert wireless cameras to our wired DVR systems or other wired DVR systems is very easy.
More importantly, all of the features and recording options in the wired DVR such as schedule recording, mask
field, enhanced motion detect, remote internet and mobile phone access, e-mail alerts and alarm functions all
work as they should. In addition you get the benefit of a large hard drive for extended recording time.
To make the connection you will need a Male BNC to Female RCA adaptor.
This is used to allow the DWS-401 RCA cable to be connected to the BNC
Video In port on the back of the DVR. One adaptor is included in the
DWS-401 Kit. (See image at right).
Step 1: Install and pair the wireless camera to the DWS-401 receiver
as per instructions. Do not insert the SD card. All recording will be done
on the wired DVR. (Note: You must first connect the DWS-401 to a TV
or monitor in order to see the setup menu to pair the camera. Only the
camera video stream and not the setup menu is visible through the BNC
camera connection on the wired DVR.)
Step 2: Attach the BNC Male/RCA Female adaptor described in Step 1 to one of
the Video In BNC ports of the DVR.
Step 3: Connect the AV cable that ships with the DWS-401 to the AV Out port on the DWS-401 receiver. Then
connect the yellow RCA plug to the adaptor on the Video In Port you just installed in Step 2. (Nore: If recording
sound connect the White RCA plug to the Audio In port of the same number as the Video In port. Both port
numbers must be the same to sync the sound with the video image.) That’s it! You’re connected.
Step 4: Configure your recording settings on the wired DVR system.
Paired Wireless
Camera
Tip:
for every Video In
S-401 receiver
You need one DW
ries receivers
DVR. The DWS Se
d
re
wi
e
th
on
Port
eras per receiver.
of pairing 4 cam
e
have the capability
one Channel of th
four cameras in
g
in
rd
co
re
or
You can pair all
ion
ot
, however any m
e
Live View screen
eras will affect th
m
ca
s
les
re
wi
4
e
th
te
of
y
ra
an
pa
se
m
fro
cannot
one channel. You
.
en
re
sc
e
on
recording on the
as
. They record
as
er
m
ca
ur
be
fo
a
e
out thes
ly one camer
endation that on
p.
It is our recomm
r this type of setu
fo
r
ive
Series rece
paired per DWS
Wired DVR System
AV Cable from Wireless Receiver to
Video In 1 and Audio In 1
(Yellow to Video; White to Audio)
CAMERA KNOWLEDGE
CAMERA KNOWLEDGE
Male BNC/Female RCA adaptor
to Video In 1
17
COMPRESSION FORMATS
The foundation of these standards is JPEG, named after the group that developed
it in the mid-1980s, the Joint Photographic Experts Group. The first JPEG
standard was released in 1991. Another group of developers, in the late 1980s,
developed a standard for compressing moving pictures and audio - the Motion
Picture Experts Group, hence the name MPEG. MPEG-4 was released in 1998.
H.264/AVC (for advanced video coding), is the latest block-oriented motioncompensation-based codec standard developed by the ITU-T Video Coding
Experts Group (VCEG) together with the ISO/IEC Motion Picture Experts
Group (MPEG), and it was the product of a partnership effort known as
the Joint Video Team (JVT). The ITU-T H.264 standard and the ISO/IEC
MPEG-4 AVC standard (formally, ISO/IEC 14496-10 - MPEG-4 Part 10,
Advanced Video Coding) are jointly maintained so that they have identical
technical content. H.264 is used in such applications as Blu-ray Disc, videos
from You Tube and the iTunes Store, DVB broadcast, direct-broadcast
satellite television service, cable television services, and real-time video
conferencing. The standardization of the first version of H.264/AVC was
completed in May 2003. Version 13 was implemented in March 2010.
H.264 provides good video quality at substantially lower bit rates than previous standards. Basically
it compares compressed images using the first compressed image as a reference frame, then it sends
only the parts of the following images that differ from the reference image. This substantially lowers
the amount of data that needs to be transferred making it more attractive for video network delivery
and the delivery of HD video. H.264 is an open format and is available for anyone to implement.
M-JPEG is a picture compression format utilizing a video codec where each frame is separately
compressed into a JPEG image. The resulting quality of video compression is independent
from the motion in the image. Each individual image is a complete JPEG compressed image,
unlike H.264 which uses reference images. M-JPEG technology is simpler however uses more
storage space. As images are compressed, clarity can suffer. A balance needs to be drawn
at reducing image size and keeping the image clear. Latest versions of H.264 improve clarity.
M-JPEG is ideal for courtroom evidence, whereas H.264 could be challenged as every frame is
not a complete picture. However, due to its widespread use H.264 is becoming more accepted for
courtroom evidence, depending on what is being reviewed. Consulting the District Attorney or other
law enforcement authority before using any video format is highly recommended.
Compressed file size of H.264, MPEG-4 and M-JPEG
H.264
1%
MPEG-4
2%
M-JPEG
0
18
1
2
~
~
20%
20
~
~
CAMERA KNOWLEDGE
CAMERA KNOWLEDGE
100%
NOTES
NOTES
19
©2013 BRK Brands Inc.
a Jarden Corporation Company (NYSE: JAH)
3901 Liberty Street Road, Aurora, IL 60504-8122
Customer Service: 800-275-2576 Tech Services: 800-323-9005
All rights reserved.
First Alert is a registered trademark of the First Alert Trust
BRK is a registered trademark of BRK Brands, Inc.
CM3165
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
