DLP TV
TM
Experience perfect vision
Samsung’s DLP™ TV delivers unmatched brightness, contrast levels and color accuracy, plus full digital convergence and a host of top-notch
features. Its sleek design and lightweight construction also make this monitor the most attractive and versatile TV your home has
ever seen.
Shown: HLM617W, 61" DLP™ TV
DL P
TM
TV
Te c h n o l o g y
True harmony of design,
performance and value
HDTV monitor with DLP technology
TM
lay
icro-disp .
rs
gy is a m
technolo icroscopic mirro
™
LP
D
f
00 m
rt o
The hea integrates 921,6
at
panel th
Digital Light Processing (DLPTM) technology is found in leading digital cinemas
the world over. The heart of DLPTM technology is a micro-display panel no larger
than a postage stamp, which integrates 921,600 microscopic mirrors to deliver
eye-popping, high definition detail, color and clarity. Samsung applies the magic
of DLPTM technology to your home theater via its patented, compact optical engine
that replaces the large, heavy picture tubes found in direct-view sets. Best of
all, Samsung DLPTM TVs are lighter, more affordable and use far less power than
plasma TVs. Now you can enjoy the spine-tingling thrills of digital television in
a sleek, table-top design that’s significantly smaller, lighter and brighter than a
conventional projection TV. Samsung’s advanced convergence technologies also
make the Tantus series HDTV monitor compatible with your HDTV tuner, PC,
DVD, game console, VCR, camcorder, digital camera, and much more.
DL P
TM
TV
Te c h n o l o g y
Samsung optical engine
Samsung’s patented optical engine ensures maximum brightness, flicker-free video, detailed text and still images, and
a full 160-degree viewing angle. DLPTM micro-display technology and Samsung’s proprietary Bent Light Lens System
give you a big-screen TV without the big-screen hassle. Its ultra-slim, ultra-lightweight design lets you put it virtually
anywhere. And its optical engine is durable, long-lasting, and never needs calibrating.
➁
④
TM
DLP Panel
③
Digital Light Processing
① Light source – Samsung uses a 100-Watt Ultra-High-Pressure (UHP) lamp, which maintains uniform
brightness over its 8,000-hour life.* Replace the bulb after it expires, and the DLP™ performs like new again.
➁ Color wheel – The Samsung Color Management System™ (SCMS) uses a six-segmented wheel (two reds, two
greens, two blues) to create brilliant and accurate colors never before seen on a standard TV.
User-friendly, attractive,
intelligent TVs
③ DLP™ panel – Texas Instruments’ second-generation DLP™ chip comes closer than any other display
to reproducing an exact mirror image of its source material. The 921,600 mirrors on the DLP™ chip are less
than one micron apart, resulting in a seamless digital picture that's sharp at any size.
④ HD lens – Processed light reflected from the DLP™ Panel is projected and expanded by a lens specially
designed to handle the challenge of high-resolution images.
Micro Fine Pitch Screen – The brilliant images you see appear on a micro-fine pitch (0.155mm) screen with
anti-glare coating, which offers eye-popping clarity and a very wide viewing angle (160 degrees).
* HLM617W uses a 120-Watt/6,000 hour lamp.
DL P
TM
TV
P i c t u re
DigitAllclarity
DigitAllversatility
Virtually unlimited convergence
DLP TV delivers the perfect picture
TM
DLP™ technology is the only display solution that enables projection systems to create a purely digital connection
Samsung DLPTM TVs are multimedia-ready. They provide multiple sets of inputs and outputs to offer you maximum
between a digital video or graphic source and the screen in front of you.
flexibility to expand your home theater. They can handle your PC, DVD, game console, HDTV receiver, satellite dish,
Game
Console
camcorder and more. Plug-and-play has never been more convenient – just plug into the side or rear jacks, and the
TV automatically identifies your device. Add Samsung's versatile picture-in-picture (PIP) options, and you can surf the
Bringing detail to life
Camcorder
Web while watching TV.
>
VCR
Notebook
Great for watching TV, movies and sports.
Seamless and lifelike
(DLP TV)
TM
Grainy and pixellated
(Conventional TV)
Contrast ratio 1000:1
(DLP TV)
TM
Contrast ratio 600:1
(Conventional TV)
Lifelike picture
Brighter and clearer
The surface of the DLP™ panel is covered with almost a million micro-mirrors (1280 x 720),
At 400 cd/m2, DLP™ outshines other micro-display technologies for a bright, clear picture, with
that act as pixels. This incredibly high pixel count creates a striking, digital image with seamless
incredible contrast and color accuracy. Its unique optical engine preserves the intensity of the
resolution, amazing detail and brilliant, lifelike colors. And because the pixels are less than one
original image with vibrant colors and rich, deep blacks. Its high, 1000:1 contrast ratio makes
micron apart, you won’t notice the “screen door” effect apparent with other TVs.
for ideal color separation and crisp, detailed images. That’s why Samsung DLP™ is perfect
Crystal-clear text images allow your DLP TV
to double as a computer monitor.
TM
Set
Top
Box
DVD
• Two HD component inputs
• One DVD Input
• One PC Input
HD component video inputs
This enables the Tantus to receive any digital broadcast, whether from terrestrial sources, satellite receivers or cable.
For seamless connection to your favorite digital media, try Samsung's HDTV tuners.
for any source material that demands minute detail, such as HDTV, computer images and DVDs.
DVI HDTV interface
Ultra-smooth action
Consistent screen image
DVI input enables an all-digital rendering of video without the losses associated with an analog interface. DVI adds the
Samsung’s DLP™ micro-mirrors can switch on and off over 5,000 times a second – that’s up
The DLP™ TV is much more durable than competing technologies because the display doesn’t
quality and functionality of a digital interface, while maintaining the simplicity of supporting uncompressed video formats.
to ten times faster than other micro-displays. This allows DLP™ TV to smoothly and accurately
physically age or deteriorate. Its Ultra-High-Pressure lamp delivers consistent light output and
display fast-switching content like HDTV and DVD.
picture quality throughout its long lifespan.
HDTV Tuner
Digital Visual Interface
DL P
TM
TV
P i c t u re
DigitAllsensation
Film source
24 frames
30 frames
DVD
Sleek and lightweight design
→
30 frames
(Up-converts by
adding new 6 frames)
→
→
Cinema Progressive Scan and 3:2 Pull Down
The Cinema Progressive Scan enhancement automatically up-converts all non-digital signals
Artificial 60 frames
Natural 60 frames
to a smooth, clear 720 lines of progressive scan. The 3:2 pull down feature is a must for any
And unlike plasma TVs (costing nearly twice as much), no special mounting brackets,
during the transfer from film to video. These added frames cause blurring, stuttering and other
wiring or outlets are required. No other TV combines a brilliant picture, convenience,
motion artifacts, especially during fast-action sequences. 3:2 pull down eliminates them and
Interlaced
gives your DVDs a look and feel that’s much closer to film. Cinema Progressive Scan with 3:2
Progressive
pull down is powered by Faroudja’s patented DCDiTM video processing on Tantus models.
1280 x 720 progressive display quality
Samsung’s DLPTM TV gives you the best of all worlds. At less than 18" deep and under
78 lbs, you can put a 50", widescreen DLPTM TV in places you never thought possible.
Screen
movie enthusiast. It analyzes each frame of video, removing unclear frames that were added
DigitAllwow
Cinema Progressive
value, and “wow factor” like Samsung's DLPTM TV.
Note: Most DVD movies originate in 24-frames-per-second analog
film before being converted to 30-frames-per-second video.
DCDi Digital Processing by FAROUDJA
TM
Samsung delivers flicker-free, static images, thanks to its all-format conversion system.
DCDiTM (Directional Correlational Deinterlacing) is the highest-quality video processing for any video format
Progressive scan is a must for rock-steady text, still images and smooth action sequences.
(DVD movies, HDTV broadcasts, game consoles). It creates cinema-quality images, and adds vibrancy and
depth. Available on all Tantus models (HLM617W, HLM507W and HLM437W).
Sound Reality
Before Faroudja Processing
The Samsung DLPTM TV has four built-in speakers and a 30-Watt Virtual Dolby
Interlaced Scan
DLP
TM
TV 720P Progressive Scan
After Faroudja Processing
sound system. Tantus models incorporate Barkus Berry Electronics Sound Clarifying
technology, which creates more lifelike sound and clearer dialog.
As slim as 16 inches*
Wide viewing angle
Left side, right side or upside-down* – whatever your location, Samsung DLPTM TVs allow
you to see any display clearly, thanks to its 160-degree-wide viewing angle. Unlike traditional
projection TVs, the image doesn’t get darker as you move away from the center.
Decodes
De-interlaces
Enhances
Scales
Isolates the key elements
of the video signal and
removes picture jitter.
Removes scan lines and
motion artifacts with
line doubling.
Analyzes picture details
and improves the clarity
of the picture.
Optimizes pictures for a
specific display based on
type of source material.
BBE
Solution
Original Sound
BBE® Off
• Music before Processing
• First Part of transient
• Initial transient lost
• Envelope distortion
BBE® On
• Corrects Distortion
• Corrects phase delay
160˚
Side View
160˚
Top View
* Requires optional service setup.
* 43" model.
DL P
TM
TV
F e a t u re s
Tantus models
DigitAllconvenience
Favorite channel
Multi-function picture choices
> Five picture formats
>
You can program your favorite channels for easy access and quick channel
Choose the perfect aspect ratio for what you’re watching, whether it’s sports, TV or movies.
surfing. Get to your favorite shows faster, and skip those channels that you
Choose from Wide, Panorama, Zoom1, Zoom2 or Normal.
rarely watch.
Picture mode
Adjust the picture settings and color temperature to suit your programming. Choose from
Mild, Standard, Movie or Custom settings.
> Multi-picture format
Experience
perfect vision
2-tuner PIP and
split-screen side-by-side
Samsung lets you simultaneously watch two TV programs – or a TV program
Five audio pre-sets give you the best dynamic sound settings for what you’re watching.
and a DVD or other source. You can even re-size or re-position the PIP window.
Choose from Standard, Music, Movie, Speech or Custom.
Picture mode
Aspect
Sound mode
Melody On/Off
Split Screen
2-Tuner PIP
Auto volume leveler
Samsung Projection TVs turn on and off with a clear, pleasant melody. This sound
The Auto Volume Leveler stabilizes sound output to avoid rapid volume shifts
lets you know that the TV is being switched on or off.
from channel changes or commercials.
Samsung’s DLPTM TVs deliver an unmatched combination of picture
quality, digital convergence, features and lightweight convenience,
making them the most attractive and versatile TVs you’ve ever seen.
HLM617W
DNIeTM Video Enhancer (HLM617W only)
Samsung’s Digital Natural Image engine enhances all video inputs for an overall improvement in
picture quality. DNIeTM by Samsung improves contrast, white level, picture detail and incorporates
digital noise reduction to improve lower quality analog video source.
DL P
TM
TV
Line-up
Tantus models
Specifications
Model Number
HLM617W
HLM507W
HLM437W
HLM5065W
Size
61"
50"
43"
50"
43"
Aspect Ratio
16:9 Wide
16:9 Wide
16:9 Wide
16:9 Wide
16:9 Wide
Display Device/Light Engine
Single-panel,
Single-panel,
Single-panel,
Single-panel,
Single-panel,
HD2 DLP™
HD2 DLP™
HD2 DLP™
HD2 DLP™
HD2 DLP™
Lamp Wattage/Lamp Life (hours)
120/6000
100/8000
100/8000
100/8000
100/8000
Resolution (Horizontal)
1280 x 720
1280 x 720
1280 x 720
1280 x 720
1280 x 720
Display Format
720P
720P
720P
720P
720P
Brightness
400 cd/m2
400 cd/m2
400 cd/m2
400 cd/m2
400 cd/m2
Contrast
1000:1
1000:1
1000:1
1000:1
1000:1
Digital Comb Filter
3D Y/C
3D Y/C
3D Y/C
3D Y/C
3D Y/C
Protective Shield
Anti-Glare
Anti-Glare
Anti-Glare
Anti-Glare
Anti-Glare
Ultra-Fine Pitch Screen
.155mm
.155mm
.155mm
.155mm
.155mm
Video Processing
DCDiTM by Faroudja
DCDiTM by Faroudja
DCDiTM by Faroudja
Sage Scaler
Sage Scaler
Sound
Features
HLM4365W
3:2 Pull Down
Yes (Faroudja)
Yes (Faroudja)
Yes (Faroudja)
Film mode
Film mode
Samsung DNIeTM Video Enhancer
Yes
No
No
No
No
Output Power
30 Watts
30 Watts
30 Watts
30 Watts
30 Watts
Dolby System
Virtual
Virtual
Virtual
Virtual
Virtual
2-Way Dynamic Speakers
Yes
Yes
Yes
Yes
Yes
MTS Stereo with dbx®
Yes
Yes
Yes
Yes
Yes
BBE Audio
Yes
Yes
Yes
Yes
Yes
2-Tuner PIP
Yes
Yes
Yes
Yes
Yes
Split-Screen Side-By-Side
Yes
Yes
Yes
No
No
HDTV Upgradeable
Yes
Yes
Yes
Yes
Yes
with Receiver/Decoder
Terminals
HLM507W
Available on all Tantus models (including HLM617W):
• Texas Instruments HD-2 second generation DLPTM 1280x720 panel
• All format conversion to 720P
• Faroudja DCDiTM de-interlacing and 3:2 pull down
• 1 DVI digital video interface
DVI-HDTV Interface
Yes
Yes
Yes
Yes
Yes
HDTV Component
Video Input (Y, Pb, Pr) 1080i, 720P, 480P
2
2
2
2
2
DVD Component Video (Y, Pb, Pr) 480i/P
S-Video
RCA
1
1 Side/2 Rear
1 Side/2 Rear
1
1 Side/2 Rear
1 Side/2 Rear
1
1 Side/2 Rear
1 Side/2 Rear
1
1 Side/2 Rear
1 Side/2 Rear
1
1 Side/2 Rear
1 Side/2 Rear
PC Input (D-Sub 15-pin XGA)
1
1
1
1
1
56.5" x 21.5" x 41.2"
46.6" x 17.6" x 33.8"
40.5" x 15.7" x 29.7"
48.4" x 17.5" x 33.6"
42.3" x 15.7" x 29.7"
94.7 lbs
77.6 lbs
66.1 lbs
81.6 lbs.
69.4 lbs.
Cabinet/Color
Ultra-thin bezel/silver gray
Ultra-thin bezel/silver gray
Ultra-thin bezel/silver gray
Sleek bezel/silver gray
Sleek bezel/silver gray
UPC
036725 2 6170 9
036725 2 5070 3
036725 2 4370 5
036725 2 5065 9
036725 2 4365 1
HLM437W
• 2 HD Component Video Inputs
• 1 DVD 480i/480P auto sensing Component Video Input
• Computer RGB input
• Optional matching stand
Dimensions Size (W x D x H)
Weight
DL P
TM
TV
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
