LCD Televisions – Specifications
Features/Models
TC-26LX70
TC-32LX70
TC-32LX700
Screen size diagonal
26"
32"
32"
Aspect ratio
16:9
16:9
16:9
Panel
IPS
IPS
IPS (ALPHA)
Number of pixels
1,049,088
(1,366 x 768)
1,049,088
(1,366 x 768)
1,049,088
(1,366 x 768)
Brightness (Panel luminance)
500 cd/m2
500 cd/m2
500 cd/m2
Dynamic contrast ratio
7000:1
7000:1
8500:1
Response time
8 msec
8 msec
6 msec
Viewing angle
178°
178°
178°
Motion adaptive 3D Y/C digital comb filter
•
•
•
HDTV display capability
(1080p1, 1080i, 720p)2
•
•
•
EDTV display capability (480p)2
•
•
•
Aspect control (SDTV/EDTV)
Full, Just, 4:3, Zoom
Full, Just, 4:3, Zoom
Full, Just, 4:3, Zoom
Aspect control (HDTV)
Full, H-Fill, Just,
4:3, Zoom
Full, H-Fill, Just,
4:3, Zoom
Full, H-Fill, Just,
4:3, Zoom
Progressive scan
•
•
•
Motion picture pro™
--
--
•
Intelligent scene controller™
•
•
•
3D colour management
•
•
•
Video
Sub-pixel controller
•
•
•
Digital cinema reality (3:2 pull down)
480i only
480i only
480i only
Speakers
Full-range x 2 (L, R)
Full-range x 2 (L, R)
Tweeter x 2,
Woofer x 2 (L, R)
Number of speakers
2
2
4
Audio output
20 W (10% THD)4
20 W (10% THD)4
20 W (10% THD)3
BBE® ViVA HD3D Sound
--
--
•
Surround Sound
•
•
•
AI Sound
•
•
•
Audio leveler
•
•
•
Speakers on/off
•
•
•
Integrated ATSC/NTSC tuner
•
•
•
SD memory card slot
--
--
•
(SDHC compatible)
HDMI input
2
2
2
Composite video input (rear/side)
2/1
2/1
2/1
S-Video input
2
2
2
Component video input (Y, Pb, Pr)
1
1
1
Composite video output
1
1
1
Analogue audio output
1
1
1
Digital audio output
1
1
1
Headphone jack
1
1
1
EZsync™
•
•
•
Trilingual menu (English/Spanish/French)
•
•
•
Multi-brand system remote
N2QAYB000102
N2QAYB000102
N2QAYB000100
V-Chip program lock out
•
•
•
Built-in closed caption decoder
•
•
•
On/Off sleep timers (5 programmable)
•
•
•
Video picture memory
•
•
•
Video input labelling
•
•
•
AC 120 V / 60 Hz
AC 120 V / 60 Hz
AC 120 V / 60 Hz
Average use
116 W
132 W
138 W
Stand-by
condition
0.1 W
0.1 W
0.1 W
Energy Star® qualified
•
•
•
Receiving system
ATSC / NTSC
ATSC / NTSC
ATSC / NTSC
657 x 515 x 239
791 x 592 x 239
836 x 592 x 248
25.9 x 20.3 x 9.4
31.1 x 23.3 x 9.4
32.9 x 23.3 x 9.8
657 x 468 x 117
791 x 545 x 117
836 x 540 x 107
25.9 x 18.4 x 4.6
31.1 x 21.5 x 4.6
32.9 x 21.3 x 4.2
Weight
14 kg / 30.9 lb
16.5 kg / 36.4 lb
18 kg / 39.7 lb
Swivel angle
NA
NA
± 15°
VESA compatible
200 x 100 mm
200 x 100 mm
200 x 100 mm
Gross weight
18 kg / 39.7 lb
21 kg / 46.3 lb
22 kg / 48.5 lb
Audio
Jacks
Convenience
General
Power supply
Power consumption
mm
Dimensions with stand
(W x H x D)
inch
mm
Dimensions without stand
(W x H x D)
inch
1
Available through HDMI only.
All signals will be converted to match the panel's native resolution.
3 2-Way speaker system (8 ohms, 350Hz-17kHz / 80Hz-350Hz)
4 Full range speaker system (8 ohms, 80Hz-17kHz)
2
Note: Specifications are subject to change without notice.
