Cyber-shot® Digital Still Camera
With Sony’s Smile Shutter technology, the DSC-T300 helps automatically6 capture smiles as they happen, while Face Detection
technology helps deliver accurate, natural images of family and friends. You can expect stunning detail and color thanks to its 10.1
megapixel resolution, Carl Zeiss® 5x optical zoom lens, optical image stabilization, and Intelligent Scene Recognition Mode.
10.1 MP Super HAD™ CCD
More megapixels give you more detail
and definition when you make big
prints or crop in tight on your subject.
The advanced Sony® Super HAD™
(Hole Accumulated Diode) CCD
design allows more light to pass to
each pixel, increasing sensitivity and
reducing noise.
Carl Zeiss® 5X Optical Zoom Lens
5X optical zoom gives you the power
to get even closer to the action -- a real
benefit for distant landscape views and
dramatic portraits.
3.5”1 Widescreen Clear Photo LCD
Plus™ Display
A huge 3.5”1 widescreen Clear Photo
LCD Plus™ LCD display includes an
anti-reflective coating that provides for
excellent visibility to help you
compose, view, and share photos with
superb clarity and color reproduction,
even in bright sunlight.
Face Detection
Face Detection technology
automatically controls flash, focus,
exposure, and white balance to help
reveal faces in shadows, make skin
tones look more natural, reduce redeye, and eliminates harsh facial glare.
Smile Shutter Mode
Smile Shutter™ technology captures
smiles the moment they happen6 without the need to press the shutter. The
mode can be set to capture when your
subject laughs, smiles or even grins,
and like Face Detection is able to
differentiate children and adults to set
Sony Double Anti-Blur Solution
The combination of Super SteadyShot®
optical image stabilization and high
ISO sensitivity helps compensate for
shaky hands, minimizes blur, and allow
flash-free shooting to preserve the
Super SteadyShot® Optical Image
Super SteadyShot® Image Stabilization
compensates for shaky hands and
minimizes blur with a built-in gyro
sensor that detects camera movement
and sends correcting signals to a
stabilization lens — so there’s no need
to crop in on your shot to reduce blur.
High Sensitivity (ISO 3200) Mode
With high sensitivity of ISO 3200, you
can shoot effectively in low light
without flash to preserve the mood,
while the Sony Clear RAW™ Noise
Reduction system helps suppress the
color noise that can degrade low-light
Intelligent Scene Recognition Mode
Intelligent Scene Recognition mode
automatically detects 5 different types
of scenes and selects the appropriate
camera setting: Backlight, Backlight
Portrait, Twilight, Twilight Portrait,
Twilight using a Tripod. Intelligent Scene
Recognition has two different modes,
advanced and auto. Advanced mode
takes two shots, one with the standard
automatic settings and the other with
optimized settings. Auto mode takes a
single shot, arbitrarily deciding on the
proper setting.
Dynamic Range Optimization Standard
& Plus
Dynamic Range Optimization --Powered by the exclusive Sony BionzTM
high-speed processing engine,
Dynamic Range Optimization(DRO)
preserves image data in bright
highlights and reveals more detail in
shadows or backlit areas -- for great
results even in difficult lighting
conditions. New DRO Plus mode
enhances optimization, analyzing each
region of an image and performing
additional image processing.
Convenient Photo Modes
MPEG Movie VX Fine Mode
Automatic Macro Shooting
9-Point Auto Focus
Smart Zoom® Feature5
Burst Mode
Simple Icon Setup Controls
Easy Shooting Mode
Function Guide
15 MB2 Internal Memory
Memory Stick Duo™ Media
Stamina® Battery Power
Easy Image Management
HDTV Compatibility 3
Megapixel: 10.1 MP
Imaging Device: 1/2.3" Super HAD™ CCD
Recording Media: 15MB internal Flash
Memory, optional Memory Stick® DUOTM
Media, optional Memory Stick PRO Duo™
White Balance: Automatic, Cloudy, Daylight,
Fluorescent 1, Fluorescent 2, Fluorescent
3, Incandescent, Flash
Self Timer: Yes (10 seconds, 2 seconds, Off)
Memory Stick PRO™ Media Compatibility:
Tested to support up to 16GB Memory
Stick PRO Duo™ Media capacity2 ; does
not support Access Control security
Still Image Mode(s): Burst, JPEG (Fine),
Exposure Bracketing
Red-Eye Reduction: Yes (On/Off all modes)
Burst Mode: 100 shots at 1.6 fps
Erase/Protect: Yes/Yes
Date/Time Stamp: No/ No
Media/Battery Indicator: Yes/Yes
Color Mode(s): Black & White, Natural,
Sepia, Vivid
Convenience Features
Real Imaging Processor™ Technology: Yes Bionz
AF Illuminator Light: Yes
PictBridge Compatible: Yes
Multi-Pattern Measuring: Yes
Scene Mode(s): Beach, Fireworks, High
Speed Shutter, High Sensitivity,
Landscape, Snow, Soft Snap, Twilight,
Twilight Portrait, Smile Shutter, and
Movie Mode(s): MPEG VX Fine(640x480 at
30fps) (MPEG VX Fine requires Memory
Stick PRO Duo™ Media), MPEG VX
Standard(640x480 at 16.6fps), Presentation
Mode (320 x 240 at 8.3fps).
Power Save Mode: Yes (after approx. 3 min.
of inactivity)
In-Camera Editing: In-Camera Retouching --Red-eye correction, soft edge filter, cross
filter, partial color filter, fish-eye filter, retro,
radiation, trimming, unsharp masking and
happy face.
Cyber-shot® Digital Still Camera
Focal Length: 5.8 - 29mm
35mm Equivalent: Yes
Focus: 9 Area Multi-Point AF, Center AF,
Flexible Spot
Focal Distance: W:Approx. 3 1/8" (8cm) to
Infinity, T:Approx. 31 1/2"(80cm) to Infinity;
Close Focus Enabled: .3/8"(1cm) to 7
7/8" (20cm)
Aperture Range: Auto(F3.5-F10) / Program
Shutter Speed: Auto(1/4 - 1/1,000) / Program
Auto(1" - 1/1,000)
Exposure Compensation: ±2.0 EV, 1/3 EV
Step Increments
ISO: Auto, 80, 100, 200, 400, 800, 1600, 3200
Filter Diameter: N/A
Smart Zoom® Technology: Up to 7.0X (5MP),
8.9X (3MP), 9.5X (16:9 2MP) 28X (VGA
Digital Zoom: 2X (Precision)
Optical Zoom: 5X
Macro Mode: Yes
Total Zoom: 10X
Minimum Focus Distance: 19-11/16" (50cm)
Normal, 3-1/8" (8cm) Macro, 3/8" (1cm)
Magnifying Glass
Face Detection: Yes
Battery Type: Lithium-Ion NP-BD1
Battery Capacity: 3.6V, 680 mAh
Supplied Software: Windows: Picture Motion
Browser Vers 3.0.02 + USB Driver
Operating System Compatibility: Microsoft®
2000 Professional, Me, XP Home and
Professional, and Vista; Macintosh® OS
9.1/9.2/OS X (10.1-10.5)
Service and Warranty Information
Limited Warranty Term: 1 Year Parts & Labor
Supplied Accessories
NP-BD1 rechargeable battery
BC-CSD battery charger
A/V and USB multi-connector cables
Optional Accessories
Super SteadyShot® optical image
stabilization: Yes
Accessory Kit (ACC-CLGB)
Inputs and Outputs
Color: Silver
UPC Code: 027242724921
Accessory Terminal: Multi connector
Audio/Video Output(s): Yes via Mutli-Use
USB Port(s): Yes (Supports USB 2.08 )
HD Output: Yes (1080i) with optional
LCD: 3.5"1 Widescreen (230K Pixels) Clear
Photo LCD™ Plus screen
Viewfinder: N/A
Lens Construction: 12 Elements in 10 Groups,
(including 3 aspheric elements,1 prism)
Microphone/Speaker: Yes/ Yes
Lens Type: Carl Zeiss® Vario-Tessar®
Docking Station: Yes, via optional HD cradle
Operating Conditions
Flash Effective Range: Auto: Approx.0.1Approx.3.5m(W) / Approx.0.8-Approx.2.7m
Flash Mode(s): Auto, Forced On, Forced
Off, Slow Synch
1. Viewable area; measured diagonally.
2. Available storage capacity may vary and a portion of the memory is used for data management
3. HD viewing requires a Sony HD connector cable or HD Cyber-shot Station® cradle and HDTV. All sold
4. Music tracks can be up to five minutes long. When using Music Transfer to download music, tracks
longer than five minutes will be reduced to five minutes when uploading to the Cyber-shot.
5. Smart Zoom® feature will not work at highest resolution setting.
6. Up to 6 shots while in Smile Shutter mode.
7. Shooting at high frame rate of up to 30 frames per second requires Memory Stick PRO Duo™ media.
8. Special TV settings are required. Further details are available in the BRAVIA® instruction manual.
© 2007 Sony Electronics, Inc.
All rights reserved. Reproduction in whole or in part without written permission is prohibited. Sony, Bionz,
Bravia, Clear Photo LCD Plus, Clear RAW, Cyber-shot, Handycam, Memory Stick Duo, Memory Stick
PRO Duo, Picture Station, Smart Zoom, Stamina, Super HAD, Super SteadyShot, and Walkman are
trademarks of Sony. All other trademarks are trademarks of their respective owners.
Please visit the Dealer Network for more information at
Sony Electronics Inc. •16530 Via Esprillo •San Diego, CA 92127 •1.800.222.7669 •www.sony.com
