THE WORLDWIDE

AUTHORITY IN AUDIO

THX

®

-certified movie house like the Samuel Goldwyn Theater

JBL. If you’ve heard your favorite band rock at the Georgia Dome, you know JBL. Chances are, JBL

®

studio monitors were used to mix and master your most-played CDs and DVDs.

JBL equipment has been setting – and is continuously raising – audio performance standards in theaters, concert halls, recording studios and

REPRODUCTION FOR

arenas around the world for more than sixty years. Our professional heritage is what makes JBL JBL. And it’ s what puts JBL car audio miles ahead of the competition.

MORE THAN 60 YEARS.

(actually, hear ) why we’ve got street creds like nobody else in the business.

SPECIFICATIONS

Description

thE laTest sUccess oF the JBL cAr stoRy

60th annIverSary

560GTi & 660GTi

Power Handling, Peak

Power Handling, RMS

Sensitivity (@ 2,83V)

Frequency Response

Crossover Frequency

Voice Coil Diameter

Impedance

560GTi 660GTi

130mm (5-1/4") 2-Way 160mm (6-1/2") 2-Way

Professional-Grade Professional-Grade

Automotive Component Automotive Component

Speaker System Speaker System

500W 600W

125W

91dB

150W

92dB

58Hz – 30kHz

2500Hz

50mm (2")

4 ohms

50Hz – 30kHz

2500Hz

50mm (2")

4 ohms

JBLC1233.car.euro.ctlg08.vF.qxd 3/6/08 11:19 AM Page 4

4

6000-Watt Balanced-Current Subwoofer

Amplifier With Current Servos

• 8110 Watts RMS x 1 channel at 4 ohms,

14,4V supply and ≤1% THD + N

• 7400 Watts RMS x 1 channel at 1 ohm,

14,4V supply and ≤1% THD + N

• Frequency response: 10Hz – 270Hz (–3dB)

• Built-in, variable electronic crossover with selectable slope

• Dynamic Bass Optimization (DBO) circuit

• Variable phase control

• Preamp outputs

• Internal lighting

• Remote level control included

• Dimensions (L x W x H):

747mm x 585mm x 165mm

(29-3/8" x 23" x 6-1/2")

C508GTi MkII

130mm (5-1/4") 2-Way Component System

• Power handling: 125W RMS, 500W peak

• Frequency response: 58Hz – 21kHz

• Sensitivity: 88dB

• System impedance: 4 ohms

• Voice-coil diameter: woofer 50mm (2") edge-wound; tweeter 25mm (1")

• Mounting depth: woofer 61mm

(2-3/8"); tweeter 29mm (1-1/8")

• Overall diameter: woofer 133mm (5-1/4"); tweeter 53mm (2-1/16")

• Cutout diameter: woofer 118mm

(4-5/8"); tweeter 45mm (1-3/4")

• Crossover dimensions (L x W x H):

153mm x 115mm x 45mm

(6" x 4-1/2" x 1-3/4")

C608GTi MkII

160mm (6-1/2") 2-Way Component System

• Power handling: 150W RMS, 600W peak

• Frequency response: 50Hz – 21kHz

• Sensitivity: 89dB

• System impedance: 4 ohms

• Voice-coil diameter: woofer 50mm (2") edge-wound; tweeter 25mm (1")

• Mounting depth: woofer 68mm

(2-11/16"); tweeter 29mm (1-1/8")

• Overall diameter: woofer 159mm (6-1/4"); tweeter 53mm (2-1/16")

• Cutout diameter: woofer 131mm

(5-1/8"); tweeter 45mm (1-3/4")

• Crossover dimensions (L x W x H):

153mm x 115mm x 45mm

(6" x 4-1/2" x 1-3/4")

W15GTi MkII

380mm (15") Differential Drive ®†

Subwoofer

Design

• Power handling, RMS: 800W

• Power handling, peak: 5000W

• Sensitivity: 92dB

• Differential Drive Design (DDD) motor

• Die-cast vented basket

• Kevlar ® -impregnated paper woofer cone

• Dual 6-ohm voice coils

• Nitrile-butylene surround

• Mounting depth: 260mm (10-1/4")

W12GTi MkII

300mm (12") Differential Drive ®†

Subwoofer

Design

• Power handling, RMS: 700W

• Power handling, peak: 4000W

• Sensitivity: 91dB

• Differential Drive Design (DDD) motor

• Die-cast vented basket

• Kevlar ® -impregnated paper woofer cone

• Dual 6-ohm voice coils

• Nitrile-butylene surround

• Mounting depth: 260mm (10-1/4")

† U.S. patent no. 5,748,760 and other patents pending

5

JBLC1233.car.euro.ctlg08.vF.qxd 3/6/08 11:19 AM Page 6

P1224

300mm (12") Subwoofer

• Power handling: 400W RMS, 1600W peak

• Frequency response: 23Hz – 200Hz

• Sensitivity (2,83V @ 1m): 94dB

• Impedance: 2 ohms/8 ohm

• Kevlar ® -impregnated paper woofer cone

• Dual 4-ohm voice coils

• Vented polepiece

• Mounting depth: 149mm (5-7/8")

P1222

300mm (12") Subwoofer

• Power handling: 400W RMS, 1600W peak

• Frequency response: 23Hz – 200Hz

• Sensitivity (2,83V @ 1m): 97dB

• Impedance: 4 ohms/1 ohm

• Kevlar ® -impregnated paper woofer cone

• Dual 2-ohm voice coils

• Vented polepiece

• Mounting depth: 172mm (6-3/4")

P1022

250mm (10") Subwoofer

• Power handling: 400W RMS, 1600W peak

• Frequency response: 25Hz – 200Hz

• Sensitivity (2,83V @ 1m): 96dB

• Impedance: 4 ohms/1 ohm

• Kevlar ® -impregnated paper woofer cone

• Dual 2-ohm voice coils

• Vented polepiece

• Mounting depth: 172mm (6-3/4")

PB1220

300mm (12") Bass-Reflex Subwoofer Box

• Power handling, RMS: 400W

• Power handling, peak: 1600W

• Frequency response: 32Hz – 200Hz

• Sensitivity (2,83V @ 1m): 90dB

• Impedance: 2 ohms

• Dimensions (L x D x H):

577mm x 491mm x 424mm

(22-11/16" x 19-5/16" x 16-11/16")

T696

6" x 9" High-Output 3-Way Loudspeaker

• Power handling, RMS: 150W

• Power handling, peak: 450W

• Impedance: 4 ohms

• Frequency response: 35Hz – 20kHz

• Sensitivity (2,83V @ 1m): 93dB

• Proprietary cast-aluminum frame

• Carbon-fiber-finish grilles

• Built-in tweeter-level control

• Tweeter protection circuit

• Mounting depth: 81mm (3-3/16")

6

7

JBLC1233.car.euro.ctlg08.vF.qxd 3/6/08 11:20 AM Page 8

8

P963

6" x 9" 3-Way Coaxial Loudspeaker

• Power handling, RMS: 110W

• Power handling, peak: 330W

• Frequency response: 35Hz – 23kHz

• Sensitivity: 96dB

• Crossover type: outboard

• Tweeter level control (0/–3dB)

• Tweeter protection (PTC)

• Mounting depth: 82mm (3-1/4")

CompOneNt sYsteMs

MuLtielemEnts

P462

100mm (4") 2-Way Coaxial Loudspeaker

• Power handling, RMS: 50W

• Power handling, peak: 150W

• Frequency response: 75Hz – 23kHz

• Sensitivity (2,83V @ 1m): 91dB

• Crossover type: outboard

• Woofer mounting depth: 48mm (1-15/16")

P6560C

165mm 2-Way Component Loudspeaker

• Power handling, RMS: 90W

• Power handling, peak: 270W

• Frequency response: 45Hz – 23kHz

• Sensitivity (2,83V @ 1m): 94dB

• Impedance: 2 ohms

• Crossover type: outboard

• Tweeter level control (0/–6dB)

• Tweeter protection (PTC)

• Mounting depth: 63mm (2-1/2")

P6563C P560C

87mm/165mm 3-Way Component Loudspeaker

• Power handling, RMS: 90W

• Power handling, peak: 270W

• Frequency response: 45Hz – 23kHz

• Sensitivity (2,83V @ 1m): 94dB

• Impedance: 2 ohms

• Crossover type: outboard

• Tweeter level control (0/–6dB)

• Midrange level control (0/–3dB)

• Tweeter protection (PTC)

• Mounting depth: 37mm/63mm (1-1/2"/2-1/2")

130mm (5-1/4") 2-Way Component Loudspeaker

• Power handling, RMS: 75W

• Power handling, peak: 225W

• Frequency response: 55Hz – 23kHz

• Sensitivity (2,83V @ 1m): 92dB

• Impedance: 2 ohms

• Crossover type: outboard

• Tweeter level control (0/–6dB)

• Tweeter protection (PTC)

• Mounting depth: 53mm (2-1/8")

P6562

165mm 2-Way Coaxial Loudspeaker

• Power handling, RMS: 75W

• Power handling, peak: 225W

• Frequency response: 45Hz – 23kHz

• Sensitivity (2,83V @ 1m): 93dB

• Impedance: 2 ohms

• Crossover type: outboard

• UniPivot ™ rotating tweeter

• Tweeter level control (0/–3dB)

• Mounting depth: 61mm (2-7/16")

P562

130mm (5-1/4") 2-Way Coaxial Loudspeaker

• Power handling, RMS: 55W

• Power handling, peak: 165W

• Frequency response: 55Hz – 23kHz

• Sensitivity (2,83V @ 1m): 92dB

• Impedance: 2 ohms

• Crossover type: outboard

• UniPivot ™ rotating tweeter

• Tweeter level control (0/–3dB)

• Mounting depth: 53mm (2-1/8")

9

JBLC1233.car.euro.ctlg08.vF.qxd 3/6/08 11:20 AM Page 10

www

.jbl.com

GTO5355

660-Watt 5-Channel Full-Range Amplifier

• 55W RMS x 4 + 225W RMS x 1 channel at 4 ohms and ≤1% THD + N*

• 75W RMS x 4 + 360W RMS x 1 channel at 2 ohms and ≤1% THD + N*

• Signal-to-noise ratio: 85dBA

(reference 1W into 4 ohms)*

• Signal-to-noise ratio: 104dBA

(reference rated power into 4 ohms)

• THD + N: 0.04% (rated power @ 4 ohms)

• Built-in variable electronic crossover

• Variable bass boost (0 to +12dB @ 50Hz)

• Frequency response:

10Hz – 83kHz and 20Hz – 250Hz (–3dB)

• Maximum power: 660 watts

• RCA low-level preamp inputs

• Dimensions (L x W x H):

472mm x 264mm x 54mm

(18-9/16" x 10-3/8" x 2-1/8")

*CEA-2006A compliant

GTO1004

600-Watt 4-Channel Full-Range Amplifier

• 100W RMS x 4 channels at 4 ohms and ≤1% THD + N*

• 150W RMS x 4 channels at 2 ohms and ≤1% THD + N*

• Signal-to-noise ratio: 85dBA

(reference 1W into 4 ohms)*

• Signal-to-noise ratio: 104dBA

(reference rated power into 4 ohms)

• THD + N: 0.05% (rated power @ 4 ohms)

• Built-in variable electronic crossover

• Variable bass boost (0 to +12dB @ 50Hz)

• Frequency response:

10Hz – 100kHz (–3dB)

• Maximum power: 600 watts

• RCA low-level preamp inputs

• RCA low-level preamp outputs

• Dimensions (L x W x H):

472mm x 264mm x 54mm

(18-9/16" x 10-3/8" x 2-1/8")

*CEA-2006A compliant

GTO504

280-Watt 4-Channel Full-Range Amplifier

• 55W RMS x 4 channels at 4 ohms and

≤1% THD + N*

• 70W RMS x 4 channels at 2 ohms and

≤1% THD + N*

• Signal-to-noise ratio: 90dBA

(reference 1W into 4 ohms)*

• Signal-to-noise ratio: 105dBA

(reference rated power into 4 ohms)

• THD + N: 0.02% (rated power @ 4 ohms)

• Built-in independent variable electronic crossover

• Variable bass boost

(0 to +12dB @ 50Hz)

• Frequency response:

10Hz – 100kHz (–3dB)

• Maximum power: 280 watts

• RCA low-level preamp inputs

• RCA low-level preamp outputs

• Dimensions (L x W x H):

351mm x 264mm x 54mm

(13-3/16" x 10-3/8" x 2-1/8")

*CEA-2006A compliant

GTO752

220-Watt 2-Channel Full-Range Amplifier

• 75W RMS x 2 channels at 4 ohms and

≤1% THD + N*

• 110W RMS x 2 channels at 2 ohms and ≤1% THD + N*

• Signal-to-noise ratio: 90dBA

(reference 1W into 4 ohms)*

• Signal-to-noise ratio: 108dBA

(reference rated power into 4 ohms)

• THD + N: 0.07% (rated power @ 4 ohms)

• Built-in variable electronic crossover

• Variable bass boost

(0 to +12dB @ 50Hz)

• Frequency response:

10Hz – 100kHz (–3dB)

• Maximum power: 220 watts

• RCA low-level preamp inputs

• RCA low-level preamp outputs

• Dimensions (L x W x H):

312mm x 264mm x 54mm

(12-1/4" x 10-3/8" x 2-1/8")

*CEA-2006A compliant

GTO14001

1500-Watt Mono Subwoofer Amplifier

• 1200W RMS x 1 channel at 4 ohms and ≤1% THD + N*

• 1500W RMS x 1 channel at 2 ohms and ≤1% THD + N*

• Signal-to-noise ratio: 77dBA

(reference 1W into 4 ohms)*

• Signal-to-noise ratio: 108dBA

(reference rated power into 4 ohms)

• THD + N: 0.05% (rated power @ 4 ohms)

• Built-in variable electronic crossover

• Dynamic Bass Optimization (DBO) circuit

• Frequency response: 20Hz – 330Hz (–3dB)

• Maximum power: 1500 watts

• RCA low-level preamp inputs

• RCA low-level preamp outputs

• Remote bass level control included

• Dimensions (L x W x H):

472mm x 264mm x 54mm

(18-9/16" x 10-3/8" x 2-1/8")

*CEA-2006A compliant

GTO7001

700-Watt Mono Subwoofer Amplifier

• 425W RMS x 1 channel at 4 ohms and

≤1% THD + N*

• 700W RMS x 1 channel at 2 ohms and

≤1% THD + N*

• Signal-to-noise ratio: 80dBA

(reference 1W into 4 ohms)*

• Signal-to-noise ratio: 107dBA

(reference rated power into 4 ohms)

• THD + N: 0.02% (rated power @ 4 ohms)

• Built-in variable electronic crossover

• Dynamic Bass Optimization (DBO) circuit

• Frequency response: 20Hz – 330Hz (–3dB)

• Maximum power: 700 watts

• RCA low-level preamp inputs

• RCA low-level preamp outputs

• Remote bass level control included

• Dimensions (L x W x H):

381mm x 264mm x 54mm

(15" x 10-3/8" x 2-1/8")

*CEA-2006A compliant

GTO3501

360-Watt Mono Subwoofer Amplifier

• 225W RMS x 1 channel at 4 ohms and

≤1% THD + N*

• 360W RMS x 1 channel at 2 ohms and

≤1% THD + N*

• Signal-to-noise ratio: 85dBA

(reference 1W into 4 ohms)*

• Signal-to-noise ratio: 104dBA

(reference rated power into 4 ohms)

• THD + N: 0.04% (rated power @ 4 ohms)

• Built-in variable electronic crossover

• Dynamic Bass Optimization (DBO) circuit

• Frequency response: 20Hz – 330Hz (–3dB)

• Maximum power: 360 watts

• RCA low-level preamp inputs

• RCA low-level preamp outputs

• Remote bass-level control included

• Dimensions (L x W x H):

312mm x 264mm x 54mm

(12-1/4" x 10-3/8" x 2-1/8")

*CEA-2006A compliant

10

11

JBLC1233.car.euro.ctlg08.vF.qxd 3/6/08 11:20 AM Page 12

12

GTO1204BP-D

300mm (12") Dual Band-Pass Subwoofer Box

• Subwoofer type: 2 x GTO1204/300mm

• Power handling, RMS: 600W

• Power handling, peak: 1800W

• Frequency response: 35Hz – 150Hz

• Sensitivity (2,83V @ 1m): 98dB

• Impedance: 2 x 4 ohms

• Dimensions (L x D x H):

900mm x 450mm x 370mm

(35-7/16" x 17-3/4" x 14-9/16")

GTO1204BR

300mm (12") Bass-Reflex Subwoofer Box

• Subwoofer type: GTO1204/300mm

• Power handling, RMS: 300W

• Power handling, peak: 1200W

• Frequency response: 35Hz – 300Hz

• Sensitivity (2,83V @ 1m): 93dB

• Impedance: 4 ohms

• Dimensions (L x D x H):

520mm x 414mm x 370mm

(20-1/2" x 16-5/16" x 14-9/16")

GTO1204BP

300mm (12") Band-Pass Subwoofer Box

• Subwoofer type: GTO1204/300mm

• Power handling, RMS: 300W

• Power handling, peak: 1200W

• Frequency response: 30Hz – 150Hz

• Sensitivity (2,83V @ 1m): 93dB

• Impedance: 4 ohms

• Dimensions (L x D x H):

520mm x 450mm x 370mm

(20-1/2" x 17-3/4" x 14-9/16")

BassPro ™ II

Amplified Subwoofer System

• 100W RMS 4-channel amplifier

• Quad-voice-coil subwoofer

• Variable electronic crossover

• Accepts low-level or high-level inputs

• Remote bass-level control included

• Dimensions (L x D x H):

410mm x 242mm x 312mm

(16-1/8" x 9-1/2" x 12-1/4")

GTO1514

380mm (15") Subwoofer

• Power handling, RMS: 350 watts

• Power handling, peak: 1400 watts

• Frequency response: 23Hz – 400Hz

• Sensitivity: 93dB

• Impedance: 4 ohms

• Polypropylene woofer cone

• Proprietary aluminium die-cast basket

• Vented motor structure

• 4-Ohm voice coil

• Mounting depth: 143mm (5-5/8")

GTO1214

300mm (12") Subwoofer

• Power handling, RMS: 350 watts

• Power handling, peak: 1400 watts

• Frequency response: 23Hz – 400Hz

• Sensitivity: 90dB

• Impedance: 4 ohms

• Polypropylene woofer cone

• Proprietary aluminium die-cast basket

• Vented motor structure

• 4-Ohm voice coil

• Mounting depth: 129mm (5-1/16")

GTO1014

250mm (10") Subwoofer

• Power handling, RMS: 350 watts

• Power handling, peak: 1400 watts

• Frequency response: 25Hz – 400Hz

• Sensitivity: 88dB

• Impedance: 4 ohms

• Polypropylene woofer cone

• Proprietary aluminium die-cast basket

• Vented motor structure

• 4-Ohm voice coil

• Mounting depth: 122mm (4-13/16")

GTO1202D

300mm (12") Dual-2-Ohm-Voice-Coil

Subwoofer

• Power handling, RMS: 300W

• Power handling, peak: 1200W

• Frequency response: 23Hz – 400Hz

• Sensitivity: 93dB

• Impedance: 4 ohms/1 ohm

• Polypropylene woofer cone

• Reduced-depth proprietary frame

• Vented polepiece

• Hi-roll butyl surround

• Mounting depth: 129mm (5-1/16")

GTO804

200mm (8") Single-4-Ohm-Voice-Coil

Subwoofer

• Power handling, RMS: 200W

• Power handling, peak: 800W

• Frequency response: 30Hz – 400Hz

• Sensitivity: 91dB

• Impedance: 4 ohms

• Polypropylene woofer cone

• Reduced-depth proprietary frame

• Vented polepiece

• Hi-roll butyl surround

• Mounting depth: 112mm (4-3/8")

13

JBLC1233.car.euro.ctlg08.vF.qxd 3/6/08 11:20 AM Page 14

1 4

GTO937

6" x 9" 3-Way Loudspeaker

• Power handling, RMS: 100W

• Power handling, peak: 300W

• Frequency response: 50Hz – 21kHz

• Sensitivity: 94dB

• Impedance: 2 ohms

• Plus One ® (patent pending) woofer cone

• 13mm (1/2") My-Ti ™ super tweeter

• 25mm (1") Edge-driven My-Ti tweeter

• Mounting depth: 83mm (3-1/4")

GTO637

160mm (6-1/2") 3-Way Loudspeaker

• Power handling, RMS: 60W

• Power handling, peak: 180W

• Frequency response: 55Hz – 21kHz

• Sensitivity: 92dB

• Impedance: 2 ohms

• Mounting depth: 54mm (2-1/16")

GTO607C

160mm (6-1/2") 2-Way Component

System

• Power handling, RMS: 70W

• Power handling, peak: 210W

• Frequency response: 55Hz –

21kHz

• Sensitivity: 92dB

• Impedance: 2 ohms

• Mounting depth: 53mm (2-1/16")

GTO6537

165mm 3-Way Loudspeaker

• Power handling, RMS: 60W

• Power handling, peak: 180W

• Frequency response: 55Hz – 21kHz

• Sensitivity: 92dB

• Impedance: 2 ohms

• Mounting depth: 59mm (2-5/16")

GTO507C

130mm (5-1/4") 2-Way Component

System

• Power handling, RMS: 55W

• Power handling, peak: 165W

• Frequency response: 70Hz – 21kHz

• Sensitivity: 91dB

• Impedance: 2 ohms

• Plus One ®

(patent pending) woofer cone

• 25mm (1") My-Ti ™ tweeter

• Outboard crossover system

• Mounting depth: 59mm (2-5/16")

GTO837

200mm (8") 3-Way Loudspeaker

• Power handling, RMS: 100W

• Power handling, peak: 300W

• Frequency response: 50Hz – 21kHz

• Sensitivity: 94dB

• Impedance: 2 ohms

• Mounting depth: 74mm (3")

GTO527

130mm (5-1/4") 2-Way Loudspeaker

• Power handling, RMS: 45W

• Power handling, peak: 135W

• Frequency response: 70Hz – 21kHz

• Sensitivity: 91dB

• Impedance: 2 ohms

• Plus One ® (patent pending) woofer cone

• 25mm (1") Edge-driven My-Ti

™ tweeter

• Mounting depth: 61mm (2-3/8")

GTO17t

25mm (1") Edge-Driven My-Ti ™

Tweeter

• Power handling, RMS: 50W

• Power handling, peak: 150W

• Frequency response: 2.5kHz – 21kHz

• Sensitivity: 92dB

• Impedance: 2 ohms

• Mounting depth: 30mm (1-3/16")

GTO427

100mm (4") 2-Way Loudspeaker

• Power handling, RMS: 35W

• Power handling, peak: 105W

• Frequency response: 90Hz – 20kHz

• Sensitivity: 90dB

• Impedance: 2 ohms

• Mounting depth: 54mm (2")

GTO927

6" x 9" 2-Way Loudspeaker

• Power handling, RMS: 100W

• Power handling, peak: 300W

• Frequency response:

50Hz – 21kHz

• Sensitivity: 94dB

• Impedance: 2 ohms

• Mounting depth:

83mm (3-1/4")

GTO8627

6" x 8"/5" x 7"

2-Way Loudspeaker

• Power handling, RMS: 60W

• Power handling, peak: 180W

• Frequency response:

50Hz – 21kHz

• Sensitivity: 92dB

• Impedance: 2 ohms

• Mounting depth:

62mm (2-7/16")

GTO6427

4" x 6" 2-Way Loudspeaker

With DIN Adapter

• Power handling, RMS: 40W

• Power handling, peak: 120W

• Frequency response:

75Hz – 21kHz

• Sensitivity: 91dB

• Impedance: 2 ohms

• Mounting depth:

47mm (1-7/8")

GTO327

87mm (3-1/2")

2-Way Loudspeaker

• Power handling, RMS: 25W

• Power handling, peak: 75W

• Frequency response:

90Hz – 20kHz

• Sensitivity: 89dB

• Impedance: 2 ohms

• Mounting depth:

37mm (1-7/16")

GTO627

160mm (6-1/2")

2-Way Loudspeaker

• Power handling, RMS: 60W

• Power handling, peak: 180W

• Frequency response:

55Hz – 21kHz

• Sensitivity: 92dB

• Impedance: 2 ohms

• Mounting depth:

54mm (2-1/16")

GTO6527S GTO6527

165mm 2-Way

Slim-Line Loudspeaker

165mm 2-Way Loudspeaker

• Power handling, RMS: 60W

• Power handling, RMS: 55W

• Power handling, peak: 165W

• Frequency response:

55Hz – 21kHz

• Sensitivity: 92dB

• Power handling, peak: 180W

• Frequency response:

55Hz – 21kHz

• Sensitivity: 92dB

• Impedance: 2 ohms

• Impedance: 2 ohms

• Plus One ® (patent pending) woofer cone

• 25mm (1") Edge-driven

My-Ti ™ tweeter

• Mounting depth: 47mm (1-13/16")

• Plus One ® (patent pending) woofer cone

• 25mm (1") Edge-driven

My-Ti ™ tweeter

• Mounting depth: 59mm (2-5/16")

GTO6507C

165mm 2-Way Component System

• Power handling, RMS: 70W

• Power handling, peak: 210W

• Frequency response:

55Hz – 21kHz

• Sensitivity: 92dB

• Impedance: 2 ohms

• Plus One ® (patent pending) woofer cone

• 25mm (1") My-Ti ™ tweeter

• Outboard crossover system

• Mounting depth: 61mm (2-3/8")

GTO6507SC

165mm Shallow-Mount 2-Way

Component System

• Power handling, RMS: 60W

• Power handling, peak: 180W

• Frequency response:

55Hz – 21kHz

• Sensitivity: 92dB

• Impedance: 2 ohms

• Mounting depth: 45mm (1-3/4")

1 5

JBLC1233.car.euro.ctlg08.vF.qxd 3/6/08 11:20 AM Page 16

www.jbl.com

GT5-A402

240-Watt 2-Channel Power Amplifier

• Class AB

• Output power (RMS, <1% THD + N; 4 ohms):

2 x 40W

• Output power (RMS, <1% THD + N; 2 ohms):

2 x 60W

• Crossover type (12dB/oct., 20Hz – 320Hz; front):

LP/HP/flat

• Signal-to-noise (@ 1W): 85dBA

• Backlit JBL logo

• Bass boost (+6dB @ 50Hz): switch

• Dimensions (L x W x H):

191mm x 235mm x 54mm

(7-1/2" x 9-1/4" x 2-1/8")

GT5-A604

640-Watt 4-Channel Power Amplifier

• Class AB

• Output power (RMS, <1% THD + N; 4 ohms):

4 x 60W

• Output power (RMS, <1% THD + N; 2 ohms):

4 x 80W

• Crossover type (12dB/oct., 20Hz – 320Hz; front):

LP/HP/flat

• Crossover type (12dB/oct., 20Hz – 320Hz; rear):

LP/HP/flat

• Signal-to-noise (@ 1W): 85dBA

• Auxiliary outputs

• Backlit JBL logo

• Bass boost (+6dB @ 50Hz): variable

• Dimensions (L x W x H):

305mm x 235mm x 54mm

(12" x 9-1/4" x 2-1/8")

GT5-A3001

450-Watt 1-Channel Power Amplifier

• Class AB

• Output power (RMS, <1% THD + N; 4 ohms):

175W

• Output power (RMS, <1% THD + N; 2 ohms):

225W

• Output power (RMS, <1% THD + N; 1 ohm):

300W

• Crossover type (12dB/oct., 20Hz – 320Hz; sub): LP

• Signal-to-noise (@ 1W): 95dBA

• Auxiliary outputs

• Backlit JBL logo

• Dimensions (L x W x H):

305mm x 235mm x 54mm

(12" x 9-1/4" x 2-1/8")

GT5-10

250mm (10") Single-Voice-Coil

Subwoofer

• Power handling, RMS: 250 watts

• Power handling, peak: 1000 watts

• Frequency response: 30Hz – 500Hz

• Sensitivity: 91dB

• Impedance: 4 ohms

• Polypropylene woofer cone

• I-beam basket

• Progressive spider

• Hi-roll rubber surround

• Mounting depth: 151mm (5-15/16")

GT5-12

300mm (12") Single-Voice-Coil

Subwoofer

• Power handling, RMS: 275 watts

• Power handling, peak: 1100 watts

• Frequency response: 23Hz – 450Hz

• Sensitivity: 93dB

• Impedance: 4 ohms

• Polypropylene woofer cone

• I-beam basket

• Progressive spider

• Hi-roll rubber surround

• Mounting depth: 164mm (6-7/16")

GT5-15

380mm (15") Single-Voice-Coil

Subwoofer

• Power handling, RMS: 300 watts

• Power handling, peak: 1200 watts

• Frequency response: 20Hz – 400Hz

• Sensitivity: 96dB

• Impedance: 4 ohms

• Polypropylene woofer cone

• I-beam basket

• Progressive spider

• Hi-roll rubber surround

• Mounting depth: 185mm (7-5/16")

GT5-1204BR

300mm (12") Bass-Reflex Subwoofer Box

• Power handling, RMS: 275W

• Power handling, peak: 1100W

• Frequency response: 45Hz – 150Hz

• Sensitivity (2,83V @ 1m): 92dB

• Impedance: 4 ohms

• Dimensions (L x D x H):

570mm x 305mm x 369mm

(22-7/16" x 12" x 14-1/2")

GT5-1204BP

300mm (12") Band-Pass Subwoofer Box

• Power handling, RMS: 275W

• Power handling, peak: 1100W

• Frequency response: 35Hz – 100Hz

• Sensitivity (2,83V @ 1m): 90dB

• Impedance: 4 ohms

• Dimensions (L x D x H):

602mm x 342mm x 420mm

(23-11/16" x 13-7/16" x 16-1/2")

GT5-2402BR

300mm (12") Bass-Reflex Subwoofer Box

• Power handling, RMS: 550W

• Power handling, peak: 1600W

• Frequency response: 40Hz – 200Hz

• Sensitivity (2,83V @ 1m): 95dB

• Impedance: 2 ohms

• Dimensions (L x D x H):

889mm x 318mm x 393mm

(35" x 12-1/2" x 15-7/16")

16

Photo by Rudra Sen

JBLC1233.car.euro.ctlg08.vF.qxd 3/6/08 11:20 AM Page 18

GT5-402

100mm (4") 2-Way Coaxial System

• Power handling, RMS: 30W

• Power handling, peak: 90W

• Frequency response: 75Hz – 20kHz

• Sensitivity: 91dB

• Impedance: 4 ohms

• Mounting depth: 47mm (1-7/8")

GT5-502

130mm (5-1/4") 2-Way Coaxial System

• Power handling, RMS: 35W

• Power handling, peak: 105W

• Frequency response: 70Hz – 20kHz

• Sensitivity: 93dB

• Impedance: 4 ohms

• Mounting depth: 53mm (5-1/4")

GT5-500C

130mm (5-1/4") 2-Way Component System

• Power handling, RMS: 40W

• Power handling, peak: 120W

• Frequency response: 70Hz – 20kHz

• Sensitivity: 91dB

• Impedance: 4 ohms

• Mounting depth: 53mm (2-3/16")

GT5-650C

165mm 2-Way Component System

• Power handling, RMS: 50W

• Power handling, peak: 150W

• Frequency response: 55Hz – 20kHz

• Sensitivity: 91dB

• Impedance: 4 ohms

• Mounting depth: 56mm (2-1/4")

GT5-652

165mm 2-Way Coaxial System

• Power handling, RMS: 45W

• Power handling, peak: 135W

• Frequency response: 55Hz – 20kHz

• Sensitivity: 93dB

• Impedance: 4 ohms

• Mounting depth: 56mm (2-1/4")

GT5-803

200mm (8") 3-Way Coaxial System

• Power handling, RMS: 70W

• Power handling, peak: 210W

• Frequency response: 40Hz – 20kHz

• Sensitivity: 92dB

• Impedance: 4 ohms

• Mounting depth: 77mm (3-1/16")

GT5-963

6" x 9" 3-Way Coaxial System

• Power handling, RMS: 70W

• Power handling, peak: 210W

• Frequency response: 50Hz – 20kHz

• Sensitivity: 91dB

• Impedance: 4 ohms

• Mounting depth: 72mm (2-3/16")

18

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
