Panasonic
Feature List
KX-TA1232 • KX-TA624-4
ADVANCED HYBRID TELEPHONE SYSTEM
www.voicesonic.com
Phone: 877-289-2829
S
You have a thriving home business, two kids who
Panasonic KX-TA624, KXTA624, KX TA624, TA624, KX-TA1232, KXTA1232, KX TA1232, TA1232
love to talk on the p h o n e , t h re e t e l e p h o n e l i n e s,
Improve the Lines of Communication in
Your Home with a Panasonic Advanced
Hybrid Telephone System
two computers, two answering m a c h i n e s a n d
Enter a Panasonic
a f a x m a c h i n e. Ne e d l e s s t o s a y, t h e l i n e s o f
Advanced Hybrid
c o m m u n i c a t i o n i n y o u r h o m e a re quite complex.
4/4
4/4
4
Telephone System
Expressly designed to streamline home
communications, an Advanced Hybrid System
organizes your phone lines into a cohesive
system and makes a host of advanced features
Specifications
KX-TA624-4 Control Unit
Capacity:
Intercom Path:
Dialing Method:
Dialing Conversion:
Switching:
Power Failure:
Back Up:
Connections:
Intercom:
Paging:
External Music:
SMDR:
Power Source:
Dimensions (HxWxD):
Weight:
KX-TA1232 Control Unit
3–6 CO lines, 8–24 extensions
4 paths
External – Tone/Pulse (10 pps, 20 pps)
Internal – Tone/Pulse (10 pps, 20 pps)
Tone to pulse or pulse to tone
Space division CMOS Crosspoint Switch
Transfer: 2 CO lines to pre-assigned extensions
Several hours with UPS (depending upon use)
CO lines: Modular Jack (RJ-11)
4 Pin Modular Connector
Phono Jack
2-Conductor Jack
RS-232C Interface Port (D-Sub, 9 Pin)
AC 120 V, 60 Hz
11-3/4" x 14-1/2" x 4"
11.7 lbs.
Capacity:
Intercom Path:
Dialing Method:
Dialing Conversion:
Switching:
Power Failure:
Back Up:
Connections:
Intercom:
Paging:
External Music:
SMDR:
Power Source:
Dimensions (HxWxD):
Weight:
8–12 CO lines, 16–32 extensions
Non-blocking with proprietary phones
External – Tone/Pulse (10 pps, 20 pps)
Internal – Tone/Pulse (10 pps, 20 pps)
Tone to pulse or pulse to tone
Non-blocking PCM Time Sharing
Pre-assigned extensions
Several hours with UPS (depending upon use)
CO lines: Modular Jack (RJ-14C)
Amphenol Connector
Phono Jack
2-Conductor Jack
RS-232C
AC 120 V, 60 Hz
25-3/16" x 12-5/8" x 4.5"
17.8 lbs.
available to each extension in your home.
•
With an Advanced Hybrid System all of your
residential, home office and fax lines can be
accessed from any system phone jack. You can
1
Requires subscription to name-and-number Caller ID service offered by certain telephone companies for a fee. Also requires an optional KX-TA62493 or KX-TA123293 Caller ID card.
Requires an optional KX-TA62491 or KX-TA123291 DISA card. Fax detection is not available on model KX-TA1232.
Requires an optional KX-T30865 Door Phone and an optional KX-TA62460 or KX-TA123260 Door Opener Adapter Card.
4
Distinctive ringing patterns are compatible with Panasonic proprietary phones only.
assign specific lines to each phone, make
2
3
room-to-room intercom calls, forward your calls
See More
Panasonic Manuals
3DQDVRQLF7HOHSKRQH6\VWHPV
www.voicesonic.com
Phone: 877-289-2829
to an outside location, monitor a room, page all
Panasonic Telephone Systems
system extensions and more.
29068 Marion.F4r5
10/25/02
10:16 AM
Page 2
Advanced
Hybrid
System
Telephones
A Variety of Options Enables Customized Solutions
Off-Premises Call Forwarding
The KX-TA1232 system works with all of our KX-T7000 and KX-T7300 series telephones
This feature comes in handy if you’re going to be away from home for awhile and don’t want to miss any calls. Simply
and the KX-T7750, KX-T7720, KX-T7730 and the KX-T7740. The KX-TA624-4 system
program the system to forward your calls to an outside telephone number or to your cellular phone and you can
works with all the phones listed above plus the KX-T7735. In addition both systems
answer your calls wherever you go.
•
operate with our wireless telephones, most single line phones, answering
Direct Inward System Access (DISA) with Outgoing
Message & Fax Detection2
machines, fax machines and modems so you can utilize the equipment
you already own. All the models can be individually programmed so you
If several family members share one telephone line, an optional DISA OGM/FAX Detection Card is a wise choice
can custom tailor the system for your residence.
because it enables outside callers to reach their intended party directly. The caller will hear a message instructing
By adding an optional Panasonic KX-TVS Series Voice Processing
them to dial a single-digit code for the desired party. The caller is then routed to that person’s extension
System, you can enjoy automated attendant service, individual voice-
automatically. With this option, each family member can field their own calls and have their own answering machines,
mail boxes and more—without expensive software or hardware upgrades. With all of
even though they share the same line! DISA card also enables you to call into the system from outside your home
these choices, it’s easy to custom-design a system that’s just right for you.
and utilize one of the system’s lines to make calls. This feature can be helpful when you need to make calls from a
•
Add Wireless
•System
Phone
client’s office or are using a cellular phone.
Expand Your System as Your Needs Grow
Both systems work with standard telephone lines, so you don’t need to upgrade your phone service.
Additionally, if a fax call is received (and a CNG tone is detected) during the outgoing message, the call will be
Model KX-TA624-4 has a base configuration of three central office lines and eight stations. It can easily expand to up
automatically routed to the designated fax extension, eliminating the need for a dedicated fax line. (available on
to six central office lines and 24 stations with the addition of two plug-in cards, models KX-TA62470 and KX-TA62477.
KX-TA624 only)
KX-TA1232
3
The KX-TA1232 is initially configured for eight central office lines and 16 stations. It can expand up to 12 central
office lines and 32 stations with the addition of plug-in card models KX-TA123260 and KX-TA123270.
Door Phone & Door/Gate Opener
Add security to your home with an optional Door Phone and Door/Gate Opener
Adapter Card. With these options installed, our Advanced Hybrid Telephone
Room-to-Room Intercom
Systems can interface with up to four door intercoms and can control up
Finishing up some paperwork in your home office and need to find out if your son is ready for his soccer
to four electronic door contact closures. If you have more than one door intercom,
practice? By using the room-to-room intercom feature, you can call him in his room and get the answer you need
you can assign each one a unique ringing pattern to help you distinguish which
for productivity
and Mobility
KX-TA624-4
4
one was pressed. You can also use these adapter cards to remotely control out-
without leaving your desk.
side lights.
Flexible Line Buttons
You can use the central office (CO) line buttons on each proprietary telephone to access a CO line or
you can program them for one-touch operation of system features like intercom calling, speed dialing or
Room-to-Room Intercom & Paging
Other Great Features
Toll Restriction This feature lets you prohibit certain outgoing calls by restricting selected system extensions from
will ring on each line. Night Mode Great for children’s rooms or a home office, this feature automatically prevents
Single-Line Device Integration
selected extensions from ringing at night. Room Monitor
Panasonic Advanced Hybrid Telephone Systems allow you to connect many types of single-line telephone devices
room from any system phone in the house. The room
❹
Allows you to silently monitor a
being monitored must contain
such as answering machines, cordless phones, fax machines and computer modems, without the need for additional
a proprietary system phone with a built-in speakerphone
Paging Allows you to make
cards or modules. You save money by using equipment that you already own and by avoiding upgrade costs.
a voice announcement simultaneously to all proprietary
phones in the system. Rounding
➎
Call Waiting Caller ID1
The KX-T7135, KX-T7030, KX-T7335 and the KX-T7730 all have a 1 line LCD display that can alternately display Caller
ID name and number. All the displays with the exception of the KX-T7030 are backlit, making it a simple task to locate
the phone and view the display information in the dark or poorly lit
room, Our top of the line KX-T7735 has a 16 character, 3 line backlit LCD that shows both caller ID name and number, at the same time.
●
accessing specified area codes or exchanges. Flexible Ringing Assignment Allows you to program which phones
paging.
KX-T7735 3 Line Backlit LCD Display
call 877-289-2829
or visit:
www.voicesonic.com
up the troops for dinner has never been easier! Conferencing Allows you to combine two calls
from two different lines together, so you can talk to both parties at the same time.
Background Music Connects an appropriate audio source to the system and you can play
music through any proprietary phone with a built-in speakerphone. When the phone rings or the
handset is lifted, the music will temporarily stop. System Speed Dial Lets you program
frequently called numbers into the system for quick and easy dialing from any system phone.
1 Requires subscription to name-and-number Caller ID service offered by certain telephone companies for a fee. Also requires an optional KX-TA62493
or KX-TA123293 Caller ID card.
2 Requires an optional KX-TA62491 or KX-TA123291 DISA card. Fax detection is not available on model KX-TA1232.
3 Requires an optional KX-T30865 Door Phone and an optional KX-TA62460 or KX-TA123260 Door Opener Adapter Card.
4 Distinctive ringing patterns are only compatible with Panasonic proprietary phones.
1
Name & Number Call Waiting Caller ID
●
Off-Premises Call Forwarding
●
Door Phone & Door/Gate Opener3
●
Wireless Telephone & Voice Mail Integration
The KX-T7885 wireless
phone uses 900 MHz operation
and Panasonic Sound Charger™
technology for great range
and crisp, clear sound. Model
KX-TD7895 adds Digital
Spread Spectrum technology
for an even longer range and protection from
eavesdropping. Both models feature flexible
keys that can be programmed to access
central office lines or system functions like
speed dialing. They also have fixed keys
for intercom, hold, redial, conference and
transfer functions.
Choose from a Wide
•Range
of proprietary
System Phones
The Panasonic KX-T7000 and KX-T7700 Series
of proprietary phones offers a wealth of
features from which to choose, so you
can build a system that fits your needs
to a “T”. Flexible CO line buttons,
programmable soft keys, monitor speakers,
automatic redial and headset compatibility
are among the many features available.
Most of the phones even come in two colors:
ash white or matte black.
