Safety Information
Warning
This pictograph intends to alert you to the presence of important operating instructions and
installation instructions. Failure to heed the
instructions may result in severe injury or death.
Warning
Observe the following warnings when using
this unit.
❑ The driver should neither watch the display nor
operate the system while driving.
Watching the display or operating the system will distract
the driver from looking ahead of the vehicle and can cause
accidents. Always stop the vehicle in a safe location and use
the parking brake before watching the display or operating
the system.
❑ Use the proper power supply.
This product is designed for operation with a negative
grounded 12 V DC battery system. Never operate this product with other battery systems, especially a 24 V DC battery
system.
❑ Keep batteries and insulation film out of reach of
infants.
Batteries and insulation film can be ingested, so keep them
out of the reach of infants. If an infant ingests a battery or
insulation film, please seek immediate medical attention.
❑ Protect the Deck Mechanism.
Do not insert any foreign objects into the slot of this unit.
❑ Do not disassemble or modify the unit.
Do not disassemble, modify the unit or attempt to repair the
product yourself. If the product needs to be repaired, consult your dealer or an authorized Panasonic Servicenter.
❑ Do not use the unit when it is out of order.
If the unit is out of order (no power, no sound) or in an
abnormal state (has foreign objects in it, is exposed to
water, is smoking, or smells), turn it off immediately and
consult your dealer.
❑ The remote control unit should not lie about in the
car.
If the remote control unit lies about, it could fall on the floor
while driving, get wedged under the brake pedal, and lead to
a traffic accident.
❑ Refer fuse replacement to qualified service personnel.
When the fuse blows out, eliminate the cause and have it
replaced with the fuse prescribed for this unit by a qualified
service engineer. Incorrect replacement of the fuse may lead
to smoke, fire, and damage to the product.
■ This manual uses pictographs to show you how to use the
product safely and to alert you to potential dangers resulting
from improper connections and operations. The meanings of
the pictographs are explained below. It is important that you
fully understand the meanings of the pictographs in order to
use this manual and the system properly.
Caution
This pictograph intends to alert you to the presence of important operating instructions and
installation instructions. Failure to heed the
instructions may result in injury or material damage.
Observe the following warnings when
installing.
❑ Disconnect the lead from the negative (–) battery
terminal before installation.
Wiring and installation with the negative (–) battery terminal
connected may cause electrical shock and injury due to a
short circuit.
Some cars equipped with the electrical safety system have
specific procedures of battery terminal disconnection.
FAILURE TO FOLLOW THE PROCEDURE MAY LEAD TO THE
UNINTENDED ACTIVATION OF THE ELECTRICAL SAFETY
SYSTEM RESULTING IN DAMAGE TO THE VEHICLE AND
PERSONAL INJURY OR DEATH.
❑ Never use safety-related components for installation, grounding, and other such functions.
Do not use safety-related vehicle components (fuel tank,
brake, suspension, steering wheel, pedals, airbag, etc.) for
wiring or fixing the product or its accessories.
❑ Installing the product on the air bag cover or in a
location where it interferes with airbag operation is
prohibited.
❑ Check for piping, gasoline tank, electric wiring, and
other items before installing the product.
If you need to open a hole in the vehicle chassis to attach or
wire the product, first check where the wire harness, gasoline tank, and electric wiring are located. Then open the hole
from outside if possible.
❑ Never install the product in a location where it interferes with your field of vision.
❑ Never have the power cord branched to supply other
equipment with power.
❑ After installation and wiring, you should check the
normal operation of other electrical equipment.
The continuation of their using in abnormal conditions may
cause fire, electrical shock or a traffic accident.
❑ In the case of installation to an airbag-equipping
car, confirm warnings and cautions of the vehicle
manufacturer before installation.
❑ Make sure the leads do not interfere with driving or
getting in and out of the vehicle.
❑ Insulate all exposed wires to prevent short circuiting.
❑ Do not install the product where it is exposed to
strong vibrations or is unstable.
Caution
Observe the following cautions when using this
unit.
❑ Keep the sound volume at an appropriate level.
Keep the volume level low enough to be aware of road and
traffic conditions while driving.
❑ Do not insert or allow your hand or fingers to be
caught in the unit.
To prevent injury, do not get your hand or fingers caught in
moving parts or in the disc slot. Especially watch out for
infants.
❑ This unit is designed for use exclusively in automobiles.
❑ Do not operate the unit for a prolonged period with
the engine turned off.
Operating the audio system for a long period of time with the
engine turned off will drain the battery.
❑ Do not expose the unit to direct sunlight or excessive heat.
Otherwise these will raise the interior temperature of the
unit, and it may lead to smoke, fire, or other damage to the
unit.
❑ Do not use the product where it is exposed to water,
moisture, or dust.
Exposure of the unit to water, moisture, or dust may lead to
smoke, fire, or other damage to the unit. Make especially
sure that the unit does not get wet in car washes or on rainy
days.
Avoid slanted or strongly curved surfaces for installation. If
the installation is not stable, the unit may fall down while
driving and this can lead to an accident or injury.
❑ Installation Angle
The product should be installed in a horizontal position with
the front end up at a convenient angle, but not more than
30˚.
The user should bear in mind that in some areas there may
be restrictions on how and where this unit must be installed.
Consult your dealer for further details.
❑ Wear gloves for safety. Make sure that wiring is
completed before installation.
❑ To prevent damage to the unit, do not connect the
power connector until the whole wiring is completed.
❑ Do not connect more than one speaker to one set of
speaker leads. (except for connecting to a tweeter)
Observe the following cautions when handling
the battery for the remote control unit.
● Use only specified battery (CR2025).
● Match the polarity of the battery with the (+) and (–) marks
in the battery case.
● Replace dead battery as soon as possible.
● Remove the battery from the remote control unit when not
using it for an extended period of time.
● Insulate the battery (by placing them in a plastic bag or covering them with vinyl tape) before disposal or storage.
Observe the following cautions when
installing.
● Dispose of the battery according to the local regulations.
● Do not disassemble, recharge, heat or short the battery. Do
❑ Refer wiring and installation to qualified service
personnel.
In case of battery leakage
● Thoroughly wipe the battery liquid off the battery case and
Installation of this unit requires special skills and experience.
For maximum safety, have it installed by your dealer.
Panasonic is not liable for any problems resulting from your
own installation of the unit.
❑ Follow the instructions to install and wire the product.
English
ponents of your car audio system carefully before using the
system. They contain instructions about how to use the system in a safe and effective manner. Panasonic assumes no
responsibility for any problems resulting from failure to
observe the instructions given in this manual.
Safety Information
■ Read the operating instructions for the unit and all other com-
not throw a battery into a fire or water.
insert new battery.
● If any part of your body or clothing comes into contact with
battery liquid, wash it with plenty of water.
● If battery liquid comes into contact with your eyes, wash
them with plenty of water and get immediate medical attention.
Not following the instructions to properly install and wire the
product could cause an accident or fire.
❑ Take care not to damage the leads.
When wiring, take care not to damage the leads. Prevent
them from getting caught in the vehicle chassis, screws, and
moving parts such as seat rails. Do not scratch, pull, bend or
twist the leads. Do not run them near heat sources or place
heavy objects on them. If leads must be run over sharp
metal edges, protect the leads by winding them with vinyl
tape or similar protection.
❑ Use the designated parts and tools for installation.
Use the supplied or designated parts and appropriate tools
to install the product. The use of parts other than those supplied or designated may result in internal damage to the unit.
Faulty installation may lead to an accident, a malfunction or
fire.
❑ Do not block the air vent or the cooling plate of the
unit.
Blocking these parts will cause the interior of the unit to
overheat and will result in fire or other damage.
2
CQ-C8401U/C8301U/C7401U/C7301U
CQ-C8401U/C8301U/C7401U/C7301U
3
Safety Information (continued)
Before Reading These Instructions
The following applies only in the U.S.A.
Caution
XXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXXX
XXXXXXXXXXXXXX
XXXXXXXXXXXXXXXX
OO-OOOOO
English
THIS PRODUCT IS A CLASS I LASER PRODUCT.
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE
OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN
MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR BY YOURSELF.
REFER SERVICING TO QUALIFIED PERSONNEL.
Part 15 of the FCC Rules
FCC Warning:
Any unauthorized changes or modifications to this
equipment would void the user's authority to operate
this device.
Operating
Instructions
Installation
Instructions
(YEFM285591)
(YEFM293907)
Owners
Information Card
Removable Face
Plate Case
(YEFA131646)
Instruction kit
Q'ty: 1
POWER
SOURCE MENU
SEL
SRC
VOL
SET
BAND
MUTE
1
2
3
RANDOM
SCAN
REPEAT
4
5
7
8
9
0
DISP
6
TUNE
TUNE
#
NUMBER
Before Reading These Instructions
Differences Among 4 Models
Panasonic welcomes you to our constantly growing family of electronic products owners.
We endeavor to give you the advantages of precise electronic and mechanical engineering, manufactured with carefully
selected components, and assembled by people who are proud of the reputation their work has built for our company. We
know this product will bring you many hours of enjoyment, and after you discover the quality, value and reliability we have
built into it, you too will be proud to be a member of our family.
This operating instruction manual is for 4 models CQ-C8401U, CQ-C8301U CQ-C7401U and CQ-C7301U.
The difference among these models’ are mentioned below.
All screens and main body illustrations in this book represent CQ-C8401U unless otherwise specified.
Accessories
CAR AUDIO
Remote Control Unit
(including a battery)
(CR2025)
Power Connector
Mounting Collar
Trim Plate
(EUR7641010)
(YEAJ02871)
(YEFX0217222)
(YEFC05654)
Q'ty: 1
Lock Cancel Plate
Q'ty: 1
Mounting Bolt
Q'ty: 1
Q'ty: 1
Tapping Screw
(5 mmø x 16 mm)
Hex. Nut
(5 mmø)
(YEP0FZ5701)
Features
Models
Maximum Power Output
CQ-C8401U
CQ-C8301U
CQ-C7401U
CQ-C7301U
60 W
50 W
50 W
50 W
Subwoofer-output
5V
5V
5V
Preout
5V
5V
5V
2.5 V
2.5 V
CH/AUX-IN Cord *1
No
No
Yes
Yes
AUX1-IN Cord *2
Yes
Yes
No
No
CH/AUX2-IN Cord *1
Yes
Yes
No
No
*1 You can connect only one of a changer, an XM receiver and other commercially available portable audio
equipment.
*2 You can connect commercially available portable audio equipment and the like.
Q'ty: 1 set
Notes:
¡ The number in parenthesis underneath each accessory part name is the part number
for maintenance and service.
¡ Accessories and their parts numbers are subject to modification without prior notice
due to improvements.
¡ Mounting Collar and Trim Plate are mounted on the main unit at shipment.
Safety Information, Before Reading These Instructions
Q'ty: 1 set
Rear Support Strap
(YEFG04019)
Q'ty: 1
4
CQ-C8401U/C8301U/C7401U/C7301U
CQ-C8401U/C8301U/C7401U/C7301U
5
Before Reading These Instructions
Customer Services Directory
Accessory Purchases:
Purchase Parts, Accessories and Instruction Books
online for all Panasonic Products by visiting our Web
Site at:
http://www.pasc.panasonic.com
or, send your request by E-mail to:
[email protected]
You may also contact us directly at:
1-800-332-5368 (Phone) 1-800-237-9080 (Fax Only)
(Monday-Friday 9 am to 8 pm, EST.)
Panasonic Services Company
20421 84th Avenue South, Kent, WA 98032
(We accept Visa, MasterCard, Discover Card, American
Express, and Personal Checks)
For hearing or speech impaired TTY users, TTY : 1-866605-1277
Service in Puerto Rico
Matsushita Electric of Puerto Rico, Inc.
Panasonic Sales Company
Factory Servicenter:
Ave. 65 de Infantería, Km. 9.5, San Gabriel Industrial
Park,
Carolina, Puerto Rico 00985
Phone (787) 750-4300, Fax (787) 768-2910
PANASONIC CONSUMER ELECTRONICS COMPANY,
DIVISION OF MATSUSHITA ELECTRIC CORPORATION OF AMERICA
One Panasonic Way, Secaucus, New Jersey 07094
WARRANTY SERVICE
For product operation and information assistance,
please contact your Dealer or our Customer Care Centre
at:
Telephone #: (905) 624-5505 Fax #: (905) 238-2360
Web: www.panasonic.ca
For product repairs, please contact one of the following:
・Your Dealer who will inform you of an authorized
Servicentre nearest you.
・Our Customer Care Centre at (905) 624-5505 or
www.panasonic.ca
・A Panasonic Factory Servicentre listed below:
Richmond, British
Columbia
Panasonic Canada Inc.
12111 Riverside Way
Richmond, BC V6W 1K8
Tel: (604) 278-4211
Fax: (604) 278-5627
Mississauga, Ontario
Panasonic Canada Inc.
5770 Ambler Dr.
Mississauga, ON L4W 2T3
Tel: (905) 624-8447
Fax: (905) 238-2418
WARRANTIES, INCLUDING THE WARRANTY OF MERCHANTABILITY, ARE LIMITED TO THE PERIOD OF THE LIMITED WARRANTY.
U.S.A.
PANASONIC SALES COMPANY,
DIVISION OF MATSUSHITA ELECTRIC OF PUERTO RICO, INC.
Ave. 65 de infanteria, Km. 9.5, San Gabriel Industrial Park
Carolina, Puerto Rico 00985
LIMITED WARRANTY COVERAGE
If your product does not work properly because of defects in materials and workmanship.
Panasonic Consumer Electronics Company or Panasonic Sales
Company (collectively referred to as “the warrantor”) will, for the
length of the period indicated in the chart below, which starts with
the date of original purchase (“warranty period”), at its option either
(a) repair your product with new or refurbished parts, or (b) replace
it with a new or refurbished product. The decision to repair or
replace will be made by the warrantor.
During the “Labor” warranty period, there will be no charge for
labor. During the “Parts” warranty period, there will be no charge for
Categories
Lachine, Quebec
Panasonic Canada Inc.
3075, rue Louis A. Amos
Lachine, QC H8T 1C4
Tel: (514) 633-8684
Fax: (514) 633-8020
This warranty gives you specific legal rights and you may also have
other rights which vary from state to state. If a problem with this
product develops during or after the warranty period, you may contact your dealer or Servicenter. If the problem is not handled to your
satisfaction, then write to warrantor’s Consumer Affairs Department
at the addresses of the warrantor.
PANASONIC AUTO PRODUCTS
LIMITED WARRANTY
Calgary, Alberta
Panasonic Canada Inc.
6835-8th St. N. E. Calgary,
AB T2E 7H7
Tel: (403) 295-3955
Fax: (403) 274-5493
Parts
Labor
Audio Components (except items listed
below)
MXE Series Audio Components (except
items listed below)
Speakers
One (1) Year
One (1) Year
Two (2) Years
Two (2) Years
One (1) Year
Not Applicable
Accessories (in exchange for defective
items)
Ninety (90) Days Not Applicable
parts. You must carry in or mail in your product during the warranty
period. If non-rechargeable batteries are included, they are not warranted. This warranty only applies to products purchased and serviced in the United States or Puerto Rico. This warranty is extended
only to the original purchaser of a new product which was not sold
“as is”. A purchase receipt or other proof of the original purchase
date is required for warranty service.
CARRY-IN OR MAIL-IN SERVICE
For Carry-In or Mail-In Service in the United States, call 1-800-211PANA (7262) or visit
Panasonic Web Site: http://www.panasonic.com
For assistance in Puerto Rico, call Panasonic Sales Company (787)750-4300 or fax (787)-768-2910.
LIMITED WARRANTY LIMITS AND EXCLUSIONS
This warranty ONLY COVERS failures due to defects in materials and
workmanship, and DOES NOT COVER normal wear and tear or cosmetic damage. The warranty ALSO DOES NOT COVER damages
which occurred during shipment, failures which are caused by products not supplied by the warrantor, failures which result from accident, misuse, abuse, neglect, mishandling, misapplication, alteration, faulty installation, set-up adjustment, maladjustment of consumer control, improper maintenance, improper antenna, inadequate
signal reception or pickup, power line surge, improper voltage supply, lightning, modification, commercial use (such as use in hotels,
offices, restaurants, or other business uses) or rental use of the
product, or service by anyone other than the technician from Factory
Servicenter or other authorized service centers, or damage that is
attributable to acts of God.
THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED
UNDER “LIMITED WARRANTY COVERAGE”. THE WARRANTOR IS
NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES
RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT
OF ANY BREACH OF THIS WARRANTY. (As examples, this excludes
damages for lost time, cost of having someone remove or re-install
an installed unit if applicable, travel to and from the sevicer, and loss
of media, data or other memory contents. The items listed are not
exclusive, but are for illustration only.) ALL EXPRESS AND IMPLIED
6
CQ-C8401U/C8301U/C7401U/C7301U
Some states do not allow the exclusion or limitation of incidental or
consequential damages, or limitations on how long an implied warranty lasts, so the exclusions may not apply to you.
PARTS AND SERVICE WHICH ARE NOT COVERED BY THIS LIMITED
WARRANTY ARE YOUR RESPONSIBILITY.
Customer’s Record
Model
No.
Serial
No.
Dealer’s
No.
Code
No.
Dealer’s
Address
Date of
Purchase
CANADA
Panasonic Canada Inc.
5770 Ambler Drive, Mississauga Ontario L4W 2T3
PANASONIC PRODUCT LIMITED WARRANTY
Panasonic Canada Inc. warrants this product to be free from defects
in materials and workmanship and agrees to remedy any such defect
for a period as stated below from the date of original purchase.
CAR AUDIO PRODUCT – ONE (1) YEAR, PARTS AND LABOUR
(The labour to install or remove the product is not warranted)
Before Reading These Instructions
Obtain Product Information and Operating Assistance;
locate your nearest Dealer or Servicenter; purchase
Parts and Accessories; or make Customer Service and
Literature requests by visiting our Web Site at:
http://www.panasonic.com/support
or, contact us via the web at:
http://www.panasonic.com/contactinfo
You may also contact us directly at:
1-800-211-PANA (7262),
Monday-Friday 9 am-9 pm; Saturday-Sunday 10 am-7
pm, EST.
For hearing or speech impaired TTY users, TTY : 1-877833-8855
CANADA
Limited Warranty
U.S.A.
LIMITATIONS AND EXCLUSIONS
This warranty does not apply to products purchased outside Canada
or to any product which has been improperly installed, subjected to
usage for which the product was not designed, misused or abused,
damaged during shipping, or which has been altered or repaired in
any way that affects the reliability or detracts from the performance,
nor does it cover any product which is used commercially. Dry cell
batteries are also excluded from coverage under this warranty.
This warranty is extended to the original end user purchaser only. A
purchase receipt or other proof of the original purchase date is
required before warranty service is performed.
THIS EXPRESS, LIMITED WARRANTY IS IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
IN NO EVENT WILL PANASONIC CANADA INC. BE LIABLE FOR ANY
SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES.
In certain instances, some jurisdictions do not allow the exclusion or
limitation of incidental or consequential damages, or the exclusion of
implied warranties, so the above limitations and exclusions may not
be applicable.
IF YOU SHIP THE PRODUCT TO A SERVICENTRE
Carefully pack and send prepaid, adequately insured and preferably
in the original carton.
Include details of the defect claimed, and proof of the date of original
purchase.
CQ-C8401U/C8301U/C7401U/C7301U
7
Features
Contents
Full lineup of optional parts
Sound Control
SQ (Sound Quality)
You have six preset modes (FLAT, ROCK, POP, VOCAL, JAZZ,
CLUB). You can customize your settings for these (except
FLAT) and save them for instant recall.
SQ7 (7-Band Sound Quality)
The level is adjustable in each of seven bands. This lets you
fine tune sound quality for each genre to suit car-interior
acoustics and your personal preferences.
The XM name and related logos are trademarks of XM Satellite
Radio Inc.
Notes:
¡A changer and an XM receiver are not connectable at the
same time.
¡ To connect the XM receiver (XMD1000), it is required to use
an optional extension cord (XMDPAN100) that is produced by
XM exclusively for Panasonic products.
Customize
Initially stored moving images and still images are editable to
taste. IMAGE STUDIO* allows you to process images from a
digital camera or other devices without difficulty. ( a page 37)
* This software is downloadable from Panasonic Web site
(http://panasonic.co.jp/pas/en/software/customize/index.html)
.
Français
46
Español
90
Common
Fully Motorized Front Panel
A touch is all it takes to slide the front panel down for access to
the disc slot. A three-stage tilt function permits viewing angle
to be adjusted to 15, 25 or 35 degrees for optimum display
visibility.
English
¡Safety Information
¡Before Reading These Instruction
¡Features
¡Controls Layout
¡Preparation
¡General
2
4
8
10
12
14
Each Source
WMA MP3 CD Player/Receiver with Full Dot Matrix Display
An optional XM tuner allows you to receive the XM radio
service. A DVD changer instead of an XM tuner is also
connectable.
¡ Toll free number
XM Tuner P/N: XMD1000
Call 1-800-XM-RADIO(96-72346)
Extension cord P/N: XMDPAN100
Call 1-800-942-TERK(8375)
¡Radio
¡CD Player
¡MP3/WMA Player
¡XM Tuner
¡Disc Changer
20
22
24
28
30
As Needed
CQ-C8401U/C8301U/C7401U/C7301U
¡Audio Setting
¡Function Setting
¡Display Setting
¡Customize the Display
¡Troubleshooting
¡Error Display Messages
¡Notes on Discs
¡Maintenance
¡Specifications
34
35
36
37
39
42
44
44
45
Delightful sound space thanks to system buildup
XM Receiver
XMD1000: manufactured by XM
Satellite Radio
(Option)
Headrest Monitor: CY-V7100U (Option)
CQ-C8401U/C8301U
CQ-C7401U/C7301U
Head unit
DVD Changer
CX-DH801U
(Option)
Stereo/Mono
Power Amplifier (Option)
8
Sub-Woofer
(Option)
*You can connect only one of a changer, an XM receiver
and other commercially available portable audio
equipment.
CQ-C8401U/C8301U/C7401U/C7301U
CQ-C8401U/C8301U/C7401U/C7301U
9
Controls Layout
Note: This instruction manual explains operations for use with the buttons on the main unit. (Different operations excluded)
0
#
TILT
OPEN (eject)
BAND
SRC
SQ Sound Quality
MENU
DIM Dimmer
SRC Source
PWR Power
y / 5 Pause/Play
BAND
SET
APM Auto Preset
Main Unit
Memory
SRC
CQ-C8401U
Number
POWER
SRC (SOURCE)
VOL
MENU
SEL
POWER
SOURCE
SEL Select
MENU
SRC
VOL Volume
}:Up
{:Down
RANDOM
4
RANDOM
POWER
SOURCE MENU
SEL
SRC
SCAN
5
REPEAT
6
7
SCAN
REPEAT
9
VOL
SET
SET
BAND
BAND
MUTE
1
2
3
RANDOM
SCAN
REPEAT
4
5
6
7
8
9
0
DISP
BAND
Pause/Play
SET
APM Auto Preset
MUTE
TUNE
Memory
MUTE
SBC·SW Super Bass
Control·Subwoofer
TUNE
#
TUNE
TRACK (FILE)
NUMBER
DISP
DISP Display
CAR AUDIO
8
0
P·SET (Preset)
DISC (FOLDER)
TUNE
TRACK (FILE)
One-touch operation is available for selecting a track
playing style by use of [4] (RANDOM), [5] (SCAN), or
[6] (REPEAT). (For a Folder/Disc playing style, hold
down the same button for 2 sec. or more.)
D·M Direct Memory
DISP Display
Release
When Face Plate
Opens
Disc slot
CQ-C8401U/C8301U/C7401U/C7301U
Functions Only by Remote Control Unit
MUTE
SBC·SW Super Bass
Control·Subwoofer
10
9
Controls Layout
P·SET Preset
DISC (FOLDER)
VOLUME
PUSH SEL Select
Remote Control Unit
NUMBER
–
English
Number Buttons
Direct Access
A channel (XM mode), a track (CD mode), a disc (Disc
changer), a file and a folder (MP3/WMA mode) can be
directly selected.
Example: Track number 5
1 Press [#] (NUMBER).
2 Press [5].
3 Press [BAND] (SET).
CQ-C8401U/C8301U/C7401U/C7301U
11
SRC
CQ-C8401U
Security Function
Setting
1 Set your car's ignition switch to the ACC
or On position.
(DEMONSTRATION)
First Time Power On
The demonstration screen appears.
2 Press [DISP] (Display).
The demonstration screen is cancelled, and no more
appears.
3 Press [SRC] (PWR: Power).
Note: If you would like to turn on the power and make
the demonstration message appear, hold down [SRC]
(PWR: Power) for 4 sec. or more after turning off the
power in other than the XM mode.
The following functions are activated when the Security
Function is ON. (a page 35)
¡ The security indicator lights up when removing the
face plate.
Security Indicator
You may need to set the following depending on the
devices to be connected.
Using Subwoofer
Warning
Keep batteries and insulation film out of reach of
infants. If an infant ingests a battery, please seek
immediate medical attention.
Pull the insulation film out
from the backside of
remote control gently.
Other Settings
¡ Subwoofer level adjustment (a page 34)
¡ Subwoofer low pass filter (a page 34)
Preparation Before Initial Use
Cautions
Battery Replacement
Tough pointed object
q Remove the battery holder
with the remote control unit
placed on a flat surface.
q Stick your thumbnail into
the groove, and push the
holder in the direction of
the arrow, and at the
same time.
w
w Pull it out in the direction
q
of the arrow using a
tough pointed object.
Back side
w Put a battery in the case
with (+) side facing up.
e Put the case back.
Connecting XM tuner
¡ Connect the optional XM receiver (XMD1000).
¡ To connect the XM receiver (XMD1000), it is required
to use an optional extension cord (XMDPAN100) that is
produced by XM exclusively for Panasonic products.
Getting Started
It is required to sign up to become an XM Satellite Radio
subscriber. After checking your XM Satellite Radio ID,
sign up on the XM’s website or by calling them.
Note: Battery Information:
Battery Type: Panasonic lithium battery (CR2025)
(Included in the remote control)
Battery Life: Approximately 6 months under normal use
(at room temperature)
2
Note: Adjust the clock when “ADJUST” appears on the
display.
XM receiver (XMD1000).
¡ Radio ID also can be found by turning your XM Radio
to channel 0. (a page 28.)
2 Activate the XM Satellite Radio
Select either of the below to sign up.
¡ Web site: http://www.xmradio.com/activation
¡ Phone number: 1-800-XM-RADIO (1-800-967-2436)
Note: Refer to the operating instructions for the XM
receiver for details.
CQ-C8401U/C8301U/C7401U/C7301U
5 Adjust the setting value.
1 Press [MENU] to display the menu
display.
For using the remote control, hold down [SEL]
(MENU) for 2 sec. or more.
2 Press []] or [[] to display the
DISPLAY menu.
3 Press [{] to select “CLOCK ADJ”.
4 Press [BAND] (SET) to confirm the
display.
3
12
Check of XM Satellite Radio ID
1
¡ Write down the ID indicated on the lower right of your
¡Remove and dispose of an old battery immediately.
¡Do not disassemble, heat or short a battery. Do not
throw a battery into a fire or water.
¡Follow local regulations when disposing of a battery.
¡Improper use of a battery may cause overheating, an
explosion or ignition, resulting in injury or a fire.
Clock adjustment
Remote Control Preparation
Insulation film
¡ The alarm sounds and the message appears on the
screen to warn you to remove the face plate at ACC
off.
Preparation
The demonstration message appears for first use.
English
Preparation
[[]: Adjusting minutes
[]]: Adjusting hours
[}]: Forward
[{]: Backward
6 Press [BAND] (SET) to confirm the
adjustment.
7 Press [MENU].
For using the remote control, hold down [SEL]
(MENU) for 2 sec. or more.
CQ-C8401U/C8301U/C7401U/C7301U
13
General
This chapter explains how to turn on or off the power, how to adjust the volume, etc.
Open/Eject
(PWR: Power)
Power On/off
Power off
Hold down [SRC] (PWR) until you hear a
beep, then release it.
Note: The ending screen appears. You can change the
ending screen (moving image). (a page 37)
3 Put the face
] (OPEN).
When a disc is already loaded, the disc will automatically
be ejected.
plate in the case.
SRC
English
Note: The opening screen appears. You can overwrite
opening screen (moving image) with new one. (a page
37)
You can remove the face
plate to prevent it from
being stolen.
Press [
CQ-C8401U
(OPEN/CLOSE, TILT)
SRC
Face Plate Motion (Open/Close, Tilt)
Press [SRC] (PWR: Power).
CQ-C8401U
Tilt
Cautions:
¡ To avoid damaging the face plate, do not push it
down or place objects on it while it is open.
¡ Do not pinch your finger or hand in the face plate.
¡ Do not insert foreign objects into the disc slots.
¡ For the following cases, the face plate automatically closes. Use caution not to catch your finger.
¡ After a lapse of 20 seconds
¡ When a disc is inserted
¡ When the face plate is removed (a page 14)
Note: The last selected
angle is memorized even
after turning off the power.
Close
Press [
The display angle changes among 4 levels as follows
every time you hold down [
] (TILT) for 1 sec. or
more and release.
General
Power on
TILT 1
TILT 2
TILT 3
OPEN
] (OPEN).
14
place.
CQ-C8401U
(The face plate disengages with a click
when it is removed.)
2 Press the right end of the face plate
until “click” is heard.
The face plate automatically closes after a lapse of 5
seconds while it is open.
The power is automatically turned off while the unit
is active.
Cautions:
¡ It is recommended to remove or mount the face
plate when the plate is at the closed position.
Do not remove or mount the face plate when the
plate is in motion.
¡ This face plate is not waterproof. Do not expose it to
water or excessive moisture.
¡ Do not remove the face plate while driving your car.
¡ Do not place the face plate on the dashboard or
nearby areas where the temperature rises to high
levels.
¡ Do not touch the contacts on the face plate or on the
main unit, since this may result in poor electrical
contacts.
¡ If dirt or other foreign substances get on the contacts, wipe them off with clean and dry cloth.
¡ To avoid damaging the face plate, do not push it
down or place objects on it while it is open.
CQ-C8401U/C8301U/C7401U/C7301U
Setting Range: 0 to 40
Default: 18
Notes:
¡ The volume level can be set independently for each
source. (For radio, one volume setting for AM, one
volume setting for all FMs)
¡ The volume is not adjustable while an error display is
on the monitor. (a page 42)
Volume off (down)
Press [
MUTE (ATT: Attenuation)
1 Slide the left side of the face plate in
q Up
w Down
(VOLUME)
1 Turn off the power (a page 14)
2 Press [ ]
Volume Adjustment
Mounting
Temporary Volume Off (Down)
Removing
(Release).
(Anti-Theft System)
Face Plate Removing/Mounting
TILT OFF
] (MUTE).
SRC
CQ-C8401U
Cancel
Press [
] (MUTE) again.
Note: Volume-down range can be specified. (a page
35)
CQ-C8401U/C8301U/C7401U/C7301U
15
SRC
Radio
The display changes as follows every time [DISP] is
pressed.
Note: The graphic pattern and still image are selectable. (a
page 36)
CQ-C8401U
At power-on:
Auxiliary (AUX or AUX 2)
FM1, FM2, FM3, AM (a page 20)
Mode
When connecting CD Changer, DVD Changer
(a page 30, 32)
Display OFF
All displays disappear in 5 seconds.
Folder hierarchy (for CQ-C8401U/C8301U, MP3/WMA
mode only.)
When connecting a device that is not
controlled by this unit.
(DISP: Display)
When loading CD (a page 22)
Display Change
(SOURCE)
Source Selection
When connecting XM Tuner (a page 28)
Player
CQ-C8401U
SRC
Ordinary display + graphic pattern
Only still image
Ordinary display + still image
Only graphic pattern
When loading MP3/WMA disc (a page 24)
Ordinary display + clock
General
The source changes as follows every time [SRC]
(Source) is pressed.
English
General
CQ-C8401U/C8301U
Auxiliary (AUX1)
Only for CQ-C8401U/C8301U
Note: The graphic equalizer of 19 bands is
selectable when selecting a still image.
When connecting a device that is not controlled by this
unit
CQ-C7401U/C7301U
Clock display (Default)
Off
The rear speaker can be used as a substitutional
subwoofer when a subwoofer is not connected.
The dimmer level changes as follows every time you hold
down [MENU] (DIM:Dimmer) for 2 sec. or more.
SRC
CQ-C8401U
Off (default)
On
Note: If ON is selected, the settings of subwoofer level
adjustment and subwoofer low pass filter are activated.
(a page 34)
CQ-C8401U/C8301U/C7401U/C7301U
Lights when activated.
Brighter (Default)
(DIM: Dimmer)
Holding down [ ] (SBC·SW) for 2 sec. or
more toggles SBC-SW on and off.
Dimmer Control
(SBC-SW: Super Bass Control·Subwoofer)
Substitutional Subwoofer
Note: Please connect a CD changer or a DVD changer
to CH/AUX2 (CQ-C8401U/C8301U), CH/AUX (CQC7401U/C7301U). (a Installation Instructions)
16
At power-off:
SRC
CQ-C8401U
Medium
Darker
Note: This setting is not adjustable with the remote
control.
CQ-C8401U/C8301U/C7401U/C7301U
17
General
SRC
You can make fine adjustments to the currently selected
SQ presetting in ROCK, POP, VOCAL, JAZZ, or CLUB in
accordance with your car type or taste.
CQ-C8401U
SRC
CQ-C8401U
English
The sound type each of which is adjusted with 7 bands
changes every time you press [SQ].
1 Hold down [SQ] (Sound Quality) for 2
sec. or more.
1. FLAT
(default)
4 Hold down [}] or [{] for 2 sec. or
6. CLUB
more to confirm your adjustment.
The targeted SQ preset appears.
2. ROCK
Note: If you press [DISP], the presetting is canceled. The presetting is active until another SQ preset is called up.
3. POP
18
Notes:
¡ Setting of SQ, bass/treble and volume are influenced
one another. If the influence mentioned above causes
distortion to the audio signal, readjust bass/treble or
volume.
¡ Each SQ (except FLAT) level is changeable. (a page
19)
CQ-C8401U/C8301U/C7401U/C7301U
[[]: Higher frequency
[]]: Lower frequency
q : Level Up
w : Level Down
Lights when activated.
Change of SQ Presetting
(SQ: Sound Quality)
SQ Selection Based on Genre
4. VOCAL
3 Hold down [}] or [{] for 2 sec. or
more to confirm your adjustment.
The existing adjustment is overwritten with new
adjustment.
Notes:
¡ FLAT is not changeable.
¡ If no operation takes place for more than 10 seconds, the display returns to the regular mode.
¡ This adjustment is executable in the AUDIO menu
as well. (a page 34)
¡ If you hold down [BAND] for 2 sec. or more on
the SQ call-up screen, the presetting that is called
up can be turned into the default.
General
2 Adjust each frequency.
5. JAZZ
Note: You can select a SQ preset to be targeted
with [}] and [{] (and [2]-[6] on the remote control).
CQ-C8401U/C8301U/C7401U/C7301U
19
Radio
This chapter explains how to listen to the radio.
SRC
CQ-C8401U
radio mode.
Operation Flow
3 Select a station.
[]] (TUNE): Lower
[[] (TUNE): Higher
Note: Hold down for 0.5 sec. or more and release
for station search.
Preset station selection
[{] (P·SET: Preset): Lower preset number
[}] (P·SET: Preset): Higher preset number
Station Preset
Frequency adjustment
Band
Frequency
Manual station preset
1 Tune in to a station.
2 Hold down [}] or [{] for 2 sec. or
more.
3 Select a preset number by pressing [}]
or [{].
the station by holding down [}]
4 Preset
or [{] for 2 sec. or more.
Stations with good receiving conditions automatically
preset.
1 Select a band.
2 Hold down
CQ-C8401U
Frequency/preset number blinks once.
[BAND] (APM)
for 2 sec. or
more.
Notes:
¡ New stations overwrite existing saved stations.
¡ In step 2, a station can be registered by holding down
the numeric button [1] to [6] for 2 sec. or more.
¡ To stop presetting stations, press [DISP] (Display).
1 Press [MENU] to display the menu dis-
Indicates the intensity of
the radio wave.
play.
For using the remote
control, hold down
[SEL](MENU) for 2
sec. or more.
Preset Number
D•M station Calling
Press [D.M] (Direct Memory).
D•M station Setting
q Select a station you would like to preset.
w Hold down [D.M] (Direct Memory) for 2 sec. or
more.
SRC
CQ-C8401U
Radio
Note: New stations overwrite existing saved stations.
You can assign your favorite broadcasting station to
the [D·M] button. As the result of doing that, your
favorite broadcasting station can be received even if
the unit is in the CD mode, CD changer mode, XM
mode or AUX mode. (Default: FM 87.9 MHz)
Direct Memory
Auto Preset Memory (APM)
The preset stations under best receiving conditions
are received for 5 sec. each after presetting the stations (SCAN). To stop scanning, press [}] or [{].
Radio Menu Display
Radio Mode Display
Note: Direct selection can be executed with [1] to
[6] buttons on remote control.
(APM: Auto Preset Memory, P·SET: Preset)
2 Press [BAND] to select a band.
Up to 6 stations can be preset in AM, FM1, FM2, and FM3
respectively.
Preset stations can be simply called up by pressing [}]
(P·SET) or [{] (P·SET).
Notes:
¡ Direct selection can be executed with [1] to [6] buttons on remote control.
¡ You can switch between 6 and 18 for FM presetting
stations.
¡ Preset stations are changeable.
English
1 Press [SRC] (Source) to select the
CQ-C8401U
AUTO PRESET
Preset range for FM bands
2 Press [}] or [{] to select a mode to be
adjusted.
3 Press [BAND]
(SET) to adjust.
: Individual setting for FM1-3 each
: Setting of FM1-3 together
PRESET EDIT
CQ-C8401U
Replacement of preset station
[}] [{] : Selection
[BAND] : Locked
4 Press [MENU] to confirm the adjustment.
For using the remote control, hold down [SEL]
(MENU) for 2 sec. or more.
20
CQ-C8401U/C8301U/C7401U/C7301U
CQ-C8401U/C8301U/C7401U/C7301U
21
When a disc is already loaded, press [SRC] (Source) to
select the CD mode.
] (OPEN) to open the face
lights), the disc
2 Load a disc with the label-side facing up.
The face plate closes automatically, and the unit recognizes the disc and starts playing automatically,
too.
3 Select a desired portion.
Track selection
Random and Repeat play can be set.
[7] (TRACK): Next track
[6] (TRACK): Preceding track (press twice)
Note: Hold down for fast forward/reverse.
Pause
Press [BAND] (h / 5).
Press again to cancel.
4 Press [
] (OPEN) to eject the disc.
Track number
Time
1 Press [MENU] to display the menu display.
For using the remote
control, hold down
[SEL] (MENU) for 2
sec. or more.
CQ-C8401U
RANDOM
: Off
: Random playback
(RANDOM, REPEAT)
Operation Flow
When a disc is already loaded (
will automatically be ejected.
CQ-C8401U
SRC
¡ Refer to the section on “Notes on CD/CD Media (CD-ROM,
CD-R, CD-RW)” (a page 44).
¡ This unit does not support a MIX mode CD (a CD containing
both CD-DA and MP3/WMA data). In case of using such a
CD, problems may occur such as anacoustic playback.
2 Press [}] or [{] to select a mode to be
adjusted.
: Off
3 Press [BAND]
(SET) to adjust.
REPEAT
: Playing the current track repeatedly
CQ-C8401U
TEXT (CD-TEXT)
: Enabled (Default)
: Disabled
4 Press [MENU] to confirm the adjustment.
CD Player
plate.
Random, Repeat Play (CD Menu Display)
1 Press [
Cautions:
¡ This unit does not support 8 cm (3”) discs.
¡ Do not use irregularly shaped discs. (a page 44)
¡ Do not use discs that have a seal or label attached.
¡ To avoid damaging the face plate, do not push it down or
place objects on it while it is open.
¡ Do not pinch your finger or hand in the face plate when the
face plate is in motion.
¡ Do not insert foreign matter into the disc slots.
English
CD Player
22
Play Mode Selection
CD-TEXT display
Notes:
¡ For scrolling text, hold down [DISP] for 2 sec. or
more.
¡ “NO TEXT” is displayed when there is no information
on the disc.
Play Mode indicators
Lights when each mode is
activated.
CQ-C8401U/C8301U/C7401U/C7301U
Lights when the disc is
loaded.
Functions Only by
Remote Control Unit
CD Mode Display
For using the remote control, hold down [SEL]
(MENU) for 2 sec. or more.
SCAN play
One-touch operation is available for selecting a track
playing style by use of [RANDOM] or [REPEAT].
RANDOM
Press [RANDOM].
Press again to cancel.
REPEAT
Press [REPEAT].
Press again to cancel.
You can find your favorite file by playing first 10-sec. of
each track.
Press [SCAN].
Press again to cancel.
Direct Access
A track can be directly selected.
Example: track number 5
1 Press [#] (NUMBER).
2 Press [5].
3 Press [SET].
Note: To suspend direct
selection, press [DISP] (Display).
CQ-C8401U/C8301U/C7401U/C7301U
23
MP3/WMA Player
CQ-C8401U
SRC
] (OPEN) to open the face
plate.
When a disc is already loaded (
will automatically be ejected.
lights), the disc
2 Load a disc with the printed-side facing 3 Select a desired portion.
Random and Repeat play can be set.
1 Press [MENU] to display the menu dis-
Folder selection
[}] (FOLDER): Next folder
[{] (FOLDER): Preceding folder
File selection
[7] (TRACK): Next file
[6] (TRACK): Preceding file (press twice)
Note: Hold down for fast forward/reverse.
Pause
Press [BAND] (h / 5).
Press again to cancel.
4 Press [
] (OPEN) to eject the disc.
File number
Time
Folder number
play.
For using the remote
control, hold down
[SEL] (MENU) for 2
sec. or more.
RANDOM
: Off
: Random playback (disc)
CQ-C8401U
FOLDER RANDOM
: Off
(RANDOM, REPEAT)
The face plate closes automatically, and the unit recognizes the disc and starts playing automatically,
too. (It may take several minutes to start for a disc
that has a lot of files.)
Random, Repeat Play (MP3/WMA Menu Display)
Operation Flow
up
English
1 Press [
Notes:
¡ Refer to the section on “Notes on MP3/WMA” (a page 26)
¡ This unit does not support a MIX mode CD (a CD containing
both CD-DA and MP3/WMA data). In case of using such a
CD, problems may occur such as anacoustic playback.
2 Press [}] or [{] to select a mode to be
adjusted.
3
Press [BAND]
(SET) to adjust.
: Random playback (folder)
REPEAT
: Off
CQ-C8401U
: Playing the current file repeatedly
FOLDER REPEAT
4 Press [MENU] to
: Off
confirm the adjustment.
: Playing the current folder repeatedly.
For using the remote control, hold down [SEL]
(MENU) for 2 sec. or more.
TEXT
: Folder name/File name
: Album/Title (tag information)
: No display
Hold down [SCAN] for 2 sec. or more. Hold down
again to cancel.
Play Mode Selection
Information Display
Notes:
¡ For scrolling text, hold down [DISP] for 2 sec. or
more.
¡ “NO TEXT” is displayed when there is no information
on the disc.
¡ ID3/WMA tag information is displayed for the album
name and title/artist name.
Play Mode indicators
Lights when each mode is
activated.
Lights when the disc is
loaded.
(Folder Random)
(Folder Repeat)
(Folder Scan)
Functions Only by
Remote Control Unit
MP3/WMA Mode Display
File type indicator
MP3/WMA Player
When a disc is already loaded, press [SRC] (Source) to
select the MP3/WMA mode.
One-touch operation is available for selecting a track
playing style by use of [RANDOM] or [REPEAT] .
RANDOM, REPEAT
Press the button. Press again to cancel.
FOLDER RANDOM, FOLDER REPEAT
Hold down the button for 2 sec. or more. Hold
down again to cancel.
SCAN play
You can find your favorite file by playing first 10-sec. of
each file.
Direct Access
A file in the current folder can be directly selected.
Example: file number 5
1 Press [#] (NUMBER).
2 Press [5].
3 Press [SET].
Notes:
¡ For folder selection, enter a number after pressing [#]
(NUMBER) twice.
¡ To suspend direct selection, press [DISP] (Display).
SCAN (All files)
Press [SCAN]. Press again to cancel.
FOLDER SCAN (1st file in each folder)
24
CQ-C8401U/C8301U/C7401U/C7301U
CQ-C8401U/C8301U/C7401U/C7301U
25
MP3/WMA Player
Notes:
¡ MP3/WMA encoding and writing software is not supplied with this unit.
Points to remember when making MP3/WMA files
Notes on MP3/WMA
Common
¡ High bit rate and high sampling frequency are recommended for high quality sounds.
¡ Selecting VBR (Variable Bit Rate) is not recommended
because playing time is not displayed properly and
sound may be skipped.
¡ The playback sound quality differs depending on the
encoding circumstances. For details, refer to the user
manual of your own encoding software and writing
software.
MP3
¡ It is recommended to set the bit rate to “128 kbps or
more” and “fixed”.
WMA
¡ It is recommended to set the bit rate to “64 kbps or
more” and “fixed”.
¡ Do not set the copy protect attribute on the WMA file
to enable this unit to play back.
Displayed items
¡ CD-TEXT
Disc title
Track title
¡ MP3 (ID3 tag)
Album name
¡ MP3/WMA
Folder name
File name
¡ WMA (WMA tag)
Album name
Title name/artist name
Title name/artist name
Displayable characters
¡ Displayable length of file name/folder name: within 64
characters
¡ Name files and folders in accordance with the standard of each file system. Refer to the instructions of
writing software for details.
¡ ASCII character set and special characters in each language can be displayed.
ASCII character set
A to Z, a to z, digits 0 to 9, and the following symbols:
(space) ! ” # $ % & ’ ( ) * + , - . / : ; < = > ? @ [ \ ] ˆ
_`{|}~
Notes:
¡ With some software in which MP3/WMA format files
have been encoded, the character information may not
be displayed properly.
¡ Undisplayable characters and symbols will be converted into an asterisk ( ).
Caution: Never assign the “.mp3”, or
“.wma” file name extension to a file that is
not in the MP3/WMA format. This may not
only produce noise from the speaker damage, but also damage your hearing.
*
Windows Media, and
the Windows logo are
trademarks, or registered trademarks of
Microsoft Corporation
in the United States
and/or other countries.
¡ The file extension “.mp3” or “.wma” should be
assigned to each file depending on the file format.
¡ This unit does not have a play list function.
¡ Although Multi-session recording is supported, the
use of Disc-at-Once is recommended.
English
Recording MP3/WMA files on a CD-media
¡ You are recommended to minimize the chances of
making a disc that contains both CD-DA files and
MP3/WMA files.
¡ If CD-DA files are on the same disc as MP3 or WMA
files, the songs may not play in the intended order,
or some songs may not play at all.
¡ When storing MP3 data and WMA data on the same
disc, use different folders for each data.
¡ Do not record files other than MP3/WMA files and
unnecessary folder on a disc.
¡ The name of an MP3/WMA file should be added by
rules as shown in the following descriptions and also
comply with the rules of each file system.
¡ You may encounter trouble in playing MP3/WMA files
or displaying the information of MP3/WMA files
recorded with certain writing software or CD
recorders.
Notes on MP3/WMA (continued)
MP3 (MPEG Audio Layer-3) and WMA (Windows MediaTM
Audio) are the compression formats of digital audio. The
former is developed by MPEG (Motion Picture Experts
Group), and the latter is developed by Microsoft
Corporation. Using these compression formats, you can
record the contents of about 10 music CDs on a single
CD media (This figures refer to data recorded on a 650
MB CD-R or CD-RW at a fixed bit rate of 128 kbps and a
sampling frequency of 44.1 kHz).
Display Information
Supported file systems
ISO 9660 Level 1/Level 2, Apple Extension to ISO 9660,
Joliet, Romeo
Note:
¡ Apple HFS, UDF 1.50, Mix CD and CD Extra are not
supported.
Compression formats
(Recommendation: “Points to remember when making MP3/WMA files” on the previous page)
Compression method
Bit rate
VBR
Sampling frequency
MPEG 1 audio layer 3 (MP3)
32 k-320 kbps
Yes
32, 44.1, 48 kHz
MPEG 2 audio layer 3 (MP3)
8 k-160 kbps
Yes
16, 22.05, 24 kHz
Windows Media Audio Ver. 2, 8
64 k-192 kbps
No
32, 44.1, 48 kHz
Folder selection order/file playback order
Maximum number of files/folders
¡ Maximum number of files: 999
¡ Maximum number of files in one folder: 255
¡ Maximum depth of trees: 8
¡ Maximum number of folders: 255 (Root folder is
included.)
Root Folder
(Root Directory)
1
2
q
Folder Selection
4
e
w
Notes:
¡ This unit counts the number of folders irrespective of
the presence or absence of an MP3/WMA file.
¡ If the selected folder does not contain any MP3/WMA
files, the nearest MP3/WMA files in the order of playback will be played.
¡ Playback order may be different from other MP3/WMA
players even if the same disc is used.
¡ “ROOT” appears when displaying the root folder
name.
In the order
1
–
8
3
File Selection
In the order
–
y
q
5
MP3/WMA Player
What is MP3/WMA?
6
r
8
7
Tree 1
Tree 2
Tree 3
t
y
Tree 4
Tree 8
(Max.)
Copyright
It is prohibited by copyright laws to copy, distribute and
deliver copyrighted materials such as music without the
approval of copyright holder except enjoying yourself
personally.
No warranty
Above description complies with our investigations as of
December 2004. It has no warranty for reproducibility
and displayability of MP3/WMA.
26
CQ-C8401U/C8301U/C7401U/C7301U
CQ-C8401U/C8301U/C7401U/C7301U
27
XM Tuner
Press [BAND] to select a band.
Channel selection
¡ Connect the optional XM receiver (XMD1000).
¡ To connect the XM receiver (XMD1000), it is
[]] (TUNE): Preceding channel
[[] (TUNE): Next channel
required to use an optional extension cord
(XMDPAN100) that is produced by XM exclusively for Panasonic products.
indicates the satellite tuner
is ready.
Indicates the intensity of
the radio wave.
(P·SET: Preset)
Channel Preset
For using the remote
control, hold down
[SEL] (MENU) for 2
sec. or more.
TEXT
Text display
: Enabled (Default)
CQ-C8401U
: Disabled
2 Press [BAND] (SET) to adjust.
XM Tuner
Channel number/name
Artist name/Song title
3 Press [MENU] to
confirm the
adjustment.
CQ-C8401U
For using the remote
control, hold down
[SEL] (MENU) for 2
sec. or more.
4 Preset the channel by holding down [}]
or [{] for 2 sec. or more.
Preset number/channel number blinks once.
Notes:
¡ New channels overwrite existing saved channels.
¡ In step 2, a channel can be registered by holding
down the numeric button [1] to [6] on remote control
for 2 sec. or more.
¡ To stop presetting channels, press [DISP] (Display).
28
[{] (P·SET: Preset): Preceding category
[}] (P·SET: Preset): Next category
play.
TEXT Setting (XM Tuner Menu Display)
XM Tuner Mode
Display
Note: Direct selection can be executed with [1] to
[6] buttons on remote control.
Band
[}] or [{].
Category selection
1 Press [MENU] to display the menu dis-
[{] (P·SET: Preset): Lower preset channel
[}] (P·SET: Preset): Higher preset channel
Preset Number
1 Tune into a channel.
2 Hold down [}] or [{] for 2 sec. or more.
3 Select a preset number by pressing
[]] (TUNE): Preceding channel in current category
[[] (TUNE): Next channel in current category
Preset channel selection
Notes:
¡ “RADIO ID” is displayed with channel 0.
¡ “UPDATING” is displayed during the update of the
identification code.
¡ “LOADING” is displayed during the acquisition of
audio data or information.
Up to 6 channels can be preset in XM1 to XM3
respectively.
Preset channels can be simply called up by pressing [}]
(P·SET) or [{] (P·SET).
Note: Direct selection can be executed with [1] to [6]
buttons on remote control.
CQ-C8401U
lights when activated
CQ-C8401U/C8301U/C7401U/C7301U
Functions Only by
Remote Control Unit
Operation Flow
3 Select a channel.
SRC
Channel selection
(P·SET: Preset)
Satellite Radio mode.
2
You can toggle the category on and off every time you
hold down [BAND] for 2 sec. or more. If the category is
set to on, the unit operates as follows for each button:
CQ-C8401U
SRC
Selection by Category
1 Press [SRC] (Source) to select the XM
English
The optional XM receiver allows you to receive the XM radio service.
Direct Access
A channel can be directly selected.
Example: channel number 5
1 Press [#] (NUMBER).
2 Press [5].
3 Press [SET].
Note: To suspend direct selection, press [DISP]
(Display).
CQ-C8401U/C8301U/C7401U/C7301U
29
Disc Changer (When CDs or MP3 discs are loaded)
When a magazine is already loaded(
lights), press
[SRC] (Source) to select the CD changer mode.
CQ-C8401U
SRC
The unit recognizes the magazine and starts playing
automatically.
2 Select a desired portion.
Operation Flow
[}]: Next disc
[{]: Preceding disc
Folder up/Down
Hold down for 2 sec. or more.
[}] (FOLDER): Next folder
[{] (FOLDER): Preceding folder
Track/File selection
[7]: Next track/file
[6]: Preceding track/file (press twice)
Note: Hold down for fast forward/reverse.
Pause
Press [BAND] (y / 5).
Press again to cancel.
Time
Disc number
1 Press [MENU] to display the menu display.
For using the remote
control, hold down
[SEL] (MENU) for 2
sec. or more.
(From selected disc: DVD-CH)
RANDOM (Only for MP3 disc)
2 Press [}] or [{] to select a mode to be
adjusted.
DISC RANDOM (Only for CD changer)
: Off (default)
3 Press [BAND]
(SET) to adjust.
: Random playback (from selected folder)
: Random playback (from selected disc)
CQ-C8401U
REPEAT
: Off (default)
: Playing the current track/file repeatedly
4 Press [MENU] to
DISC REPEAT (Only for CD-DA disc)
confirm the adjustment.
For using the remote control, hold down [SEL]
(MENU) for 2 sec. or more.
: Off (default)
: Playing the current disc repeatedly
FOLDER REPEAT (Only for MP3 disc)
: Off (default)
: Playing the current folder repeatedly
(CD changer)
DISC SCAN (1st file in each disc, only for CD
changer)
Play Mode Selection
(DVD changer)
Play Mode indicators
lights when each mode is
activated.
lights when the changer is
connected.
(Disc Random, Only for CD changer)
(Disc Repeat)
(Disc Scan, Only for CD changer)
CQ-C8401U/C8301U/C7401U/C7301U
Functions Only by
Remote Control Unit
CD Changer Mode Display
: Off (default)
: Random playback (from whole magazine: CD-CH)
CQ-C8401U
Changer indicator
30
RANDOM (Only for CD-DA disc)
: Off (default)
(RANDOM, REPEAT)
Disc selection
¡ Trouble may occur while playing CD-Rs. Refer to the section
on “Notes on CD/CD Media (CD-ROM, CD-R, CD-RW)”. (a
page 44)
¡ This unit does not support the following through the CD
changer.
¡MP3 playback.
Random and Repeat play can be set.
Random, Repeat Play (Disc Changer Menu Display)
Note: The changer is automatically turn on when
the magazine is inserted.
Notes:
¡ Please connect a CD changer or a DVD changer to CH/AUX2
terminal (CQ-C8401U/C8301U), CH/AUX terminal (CQC7401U/C7301U).
¡ When CX-DP880 or CX-DH801U is connected, a CD-RW
disc is playable.
One-touch operation is available for selecting a track
playing style by use of [RANDOM] or [REPEAT].
RANDOM, REPEAT
Press the button. Press again to cancel.
DISC RANDOM, DISC REPEAT
Hold down the button for 2 sec. or more. Hold
down again to cancel.
SCAN play
You can find your favorite file by playing first 10-sec. of
each file.
Hold down [SCAN] for 2 sec. or more. Hold down
again to cancel.
Direct Access
A disc can be directly selected.
Example: disc number 5
1 Press [#] (NUMBER).
2 Press [5].
3 Press [SET].
Note: To suspend direct
selection, press [DISP] (Display).
Disc Changer (When CDs or MP3 discs are loaded)
1 Load a magazine (discs).
English
Connected an optional CD changer or an optional DVD changer can be controlled by this unit.
SCAN (CD changer: All tracks, DVD changer:
from selected disc)
Press [SCAN]. Press again to cancel.
CQ-C8401U/C8301U/C7401U/C7301U
31
Disc Changer (when DVDs or VCDs are loaded)
Connected an optional DVD changer (CX-DH801U) can be controlled by this unit.
CQ-C8401U
SRC
English
When a magazine is already loaded(
lights), press
[SRC] (Source) to select the DVD changer mode.
Notes:
¡ Please connect a CD changer or a DVD changer to
CH/AUX2. (Only for CQ-C8401U/C8301U)
¡ “AUX 2” is display when connecting a changer that is not
compatible with this unit. (Only for CQ-C8401U/C8301U)
2 Select a desired portion.
Notes:
¡ For DVD operations other than the above (i.e. DVD
menu, closed caption, etc.), use the remote control unit supplied with the DVD changer.
¡ The remote control unit supplied with the DVD
changer does not work properly when you aim it
at this unit.
¡ When using the remote control unit supplied with
the DVD changer, aim it at the monitor display
(CY-V7100U).
Chapter/Track selection
[7]: Next chapter/Next track
[6]: Preceding chapter/ Preceding track
(press twice)
Note: Hold down for fast forward/reverse.
Pause
Chapter number
Time
Disc number
Changer indicator
¡For a DVD insertion
Press [MENU] to display the menu display.
For using the remote
control, hold down
[SEL] (MENU) for 2
sec. or more.
CQ-C8401U
CHAPTER REPEAT
: Off (Default)
: Playing the current chapter repeatedly.
TITLE REPEAT
: Off (Default)
2 Press [}] or [{] to select a mode to be
adjusted.
(RANDOM, REPEAT)
[}]: Next disc
[{]: Preceding disc
Press again to cancel.
DVD Changer Mode Display
1
Disc selection
Press [BAND] (y / 5).
32
Repeat play can be set.
Random, Repeat Play (DVD Changer Menu Display)
Note: The power is turned on automatically when
inserting a magazine.
Note: The unit may not operate for some DVDs.
3 Press [BAND]
(SET) to adjust.
: Playing the current title repeatedly.
¡For a VCD insertion
CQ-C8401U
REPEAT
: Off (Default)
: Playing the current track repeatedly
4 Press [MENU] to confirm the adjustment.
DISC REPEAT
: Off (Default)
For using the remote control, hold down [SEL]
(MENU) for 2 sec. or more.
: Playing the current disc repeatedly
Notes:
¡ The unit may not operate for some VCDs.
¡ The unit may not operate for a disc with the play back
function activated.
Disc type
Play Mode indicators
lights when each mode is
activated.
lights when the changer is
connected.
(Disc Repeat)
(Chapter Repeat)
(Title Repeat)
CQ-C8401U/C8301U/C7401U/C7301U
Play Mode Selection
Functions Only by
Remote Control Unit
Operation Flow
The unit recognizes the magazine and starts playing
automatically.
Direct Access
One-touch operation is available for selecting a chapter
playing style by use of or [REPEAT].
CHAPTER REPEAT, REPEAT
Press the button. Press again to cancel.
TITLE REPEAT, DISC REPEAT
Hold down the button for 2 sec. or more. Hold
down again to cancel.
A disc can be directly selected.
Example: disc number 5
1 Press [#] (NUMBER).
2 Press [5].
3 Press [SET].
Disc Changer (when DVDs or VCDs are loaded)
1 Load a magazine (discs).
Note: To suspend direct
selection, press [DISP] (Display).
CQ-C8401U/C8301U/C7401U/C7301U
33
Audio Setting
Function Setting
2 Press [VOLUME] (SEL: Select) to select
clockwise or
counterclockwise
to adjust.
AUDIO Menu Display
Note: If no operation takes place for more than 10 seconds in the audio menu (2 sec. in Main volume adjustment), the display returns to the regular mode.
CQ-C8401U
MUTE KEY
Setting [MUTE] buttons’ functions
: Volume off (Default)
2 Press []] or [[] to display the FUNCTION menu.
(Setting range: L15 to R15 and Center, Default: Center)
q : Right enhanced
w : Left enhanced
be adjusted.
Fader adjustment
(Setting range: R15 to F15 and Center, Default: Center)
q : Front enhanced
w : Rear enhanced
Subwoofer level adjustment
(Setting range : mute (-∞), -6 dB to +6 dB, 2 dB Step,
Default: 0 dB)
q : Up
w : Down
:
Volume down by 10 steps
:
Volume down by 5 steps
SECURITY
3 Press [}] or [{] to select a function to
BASS
(Setting range: -12 dB to +12 dB, 2 dB Step, Default:
Bass 0 dB)
q : Up
w : Down
For using the remote
control, hold down
[SEL] (MENU) for 2
sec. or more.
Balance adjustment
Main volume adjustment
(Setting range: 0 to 40, Default: 18)
q : Up
w : Down
play.
q : Up
w : Down
[[]: Higher frequency
[]]: Lower frequency
a mode to be
adjusted.
3 Turn [VOLUME]
1 Press [MENU] to display the menu dis-
(Adjustable frequency: 60, 160, 400, 1 k, 3 k, 6 k, 16 k (Hz),
Setting range: –12 dB to +12 dB, 2 dB Step) (a page 18)
English
(SEL: Select) to
display the
AUDIO menu
display.
SQ preset change
FUNCTION Menu Display
1 Press [VOLUME]
Adjustment to display on the FUNCTION menu
Setting the security function (a page 13)
: ON (Default)
: OFF
4 Press [BAND]
(SET) to adjust.
CQ-C8401U
5 Press [MENU] to confirm the adjustment.
For using the remote control, hold down [SEL]
(MENU) for 2 sec. or more.
Subwoofer Low Pass Filter
Audio Setting, Function Setting
Adjustment to each speaker and an optional subwoofer
(Setting range: 80 Hz, 120 Hz, 160 Hz, Default: 80 Hz)
q : Up
w : Down
TREBLE
Subwoofer output range
Other speakers output ranges
(Setting range: -12 dB to +12 dB, 2 dB Step, Default:
Treble 0 dB)
q : Up
w : Down
Note: Do not activate SQ and Bass/Treble at same time
to avoid causing sound distortion.
34
High Pass Filter
(Setting range: Filter OFF, 90 Hz, 135 Hz, 180 Hz, 225 Hz,
Default: Filter OFF)
q : Up
w : Down
CQ-C8401U/C8301U/C7401U/C7301U
CQ-C8401U/C8301U/C7401U/C7301U
35
Customize the Display (Customize Function)
Adjustment to display on the DISPLAY menu
1 Press [MENU] to display the menu
display.
For using the remote
control, hold down
[SEL] (MENU) for 2
sec. or more.
CQ-C8401U
STILL IMAGE
(Setting range: 11types, Default: All)
You can edit the moving images and still images that are initially stored in the unit. You also can use the data that is downloaded from
the Panasonic Web site and the data that is stored with a digital camera or other devices and processed with exclusive software,
IMAGE STUDIO. See “Notes on Customize function” (a page 38) as well.
Note: Visit Panasonic Web site (http://panasonic.co.jp/pas/en/software/customize/index.html) for details.
Switching by []] or [[]
Preparation:
Put the CD-R/RW that contains data to
be customized in hand.
All:
Sequential display from pattern 1 to 10
No.1-10
6 Select a file.
English
Display Setting
1 If there is a disc inside, take out the
disc.
[}][{][]][[]:Select
[BAND] (SET): Confirm
2 Press [SRC] to
DISPLAY menu.
select the CD
mode.
3 Press [}] or [{] to select a function to
be adjusted.
SRC
4 Press [BAND]
(SET) to confirm
the display.
3 Hold down [SEL] for 4 sec. or more to
CQ-C8401U
display the menu screen.
5 Adjust the setting value.
6 Press [BAND] (SET).
7 Press [MENU] to confirm the
(Setting range: 1 to 5, Default: Contrast 3)
[[]: Tilting up view angle
[]]: Tilting down view angle
adjustment.
For using the remote control, hold down [SEL]
(MENU) for 2 sec. or more.
GRAPHIC PATTERN
CLOCK ADJ
Note: Adjust the clock when “ADJUST” appears on the
display.
[[]: Adjusting minutes
[]]: Adjusting hours
[}]: Forward
[{]: Backward
4 Load a CD-R/RW that contains data.
Note:
¡ It may take time for the unit to identify the CDR/RW.
¡ Discs recorded by the packet writing software are
not supported.
5 Select an item to be customized.
[]][[]:
Select
[BAND] (SET): Confirm
GRAPHIC PATTERN
Moving image (graphic pattern) data (a page 36)
STILL IMAGE
Notes:
¡ The graphic pattern and still image are changeable.
(a page 37)
¡ If corrupted data is selected, “DISPLAY FILE INCOMPLETE” appears. (a page 38)
Still image data (a page 36)
OPENING MESSAGE
Moving image at power on (a page 14)
CLOSING MESSAGE
Moving image at power off (a page 14)
36
Notes:
¡ New data overwrites existing data.
¡ If “BACK” is selected, the screen of step 6
appears.
[}][{]:
Select
[BAND] (SET): Confirm
Note: To exit the customize menu, hold down
[SEL] 4 sec. or more.
All:
Sequential display from pattern A to D.
Pattern A-D
S.A.:
19-band display (Spectrum analyzer)
[]][[]:
Select
[BAND] (SET): Confirm
8 Confirm the changed item.
(Setting range: 6 types, Default: All)
Switching by []] or [[]
7 For a moving image file or still image
file, select where to save the file.
CUSTOMIZE Menu Display
DISPLAY Menu Display
CONTRAST
Notes:
¡ Files are automatically identified by their extensions, and target files are displayed.
¡ If ”BACK” is selected, the screen of step 5
appears.
Display Setting, Customize the Display (Customize Function)
2 Press []] or [[] to display the
CQ-C8401U/C8301U/C7401U/C7301U
Customization is performed. Do not turn off the
power in mid-operation. (It takes approx. 1 minutes
to complete this operation for a 168 kB moving
image.) After completion of this operation, the
screen of step 5 appears.
Note: If “NO” is selected, the screen of step 5
appears.
9 Hold down [SEL] 4 sec. or more.
The CD mode comes back. Press the [OPEN] button to eject the disc.
CQ-C8401U/C8301U/C7401U/C7301U
37
At Customizing
The download service may be suspended or stopped
without advance notice. The download service is not
available in some areas. Please visit the site below for
further information.
Panasonic Web site:
(http://www.panasonic.co.jp/global/)
¡ If customizing is interrupted on account of turning off
the power, stopping the engine, removing the face
plate or other reasons, you may lose the data. In such
a case, try customizing again.
¡ The default image exists on the Panasonic Web site. If
you would like to restore it, download the image from
the site.
Download site:
Notes on IMAGE STUDIO
¡ This download service is not available in some areas.
For details, please access the Panasonic website.
¡ IMAGE STUDIO is available only by downloading from
the address below. It is not bundled with this unit.
¡ Refer to the downloaded operating manual for how to
use IMAGE STUDIO.
¡ The customize-specific file is downloadable from the
URL below. You can create exclusive files stored with
a digital camera or other devices by using exclusive
software, IMAGE STUDIO that can be accessed from
the same URL.
¡ Do not change the extension. Otherwise, the data cannot be recognized.
If the described suggestions do not solve the problem, it is
recommended to take the unit to your nearest authorized Panasonic
Servicenter. The product should be serviced only by qualified personnel.
Please refer the checking and the repair to professionals. Panasonic
shall not be liable for any accidents arising out of neglect of checking the
unit or your own repair after your checking.
Problem
NO FILES DETECTED
No power to the
unit
Type
Extension
Max. number
GRAPHIC PATTERN
.pfm
10
STILL IMAGE
.pfs
15
OPENING MESSAGE
.pfo
5
CLOSING MESSAGE
.pfe
5
Possible cause a Possible solution
The power cord (battery, power and ground) is connected in the wrong way.
a Check the wiring.
Fuse blows out.
a Eliminate the cause of fuse blowout and replace the fuse with new one.
Consult your dealer.
CUSTOMIZING FAILED
Customize failed
a Check to see whether or not the extension is correct and file contents are appropriate.
Sound is not
generated.
Intended moving image or still image is damaged.
a Customize it again and overwrite the file with
new one.
Common
¡ Save only customize-specific data.
¡ Save all data in the root directory. Files contained in a
folder cannot be recognized.
¡ Follow the table below with regard to the number of
files that are saved to a disc. Files beyond the specified capacity are not readable.
¡ Discs recorded by the packet writing software are not
supported.
¡ Do not use the unit in an irregular condition, for
example, without sound, or with smoke or a foul
smell, which can cause ignition or electric shock.
Immediately stop using the unit and consult your
dealer.
¡ Never try to repair the unit by yourself because it is
dangerous to do so.
Error Display Messages
DISPLAY FILE INCOMPLETE
At Disc Making
Warning
Check and take steps as described below.
No customize-specific data on the disc
a Load a disc that contains customize-specific
data.
Notes on File
Notes on Customize Function
http://panasonic.co.jp/pas/en/software/
customize/index.html
If You Suspect Something Wrong
The demonstration
screen displayed
and no operable
Noise
MUTE is set to ON.
a Set MUTE to OFF.
The wiring of speaker lines are not correct, or a break or poor contact arises.
a Check the wiring in accordance with the wiring diagram. (Installation
Instructions)
You cannot operate the unit while the demonstration screen appears.
a Press [DISP] to end the demonstration screen.
If the demonstration screen appears frequently, there is a possibility that poor
contact or wrong wiring arises between the battery lead of the unit and the battery
cable of the car. (The battery lead should be always powered.)
a Check the battery wiring in accordance with the wiring diagram.
English
Note on Download Service
Troubleshooting
Customize the Display (Customize Function), Troubleshooting
Customize the Display (Customize Function)
There is an electromagnetic-wave generator such as a cellular phone near the unit or
its electrical lines.
a Keep an electromagnetic-wave generator such as a cellular phone away from
the unit and the wiring of the unit. In case that noise cannot be eliminated
due to the wiring harness of the car, consult your dealer.
The contact of the ground lead is poor.
a Make sure that the ground lead is connected to an unpainted part of the chassis securely.
Noise is made in
step with engine
revolutions.
38
CQ-C8401U/C8301U/C7401U/C7301U
Alternator noise comes from the car.
a Change the wiring position of the ground lead.
a Mount a noise filter on the power supply.
CQ-C8401U/C8301U/C7401U/C7301U
39
Troubleshooting
The speaker
channels are
reversed between
right and left.
The sound field is
not clear in the
stereo mode.
Central sound does
not settled.
The power fails
unintentionally.
Poor reception or
noise
BALANCE/FADER setting is not appropriate.
a Readjust BALANCE/FADER.
There is a break, a short circuit, poor contact or wrong wiring regarding the speaker
wiring.
a Check the speaker wiring.
No playback or
disc ejected
The speaker wiring is confused between right and left.
a Perform the speaker wiring in accordance with the wiring diagram.
The plus and minus terminals at right and left channels of speakers are connected
reversely.
a Perform the speaker wiring in accordance with the wiring diagram.
Sound skipping or
noise
Sound skipping
due to vibration
Disc unejectable
The safety device works.
a Call the store where you purchased the unit, or your nearest Panasonic
Servicenter.
No contract with XM Satellite Radio Inc.
a Refer to page 13 of this book and the XM's website to sign up for XM Radio
service.
The disc is inserted upside down.
a Insert a disc correctly.
There is a flaw or foreign material on the disc.
a Remove the foreign material, or use a flawless disc.
There is a flaw or foreign material on the disc.
a Remove the foreign material, or use a flawless disc.
The unit is not sufficiently secured.
a Secure the unit to the console box with the rear support strap, etc.
The unit is tilted at over 30˚ in the front-to-end direction.
a Make the angle 30˚ or less.
Something such as a peeled label obstructs the disc coming out.
a Hold down the [OPEN] button for 2 sec. or more when the face plate is open
(disc forced ejection). In case that the disc forced ejection does not work,
consult the dealer
The microcontroller in the unit operates abnormally due to noise or other factors.
a Unplug the power cord and plug it again. In case the unit is still out of order,
consult the dealer.
Antenna installation or wiring of antenna cable is faulty.
a Check whether the antenna mounting position and its wiring are correct. In
addition, check to see whether the antenna ground is securely connected to
the chassis.
English
Channel
unselectable
Possible cause a Possible solution
No playback or
disc ejected
The disc has unplayable formatted data.
a Refer to the description about MP3/WMA for playable sound data except CDDA (i.e. music CD).
The CD-R/RWs that
are playable on
other devices are
not playable on
this unit.
The playability of some CD-R/RWs may depend on the combination of media,
recording software and recorder to be used even if these CD-R/RWs are playable on
other devices such as a PC.
a Make CD-R/RWs in different combination of media, recording software and
recorder after referring to the description about MP3/WMA.
Troubleshooting
Common (continued)
No sound from
speaker(s)
Some operations are not executable in particular modes such as menu mode.
a Read the operating instructions carefully and cancel the mode. In case the
unit is still out of order, consult the dealer.
XM Tuner
Some operations
are not executable.
Problem
Possible cause a Possible solution
CD
Problem
The number of auto
preset stations is
less than 6.
Preset stations
cannot be stored.
40
The number of receivable stations is less than 6.
a Move to an area where receivable stations number is maximum, and try presetting.
The contact of the battery lead is poor, or the battery lead is not always powered.
a Make sure that the battery lead is connected securely, and preset stations
again.
CQ-C8401U/C8301U/C7401U/C7301U
MP3/WMA
Radio
No power is supplied to the antenna amplifier (when using a film antenna, etc.).
a Check the wiring of the antenna battery lead.
Sound skipping or
noise
There is a flaw or foreign material on the disc.
a Remove the foreign material, or use a flawless disc. For MP3/WMA, refer to
the description about MP3/WMA.
Playing VBR (Variable Bit Rate) files may cause sound skipping.
a Play Non-VBR files.
CQ-C8401U/C8301U/C7401U/C7301U
41
No response to
pressing buttons
The disc is dirty, or is upside down.
a Check the disc.
The battery is weak.
aReplace the battery with new one.
The disc has scratches.
a Check the disc.
The aiming direction of the remote control unit is wrong.
aAim the remote control unit at the sensor of the unit and press buttons.
No operation by some cause.
a Call the store where you purchased the unit, or your nearest Panasonic
Servicenter.
The file is not readable.
a Eject the disc.
(After 5 seconds)
A WMA file can be copyrighted.
a The file protected by copyright is not playable.
To next file automatically
No disc.
Display
Possible cause a Possible solution
The disc is dirty, or is upside down.
Error Display Messages
Possible cause a Possible solution
XM Tuner
Cannot receive XM satellite radio.
a Verify the wiring.
XM antenna unconnected.
a Connect the XM antenna.
XM broadcasts unreceivable because of poor receiving conditions.
a Move to an area where XM broadcasts can be received well.
Channel not in service
a This channel is not currently in service. Tune to another channel.
(After 5 seconds)
To next disc automatically
DISC Changer
Display
English
Possible cause a Possible solution
The battery is inserted in the wrong direction. A wrong battery is inserted.
aInsert a correct battery in the correct direction.
The sensor is exposed to direct sunlight. (The remote control unit may not be
operable when the sensor is exposed to direct sunlight. In such a case, the
system is not faulty.)
aBlock off sunlight to the sensor.
Remote control unit
Display
Possible cause a Possible solution
CD/MP3/WMA
Problem
Error Display Messages
The disc has scratches.
a Eject the magazine.
¡Check the disc.
¡Load the disc again.
Troubleshooting, Error Display Messages
Troubleshooting
No operation by some cause.
a Eject the magazine. If failure persists, press the reset switch on the disc
changer. If normal operation is not restored, call the store where you purchased the unit or the nearest Panasonic Servicenter to ask for repairs.
An error arises in the DVD changer.
a Check the DVD changer. (“REGION ERROR” etc.)
No disc is in the CD Changer (magazine).
a Insert discs into the changer (magazine).
The changer has become disconnected from the unit in the changer mode.
a Verify the wiring.
Note: Messages in the action and display sections of the error chart vary with changers. Refer to the operating
instructions for the Disc changer for details.
42
CQ-C8401U/C8301U/C7401U/C7301U
CQ-C8401U/C8301U/C7401U/C7301U
43
General
TEXT
How to hold the disc
¡ Do not touch the underside of the disc.
¡ Do not scratch on the disc.
¡ Do not bend the disc.
¡ When not in use, keep disc in the case.
Printed side
Do not use irregularly shaped discs.
Do not leave discs in the following places:
¡ In direct sunlight
¡ Near car heaters
¡ Dirty, dusty and damp areas
¡ On seats and dashboards
Disc cleaning
Use a dry, soft cloth to wipe from the center outward.
Do not attach any seals or labels to your discs.
Do not write on the disc label with a ballpoint
pen or other hard-point pens.
<Correct>
<Wrong>
¡ You may have trouble playing back some CD-R/RW discs recorded on CD recorders (CD-R/RW drives), either due
to their recording characteristics or dirt, fingerprints, scratches, etc. on the disc surface.
¡ CD-R/RW discs are less resistant to high temperatures and high humidity than ordinary music CDs. Leaving them
inside a car for extended periods may damage and make playback impossible.
¡ Some CD-R/RWs can not be played back successfully thanks to incompatibility among writing software, a CD
recorder (CD-R/RW drive) and the discs.
¡ This player cannot play the CD-R/RW discs if the session is not closed.
¡ This player cannot play the CD-R/RW discs which contains other than CD-DA or MP3/WMA data.
¡ Be sure to observe the instructions of CD-R/RW disc for handling it.
Cleaning the
Unit
Maintenance
Fuse
Sampling Frequency
DA Converter
Pick-Up Type
Light Source
Wavelength
Frequency Response
Signal to Noise Ratio
Total Harmonic Distortion
Wow and Flutter
Channel Separation
8 times oversampling
4 DAC System
Astigma 3-beam
Semiconductor laser
790 nm
20 Hz - 20 kHz (±1 dB)
96 dB
0.01 % (1 kHz)
Below measurable limits
75 dB
FM
Frequency Range
Usable Sensitivity
50 dB quieting Sensitivity
Frequency Response
Alternate channel selectivity
Stereo Separation
Image response ratio
IF response ratio
Signal to noise ratio
87.9 MHz - 107.9 MHz
10.2 dBf. (0.9 µV, 75Ω)
15.2 dBf. (1.6 µV, 75Ω)
30 Hz - 15 kHz (±3 dB)
75 dB
35 dB (at 1 kHz)
75 dB
100 dB
62 dB
AM
Frequency Range
Usable Sensitivity
530 kHz - 1 710 kHz
27 dB/µV (S/N 20 dB)
Your product is designed and manufactured to ensure the minimum of maintenance. Use a soft cloth for
routine exterior cleaning. Never use benzine, thinner, or other solvents.
If the fuse blows out, consult your dealer, or your nearest authorized Panasonic Servicenter.
44
CD Player
Do not use irregularly shaped discs.
Speaker Impedance
Pre-amp output voltage
Subwoofer-output voltage
Pre-amp output impedance
Subwoofer-output impedance
Dimensions (Main Unit)
Weight (Main Unit)
DC 12 V (11 V - 16 V), Test Voltage 14.4 V, Negative Ground
Bass; ±12 dB at 60 Hz, Treble; ±12 dB at 16 kHz
60, 160, 400, 1 k, 3 k, 6 k, 16 k (Hz)
-12 dB to 12 dB (2 dB step)
Less than 2.2 A (CD mode, 0.5 W 4-Speaker)
60 W x 4 (at 1 kHz) (CQ-C8401U),
50 W x 4 (at 1 kHz) (CQ-C8301U/C7401U/C7301U)
4-8Ω
5 V (CQ-C8401U/C8301U/C7401U), 2.5 V (CQ-C7301U) (CD mode, 1 kHz, 0 dB)
5 V (CQ-C8401U/C8301U/C7401U), 2.5 V (CQ-C7301U) (CD mode, 1 kHz, 0 dB)
60 Ω (CQ-C8401U/C8301U/C7401U), 200 Ω (CQ-C7301U)
60 Ω (CQ-C8401U/C8301U/C7401U), 200 Ω (CQ-C7301U)
178(W) x 50(H) x 155(D) mm {7” x 1 15/16 ”x 6 1/8”}
1.6 kg {3 lbs. 8 oz}
Power Supply
Tone Controls (Bass/Treble)
Equalizer Center Frequency
Variable Range of Equalizer
Current Consumption
Maximum Power Output
Notes on discs, Maintenance, Specifications
If you use commercial CDs, they must have
either of these labels shown at right.
Some copy-protected music CDs are not
playable.
English
Specifications
Stereo Radio
Notes on
CD-Rs/RWs
Notes on CD/CD Media (CD-ROM, CD-R, CD-RW)
Notes on Discs
Warning
¡Use fuses of the same specified rating (15 A). Using substitutes or fuses with higher ratings, or connecting the
unit directly without a fuse could cause fire or damage to the unit. If the replaced fuse fails, contact your
nearest authorized Panasonic Servicenter.
CQ-C8401U/C8301U/C7401U/C7301U
Power Output:
24 W RMS x 4 Channels at 4 Ω and ≤ 1%
THD+N (for CQ-C8401U)
17 W RMS x 4 Channels at 4 Ω and ≤ 1%
THD+N (for CQ-C8301U/C7401U/C7301U)
Signal to Noise Ratio:
78 dBA (reference: 1 W into 4 Ω)
(for CQ-C8401U/C8301U/C7401U)
87 dBA (reference: 1 W into 4 Ω)
(for CQ-C7301U)
Above Specifications comply with EIA standards.
Notes:
¡Specifications and design are subject to modification
without notice due to improvements.
¡Some figures and illustrations in this manual may be
different from your product.
CQ-C8401U/C8301U/C7401U/C7301U
45
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
