Introduction

In 1974, brothers Phil and Terry Clarke founded Klark Teknik Research Ltd. In the years immediately following, their pioneering approach to design and development allowed them to introduce some truly groundbreaking designs. The world’s first digital delay and digital reverb units emanated from their laboratory, and their descendants remain in common usage all over the world to this day.

However, it was their concepts for equalisation devices that really changed the world of professional audio resulting in the uniquely capable DN370 and the world famous DN360.

Today Klark Teknik continues to bring innovation in design, engineering and sonic quality in both the analogue and digital realm of signal processing. Uniquely in its field, Klark Teknik also provides the customer with an opportunity to invest in leading-edge equipment with an extraordinary working lifespan and unrivalled retained value.

Klark Teknik products are represented by an international network of appointed distributors, all of whom are authorised to sell and provide technical support for our products. Full contact details for all our distributors are available from the website at www.klarkteknik.com, however please contact the factory direct for information if necessary.

Contents

Helix DN9331 RAPIDE

Helix DN9340E

Helix DN9344E

Helix DN9848E

Graphic Controller

Dual EQ

Quad EQ

System Controller

ELGAR

Helix EQ RCS

Midas and Klark Teknik remote control framework remote control add in for DN9340E / DN9344E

Helix System Controller RCS

remote control add in for DN9848E

STS

Midas and Klark Teknik solo tracking system

DN370

DN360

DN1248

DN410

DN500

DN504

DN514

DN1414

DN100

Accessories

dual channel 30 band 1/3 octave graphic equaliser dual channel 30 band 1/3 octave graphic equaliser mic splitter dual channel 5 band parametric equaliser dual compressor/limiter expander quad compressor limiter quad auto gate di module active di factory options

Reference

FAQ’s

Line drawings

frequently asked questions

.

.

.

.

Show Command Component

Show Command Component

Show Command Component

Show Command Component

.

.

.

Show Command Component

Show Command Component

Show Command Component page 16 page 18 page 20 page 22 page 24 page 26 page 28 page 30 page 32 page 34 page 35 page 36 page 44 page 4 page 6 page 8 page 10 page 12 page 13 page 14 page 15 page 3

Helix DN9331 RAPIDE -

Graphic Controller

Unique, immediate and tactile, the DN9331 Helix

RAPIDE offers direct access to all of the graphic equalisation functions of Helix digital equalisers.

Instant recall of fader positions is made possible by the use of thirty one console-quality 100 mm long travel high resolution motorised faders, custom manufactured to Klark Teknik’s exacting standards, featuring long life conductive plastic tracks and driven by fast acting precision servo control circuits.

A generously specified power supply ensures high speed of response, and can supply the peak currents required by simultaneous multiple fader movements, without the lag effects experienced with lower-grade remote fader units.

Integrating a Midas/Klark Teknik STS Solo Tracking

System interface, the Helix RAPIDE is ideal for use in stage monitoring systems, when combined with a

Midas Heritage, Legend or Siena console, the solo buttons on each aux send can be used to instantly recall the graphic equaliser settings of the connected channel of Helix digital equalisation, offering the monitor engineer unparalleled speed of access in situations demanding an immediate response.

A flexible user interface allows custom remote channel assignments across four banks of 32 channel selection buttons. Four freely assignable group buttons and a global ‘all channels’ button allow relative adjustment of channels, especially important when the priority is to stop on-stage feedback first, and determine the source second.

The Helix RAPIDE is the networking centre of the

Show Command System, an eight external port

Ethernet hub is incorporated into the device, allowing the connection of Helix digital equalisers and system processors, with wired or wireless connections to laptop or tablet PCs running the

Elgar Helix EQ RCS and System Controller RCS.

The Helix RAPIDE is fully backwards-compatible with the original Helix DN9340 and DN9344 digital equalisers which may be interfaced using Ethernetto-serial converters.

page 4

Architect’s & Engineer’s Specification

The digital graphic equaliser remote controller shall offer control of 31 bands of Klark Teknik Helix graphic equalisation and have 31 motorised 100 mm faders representing frequencies from 20Hz-20kHz on 1/3 octave centres to BS EN ISO 266:1997.

The unit shall be contained in a 6U 19” rackmount enclosure, which shall be so designed as to also allow the unit to perform as a freestanding console.

The unit shall provide remote control of up to 64 channels of Klark Teknik Helix graphic equalisation.

The remote control interface shall be via Ethernet and there shall be an Ethernet switch integrated into the unit with eight external ports fitted with Ethercon connectors. There shall also be a rear panel RS-232 port provided for remote control from Midas Heritage,

Legend and Siena mixing consoles, which implements the Klark Teknik and Midas Solo Tracking System control.

The user interface shall provide for four banks of 32 channels of user-assignable channel access, implemented as four bank and 32 channel nonlatching illuminating pushbutton switches. There shall be four non-latching illuminating pushbutton switches provided for the selection of groups, each of the four groups permitting the relative adjustment of multiple channels of Helix graphic equalisation. There shall also be a non-latching illuminating pushbutton for global access of all addressable channels of Helix graphic equalisation and applying relative adjustment to all channels. A non-latching illuminating pushbutton shall also be provided to bypass the currently selected channel(s) of Helix graphic equalisation.

Eleven-segment LED bargraph meters shall be provided for monitoring the input and output audio signal levels of an individual channel.

A 20 x 2 alphanumeric LCD display shall be provided for the display of parameter information and three rotary encoders shall be provided for parameter adjustment. Momentary pushbutton switches shall be provided for memory store and recall and setup menu access.

The unit shall be capable of operating from a 90 to

250V, 50 to 60 Hz a.c. power source.

The digital graphic equaliser remote controller shall be the Klark Teknik DN9331 Helix RAPIDE, and no alternative specification option is available.

.

Technical Specification

F

Equalisation

Centre Frequencies

31 Bands

To BS EN ISO 266:1997

20Hz-20kHz, 1/3 octave

Maximum Boost/Cut

F

Power Requirements

Voltage

±12dB

100V – 240V a.c. ± 10%

50/60 Hz

F

Terminations

Ethernet Communications Ethercon

Solo Tracking System 9-pin D-type

F

Power

3-pin IEC

F

Dimensions

Width

Height

Depth

483 mm (19 inch)

264 mm (7 inch) 6RU High

150 mm (6 inch) Top

80 mm (3 inch) Bottom

F

Weight

Net

Shipping

10kg

13kg

.

STS Compatible

.

Show Command Component

Trade Descriptions Act:

Due to the company policy of continuing improvement, we reserve the right to alter these specifications without prior notice. E&OE.

page 5

Helix DN9340E - Dual EQ

The concept of an equalisation device which allows the user to not only select from a menu of various

EQ types but also to integrate them with each other in any combination is one that could only have come from Klark Teknik. At the heart of Helix

DN9340E is the fact that it sounds incredible – the most common remark from first-time users is ‘it sounds just like a great analogue EQ!’

For the uninitiated, the new Helix DN9340E is a dual channel, 2RU, all-digital equalisation unit that simultaneously offers a five-mode 31-band graphic

EQ, twelve bands of full parametric EQ, four configurable filters (HPF, LPF, hi shelf, lo shelf and notch) and two bands of true dynamic EQ (T-DEQ) per channel. Unit control is provided by both a touch strip and rotary controls, full input and out metering is provided plus dedicated meters for the

T-DEQ function. A large, bright LCD display provides visual reference for all functions and the entire menu structure is simple and intuitive. Helix can also be linked to Midas Siena, Legend and Heritage consoles via the Solo Tracking System (STS): this allows any channel of connected Helix EQ to be edited from the control surface of a single Helix

DN9340E unit or PC simply by activating the appropriate PFL function on the console (STS only works on the outputs of the Siena).

By linking a DN9331 RAPIDE to the DN9340E it allows the user to have instant control over the

Helix 31 band graphic EQ function thanks to the unique 31 Klark Teknik 100mm motorised faders fitted to this unit.

The Helix DN9340E also features AES/EBU digital inputs and outputs as standard, complete with word clock sync inputs. Whilst the internal sample rate of all DN9340/44E units remain at

48kHz/44.1kHz, these digital connections are all 96 kHz compatible allowing easy interface with any other digital device featuring the higher sample rate.

Secondly the Helix DN9340E unit also features a dual port Ethernet communications interface. This is to facilitate much faster communication, response and metering between units than was previously possible with serial comms. The Ethernet ports allow for control of the units from a PC, either via

Ethernet or wirelessly with the Helix EQ Remote

Control Software (RCS) an ELGAR Add-In.

page 6

Architect’s & Engineer’s Specification

The Digital Equaliser shall provide two audio channels

(analogue and digital, in and out) in a standard 2U 19” rack mount chassis.

Each audio channel shall include: Source select

(analogue or digital), input gain, delay up to one second, up to four filters, two dynamic EQ bands, up to 12 parametric EQ bands and a 31 band graphic EQ.

Digital inputs shall run at any sample rate up to 96kHz with internal sample rate conversion. The sample rate converter can be bypassed when the incoming digital signal has a sample rate of 44.1kHz or 48kHz.

A word clock input shall be provided to allow the system to lock to an external clock source. In addition, the word clock input can be used to only clock the digital outputs allowing digital audio to come into the unit at one sample rate and go out at another.

Digital outputs shall also run at any sample rate up to

96kHz. In standard operation, they shall run at the system sample rate (48kHz or 44.1kHz). Using the internal SRC, the digital outputs can also run at the same sample rate as the digital inputs or the word clock input.

All delay times shall be set in milliseconds and microseconds, or in distance units (metric and imperial) with a temperature compensation facility.

The high and low pass filters shall be selectable from notch, high pass, low pass, high shelf and low shelf types. The Low pass and high pass filters shall have selectable slopes of 6, 12, 18, 24, 36 and 48 dB per octave and the high and low shelf filters shall have selectable slopes of 6 and 12 dB per octave and ±12 dB of gain.

The dynamic EQ sections shall have independent high and low level thresholds and gain and be selectable from parametric EQ, or high shelf or low shelf filter types.

The parametric EQ shall provide proportional-Q, constant-Q and symmetrical-Q responses. The dynamic

EQ sections shall also have independent attack and release times.

The parametric EQ sections shall have up to 12 dB of cut or boost and a Q value variable from 0.4 to 20. The parametric EQ shall provide proportional-Q, constant-Q and symmetrical-Q responses.

The graphic EQ section shall provide 31 bands on standard frequencies defined in BS EN ISO 266 : 1997.

Proportional-Q, constant-Q and symmetrical-Q responses shall be provided as well as emulations of

Klark Teknik DN27 and DN360 Graphic Equalisers.

Each Digital Equaliser shall meet or exceed the following performance specifications:

Frequency response: ±0.3 dB (20 Hz to 20 kHz)

Distortion @ +4 dBu: <0.01% (20 Hz to 20 kHz)

Dynamic Range: 115 dB (20 Hz to 20 kHz unweighted)

All analogue audio inputs and outputs shall be electronically balanced and use XLR connectors. All digital audio inputs and outputs shall be 110Ω AES/EBU and use XLR connectors. A 480 x 64 graphic LCD shall be provided to display a graphical representation of the equaliser section responses. All parameters shall be displayed and adjusted via a 20 x 2 alphanumeric LCD display, three rotary encoders and individual menu buttons for each equaliser section. A dual touchstrip shall be provided for use with the graphic LCD to allow the selection of graphic EQ band and gain, and centre or corner frequency for filters, and dynamic and parametric

EQ. The graphic and alphanumeric LCDs and the dual touchstrip shall have LED backlights.

There shall be provision for 32 system memories and 32 factory presets with a security lock-out feature. There shall also be a security lock-out feature that is enabled when the unit is under remote control.

The Digital Equaliser shall be provided with RS-232 ports on the front and rear panels and two Ethernet ports on the rear panel. The Ethernet ports and front panel RS-

232 port shall be provided for remote control from a master Digital Equaliser or a PC and additionally the front panel RS-232 port shall also provide the facility to download software updates and preset memories into the Digital Equaliser. The rear panel RS-232 port shall be provided for remote control from Midas Heritage and

Legend mixing consoles. The Digital Equaliser shall be controllable from the ELGAR remote control PC software.

The unit shall be capable of operating from a 100 to

240V, 50 to 60 Hz a.c. power source.

The Digital Equaliser shall be the Klark Teknik model

DN9340E and no alternative option is available.

.

Technical Specification

F

Digital Inputs

Digital Inputs

Type

Impedance

Sample Rate

Word Length

*SRC Input at these sample rates

F

Analogue Inputs

Type

Two

One 2-Channel Input

AES / EBU

110Ω

44.1kHz, 48kHz, 88.2kHz*,

96kHz*

24-bit or 16-bit

Impedance (Ω)

Common Mode

Rejection

Maximum Level

F

Word Clock Input

Type

Impedance

Two

Electronically balanced

(pin 2 hot)

20k

>80dB @ 1 kHz

+21dBu

BNC

75Ω

F

Digital Outputs

Type

Impedance

Sample Rate

Word Length

**SRC Output - these rates are only available when used in conjunction with a word clock or a digital input running at that frequency.

F

Outputs

Type

Two

Electronically balanced

(pin 2 hot)

+21dBu into >2k Maximum Level

F

Performance

Frequency response

(20Hz to 20kHz)

Distortion (THD+N)

@ +4dBu (20Hz to 20 kHz)

Dynamic range

(20Hz-20kHz unweighted)

±0.3 dB with all filters and EQ flat

<0.01%

115 dB

F Processing (Per Channel)

Input Gain

Delay

Filters

Types

Dynamic EQ

Range

Responses

Parametric EQ

Range

Responses

Graphic EQ

Range

Responses

+12dB to -40dB in 0.1dB steps plus Off

0-1 second (342.25 m or

333'10” at 20C in 20.8us steps)

4 Filters (max)

Low Pass, High Pass, Low

Shelf, High Shelf, Notch

2 Bands (max)

±12dB

Proportional, Constant,

Symmetrical

12 Bands (max)

±12dB

Proportional, Constant,

Symmetrical

31 Bands On ISO standard frequencies

±12dB

Proportional, Constant,

Symmetrical, DN27, DN360

F

Power Requirements

Voltage

Consumption

F

Terminations

Audio inputs/outputs

Ethernet inputs/outputs

RS-232

World Clock

Power

One 2-Channel Output

AES / EBU

110Ω

44.1kHz, 48kHz, 88.2kHz**,

96kHz**

24-bit

100 V - 240 V ±10%

<60W

3 pin XLR

Ethercon

8 pin Mini-DIN socket

(front)

9 pin D-type (rear)

BNC

3 pin IEC

F

Dimensions

Width

Height

Depth

F

Weight

Net

Shipping

.

.

STS Compatible

483 mm (19inch)

88 mm (3.5 inch) - (2RU)

303 mm (12 inch)

6kg

8kg

Show Command Component

Trade Descriptions Act:

Due to the company policy of continuing improvement, we reserve the right to alter these specifications without prior notice. E&OE.

page 7

Helix DN9344E - Quad EQ

Helix DN9344E is a fantastic example of how clever digital design can make products smaller and lighter without sacrificing functionality. Helix

DN9344E Quad EQ is actually, as the name suggests, TWO complete DN9340E Helix Dual EQ units in just a single rackspace device, providing four discrete or two pairs of stereo-linked channels of multi-configurable EQ, that can be controlled singly or as part of a larger system from a single

DN9340E Helix Dual EQ, or via Helix EQ Remote

Control Software (RCS). Up to 64 channels can be controlled from one master unit or the RCS.

Additionally the 31 band graphic function of the unit can be controlled via the unique DN9331

RAPIDE with its 31 motorised 100mm faders. Perfect for installations, it is also fitted with contact closures to allow for memory recall by a mechanical device.

The principal operational advantage of the Helix

DN9344E is that it offers all the functionality of several standalone devices in one package, thus saving massively on both cost and rackspace. For instance, enough EQ for a 24-way monitor mix plus two sidefills will fit into just SIX rackspaces (six

DN9344E Quad EQs), at a comparative cost to the same number of channels of top-class analogue graphic EQ.

The Helix DN9344E also features AES/EBU digital inputs and outputs as standard, complete with word clock sync inputs. Whilst the internal sample rate of all DN9340/44E units remain at

48kHz/44.1kHz, these digital connections are all 96 kHz compatible allowing easy interface with any other digital device featuring the higher sample rate.

The DN9344E unit is equipped with dual port

Ethernet communications interface. This is to facilitate much faster communication, response and metering between units than was previously possible with serial comms. The Ethernet ports allow for control of the units from a PC, either via

Ethernet or wirelessly with the Helix EQ Remote

Control Software (RCS) an ELGAR Add-In.

page 8

Architect’s & Engineer’s Specification

The Digital Slave Equaliser shall provide four audio channels (analogue and digital, in and out) grouped as two linkable pairs in a standard 2U 19” rack mount chassis.

Each audio channel shall include: Source select

(analogue or digital), input gain, delay up to one second, up to four filters, two dynamic EQ bands, up to 12 parametric EQ bands and a 31 band graphic EQ.

Digital inputs shall run at any sample rate up to 96kHz with internal sample rate conversion. The sample rate converter can be bypassed when the incoming digital signal has a sample rate of 44.1kHz or 48kHz.

A word clock input shall be provided to allow the system to lock to an external clock source. In addition, the word clock input can be used to only clock the digital outputs allowing digital audio to come into the unit at one sample rate and go out at another.

Digital outputs shall also run at any sample rate up to

96kHz. In standard operation, they shall run at the system sample rate (48kHz or 44.1kHz). Using the internal SRC, the digital outputs can also run at the same sample rate as the digital inputs or the word clock input.

All delay times shall be set in milliseconds and microseconds, or in distance units (metric and imperial) with a temperature compensation facility.

The high and low pass filters shall be selectable from notch, high pass, low pass, high shelf and low shelf types. The Low pass and high pass filters shall have selectable slopes of 6, 12, 18, 24, 36 and 48 dB per octave and the high and low shelf filters shall have selectable slopes of 6 and 12 dB per octave and ±12 dB of gain.

The dynamic EQ sections shall have independent high and low level thresholds and gain and be selectable from parametric EQ, or high shelf or low shelf filter types. The parametric EQ shall provide proportional-

Q, constant-Q and symmetrical-Q responses. The dynamic EQ sections shall also have independent attack and release times.

The parametric EQ sections shall have up to 12 dB of cut or boost and a Q value variable from 0.4 to 20. The parametric EQ shall provide proportional-Q, constant-

Q and symmetrical-Q responses.

The graphic EQ section shall provide 31 bands on standard frequencies defined in BS EN ISO 266 : 1997.

Proportional-Q, constant-Q and symmetrical-Q responses shall be provided as well as emulations of

Klark Teknik DN27 and DN360 Graphic Equalisers.

Each Digital Slave Equaliser shall meet or exceed the following performance specifications:

Frequency response: ±0.3 dB (20 Hz to 20 kHz)

Distortion @ +4 dBu: <0.01% (20 Hz to 20 kHz)

Dynamic Range: 115 dB (20 Hz to 20 kHz unweighted)

All analogue audio inputs and outputs shall be electronically balanced and use XLR connectors. All digital audio inputs and outputs shall be 110Ω

AES/EBU and use XLR connectors. There shall be two three-character starburst LED displays per pair of audio channels for displaying recalled memory, communications channel setting and remotely-set user information. There shall also be physical write-on strips for each pair of audio channels plus an additional one for the unit as a whole.

There shall be provision for 32 system memories and

32 factory presets.

The Digital Slave Equaliser shall be provided with an

RS-232 port on the front panel and two Ethernet ports on the rear panel. The Ethernet ports and RS-232 port shall be provided for remote control from a master

Digital Equaliser or a PC and additionally the front panel RS-232 port shall also provide the facility to download software updates and preset memories into the Digital Slave Equaliser. There shall also be a rear panel relay contact closure port to allow the recall of specific preset memories. The Digital Slave Equaliser shall be controllable from the ELGAR remote control

PC software. and have utility software to allow the editing of factory presets using an industry standard

PC spreadsheet application.

The unit shall be capable of operating from a 100 to

240V, ±10%.

The Digital Slave Equaliser shall be the Klark Teknik model DN9344E and no alternative option is available.

.

Technical Specification

F

Digital Inputs

Digital Inputs

Type

Impedance

Sample Rate

Word Length

*SRC Input at these sample rates

F

Analogue Inputs

Type

Two

Two 2-Channel Inputs

AES / EBU

110Ω

44.1kHz, 48kHz, 88.2kHz*,

96kHz*

24-bit or 16-bit

Impedance (Ω)

Common Mode

Rejection

Maximum Level

F

Word Clock Input

Type

Impedance

Two

Electronically balanced

(pin 2 hot)

20k

>80dB @ 1 kHz

+21dBu

BNC

75Ω

F

Digital Outputs

Type

Impedance

Sample Rate

Word Length

**SRC Output - these rates are only available when used in conjunction with a word clock or a digital input running at that frequency.

F

Outputs

Type

Two

Electronically balanced

(pin 2 hot)

+21dBu into >2k Maximum Level

F

Performance

Frequency response

(20Hz to 20kHz)

Distortion (THD+N)

@ +4dBu (20Hz to 20 kHz)

Dynamic range

(20Hz-20kHz unweighted)

±0.3 dB with all filters and EQ flat

<0.01%

115 dB

F Processing (Per Channel)

Input Gain

Delay

Filters

Types

Dynamic EQ

Range

Responses

Parametric EQ

Range

Responses

Graphic EQ

Range

Responses

+12dB to -40dB in 0.1dB steps plus Off

0-1 second (342.25 m or

333'10” at 20C in 20.8us steps)

4 Filters (max)

Low Pass, High Pass, Low

Shelf, High Shelf, Notch

2 Bands (max)

±12dB

Proportional, Constant,

Symmetrical

12 Bands (max)

±12dB

Proportional, Constant,

Symmetrical

31 Bands On ISO standard frequencies

±12dB

Proportional, Constant,

Symmetrical, DN27, DN360

F

Power Requirements

Voltage

Consumption

F

Terminations

Audio inputs/outputs

Ethernet inputs/outputs

RS-232

World Clock

Power

Two 2-Channel Outputs

AES / EBU

110Ω

44.1kHz, 48kHz, 88.2kHz**,

96kHz**

24-bit

100V to 240 V a.c. ±10%

<60W

3 pin XLR

Ethercon

8 pin Mini-DIN socket

(front)

9 pin D-type (rear)

BNC

3 pin IEC

F

Dimensions

Width

Height

Depth

F

Weight

Net

Shipping

483 mm (19inch)

88 mm (3.5 inch) - (2RU)

303 mm (12 inch)

6kg

8kg

.

STS Compatible

.

Show Command Component

Trade Descriptions Act:

Due to the company policy of continuing improvement, we reserve the right to alter these specifications without prior notice. E&OE.

page 9

Helix DN9848E -

System Controller

The digital system controller has been one of the fastest developing areas of signal processing in recent years. This is principally because it allows designers to combine a number of key control functions within a single device, thereby lowering overall costs and adding convenience.

Unfortunately, in many cases the relevance of the audio performance of the device has been overshadowed by the ‘bells and whistles’ functionality of the unit, ultimately somewhat defeating the object of the exercise. With the new

Klark Teknik Helix DN9848E system controller, no compromise has been made in either the feature set or the audio performance.

The Helix DN9848E brings a new level of flexibility to system control whether for live production or installation use. Since there is no preset routing within the device, it can be easily preprogrammed to perform almost any system-control task. Limiters and compressors on all outputs plus compressors on all inputs provide ultimate speaker control and protection, whilst no less than ninety-six bands of fully parametric EQ allow for both room and system equalisation. Best of all, there’s enough processing power onboard to allow every function to be available all the time, regardless of what is already in use.

The DN9848E System Controller features AES/EBU digital inputs as standard. Whilst the internal sample rate of the DN9848E unit remains at 48kHz, these digital connections are all 96 kHz compatible allowing easy interface with any other digital device featuring the higher sample rate. The unit now features a dual port Ethernet communications interface. This is to facilitate much faster communication, response and metering when controlling multiple units, than was previously possible with serial comms.

page 10

The DN9848E incorporates some customerrequested operational additions. The userconfigurability of the unit includes full matrix mixing capability between inputs and outputs, providing an unequalled level of flexibility. Whilst programming, inputs or outputs can now be

‘ganged’ so that the user can enter program data into one input or output menu and all connected inputs or outputs will be simultaneously updated.

Input and output parameters can also be copied from one to another. The internal memory structure has also been revised such that it is now possible to back up the RAM-based system memories into nonvolatile flash memory.

The proprietary ELGAR software coupled with Helix

System Controller Remote Control Software (RCS)

Add-In allows simple up-and-down-loading of system parameters into the FLASH memory locations, as well as storage and transmission of system information.

Should for example you need a new system configuration to be loaded into a unit on the other side of the world? No problem, simply email the

ELGAR file to wherever it needs to go, it can then be uploaded into the unit in seconds.

Architect’s & Engineer’s Specification

The Loudspeaker Processor shall provide four analogue and four digital input channels and eight output channels with fully featured matrix mixing in a standard 1U 19” rack mount chassis.

Each input channel shall include: input name, input gain control, input source select (analogue or digital), delay up to one second, eight parametric EQ stages

(+6 dB boost, -18 dB cut) and a compressor.

Digital inputs shall run at any sample rate up to 96kHz with internal sample rate conversion. The sample rate converter can be bypassed when the incoming digital signal has a sample rate of 48kHz.

Each output channel shall include: output name; configurable routing; delay up to 300 milliseconds; two cascaded all-pass phase correction filters, low and high pass crossover filters with slopes of 6, 12, 18, 24,

36 and 48 dB per octave and options of Linkwitz-Riley,

Butterworth and Bessel characteristics where appropriate; six parametric EQ sections with up to 12 dB of cut or boost (optionally two of these stages are configurable as low frequency and high frequency shelf filters respectively); a phase invert function; an output level control; and a compressor and a limiter.

All delay times shall be set in milliseconds and microseconds, or in distance units (metric and imperial) with a temperature correction facility.

Each Loudspeaker Processor shall meet or exceed the following performance specifications:

Frequency response

+/- 0.3dB (20Hz to 20kHz)

Distortion (THD+N)

<0.02% @ 1kHz, +8dBu

Dynamic Range

>114dB (20Hz to 20kHz unweighted)

All analogue inputs and outputs shall be electronically balanced and use XLR connectors. All digital inputs shall be 110Ω AES/EBU and use XLR connectors. All parameters shall be displayed and adjusted via an alphanumeric LCD display, three rotary encoders and individual menu buttons for each input and output channel.

There shall be provision for six user memories and in addition 32 system memories and 99 factory presets with a security lock-out feature. There shall also be a security lock-out feature that is enabled when the unit is under remote control.

The Loudspeaker Processor shall be provided with an

RS-232 and Ethernet ports for remote control and software updates. The Loudspeaker Processor shall be controllable from the ELGAR remote control PC software

The unit shall be capable of operating from a 100V to

240V, ±10%.

The Loudspeaker Processor shall be the Klark Teknik model DN9848E and no alternative option is available.

.

Technical Specification

F

Digital Inputs

Type

Impedance

Sample Rate

Two 2-Channel Inputs

AES / EBU

110Ω

96kHz*, 88.2kHz*, 48kHz,

44.1kHz*

24-bit or 16-bit

F

Word Length

*SRC Input at these sample rates

Analogue Inputs

Type

Four

Electronically balanced

(Pin 2 Hot)

Impedance (Ω)

Balanced

Unbalanced

Common Mode Rejection

Maximum level

F

Audio Outputs

Type

Eight

Electronically Balanced

(Pin 2 Hot)

Minimum load impedance 56Ω/20nF

Source impedance 56Ω

Maximum level + 21dBu into > 2kΩ

F

Performance

Frequency response

20k

10k

>80dB @ 1kHz

+ 21dBu

Distortion (THD+N)

Dynamic range

(20 Hz to 20 kHz) +/- 0.3dB

with all filters and EQ flat

<0.02% @ 1kHz, +8 dBu

(20 Hz to 20 kHz unweighted) >114dB

F

Input Processing (per channel)

Input gain +12dB to -40dB in 0.1 dB steps plus Off

Parametric EQ 1-12

Frequency range: 20Hz to 20kHz in 21 steps per octave

Boost/cut: +6/-18dB in 0.1dB steps

Q: 3.0 to 0.08

Compressor

Threshold:

+21dBu to - 10dBu in 0.1dB steps

Attack:

Delay

40us to 100ms

Insert: On/Off

Release: 10ms to 2000ms

Ratio: 1:1 to 5:1

Knee: Hard/Soft

0 to 1 second

342.25 m or 1122’ 10” at 20(C) in 20.8us steps

F

Output Processing (per channel)

Routing Full featured matrix mixing: any combination of inputs can be routed to any output in .1dB steps from 0dB to

–40dB and OFF.

Delay 0 to 300ms (102.68 m or

333’ 10” at 20(C)in 5.02 us steps)

Phase correction filters

All pass filter

Low pass filter

0˚ to 180˚ in 5˚ steps

1st and 2nd order frequency range 20Hz to

20kHz in 21 steps per octave.

Supported configurations are:- Butterworth (6dB/Oct,

12dB/Oct, 18dB/Oct,

24dB/Oct, 36dB/Oct,

48dB/Oct)

Linkwitz-Riley (12dB/Oct,

24dB/Oct)

Bessel (12dB/Oct,18dB/Oct,

24dB/Oct, 36dB/Oct,

48dB/Oct)

High pass filter

Parametric EQ 1/

Low shelf filter

Parametric EQ 2-5

Parametric EQ 6/

Hi shelf filter

Polarity invert

Output gain

Normal/invert

+12dB to -40dB in 0.5dB steps plus Off

Look-ahead limiter

Compressor

Threshold: +21dBu to -

10dBu in 0.5dB steps

Release: 10ms to 1000ms

Knee: Hard/Soft

Threshold: +21dBu to

-10dBu in 0.1dB steps

Attack: 40us to 100ms

Insert: On/Off

Release: 10ms to 2000ms

Ratio: 1:1 to 5:1

Knee: Hard/Soft

On/off Mute

F

Terminations

Audio inputs/outputs

Ethernet inputs/outputs

RS-232

Power

F

Power Requirements

Voltage / Consumption

3 pin XLR

Ethercon

8 pin Mini-DIN socket

3 pin IEC

100 to 240V a.c ±10%

50/60Hz < 60VA

F

Dimensions

Height

Width

Depth

44 mm (1.75 inch) - (1U)

483mm (19 inch)

287mm (12 inch)

F

Weight

Nett

Shipping

4kg

6kg

.

Show Command Component

frequency range 20Hz to

20kHz in 21steps per octave.

Supported configurations are :-

12dB/Oct Peaking

24dB/Oct Peaking

Butterworth (6dB/Oct,

12dB/Oct, 18dB/Oct,

24dB/Oct, 36dB/Oct,

48dB/Oct)

Linkwitz-Riley (12 dB/Oct,

24dB/Oct)

Bessel (12dB/Oct,18dB/Oct,

24dB/Oct, 36dB/Oct,

48dB/Oct)

Peaking Filter Boost: 0dB to

+6dB in 0.1dB steps.

frequency range 20Hz to

20kHz in 21steps per octave.

Boost/cut: +12/-12dB in 0.1dB steps

Parametric EQ Q: 3.0 to

0.08

Shelf slope: 6dB/Oct and

12dB/Oct frequency range 20Hz to

20kHz in 21steps per octave.

Boost/cut: +12/-12dB in 0.1dB steps

Q: 3.0 to 0.08

frequency range 20Hz to

20kHz in 21steps per octave.

Boost/cut: +12/-12dB in 0.1dB steps

Parametric EQ Q: 3.0 to

0.08

Shelf slope: 6 dB/Oct and

12dB/Oct

Trade Descriptions Act:

Due to the company policy of continuing improvement, we reserve the right to alter these specifications without prior notice. E&OE.

page 11

Midas and Klark Teknik

ELGAR Framework

ELGAR is a software shell for a PC that allows Midas and Klark Teknik product control software, called

Add-Ins, to operate.

ELGAR allows data from individual units, for example a number of Helix units and a Midas

Heritage 1000, via the relevant Add-In to be stored within one show file on your PC. You can therefore have your entire show with you on your laptop, allowing you to fine tune settings in your hotel room and then just upload it later at the venue.

ELGAR will also ensure that the correct Add-In will only communicate with the correct piece of hardware – in other words it will make certain that a

Helix Remote Control Add-In will only talk to the

Helix unit and not the Heritage 1000.

.

Show Command Component

Helix DN9848E Remote Control Software operating under Elgar

Helix EQ Remote Control Software operating under Elgar page 12

Midas Heritage 1000 Library Manager operating under Elgar

Helix EQ

Remote Control Software

Add-In

To further increase the functionality and control of the Helix EQ is the add-in for the Midas and Klark

Teknik ELGAR control shell – the Helix EQ RCS.

This allows remote PC access to all the functions of

Helix EQ, including overall system store and recall.

An extremely intuitive Graphical User Interface (GUI) allows simple navigation between function pages, the overall number of which has been kept to a minimum. The system is designed to work with all

PCs including the latest handheld PC tablets for ease of wireless connection and portability. Realtime indication of unit online / offline status is visible on all pages and the individual function pages have familiar and easy to use controls whether using a mouse, keypad or stylus.

The make or break of this type of system is always navigation, and this is one of the Helix EQ RCS’s real strengths, using our proprietary ‘FastNav’ page. This is a control panel that is always active, and shows every function of every channel. Thus it is possible to move between, for instance, the graphic EQ for channel 10 and the T-DEQ controls for channel 37 with a single click.

Available now as a free download from www.klarkteknik.com.

.

Show Command Component

page13

Helix System Controller

Remote Control Software

Add-In

Helix System Controller Remote Control Software

(RCS) provides online remote control and offline system configuration, either via wired or wireless

Ethernet technology.

The remote control software allows intuitive control of every function of an individual unit or units, it also (and uniquely) allows inputs and outputs to be assigned to control groups.

These groups can then be made to control any parameter of the unit or the system – muting, delay,

EQ, dynamics, speaker or room zones, whatever you need.

Simple screens with easy-access controls make for quick adjustments and entire system set-ups can then be stored as an ELGAR computer file.

ELGAR, Helix System Controller RCS and Helix EQ

RCS are available free of charge from the Klark

Teknik website.

.

Show Command Component

STS -

Solo Tracking System

Helix offers the ability to link to all Midas consoles in the Heritage, Legend and Siena range via the Solo

Tracking System (STS). This means that when you press any solo key on the console, the EQ for that input or output (outputs only for Siena) is instantly shown on the Helix DN9340E Dual EQ or a wired or wireless PC ready for immediate control. Once displayed on the your chosen user interface you naturally have complete access to all the Helix EQ functions allocated to that input or output. The graphic EQ portion of Helix will also be displayed on a DN9331 RAPIDE Graphic Controller if connected into the system.

A RS-232 connection is supplied on the rear panel of Helix DN9331 and DN9340E for this purpose, and up to 64 channels of Helix can be interconnected using standard Cat 5 cables.

page 14 page 10 page 15

DN370 -

Dual Channel 30 Band 1/3

Octave Graphic Equaliser

The Klark Teknik DN370 is the latest evolutionary step in a process of design refinement that goes back over 30 years. With DN370 we’ve started from the ground up and produced a unit that is totally without compromise, and one that we believe is the finest professional graphic equaliser in the world today. It also perfectly complements the existing

Klark Teknik range of equalisers, both analogue and digital.

Our aim is simply to provide discerning professional users with the best possible solutions for system control. Our market research shows that the graphic equaliser is still the most commonly-used EQ device in fixed and mobile live sound applications, as well as many installations, mainly because the physical user interface provides instant access and controllability in even the most demanding environments. To this end we have completely reevaluated the role of the graphic EQ, focusing exclusively on providing a new feature set that better reflects the needs of modern users.

Like all Klark Teknik units, DN370 is engineered for a lifetime of hard use and carries our 3-year international factory warranty. page 16

Architect’s & Engineer’s Specification

The equaliser shall provide ±12dB of boost and cut at

30 1/3 octave ISO centre frequencies from 25Hz-

20kHz, selectable to ±6dB for increased fader resolution.

The equaliser shall meet or exceed the following performance specifications:

Frequency Response ± 0.5dB (20Hz-20kHz)

Distortion (THD+N) <0.003% @1kHz, +4dBu

Dynamic Range >114 dB (20Hz-20kHz unweighted,

±12 dB range)

The equaliser shall allow have one adjustable secondorder low pass filter and one adjustable second-order high pass filter per channel, and two adjustable overlapping notch filters per channel.

The unit shall have an equalisation section by-pass and shall be fail-safe, that is the unit shall return automatically to the by-pass condition in the event of power supply interruption.

Each equaliser shall use centre-detented slide potentiometers arranged to give a graphical display of frequency plotted against level. The slide potentiometers shall have protective covers to inhibit the ingress of dirt and dust.

All audio connections shall be electronically balanced and use XLR and Phoenix style connectors. Input and output transformers shall be available as an option.

The unit shall be capable of operating from a 100-

240V ± 10% 50/60Hz a.c. power source.

The equaliser shall be the Klark Teknik Dual Channel model DN370, and no alternative specification option is available.

.

Technical Specification

F

Inputs

Type

Impedance (Ω)

Maximum input level

Two

Electronically balanced

(pin 2 hot)

20k

+22dBu

F

Outputs Two

(pin 2 hot)

Minimum load impedance 600 Ω

Source impedance

Maximum output level

<60 Ω

+22dBu into >2kΩ

F

Performance

Frequency response relative to signal at 1kHz

EQ out

EQ in (flat)

Distortion (THD+N)

Dynamic range

Overload indicator

Gain

±0.5 dBu 20Hz-20kHz

±0.5 dBu

±0.5 dBu

< 0.003% @ 1kHz, +4 dBu

>114dB (20Hz-20kHz unweighted, ±12dB range)

+20 dBu

- ∞ to +6dBu

Centre Frequencies

To BS EN ISO 266:1997

Maximum Boost/Cut

High Pass Filter Slope

Low Pass Filter Slope

Notch filter attenuation

F

Terminations

Audio

25Hz-20kHz, 1/3 octave

Tolerance ±5%

±12dB, ±6dB

12 dB/octave

12 dB/octave

>17dB, Q=32

3-pin XLR and

6-pin Phoenix

F

Power Requirements

Voltage 100-240V ± 10% a.c.

Consumption <60W

F

Dimensions

Height

Width

Depth

133mm (5.25 inch - 3U)

482mm (19 inch)

205mm (8 inch)

F

Weight

Nett

Shipping

5.8kg

7.0kg

F

Options

Input and output balancing transformers

Trade Descriptions Act:

Due to the company policy of continuing improvement, we reserve the right to alter these specifications without prior notice. E&OE.

page 17

DN360 -

Dual Channel 30 Band 1/3

Octave Graphic Equaliser

Now approaching some 22 years in continuous production, the DN360 dual graphic EQ has achieved ubiquity in professional audio circles. With nearly 36,000 units in the field worldwide, and the lowest failure rate of any comparable product, the

DN360 even today remains the dual graphic EQ of choice in most instances.

Why is it still so popular, especially in this menudriven digital age? The answer is threefold: instant access, total reliability, and the great sound of the best analogue EQ money can buy. One of the main contributors to DN360s audio performance is its variable ‘Q’ design, meaning that the ‘Q’ value of any fader becomes narrower as the fader approaches maximum cut or boost.

So rather than a collection of unconnected cuts and boosts (as provided by a ‘constant-Q’ device) the

DN360 user is rewarded with a flowing, musical response with any overall fader setting. This proprietary design also allows every fader to function correctly regardless of the relative position of its neighbours, another design fault inherent in

‘constant-Q’ units. Each channel also features an

18dB/octave high-pass filter set at 30Hz to eliminate subsonic ‘rumble’ if required, plus an EQ in/out switch and an overall 6dB / 12dB fader scale switch for normal or high fader resolution.

A design classic, still made as only KT know how.

page 18

Architect’s & Engineer’s Specification

The equaliser shall provide 30 bands of 12dB* of boost and cut on ISO frequency centres, from 25Hz-20kHz.

*Selectable to 6dB for increased fader resolution.

Each equaliser shall meet or exceed the following performance specifications:

Distortion (THD+N) <0.01% @1kHz, +4dBu

Frequency response ±0.5dB(20Hz-20kHz)

Noise <-90dBu (20Hz-20kHz unweighted)

Maximum Output level into 600Ω +22dBu

Each equaliser shall allow for; subsonic frequency attenuation at 18dB/octave, equalisation section bypass and shall be fail-safe, that is the unit shall return automatically to the by-pass condition in the event of power supply interruption.

Each equaliser shall use centre detented slide potentiometers arranged to give a graphical display of frequency plotted against level.

A rear panel switch shall be provided to isolate the signal ground connections, quickly and safely, from the chassis ground.

All audio connections shall be via XLR style connectors and a tamperproof front panel cover shall be available to fit the unit.

The unit shall be capable of operating from a

115/230V ± 12% 50/60Hz AC power source.

The equaliser shall be the Klark Teknik Dual Channel

Model DN360, and no alternative specification option is available

.

Technical Specification

F

Inputs

Type

Two

Electronically balanced

(pin 3 hot)

Impedance (Ω)

Balanced

Unbalanced

F

Outputs

Type

Min. load impedance

Source impedance

Max. level

20k

10k

Two

Unbalanced (pin 3 hot)

600Ω

<60Ω

+22dBu

F

Performance

Frequency response (20Hz-20kHz)

Eq out

Eq in (flat)

±0.5dB

±0.5dB

Distortion (THD+N)

Equivalent input noise

Eq in (flat)

Channel separation

Overload indicator

Gain

<0.01% @ 1kHz, + 4dBu

(20Hz-20kHz unweighted)

<-90dBu

>75dB @ 1KHz

+19dBu

-∞ to +6dB

F

Filters

Centre frequencies 2x30, to ISO 266:1997

25Hz-20kHz 1/3 octave

±5%

±6/12dB

18dB/octave - 3dB @ 30Hz

Tolerance

Maximum boost/cut

Subsonic filter

F

Terminations

Inputs

Outputs

Power

F

Power Requirements

Voltage

Consumption

3 pin XLR

3 pin XLR

3 pin IEC

115/230V 50/60Hz

<15VA

F

Dimensions

Height

Width

Depth

133mm (5.25 inch) - (3U)

482mm (19 inch)

205mm (8 inch)

F

Weight

Nett

Shipping

5.8kg

7kg

F

Options

Security Cover

Transformer input* /output balancing

*Input transformer balancing is non retrofittable and has to be specified with order.

** “MELT”: Proprietary thick-film circuit.

Trade Descriptions Act:

Due to the company policy of continuing improvement, we reserve the right to alter these specifications without prior notice. E&OE.

page 19

DN1248 -

Microphone Splitter

Back in 1999, Klark Teknik responded to market demand by producing exactly what our customers had been requesting for years – a roadworthy and flexible active signal splitter system with the superlative audio performance they’d expect from

Klark Teknik. So, DN1248 was born, and also delivered with a host of features simply not found in any comparable unit.

We specified an internal power supply (with a factory option of dual auto-switching PSUs at very low cost), more inputs and outputs per unit than any competitor, a uniquely flexible solo buss system, and a Midas Heritage-series microphone preamp, all made available at a per-channel price appreciably lower than any comparable device. These features have made DN1248 one of our most successful units worldwide, but still some customers were not satisfied. So, once again we have responded to market demand, hence the introduction of the new

DN1248 Plus.

This unit takes all the operational and cost advantages of the original, and adds a duplicate set of inputs and outputs to the rear panel. This adds a further dimension of flexibility, and allows users to upgrade their existing systems with the minimum of re-wiring. Add in the regular KT 3-year international factory warranty, and you have a unit that exceeds the expectations of even the most demanding users.

.

page 20

Architect’s & Engineer’s Specification

The Mic Splitter shall provide 12 discrete audio channels in a standard 3U 19" rack mount chassis.

Each channel shall have a microphone preamplifier, two transformer-isolated outputs, and two electronically balanced outputs. Optionally, all outputs may be transformer-isolated.

Each channel shall also provide separate +30dB boost and -15dB pad switches, switchable +48V phantom power, an earth lift function and a soloing facility.

The Mic Splitter shall have a headphone amp to allow the monitoring of soloed audio channels.

The headphone amplifier shall have a headphone jack socket for the headphones, a rotary level control for the headphones output and a seven-segment LED bargraph for monitoring the soloed signal level.

Each Mic Splitter shall meet or exceed the following performance specifications:

Electronically Balanced Outputs

Distortion (THD+N)

< 0.01% @1 kHz, +4 dBu

Frequency response

+0 / -0.5 dB (20 Hz to 20 kHz)

Transformer Balanced Outputs

Distortion (THD+N)

<0.04% @1 kHz , +4 dBu

Frequency response

+0 / -1.0 dB (20 Hz to 20 kHz)

The audio connections for each of the twelve audio channels shall be via 3-pin XLR style connectors -

Inputs : two parallel-connected female XLR connectors (one on the front panel and the other on the rear panel).

Transformer Outputs: one male XLR connector on the front panel for each output.

Electronic Outputs: one output with one front and one rear panel male XLR connectors, one output with one rear panel male XLR connector only.

The rear panel input XLRs and output XLRs shall be mounted on three removable plates, and be grouped as one panel of input connectors and two panels of output connectors

All inputs and outputs shall be made available internally on PCB-mounted terminal strips to enable users to retrofit alternative rear panel connector configurations.

The unit shall be capable of operating from a 110 to

240V ±10%, 50 to 60 Hz AC power source. The unit shall have the option of dual redundant power supplies.

The Mic Splitter shall be the Klark Teknik model

DN1248 plus and no alternative option is available.

.

Technical Specification

F

Inputs

Input impedance

CMRR

Equivalent input noise

Connectors

Signal present level

Signal clip level

F

Outputs

Electronically balanced

Two

parallel-connected female XLR connectors

(one on the front panel and the other on the rear panel

> 2kΩ

> -100 dB @ 100 Hz to

10 kHz

< - 100 dBm @ unity gain

3 pin female XLR

(external)

3 way terminal strip

(internal)

> - 25dBu

> + 21dBu

Source impedance

Min Load

Max level

Connectors

Transformer balanced

& isolated one output with one front and one rear panel male

XLR connectors, one output with one rear panel male XLR connector only

50Ω

600Ω

+ 21dBu @ 1kHz

3 pin male XLR

(external)

3 way terminal strip

(internal) one male XLR connector on the front panel for each output

Source impedance

Min Load

Max level

Connectors

70Ω

600Ω (-3dB level loss into

200Ω)

+ 18dBu @ 1kHz

3 pin male XLR

(external)

3 way terminal strip

(internal)

F

Performance

Electronically balanced outputs

Frequency response

Distortion (THD+N)

20Hz to 20kHz

+ 0 / - 0.5dB

< 0.01 % @1kHz, +4dB

Transformer balanced & isolated outputs

Frequency response

Distortion (THD+N)

20Hz to 20kHz

+ 0 / - 1.0dB

< 0.04 % @1kHz, +4dB

F

Terminations

Audio Inputs / Outputs

Power

F

Power Requirements

3 pin XLR

3 pin IEC

110 to 240V ±10%,

50/60Hz < 60W

F

Dimensions

Height

Width

Depth

F

Weight

Nett

Shipping

132 mm (5.2 inches) - (3U)

483 mm (19 inches)

300 mm (12 inches)

7.4 kg

8.4 kg

F

Options

*Dual power supply

*All outputs transformer balanced

* All options are non retrofittable and must be specified with order

Trade Descriptions Act:

Due to the company policy of continuing improvement, we reserve the right to alter these specifications without prior notice. E&OE.

page 21

DN410 -

Dual Channel 5 Band

Parametric Equaliser

Klark Teknik’s international reputation is founded on their EQ products, and one of the reasons for this is the DN410. Built to stand years of hard use yet sensitive and accurate, they remain the premier choice of audio professionals who require the very best in great-sounding analogue parametric EQ.

Each EQ channel features five bands of fully parametric EQ, with each band having an active range of 20Hz to 20kHz. This design makes it simple to accurately EQ out problem frequencies by dialling in a narrow-Q notch filter then sweeping it across the frequency range. It also means that EQ bands can be placed very close together or overlapped if required, unlike some competitive units which allocate specific frequency ranges to their units.

Each EQ band has an in / out button, and the unit is also fitted with an overall in / out switch for easy comparison of EQ’d and non-EQ’d responses

.

page 22

Architect’s & Engineer’s Specification

The dual channel equaliser shall provide five bands of fully parametric filters and separate tuneable high & low cut filters. Each equaliser filter shall provide 25dB of attenuation and 15dB of accentuation at continuously variable frequencies ranging from 20Hz-

20kHz and shall allow for bandwidth adjustment from

1/12 to 2 octaves.

The equaliser shall meet or exceed the following performance specifications:

Distortion (THD+N) <0.01% @ 1kHz, 4dBu

Frequency response ±1dB (20Hz-20kHz)

Noise <-94dBu (20Hz-20kHz unweighted)

Maximum output level into 600Ω +22dBu

The equaliser shall have adjustable low & high cut

12dB/octave slope filters ranging from 15Hz-300Hz &

2.5kHz-30kHz.

Stereo and mono operation of the unit shall be possible with all 10 filters available in mono mode.

Separate in/out switches shall be provided for each parametric filter section, and each complete equaliser channel.

The equaliser shall be fail-safe, that is the unit shall return automatically to the bypass condition in the event of power supply interruption.

A rear panel switch shall be provided to isolate the signal ground connections, quickly and safely, from the chassis ground.

All audio connections shall be via XLR style connectors and a tamperproof front panel cover shall be available to fit the unit.

The unit shall be capable of operating from a

115/230V ±12% 50/60Hz AC power source.

The equaliser shall be the Klark Teknik Model DN410 and no alternative specification option is available.

.

Technical Specification

F

Inputs

Type

Two

Electronically balanced

(pin 3 hot)

Impedance (Ω)

Balanced

Unbalanced

F

Outputs

Type

Min. load impedance

Source impedance

Max. level

20k

10k

Two

Unbalanced (pin 3 hot)

600Ω

<60Ω

+22dBu

F

Performance

Frequency response (20Hz-20kHz)

Eq in (Flat, one band active) ±1dB

Eq out

Distortion (THD+N)

±1dB

<0.01% @ 1kHz, +4dBu

Equivalent input noise

Channel separation

Gain

Overload indicator

(20Hz-20kHz unweighted)

<-94dBu

>75dB @ 1kHz

-∞ to +6dB

+19dBu

F

Filters

Type

Bandwidth

Max. boost/cut

Frequency ranges

Parametric (2 x 5)

Variable from 1/12 ~ 2 octaves

+15/-25dB

20Hz-200Hz/

200Hz-2kHz/2kHz-20kHz

15Hz-300Hz/12dB octave

2k5Hz-30kHz/12dB octave

High Pass filter

Lower Pass filter

F

Terminations

Input

Output

Power

3 pin XLR

3 pin XLR

3 pin IEC

F

Power Requirements

Voltage

Consumption

F

Dimensions

Height

Width

Depth

115/230V 50/60Hz

<15VA

89mm (3.5 inch) - (2U)

482mm (19 inch)

235mm (9.25 inch)

F

Weight

Nett

Shipping

5kg

6kg

F

Options

Security cover

Transformer input* / output balancing

* Input transformer balancing is non retrofittable and has to be specified with order.

Trade Descriptions Act:

Due to the company policy of continuing improvement, we reserve the right to alter these specifications without prior notice. E&OE.

page 23

DN500 -

Dual Compressor/Limiter

Expander

The DN500 Plus dual compressor provides two channels of full function compression, expansion, limiting and peak clipping in 1RU. A fully variable knee control allows continuous definition of compression style, and auto / manual modes provide either fast set-up or the necessary control for advanced compression effects.

The DN500 Plus has been a broadcast-industry standard for many years, due mainly to its extremely low noise performance, typically >2dB quieter than any comparable product.

Expansion characteristics are continuously variable between hard gating and gentle expansion thanks to the flexible expander section, and both compressor and expander section are fitted with their own side chain inputs. The channels can be ganged together for stereo operation, and the peak clipper eliminates transient overload whilst tracking the limiter threshold for total protection.

page 24

Architect’s & Engineer’s Specification

The compressor/limiter shall provide two complete channels of compression, expansion, peak limiting and peak clipping. The compressor section shall provide for adjustment of Threshold, Ratio, Knee,

Attack and Release and have push button selection of auto or manual modes. The expander section shall provide for adjustment of Threshold, Ratio and

Release and have push button selection of Auto or

Fixed attack times. The limiter section shall provide for adjustment of Threshold and have push button selection of a Peak Clipper. An output gain control and level meter shall be provided. Gain reduction meters shall be provided for both compressor and expander sections.

The compressor/limiter shall meet or exceed the following specifications:

Distortion (THD+N) <0.03% @1kHz, +4dBu

Frequency response ±0.5dB (20Hz-20kHz)

Noise <-94dBu (20Hz-20kHz unweighted)

Compressor Attack time 50μs-20ms

Compressor Release time 60ms-2 secs

Maximum output level into 600Ω +21dBu

Push button switches shall be provided to select compressor, expander and channel bypass and to link both channels for stereo operation. Side chain inputs shall be provided for both compressor and expander sections. Channel inputs and outputs shall be via XLR style connectors, external side chain inputs shall be via 1/4” jack. A tamperproof front panel cover shall be available to fit the unit. The compressor/limiter shall be 19” standard rack mountable and 1U high. The unit shall be capable of operating from a 100V, 115V, 220-

240V 50/60Hz AC power source.

The compressor/limiter shall be the Klark Teknik

Model DN500 Plus and no alternative specification option is available.

.

Technical Specification

F

F

Inputs

Type

Impedance (Ω)

Balanced

Unbalanced

Side Chain Inputs

Type

Two

Electronically balanced

(pin 3 hot)

20k

10k

Two (Compressor) +

Two (Expander)

Electronically balanced

(tip hot)

Impedance (Ω)

Balanced

Unbalanced

F

Audio Outputs

Type

Min. Load impedance

Source impedance

Max.level

F

Performance

Frequency response

Distortion (THD+N)

Equivalent input noise

20k

10k

Two

Unbalanced (pin 3 hot)

600Ω

<60Ω

+21dBu

(20Hz-20kHZ)

±0.5dB

<0.03% @ 1kHz, +4dBu

(20Hz-20kHz unweighted)

<-94dBu

F

Compressor

Threshold

Ratio

Knee

Envelope

-30dBu to +20dBu

1:1 to 50:1

1dB (Hard) to 40dB (soft)

Switchable auto (attack and release controls disabled) or manual

50μs to 20ms

60ms to 2 secs

Attack (90% capture)

Release (90% recovery)

F

Expander

Threshold

Ratio

Attack

(2ms)

Release (90% recovery)

Output Gain

F

Limited/Clipper

Threshold

F

Terminations

Audio inputs/outputs

Side-Chain inputs jack

Power

-40dBu to +20dBu

1:1 to 25:1

Switchable auto or fixed

40ms to 2 secs

-10dB to +30dB

0dBu to +20dBu

3 pin XLR

Normalled 1/4 inch stereo

3 pin IEC

F

Power Requirements

Voltage

50/60Hz

Consumption

F

Dimensions

Height

Width

Depth

100V, 115V, 220-240V

<30VA

44.5mm (1.75 inch) - (1U)

482mm (19 inch)

292mm (11.5 inch)

F

Weight

Nett

Shipping

5kg

6kg

F

Options

Security cover

Transformer input* / output balancing

*Input transformer balancing is non retrofittable and has to be specified with order.

Trade Descriptions Act:

Due to the company policy of continuing improvement, we reserve the right to alter these specifications without prior notice. E&OE.

page 25

DN504 -

Quad Compressor Limiter

The DN504 Plus packs four fully featured compressors into just 1RU, and boasts audio performance equal to its super-quiet stable mate the DN500 Plus.

Fitted with hard / soft knee controls, auto and manual attack / release functions, and side chain inputs for each channel, the DN504 Plus is especially suited for in-ear monitoring applications, especially since channels can be linked as stereo pairs if required. Comprehensive gain reduction and output level metering completes this extremely useful and space-saving professional tool.

page 26

Architect’s & Engineer’s Specification

The compressor/limiter shall provide four complete channels of compression. Each channel shall provide for adjustment of Threshold, Ratio, Attack and Release and have push button selection of auto or manual modes and hard or soft knee. An output gain control and level meter shall be provided. Gain reduction meters shall also be provided for each channel.

The compressor/limiter shall meet or exceed the following specifications:

Distortion (THD+N) <0.03% @1kHz, +4dBu

Frequency response ±0.5dB (20Hz-20kHz)

Noise <-94dBu (20Hz-20kHz unweighted)

Compressor Attack time 50μs-20ms

Compressor Release time 60ms-2 secs

Maximum output level into 600Ω +21dBu

Push button switches shall be provided to select channel bypass and to link adjacent channels for stereo operation. Side chain inputs shall be provided for each compressor section. Channel inputs and outputs shall be via XLR style connectors, external side chain inputs shall be via 1/4” jack. A tamperproof front panel cover shall be available to fit the unit. The compressor/limiter shall be 19”standard rack mountable and 1U high. The unit shall be capable of operating from a 100V, 115V,

220-240V 50/60Hz AC power source.

The compressor/limiter shall be the Klark Teknik Model

DN504 Plus and no alternative specification option is available.

.

Technical Specification

F

Inputs

Type

Four

Electronically balanced

(pin 3 hot)

F

Impedance (Ω)

Balanced

Unbalanced

Side Chain Inputs

Type

20k

10k

Four

Electronically balanced

(tip hot)

F Impedance (Ω)

Balanced

Unbalanced

F

Audio Outputs

Type

Min. Load impedance

Source impedance

Max. Level

F

Performance

Frequency response

Distortion (THD+N)

Equivalent input noise

20k

10k

Four

Unbalanced (pin 3 hot)

600Ω

<60Ω

+21dBu

(20Hz-20kHz) ±0.5dB

<0.03% @ 1kHz, +4dBu

(20Hz-20kHZ unweighted)

<-94dBu

>90dB @ 1kHz Channel separation

F

Compressor

Threshold

Ratio

Knee

Envelope

-30dBu to +20dBu

1:1 to 50:1

Switchable 1dB (hard) /

40dB (soft)

Switchable auto (attack and release controls disabled) or manual

50μs to 20ms

60ms to 2 secs

-10dB to +30dB

Attack (90% capture)

Release (90% recovery)

Output gain

F

Terminations

Audio inputs/outputs

Side-chain inputs

Power

F

Power Requirements

Voltage

50/60Hz

Consumption

F

Dimensions

Height

Width

Depth

F

Weight

Nett

Shipping

3 pin XLR

Normalled 1/4 inch stereo jack

3 pin IEC

100V, 115V, 220-240V

<30VA

44.5mm (1.75 inch) - (1U)

482mm (19 inch)

292mm (11.5 inch)

5kg

6kg

F

Options

Security cover

Transformer input* / output balancing

*Input transformer balancing is non retrofittable and has to be specified with order.

Trade Descriptions Act:

Due to the company policy of continuing improvement, we reserve the right to alter these specifications without prior notice. E&OE.

page 27

DN514 -

Quad Auto Gate

The DN514 Plus has assumed industry standard status as the multi-channel frequency-conscious gate unit of choice for live and recording applications. Providing the same ultimate audio performance as its DN500 Plus series siblings, the

DN514 Plus is extremely comprehensive but easy to set up.

Two semi-automatic attack modes (calibrated for

‘Fast’ and ‘Slow’) allied with a hold value that is automatically scaled to the release time, allow each gate to be precisely configured to its application. It is also fitted with the unique ‘Sync’ function, which locks all four gate release times, allowing easy synchronisation of harmony parts. Each gate also features a side chain input, and an additional key input to allow external triggering if required. LED indicators show gate status, and both Master (unit) and individual channel bypass switches aid set-up.

page 28

Architect’s & Engineer’s Specification

The noise gate shall provide four channels of frequency-conscious gating with each channel having adjustable low and high cut 12dB/octave filters, variable from 20Hz-5kHz and 80Hz-20kHz, switchable into side chain or audio signal path.

The noise gate shall meet or exceed the following specifications:

Distortion (THD+N) <0.03% @1kHz, +4dBu

Frequency response ±0.5dB (20Hz-20kHz)

Noise<-100dBu gate closed (20Hz-20kHz unweighted)

<-94dBu gate open (20Hz- 20kHz unweighted)

Attack time 50μs-2ms

Hold time/Release time 40ms-2 secs

Maximum output level into 600Ω +21dBu

A tamperproof front panel cover shall be available to fit the unit. The noise gate shall be 19” standard rack mountable and 1U high.

The unit shall be capable of operating from a 100V,

115V, 220-240V 50/60Hz AC power source.

The noise gate shall be the Klark Teknik Model DN514

Plus and no alternative specification option is available.

.

Technical Specification

F

Inputs

Type

Four

Electronically balanced

(pin 3 hot)

F

Impedance(Ω)

Balanced

Unbalanced

Key Inputs

Type

20k

10k

Four

Electronically balanced

(tip hot)

F

Impedance (Ω)

Balanced

Unbalanced

Audio Outputs

Type

Min. Load impedance

Source impedance

Max. level

20k

10k

Four

Unbalanced (pin 3 hot)

600Ω

<60Ω

+21dBu

F

Performance

Frequency response

Distortion (THD+N)

Equivalent input noise

Gate open

Gate closed

Attack programme related, semi-automatic

(20Hz-20kHz)

±0.5dB

<0.03% @ 1kHz, +4dBu

(20Hz-20kHz unweighted)

<-94dBu

<-100dBu

Hold/Release

Threshold

Attenuation

50μs to 200μs “Fast”

500μs to 2ms “Slow”

Variable 40ms to 2sec

Variable-40dBu to +20dBu

>84dB Gate closed

F

Key Filters

High pass filter

Low pass filter

F

Terminations

Audio inputs/outputs

Key inputs

Power

20Hz-5kHz/12dB octave

80Hz-20kHz/12dB octave

3 pin XLR

Normalled 1/4 inch stereo jack

3 pin IEC

F

Power Requirements

Voltage

50/60Hz

Consumption

100V, 115V, 220-240V

<30VA

Dimensions

Height

Width

Depth

F

Weight

Nett

Shipping

44.5mm (1.75 inch) - (1U)

482mm (19 inch)

292mm (11.5 inch)

5kg

6kg

F

Options

Security cover

Transformer input* / output balancing

*Input transformer balancing is non retrofittable and has to be specified with order.

Trade Descriptions Act:

Due to the company policy of continuing improvement, we reserve the right to alter these specifications without prior notice. E&OE..

page 29

DN1414 -

Di Module

A good DI (direct-injection) device is essential in almost any system. Given that its primary function is to replace a microphone, the audio performance is critical. They also need to be extremely rugged, and also capable of providing flexible operation. The

Klark Teknik DN1414 DI module both meets these criteria, and more.

The DN1414 multiple DI module brings all the advantages of the DN100 to a rackmount format, packing no less than 14 discrete DI boxes into a single 3RU package.

10 channels are configured as per the DN100, and the two remaining channels are arranged in pairs, featuring simple jack in / XLR out connection for use as single DI units or as stereo pairs.

Customers can specify a factory-fitted dual power supply option if required, and the unit is also fitted as standard with a multipin retrofit kit. This allows a user to fit the multipin connector of their choice to a blank panel on the rear and then hard wire the outputs direct to it.

All this makes the DN1414 a very flexible device which suits a number of applications in live production, in the studio and in broadcast.

page 30

Architect’s & Engineer’s Specification

The Multiple DI Module shall provide 14 discrete audio channels in a standard 3U 19” rack mount chassis, each channel providing galvanic isolation and impedance matching for a variety of input signals.

Each channel shall also provide separate -30 dB pad and -15 dB attenuation switches, and an earth lift function.

Each Multiple DI Module shall meet or exceed the following performance specifications:

Distortion (THD+N) < 0.01% @1kHz, +4dB

Frequency response +0 / -1.0dB (20Hz to 20kHz)

The DI Module shall have ten single audio channels and two dual audio channels. All channels shall have a 1/4” TRS jack input which is capable of accepting balanced or unbalanced inputs. The ten single audio channels shall have a female 3-pin XLR connector in parallel with the jack socket. In use the XLR input shall present a 20k Ω input impedance and the 1/4” jack socket a nominal 1M Ω input impedance.

The ten single channels shall also have an unbalanced link output on a 1/4” TS jack socket.

All outputs shall be transformer isolated and shall use

3-pin male XLR connectors.

The unit shall be capable of operating from a 100 to

240V ±10%, 50 to 60Hz AC power source.The unit should have the option of dual redundant power supplies.

The DI Module shall be the Klark Teknik model

DN1414 and no alternative option is available.

.

Technical Specification

F

Audio Inputs

Type

Impedance

TRS jack input

XLR input

Max level

Two per mono channel

One per stereo channel

Electronically balanced

1MΩ

20kΩ

+ 21dBu with no input attenuation

- 30dB

F

Pad

Audio Outputs

Type

Source impedance

Min Load

Max level

Two per mono channel

One per stereo channel

Transformer isolated

50Ω

600Ω

(-3dB level loss into 200Ω )

> + 21dBu @ 1kHz with load > 1kΩ

Link Output (Channels 1-10)

Source impedance

Min Load

Max level

50Ω

600Ω

(-3dB level loss into 200Ω )

> + 21dBu @ 1kHz with load > 1kΩ

F

Performance

Noise -100dBu between 20Hz and 20kHz unweighted

20Hz to 20kHz +/- 0.5dB

<0.01% @ 1kHz, +4dBu

Frequency response

Distortion (THD+N) output

F

Terminations

Audio Inputs

Audio Outputs

Power

F

Power Requirements

3 pin XLR & 1/4” TRS jacks

3 pin XLR

3 pin IEC

100 to 240V ±10% a.c @

50/60Hz @ < 60 VA

F

Dimensions

Height

Width

Depth

F

Weight

Nett

Shipping

F

Options

*Dual power supply

132 mm (5.2 inches) - (3U)

483 mm (19 inches)

300 mm (12 inches)

8kg

9kg

*All options are non retrofittable and must be specified with order.

Trade Descriptions Act:

Due to the company policy of continuing improvement, we reserve the right to alter these specifications without prior notice. E&OE.

page 31

DN100 -

Active Di

The Klark Teknik DN100 Direct Injection Box is the natural successor to the long-established LBB100.

A ground-up redesign provides an extended dynamic range, lower noise floor and all the worldclass audio performance you’d expect from Klark

Teknik. DN100 is also designed to handle the rigours of life on the road: a thick aluminium shell protects the electronics, and this in turn is protected by a tough silicone rubber casing, which is replaceable and available as a spare part.

We’ve also fitted a Kensington security slot in one of the end panels to allow the unit to be made secure using a Kensington MicroSaver security cable.

Attention to detail – it’s what makes a good unit into a great one.

page 32

Architect’s & Engineer’s Specification

The Direct injection module shall provide the functions of transformer isolation, impedance matching and attenuation into a low impedance active balanced input. The module shall be able to accept a maximum input level of at least 30dBu provide switchable attenuation from 0 to 20dB and output the signal into a balanced 600 Ω load.

Input connectors shall include two quarter inch jack sockets and one 3-pin XLR socket, all linked. Input impedance shall be 1M Ω (jacks sockets), 20K Ω (XLR only).

The output shall be transformer balanced and isolated, with a source impedance of 150 Ωs, capable of driving a 10dBu signal into a 2k_ load. The output connector shall be a 3-pin XLR socket.

An earth lift switch shall be provided to disconnect input and output grounds when required.

The unit shall obtain power from a 48V phantom supply.

The unit shall achieve or exceed the following specifications:

Output noise -100dBu. 20Hz to 20kHz unweighted, with input terminated by 10k Ω resistor.

Distortion (THD+N) < 0.01% @ 1 kHz, +4dBu.

Frequency response +0.5/-1dB 20Hz to 20kHz.

Power consumption <10mA

The Direct Injection Module shall be the Klark Teknik model DN100 and no alternative option is available.

.

Technical Specification

F

Inputs

Type

Impedance

Connectors

Max. Level

Four

active electronic, balanced or unbalanced

1M Ωs nominal, balanced or unbalanced (jack connectors)

20K Ωs (XLR input only)

2 quarter inch jacks and 3pin XLR linked in parallel

30dBu

F

Output

Connector

Max. Level

Min. load

F

Performance

Noise

Frequency response

Distortion (THD+N) output

F

Power Requirement

Current consumption

Weight

F

Dimensions

Length

Width

Height balanced

3 pin XLR

10dBu with load >2k Ωs

600 Ωs

-100dBu, 20Hz to 20kHz unweighted, with input terminated by 10k resistor

+0.5/-1dB 20Hz to 20kHz

<0.01% @ 1kHz, +4dBu

<10mA

<1kg

142mm (5.6 inch)

106mm (4.2 inch)

60mm (2.35 inch)

* The DN100 has been designed to allow use at phantom voltages less than

+48V. The unit will function down to +20V (when used with 6k8 dropping resistors) but with reduced headroom and dynamic range. All the specifications above are quoted using standard +48V Phantom power.

Trade Descriptions Act:

Due to the company policy of continuing improvement, we reserve the right to alter these specifications without prior notice. E&OE.

page 33

ACCESSORIES all the extras

Balancing Transformers: most KT units can be supplied with input and / or output balancing transformers if required.

Dual Power Supplies: the DN1248 Plus active splitter system and the DN1414 multiple DI module can be factory-fitted with dual power supplies if required.

The suffix ‘DP’ is applied when this option is specified.

All-Transformer Balancing: the DN1248 Plus can also be factory-fitted with all outputs transformer balanced if required. The suffix ‘AT’ is applied if this option is specified. This unit can also be fitted with both the Dual PSU option and the All-Transformer option if required, in this case the suffix ‘FM’ is applied.

page 34

Reference

FAQ

The Helix DN9848E displays its filter steepness as “bandwidth” in octaves – what are the corresponding values expressed as “Q”?

What is AES/EBU?

Why do I need to set the destination wordlength for my digital outputs?

How should I set the gain on my Active Splitter system?

What is the sampling rate and wordlength of the DN9848 ?

What is Dynamic Equalisation (T-DEQ)?

What is the difference between the various Q types on the DN9340 Helix Equaliser?

White Papers

Paper 1: The Use Of Look-Ahead Limiters In Loudspeaker Driver Protection

Paper 2: Phase adjustment on the Klark Teknik DN9848 Loudspeaker Processor

Line drawings

page 36 page 36 page 37 page 38 page 39 page 40 page 41 page 42 page 44 page 46 page 35

FAQ

Frequently asked questions

The Helix DN9848E displays its filter steepness as “bandwidth” in octaves – what are the corresponding values expressed as

“Q”?

DN9848E PEQ Bandwidth

0.08 Oct

0.1 Oct

0.2 Oct

0.3 Oct

0.4 Oct

0.5 Oct

0.6 Oct

0.7 Oct

0.8 Oct

0.9 Oct

1.0 Oct

1.2 Oct

1.5 Oct

2.0 Oct

2.5 Oct

3.0 Oct

Equivalent Q setting

18.03

14.42

7.21

4.80

3.60

2.87

2.39

2.04

1.78

1.58

1.41

1.17

0.92

0.67

0.511

0.40

What is AES/EBU?

AES/EBU is the term used for a professional digital audio transmission system, jointly specified by the Audio

Engineering Society (AES) and the European Broadcast

Union (EBU), and published by the former as their AES3 standard (at the time of writing, the current version is

AES-2003). It allows the transmission of two channels down a shielded twisted-pair cable using time division multiplexing (TDM) with one sample from each channel being transmitted within the sample period of the system.

Typically, XLR connections are used for AES interfaces, and because of the TDM format, one XLR cable carrying

AES/EBU data can replace two regular analogue connections. The clock for the data transmission is embedded in the data, using a process known as biphase mark encoding or Manchester encoding. This means that the incoming data can be used a the clock source for the master clock within a unit equipped with an AES/EBU interface, and this is the preferred mode of operation, as it guarantees that the unit is synchronised to the incoming data stream.

For large digital transmission systems using AES/EBU interfaces, such as those encountered in broadcast and studio installations, a distributed clock signal operating at the sampling frequency is distributed to all units, separate to the AES/EBU signals. This is generally known as 'word clock' and allows all connected units to be synchronised on a sample-accurate basis. Word clock is most commonly connected using 75 ohm, BNC connectors. As the DN9340E is primarily designed for live applications, it will always take the clock reference from the incoming data stream when an external clock reference is selected. However, the provision of a word clock input on the AES/EBU interface allows the unit to be used as analogue to digital converter, synchronised to a system word clock if one is available.

FAQ

Frequently asked questions

Why do I need to set the destination wordlength for my digital outputs?

The correct setting of the output wordlength is necessary to avoid distortion caused by truncation of the audio data. If a 24-bit audio signal is transmitted to a 16bit device (such as a DAT recorder), the lower 8 bits will simply be ignored or “truncated”. This results in an error with an amplitude (on average) of half the size of the least significant bit (LSB) of the 16-bit signal. Because the size of the error for each individual sample will depend on the actual data in the input (24-bit) waveform, the error will be related to the input signal, and will therefore appear as harmonic distortion. This distortion, once created, can never be corrected by subsequent processing.

In order to avoid this situation, we need to add a random noise signal with an amplitude of “half an LSB” (called

“dither”) to the 24-bit waveform BEFORE we truncate it to

16 bits. This has the effect of randomising the error so that it no longer relates to the input signal (although the error still has the same total energy). Our 16-bit signal now has random noise at the _ LSB level, instead of harmonic distortion at the _ LSB level - which is very much better to listen to…

For the mathematically inclined, this is rather like rounding numbers. As an example, 7.9 and 7.1 will both truncate to 7 exactly, but we know that this is not the

“minimum error” answer. If, however, we add 0.5

(equivalent to _ LSB) before we truncate, we get

7.9+0.5=8.4 ~ 8 and 7.1+0.5=7.6 ~ 7 which is the answer we expect. Note that if you do this “wrong” at the start, and get 7 in both cases, it doesn't help to add the 0.5

afterwards! This is also true for the audio - once you have caused distortion by truncating, you cannot remove it by adding noise.

So, in practice, it is always safest to set the wordlength to

16-bit. This will ensure that any 16-bit (or better) device will connect up OK and will receive a correctly-dithered, low distortion signal. Only if you are absolutely sure that the destination device actually makes use of the additional bits should you select 20-bit or 24-bit operation to achieve the maximum dynamic range available from the unit.

page 36 page 37

FAQ

Frequently asked questions

How should I set the gain on my Active Splitter system?

The use of an active microphone splitter system in place of the traditional passive transformer-based splitter provides a number of clear advantages. These include easier control over microphone powering, headphone monitoring facilities, and metering, in addition to the fundamental advantage of improved line drive capability.

The combination of low output impedance and higher signal level mean that an active splitter is potentially capable of quieter performance and better noise immunity than a passive one, as well as minimising highfrequency losses due to cable capacitance. However, if these benefits are to be realised in practice, it is necessary to set up the complete system (including both the splitter and the console) with the correct gain structure. Failure to do this may result in the system actually performing worse when compared with a simple passive splitter, so it is well worth spending a few minutes to get familiar with the concepts involved. The reason that it matters at all is that amplifiers are not perfect. All active electronics add a small amount of noise to the signal - for example a typical well-designed amplifier will have residual noise at around -100dBu on its output, irrespective of any input signal.

Figure 1

Figure 1 shows a microphone connected directly to a console. In this simple case we bring the microphone signal into the console, and immediately amplify it in the first active stage - the microphone amplifier. To take a practical example, a common dynamic vocal microphone subjected to an SPL of 110dB will produce an output of approximately -33dBu. In order to bring this up to a usable level in the console, we will set the microphone amplifier to +33 dB of gain, resulting in a 0dBu signal leaving the amplifier. To this will be added the noise of the amplifier, but since this is at around -100dBu on the amplifier output, we still have a signal-to-noise ratio of around 100dB.

Figure 2 matter is how best to set the gain of the two microphone amplifiers. It is tempting to simply set the splitter to unity gain, and insert it in the signal path expecting nothing to change - after all, this is what we would do with a passive splitter. However, we can immediately see a problem with this approach. We bring our microphone signal at the same level of -33dBu into the splitter, but now instead of it immediately hitting an amplifier with gain, it is simply passed at the same level through the splitter.

The splitter's microphone amplifier and the line driver will each add noise at about -100dBu to this signal, just as the console's microphone amplifier did. Note that because the signal is still at -33dBu, the signal-to-noise ratio at point A is now only 67dB. This signal arrives at the microphone amplifier in the console, and we boost the whole thing by +33dB. This restores the signal to

0dBu as desired, but also brings up the splitter's output noise by 33dB - so we still have a signal-to-noise of only

67dB. The additional noise at -100 from the console's microphone amplifier is of no real consequence in this case.

In order to restore the performance of our system and to actually benefit from the improved line driving ability of the splitter, what we should have done is to use the microphone amplifier on the splitter. If we set the splitter's microphone amplifier to +33dB of gain, then the noise contribution of that amplifier (at -100dBu) will now be added to a signal with a level of 0dBu, instead of

-33dBu. This will preserve our 100dB signal-to-noise ratio in the splitter, instead of reducing it to 67dB. The console input section is now set to 0dB of gain, so there is no increase in the splitter's noise contribution as a result, and we merely add the console noise at -100dBu to our signal.

So, the conclusion that we reach is:

When using any active splitter system, as much gain as possible should be added using the splitter's microphone amplifier, and as little as possible using the console.

Obviously the limit of this approach will be the point at which the splitter's output will clip on loud sounds. It is worth noting, however, that with the popular dynamic vocal microphone used for this example, and +30dB of gain on the splitter's microphone amplifier, that it would require an SPL of 133.3dB to produce an output of

+20dBu from the splitter - still within the output capability of most professional equipment.

FAQ

Frequently asked questions

What is the sampling rate and wordlength of the DN9848 ?

We are often asked questions such as “why don’t you quote the number of bits for your analogue-to-digital converters (ADCs)?” by people wishing to compare our equipment with products from other manufacturers. This has been a deliberate policy, because of the danger of making "over simple" comparisons between competing units based on numbers of bits or sample rates. In many cases the actual performance may differ substantially from the "apparent quality" based on the numbers in the specification. So, in response to these questions, here is a summary of the DN9848 architecture, with some background on how this can be sensibly compared with competitor products.

DSP sample rate is 48 kHz. This allows us a theoretical

24kHz audio bandwidth, although we only specify 20 Hz to 20 kHz, and we deliberately roll off above 20kHz. In our opinion, bandwidths wider than this are in general undesirable for live sound, as they merely increase the likelihood of HF driver failure without any sonic advantage. Many people over the years have conducted subjective listening tests comparing 96kHz sampled systems to 48kHz systems and found that they sound different. However, this usually involves different analogue stages, different ADCs and DACs, different phase responses and so on, so it is no surprise that they sound different. On the other hand, if a 96 kHz sampled system is built, and then a 20 kHz digital filter is introduced inside the system, we remain convinced that the result is inaudible. This assumes, of course, that the filter is linear phase and has low ripple in the passband

(not always the case !). 96kHz sampling also causes problems with the noise performance of low frequency

EQ stages (because the differences between adjacent samples are smaller), so a 96 kHz system typically requires a longer wordlength to achieve the same noise performance as a 48 kHz one. The one advantage of a

96kHz system in live sound is that it is possible to reduce the latency (delay) through the system a little. Note also when comparing 96kHz and 48kHz systems that many

96kHz systems specify audio bandwidths of 30kHz or even 40kHz, and then only specify the noise performance up to 20kHz. Clearly if the system is flat to

30kHz, then all the noise up to 30kHz will be arriving at the power amplifiers and should be included in the noise measurement. This is particularly true when oversampling ADCs are used, which have a noise profile that typically rises with frequency.

DSP wordlength is 24-bit, fixed-point (optionally 48-bit fixed-point where necessary for the algorithms). This gives us a theoretical internal dynamic range of 144 dB, so this is comfortably better than the converters that are currently available. Fixed-point versus floating-point is a big discussion, but in general a 24-bit fixed-point system is harder to design than a 24-bit floating-point system but sounds better. This is because when there is a typical loud-ish signal level passing through the unit, the "step size" available between samples is smaller on the fixedpoint system. In addition, the step size is fixed, whereas a floating-point system has a variable step size depending on the instantaneous signal level. In other words in a floating-point system the quality of the quiet hi-hat cymbal will be modulated by the signal level of the bass guitar - not generally a good thing... Obviously the floating-point system has a theoretical noise advantage at very low signal levels, but by the time the level is low enough for this to be significant, the ADC and DAC noise will be dominating, not the DSP noise.

The ADC and DAC parts that we use are both "nominal

24-bit" items, but this is essentially meaningless. If a manufacturer claims that they have a "24-bit converter" in their product, then the next question to ask is how you should measure the unit to confirm the 144 dB dynamic range that this implies. In practice no-one is achieving even 20-bit noise performance (=120 dB dynamic range) from a digital system of this kind at the present time. The DN9848 achieves >114 dB dynamic range or "19 bits" overall from input to output. Note that this is an unweighted figure (i.e. flat frequency response).

Some manufacturers quote "A-weighted" figures which flatter the unit's performance significantly by applying a psycho-acoustic curve to the measurement.

Measurements which specify the dynamic range of the

ADC or DAC in isolation should also be treated with caution, since these are often “data sheet” numbers supplied by the IC manufacturer which are rarely if ever achieved in practice. The ultimate safety net is to say

“could I verify this measurement myself with an example of the unit and a test set ?” – if you can, then the manufacturer is unlikely to be exaggerating – the potential for embarrassment is too great ! If the figures can only be verified by calculation or internal connections to the circuitry, then the figures may be less useful…

The other key performance issue even for digital products is the analogue audio stages - in particular the difference between bench measurements and real-world performance. KT units are designed to perform not only when connected to test equipment on a bench, but also when driving long cables, unbalanced loads, and in the presence of external electrical and magnetic fields. Issues such as common-mode rejection (especially at high frequencies) and impedance balancing of outputs can have a dramatic effect on the actual performance obtained, as opposed to the "brochure specification".

In the end, the one-sentence summary is "don't worry too much about the bits and sample rates - trust the same real-world performance measurements of noise and distortion that you would apply to analogue".

And after that, there are always your ears… page 39 page 38

Figure 2 shows the same signal connected using an active splitter system. The splitter contains a variablegain microphone amplifier, which then feeds a number of independent output amplifiers. One of these is then connected to the console input, which itself has a variable-gain microphone amplifier. The crux of the

FAQ

Frequently asked questions

What is Dynamic Equalisation (T-DEQ)?

Over the years a number of professional audio products have provided dynamic equalisation functions of various types. What all these systems have in common is that the frequency response of the device varies depending on the signal level. Many units are based on compressor

/ expander technology with frequency selection, and the controls often resemble those of a dynamics processor.

The system developed by the Klark Teknik research and development team for the Helix series is rather different.

It draws on KT's unrivalled experience in equalisation, and uses the signal level to directly control parametric equalisers. This purely EQ-based solution allows simple controls that directly relate to the signal levels. As a result, it is very easy to set the point at which the dynamic EQ starts to operate, and also to set precisely its maximum effect. We refer to this technique as

"Threshold Dependent Equalisation".

In order to understand the operation, let us first consider a conventional parametric EQ section (Figure 1). The three controls available to us are frequency, Q (or bandwidth), and the amount of cut or boost.

In this example, [low threshold] is -20dBu, [low level] is

+12dB, [high threshold] is set to -5dBu, and [high level] is

0dB. Thus the lowest trace shows an input at -25dBu with a standard parametric boost of +12dB at 1kHz. The

-20dBu trace shows an identical response, as expected.

However, once above this level, the filter gradually fades out with increasing signal, until at all levels above 0dBu, the response is flat.

The shape of the curves for -5dBu and -10dBu require some explanation. These appear as they do because of the nature of the frequency sweep measurement. The

Helix equaliser uses a copy of the actual filter in use for its level calculation, so that depending on the Q of the filter, our input signals are 'ignored' as we move away from the centre frequency by the correct amount. Thus as the sweep measurement moves across the centre frequency (1kHz in this case), the dynamic EQ is ramping smoothly in and out again, leading to the curves in

Figure 2. Note that if the level is outside the range specified by the two thresholds, the unit behaves like a fixed parametric EQ. This means that we do not have to guess how much EQ will eventually be applied - it is explicitly set in advance.

Without changing modes or making any other selections, we can make the unit operate 'the other way up' just by selecting suitable values for the two thresholds and levels see Figure 3.

This shows a series of responses for the parametric EQ with different input levels. As expected, there is no change in the shape of the curve with different input levels. If the input is 10dB louder, the output is 10dB louder at every frequency.

If we now replace the parametric with a Helix equaliser and select the dynamic EQ, we have some additional controls. Frequency and Q controls are as before, but now we have two pairs of controls replacing the single cut and boost control; these are [low threshold] / [low level], and [high threshold] / [high level]. If we set the frequency and Q controls to the area that we wish to control, then the processor will monitor the signal level in that frequency range. If the signal level in this part of the spectrum is below the [low threshold] setting, then the unit considers this a 'quiet' signal. The EQ applied to the signal will be controlled by the [low level] control. If the signal level is above the [high threshold] level, then the unit considers this a 'loud' signal, and will apply the amount of EQ set by the [high level] control. If the signal level is between the two thresholds, then the equaliser will seamlessly morph between the two equaliser settings in real time. Manual control over attack and release times is available to set the speed of response to suit the application.

As an example, consider Figure 2, which shows the Helix applying a boost at low signal levels which is automatically 'wound out' at high level.

In this case, [low threshold] is -20dBu, [low level] is 0dB,

[high threshold] is -5dBu, and [high level] is +12dB, so that instead of cutting this frequency range as the level increases, we are now boosting it. Again, we have precise control over the maximum amount of boost that will be applied, and the level at which this will occur.

Note the shape of the curve for -5dBu, which has

'expected values' outside the filter range and at the centre frequency, but intermediate values that show the

EQ ramping in and out either side of the centre frequency.

Needless to say, there is no requirement for one of the levels to be 0dB. Figure 4 shows the transition from a

+12dB boost at low level to a -12dB cut at high levels.

Again, the intermediate curves show the effect of the sweep signal moving in and out of the 'area of interest' of the level detector as the curve is formed.

FAQ

Frequently asked questions

What is the difference between the various Q types on the Helix DN9340E Equaliser?

The “Q” of an audio equaliser describes the steepness of the filter - the degree to which it will affect signals either side of its nominal or “centre” frequency. In general, the Q of a peaking filter is defined mathematically as , centre frequency / bandwidth where the bandwidth (in Hz) is the range of frequencies affected by the filter. Because the frequency response of such a filter is a smooth curve (not a sharp “brick wall” filter like the ones in an analogue-todigital converter) we have to decide how we choose to define the bandwidth, and the established convention is that we use the bandwidth to the “-3dB” points on either side of the centre frequency, where the gain is 3dB less than the maximum gain.

Constant Q

In the example above, the filter is centred on 1 kHz, the lower 3dB point is at approximately 800 Hz, and the upper one is at approximately 1.25 kHz. This filter therefore has a

Q of 1000 / (1250-800)=2.2 In a typical parametric equaliser (and in the case of the Helix system the graphic and dynamic sections too) we have a manual control for the Q of the filter, and this allows us to set any Q that we require. In general high-Q, narrow filters are used for notching out problem frequencies without affecting the programme material too much, while gentler low-Q filters are useful for adjusting the tonal balance. In the case of graphic equalisers there is another issue - that of interaction between adjacent bands. In general, lower-Q filters will blend together more smoothly, but higher-Q filters provide more selective control of problems - at the expense of more frequency response ripple.

So far so simple - but why the different types? This is due to the way in which the Q of the filter varies (or not) when the gain control is adjusted. There are three modes available in the Helix system, which we term Proportional,

Constant, and Symmetrical Q.

Proportional Q

A constant Q equaliser has the same Q at all cut and boost settings. In other words, the bandwidth between the 3dB points does not change at all as the gain is adjusted. The really important thing to notice about this is that the resulting frequency response is NOT symmetrical in cut and boost. This is because of the definition of Q which is based on the 3dB points relative to maximum gain. The maximum gain of the filter when in cut is, of course, 0dB, and the bandwidth is determined by the -3dB points relative to 0dB and NOT relative to the minimum gain (at the centre frequency). This makes a lot of sense musically too - if you listen to a music signal and apply a notch filter, and then change the shape of the curve around the minimum gain (centre) point, it will make little difference to the sound (since that area is already attenuated a lot).

However, if you change the curve around the 3dB points, this will affect the sound much more, as more or less of the signal “falls into” the notch. It is this bandwidth that the constant-Q filter is keeping constant. Note that many equalisers that are described as “Constant Q” by their manufacturers do NOT fall into this category, and are what we would term symmetrical-Q designs.

Symmetrical Q

This class of equaliser has the same curves in boost as the constant-Q type, but then has cut responses that are symmetrical with the boost ones. In other words, the bandwidth in cut is defined not according to our usual definition of Q (see constant-Q above) but as “the point were the signal is cut by 3dB less than the maximum cut”.

Most equalisers described by their manufacturers as

“Constant Q” in fact produce symmetrical responses.

Proportional Q is the mode of operation familiar to users of the Klark Teknik analogue graphic equalisers such as the DN360. As the amount of cut or boost is increased, the

Q also increases. This has the effect of making the equaliser “focus” more tightly as the amount of EQ is increased. This allows a fairly low-Q filter at small cut and boost settings, providing gentle control of tonal balance and low ripple. At high gain settings, a proportional-Q equaliser “automatically” increases Q for more dramatic problem solving such as suppression of feedback or unwanted resonances. In the interests of clarity, the Q setting shown on the display is the Q at full cut or boost the Q at lower gain settings will be lower than that shown on the panel.

page 41 page 40

White Paper

Paper 1: The Use Of Look-Ahead Limiters In

Loudspeaker Driver Protection

The limiter in a loudspeaker processor is the last line of defence in protecting the speaker drivers from damage, and as such it has a very specific and critical job to do.

One of the chief modes of loudspeaker failure is driver over-excursion, and unless the limiter is designed to act instantly in response to sudden increases in level, it will allow through brief transients that can cause damage through over-excursion. All dynamics processors take a finite amount of time to respond to a change in input level, and unless additional steps are taken the result is that the input signal is initially let through at anything up to its full level, until the gain element in the limiter can act in response to the increase in signal level.

The DN9848 exploits the fact that digital signal processing works on a sample-by-sample basis (the signal data samples are clocked through the unit at the sample rate of 48 kHz) and that there is a small delay through each processing block, and literally ‘looks-ahead’ further back in the signal chain to sample the data for the limiter side chain, so that the limiter can apply the required gain reduction on an instantaneous sample-bysample basis, so that the limiter never lets through any dangerous transients.

In the example below a 10 kHz tone burst of 10 ms duration has been used as the input signal and the output of both a DN9848 and a leading competitor are shown. Note the very large transient of the competitor unit which does not have a look-ahead limiter.

Input Signal

DN9848

Competitor

Signal source: Audio Precision System One

Settings: Waveform: Burst – Normal. Frequency: 10.0

kHz. Burst: 10 ms. Interval: 100 ms. High Level: +10.0

dBu Low level: -40.0 dBu

DN9848 settings: HPF: 1.25kHz Lnk-Ril 24dB/Oct. LPF:

20kHz Lnk-Ril 24dB/Oct. Limiter Threshold: 0.0dBu

Release: 50ms Response: Hard Knee

Competitor settings: HPF: 1.26kHz Lnk-Ril 24dB/Oct.

LPF: 22kHz Lnk-Ril 24dB/Oct. Limiter Threshold: 0.0dBu

Attack & Release: Automatic

All other settings are default on both units.

page 42

White Paper

As with all units that use sigma-delta ADC and DAC converters, there is a propagation delay from input to output, 3.2 ms for the DN9848 and 2.1 ms for the competitor unit, the additional delay in DN9848 is caused by the use of sigma-delta converters for both analogue-to-digital and digital-to analogue conversion

(the competitor unit uses a different method of digitalto-analogue conversion), which allows the DN9848 to achieve its superior dynamic range.

In order to prevent driver failure, the competitor product’s limiter threshold needs to be reduced such that the peak of the transient is at the same level as the threshold of the DN9848’s look-ahead limiter, with a major effect on efficiency of speaker systems, as the effect of reducing the limiter threshold is to limit the amount of continuous output power available, which means more amplifiers and more speaker cabinets to achieve the same SPL. In the example below the competing unit’s limiter threshold has been reduced so that level of the transient peak matches the threshold of the DN9848’s limiter:-

Input Signal

DN9848

Competitor

The limiter threshold of the competitor’s unit has been lowered to -10.0 dBu to avoid the risk of driver damage from the initial transient, at the cost of greatly reducing the efficiency of the PA system. The look-ahead capability of the DN9848’s limiters allows the thresholds to be set at the levels required to protect the loudspeaker drivers, without the need to be concerned about transients being passed by the limiters. This allows the PA system performance to be maximised by safely exploiting the full operational range of the loudspeaker drivers. page 43

White Paper

Paper 2: Phase adjustment on the Klark Teknik

DN9848 Loudspeaker Processor

To meet the demands of a wide range of situations, the

Klark Teknik DN9848 provides two all-pass filters with complementary control parameters for fine-tuning the phase response on each output. Although some crossover filter designs, e.g. Linkwitz-Riley types, are inherently phase-aligned at crossover, others such as

Butterworth or Bessel responses may require manual phase alignment. Even Linkwitz-Riley filters may not produce accurate phase coherence when HPF and LPF are combined to produce a band-pass output. In addition, the phase response of the drive units and cabinets (especially horn-loaded types) may require compensation to achieve correct acoustic phase, even if the electrical phase is correct. The DN9848 filters provide straightforward tuning control in all cases.

The first filter of the DN9848 is presented as a “phase shifter” for which you can specify a particular phase shift at a reference frequency, namely a HPF or LPF (typically the cross-over point) or one of the 6 PEQs. The plots in

Fig. 1 show the effect of these controls on the filter response when set to a 90° phase shift at references points equivalent to 20 Hz, 300 Hz, 1 kHz and 20 kHz.

Referring to the figure, the overall response always remains the same shape i.e. tending from +180 at low frequencies to 0° at high frequencies, but is shifted along the frequency axis to achieve the required phase shift at the specified reference point.

Figure 1.

Response of the Phase Shifter filter for a phase shift of

90° at reference points equivalent to 20 Hz, 300 Hz, 1 kHz and 20 kHz

The second filter, presented to the user as an “all-pass filter”, enables the user to set the Order and Q of the phase shift, at a particular Frequency. The Order can be switched to Off (no filter), 1st order (90° shift) or 2nd

Order (180 ° shift). page 44

White Paper

Fig. 2 shows the response of the filter for a 1st order shift.

In this mode, the Q control is disabled. As can be seen, the filter behaves in an identical manner to the phase shifter i.e. the response tends from +180 at low frequencies to 0° at high frequencies, shifted along the frequency axis according to the chosen frequency. In effect, this is a phase shifter for which the frequency is entered directly, rather than being referred to a HPF/LPF etc.

Figure 2:

Response of the All Pass Filter for 1st Order phase shift at frequencies of 300Hz, 1kHz and 10kHz

Fig. 3 shows the response of the filter for a 2nd order shift, with the Q control set to 1, at frequencies of 300Hz,

1kHz, and 10kHz, and also Q set to 6 (max) and 0.4 (min) at 1kHz. As can be seen, the filter response now tends from 360° at low frequencies to 0° at high frequencies, and Q controls the rate at which the phase changes (i.e.

the slope) around the transition point. With low Q, the phase changes gradually across the whole frequency range. With high Q, the phase changes rapidly in the transition area, and is unchanging at 360°/0° over the remainder of the frequency spectrum. . Hence, the 2nd order all-pass provides the user the additional control of shaping the phase shift ‘window’.

Figure 3:

Response of the All Pass Filter for 2nd Order phase shift with Q=1 at frequencies of 300Hz, 1kHz and 10kHz and also with Q=6 at (max) and Q=0.4 (min) at 1kHz

Note: Both filters are all-pass with a flat amplitude response between 20Hz and 20kHz; only the phase response changes with frequency.

page 45

LINE DRAWINGS

These diagrams are for pictorial reference only

HELIX DN9340E Dual EQ

Helix DN9344E Quad EQ

Helix DN9848E System Controller

page 46

LINE DRAWINGS

These diagrams are for pictorial reference only

DN9331 RAPIDE Graphic Controller

page 47

LINE DRAWINGS

These diagrams are for pictorial reference only

DN1248 Plus Mic Splitter

LINE DRAWINGS

These diagrams are for pictorial reference only

DN370 Dual Channel 30 Band 1/3 Octave Graphic Equaliser

DN1248

PUSH

IN

SOLO

OUT

PSU 1

PSU 2

4

OUTPUT 4

3 2 1

8

7

6 5

12 11 10 9

C US

SUPPLY VOLTAGE 100-240V AC~50-60Hz 60W FUSE T 0.5L250V

DN360 dual channel 30 band 1/3 octave graphic equaliser

4

OUTPUT 1

3 2 1

8 7 6 5

12 11 10 9

PUSH

4

INPUT

PUSH

3

PUSH

2

PUSH

1

PUSH

8

PUSH

7

PUSH

6

PUSH

5

PUSH

12

PUSH

11

PUSH

10

PUSH

9

DN410 Dual Channel 5 Band Parametric Equaliser

page 48 page 49

LINE DRAWINGS

These diagrams are for pictorial reference only

DN500 Plus Dual Compressor/Limiter Expander

DN504 Plus Quad Compressor Limiter

DN514 Plus Quad Auto Gate

page 50

LINE DRAWINGS

These diagrams are for pictorial reference only

DN1414 Di Module

DN100 Active Di

page 51

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
