240V Battery Chargers (P.4 - P.10)
Page 4 - 240VAC to 12VDC 10 Amp Battery Charger
Page 5 - 4 Stage Dual Chemistry 12VDC 30Amp Battery Charger
Page 6 - 4 Stage Dual Chemistry 24VDC 18Amp Battery Charger
Page 7 - 240VAC To 48VDC at 10A Battery Charger
Page 8 - 240VAC To 12/24 VDC at 20/10A Battery Charger Auto Select
Page 9 - 240VAC To 12V at 5A / 15A / 30A Lead Acid Battery Charger
Page 10 - 240VAC To 12V 30A Lead Acid Battery Charger for Fixed Connections
24V-12V Battery Chargers (P.11 - P.12)
Page 11 - 24V To 12VDC at 40A / 60A Switchmode Battery Charger
Page 12 - 24V To 12VDC at 10A / 20A / 30A Switchmode Battery Chargers
12V-24V Battery Chargers (P.13)
Page 13 - 12V To 24VDC Switchmode Battery Charger
12V-12V Booster Chargers (P.14)
Page 14 - 12V Multi Chemistry Booster Charger
High Voltage Reducer/Charger (P.15)
Page 15 - 22V-80V to 12/24V Reducer/Charger
Solar Regulators (P.16 - P.23)
Page 16 - 200W Solar Battery Chargers Maximum Power Point Trackers
Page 17 - 1800W Solar Battery Chargers Maximum Power Point Trackers
Page 18 - 3600W Solar Battery Chargers Maximum Power Point Trackers
Page 19 - High Voltage MPPT Series 400W & 1800W
Page 20 - Booster MPPT Series 80W, 150W, 350W, 800W and 1500W
Page 21 - High Voltage Disconnect for use with HVMPPT series
Page 22 - HIgh Voltage Luminare/LED Driver with MPPT Solar Battery Charger
Page 23 - MCM Monitoring and Control Module for MPPT Series
Voltage Doublers (P.24)
Page 24 - 12V To 24VDC Single/Multi-Circuit Voltage Doublers
Linear Voltage Reducer (P.25 - P.27)
Page 25 - 12V To 24VDC Multi-Circuit Voltage Reducers
Page 26 - 24V To 12VDC Multi-Circuit Lighting Reducers 4 Circuits
Page 27 - 24V To 12VDC Single Circuit Linear Voltage Reducers “Keylink Series”
Switchmode Voltage Reducer (P.28 - P.30)
Page 28 - Compact 7A 24V To 12VDC Switchmode Voltage Reducers
Page 29 - 24V To 12VDC Single Circuit Switchmode Voltage Reducers
Page 30 - 24V To 12VDC 40A / 60A Switchmode Voltage Reducers
Battery Equalizers (P.31)
Page 31 - 24V To 12VDC 40A / 60A Switchmode Battery Equalizer
Product Listing
Pure/Modified Sinewave Inverters (P.32 - P.34)
Page 32 - DC To AC - HFS Sinewave Power Inverters
Page 33 - DC To AC - Modified Sinewave Power Inverters
Page 34 - DC To AC - Pure Sinewave Power Inverters
Fluorescent Lighting Products (P.35 - P.37)
Page 35 - Fluorescent Lamp Low Voltage Inverters For T8 Tubes
Page 36 - Fluorescent Lamp Low Voltage Inverters For T5 Tubes
Page 37 - Low Voltage Fluorescent Interior Light “ FLC Series” For T5 Tubes
Brake Controllers & Reversing Buzzers (P.38 - P.41)
Page 38 - 12 Volt Trailer Electric Brake Control
Page 39 - Advanced Micro-Controlled Electronic Brake Controller
Page 40 - Remote Head 12V & 24V Electronic Brake Controller
Page 41 - 12/24 VDC Dual Voltage Reverse Buzzer
Timed Flashing Modules (P.42)
Page 42 - WIG - WAG Flashing Modules / Timed Flasher Modules
Day Time Running Lights and Hand Brake Alarms (P.43)
Page 43 - Lights On Keys On and Hand Brake Alarm
Battery Master Switch (P.44)
Page 44 - Battery Master Switch 12V and 24V
Electronic Battery Isolator (P.45)
Page 45 - Electronic 100/150 Amp Battery Isolator
Low Battery Monitors/Disconnects (P.46 - P.47)
Page 46 - Micro-Controlled 12V / 24V 50 and 20 Amps Low Voltage Disconnects
Page 47 - Low Battery Monitors and Disconnects
Battery Isolators (P.48 - P.49)
Page 48 - Micro-Controlled Solenoid Battery Isolator
Page 49 - Battery Isolator Installation Kit
Uninterruptible Power Supply (P.50)
Page 50 - 12 Volt Uninterruptable Power Supply “Powermaster Series”
Regulated Power Supply (P.51)
Page 51 - 240VAC to 12VDC Linear Regulated Power Supply | 240VAC to 12VDC Fully Regulated Power Supply
Water Level Indicator (P.52 - P.53)
Page 52 - 12VDC and 24VDC Water Level Indicators
Page 53 - Water Level Indicators Installation Kits
ABS Plastic / Alloy Housings (P.54)
Page 54- ABS Plastic / Alloy Housings c/w Mounting Lugs
240VAC to 12VDC @ 10 Amps
BATTERY CHARGERS
Features:
• Automatic 2 stage charger
BC240-1210
• Designed to charge 12V lead acid batteries
• High reliability switchmode technology giving
long life operation
• Compact and rugged aluminium heat sink construction
• Unit cooling via load activated fan
• LED light indicators display charging mode
Approvals:
Safety Standard No. N17018
C Tick No. N1408 (EMI/RFI)
AS/ANZ 60950 : 2000
AS/ANZ 2064 Group 1, Class A
Designed In Australia By
GSL Electronics
4
www.gsl.com.au
High Performance
Award Winning 4 Stage Dual Chemistry
240VAC to 12VDC @ 30AMP
BATTERY CHARGER
Features:
• Innovative 4 stage fully automatic charger for
optimal fast charging and extended battery life
• Award winning microprocessor design insures
accurate voltage and current charging parameters
• Low ripple charge and completely operational
from 180VAC to 250VAC
• Compact heavy duty aluminium construction
• Fully protected against overload, over temperature
and battery reversal
• No sparks connection
• Innovative voltage free leads with no power
dissipation when disconnected
• Dual battery chemistry, selectable
lead acid or calcium batteries
• High output 30 amps
• Custom charge voltages between
10V and 16V available upon request*
BC240-1230
* Conditions Apply, call main office for more information.
Designed and Made In Australia By
GSL Electronics
www.gsl.com.au
5
High Performance
Award Winning 4 Stage Dual Chemistry
240VAC to 24VDC @ 18AMP
BATTERY CHARGER
Features:
• Innovative 4 stage fully automatic charger for
optimal fast charging and extended battery life
• Award winning microprocessor design insures
accurate voltage and current charging parameters
• Low ripple charge and fully operational
from 180VAC To 250VAC
• Compact heavy duty aluminium construction
• Fully protected against overload, over
temperature and battery reversal
• No sparks connection
• Innovative voltage free leads with no power
dissipation when disconnected
• Dual battery chemistry, selectable
lead acid or calcium batteries
• Custom charge voltages between
18V and 30V available upon request*
BC240-2418
* Conditions Apply, call main office for more information.
Designed and Made In Australia By
GSL Electronics
6
www.gsl.com.au
High Performance
Award Winning 4 Stage Dual Chemistry
240VAC to 48VDC @ 10AMP
BATTERY CHARGER
Features:
• Innovative 4 stage fully automatic charger for
optimal fast charging and extended battery life
• Award winning microprocessor design insures
accurate voltage and current charging parameters
• Low ripple charge and fully operational
from 180VAC To 250VAC
• Compact heavy duty aluminium construction
• Fully protected against overload,
over temperature and battery reversal
• No spark connection
• Innovative voltage free leads with no power
dissipation when disconnected
• Dual battery chemistry, selectable lead acid or
calcium batteries
Custom
charge voltages between
•
32V and 62V available upon request*
BC240-4810
* Conditions Apply, call main office for more information.
Designed and Made In Australia By
GSL Electronics
www.gsl.com.au
7
High Performance
Award Winning Design
240VAC to 12/24VDC @ 20/10AMP
BATTERY CHARGER AUTO SELECT
Features:
• Innovative 4 stage fully automatic charger for
optimal fast charging and extended battery life
• Award winning microprocessor design insures
accurate voltage and current charging parameters
• Low ripple charge and fully operational
from 180VAC To 250VAC
• Compact heavy duty aluminium construction
• Fully protected against overload,
over temperature and battery reversal
• No spark connection
• Innovative voltage free leads with no power
dissipation when disconnected
• Automatically selects and charges
12V or 24V batteries
• Compact and lightweight design
BC240-12202410
Designed and Made In Australia By
GSL Electronics
8
www.gsl.com.au
High Performance
Award Winning Design
240VAC To 12V @ 5A / 15A / 30A
LEAD ACID BATTERY CHARGER
Features:
• Innovative 4 stage fully automatic charger for
optimal fast charging and extended battery life
• Award winning microprocessor design insures
accurate charging parameters with unique
zero power consumption when not connected
to the battery
• Low ripple charge and fully operational from
180VAC To 250VAC
• Compact heavy duty aluminium construction
• Fully protected against overload, over
temperature and battery connection reversal
• No sparks connection
• Innovative voltage free leads with no power
dissipation when disconnected
• Selectable output current between 5 Amp,
15 Amp and 30 Amp
• Available in custom charge rates,
Conditions Apply.
BC240-1230-S
Designed and Made In Australia By
GSL Electronics
www.gsl.com.au
9
High Performance
Award Winning Design
240VAC To 12V @ 30A
Lead Acid Battery Charger for Fixed Connections
Features:
• Suitable for use on RV’s and fixed
connection vehicle applications
• No drain on battery when disconnected
from AC power supply
BCAC240-1230RV
• Innovative 4 stage fully automatic charger for
optimal fast charging and extended battery life
• Award winning microprocessor design insures
accurate voltage and current charging parameters
• Low ripple charge and completely operational
from 180VAC to 250VAC
• Compact heavy duty aluminium construction
• Fully protected against overload,
and over temperature
• No sparks connection
• Innovative voltage free leads with no power
dissipation when disconnected
• Dual battery chemistry, selectable
lead acid or calcium batteries
• High output 30 amps
Designed and Made In Australia By
GSL Electronics
10
www.gsl.com.au
High Performance
24V To 12VDC
Available in 40A and 60A
SWITCHMODE BATTERY CHARGER
Features:
• Microprocessor based, 3 stage fast charge
• High efficiency switchmode technology
• High reliability and longer battery life
• Control wire with delayed reaction to
REC - 1260C
avoid cold cranking problems
• Battery detection avoids connection
reversal and sparking problems
• Time out on bulk charge to avoid
battery over charging
• Current limiting under overload and
short circuit conditions
• Compact and light weight aluminium
heatsink construction
Designed and Made In Australia By
GSL Electronics
www.gsl.com.au
11
24V TO 12VDC Switchmode
BATTERY CHARGER
Features:
• High efficiency switchmode technology
• Control wire via ignition
BC2412-30
• Automatic 2 stage charge
• Current and Voltage limiting protection
• Compact and lightweight aluminium
heatsink construction
• Output over voltage protection
• Applicable where there are high current drain
loads e.g. winches, rear lift platforms
Designed In Australia By
GSL Electronics
12
www.gsl.com.au
12V TO 24VDC Switchmode
BATTERY CHARGER
MCB-2440
• High efficiency switchmode technology
• Control wire via ignition
• Immediate charging at switch on
• Automatic 2 stage charge
• Current limiting protection
• Diode protection to guard against
incorrect wiring of input to output leads
• Short circuit protection via fuse
• Compact and lightweight aluminium
heatsink construction
BC1224-280:
• High efficiency switchmode technology
• Control wire via ignition
• Immediate charging at switch on
• Automatic 2 stage charge
• Current limiting protection
• Diode protection to guard against
incorrect wiring of input to output leads
• Short circuit protection via fuse
• Compact and lightweight aluminium
heatsink construction
MCB-2420
BC1224-280
BC1224-280
Input Voltage
11V to 15VDC
Output Voltage
Load Regulation
Output Power
Stand By Current (Approx)
28VDC
5%
280W
140mA
Switching Frequency
Input Protection Via Fuse
25KHz
Output Short Circuit Protection
Input To Output Protection
No
Yes
Output Connections - 4 Fly Leads
Yes
Dimensions mm (L x W x H)
Weight
220 x 135 x 60
30A
1.76Kg
Designed and Made In Australia By
GSL Electronics
www.gsl.com.au
13
High Performance
12V Multi Chemistry
BOOSTER CHARGER
Features:
• Australian award winning microprocessor design
ensures accurate voltage and current charging
parameters from as low as 9.2V input
• Automatic 3 stage charging ensures optimal fast
charge and extended battery life
• Low minimum input voltage compensates for
voltage drop in long cable lengths between main
and auxiliary battery
• Selectable chemistry switch enables accurate
charge voltage for AGM/GEL/FLOODED batteries
• Fan cooled lightweight aluminium heat sink
construction
• Short circuit protection
• Over temperature protection
• Over current protected
• Reverse polarity protected
• No spark connection to auxiliary battery
MCB-1225
“Best dual/auxiliary battery charging system on the market...”
MCB-1225L
Lowest Operating Voltage
Maximum Operating Voltage
Maximum Current at Bulk Charge
Charge Voltage for Lithium
Charge Voltage for Lead Acid
10.5V
15V
Charge Voltage for Fixed Output
Float Voltage
25A
14.6V
14.4V
13.5V
13.5V
Dimensions cm (LxWxH)
17.5 x 13.5 x 6.3
Weight
1.4 Kg
Designed and Made In Australia By
GSL Electronics
14
www.gsl.com.au
High Voltage
22V-80VDC to 12V/24V
REDUCER/CHARGER
Designed to operate from 22V to 90V in 12V mode and
from 44V to 90V in 24V mode and supply 25Amps output.
This reducer charger fits the bill when you are in need for
a reducer or charger from a 48V or a 72V system making it
cheaper and easier to source easily available 12V and 24V
appliances and lighting.
REC-25HV
Features:
• microprocessor design ensures accurate voltage and
current charging parameters
• Automatic 3 stage charging ensures optimal fast
charge and extended battery life
• Remote enable can be disabled via internal jumper
• Charging modes suitable for Lithium, AGM, GEL and
Flooded
• Short circuit protection
• Over temperature protection
• Over current protected
Designed and Made In Australia By
GSL Electronics
www.gsl.com.au
15
High Performance Low Cost
200W Solar Charger
MAXIMUM POWER POINT TRACKER
Increase your charging, with the revolutionary MPPT
series using the technology that won GSL the
prestigious “2008 EDN Innovation award”. This
innovative solar charger is extremely cost effective,
efficient, compact and easy to use. Reliability is
enhanced by a multilevel over temperature protection
and a robust maximum power tracking algorithm.
Features:
MPPT12-2
MPPT12-1: Lowest cost MPPT in the market:
• Ideal for charging batteries with new low
cost and high efficiency grid type panels
• Simple 3 wire “plug and play” connection
• Autoselect for 12V and 24V panels and batteries
MPPT12-2: More features and flexibilty
• Built in load switch configurable as a variable
dusk to dawn or low voltage disconnect
• Remote load control option and alarm
• Surge, PV short and reverse current protection
Designed In Australia By
GSL Electronics
16
www.gsl.com.au
High Performance Low Cost
1800W Solar Charger
MAXIMUM POWER POINT TRACKER
MPPT30-1
Increase your charging, with the revolutionary GSL MPPT
series battery charging technology that won us the
prestigious“2008 EDN Innovation award”.
This innovative solar charger is extremely cost effective,
efficient, compact and easy to use.
Reliability is enhanced by a multilevel over temperature
protection and a robust maximum power tracking
algorithm.
Features:
MPPT30-1:
• Ideal for charging batteries with new low
cost and high efficiency grid type panels
• Simple 3 wire “plug and play” connection
• Suitable for 12V to 48V panels and batteries
MPPT30-2:
• Additional features for the more advanced user
such as dusk to dawn, low voltage disconnect,
remote alarm and programming capability.
• Optional LCD display for voltage and charge status.
• Triple chemistry vented, GEL and AGM cells
MPPT30-1L and MPPT30-2L:
• Designed with charging functionality for the new Lithium (LiFePO4) Batteries emerging on the market.
• Built with three different charging schemes “High Capacity” , “Long Life” and “Nominal” to ensure you can
get the most from your batteries and suit your charging style.
- Available in custom charge rates. Conditions Apply.
Designed and Made In Australia By
GSL Electronics
www.gsl.com.au
17
High Performance Low Cost
3600W Solar Charger
MAXIMUM POWER POINT TRACKER
MPPT60-1
Increase your charging with the revolutionary GSL
MPPT series using the technology that won us the
prestigious “2008 EDN Innovation award”. This
innovative solar charger is extremely cost effective,
efficient, compact and easy to use. Reliability is
enhanced by a multilevel over temperature protection
and a robust maximum power tracking algorithm.
Features:
MPPT60-1:
MPPT60-2:
• Ideal for charging batteries with new low
cost and high efficiency grid type panels
• Simple 3 wire “plug and play” connection
• Suitable for 12V to 48V panels and batteries
• Additional features for the more advanced user
such as dawn to dusk, low voltage disconnect,
remote alarm and programming capability.
• Optional LCD display for voltage and charge status.
• Triple chemistry vented, GEL and AGM cells
MPPT60-1L and MPPT60-2L:
• Designed with charging functionality for the new Lithium (LiFePO4) Batteries emerging on the market.
• Built with three different charging schemes “High Capacity” , “Long Life” and “Nominal” to ensure you can
get the most from your batteries and suit your charging style.
MPPT60-1C and MPPT60-2C:
• Designed with to work in Parallel for greater flexibilty and charge batteries that are under constant use.
(Not recomended for storage batteries)
- Available in custom charge rates. Conditions Apply.
18
Designed and Made In Australia By
GSL Electronics
www.gsl.com.au
New High Performance Low Cost
HIGH VOLTAGE
MAXIMUM POWER POINT TRACKERS
Our new MPPT High Voltage range accommodates strings of panels up to
180VDC open circuit with the MPPT30HV and 90VDC with our MPPT10HV.
Using our same proven and robust Maximum Power Point Tracking algorithim
featured in all our solar products.
Note : For added saftey should be used in conjunction with MIHV160 or MIHV240 (see
page 20)
MPPT10HV
Features:
MPPT10HV:
• Maximum output 10Amps / 400Watts
• Low Voltage Disconnect
• Adaptive Dawn to Dusk
• Autoselect “plug and play” connection for input and
output voltages
• Both Lead and Lithium based chemistries
• Remote Alarm and Load Control capabilites
• Surge and PV short protection
19
MPPT30HV
MPPT30HV:
• Input panel voltage up to 180 Voc input
• Ideal for charging batteries from higher voltage panels
• Autoselect for 12V, 24V and 48V panels and batteries
• Dual lead acid and Lithium
• Built in load switch configurable as a variable dawn to
dusk or low voltage disconnect
• Remote load control option and alarm
• Low voltage disconnect
• Surge, PV short and reverse current protection
• Connectivity to the MCM product for Remote
Monitoring and Control
19
High Performance Low Cost
BOOSTER
MAXIMUM POWER POINT TRACKERS
BMPPT250
The BMPPT Range is designed for systems where a limited space
is available for panel mounting or redesigning old systems going
from lower voltage panels to higher voltage batteries.
Ideal for situations where you can only fit a 12V panel but require
a 24V or 48V charging system.
BMPPT1500
The two larger models of our range offer the full featured
functionality that can be found in the rest of the solar
range through the MCM and the supported GUI.
Most of the BMPPT range has Lithium charging functionality on
top of their proven and reliable lead acid charging programs.
Designed and Made In Australia By
GSL Electronics
20
www.gsl.com.au
20
HIGH VOLTAGE DISCONNECT
MIHV Series
For use with MPPTHV Range
The MIHV160 and MIHV240 provide extra peace of mind
to help prevent over voltage issues if there is a fault in the
system. Designed specifically to provide added saftey to
our High Voltage range of MPPT’s. These features also apply
to any solar or battery charging system that has a higher
voltage to a lower voltage battery.
MIHV240
Features:
• Auto detects 12V/24V/48V nominal battery voltages
• Enables partial battery charge even in the case of
MPPT failure.
• Built in self resetting over temperature protection
• Status indication
• Compatible with GSL MPPT Series
• Compact heavy duty aluminium extrusion and
heavy duty brass connections
Designed and Made In Australia by
GSL Electronics
www.gsl.com.au
21
HIGH VOLTAGE LUMINARE/LED DRIVER
Combined with
MPPT SOLAR BATTERY CHARGER
LMS Series
LMS2025
Designed specifically for solar lighting applications the LMS2025 is
a one stop device for charging and driving high voltage LED lighting
and their attached batteries.
Combining our award winning MPPT charger with a stable constant
current LED Driver. Built to run a LED lighting/Luminaires 0.45A at
voltages from 15V to 55V from a 12V Battery with 95% efficiency.
Coupled with keeping a battery charged from a 200W panel
(maximum Voc of 55V) also at 98% efficiency (typical).
All of these power packed features fit into a small form factor
measuring just 170mm x 175mm x 40mm making it compact
and capable of fitting into the tightest of situations.
The driver has a digital remote wire allowing the light to be switched
off. This wire can be used with a grounded switch or attached to a
light sensor switch to enable the light to be operated automatically at
night time.
Additional Features to be considered :
(MOQ applies):
• Dimmer via external controls
• ON / OFF Dawn to Dusk Controls
• Variable Current Settings (0.1A-2A / 15V-80V)
• Remote Alarm
• IP Rated units
• Up to 90VDC LED’s / Luminaires
Designed and Made In Australia by
GSL Electronics
22
www.gsl.com.au
High Performance Low Cost
Monitor and Control Module
MAXIMUM POWER POINT TRACKERS
Features:
• Simple to operate
• Displays system parameters
• Enables load control and voltage settings
• Low cost
• Compatible with GSL MPPT Series
• PC connectivity
• Can be positioned up to 1m from MPPT
Display:
• Battery voltage
• Battery current and amph
• Load current and amph
• PV Voltage
• MPPT temperature
• Low battery voltage alarm
• High temperature alarm
Display Type:
• Dual line 32 character LCD
MCM
Control:
• Load connect / disconnect
• Output voltage programming
• Alarm ( Over Temerpature and Low Voltage)
level setup
Connectivity:
• PC via USB
• PC GUI for all display and control
• MPPT via standard 9 pin connector
Designed In Australia for
GSL Electronics
www.gsl.com.au
23
12V To 24VDC Voltage Doublers
Single / Muli Circuit
Features:
• High efficiency switchmode technology
• Soft start - via control wire
VI1224-10
• Overload protection
• Input to output protection
• Compact and lightweight aluminium
heatsink construction
• Suitable for most automotive,
marine and industrial applications
• Polymer encapsulation on VI1224-340 for
waterproofing and to reduce water ingress.
* Denotes Encapsulated
Note (1): With vehicle engine running.
Designed and Made In Australia By
GSL Electronics
24
www.gsl.com.au
12V To 24VDC Voltage Reducers
Muli Circuit
Features:
VR 13
• For use with incandescent and LED lighting only
• High efficiency
• Compact and light weight aluminium
heatsink construction
• Polymer encapsulation(on selected models) to reduce
water intake
• Limited short circuit and overload protection
NEW
VR 11
New smaller compact design for external mouting
on the draw bar of the trailer. Featuring direct feed
wiring removing the need to wire a 24V source to
the reducer. The VR 11 offers the best of the current
range of voltage reducers in a small compact
package.
VR 11
* Denotes Encapsulated
Designed and Made In Australia By
GSL Electronics
www.gsl.com.au
25
24V To 12VDC
Multi Circuit Lighting Reducers
4 CIRCUITS
Features:
Multi circuit reducers are designed specifically for
applications with incandescent & LED lighting for caravans,
MCR 120
box trailers and other automotive vehicles. When choosing
which model to use: determine the load required to be
carried by each circuit as accurately as possible.
Choose the model which has a capacity of 10-15% above
the estimated current needed to allow for wiring resistance
in trailers. The MCR 120 and MCR 240 series are designed
for caravans, box trailers and other small trailers where the
length of cable does not exceed 6m.
Designed In Australia By
GSL Electronics
26
www.gsl.com.au
24V To 12VDC Single Circuit
LINEAR VOLTAGE REDUCERS
“Keylink Series”
Features:
• Output - fail safe protection to guard
communication and electronic equipment
against over voltage
• Current limiting under overload, short circuit condition.
The unit will respond to overload and short circuit
conditions by folding back the output voltage.
• Ideal for use with communications equipment
VR 2P
Designed and Made In Australia By
GSL Electronics
www.gsl.com.au
27
Compact 7A, 24V To 12VDC
Switchmode Voltage Reducer
Features:
• High efficiency switchmode technology
• High reliability and low noise design
SM 107
• Input and output status indicators
• Current limiting under overload and
short circuit conditions
• Accurate output over voltage protection
to safeguard 12V equipment
• Compact and lightweight design
• SM107MC and SM107-M are designed for
applications that require constant voltage
supplied for memory functions.
• SM107MC is for applications that call for a high current
memory drain (up to full output) and a low current (20mA)
switching wire for the control/remote wire of the device being
attached.
• SM107M is for applications that have a constant memory
wire requirement that is below 20mA.
Designed In Australia By
GSL Electronics
28
www.gsl.com.au
24V To 12VDC Single Circuit
Switchmode Voltage Reducer
Features:
• High efficiency switchmode technology
• Overload, short circuit, over voltage and
SM 120
thermal protection
• Compact and lightweight aluminium
heatsink construction
Designed In Australia By
GSL Electronics
www.gsl.com.au
29
High Performance
24V To 12VDC
Available in 40A and 60A
SWITCHMODE VOLTAGE REDUCERS
Features:
• Microprocessor based, high output
stability and protection
• High efficiency switchmode technology
• Control wire via ignition
• Thermal, over voltage, overload and
short circuit protection
REC - 1260R
• Compact and lightweight aluminium
heatsink construction
• Able to suit most applications where high
efficiency and regulated 12V is required
Designed and Made In Australia By
GSL Electronics
30
www.gsl.com.au
High Performance
24V To 12VDC
Available in 40A and 60A
SWITCHMODE BATTERY EQUALIZER
Features:
• Microprocessor based, accurately insures that
the voltage on both batteries remains equal
even under highly unbalanced 12V current
• Status indication for both 24V and 12V buses
• High efficiency switchmode technology
• Improved reliability and extends battery life
• Control wire via ignition
• Current limiting under overload and short
circuit conditions
• Thermal and over voltage protection
• Compact and lightweight aluminium
heatsink construction
REC - 1260E
Designed and Made In Australia By
GSL Electronics
www.gsl.com.au
31
SWB1000-12
32
32
SWB1800-12
SWB2500-12
•Proven Quality • Modern Design • Soft Start • Input to Output Isolation • Portable
• Lightweight • Easy Installation • Reverse Polarity and Output Short Circuit Protection
• Overload and Low Battery Shutdown / Alarm
DC TO AC POWER SOLUTIONS
33
INV150-12
INV350-12
INV600-12
•Proven Quality • Modern Design • Soft Start • Input to Output Isolation • Portable
• Lightweight • Easy Installation • Reverse Polarity and Output Short Circuit Protection
• Overload and Low Battery Shutdown / Alarm
DC TO AC POWER SOLUTIONS
INV1000-12
34
SW150-12
SW350-12
SW650-12
www.gsl.com.au
GSL Electronics
SW1200-12
•Proven Quality • Modern Design • Soft Start • Input to Output Isolation • Portable
• Lightweight • Easy Installation • Reverse Polarity and Output Short Circuit Protection
• Overload and Low Battery Shutdown / Alarm
DC TO AC POWER SOLUTIONS
Fluorescent Lamp
For T8 Tubes
LOW VOLTAGE INVERTERS
Features:
• Sine wave - high efficiency with low current drain
• Protection against reverse polarity connection
FL12-20
• Connection to both input and output via screw
terminals located on PCB
• Compact and lightweight aluminium
heatsink construction
• Optional extruded aluminium cover available,
refer table for applications
• Pre-punched slots at either end of heatsink
for ease of installation
Note: - These products suit T8 tubes only
Designed and Made In Australia By
GSL Electronics
www.gsl.com.au
35
Fluorescent Lamp
For T5 Tubes
LOW VOLTAGE INVERTERS
Features:
• Sine wave - high efficiency with low current drain
• Protection against reverse polarity connection
• Connection to both input and output via
screw terminals located on PCB
• Compact and lightweight aluminium
heatsink construction
• Optional extruded aluminium cover
available, refer table for applications
• Pre-punched slots at either end of
heatsink for ease of installation
FL12-8
Note: - These products suit T5 tubes only
- T5 tubes available for purchase
Designed and Made In Australia By
GSL Electronics
36
www.gsl.com.au
Fluorescent Interior Light
For T5 Tubes
LOW VOLTAGE FLC SERIES
Features:
• The GSL interior FLC series are suited
ideally for ceiling and wall mounting
• Incorporates a built in on/off switch
• Suitable for mobile homes, caravans, boats
and solar powered installations with either a
12V or 24V DC electrical system
FLC12-8
• Light weight aluminium construction
• Fitted with a clear diffuser
• Assembly is fixed by means of two (2) screws
• Easy tube replacement
• Utilizes slim line type 5 tubes
Note: - These products suit T5 tubes only
- T5 tubes available for purchase
Designed and Made In Australia By
GSL Electronics
www.gsl.com.au
37
12 Volt Tralier
ELECTRIC BRAKE CONTROL
XLE-12
Features:
• Compact size design for easy installation
• Operates reliably even on roughest roads
• Adjustable brake pressure via control knob
• Suitable for single axel trailers
• Easy connection, only four wires to connect
• Light weight Aluminium heatsink construction
• Can be mounted in any position
• LED status indicator
• Designed for negative earth (ground)
XLE-12T
systems only
The XLE - 12 is an electronic, rugged and easily installed unit.
Note: * Please check with relevant authorities in your state for the
use of the XLE-12T as it is prohibited for use in some states.
Designed and Made In Australia By
GSL Electronics
38
www.gsl.com.au
High Performance
Advanced Micro Controlled
ELECTRONIC BRAKE CONTROLLER
Features:
• New generation microprocessor based
• 12V and 24V versions available
• Digital display for accurate setup
• Open circuit and overload indication
• Easy setup via 2 push button switches
• Convenient override slide knob
• 3 Ramp up levels for brake speed actuation
• Compact and rugged aluminium extrusion
• 2 Axel capability
Universal Mounting Bracket
EBC
“Designed in conjunction with leading Australian towing experts...”
Designed In Australia By
GSL Electronics
www.gsl.com.au
39
12V and 24V
REMOTE BRAKE CONTROLLER
Features:
• Convenient installation, control box can be
mounted under dash.
• Ideal for modern vehicles where airbags
leave no safe way for traditional brake
controllers to be mounted.
• New generation microprocessor based
• 12V and 24v versions available
• Open circuit and overload indication
• Easy setup via 2 push button switches
• Convenient push button
• Compact and rugged aluminium extrusion
• 2 axel capability
RBC-24
Designed and Made In Australia By
GSL Electronics
40
www.gsl.com.au
12/24 Dual Voltage
REVERSING BUZZER
Features:
• Dual Voltage 12 or 24VDC
• Compact and lightweight, black powder
XBA-12
coated heatsink
A
• high intensity piezo buzzer
• When reverse gear is engaged on the vehicle,
the reversing lamps illuminate and at the same
time the module begins to sound
“The XBA-12 is designed to suit most vehicles such as 4WD’s, Commercial,
Forklifts and Agricultural vehicles...”
Designed and Made In Australia By
GSL Electronics
www.gsl.com.au
41
WIG - WAG Flashing Modules
TIMED Flashing Modules
Models: TFM-12, TFM-24, STFM-24
The module is designed for the use in school buses
as required by the RTA. The module is activated and
operates the four amber lamps (which are fitted
externally on the bus), when the bus door(s) are
opened. Voltage is supplied to operate the two (2)
of the four (4) amber lights alternately. The lamps
remain flashing until the door(s) are closed and then
for a further period of 21 to 28 seconds. The cycle is
repeated each time the door(s) are opened.
TFM-12 & FLM-24N
TFM - 12 & TFM - 24 models are designed for use on
vehicles with negative earth air pressure switches.
STFM is designed for use on STA vehicles with a
positive voltage feed door air pressure switches.
Models: FLM-24P, FLM-24N & FLM-12N
These modules are designed for use in conjunction with either STFM-24,TFM-24, TFM-12 (To flash vehicle headlights
alternately). The modules are activated and operate only when the timer unit is activated (via the door air pressure
switches) and flashes the vehicles headlights (in a alternate pattern). The module is also fitted with a second channel,
which may be used to dip the vehicles headlights if so desired. These can be adjusted for positive or negative fed
vehicles with the movement of a jumper internally.
Designed and Made In Australia By
GSL Electronics
42
www.gsl.com.au
Vehicle Saftey Devices
Daytime Running Lights & Hand Brake Alarms
LOKO 1224 - Daytime Running Lights (DRL)
LOKO 1224
• Suits most vehicles
• 12V and 24V compatability
• Works with both Positive and Negitive switches
• Parking light enable/disable
• Delayed headlight initialization for reduced ignition
loading.
• Low voltage cutout
• Adjustable low voltage cutout and delay times
available upon request. [Minimum Order Quantity Applies]
HB 12/24 - Handbrake Alarm
• Suits most vehicles
• Compatable with both 12V and 24V Vehicles
• Works with both Positive and Negitive switches
• One Button press easy setup for positive and
negative swtiching.
HB 12/24
Designed and Made In Australia for
GSL Electronics
www.gsl.com.au
43
Battery Master Switch
BMS Series
Features:
Battery Master Switch, models BMS-12L, BMS-K-12L &
BMS-124 are a fully sealed, heavy duty, double pole switch
designed for commercial vehicles They are also suitable for
industrial and marine applications.
BMS-12L
The outer case is made from an anti-crack material, it has
great resistance to damage from impact, is impervious to fuel
oils, petroleum etc. and in case of fire has self extinguishing
properties.
The Battery Master Switch can be operated manually. It can
also be switched ‘OFF’ electronically by a momentary push
switch (cab mounted , not supplied) which operates a solenoid inside the main switch.
The Battery Master Switch is designed so that the ‘alternator field circuit contacts open prior to the main contacts
opening. When the switch is turned off electronically this is aprox. 2-3 miliseconds. When turned off manually, the delay
on both models is 100-150 milliseconds.
Main terminals of the Battery Switches are 4 heavy duty studs and the Auxiliary terminals are screws protected by a
detachable cover on the front of the switch.
The BMS-K-12L is specifically designed for dual positive isolation.
Designed In Australia By
GSL Electronics
44
www.gsl.com.au
Electronic
100 / 150 Amp
BATTERY ISOLATORS
Features:
• Microprocessor control - improved
reliability, stability and life expectancy
• Effective current limiting to protect vehicle
electrical system from overload
• Galvanic insulation between positive
main and auxiliary terminals
• No damage with short surges up to 60V or
main connections inverted
• Delay of 2 seconds to connect when enabled
• No delay to connect once enabled or to
disconnect if disabled
• Voltage dip protection via 2 second delay
• Accuracy better than 0.5% or 50mV
• Custom cut off and cut in voltage available *
EBI-150M
* Conditions Apply, call main office for more information.
Designed and Made In Australia By
GSL Electronics
www.gsl.com.au
45
Micro Controlled
12V / 24V 50Amp & 12V 20A
LOW VOLTAGE DISCONNECTS
LVD-5012 / LVD-5024
Features:
• Solid state design with accuracy better than 0.5%
• Current limited for overload
LVD-5012-1
• 2 second delay for starting of vehicle and settling
of input voltage
• 2 second delay for connecting/disconnecting
for voltage surges/dips
• Less than 0.15V drop at full 50A load
• Low standby current drain of less than 20mA
• Aluminium extrusion 120(L) X 50(W) X 40(H) mm
• LED status indicator
• Custom cut out and cut in voltages available *
* Conditions Apply, call main office for more information.
LVD-2012
Features:
LVD-2012-1
• Current limited for overload
• Aluminium extrusion 120(L) X 50(W) X 40(H) mm
• Encapsulated to resist moisture ingress
Designed and Made In Australia By
GSL Electronics
46
www.gsl.com.au
Low Battery
MONITORS AND DISCONNECTS
Features:
Low
Battery Disconnects
LBC - 12B
• Low voltage disconnect to protect battery
• Built in LED indicator
• Spike protected
• Low current drain
• Warning indicator with audible buzzer *
• Lightweight construction
* “B” Model Only
Features:
Low
Battery Monitor
LBM - 24
• Warns when battery voltage drops to 21V
• Warning indicators via audible buzzer and lamp
• Spike protected
• Low current drain
• Lightweight construction
Designed and Made In Australia By
GSL Electronics
www.gsl.com.au
47
Micro Controlled
SOLENOID BATTERY ISOLATOR
Features:
• Available in 12 and 24VDC versions at 100amp.
• Spike protected
• Delayed start
• Simple Installation - with 2 mounting points
• Suited to all vehicles, boats, caravans
and mobile homes
• Override (optional requires momentary switch)
KBI-100A-12
Designed In Australia By
GSL Electronics
48
www.gsl.com.au
Battery
ISOLATOR INSTALLATION KIT
BIK-1
Features:
• Isolator installation kit used in conjunction with BATTERY ISOLATOR products
• Simple and Easy Installation
GSL Electronics
www.gsl.com.au
49
12 Volt
UNINTERRUPTABLE POWER SUPPLY
“Powermaster Series”
Features:
• Auto changeover without interruption
upon mains failure
• 10A auto 2 stage charger
• Low voltage disconnect to protect battery
UPS240-1210
• High efficiency switchmode technology
• Compact and lightweight anodized
aluminium heatsink construction
Approvals:
Safety Standard No. N17018
C Tick No.N1408 (EMI,RFI)
AS/ANZ 60950 : 2000
AS/NZS2064 Group1, Class A
Designed and Made In Australia By
GSL Electronics
50
www.gsl.com.au
240VAC to 12VDC
LINEAR REGULATED
Power Supply
Features:
• Output short circuit protected
• Overload protected
• Thermal fuse protection against
overheating or excessive primary current
• Low ripple voltage
12 Volt
FULLY REGULATED POWER SUPPLY
“Powermaster Series”
Features:
• High efficiency switchmode technology
RPS12-10
• Compact and lightweight anodized
aluminium heatsink construction
• Suitable for communications equipment or
where stable regulated DC voltage is required
Approvals:
AS/NZS 60950; 2000 Inc. Amendment 1
Approval No. 17018
C Tick Approved AS/NZS 4417
Designed and Made In Australia By
GSL Electronics
www.gsl.com.au
51
12VDC and 24VDC
WATER LEVEL INDICATORS
Features:
• Suits negative earth systems
• Warning indication by audible
WLI-24
buzzer and a dash-mounted lamp
• Suits water based applications in automotive,
agricultural, marine and industrial equipment
• Sensor probes available to suit both plastic
and metal header tanks
• Light weight construction
Designed and Made In Australia By
GSL Electronics
52
www.gsl.com.au
Water Level Indicator
INSTALLATION KITS
Model: 230058
Probe Kit
Suits Plastic Tanks
Model: 230059
121 mm Probe Kit
Suits Plastic Header Tanks
Model: 230061
Probe Kit
Suits Metal Tanks
GSL Electronics
www.gsl.com.au
53
ABS Plastic / Alloy Housing
C/W MOUNTING LUGS
VW-450
VW-460
VW-480
Designed In Australia By
GSL Electronics
54
www.gsl.com.au
GSL Electronics designs and manufactures power conversion and electronic
equipment for the automotive and communications industries. We take pride in
delivering quality products at very competitive prices.
Our range includes solar chargers, voltage reducers, voltage doublers, battery
chargers,battery isolators, fluorescent lights, light inverters, power inverters,
power supplies, brake controls and reversing alarms.
Today you will find GSL products distributed by leading wholesalers and
dealers throughout Australia and New Zealand. Thank you for the continued
support of all our customers.
GSL has a fully trained and permanent workforce which enables us to maintain
a consistently high standard of manufacturing. Our engineering, technical and
production personnel bring many years of industry knowledge to each product.
GSL’s commitment to research and development means we have a solid
understanding of the proven manufacturing technologies. We also monitor
new technologies to identify those that are likely to be of future interest to our
customers and strategic partners.
We welcome enquiries from prospective distributors. To discuss the benefits of
becoming a GSL distributor, contact us today.
Distributed By:
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
