Today Honda ATVs are recognised as
the best 4-wheeled motorcycles on
the planet. And it’s been that way ever
since these tough, reliable vehicles
were first introduced onto the market.
First conceived as a form of transport for people in
remote mountain areas – these amazing ALL-Terrain
Vehicles (ATVs) instantly became a worldwide hit in
both the workplace and the leisure market.
And in Australia, where conditions are amongst the
toughest on earth – Honda ATVs are ranked as the
number one selling agricultural 4-wheeled bikes.*
Thriving in all kinds of conditions across the planet
from the ice and snow of the Antarctic to undiscovered
off-road trails in South America, Honda TRX™ is
recognised worldwide as the best in its field. And not
content to rest on its past achievements – Honda is
still leading the way into the future for the 4-wheeled
motorcycle category with a never-ending procession of
technological advances.
*Source – 2013 FCAI Retail Report.
More than 20 years
old and still going
strong
The hardest and oldest working
Honda TRX™ is still alive. The
TRX200 owned by Graeme and
Sandra Grivell has given them
over 20 years of faithful service
on their sheep station in
Langhorne Creek, SA. Currently
on display at the Australian
Outback Spectacular on the
Gold Coast.
SAFETY
Honda promotes the safe, responsible
operation of its range of 4-wheelers.
Honda Australia Rider Training (HART)
is fully owned and run by Honda, who
apart from being the world’s largest
motorcycle manufacturer, is also
one of the world’s largest trainer of
motorcyclists. Completing an ATV
training course is an important step in
learning to operate your ATV safely.
Honda is a Quality Endorsed Company
and HART’s instructors are qualified
and experienced to deliver industry
leading ATV training. Visit HART online
at hart.honda.com.au
It’s important to Honda that you operate your ATV
with the highest safety considerations in mind, please
carefully read the instructions for safe ATV operation
on the right side of this page.
Honda also encourages you to read your Honda
owner’s manual and watch the “You and Your ATV”
safety DVD which comes free with every Honda ATV.
Adhere to these safe riding practices and you’ll get
pleasure and enjoyment from your ATV for many years
to come.
For further information on how Honda is dedicated to
the advancement of ATV safety contact Honda Australia
on 1300 1 Honda or visit us online at honda.com.au
DO
- Complete an accredited ATV course.
- Always wear an approved helmet, eye protection, leather
gloves and boots.
- Wear long pants and a long-sleeved shirt to avoid injury
from branches and to avoid the effects of the sun.
- Make sure your feet remain on the footrests at all times.
- Always secure your load and check your recommended
rack and tow capacity.
- Always fasten your load as low as possible to prevent the
ATV from overturning.
- Check operating controls and tyre pressures on a daily
basis.
- If you can’t see ahead, it is recommended that you slow
down.
- Be on the constant look out for rocks, holes, logs, wire
and other hidden dangers.
- Study the owner’s manual carefully.
- Make sure you service and maintain your ATV as per the
maintenance schedule in your owner’s manual.
DON’T
- Never carry passengers. ATVs are designed for a single
rider only.
- Never ride your ATV on bitumen roads.
- Never allow children under the age of 16 to ride an ATV.
- Never leave the ignition key in an unattended ATV.
- Never exceed the recommended rack and tow capacity
of your ATV.
- Never ride your ATV up a slope or embankment that is
too steep to walk up.
- Never have your ATV serviced by an unqualified mechanic.
- And please, never harm the environment through
irresponsible riding.
hondamotorcycles.com.au | 3
PIONEER™ 500
Honda adds a compact, affordable and hard
working side-by-side to its product line-up
with the Pioneer™ 500.
SpeCIFICATIoNS
Engine Type
Bore and Stroke
Compression Ratio
Carburation
Ignition
Clutch
Transmission
Drive
*overseas model shown.
Unique Features
Additional Features
The pioneer 500 has taken the best features
of its full-sized SXS models and put them in a
smaller package. The pioneer™ 500 is smaller,
narrower and developed for access to all
those farm tracks and trails off-limits to larger
machines.
•Newchassiswithcompact
dimensions: 102.5-inch overall
length and 73.1-inch wheelbase.
•50-inchoverallwidthallowsaccess
to width-restricted trails.
•Fuel-injectedengineprovidesgreat
performance and excellent fuel
efficiency in a variety of conditions.
•Five-speedgearboxwithreverse
and a LoW first gear uses an
•Twist-actiondoorreleaseknob
opens the door and net together as
one unit.
•Hydraulicdiscbrakesfrontandrear.
•Large,flatrearcarrieroffersaload
capacity of 204kg and multiple
hook points for tie-downs.
•Towingcapacityof453.5kgtotake
on tough jobs.
•FulllineofHondaaccessories
adds weather protection,
storage capacity and expanded
functionality.
•Transferableone-yearlimited
warranty; extended coverage
available with a Honda protection
plan.
92.0mm x 71.5mm
Automatic
Programmed Fuel Injection (PGM-FI),
36mm throttle body
Full transistor with electronic
advance
Automatic
Electric-shift five-speed with reverse
(First gear is L = LOW)
Direct front and rear driveshafts
Dimensions
2,603mm x 1,270mm x 1,838mm
(LxWxH)
Wheelbase
1,856mm
Seat Height
728mm
Ground Clearance
243mm
Fuel Capacity
electric shift system featuring
paddle shifters mounted on the
steering column.
475cc liquid-cooled OHV
longitudinally mounted singlecylinder four-stroke
15.5 litres (including 4.1 litres
reserve)
Front Tyre
24 x 8-12 inch
Rear Tyre
24 x 10-12 inch
Front Suspension
Independent double-wishbone;
150mm travel
Rear Suspension
Independent double-wishbone with
preload adjustablility; 150mm travel
Front Brake
Dual hydraulic 190mm discs
Rear Brake
200mm hyrdraulic disc
Towing Capacity
Max. Weight
Capacity:
Kerb Weight
Warranty Period
453.5kg
204kg
458kg
12 months
hondamotorcycles.com.au | 5
Pioneer™ 700-2
SpeCIFICATIoNS
Engine Type
Honda’s Pioneer™ 700-2 sets
the standard as the ultimate
in hard-working, hard-playing
side-by-sides. With the ability to
carry two people and a load of
gear and supplies, this side-byside is ideal for reaching those
hard to get to places.
Bore and Stroke
Compression Ratio
Carburation
Ignition
Clutch
Transmission
*overseas model shown.
Unique Features
Additional Features
Quick acceleration, good top speed and
smooth-riding long-travel suspension are
some of the keys to what makes the pioneer
700-2 so special. The handy tilt bed adds
lots of versatility, and being a Honda, it also
features industry-leading safety features plus
outstanding value.
•PoweredbyHonda’sprovenfuelinjected, 675cc, liquid-cooled, oHV
single-cylinder, four-stroke engine
the pioneer 700-2 has lots of
torque and plenty of power.
Available in Honda’s iconic Red colour, this
workhorse of a machine can also be dressed
up, modified and personalised by choosing
from a range of Honda Genuine Accessories.
packed with Honda expertise and features,
the pioneer 700-2 leads the way in innovative
side-by-side vehicle technology.
•Fuelinjectionmeansitwillalways
start up, even on cold days or
at high altitude and an all-new
intake design helps minimise dust
ingestion.
•ReadytotacklethetoughestAustralian terrain, the compact dimensions of Honda’s new side-by-side
offers high level of manoeuvrability
and the impressive turning radius
will get the pioneer 700-2 out of
any tight spot.
•ThePioneer700-2hasrugged
and aggressive styling and its
design incorporates proven Honda
technology for legendary Honda
reliability.
102.0 x 82.6mm
9.2:1
Fuel Injection (PGM-FI), 40mm
throttle body
Full-transistorised with electronic
advance
Automatic
Automotive-style with hydraulic
torque converter, three forward
gears and reverse. Three drive
modes include 2WD, 4WD and 4WD
with differential lock.
Drive
Direct front and rear driveshafts
Dimensions
2,916mm x 1,552mm x 1,971mm
(LxWxH)
Wheelbase
1,950mm
Ground Clearance
267mm
Turning Ratio
4.5m
Fuel Capacity
30 litres (including 4.5 litre reserve)
Front Tyre
25 x 8-12 inch
Rear Tyre
25 x 10-12 inch
Front Suspension
Independent double-wishbone;
200mm travel
Rear Suspension
Independent double-wishbone;
231mm travel
Front Brake
200mm hydraulic disc
Rear Brake
170mm hydraulic disc
Towing Capacity
680kg
Max Weight
Capacity
Kerb Weight
453kg
Warranty Period
6 | Honda ATV Range
675cc liquid-cooled OHV singlecylinder four-stroke
572kg
12 months
PIONEER
IONEER™ 700-4
SpeCIFICATIoNS
Engine Type
Now you don’t have to choose
between a two-person or fourperson Side-by-Side: The allnew Honda Pioneer™ 700-4
boasts an innovative convertible
design that allows the two rear
seats to fold into the bed.
Bore and Stroke
Compression Ratio
Carburation
Ignition
Clutch
Transmission
Drive
*overseas model shown.
Additional Features
owners can opt to use the pioneer
ioneer 700-4 with
two-seat, three-seat or four-seat configurations
and, best of all, the rear seats fold quickly and
easily without the need for tools. once folded
away the pioneer 700-4’s entire tilt-bed space
can be fully utilized.
•All-new
ll-newconvertibleseating
convertible seating
design offers the versatility and
adjustability of two, three, or fourperson seating configurations.
Available in Honda’s iconic Red colour, this
workhorse of a machine can also be dressed
up, modified and personalised by choosing from
a range of Honda Genuine Accessories.
packed with Honda expertise and features, the
pioneer 700-4 exceeds previous side-by-side
vehicles and boasts Honda reliability and
dependability nobody can touch.
•Seatingarrangementcanbe
quickly and easily changed thanks
to a folding, stow-away rear-seat
design, and provides full bed space
and tilt function while in the twoperson configuration.
oweredbyHonda’sprovenfuel•Powered
by Honda’s proven fuelinjected, 675cc, liquid-cooled, oHV
single-cylinder, four-stroke engine
the pioneer 700-4’s has lots of
torque and plenty of power.
•Withtheoveralldimensionsofa
two-person design, the pioneer
700-4 maintains a high level of
maneuverability while still being
able to seat up to four people.
hePioneer700-4hasrugged
•The
Pioneer 700-4 has rugged
and aggressive styling and its
design incorporates proven Honda
technology for legendary Honda
reliability.
102.0 x 82.6mm
9.2:1
Fuel Injection (PGM-FI), 40mm
throttle body
Full-transistorised with electronic
advance
Automatic
Automotive-style with hydraulic
torque converter, three forward
gears and reverse. Three drive
modes include 2WD, 4WD and 4WD
with differential lock.
Direct front and rear driveshafts
Dimensions
2,916mm x 1,552mm x 1,985mm
(LxWxH)
Wheelbase
1,950mm
Ground Clearance
Unique Features
675cc liquid-cooled OHV singlecylinder four-stroke
267mm
Turning Ratio
4.5m
Fuel Capacity
30 litres (including 4.5 litre reserve)
Front Tyre
25 x 8-12 inch
Rear Tyre
25 x 10-12 inch
Front Suspension
Independent double-wishbone;
200mm travel
Rear Suspension
Independent double-wishbone;
231mm travel
Front Brake
200mm hydraulic disc
Rear Brake
170mm hydraulic disc
Towing Capacity
680kg
Max Weight
Capacity
Kerb Weight
453kg
Warranty Period
633kg
12 months
hondamotorcycles.com.au | 7
TRX680FA
SpeCIFICATIoNS
Engine Type
Since its introduction, the
TRX680FA has remained
at the top of its class a direct result of its
impressive credentials.
Bore and Stroke
Carburation
Honda’s largest liquid-cooled 4-stroke ATV
features a single-cylinder fuel injected 675cc
oHV
HV engine that provides ample torque and
dependable power.
Honda’s automotive-style automatic ATV
transmission draws power through hydraulic
clutches and a torque converter to drive three
forward gears and reverse.
The TRX680FA features Honda’s
fully independent ATV rear suspension for
comfortable cruising over the toughest
terrain.
40mm fuel injection system for consistent
performance at high altitude, improved cold
weather starting, improved fuel consumption
and increased power.
Dual front disc brakes feature callipers
with patented built-in scraper for improved
8 | Honda ATV Range
Additional Features
braking performance in all conditions.
Brake pads feature thick, long-wear material
with improved mud durability, feel and
control. pads feature internal scraper that
give audible warning when pad life is low.
Stainless steel exhaust system provides
superior corrosion resistance and minimises
noise levels.
Washable air filter for easy maintenance and
consistent performance.
extensive weight-saving measures include
the use of aluminium for the following
components: forged front upper control arms,
rear upper and lower control arms, rear
knuckles, front and rear wheels.
SUV styling features flowing fenders with
integrated headlights and taillights.
No belts.
••Liquid-cooled
iquid-cooledoverhead-valve
overhead-valve
single-cylinder fuel injected
675cc 4-stroke engine is mounted
longitudinally in the frame, allowing
direct driveshaft alignment to
front and rear wheels for improved
drivetrain efficiency.
•Snorkel-typeairintakesystem
is specially designed for water
crossings.
••E lectricShiftProgram(ESP®)
lectric Shift Program (ESP®)
allows the rider to manually select
gears by simply pressing two
push-buttons mounted on the left
handlebar.
•Includesalow-fuelwarninglight.
Programmed electronic fuel injection
with Idle Air Control Valve
Full-transistorised with electronic
advance, Dual spark plug
Starter
Electric with auxiliary recoil
Clutch
Automatic
Drive
Unique Features
102.0 x 82.6mm
Ignition
Transmission
*overseas model shown.
675cc liquid-cooled OHV semi
dry-sump longitudinally mounted
single-cylinder 4-stroke
Automatic with hydraulic clutches
and a torque converter, three
forward gears, reverse and
electronic controls
Direct front and rear driveshafts with
torque-sensitive front differential
Dimensions
2,113mm x 1,189mm x 1,207mm
(LxWxH)
Wheelbase
1,289mm
Seat Height
875mm
Ground Clearance
234mm
Turning Ratio
3.2m
Fuel Capacity
17 litres (including 4.3 litre reserve)
Front Tyre
25 x 8-12 radial
Rear Tyre
25 x 10-12 radial
Front Suspension
Independent double-wishbone;
175mm of travel
Rear Suspension
Independent double-wishbone;
203mm of travel
Front Brake
Dual hydraulic 180mm discs
Rear Brake
Single hydraulic mechanical disc
Max Weight
Capacity
Kerb Weight
Warranty Period
220kg
291kg
36 months
TRX500FPA
FPA
SpeCIFICATIoNS
Engine Type
Honda’s TRX500FPA with its
innovative Hondamatic™
transmission, is both strong
and smart, ready for the
toughest work
Bore and Stroke
Carburation
Additional Features
The state of the art Hondamatic™ Hydrostatic
transmission is the first continuously variable
transmission (CVT) of its kind and does not
require either pulleys or belts. Which means
Hondamatic™ offers true engine braking.
•Honda’seasy-to-useTraxLok®
selectable 4WD drive system
to further expand its off-road
capabilities when the going gets
tough.
What’s more, the TRX500FpA is also the only
CVT Auto ATV with five transmission variables.
And since you won’t ever need to replace worn
out belts – you can enjoy the benefits of much
greater reliability.
•Multi-functionLCDdigital
instrumentation is compact,
tough and waterproof, featuring
large readouts for Hondamatic™
transmission modes, gear selector
position, speedometer, fuel gauge,
odometer, resettable trip meter and
hour meter/clock.
electric power Steering (epS) features
sophisticated torque sensors that measure how
much force you’re applying and then tailor how
much extra assist you need. It makes your life
much easier, especially when riding over ruts,
rocks and logs or on hill sides.
A computer-controlled electric Shift program
(ESP®)maximisesyourtransmission’spower
and control by allowing you to manually select
gears just by pressing two push-buttons which
are conveniently mounted on the left handlebar.
•Largefrontandrearcargoracks
are rated at 30 and 60 kilograms,
respectively and unique rearopening storage compartment
allows easy access when rack is
loaded.
•Waterproofaccessorysocket
provides 12-volt, 10-amp power
with a built-in temperature-type
fuse.
•Uniquelydesignedfloorboards
allow the rider’s feet to grip the
footrests while keeping away mud
and debris.
•Tripleheadlightsystemwith
single 45-watt upper light and dual
30-watt lower lights includes multireflector lenses for optimal light
distribution plus a 21-watt brake
light and taillight.
36mm constant velocity
DC-CDI full transistor with electronic
advance
Starter
Electric with auxiliary recoil
Clutch
Automatic / Centrifugal
Drive
Unique Features
92 x 75mm
Ignition
Transmission
*overseas model shown.
499cc liquid-cooled OHV dry-sump
longitudinally mounted singlecylinder four-stroke
HondamaticTM hydrostatic
transmission, continuously variable
with electronic controls
Direct front and rear driveshafts with
torque-sensitive front differential
Dimensions
2,108mm x 1,188mm x 1,179mm
(LxWxH)
Wheelbase
1,286mm
Seat Height
861mm
Ground Clearance
190mm
Turning Ratio
3.3m
Fuel Capacity
15 litres (4.9 litre reserve)
Front Tyre
25 x 8-12
Rear Tyre
25 x 10-12
Front Suspension
Independent double-wishbone;
170mm of travel
Rear Suspension
Swingarm with dual shock
absorbers; 170mm of travel
Front Brake
180mm front discs with
single-piston callipers
Rear Brake
Sealed mechanical drum
Max Weight
Capacity
Kerb Weight
Warranty Period
220kg
287kg
36 months
hondamotorcycles.com.au | 9
TRX500FM2
SpeCIFICATIoNS
Engine Type
Honda’s next generation
TRX500FM2, complete with
revised Electric Power
Steering, will continue to
hold its reputation as a hardworking partner.
Bore and Stroke
Carburation
Unique Features
Additional Features
Honda’s electric power Steering (epS) system
incorporates new eCU mapping for improved
linearity in steering response, reduced
low-speed steering effort for enhanced
manoeuvrability and decreased kickback
traits for improved all-around steering action.
•Powerfulliquid-cooled475cc
single-cylinder oHV four-stroke
engine is longitudinally mounted in
the frame allowing direct driveshaft
alignment to front and rear wheels
for improved drivetrain efficiency.
All-new double-cradle steel frame developed
with Computer Aided engineering features
increased stiffness and reduces weight for even
more precise handling and a smoother ride.
•RevisedmappingfortheElectronic
Fuel Injection program gives the
strong engine improved power
delivery, throttle response and fuel
efficiency.
A selectable locking front differential has
beenaddedtotheTRX500FM2’sTraxLok®
selectable 4WD drive system to further
expand its off-road capabilities when the
going gets tough.
Maximum weight capacity has been
increased to 250kg.
10 | Honda ATV Range
•Newfuelpumpisderivedfrom
Honda automobile technology. It
mounts in the fuel tank for better
heat isolation and offers increased
fuel filter life.
•ThenewTraxLok system also
features a Speed override mode
®
that can be engaged when the
front differential is locked, this
allows increased wheel speed
under severe conditions such as
deep mud.
•New,aggressivelystyledbodywork
provides improved mud and water
protection and an all-new onepiece fuel tank/side cover panel allows easy access for maintenance.
•Overhead-valvedesigncreates
a compact engine for excellent
ground clearance while maintaining a broad, easy-to-use
powerband.
•RevolutionaryElectricPowerSteering (epS) with new three-point
mounting setup for the epS system
makes the entire mechanism
more rigid for even more precise
steering.
•Anewchassisfeaturinglongertravel suspension elevates performance to a whole new level while a
brand new enclosed axle swingarm
has been developed to balance
and optimise strength and rigidity,
while improving rider comfort.
•Honda’sTRX500FM2isformerly
the TRX500FpM.
92.0 x 71.5mm
Programmed Fuel Injection (PGM-FI),
36mm throttle body
Ignition
Full transistorised with electronic
advance
Starter
Electric with auxiliary recoil
Clutch
Automatic / Centrifugal
Transmission
*overseas model shown.
475cc liquid-cooled fuel injected
OHV longitudinally mounted singlecylinder 4-stroke
5-speed with reverse
Drive
Direct front and rear driveshafts
with TraxLok® and locking front
differential
Dimensions
2,103mm x 1,205mm x 1,219mm
(LxWxH)
Wheelbase
1,268mm
Seat Height
869mm
Ground Clearance
190mm
Turning Ratio
3.2m
Fuel Capacity
14.7 litre (4.9 litre reserve)
Front Tyre
25 x 8-12 inch
Rear Tyre
25 x 10-12 inch
Front Suspension
Independent double-wishbone;
185mm of travel
Rear Suspension
Swingarm with single shock;
185mm of travel
Front Brake
Dual hydraulic 190mm discs
Rear Brake
Sealed 160mm mechanical drum
Max Weight
Capacity
Kerb Weight
Warranty Period
250kg
293kg
36 months
TRX500FM1
SpeCIFICATIoNS
Engine Type
With a host of new updates
the TRX500FM1 is a tough
and seasoned workhorse
that will continue
to impress.
Bore and Stroke
Carburation
Unique Features
Additional Features
A new chassis featuring longer-travel
suspension elevates performance to a
whole new level. Revised mapping for the
electronic Fuel Injection program gives the
strong liquid-cooled 475cc single-cylinder
oHV four-stroke engine improved power
delivery, throttle response and increased fuel
efficiency.
•Powerfulliquid-cooled475cc
single-cylinder oHV four-stroke
engine is longitudinally mounted in
the frame allowing direct driveshaft
alignment to front and rear wheels
for improved drivetrain efficiency.
A selectable locking front differential has
beenaddedtotheTRX500FM1’sTraxLok®
selectable 4WD drive system to further
expand its off-road capabilities when the
going gets tough.
All-new double-cradle steel frame developed
with Computer Aided engineering features
increased stiffness and reduces weight for
even more precise handling and a smoother
ride.
•Newfuelpumpisderivedfrom
Honda automobile technology. It
mounts in the fuel tank for better
heat isolation and offers increased
fuel filter life.
•ThenewTraxLok system also
features a Speed override mode
that can be engaged when the
front differential is locked, this
allows increased wheel speed
under severe conditions such as
deep mud.
®
•Overhead-valvedesigncreates
a compact engine for excellent
ground clearance while maintaining a broad, easy-to-use
powerband.
•TheTRX500FM1hasasuperheavy-duty automatic clutch with
a low-rpm engagement point for
excellent driveability and towing
capability.
•Abrandnewenclosedaxle
swingarm has been developed
to balance and optimise strength
and rigidity, while improving rider
comfort.
•New,aggressivelystyledbodywork
provides improved mud and water
protection while an all-new onepiece fuel tank/side cover panel allows easy access for maintenance.
•Otherupdatessuchasmorepowerful headlights, new electronic
instrumentation and improved rider
ergonomics ensure the TRX500FM1
offers even greater practicality and
value than ever before.
•Honda’sTRX500FM1isformerly
the TRX500FM.
92.0 x 71.5mm
Programmed Fuel Injection (PGM-FI),
36mm throttle body
Ignition
Full transistorised with electronic
advance
Starter
Electric with auxiliary recoil
Clutch
Automatic / Centrifugal
Transmission
*overseas model shown.
475cc liquid-cooled fuel injected
OHV longitudinally mounted singlecylinder 4-stroke
5-speed with reverse
Drive
Direct front and rear driveshafts
with TraxLok® and locking front
differential
Dimensions
2,103mm x 1,205mm x 1,219mm
(LxWxH)
Wheelbase
1,268mm
Seat Height
869mm
Ground Clearance
190mm
Turning Ratio
3.2m
Fuel Capacity
14.7 litre (4.9 litre reserve)
Front Tyre
25 x 8-12 inch
Rear Tyre
25 x 10-12 inch
Front Suspension
Independent double-wishbone,
185mm of travel
Rear Suspension
Swingarm with single shock, 185mm
of travel
Front Brake
Dual hydraulic 190mm discs
Rear Brake
Sealed 160mm mechanical drum
Max Weight
Capacity
Kerb Weight
Warranty Period
250kg
287kg
36 months
Maximum weight capacity has been
increased to 250kg.
hondamotorcycles.com.au | 11
TRX420FA2
SpeCIFICATIoNS
Engine Type
For reliable and rewarding
ATV action choose Honda’s
high-tech TRX420FA2 which
features EPS and DCT.
Bore and Stroke
Carburation
Additional Features
The automatic Dual Clutch Transmission
(DCT) provides the compact size and
strength of a manual transmission with the
convenience of an automatic transmission.
•TheruggedOHVliquid-cooled,
fuel-injected 420cc longitudinally
mounted engine allows direct
driveshaft alignment to both front
and rear wheels for maximum
drivetrain efficiency.
An all-new double-cradle steel frame
developed with Computer Aided engineering
features increased stiffness for even more
precise handling and a smoother ride.
New front and rear suspension features an
increase in travel at both ends plus new
shocks for a plush and controlled ride.
Honda TraxLok® 2WD/4WD system offers
two drive modes.
12 | Honda ATV Range
•NewmappingfortheProgrammed
Fuel Injection (pGM-FI) system
improves power delivery and
throttle response and increases
fuel efficiency for greater range.
•TheDCTfeaturesanewdual
shift-mapping program that
automatically selects between
two transmission shifting modes
- either Cruise or Sport mode - for
optimum shift timing depending
on the rider’s pattern of throttle
operation.
•TheElectricPowerSteering
(epS) system is next generation,
incorporating new eCU mapping
for improved linearity in steering
response, reduced low-speed
steering effort for enhanced
manoeuvrability and decreased
kickback traits for improved allaround steering action.
•Overhead-valvedesignprovides
compact engine dimensions for
excellent ground clearance while
maintaining a broad, easy-to-use
powerband.
•Adjustablespringpreloadisnow
featured on all shocks to allow
suspension tuning to match varying
loads and riding conditions.
•Newenclosed-axletypeswingarm
with optimised stiffness for
improved toughness, durability, and
excellent handling performance.
•Dualfronthydraulicdiscbrakes
and sealed mechanical rear drum
brake for strong stopping power.
PGM-FI 34mm throttle body with
Idle Air
Control Valve (IACV)
Full-transistorised type with
electronic advance
Starter
Electronic with optional auxiliary
recoil
Clutch
Automatic
Drive
Unique Features
86.5 x 71.5mm
Ignition
Transmission
*overseas model shown.
420cc liquid-cooled OHV
longitudinally mounted singlecylinder 4-stroke
Automatic/ESP® 5-speed with
reverse
Direct front and rear driveshafts with
torque-sensitive front differential
Dimensions
2,103mm x 1,205mm x 1,174mm
(LxWxH)
Wheelbase
1,268mm
Seat Height
856mm
Ground Clearance
183mm
Turning Ratio
2.8m
Fuel Capacity
14.7 litres (including 4.9 litre reserve)
Front Tyre
24 x 8-12 radial
Rear Tyre
24 x 10-11 radial
Front Suspension
•New,aggressivelystyledbodywork
also provides better mud and water
protection.
Independent double-wishbone;
170mm of travel
Rear Suspension
•Honda’sTRX420FA2isformerlythe
TRX420FpA.
Swingarm with single shock,
170mm of travel
Front Brake
Dual hydraulic 180mm discs
Rear Brake
Mechanical drum brake
Max Weight
Capacity
Kerb Weight
Warranty Period
220kg
291kg
36 months
TRX420FM2
SpeCIFICATIoNS
Engine Type
The TRX420FM2 offers the
ease and convenience of
Honda’s new-generation
Electric Power Steering
delivering lighter steering
effort especially at lower
speeds.
Bore and Stroke
Carburation
Unique Features
Additional Features
The electronic power Steering (epS) system
is next generation, incorporating new eCU
mapping for improved linearity in steering
response, reduced low-speed steering effort
for enhanced manoeuvrability and decreased
kickback traits for improved all-around
steering action.
•RuggedOHVliquid-cooled,fuelinjected 420cc longitudinally
mounted engine allows direct
driveshaft alignment to both front
and rear wheels for maximum
drivetrain efficiency.
All-new double-cradle steel frame developed
with Computer Aided engineering features
increased stiffness for even more precise
handling and a smoother ride.
New front and rear suspension systems
feature an increase in travel for a plush and
controlled ride.
•NewmappingfortheProgrammed
Fuel Injection (pGM-FI) system
improves power delivery and
throttle response, and increases
fuel economy for greater range.
•Overhead-valvedesignprovides
compact engine dimensions for
excellent ground clearance while
maintaining a broad, easy-to-use
powerband.
•Super-heavy-dutyautomatic
clutch with a low-rpm engagement
point for excellent driveability and
towing capability.
•Newthree-pointmountingsetupfor
the epS system makes the entire
steering mechanism more rigid for
even more precise steering.
•HondaTraxLok® 2WD/4WD system
offers two drive modes: 2WD and
4WD with TraxLok® torque-sensing
front differential.
•Newenclosed-axletypeswingarm
with optimised stiffness for
improved toughness and
durability, and excellent handling
performance.
•New,aggressivelystyledbodywork
also provides better mud and water
protection.
•Honda’sTRX420FM2isformerly
the TRX420FpM.
86.5 x 71.5mm
Keihin 34mm throttle-body fuelinjection system
Ignition
Full-transistorised with electronic
advance
Starter
Electric with auxiliary recoil
Clutch
Automatic / Centrifugal
Transmission
*overseas model shown.
420cc liquid-cooled OHV
longitudinally mounted singlecylinder 4-stroke
5-speed with reverse
Drive
Direct front and rear driveshafts
Dimensions
Wheelbase
2,103mm x 1,205mm x 1,174mm
(LxWxH)
1,268mm
Seat Height
856mm
Ground Clearance
183mm
Turning Ratio
2.8m
Fuel Capacity
14.7 litre (including 4.9 litre reserve)
Front Tyre
24 x 8-12 inch
Rear Tyre
24 x 10-11 inch
Front Suspension
Independent double-wishbone;
170mm of travel
Rear Suspension
Swingarm with single shock
absorber; 170mm travel
Front Brake
Dual hydraulic discs
Rear Brake
Sealed mechanical drum
Max Weight
Capacity
Kerb Weight
Warranty Period
220kg
283kg
36 months
•Adjustablespringpreloadnow
featured on all shocks to allow
suspension tuning to match varying
loads and riding conditions.
hondamotorcycles.com.au | 13
TRX420TM1/FM1
SpeCIFICATIoNS
Engine Type
With an impressive list of
features these mid-sized
workhorses boast maximum
durability and excellent
handling performance.
Bore and Stroke
Carburation
Unique Features
Additional Features
All-new double-cradle steel frame developed
with Computer Aided engineering features
increased stiffness for even more precise
handling and a smoother ride.
•RuggedOHVliquid-cooled,fuelinjected 420cc longitudinally
mounted engine allows direct
driveshaft alignment to both front
and rear wheels for maximum
drivetrain efficiency.
New mapping for the programmed Fuel
Injection (pGM-FI) system improves power
delivery and throttle response, and increases
fuel economy for greater range.
New front and rear suspension systems
feature an increase in travel for a plush and
controlled ride.
•Overhead-valvedesignprovides
compact engine dimensions for
excellent ground clearance while
maintaining a broad, easy-to-use
powerband.
•Adjustablespringpreloadisnow
featured on all shocks to allow
suspension tuning to match varying
loads and riding conditions.
•Newenclosed-axletypeswingarm
with optimized stiffness for
14 | Honda ATV Range
•Newrubberswingarmpivot
bushings yield increased lowspeed ride comfort and increased
durability.
•Newfuelpumpisderivedfrom
Honda automobile technology. It
mounts in the fuel tank for better
heat isolation and offers increased
filter life.
•Dualfronthydraulicdiscbrakes
and sealed mechanical rear drum
brake for strong stopping power.
•Rearbrakeisnowlocatedinside
the right rear wheel for improved
durability and increased ground
clearance.
•New,aggressivelystyledbodywork
also provides better mud and water
protection.
•TheTRX420FM1offersHonda’s
TraxLok® 2WD/4WD system
with two drive modes while the
TRX420TM1 is two-wheel drive.
•Honda’sTRX420TM1/FM1is
formerly the TRX420TM/FM.
Keihin 34mm throttle-body fuelinjection
Full transistor with electronic
advance
Starter
Electric with auxiliary recoil standard
Clutch
Automatic / Centrifugal
5-speed with reverse
Drive
Direct front and rear driveshafts
(FM) Direct rear driveshaft (TM)
Dimensions
2,103mm x 1,205mm x 1,174mm
(LxHxW)
Wheelbase
1,268mm
Seat Height
856mm
Ground Clearance
183mm
Turning Ratio
improved toughness and
durability, and excellent handling
performance.
86.5 x 71.5mm
Ignition
Transmission
*overseas model shown.
420cc liquid-cooled OHV
longitudinally mounted singlecylinder 4-stroke
Fuel Capacitay
3.29m (FM) 2.7m (TM)
14.7 litre (4.9 litre reserve)
Front Tyre
24 x 8-12 inch
Rear Tyre
24 x 10-11 inch
Front Suspension
Independent double-wishbone;
170mm of travel
Rear Suspension
Swingarm with single shock;
170mm of travel
Front Brake
Dual hydraulic discs
Rear Brake
Sealed mechanical drum
Kerb Weight
Warranty Period
277kg (FM) 261 (TM)
36 months
TRX250TM
SpeCIFICATIoNS
Engine Type
Tried, tested & proven over
14 years working in the
Australian market.
Excellent breeding, built
from tough DNA
Bore and Stroke
Carburation
Unique Features
Additional Features
•Lightweight,OHVair-cooled229cc
engine is longitudinally mounted to
allow direct driveshaft alignment
to rear wheels for fewer frictional
losses.
•Frontandrearsuspension
has been upgraded for more
comfortable all-day riding.
•Automaticcam-chaintensioner
reduces maintenance.
•Maintenance-freeshaftdrive
routes power directly from the
longitudinally mounted engine
without inefficient directional
changes.
An oil cooler is standard equipment, ensuring
optimal engine temperatures under difficult
operating conditions.
Uniquely designed floorboards, which allow
the rider’s feet to grip the footrests while
keeping mud and debris away from the
rider’s feet.
•Convenientelectricstarterwith
auxiliary recoil starter.
•Five-speedtransmissionwith
reverse and automatic clutch.
•Lightweightdouble-cradle
steel chassis.
•Ergonomicallydesignedseating
and control layouts provide a
comfortable operating position for
a wide range of rider sizes.
•MeetsEPAandCARBemissions
levels.
•Largecargoracksfrontand
rear allow payloads of 15 and
30 kilograms, respectively.
•Large,lightweightplasticfueltank
with9litrecapacity.
20mm piston-valve
AC-CDI with electronic advance
Starter
Electric with auxiliary recoil
Clutch
Automatic / Centrifugal
Drive
TRX250TM features the high-performance
cylinder head from the TRX250eX for
increased performance.
68.5 x 62.2mm
Ignition
Transmission
*overseas model shown. *2013 FCAI Retail Report.
229cc air-cooled OHV longitudinally
mounted single-cylinder 4-stroke
5-speed with reverse
Direct rear enclosed driveshaft
Dimensions
1,905mm x 1,035mm x 1,070mm
(LxWxH)
Wheelbase
1,131mm
Seat Height
793mm
Ground Clearance
150mm
Turning Ratio
2.5m
Fuel Capacity
9.1 litre (including 2.6 litre reserve)
Front Tyre
22 x 7 -11 inch
Rear Tyre
22 x 10-9 inch
Front Suspension
Independent double-wishbone;
130mm of travel
Rear Suspension
Swingarm with single shock;
125mm of travel
Front Brake
Dual sealed hydraulic drum
Rear Brake
Sealed mechanical drum
Max Weight
Capacity
175kg
Kerb Weight
199kg
Warranty Period
36 months
hondamotorcycles.com.au | 15
CRF250L
SpeCIFICATIoNS
Engine Type
Honda’s CRF250L is a machine
that’s more than ready to
take on some serious off-road
challenges without giving
up street-riding
accommodations.
Bore and Stroke
Compression Ratio
Carburation
Additional Features
Compact and sophisticated liquid-cooled
DOHC249ccsingle-cylinderfour-stroke
powerplant produces smooth and consistent
torque at low rpm to aid off-road work,
yet the short-stroke engine also spins up
excellent high-rpm performance for the
street. The CRF250L pumps out a wellbalanced and very capable level of power,
along with excellent fuel economy.
•Wrappedinstylingthatpredicts
the look of the next-generation CRF
machines, the CRF250L boasts
slim yet tough characteristics
unique to Honda’s off-road bikes.
Incorporates advanced technologies inherited
from the high performing and best selling
CBR250R engine with CRF off-road race DNA.
The CRF250L offers the full package, whether
the day calls for low-cost transportation, a
weekday commute or genuine dual-sport
adventure.
Brand-new chassis developed specifically
for the CRF250L provides excellent stability
and agility.
16 | Honda ATV Range
•Designedwithuserfriendliness
in mind, the new CRF250L offers
specifications and equipment
such as a bright headlight, twin
trip meter, fuel gauge and a clock,
along with a range of optional parts
and accessories to cater for all
requirements.
•Extremelycompactrollerrocker
arm design for the low-friction
valve train allows the use of a
smaller cylinder head.
•Gear-drivencounterbalancer
shaft helps quell vibrations for
rider comfort and a strong 43mm
inverted fork provides 222mm of
travel.
•Pro-Linksingle-shockrear
suspension delivers 240mm of
rear-wheel travel while front and
rear disc brakes for strong and
consistent stopping power.
•TheCRF250LisLAMSapproved.
10.7:1
PGM-FI electronic fuel injection
CDI with electronic advance
Starter
Electric
Drive
Unique Features
76 x 55mm
Ignition
Transmission
*overseas model shown.
249.6cc liquid-cooled 4-stroke DOHC
4-valve single cylinder
6-speed constant mesh transmission
Chain
Dimensions
2,195mm x 815mm x 1,195mm
(LxWxH)
Wheelbase
1,445mm
Seat Height
875mm
Ground Clearance
255mm
Fuel Capacity
7.7 litres
Front Tyre
3.00 x 21 inch
Rear Tyre
120/80 x 18 inch
Front Suspension
43mm inverted fork, 222mm travel
Rear Suspension
Pro-link single shock, 240mm travel
Front Brake
Hydraulic disc
Rear Brake
Hydraulic disc
Kerb Weight
Warranty Period
143kg
12 months
CRF230F
SpeCIFICATIoNS
Engine Type
With quality in every bolt,
Honda’s CRF230F is the ideal
machine for recreational riders
discovering the exciting world
of off-road riding
Bore and Stroke
Compression Ratio
Carburation
Unique Features
Additional Features
•TheCRF230F’slightweighthightensile steel frame wrapped in CRF
Honda Racing-inspired bodywork,
translates to hard edged looks – an
important factor for those who like
to be the leader of the pack.
The convenience of electric start, plus
a smooth shifting 6-speed gearbox, an
easy-to-use heavy duty clutch and a 28mm
carburetor offering superb throttle response
mean the CRF230F is a bike built for fun.
•Abox-sectionaluminium
swingarm, and pro-Link rear
suspension assist to offer sure and
easy handling. 37mm leading-axle
Showa front fork offers 216mm of
suspension travel and heavy-duty
Showa rear shock offers 230mm
of travel.
•Motocross-styleseatislowand
comfortable, and allows maximum
rider movement.
Fork boots keep dirt and moisture
away from fork seals.
9.0:1
28mm piston-valve
CDI
Starter
Electric
Transmission
6-speed
#520 O-ring-sealed chain
Dimensions
2,059mm x 812mm x 1,190mm
(LxWxH)
Wheelbase
1,372mm
Rake (Caster Angle)
26°45’
Trail
111mm
Seat Height
872mm
Ground Clearance
305mm
Fuel Capacity
The popular CRF230F features an ever
faithful 223cc air-cooled 4-stroke singlecylinder engine that delivers smooth, even
power and torque across a wide rpm range
making it the perfect enduro for teens and
the young at heart. The rider focused features
don’t stop there.
65.5 x 66.2mm
Ignition
Drive
*overseas model shown.
223cc air-cooled, single cylinder
4-stroke, SOHC ; 2-valve
8.2 litres (including 1.5 litre reserve)
Front Tyre
80/100 - 21 inch
Rear Tyre
100/100 - 18 inch
•Snail-typechainadjustersforeasy
maintenance.
Front Suspension
37mm leading axle Showa fork;
216mm travel
•Large8.2litreplasticfueltankand
thrifty four-stroke engine for long
range.
Rear Suspension
Pro-Link Showa single shock with
spring pre-load adjustability; 230mm
of travel
•High-impactplasticskid-plate
protects lower engine cases.
Front Brake
240mm hydraulic disc with dualpiston calliper and sintered metal
pads.
Rear Brake
110mm leading drum
•Easilydetachablenumberplate.
Kerb Weight
Warranty Period
113.8kg
6 months
•Powerful240mmfrontdiscbrake
and lightweight rear drum brake.
hondamotorcycles.com.au | 17
CTX200/A
SpeCIFICATIoNS
Engine Type
The CTX200/A is one tough
little nugget from Honda
that delivers on all the
points that count. With
top marks for reliability,
quality, durability, comfort
and economy – it’s no
wonder this bike has a
mighty reputation with
farmers right across the
nation
Bore and Stroke
Carburation
Starter
Electric with kick start back up
Additional Features
•Excellentbrakingfromfront
hydraulic disc brake with twinpiston calliper and rear mechanical
drum brake.
5-speed transmission.
Sealed long-life o-ring drive chain.
Carby-mounted choke, back-up kick start and
electric starter with CDI ignition.
Dismount while still in gear thanks to the
manual clutch with handlebar mounted lock.
Controlled suspension action and improved
handling thanks to the large diameter front
forks with long 158mm travel.
18 | Honda ATV Range
•Enjoyhoursofcomfortablesaddle
time with the wide, thickly padded
seat.
•“Bigfoot”standsonbothsides.
•Heavy-dutyfront/rearcarryracks.
•Nowcomeswithoptionalall
road-legal equipment (mirrors,
indicators etc) so it can be
registered and legally used on all
Australian roads.
5-speed, constant mesh
Chain
Dimensions
2,196mm x 938mm x 1,152mm
(LxWxH)
Wheelbase
1,363mm
Seat Height
823mm
Ground Clearance
238mm
Fuel Capacity
Dependable197ccair-cooled4-stroke
2-valve single cylinder engine.
Kehin 22mm round slide type
AC-CDI
Drive
Unique Features
63.5 x 62.2mm
Ignition
Transmission
*overseas model shown.
197cc single-cylinder air-cooled OHC
2-valve 4-stroke
8.5 litres (including 1.8 litre reserve)
Front Tyre
80/100-21 inch
Rear Tyre
100/100 - 18inch
Front Suspension
37mm telescopic fork; 158mm of
travel
Rear Suspension
Pro-Link single shock; 150mm of
travel
Front Brake
240mm single hydraulic disc,
2-piston calliper
Rear Brake
Mechanical drum
Kerb Weight
Warranty Period
135.8kg
12 months
XR150L
SpeCIFICATIoNS
Engine Type
Looking for a rugged and reliable
two-wheeled farm machine?
Look no further than Honda’s
newly announced XR150L.
Bore and Stroke
Compression ratio
Carburation
Starter
Transmission
Unique Features
Additional Features
The new Honda XR150L will replace the
XR125L, and takes its best features with
updates to create a package that combines
rugged durability with low operating costs.
•TheXR150L’shighperformance
150cc engine has features
reducing friction, improving fuel
efficiency and cooling performance.
The XR150L is durable, reliable and safe
with comfortable suspension and a high
performance 150cc engine. It is an essential
piece of equipment for any farm.
•There’salsoanewinternalengine
balancer which reduces vibration
and will result in greater rider
comfort during a hard day’s work
on the farm.
•All-dayridercomfortwillbe
ensured by the redesigned seat
and rubber covers on the footpegs,
which can be removed for safe,
9.5:1
20mm piston-valve
Electric and backup kick starter
5 Speed
2,090mm x 811mm x 1,125mm
(LxWxH)
Wheelbase
1,362mm
Seat Height
825mm
Ground Clearance
243mm
12 Litres
Front Tyre
70/100-19 inch
Rear Tyre
110/90-17 inch
Front Suspension
Telescopic Fork / 160mm travel
Rear Suspension
Single Shock / 152mm travel
Kerb Weight
non-slip riding when the terrain
gets tough.
57.3mm x 57.8mm
Dimensions
Fuel Capacity
*overseas
verseas model shown.
149cc 4-stroke, single-cylinder,
air-cooled, OHV
Warranty Period
129kg
12 months
•Freshstylingincludesanew
headlight design with protective
shield; a new, higher front fender;
a narrower and more comfortable
fuel tank that has the same 12 litre
capacity as the XR125.
•Withalargeraircleaneranda
sealed, maintenance-free battery,
the XR150L requires less attention,
with enhanced reliability and
safety.
hondamotorcycles.com.au | 19
TRX450ER
SpeCIFICATIoNS
Engine Type
Honda’s race-ready TRX450ER
- has won in virtually every
ATV racing discipline.
Bore and Stroke
Carburation
In Australia, the bike has well and truly
stamped its authority on the competition after
being piloted to victory in the Finke Desert
Race.
powerful 4-stroke 450cc liquid-cooled fourvalve Unicam engine is based on the awardwinning CRF450R motocross and CRF450X
off-road engines.
Additional Features
40mm Keihin FCR-type carburetor features
four rollers on the flat slide, resulting in very
light throttle effort and smooth operation.
•Throttle
hrottleleverandcarburetor
lever and carburetor
feature full-closed detection
system.
Vertically split crankcases feature a built-in
oil pump, reducing weight compared to a
conventional design.
•Largeairfilterallowsmaximum
airflow for maximum engine power.
•Convenientoil-levelwindowallows
for at-a-glance oil check.
•Enginecasesprotectedbyhighimpact plastic skid-plate.
Lightweight aluminium wheels reduce
unsprung weight for outstanding handling.
access to the air filter.
•Long,narrowseatisdesignedfor
superior comfort. Saddle is also
easy to remove for convenient
Keihin 40mm flat side with Throttle
Position Sensor (TPS)
CD with electronic advance
Starter
Electric
Clutch
Wet multi-plate
Drive
Unique Features
96 x 62mm
Ignition
Transmission
*overseas model shown.
450cc liquid-cooled single-cylinder
4-stroke
5-speed
O-ring-sealed chain
Dimensions
1,862mm x 1,177mm x 1,100mm
(LxWxH)
Wheelbase
1,275mm
Seat Height
833mm
Ground Clearance
111mm
Fuel Capacity
10.3 litre (including 3 litre reserve)
Front Tyre
21 x 7R-10 knobby radial
Rear Tyre
20 x 10-9 knobby radial
Front Suspension
Independent double-wishbone;
with Showa shocks, featuring
adjustable spring pre-load, rebound
and compression damping; 215mm
travel
Rear Suspension
Pro-Link with single Showa shock
featuring adjustable spring pre-load,
rebound and compression damping;
237mm travel
Lightweight, compact, internal auto
decompressor provides superb cold-starting
and hot-starting operation.
Front Brake
Cylinder-head cover is made of magnesium
to reduce engine weight.
Dual hydraulic 174mm discs with
twin-piston callipers
Rear Brake
Single hydraulic 190mm disc with
single piston calliper
press-fitted steel spark-plug pipe fits
between forked exhaust rocker arms, further
contributing to compact cylinder-head design.
Kerb Weight
Long, narrow seat is designed for superior comfort.
20 | Honda ATV Range
Independent, double-wishbone, front suspension
with fully adjustable Showa shocks.
Warranty Period
176kg
12 months
TRX250X
SpeCIFICATIoNS
Engine Type
Honda’s sporty, fun-to-ride
TRX250X offers TRX450ER
race-inspired styling, front
and rear suspension built to
take on anything the track can
throw at it, as well as Honda’s
revolutionary innovation – the
SportClutch
Bore and Stroke
Carburation
*overseas model shown.
229CC air-cooled OHV longitudinally
mounted single-cylinder 4-stroke
68.5 x 62.2mm
20mm piston-valve
Ignition
CD with electronic advance
Starter
Electric with Auxiliary Recoil
Clutch
Honda SportClutch
Transmission
5-speed with reverse
Drive
Direct rear driveshaft
Dimensions
1739mm x 1,062mm x 1,082mm
(LxWxH)
Wheelbase
1124mm
Seat Height
797mm
Ground Clearance
146mm
Turning Ratio
2.8m
Fuel Capacity
9.5 litres (including 2.6 litre reserve)
Front Tyre
22 x 7-10 knobby radial
22 x 10-9 knobby radial
Unique Features
Additional Features
Rear Tyre
TRX450eR-inspired bodywork.
•Closedcrankcaseventsystem.
Hand-operated Honda SportClutch that
enables the rider to experience manual clutch
actuation with the advantage of no stalling.
•Automaticcam-chaintensioner.
Front Suspension
Independent double-wishbone;
150mm of travel
Rear Suspension
Swingarm with single shock;
145mm of travel
LightweightOHVair-cooled229ccengineis
longitudinally mounted to allow direct driveshaft alignment to rear wheels.
•Electricstarter.
•Maintenance-freedriveshaft.
•Large,lightweightplasticfueltank
with9.5litrecapacity.
•Snorkel-typeairintakesystem.
•Maintenance-freebattery.
•Reusable,washablefoam
air filter.
ergonomic seat is designed for recreational riding,
providing superb comfort and excellent rider
manoeuvrability.
LightweightOHVair-cooled229ccengine.
Front Brake
Dual hydraulic 174mm discs
Rear Brake
Sealed mechanical drum
Kerb Weight
Warranty Period
171kg
12 months
•Standardtoolkitincludes
a tyre pressure gauge.
hondamotorcycles.com.au | 21
TRX90X
SpeCIFICATIoNS
Engine Type
With TRX450ER-inspired
styling, an electric starter, a
refined suspension system
and a bulletproof 86cc SOHC
4-stroke engine, the TRX90EX
is a great place for young
riders to start.
Bore and Stroke
Carburation
Additional Features
Honda’s 86cc SoHC 4-stroke engine offers
smooth power delivery and legendary
reliability.
•Maintenance-freebattery.
Convenient electric starter for ease of starting
in all conditions.
Maintenance-free CD ignition system never
needs attention.
Honda’s durable automatic clutch makes
takeoffs and shifting a breeze.
Independent front suspension features a pair
of rugged shock absorbers.
Versatile 4-speed transmission.
Uniquely designed centre mud guards keep
mud and debris away from the rider’s feet.
22 | Honda ATV Range
•Reusable,washablefoamairfilter.
•Keyedignitionswitchforadded
security.
Starter
Electric
Clutch
Automatic
•DurableO-ringchaindrivesystem.
•Standardparkingbrake.
Comfortable handlebar grips and levers.
Uniquely designed centre mud guards. Keep mud
and debris away from the rider’s feet.
4-speed
O-ring-sealed chain
Dimensions
1,489mm x 895mm x 928mm
(LxWxH)
Wheelbase
983mm
Seat Height
660mm
Ground Clearance
100mm
Turning Ratio
2.5m
Fuel Capacity
6.3 litres (including 1 litre reserve)
Front Tyre
20 x 7-8
Rear Tyre
19 x 8-8
Front Suspension
Independent double-wishbone;
65mm of travel
Rear Suspension
Swingarm with single shock;
65mm of travel
•Adjustablethrottlelimiter.
•Comfortablehandlebargripsand
levers.
16mm piston-valve
CDI
Drive
Unique Features
47 x 49.5mm
Ignition
Transmission
*overseas model shown.
86cc air-cooled SOHC single-cylinder
4-stroke
Front Brake
Dual sealed drum
Rear Brake
Sealed drum
Kerb Weight
Warranty Period
119kg
12 months
hondamotorcycles.com.au | 23
Your purchase of a Honda motorcycle
guarantees you servicing and
comprehensive parts backup from
one of the biggest motorcycle dealer
networks in Australia. And with a
range of flexible finance packages
available, Honda Mpe Financial
Services can help you own the Honda
motorcycle of your dreams sooner.
engineered for your Honda. only
one brand of oils and chemicals
guarantees performance in
Honda engines. Starting with the
development by R&D in Japan
nobody else crafts these products
to the industry’s most demanding
standards… Honda quality!
Renowned for quality and reliability,
Honda Genuine parts are made to
ensure optimum performance on all
levels. By insisting on Honda Genuine
parts you’re guaranteed the best
parts money can buy. Don’t settle for
anything else, always demand Honda
Genuine parts.
At Honda, our goal is to create the
best motorcycles in the world and
is matched by an equally strong
commitment to responsible and safe
riding. Remember, always wear a
helmet, eye protection and protective
clothing when you ride. Always
obey the road laws and always use
common sense. Never ride under
the influence of alcohol or drugs and
never use the street as a racetrack.
Respect your own limitations.
Respect the rights of others on
the road. And respect the overall
motorcycling experience, there’s
nothing else like it!
Honda Motorcycles are all about
freedom, performance, adventure
and superior quality. When it comes
to making sure you can enjoy your
new Honda you can rely on the
Honda Australia extended Warranty
and Honda Insurances to provide
you with the peace of mind that your
riding pleasure and security will
be maintained. For full terms and
conditions, please see your local
Dealer.
Honda recommends that all riders
take a training course and read
their owner’s manual thoroughly.
For safety or training information,
call your local Honda Australia Rider
Training centre: Melbourne (03)
92701377,Sydney(02)91445725,
Brisbane (07) 3341 5657. Website:
hart.honda.com.au
HMC21059
In the interests of product development, Honda reserves the right to alter specifications and features without notice. Availability of stock depicted
in this brochure and colours may vary from time to time. For complete details see your local Honda Motorcycle Dealer. Colours, specifications and
modelavailabilityasat19/06/2014.HondaRentispoweredbyBOQCreditPtyLtdABN92080151266(tradingasHondaMPEFinancialServices)in
conjunctionwithHondaAustraliaMotorcyclesandPowerEquipmentPtyLtdABN96006662862(tradingasHondaMPE).HondaRentisavailableto
approved personal customers. Credit fees and charges may apply. Terms and conditions apply.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
