Introduction

This INSTEON Hub Developer’s Guide is for users of INSTEON Modem chips, such as the IN2680A

Powerline Modem Interface or the IN2682A RF Modem Interface, and also for purchasers of the

INSTEON PowerLinc™ Modem (PLM) module.

The information in this document is excepted from the INSTEON Developer’s Guide

2

, which purchasers of an INSTEON Software Development Kit may download from http://code.insteon.com

.

The INSTEON Hub

The INSTEON Hub is an INSTEON-to-Ethernet Bridge module that plugs into a power outlet and also has a ethernet port that you connect to your network. It uses an IN2680A Powerline Modem chip that offers a simple set of ASCII IM Serial Commands

12

for interacting with INSTEON devices.

The Hub uses a daughter board to implement serial communications with the host. Daughter boards interface to the PLM’s main board via an 8-pin connector using TTL-level serial communications.

Page 1 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

Other Documents Included by Reference

This INSTEON Hub Developer’s Guide contains information abstracted from the comprehensive

INSTEON Developer’s Guide, 2 nd

Edition.

Although the full INSTEON Developer’s Guide is largely self-contained, there are aspects of INSTEON technology, such as listings of INSTEON Commands, INSTEON Device Categories, and INSTEON

Product Keys, that require continuous updating as developers create new INSTEON products.

Accordingly, SmartLabs maintains separate documents for that kind of information.

All of the documents listed in this section are available for downloading at http://code.insteon.com

.

INSTEON Developer’s Guide

The book-length INSTEON Developer’s Guide, 2

nd

Edition is the primary source for the information contained in this (much shorter) INSTEON Hub Developer’s Guide. Some links in this document refer to information found there. Developers who purchase an INSTEON Software Developer’s Kit may download the INSTEON Developer’s Guide from http://code.insteon.com

.

INSTEON Conformance Specification

The INSTEON Conformance Specification identifies those aspects of INSTEON that assure interoperability with other INSTEON products. The Conformance Spec assumes that readers have already gained familiarity with INSTEON technology by reading the INSTEON Developer’s Guide.

INSTEON Command Tables Document

The current tables of INSTEON Commands are contained in a separate document titled INSTEON

Command Tables, which is integral to both the INSTEON Conformance Specification and the INSTEON

Developer’s Guide.

The filename for that document is INSTEON Command Tables yyyymmddx.doc, where yyyy is the year,

mm is the month, dd is the day, and x is a daily version letter beginning with a. Be sure to refer to the document with the latest date.

INSTEON Device Categories and Product Keys Document

The current table of INSTEON Device Categories (DevCats), Subcategories (SubCats), and INSTEON

Product Keys (IPKs) is contained in a separate document titled INSTEON Device Categories and Product

Keys, which is also integral to both the INSTEON Conformance Specification and the INSTEON

Developer’s Guide.

The filename for that document is INSTEON DevCats and Product Keys yyyymmddx.doc, where yyyy is the year, mm is the month, dd is the day, and x is a daily version letter beginning with a. Be sure to refer to the document with the latest date.

Page 2 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

INSTEON Modem Reference

Software Reference

INSTEON Modem (IM) chips and the SmartLabs Hub offer developers a simple, robust interface to an

INSTEON network.

INSTEON Hubs provide a simpler interface to many of the low-level IBIOS Serial Commands implemented in the SmartLabs Hub described in the INSTEON Developer’s Guide

2

, but they also handle

ALL-Linking, ALL-Link Database management, ALL-Link Cleanup messages, X10 powerline interfacing, and message acknowledgement. The RS232 serial interface to the host is similar to that of the PLC.

In This Section

Page 3 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

IM Serial Communication Protocol and Settings

5

Describes the serial communication protocol

IM Power-up and Reset States

11

Explains what happens when you power up the IM or reset it.

IM Serial Commands

12

Lists the IM Serial Commands and describes what they do, in a single table and individual charts grouped by functionality.

Page 4 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

IM Serial Communication Protocol and Settings

In This Section

IM Serial Communication Protocol

6

Gives the protocol for communicating serially with an INSTEON Modem.

Page 5 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

IM Serial Communication Protocol

All INSTEON Modem (IM) Serial Commands start with ASCII 0x02 (STX, Start-of-Text) followed by the

Serial Command Number (see IM Serial Commands

12

). What data follows the Command depends on the

Command syntax (see IM Serial Command Summary Table

13

and IM Serial Command Charts

18

).

When you send a message to the IM, it will respond with an echo of the 0x02 and the IM Command

Number followed by any data that the Command returns (often just an echo of what you sent to it). The last byte it sends back will be ASCII 0x06 (ACK, Acknowledge).

(S: and R: denote serial data you Send to or Receive from the IM, respectively.)

S:

0x02 <Command Number> <parameters>

R:

0x02 <Command Number> <any returned data> 0x06 (ACK)

If the IM is not ready, it will respond with an echo of the 0x02 and the IM Command Number followed by

ASCII 0x15 (NAK, Negative Acknowledge).

S:

0x02 <Command Number> <parameters>

R:

0x15 (NAK)

If you receive 0x15 (NAK), resend your Serial Command.

INSTEON HUB communication syntax and examples

Insteon Commands

(Commands to send (through the HUB and PLM) to other Insteon devices)

Control Commands

Cmd1

0x11 On

0x12 Fast On

0x13 Off

0x14 Fast Off

0x15 Bright

0x16 Dim

0x17 Start Dim/Brt

0x18 Stop Dim/Brt

Query Commands

0x10 ID Request

0x19 Status Request

Cmd2

Group number or On level

Group number or Ignored

Group number or Ignored

Group number or Ignored

Group number or Ignored

Group number or Ignored

01 = bright 00 = dim

Ignored

Ignored

Ignored

Page 6 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

Command Syntax

<ip address>/X?YYYYY=I=X

Where X is a number. All the examples show either a 0 (zero) or a 1 (one). The YYYY is the command bytes. The suffix is always this:

=

I (letter I)

=

Number

0 (zero): means a “short form” command that doesn’t include a destination and flags byte,

3: the full Insteon command as you would send to the Insteon modem.

For a group: http://172.16.1.34/0?1101=I=0 where 0x11 is the command and 01 is the group. (URL is an example of intranet)

For a group: http://bobbieshome.myhouse:8000/0?13182=I=0 where 0x13 is the command and 182 is the group. (URL is an example of internet using getmyip.com to track Dynamic DNS for the hub) (Note the interesting combination of Hex and decimal numbers i.e. 13 182)

For a device: http://172.16.1.34/3?02620102030F117F=I=3 where 010203 is the device ID and 0F is the flags byte and 0x11 is the command and 7F is the on level (1/2 brightness).

Insteon Commands to send to the Hub for the PLM

0x09 Enter Linking mode

0x0A Enter UnLinking

0x08 Cancels Un/Linking

Group Number

Group Number

Ignored http://172.16.1.34/0?0901=I=0 where 0x09 is the command and 01 is the group. http://172.16.1.34/0?0A239=I=0 where 0x0A is the command and 239 is the group. http://172.16.1.34/0?08=I=0 where 0x08 is the command.

Hub Commands

http://172.16.1.34/1?XB=M=1 Clear Insteon buffer

Commands that will be in the INSTEON Buffer

The INSTEON buffer can be read from “/buffstatus.xml” and can hold up to 100 characters or 50 hex bytes. http://172.16.1.34/buffstatus.xml

Page 7 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

Group Commands

026101110106

026101110115

Echo of your Command: Turn group 1 On

Response if you tried to turn on an empty group

025009316B09D682611101 Ack from a device (Clean-up)

09316B

09D682

61 Flags byte

ID of a device in your group

ID of the Hub

20 = Ack + 40 = Group + 1 = Hop count

025806

025815

Group command completed

Group command quit early

Ok

Ok

Individual Device Control Commands (Point to Point)

Example of turning on device 0E7986 to Full On

Send: http://172.16.1.34/3?02620E79860F11FF=I=3

The Buffer will have

02620E79860F11FF0602500E798609D6822B11FF

Send and PLM Echoes back to the buffer:

0262 Pass through Command to PLM

0E7986 Device ID to Control

0F

11

FF

PLM Adds:

06

Flags Byte (Constant)

CMD1 (On)

CMD2 (Brightness level)

PLM Says got it

Once the Device responds (Could be ¼ of a second but not>3 secs)

0250 From PLM Insteon Received

0E7986

09D682

From this device

To (ID of PLM/Hub)

2B

11

FF

20 = ACK + B = hop count

CMD1 The command the device received

Cmd2 The On level it will go to

Note: The timing will be such that even if you see the 0250 in the buffer you are not guaranteed that the rest of the data is in the buffer yet.

Pretend example of a timing issue to resolve.

2:01.1 buffer has Null (just emptied it)

2:02.2 send http://172.16.1.34/3?02620102030F117F=I=3

2:03.0 ask for the buffer

2:03.5 get 02620E79860F11FF0602500E7

2:03.7 ask for the buffer again

2:03.9 get 02620E79860F11FF0602500E798609D6822B11FF

In a group command, the buffer will quickly wrap with the clean-ups so searching for the 0258 is a little tricky since that is also a valid Partial Insteon ID.

Linking Example:

Page 8 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

Send go into Linking mode group 137. http://172.16.1.34/0?09137=I=0

The PLM echoes and adds an 06

0264018906 (0264 linking command 01 controller and group 0x89)

Press and hold the button on the new device

02640101060253010108B6EA010195

0264010106

0253

01

Left in the buffer from go into linking mode

Linking completed

Device can be a controller (00 and FF are valid)

01

08B6EA

01

01

95

Group

ID of device

Device Category (01 = Dimmer)

Device SubCat (01 = SwitchLinc)

Firmware Version of New device

Page 9 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

ID Request Example:

http://172.16.1.34/3?02620E79860F1000=I=3

The buffer will have

02620E79860F10000602500E798609D6822B100002500E798601009C8B0100

0262 Pass through Command to PLM

0E7986

0F

10

00

06

0250

0E7986

09D682

2B

Insteon ID

Flags

CMD1

CMD2

Insteon Message

From

To

Flags Byte 20 = ACK + B = Hop count

10

00

0250

0E7986

01

00

9C

8B

01

00

Echo CMD1

Echo CMD2

Insteon Message (about 1 sec later)

From

Cat

(SubCat)

(01 = Dimmer)

(00 = LampLinc)

Firmware version

Flags Byte 80 = Broadcast + B = hop count

CMD1

CMD2

01 = ID Request

00 = Ignore

Status Request Example:

http://172.16.1.34/3?02620E79860F1900=I=3

The buffer will have

02620E79860F19000602500E798609D6822B03FF

0262

0E7986

0F

19

Pass Through

ID

Flags

CMD1 Status Request

CMD2 00

06

0250

0E7986

09D682

2B

03

FF

Insteon Received

From

To

20 = ACK + B = Hop Count

03 is the Delta…gets changed every time EE is changed (Ignore)

Current On Level could be 00 – FF

Note: Status Request returns Info in the ACK while ID request generates

Page 10 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

IM Power-up and Reset States

This section describes the IM Power-up Behavior

11

and the IM Factory Reset State

11

.

IM Power-up Behavior

The table below shows the state of the IM when it powers up. Holding down the SET Button while powering up will cause a factory reset.

LED Indication

LED on steadily

Meaning

The IM detected an external EEPROM (up to 32 Kb) for storage of database links. Effective with product revisions 2.75 or greater, a 128Kb EEPROM is included for storage of database links

LED blinks six times The IM did not detect an external EEPROM, so it will use the internal

EEPROM in the processor chip. A maximum of 31 ALL-Links are permitted.

An attempt to add a 32 nd

ALL-Link will result in the 31 st

being erased.

LED off The user pressed and held the IM’s SET button for 10 seconds while powering up, causing the IM to perform a factory reset and go into the IM Factory Reset

State

11

. At the conclusion of the reset, the IM’s LED will give one of the two indications above. You will also receive a User Reset Detected

44

message from the IM.

IM Factory Reset State

Resetting the IM to its factory default condition by holding down the SET Button for ten seconds while powering it up or by sending it a Reset the IM

43

Command puts it into the following state:

IM Resource Factory Reset State

ALL-Link Database Erased (set to all zeros).

Host Device

Category, Device

Subcategory,

Firmware Version

Set to the original DevCat (0x03), SubCat (0x05), and firmware version hardcoded into the IM’s firmware at the factory.

Cleared (set to all zeros). IM Configuration

Flags

Page 11 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

IM Serial Commands

The IM Serial Command set is a simple but complete interface between a host application and an

INSTEON network. For example, a microcontroller in a thermostat could use an INSTEON Powerline

Modem chip to send and receive messages to other INSTEON or X10 devices on the home’s powerline.

In this section, the IM Serial Commands are presented twice, once as a summary table, and again as a series of charts grouped by functionality.

In This Section

IM Serial Command Summary Table

13

Describes all of the IM Serial Commands in table form ordered by Command Number.

IM Serial Command Charts

18

Describes all of the IM Serial Commands using individual charts for each Command, grouped by functionality.

Page 12 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

IM Serial Command Summary Table

This table lists all of the Modem Serial Commands supported by INSTEON powerline or RF modem chips.

Code

Gives the hexadecimal number of the IM Serial Command. Note that IM Commands sent by an IM to the host begin at 0x50 and IM Commands sent by the host to an IM begin at 0x60.

Command

Gives the name of the IM Serial Command as a link to the complete explanation of the Command in the IM Serial Command Charts

18

.

Format

Gives the syntax of the IM Serial Command, including any parameters.

S: and R: denote serial data you Send to or Receive from the IM, respectively. See IM Serial

Communication Protocol

6

for more information.

All IM Serial Commands start with ASCII 0x02 (STX, Start-of-Text) followed by the Serial Command

Number.

All fields in this table contain only one byte, except as noted.

INSTEON Modem Serial Commands

Commands Sent from an IM to the Host

Code Command

0x50

INSTEON Standard Message

Received

22

0x51

INSTEON Extended

Message Received

23

0x52

X10 Received

28

0x53

0x54

0x55

ALL-Linking Completed

Button Event Report

User Reset Detected

51

44

35

Format

R: 0x02 0x50

<INSTEON Standard message (9 bytes)>

R: 0x02 0x51

<INSTEON Extended message (23 bytes)>

R: 0x02 0x52

<Raw X10> <X10 Flag>

R: 0x02 0x53

<0x00 (IM is Responder) | 0x01 (IM is Controller | 0xFF Link Deleted)>

<ALL-Link Group>

<ID high byte> <ID middle byte> <ID low byte>

<Device Category> <Device Subcategory> <0xFF | Firmware Revision>

R: 0x02 0x54 <0x02>

IM’s SET Button tapped

R: 0x02 0x54 <0x03>

IM’s SET Button held

R: 0x02 0x54 <0x04>

IM’s SET Button released after hold

R: 0x02 0x54 <0x12>

IM’s Button 2 tapped

R: 0x02 0x54 <0x13>

IM’s Button 2 held

R: 0x02 0x54 <0x14>

IM’s Button 2 released after hold

R: 0x02 0x54 <0x22>

IM’s Button 3 tapped

R: 0x02 0x54 <0x23>

IM’s Button 3 held

R: 0x02 0x54 <0x24>

IM’s Button 3 released after hold

R: 0x02 0x55

User pushed and held IM’s SET Button on power up

Page 13 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

0x56

ALL-Link Cleanup Failure

Report

31

R: 0x02 0x56 <0x01>

<ALL-Link Group>

<ID high byte> <ID middle byte> <ID low byte>

0x57

ALL-Link Record Response

39

R: 0x02 0x57

<ALL-Link Record Flags>

<ALL-Link Group>

<ID high byte> <ID middle byte> <ID low byte>

<Link Data 1> <Link Data 2> <Link Data 3>

0x58

ALL-Link Cleanup Status

Report

32

R: 0x02 0x58 <0x06>

ALL-Link Cleanup sequence completed

R: 0x02 0x58 <0x15>

ALL-Link Cleanup sequence aborted due to INSTEON traffic

0x59

Database Record Found

32

R: 0x02 0x59 <Database Address high byte>

<Database Address low byte (low nibble should be 0xF | 0x8)>

<ALL-Link Record Flags>

<ALL-Link Group>

<ID high byte> <ID middle byte> <ID low byte>

<Link Data 1> <Link Data 2> <Link Data 3>

Commands Sent from the Host to an IM

0x60

Get IM Info

48

0x61

Send ALL-Link Command

29

0x62

Send INSTEON Standard or

Extended Message

19

0x63

Send X10

27

0x64

Start ALL-Linking

33

0x65

Cancel ALL-Linking

34

0x66

Set Host Device Category

49

S: 0x02 0x60

R: 0x02 0x60

<ID high byte> <ID middle byte> <ID low byte>

<Device Category> <Device Subcategory> <Firmware Revision>

<0x06>

S: 0x02 0x61

<ALL-Link Group>

<ALL-Link Command>

<0xFF | 0x00>

R: 0x02 0x61

<ALL-Link Group>

<ALL-Link Command>

<0xFF | 0x00>

<0x06>

S: 0x02 0x62

<INSTEON Standard message (6 bytes, excludes From Address) |

INSTEON Extended message (20 bytes, excludes From Address)>

R: 0x02 0x62

<INSTEON Standard message (6 bytes, excludes From Address) |

INSTEON Extended message (20 bytes, excludes From Address)>

<0x06>

S: 0x02 0x63

<Raw X10> <X10 Flag>

R: 0x02 0x63

<Raw X10> <X10 Flag>

<0x06>

S: 0x02 0x64

<0x00 (IM is Responder) | 0x01 (IM is Controller) |

0x03 (IM is either) | 0xFF (Link Deleted)

bit2 set = use Set Database Link Data for next Link>

<ALL-Link Group>

R: 0x02 0x64

<0x00 (IM is Responder) | 0x01 (IM is Controller) |

0x03 (IM is either) | 0xFF (Link Deleted)>

<ALL-Link Group>

<0x06>

S: 0x02 0x65

R: 0x02 0x65

<0x06>

S: 0x02 0x66

<Device Category> <Device Subcategory> <0x00 | Firmware Revision>

Page 14 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

0x67

Reset the IM

43

0x68

Set INSTEON ACK Message

Byte

24

0x69

0x6A

0x6B

0x6C

0x6D

0x6E

0x6F

0x72

0x73

Get First ALL-Link Record

Get Next ALL-Link Record

Set IM Configuration

46

Get ALL-Link Record for

Sender

38

LED On

LED Off

52

53

RF Sleep

50

Get IM Configuration

45

Manage ALL-Link Record

36

37

40

0x70

Set INSTEON NAK Message

Byte

26

0x71

Set INSTEON ACK Message

Two Bytes

25

R: 0x02 0x66

<Device Category> <Device Subcategory> <0x00 | Firmware Revision>

<0x06>

S: 0x02 0x67

R: 0x02 0x67

<0x06>

S: 0x02 0x68

<Command 2 Data>

R: 0x02 0x68

<Command 2 Data>

<0x06>

S: 0x02 0x69

R: 0x02 0x69

<0x06>

S: 0x02 0x6A

R: 0x02 0x6A

<0x06>

S: 0x02 0x6B

<IM Configuration Flags>

R: 0x02 0x6B

<IM Configuration Flags>

<0x06>

S: 0x02 0x6C

R: 0x02 0x6C

<0x06>

S: 0x02 0x6D

R: 0x02 0x6D

<0x06>

S: 0x02 0x6E

R: 0x02 0x6E

<0x06>

S: 0x02 0x6F

<Control Flags>

<ALL-Link Record Flags>

<ALL-Link Group>

<ID high byte> <ID middle byte> <ID low byte>

<Link Data 1> <Link Data 2> <Link Data 3>

R: 0x02 0x6F

<Control Flags>

<ALL-Link Record Flags>

<ALL-Link Group>

<ID high byte> <ID middle byte> <ID low byte>

<Link Data 1> <Link Data 2> <Link Data 3>

<0x06>

S: 0x02 0x70

<Command 2 Data>

R: 0x02 0x70

<Command 2 Data>

<0x06>

S: 0x02 0x71

<Command 1 Data>

<Command 2 Data>

R: 0x02 0x71

<Command 1 Data>

<Command 2 Data>

<0x06>

S: 0x02 0x72

R: 0x02 0x72

<0x06>

S: 0x02 0x73

Page 15 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

R: 0x02 0x73

<IM Configuration Flags>

<Spare 1>

<Spare 2>

<0x06>

Page 16 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

These commands added after initial release:

INSTEON Modem Serial Commands

Code Command

0x74

Cancel Cleanup

22

0x75

0x76

0x77

0x78

Read 8 bytes from

Database

23

Beep

35

Set Status

51

Commands Sent from the Host to an IM

Write 8 bytes to Database

28

Format

S: 0x02 0x74

R: 0x02 0x74

<0x06>

S: 0x02 0x75 <Database Address high byte>

<Database Address low byte (low nibble should be 0xF | 0x8)>

R: 0x02 0x75 <Database Address high byte>

<Database Address low byte (low nibble should be 0xF | 0x8)>

<0x06>

<Database Record Found Response (12 bytes)>

S: 0x02 0x76 <Database Address high byte>

<Database Address low byte (low nibble should be 0xF | 0x8)>

<ALL-Link Record Flags>

<ALL-Link Group>

<ID high byte> <ID middle byte> <ID low byte>

<Link Data 1> <Link Data 2> <Link Data 3>

R: 0x02 0x76 <Database Address high byte>

<Database Address low byte (low nibble should be 0xF | 0x8)>

<ALL-Link Record Flags>

<ALL-Link Group>

<ID high byte> <ID middle byte> <ID low byte>

<Link Data 1> <Link Data 2> <Link Data 3> <0x06>

S: 0x02 0x77

R: 0x02 0x77 <0x06>

IM will beep

S: 0x02 0x78 <Status>

R: 0x02 0x78 <Status>

<0x06>

IM will report Status in cmd2 of a direct Status Request command (0x19)

0x79

Set Database Link Data for next Link

44

0x7A

Set Application Retries for

New Links

31

0x7B

Set RF Frequency Offset

39

0x7C

Set Acknowledge for

TempLinc command

RF Modem only commands

S: 0x02 0x79 <Link Data 1> <Link Data 2> <Link Data 3>

(Note: bit 2 must be set in Start All-Linking command to use Link Data)

R: 0x02 0x79 <Link Data 1> <Link Data 2> <Link Data 3>

<0x06>

S: 0x02 0x7A <Number of Application Retries for new links>

R: 0x02 0x7A <Number of Application Retries for new links>

<0x06>

S: 0x02 0x7B <RF Frequency Offset

(increase frequency from least offset: 0x00 up to most offset: 0x7F; decrease frequency from least offset: 0xFF down to most offset: 0x8F)>

R: 0x02 0x7B <RF Frequency Offset>

<0x06>

S: 0x02 0x7C <XXXXXXXXXXXXXXXX>

R: 0x02 0x7C <XXXXXXXXXXXXXXXX>

<0x06>

Page 17 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

IM Serial Command Charts

The following charts describe the IM Commands individually in a chart format, grouped by functionality.

These are the same IM Commands as in the IM Serial Command Summary Table

13

, which is ordered by

Command Number.

Note that IM Commands sent by an IM to the host begin at 0x50 and IM Commands sent by the host to an IM begin at 0x60. When the host sends an IM Command to an IM, the IM will respond with a message according to the IM Serial Communication Protocol

6

.

In This Section

INSTEON Message Handling

19

Commands for sending and receiving INSTEON messages.

X10 Message Handling

27

Commands for sending and receiving X10 messages.

INSTEON ALL-Link Commands

29

Commands for sending ALL-Link Commands with automatic handling of ALL-Link Cleanup Commands.

ALL-Linking Session Management

33

Commands for creating ALL-Links between an IM and other INSTEON devices.

ALL-Link Database Management

36

Commands for managing ALL-Link Records in the IM’s ALL-Link Database.

IM Status Management

43

Commands for resetting and configuring the IM.

IM Input/Output

51

Commands for managing the IM’s SET Button and LED.

Page 18 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

INSTEON Message Handling

Send INSTEON Standard or Extended Message

This Command lets you send either a Standard-length or an Extended-length INSTEON message, depending only on what kind of INSTEON message you include in the body of the Command.

Send INSTEON Standard-length Message

Send INSTEON Standard-length Message (0x62)

What it does

What you send

What you’ll get

LED indication

Related Commands

Allows you to send a raw Standard-length INSTEON message.

8 bytes.

9 bytes.

None.

IM 0x50 INSTEON Standard Message Received

22

IM 0x51 INSTEON Extended Message Received

23

Command Sent from Host to IM

3

4

5

6

Byte Value

1

2

0x02

0x62

<To Address high>

<To Address middle>

<To Address low>

<Message Flags>

7

8

7

8

9

<Command 1>

<Command 2>

Byte Value

1

2

3

0x02

0x62

<To Address high>

4

5

6

<To Address middle>

<To Address low>

<Message Flags>

<Command 1>

<Command 2>

<ACK/NAK>

Meaning

Start of IM Command

IM Command Number

The high byte of the INSTEON ID of the message addressee.

The middle byte of the INSTEON ID of the message addressee.

The low byte of the INSTEON ID of the message addressee.

The INSTEON message flags indicating message type and hops.

Extended Message Flag (bit 4) is 0

INSTEON Command 1 for the addressee to execute

INSTEON Command 2 for the addressee to execute

Message Returned by IM to Host

Meaning

Echoed Start of IM Command

Echoed IM Command Number

Echoed <To Address high>

Echoed <To Address middle>

Echoed <To Address low>

Echoed <Message Flags>

Extended Message Flag (bit 4) is 0

Echoed <Command 1>

Echoed <Command 2>

0x06 (ACK) if the IM executed the Command correctly

0x15 (NAK) if an error occurred

Notes

The From Address is not required because the IM will automatically insert its own INSTEON ID into the message.

For more information on INSTEON Commands and the latest Command set, please download the current

INSTEON Command Tables Document

2

from http://code.insteon.com

.

Page 19 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

Send INSTEON Extended-length Message

Send INSTEON Extended-length Message (0x62)

12

13

14

15

16

7

8

9

10

11

17

18

19

20

21

22

14

15

16

17

18

7

8

9

10

11

12

13

What it does

What you send

What you’ll get

LED indication

Related Commands

Byte Value

1

2

3

0x02

0x62

<To Address high>

4

5

6

<To Address middle>

<To Address low>

<Message Flags>

<Command 1>

<Command 2>

<User Data 1>

<User Data 2>

<User Data 3>

<User Data 4>

<User Data 5>

<User Data 6>

<User Data 7>

<User Data 8>

<User Data 9>

<User Data 10>

<User Data 11>

<User Data 12>

<User Data 13>

<User Data 14>

4

5

6

Byte Value

1 0x02

2

3

0x62

<To Address high>

<To Address middle>

<To Address low>

<Message Flags>

<Command 1>

<Command 2>

<User Data 1>

<User Data 2>

<User Data 3>

<User Data 4>

<User Data 5>

<User Data 6>

<User Data 7>

<User Data 8>

<User Data 9>

<User Data 10>

Allows you to send a raw Extended-length INSTEON message.

22 bytes.

23 bytes.

None.

IM 0x50 INSTEON Standard Message Received

22

IM 0x51 INSTEON Extended Message Received

23

Command Sent from Host to IM

Meaning

Start of IM Command

IM Command Number

The high byte of the INSTEON ID of the message addressee.

The middle byte of the INSTEON ID of the message addressee.

The low byte of the INSTEON ID of the message addressee.

The INSTEON message flags indicating message type and hops.

Extended Message Flag (bit 4) is 1

INSTEON Command 1 for the addressee to execute

INSTEON Command 2 for the addressee to execute

Extended message data

Extended message data

Extended message data

Extended message data

Extended message data

Extended message data

Extended message data

Extended message data

Extended message data

Extended message data

Extended message data

Extended message data

Extended message data

Extended message data

Message Returned by IM to Host

Meaning

Echoed Start of IM Command

Echoed IM Command Number

Echoed <To Address high>

Echoed <To Address middle>

Echoed <To Address low>

Echoed <Message Flags>

Extended Message Flag (bit 4) is 1

Echoed <Command 1>

Echoed <Command 2>

Echoed Extended message data

Echoed Extended message data

Echoed Extended message data

Echoed Extended message data

Echoed Extended message data

Echoed Extended message data

Echoed Extended message data

Echoed Extended message data

Echoed Extended message data

Echoed Extended message data

Page 20 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

19

20

21

22

23

<User Data 11>

<User Data 12>

<User Data 13>

<User Data 14>

<ACK/NAK>

Echoed Extended message data

Echoed Extended message data

Echoed Extended message data

Echoed Extended message data

0x06 (ACK) if the IM executed the Command correctly

0x15 (NAK) if an error occurred

Notes

The From Address is not required because the IM will automatically insert its own INSTEON ID into the message.

For more information on INSTEON Commands and the latest Command set, please download the current INSTEON Command Tables Document

2

from http://code.insteon.com

.

Page 21 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

INSTEON Standard Message Received

INSTEON Standard Message Received (0x50)

What it does

When you’ll get this

What you’ll get

LED indication

Related Commands

Byte Value

1

2

3

0x02

0x50

<From Address high>

4

5

6

<From Address middle>

<From Address low>

<To Address high>

7

8

9

10

11

<To Address low>

<Message Flags>

<Command 1>

<Command 2>

Informs you of an incoming Standard-length INSTEON message.

A Standard-length INSTEON message is received from either a Controller or Responder that you are

ALL-Linked to.

11 bytes.

The LED will blink during INSTEON reception.

IM 0x51 INSTEON Extended Message Received

23

IM 0x52 X10 Received

28

Message Sent from IM to Host

<To Address middle>

Meaning

Start of IM Command

IM Command Number

The high byte of the INSTEON ID of the message originator.

The middle byte of the INSTEON ID of the message originator.

The low byte of the INSTEON ID of the message originator.

The high byte of the INSTEON ID of the message addressee.

If the message is an ALL-Link Broadcast (bits 7 and 6 of the <Message Flags> byte are set) then this will be 0.

The middle byte of the INSTEON ID of the message addressee.

If the message is an ALL-Link Broadcast (bits 7 and 6 of the <Message Flags> byte are set) then this will be 0.

The low byte of the INSTEON ID of the message addressee.

If the message is an ALL-Link Broadcast (bits 7 and 6 of the <Message Flags> byte are set) then this will indicate the ALL-Link Group Number.

The INSTEON message flags indicating message type and hops.

INSTEON Command 1 field of the message.

INSTEON Command 2 field of the message.

This byte contains the ALL-Link Group Number of the ALL-Link Broadcast when either bit 6 of the <Message Flags> byte is set (ALL-Link Cleanup) or bits 6 and 5 of the

<Message Flags> byte are set (ALL-Link Cleanup ACK).

Notes

This is the same as IM 0x51 INSTEON Extended Message Received

23

, except that there is no <User

Data>.

Normally, the IM will only send the host INSTEON messages that are explicitly addressed to the IM or that are from devices that the IM is ALL-Linked to. This behavior can be modified—see the About Monitor

Mode

46

note in the Set IM Configuration

46

chart for more information.

For more information on INSTEON Commands and the latest Command set, please download the current

INSTEON Command Tables Document

2

from http://code.insteon.com

.

Page 22 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

INSTEON Extended Message Received

INSTEON Extended Message Received (0x51)

What it does

When you’ll get this

What you’ll get

LED indication

Related Commands

Informs you of an incoming Extended-length INSTEON message.

An Extended-length INSTEON message is received from either a Controller or Responder that you are ALL-Linked to.

25 bytes.

The LED will blink during INSTEON reception.

IM 0x50 INSTEON Standard Message Received

22

IM 0x52 X10 Received

28

Message Sent from IM to Host

Byte Value

1

2

3

0x02

0x51

<From Address high>

4

5

6

<From Address middle>

<From Address low>

<To Address high>

7

8

9

10

11

<To Address middle>

<To Address low>

<Message Flags>

<Command 1>

<Command 2>

19

20

21

22

23

24

25

12

13

14

15

16

17

18

Notes

<User Data 1>

<User Data 2>

<User Data 3>

<User Data 4>

<User Data 5>

<User Data 6>

<User Data 7>

<User Data 8>

<User Data 9>

<User Data 10>

<User Data 11>

<User Data 12>

<User Data 13>

<User Data 14>

Meaning

Start of IM Command

IM Command Number

The high byte of the INSTEON ID of the message originator.

The middle byte of the INSTEON ID of the message originator.

The low byte of the INSTEON ID of the message originator.

The high byte of the INSTEON ID of the message addressee.

If the message is an ALL-Link Broadcast (bits 7 and 6 of the <Message Flags> byte are set) then this will be 0.

The middle byte of the INSTEON ID of the message addressee.

If the message is an ALL-Link Broadcast (bits 7 and 6 of the <Message Flags> byte are set) then this will be 0.

The low byte of the INSTEON ID of the message addressee.

If the message is an ALL-Link Broadcast (bits 7 and 6 of the <Message Flags> byte are set) then this will indicate the ALL-Link Group Number.

The INSTEON message flags indicating message type and hops.

INSTEON Command 1 field of the message.

INSTEON Command 2 field of the message.

This byte contains the ALL-Link Group Number of the ALL-Link Broadcast when either bit 6 of the <Message Flags> byte is set (ALL-Link Cleanup) or bits 6 and 5 of the

<Message Flags> byte are set (ALL-Link Cleanup ACK).

Extended message data

Extended message data

Extended message data

Extended message data

Extended message data

Extended message data

Extended message data

Extended message data

Extended message data

Extended message data

Extended message data

Extended message data

Extended message data

Extended message data

This is the same as IM 0x50 INSTEON Standard Message Received

22

, except that there are 14 bytes of

<User Data>.

Normally, the IM will only send the host INSTEON messages that are explicitly addressed to the IM or that are from devices that the IM is ALL-Linked to. This behavior can be modified—see the About Monitor

Mode

46

note in the Set IM Configuration

46

chart for more information.

For more information on INSTEON Commands and the latest Command set, please download the current

INSTEON Command Tables Document

2

from http://code.insteon.com

.

Page 23 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

Set INSTEON ACK Message Byte

Set INSTEON ACK Message Byte (0x68)

What it does

What you send

What you’ll get

LED indication

Related Commands

Byte Value

1 0x02

2

3

0x68

<Command 2 Data>

Allows you to put one byte of data into the Command 2 field of the INSTEON ACK message that the

INSTEON Engine automatically sends after it receives an INSTEON Direct message.

3 bytes.

4 bytes.

None.

IM 0x50 INSTEON Standard Message Received

22

IM 0x51 INSTEON Extended Message Received

23

IM 0x71 Set INSTEON ACK Message Two Bytes

25

IM 0x70 Set INSTEON NAK Message Byte

26

Command Sent from Host to IM

Meaning

Start of IM Command

IM Command Number

Data byte to place into the Command 2 field of the ACK response.

Message Returned by IM to Host

Byte Value

1

2

3

0x02

0x68

<Command 2 Data>

4 <ACK/NAK>

Meaning

Echoed Start of IM Command

Echoed IM Command Number

Echoed <Command 2 Data>

0x06 (ACK) if the IM executed the Command correctly.

0x15 (NAK) if an error occurred.

Notes

You have only about 15 milliseconds after the receipt of an INSTEON Direct message from the IM to send this Command to the IM. The reason is that the INSTEON Engine in the IM automatically sends

Acknowledgement messages in assigned timeslots.

Use Set INSTEON ACK Message Two Bytes

25 when you need to return two bytes of data in an ACK message.

Use Set INSTEON NAK Message Byte

26 when you need to return one byte of data in a NAK message.

Certain INSTEON Direct Commands require returned data in the Acknowledgement message. For more information on INSTEON Commands and the latest Command set, please download the current

INSTEON Command Tables Document

2

from http://code.insteon.com

.

Page 24 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

Set INSTEON ACK Message Two Bytes

Set INSTEON ACK Message Two Bytes (0x71)

What it does

What you send

What you’ll get

LED indication

Related Commands

Byte Value

1 0x02

2

3

4

0x71

<Command 1 Data>

<Command 2 Data>

Byte Value

1 0x02

2

3

0x71

<Command 1 Data>

4

5

<Command 2 Data>

<ACK/NAK>

Allows you to put two bytes of data into the combined Command 1 and Command 2 fields of the

INSTEON ACK message that the INSTEON Engine automatically sends after it receives an

INSTEON Direct message.

4 bytes.

5 bytes.

None.

IM 0x50 INSTEON Standard Message Received

22

IM 0x51 INSTEON Extended Message Received

23

IM 0x68 Set INSTEON ACK Message Byte

24

IM 0x70 Set INSTEON NAK Message Byte

26

Command Sent from Host to IM

Meaning

Start of IM Command

IM Command Number

Data byte to place into the Command 1 field 2 of the ACK response.

Data byte to place into the Command 2 field 2 of the ACK response.

Message Returned by IM to Host

Meaning

Echoed Start of IM Command

Echoed IM Command Number

Echoed <Command 1 Data>

Echoed <Command 2 Data>

0x06 (ACK) if the IM executed the Command correctly.

0x15 (NAK) if an error occurred.

Notes

You have only about 15 milliseconds after the receipt of an INSTEON Direct message from the IM to send this Command to the IM. The reason is that the INSTEON Engine in the IM automatically sends

Acknowledgement messages in assigned timeslots.

Use Set INSTEON ACK Message Byte

24

when you only need to return one byte of data in an ACK message.

Use Set INSTEON NAK Message Byte

26

when you need to return one byte of data in a NAK message.

Certain INSTEON Direct Commands require returned data in the Acknowledgement message. For more information on INSTEON Commands and the latest Command set, please download the current

INSTEON Command Tables Document

2

from http://code.insteon.com

.

Page 25 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

Set INSTEON NAK Message Byte

Set INSTEON NAK Message Byte (0x70)

What it does

What you send

What you’ll get

LED indication

Related Commands

Byte Value

1 0x02

2

3

0x70

<Command 2 Data>

Byte Value

1 0x02

2

3

4

0x70

<Command 2 Data>

<ACK/NAK>

Allows you to change the INSTEON ACK message that the INSTEON Engine automatically sends after it receives an INSTEON Direct message into a NAK message, and to put one byte of data into the Command 2 field of that message.

3 bytes.

4 bytes.

None.

IM 0x50 INSTEON Standard Message Received

22

IM 0x51 INSTEON Extended Message Received

23

IM 0x68 Set INSTEON ACK Message Byte

24

IM 0x70 Set INSTEON ACK Message Two Bytes

25

Command Sent from Host to IM

Meaning

Start of IM Command

IM Command Number

Data byte to place into the Command 2 field of the ACK response.

Message Returned by IM to Host

Meaning

Echoed Start of IM Command

Echoed IM Command Number

Echoed <Command 2 Data>

0x06 (ACK) if the IM executed the Command correctly.

0x15 (NAK) if an error occurred.

Notes

You have only about 15 milliseconds after the receipt of an INSTEON Direct message from the IM to send this Command to the IM. The reason is that the INSTEON Engine in the IM automatically sends

Acknowledgement messages in assigned timeslots.

Use Set INSTEON ACK Message Byte

24

or Set INSTEON ACK Message Two Bytes

25

when you need to return one or two bytes of data in an ACK message.

NAK messages report certain error conditions in a receiving device. See NAK Error Codes in the

INSTEON Developer’s Guide

2

for more information.

Page 26 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

X10 Message Handling

Send X10

4-bit

Code

0x6

0xE

0x2

0xA

0x1

0x9

0x5

0xD

0x7

0xF

0x3

0xB

0x0

0x8

0x4

0xC

What it does

What you send

What you’ll get

LED indication

Related Commands

Byte Value

1 0x02

2

3

0x63

<Raw X10>

4 <X10 Flag>

Byte Value

1

2

3

0x02

0x63

<Raw X10>

4

5

<X10 Flag>

<ACK/NAK>

4 MSBs of <Raw X10>

X10 House Code

E

F

G

H

I

A

B

C

D

M

N

O

P

J

K

L

Send X10 (0x63)

Allows you to send a raw X10 Address or X10 Command.

4 bytes.

5 bytes.

None.

IM 0x52 X10 Received

28

Command Sent from Host to IM

Meaning

Start of IM Command

IM Command Number

The four most significant bits contain the X10 House Code.

The four least significant bits contain the X10 Key Code.

0x00 indicates that the X10 Key Code is an X10 Unit Code.

0x80 indicates that the X10 Key Code is an X10 Command.

Message Returned by IM to Host

Meaning

Echoed Start of IM Command

Echoed IM Command Number

Echoed <Raw X10>

Echoed <X10 Flag>

0x06 (ACK) if the IM executed the Command correctly

0x15 (NAK) if an error occurred

X10 Translation Table

X10 Unit Code

<X10 Flag> = 0x00

5

6

7

8

9

1

2

3

4

10

11

12

13

14

15

16

4 LSBs of <Raw X10>

X10 Command

<X10 Flag> = 0x80

All Lights Off

Status = Off

On

Preset Dim

All Lights On

Hail Acknowledge

Bright

Status = On

Extended Code

Status Request

Off

Preset Dim

All Units Off

Hail Request

Dim

Extended Data (analog)

Page 27 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

X10 Received

H

I

J

K

L

M

N

O

P

D

E

F

G

A

B

C

4-bit

Code

0xD

0x7

0xF

0x3

0xB

0x0

0x8

0x4

0xC

0x6

0xE

0x2

0xA

0x1

0x9

0x5

What it does

When you’ll get this

What you’ll get

LED indication

Related Commands

Byte Value

1 0x02

2

3

0x52

<Raw X10>

4 <X10 Flag>

X10 Received (0x52)

Informs you of an X10 byte detected on the powerline.

Any X10 traffic is detected on the powerline.

4 bytes.

The LED will blink during X10 reception.

IM 0x63 Send X10

27

IM 0x50 INSTEON Standard Message Received

22

IM 0x51 INSTEON Extended Message Received

23

Message Sent from IM to Host

4 MSBs of <Raw X10>

X10 House Code

Meaning

Start of IM Command

IM Command Number

The four most significant bits contain the X10 House Code.

The four least significant bits contain the X10 Key Code.

0x00 indicates that the X10 Key Code is an X10 Unit Code.

0x80 indicates that the X10 Key Code is an X10 Command.

X10 Translation Table

8

9

10

11

12

13

14

15

16

2

3

4

5

6

7

X10 Unit Code

<X10 Flag> = 0x00

1

4 LSBs of <Raw X10>

X10 Command

<X10 Flag> = 0x80

All Lights Off

Status = Off

On

Preset Dim

All Lights On

Hail Acknowledge

Bright

Status = On

Extended Code

Status Request

Off

Preset Dim

All Units Off

Hail Request

Dim

Extended Data (analog)

Page 28 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

INSTEON ALL-Link Commands

Send ALL-Link Command

Send ALL-Link Command (0x61)

What it does

What you send

What you’ll get

LED indication

Related Commands

Sends an ALL-Link Command to an ALL-Link Group of one or more Responders that the IM is ALL-

Linked to.

5 bytes.

6 bytes for the echo of the Command and then an additional 11 bytes in an INSTEON Standard

Message Received

22

message for each device in the group that acknowledges ALL-Link Cleanup, or

7 bytes in an ALL-Link Cleanup Failure Report

31

message for each device in the group that does not acknowledge ALL-Link Cleanup.

None.

IM 0x50 INSTEON Standard Message Received

22

IM 0x56 ALL-Link Cleanup Failure Report

31

IM 0x58 ALL-Link Cleanup Status Report

32

Command Sent from Host to IM

Byte Value

1 0x02

2

3

4

5

0x61

<ALL-Link Group>

<ALL-Link Command>

<Broadcast Command 2>

Meaning

Start of IM Command

IM Command Number

ALL-Link Group Number that the ALL-Link Command is sent to

ALL-Link Command

Sent in the Command 2 field of the ALL-Link Broadcast message only. Command 2 will always contain the ALL-Link Group Number for the ALL-Link Cleanup messages that follow.

Message Returned by IM to Host

4

5

6

Byte Value

1 0x02

2

3

0x61

<ALL-Link Group>

<ALL-Link Command>

<Broadcast Command 2>

<ACK/NAK>

Meaning

Echoed Start of IM Command

Echoed IM Command Number

Echoed <ALL-Link Group>

Echoed <ALL-Link Command>

Echoed <Broadcast Command 2>

0x06 (ACK) if the IM executed the Command correctly

0x15 (NAK) if an error occurred or the group does not exist

Notes

The IM automatically sends ALL-Link Cleanup messages to each member of an ALL-Link Group following an ALL-Link Broadcast message. If the IM detects other INSTEON traffic during this process, it will abort the ALL-Link Cleanup sequence and send you an ALL-Link Cleanup Status Report

32

with a

Status Byte of 0x15 (NAK). The Cleanup sequence proceeds in the order in which the devices in the

ALL-Link Group were added to the ALL-Link Database. If the IM finishes sending all of the Cleanup messages, it will send you an ALL-Link Cleanup Status Report

32

with a Status Byte of 0x06 (ACK).

For each ALL-Link Cleanup message that the IM sends, you will either receive an INSTEON Standard

Message Received

22

when the Responder answers with a Cleanup acknowledgement message, or else you will receive an ALL-Link Cleanup Failure Report

31

if the Responder fails to answer with a

Cleanup acknowledgement message. The IM will send you an ALL-Link Cleanup Status Report

32 whether or not every ALL-Link Group member acknowledges the Cleanup Command that the IM sends to it.

You can cause the IM to cancel its own Cleanup sequence by sending it a new Send ALL-Link

Command

29

or Send INSTEON Standard or Extended Message

19

during the time that it is sending a

Cleanup sequence (i.e. after it has finished sending an ALL-Link Broadcast message). The IM will send you an ALL-Link Cleanup Status Report

32

in those cases.

Page 29 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

The IM first sends an ALL-Link Broadcast message with Max Hops set to 3. When it sends the ensuing

ALL-Link Cleanup messages, it sets Max Hops to 1. If the IM’s INSTEON Engine needs to retry a

Cleanup message, it will automatically increment Max Hops for each retry, up to a maximum of value of

3.

The IM sends the ALL-Link Broadcast message immediately if there is no other INSTEON traffic. If there is other INSTEON traffic, the IM will wait for one silent powerline zero crossing following a completed INSTEON message. The IM will send the first ALL-Link Cleanup message after a delay of 7 zero crossings. Subsequent Cleanups will go out with a delay of 2 zero crossings.

Do not use this command to control light levels with the Light Start Manual Change INSTEON

Command SA 0x17. Use Send INSTEON Standard-length Message

19

to send INSTEON Command

SD 0x17 instead.

For more information on INSTEON Commands and the latest Command set, please download the current INSTEON Command Tables Document

2

from http://code.insteon.com

.

Page 30 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

ALL-Link Cleanup Failure Report

ALL-Link Cleanup Failure Report (0x56)

What it does

When you’ll get this

4

5

6

7

What you’ll get

LED indication

Related Commands

Byte Value

1 0x02

2

3

0x56

0x01

Notes

<ALL-Link Group>

<ID high byte>

<ID middle byte>

<ID low byte>

Reports that an ALL-Link Group member did not acknowledge an ALL-Link Cleanup Command.

An ALL-Link Group member that you are trying to control did not acknowledge the ALL-Link Cleanup

Command sent by the IM.

7 bytes.

None.

IM 0x58 ALL-Link Cleanup Status Report

32

Message Sent from IM to Host

Meaning

Start of IM Command

IM Command Number

Indicates that this ALL-Link Group member did not acknowledge an ALL-Link Cleanup

Command.

Indicates the ALL-Link Group Number that was sent in the ALL-Link Cleanup

Command.

The high byte of the INSTEON ID of the device that did not respond.

The middle byte of the INSTEON ID of the device that did not respond.

The low byte of the INSTEON ID of the device that did not respond.

The IM automatically sends ALL-Link Cleanup messages to each member of an ALL-Link Group following an ALL-Link Broadcast message. If the IM detects other INSTEON traffic during this process, it will abort the ALL-Link Cleanup sequence. If the Cleanup sequence is aborted, you will not receive this message nor will you receive a Cleanup acknowldgement message for any subsequent devices in the ALL-Link Group. The Cleanup sequence proceeds in the order in which the devices in the ALL-

Link Group were added to the ALL-Link Database.

For each ALL-Link Cleanup message the IM sends, you will either receive an INSTEON Standard

Message Received

22

when the Responder sends you an ACK, or you will receive this message.

However, it can take awhile before you receive this message. Worst case, if the IM has to wait for a clear line and then retries the Cleanup message for the maximum of five times, the wait will be 2.150 seconds after sending the ALL-Link Broadcast message, or 1.550 seconds after receiving the first

Cleanup acknowledgement or this message. If the Cleanup sequence was aborted due to other

INSTEON traffic, you will not get this message even then. However, you will receive ALL-Link Cleanup

Status Report

32

with a Status Byte of 0x15 (NAK) indicating that the Cleanup sequence was aborted.

It is possible that this ALL-Link Group member did in fact properly receive the ALL-Link Broadcast message that preceded the ALL-Link Cleanup message.

Page 31 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

ALL-Link Cleanup Status Report

ALL-Link Cleanup Status Report (0x58)

What it does

When you’ll get this

What you’ll get

LED indication

Related Commands

Notifies you if a

Send ALL-Link Command

29

completed with all Cleanup messages sent, or else if

Cleanups were interrupted due to other INSTEON traffic.

After you issue a

Send ALL-Link Command

29

and the IM finishes sending Cleanups to all members of the ALL-Link Group, or else when the Cleanup sequence is aborted due to other INSTEON traffic.

3 bytes.

None.

IM 0x61 Send ALL-Link Command

29

IM 0x56 ALL-Link Cleanup Failure Report

31

Message Sent from IM to Host

Byte Value

1

2

3

0x02

0x58

<Status Byte>

Meaning

Start of IM Command

IM Command Number

<0x06> (ASCII ACK) The ALL-Link Command sequence initiated previously using

Send

ALL-Link Command

29

completed. The IM first sent an ALL-Link Broadcast message, followed by ALL-Link Cleanup messages sent to all members of the specified ALL-Link

Group. If any member of the ALL-Link Group does not return a Cleanup acknowledgement, you will receive an

ALL-Link Cleanup Failure Report

31

from that member.

<0x15> (ASCII NAK) The ALL-Link Command sequence initiated previously using

Send

ALL-Link Command

29

terminated before the IM sent ALL-Link Cleanup messages to all members of the specified ALL-Link Group. This is normal behavior when the IM detects

INSTEON traffic from other devices.

Notes

The IM automatically sends ALL-Link Cleanup messages to each member of an ALL-Link Group following an ALL-Link Broadcast message. If the IM detects other INSTEON traffic during this process, it will abort the ALL-Link Cleanup sequence and send you this message with a Status Byte of 0x15

(NAK). The Cleanup sequence proceeds in the order in which the devices in the ALL-Link Group were added to the ALL-Link Database. If the IM finishes sending all of the Cleanup messages, it will send you this message with a Status Byte of 0x06 (ACK).

For each ALL-Link Cleanup message that the IM sends, you will either receive an INSTEON Standard

Message Received

22

when the Responder answers with a Cleanup acknowledgement message, or else you will receive an ALL-Link Cleanup Failure Report

31

if the Responder fails to answer with a

Cleanup acknowledgement message. The IM will send you this message whether or not every ALL-

Link Group member acknowledges the Cleanup Command that the IM sends to it.

You can cause the IM to cancel its own Cleanup sequence by sending it a new Send ALL-Link

Command

29

or Send INSTEON Standard or Extended Message

19

during the time that it is sending a

Cleanup sequence (i.e. after it has finished sending an ALL-Link Broadcast message). The IM will send you this message in those cases.

Page 32 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

ALL-Linking Session Management

Start ALL-Linking

Start ALL-Linking (0x64)

What it does

What you send

What you’ll get

LED indication

Related Commands

Byte Value

1 0x02

2

3

0x64

<Link Code>

4 <ALL-Link Group>

Byte Value

1 0x02

2

3

4

5

0x64

<Code>

<ALL-Link Group>

<ACK/NAK>

Puts the IM into ALL-Linking mode without using the SET Button.

4 bytes.

5 bytes for this Command response and then an additional 10 bytes in an

ALL-Linking Completed

35 message once a successful ALL-Link has been established.

The LED will blink continuously at a rate of ½ second on and ½ second off until the ALL-Link is completed or canceled.

IM 0x53 ALL-Linking Completed

35

IM 0x65 Cancel ALL-Linking

34

Command Sent from Host to IM

Meaning

Start of IM Command

IM Command Number

The type of ALL-Link to establish.

0x00 ALL-Links the IM as a Responder (slave).

0x01 ALL-Links the IM as a Controller (master).

0x03 ALL-Links the IM as a Controller when the IM initiates ALL-Linking, or as a

Responder when another device initiates ALL-Linking.

0xFF Deletes the ALL-Link.

The ALL-Link Group Number to be linked to or deleted.

Message Returned by IM to Host

Meaning

Echoed Start of IM Command

Echoed IM Command Number

Echoed <Code>

Echoed <ALL-Link Group>

0x06 (ACK) if the IM executed the Command correctly

0x15 (NAK) if an error occurred

Page 33 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

Cancel ALL-Linking

What it does

What you send

What you’ll get

LED indication

Related Commands

Cancel ALL-Linking (0x65)

Cancels the ALL-Linking process that was started either by holding down the IM’s SET Button or by sending a

Start ALL-Linking

33

Command to the IM.

2 bytes.

3 bytes.

The LED will stop blinking.

IM 0x64 Start ALL-Linking

33

IM 0x54 Button Event Report

51

Command Sent from Host to IM

Byte Value

1

2

0x02

0x65

Byte Value

1

2

0x02

0x65

3 <ACK/NAK>

Meaning

Start of IM Command

IM Command Number

Message Returned by IM to Host

Meaning

Echoed Start of IM Command

Echoed IM Command Number

0x06 (ACK) if the IM executed the Command correctly

0x15 (NAK) if an error occurred

Page 34 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

ALL-Linking Completed

What it does

When you’ll get this

What you’ll get

LED indication

Related Commands

4

5

6

7

8

Byte Value

1 0x02

2

3

0x53

<Link Code>

9

10

<ALL-Link Group>

<ID high byte>

<ID middle byte>

<ID low byte>

<Device Category>

<Device Subcategory>

<0xFF | Firmware Version>

ALL-Linking Completed (0x53)

Informs you of a successful ALL-Linking procedure.

An ALL-Linking procedure has been completed between the IM and either a Controller or Responder.

10 bytes.

None.

IM 0x64 Start ALL-Linking

33

IM 0x65 Cancel ALL-Linking

34

Message Sent from IM to Host

Meaning

Start of IM Command

IM Command Number

Indicates the type of link made.

0x00 means the IM is a Responder (slave) to this device

0x01 means the IM is a Controller (master) of this device

0xFF means the ALL-Link to the device was deleted

If done manually (by pushing the SET Button) the Controller / Responder relationship between the IM and the device is determined automatically. You can assign the

Controller / Responder relationship unconditionally by using the

Start ALL-Linking

33

Command.

Indicates the ALL-Link Group Number that was assigned to this link.

If done manually (by pushing the SET Button) the ALL-Link Group Number is automatically assigned by the IM. You can assign ALL-Link Group Numbers unconditionally by using the

Start ALL-Linking

33

Command.

The high byte of the INSTEON ID of the device that was ALL-Linked.

The middle byte of the INSTEON ID of the device that was ALL-Linked.

The low byte of the INSTEON ID of the device that was ALL-Linked.

The Device Category (DevCat) of the Responder device that was ALL-Linked.

(Only valid when the IM is a Controller)

The Device Subcategory (SubCat) of the Responder device that was ALL-Linked.

(Only valid when the IM is a Controller)

0xFF for newer devices.

For legacy devices this is the firmware version of the Responder device that was ALL-

Linked.

(Only valid when the IM is a Controller)

Page 35 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

ALL-Link Database Management

Get First ALL-Link Record

What it does

What you send

What you’ll get

LED indication

Related Commands

Byte Value

1

2

0x02

0x69

Byte Value

1 0x02

2

3

0x69

<ACK/NAK>

Get First ALL-Link Record (0x69)

Returns the first record in the IM’s ALL-Link Database. The data will follow in an ALL-Link Record

Response

39

message.

2 bytes.

3 bytes.

None.

IM 0x57 ALL-Link Record Response

39

IM 0x6A Get Next ALL-Link Record

37

IM 0x6C Get ALL-Link Record for Sender

38

Command Sent from Host to IM

Meaning

Start of IM Command

IM Command Number

Message Returned by IM to Host

Meaning

Echoed Start of IM Command

Echoed IM Command Number

0x06 (ACK) if an ALL-Link Record Response

39

follows

0x15 (NAK) if the database is empty.

Note

Use this to begin scanning the IM’s ALL-Link Database. Follow up with Get Next ALL-Link Record

37

Commands until you receive a NAK.

In the IM Factory Reset State

11

the ALL-Link Database will be cleared, so you will receive a NAK.

Page 36 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

Get Next ALL-Link Record

What it does

What you send

What you’ll get

LED indication

Related Commands

Get Next ALL-Link Record (0x6A)

Returns the next record in the IM’s ALL-Link Database. The data will follow in an ALL-Link Record

Response

39

message.

2 bytes.

3 bytes.

None.

IM 0x57 ALL-Link Record Response

39

IM 0x69 Get First ALL-Link Record

36

IM 0x6C Get ALL-Link Record for Sender

38

Command Sent from Host to IM

Byte Value

1 0x02

2

0x6A

Byte Value

1 0x02

2

3

0x6A

<ACK/NAK>

Meaning

Start of IM Command

IM Command Number

Message Returned by IM to Host

Meaning

Echoed Start of IM Command

Echoed IM Command Number

0x06 (ACK) if an ALL-Link Record Response

39

follows

0x15 (NAK) if there are no more records.

Note

Use this to continue scanning the IM’s ALL-Link Database until you receive a NAK. Begin the scan up with a Get First ALL-Link Record

36

Command.

In the IM Factory Reset State

11

the ALL-Link Database will be cleared, so you will receive a NAK.

Page 37 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

Get ALL-Link Record for Sender

Get ALL-Link Record for Sender (0x6C)

What it does

What you send

What you’ll get

LED indication

Related Commands

Byte Value

1

2

0x02

0x6C

Byte Value

1 0x02

2

3

0x6C

<ACK/NAK>

This gets the record from the IM’s ALL-Link Database for the last INSTEON message received from an INSTEON device that is in the IM’s ALL-Link Database. The data will follow in an ALL-Link

Record Response

39

message.

2 bytes.

3 bytes.

None.

IM 0x57 ALL-Link Record Response

39

IM 0x69 Get First ALL-Link Record

36

IM 0x6A Get Next ALL-Link Record

37

Command Sent from Host to IM

Meaning

Start of IM Command

IM Command Number

Message Returned by IM to Host

Meaning

Echoed Start of IM Command

Echoed IM Command Number

0x06 (ACK) if an ALL-Link Record Response

39

follows

0x15 (NAK) if the last INSTEON message received had a From Address not in the IM’s

ALL-Link Database.

Note

If you send this after receiving an INSTEON message from an INSTEON device that is not in the IM’s

ALL-Link Database, you will receive a NAK in response.

Sending a Get Next ALL-Link Record

37

Command after this will return the ALL-Link Record that follows this one, but your actual position within the ALL-Link Database will be unknown (unless you are at the end).

In the IM Factory Reset State

11

the ALL-Link Database will be cleared, so you will receive a NAK.

Page 38 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

ALL-Link Record Response

ALL-Link Record Response (0x57)

What it does

When you’ll get this

What you’ll get

LED indication

Related Commands

4

5

6

7

8

9

10

Note

<ALL-Link Group>

<ID high byte>

<ID middle byte>

<ID low byte>

<Link Data 1>

<Link Data 2>

<Link Data 3>

Provides a record from the IM’s ALL-Link Database.

You get this when you have requested it, in response to a Get First ALL-Link Record

36

a Get Next

ALL-Link Record

37

, or a Get ALL-Link Record for Sender

38

Command.

10 bytes.

None.

IM 0x69 Get First ALL-Link Record

36

IM 0x6A Get Next ALL-Link Record

37

IM 0x6C Get ALL-Link Record for Sender

38

Message Sent from IM to Host

Byte Value

1 0x02

2

3

0x57

<ALL-Link Record Flags>

Meaning

Start of IM Command

IM Command Number

ALL-Link Database control flags for this ALL-Link Record

Bit 7 1 = Record is in use

0 = Record is available

Note: This bit will always be set to 1.

Bit 6 1 = IM is a Controller (master) of the device with <ID>

given in bytes 5 – 7 below,

0 = IM is a Responder (slave) to the device with <ID>

given in bytes 5 – 7 below

Bit 5 Product dependent

Bit 4 Product dependent

Bit 3 Reserved (set to 0)

Bit 2 Reserved (set to 0)

Bit 1 1 = Record has been used before

0 = ‘High-water Mark’

Note: This bit will always be set to 1.

Bit 0 Reserved (set to 0)

ALL-Link Group Number for this ALL-Link Record

INSTEON ID high byte for device ALL-Linked to

INSTEON ID middle byte for device ALL-Linked to

INSTEON ID low byte for device ALL-Linked to

Link Information (varies by device ALL-Linked to)

Link Information (varies by device ALL-Linked to)

Link Information (varies by device ALL-Linked to)

See the section INSTEON All-Link Database in the INSTEON Developer’s Guide

2

for details about the contents of an ALL-Link Record.

Page 39 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

Manage ALL-Link Record

What it does

What you send

What you’ll get

LED indication

Related Commands

Byte Value

1 0x02

2

3

0x6F

<Control Code>

Manage ALL-Link Record (0x6F)

Updates the IM’s ALL-Link Database (ALDB) with the ALL-Link Record information you send. Use caution with this Command—the IM does not check the validity of the data.

11 bytes.

12 bytes.

None.

IM 0x57 ALL-Link Record Response

39

Command Sent from Host to IM

Meaning

Start of IM Command

IM Command Number

What to do with the ALL-Link Record

0x00

Find First

Starting at the top of the ALDB, search for the first ALL-Link Record matching the <ALL-Link Group> and <ID> in bytes 5 – 8. The search ignores byte 4,

<ALL-Link Record Flags>.

You will receive an ACK at the end of the returned message if such an ALL-

Link Record exists, or else a NAK if it doesn’t. If the record exists, the IM will return it in an ALL-Link Record Response

39

message.

0x01

Find Next

Search for the next ALL-Link Record following the one found using <Control

Code> 0x00 above. This allows you to find both Controller and Responder records for a given <ALL-Link Group> and <ID>. Be sure to use the same

<ALL-Link Group> and <ID> (bytes 5 – 8) as you used for <Control Code>

0x00.

You will receive an ACK at the end of the returned message if another matching ALL-Link Record exists, or else a NAK if it doesn’t. If the record exists, the IM will return it in an ALL-Link Record Response

39

message.

0x20

Modify First Found or Add

Modify an existing or else add a new ALL-Link Record for either a Controller or Responder.

Starting at the top of the ALDB, search for the first ALL-Link Record matching the <ALL-Link Group> and <ID> in bytes 5 – 8. The search ignores byte 4,

<ALL-Link Record Flags>.

If such an ALL-Link Record exists, overwrite it with the data in bytes 4 – 11; otherwise, create a new ALL-Link Record using bytes 4 – 11.

Note that the IM will copy <ALL-Link Record Flags> you supplied in byte 4 below directly into the <ALL-Link Record Flags> byte of the ALL-Link Record in an ALDB-L (linear) database. Use caution, because you can damage an

ALDB-L if you misuse this Command. For instance, if you zero the <ALL-

Link Record Flags> byte in the first ALL-Link Record, the IM’s ALDB-L database will then appear empty.

0x40

Modify First Controller Found or Add

Modify an existing or else add a new Controller (master) ALL-Link Record.

Starting at the top of the ALDB, search for the first ALL-Link Controller

Record matching the <ALL-Link Group> and <ID> in bytes 5 – 8. An ALL-

Link Controller Record has bit 6 of its <ALL-Link Record Flags> byte set to 1.

If such a Controller ALL-Link Record exists, overwrite it with the data in bytes

5 – 11; otherwise, create a new ALL-Link Record using bytes 5 – 11. In either case, the IM will set bit 6 of the <ALL-Link Record Flags> byte in the

ALL-Link Record to 1 to indicate that the record is for a Controller.

0x41

Modify First Responder Found or Add

Modify an existing or else add a new Responder (slave) ALL-Link Record.

Starting at the top of the ALDB, search for the first ALL-Link Responder

Record matching the <ALL-Link Group> and <ID> in bytes 5 – 8. An ALL-

Link Responder Record has bit 6 of its <ALL-Link Record Flags> byte cleared to 0.

If such a Responder ALL-Link Record exists, overwrite it with the data in bytes 5 – 11; otherwise, create a new ALL-Link Record using bytes 5 – 11.

In either case, The IM will clear bit 6 of the <ALL-Link Record Flags> byte in the ALL-Link Record to 0 to indicate that the record is for a Responder.

Page 40 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

4

5

6

7

8

9

10

11

<ALL-Link Record Flags>

<ALL-Link Group>

<ID high byte>

<ID middle byte>

<ID low byte>

<Link Data 1>

<Link Data 2>

<Link Data 3>

9

10

11

12

6

7

8

Byte Value

1

2

3

0x02

0x6F

<Control Code>

4

5

<ALL-Link Record Flags>

<ALL-Link Group>

<ID high byte>

<ID middle byte>

<ID low byte>

<Link Data 1>

<Link Data 2>

<Link Data 3>

<ACK/NAK>

0x80

Delete First Found

Delete an ALL-Link Record.

Starting at the top of the ALDB, search for the first ALL-Link Record matching the <ALL-Link Group> and <ID> in bytes 5 – 8. The search ignores byte 4,

<ALL-Link Record Flags>.

You will receive an ACK at the end of the returned message if such an ALL-

Link Record existed and was deleted, or else a NAK no such record exists.

ALL-Link Database control flags for this ALL-Link Record

Bit 7 1 = Record is in use

0 = Record is available

Note: This bit is only settable for ALDB-L (linear) databases using <Control

Code> 0x20. It is handled automatically by ALDB-T (threaded) databases.

Bit 6 1 = IM is a Controller (master) of the device with <ID>

given in bytes 6 – 8 below,

0 = IM is a Responder (slave) to the device with <ID>

given in bytes 6 – 8 below

Bit 5 Product dependent

Bit 4 Product dependent

Bit 3 Reserved (set to 0)

Bit 2 Reserved (set to 0)

Bit 1 1 = Record has been used before

0 = ‘High-water Mark’

Note: This bit is only settable for ALDB-L (linear) databases using <Control

Code> 0x20. It is handled automatically by ALDB-T (threaded) databases.

Bit 0 Reserved (set to 0)

ALL-Link Group Number for this ALL-Link Record

INSTEON ID high byte for device ALL-Linked to

INSTEON ID middle byte for device ALL-Linked to

INSTEON ID low byte for device ALL-Linked to

Link Information: varies by device ALL-Linked to

Link Information: varies by device ALL-Linked to

Link Information: varies by device ALL-Linked to

Message Returned by IM to Host

Meaning

Echoed Start of IM Command

Echoed IM Command Number

Echoed <Control Code>

Echoed <ALL-Link Record Flags>

Echoed <ALL-Link group>

Echoed <ID high byte>

Echoed <ID middle byte>

Echoed <ID low byte>

Echoed <Link Data 1>

Echoed <Link Data 2>

Echoed <Link Data 3>

0x06 (ACK) if the IM executed the Command correctly.

0x15 (NAK) if an error occurred or the ALL-Link Record doesn’t exist.

Notes

See the section INSTEON All-Link Database in the INSTEON Developer’s Guide

2

for details about the contents of an ALL-Link Record.

Note that except for Find Next, all ALDB searches begin at the top of the ALDB, which means that the

IM will always perform modify or delete operations on the first matching record that it finds in its ALDB.

You must therefore use caution when deleting records because an ALDB may contain multiple

Controller and Responder records matching a given <ALL-Link Group> and <ID>. If you want to delete

Page 41 © 2013 INSTEON

INSTEON Hub: Developer’s Guide only one of the matching records, then you should:

1. Use Find First and Find Next to find and buffer all of the records matching the <ALL-Link

Group> and <ID>,

2. Use Delete First Found enough times to delete all of the matching records,

3. Put back the records you did not want to delete using Modify First Controller Found or Add or Modify First Responder Found or Add.

Please be aware that you can damage an ALDB-L (linear) database if you misuse the Modify First

Found or Add operation, <Control Code> 0x20. For instance, if you zero bit 1 of the <ALL-Link

Record Flags> byte in the first record in an ALDB-L, the ALDB-L will then appear empty. Or, if you zero bit 7 of the <ALL-Link Record Flags> byte in an ALDB-L record, then that record will appear

deleted. In an ALDB-T (threaded) database, the IM handles those bits for you automatically, so the

Modify First Found or Add operation is not so risky. Nevertheless, it is always preferable to use

Modify First Controller Found or Add or Modify First Responder Found or Add instead, because with Modify First Found or Add you cannot be sure if you are modifying a record for a Controller or

Responder.

Page 42 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

IM Status Management

Reset the IM

What it does

What you send

What you’ll get

LED indication

Related Commands

Byte Value

1 0x02

2

0x67

Byte Value

1 0x02

2

3

0x67

<ACK/NAK>

Reset the IM (0x67)

Puts the IM into the IM Factory Reset State

11

, which clears the entire ALL-Link Database.

2 bytes.

3 bytes.

While the reset procedure is being processed, the Status LED will turn off. At the conclusion of the reset procedure, the Status LED will illuminate steadily.

IM 0x55 User Reset Detected

44

Command Sent from Host to IM

Meaning

Start of IM Command

IM Command Number

Message Returned by IM to Host

Meaning

Echoed Start of IM Command

Echoed IM Command Number

0x06 (ACK) if the IM executed the Command correctly

0x15 (NAK) if an error occurred

Notes

The IM will send the <ACK/NAK> byte after it erases the EEPROM.

~20 seconds for models with external EEPROM (for product revisions less than 2.4 or firmware verisons 52 or earlier.

~2 seconds for models with no external EEPROM

Effective with product revisions 2.5 or greater, the reset time is reduced to ~3 seconds.

See the IM Factory Reset State

11

section for complete information on the state of the IM after sending this Command.

Page 43 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

User Reset Detected

What it does

When you’ll get this

What you’ll get

LED indication

Related Commands

User Reset Detected (0x55)

Reports that the user manually put the IM into the IM Factory Reset State

11

.

The user held down the IM’s SET Button for at least 10 seconds when power was first applied.

2 bytes (not until about 20 seconds after applying power to the IM with the SET Button held down).

The LED will turn off for about 20 seconds. Once the LED turns back on the reset is complete.

IM 0x67 Reset the IM

43

Message Sent from IM to Host

Byte Value

1

2

0x02

0x55

Notes

Meaning

Start of IM Command

IM Command Number

The IM will send this message after it erases the EEPROM.

~20 seconds for models with external EEPROM (for product revisions less than 2.4 or firmware verisons 52 or earlier.

~2 seconds for models with no external EEPROM

Effective with product revisions 2.5 or greater, the reset time is reduced to ~3 seconds.

See the IM Factory Reset State

11

section for complete information on the state of the IM after receiving this message.

Page 44 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

Get IM Configuration

What it does

What you send

What you’ll get

LED indication

Related Commands

Get IM Configuration (0x73)

Returns the IM’s Configuration Flags byte. Also returns two spare bytes of data reserved for future use.

2 bytes.

6 bytes.

None.

IM 0x6B Set IM Configuration

46

Command Sent from Host to IM

Byte Value

1 0x02

2

0x73

3

4

5

6

Byte Value

1

2

0x02

0x73

<IM Configuration Flags>

<Spare 1>

<Spare 2>

<ACK/NAK>

Meaning

Start of IM Command

IM Command Number

Message Returned by IM to Host

Meaning

Echoed Start of IM Command

Echoed IM Command Number

IM’s Configuration Flags. See Set IM Configuration

46

for bit definitions.

0x00, reserved for future use

0x00, reserved for future use

0x06 (ACK) if the IM executed the Command correctly

0x15 (NAK) if an error occurred

Note

Because Set IM Configuration

46

sets all of the <IM Configuration Flags> at once, to change an individual bit, first use this Command to determine the current state of all of the <IM Configuration

Flags>.

Page 45 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

Set IM Configuration

What it does

What you send

What you’ll get

LED indication

Related Commands

Set IM Configuration (0x6B)

Allows you change operating parameters of the IM.

3 bytes.

4 bytes.

None.

IM 0x73 Get IM Configuration

45

IM 0x54 Button Event Report

51

IM 0x50 INSTEON Standard Message Received

22

IM 0x51 INSTEON Extended Message Received

23

IM 0x6D LED On

52

IM 0x6E LED Off

53

Command Sent from Host to IM

Byte Value

1 0x02

2

3

0x6B

<IM Configuration Flags>

Meaning

Start of IM Command

IM Command Number

Flag byte containing Configuration Flags that affect IM operation. These all default to 0.

Bit 7 = 1

Disables automatic linking when the user pushes and holds the SET

Button (see Button Event Report

51

).

Bit 6 = 1 Puts the IM into Monitor Mode (see About Monitor Mode

46

in the Notes below).

Bit 5 = 1

Bit 4 = 1

Disables automatic LED operation by the IM. The host must now control the IM’s LED using LED On

52

and LED Off

53

.

Disable host communications Deadman feature (i.e. allow host to delay more than 240 milliseconds between sending bytes to the IM).

Bit 3 = 1 Serial commands to the interface will NAK if it is busy processing an

INSTEON command.

Bits 2 - 0 Reserved for internal use. Set these bits to 0.

Message Returned by IM to Host

Byte Value

1

2

0x02

0x6B

3

4

<IM Configuration Flags>

<ACK/NAK>

Meaning

Echoed Start of IM Command

Echoed IM Command Number

Echoed <IM Configuration Flags>

0x06 (ACK) if the IM executed the Command correctly.

0x15 (NAK) if an error occurred.

Notes

When the IM is in the IM Factory Reset State

11

, the <IM Configuration Flags> will all be set to zero.

This Command sets all of the <IM Configuration Flags> at once. To change an individual bit, first use

Get IM Configuration

45

to determine the current state of all of the <IM Configuration Flags>.

About Monitor Mode

Normally, the IM will only send the host an INSTEON Standard Message Received

22

or INSTEON

Extended Message Received

23

notification when it receives an INSTEON messages directed specifically to the IM. There are three possibilities:

1. The IM received a Direct message with a To Address matching the IM’s INSTEON ID,

2. The IM received an ALL-Link Broadcast message sent to an ALL-Link Group that the IM belongs to as a Responder (i.e. the message’s From Address and ALL-Link Group Number match a Responder entry in the IM’s ALL-Link Database), or

3. The IM received an ALL-Link Cleanup message with a To Address matching the IM’s

INSTEON ID and the message’s From Address and ALL-Link Group Number match a

Page 46 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

Responder entry in the IM’s ALL-Link Database.

In Monitor Mode, the IM will also notify the host of received INSTEON messages that contain a From

Address matching any INSTEON ID in the IM’s ALL-Link Database, even if the To Address does not match the IM’s INSTEON ID or the IM does not belong to an ALL-Link Group associated with the message. In other words, if the message originator is in the IM’s ALL-Link Database as either a

Controller or Responder, the IM will pass the message to the host even if it is not specifically directed to the IM. In this way you can monitor messages between other INSTEON devices as long as the sender is in the IM’s ALL-Link Database.

Please be aware that the IM may not always detect this traffic. If the message originator and addressee are close to one another and the IM is farther away, the message originator may not cause the message to hop enough times for the IM to hear it. To know for sure what an INSTEON device’s status is, you can usually query it directly using an appropriate INSTEON Direct Command. For more information on INSTEON Commands and the latest Command set, please download the current

INSTEON Command Tables Document

2

from http://code.insteon.com

.

Page 47 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

Get IM Info

What it does

What you send

What you’ll get

LED indication

Related Commands

Byte Value

1 0x02

2

0x60

6

7

8

9

Byte Value

1 0x02

2

3

4

5

0x60

<ID high byte>

<ID middle byte>

<ID low byte>

<Device Category>

<Device Subcategory>

<Firmware Version>

<ACK/NAK>

Get IM Info (0x60)

Identifies the IM’s 3 byte INSTEON ID, Device Category (DevCat), Device Subcategory (SubCat), and firmware version.

2 bytes.

9 bytes.

None.

IM 0x66 Set Host Device Category

49

IM 0x73 Get IM Configuration

45

IM 0x6B Set IM Configuration

46

Command Sent from Host to IM

Meaning

Start of IM Command

IM Command Number

Message Returned by IM to Host

Meaning

Echoed Start of IM Command

Echoed IM Command Number

IM’s INSTEON ID high byte

IM’s INSTEON ID middle byte

IM’s INSTEON ID low byte

IM’s Device Category

IM’s Device Subcategory

IM’s Firmware Version

0x06 (ACK) if the IM executed the Command correctly

0x15 (NAK) if an error occurred

Note

Using the Set Host Device Category

49

Command to change the host’s DevCat and SubCat will only affect the data transmitted by the IM to other INSTEON devices during ALL-Linking.

When the host sends this Command to the IM, the IM will return the original DevCat, SubCat and firmware version hard-coded into the IM’s firmware at the factory.

Page 48 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

Set Host Device Category

What it does

What you send

What you’ll get

LED indication

Related Commands

Byte

1

2

3

4

5

Value

0x02

0x66

<Device Category>

<Device Subcategory>

<0xFF | Firmware Version>

Set Host Device Category (0x66)

Lets you set the Device Category (DevCat) and Device Subcategory (SubCat) of the host device connected to the IM.

5 bytes.

6 bytes.

None.

IM 0x60 Get IM Info

48

Command Sent from Host to IM

Meaning

Start of IM Command

IM Command Number

INSTEON Device Category (DevCat) of the host device connected to the IM.

INSTEON Device Subcategory (SubCat) of the host device connected to the IM.

0xFF

In legacy devices this byte represented a BCD-encoded firmware version. The high nibble (4 bits) gave the major revision number and the low nibble gave the minor revision.

In current devices use the INSTEON Product Data Request and Product Data

Response Commands to retrieve the firmware version as user-defined data.

Message Returned by IM to Host

Byte

1

2

3

4

5

6

Value

0x02

0x66

<Device Category>

<Device Subcategory>

<0xFF | Firmware Version>

<ACK/NAK>

Meaning

Echoed Start of IM Command

Echoed IM Command Number

Echoed <Device Category>

Echoed <Device Subcategory>

Echoed <0xFF> or <Firmware Version>

0x06 (ACK) if the IM executed the Command correctly

0x15 (NAK) if an error occurred

Notes

For INSTEON compliance, you must obtain an approved DevCat and SubCat assignment for your host product from SmartLabs.

The IM stores these values in EEPROM so they will not be erased if power is lost.

When the IM is in the IM Factory Reset State

11

, these values will be set to those hard-coded into the

IM’s firmware at the factory.

Using this Command to change the host’s DevCat and SubCat will only affect the data transmitted by the IM to other INSTEON devices during ALL-Linking.

When the host sends a Get IM Info

48

Command to the IM, the IM will return the original DevCat, SubCat and firmware version hard-coded into the IM’s firmware at the factory.

For the latest list of assigned INSTEON DevCats, please download the INSTEON Device Categories and Product Keys Document

2

from http://code.insteon.com

.

Page 49 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

RF Sleep

What it does

What you send

What you’ll get

LED indication

Related Commands

Byte Value

1 0x02

2

3

4

0x72

<Command 1 Data>

<Command 2 Data>

Byte Value

1 0x02

2

3

4

5

0x72

<Command 1 Data>

<Command 2 Data>

<ACK/NAK>

RF Sleep (0x72)

Directs an RF IM to go into power saving sleep mode. To wake up the RF IM, send it one byte of serial data.

2 bytes.

3 bytes.

None.

None.

Command Sent from Host to IM

Meaning

Start of IM Command

IM Command Number

Data byte to place into the Command 1 field 2 of the ACK response.

Data byte to place into the Command 2 field 2 of the ACK response.

Message Returned by IM to Host

Meaning

Echoed Start of IM Command

Echoed IM Command Number

Echoed <Command 1 Data>

Echoed <Command 2 Data>

0x06 (ACK) if the IM executed the Command correctly.

0x15 (NAK) if an error occurred.

Notes

It does not matter what byte you send serially to wake up the RF IM.

When the RF IM wakes up, it will reinitialize, but memory will not be altered as it would be in the IM

Factory Reset State

11

. Wait a minimum of 40 milliseconds before sending any further IM Serial

Commands.

Page 50 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

IM Input/Output

Button Event Report

What it does

When you’ll get this

What you’ll get

LED indication

Related Commands

Byte

1

2

3

Value

0x02

0x54

<Button Event>

Button Event Report (0x54)

Reports user SET Button events.

The user operates the SET Button, or if they exist, Button 2 or Button 3.

3 bytes.

If the event is SET Button Press and Hold the IM will automatically go into ALL-Linking mode which will cause the LED to blink continuously at a rate of ½ second on and ½ second off. Automatic linking may be turned off by setting IM Configuration Flags bit 7 (see Set IM Configuration

46

).

IM 0x53 ALL-Linking Completed

35

IM 0x64 Start ALL-Linking

33

IM 0x65 Cancel ALL-Linking

34

Message Sent from IM to Host

Meaning

Start of IM Command

IM Command Number

Indicates the type of SET Button event that occurred.

0x02 The SET Button was Tapped

0x03 There was a SET Button Press and Hold for more than three seconds.

This automatically puts the IM into ALL-Linking mode unless IM Configuration

Flags bit 7 is set.

0x04

The SET Button was released after a SET Button Press and Hold event was recorded.

0x12 Button 2 was Tapped

0x13 There was a Button 2 Press and Hold for more than three seconds.

0x14 Button 2 was released after a Button 2 Press and Hold event was recorded.

0x22 Button 3 was Tapped

0x23 There was a Button 3 Press and Hold for more than three seconds.

0x24 Button 3 was released after a Button 3 Press and Hold event was recorded.

Page 51 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

LED On

What it does

What you send

What you’ll get

LED indication

Related Commands

Byte Value

1 0x02

2

0x6D

Byte Value

1 0x02

2

3

0x6D

<ACK/NAK>

LED On (0x6D)

Turns on the IM’s LED if IM Configuration Flags bit 5 = 1.

2 bytes.

3 bytes.

The LED will go on.

IM 0x6B Set IM Configuration

46

IM 0x6E LED Off

53

Command Sent from Host to IM

Meaning

Start of IM Command

IM Command Number

Message Returned by IM to Host

Meaning

Echoed Start of IM Command

Echoed IM Command Number

0x06 (ACK) if the IM executed the Command correctly.

0x15 (NAK) if an error occurred or IM Configuration Flags bit 5 = 0.

Page 52 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

LED Off

What it does

What you send

What you’ll get

LED indication

Related Commands

Byte Value

1 0x02

2

0x6E

Byte Value

1 0x02

2

3

0x6E

<ACK/NAK>

LED Off (0x6E)

Turns off the IM’s LED if IM Configuration Flags bit 5 = 1.

2 bytes.

3 bytes.

The LED will go off.

IM 0x6B Set IM Configuration

46

IM 0x6D LED On

52

Command Sent from Host to IM

Meaning

Start of IM Command

IM Command Number

Message Returned by IM to Host

Meaning

Echoed Start of IM Command

Echoed IM Command Number

0x06 (ACK) if the IM executed the Command correctly.

0x15 (NAK) if an error occurred or IM Configuration Flags bit 5 = 0.

Page 53 © 2013 INSTEON

INSTEON Hub: Developer’s Guide

Cancel Cleanup

What it does

What you send

What you’ll get

LED indication

Related Commands

Byte Value

1

2

0x02

0x74

Byte Value

1

2

3

0x02

0x74

<ACK/NAK>

Cancel Cleanup (0x74)

Cancels cleanup from ALL-Link Command

2 bytes.

3 bytes.

None.

IM 0x61 Send ALL-Link Command

29

Command Sent from Host to IM

Meaning

Start of IM Command

IM Command Number

Message Returned by IM to Host

Meaning

Echoed Start of IM Command

Echoed IM Command Number

0x06 (ACK) if the IM executed the Command correctly.

0x15 (NAK) if an error occurred.

Page 54 © 2013 INSTEON

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement

Table of contents
