XSA 5.5 Administration Guide

XSA 5.5 Administration Guide

© 2015

Xerox Secure Access Unified

ID System® 5.5

Administration Guide

Xerox Secure Access Unified ID System® 5.5 Administration Guide

Document Revision History

Revision Date

June 26, 2015

September 12, 2014

March 31, 2014

November 7, 2013

Revision List

• Updated for software version 5.5

• Updated for software version 5.4

• Updated for software version 5.3

• Initial document release

© 2015 Nuance Communications. All rights reserved.

All rights to this document, domestic and international, are reserved by Nuance Communications. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means (electronic, mechanical, photocopying, recording, or otherwise) without prior written permission of Nuance.

Trademarks

Equitrac

® and Follow-You Printing

®

are registered trademarks of Nuance Communications.

All other brands and their products are trademarks or registered trademarks of their respective holders, and should be noted as such.

Symbols Used In This Guide

The following symbols are used in the margins of this guide:Xerox Secure Access Unified ID System® Administration Guide

Note

Caution

Warning

The accompanying text provides cross-reference links, tips, or general information that can add to your understanding of the topic.

The accompanying text provides key information about a step or action that might produce unexpected results if not followed precisely.

Read the accompanying text carefully. This text can help you avoid making errors that might negatively affect program behavior.

Xerox Secure Access Unified ID System® Administration Guide

Contents

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

What is Xerox Secure Access? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Core Server Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Core Accounting Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Document Routing Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Device Control Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Administering Xerox Secure Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

System Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Licensing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Xerox Secure Access Licensing Workflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Component License Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Changing the License View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Assigning Licenses to Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Additional Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

2 Managing Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Devices Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Device Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Managing Secure Printing Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Physical Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Physical Device Configuration Workflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Manually Adding and Configuring a Physical Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Creating Managed Print Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Configuring Physical Devices with the Printer Configuration Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Configuring a Printer Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Configuring Print Queues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Editing and Removing Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Control Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Supported Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Adding and Configuring a Control Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Associating a Control Terminal With a Physical Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Configuring SNMP Communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

3 Using Single Function Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Single Function Terminals Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Nuance ID Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Hardware Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Xerox Secure Access Unified ID System® Administration Guide 3

Contents

Setting Up the ID Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Connecting the ID Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Determining the ID Controller IP Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Configuring the ID Controller via a Web Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Integrating the ID Controller into Equitrac . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Configuring the ID Controller in System Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

User Authentication at the Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Offline Behavior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

4 Creating & Managing Accounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Accounts Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Why Use Accounts? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

User Account . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Working with User Accounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Creating User Accounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Adding and Editing Users Individually . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Importing Users with Active Directory Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Configuring Active Directory Synchronization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Active Directory LDS Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Configuring LDAP Synchronization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

LDAP Field Mapping to CAS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Qualifying Accounts by Domain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Adding Users from a Flat File Import . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Importing LDAP User Accounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Managing User Accounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Locking Accounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Removing Accounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Managing Search Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Managing the Filter List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Accounts System Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

User Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

External User Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Deleting Objects in Synchronized Directories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Associating Swipe Cards with Secure Access Accounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

5 Advanced Printing Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Enabling Secure Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Secure Printing Configuration Workflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Administering the Secure Print Queue . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

4 Xerox Secure Access Unified ID System® Administration Guide

Contents

Managing Device Pull Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Choosing Devices to Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Printer Pull Group Workflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Setting Up Follow-You Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Follow-You Printing Configuration Workflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Identifying the Home Server for each User . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Configuring Follow-You Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

6 Configuring HID Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

HID Encoding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Supported HID Card Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Determining HID Card Encoding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Disabling and Enabling HID Decoding on the Control Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

HID Decoding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

7 Using Xerox Secure Access Utilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Enabling SSL Communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

Directory Synchronization Access Permissions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

Purge Database Transactions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106

Modifying User Accounts from a Flat File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

EQCmd Actions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108

EQCmd Batch File Process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110

Refining the User Group View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Print Queue Viewer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

Xerox Secure Access Unified ID System® Administration Guide 5

Contents

6 Xerox Secure Access Unified ID System® Administration Guide

Introduction

1

Topics

What is Xerox Secure Access?

Core Server Components

Administering Xerox Secure Access

Licensing

Additional Documentation

After you successfully install Xerox Secure Access Unified ID System

®

and perform initial configuration tasks outlined in the Xerox Secure Access Unified ID System® Installation Guide, you can further customize your deployment. Use this guide to perform advanced configuration tasks for all components and features of Xerox Secure Access.

This chapter provides information about:

• key features of Xerox Secure Access used in business environments

• Administrative Applications that enable system configuration and ongoing management

• limiting access to the Administrative Applications to prevent unauthorized users from making changes to system components or printing accounts

• purchasing licenses to enable core and optional functionality

Xerox Secure Access Unified ID System® Administration Guide 7

Chapter 1: Introduction

What is Xerox Secure Access?

Xerox Secure Access is a software-based print tracking and document accounting solution that reduces print expenses, eliminates wasteful printing, deploys equipment for maximum efficiency, and even contributes to a better environment. Xerox Secure Access allows you to track, analyze and, if necessary, allocate expenses for every document that any employee sends to any networked printer, copier or multi-function device.

Xerox Secure Access is an ideal solution for businesses because it provides the following features:

Authentication happens when the user approaches a device and authenticates themselves with valid user credentials. Desktop Printing is not considered authentication.

Secure Printing holds documents sent to print in a proprietary queue until a user releases the job via an MFP embedded device. This prevents situations where proprietary documents sit at the printer for all users to see until the user picks up the job.

Follow-You Printing

®

holds print jobs in a secure print queue and allows the user to release the print jobs to a compatible device, even across print servers. A user can select a particular printer when they submit a print request, then use any MFP embedded device and redirect the job to a different compatible printer.

8 Xerox Secure Access Unified ID System® Administration Guide

Chapter 1: Introduction

Core Server Components

Xerox Secure Access is comprised of the following main core server components:

• Core Accounting Server (CAS)

• Document Routing Engine (DRE)

• Device Control Engine (DCE)

There are three main core components, every Xerox Secure Access installation requires at least the Core Accounting

Server (CAS) and either a Document Routing Engine (DRE) or a Device Control Engine (DCE).

The components can be installed on a single server, or you can distribute the components across multiple servers to distribute the print load tracking or device management activities.

The core server components communicate on designated ports. Each component "listens" on a specific port for information or requests from the other components. Refer to the Xerox Secure Access Unified ID System® Installation

Guide for a complete list of port assignments per component.

Making Changes to Server Components

If you make configuration changes within System Manager to any of the core Xerox Secure Access server components

(CAS, DRE, DCE), such as changing printer languages, you must wait a minimum of thirty seconds before these changes take effect.

The delay in updating server components is a function of the CAS polling feature. This means that the delay may be longer in the event that CAS is unavailable for some reason during that polling period after the server changes. CAS sends the change data to the relevant components once the connection is restored.

Core Accounting Server

The Core Accounting Server (CAS) verifies users, calculates transaction charges, and assigns those charges to an appropriate user or group account. CAS calculates charges using page count and job attribute information received from the Port Monitor, along with printer costs defined by the administrator.

• user verification

• print charge calculations

• output tracking

• account balance management

Xerox Secure Access Unified ID System® Administration Guide 9

Chapter 1: Introduction

Every Xerox Secure Access installation requires a pre-installed database. CAS uses the database instance to create an accounts database that contains all printer, user, transaction, and balance information. The database can reside on the same machine as CAS, or on a separate server if needed. See System Requirements in the Xerox Secure Access Unified ID

System® Installation Guide for information about supported databases.

For installations that support a large user base, or where you support remote office locations, you may need to deploy multiple accounting servers.

Document Routing Engine

The Document Routing Engine (DRE) is the print server. Its primary function is to enable document flow from user workstations to output devices such as printers, plotters, or MFPs and capture the document characteristics of all output. Each time a user releases a print job, DRE communicates the job characteristics to CAS.

The Managed Print Port Monitor is installed with each DRE. The Port Monitor integrates with the Windows

®

printing subsystem and functions as part of the spooler service, allowing the Port Monitor to receive and route print jobs to parallel network-connected printers.

If there are many printers within your deployment that generate frequent throughput, you may need to deploy multiple DREs. You can designate specific printers to each DRE, balancing the overall load to streamline the data flow.

The diagram below shows a typical DRE workflow. First, a user generates a print request. The DRE Port Monitor intercepts the request before it gets to the printer and "holds" the print job while it waits for a user validation response from CAS. CAS then checks its database and either validates the user, or denies the request. The response is sent back to DRE, and the print job is forwarded to the printer if the user was validated. If denied, the user receives a notification message on their desktop (if configured). After the job is printed, the page count and job attributes are forwarded to the CAS database for tracking.

1

Print Request

2

Validate Print Request

Port

Monitor

3

Job is Printed

4

Update Job Attributes

DRE

Basic DRE workflow used to measure print usage

CAS

DB

For installations that require secure document printing, you can configure DRE to hold documents in a print queue until the user releases them from an embedded device. See

Enabling Secure Printing

on page 80 for details.

10 Xerox Secure Access Unified ID System® Administration Guide

Chapter 1: Introduction

Although DRE is a core component, it is not required in all deployments. DRE manages communications with physical printing devices. If you are only tracking copy transaction on devices with embedded devices (rather than tracking print jobs), you do not need to install the DRE component.

DRE functionality can be configured in System Manager.

Device Control Engine

The Device Control Engine (DCE) provides communication with copy and fax devices and with multifunction devices that provide fax and scan features. You must install specific embedded devices or terminals to enable

communication with these devices. See

Control Terminals

on page 33 for details.

DCE communicates with CAS to verify user credentials, and forwards the copy and fax information generated by these devices for tracking in the accounting database.

The diagram below shows a basic DCE workflow. First, a user requests access to a multi-function device via a terminal keypad. The request is handled by DCE, which then forwards a user validation request to CAS. CAS then checks its database and either validates the request, or denies it. After the user completes their copy, fax, or scan, the job attributes are forwarded to CAS for tracking.

2

Validate Login Request

1

Login Requested

3

Update Job Attributes

DCE

Basic DCE workflow used to measure multifunction device usage

DB

CAS

Although DCE is a core component, it is not required in all deployments. If you intend to track printing from workstations only, and do not need to track copy, scan, or fax jobs, you do not need to install the DCE component.

Instead, you need the DRE component only.

Xerox Secure Access Unified ID System® Administration Guide 11

Chapter 1: Introduction

Administering Xerox Secure Access

The majority of Xerox Secure Access Server administration takes places in the Administrative Applications. These applications are typically installed on the Core Accounting Server (CAS), but can also be installed on any server or workstation within the deployment for ease of administration.

NOTE: When you install System Manager on a workstation other than the CAS, you must have administrator rights on the CAS to run it.

By default, the installer places the Administrative Applications on the Start menu. (Start > All Programs > Xerox

Secure Access).

Before you can access the Administrative Applications, you must select the accounting server that you want to work with. The accounting server collects information from, and writes to, a single accounts database, so you can connect to only one accounting server at a time.

If you deployed multiple

CAS servers, each CAS is listed in this window.

If you deployed multiple CAS servers, the Select accounting server dialog box displays each time you open an

Administrative Application, and you need to select the appropriate CAS before proceeding. If you only have one CAS, you can disable this feature by unchecking the Display at startup option. However, if you disabled the Display at startup option, and later need to access a different CAS, select Tools > Options within any of the Administrative

Applications, and check the Display server selection dialog on startup option. The next time you launch an

Administrative Application, the Select accounting server dialog box opens.

12 Xerox Secure Access Unified ID System® Administration Guide

Chapter 1: Introduction

System Manager

System Manager allows Administrators to perform advanced configuration and maintenance tasks. System Manager controls system-wide configuration and integration settings, as well as the behavior of the accounting server, the

Managed Print Port Monitor on local and remote print servers. You can install System Manager on CAS or on any

Windows workstation on the network.

The System Manager interface is divided into sections. The Manager tools are listed beneath the current CAS System heading. When you make a selection from these tools, the contents of the right pane update to show the available options. Alternatively, you can select a task from the Current tasks list, although for some options, such as

Configuration, tasks are listed only in the right pane.

Xerox Secure Access Unified ID System® Administration Guide 13

Chapter 1: Introduction

Licensing

The Xerox Secure Access software comes with a unique serial number. When you supply this product serial number and the machine name on which you are installing the software, you are provided with an activation code that is proof of registration.

For more information on obtaining activation codes and registering licenses in System Manager after the initial installation, refer to the Xerox Secure Access Unified ID System® Installation Guide.

When Xerox Secure Access is installed for the first time on a specified machine, a limited default license is generated and applied during installation. The auto-generated default license allows full operation of System Manager’s features for 45 days, however, there is a limit of only one of each licensable item.

After installation, obtain and register the Base and Feature component licenses in the System Manager Administrative

Application before the 45 day default license expires. A new default license cannot be generated by reinstalling Xerox

Secure Access on the same machine. When applying the full licenses, the default license is automatically overwritten.

For more information on obtaining activation codes and registering licenses in System Manager after the initial installation, refer to the Xerox Secure Access Unified ID System® Installation Guide.

Xerox Secure Access Licensing Workflow

1

2

The Xerox Secure Access solution requires a combination of a Base license (with a system expiry date) and the desired feature licenses. Xerox MPS licensing needs to be applied in the following order:

Obtain and install a Base license.

Obtain and install any feature licenses as required.

NOTE: Some feature licenses may require that another feature license is installed as on the system as a prerequisite.

For example, the Follow-You Printing license requires an Authentication license already installed on the system.

3

Once the desired licenses are installed, they need to be assigned to devices in the License Assignment View in

System Manager.

Component License Structure

The Xerox Secure Access system utilizes a licensing structure which allows licenses to be assigned on a per device basis.

Authentication – Any time the user approaches a device and authenticates themselves, they are using an

Authentication license. Desktop Printing is not considered authentication.

• Licenses are assigned per device where authentication is required.

• Does not require a prerequisite.

Follow-You Printing – Allows the user the ability to release a job from a device with this license assigned to it.

• License are assigned per device where Follow-You Printing is required.

• Requires an Authentication license as a prerequisite.

14 Xerox Secure Access Unified ID System® Administration Guide

Chapter 1: Introduction

Changing the License View

You can change the view in System Manager’s right pane if you need to see specific information:

License View lists all currently licensed components.

Assignment View lists all assigned component licenses, the date on which Xerox Secure Access last assigned the license to a component connecting to CAS, and the number of licenses assigned.

Xerox Secure Access Unified ID System® Administration Guide 15

Chapter 1: Introduction

Assigning Licenses to Devices

2

3

Licenses must be assigned to each printer that will use that particular feature.

To assign a license, do the following:

1

Open System Manager, and select Licensing in the left pane.

Select the Assignment View tab to open the list of all assigned licenses.

Expand or right-click the desired license option, and select Add to open the Assign license dialog box.

4

5

On the Assign license dialog box, select the checkbox for the device(s) to assign the license to.

At the bottom of the dialog box is a counter displaying the number of available licenses and available devices.

These numbers decrease with every license assigned.

Click OK after the licenses have been assigned to the desired devices.

The devices assigned to the license now display under the selected license option.

To remove an assigned license from a device, right-click the device and select Remove assignment. The number of used licenses will be adjusted accordingly.

16 Xerox Secure Access Unified ID System® Administration Guide

Chapter 1: Introduction

Additional Documentation

To learn more about the advanced features and functionality of the Xerox Secure Access Suite(s), refer to the table below to determine the Guide you need.

For a complete list of product specification and system requirements, contact your Equitrac representative.

Guide

Planning Guide

Installation Guide

Cluster Deployment Guide

Embedded Guides

When to refer to this guide

Prior to installing Xerox Secure Access, read this guide to understand how to deploy Xerox Secure Access on your network.

Use this guide to perform an initial installation or upgrade.

If you are deploying Xerox Secure Access in a cluster environment, use this guide to plan the installation.

Use these specific guides for Xerox embedded devices.

Print Server Module Guides:

UNIX

Linux SUSE

If your deployment utilizes a UNIX print server, use this guide to configure the print server after the installation is completed.

If you plan to deploy Xerox Secure Access components across a cluster, use the

Cluster Deployment Guide for planning and implementation.

Xerox Secure Access Unified ID System® Administration Guide 17

Chapter 1: Introduction

18 Xerox Secure Access Unified ID System® Administration Guide

2

Managing Devices

Topics

Devices Overview

Physical Devices

Control Terminals

Configuring SNMP Communication

Xerox Secure Access can track transaction data from many different device types. From physical printers to virtual queues, to control terminals, Xerox Secure Access can be configured to meet the needs of any size organization. All devices you want to track must be registered in the Xerox Secure Access database.

Instructions to install all device types are provided in the Xerox Secure Access Unified ID System® Installation Guide.

This chapter provides information to help you make changes to existing device configuration, and to manage devices over time.

This chapter provides information about:

• the various device types and capabilities that Xerox Secure Access supports

• setting up each device in System Manager

• configuring device capabilities and options

Xerox Secure Access Unified ID System® Administration Guide 19

Chapter 2: Managing Devices

Devices Overview

Xerox Secure Access can track and control printing to many different types of devices. Each device must be registered in the Xerox Secure Access database. When a user accesses a registered device, Xerox Secure Access tracks and sends the transaction data to CAS.

There are two different ways that device registration can occur:

• Configure each device to use the Managed Print Port Monitor

Each device on a DRE print server that you want Xerox Secure Access to track must communicate with the

Managed Print Port Monitor. For a new device, set the port to an Managed Print Port. If you print a test page when configuring the port, the queue is created automatically and appears within System Manager. For existing devices, convert the port to an Managed Print Port. See

Creating Managed Print Ports

on page 25.

• A print request is sent to a device for the first time

DRE registers a print queue and port for a physical device the first time a print request is sent to the unknown device. The device is displayed within System Manager.

Device Types

Xerox Secure Access can control printing to multiple device types. When a user accesses a registered device, Xerox

Secure Access tracks and stores the data to CAS.

Physical Devices – The actual piece of hardware that prints or copies. Physical devices include select devices that also copy, scan or fax. Xerox Secure Access adds physical devices to the database automatically when you use

Windows to add a print queue, or when you add and configure printers for a UNIX print server.

Embedded Devices – Embedded devices are the connections to physical devices that track transactions.

When working with devices, you can change the view in System Manager to make it easier to find and manage devices.

The different views available are: Standard view, Server view, Type view, Custom group view, Routing group view, and

Workstation view.

To sort devices in any view, click a column title to sort that column alphabetically. Click the column title again to sort in reverse-alphabetical order. Click and drag the column widths individually to enhance the current view, or to hide a column that you do not want to display. Additionally, you can right-click the column title bar and select Secure

printing from the list. The Secure printing column can be made visible in all views except the Workstation view. By

default, this column is not visible, and must be selected from the title bar options.

When the Secure printing column is visible, the secure printing setting of the physical devices and print queues are displayed. See

Managing Secure Printing Settings

on page 21 for more details on configuring and managing the

secure printing settings.

20 Xerox Secure Access Unified ID System® Administration Guide

Chapter 2: Managing Devices

Managing Secure Printing Settings

When working with devices in System Manager > Devices, you can add an optional Secure printing column to make it easier and manage device secure printing settings. The Secure printing column is available in the Standard view,

Server view, Type view, Custom group view, and Routing group view. This column is not available in the Workstation view. By default, this column is not visible, and must be added to the desired view(s).

To add the Secure printing column to any of these views, right-click the column title bar and select Secure printing from the list. When the Secure printing column is visible, the secure printing setting of the physical devices and print queues are displayed. Physical devices display the Secure printing default setting of the physical device configuration in this column. Print queues display the existing Secure printing setting of its configuration, and displays the actual secure printing state for that queue—either Enabled or Disabled.

The Secure printing options for physical devices are:

New queue: use system default – secure document release is set to Enabled or Disabled as the global Secure

printing default for Follow-You Printing as configured in System Manager > Configuration > DRE/DRC and

Follow-You Printing.

If the Secure printing default is configured as Enabled (or Disabled), and the physical device displays New queue: use default, the newly created print queue will be set to Enabled (or Disabled) accordingly.

New queue: enabled – secure document release is enabled on the newly created print queue.

If the physical device displays New queue: enabled in the Secure printing column, then the newly created print queue will be set to Enabled.

New queue: disabled – secure document release is disabled on the newly created print queue.

If the physical device displays New queue: disabled in the Secure printing column, then the newly created print queue will be set to Disabled.

The terminology ‘New queue’ denotes that the setting applies to newly created print queues that are defined automatically.

You can change the secure printing settings of physical devices or print queues, and apply these changes to more than one device at a time. For example, you can select multiple devices and set the secure printing value to New queue:enabled, which in turn will set any newly created print queues for the specified devices to Enabled.

Xerox Secure Access Unified ID System® Administration Guide 21

Chapter 2: Managing Devices

Physical Devices

A physical device is the piece of hardware that performs the print, copy, scan, or fax. Xerox Secure Access can track usage on any physical device that is registered in System Manager.

Within Xerox Secure Access, a physical device has three components:

Device – the device name is registered in the Equitrac database and is used to manage the main device characteristics. device, port, and queue.

Port – a port connection on the device that works with the Managed Print Port Monitor to track printed documents sent to the device. The Port Monitor communicates with DRE or DCE to control the job requests made to the device.

Queue – A virtual list of jobs waiting to print on the device.

You do not have to manually create the three components. Instead, you create the printer using the Operating System’s

(Windows/UNIX) Add Printer utility and assign the Managed Print Port Monitor to the device. Xerox Secure Access automatically adds print queues and port connections to the database when a user prints to the device for the first time.

Physical Device Configuration Workflow

The workflow for configuring physical devices within Xerox Secure Access is quite simple:

1

2

3

4

If it is a new device, use the Operating System’s Add Printer functionality to create the printer definition to use an

Managed Print Port.

You can either create a new device with a standard TCP/IP port and then convert it to an Managed Print Port, or you can create an Managed Print Port directly. See

Creating Managed Print Ports

on page 25.

The port and the queue are created automatically, the first time a user prints to the device.

The first time a user prints to the device, the Managed Print Port Monitor on the device contacts DRE, then the queue and port are created automatically. However, to register the device immediately, send a test job the printer yourself to force the registration to occur within the Secure Access database.

Verify the device in System Manager.

Open System Manager, and switch to Devices. Within thirty seconds to a minute after registering the device, the device appears in System Manager. If you do not see a device, first try refreshing System Manager. CAS requires a few moments to complete the communication requirements with the device and DCE or DRE before it can populate the information in System Manager.

Edit the physical device summary.

22 Xerox Secure Access Unified ID System® Administration Guide

Chapter 2: Managing Devices

Manually Adding and Configuring a Physical Device

When you add and configure printers using the Managed Print Port Monitor on a printer server, Xerox Secure Access automatically adds the device to the CAS database when the printer port contacts DRE.

DRE registers a print queue and port for the physical device with the Xerox Secure Access database the first time a user prints to that device.

CAUTION: Ensure that you apply licenses before managing devices in Windows and configuring devices in System

Manager. If you add licenses after adding physical devices, the print queues do not show up in System Manager until

15 minutes of time expires. After Xerox Secure Access is licensed, a job is printed to the printer or the DRE service is restarted, which registers the devices and populates System Manager.

1

2

In System Manager, select Devices in the left pane.

Select Add physical device under Current tasks, or right-click anywhere in the right pane and select Add

physical device from the menu.

3

4

5

6

7

Enter a Name, Hostname/IP address, and Description for the physical device.

Select the appropriate Manufacturer and Model for the physical device from the drop-down lists.

Enter Monthly volume, Speed (in pages per minute), and descriptive location data in the appropriate fields.

Verify the detected color capability setting in the Monochrome settings field. This setting is automatically detected based on the SNMP data, but you can change the option to Monochrome if you want all printed documents to be counted as monochrome, even when color is printed.

Select an SNMP configuration set from the drop-down list.

The device Type displays Physical device.

The Hardware address automatically displays when the device contacts DRE.

NOTE: Pricing does not apply to Xerox Secure Access.

Xerox Secure Access Unified ID System® Administration Guide 23

Chapter 2: Managing Devices

8

9

Set the Release behavior options. Leave the default setting unless you are setting up Print pull groups. See

Managing Device Pull Groups

on page 82 for details.

Change the settings, as required:

Physical Device Settings Description

Rule set Rule Sets do not apply to Xerox Secure Access

Print language

Track mailbox & proof printing

Change the default printer language settings that are used by this device.

Select At output time when printing is being tracked by an Managed Print Port.

Select At send time when printing is being tracked locally by polling the device for print activity.

DME servers do not apply to Xerox Secure Access DME server

Secure printing default Select System default to use the global secure printing default for new devices and existing physical devices on upgrade.

Select Enabled or Disabled to override the system default setting for individual or grouped physical devices.

10

Click OK to save the physical device configuration settings.

24 Xerox Secure Access Unified ID System® Administration Guide

Chapter 2: Managing Devices

Creating Managed Print Ports

Xerox Secure Access uses specialized ports to track print devices. Each monitored device must use an Managed Print

Port. Depending on your printing hardware, you may need more than one port using the Managed Print Port Monitor on a print server. You can configure a new printer definition that uses the Managed Print Port Monitor.

You can create Managed Print Ports directly for new devices, or convert existing devices from standard TCP/IP ports into Managed Print Ports. For new devices, see

Add a Printer on an Managed Print Port

(below). Alternatively, new

devices can be created using standard TCP/IP ports and then converted it to an Managed Print Port. For existing devices,

Convert an Existing TCP/IP Port to Managed Print Port

on page 26. Converting from TCP/IP to Managed

Print Ports allows them to be quickly converted back to TCP/IP ports to determine if reported errors within the print environment are due to the Equitrac server or the normal print environment.

NOTE: If you are working in a cluster environment, these instructions do not apply. See the Cluster Deployment Guide to set up Managed Print Ports for clusters.

Add a Printer on an Managed Print Port

To create Managed Print Ports for new devices, do the following:

1

2

3

4

5

6

7

8

Using the standard Windows interface, open the Add Printer wizard.

Follow the prompts to add a local printer and create a new port.

Select Managed Print Port as the type of port you want to create and click Next.

The Add Managed Print Port wizard displays and you are prompted to ensure that the printer device is turned on, connected to the network, and properly configured. Click Next to continue.

Click Next and select Physical printer as your Device Type from the drop-down list.

Specify a Printer name or IP Address. The wizard supplies a Port name prefaced with "EQ_" based on the printer name or IP address. If another naming convention is preferred, rename the port accordingly.

Click Next to continue with the port configuration options. The Port Configuration screen displays. The Detected

device information displays automatically if the wizard is able to collect this data

Convert an Existing TCP/IP Port to Managed Print Port

on page 26 from the printer.

Select the Use custom settings option:

9

• If you select Raw port communication, identify the TCP Port number, and specify if the port monitor should hold the connection open.

• If you select LPR, specify the name of the print Queue on the physical device (e.g. PORT1).

• If you select Specific device, select the appropriate Manufacturer and Model from the drop-down lists. The device uses the relevant default communications parameters based on these selections.

Click Next and specify the Physical device name. This is the name of the device that is displayed within System

Manager.

10

Review the details for this new port and device registration, and click Finish to close the Add Managed Print Port wizard, or Back to change any of the settings.

11

Specify the Manufacture and model to install the printer driver, and click Next.

Xerox Secure Access Unified ID System® Administration Guide 25

Chapter 2: Managing Devices

NOTE: If the device is part of a pull group, it must use the same drivers as all other devices in the pull group. You must select the model of the pull group driver, not the model of the device. If DRE is a 64-bit server you must remember to also load the 32-bit driver to the server.

12

Specify the version of the print driver to use, and click Next.

13

Enter the Printer name, and click Next. This is the name of the device that is displayed in System Manager.

14

Select to share or not to share the printer with others, and click Next. If sharing the printer, enter a Share name, and optionally provide a printer location and any comments.

15

Click the Print a test page button, and click Finish to close the Add Printer wizard.

16

Confirm that the test page printed successfully.

17

Verify that the physical device and its printer port and print queue appear in System Manager > Devices.

Convert an Existing TCP/IP Port to Managed Print Port

2

3

Use the Printer Configuration Wizard to convert from a TCP/IP port to Managed Print Ports. Converting from TCP/

IP to Managed Print Ports allows them to be quickly converted back to TCP/IP ports if desired.

To convert from TCP/IP printer ports to Managed Print Ports, do the following:

1

4

Select Start > All Programs > Xerox Secure Access > Printer Configuration Wizard.

Click Next on the Welcome screen to continue with the conversion.

Select Convert printers to use Managed Print Ports, and click Next. Optional – Uncheck Auto-discover model if the printers are off-line or have SNMP disabled. If selected, the wizard sends an SNMP request to each device, and then times-out on each failed connection attempt, greatly increasing the time to run the conversion.

Select the desired print server(s) from the list, and click Next. Optionally, enter the name of other print servers in the Add field, and click the Add button to place them in the PrintServer list. Print servers can only be added one at a time.

26 Xerox Secure Access Unified ID System® Administration Guide

Chapter 2: Managing Devices

5

Select the printer(s) to be converted, and click Next. If a printer exists on more than one print server, it displays multiple times in the Printer list along with the name of its associated server in the PrintServer list.

6

Set the Printer Name and Port Name as they will display in the System Manager Devices view. You can use the default naming templates for the printer "<ip>_<printer>" and port "EQ_<ip>", or change the names as desired.

Typing over the <ip> value, automatically replaces the printer IP address.

Typing over the <printer> value, automatically replaces the print queue name. For example, you can change the printer default "<ip>_<printer>" to

"2nd floor <printer>" to associate the selected printer(s) with the 2nd floor in your environment, or you can remove "<printer>" from the name to only display the printer’s IP address in System Manager

NOTE: The printer and port names can be changed individually or as a group. If multiple printers are selected, the naming convention affects the entire selection.

Xerox Secure Access Unified ID System® Administration Guide 27

Chapter 2: Managing Devices

7

On the Properties page, select the properties you want to assign to the printers from the SDR and Pull Group drop-down lists, and then click Next. The properties can be applied to single or grouped printers. Rule Sets do not apply to Xerox Secure Access.

8

9

On the Price Lists page, click Next to skip this page. Price Lists do not apply to Xerox Secure Access.

Click Finish to complete the conversion process. Alternatively, you can select the Return to Start checkbox and click Next to return to the Wizard’s main page without completing the conversion.

10

Open the Printers and Faxes window, and print a test page for EACH converted printer.

11

Confirm that the test page printed successfully.

12

Verify that the physical device and its printer port and print queue display in System Manager > Devices.

Configuring Physical Devices with the Printer Configuration Wizard

1

2

Use the Printer Configuration Wizard to reconfigure existing Xerox managed printers. The wizard allows for properties such as pull groups and SDR to be set across multiple devices simultaneously.

To configure existing Xerox managed printers, do the following:

3

4

Select Start > All Programs > Xerox Secure Access > Printer Configuration Wizard.

Click Next on the Welcome screen to continue with the conversion.

Select Configure Xerox Managed Printers, and click Next. Optional – Uncheck Auto-discover model if the printers are off-line or have SNMP disabled. If selected, the wizard sends an SNMP request to each device, and then times-out on each failed connection attempt, greatly increasing the time to run the configuration.

On the Properties page, select the properties you want to assign to the printers from the SDR and Pull Group drop-down lists. Rule Sets do not apply to Xerox Secure Access. The properties can be applied to single or grouped

28 Xerox Secure Access Unified ID System® Administration Guide

Chapter 2: Managing Devices

printers. Multiple Pull groups can be assigned by entering a semi-colon separated list of groups in the Pull Group field.

5

6

On the Price Lists page, click Next to skip this page. Price Lists do not apply to Xerox Secure Access.

Click Finish to complete the configuration process. Alternatively, you can select the Return to Start checkbox and click Next to return to the Wizard’s main page without completing the configuration.

Configuring a Printer Port

To view the port in System Manager, switch to Devices, then select Standard View. Expand the device that you want to modify, then click to view the port summary.

Option

Name

Description

Description

The name for the port. By default, the port is assigned the device IP Address.

A text description of the port that appears in System Manager. The description should reflect the device name that the port belongs to, or the location where the device is located.

Xerox Secure Access Unified ID System® Administration Guide 29

Chapter 2: Managing Devices

Option

Description

Server

Type

Port number

Queue print server

Proxy IP address

Pricing

Rule set

Connectivity

Displays the local print server. This field is provided for information only.

Indicates that you are viewing information about a port.

Displays the currently configured TCP/IP port number for this port.

Displays the name of the DRE print server that manages this port.

Use this field to identify the print queue name of the printers using a Passthrough port. In order to retrieve SNMP data from the DME console, the Hostname/IP address field in the Physical device

summary dialog box should contain the IP address of the physical printer.

Pricing does not apply to Xerox Secure Access.

Rule sets do not apply to Xerox Secure Access.

You can edit this field only when the port communication type is set to RAW. This option does not apply to LPR and Passthrough ports.

Choose Hold port Open to ensure that users can only print to the device through the print server, preventing users from bypassing the accounting server and establishing an exclusive connection to the network printer.

Choose Close port on completion to share the printer connection with other non-Equitrac printer definitions.

Notification page

Uses printer job language (PJL)

Determines if users are notified when print errors occur on this port.

Enable this option for Print Job Language (PJL) compatible devices. If the user cancels printing mid-job, Xerox Secure Access combines the information from the Datastream Interpreter (DSI) and the PJL page count to determine an accurate page count and document details.

When disabled, Xerox Secure Access uses only the DSI page counting method configured at the physical device level.

Note: Enabling PJL support may reduce the throughput speed of the device.

Uses SNMP counting If the user cancels printing mid-job, or there is a printer error, Xerox Secure Access combines the information from the DSI and the SNMP page count to determine how many pages were printed.

In order for SNMP page counting to work, only one port can talk to the MFP.

Idle timeout When SNMP counting is selected, you can set the idle timeout value in seconds for the amount of time that the device has been in idle state since the job was canceled. Once this time is reached,

Xerox Secure Access assumes the printing is complete and polls the device again to determine how many pages were printed.

30 Xerox Secure Access Unified ID System® Administration Guide

Chapter 2: Managing Devices

Configuring Print Queues

When a user prints to a physical device for the first time, a print queue is created for the device automatically. The new queue uses default settings only, so make modifications to the queue as soon as possible.

To view the queue in System Manager, select Devices. Expand the device that you want to modify to view the port, then expand the port to view the queue.

In the Print Queue Summary dialog box, you can set these options:

Option

Description

Pricing

Secure Printing

Rule set

Separator page

Description

A text description of the queue that appears in System Manager. Enter a good description if you commonly use the Type view. The description should reflect the device name that the queue belongs to.

Pricing does not apply to Xerox Secure Access.

Enable this option to hold all jobs in a virtual print queue, rather than forwarding the jobs directly to the device for immediate output.

Secure printing is disabled by default.

Rule sets do not apply to Xerox Secure Access.

Prints a specific print separator before each job released from this queue.

Xerox Secure Access Unified ID System® Administration Guide 31

Chapter 2: Managing Devices

Editing and Removing Devices

You can edit the properties of a physical device, print queue, port, embedded device or control terminal at any time.

Changes can be made to more than one device at a time. For example, if you want to set secure printing on all queues, select the queues, then set secure printing on all devices at once.

When multiple devices are selected, the summary dialog box opens and disables any properties that are not shared among the devices. For example, the Name and Hostname/IP address fields are blank in the dialog box and are not editable. If the settings on the devices do not match, Xerox Secure Access displays the lists and options as empty fields.

You can edit these fields, which in turn changes the field on every selected device, or leave the option “empty” to keep the existing settings.

A device can be deleted at any time. In System Manager, right-click the device, and select Delete from the list. If the device was tracked using DME, it no longer appears in the DME console.

Deleted devices cannot be re-added to the database as the same device. The database assigns a unique identifier to each device, and a record of the device is kept in the database even after the device is deleted from System Manager. If you delete a device and need to re-add it, you must choose a unique device name.

32 Xerox Secure Access Unified ID System® Administration Guide

Chapter 2: Managing Devices

Control Terminals

Control terminals are small network devices that are installed on or near printers, copiers, or multi-function devices.

Control terminals enable users to release print jobs securely at the printer. Control terminals can also track copy transactions through a copy control cable connected to the copier.

Supported Devices

Xerox Secure Access supports the PageCounter Mini. This device can only be configured for Release all or Release all

and enable copier and does not support full use of Follow-You Printing across print servers.

Adding and Configuring a Control Terminal

Control terminals can be added to System Manager automatically or manually. When a control terminal is poweredup and connected to the network, DCE registers the control terminal and automatically adds it in System Manager >

Devices under the Unassigned control terminals group. Once the control terminal has been added to the list of

Devices, it can be assigned to a specific physical device. See

Associating a Control Terminal With a Physical Device

on page 35.

To manually add and configure a PageCounter Mini control terminal, do the following:

1

In System Manager > Devices, right-click a physical device and select Add control terminal from the menu.

2

3

4

In the Device interface summary dialog box, enter a unique Name and a Description for the control terminal.

The Server value defaults to the current DCE host. Change the server, if necessary, by selecting another server from the drop-down list.

The Type automatically displays Control terminal.

The Hardware address automatically displays when the control terminal contacts DCE.

If needed, override the copier type associated with your MFP device model to define a more appropriate copier type for your hardware. The Xerox Secure Access device database that maps MFP devices to copier types may not contain every available model.

Select <unconfigured> to use the physical device copier type, select <Default> to override the physical device copier type with the default copier type, or, select a copier type from the drop-down list.

Enter the IP address, Gateway IP, and Subnet mask for the control terminal.

Xerox Secure Access Unified ID System® Administration Guide 33

Chapter 2: Managing Devices

5

Xerox Secure Access returns this information to the device if you configure the device to use the modified BOOTP protocol for initialization instead of a static IP address. See your control terminal documentation for details on device configuration.

The Terminal type is automatically detected and displayed when the control terminal contacts DCE.

If you have enabled secure printing, configure the following control terminal functionality:

NOTE: Rule sets do not apply to Xerox Secure Access.

a

Select a Control to specify the device’s default functionality, as described in the following table.

Control Option

Copy and release

Description

Provide copy and print release control for documents sent to the associated physical device.

Copy only Provide copy control only.

Copy then release Enable the copier immediately upon authentication.

If the user presses Print, the print functionality is available and control terminal prompts are displayed according to the

Release Behavior that is configured.

Release only Provide print release control only.

Release then copy Release all documents immediately after the user authenticates, and enables copying.

Control Terminal Prompt

Select use:

Print Copy End

N/A

Copying...

Print End

N/A

N/A b

When configuring control terminals for print transactions only, select the Release Behavior to determine the device’s default release behavior:

Release Behavior Description

First is released The device releases only the first queued document automatically after user login.

Prompt The device prompts the user to release all or select documents for that user.

Control Terminal Prompt

N/A

Release all at login The device releases all queued documents for the current user automatically after successful login.

Select to release User can select one or more documents to release or delete.

1 documents found on local servers

All Select End

N/A

Document1.txt

Print Del End

6

7

Select a Card Reader HID decoding from the drop-down list. See

HID Decoding

on page 100 for setup details.

Click OK to save these settings, or Cancel to close the dialog box without saving any changes.

34 Xerox Secure Access Unified ID System® Administration Guide

Chapter 2: Managing Devices

Associating a Control Terminal With a Physical Device

When a control terminal is powered-up and connected to the network, DCE registers the control terminal in System

Manager > Devices under the Unassigned control terminals group.

To associate any unassigned control terminal with a physical device, do the following:

1

In System Manager > Devices, switch to Standard view. The list of unassigned control terminals is displayed.

2

3

Right-click on a control terminal in the right pane and select Assign control terminal from the menu.

In the Assign Control Terminal to device dialog box, select a physical device from the list and click OK.

The right pane updates to display the new control terminal association.

Alternatively, you can select the control terminal in the right pane, and drag it to a physical device.

Xerox Secure Access Unified ID System® Administration Guide 35

Chapter 2: Managing Devices

Configuring SNMP Communication

SNMP communication is essential to managing network activity. Your network can use either SNMPv2 or SNMPv3 to manage DME monitored devices. SNMPv2 uses community names to authenticate requests, and SNMPv3 uses a combination of authentication and privacy keys and protocols to send and receive information from devices on the network. SNMPv3 provides a higher level of security, and is recommended to use where supported.

To configure SNMP communication, do the following:

1

In System Manager, navigate to Configuration > SNMP configuration. The SNMP configuration dialog box opens.

2

3

Enter a Polling interval value for SNMP status changes (in minutes). Choose a polling interval value that is not too low so that network traffic is properly accounted for.

Click <Default> to open the default SNMP configuration dialog box.

4

Enable SNMP version 2 or SNMP version 3.

• If Enable SNMP v2 is selected, enter your Community names in the Get and Set fields. By default, Get is

"public" and Set is "private".

36 Xerox Secure Access Unified ID System® Administration Guide

Chapter 2: Managing Devices

5

—Or—

• If Enable SNMP v3 is selected, provide the following information:

Security Name: User name or Account name (depending on MFP manufacturer)

Context Name: Not required by all MFP manufactures. Refer to the manufacturer’s documentation for

Context name details.

Authentication Key: Pass-phrase (at least 8 characters in length)

Authentication Protocol: Either MD5 or SHA1 security algorithm

Privacy Key: Pass-phrase (at least 8 characters in length)

Privacy Protocol: Either DES or AES encryption algorithm

Authentication Keys and Privacy Keys are generated from user-configurable pass phrases. An Authentication key value is required in order to enter a Privacy key value.

User-based authentication protocol uses the MD5 or SHA1 security algorithms to authenticate users. The privacy protocol uses the DES or AES encryption algorithm to encrypt and decrypt SNMP messages.

Click OK to save the settings.

If desired, click <Add> and follow the previous steps to create additional SNMP configurations.

If you change the default names in System Manager, you must also change them on all of your physical devices to match, in order for SNMP communication to work. Consult your MFP manufacturer’s documentation for information on changing these settings.

Xerox Secure Access Unified ID System® Administration Guide 37

Chapter 2: Managing Devices

38 Xerox Secure Access Unified ID System® Administration Guide

3

Using Single Function Terminals

Topics

Single Function Terminals Overview

Nuance ID Controller

Setting Up the ID Controller

Integrating the ID Controller into Equitrac

Troubleshooting

Use Single Function Terminals (SFT) if your deployment requires tracking and secure release of print jobs from single function network printers. Single Function Terminals offer user authentication independent of printer manufacturer.

Users log in and release their print jobs by card swipe.

Support for Single Function Terminals does not require any additional licensing.

This chapter provides information on:

• Single Function Terminals in Equitrac

• Nuance ID Controller (Single Function Terminal).

Xerox Secure Access Unified ID System® Administration Guide 39

Chapter 3: Using Single Function Terminals

Single Function Terminals Overview

Single Function Terminals (SFT) are network devices with card reader. Once an SFT is registered into Equitrac, you can assign it to a physical device. This enables users to simply go to the terminal and swipe their cards for secure print release on the associated printer.

To ensure secure print job release, the Secure Printing option of the assigned physical device must be enabled. If

Secure Printing is disabled, all print jobs are released immediately. Depending on the SFT settings (as configured in

System Manager), a card swipe releases either only one job in the print queue, (which could be either the absolute oldest queued document, or the first queued document of the logged-in user, followed by the first queued document of any available delegator jobs assigned to that user), or all jobs in the print queue.

SFTs appear in System Manager as control terminals. They support relevant global settings in the System Manager and offline usage. Some specific settings (such as HID decoding and User Authentication) come with some limitations due to the physical capabilities of SFTs.

Terminal identification and user authentication are performed against CAS. Once a card owner is identified, DRE releases the job (prints it and removes it from the queue) to the assigned physical device using any specified rule sets of the physical device.

In the Equitrac server, the DCE service is responsible for communicating with the terminals. It listens on TCP/IP port

7800 for incoming requests. Make sure that you open this port in your Firewall on the machine where the DCE service is running.

40 Xerox Secure Access Unified ID System® Administration Guide

Chapter 3: Using Single Function Terminals

Nuance ID Controller

The Nuance ID Controller offers user authentication independent of printer manufacturer. Thus, the Nuance ID

Controller offers card swipe and job release functionality on Xerox embedded devices and non-Xerox devices. The user swipes their card at the card reader attached to the ID Controller to log into the printer and release their associated print jobs.

The Nuance ID Controller works similarly to PageCounter control terminals. However, due to the lack of keyboard and display panel, advanced functionalities such as Follow-You Printing are not available.

When a user swipes a card at the terminal:

1

2

User authentication is performed.

Print jobs (as configured in Equitrac Office or Express) are released to the assigned printer.

This chapter provides the following information:

• ID Controller hardware overview.

• ID Controller setup, including connecting the controller, configuration via the device’s own web interface, and

Integration with the Equitrac software (via System Manager).

Hardware Overview

The Nuance ID Controller features a built-in 2-port switch (no need for additional network outlet). It supports fullduplex transmission. It is supplied with a switch mode power supply (input: 100-240V~, 50-60Hz/500mA, output:

12V, 1.25A).

Requirements

• One free network socket (RJ-45 port, 10/100 BASE-TX).

• One free power socket.

• A web browser with JavaScript (Active Scripting) enabled (Firefox or Chrome recommended).

• Minimum controller firmware version S80 602.102*81.

• An Equitrac card reader (HID, Indala, Legic, MiFare or Mag Stripe). Card numbers coming from the other types of card readers may not process correctly.

• Equitrac Office or Express version 4.2.6 (or higher)

• Authentication and Follow-You licenses as ID Controller must be assigned to a physical device.

The controller and the printer are independent network devices with their own IP addresses. Physical connection between these devices is not required. Separate licensing is not required to use the Nuance ID Controller.

Prerequisites

The ID controller will always run in auto-negotiation. Equitrac recommends that MFP and backbone network that are connected to the ID Controller should be set to auto-negotiate.

Xerox Secure Access Unified ID System® Administration Guide 41

Chapter 3: Using Single Function Terminals

Setting Up the ID Controller

1

2

3

4

5

6

The complete setup process for the Nuance ID Controller consists of the following steps:

Connect the controller device to the network and to an Equitrac card reader.

Determine the IP address of the controller.

Configure the controller through its web administration interface.

Swipe a card to register the controller automatically into the Equitrac database.

Launch System Manager and assign the controller to a physical device. Optionally, you can also configure it.

Assign card numbers to Equitrac accounts.

Connecting the ID Controller

The following diagram shows the physical hardware connections:

42 Xerox Secure Access Unified ID System® Administration Guide

Chapter 3: Using Single Function Terminals

2

3

To connect the Nuance ID Controller, do the following:

1

4

Connect a USB card reader to the controller’s USB port using a USB cable.

Connect the controller’s LAN network port to your network using a network cable.

(optional) Connect a network cable to the printer via the controller’s printer port. The network traffic related to the printer is not blocked or modified by the controller. It behaves like a hub, which is useful if you want to use two network connectors separately.

Connect the power supply to the controller.

Determining the ID Controller IP Address

When the Nuance ID Controller is switched on, it tries to acquire an IP address immediately. Its LAN network port light changes from flashing to fixed when an IP address is set.

Due to the lack of device display, the following methods are recommended when determining the IP address of the

Nuance ID Controller:

• Log in to the DHCP server and look up the assigned IP address based on the MAC address. The MAC address of the Nuance ID Controller is printed on the white label on the bottom of the controller. The MAC address is a 12digit hexadecimal number (e.g.

00C076FF00F2).

• If you do not have access to the DHCP server, use an IP Scanner application to explore the used subnet.

Configuring the ID Controller via a Web Interface

The Nuance ID Controller needs to be configured via its web administration interface before adding the controller device to Equitrac System Manager. To configure the Nuance ID Controller, do the following:

1

Open a JavaScript-enabled web browser and enter the controller IP address into the Address field. The interface is available in English, entitled SafeCom IDController and some of its pages may be password-protected.

The Home page opens, providing a device summary:

NOTE: Make sure that you open the web site of the appropriate controller by comparing the MAC address and that the minimum controller firmware version is S80 602.102*81.

Xerox Secure Access Unified ID System® Administration Guide 43

Chapter 3: Using Single Function Terminals

2

Click the Advanced Configuration tab (if prompted, enter your credentials).

3

To configure the IP address of the controller or the DNS server, select the TCP/IP option. The TCP/IP Settings page opens.

c a b

Set the IP Lookup Method to your preference. Automatic lookup is available through DHCP, BOOTP, and

RARP protocols.

Set DNS servers to resolve hostnames and IP addresses. A maximum of 14 DNS servers can be specified.

Click the Save & Continue button to save the settings and return to the Advanced Configuration page.

44 Xerox Secure Access Unified ID System® Administration Guide

Chapter 3: Using Single Function Terminals

4

Select SafeCom on the Advanced Configuration page. The SafeCom Settings page opens.

5

Use this page to configure the device for communication with the DCE service (only a single DCE can be used).

a b

In the SafeCom DS IP Address field, enter the IP address of the DCE server. Is recommended to use a single

IP address only.

Make sure that the value in the SafeCom DS Port Number is 7800 as the DCE service listens on port 7800.

c

Click the Save & Continue button to save the settings.

Reboot the ID controller to apply the new settings.

Xerox Secure Access Unified ID System® Administration Guide 45

Chapter 3: Using Single Function Terminals

Integrating the ID Controller into Equitrac

1

2

Once the Nuance ID Controller has been physically connected and configured through its web administration interface, it can now be registered and configured in System Manager.

Before you start, make sure that:

• The controller is turned on.

• The controller is set it up to communicate with DCE through port 7800.

• System Manager is operating error-free.

To register the Nuance ID Controller in Equitrac, do the following:

3

Open System Manager.

Swipe a supported card on the card reader attached to the ID Controller.

Make sure that the terminal appears in System Manager > Devices under Unassigned control terminals.

4

5

Right-click the control terminal in the right pane, and select Assign control terminal from the menu.

—Or—

Drag-and-drop the control terminal onto a physical device.

In the Assign Control Terminal to device dialog box, select a physical device from the list and click OK.

46

CAUTION: Ensure that the physical device has the Secure printing option enabled.

Xerox Secure Access Unified ID System® Administration Guide

Chapter 3: Using Single Function Terminals

6

Click Refresh. The right pane updates to display the control terminal associated with a physical device.

7

8

Swipe an Equitrac user-assigned card at the control terminal to initiate a test print.

Confirm that the test page printed successfully after the card swipe.

Configuring the ID Controller in System Manager

To configure the Nuance ID Controller, do the following:

1

2

Select System Manager > Devices.

Click the control terminal in the right pane. The Terminal properties dialog box opens.

3

4

Optionally, you can modify the Name and Description for the terminal. Other properties in the Definition section are for your information and cannot be edited.

Hardware address – The MAC address of the control terminal used to identify the terminal in the network.

Last known IP address – Displays the terminal’s last associated IP address. This cannot be used to identify the terminal since a dynamic IP address may be used for the terminal when it connected to the network.

Terminal type – Identifies the type of control terminal (e.g. SFT: Nuance ID Controller)

Select a Release behavior at login method from the drop-down list.

Release all (default) – The device releases all queued documents for the current user automatically with one card swipe. If Account limits is enforced and there are insufficient funds in the user account, then only print jobs that cost less than the available funds will be released.

Release first in queue – The device releases only the first queued document (oldest job in the print queue).

Xerox Secure Access Unified ID System® Administration Guide 47

Chapter 3: Using Single Function Terminals

5

Other properties in the Behavior section are pre-set, and cannot be edited.

Rule set – Uses the associated physical device’s rule set.

Control – The ID controller only provides print release functionality.

If using HID cards, select a Card Reader HID decoding from the drop-down list. This setting does not affect non-

HID cards.

You can select multiple SFTs and set common property values for all selected terminals at one time. However, you can only edit the Description, Release behavior and HID decoding fields when working with multiple SFTs. System

Manager supports different types of control terminals (e.g. Nuance ID Controller and PageCounter), and if you select different terminal types then the Edit option is disabled.

User Authentication at the Terminal

1

2

User authentication functionalities are limited in scope for Single Function Terminals. Some authentication options are not available when enabling user login at SFTs.

To enable users to log in with a swipe card at an SFT, do the following:

Open System Manager, and navigate to Configuration > Security and authentication > User authentication.

In the Authentication options section, set the Input type to Card swipe only or Card swipe or keypad entry. If the Input type is set to Keypad only, the SFTs will reject all card swipes.

NOTE: The Secondary prompt setting does not apply to SFTs.

3

Click OK to save the settings and close the User authentication dialog box.

48 Xerox Secure Access Unified ID System® Administration Guide

Chapter 3: Using Single Function Terminals

Offline Behavior

Single Function Terminals support offline usage. Even if the CAS service is offline, the terminal can still remain operational using the DCE cache (DCE local database). Offline usage only works with terminals already registered in

Equitrac with login caching enabled on DCE servers.

If the terminal, the assigned physical device or the assignment itself are modified in CAS, the DCE cache receives this updated information within 10 seconds. If the CAS service goes offline after DCE registers the latest update and a card is swiped at a terminal, the terminal and the assigned physical device are found the same way as if CAS were online.

If login caching is enabled when CAS is offline, then DCE allows user identification at the terminal when CAS is offline only if they had already been identified while CAS was online. If login caching is disabled when CAS is offline, then users cannot log in at the terminal.

For example, if DCE caching is enabled, and User1 swipes a card at the terminal while CAS was online but User2 did not, then if CAS goes offline, User1 can still log in at the terminal but User2 cannot until CAS comes online again.

Once CAS is back online, then User2 can log in, and continue to log in even if CAS goes offline again.

NOTE: Card number association changes are not supported in offline mode.

To set the offline behavior, do the following:

1

2

Open System Manager, and navigate to Configuration > Security and authentication > User authentication.

In the CAS offline behavior section, do the following:

3 a b

Set the Login caching from the DCE servers drop-down list to Enabled. Enabling login caching allows only previously CAS-identified users to log in when CAS is offline.

Determine how DRE servers handle print jobs when CAS is offline.

Auto select – If color quota is enforced, then the Do not print option is used. If color quota is not enforced, then the Print, charge accounts later option is used.

Do not print – Users cannot print, and must wait until CAS is back online in order to print.

Print, charge accounts later – Users can print, and then the print job is charged to their account when CAS is back online.

Click OK to save the settings and close the User authentication dialog box.

Xerox Secure Access Unified ID System® Administration Guide 49

Chapter 3: Using Single Function Terminals

Troubleshooting

Retrieving Card Numbers

1

2

3

4

5

6

If a card number is unavailable but you need to retrieve it, you can find this information in the trace log.

7

In the Diagnostics section of System Manager, select Settings.

Click EQ Device Control Engine in the tree view. The Trace file settings window opens.

Select EQ Device Control Engine and Additional Tracing Settings at the top of the list.

Scroll down the list to also select the two sft items, and click OK.

Swipe the card at the terminal. The card number appears in the log file.

In the Diagnostics section, select Files.

Expand EQ Device Control Engine in the tree view, and then double-click the

EQDCESrv_SFT.log file. Card numbers are shown as

CardNo=[0123456789].

Card Reader Behavior

Equitrac card readers (with the minimum controller firmware version S80 602.102*81) indicate error conditions via the red light blinking for a second accompanied by a long beep. Check the following for potential error causes:

• User authentication option in Equitrac System Manager is set to Keypad only.

• The terminal is not assigned to a physical device.

• There is no associated Equitrac account for the card number.

• There are no print jobs in the print queue.

If the issue still persists, contact Technical Support.

ID Controller Network Duplex Mismatch Behavior

The ID controller will always run in auto-negotiation. MFP and backbone network that are connected to the ID

Controller should be set to auto. Equitrac recommends the following solution:

When using an ID controller, set both the MFP/Printer and network switch to use auto-negotiate for network speed.

Otherwise, if either are forced to full duplex, auto-negotiate fails and the ID controller will use half-speed which will have an impact on print performance and poor network connectivity on the device.

If the issue still persists, contact Technical Support.

50 Xerox Secure Access Unified ID System® Administration Guide

4

Creating & Managing Accounts

Topics

Accounts Overview

Working with User Accounts

Managing User Accounts

Managing Search Filters

Accounts System Configuration

Printing Accounts are required to track copy, fax, scan, and print usage. Each time a user submits a job, the Core

Accounting Server (CAS) validates the job request, then logs the transaction details to the database.

Printing Accounts are created and managed within System Manage. Access to this manager is restricted to selected domain groups. You must be a member of the Domain controller assigned to the Accounts permission to open and use System Manage.

This chapter provides information to:

• determine the account types required for your deployment

• create the three different account types

• manage accounts on an on-going basis

• set system configuration options that affect all accounts

Xerox Secure Access Unified ID System® Administration Guide 51

Chapter 4: Creating & Managing Accounts

Accounts Overview

Why Use Accounts?

If you want Xerox Secure Access to track printing per Users, you need to create printing accounts. You can use accounts to set limits on the amount of printing each account can perform, and on the number of color pages each account can produce.

Each account is logged in the database. Print, scan, fax, and copy job transaction details are logged to the account.

User Account properties can also include name, email address, and account balance.

Each time a user submits a print request, the Port Monitor on the target device contacts the Core Accounting Server

(CAS) to verify the users credentials. CAS checks the database entry for the account, and either verifies or denies the print request. If verified, the print job is released to the print queue. After the job has printed, the Port Monitor forwards the transaction details to CAS, which updates the account information and transaction details for that account.

52 Xerox Secure Access Unified ID System® Administration Guide

Chapter 4: Creating & Managing Accounts

User Account

User accounts allow valid users to print to monitored devices, and enables print tracking. Each user who prints to one or more monitored devices, or who login to a control terminal to use copy, scan, or fax functions, must have an Xerox

Secure Access printing account.

Grouping Accounts

If you are managing a large organization, you may have more than 1000 users. Rather than presenting an enormous list of users, System Manage can be configured to group users alphabetically or numerically.

To enable the User group view, do the following:

1

Click Tools > Options.

2

3

4

5

In the Options dialog box, select the Enable grouping checkbox.

Set the Alphabetical ranges to either Predefined or Optimized size.

If Optimized size is selected, enter a Maximum group size to display in System Manage. The group size range must be within 100 - 10,000.

Click OK to save the settings.

A User group view tab is placed on the System Manage toolbar.

Click the User group view tab to select a user group to view and access in the right pane. The System Manage title bar displays the selected group.

If you want to further refine the views in System Manage, use the EQAccountRegroup tool to divide the groups into smaller subgroups for easier viewing. See

Refining the User Group View

on page 111.

Xerox Secure Access Unified ID System® Administration Guide 53

Chapter 4: Creating & Managing Accounts

Working with User Accounts

When you first implement Xerox Secure Access, you can choose from three methods to create user accounts: create accounts with Xerox Secure Access one at a time, allow the system to create users automatically, or import users from

Synchronized Directories (e.g. Active Directory and LDAP). Instructions for each method are provided within this chapter.

Creating User Accounts

Xerox Secure Access provides several different methods to create user accounts. Use the table below to determine the best method for your needs. Instructions are provided within this section for each method.

Method

Purpose

Add users individually

Use System Manage within Xerox Secure Access to add users one at a time.

Allow Xerox Secure Access to create users automatically

Configure Xerox Secure Access to create a new account automatically when a print request is received from a user not known to the Accounting Server.

Import Users with Active

Directory Synchronization

Use Active Directory Services to batch import user data, then synchronize updates as they occur.

Minimizes administration because updates occur automatically via communication with the Active Directory Services.

Offers PIN code and home server synchronization to single or multiple Active Directory servers.

LDAP Synchronization

Flat-File Import

Has all the same features as Active Directory Synchronization. The LDAP server must support persistent search (e.g. Novell eDirectory).

Use the EQCmd.exe utility to import a file containing user account data.

54 Xerox Secure Access Unified ID System® Administration Guide

Chapter 4: Creating & Managing Accounts

Adding and Editing Users Individually

If you are managing a smaller number of users, you may prefer to create users one at a time.

1

2

In System Manage, select Users in the left pane.

Select Add user under Current tasks to open the Add User dialog box.

3

Enter the following information in the fields provided

.

Field

User ID

Full Name

Email address

Location

Additional

Information

Description

ID logged to the database to track the account (required field).

To qualify user IDs with the domain name, use the <domain.com>\userID format. If you configured

Xerox Secure Access to identify users by qualifying and recording the user’s originating domain in the accounts database (System Manager > Configuration > Domain qualification), you must also include the domain information in the User ID.

The full name of the user. Enter a full name to easily identify the user within System Manager. This name also appears in account statements.

The email address is used to send notification email messages to the users in event of job error.

Enter the location you wish to assign the user to.

Enter any additional information that you may find useful when pulling up a user’s information.

Xerox Secure Access Unified ID System® Administration Guide 55

Chapter 4: Creating & Managing Accounts

Field

PIN Information

Description

If the user enters PIN codes on a control terminal, enter a Primary PIN and an optional Secondary

PIN. The primary PIN identifies the user, and the secondary PIN is used as a password.

You can also enter an Alternate primary PIN that serves as another primary PIN for this user. The user can enter either primary PIN at a control mechanism.

The DRE print server that manages this users print jobs.

Home Server

Xerox Secure Access adds the User to the accounts database and lists the User name in the right pane.

To edit an existing User, do the following:

1

2

3

In System Manage, select Users in the left pane.

Right-click a User in the right pane, and select Properties from the menu to open its Properties window and modify any of the editable fields.

Click OK to save the changes.

56 Xerox Secure Access Unified ID System® Administration Guide

Chapter 4: Creating & Managing Accounts

Importing Users with Active Directory Services

System Manager provides a utility to import uses via Active Directory Services (ADS). If you want to minimize administration overhead, and you are managing a large number of User Accounts, you should use ADS to synchronize user accounts.

WARNING: The Equitrac services must be started by a Domain account with access to the contact Active Directory. If services are started under the local administrative account, the Active Directory synchronization fails.

CAUTION: If you plan to use Active Directory Services to generate user accounts, you must decide before performing the first synchronization whether or not to use Domain Qualification. See

Qualifying Accounts by Domain

on page

63 for instructions.

Configuring Active Directory Synchronization

It is important to select options in the correct order in the Directory Services synchronization dialog box. Performing these steps causes a task to run in the background. You can see the result of the task in the System Manage—the list of users populates automatically when the task is complete.

An Active Directory server consists of containers that contain records (users, computers, printers, etc.) organized by type, geographical location or similar. Synchronization, settings and any related operations available in this window can be applied to servers or individual containers, depending on your selection.

To configure active directory synchronization, do the following:

1

In System Manager, navigate to Configuration > Directory Services synchronization and select the Active

Directory tab.

2

Above the tree view in the Servers and containers group, click Add server...

Xerox Secure Access Unified ID System® Administration Guide 57

Chapter 4: Creating & Managing Accounts

4

5

3

Enter the Domain Controller server name. (A domain controller refers to a server shared by a group of computers that use a common accounts database.) The fully qualified domain name—not the IP address—must be entered for the Domain Controller.

Enter the Application partition for the directory of users, or click Browse to select from a list of partitions.

Click OK to add it to the domain controller list. A specific server can only be added once to the list.

6

7

8

Click Modify if you wish to make changes to any of the domain servers in the list.

Click Remove to clear any of the domain servers from the list.

To add individual containers, select a server in the tree view and click Add Container... A container is a subset of a

Domain controller. Select one or more containers that belong to the selected Domain Controller. A specific container can only be added once to the same server.

CAUTION: Ensure that the Organization Units (OU) containers you choose are comprised of user account data only.

If the OUs contain other data (such as system or contact information), you will see unexpected results. You may need to create specific OU containers to be used only for importing and synchronization purposes.

9

Select a container and click Remove to clear it from the list.

10

Click Test to open an Active Directory lookup dialog box. Enter a user account name. When the domain controller is contacted, the dialog box shows the ADS properties for that account. You can test servers as well as containers, depending on your list selection. Lookups may get resource intensive operations: ensure that you use this functionality on an entire server only if your task specifically requires it.

11

Optionally, you can move servers and containers up or down the tree view. Select the item to move and use the

Move Up or Move Down buttons next to the view.

NOTE: Controls in this group are also accessible from the item context menu.

12

Under Filtering, you can specify a search filter for synchronization. Click the (...) button if you wish to assemble a filter using a graphical interface. A standard filter dialog box opens. Use this to specify conditions. To specify an unlisted field use the Search filter textbox. Only user accounts that meet these conditions are included in the synchronization.

Click the checkbox Filtering is specified at the container level

if you are working with containers instead of servers.

NOTE: If filters are applied after the initial user import, updates to users who do not match the filter specifications are ignored.

13

In the Field mappings section, you can link Xerox Secure Access user fields to ADS attributes. You should enter the AD attribute name, not the field label. Synchronization uses the specified mappings.

Click the Mappings are specified at the container level checkbox to set field mappings for containers instead of servers.

58 Xerox Secure Access Unified ID System® Administration Guide

Chapter 4: Creating & Managing Accounts

Check the options you want to associate with the user accounts in the selected containers:

Account name – contains the user login ID. This is mapped to the User ID property in Xerox Secure Access.

Display name – contains a description of the user, such as the full user name. This is mapped into the Full

name property for the user within Xerox Secure Access.

Email address – contains the user’s email address.

Primary PIN and Secondary PIN – map the numeric PIN values found on the ADS to the PrimaryPIN and

SecondaryPIN fields in Xerox Secure Access.

Alternate PIN – maps the alternative primary PIN.

Location – maps the user’s physical location.

Home Server – maps the name of a particular print server to the Home Server field in the Xerox Secure Access database. If you are enabling Follow-You Printing, ensure that you select the Home Server attribute for these users.

NOTE: Department, Color quota, Home folder and Delegates do not apply to Xerox Secure Access.

14

Use the controls in the Synchronization group (under Field mappings) to specify synchronization settings.

15

Click the checkbox Synchronization is specified at the container level if you want to synchronize containers rather than servers. Ensure that you only use this option with a container selected.

16

Select or clear AD update options—Adds, Deletes, or Changes—to specify which AD accounts Xerox Secure

Access receives and applies to the accounts database during subsequent synchronizations.

You must have at least one option selected to perform synchronization or save your changes.

You can import added or changed users, or remove inactive accounts from the Secure Access accounts database.

Leave these settings at the default to ensure the accounts are updated and kept in sync with the ADS server.

NOTE: The Deletes option only works if the "isDeleted" AD attribute is set to true. In case the entire user record is removed from AD, Xerox Secure Access cannot detect this deletion due to an AD limitation, and the corresponding user is not deleted automatically from Secure Access database.

17

Click the Automatic synchronization checkbox to enable adjustments to the Synchronization interval. Use this to change how often Xerox Secure Access synchronizes its accounts database with the specified AD. The synchronization interval value must be at least 15 minutes. The maximum value 10080 minutes (one week).

18

After specifying the synchronization settings, click Synchronize Now… to schedule a single synchronization process (as opposed to automatic synchronization, which is performed periodically). Click OK to have this single synchronization performed in the background.

19

Click OK to exit the dialog box. The task continues to run even though the dialog box is closed. Server settings apply to all containers of the server.

20

After a few minutes, refresh System Manage, then check the list of Users to ensure successful import of the accounts. Open the user account properties and ensure that the settings are correct.

Xerox Secure Access Unified ID System® Administration Guide 59

Chapter 4: Creating & Managing Accounts

Active Directory LDS Support

Xerox Secure Access supports Active Directory Lightweight Directory Services (AD LDS) to synchronize a subset of the Active Directory tree to a local LDS server.

Like Active Directory, AD LDS provides a hierarchical data store for storage of directory data, a Directory Service with an LDAP directory service interface. Unlike Active Directory, however, multiple AD LDS instances can be run on the same server. AD LDS shares the code base with Active Directory and provides the same functionality as Active

Directory, including an identical API, but does not require the creation of domains or domain controllers.

AD LDS operates independently of Active Directory and independently of Active Directory domains or forests. It operates either as a standalone data store, or it operates with replication. Its independence enables local control and autonomy of directory services for specific applications. It also facilitates independent, flexible schemas, and naming contexts.

AD LDS is ideal for applications that require directory services, but do not require the complete infrastructure features of Active Directory.

60 Xerox Secure Access Unified ID System® Administration Guide

Chapter 4: Creating & Managing Accounts

Configuring LDAP Synchronization

LDAP synchronization requires that the LDAP server supports search functionality. LDAP import will not work if the

Base DN or user names contain spaces.

To configure LDAP synchronization, do the following:

1

In System Manager, navigate to Configuration > Directory Services synchronization and select the LDAP tab.

2

Above the tree view in the Servers group, click Add... to open the New LDAP server dialog box.

c a b

Enter the LDAP server name.

Enter the Port number. The default value depends on whether you have the Use SSL checkbox marked or clear

(see below).

In the Base DN field, enter the location within the directory to start the search. For example, if the entire directory is to be searched under an organization of “Nuance”, this would be “O=nuance”. Ensure the Base DN name does not contain spaces, or the import will fail.

f d e

Enter a Login ID. The login ID is the fully qualified user ID (e.g. CN=admin, O=nuance).

Enter a Login password.

Select an LDAP version from the drop-down list.

Xerox Secure Access Unified ID System® Administration Guide 61

Chapter 4: Creating & Managing Accounts

3

4

5

6 g

Select Use SSL if you want use Secure Socket Layer encryption.

h

Click OK to add the new server.

Click Modify if you wish to make changes to any of the LDAP servers in the list.

Click Remove if you wish to remove any of the LDAP servers from the list.

Click Test to confirm that Persistent Search is enabled. An LDAP lookup dialog box opens. Enter a user account name. If Persistent Search is enabled, the dialog box shows the LDAP properties for that account. If a search filter

(see below) is specified, the lookup only returns users matching the selected filter.

Optionally, you can move servers and containers up or down the tree view. Select the item to move and use the

Move Up or Move Down buttons next to the view.

NOTE: Controls in this group are also accessible from the item context menu.

7

To specify import search criteria, enter it in the Search filter field under Filtering. "(objectClass=person)" is the default search filter, and can be modified as needed. Use standard LDAP filter syntax to define the search criteria. he search filter criteria also affects the information returned in the LDAP lookup Test tool.

If desired, you can enter additional search criteria along with the Object class. For example, if the search filter entered is "(&(objectClass=person)(l=Waterloo)", this would search for objects that have the Object class = person

AND also have a location set to Waterloo.

NOTE: When using LDAP email search, the Search filter field is not active. LDAP email search looks for entries in the displayName attribute, not the email address. The displayName attribute must match what is entered in the LDAP server.

8

In the Field mappings section, you can link Xerox Secure Access user fields to LDAP attributes. The LDAP lookup must resolve to a unique user identifier.

The specified field mappings are used by synchronization. Check the options you want to associate with the user accounts in the selected containers:

Account name – contains the user login ID. This is mapped to the User ID property in Xerox Secure Access.

Display name – contains a description of the user, such as the full user name. This is mapped into the Full

name property for the user within Xerox Secure Access.

Email address – contains the user’s email address.

Primary PIN and Secondary PIN – map the numeric PIN values found on LDAP to the PrimaryPIN and

SecondaryPIN fields in Xerox Secure Access.

Alternate PIN – maps the alternative primary PIN.

Location – maps the user’s physical location.

Home Server – maps the name of a print server to the Home Server field in the Xerox Secure Access database.

If you are enabling Follow-You Printing, ensure that you select the Home Server attribute for these users.

NOTE: Department, Color quota, Home folder and Delegates do not apply to Xerox Secure Access.

9

Use the controls in the Synchronization group (under Field mappings) to specify synchronization settings.

10

Select or clear update options—Adds, Deletes, or Changes—to specify which accounts Xerox Secure Access receives and applies to the accounts database during subsequent synchronizations. At least one option selected to perform synchronization or save the changes.

62 Xerox Secure Access Unified ID System® Administration Guide

Chapter 4: Creating & Managing Accounts

11

Click the Automatic synchronization checkbox to enable adjustments to the Synchronization interval. Use this to change how often Xerox Secure Access synchronizes its accounts database with the specified LDAP server. The synchronization interval value must be at least 15 minutes. The maximum value 10080 minutes (one week).

12

After specifying the synchronization settings, click Synchronize Now… to schedule a single synchronization process (as opposed to automatic synchronization, which is performed periodically). Click OK to have this single synchronization performed in the background.

13

Click OK to exit the dialog box. The task continues to run even though the dialog box is closed.

After a few minutes, refresh System Manage, then check the list of Users to ensure successful import of the accounts.

Open the user account properties and ensure that the settings are correct.

LDAP Field Mapping to CAS

Mapping the LDAP attributes to CAS fields provides a way to cross-reference the attributes received from the LDAP server with the corresponding fields for the user account in the CAS database. When a user logs in and is authenticated based on the LDAP configuration, CAS looks up the LDAP attributes mapping and imports the correct fields into the user’s account. CAS updates the fields with every authentication if the field has changed.

An LDAP server does not need to be added to the LDAP synchronization dialog box for field mapping.

Qualifying Accounts by Domain

If you plan to use Active Directory Synchronization to generate user accounts, you must decide before performing

the first synchronization whether or not to use Domain Qualification.

Performing an initial synchronization creates user accounts based on Windows credentials without specifying a domain for the imported users. If you enable Domain Qualification after the initial synchronization, however, the process creates a second account for every Windows user. Also check the configuration of your control system; to maintain consistency in user data, both the control system and Xerox Secure Access should be similarly configured to use or not use domain data.

Therefore, to prevent slowing down system resources by doubling the number of user accounts unnecessarily, decide whether or not to enable Domain Qualification before you perform a synchronization. If you enable domain qualification and want to subsequently create users manually, ensure that you include the domain qualification in the user ID you create, using the following format: user’s_domain\userID .

To set the domain qualification option, do the following:

1

2

In System Manager, navigate to Configuration > Domain qualification.

Select or clear the Qualify all user IDs with NT domain information option as necessary, depending on whether or not you want to use domain-qualified user IDs.

3

If necessary, provide a default domain name for unqualified users attempting to print, and click OK.

Xerox Secure Access Unified ID System® Administration Guide 63

Chapter 4: Creating & Managing Accounts

Adding Users from a Flat File Import

Use the EQCmd.exe utility to add, delete, modify and query user accounts from a flat file. This method is a one-time import and does not synchronize data beyond the import.

Xerox Secure Access installs this utility on the accounting server in the Program Files\Xerox\Xerox Secure

Access\Tools folder.

The command line utility accepts commands in the following format:

EQCmd -s<Server> <Action> <Obj_type> <Obj_ID>|All [<Options>]

Execute the command with a batch file:

EQCmd -s<Server> -f<BatchFile> [-o<OutputFile>]

The OutputFile parameter is an optional parameter which specifies where to output a trace file. If not specified, then

EQCmd will attempt to write the output file to the same folder where the batch file exists, using the same name as the batch file, but adding the .log extension. If the trace file cannot be opened, the utility will log a warning to the console screen and proceed with the batch file, writing all messages to the console.

Xerox Secure Access accepts CSV files as batch files. Batch operation allows all the command actions except for query command. Use the following table to fill in the parameters.

Parameters enclosed in parentheses < > are mandatory; parameters within square brackets [ ] are optional.

Parameter

Server

Action

Obj_type

Obj_ID

Variables

Specify the name or IP address of CAS.

Specify the action to take on the account. Use one of:

• add - Add a user.

• delete - Delete a user. It does not use <details> parameter.

• query - Query database. Output differs based on <Obj_type>.

• modify - Modify an object attribute.

• adjust - Adjust the user account balance; set a new balance to an object type or set a balance no less than a certain amount.

• lock/unlock - Lock or unlock a user.

Use one of:

• ur - user

Applies

<action> only to the specified object ID. Use double quotes around object IDs that have a space, for example human resources. Use All To apply

<Action> to all accounts of <Obj_type>.

Note: You can use “All” for “Assign”, “Remove”, “Query”, “Adjust” actions. You cannot use it for “Add”,

“Delete”, “Modify”, “Lock” and “Unlock” actions.

64 Xerox Secure Access Unified ID System® Administration Guide

Chapter 4: Creating & Managing Accounts

Parameter

Options for

Action

Command

Variables

Specify additional values. Use double quotes around detail values that have spaces or for empty values.

Specify amounts with a period for the decimal separator. For the modify action, place “!” for required fields that you don't wish to change.

<desc>: Description

<user_ID>: User ID

<user_name>: User name

<email>: User email

For a complete list of Action parameters, see

Modifying User Accounts from a Flat File

on page 107.

Importing LDAP User Accounts

You can use the EQCmd.exe utility to import a class containing specific LDAP users into the CAS database. Xerox

Secure Access installs the EQCmd.exe utility and the EQLDAPImport.ini on the accounting server in the Program

Files\Xerox\Xerox Secure Access\Tools folder.

After you create the LDAP class, call the class from the command line using the following format:

EQCmd.exe -s<CASServer> import ur <LDAPServer> <SearchRoot>

You can run the command line with the EQLDAPImport.ini file using the following format:

EQCmd.exe -s<CASServer> import ur <LDAPServer> <SearchRoot> <ini file>

CAUTION: Do not edit the original EQLDAPImport.ini file directly. Create a copy and modify it as needed, and then provide the EQLDAPImport copy file to EQCmd.

Command line parameters enclosed in parentheses < > are mandatory; parameters within square brackets [ ] are optional.

Parameter

CASServer

LDAPServer

SearchRoot

Definition

The name or IP address of CAS that you want to add a user accounts to.

The name or IP address of the LDAP server to import an account from.

The LDAP search root used to begin the import. For example "ou=Accounting, dc=metrics,dc=com".

The following table list the fields in EQLDAPImport.ini required to configure LDAP import.

Parameter Definition

[AccountSettings] This section specifies some initial settings for created accounts.

[ConnectionSettings] This section specifies how to connect and login to the LDAP server.

LoginID The LoginID for binding to the LDAP server.

Xerox Secure Access Unified ID System® Administration Guide 65

Chapter 4: Creating & Managing Accounts

Parameter

Password

BindMethod

UseSSL

Definition

The Password for the LoginID for binding to the LDAP server.

The authentication binding method. Supported values are "simple", "ntlm" and "negotiate".

Select whether or not to use SSL. "0=no, 1=yes".

Version

DataEncoding

[Attributes] This section specifies the attributes to import and map.

AccountName The attribute for lookup of the account name. If left blank, the default behavior is to look for the following attributes (in order): "sAMAccountName", "uid".

Email

What version of LDAP to use.

Encoding of LDAP data to expect. Supported values are "unicode16" or "utf8" or "ascii".

FullName

The attribute for lookup of the email address. If left blank, the default behavior is to look for the attribute "mail".

The attribute for lookup of the full name. If left blank, the default behavior is to look for the following attributes (in order): "displayName", "cn".

HomeServer

PrimaryPIN

SecondaryPIN

AlternatePIN

The attribute to look up the home server. If left blank, home servers are not imported.

The attribute to look up the primary PIN. If left blank, primary PINs are not imported.

The attribute to look up the secondary PIN. If left blank, secondary PINs are not imported.

The attribute to look up the alternate primary PIN. If left blank, alternate PINs are not imported.

Locked=logindisabled The attribute to look up to find if the account is locked.

Location The attribute to look up the location. If left blank, location is not imported.

[General Settings] This section specifies the general settings to import.

SearchFilter=

(objectClass=person)

The attribute to look up the class type to import.

66 Xerox Secure Access Unified ID System® Administration Guide

Chapter 4: Creating & Managing Accounts

Managing User Accounts

After you create the required User accounts, you can perform account management tasks such as locking or removing accounts, and performing account transactions.

Locking Accounts

When you lock an account, Xerox Secure Access cannot charge print jobs to it. The account is maintained in the database but it is inactive.

Locking an account can have different consequences for network users, depending on the account type that is locked and the types of accounts that you are using at your organization.

To lock an account:

1

2

3

In System Manage, click Users to view the list of accounts.

Click a user account from the list. The Account Properties dialog box opens.

In the Account Information section, select the Account Locked checkbox and click OK.

The account is locked. Users must charge print jobs to another account. If users do not have access to another account, they are unable to print.

To unlock or enable the account, clear the Account locked checkbox and click Save.

Removing Accounts

Each Xerox Secure Access account has a unique identifier in the database. While you can remove and delete an account and add a new account with the same name, the transactions for the deleted account are not associated with the new account. The audit trail for any account ends the moment you delete it, however, the accounts database retains all transaction records,

If you want to disable an account temporarily, but do not want to delete it permanently, you can lock the account so the system cannot charge print jobs to it.

When you delete an account, that account is permanently closed. Since each account has a unique identifier, once you delete an account, you cannot recreate it, even if you assign a new account with the same name. Deleting Single or

Multiple Accounts

1

2

3

In System Manage, click Users to view the list of accounts.

Click a user account from the list.

Use

SHIFT

-click or

CTRL

-click to select multiple accounts.

Right-click on the account(s) you wish to delete and select Delete from the menu.

Xerox Secure Access Unified ID System® Administration Guide 67

Chapter 4: Creating & Managing Accounts

4

Click one of the options on the Delete dialog box.

Yes – deletes the selected account. When deleting multiple accounts, you can click Yes to step through and delete the selected accounts one at a time.

Yes to All – deletes all of the selected accounts at once.

No – prevents an account from being deleted. If you click No when multiple accounts are being deleted, the next account in the selection appears in the Delete dialog box.

Cancel – closes the Delete dialog box and stops the delete process.

CAUTION: If you click Yes when deleting multiple accounts, and then you click Cancel before deleting the remaining selected accounts, any deleted accounts are permanently removed from the database, regardless when you click

Cancel. Cancel only affects the selected accounts that you did not yet delete.

68 Xerox Secure Access Unified ID System® Administration Guide

Chapter 4: Creating & Managing Accounts

Managing Search Filters

1

2

System Manage offers search filters for User accounts. If you are managing a large organization, you may have more than 10,000 accounts. Rather than scrolling through an enormous list, System Manage can be configured to search for accounts with similar attributes.

To create and manage filters, do the following:

In System Manage, click Users to view the list of accounts.

Click Filter > Add filter from the Toolbar.

3

In the New filter dialog box, click <Add filter criteria...>.

4

5

6

7

In the New filter criteria dialog box, do the following: a

Select a Field from the drop-down list.

b c

Select an Operator from the drop-down list.

Enter a Value.

d

Click OK to save the filter criteria and close the dialog box.

In the New filter dialog box, enter the filter Name. If a name is not specified. a format similar to an SQL condition will be used to generate the name to display in the list. For example, the filter selections of field: Balance,

operator: Greater than or equal to, and value: $10.00 displays as Balance >= $10.00.

Select the Save to list checkbox to add the new filter to the list of most recently used filters. Up to 25 filters can be stored in the Filter drop-down list. Clear the checkbox if you do not want to add the filter to the list.

Click OK to save the search filter.

Xerox Secure Access Unified ID System® Administration Guide 69

Chapter 4: Creating & Managing Accounts

Filter Attributes

The following table lists the search filter attributes for User accounts.

Account Type

Users

Definition

• Additional information

• Balance

• Email address

• Full name

• Home server

• Locked

• Minimum Balance

• Primary PIN

• Quota usage

• User ID

Operators

The following operators are available for all account types:

• Contains

• LIKE

• Not contains

• NOT LIKE

• Equal to

• Greater than

• Greater than or equal to

• Less than

• Less than or equal to

• Not equal to

NOTE: The operators are dependent upon the definition attribute, and are not all available for all definitions.

NOTE: At least one location must be defined for any user in order for the Location search filter to be available.

70 Xerox Secure Access Unified ID System® Administration Guide

Managing the Filter List

To manage the filter list, do the following:

1

2

In System Manage, click Users to view the list of accounts.

Click Filter > Manage filter list from the Toolbar.

Chapter 4: Creating & Managing Accounts

3

Add, Delete, or re-order the filters as needed.

NOTE: You cannot edit a filter. If an existing filter does not meet your criteria, you must delete it, and then create a new one to replace it. Press Add to open the New filter dialog box, and create the desired filter.

4

Click OK to save any changes to the filter list.

System Manage offers the option to display the Manage filter list before opening the accounts view. This feature allows a search filter to be selected before the view is populated with the full list of accounts.

To configure this option, do the following:

1

In System Manage, click Tools > Options. from the Toolbar.

2

3

From the Filtration section in the Options dialog box, select Users views. Departments and Billing codes do not apply to Xerox Secure Access.

Click OK to save the settings, and close the dialog box.

The Manage filter list will appear before the view is populated. Select the filter from the list, and click OK to populate the view with the applied search filter.

Xerox Secure Access Unified ID System® Administration Guide 71

Chapter 4: Creating & Managing Accounts

Accounts System Configuration

System configuration options determine how the Accounting Server validates accounts, provides error notifications, assigns charges, and handles unknown print requests or unidentified documents.

User Authentication

If your Xerox Secure Access deployment uses control terminals or embedded devices, you can configure CAS to validate user accounts against primary and secondary accounts PINs. PIN information connects an Xerox Secure

Access printing account with user logon information when a user logs onto a control terminal or releases a print job.

The primary PIN is the alpha-numeric sequence that uniquely identifies the user, and can be data encoded on a magnetic swipe card or entered via a terminal keypad. The secondary PIN acts as a device password, and is entered via a terminal keypad.

To configure user authentication settings, perform the following procedure:

1

In System Manager, navigate to Configuration > User authentication.

2

Select one or more Authentication mechanisms:

Xerox Secure Access PINs – Leave selected only if you want to connect an Xerox Secure Access printing account with logon information.

External user ID and password – Select to verify all user information outside of Xerox Secure Access.

72 Xerox Secure Access Unified ID System® Administration Guide

Chapter 4: Creating & Managing Accounts

3

4

5

Xerox Secure Access PIN with external password – Enable if users swipe their cards for identification, and must also enter their domain user account password.

Xerox Secure Access cross-checks the database for the corresponding Secure Access account name, then verifies the credentials against the selected external authority for network logon. See

External User Authentication

on page 75 for details.

Select the Store secondary PIN encrypted checkbox if you want the secondary PIN to be encrypted.

Select the CAS offline behavior for the Login caching from the DCE servers drop-down list.

Disabled – Prevents user login when CAS is offline.

Enabled – Allows only previously CAS-validated users to login when CAS is offline.

DCE login caching determines whether a user login is accepted or denied when CAS is offline. If DCE caching is disabled when CAS is offline, then users cannot login. If DCE caching is enabled when CAS is offline, then DCE allows users to login only if they had previously logged in when CAS was online.

For example, if DCE caching is enabled, and User1 authenticated while CAS was online, but User2 did not, then if

CAS goes offline, User1 can still login, but User2 cannot login until CAS comes online again. Once CAS is back online, then User2 can login, and continue to login even if CAS goes offline again.

Select your Authentication options: a

Select the Input type to determine how users are authenticated.

Card swipe only – Users authenticate with a swipe card.

Card swipe or keypad entry – Users authenticate with a swipe card or at the MFP front panel.

Keypad only – Users authenticate at the MFP front panel.

b

Select the Secondary prompt to determine when users are prompted for a secondary PIN.

Always – User must enter a secondary PIN.

If PIN2 available – User must enter a secondary PIN if they have a PIN 2 value associated with their user account. Users with a PIN 2 value will be prompted to enter it. This applies for both keyboard and card swipe logins. This option only applies to select embedded devices.

If PIN2 available or keyboard login – User must enter a secondary PIN if they have a PIN 2 value associated with their user account, or if they entered their primary PIN or network ID via the keyboard

(rather than with a swipe card). Users with a PIN 2 value will be prompted to enter it, while users who login via the keyboard and do not have a PIN 2 will be prompted to enter a network password. This option only applies to select embedded devices.

Never – Secondary PIN is not required.

Only with keyboard login – User must enter a secondary PIN if they entered their primary PIN via the keyboard (rather than with a swipe card). This option prevents users from typing in someone else’s primary

PIN while still allowing valid users to login without a card.

NOTE: Use either If PIN2 available or keyboard login or Only with keyboard login when two-level authentication is required to register new cards. In order to register the card, the user is required to manually enter the primary and secondary login credentials. Regardless which of the above options is selected, if a user has a PIN 2 value associated with their Xerox Secure Access user account, they must enter it in order to successfully login. If any users have a PIN

2 value, select If PIN2 available or keyboard login. Do not select Only with keyboard login.

Xerox Secure Access Unified ID System® Administration Guide 73

Chapter 4: Creating & Managing Accounts

c d

If using a control terminal, determine the Card setup. For details on entering the decoding parameters, see

HID Decoding

on page 100.

Select Auto-register primary PINs to enable users to register an unrecognized swipe card for future use. To complete the card registration, the user is required to login with a valid user ID and password. Optionally, you can select Register as alternate PIN to record the PIN as the Alternate PIN instead of the Primary PIN.

NOTE: If the Auto-register primary PINs option is not selected, then the user cannot register their card, and must login manually.

6

Click OK to save the settings.

74 Xerox Secure Access Unified ID System® Administration Guide

Chapter 4: Creating & Managing Accounts

External User Authentication

If the user authentication method is set to a Windows or LDAP external authority, the authentication settings must be configured in System Manager.

To configure the external authority for user authentication, do the following:

1

In System Manager, navigate to Configuration > External authentication.

NOTE: One or more external authority can be used for user authentication.

2

3

Select Windows to validate user accounts against a Windows domain. If using Windows authentication, enter the

Domain name.

Select LDAP to validate user accounts against an LDAP server. If using LDAP authentication, do the following: a b

Enter the host LDAP Server name. The fully qualified domain name of the LDAP server may be required for certificates imported for SSL. Ensure that the LDAP server’s fully qualified domain name is resolvable.

Enter the Port number used by the LDAP server.

c

Select an LDAP lookup Type from the drop-down list. Use AD-style when connecting to a Windows domain controller, and use Simple bind when connecting to a Linux/Unix server.

First try AD-style, then try simple – If selected, only Direct bind is used as the Authentication method.

Xerox Secure Access Unified ID System® Administration Guide 75

Chapter 4: Creating & Managing Accounts

f d

Try AD-style – If selected, either Direct bind or Lookup then bind can be used as the Authentication method. SSL is not available with the Try AD-style lookup option.

Try simple – If selected, either Direct bind or Lookup then bind can be used as the Authentication method.

Select Force SSL to use SSL (Secure Socket Layer) encryption. e

Select Use LDAP version 3 to use LDAP 3.

In the Authentication method section, select either Direct bind or Lookup then bind.

If Direct bind is selected, do the following:

• Enter the LDAP DN Prefix (e.g. CN=admin) and DN Suffix (e.g. ,O=nuance) to be placed, respectively, before and after the supplied user ID for simple authentication against LDAP.

• Select your User ID modification method. If the user ID has the format of an email address, this setting allows the email domain to be removed.

If Lookup then bind is selected, do the following:

• In the Search filter field, enter the import search criteria using standard LDAP filter syntax. For example, the search filter (&(objectClass=person)(uid=%value%)) would search for the person entry AND the specific user ID. Or, the search filter (|(uid=%value%)(mail=%value%)) would authenticate a user by email address. The %value% is replaced with the value entered by the user at login.

NOTE: 'uid’ can be used to connect to a Linux server, whereas 'sAMAccountName' should be used to connect to a

Windows domain controller.

• Select the search Scope from the pull-down menu.

Base – searches the base entry.

One level – searches all entries in the first level below the base entry.

Subtree – searches the base entry and all entries in the tree below the base entry. This is the default setting.

• In the Base DN field, enter the location within the directory to start the search. For example, if the entire directory is to be searched under an organization of “Nuance”, this would be “O=nuance”. Ensure the Base

DN name does not contain spaces, or the import will fail.

User ID field to match – enter the LDAP attribute used to match the Secure Access user ID field in CAS.

• Select the Anonymous login/As service login checkbox to allow the admin to specify that the LDAP server supports anonymous login (for simple LDAP type), or to login as the user the service is running as (for AD type).

• Enter the LDAP server Login ID and Login Password. Cannot enter credentials if the Anonymous login/

As service login option is selected.

NOTE: For AD, the supplied Login ID would be either in NT4 format (domain\user) or UPN format ([email protected]).

NOTE: For simple bind, the options are to bind anonymously or with the supplied credentials. The Login ID has to be in distinguished name format (e.g. uid=admin,dc=example,dc=com).

g

Select the Synchronize user attributes on login checkbox to enable LDAP synchronization of user attributes on LDAP authentication.

76 Xerox Secure Access Unified ID System® Administration Guide

Chapter 4: Creating & Managing Accounts

This feature allows user account details to be imported into the Xerox Secure Access software when the user logs into an endpoint. A traditional LDAP import/synchronization using persistent search, imports all users initially and then updates account details in the LDAP database as changes occur (see

Configuring LDAP

Synchronization

on page 61).

If you do not want to keep a persistent connection open to a database server, the Synchronize user attributes on

login feature imports user account details as needed. The new synchronization can be configured to import the same user account details as the standard LDAP sync (e.g. Primary PIN and email address).

NOTE: Ensure that Lookup then bind is selected when using the synchronize user attributes feature. Direct bind does not enable this feature.

4

Click Test to open an LDAP lookup dialog box. Enter an account User name and Password, and then click

Lookup. If Persistent Search is enabled, the dialog box shows the LDAP properties for that account.

5

Click OK to save the settings.

NOTE: The LDAP lookup must resolve to a unique user identifier.

Deleting Objects in Synchronized Directories

When you delete an object, such as a user, from a Windows Active Directory, the deleted object goes into a deleted

object container for a period of time. When you use the Xerox Secure Access Scheduling feature to synchronize Active

Directory accounts, the Scheduler looks at this container for deleted user accounts. If you have selected the Deletes

ADS update option, Scheduler also flags any corresponding user accounts in Xerox Secure Access as deleted.

In order to access the contents of the deleted object container, you must use the

EQModifyDeletedContainerSecurity command line tool to give Xerox Secure Access permission to view and manage the container’s contents. This utility assigns container access permissions to the user ID that starts the

Scheduler service. See

Directory Synchronization Access Permissions

on page 105 for more information on using

this utility.

NOTE: To run this utility, you must have Active Directory administrator privileges in addition to having Xerox Secure

Access System Manager rights.

Xerox Secure Access Unified ID System® Administration Guide 77

Chapter 4: Creating & Managing Accounts

Associating Swipe Cards with Secure Access Accounts

If your users swipe magnetic cards to identify themselves at the printer or copier through an external XCP device or control terminal, use the Card Swipe wizard to add the swipe card account associations to the Secure Access database.

This wizard enables you to swipe a magnetic swipe card on an XCP device, or on a simple wedge card reader with keyboard interface. The wedge card reader option is mandatory if you are using card readers that do not interface with a PC. Contact Equitrac Technical Support for a list of compatible wedge card readers.

CAUTION: For XCP devices only, disconnect the network cable from the card reader when using the Card Swipe wizard. The only cable you can attach to the card reader during this procedure is the nine-pin serial cable. If both the serial and network cables are connected for the wizard, you risk registering unusable characters from the XCP device in the PIN information.

4

5

8

9

To add account identifications for magnetic cards:

1

2

3

6

7

Before you start the Card Swipe Wizard, you must shut down the Device Control Engine.

Select Start > Control Panel > Administrative Tools > Services. Right-click the EQ DCE Service in the right pane and select Stop.

For XCP devices only, ensure that you have configured the COM port for the card reader correctly in the operating system BIOS and Control Panel. For all other devices, proceed to the next step.

Use a nine-pin cable to connect the card reader to the serial port.

On an administrative workstation, browse to Programs Files\Xerox\Xerox Secure Access\Tools. Select the Card

Swipe Wizard.

In the wizard’s first dialog box, select a Card swipe unit. If you select XCP, specify the serial port to which the card reader is connected.

Enter the Windows network name of the computer that hosts the accounting server. Click Next.

Swipe the magnetic card.

In the following dialog box, verify that the card reader has successfully retrieved the primary PIN data from the card. Optionally, you can specify a secondary PIN for the card. Click Next.

NOTE: The card reader reads the primary PIN from the card based on the card swipe position you configure in

System Manager > Devices > Control Terminals; see

Control Terminals

on page 33 for details. The secondary PIN is

like a password for the user. If you use the secondary PIN, you must also configure Xerox Secure Access to prompt for it; see

User Authentication

on page 72 for details.

10

In the following dialog box, select the type of account that Xerox Secure Access associates with this card. In the accompanying text box, specify the name of the account and click Verify. The wizard verifies that the specified account exists in the Xerox Secure Access database and displays the account description.

11

To continue using the wizard to configure more cards with Xerox Secure Access accounts, click Another card.

12

To exit the wizard, click Finish.

13

Open Start > Control Panel > Administrative Tools > Services. Right-click the EQ DCE Service in the right pane and select Start.

The account identifications appear in System Manage.

78 Xerox Secure Access Unified ID System® Administration Guide

5

Advanced Printing Configuration

Topics

Enabling Secure Printing

Managing Device Pull Groups

Setting Up Follow-You Printing

Beyond the basic configuration, Xerox Secure Access offers several different advanced printing options. This chapter provides reference information and complete instructions to configure each of these advanced features:

Secure printing sets up virtual print queues that hold jobs until they are released at an MFP embedded device by a valid user.

Device Pull Groups provide a method of organizing compatible printers to allow users to release print jobs from the secure queue to any device within the pull group on the same print server. Pull Groups extend secure printing functionality, and are required for Follow-You Printing.

Follow-You Printing extends the Secure Printing functionality to allow users to pull their print jobs from one secure print queue to another, even across Print Servers.

Xerox Secure Access Unified ID System® Administration Guide 79

Chapter 5: Advanced Printing Configuration

Enabling Secure Printing

Secure printing holds documents in a secure print queue until the user releases the document from an embedded device.

In environments where users print proprietary or confidential documents, secure printing gives users the power to control the timing of their output. Xerox Secure Access holds documents sent to registered devices in DRE’s secure print queue. Through a client application or control terminal, users can view documents in the queue, then select, delete, or release documents for printing.

Depending on the needs of your organization, you can setup basic secure printing only or extend the functionality to use Follow-You Printing. For more on Follow-You Printing, see

Managing Device Pull Groups

on page 82.

Secure Printing Configuration Workflow

You can enable secure printing on any device that is configured to use the Managed Print Port Monitor. Follow this workflow to enable basic secure printing system-wide.

1

2

Convert all existing ports to Managed Print Ports.

See

Creating Managed Print Ports

on page 25 for instructions on converting or adding ports.

Enable secure printing on each device queue.

For every device that you want to hold print jobs in a queue, rather than printing directly, enable the secure printing option on the device’s queue: a b

In System Manager, click Devices.

Switch to Standard view, then expand the device’s port to view the print queue for that printer/port.

c

Click the print queue link to open the Device summary dialog box.

80

d

In the Behavior options, enable the Secure printing option and click OK.

Xerox Secure Access Unified ID System® Administration Guide

Chapter 5: Advanced Printing Configuration

Administering the Secure Print Queue

The Print Queue Viewer provides a tool for Administrators to view and delete documents within the secure print queue. Each DRE has its own print queue, and therefore its own Viewer. If you deployed multiple DREs you can run multiple Viewers at the same time. You must specify the print server (DRE) you want to connect to when you launch the Viewer.

1

2

On your Windows desktop, navigate to Start > All Programs > Xerox Secure Access > Print Queue Viewer. This creates the Viewer icon in the Windows system tray.

Double-click the icon to open the Print Queue Viewer.

3

4

Click any document in the list to select it. Hold down

SHIFT

or

CTRL

to select multiple documents in the queue.

You can sort documents in the list by clicking any of the column headings visible in the Viewer.

To delete selected documents from the queue, press the Delete key or choose Delete from the Document menu.

Select View > Simple view or View > Full view to change the default view depending on how many document details you want to display.

NOTE: Start the Print Queue Viewer with the

-s

option to customize Viewer’s visible columns. Select View > Custom

view, and then select View > Select columns to select or clear columns as desired.

Select View > Hide to close the Viewer without shutting down the service. The Viewer icon remains visible in the

Windows system tray. Use the Refresh option to update the Viewer document list while the Viewer is open; the list does not refresh automatically.

To shut down the service, right-click the icon in the system tray and select Exit. You can also select Show/Hide to open or close the Print Queue Viewer window.

Xerox Secure Access Unified ID System® Administration Guide 81

Chapter 5: Advanced Printing Configuration

Managing Device Pull Groups

As you configure devices in System Manager, you can create and manage printer pull groups that group similar devices together. With secure printing enabled, users can release jobs from the pull group queue to any compatible device within the pull group. Pull groups are required to support Follow-You Printing.

The groups you create should reflect the needs of your organization. For example, you can group compatible devices by physical location or by manufacturer.

You can create pull groups that include a selection of devices from a single print server only OR across multiple print servers.

Two pull groups are created from a single printer server

Two pull groups are created from across printer servers

Choosing Devices to Group

The key to creating pull groups is to ensure that all device drivers within the group are technologically compatible. If you want a print job generated for one printer to output successfully on another printer, you must ensure that the other printer can understand all of the print commands included in the datastream from the driver.

If the user specifies staples for the print job, but the target device does not support staples, Xerox Secure Access charges for the staples if the associated price list specifies a finishing cost. Similarly, if the user specifies the print job as full color, but releases the job on a machine that supports black and white only, the output is black and white, but

Xerox Secure Access charges for color, depending on the price list on the release machine, and color attributes that are recorded in the database.

You can also add the same device to multiple pull groups. For example, if you want to enable users to retrieve all print jobs (both color and monochrome) at a color device, but only monochrome print jobs at a monochrome device, you can add the same device to two different pull groups: one groups color devices, the other groups monochrome devices.

82 Xerox Secure Access Unified ID System® Administration Guide

Chapter 5: Advanced Printing Configuration

Printer Pull Group Workflow

To create a pull group, follow this workflow:

1

2

3

Enable secure printing on all physical devices that you want to add to the pull group.

See

Secure Printing Configuration Workflow

on page 80 for instructions.

Associate a control terminal with each physical device that is part of a control group.

See

Control Terminals

on page 33 for instructions.

Assign two or more devices to one or more pull groups.

a b

In System Manager, select Devices, then click on one or more physical devices.

Use

CTRL

-click or

SHIFT

-click to select more than one device.

In the Physical Device Summary dialog box, select Release documents from pull group. Type in the name of the Pull group (e.g. PullGroupA), then click OK to apply the change. You only have to type in the name of the

Pull group the first time you use it. Afterward, it appears in the list automatically. c d

Repeat steps a and b for each physical device that should be part of a Pull group.

To add the device to multiple pull groups, enter the name of the pull groups into the Release documents from

pull group field, separated by a semi-colon. For example, PullGroupA; PullGroupB; PullGroupC.

Xerox Secure Access Unified ID System® Administration Guide 83

Chapter 5: Advanced Printing Configuration

Setting Up Follow-You Printing

Follow-You Printing extends the basic functionality of secure printing by allowing a user to release a print job to other compatible devices in the organization. Even if you deployed multiple DRE print servers, each of which manages a separate set of devices, you can configure Xerox Secure Access to allow printing across print servers.

For example, a user who works in two different buildings can submit their print job from their computer in Building

A, and while enroute to a meeting in Building B, the user can walk up to an embedded device and pull the job to a compatible printer nearest them.

When a user submits a print request, they select a destination printer, but the job is actually held in DREs secure print queue. The user can walk up to an embedded device, and release the job to any compatible printer in the Pull group.

Users may also retrieve Follow-You Printing jobs on a device connected to a different CAS and DCE/DRE server. For more information, see

Follow-You Printing Across Multiple Accounts Servers

on page 86.

Pull groups are simply groups of compatible printers, manually grouped by the Administrator. Devices assigned to a

Pull group can be managed by any DRE print server, allowing the user to print across Print Servers and “pull” their print job where it is needed. For full details on Pull groups, see

Printer Pull Group Workflow

on page 83.

Follow-You Printing Configuration Workflow

To set up Follow-You Printing, complete the following workflow.

1

2

Enable secure printing on each device.

Configure the devices to use secure printing. See

Enabling Secure Printing

on page 80 for instructions.

Create Pull groups, and add physical devices to each Pull group.

Identifying the Home Server for each User

When Follow-You Printing is enabled, and you have deployed many DRE Print Servers, you can set the Home Server attribute to help users locate their print jobs a little more quickly. This is an optional setting, and is used only to assist users locate their print jobs when releasing.

The Home Server is the DRE that hosts the devices that the user typically prints to. If the user wants to release jobs to devices on a different Print Server, they can use the Search functionality provided.

To establish the Home Server per user, switch to System Manage, and select Users. Click on any user account to open the Properties dialog box. In the Home server field enter the DRE print server that serves as the users main server.

CAUTION: If you are using ADS to synchronize User Accounts, ensure that you assign a Home Server value in the

Active directory synchronization dialog box. See

Importing Users with Active Directory Services

on page 57 for

instructions.

84 Xerox Secure Access Unified ID System® Administration Guide

Chapter 5: Advanced Printing Configuration

Configuring Follow-You Printing

To configure Follow-You Printing settings, do the following:

1

In System Manager, navigate to Configuration > Printing > DRE/DRC and Follow-You Printing.

2

3

4

Select the Site where you want Follow-You Printing to be accessible from.

In the Settings section, select any of the following options:

Cost the job before printing – Pricing does not apply to Xerox Secure Access.

Reprice after release – Pricing does not apply to Xerox Secure Access.

Released document name – enter a name for the document as it will appear in the print queue viewer after the job has been released from the Equitrac secure print queue.

Hide document name in Windows print window – select this option if you do not want certain documents

(e.g. confidential) from being viewed in the general print queue.

Only print released job while user is logged in to device– if the user logs off prior to printing, the job is put back into the print queue without being released, and the re-queued print job is not charged to the user.

In the Space management section, do the following: a

Enter the Job expiry time. This is denoted in hours.

b c

Enter the Print distribution job expiry time. This is denoted in hours.

Enter the Minimum disk space required to hold a print job.

Xerox Secure Access Unified ID System® Administration Guide 85

Chapter 5: Advanced Printing Configuration

5

6

7

Select Enabled or Disabled as the global Secure printing default for Follow-You Printing.

Select Retrieve username from PJL setting for applications that insert the PJL string into the print job. For example HP ePrint Enterprise uses this PJL setting.

Click OK to save the settings.

Follow-You Printing Across Multiple Accounts Servers

2

3

Users are able to retrieve Follow-You Printing jobs on MFPs connected to several CASs. Follow this workflow to configure multi-server Follow-You Printing:

1

User must be registered in the database on all relevant CASs with the home server value correctly set. See

Working with User Accounts

on page 54. Users must always print on their home server.

The pull group name must be the same on every CAS. See

Managing Device Pull Groups

on page 82.

Both DCE/DRE servers need to be running under the same security credentials. See your operating system’s documentation for more information on this.

86 Xerox Secure Access Unified ID System® Administration Guide

6

Configuring HID Cards

Topics

HID Encoding

HID Decoding

HID cards can be configured to allow users to identify themselves at control terminals in the same way as when using a magnetic stripe or proximity card.

Xerox Secure Access Unified ID System® Administration Guide 87

Chapter 6: Configuring HID Cards

HID Encoding

1

2

HID cards can be used to allow users to identify themselves at the control terminal just as though they were using a magnetic stripe or other supported proximity card. To configure HID cards to function with the control terminal, you must identify how your HID cards are encoded with your facility and ID codes and how that information relates to the user PIN data in Xerox Secure Access. You can then configure the Secure Access server to interpret the data it receives and use it to identify your users.

To configure the control terminal to accurately read HID cards, you require the following:

3

4

Ensure Xerox Secure Access is running.

Ensure you are still running the correct control terminal firmware version. Firmware versions prior to 1.1.47 do not support the HID decoding described in this document.

Ensure that the type of HID proximity card you are using is supported. See

Supported HID Card Types

on page 88

for details.

Write down the following HID card encoding information:

Facility Start – the position in the raw bitstream (0 based, left to right, inclusive) where the Facility code begins.

Facility End – the position in the raw bitstream (0 based, left to right, inclusive) where the facility code ends.

Facility Width – the number of expected decimal digits representing the facility code from among the string of numbers returned by the control terminal.

ID Start – the position in the raw bitstream (0 based, left to right, inclusive) where the ID code begins.

ID End – the position in the raw bitstream (0 based, left to right, inclusive) where the ID code ends.

ID Width – the number of expected decimal digits representing the ID from among the string of numbers returned by the control terminal.

NOTE: The terminal returns a single value comprising of both the facility code (if used) and ID

(facility + ID).

If you do not know the encoding used on your HID proximity cards, this document provides a reasonable method to

ascertain your card encoding. See

Determining HID Card Encoding

on page 92. However, if you do not succeed in

discovering your card encoding using the method provided, contact your HID vendor for assistance.

Supported HID Card Types

The following is a list of supported HID card formats. The illustrations shown for each card is from HID’s product data sheets. However, refer to the HID Web site in case of discrepancy.

RFID Carrier frequency

The RF signal used to exchange information between the powered card reader and the passive card can operate at many different frequencies and ranges (125 KHz carrier frequency, or Mifare and Legic standard using a 13.56 MHz carrier frequency).

88 Xerox Secure Access Unified ID System® Administration Guide

Chapter 6: Configuring HID Cards

HID offers a variety of products using different carrier frequencies and standards (HID IClass cards, HID Corporate

1000, HID Mifare, and others). However, since the control terminals have HID readers using a 125KHz carrier frequency, only certain card formats can be read by the control terminal.

Card Numbering and Labelling

All cards have the following numbering system printed on them for distribution purposes:

Card ID Number: 12345

Sales Order Number: YYYYYYYY-YY

Format: 12345 YYYYYYYY-YY

These numbers do not directly relate to the data stored on them. Some organizations may choose to deploy cards with labels that clearly display the Facility and ID codes stored on the card. Other may choose to obfuscate the data for security reasons and omit labels completely, or label the cards with a randomly generated serial number. For this reason, it is not always possible to infer the facility or ID codes from card labels, nor can you infer the type of encoding used on the cards based on the numbers printed on the exterior. See

Determining HID Card Encoding

on page 92 for

more details.

MicroProx Tag

RF-programmable, 125 kHz, customer-specified numbers.

ISOProx II

RF-programmable, 125 kHz, customer-specified ID numbers, locations marked for horizontal and vertical slot punch.

Xerox Secure Access Unified ID System® Administration Guide 89

Chapter 6: Configuring HID Cards

DuoProx II

RF-programmable, 125 kHz, customer-specified ID numbers, locations marked for horizontal and vertical slot punch.

Smart ISOProx II

RF-programmable 125kHz, customer-specified ID numbers, location marked for vertical slot punch.

Smart DuoProx II

RF-programmable 125kHz, customer-specified ID numbers, location marked for vertical slot punch.

90 Xerox Secure Access Unified ID System® Administration Guide

ProxKey II

RF-programmable, 125 kHz, charcoal gray, customer-specified ID Numbers.

Chapter 6: Configuring HID Cards

ProxCard

®

II

RF-programmable, 125 kHz, HID artwork, customer-specified ID numbers, vertical slot punch.

Xerox Secure Access Unified ID System® Administration Guide 91

Chapter 6: Configuring HID Cards

Determining HID Card Encoding

HID uses a proprietary encoding format to encode data (ID or facility code and ID) on proximity cards. Generally, the encoding types used are either 26 or 37-bits, or in the case of some corporate cards, 35-bits.

Encoding Types

The encoding is comprised of a beginning and end parity bit. Between these parity bits is a string of binary digits. The first part—on the left—can be the facility code if your site uses one. The second part (possibly the entire string if there is no facility code) of the binary string—on the right—is the encoded ID code.

26-bit encoding

37-bit encoding with Facility code and ID code

37-bit encoding with ID code only

Although it is possible to decipher the type of encoding used via the Card Swipe Wizard, it is best to contact your HID vendor to determine the encoding type used on your proximity cards.

The embedded HID card reader always returns 16 octal digits, which when converted to binary equals 48 digits. The

HID card reader zero-pads the string returned from the card to equal 48 binary digits, regardless of the proprietary encoding used on the card. Therefore, knowing the type of encoding used on your card helps, since the actual digits returned from the card always appear at the end of the data string. The trick then is to decipher where the facility code

(if used) and ID code begin and end within the binary data string.

92 Xerox Secure Access Unified ID System® Administration Guide

Chapter 6: Configuring HID Cards

To determine card encoding, you require the following:

• The ability to convert between different numeric notations (octal, binary, and decimal). You can use the calculator application available in most versions of Windows for this. However, you need to change the view to Scientific. See the help file within the calculator application for detailed instructions.

• An embedded device with an HID proximity card reader.

• One or more sample HID Proximity cards (see

Supported HID Card Types

on page 88 for supported card

formats).

• The codes expected to be returned by the sample proximity cards. Contact your security system administrator or

HID vendor for assistance.

Determining Code Start and Stop Positions – Known Codes

If you have a sample card and you know the codes you expect to see returned from it, you can follow the procedure below to determine where the codes begin and end in the binary data string returned from the HID card reader.

1

To see the full value of the data string returned by the HID card reader, you must change the card swipe PIN settings: a

Open System Manager and click on the Configuration > User authentication link to open the User

authentication dialog box.

b

Change the from and to positions in the Card setup area to read:

Use data from position 1 to 32 as the primary PIN.

2

3

4

Configure your HID embedded device to use a static IP. Change the server IP address setting to point to the IP address of the system on which you run the Card Swipe Wizard.

Temporarily disable HID decoding on the device to examine the raw data only (see

Disabling and Enabling HID

Decoding on the Control Terminal

on page 99).

If you plan to run the Card Swipe Wizard on the server running DCE, stop the EQ DCE Service on the server:

Xerox Secure Access Unified ID System® Administration Guide 93

Chapter 6: Configuring HID Cards

5

On an administrative workstation, browse to the Tools folder within the directory where Xerox Secure Access is installed (for example, C:\Programs Files\Xerox\Xerox Secure Access\Tools) and run the CardSwipeWizard.exe file to launch the Card Swipe Wizard.

6

7

8

9

Select PageCounter device as the Card swipe unit.

Enter the Windows network name of the computer that hosts the accounting server and click Next.

Power on the control terminal configured in step 2 and wait for it to connect to the system running the Card Swipe

Wizard.

Take your sample card (for example, with the number 87343 11082200-1 printed on the card) and swipe it at the terminal. The Card Swipe Wizard displays the extracted data string from the sample card in the Primary PIN field.

The following table shows the number printed on the card as well as the expected values that you know should be returned by the HID card reader.

Number Printed on the

Card

87343 11082200-1

Expected Facility Code to be returned (in decimal)

109

Expected ID Code to be returned (in decimal)

86343

CAUTION: The number printed on the card may not be the facility code or ID code.

Since HID decoding is disabled on the terminal, the HID card reader in the control terminal return the entire data string from the card in octal format.

Number Printed on the Card

87343 11082200-1

Value returned (octal)

0000201550521216

10

Convert the extracted octal string to its binary value using the Microsoft Windows Calculator:

Value returned (octal)

0000201550521216

Value returned (binary)

000000000000010000001101101000101010001010001110

94 Xerox Secure Access Unified ID System® Administration Guide

Chapter 6: Configuring HID Cards

NOTE: It is important to keep the leading digits in the stream. The Windows Calculator usually strips off leading zeros. To adjust your output, you have to ensure there is a group of three binary digits for each octal digit in the raw data stream. You should have a total of 48 binary digits.

You can now analyze the resulting sets of the binary sequence found from one of your samples. Convert the expected codes to be returned from the wizard from decimal to binaryOpen the HIDEncoding-Ruler.txt file.

Expected Facility Code

(in decimal)

109

Expected Facility Code

(in binary)

1101101

Expected ID code

(in decimal)

86343

Expected ID code

(in binary)

10101000101000111

11

Paste the binary string you converted from the Card Swipe Wizard into Notepad above the makeshift ruler. Be sure to add enough leading zeros to make the string equal 48 digits: a

If you use a facility code, click Edit > Find and input the expected binary string representing the facility code to have Notepad find the digits for you: b

Using the ruler, you can see that in the example above that the facility code is located from digit 20 to digit 26 inclusive.

Click Edit > Find again and input the expected binary string representing the ID code to have Notepad find the string for you:

Using the ruler, you can see from the example above that the ID code is located from digit 30 to digit 46 inclusive.

Xerox Secure Access Unified ID System® Administration Guide 95

Chapter 6: Configuring HID Cards

NOTE: It is possible that the starting bit might actually begin one or more digits earlier if there are leading zeros.

Therefore it is a good idea to test the card after this procedure to ensure that you have recorded the correct start

and end positions. See

HID Decoding

on page 100.

12

Record the start and end locations for the facility code (if used) and ID code to use when setting up Xerox Secure

Access.

13

Close the Card Swipe Wizard.

14

If required, restart EQ DCE Service on the DCE server.

15

Enable HID decoding on the control terminal.

NOTE: If you need to use the Card Swipe Wizard to read HID cards and setup Xerox Secure Access PINs, you need to temporarily enable local caching on the control terminals, then ensure the control terminal that you are using the

Card Swipe Wizard on connects to DCE. Finally, disable the local caching setting on the control terminals. The control terminal can be used with HID cards.

Determining Code Start and Stop Positions – Unknown Codes

If you have sample cards but do not know the codes you expect to see returned from them, you can follow the procedure below to determine the codes and where they begin and end in the binary data string returned from the

HID card reader.

1

To see the full value of the data string returned by the HID card reader, you must change the card swipe PIN settings: a b

In Xerox Secure Access, open System Manager and click on the Configuration > User authentication link to open the User authentication dialog box.

Change the from and to positions in the Card setup area to read:

Use data from position 1 to 32 as the primary PIN.

2

3

Configure your HID embedded control terminal control terminal to use a static IP. Change the server IP address setting to point to the IP address of the system on which you run the Card Swipe Wizard.

Disable HID decoding on the control terminal (see

Disabling and Enabling HID Decoding on the Control

Terminal

on page 99).

If you plan to run the Card Swipe Wizard on the server running DCE, stop the EQ DCE Service on the server:

WARNING: The Card Swipe Wizard can only talk to one control terminal at a time. If there are multiple terminals pointing to the system running the Card Swipe Wizard, you need to unplug all but the one you configured in step 2.

5

6

4

On an administrative workstation, browse to the Tools folder within the directory where Xerox Secure Access was installed (the default installation folder location is C:\Programs Files\xerox\Xerox Secure Access\Tools) and run the CardSwipeWizard.exe file to launch the Card Swipe Wizard.

In the wizard’s first dialog box, select PageCounter device as the Card swipe unit.

Enter the Windows network name of the computer that hosts the accounting server and click Next.

96 Xerox Secure Access Unified ID System® Administration Guide

Chapter 6: Configuring HID Cards

7

8

Power on the control terminal configured in step 2 and wait for it to connect to the system running the Card Swipe

Wizard.

Take a sample of five or more cards (for example, with the format 87343 11082200-1 printed on the cards) and swipe them at the terminal. The Card Swipe Wizard displays the extracted data strings in the Primary PIN fields.

Number printed on Card

87343 11082200-1

87344 11082200-1

87345 11082200-1

87346 11082200-1

87347 11082200-1

Value returned from Card Swipe Wizard (octal)

0000201550521216

0000201550521220

0000201550521223

0000201550521225

0000201550521226

NOTE: For a more precise determination, it is best to use a large number of cards. However, five to seven cards should suffice for this procedure.

9

Since HID decoding is disabled on the terminal, the HID card reader in the control terminal returns the entire data string from the card in octal format.

Convert each octal number to its binary value:

Value returned (octal)

0000201550521216

0000201550521220

0000201550521223

0000201550521225

0000201550521226

Value returned (binary)

000000000000010000001101101000101010001010001110

000000000000010000001101101000101010001010010000

000000000000010000001101101000101010001010010011

000000000000010000001101101000101010001010010101

000000000000010000001101101000101010001010010110

NOTE: It is important to keep the leading digits in the stream. The MS Calculator usually strips off leading zeros. To adjust your output, you have to ensure there is a group of three binary digits for each octal digit in the raw data stream. You should have a 48 digit binary string for each card.

You can now analyze the resulting sets of the binary sequence found from your samples.

10

Open the HIDEncoding-Ruler.txt file.

Xerox Secure Access Unified ID System® Administration Guide 97

Chapter 6: Configuring HID Cards

11

Now paste each of the binary strings you converted from the Card Swipe Wizard into Notepad above the makeshift ruler. Be sure to add enough leading zeros to make each string equal 48 digits and then look for patterns:

Try to match the returned binary strings against the card encoding type formats to see if your cards seem to match any of them. If they do, use the format to determine the start and end positions of the facility (if used) and ID codes. If they do not, as in the case above, you need to make some assumptions as follows:

• We know that if there is a facility code, it appears first (on the left) and that the ID code appears on the right.

• The facility code should be the same for all cards. Therefore if there is a set of digits on the left that are identical in all strings, then you can assume that it is the facility code. In the example given above, the pattern appears from digit 20 to 26.

• You can assume that the last binary digit in the string is a parity digit and disregard it. This assumption is based on what we know to be true about HID encoding types.

• If you contacted your HID vendor, hopefully they gave you the card encoding type and the card ID range. If you know the card ID range, you can use the information to help determine where the ID code starts and ends.

For example, if you know that the cards deployed at your site are between 75,000 and 200,000 you can determine that the largest card ID (200,000) in binary would require 18 digits (110000110101000000), therefore you would be able to assume the ID portion of the string is from digits 29 to 46 inclusive.

NOTE: The ID portion could actually be from digit 27 to 46 inclusive, or the facility code could be from digit 20 to 29.

Therefore, you may need to analyze these patterns several times to determine exactly where the codes start and end.

12

Record the start and end locations for the facility code (if used) and ID code for use in setting up Xerox Secure

Access.

13

Close the Card Swipe Wizard.

14

If required, restart EQ DCE Service on the DCE server.

NOTE: It is best to test the assumptions you made during this procedure by reading an HID card with the control terminal and verifying that the card can log in. The card points to the correct account if the HID decoding parameters are set correctly.

15

Enable HID decoding on the control terminal.

98 Xerox Secure Access Unified ID System® Administration Guide

Chapter 6: Configuring HID Cards

Disabling and Enabling HID Decoding on the Control Terminal

The HID card reader within the control terminal returns the data from the cards in octal format. However, when HID decoding is enabled, the control terminal converts the data returned by the HID card reader into a decimal string as configured by your HID parameters. Therefore you need to Disable HID decoding prior to using the Card Swipe

Wizard to extract the encoded octal data value.

NOTE: By default, control terminals with internal HID proximity readers have HID decoding turned on. You only need to disable HID decoding on one control terminal to determine your HID decoding format.

3

4

To disable HID decoding on a control terminal, complete the following:

1

2

5

Enter Manager Mode on the control terminal, see your Equitrac PageCounter Administration Guide for details regarding Manager Mode.

Press 4 for Devices.

Press 1 for HID Card Settings

Enable or disable HID decoding by completing one of the following:

• Press 1 to enable HID decoding

• Press 2 to disable HID decoding

Disabling decoding for the duration of a test ensures that the terminal returns the raw data (represented in octal format) read from the card.

Press F3 (Back) until you exit Manager Mode.

The control terminal automatically reboots.

WARNING: If you manually reboot the terminal before exiting Manager Mode, your changes are not saved.

You must re-enable HID decoding once you have finished determining your HID parameter values using the Card

Swipe Wizard. Turning HID decoding on again enables the control terminal to return the proper PINs from your HID proximity cards.

Xerox Secure Access Unified ID System® Administration Guide 99

Chapter 6: Configuring HID Cards

HID Decoding

Due to the variation in encoding formats allowed by HID, the USB card reader or control terminals must be configured to return card information in a standard format. You configure the card decoding parameters on the accounting server and these settings are relayed to your USB card reader or control terminals. For details on how HID card values are encoded. See

Determining HID Card Encoding

on page 92 for details.

Xerox Secure Access can support a mixed HID card environment (e.g. different card configurations with different facility codes read by the same USB card reader), and a mixed device and card reader environment (e.g. Equitrac and non-Equitrac card readers decoding the same ID value from the card). In order to accomplish this, you can create different HID profiles (referred to as "Decoding groups") to determine how a specific card reader decodes the HID card data.

To configure how the USB card reader or control terminal decodes the ID and Facility codes, do the following:

1

2

3

Ensure that your card type and encoding format are supported, and that you know the details of how your HID

cards are encoded with your facility and ID information. See

Determining HID Card Encoding

on page 92 for

details.

Open System Manager, and click Configuration > User authentication.

Click <None> located beside HID decoding within the Card setup section.

4

In the HID decodings dialog box, click Add from the Decoding groups section.

100 Xerox Secure Access Unified ID System® Administration Guide

Chapter 6: Configuring HID Cards

5

Enter an HID decoding group name, and click OK.

6

7

Select the group from the list, and then click Add from the Decoding groups settings section.

In the HID decoding dialog box, enter the following:

In the case where you do not need to extract facility code information, check ID codes only. If you need to extract both Facility code and ID code, check both options. a

In the Facility code Start field, enter the position in the raw bitstream (0 based, left to right, inclusive) where the Facility code begins. b c

In the Facility code End field, enter the position in the raw bitstream (0 based, left to right, inclusive) where the facility code ends.

In the Facility code Width field, enter the number of decimal digits for the facility portion of the value that the

USB card reader or control terminal outputs. Numbers are zero-padded on the left as needed. d e

In the ID code Start field, enter the position in the raw bitstream (0 based, left to right, inclusive) where the ID code begins.

In the ID code End field, enter the position in the raw bitstream (0 based, left to right, inclusive) where the ID code ends. f g

In the ID code Width field, enter the number of decimal digits for the ID code portion of the value that the

USB card reader or control terminal outputs. Numbers are zero-padded on the left as needed. The USB card reader or control terminal returns a single value for each card swipe that is the decoded facility code followed by the decoded ID

.

Enter a Matching facility code if you want the card reader to locate the same facility code on different HID formatted cards. i h

Select the Include facility code in PIN option if the facility code is part of the user PIN.

Click OK.

8

9

Repeat this procedure for any additional decoding groups you want to define for you environment.

If more than one group is defined, the first group in the list will be used as the default decoding by the embedded device. If you want to change the default, select a group from the list and click Make default.

10

Click OK to save the decoding groups.

Xerox Secure Access Unified ID System® Administration Guide 101

Chapter 6: Configuring HID Cards

102 Xerox Secure Access Unified ID System® Administration Guide

7

Using Xerox Secure Access Utilities

Topics

Enabling SSL Communication

Directory Synchronization Access Permissions

Purge Database Transactions

Modifying User Accounts from a Flat File

Refining the User Group View

Print Queue Viewer

Xerox Secure Access provides several different utilities that can help you speed up the time spent on configuration tasks. This chapter contains instructions to run some of these utilities. Instructions to use other utilities are located throughout this guide in the appropriate location. Use the table below to locate instructions for running all Secure

Access utilities.

Utility

CardSwipeWizard.exe

EQAccountRegroup.exe

EQCmd.exe

EQEnableSSL.exe

EQModifyDeletedContainer

Security.exe

EQPrinterConversion

Wizard.exe

EQTransactionPurge.exe

Description See Page

Determines the encoding and data positions on magnetic or prax cards.

Determining Code Start and Stop

Positions – Known Codes

on page 93

Filters the User Group view when managing a large account base.

Refining the User Group View

on page 111

Adds, deletes, modifies or query user, accounts from a flat file.

Modifying User Accounts from a Flat

File

on page 107

Enables/disable SSL communication between Equitrac services and clients.

Changes the administrative access permissions on the deleted objects container in a Windows Active Directory.

Converts existing printer ports to an

Managed Print Port, allowing Equitrac to monitor the device.

Purges transactions from the database.

Enabling SSL Communication

on page 104

Directory Synchronization Access

Permissions

on page 105

Creating Managed Print Ports

page 25

Purge Database Transactions

page 106

on

on

Xerox Secure Access Unified ID System® Administration Guide 103

Chapter 7: Using Xerox Secure Access Utilities

Enabling SSL Communication

Communication between Secure Access components running in a Windows environment can utilize SSL (Secure

Socket Layer) if required. To enable this feature, run the EQEnableSSL.exe utility located in the Program

Files\Xerox\Xerox Secure Access\Tools folder.

NOTE: EQEnableSSL.exe must be run on every system running Xerox Secure Access software that uses an SSL connection. (e.g. CAS, DRE, DCE). Shutdown all Equitrac services and utilities (e.g. System Manager) before running this command.

The command-line utility accepts the following command:

EQEnableSSL.exe [-e -d –h]

The following table lists the values for each letter.

Value

-e

-d

-h

Description

enables SSL communication from this system.

disables SSL communication from this system.

displays this help screen.

No parameters display the current settings.

NOTE: For compatibility reasons, management communications are not currently encrypted even if this feature is enabled. Non-Windows DREs do not support encrypted connections.

104 Xerox Secure Access Unified ID System® Administration Guide

Chapter 7: Using Xerox Secure Access Utilities

Directory Synchronization Access Permissions

EQModifyDeletedContainerSecurity.exe changes the administrative access permissions on the deleted objects

container in a Windows Active Directory, so that Xerox Secure Access can access the objects during directory synchronizations.

By default, only Active Directory administrators have access permission. The Windows account running the Xerox

Secure Access services need this access if you wish to synchronize deleted accounts between Active Directory and

Xerox Secure Access.

The account running the EQModifyDeletedContainerSecurity.exe command must be an administrator in the Active

Directory domain.

See

Importing Users with Active Directory Services

on page 57 for more information on configuring Active

Directory Synchronization options.

Xerox Secure Access installs this utility on the accounting server in the Program Files\Xerox\Xerox Secure

Access\Tools folder.

The command line utility accepts commands in the following format:

EQModifyDeletedContainerSecurity.exe <-s server> [-p | {-r} -a accountname]

Parameters enclosed in parentheses < > are mandatory; parameters within square brackets [ ] are optional.

Parameter

-s server

-p

-r

- a accountname

Description

Server name of the Active Directory domain controller.

Display current permissions on the container.

Remove access permissions for the specified accountname.

Account to be granted access to the container. Access permission is removed if specified with the -r option.

Xerox Secure Access Unified ID System® Administration Guide 105

Chapter 7: Using Xerox Secure Access Utilities

Purge Database Transactions

The EQTransactionPurge.exe utility purges transactions from the database.

Xerox Secure Access installs this utility on the accounting server in the Program Files\Xerox\Xerox Secure

Access\Tools folder.

The command line utility accepts commands in the following format:

EQTransactionPurge.exe [-f] [-u] <-o n | -d yyyy-mm-dd | -i NNNNN> [-t]

Parameters enclosed in parentheses < > are mandatory; parameters within square brackets [ ] are optional.

-i

-t

-o

-d

Parameter

-f

-u

Description

Force transaction purge.

Purge from uplink tables.

Purge transactions more than n days old.

Purge transactions on given date or older.

Purge a single transaction where NNNNN is a 32 digit transaction ID.

Enable trace logging.

106 Xerox Secure Access Unified ID System® Administration Guide

Chapter 7: Using Xerox Secure Access Utilities

Modifying User Accounts from a Flat File

Use the EQCmd.exe utility to add, delete, modify and query user accounts from a flat file. This method is a one-time import and does not synchronize data beyond the import.

Xerox Secure Access installs this utility on the accounting server in the Program Files\Xerox\Xerox Secure

Access\Tools folder.

The command line utility accepts commands in the following format:

EQCmd -s<Server> <Action> <Obj_type> <Obj_ID>|All [<Options>]

Execute the command with a batch file:

EQCmd -s<Server> -f<BatchFile>

Command-line parameters enclosed in parentheses < > are mandatory and require a specified value. Parameters within square brackets [ ] are optional entries and do not need to have a specified value if they will not be included in the command. Optional parameters that will be in the command, do require a specified value.

Xerox Secure Access accepts CSV files as batch files. Batch operation allows all the command actions except for query command. Use the table below to fill in the parameters.

Parameter

Server

Action

Obj_type

Obj_ID

Variables

Specify the name or IP address of CAS.

Specify the action to take on the account. Use one of:

• add - Add users.

• delete - Delete users. It does not use <details> parameter.

• query - Query database. Output differs based on <Obj_type>.

• modify - Modify an object attribute.

• adjust - Adjust the user account balance; set a new balance to a object type or set a balance no less than a certain amount.

• lock/unlock - Lock or unlock a user.

Use one of:

• ur - user

Applies

<action> only to the specified object ID. Use double quotes around object IDs that have a space, for example human resources. To apply

<Action> to all accounts of <Obj_type>, use All.

Note: You can use “All” for “Assign”, “Remove”, “Query”, “Adjust” actions. You cannot use it for “Add”,

“Delete”, “Modify”, “Lock” and “Unlock” actions.

Xerox Secure Access Unified ID System® Administration Guide 107

Chapter 7: Using Xerox Secure Access Utilities

Parameter Variables

Options for Action

Command

Specify additional values.

<init_bal> - Does not apply to Xerox Secure Access

<desc> - Description

<user_id> - User ID

<user_name> - Full user name

<email> - User email

<amount> - Amount of balance value. The value can be both positive (+) and negative (-).

<primaryPIN> - User Primary PIN

<secondaryPIN> - User Secondary PIN and Confirm Secondary PIN

<alternatePIN> - Alternate to user Primary PIN

<home_server> - DRE print server

<locked> - User account is locked

<location> - Location of the user

<delegate_id> - Does not apply to Xerox Secure Access

<additional_info> - Additional information about the user

<home_folder> - Does not apply to Xerox Secure Access

EQCmd Actions

Add

Parameters within the square brackets [ ] must contain values up to and including the final field needed. For example, if the final field is <primaryPIN>, all fields to the left must have a specified value—those to the right can be excluded from the command. If you want to leave a field blank (i.e. skip a field), enter "0" (zero) to indicate an empty value. Use double quotes around detail values that have spaces. Specify monetary amounts with a period for the decimal separator. The parameters must be entered in the specified order.

NOTE: There is one parameter in the EQCmd utility that does not apply to Xerox Secure Access but must be part of the utility. Input "0" (zero) where indicated in the following Add actions.

Add User: add ur <user_id> [<init_bal> <user_name> 0 <email> <primaryPIN> <secondaryPIN>

<alternatePIN> <home_server> <locked> <location> 0 <additional_info> <home_folder>]

Example: EQCmd -sMyServer add ur JohnD 35.50 “John Doe” 0 [email protected] 123 456 321

WATSRV lock Waterloo 0 UserX_folder

Delete

Delete a user: delete ur <user_id>

108 Xerox Secure Access Unified ID System® Administration Guide

Chapter 7: Using Xerox Secure Access Utilities

Query

Displays results from query database. Query is only allowed from the command prompt, not in CSV file batch operation.

Query a user: query ur <user_id>|All

It displays: user_ID Full_name Email Balance Limit Status

Modify

Modifies the database settings for a user.

Modifying requires values up to and including the final modified field. For example, if the final field is <email>, all fields to the left must have a specified value—those to the right can be excluded from the command. Insert an “!” for the fields to the left that you do not want to change. Any unmodified field after <email> can be left blank.

NOTE: There is one parameter in the EQCmd utility that does not apply to Xerox Secure Access but must be part of the utility. Input "!" where indicated in the following Modify actions.

Modify a user: modify ur <user_id> [<user_name> ! <email> <primaryPIN> <secondaryPIN>

<alternatePIN> <home_server> <locked> <location> <additional_info> <home_folder>]

Example: Update email address of user johnd and keep the rest of the information:

EQCmd -sMyServer modify ur johnd! ! [email protected] !

To lock a user, set the

<locked> value to "1". To unlock a user, use the unlock ur <user_id>

command. See

Lock and Unlock

on page 110 for details.

Adjust

Allows the administrator to adjust the balance for a certain object type. Adjust has three formats:

...adjust <Obj_type> <Obj_ID>|All <amount>

...adjust <Obj_type> <Obj_ID>|All set <amount>

...adjust <Obj_type> <Obj_ID>|All atleast <amount>

adjust … <amount>

Allows the administrator to adjust a balance to an object type. When adjusting the user balance, there is also a description field to state what the adjustment was regarding. Use double quotes around the description, with a maximum string length of 225 characters.

Adjust a user balance: adjust ur <user_id>|All <amount> <description>

Example: adjust user balance by $50.00 with a description of the adjustment

EQCmd -sMyServer adjust ur johnd 50 ”deposit funds”

Xerox Secure Access Unified ID System® Administration Guide 109

Chapter 7: Using Xerox Secure Access Utilities adjust … set <amount>

Allows the administrator to set a new balance to an object type. When adjusting the user balance, there is also a description field to state what the adjustment was regarding. Use double quotes around the description, with a maximum string length of 225 characters.

Set a new balance to a user: adjust ur <user_id>|All set <amount> <description>

adjust … atleast <amount>

Allows the administrator to set the object balance value no less than a certain amount. For example: if a user current balance is $10, if the administrator set atleast amount $5.00, the user's new balance is still $10; if the administrator set the atleast amount $15, then the user's new balance is changed to $15.00.

Atleast a user account: adjust ur <user_id>|All atleast <amount> <description>

Lock and Unlock

Allow the administrator to lock/unlock a user.

Lock a user: lock ur <user_id>

Unlock a user: unlock ur <user_id>

EQCmd Batch File Process

EQCmd has a batch mode. It accepts a CSV file as an batch file, one file per server.

[Xerox Secure Access\Tools file path]\EQCmd –s<Server> –fBatchFileName.csv

NOTE: Copy the .csv file to the Xerox Secure Access > Tools folder.

CSV File Format

<Action>, <Obj_type>, <Obj_ID>|All, [<Details>]

110 Xerox Secure Access Unified ID System® Administration Guide

Chapter 7: Using Xerox Secure Access Utilities

Refining the User Group View

For large installations, you may have a large-enough account base that the User Group view does not provide a sufficiently refined view of the user accounts. Xerox Secure Access includes a command line utility to divide the group listing into smaller sections or sub-sections for easier viewing.

On CAS, open the command prompt, and navigate to the Program Files\Xerox\Xerox Secure Access\Tools, then type the following command and replace the variables with appropriate values:

EQAccountRegroup [-sCASName] [-f filename] [-q] -t accounttype [-g groupmaxsize] [-l refinedgroupminimum]

-s identifies the core accounting server hosting the accounts you wish to view.

Argument

-t

-s

-f

-q

-g

-l

Result

required argument that identifies the type of account listing you want to view:

• use

-t ur for user accounts

Optional argument that identifies the core accounting server hosting the accounts

If you run the command on CAS, you do not need to enter this argument.

Identifies the output path for the command log file

Example: diagnostics.txt

Hides error details from the console

Specifies the limit when the subgroups appears in System Manage.

Example:

-g 2000 shows the users in the normal view until the number of users reaches 2000.

Specifies the number of users within the subgroups.

Example:

-l 100 list at most 100 users in each subgroup

The following example illustrates the overall usage of the command.

Subgroup after

2000 accounts

EQAccountRegroup -sBora -f diagnostics.txt -t ur -g 2000 -l 100

CAS Output Path

User

Accounts

100 users in each subgroup

Xerox Secure Access Unified ID System® Administration Guide 111

Chapter 7: Using Xerox Secure Access Utilities

The command is invoked on CAS called Bora, with the command log saved to a file called diagnostics.txt. The user accounts are grouped, and if there are more than 2000 user accounts, the tool splits them into viewable groups of 100.

When you open the User group view dialog box, Xerox Secure Access sorts the list alphabetically. Using this example, if there are less than 2000 users, only views based on first character (0-9, A-Z) are available. When there are 2000 or more users then the refined groupings are available. The refined groups in this example list a maximum of 100 accounts, though not necessarily 100 accounts in each group.

The refinements are based on first character groups that have over 100 accounts. If a first character group has 100 accounts or less, it is not further refined. For example if there are 99 users with names starting with B, then the tool does not refine the view of the B accounts. If there are 200 accounts starting with B, then there are two sub-groups of

Bs available in the refined view.

Print Queue Viewer

The Print Queue Viewer provides a tool for Administrators to view and delete documents within the secure print queue. Each DRE has its own print queue, and therefore its own Viewer. If you deployed multiple DREs you can run multiple Viewers at the same time. You must specify the print server (DRE) you want to connect to when you launch the Viewer.

The Print Queue Viewer utility is installed as part of the management tools when Xerox Secure Access is installed on your system. The EQPrintQueueViewer.exe file is placed in the Program Files\Xerox\Xerox Secure Access\Tools folder, and a shortcut is created in the Xerox Secure Access group under the Windows Start menu.

To open the Print Queue Viewer, do the following:

1

2

On your Windows desktop, navigate to Start > All Programs > Xerox Secure Access >

Print Queue Viewer. This creates the Viewer icon in the Windows system tray.

Double-click the icon to open the Print Queue Viewer.

3

4

Click any document in the list to select it. Hold down

SHIFT

or

CTRL

to select multiple documents in the queue.

You can sort documents in the list by clicking any of the column headings visible in the Viewer.

To delete selected documents from the queue, press the Delete key or choose Delete from the Document menu.

Select View > Simple view or View > Full view to change the default view depending on how many document details you want to display.

NOTE: Start the Print Queue Viewer with the

-s

option to customize Viewer’s visible columns. Select View > Custom

view, and then select View > Select columns to select or clear columns as desired.

112 Xerox Secure Access Unified ID System® Administration Guide

Chapter 7: Using Xerox Secure Access Utilities

Select View > Hide to close the Viewer without shutting down the service. The Viewer icon remains visible in the

Windows system tray. Use the Refresh option to update the Viewer document list while the Viewer is open; the list does not refresh automatically.

To shut down the service, right-click the icon in the system tray and select Exit. You can also select Show/Hide to open or close the Print Queue Viewer window.

Running Print Queue Viewer on a Workstation

To run the Print Queue Viewer application on a workstation, choose one of the following options:

• Use the Xerox Secure AccessInstaller with one of the management tools, such as System Manager.

The EQPrintQueueViewer.exe file is placed in the Program Files\Xerox\Xerox Secure Access\Tools folder, and a shortcut is automatically created in the Xerox Secure Access group under the Windows Start menu.

—Or—

• Copy the EQPrintQueueViewer.exe file to the workstation.

When manually copying EQPrintQueueViewer.exe you need to run it with the -s<DRE_server> option if you want to customize the Print Queue Viewer columns, and to view other user’s print jobs.

If the -s<DRE_server> option is not used, then the Print Queue Viewer only shows print jobs for the current user.

After running EQPrintQueueViewer.exe, a shortcut is created in the Xerox Secure Access group under the

Windows Start menu.

Xerox Secure Access Unified ID System® Administration Guide 113

Chapter 7: Using Xerox Secure Access Utilities

114 Xerox Secure Access Unified ID System® Administration Guide

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement

Table of contents
