Preface

The Sun ZFS Storage 7x20 Appliance Installation Guide contains installation, cabling and initial configuration documentation for Oracle's Sun ZFS Storage 7120, 7320, 7420 and 7700 NAS appliances.

This documentation is also available while using the appliance Browser User Interface (BUI), accessible via the Help button. The appliance documentation may be updated using the System

Upgrade procedure documented in the System Service Manual.

Who Should Use This Book

This guide is for users and system administrators who install and use the Sun ZFS Storage 7x20

NAS appliances.

Related Documentation

Refer to the following documentation for administration information, hardware overviews, service procedures and software update notes.

Administration Guide, Analytics Guide and Service Manual (http://wikis.sun.com/ display/fishworks/documentation/

)

Release Notes (http://wikis.sun.com/display/fishworks/software+updates)

Documentation, Support, and Training

The Sun web site provides information about the following additional resources:

Documentation (http://www.sun.com/documentation/)

Support (http://www.sun.com/support/)

Training (http://www.education.oracle.com)

7

8

1

1

Introduction

Overview

Introduction

The Sun ZFS Storage 7000 family of products provide efficient file and block data services to clients over a network, and a rich set of data services that can be applied to the data stored on the system.

Platforms

7120

7320

7420/7720

7700

Legacy platforms are documented in the 7110, 7210, 7310, 7410, J4400/J4500 sections of the Sun

Storage 7000 Unified Storage System Service Manual available at http://wikis.sun.com/display/ fishworks. (http://wikis.sun.com/display/fishworks.)

Expansion Storage

Sun Disk Shelf

9

Overview

10

Protocols

Sun ZFS Storage appliances include support for a variety of industry-standard client protocols, including:

SMB

NFS

HTTP and HTTPS

WebDAV iSCSI

FC

SRP iSER

FTP

SFTP

Key Features

Sun ZFS Storage systems also include new technologies to deliver the best storage price/performance and unprecedented observability of your workloads in production, including:

Analytics, a system for dynamically observing the behavior of your system in real-time and viewing data graphically

The ZFS Hybrid Storage Pool, composed of optional Flash-memory devices for acceleration of reads and writes, low-power, high-capacity disks, and DRAM memory, all managed transparently as a single data hierarchy

Data Services

To manage the data that you export using these protocols, you can configure your Sun ZFS

Storage system using the built-in collection of advanced data services, including:

RAID-Z (RAID-5 and RAID-6), mirrored, and striped disk configurations

Unlimited read-only and read-write snapshots, with snapshot schedules

Data deduplication

Built-in data compression

Remote replication of data for disaster recovery

Active-active clustering for high availability (7310, 7320, 7410, 7420, and 7720)

Thin provisioning of iSCSI LUNs

Virus scanning and quarantine

NDMP backup and restore

Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

Availability

To maximize the availability of your data in production, Sun ZFS Storage appliances include a complete end-to-end architecture for data integrity, including redundancies at every level of the stack. Key features include:

Predictive self-healing and diagnosis of all system hardware failures: CPUs, DRAM, I/O cards, disks, fans, power supplies

ZFS end-to-end data checksums of all data and metadata, protecting data throughout the stack

RAID-6 (double- and triple-parity) and optional RAID-6 across disk shelves

Active-active clustering for high availability (7310, 7320, 7410, 7420, and 7720)

Link aggregations and IP multipathing for network failure protection

I/O Multipathing between the controller and disk shelves

Integrated software restart of all system software services

Phone-Home of telemetry for all software and hardware issues

Lights-out Management of each system for remote power control and console access

Browser User Interface (BUI)

Overview

The browser user interface

The BUI is the graphical tool for administration of the appliance. The BUI provides an intuitive environment for administration tasks, visualizing concepts, and analyzing performance data.

The management software is designed to be fully featured and functional on the following supported web browsers: Firefox 3.x, Internet Explorer 7 and 8, Safari 3.1 or later, and WebKit

525.13 or later.

Chapter 1 • Introduction 11

Overview

Direct your browser to the system using either the IP address or host name you assigned to the

NET-0 port during initial configuration as follows: https://ipaddress:215 or https://hostname:215. The login screen appears.

The online help linked in the top right of the BUI is context-sensitive. For every top-level and second-level screen in the BUI, the associated help page appears when you click the Help button.

Command Line Interface (CLI)

The CLI is designed to mirror the capabilities of the BUI, while also providing a powerful scripting environment for performing repetitive tasks. The following sections describe details of the CLI. When navigating through the CLI, there are two principles to be aware of:

Tab completion is used extensively: if you are not sure what to type in any given context, pressing the Tab key will provide you with possible options. Throughout the documentation, pressing Tab is presented as the word "tab" in bold italics.

Help is always available: the help command provides context-specific help. Help on a particular topic is available by specifying the topic as an argument to help, for example help

commands

. Available topics are displayed by tab-completing the help command, or by typing help topics.

You can combine these two principles, as follows: dory:> help tab builtins commands general help properties script

12 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

2

2

Installation

Installation

Introduction

This section addresses how to physically install the system chassis into a rack, connect controllers in a cluster, and expand storage. The following topics are described.

Overview

7x20 controller installation tasks

Sun Disk Shelf installation tasks

7700 cabinet planning and installation tasks

Cabling

Powering on the appliance

Initial configuration

Refer to the following sections of the Sun Storage 7000 Unified Storage System Installation Guide for legacy platform installation instructions at http://wikis.sun.com/display/fishworks.

(http://wikis.sun.com/display/fishworks.)

7x10 installation tasks

J4400/J4500 Disk Shelf Installation

13

Overview

Overview

14

Precautions

Observe the following cautions when installing any Sun ZFS Storage 7x20 controller or cabinet.

Always load equipment into a rack from the bottom up so that it will not become top-heavy and tip over. Deploy the anti-tip bar to the prevent the rack from tipping during equipment installation.

Ensure that the temperature in the rack does not exceed the controller's maximum ambient rated temperatures. Consider the total airflow requirements of all equipment installed in the rack to ensure that the equipment is operated within its specified temperature range.

For best results, only qualified Sun service personnel should perform cluster installation and configuration. Contact Sun Service for assistance.

Prerequisites

Refer to the Quick Setup poster that shipped with the product or the following hardware service sections located in the Sun ZFS Storage 7x20 Service Manual at http://wikis.sun.com/display/ fishworks (http://wikis.sun.com/display/fishworks) for an overview of your system controller or cabinet.

7120 Overview - view component diagrams and specifications

7320 Overview - view component diagrams and specifications, and cluster options

7420/7720 Overview - view component diagrams, specifications, and cluster options

7700 Overview - view component diagrams and specifications

If you intend to install disk shelves into the same rack, refer to the Disk Shelf Installation section for how to install them into the bottom of your rack.

Legacy platform overviews are provided in the 7110 Overview, 7210 Overview, 7310 Overview,

7410 Overview sections of the Sun Storage 7000 Unified Storage Service Manual on http://wikis.sun.com/display/fishworks. (http://wikis.sun.com/display/fishworks.)

For controller installation, check that your rack is compatible with the slide rail and cable management assembly options as follows:

The structure is a four-post rack with mounting at both front and back. Two-post racks are

not compatible.

The horizontal opening and unit vertical pitch conforms to ANSI/EIA 310-D-1992 or IEC

60927 standards.

The distance between the front and back mounting planes is between 24 in and 36 in (610 mm to 915 mm).

Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

7x20 Controllers

The distance to the front cabinet door, providing clearance depth in front of the front mounting plane, is at least 1 in (25.4 mm).

The distance to the back cabinet door, providing clearance depth behind the front mounting plane, is at least 31.5 in (800 mm) with the cable management assembly, or 27.5 in (700 mm) without the cable management assembly.

The distance between structural supports and cable troughs, providing clearance width between the front and back mounting planes, is at least 18 in (456 mm).

For cabinet installation, you will need a total distance of at least 15 ft/4.5 m for safe maneuvering when you roll the cabinet off the shipping pallet. Caution - Moving the 7700 cabinet off the pallet requires at least three people.

Controller, Cabinet and Disk Shelf Installation Tasks

The following sections provide installation tasks with enumerated steps.

7x20 controller installation tasks

Sun Disk Shelf installation tasks

7700 cabinet planning and installation tasks

7x10 controller installation tasks

7x20 Controllers

7x20 Controller Installation Tasks

This section provides enumerated steps for installing the Sun ZFS Storage 7120, 7320 or 7420 controllers into a rack using the rail assembly in the rack mount kit. Note that if your rack mount kit shipped with installation instructions, use those instructions instead.

Observe the following cautions:

Always load equipment into a rack from the bottom up so that it will not become top-heavy and tip over. Deploy the anti-tip bar to the prevent the rack from tipping during equipment installation.

Ensure that the temperature in the rack will not exceed the controller's maximum ambient rated temperatures. Consider the total airflow requirements of all equipment installed in the rack to ensure that the equipment is operated within its specified temperature range.

Chapter 2 • Installation 15

7x20 Controllers

Prerequisites

Refer to the Quick Setup poster that shipped with the product or the Sun ZFS Storage Appliance

Service Manual located on http://wikis.sun.com/display/fishworks (http://wikis.sun.com/ display/fishworks

) for an overview of your controller.

7120 Overview - view component diagrams and specifications

7320 Overview - view component diagrams and specifications

7420/7720 Overview - view component diagrams and specifications

Tools and Equipment Needed

To install the system, you need the following tools:

No. 2 Phillips screwdriver

ESD mat and grounding strap

Pencil, stylus, or other pointed device, for pushing front panel buttons

You also need a system console device, such as one of the following:

Sun workstation

ASCII terminal

Terminal server

Patch panel connected to a terminal server

Tasks

7x20 Controllers Tasks

Installing Mounting Brackets on the Controller Chassis

If the mounting brackets are shipped inside the slide rails, you must remove them before beginning this procedure, as follows.

Unpack the slide rails and locate the slide rail lock at the front of the assembly.

Squeeze and hold the tabs at top and bottom of the lock (1) while you pull the mounting bracket out to the stop.

Push the mounting bracket release button toward the front of the mounting bracket (2) while withdrawing the bracket from the assembly.

The following graphic illustrates the procedure for disassembling the 7120/7320 rail kit.

16 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

The following graphic illustrates the procedure for disassembling the 7420 rail kit.

7x20 Controllers

Chapter 2 • Installation 17

7x20 Controllers

1

Position a mounting bracket against the chassis so that the slide rail lock is at the front of the chassis, and the keyed openings on the mounting bracket are aligned with the locating pins on the side of the chassis.

The following graphic illustrates how to attach the 7120/7320 mounting brackets.

18 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

The following graphic illustrates how to attach the 7420 mounting brackets.

7x20 Controllers

2

With the heads of the four chassis locating pins protruding though the four keyed openings in the mounting bracket, pull the mounting-bracket toward the front of the chassis until the mounting-bracket clip locks into place with an audible click.

3

Verify that all mounting pins are securely fastened to the chassis.

4

Repeat to install the remaining mounting bracket on the other side of the chassis.

Installing the Controller Chassis into the Rack Slide Rails

This procedure requires a minimum of two people because of the weight of the chassis.

Attempting this procedure alone could result in equipment damage or personal injury. Always load equipment into rack from the bottom up.

Chapter 2 • Installation 19

7x20 Controllers

1

If you are using a universal 19-inch cabinet, snap an M6 square cage nut into the top and bottom holes of the location where you will be installing the rail plate as shown.

2

Position a slide rail assembly in your rack so that the brackets at each end of the slide rail assembly are on the outside of the front and back rack posts. The following graphic illustrates

20 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

the rail assembly brackets.

7x20 Controllers

3

Attach each slide rail assembly to the rack posts, but do not tighten the screws completely.

Chapter 2 • Installation 21

7x20 Controllers

4

From the front of the rack, set the proper width of the rails with the rail-width spacer (1).

5

Tighten the screws on the brackets.

6

Remove the spacer and confirm that the rails are attached tightly to the rack.

22 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

7

If your rack includes an anti-tip foot, extend it from the bottom of the rack.

7x20 Controllers

8

Lower the rack stabilization feet if you have not already done so.

9

Push the slide rails into the slide rail assemblies in the rack as far as possible.

Chapter 2 • Installation 23

7x20 Controllers

10

Raise the chassis so that the back ends of the mounting brackets are aligned with the slide rail and insert the chassis into the slide rails, pushing the chassis slowly, until the mounting brackets meet the slide rail stops (~12 in or 30 cm). You will hear an audible click.

The following graphic illustrates the 7120/7320 chassis insertion and slide rail locks usage.

24 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

The following graphic illustrates 7420 chassis insertion.

7x20 Controllers

Installing the Cable Management Assembly

This procedure is completed from the back of the equipment rack.

Chapter 2 • Installation 25

7x20 Controllers

1

Attach the cable management assembly (CMA) rail extension to the left slide rail until the extension locks into place.

2

Insert the CMA mounting bracket connector into the right slide rail until the connector locks

26

into place.

Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

7x20 Controllers

3

Insert the right CMA slide rail connector (1) into the right slide rail assembly (2) until the connector locks into place.

Chapter 2 • Installation 27

7x20 Controllers

4

Insert the left CMA slide rail connector (1) into the rail extension on the left slide rail assembly

(2) until the connector locks into place.

28 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

Sun Disk Shelf

5

After you install and route the cables through the assembly, attach the hook and loop straps (1) to secure the cables. Then attach the right and left outer latches to support the assembly.

Sun Disk Shelf

Precautions

Observe the following cautions when installing a Sun Disk Shelf into a rack using the rail assembly in the bolt-on rack mount kit. Note that if your rack mount kit shipped with installation instructions, use those instructions instead.

Always load equipment into a rack from the bottom up so that it will not become top-heavy and tip over. Deploy the anti-tip bar to the prevent the rack from tipping during equipment installation.

Ensure that the temperature in the rack does not exceed the controller's maximum ambient rated temperatures. Consider the total airflow requirements of all equipment installed in the rack to ensure that the equipment is operated within its specified temperature range.

Chapter 2 • Installation 29

Sun Disk Shelf

Prerequisites

Refer to the poster that shipped with the product or the Sun ZFS Storage 7x20 Service Manual located on http://wikis.sun.com/display/fishworks (http://wikis.sun.com/display/ fishworks

) for an overview of your disk shelf.

Sun Disk Shelf Overview - view component diagrams and specifications

Tools and Equipment Needed

To install the shelf, you need the following tools:

You will need a No. 2 Phillips head screwdriver that is a minimum of 4 inches long.

A mechanical lift is highly recommended because the chassis can weigh between 91-170 lbs.

(42-77kg). At least three people are required: two to install the shelf or controller and one spotter to engage the rails.

:If a mechanical lift is not available, remove the power supplies, SIM boards and hard disk drives to reduce the weight, see Sun Disk Shelf Maintenance Procedures and Controller

Maintenance Procedures for instructions included in the Sun ZFS Storage 7x20 Service

Manual on http://wikis.sun.com/display/fishworks. (http://wikis.sun.com/display/ fishworks.

)

Use one of the following racks for the Sun Disk Shelf.

Sun Rack 900/1000 cabinet

Sun Fire cabinet

Sun StorEdge Expansion cabinet

Sun Rack II 1042/1242 cabinet

Any 19-inch wide, 4-post, EIA-compatible rack or cabinet with a front-to-back depth between vertical cabinet rails of 61 cm to 91 cm (24 in. to 36 in.). The cabinet can have threaded or unthreaded cabinet rails.

Position the rack where the shelf is to be installed adjacent to the rack where the controller is installed, if separate. Stabilize the cabinet and lock the casters.

30 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

Sun Disk Shelf

Tasks

Sun Disk Shelf Tasks

Installing the Sun Disk Shelf into the Rack Slide Rails

1

Starting at the bottom of the cabinet, locate the appropriate rack unit (RU) height. Install Disk

Shelves below controllers to prevent rack from tipping. The Sun Disk Shelf requires four standard mounting units (4RU) of vertical space in the cabinet.

2

If you are using a universal 19-inch or Sun Rack II cabinet, snap an M6 square cage nut into the

4U location where you will be installing the system. Install in the top and bottom holes.

3

Install appropriate rail plates in four locations on the rack (2 front and 2 back) by aligning the two pins on the rail plate with holes on the cabinet rails.

Chapter 2 • Installation 31

Sun Disk Shelf

4

Insert M6 screws in the top and bottom holes of each rail plate and tighten (8 total places).

5

Install each rail by first aligning the front pins of the rack adapter plates with corresponding holes in the front of the rail, then adjust the rail to fit the rack and insert the pins from the rear rack adapter plates into the corresponding holes of the rail.

32 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

Sun Disk Shelf

6

Install four 8-32 screws into the four remaining front and rear holes of each rack rail (16 total).

Chapter 2 • Installation 33

Sun Disk Shelf

7

Using a mechanical lift or two people, one at each side of the shelf or controller, carefully lift and rest the shelf on the bottom ledge of the left and right rails. The following graphic illustrates the chassis insertion.

34

8

Carefully slide the shelf into the cabinet until the front flanges of the shelf touch the vertical face of the rack.

9

Tighten the captive screws on each side of the front of the shelf to secure the shelf to the rack.

10

At the back of the disk shelf, slide a system locking clip onto each lower corner of the chassis.

See Also

Cabling Diagrams

Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

Cabinet

Cabinet

7700 Cabinet Planning and Installation

Use the following system specifications to ensure that the installation site is ready for the new

Sun ZFS Storage 7700 system. Pay particular attention to specifications to determine if power and air conditioning requirements are met by your datacenter.

To view component diagrams and specifications, refer to the 7700 Overview section of the Sun

ZFS Storage 7x20 Service Manual at http://wikis.sun.com/display/fishworks.

(http://wikis.sun.com/display/fishworks.)

Space Requirements

Caution

- Three people are required to offload the cabinet: two at the front and one at the rear.

The table below lists specifications for the shipping package.

Item

1

2

3

4

Description U.S.

Metric

Height

Depth

85.25 in 216.5 cm

52.5 in 133.3 cm

Width

Unloading distance

45.5 in

15 ft

115.5 cm

4.45 m

Maximum weight, storage system cabinet 1,970 lb 894 kg

Chapter 2 • Installation 35

Cabinet

Caution -

The shipping pallet is designed so that the cabinet can only be unloaded in one direction. Orient the shipping container so that the label RAMPS ATTACH THIS SIDE is facing the direction the cabinet should be offloaded from the pallet. When you roll the cabinet off the shipping pallet, you will need a total distance of at least 15 feet/4.5 meters for safe maneuvering, as shown above.

Tools

During unpacking, you will need these tools to unpack the shipping package:

Cutters for the package strapping tape

#2 Phillips screwdriver

These tools are included in the shipping package:

13 mm/17 mm combination open end wrench

19 mm open end wrench

Physical Specifications

The following figure shows the system cabinet.

36

Figure Legend

1

2

Fan trays 5 Power supplies

Leaf controller cards (LCCs) 6 Rack controller card (RCC)

3 Disk trays 7 Storage controllers

Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

Cabinet

Figure Legend

4 Disk drives

The following table lists physical specifications for the storage system main cabinet.

Description U.S.

Metric

Width

Depth (without doors)

Depth (with front and rear doors)

23.5 in 60 cm

43.0 in 109 cm

46.0 in 117 cm

Height

Maximum weight, storage system cabinet

79.5 in 202 cm

1,740 lb 790 kg

Clearance, front or rear of system for service access 48 in

Clearance, above system 18 in

122 cm

46 cm

Service Access

All customer replaceable units (CRUs) are accessed from the front or back of the cabinet. There are no CRUs inside the cabinet.

Caution

- Access to the inside of the cabinet is limited to Sun Service personnel only. There are no CRUs inside of the cabinet.

If the system is located in a row of cabinets and an internal FRU must be replaced, the system must be moved forward or backward out of the row for removal of the side panels. The front and rear clearance values in the table above account for this movement.

Cooling

The following table lists the specifications for the main cabinet.

Cooling Specifications Operating Non-Operating

Maximum Heat output, main system 5300 W (estimated)

Ambient temperature range

Humidity range

Altitude range

5 to 35C/41 to 95F

3 km/12,000 ft.

0 to 50C/32 to 122F

20 - 80% relative humidity 8 - 80% relative humidity

12 km/40,000 ft.

The airflow patterns in the storage system are as follows:

Chapter 2 • Installation 37

Cabinet

Air enters the front and rear of the cabinet.

Fan trays at the top of the cabinet pull exhaust air out of the central area of the cabinet.

Two storage controllers at the bottom of the storage system cabinet push exhaust air out through the rear of the cabinet.

The following figure shows the airflow patterns in the storage system.

Underfloor Cooling Scheme

The following illustration shows underfloor cooling of the cabinet and is described in the table.

38 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

Cabinet

2

3

Figure Legend

1

Front of System

Allow underfloor cooling at front and back

Warm air is ventilated from the top. Allow 18 " of clearance.

Overhead Cooling Scheme

The following illustration shows overhead cooling of the cabinet and is described in the table.

Chapter 2 • Installation 39

Cabinet

Figure Legend

1

2

3

Front of System

Overhead cooling should be directed at both front and back of system.

Warm air is ventilated from the top. Allow 18

" of clearance.

Overhead Cooling Hot/Cold Aisle

The following illustration shows overhead cooling for hot/cold aisle and is described in the table.

40 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

Cabinet

3

4

Figure Legend

1

2

Front of System

Overhead cooling in the cold aisle should be directed at the front of the system.

Warm air is ventilated from the top. Allow 18

" of clearance.

Hot aisle ambient temperature cannot exceed 35C (95F)

Electrical Specifications

The following table lists the specifications for the main cabinet.

Electrical Specifications

AC voltage range

Value

200-240 VAC, 50-60 Hz

Chapter 2 • Installation 41

Cabinet

Electrical Specifications Value

AC current, maximum for main cabinet (5300 W) 26.5A total

Power Cords

Storage controller 0

Storage controller 1

Main cabinet

Description

2 power cords, rated at 10 A each, N+1 redundancy

2 power cords, rated at 10 A each, N+1 redundancy

6 power cords, rated at 16 A each, divided into 2 separate circuits of 3 cords. Each circuit provides N+1 redundancy

Caution

- The electrical power to the system must be controlled by external breaker switches.

Do not plug in any power cables. Only power on the system by following the instructions in the

Powering On and Configuration

section of the Sun ZFS Storage 7x20 Installation Guide available at http://wikis.sun.com/display/fishworks. (http://wikis.sun.com/display/ fishworks.

)

Two separate electrical sources are required for redundant operation of the storage system main cabinet, as shown in the following figure.

42 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

Cabinet

1

2

3

Figure Legend

Storage cabinet and storage controller power cords 4 Power source A

Wall power outlets

Circuit breakers or wall-mounted power switches

5 Power source B

Site Planning Checklists

Access Route

Confirm that the unloading specifications for the shipping package in

Space Requirements

have been addressed.

Requirements

Has the Sun ZFS Storage 7700 Appliance location been allocated?

Is the location vacant for the new equipment?

Yes No NA

Chapter 2 • Installation 43

Cabinet

44

Requirements

Does the floor layout meet the equipment maintenance access requirements?

Is there adequate space available for maintenance?

Is the floor to ceiling height a minimum of 103.25 in (8.6 feet)?

Have cabinet stabilization measures been considered? (Leveling feet?)

Do you need to obtain permission to remove floor tiles to accommodate service?

Does the raised floor satisfy the weight requirements for the new hardware?

Are there cable routing channels?

Are there cable routing cutouts?

Yes No NA

Data Center Environment

Confirm that the cooling specifications for the cabinet in

Cooling Requirements

have been addressed.

Requirements

Does the computer room air handling meet temperature and humidity requirements?

Does the installation floor layout satisfy the ventilation requirements?

Will the equipment be positioned so that the exhaust air of one rack does not enter the air inlet of another rack?

Do the computer room air conditioners provide sufficient airflow?

Is airflow adequate to prevent hotspots?

Can the computer room continuously satisfy environmental requirements?

Can more vented floor tiles be obtained if required?

Yes No NA

Facility Power

Confirm that the power specifications for the cabinet in

Electrical Specifications

have been addressed.

Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

Cabinet

Requirements

Do you know the required operating voltages and electrical current levels of the device and peripherals? As an aggregate, the system will draw

48amps at 208 volts

. This needs to be split across two separate power grids and divided into smaller circuits.

Are separate power sources available for the new equipment at the designated location?

Are power outlets available for the new equipment at the designated location?

Are enough power outlets provided? 10 L6-20 total. Six L6-20/C19

(cabinet) and four L6-20/C13 (controllers)

split across two separate power grids.

Are the circuit breakers for the equipment suitable in terms of voltage and current-carrying capacities?

Does the power frequency meet the equipment specifications?

Yes No NA

Logistics

Confirm that the logistical requirements for the cabinet in

Unpacking and Moving the Cabinet

have been addressed.

Requirements

Do you have contact information for data center personnel?

Is there security or access control for the data center?

Are laptops, cell phones, and cameras allowed in the data center?

Does the building have a delivery dock?

Is there a delivery/unpacking/staging area?

Is the delivery inside?

If the delivery is not inside, is the site prepared for uncrating?

Is the unpacking/staging area protected from the elements?

Does the building have an adequate receiving area?

Will sufficient moving personnel be available to install the hardware?

Are you prepared for uncrating and trash removal?Is uncrating of cabinet and cabinet trash removal required?

Are there any restrictions on delivery truck length, width or height?

Yes No NA

Chapter 2 • Installation 45

Cabinet

Requirements

Does the customer allow cardboard boxes and/or other packing material in the computer room?

If no, do ground level deliveries require a truck with a side rail lift ?

Is there a time constraint on dock access? If yes, provide time constraints.

Is tail-lift required on Delivery Carrier to unload the equipment at delivery dock?

Is delivery only required to end-user's loading bay or is delivery inside required?

Will any lifters, ramps, steel plates, or floor covers be required to place the equipment in the computer room?

Is a list of special equipment requirements needed by the delivery carrier available? (Non-Floor Damaging Rollers, Transport Dollies, Pallet Jacks, or Fork Lifts)

Have any special delivery options (including inside delivery and/or waste removal) been communicated while placing the order?

Yes No NA

Safety Items

For your protection, observe the following safety precautions when setting up your equipment:

Follow all Sun cautions, warnings, and instructions marked on the equipment and described in Important Safety Information for Sun Hardware Systems.

Ensure that the voltage and frequency of your power source match the voltage inscribed on the equipment's electrical rating label.

Requirements

Is there an emergency power shutoff? Where?

Is there a fire protection system in the data center room?

Is the computer room adequately equipped to extinguish a fire?

Is antistatic flooring installed?

Is the floor below the raised floor free of obstacles and blockages?

Yes No NA

46 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

Cabinet

Tasks

Cabinet Tasks

Unpacking and Moving the Cabinet

The following instructions illustrate how to unpack and move the 7700 cabinet. As a prerequisite to this task, familiarize yourself with the 7420/7720 storage controller rear panel section of the Sun ZFS Storage 7x20 Service Manual at http://wikis.sun.com/display/fishworks.

(http://wikis.sun.com/display/fishworks.)

1

Use a forklift or pallet jack to move the shipping carton to a location that is as close to the installation site as possible.

2

Ensure that you have enough space to remove the storage system from the shipping pallet. See the

Space Requirements

section for dimensions.

3

Cut the straps that hold the carton onto the shipping pallet.

4

Remove the top of the carton, and unlock the sides of the carton.

Chapter 2 • Installation 47

Cabinet

5

Remove the carton sides, top, and accessories kit.

6

Remove the ramps from the pallet as shown in the following illustration.

48 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

Cabinet

7

Install the pallet ramps. Ensure that you lock the ramps to the pallet skids and that you lower the ramp bolts so that they rest on the floor.

8

Open the cabinet doors, and remove the shipping restraints.

9

Check that the leveling feet have not lowered during transportation.

Chapter 2 • Installation 49

Cabinet

10

With at least two other people, move the cabinet off of the pallet. Ensure that the cabinet does not tilt to either side while you are moving the cabinet. Never move the cabinet alone.

11

Standing at both ends of the cabinet, move the storage system to the installation site. Caution: all four casters swivel. When moving the cabinet down ramps, do not allow it to turn unexpectedly. The front or rear door must always face the direction of travel. The cabinet can tip over if the cabinet is moved sideways up or down a ramp. Three people are required to move the cabinet: one person should be at the front to guide the movement and two at the rear.

50 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

12

Lower all four of the stabilization feet as shown in the illustration.

Cabinet

13

Complete

Powering on and Configuration

section of the Sun ZFS Storage 7x20 Installation

Guide available at http://wikis.sun.com/display/fishworks. (http://wikis.sun.com/display/ fishworks.

)

Chapter 2 • Installation 51

52

3

Cabling

3

Cabling

Cabling Diagrams

The diagrams in the sections that follow illustrate how to properly connect storage controllers or cabinets, either in standalone or clustered configurations, to one or more disk shelves or expansion cabinets. Use the images as a key to understanding how the abstracted diagrams correspond to actual hardware:

Connecting Expansion Storage to the 7120

Connecting Expansion Storage to the 7320

Connecting Expansion Storage to the 7320 Cluster

Connecting Expansion Storage to the 7420 (2 HBAs)

Connecting Expansion Storage to the 7420 (3 HBAs)

Connecting Expansion Storage to the 7420 (4 HBAs)

Connecting Expansion Storage to the 7420 Cluster (2 HBAs)

Connecting Expansion Storage to the 7420 Cluster (3 HBAs)

Connecting Expansion Storage to the 7420 Cluster (4 HBAs)

Connecting Expansion Storage to the 7700

Oftentimes, the need to expand storage requires the addition of another HBA to your storage controller. While in single-head configurations, this is not possible to do without disrupting service. In a clustered configuration, the heads can be powered down individually for servicing and reconnected to the new storage chain. For instructions, refer to the following sections of the

53

7120 Cabling

Sun ZFS 7x20 Appliance Service Manual available at http://wikis.sun.com/display/fishworks.

(http://wikis.sun.com/display/fishworks.)

Expanding from 2 to 3 HBAs

Expanding from 3 to 4 HBAs

To view cabling diagrams for legacy platforms, refer to the following sections of the Sun Storage

7000 Unified Storage System Installation Guide at http://wikis.sun.com/display/fishworks.

(http://wikis.sun.com/display/fishworks.)

Connecting Expansion Storage to the 7210

Connecting Expansion Storage to the 7310

Connecting Expansion Storage to the 7310 Cluster

Connecting Expansion Storage to the 7410 (2 HBAs)

Connecting Expansion Storage to the 7410 (3 HBAs)

Connecting Expansion Storage to the 7410 Cluster (2 HBAs)

Connecting Expansion Storage to the 7410 Cluster (3 HBAs)

7120 Cabling

Connecting Expansion Storage to the Sun ZFS Storage

7120

The Sun ZFS Storage 7120 can support up to two Sun Disk shelves. The figures below show the complete set of supported configurations, as well as steps to migrate from one state to another.

Sun ZFS Storage 7120

NOTE:

Cabling diagrams are not representative of proper slot location for HBAs.

54 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

Cabling Diagrams

fig.1

Sun ZFS Storage 7120 system with one Sun Disk shelf

7120 Cabling

Chapter 3 • Cabling 55

7320 Cabling

fig.2

Sun ZFS Storage 7120 system with two Sun Disk shelves

7320 Cabling

Connecting Expansion Storage to the Sun Storage

7320

The Sun ZFS Storage 7320 can support up to four Sun Disk shelves. The figures below show the complete set of supported standalone configurations, as well as steps to migrate from one state to another.

NOTE:

Cabling diagrams are not representative of proper slot location for HBAs.

56 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

Cabling Diagrams

fig.1

Sun ZFS Storage 7320 with one Sun Disk shelf

7320 Cabling

Chapter 3 • Cabling 57

7320 Cabling

fig.2

Sun ZFS Storage 7320 with two Sun Disk shelves

fig.3

Sun ZFS Storage 7320 with three Sun Disk shelves

58 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

7320 Cluster Cabling

fig.4

Sun ZFS Storage 7320 with four Sun Disk shelves

7320 Cluster Cabling

Connecting Expansion Storage to the Sun Storage

7320 Cluster

The Sun ZFS Storage 7320 cluster can support up to four Sun Disk shelves. The figures below show the complete set of supported redundant cluster configurations, as well as steps to migrate from one state to another.

NOTE:

Cabling diagrams are not representative of proper slot location for HBAs.

Chapter 3 • Cabling 59

7320 Cluster Cabling

Cabling Diagrams

fig.1

Sun ZFS Storage 7320 cluster with one Sun Disk shelf

60 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

7320 Cluster Cabling

fig.2

Sun ZFS Storage 7320 cluster with two Sun Disk shelves

fig.3

Sun ZFS Storage 7320 cluster with three Sun Disk shelves

Chapter 3 • Cabling 61

7420 Cabling pt.1

fig.4

Sun ZFS Storage 7320 cluster with four Sun Disk shelves

7420 Cabling pt.1

Connecting Expansion Storage to the Sun Storage

7420 (2 HBAs)

The Sun ZFS Storage 7420 is available with either two, three, or four HBA cards installed, each of which can support up to six Sun Disk shelves. The figures below show a representative sample of stable, balanced configurations with two HBAs, as well as steps to migrate from one state to another.

NOTE:

Diagrams below are not representative of proper slot location for HBAs.

62 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

7420 Cabling pt.1

Cabling Diagrams

fig.1

Sun ZFS Storage 7420 with two HBAs and one Sun Disk shelf

fig.2

Sun ZFS Storage 7420 with two HBAs and two Sun Disk shelves

Chapter 3 • Cabling 63

7420 Cabling pt.1

64 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

fig.3

Sun ZFS Storage 7420 with two HBAs and three Sun Disk shelves

7420 Cabling pt.1

fig.4

Sun ZFS Storage 7420 with two HBAs and four Sun Disk shelves

fig.5

Sun ZFS Storage 7420 with two HBAs and six Sun Disk shelves

Chapter 3 • Cabling 65

7420 Cabling pt.2

fig.6

Sun ZFS Storage 7420 with two HBAs and twelve Sun Disk shelves

7420 Cabling pt.2

Connecting Expansion Storage to the Sun Storage

7420 (3 HBAs)

The Sun ZFS Storage 7420 is available with either two, three, or four HBA cards installed, each of which can support up to six Sun Disk shelves. The figures below show a representative sample of stable, balanced configurations with three HBAs, as well as steps to migrate from one state to another.

NOTE:

Diagrams below are not representative of proper slot location for HBAs.

66 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

7420 Cabling pt.2

Cabling Diagrams

fig.1

Sun ZFS Storage 7420 with three HBAs and one Sun Disk shelf

fig.2

Sun ZFS Storage 7420 with three HBAs and two Sun Disk shelves

Chapter 3 • Cabling 67

7420 Cabling pt.2

fig.3

Sun ZFS Storage 7420 with three HBAs and three Sun Disk shelves

68 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

7420 Cabling pt.2

fig.4

Sun ZFS Storage 7420 with three HBAs and four Sun Disk shelves

fig.5

Sun ZFS Storage 7420 with three HBAs and six Sun Disk shelves

Chapter 3 • Cabling 69

7420 Cabling pt.2

fig.6

Sun ZFS Storage 7420 with three HBAs and nine Sun Disk shelves

fig.7

Sun ZFS Storage 7420 with three HBAs and eighteen Sun Disk shelves

70 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

7420 Cabling pt.3

7420 Cabling pt.3

Connecting Expansion Storage to the Sun Storage

7420 (4 HBAs)

The Sun ZFS Storage 7420 is available with either two, three, or four HBA cards installed, each of which can support up to six Sun Disk shelves. The figures below show a representative sample of stable, balanced configurations with four HBAs, as well as steps to migrate from one state to another.

NOTE:

Diagrams below are not representative of proper slot location for HBAs.

Cabling Diagrams

fig.1

Sun ZFS Storage 7420 with four HBAs and one Sun Disk shelf

Chapter 3 • Cabling 71

7420 Cabling pt.3

fig.2

Sun ZFS Storage 7420 with four HBAs and two Sun Disk shelves

fig.3

Sun ZFS Storage 7420 with four HBAs and three Sun Disk shelves

fig.4

Sun ZFS Storage 7420 with four HBAs and four Sun Disk shelves

72 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

7420 Cabling pt.3

fig.5

Sun ZFS Storage 7420 with four HBAs and five Sun Disk shelves

fig.6

Sun ZFS Storage 7420 with four HBAs and eight Sun Disk shelves

Chapter 3 • Cabling 73

7420 Cluster Cabling pt.1

fig.7

Sun ZFS Storage 7420 with four HBAs and twelve Sun Disk shelves

fig.8

Sun ZFS Storage 7420 with four HBAs and twenty-four Sun Disk shelves

7420 Cluster Cabling pt.1

74

Connecting Expansion Storage to the Sun Storage

7420 Cluster (2 HBAs)

The Sun ZFS Storage 7420 cluster is available with either two, three, or four HBA cards installed, each of which can support up to six Sun Disk shelves. The figures below show a representative sample of stable, balanced and redundant cluster configurations with two HBAs, as well as steps to migrate from one state to another.

Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

7420 Cluster Cabling pt.1

NOTE:

Diagrams below are not representative of proper slot location for HBAs.

Cabling Diagrams

fig.1

Sun ZFS Storage 7420 cluster with two HBAs and one Sun Disk shelf

Chapter 3 • Cabling 75

7420 Cluster Cabling pt.1

fig.2

Sun ZFS Storage 7420 cluster with two HBAs and two Sun Disk shelves

76 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

7420 Cluster Cabling pt.1

fig.3

Sun ZFS Storage 7420 cluster with two HBAs and three Sun Disk shelves

Chapter 3 • Cabling 77

7420 Cluster Cabling pt.1

fig.5

Sun ZFS Storage 7420 cluster with two HBAs and four Sun Disk shelves

fig.6

Sun ZFS Storage 7420 cluster with two HBAs and six Sun Disk shelves

78 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

7420 Cluster Cabling pt.2

fig.7

Sun ZFS Storage 7420 cluster with two HBAs and twelve Sun Disk shelves

7420 Cluster Cabling pt.2

Connecting Expansion Storage to the Sun Storage

7420 Cluster (3 HBAs)

The Sun ZFS Storage 7420 cluster is available with either two, three, or four HBA cards installed, each of which can support up to six Sun Disk shelves. The figures below show a representative sample of stable, balanced and redundant cluster configurations with three

HBAs, as well as steps to migrate from one state to another.

NOTE:

Diagrams below are not representative of proper slot location for HBAs.

Chapter 3 • Cabling 79

7420 Cluster Cabling pt.2

Cabling Diagrams

fig.1

Sun ZFS Storage 7420 cluster with three HBAs and one Sun Disk shelf

80 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

7420 Cluster Cabling pt.2

fig.2

Sun ZFS Storage 7420 cluster with three HBAs and two Sun Disk shelves

fig.3

Sun ZFS Storage 7420 cluster with three HBAs and three Sun Disk shelves

Chapter 3 • Cabling 81

7420 Cluster Cabling pt.2

82 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

7420 Cluster Cabling pt.2

fig.4

Sun ZFS Storage 7420 cluster with three HBAs and four Sun Disk shelves

fig.5

Sun ZFS Storage 7420 cluster with three HBAs and six Sun Disk shelves

Chapter 3 • Cabling 83

7420 Cluster Cabling pt.2

fig.6

Sun ZFS Storage 7420 cluster with three HBAs and nine Sun Disk shelves

84 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

7420 Cluster Cabling pt.3

fig.7

Sun ZFS Storage 7420 cluster with three HBAs and eighteen Sun Disk shelves

7420 Cluster Cabling pt.3

Connecting Expansion Storage to the Sun Storage

7420 Cluster (4 HBAs)

The Sun ZFS Storage 7420 cluster is available with either two, three, or four HBA cards installed, each of which can support up to six Sun Disk shelves. The figures below show a representative sample of stable, balanced and redundant cluster configurations with four HBAs, as well as steps to migrate from one state to another.

NOTE:

Diagrams below are not representative of proper slot location for HBAs.

Cabling Diagrams

Chapter 3 • Cabling 85

7420 Cluster Cabling pt.3

fig.1

Sun ZFS Storage 7420 cluster with four HBAs and one Sun Disk shelf

fig.2

Sun ZFS Storage 7420 cluster with four HBAs and two Sun Disk shelves

fig.3

Sun ZFS Storage 7420 cluster with four HBAs and three Sun Disk shelves

86 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

7420 Cluster Cabling pt.3

fig.4

Sun ZFS Storage 7420 cluster with four HBAs and four Sun Disk shelves

Chapter 3 • Cabling 87

7420 Cluster Cabling pt.3

fig.5

Sun ZFS Storage 7420 cluster with four HBAs and four Sun Disk shelves

88

fig.6

Sun ZFS Storage 7420 cluster with four HBAs and eight Sun Disk shelves

Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

7420 Cluster Cabling pt.3

fig.7

Sun ZFS Storage 7420 cluster with four HBAs and twelve Sun Disk shelves

fig.8

Sun ZFS Storage 7420 cluster with four HBAs and twenty-four Sun Disk shelves

Chapter 3 • Cabling 89

7700 Cabling

7700 Cabling

Sun ZFS Storage 7700 SAS Cabling

The following illustration shows how SAS cabling is provided from the factory in the main cabinet.

90

fig.1

Sun ZFS Storage 7700 SAS and cluster cabling as shipped

Figure Legend

1

System controller 0 3 RCC 0

2

System controller 1 4 RCC 1

Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

4

4

Powering On and Configuring the System

Power

Powering On and Configuring the Appliance

This section provides instructions for configuring the primary network interface using the preinstalled Sun ZFS Storage 7000 command line interface (CLI). After you configure the primary interface, configure the remaining system parameters using the browser user interface

(BUI) from any client on the same network.

Prerequisites

Refer to the

Installation

section for detailed instructions to install your system in the rack.

Complete the system cabling according to the

Cabling Diagrams

section.

Gather the following information in preparation for configuring an Ethernet interface on the storage controller.

IP address

IP netmask

Host name

Domain Name Server (DNS) domain name

DNS server IP address

Default router IP address

Password

If you will access the appliance through an administrative client, configure the administrative client with the following settings:

8N1: eight data bits, no parity, one stop bit

9600 baud

Disable hardware flow control (CTS/RTS)

91

Power

92

Disable software flow control (XON/XOFF)

Refer to the Quick Setup poster that shipped with the product or the following sections in the

Sun ZFS Storage 7000 Appliance Service Manual located on http://wikis.sun.com/display/ fishworks (http://wikis.sun.com/display/fishworks) for an overview of your system controller.

7120 Overview

7320 Overview

7420/7720 Overview

7700 Overview

Connecting to ILOM

In rare cases, faults associated with uncorrectable CPU errors are not diagnosable or displayed in the controller. These faults will be preserved by and observable on the ILOM. Connect to the server ILOM (Service Processor) on the server platform to diagnose hardware faults that do not appear in the BUI.

In a cluster environment, an ILOM connection should be made to each controller.

The server ILOM provides options for (i) network and (ii) serial port connectivity. Network connection is the preferred choice, as the ILOM serial port does not always allow adequate means of platform data collection.

WARNING

: Failure to configure ILOM connectivity may lead to longer than necessary hardware fault diagnosis and resolution times.

Tasks

Power Tasks

Powering On the Appliance

You can access the system by connecting an administrative client to the serial management port on the controller. Alternatively, if there is a Dynamic Host Configuration Protocol (DHCP) server on the network, you can access the system by connecting the network management port to your network.

Note that if you are installing a cluster, configure only one controller initially. The software propagates the configuration to the peer controller during cluster initialization. After the cluster is initialized, you can administer the system from either storage controller. However, do not attempt initial configuration on both controllers independently. Refer to the Cluster documentation in the System Administration Guide located on http://wikis.sun.com/display/ fishworks (http://wikis.sun.com/display/fishworks) for more information.

Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

Power

1

To perform initial configuration using serial, connect a serial cable from the SER MGT port on the back panel of the controller to the serial port on the administrative client. Use a DB9 to RJ45 adapter if necessary.

2

To perform initial configuration using Ethernet, connect an Ethernet cable from the NET MGT port on the back panel of the controller to your network.

3

Connect an Ethernet cable from your network to the NET0 port on the back panel of the controller.

4

For 7120, 7320 and 7420, power on any disk shelves attached to the storage system by plugging the two power cords into the universal power connectors, connecting the cords to the external power source and turning on the disk shelf power switches. Wait several minutes until the power indicators are lit a steady green.

For 7700/7720, ensure that the circuit breakers are in the OFF position before connecting the six power cords for the storage rack to wall sockets that are controlled by individual circuit breakers. Connect three of the circuit breakers to one power source, and connect the remaining three to a different power source. This is required to maintain power protection through redundant power sources. See

Cabinet Electrical Specifications .

5

For 7120, 7320 and 7420, connect power cables to power supply 0 and power supply 1 on the storage controller(s) and wait until the Power/OK LED on the front panel next to the Power button lights and remains lit (approximately two minutes).

For 7700/7720, switch all of the wall circuit breakers to the ON position. Wait until the

Power/OK LEDs light and remain lit.

6

Open a terminal window or terminal emulator and issue the appropriate command, as follows:

7

For a serial port concentrator connect (for example, using telnet), and use root as the user name

and replace serial-concentrator portnumber with the appropriate value, for example: telnet

serial-concentrator portnumber

8

For a network connection, connect using SSH and use root as the user name and determine the

IP address by accessing your DHCP server for the address assigned to the Service Processor MAC address (see the label on the storage controller), for example: ssh [email protected]

9

Type the password changeme when prompted.

10

At the command prompt, type start /SP/console.

11

Type y to confirm that you want to start the console.

12

Press any key to begin configuring the appliance. The shell interface configuration screen appears. NET-0 at the top of the screen should be underlined.

Chapter 4 • Powering On and Configuring the System 93

Power

13

Verify the information on the screen, or enter values that do not appear.

14

Apply the values by pressing ESC-1 or the F1 key or by pressing Enter after confirming the password. The final shell configuration screen appears, confirming that your appliance is ready for further configuration using the BUI.

Completing Configuration

Configure the remaining system parameters through the CLI after logging in, or through a browser running on any client on the same network as the initial interface. The management software is designed to be fully featured and functional on the following supported web browsers: Firefox 3.x, Internet Explorer 7, Internet Explorer 8, Safari 3.1 or later, and WebKit

525.13 or later.

1

Direct your browser to the system using either the IP address or host name you assigned to the

NET0 port as follows: https://ipaddress:215 or https://hostname:215. The login screen appears.

94

2

Type root into the Username field and the administrative password that you entered into the appliance shell kit interface and press the Enter key. The Welcome screen appears.

3

To begin configuring the system, click Start on the Welcome screen. You are guided through the

Initial Configuration of the remaining network interfaces, DNS, time settings, directory service and storage.

Next Steps

Initial Configuration

Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

Initial

Initial

Initial Configuration

The initial configuration consists of six configuration steps.

1. Network

2. DNS

3. Time

4. Name Services (NIS, LDAP, Active Directory)

5. Storage

6. Registration & Support

Prerequisites

The initial configuration of the system is conducted after powering it on for the first time and establishing a connection, as documented in the

Installation

section, also available as a PDF on http://wikis.sun.com/display/fishworks/Documentation. (http://wikis.sun.com/display/ fishworks/Documentation.

)

Note

that the option to perform initial configuration of a cluster is only available in the BUI. If electing this option, read the clustering documentation included in the Sun ZFS Storage 7000

Administration Guide at http://wikis.sun.com/display/fishworks (http://wikis.sun.com/ display/fishworks

) before beginning initial configuration for detailed additional steps that are required for successful cluster setup. Pay careful attention to the Clustering Considerations for Networking section. Alternatively, cluster-capable appliances may be initially configured for standalone operation using the following procedure, and re-configured for cluster operation at a later time.

Summary

This procedure will configure networking connectivity, several client network services, and the layout of the storage pool for standalone operation. When completed, the appliance is ready for use - but will not have any shares configured for remote clients to access. To create shares or revisit settings, refer to the Shares and Configuration sections of the Sun ZFS Storage 7000

System Administration Guide on http://wikis.sun.com/display/fishworks.

(http://wikis.sun.com/display/fishworks.)

This procedure may be repeated at a later time by clicking the

"INITIAL SETUP" button on the

Maintenance > System screen or by entering the maintenance system setup context in the

CLI.

Chapter 4 • Powering On and Configuring the System 95

Initial

BUI

The BUI initial configuration is the preferred method and provides a screen for each of the initial configuration steps.

96

Click Start to begin basic configuration of network, time directory and support services. Click

Commit to save the configuration and go to the next screen. Arrows beneath the Commit button can be used to revisit previous steps, and change the configuration if desired.

Configuring Management Port

All standalone controllers should have at least one NIC port configured as a management interface. Select the Allow Admin option in the BUI to enable BUI connections on port 215 and

CLI connections on ssh port 22.

All cluster installations should have at least one NIC port on each controller configured as a management interface as described above. In addition, the NIC instance number must be unique on each controller.

CLI

Alternatively, use the CLI to step through the initial configuration sections. Each step begins by printing its help, which can be reprinted by typing help. Use the done command to complete each step.

Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

Initial

Performing Initial Configuration with the CLI

Login using the password you provided during

Installation :

caji console login: root

Password:

Last login: Sun Oct 19 02:55:31 on console

To setup your system, you will be taken through a series of steps; as the setup process advances to each step, the help message for that step will be displayed.

Press any key to begin initial configuration ...

In this example, the existing settings are checked (which were obtained from the DHCP server), and accepted by typing done. To customize them at this point, enter each context (datalinks, devices and interfaces) and type help to see available actions for that context. See the Network page for additional documentation or refer to the System Administration Guide at http://wikis.sun.com/display/fishworks. (http://wikis.sun.com/display/fishworks.) Pay careful attention to the Clustering Considerations for Networking section if you will configure clustering.

aksh: starting configuration with

"net" ...

Configure Networking. Configure the appliance network interfaces. The first network interface has been configured for you, using the settings you provided at the serial console.

Subcommands that are valid in this context: datalinks => Manage datalinks devices interfaces

=> Manage devices

=> Manage interfaces help [topic] => Get context-sensitive help. If [topic] is specified, it must be one of

"builtins", "commands", "general",

"help" or "script".

=> Show information pertinent to the current context show abort => Abort this task (potentially resulting in a misconfigured system)

=> Finish operating on

"net" done caji:maintenance system setup net> devices show

Devices:

DEVICE UP nge0 true nge1 false nge2 false nge3 false

MAC

0:14:4f:8d:59:aa

0:14:4f:8d:59:ab

0:14:4f:8d:59:ac

0:14:4f:8d:59:ad

SPEED

1000 Mbit/s

0 Mbit/s

0 Mbit/s

0 Mbit/s

Chapter 4 • Powering On and Configuring the System 97

Initial

98 caji:maintenance system setup net> datalinks show

Datalinks:

DATALINK CLASS nge0 device

LINKS nge0

LABEL

Untitled Datalink caji:maintenance system setup net> interfaces show

Interfaces:

INTERFACE STATE CLASS LINKS nge0 up ip nge0

ADDRS

192.168.2.80/22

LABEL

Untitled Interface caji:maintenance system setup net> done

Refer to the DNS section of the System Administration Guide at http://wikis.sun.com/display/ fishworks (http://wikis.sun.com/display/fishworks) for additional documentation on

DNS.

Configure DNS. Configure the Domain Name Service.

Subcommands that are valid in this context: help [topic] show commit

=> Get context-sensitive help. If [topic] is specified, it must be one of

"builtins", "commands", "general",

"help", "script" or "properties".

=> Show information pertinent to the current context

=> Commit current state, including any changes abort done get [prop] set [prop]

=> Abort this task (potentially resulting in a misconfigured system)

=> Finish operating on

"dns"

=> Get value for property [prop]. (

"help properties" for valid properties.) If [prop] is not specified, returns values for all properties.

=> Set property [prop] to [value]. (

"help properties" for valid properties.) For properties taking list values, [value] should be a comma-separated list of values.

caji:maintenance system setup dns> show

Properties:

<status> = online domain = sun.com

servers = 192.168.1.4

caji:maintenance system setup dns> set domain=sf.fishworks.com domain = sf.fishworks.com (uncommitted) caji:maintenance system setup dns> set servers=192.168.1.5 servers = 192.168.1.5 (uncommitted) caji:maintenance system setup dns> commit caji:maintenance system setup dns> done aksh: done with

"dns", advancing configuration to "ntp" ...

Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

Initial

Configure Network Time Protocol (NTP) to synchronize the appliance time clock. See the NTP section of the System Administration Guide at http://wikis.sun.com/display/fishworks

(http://wikis.sun.com/display/fishworks) for additional documentation.

Configure Time. Configure the Network Time Protocol.

Subcommands that are valid in this context: help [topic] => Get context-sensitive help. If [topic] is specified, it must be one of

"builtins", "commands", "general",

"help", "script" or "properties".

show => Show information pertinent to the current context commit abort done enable disable get [prop] set [prop]

=> Commit current state, including any changes

=> Abort this task (potentially resulting in a misconfigured system)

=> Finish operating on

"ntp"

=> Enable the ntp service

=> Disable the ntp service

=> Get value for property [prop]. (

"help properties" for valid properties.) If [prop] is not specified, returns values for all properties.

=> Set property [prop] to [value]. (

"help properties" for valid properties.) For properties taking list values, [value] should be a comma-separated list of values.

caji:maintenance system setup ntp> set servers=0.pool.ntp.org servers = 0.pool.ntp.org (uncommitted) caji:maintenance system setup ntp> commit caji:maintenance system setup ntp> done aksh: done with

"ntp", advancing configuration to "directory" ...

Refer to the NIS, LDAP and Active Directory sections of the System Administration Guide at http://wikis.sun.com/display/fishworks (http://wikis.sun.com/display/fishworks) for additional documentation.

Configure Name Services. Configure directory services for users and groups. You can configure and enable each directory service independently, and you can configure more than one directory service.

Subcommands that are valid in this context: nis => Configure NIS ldap ad

=> Configure LDAP

=> Configure Active Directory

Chapter 4 • Powering On and Configuring the System 99

Initial

100 help [topic] => Get context-sensitive help. If [topic] is specified, it must be one of

"builtins", "commands", "general",

"help" or "script".

=> Show information pertinent to the current context show abort => Abort this task (potentially resulting in a misconfigured system)

=> Finish operating on

"directory" done caji:maintenance system setup directory> nis caji:maintenance system setup directory nis> show

Properties:

<status> = online domain = sun.com

broadcast = true ypservers = caji:maintenance system setup directory nis> set domain=fishworks domain = fishworks (uncommitted) caji:maintenance system setup directory nis> commit caji:maintenance system setup directory nis> done caji:maintenance system setup directory> done aksh: done with

"directory", advancing configuration to "support" ...

Configure storage pools that are characterized by their underlying data redundancy, and provide space that is shared across all filesystems and LUNs. See the Storage section of the

System Administration Guide at http://wikis.sun.com/display/fishworks

(http://wikis.sun.com/display/fishworks) for additional documentation.

Configure Storage.

Subcommands that are valid in this context: help [topic] => Get context-sensitive help. If [topic] is specified, it must be one of

"builtins", "commands", "general",

"help", "script" or "properties".

=> Show information pertinent to the current context show commit done config <pool> unconfig

=> Commit current state, including any changes

=> Finish operating on

"storage"

=> Configure the storage pool

=> Unconfigure the storage pool add import

=> Add additional storage to the storage pool

=> Search for existing or destroyed pools to import scrub <start|stop> => Start or stop a scrub get [prop] => Get value for property [prop]. (

"help properties" for valid properties.) If [prop] is not specified,

Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

returns values for all properties.

set pool=[pool] => Change current pool caji:maintenance system setup storage> show

Properties: pool = pool-0 status = online profile = mirror log_profile = cache_profile = caji:maintenance system setup storage> done aksh: done with

"storage", advancing configuration to "support" ...

Refer to (Phone Home) for additional documentation of remote support configuration.

Remote Support. Register your appliance and configure remote monitoring.

Subcommands that are valid in this context: tags scrk

=> Configure service tags

=> Configure phone home help [topic] => Get context-sensitive help. If [topic] is specified, it must be one of

"builtins", "commands", "general",

"help" or "script".

=> Show information pertinent to the current context show abort done

=> Abort this task (potentially resulting in a misconfigured system)

=> Finish operating on

"support" caji:maintenance system setup support> done aksh: initial configuration complete!

Initial

Chapter 4 • Powering On and Configuring the System 101

102

Glossary

CLI

Cluster

Controller

CPU

CRU

Dashboard

Dataset

DIMM

Disk Shelf

DNS

7110

7120

7210

7310

7320

7410

7420

7720

Active Directory

Alerts

Analytics

ARC

BUI

Sun Storage 7110 Unified Storage System

Sun ZFS Storage 7120

Sun Storage 7210 Unified Storage System

Sun Storage 7310 Unified Storage System

Sun ZFS Storage 7320

Sun Storage 7410 Unified Storage System

Sun ZFS Storage 7420

Sun ZFS Storage 7720

Microsoft Active Directory server

Configurable log, email or SNMP trap events appliance feature for graphing real-time and historic performance statistics

Adaptive Replacement Cache

Browser User Interface

Command Line Interface

Multiple heads connected to shared storage

See ''Storage Controller''

Central Prcessing Unit

Customer Replaceable Component appliance summary display of system health and activity the in-memory and on-disk data for a statistic from Analytics dual in-line memory module the expansion storage shelf that is connected to the head node or storage controller

Domain Name Service

103

DTrace

DTrace

Icons iSCSI

Kiosk

L2ARC

LDAP

LED

Logzilla

LUN

FC

FRU

FTP

GigE

HBA

HCA

HDD

HTTP

Hybrid Storage

Pool

Masthead

Modal Dialog

NFS

NIC

NIS

PCIe

Pool

Project

PSU

a comprehensive dynamic tracing framework for troubleshooting kernel and application problems on production systems in real-time

Fibre Channel

Field Replaceable Component

File Transfer Protocol

Gigabit Ethernet

Host Bus Adapter

Host Channel Adapter

Hard Disk Drive

HyperText Transfer Protocol combines disk, flash, and DRAM into a single coherent and seamless data store.

icons visible in the BUI

Internet Small Computer System Interface a restricted BUI mode where a user may only view one specific screen

Level 2 Adaptive Replacement Cache

Lightweight Directory Access Protocol light-emitting diode write IOPS accelerator

Logical Unit top section of BUI screen a new screen element for a specific function

Network File System

Network Interface Card

Network Information Service

Peripheral Component Interconnect Express provide storage space that is shared across all filesystems and LUNs a collection of shares

Power Supply Unit

104 Sun ZFS Storage 7x20 Appliance Installation Guide • November 2010

ZFS

QDR

Readzilla

quad data rate read-optimized flash SSD for the L2ARC replicating shares to another appliance

Remote

Replication

Rollback

SAS

SAS-2

SATA

Schema

Updates

WebDAV

ZFS

reverts all of the system software and all of the metadata settings of the system back to their state just prior to applying an update

Serial Attached SCSI

Serial Attached SCSI 2.0

Serial ATA configurable properties for shares automating CLI tasks

Scripting

Service

Share

SIM

Snapshot

SSD

SSH

Solid State Drive

Secure Shell

Statistic

a metric visible from Analytics

Storage Controller

the head node of the appliance

Support Bundle

auto-generated files containing system configuration information and core files for use by remote support in debugging system failures

Title Bar

appliance service software

ZFS filesystem shared using data protocols

SAS Interface Module an image of a share local navigation and function section of BUI screen software or firmware updates

Web based Distributed Authoring and Versioning on-disk data storage subsystem

105

106

Index

Numbers and Symbols

7x20 Controllers

Installing Mounting Brackets on the Controller

Chassis, 16–19

Installing the Cable Management Assembly, 25–29

Installing the Controller Chassis into the Rack Slide

Rails, 19–25

C

Cabinet, Unpacking and Moving the Cabinet, 47–51

P

Power

Completing Configuration, 94

Powering On the Appliance, 92–94

S

Sun Disk Shelf, Installing the Sun Disk Shelf into the

Rack Slide Rails, 31–34

107

108

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement

Table of contents

Languages
