Induction Cooktops 600 SERIES

44 - 51

Radiant Cooktops 600 SERIES

52 - 59

Radiant Cooktops 300 SERIES

60 - 69

Gas Cooktops 400 SERIES

70 - 79

Gas Cooktops 300 SERIES

80 - 87

Accesories & Technical Data

88 - 94

600 SERIES

6 - 17

Single Ovens 400 SERIES

18 - 25

Single Ovens 100 SERIES

26 - 35

Accesories & Technical Data

36 - 41

2

Brand

1949

Fulgor is founded as a coal-stove factory

1955

1960

Fulgor first produces freestanding gas kitchens

Meneghetti is founded as a tool -and metal- pressing factory

1974

Fulgor’s built-in cooktops are created

1976

Fulgor’s electric cooktops first produced

1987

1990

First production of Meneghetti’s cooktops

Creation of Fulgor’s first glass cooktop

1991

First European production of Fulgor’s pyrolytic ovens

1994

First European production of Fulgor’s pyrolytic ovens for the North American market

2000

First production of Meneghetti’s ovens

2006

Fulgor invents world’s first dual-flame burner

2007

Meneghetti becomes first European cooktop manufacturer

2009

First production of Meneghetti’s cooker hoods

Acquisition of Fulgor by Meneghetti S.p.A.

Fulgor celebrates 60 years; Fulgor-Milano is born

2010

Meneghetti and Fulgor move forward, bringing time-honored tradition together with the latest technologies

3

4

Ovens

5

True Italian design must be as exquisite in appearance as it is in performance.

Beauty infused with intelligence; art informed by craftsmanship; form integrated with function. At

Fulgor Milano, we design extraordinary appliances for everyday living – enriching how people live in the spaces where they live. Our award-winning designs are inspired by our strong passion for food, family, friends and fine living. Our innovative line of appliances and kitchen products combine the quality, reliability and affordability that families demand with a refined elegance and understated sophistication that’s unmatched at any price. Sleek surfaces, clean lines and intuitive controls transform kitchens and dining areas into open, stylish spaces that draw crowds but never feel crowded.

6

600 Series

Single & Double Ovens

7

A modern workhorse that marries style and innovation. With many preset cooking functions, the

600 series ovens help you prepare your meals with efficiency and ease. Child safety locks and cool touch doors ensure you and your family will be protected from high temperatures while cooking and during the self clean cycle. This series offers the fastest and most versatile self clean mode available, a dual convection system for high quality performance and an oversized oven space for big results. With 5 broil levels and a selection of accessories available to you, the 600 series ovens deliver both luxury and convenience.

8

SAFETY FEATURE: COOL DOOR

Rest assured, your hands are safe with us.

Our cool-door technology has a proven guarantee

EXTRA LARGE CAVITY

Imagine the efficiency of being able to use multiple levels of a huge oven at once. We consider it an advantage, don’t you?

TELESCOPIC RACK

Our fully retractable telescopic rack makes accessibility to your cooking more convenient

MEAT PROBE

Precise cooking performance with our meat probe, available in our single ovens and upper cavity of the double ovens

DIMENSIONS single ovens 30”x 30”

28

7/16

(722 mm)

27 1/4 ”

(692 mm)

23 1/4 ”

(590 mm)

24”

(610 mm)

29

11/16

(754 mm)

27 7/8 ”

(707 mm)

double ovens 30”x 30”

28 7/16 ”

(722 mm)

23

1/4 ”

(590 mm)

49

3/4 ”

(1264 mm)

50

13/16

(1290 mm)

24”

(610 mm)

29

11/16 ”

(754 mm)

SYMBOLS

Pyrolytic Self-Clean with automatic door latch

9

True European Convection Bake

(Multi level)

Convection Broil

Dehydrate

Thaw

(Defrost)

Proof

(Warm)

Keep warm

(Warm Plus)

Oven Lights

Convection Roast

Pizza

(Lower Convection)

Bake

Broil

Fast Preheat

10

Series

Single Ovens

600

F6SP30S1

Dual fan Multifunction pyrolytic oven 30”, 600 Series

Ŷ

Stainless steel

Ŷ

Electronic controls with intuitive and easy access to the oven’s numerous cooking functions

Ŷ

Pyrolytic Self-Clean with automatic door latch

Ŷ

Electronic temperature regulation

Ŷ

12 cooking functions including “pizza” function

Ŷ

3x20W halogen lighting

Ŷ

English language

Special functions:

Ŷ

Preset/Last used temperature memory

Ŷ

Preheat bar (25%, 50%, 75%, 100%)

Ŷ

Automatic Fast Preheat

Ŷ

Keyboard Lock

Ŷ

Child door lock

Ŷ

Sabbath mode

Ŷ

12/24 hours clock format

Ŷ

°C/F° degree unit

Delivered accessories:

Ŷ

2 chromed racks

Ŷ

Enameled grill set (basin+anti-splash)

Ŷ

Meat probe

Ŷ

Telescopic chromed rack

11

12

F6SP30B1

Dual fan Multifunction pyrolytic oven 30”, 600 Series

Ŷ

Black Colour

Ŷ

Electronic controls with intuitive and easy access to the oven’s numerous cooking functions

Ŷ

Pyrolytic Self-Clean with automatic door latch

Ŷ

Electronic temperature regulation

Ŷ

12 cooking functions including “pizza” function

Ŷ

3x20W halogen lighting

Ŷ

English language

Special functions:

Ŷ

Preset/Last used temperature memory

Ŷ

Preheat bar (25%, 50%, 75%, 100%)

Ŷ

Automatic Fast Preheat

Ŷ

Keyboard Lock

Ŷ

Child door lock

Ŷ

Sabbath mode

Ŷ

12/24 hours clock format

Ŷ

°C/F° degree unit

Delivered accessories:

Ŷ

2 chromed racks

Ŷ

Enameled grill set (basin+anti-splash)

Ŷ

Meat probe

Ŷ

Telescopic chromed rack

Series

Single Ovens

600

Series

Single Ovens

600

F6SP30W1

Dual fan Multifunction pyrolytic oven 30”, 600 Series

Ŷ

White Colour

Ŷ

Electronic controls with intuitive and easy access to the oven’s numerous cooking functions

Ŷ

Pyrolytic Self-Clean with automatic door latch

Ŷ

Electronic temperature regulation

Ŷ

12 cooking functions including “pizza” function

Ŷ

3x20W halogen lighting

Ŷ

English language

Special functions:

Ŷ

Preset/Last used temperature memory

Ŷ

Preheat bar (25%, 50%, 75%, 100%)

Ŷ

Automatic Fast Preheat

Ŷ

Keyboard Lock

Ŷ

Child door lock

Ŷ

Sabbath mode

Ŷ

12/24 hours clock format

Ŷ

°C/F° degree unit

Delivered accessories:

Ŷ

2 chromed racks

Ŷ

Enameled grill set (basin+anti-splash)

Ŷ

Meat probe

Ŷ

Telescopic chromed rack

13

14

Series

Double Ovens

600

Upper

Oven

Lower

Oven

F6DP30S1

Double Dual Multifunction pyrolytic oven 30”,

600 Series

Ŷ

Stainless steel

Ŷ

Electronic controls with intuitive and easy access to the oven’s numerous cooking functions

Ŷ

Pyrolytic Self-Clean with automatic door latch

Ŷ

Electronic temperature regulation

Ŷ

12 cooking functions including “pizza” function

Ŷ

3x20W halogen lighting for each cavity

Ŷ

English language

Special functions:

Ŷ

Preset/Last used temperature memory

Ŷ

Preheat bar (25%, 50%, 75%, 100%)

Ŷ

Automatic Fast Preheat

Ŷ

Keyboard Lock

Ŷ

Child door lock

Ŷ

Sabbath mode

Ŷ

12/24 hours clock format

Ŷ

°C/F° degree unit

Delivered upper oven accessories:

Ŷ

2 chromed racks

Ŷ

Enameled grill set(basin+anti-splash)

Ŷ

Meat probe

Ŷ

Telescopic chromed rack

Delivered lower oven accessories:

Ŷ

2 chromed racks

Ŷ

Enameled grill set(basin+anti-splash)

Ŷ

Telescopic chromed rack

15

16

F6DP30B1

Double Dual Multifunction pyrolytic oven 30”,

600 Series

Ŷ

Black Colour

Ŷ

Electronic controls with intuitive and easy access to the oven’s numerous cooking functions

Ŷ

Pyrolytic Self-Clean with automatic door latch

Ŷ

Electronic temperature regulation

Ŷ

12 cooking functions including “pizza” function

Ŷ

3x20W halogen lighting for each cavity

Ŷ

English language

Special functions:

Ŷ

Preset/Last used temperature memory

Ŷ

Preheat bar (25%, 50%, 75%, 100%)

Ŷ

Automatic Fast Preheat

Ŷ

Keyboard Lock

Ŷ

Child door lock

Ŷ

Sabbath mode

Ŷ

12/24 hours clock format

Ŷ

°C/F° degree unit

Delivered upper oven accessories:

Ŷ

2 chromed racks

Ŷ

Enameled grill set(basin+anti-splash)

Ŷ

Meat probe

Ŷ

Telescopic chromed rack

Delivered lower oven accessories:

Ŷ

2 chromed racks

Ŷ

Enameled grill set(basin+anti-splash)

Ŷ

Telescopic chromed rack

Series

Double Ovens

600

Upper

Oven

Lower

Oven

Series

Double Ovens

600

Upper

Oven

Lower

Oven

F6DP30W1

Double Dual Multifunction pyrolytic oven 30”,

600 Series

Ŷ

White Colour

Ŷ

Electronic controls with intuitive and easy access to the oven’s numerous cooking functions

Ŷ

Pyrolytic Self-Clean with automatic door latch

Ŷ

Electronic temperature regulation

Ŷ

12 cooking functions including “pizza” function

Ŷ

3x20W halogen lighting for each cavity

Ŷ

English language

Special functions:

Ŷ

Preset/Last used temperature memory

Ŷ

Preheat bar (25%, 50%, 75%, 100%)

Ŷ

Automatic Fast Preheat

Ŷ

Keyboard Lock

Ŷ

Child door lock

Ŷ

Sabbath mode

Ŷ

12/24 hours clock format

Ŷ

°C/F° degree unit

Delivered upper oven accessories:

Ŷ

2 chromed racks

Ŷ

Enameled grill set(basin+anti-splash)

Ŷ

Meat probe

Ŷ

Telescopic chromed rack

Delivered lower oven accessories:

Ŷ

2 chromed racks

Ŷ

Enameled grill set(basin+anti-splash)

Ŷ

Telescopic chromed rack

17

18

400 Series

Single Ovens

19

A sleek European design and flush installation, the

400 series oven shares the same body and soul of the 600 series oven, offering many of the same professional features while providing tremendous value. Available only in a single oven configuration, this series offers an oversized oven capacity, multi pass broil, European convection, concealed bake elements and 8 baking functions; all of which are controlled by an easy to use and extremely reliable control system.

The Athena XS control gives the home chef complete control via easy to use and intuitive controls making this oven a great choice as a primary or secondary oven for a variety of kitchen designs and applications.

20

SAFETY FEATURE: COOL DOOR

Rest assured, your hands are safe with us.

Our cool-door technology has a proven guarantee

EXTRA LARGE CAVITY

Imagine the efficiency of being able to use multiple levels of a huge oven at once. We consider it an advantage, don’t you?

TELESCOPIC RACK

Our fully retractable telescopic rack enhances your cooking experience (100%)

DIMENSIONS single ovens 30”x 30”

28

7/16

(722 mm)

27

1/4

(692 mm)

23 1/4 ”

(590 mm)

24”

(610 mm)

29

11/16

(754 mm)

27

7/8

(707 mm)

SYMBOLS

Pyrolytic Self-Clean with automatic door latch

21

True European Convection Bake

Convection Broil

Bake

Broil

Thaw

(Defrost)

Convection bake

(without ring element)

Oven Lights

Series

Single Ovens

400

F4SP30S1

Multifunction pyrolytic oven 30”, 400 Series

Ŷ

Stainless steel

Ŷ

Electronic controls with intuitive and easy access to the oven’s numerous cooking functions

Ŷ

Pyrolytic Self-Clean

Ŷ

Electronic temperature regulation

Ŷ

8 cooking functions

Ŷ

3x20W halogen lighting

Ŷ

English language

Special functions:

Ŷ

12 hours clock format (AM/PM)

Ŷ

°C/F° degree unit

Ŷ

Preheat indication

Delivered accessories:

Ŷ

2 chromed racks

Ŷ

Enameled grill set (basin+anti-splash)

Optional accessories:

Ŷ

Telescopic chromed rack

23

24

F4SP30B1

Multifunction pyrolytic oven 30”, 400 Series

Ŷ

Black Colour

Ŷ

Electronic controls with intuitive and easy access to the oven’s numerous cooking functions

Ŷ

Pyrolytic Self-Clean

Ŷ

Electronic temperature regulation

Ŷ

8 cooking functions

Ŷ

3x20W halogen lighting

Ŷ

English language

Special functions:

Ŷ

12 hours clock format (AM/PM)

Ŷ

°C/F° degree unit

Ŷ

Preheat indication

Delivered accessories:

Ŷ

2 chromed racks

Ŷ

Enameled grill set (basin+anti-splash)

Optional accessories:

Ŷ

Telescopic chromed rack

Series

Single Ovens

400

Series

Single Ovens

400

F4SP30W1

Multifunction pyrolytic oven 30”, 400 Series

Ŷ

White Colour

Ŷ

Electronic controls with intuitive and easy access to the oven’s numerous cooking functions

Ŷ

Pyrolytic Self-Clean

Ŷ

Electronic temperature regulation

Ŷ

8 cooking functions

Ŷ

3x20W halogen lighting

Ŷ

English language

Special functions:

Ŷ

12 hours clock format (AM/PM)

Ŷ

°C/F° degree unit

Ŷ

Preheat indication

Delivered accessories:

Ŷ

2 chromed racks

Ŷ

Enameled grill set (basin+anti-splash)

Optional accessories:

Ŷ

Telescopic chromed rack

25

26

100 Series

Single Ovens

27

A standard-setting series with first-class performance.

Many preset cooking functions help you prepare your meals with efficiency and ease. The fastest and most versatile self-clean mode available, featuring automatic door-latch system.

Child safety locks and cool-touch doors protect you and your family from high temperatures while cooking and during the self-clean cycle. 5 broil levels.

Smaller cavity dimensions fit in any kitchen and reduce energy consumption while providing ample space for all your cooking needs.

A selection of accessories is available for your convenience.

28

HALOGEN LIGHTS

Two 20-watt halogen bulbs provide plenty of light for easy viewing

CONCEALED BAKE ELEMENTS

The concealed heating element and large broiler make it possible to cook and save energy at the same time

NEW ITALIAN DESIGN

Combining straightforwardness and ease of use with a clean Italian design, our control panel does not require an engineer to operate

DIMENSIONS single ovens 30”x 24”

28 ”

(710 mm)

23”

(585 mm)

24”

(610 mm)

22 1/16 ”

(560 mm)

29

3/8

(745 mm)

23 3/16 ”

(589 mm)

single ovens 24”x 24”

22 1/16 ”

(560 mm)

23”

(585 mm)

24”

(610 mm)

22 1/16 ”

(560 mm)

23

7/16

(595 mm)

23 3/16 ”

(589 mm)

SYMBOLS

Pyrolytic Self-Clean with automatic door latch

29

True European Convection Bake

Convection Broil

Bake

Broil

Lower Bake

Thaw

(Defrost)

Maxi Broil

Dehydrate

Convection bake

(without ring element)

Pizza

(Lower Convection)

Oven Lights

Convection Roast

Series

Single Ovens

100

F1SP30S2

Multifunction pyrolytic oven 30”, 100 Series

Ŷ

Stainless colour

Ŷ

Electronic controls

Ŷ

Rounded handle

Ŷ

Pyrolytic Self-Clean with automatic door latch

Ŷ

Electronic temperature regulation

Ŷ

7 cooking functions

Ŷ

2X20W halogen lighting

Ŷ

English language

Special functions:

Ŷ

Manual fast pre-heat

Ŷ

Child door lock

Ŷ

Sabbath mode

Ŷ

12/24 hours clock format

Ŷ

°C/°F degree unit

Delivered accessories:

Ŷ

2 chromed racks

Ŷ

Enameled grill set (basin+anti-splash)

Optional accessories:

Ŷ

Telescopic chromed rack

31

32

F1SP30S1

Multifunction pyrolytic oven 30”, 100 Series

Ŷ

Stainless colour

Ŷ

Electronic controls

Ŷ

Pyrolytic Self-Clean

Ŷ

Electronic temperature regulation

Ŷ

8 cooking functions

Ŷ

2X20W halogen lighting

Ŷ

English language

Special functions:

Ŷ

12 hours clock format (AM/PM)

Ŷ

°C/F° degree unit

Ŷ

Preheat indication

Delivered accessories:

Ŷ

2 chromed racks

Ŷ

Enameled grill set (basin+anti-splash)

Optional accessories:

Ŷ

Telescopic chromed rack

Series

Single Ovens

100

Series

Single Ovens

100

F1SP24S1

Multifunction pyrolytic oven 24”, 100 Series

Ŷ

Electronic controls

Ŷ

Pyrolytic Self-Clean

Ŷ

Electronic temperature regulation

Ŷ

8 cooking functions

Ŷ

1X20W halogen lighting

Ŷ

English language

Special functions:

Ŷ

12 hours clock format (AM/PM)

Ŷ

°C/F° degree unit

Ŷ

Preheat indication

Delivered accessories:

Ŷ

2 chromed racks

Ŷ

Enameled grill set (basin+anti-splash)

Optional accessories:

Ŷ

Telescopic chromed rack

33

34

F1SM30S1

Convection oven 30”, stainless steel, 100 Series

Ŷ

Time programmer

Ŷ

Thermostat temperature regulation

Ŷ

8 cooking functions

Ŷ

2X20W halogen lighting

Ŷ

English language

Delivered accessories:

Ŷ

2 chromed racks

Ŷ

Enameled grill set (basin+anti-splash)

Series

Single Ovens

100

Series

Single Ovens

100

F1SM24S1

Convection oven 24”, stainless steel, 100 Series

Ŷ

Time programmer

Ŷ

Thermostat temperature regulation

Ŷ

8 cooking functions

Ŷ

1X20W halogen lighting

Ŷ

English language

Delivered accessories:

Ŷ

2 chromed racks

Ŷ

Enameled grill set (basin+anti-splash)

35

36

Accesories &

Technical Data

Single & Double Ovens

Useful accessories will help you customize your appliances while giving you ease, efficiency and successful results in your cooking.

The telescopic rack is an indispensable addition to every modern oven.

OVENS ACCESSORIES 37

TELESCOPIC RACKS

FMTR124

Telescopic rack kit “100” Series

24” Stainless Steel/Chrome

FMTR130

Telescopic rack kit “100” Series

30” Stainless Steel/Chrome

FMTR630

Telescopic rack kit “400” and “600” Series

30” Stainless Steel/Chrome

38 TECHNICAL DATA 600 SERIES SINGLE OVENS

MODEL

Size

Colour

Stainless Steel Aestethics

Oven Type

Temperature Regulation

Control Panel

Control type

Clock/Timer Display

Temperature Display

Function Display

Commands

Knobs type

Language

Special Features

Preset/Last used temperature memory

Preheat bar (25%, 50%, 75%, 100%)

Automatic Fast Preheat

Child Door Lock

Commands Lock

Sabbath mode

12/24 hours clock format

°C/°F degree unit

Oven Door(s)

Oven Glass Window

Door Cooling System

Door Hinges

Handle style

Oven Cavity

Net Capacity (cbft)

Cavity Enameling Colour

Rack Positions

Oven Lights

Broil Upper Heating Element

Upper Auxiliary Element Wattage

Concealed Bake Lower Heating Element

Convection Element Wattage

Oven Accessories

Chromed racks

Enameled Grill set ( basin + anti splash )

Telescopic chromed rack

Meat probe

Dimensions/Weight - (In or Lbs)

Overall dim - width

Overall dim - height

Overall dim - depth

Cutout - width

Cutout - height (min)

Cutout - depth (min)

Power / Ratings (208/240 V, 60 Hz)

KW/Amps rating at 240V, 60Hz

KW/Amps rating at 208V, 60Hz

Cable + Conduit

Instructions for use

Use & Care Manual

Installation Manual

F6SP30S1

PYRO

30"x30"

SS

Embossed window profile with bended edges

Multifunction 2 Fans (True Euro Conv.)

Electronic

HAWK3TC - Electronic

Blue Backlight

Red LED

Red LED

2 Knobs / 6 Touch Keys

MGH "U" PLASTIC

English

X

X

X

X

X

X

X

X

F6SP30B1

PYRO

30"x30"

BLACK

Multifunction 2 Fans (True Euro Conv.)

Electronic

HAWK3TC - Electronic

Blue Backlight

Red LED

Red LED

2 Knobs / 6 Touch Keys

MGH "U" PLASTIC

English

X

X

X

X

X

X

X

X

F6SP30W1

PYRO

30"x30"

WHITE

Multifunction 2 Fans (True Euro Conv.)

Electronic

HAWK3TC - Electronic

Blue Backlight

Red LED

Red LED

2 Knobs / 6 Touch Keys

MGH "U" PLASTIC

English

X

X

X

X

X

X

X

X

Large See Through Glass

4 Pane Heat Resistant Glass

Heavy Duty Steady Tilt

Stainless Steel Tube d25mm, Plastic terminals

Large See Through Glass

4 Pane Heat Resistant Glass

Large See Through Glass

4 Pane Heat Resistant Glass

Heavy Duty Steady Tilt Heavy Duty Steady Tilt

Stainless Steel Tube d25mm, Plastic terminals Stainless Steel Tube d25mm, Plastic terminals

4.1

Grey

6

3x20W Halogen

3500 W (240V)

1032W (240V)

3000 W (240V)

2x1300 W (240V)

1

1

2

1

4.1

Grey

6

3x20W Halogen

3500 W (240V)

1032W (240V)

3000 W (240V)

2x1300 W (240V)

2

1

1

1

4.1

Grey

6

3x20W Halogen

3500 W (240V)

1032W (240V)

3000 W (240V)

2x1300 W (240V)

2

1

1

1

29 11/16" (754mm)

27-7/8" (707mm)

24" (610mm)

28 7/16" (722mm)

27-1/4" (692mm)

23-1/4" (590mm)

3.84kW - 16.9Amps

3.54kW - 17.5Amps

X

EN, SP, FR

EN, SP, FR

29 11/16" (754mm)

27-7/8" (707mm)

24" (610mm)

28 7/16" (722mm)

27-1/4" (692mm)

23-1/4" (590mm)

3.84kW - 16.9Amps

3.54kW - 17.5Amps

X

EN, SP, FR

EN, SP, FR

29 11/16" (754mm)

27-7/8" (707mm)

24" (610mm)

28 7/16" (722mm)

27-1/4" (692mm)

23-1/4" (590mm)

3.84kW - 16.9Amps

3.54kW - 17.5Amps

X

EN, SP, FR

EN, SP, FR

TECHNICAL DATA 600 SERIES DOUBLE OVENS 39

MODEL

Size

Colour

Stainless Steel Aestethics

Oven Type

Temperature Regulation

Control Panel

Control type

Clock/Timer Display

Temperature Display

Function Display

Commands

Knobs type

Language

Special Features

Preset/Last used temperature memory

Preheat bar (25%, 50%, 75%, 100%)

Automatic Fast Preheat

Child Door Lock

Commands Lock

Sabbath mode

12/24 hours clock format

°C/°F degree unit

Oven Door(s)

Oven Glass Window

Door Cooling System

Door Hinges

Handle style

Oven Cavity

Net Capacity (cbft)

Cavity Enameling Colour

Rack Positions

Oven Lights

Broil Upper Heating Element

Upper Auxiliary Element Wattage

Concealed Bake Lower Heating Element

Convection Element Wattage

Oven Accessories

Chromed racks

Enameled Grill set ( basin + anti splash )

Telescopic chromed rack

Meat probe

Dimensions/Weight - (In or Lbs)

Overall dim - width

Overall dim - height

Overall dim - depth

Cutout - width

Cutout - height (min)

Cutout - depth (min)

Power / Ratings (208/240 V, 60 Hz)

KW/Amps rating at 240V, 60Hz

KW/Amps rating at 208V, 60Hz

Cable + Conduit

Instructions for use

Use & Care Manual

Installation Manual

F6DP30S1

PYRO

30"x30"

SS

Embossed window profile with bended edges

Both Multifunction 2 Fans (True Euro Conv.)

Electronic

F6DP30SB1

PYRO

30"x30"

BLACK

Both Multifunction 2 Fans (True Euro Conv.)

Electronic

F6DP30W1

PYRO

30"x30"

WHITE

Both Multifunction 2 Fans (True Euro Conv.)

Electronic

HAWK3TC - Electronic

Blue Backlight

Red LED

Red LED

2 Knobs / 6 Touch Keys

MGH "U" PLASTIC

English

X

X

X

X

X

X

X

X

HAWK3TC - Electronic

Blue Backlight

Red LED

Red LED

2 Knobs / 6 Touch Keys

MGH "U" PLASTIC

English

X

X

X

X

X

X

X

X

HAWK3TC - Electronic

Blue Backlight

Red LED

Red LED

2 Knobs / 6 Touch Keys

MGH "U" PLASTIC

English

X

X

X

X

X

X

X

X

Large See Through Glass

4 Pane Heat Resistant Glass

Large See Through Glass

4 Pane Heat Resistant Glass

Heavy Duty Steady Tilt Heavy Duty Steady Tilt

Stainless Steel Tube d25mm, Plastic terminals Stainless Steel Tube d25mm, Plastic terminals

Large See Through Glass

4 Pane Heat Resistant Glass

Heavy Duty Steady Tilt

Stainless Steel Tube d25mm, Plastic terminals

4.1

Grey

6

3x20W Halogen

3500 W (240V)

1032W (240V)

3000 W (240V)

2x1300 W (240V)

2 per cavity

1 per cavity

1 per cavity

Upper Oven Only

4.1

Grey

6

3x20W Halogen

3500 W (240V)

1032W (240V)

3000 W (240V)

2x1300 W (240V)

2 per cavity

1 per cavity

1 per cavity

Upper Oven Only

4.1

Grey

6

3x20W Halogen

3500 W (240V)

1032W (240V)

3000 W (240V)

2x1300 W (240V)

2 per cavity

1 per cavity

1 per cavity

Upper Oven Only

29 11/16" (754mm)

50 13/16" (1290mm)

24" (610mm)

28 7/16" (722mm)

49 3/4" (1264mm)

23 1/4" (590mm)

7.68kW - 33.8Amps

6.48kW - 32.4Amps

X

EN, SP, FR

EN, SP, FR

29 11/16" (754mm)

50 13/16" (1290mm)

24" (610mm)

28 7/16" (722mm)

49 3/4" (1264mm)

23 1/4" (590mm)

7.68kW - 33.8Amps

6.48kW - 32.4Amps

X

EN, SP, FR

EN, SP, FR

29 11/16" (754mm)

50 13/16" (1290mm)

24" (610mm)

28 7/16" (722mm)

49 3/4" (1264mm)

23 1/4" (590mm)

7.68kW - 33.8Amps

6.48kW - 32.4Amps

X

EN, SP, FR

EN, SP, FR

40 TECHNICAL DATA 400 SERIES SINGLE OVENS

MODEL

Size

Colour

Oven Type

Temperature Regulation

Control Panel

Control type

Clock/Timer Display

Commands

Knobs type

Language

Special Features

Manual Fast Preheat

Child Door Lock

Sabbath mode

12/24 hours clock format

°C/°F degree unit

Oven Door(s)

Oven Glass Window

Door Cooling System

Door Hinges

Handle style

Oven Cavity

Net Capacity (cbft)

Cavity Enameling Colour

Rack Positions

Oven Lights

Broil Upper Heating Element

Upper Auxiliary Element Wattage

Concealed Bake Lower Heating Element

Lower Auxiliary Element Wattage

Convection Element Wattage

Oven Accessories

Chromed racks

Enameled Grill set ( basin + anti splash )

Telescopic chromed rack

Dimensions/Weight - (In or Lbs)

Overall dim - width

Overall dim - height

Overall dim - depth

Cutout - height (min)

Cutout - depth (min)

Power / Ratings (208/240 V, 60 Hz)

KW/Amps rating at 240V, 60Hz

KW/Amps rating at 208V, 60Hz

Cable + Conduit

Instructions for use

Use & Care Manual

Installation Manual

F4SP30S1

PYRO

30"x30"

SS

Multifunction (True Euro Conv.)

Electronic

Athena XS - Electronic

Red LED

2 Knobs

MGH "U" PLASTIC

English

F4SP30B1

PYRO

30"x30"

BLACK

Multifunction (True Euro Conv.)

Electronic

Athena XS - Electronic

Red LED

2 Knobs

MGH "U" PLASTIC

English

F4SP30W1

PYRO

30"x30"

WHITE

Multifunction (True Euro Conv.)

Electronic

Athena XS - Electronic

Red LED

2 Knobs

MGH "U" PLASTIC

English

X

Large See Through Glass

4 Pane Heat Resistant Glass

Heavy Duty Steady Tilt

Tubular Steel

4.3

Grey

6

3x20W Halogen

3100 W (240V)

1032W (240V)

1400 W (240V)

600W (240V)

2500 W (240V)

2

1

Optional

29 11/16" (754mm)

27-7/8" (707mm)

24" (610mm)

27-1/4" (692mm)

23-1/4" (590mm)

3.7kW - 16.1Amps

3.49kW - 17.1Amps

X

EN, SP, FR

EN, SP, FR

X

Large See Through Glass

4 Pane Heat Resistant Glass

Heavy Duty Steady Tilt

Tubular Steel

4.3

Grey

6

3x20W Halogen

3100 W (240V)

1032W (240V)

1400 W (240V)

600W (240V)

2500 W (240V)

2

1

Optional

29 11/16" (754mm)

27-7/8" (707mm)

24" (610mm)

27-1/4" (692mm)

23-1/4" (590mm)

3.7kW - 16.1Amps

3.49kW - 17.1Amps

X

EN, SP, FR

EN, SP, FR

X

Large See Through Glass

4 Pane Heat Resistant Glass

Heavy Duty Steady Tilt

Tubular Steel

4.3

Grey

6

3x20W Halogen

3100 W (240V)

1032W (240V)

1400 W (240V)

600W (240V)

2500 W (240V)

2

1

Optional

29 11/16" (754mm)

27-7/8" (707mm)

24" (610mm)

28 7/16" (722mm)

27-1/4" (692mm)

23-1/4" (590mm)

3.7kW - 16.1Amps

3.49kW - 17.1Amps

X

EN, SP, FR

EN, SP, FR

TECHNICAL DATA 100 SERIES SINGLE OVENS 41

MODEL

Size

Colour

Oven Type

Temperature Regulation

Control Panel

Control type

Clock/Timer Display

Commands

Knobs type

Language

Special Features

Manual Fast Preheat

Child Door Lock

Sabbath mode

12/24 hours clock format

°C/°F degree unit

Oven Door(s)

Oven Glass Window

Door Cooling System

Door Hinges

Handle style

Oven Cavity

Net Capacity (cbft)

Cavity Enameling Colour

Rack Positions

Oven Lights

Broil Upper Heating Element

Upper Auxiliary Element Wattage

Concealed Bake Lower Heating Element

Lower Auxiliary Element Wattage

Convection Element Wattage

Oven Accessories

Chromed racks

Enameled Grill set ( basin + anti splash )

Telescopic chromed rack

Dimensions/Weight - (In or Lbs)

Overall dim - width

Overall dim - height

Overall dim - depth

Cutout - width

Cutout - height (min)

Cutout - depth (min)

Power / Ratings (208/240 V, 60 Hz)

KW/Amps rating at 240V, 60Hz

KW/Amps rating at 208V, 60Hz

Cable + Conduit

Instructions for use

Use & Care Manual

Installation Manual

F1SP30S2

PYRO

30"x24"

SS

F1SP30S1

PYRO

30"x24"

SS

F1SP24S1

PYRO

24"

SS

Multifunction (True Euro Conv.) Multifunction (True Euro Conv.) Multifunction (True Euro Conv.)

Electronic Electronic Electronic

HAWK2 - Electronic

Blue/Red LED

2 Knobs / 8 Buttons

MGH "U" PLASTIC

English

X

X

X

X

X

Large See Through Glass

4 Pane Heat Resistant Glass

Heavy Duty Steady Tilt

Rounded Stainless Steel

2.78

Grey

4

2x20W Halogen

3500 W (240V)

1032W (240V)

3000 W (240V)

2500 W (240V)

2

1

29 3/8" (745mm)

23 3/16" (589mm)

22 1/16" (560mm)

28" (710mm)

23" (585mm)

24" (610mm)

3.625kW - 15.6Amps

3.529kW - 17.4Amps

X

EN, SP, FR

EN, SP, FR

Athena XS - Electronic

Red LED

2 Knobs

MGH "U" PLASTIC

English

X

Large See Through Glass

4 Pane Heat Resistant Glass

Heavy Duty Steady Tilt

Tubular Steel

2.78

Grey

4

2x20W Halogen

3100 W (240V)

1032W (240V)

1400 W (240V)

600W (240V)

2500 W (240V)

2

1

Optional

29 3/8" (745mm)

23 3/16" (589mm)

22 1/16" (560mm)

28" (710mm)

23" (585mm)

24" (610mm)

3.625kW - 15.6Amps

3.529kW - 17.4Amps

X

EN, SP, FR

EN, SP, FR

Athena XS - Electronic

Red LED

2 Knobs

MGH "U" PLASTIC

English

X

Large See Through Glass

4 Pane Heat Resistant Glass

Heavy Duty Steady Tilt

Rounded Stainless Steel

2.2

Grey

4

1x20W Halogen

2000 W (240V)

1000W (240V)

1200W (240V)

400W (240V)

2500 W (240V)

2

1

Optional

23 7/16" (595mm)

23 3/16" (589mm)

22 1/16" (560mm)

22 1/16" (560mm)

23" (585mm)

24" (610mm)

2.5kW - 10.42Amps

2.345kW - 11.3Amps

X

EN, SP, FR

EN, SP, FR

F1SM30S1

NORMAL

30"x24"

SS

Convection

Thermostat

Time Programmer

Red Led

2 Knobs / 6 Buttons

MGH "U" PLASTIC

English

F1SM24S1

NORMAL

24"

SS

Convection

Thermostat

Time Programmer

Red Led

2 Knobs / 6 Buttons

MGH "U" PLASTIC

English

Large See Through Glass Large See Through Glass

3 Pane Heat Resistant Glass 3 Pane Heat Resistant Glass

Heavy Duty Steady Tilt

Tubular Steel

Heavy Duty Steady Tilt

Tubular Steel

2.78

Grey

4

2x20W Halogen

3100 W (240V)

1032W (240V)

2100 W (240V)

2

1

29 3/8" (745mm)

23 3/16" (589mm)

22 1/16" (560mm)

28" (710mm)

23" (585mm)

24" (610mm)

3.625kW - 15.6Amps

2.720kW - 11.4Amps

X

EN, SP, FR

EN, SP, FR

2.2

Grey

4

1x20W Halogen

2000W (240V)

1000W (240V)

1200W (240V)

2

1

23 7/16" (595mm)

23 3/16" (589mm)

22 1/16" (560mm)

22 1/16" (560mm)

23" (585mm)

24" (610mm)

3050W/12,7Amps approx.

2300W/9,5 Amps approx.

X

EN, SP, FR

EN, SP, FR

42

Cooktops

43

Fulgor Milano cooktops embody Italian elegance and design while offering the quality and durability expected from one of Europe’s leading manufacturers of built in cooking appliances.

Nothing is compromised in the performance of our products. Born from a culture of cooking that is world renowned, our customers should not expect less.

You will be the envy of your guests with your beautiful

Italian appliance, which may inspire you to take your culinary skills to new elevations.

The shallow design of our cook tops allow kitchen designers to optimize space, providing the greatest flexibility possible for a variety of installation possibilities.

With a Fulgor Milano cooktop, your dream kitchen will become a reality.

44

600 Series

Induction Cooktops

45

Our 600 series induction cooktops follow the same design criteria of all our Fulgor-Milano products; style, function, and performance are at the heart of this product.

Like out radiant touch cooktops our induction units are finished off with a subtle yet elegant aluminum trim that exudes luxury, while offering all of the features you would expect from a premium cooking appliance. Our induction cook tops offer the power and control of a gas cooktop with the speed and clean-ability of a radiant cooktop, these cooktops give you the best of both worlds. From tempering fine chocolate to braising a classic osso bucco, to bringing a 15 quart stock pot to boil in minutes, the possibilities are endless with our induction technology.

46

FRAME

Aluminum frame stainless steel color protects the glass edges from damage

ELECTRONIC CONTROL

State-of-the-art “Peacock” control. LED displays cooking level. Booster function and low-power settings for accuracy

INDUCTION

Heating only the area beneath the pot means cooking softly without compromise. The exact amount of energy needed to heat the pan--no more, no less!

PERFORMANCES OF INDUCTION COOKING HOW DOES INDUCTION COOKING WORK?

• High efficiency

Induction is the most efficient technology available today for cooking.

of the cooking vessel, without loss of energy

• Reduced heating times

Induction is 30% to 50% faster compared with other existing cooking technology

• Low surface temperature

Every cooking zone consists of a copper coil (inductor) driven by an electronic system that can generate a high-frequency current in order to induce an electromagnetic field.

Some ferrite (material with a very high magnetic permeability) elements located under the inductor form a loop of magnetic flux (red lines in the picture) with the bottom of the cooking vessel (it must be made with ferro-magnetic material).

of this, surface temperatures are lower than those of traditional glassceramic cooktops. Glass is a non-stick surface, making cleaning easy

• Pan detection

bottom of the pot strong eddy currents which generate a large amount of heat stopping automatically and cooling down mere seconds after a pan is removed. It can even distinguish between types of pans

• Safety

does not detect small items like utensils that may accidentally be left on the cooktop.

Control lock prevents unintentional activation

WATER

MAGNETIC FLUX

INDUCED EDDY CURRENTS insulting material insulting material

INDUCTOR

GLASS

FERRITE ELEMENT

CURRENT GENERATED BY THE INVERTER

FERRITE ELEMENT

FERRO-MAGNETIC PAN BOTTOM

ALUMINIUM PLATE

47

DIMENSIONS cooktops 36”

3 1/16 ”

(78 mm)

1-1/2”

(38 mm) min clearance

21”

(538 mm)

19 19/64 ”

(490 mm)

- 19 5/8 ”

(498 mm)

(min-max)

cooktops 30”

36”

(919 mm)

34 1/16 ”

(865 mm)

- 34 5/16 ”

(872 mm)

(min-max)

3 9/32 ”

(84 mm)

3

1/16

(78 mm)

1-1/2”

(38 mm) min clearance

21”

(538 mm)

19

19/64

(490 mm)

- 19

5/8

(498 mm)

(min-max)

3 9/32 ”

(84 mm)

30”

(771 mm)

28 11/16 ”

(729 mm)

- 28 15/16 ”

(735 mm)

(min-max)

50

Series

Induction Cooktops

600

F6IT36S1

Induction cooktop 36”, with aluminum frame stainless steel color and glass ceramic, 600 Series

Ŷ

Slide touch control for power setting

Ŷ

Ŷ

Ŷ

“Peacock Tail” Bar for power indication

5 Digital display for power level indication

Low temperature electronic control for delicate cooking

Ŷ

Command Lock

Ŷ

Booster/Fast boil function

Ŷ

Hot Surface indication and residual heat indication

Ŷ

Timer display with 5+1 timers functions and acoustic buzzer

Ŷ

Failure Codes indication

Front Left Zone

Ŷ

Size 6”

Ŷ

Power 1200W

Ŷ

Booster 1400W

Rear Left Zone

Ŷ

Size 8”

Ŷ

Power 2200W

Ŷ

Booster 3000W

Central Zone (double)

Ŷ

Size 11” / 7”

Ŷ

Power 2650W/1800W

Ŷ

Booster 3600W/2800W

Rear Right Zone

Ŷ

Size 8”

Ŷ

Power 2200W

Ŷ

Booster 3000W

Front Right Zone

Ŷ

Size 6”

Ŷ

Power 1200W

Ŷ

Booster 1400W

Special features:

Ŷ

Pan Detection System

Ŷ

Special Big Double zone

Ŷ

Cooling fan system

Series

Induction Cooktops

600

51

F6IT30S1

Induction cooktop 30”, with aluminum frame stainless steel color and glass ceramic, 600 Series

Ŷ

Slide touch control for power setting

Ŷ

Ŷ

Ŷ

“Peacock Tail” Bar for power indication

4 Digital display for power level indication

Low temperature electronic control for delicate cooking

Ŷ

Command Lock

Ŷ

Booster/Fast boil function

Ŷ

Hot Surface indication and residual heat indication

Ŷ

Timer display with 4+1 timers functions and acoustic buzzer

Ŷ

Failure Codes indication

Front Left Zone

Ŷ

Size 6”

Ŷ

Power 1200W

Ŷ

Booster 1400W

Rear Left Zone

Ŷ

Size 8”

Ŷ

Power 2200W

Ŷ

Booster 3000W

Rear Right Zone

Ŷ

Size 7”

Ŷ

Power 1800W

Ŷ

Booster 2800W

Front Right Zone

Ŷ

Size 6”

Ŷ

Power 1200W

Ŷ

Booster 1400W

Special features:

Ŷ

Pan Detection System

Ŷ

Cooling fan system

52

600 Series

Radiant Touch Cooktops

53

Beautiful intuitive controls designed with elegance and precision. Radiant touch cooktops deliver quick and reliable performance with maximum flexibility.

Touch controls with patented Peacock control sliding bar for power-level selection and fast boil with automatic power reduction.

54

FRAME

Aluminum frame stainless steel color: Sophisticated and functional!

ELECTRONIC CONTROL

Fine-tuning of the lower temperatures plus timer function is standard with our “Peacock” tail control.

Slide touch bar for continuous setting

HEATING ELEMENT

Trademark FulLight® radiant heating elements provide quick, reliable and evenly distributed heat for more consistent cooking.

Our premium triple burner, offered in the 36” and 30” cooktop, ensures complete flexibility

DIMENSIONS cooktops 36”

3

1/16

(78 mm)

1-1/2”

(38 mm) min clearance

21”

(538 mm)

19

19/64

(490 mm)

- 19

5/8

(498 mm)

(min-max)

cooktops 30”

36”

(919 mm)

34

1/16

(865 mm)

- 34

5/16

(872 mm)

(min-max)

3

9/32

(84 mm)

3

1/16

(78 mm)

1-1/2”

(38 mm) min clearance

21”

(538 mm)

19 19/64 ”

(490 mm)

- 19 5/8 ”

(498 mm)

(min-max)

3 9/32 ”

(84 mm)

30”

(771 mm)

28 11/16 ”

(729 mm)

- 28 15/16 ”

(735 mm)

(min-max)

cooktops 24”

3 1/16 ”

(78 mm)

1-1/2”

(38 mm) min clearance

21”

(538 mm)

19

1/4

(490 mm)

- 19

9/16

(497 mm)

(min-max)

3 9/32 ”

(84 mm)

24”

(618 mm)

22 5/8 ”

(574 mm)

- 22 13/16 ”

(580 mm)

(min-max)

55

56

Series

Radiant Touch Cooktops

600

57

F6RT36S1

Electric radiant cooktop 36”, with aluminum frame stainless steel color and glass ceramic, 600 Series

Ŷ

Slide touch control for power setting

Ŷ

Ŷ

Ŷ

“Peacock Tail” Bar for power indication

5 Digital display for power level indication

Low temperature electronic control for delicate cooking

Ŷ

Command Lock

Ŷ

Automatic Fast Boil function

Ŷ

Hot Surface indication and residual heat indication

Ŷ

Timer display with 5+1 timers functions and acoustic buzzer

Ŷ

Failure Codes indication

Front Left Zone

Ŷ

Size 7”

Ŷ

Power 1800W

Bridge Element

Ŷ

Power 800W

Rear Left Zone

Ŷ

Size 8”

Ŷ

Power 1800W

Central Zone

Ŷ

Size 9” / 7” / 5”

Ŷ

Power 2500W / 1600W / 800W

Rear Right Zone

Ŷ

Size 7”

Ŷ

Power 1800W

Front Right Zone

Ŷ

Size 6”

Ŷ

Power 1200W

58

Series

Radiant Touch Cooktops

600

F6RT30S1

Electric radiant cooktop 30”, with aluminum frame stainless steel color and glass ceramic, 600 Series

Ŷ

“Peacock Tail” Bar for power indication

Ŷ

4 Digital display for power level indication

Ŷ

Low temperature electronic control for delicate cooking

Ŷ

Command Lock

Ŷ

Automatic Fast Boil function

Ŷ

Hot Surface indication and residual heat indication

Ŷ

Timer display with 4+1 timers functions and acoustic buzzer

Ŷ

Failure Codes indication

Front Left Zone

Ŷ

Size 6”

Ŷ

Power 1200W

Rear Left Zone

Ŷ

9” / 7” / 5”

Ŷ

Power 2500W / 1600W / 800W

Rear Right Zone

Ŷ

Size 8” / 5”

Ŷ

Power 2200W / 800W

Front Right Zone

Ŷ

Size 6”

Ŷ

Power 1200W

Series

Radiant Touch Cooktops

600

59

F6RT24S1

Electric radiant cooktop 24”, with aluminum frame stainless steel color and glass ceramic, 600 Series

Ŷ

3 Digital display for power level indication

Ŷ

Low temperature electronic control for delicate cooking

Ŷ

Command Lock

Ŷ

Automatic Fast Boil function

Ŷ

Hot Surface indication and residual heat indication

Ŷ

Timer display with 1 timer functions and acoustic buzzer

Ŷ

Failure Codes indication

Front Left Zone

Ŷ

Size 5” 1/2

Ŷ

Power 1200W

Rear Left Zone

Ŷ

8” / 5”

Ŷ

Power 2200W / 800W

Rear Right Zone

Ŷ

Size 7”

Ŷ

Power 1800W

60

300 Series

Radiant Cooktops

61

Our 300 series cooktops offer the same elegant

European design and family line as our radiant touch and induction cooktops but in a package that offers great value and performance to the consumer.

The manual controls are reliable, accurate and continue to be the most user friendly of all control systems available today. Even the most discerning cooks will be impressed with the functionality and performance of this mainstay. Like all Fulgor-Milano cooktops the 300 series offers a shallow profile for countless installation options.

DESIGN

Maintaining style continuity throughout the line, our knob control design ensures clarity and ease of use

HEATING ELEMENT

Trademark FulLight® radiant heating elements provide quick, reliable and evenly distributed heat for more consistent cooking

PREMIUM GLASS

World leader in premium ceramic glass for the appliance industry, using only the finest material and superior processes

DIMENSIONS cooktops 36”

2”

(50,8 mm)

1-1/2”

(38 mm) min clearance

21”

(533 mm)

19 1/4 ”

(490 mm)

- 19 9/16 ”

(497 mm)

(min-max)

cooktops 30”

36”

(914 mm)

34

1/16

(865 mm)

- 34

5/16

(872 mm)

(min-max)

2 3/16 ”

(56 mm)

2”

(50,8 mm)

1-1/2”

(38 mm) min clearance

21”

(533 mm)

19

1/4

(490 mm)

- 19

9/16

(497 mm)

(min-max)

2 3/16 ”

(56 mm)

30 1/4 ”

(767 mm)

28 11/16 ”

(729 mm)

- 28 15/16 ”

(735 mm)

(min-max)

cooktops 24”

3

1/16

(78 mm)

1-1/2”

(38 mm) min clearance

21”

(533 mm)

19

1/4

(490 mm)

- 19

9/16

(497 mm)

(min-max)

3

9/32

(84 mm)

24”

(613 mm)

22

5/8

(574 mm)

- 22

13/16

(580 mm)

(min-max)

cooktops 24” with frame

3

1/16

(78 mm)

1-1/2”

(38 mm) min clearance

21”

(538 mm)

19

1/4

(490 mm)

- 19

9/16

(497 mm)

(min-max)

3 9/32 ”

(84 mm)

24”

(618 mm)

22

5/8

(574 mm)

- 22

13/16

(580 mm)

(min-max)

63

66

Series

Radiant Cooktops

300

F3RK36B1

Electric radiant cooktop 36”, in glass ceramic,

300 Series

Ŷ

5 knobs for power level setting

Ŷ

Hot Surface indicator

Ŷ

Residual heat indication

Front Left Zone

Ŷ

Size 9” / 6”

Ŷ

Power 2500W / 1100W

Rear Left Zone

Ŷ

Size 6”

Ŷ

Power 1200W

Central Zone

Ŷ

Size 11” / 8”

Ŷ

Power 2700W / 1800W

Rear Right Zone

Ŷ

Size 7”

Ŷ

Power 1800W

Front Right Zone

Ŷ

Size 6”

Ŷ

Power 1200W

Series

Radiant Cooktops

300

67

F3RK30B1

Electric radiant cooktop 30”, in glass ceramic,

300 Series

Ŷ

4 knobs for power level setting

Ŷ

Hot Surface indicator

Ŷ

Residual heat indication

Front Left Zone

Ŷ

Size 9” / 6”

Ŷ

Power 2500W / 1100W

Rear Left Zone

Ŷ

Size 6”

Ŷ

Power 1200W

Rear Right Zone

Ŷ

Size 7”

Ŷ

Power 1800W

Front Right Zone

Ŷ

Size 6”

Ŷ

Power 1200W

68

Series

Radiant Cooktops

300

F3RK24B1

Electric radiant cooktop 24”, in glass ceramic,

300 Series

Ŷ

4 knobs for power level setting

Ŷ

Hot Surface indicator

Ŷ

Residual heat indication

Front Left Zone

Ŷ

Size 7”

Ŷ

Power 1800W

Rear Left Zone

Ŷ

Size 5 1/2”

Ŷ

Power 1200W

Rear Right Zone

Ŷ

Size 7”

Ŷ

Power 1800W

Front Right Zone

Ŷ

Size 5 1/2”

Ŷ

Power 1200W

Series

Radiant Cooktops

300

69

F3RK24S1

Electric radiant cooktop 24”, with aluminum frame stainless steel color and glass ceramic, 300 Series

Ŷ

4 knobs for power level setting

Ŷ

Hot Surface indicator

Ŷ

Residual heat indication

Front Left Zone

Ŷ

Size 7 3/4” / 4 3/4”

Ŷ

Power 1900W / 800W

Rear Left Zone

Ŷ

Size 5 1/2”

Ŷ

Power 1200W

Rear Right Zone

Ŷ

Size 7”

Ŷ

Power 1800W

Front Right Zone

Ŷ

Size 5 1/2”

Ŷ

Power 1200W

70

400 Series

Gas Cooktops

71

The 400 series “Largo” cooktops utilize the most advanced technology available and combine this with a classic Italian design, resulting in a cooktop that not only performs magnificently but also looks spectacular.

A design that lends itself to countless application possibilities, the 400 series cooktops also take the consumers cooking and maintenance needs into consideration. All grates are separated in sizes that make them easy to handle and remove for cleaning.

The burners are well orientated to ease of use, with unique configurations like a wok burner and fifth burner on a 30” unit, making this cook top one of the most versatile in the category.

Explore the Largo cooktop family and enjoy the possibilities; buon appetito!

72

CLASSIC DESIGN

Italian design principles inform the style, function and performance of this series, creating a classic yet versatile cooktop

DUAL BURNER

Fulgor-Milano uses a dual-flame European-style sealed burner to deliver a wide range of heat

EUROPEAN SEALED BURNERS

Designed with only two removable parts, our sealed burners keep spills from leaking inside the cooktop

DIMENSIONS cooktops 42”

T.B.D.

1-1/2”

(38 mm) min clearance

425

404,5

mm

- 407,5

mm

(min-max)

mm

1119

mm

1096

mm

- 1099

mm

(min-max)

cooktops 30”

74

mm

T.B.D.

1-1/2”

(38 mm) min clearance

510

489,5

mm

- 492,5

mm

(min-max)

mm

760

mm

737

mm

- 740

mm

(min-max)

74

mm

cooktops 36”

T.B.D.

1-1/2”

(38 mm) min clearance

510

489,5

mm

- 492,5

mm

(min-max)

mm

909

mm

886

mm

- 889

mm

(min-max)

74

mm

cooktops 24”

T.B.D.

1-1/2”

(38 mm) min clearance

510

489,5

mm

- 492,5

mm

(min-max)

mm

620

mm

597

mm

- 600

mm

(min-max)

74

mm

73

76

Series

Gas Cooktops

400

F4GK42S1

Gas cooktop 42”, 400 Series, with 4 burners, stainless steel

Ŷ

Electric Flame Ignition and Re-ignition

Ŷ

Ŷ

Ŷ

Flame out sensing

Heavy Duty Cast Iron Grates

On request: simmer Plate and small Pot Insert

(for single burners only)

Ŷ

On request: wok ring (for dual burner only)

Left Burner

Ŷ

Max. 18000 (BTU/h) - 5275W

Ŷ

Min. 450 (BTU/h) - 135W

Left Middle Burner

Ŷ

Max . 4000 (BTU/h) - 1175W

Ŷ

Min. 1000 (BTU/h) - 295W

Right Middle Burner

Ŷ

Max . 9000 (BTU/h) - 2640W

Ŷ

Min. 1300 (BTU/h) - 380W

Right Burner

Ŷ

Max . 15000 (BTU/h) - 4400W

Ŷ

Min. 2700 (BTU/h) - 790W

Series

Gas Cooktops

400

77

F4GK36S1

Gas cooktop 36”, 400 Series, with 5 burners, stainless steel

Ŷ

Electric Flame Ignition and Re-ignition

Ŷ

Ŷ

Ŷ

Flame out sensing

Heavy Duty Cast Iron Grates

On request: simmer Plate and small Pot Insert

(for single burners only)

Ŷ

On request: wok ring (for dual burner only)

Front Left Burner

Ŷ

Max. 6300 (BTU/h) - 1850W

Ŷ

Min. 1300 (BTU/h) - 380W

Rear Left Burner

Ŷ

Max. 9000 (BTU/h) - 2640W

Ŷ

Min. 1300 (BTU/h) - 380W

Front Middle Burner

Ŷ

Max. 18000 (BTU/h) - 5275W

Ŷ

Min. 450 (BTU/h) - 135W

Rear Right Burner

Ŷ

Max. 12000 (BTU/h) - 3520W

Ŷ

Min. 2200 (BTU/h) - 645W

Front Right Burner

Ŷ

Max. 4000 (BTU/h) - 1175W

Ŷ

Min. 1000 (BTU/h) - 295W

78

Series

Gas Cooktops

400

F4GK30S1

Gas cooktop 30”, 400 Series, with 5 burners, stainless steel

Ŷ

Electric Flame Ignition and Re-ignition

Ŷ

Ŷ

Ŷ

Flame out sensing

Heavy Duty Cast Iron Grates

On request: simmer Plate and small Pot Insert

(for single burners only)

Ŷ

On request: wok ring (for dual burner only)

Front Left Burner

Ŷ

Max. 18000 (BTU/h) - 5275W

Ŷ

Min. 450 (BTU/h) - 135W

Front Middle Burner

Ŷ

Max. 4000 (BTU/h) - 1175W

Ŷ

Min. 1000 (BTU/h) - 295W

Rear Middle Burner

Ŷ

Max. 12000 (BTU/h) - 3520W

Ŷ

Min. 2200 (BTU/h) - 645W

Rear Right Burner

Ŷ

Max. 9000 (BTU/h) - 2640W

Ŷ

Min. 1300 (BTU/h) - 380W

Front Right Burner

Ŷ

Max. 6300 (BTU/h) - 1850W

Ŷ

Min. 1300 (BTU/h) - 380W

Series

Gas Cooktops

400

79

F4GK24S1

Gas cooktop 24”, 400 Series, with 4 burners, stainless steel

Ŷ

Electric Flame Ignition and Re-ignition

Ŷ

Ŷ

Ŷ

Flame out sensing

Heavy Duty Cast Iron Grates

On request: simmer Plate and small Pot Insert

(for single burners only)

Front Left Burner

Ŷ

Max. 18000 (BTU/h) - 5275W

Ŷ

Min. 450 (BTU/h) - 135W

Rear Left Burner

Ŷ

Max. 6300 (BTU/h) - 1850W

Ŷ

Min. 1300 (BTU/h) - 380W

Rear Right Burner

Ŷ

Max. 12000 (BTU/h) - 3520W

Ŷ

Min. 2200 (BTU/h) - 645W

Front Right Burner

Ŷ

Max. 4000 (BTU/h) - 1175W

Ŷ

Min. 1000 (BTU/h) - 295W

80

300 Series

Gas Cooktops

81

Italian wing design for greater surface space and the flexibility to position large pots and pans diagonally on the cooktop.

Patented dual crown burners (36” models only) from

18,000 BTU/H for searing meat and locking in flavor, down to 450 BTU/H.

Sealed burners are easy to clean and to remove.

Heavy-duty cast-iron grates, automatic re-ignition with flame detection, and top mount injectors for better serviceability.

Useful accessories featured, like small-pot reduction, simmer plate and wok ring. Environmentally friendly, made with over 90% recyclable components.

82

CAST IRON GRATES

Heavy-duty cast-iron grates are designed for you to slide pots and pans from burner to burner

DUAL BURNER

Fulgor-Milano uses a dual-flame European-style sealed burner to deliver a wide range of burner output, from

18,000 BTU/h for meat-searing and wok cooking, down to 450 BTU/h for melting chocolate and locking in flavors

EUROPEAN SEALED BURNERS

Designed with only two removable parts, our sealed burners keep spills from leaking inside the cooktop

SMALL POT REDUCTION

Uniquely designed accessory (included) allows you to use pans smaller than 4 inches on a stable, flat cooking surface, without increasing the distance from the flame

DIMENSIONS cooktops 36”

5

1/4

(134 mm)

1-1/2”

(38 mm) min clearance

21”

(533 mm)

19 ”

(483 mm)

- 19 5/8 ”

(498 mm)

(min-max)

36”

(915 mm)

34 1/2 ”

(876 mm)

- 35 ”

(889 mm)

(min-max)

3 1/8 ”

(80 mm)

cooktops 30”

5

1/4

(134 mm)

1-1/2”

(38 mm) min clearance

21”

(533 mm)

19 ”

(483 mm)

- 19

5/8

(498 mm)

(min-max)

3

1/8

(80 mm)

30”

(762 mm)

28 1/2 ”

(724 mm)

- 29”

(737 mm)

(min-max)

83

84

85

86

Series

Gas Cooktops

300

F3GK36S1

Gas cooktop 36”, 300 Series, with 5 burners, stainless steel

Ŷ

Electric Flame Ignition and Re-ignition

Ŷ

Flame out sensing

Ŷ

Dual Crown Burner

Ŷ

Ŷ

Ŷ

Heavy Duty Cast Iron Grates

Delivered with small Pot Insert

On request: wok ring and simmer Plate

Front Left Burner

Ŷ

Max .4000 (BTU/h) - 1175W

Ŷ

Min.1000 (BTU/h) - 295W

Rear Left Burner

Ŷ

Max.15000 (BTU/h) - 4400W

Ŷ

Min.1700 (BTU/h) - 500W

Central Burner

Ŷ

Max.18000 (BTU/h) - 5275W

Ŷ

Min.450 (BTU/h) - 135W

Rear Right Burner

Ŷ

Max.9000 (BTU/h) - 2640W

Ŷ

Min.1300 (BTU/h) - 380W

Front Right Burner

Ŷ

Max. 9000 (BTU/h) - 2640W

Ŷ

Min. 1300 (BTU/h) - 380W

Series

Gas Cooktops

300

87

F3GK30S1

Gas cooktop 30”, 300 Series, with 4 burners, stainless steel

Ŷ

Electric Flame Ignition and Re-ignition

Ŷ

Flame out sensing

Ŷ

Heavy Duty Cast Iron Grates

Ŷ

Ŷ

Delivered with small Pot Insert

On request: wok ring and simmer Plate

Front Left Burner

Ŷ

Max . 15000 (BTU/h) - 4400W

Ŷ

Min. 1700 (BTU/h) - 500W

Rear Left Burner

Ŷ

Max. 9000 (BTU/h) - 2640W

Ŷ

Min. 1300 (BTU/h) - 380W

Rear Right Burner

Ŷ

Max. 12000 (BTU/h) - 3520W

Ŷ

Min. 1700 (BTU/h) - 500W

Front Right Burner

Ŷ

Max. 6300 (BTU/h) - 1850W

Ŷ

Min. 1300 (BTU/h) -380W

88

Accesories &

Technical Data

Cooktops

Our useful accessories will help you customize your appliances while giving you ease, efficiency and success in your cooking.

Our gas series accessories our guaranteed to enhance your cooking experience, ensuring there is no compromise to your cooking techniques.

COOKTOPS ACCESSORIES 89

300 & 400 GAS SERIES

SMALL POT REDUCTION

Uniquely designed accessory allows you to use pans smaller than 4 inches on a stable, flat cooking surface

WOK RING

For best results with a wok, use this separate, high-BTU burner specifically for wok cooking

SIMMER PLATE

The cast-iron simmer plate provides a steady simmer temperature, evenly distributed across a stable heating surface

90 TECHNICAL DATA 600 SERIES INDUCTION

MODEL

Size

Colour

Heating Technology

Glass Type

Frame

Control type

Special Features

Pan Detection System

Special Big Double zone

Cooling fan system

Control Features

Slide touch control for power setting

"Peacock Tail" Bar for power indication

Digital display for power level indication

Low power scale for delicate cooking

Command Lock

Booster/Fast boil function

Hot Surface indication

Residual heat indication

Acoustic buzzer

Failure Codes indication

Front Left Zone

Size

Power

Booster

Rear Left Zone

Size

Power

Booster

Central Zone (double)

Size

Power

Booster

Rear Right Zone

Size

Power

Booster

Front Right Zone

Size

Power

Booster

Dimensions/Weight - (In or Lbs)

Overall dim - width

Overall dim - height

Overall dim - depth

Cutout - width

Cutout - height (min)

Cutout - depth (min)

Approx ship weight

Power / Ratings (208/240 V, 60 Hz)

KW/Amps rating at 240V, 60Hz

KW/Amps rating at 208V, 60Hz

Cable + Conduit

Instructions for use

Use & Care Manual

Installation Manual

6"

1200W

1400W

8"

2200W

3000W

11" / 7"

2650W/1800W

3600W/2800W

8"

2200W

3000W

6"

1200W

1400W

F6IT36S1

36"

Steel

Induction

Glass Ceramic

Aluminum

Touch Control Peacock High

X

X

X

X

X

X

X

5

X

X

X

1+5

X

X

X

36" (919mm)

3 9/32" (84mm)+ conduit 15/16" (24mm)

21" (538mm)

34 1/16" (865mm) - 34 5/16" (872mm)

3 1/16" (78mm)+ conduit 15/16" (24mm)

19 19/64" (490mm) - 19 5/8" (498mm)

19.4Kg (43 Lbs)

10.800kW - 45Amps

9.700kW - 46,6Amps

X

EN, SP, FR

EN, SP, FR

F6IT30S1

30"

Steel

Induction

Glass Ceramic

Aluminum

Touch Control Peacock High

X

X

X

X

X

X

4

X

X

X

1+4

X

X

X

6"

1200W

1400W

8"

2200W

3000W

7"

1800W

2800W

6"

1200W

1400W

30" (771mm)

3 9/32" (84mm)+ conduit 15/16" (24mm)

21" (538mm)

28 11/16" (729mm) - 28 15/16" (735mm)

3 1/16" (78mm)+ conduit 15/16" (24mm)

19 19/64" (490mm) - 19 5/8" (498mm)

16.2 Kg (36 Lbs)

7.200kW - 30Amps

6510kW - 31,3Amps

X

EN, SP, FR

EN, SP, FR

TECHNICAL DATA 600 SERIES RADIANT 91

MODEL

Size

Colour

Heating technology

F6RT36S1

36"

Steel

Radiant Heaters

Glass Type Glass Ceramic

Frame Aluminum

Touch Control Peacock High Control type

Control Features

Slide touch control for power setting

"Peacock Tail" Bar for power indication

Digital display for power level indication

Low power scale for delicate cooking

Command Lock

X

X

5

X

X

Automatic Fast Boil function

Hot Surface indication

Residual heat indication

X

X

X

1+5

X

X

X

Acoustic buzzer

Failure Codes indication

Front Left Zone

Size

Power

Bridge Element

Power

7"

1800W

800W

Rear Left Zone

Size

Power

Central Zone

Size

Power

Rear Right Zone

Size

Power

Front Right Zone

Size

Power

Dimensions/Weight - (In or Lbs)

Overall dim - width

Overall dim - height

Overall dim - depth

Cutout - width (min-max)

Box - height

Cutout - depth (min-max)

Power / Ratings (208/240 V, 60 Hz)

KW/Amps rating at 240V, 60Hz

KW/Amps rating at 208V, 60Hz

Cable + Conduit

Instructions for use

Use & Care Manual

Installation Manual

7"

1800W

9" / 7" / 5"

2500W / 1600W / 800W

7"

1800W

6"

1200W

36" (919mm)

3 9/32" (84mm)+ conduit 15/16" (24mm)

21" (538mm)

34 1/16" (865mm) - 34 5/16" (872mm)

3 1/16" (78mm)+ conduit 15/16" (24mm)

19 19/64" (490mm) - 19 5/8" (498mm)

9.900kW - 41.25Amps

7.436kW - 35.75Amps

X

EN, SP, FR

EN, SP, FR

F6RT30S1

30"

Steel

Radiant Heaters

Glass Ceramic

Aluminum

Touch Control Peacock High

X

X

X

1+4

X

X

4

X

X

X

X

X

6"

1200W

9" / 7" / 5"

2500W / 1600W / 800W

8" / 5"

2200W / 800W

6"

1200W

30" (771mm)

3 9/32" (84mm)+ conduit 15/16" (24mm)

21" (538mm)

28 11/16" (729mm) - 28 15/16" (735mm)

3 1/16" (78mm)+ conduit 15/16" (24mm)

19 19/64" (490mm) - 19 5/8" (498mm)

7.100kW - 29.58Amps

5.332kW - 25.63Amps

X

EN, SP, FR

EN, SP, FR

F6RT24S1

24"

Steel

Radiant Heaters

Glass Ceramic

Aluminum

Touch Control Peacock Low

NO

NO

X

1

X

X

X

X

3

X

X

X

5"1/2

1200W

8" / 5"

2200W / 800W

7"

1800W

24" (618mm)

3 9/32" (84mm)+ conduit 15/16" (24mm)

21" (538mm)

22 5/8" (574mm) - 22 13/16" (580mm)

3 1/16" (78mm)+ conduit 15/16" (24mm)

19 1/4" (490mm) - 19 9/16" (497mm)

5.200kW - 21.67Amps

3.900kW - 18.75Amps

X

EN, SP, FR

EN, SP, FR

92 TECHNICAL DATA 300 SERIES RADIANT

MODEL

Size

Colour

Heating Technology

Glass Type

Frame

Control type

Control Features

Knobs for power level setting

Knobs type

Hot Surface indication

Residual heat indication

Front Left Zone

Size

Power

Rear Left Zone

Size

Power

Central Zone

Size

Power

Rear Right Zone

Size

Power

Front Right Zone

Size

Power

Dimensions/Weight - (In or Lbs)

Overall dim - width

Overall dim - height

Overall dim - depth

Cutout - width (min-max)

Box - height

Cutout - depth (min-max)

Approx ship weight

Power / Ratings (208/240 V, 60 Hz)

KW/Amps rating at 240V, 60Hz

KW/Amps rating at 208V, 60Hz

Cable + Conduit

Instructions for use

Use & Care Manual

Installation Manual

F3RK36B1

36"

Black

Radiant Heaters

Glass Ceramic

NO

Knobs

5

Plastic MGH "U"

X

X

9" / 6"

2500W / 1100W

6"

1200W

11" / 8"

2700W / 1800W

7"

1800W

6"

1200W

F3RK30B1

30"

Black

Radiant Heaters

Glass Ceramic

NO

Knobs

9" / 6"

2500W / 1100W

6"

1200W

7"

1800W

6"

1200W

F3RK24B1

24"

Black

Radiant Heaters

Glass Ceramic

NO

Knobs

7"

1800W

5 1/2"

1200W

7"

1800W

5 1/2"

1200W

F3RK24S1

24"

Stainless Steel

Radiant Heaters

Glass Ceramic

Aluminium

Knobs

7 3/4" / 4 3/4"

1900W / 800W

5 1/2"

1200W

7"

1800W

5 1/2"

1200W

36" (914mm)

2 3/16" (56mm)

30 1/4" (767mm)

2 3/16" (56mm)

24" (613mm) 24" (618mm)

3 9/32" (84mm)+ conduit 15/16" (24mm) 3 9/32" (84mm)+ conduit 15/16" (24mm)

21" (533mm) 21" (533mm) 21" (533mm)

34 1/16" (865mm) - 34 5/16" (872mm) 28 11/16" (729mm) - 28 15/16" (735mm) 22 5/8" (574mm) - 22 13/16" (580mm)

21" (538mm)

22 5/8" (574mm) - 22 13/16" (580mm)

2" (50,8mm) + conduit 15/16" (24mm)

19 1/4" (490mm) - 19 9/16" (497mm)

17.5 Kg (38.6Lbs)

2" (50,8mm) + conduit 15/16" (24mm)

19 1/4" (490mm) - 19 9/16" (497mm)

13.5 Kg (30Lbs)

3 1/16" (78mm)+ conduit 15/16" (24mm) 3 1/16" (78mm)+ conduit 15/16" (24mm)

19 1/4" (490mm) - 19 9/16" (497mm)

13.5 Kg (30Lbs)

19 1/4" (490mm) - 19 9/16" (497mm)

13.5 Kg (30Lbs)

9.400kW - 39.17Amps

7.060kW - 33.94Amps

X

EN, SP, FR

EN, SP, FR

4

Plastic MGH "U"

X

X

6.700kW - 27.9Amps

5.032kW - 24.19Amps

X

EN, SP, FR

EN, SP, FR

4

Plastic MGH "U"

X

X

6.000kW - 25.00Amps

4.507kW - 21.67Amps

X

EN, SP, FR

EN, SP, FR

4

Plastic MGH "U"

X

X

6.100kW - 25.42Amps

4.582kW - 22.03Amps

X

EN, SP, FR

EN, SP, FR

TECHNICAL DATA 400 SERIES GAS 93

MODEL

Size

Colour

Heating Technology

Gas Type

L.P. Conversion Kit

Top Mount Injectors

Knobs

Cooktop Features

Design

Electric Flame Ignition and

Power (Min)

Burner 3

Power (Max)

Power (Min)

Burner 4

Power (Max)

Power (Min)

Burner 5

Power (Max)

Power (Min)

Burner 6

Power (Max)

Power (Min)

Flame out sensing

Dual Crown Burner

Simmer Plate

Small Pot Insert

Wok Ring

Heavy Duty Cast Iron Grates

Number of Burners

Burner 1

Power (Max)

Power (Min)

Burner 2

Power (Max)

Dimensions/Weight - (In or Lbs)

Overall dim - width

Overall dim - height

Overall dim - depth

Cutout - width (min-max)

Cutout - height

Cutout - depth (min-max)

Power / Ratings

Electrical rating

Max Power (BTU/HR)

Cable

Instructions for use

Use & Care Manual

Installation Manual

F4GK42S1

42"

Stainless Steel

Gas

NG or LP

X

X

Plastic MGH "U" - Frontal

Largo

X

X

X

Optional

Optional (for single burners only)

Optional (for dual burner only)

4

4

Left Burner

18000 (BTU/h) - 5275W

450 (BTU/h) - 135W

Left Middle Burner

4000 (BTU/h) - 1175W

1000 (BTU/h) - 295W

Right Middle Burner

9000 (BTU/h) - 2640W

1300 (BTU/h) - 380W

Right Burner

15000 (BTU/h) - 4400W

2700 (BTU/h) - 790W

1119mm

74mm

425mm

1096mm-1099mm

T.B.D.

404,5mm - 407,5mm

120V, 60Hz

46000 (BTU/h) - 13475W

X

EN, SP, FR

EN, SP, FR

F4GK36S1

36"

Stainless Steel

Gas

NG or LP

X

X

Plastic MGH "U" - Frontal

Largo

X

X

X

Optional

Optional (for single burners only)

Optional (for dual burner only)

3

5

Front Left Burner

6300 (BTU/h) - 1850W

1300 (BTU/h) -380W

Rear Left Burner

9000 (BTU/h) - 2640W

1300 (BTU/h) - 380W

Front Middle Burner

18000 (BTU/h) - 5275W

450 (BTU/h) - 135W

Rear Middle Burner

F4GK30S1

30"

Stainless Steel

Gas

NG or LP

X

X

Plastic MGH "U" - Frontal

Largo

X

X

X

Optional

Optional (for single burners only)

Optional (for dual burner only)

2

5

Front Left Burner

18000 (BTU/h) - 5275W

450 (BTU/h) - 135W

Rear Left Burner

Rear Right Burner

12000 (BTU/h) - 3520W

2200 (BTU/h) - 645W

Front Right Burner

4000 (BTU/h) - 1175W

1000 (BTU/h) - 295W

909mm

74mm

510mm

886mm - 889mm

T.B.D.

489,5mm - 492,5mm

120V, 60Hz

52300 (BTU/h) - 15320W

X

EN, SP, FR

EN, SP, FR

Front Middle Burner

4000 (BTU/h) - 1175W

1000 (BTU/h) - 295W

Rear Middle Burner

12000 (BTU/h) - 3520W

2200 (BTU/h) - 645W

Rear Right Burner

9000 (BTU/h) - 2640W

1300 (BTU/h) - 380W

Front Right Burner

6300 (BTU/h) - 1850W

1300 (BTU/h) -380W

760mm

74mm

510mm

737mm - 740mm

T.B.D.

489,5mm - 492,5mm

120V, 60Hz

49300 (BTU/h) - 14440W

X

EN, SP, FR

EN, SP, FR

F4GK24S1

24"

Stainless Steel

Gas

NG or LP

X

X

Plastic MGH "U" - Frontal

Largo

X

X

X

Optional

Optional (for single burners only)

Not available

4

4

Front Left Burner

18000 (BTU/h) - 5275W

450 (BTU/h) - 135W

Rear Left Burner

6300 (BTU/h) - 1850W

1300 (BTU/h) -380W

Front Middle Burner

Rear Middle Burner

Rear Right Burner

12000 (BTU/h) - 3520W

2200 (BTU/h) - 645W

Front Right Burner

4000 (BTU/h) - 1175W

1000 (BTU/h) - 295W

620mm

74mm

510mm

597mm-600mm

T.B.D.

489,5mm - 492,5mm

120V, 60Hz

40300 (BTU/h) - 11800W

X

EN, SP, FR

EN, SP, FR

94 TECHNICAL DATA 300 SERIES GAS

MODEL

Size

Colour

Heating Technology

Gas Type

L.P. Conversion Kit

Top Mount Injectors

Knobs

Cooktop Features

Design

Electric Flame Ignition and

Power (Min)

Burner 3

Power (Max)

Power (Min)

Burner 4

Power (Max)

Power (Min)

Burner 5

Power (Max)

Power (Min)

Burner 6

Power (Max)

Power (Min)

Flame out sensing

Dual Crown Burner

Simmer Plate

Small Pot Insert

Wok Ring

Heavy Duty Cast Iron Grates

Number of Burners

Burner 1

Power (Max)

Power (Min)

Burner 2

Power (Max)

Dimensions/Weight - (In or Lbs)

Overall dim - width

Overall dim - height

Overall dim - depth

Cutout - width (min-max)

Cutout - height

Cutout - depth (min-max)

Power / Ratings

Electrical rating

Max Power (BTU/HR)

Cable

Instructions for use

Use & Care Manual

Installation Manual

F3GK36S1

36"

Stainless Steel

Gas

NG or LP

X

X

Plastic MGH "U" - Lateral

Lateral Wing

X

X

X

Optional

X

Optional

3

5

Front Left Burner

4000 (BTU/h) - 1175W

1000 (BTU/h) - 295W

Rear Left Burner

15000 (BTU/h) - 4400W

1700 (BTU/h) - 500W

Central Burner

18000 (BTU/h) - 5275W

450 (BTU/h) - 135W

Rear Right Burner

9000 (BTU/h) - 2640W

1300 (BTU/h) - 380W

Front Right Burner

9000 (BTU/h) - 2640W

1300 (BTU/h) - 380W

36" (915mm)

3 1/8" (80mm)

21" (533mm)

34 1/2" (876mm) - 35" (889mm)

5 1/4" (134mm)

19" (483mm) - 19 5/8" (498mm)

120V, 60Hz

55000 (BTU/h) - 16110W

X

EN, SP, FR

EN, SP, FR

F3GK30S1

30"

Stainless Steel

Gas

NG or LP

X

X

Plastic MGH "U" - Lateral

Lateral Wing

X

X

Optional

X

Optional

2

4

Front Left Burner

15000 (BTU/h) - 4400W

1700 (BTU/h) - 500W

Rear Left Burner

9000 (BTU/h) - 2640W

1300 (BTU/h) - 380W

Central Burner

Rear Right Burner

12000 (BTU/h) - 3520W

1700 (BTU/h) - 500W

Front Right Burner

6300 (BTU/h) - 1850W

1300 (BTU/h) -380W

30" (762mm)

3 1/8" (80mm)

21" (533mm)

28 1/2" (724mm) - 29" (737mm)

5 1/4" (134mm)

19" (483mm) - 19 5/8" (498mm)

120V, 60Hz

42300 (BTU/h) - 12390W

X

EN, SP, FR

EN, SP, FR

Meneghetti S.p.a. reserves the right to make updates to the information and products or discontinue models contained in this catalogue without notice

catalogue coordinators

Marketing Fulgor

lay-out, 3d graphics and colour separation

Studio Grafico NOA

Catalogue Fulgor Milano USA - Nr. 002/2013 copyright ©

Registered Trade Mark of Meneghetti

Meneghetti S.p.a.

Via Borgo Lunardon, 8

36027 Rosà ( Vicenza) - I taly

http://w w w.fulgor-milano.us e -mail:[email protected]

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
