NAUTIZ X7
Quick Start Guide
1 Identifying Components
Left to right:
Mobile Phone Indicator
RF (Radio Frequency) Indicator
Charge/Notification Indicator
Earpiece
Touch
Screen
Keypad
Power
Button
Microphone
SD Card Slot Cover
1 Identifying Components
Hand Strap
Holder
Camera
Lens
Flash
Speaker
Stylus
Battery
Cover
Hand
Strap
Holder
Power
Connector
Mini-USB Connector
Serial
Connector
Docking Connector
2 Getting Your Device Ready for Use
Installing the SIM Card and Battery
1.
Lift the latch handle of the battery cover
and turn it counterclockwise to the
unlock (vertical) position. Then, detach
the cover from the device.
2.
If you model has the phone function,
you need to install the SIM card
provided by your mobile operator. With
the SIM card’s chip side facing up and
the beveled corner pointing to the slot,
insert the card all the way into the slot.
NOTE: To remove the SIM card,
slightly push in the card to release it
and then pull the card out of the slot.
3.
4.
To install the battery, attach the bottom
side of the battery to the compartment
at an angle and then lower the upper
side to engage the connector.
Attach the bottom side of the battery
cover to the device at an angle and
then, with the handle still in the unlock
(vertical) position, fit the latch handle
into place. Secure the latch by turning
it clockwise to the lock (horizontal)
position.
3 Getting Your Device Ready for Use
Connecting to AC Power and Charging the Battery
Be sure to fully charge the battery before using your device for the
first time.
1.
Plug the DC cord of the AC
adapter into the power
connector of the device ( 1 ).
2.
Plug the female end of the
AC power cord into the AC
adapter and the male end into
an electrical outlet ( 2 ).
3.
The charge indicator glows
in amber when charging is in
progress. Do not disconnect
your device from AC power
until the battery is fully
charged, as indicated by the
amber indicator turning into
green. This will take a couple
of hours.
2
1
4 Getting Your Device Ready for Use
Performing the Initial Startup
When turning on your device for the very first time, you will be guided
through a setup process.
1.
Make sure that your device is either connected to AC power or
the battery has power.
2.
Press the power button to turn on your device. The backlight
of the keypad will light up and, after a few seconds, the setup
screen appears.
3.
Follow the on-screen instructions to complete the setup wizard.
4.
For models with the phone function only:
If a SIM card has been inserted and the mobile phone network
operator (or you) has set the PIN, you will be prompted to enter
the PIN. Enter the PIN and tap Enter. If a SIM card has not been
inserted yet, a message of an invalid or missing SIM card
will appear on the screen. You can tap Cancel to continue the
startup procedure.
5.
After the setup is completed, the Today screen appears. You can
now use your device.
5 Operating Basics
Entering the Suspend Mode
Your device automatically suspends after a period of inactivity (default 3 minutes
while on battery power and 5 minutes while on external power).
To manually suspend the device, briefly press the power button.
To resume operation, press the power button. You will be back to where you left off.
Turning Off
If you are not using your device, press and hold the power button for at least 3
seconds until the device plays a notification sound and turns off.
Using the Stylus
Use the stylus to navigate and select objects on the screen.
Pull the stylus out of the slot and extend it for ease
of use. Store it in the slot when not in use.
•
Tap
Touch the screen once with the
stylus to open items and select
options.
•
Drag
Hold the stylus on the screen and
drag across the screen to select
text and images. Drag in a list
to select multiple items.
•
Tap and hold
Tap and hold the stylus on an item
to see a list of actions available
for that item. On the shortcut menu
that appears, tap the action you
want to perform.
6 Operating Basics
Using the Keypad
2
3
4
5
3
6
7
8
1
1
9
Use the numeric keys to enter numbers (majorly for models with
the phone function).
When Fn lock is on (
), you can use the alternative functions.
Moves up, down, left and right within the
screen or menu.
Goes to the next input field.
Backspaces over one character when in a
text input field.
Enters the symbols when in an input field.
Increases the brightness level of the screen.
2
Dials or answers a call (select models only).
7 Operating Basics
Using the Keypad
3
Use the left of right soft key to perform the command shown on
the bottom left or right corner of the screen.
4
Use the Fn key to switch on or off the “alternative functions” of
the numeric keys.
5
Use the Camera key to start the Camera program and to take a
picture.
6
Use the End key to end or reject a call (select models only).
Use the End key to return to the Today screen from another
program.
7
8
9
Use the Start key to open the Start menu.
Use the OK key to close the current displayed menu or program.
Use the Action key to confirm your selection.
8 Operating Basics
Running Programs
You can switch from one program to another without closing any program.
•
To run a program, tap
on the left-top corner of the screen and select from
the Start menu.
•
To access additional programs, tap
Programs and tap the program
icon.
9 Using the Phone
(Select Models Only)
Switching On or Off the Phone
When the device is turned on, the phone is
switched on by default. When needed (for
example, on an airplane), you can switch off
the phone without turning off your device.
1.
Tap the Wireless Manager section on the
Today screen.
- or Tap the connectivity indicator on the
navigationbar and tap Wireless Manager.
2.
The Wireless Manager screen appears.
Tap Phone to switch it from on to off or
the other way around. Tap Done.
9 Using the Phone
(Select Models Only)
Starting the Phone Program
Start the Phone program by any of the three
methods:
•
Press the Send key on the device.
•
Tap Phone (left soft key) on the
Today screen.
Phone.
•
Tap
Dialing a Phone Number
1.
When on the Today screen: Press the
numeric keys on your device to start
entering the phone number. Your device
will automatically switch to the Phone
program.
While in the Phone program: Enter
the phone number using the physical or
on-screen keypad.
2.
As you enter the phone number, the program searches Contacts, Call History,
and Speed Dial to find a matching name and/or number. When you see the
name of the person to call listed, select it and the desired phone number. Or,
you can continue entering the complete phone number.
3.
Press the Send key on your device to make the call.
Answering a Call
To answer an incoming call, press the Send key on your device or tap Answer
(left soft key).
Ending a Call
To end a call, press the End key on your device or tap End on the screen.
More information
For complete information, please refer to the User Manual (in PDF format) supplied
on the disc.
