www.geotestinc.com
Get A Head Start With Geotest
In every stage of test-system development—from specification to implementation—you can
create opportunities to gain speed and shorten the development cycle. At Geotest, we help
you build better solutions faster by putting hands-on integration experience into every one
of our hardware, software and system products.
We also do more to get you closer to a fully functional test system—from delivering a
configured and tested PXI system to providing responsive support throughout your project.
Whether you need test-and-measurement hardware, application-development software,
integration services, or turnkey systems, Geotest can provide you a head start on the road
to a successful solution.
Since 1988, we’ve provided our customers a head start in thousands of military, aerospace,
semiconductor, communications, medical and industrial applications. Based in Irvine, Calif.,
our ISO-9001-certified facility houses an experienced team that distinguishes itself every
day through a deep commitment to customer service.
Product Line
This short form catalog provides an overview of our PXI, PXI Express, and software
products. Our complete product line includes:
• A family of PXI products including 20-slot 3U and 6U chassis, a 3U/6U combo
chassis, digital I/O, switching, instrumentation, and many other analog and
digital test products
• High-Speed Digital Test Instruments with test rates up to 200 MHz, 512 MB of
on-board memory and with a variety of I/O options including TTL, LVDS, ECL,
PECL, and programmable levels
• Test Development and Test Executive Software
• Instrument Controllers & Computers
• DMMs, Counters, DSOs, and other instrumentation
• Switching Modules including multiplexers, matrices, high-current, and
RF switching configurations
• Arbitrary, Function, and Pulse Generators
• CoreATE Reconfigurable Test Systems
• Avionics Support Instruments
GEOTEST
PXI CATALOG
Contents
Chassis
3U
GX7300 GX7310
GX7302
GX7312
GX7600
GX7610
6U
GX7000A
GX7010A
GX7002A GX7012A GX7100A
GX7110A
GX7111A
GX7102A
GX7112A
PXI Smart Chassis..........................................................................................................................Page
PXI Smart Slave Chassis...…...........................................................................................................Page
PXI Smart Chassis with hinged front panel for mass interconnect applications................................Page
PXI Smart Slave Chassis with hinged front panel for mass interconnect applications......................Page
PXI Express Smart Chassis ...............................................................................................................Page
PXI Express Smart Slave Chassis with hinged front panel for mass interconnect applications........Page
3
3
3
3
3
3
6U PXI Smart Chassis..........................................................................................................................Page
6U PXI Smart Slave Chassis...…...........................................................................................................Page
6U PXI Smart Chassis with integrated cable tray and hinged front panel.................................................Page
6U PXI Smart Slave Chassis with integrated cable tray and hinged front panel...................................Page
3U/6U Combination PXI Smart Chassis….....……………………..…………….………………….………Page
3U/6U Combination PXI Smart Slave Chassis…….…………………………………………………........Page
3U/6U Combination PXI Smart Slave Chassis with recessed card cage..................................…...….Page
3U/6U Combination PXI Smart Chassis with integrated cable tray and hinged front panel.................Page
3U/6U Combination PXI Smart Slave Chassis with integrated cable tray and hinged front panel.......Page
4
4
4
4
4
4
4
4
4
Controllers
3U
GX7930
GX7932/GX7934
GX7940
GX7990
MXI-4 MXI-Express 6U
GX7910 GX7920 Series
GX7922/GX7924
3U
3U
3U
3U
3U
3U
3U
Pentium® M Controllers.........................................................................................................................Page
CoreTM Duo & CoreTM 2 Duo Controllers ............................................................................................... Page
Pentium® M PXI Express Controllers....................................................................................................Page
PXI Bus Expander ...............................................................................................................................Page
PXI Bus Expander ...............................................................................................................................Page
PXI Express Bus Expander...................................................................................................................Page
4
4
4
4
4
4
Pentium® Controllers.............................................................................................................................Page
Celeron® Controller...............................................................................................................................Page
Pentium® M Controllers.........................................................................................................................Page
CoreTM Duo & CoreTM 2 Duo Controllers ............................................................................................... Page
6
6
6
6
Digital I/O
GX5292
GX5292e
GX5293 GX5641 GX5642 GX5733
GX5281
GX5282
GX5283
High Performance Dynamic Digital I/O, 100 MHz data rate.................................................................Page
High Performance PXI Express Dynamic Digital I/O, 100 MHz data rate ............................................Page
High Performance Dynamic Digital I/O, 200 MHz data rate .................................................................Page
Bi-Directional Differential RS422-TTL I/O.............................................................................................Page
Bi-Directional Differential LVDS-TTL I/O...............................................................................................Page
128 Channel Digital I/O Card................................................................................................................Page
High Speed Dynamic Digital I/O, 50 MHz data rate.............................................................................Page
High Speed Dynamic Digital I/O, 100 MHz data rate...........................................................................Page
High Speed Dynamic Digital I/O, 200 MHz data rate...........................................................................Page
7
7
7
8
8
8
8
8
8
GX5050 High Speed Dynamic Digital I/O...........................................................................................................Page
GX5055 High Performance Dynamic Digital I/O.................................................................................................Page
GX5910 TTL I/O Module.....................................................................................................................................Page
GX5930 Programmable Level I/O Module...........................................................................................................Page
GX5940 PECL I/O Module..................................................................................................................................Page
GX5960 LVDS I/O Module..................................................................................................................................Page
GX5150/GX5151High Speed Digital I/O..........................................................................................................................Page
GX5152/GX5153 Digital Stimulus / Response Instrument...............................................................................................Page
GX5731 224 Channel Digital I/O Card...............................................................................................................Page
GX5701 32 Channel Digital Input Latch Module...………………….……..............................................…………Page
GX5702 32 Channel Digital Output Latch Module..…………………………………………………………………..Page
GX5703 32 Channel LVDS Digital Input Latch Module.....……..……………………………………………..……..Page
GX5704 32 Channel Digital Power Output Latch Module...................................................................................Page
GX5705 32 Channel RS-232 I/O Module………………………………………………………………………………Page
GX5709 32 Channel RS-422 I/O Module………..…………………………………………………………………….Page
GX5710 32 Channel LVDS I/O Module………………………………………………………………………………...Page
GX5711 16 Channel LVDS to TTL Bi-Directional Converter Module………….…………………………………....Page
GX5712 16 Channel RS-422 to TTL Bi-Directional Converter Module..……………………………………...……Page
GX5732 224 Channel TTL Digital I/O Card........……..……...............……………………………………...............Page
9
9
9
9
9
9
9
10
10
10
10
10
10
10
10
10
10
10
10
6U
Toll Free: 888.837.8297
•
Phone: 949-263-2222
•
Fax: 949-263-1203
•
email: [email protected]
•
www.geotestinc.com
Contents
3U
GX2472
GX1034
SMX2040
SMX2042 SMX2044 SMX2060 SMX2064 GTX2210 GTX2220
GTX2230 GX2002
GX1648
GX1110
GX1200 GX1201
GX1838 GX1838-20 GX1222 GX1164
GX1164-2 GX1164-4
GX1164-8
GX7404 3U
GX6115
GX6125
GX6138
GX6021
GX6377
GX6384
GX6384-2
SMX4032
6U
2
Analog
Dual Channel 70 MS/s Digitizer................................................................................................................Page 11
Standards Module ....................................................................................................................................... Page 11
61/2 Digit Multimeter....................................................................................................................................Page 11
61/2 Digit Multimeter with enhanced measurement functions..................................................................Page 11
61/2 Digit Sourcing Multimeter with enhanced measurement functions..................................................Page 11
71/2 Digit Multimeter....................................................................................................................................Page 11
71/2 Digit Multimeter with enhanced measurement functions..................................................................Page 11
225 MHz Universal Time Interval Counter.................................................................................................Page 12
1.3 GHz Universal Time Interval Counter..................................................................................................Page 12
2 GHz Universal Time Interval Counter.....................................................................................................Page 12
RF Power Analyzer......................................................................................................................................Page 12
64 Channel, Analog Output Board.............................................................................................................Page 12
100 MS/sec Arbitrary Waveform Function Generator ...............................................................................Page 13
50 MS/sec Arbitrary Waveform Generator ................................................................................................Page 13
100 MS/sec Arbitrary Waveform Generator ..............................................................................................Page 13
Precision Multi-Channel DC Source (-10V to +32V).................................................................................Page 13
Precision Multi-Channel DC Source (-20V to +20V).................................................................................Page 13
Wideband Amplifier......................................................................................................................................Page 14
Programmable Resistor Card, 1 Ω to 64K Ω.............................................................................................Page 14
Programmable Resistor Card, 2 Ω to 128K Ω...........................................................................................Page 14
Programmable Resistor Card, 4 Ω to 256K Ω...........................................................................................Page 14
Programmable Resistor Card, 8 Ω to 512K Ω...........................................................................................Page 14
Power Interface & Prototype Board............................................................................................................Page 14
Switching
High Current Relay Card ............................................................................................................................Page 15
General Purpose Switching Card..............................................................................................................Page 15
High Density Switching Card.....................................................................................................................Page 15
20-Channel RF Multiplexor........................................................................................................................Page 15
Multi-Function Relay Card..........................................................................................................................Page 16
Configurable, High Density Switch Matrix, 128 cross-points...................................................................Page 16
Configurable, High Density Switch Matrix, 256 cross-points...................................................................Page 16
Low Thermal EMF Switching Card............................................................................................................Page 16
GX6062
GX6264I/C
GX6315
GX6325
GX6338
GX6616
RF Switching Card.......................................................................................................................................Page 17
PXI Scanner / Multiplexer Card..................................................................................................................Page 17
High Current Relay Card.............................................................................................................................Page 17
General Purpose Switching Card...............................................................................................................Page 18
High Density Switching Card......................................................................................................................Page 18
High Density Switch Matrix.........................................................................................................................Page 18
NX5000 NX5000-3U NX5300 6U ROM Emulator ………………………………………….……………………………....……………….Page 19
3U ROM Emulator ….......…………………………………………………………………....……………….Page 19
3U JTAG / CPU Board Test Mudule ..........………………………………………………....……………….Page 19
GX7400A
GX7415A
GX7430A GX7460A Dual Output Power Supply..........................................................................................................................Page 19
0-15 V Programmable Power Supply Module........................................................................................Page 19
0-30 V Programmable Power Supply Module...................................................................………………..Page 19
0-60 V Programmable Power Supply Module……….......................................................................……..Page 19
DIOEasy
ATEasy
Digital I/O Vector Development Software...................................................................................................Page 20
Test Executive & Development Software...................................................................................................Page 21
Emulators & JTAG / CPU Interfaces
User Power
Software
GEOTEST
PXI CATALOG
3U Chassis
GX7300
20-slot PXI Smart CHASSIS
•20 slots supporting a 3U PXI controller (embedded
or remote) and 19 3U PXI or cPCI instruments
•Built-in peripherals (hard disk drive, floppy disk drive, and
a DVD-RW drive) for embedded controller configurations
•Industry-leading 1100W of system power
•Innovative forced-air cooling configuration provides
excellent thermal management in a compact, 4U
package
•Integral Smart functions provide per-slot temperature
monitoring, system power supply monitoring, and PXI
trigger mapping
The GX7300 Series mainframes are 20-slot PXI chassis
that can accommodate up to 19 instruments and a PXI
controller (an embedded CPU or a PXI bus expander
interface such as the GX7990 or MXI-4). The 3U formfactor delivers a compact test system foot print and
provides users with the flexibility to employ both PXI
and CompactPCI 3U modules. The GX7300 series is
available in multiple models, including a slave chassis
(GX7310) and chassis with a hinged front panel for mass
interconnect applications (GX7302 & GX7312).
GX7310
GX7302
GX7312
3U, 20-Slot Smart PXI
Slave Chassis
GX7300 with a hinged
front panel for mass
interconnect applications
GX7310 with a hinged
front panel for mass
interconnect applications
GX7300
20-Slot PXI Smart Chassis
GX7302-MP
GX7310 with a MAC Panel SCOUT receiver
GX7600
9-Slot PXI Express SMART CHASSIS
• Supports a 3U (embedded or remote) PXI Express
controller, 2 PXI Express hybrid slots, 5 PXI slots,
and a PXI Express system timing slot
• Built-in peripherals (hard disk drive, and a DVD-RW
drive) for embedded controller configurations
• Compact footprint is ideal for bench top or portable
applications
• Integral Smart functions provide per slot temperature
monitoring and system power supply voltage
monitoring
• 560 W power supply
The GX7600 Series mainframes are compact, 9-slot PXI
chassis that can accommodate up to 8 instruments as
well as an embedded single slot PXI Express controller
such as the GX7940 or a PXI Express external bus
controller such as the x1 or x4 MXI - PXI Express
interface. The GX7600’s compact 3U form-factor
occupies only 9x18 inches of bench space, making it
ideal for benchtop or space constrained applications.
And when combined with 8 peripheral slots, integral
Smart functions, and the bandwidth of PXI Express,
the GX7600 represents a new level of performance,
capabilities and value for PXI mainframes.
GX7600
9-Slot PXI Express Smart Chassis
GX7610
9-Slot, Smart PXI
Express Slave Chassis
Toll Free: 888.837.8297
•
Phone: 949-263-2222
•
Fax: 949-263-1203
•
email: [email protected]
•
www.geotestinc.com
3
6U Chassis
GX7000A
6U PXI Smart CHASSIS
•20 slots supporting an embedded or remote PXI
controller and 19 PXI or cPCI instruments (3U or 6U)
•Built-in peripherals (hard disk drive, floppy disk drive, and
a CD-RW drive) for embedded controller configurations
•Integral Smart functions provide per-slot temperature
monitoring, system power supply monitoring, and PXI
trigger mapping
•800W system power supply (1100W optional)
•Integral cable tray, recessed instrumentation, cable
routing openings on top and bottom, and hinged front
panel configurations
•UUT interfacing options
The GX70xxA Series features a high-performance, 20-slot
PXI chassis that can accommodate up to 19 instruments
as well as a PXI controller (an embedded CPU or a PXI
bus expander interface such as the GX7990 or MXI-4).
The 6U form factor provides the necessary real estate
to accommodate high-performance and high-density test
instrumentation, while offering the flexibility to use 3U PXI
and cPCI instruments as well. The GX7000A’s Smart
features support the monitoring of slot temperatures and
system power supply voltages as well as providing the
ability to program or map each PXI trigger line from one
PCI segment to another.
GX7002A
GX7010A
GX7012A
GX7002-MP
GX7000AR with an
integrated cable tray
and a hinged front panel
for mass interconnect
applications (rack-mount
configuration)
6U, 20-Slot PXI chassis
for use with the GX7990
PXI Bus Expander
GX7010AR with an
integrated cable tray
and a hinged front panel
for mass interconnect
applications (rack-mount
configuration)
GX7010AR with MAC Panel SCOUT receiver
GX7100A
3U/6U COMBINATION PXI SMART CHASSIS
4
•Slots for one embedded or remote PXI controller, six
6U or 3U instruments, and seven 3U instruments
•Compatible with PXI/cPCI
•560-watt system power supply
•Built-in peripherals (hard disk drive, floppy disk drive, and
a CD-RW drive)for embedded controller configurations
•Integral Smart functions provides internal temperature
monitoring, system power supply monitoring, and PXI
trigger mapping
•Integral cable tray, recessed card cage, and hinged
front panel configurations
The GX710xA Series features a 14-slot combination PXI
chassis that accommodates 3U and 6U PXI controllers
and instruments in 4U of rack space. The GX710xA’s
unique format includes seven 3U only slots and seven
3U/6U slots arranged horizontally to reduce the overall
size of the chassis, providing the versatility and high
density necessary to address many PXI applications
and requirements. The GX7100A’s Smart features
support the monitoring of slot temperatures and system
power supply voltages as well as providing the ability
to program or map each PXI trigger line from one PCI
segment to another.
GX7102A
GX7110A
GX7111A
GX7112A
GX7100AR with an
integrated cable tray
and a hinged front panel
for mass interconnect
applications (rack-mount
configuration)
3U/6U, 14-slot PXI chassis
for use with the GX7990
PXI Bus Expander
PXI Slave Combo
Chassis with a 2"
recessed instrument
card cage
GX7111AR with an
integrated cable tray
and a hinged front panel
for mass interconnect
applications (rack-mount
configuration)
GEOTEST
PXI CATALOG
3U Controllers
GX7930
Pentium® M PXI CONTROLLERS
•3U embedded PXI controllers for use with GX7300
Series PXI chassis
•Intel Pentium® M Processor, 1.4 and 1.8 GHz
versions
•512 MB RAM standard, 1 GB RAM Max.
•On-board high performance 855GME graphics
accelerator
•On-board Gigabit Ethernet
•USB and COM ports
The GX7930 is a single-slot embedded PXI 3U controller
for use with Geotest’s GX7300 PXI chassis. The GX7930
is available with various CPUs and memory configurations
and supports a broad range of peripherals. When combined with the embedded storage peripherals of the
GX7300 Series chassis, it is the ideal solution for an
integrated PXI chassis/controller configuration.
GX7932 / GX7934
3U CORETM DUO & CORETM 2 DUO PXI CONTROLLERs
•3U embedded PXI controllers for use with GX7300
Series PXI chassis
•Intel Core Duo 1.66 GHz processor
• Intel Core 2 Duo 1.5 GHz processor
• 1 GB RAM standard, expandable to 4 GB RAM
•On-board high performance Intel 945GM graphics
accelerator
•On-board Gigabit Ethernet
•USB and COM ports
The GX7932 snf GC7934 are single-slot embedded
PXI 3U controllers for use with Geotest’s GX7300 PXI
chassis. The GX7932 features a 1.66 GHz Core Duo
processor. The GX7934 features a 1.5 GHz Core 2 Duo
processor. Both are available with up to 4 GB of RAM.
When combined with the embedded storage peripherals
of the GX7300 Series chassis, they are the ideal solution
for an integrated, high performance PXI chassis /
controller configuration.
GX7940
Pentium® M PXI Express CONTROLLERS
•3U embedded PXI Express controllers for use with
GX7600 Series PXI Express chassis
•Intel Pentium® M Processor, 1.4 and 2.0 GHz versions
• 1 GB RAM standard, 2 GB RAM Max.
•Intel 915GM graphics and memory controller
•On-board Gigabit Ethernet
•USB ports
•4 x1 PCI Express bus configuration
The GX7940 is a single-slot embedded PXI Express 3U
controller for use with Geotest’s GX7600 PXI Express
chassis. The GX7940 is available with various CPU and
memory configurations and supports a broad range of
peripherals. When combined with the embedded storage
peripherals of the GX7600 Series chassis, it is the ideal
solution for a compact, high performance, and integrated
PXI Express chassis / controller configuration.
GX7990, MXI & MXI-Express
PXI BUS EXPANDERS
•PCI to PXI or PXI to PXI interface
•Up to 132 MB/sec peak transfer rates
•Supports 32 and 64-bit configurations
•Available with a range of cables (copper and fiber)
Toll Free: 888.837.8297
•
The GX7990 & MXI-4 PXI bus expanders allow direct
control of any PXI chassis from a desktop computer or
from another chassis. The GX7990 and MXI-4 provide
transparent hardware and software interfacing to the
PXI bus using PCI bridge technology.
Phone: 949-263-2222
•
Fax: 949-263-1203
•
email: [email protected]
•
www.geotestinc.com
5
6U Controllers
GX7910
PENTIUM® PXI CONTROLLERS
•6U embedded PXI controllers for use with GX7000A
Series or GX7100A Series PXI chassis
•Intel Pentium® 4 Processor, 1.7 GHz and 2.2 GHz
•512 MB RAM standard, 1.5 GB Max.
•On-board, high-performance AGP SVGA controller
•On-board Gigabit Ethernet
•One PMC slot for added I/O options such as GPIB
•Optional Flash Disk
The GX7910 is a single-slot PXI 6U controller for use
with Geotest’s GX7100A PXI combo chassis and
GX7000A PXI chassis. The GX7910 is available in
multiple CPU and memory configurations and with a
full range of peripheral options. When combined with
the embedded storage peripherals of the GX7000A
Series and GX7100A Series chassis, it offers the ideal
system controller solution.
GX7920 Series
CELERON® PXI CONTROLLER
•6U cPCI/PXI controller for use with the GX7000A
and GX7100A series PXI chassis
•Cost-effective, Low Power Celeron® (no cache) 600
MHz processor
•Scalable memory size up to 2 GB PC333 SDRAM
•2x GbE and 2x USB interfaces on FP, 2 USB ports
on rear I/O
•PMC slot with front panel access
The GX7920-06512 provides a cost-effective solution as
a PXI controller for the GX7000A and GX7100A series
PXI chassis. The single-slot controller provides a fully
integrated controller solution—supporting all integrated
chassis peripherals (hard drive, DVD, floppy, etc.), as
well as providing a variety of I/O interfaces including USB,
Gigabit Ethernet, and RS-232. Additional flexibility is
provided by the front panel accessible PMC slot, which
can accommodate a variety of interfaces and functions
for specific applications or needs.
PENTIUM® M PXI CONTROLLERS
•6U cPCI/PXI controllers for use with GX7000A and
GX7100A Series PXI chassis
•Low-power version: Intel Pentium® M LV processor
(1.4 GHz) – GX7920-141024
•High-performance version: Intel Pentium M processor
(1.8 GHz) – GX7920-181024
•4 Gigabit Ethernet ports (2 front, 2 rear I/O)
•4 USB ports (2 front, 2 rear)
•1 GB of DDR SDRAM (expandable to 2 GB)
•IPMI V1.5 compliant
•PCI-X PMC site
•PICMG 2.0 Rev 3.0 compatible 32 bit/33 MHz
Combining the low-power/high-performance features of
Intel’s Mobile Pentium® M processor with the 855GME
chipset, the GX7920 CompactPCI system controller
offers a high-performance, single-slot, PXI controller
solution. When installed in a GX7000 or GX7100 chassis,
the controller provides an integrated, high-performance,
single-slot, PXI controller solution—supporting all
integrated chassis peripherals (hard drive, DVD, etc.)
and providing a variety of I/O interfaces including USB,
Gigabit Ethernet, and RS-232. Additional flexibility
is provided by the front-panel-accessible PMC slot,
which can accommodate a variety of interfaces and
functions for specific applications or needs.
GX7922 / GX7924
6U CORETM DUO & corETM 2 duo Controllers
• 6U cPCI/PXI controllers for use with GX7000A and
GX7100A Series PXI chassis
• Intel Core Duo 2.0 GHz processor (GX7922)
• Intel Core 2 Duo 2.16 GHz processor (GX79242)
• 3 Gigabit Ethernet ports (2 front, 1 rear I/O)
• 3 USB ports (2 front, 1 rear)
• 1 GB of DDR SDRAM (expandable to 4 GB)
• IPMI V1.5 compliant
• 64-bit / 66 MHz PMC slot
• PICMG 2.0 Rev 3.0 compatiblek
6
The GX7922 and GX7924 offer increased performance
compared to previous generation processors with no
increase in power consumption. When installed in
a GX7000A or GX7100A chassis, these controllers
provide an integrated, high performance, single slot,
PXI controller solution – supporting all integrated
chassis peripherals (hard drive, DVD, etc.) and
providing a variety of I/O interfaces including USB,
Gigabit Ethernet, and RS232.
GEOTEST
PXI CATALOG
3U Digital I/O
GX5293
3U PXI HIGH SPEED DYNAMIC DIGITAL I/O CARD
• 16 input / output channels, dynamically
configurable on a per channel basis
• 256 MB of on-board vector memory
• Supports 1.5 V, 1.8 V, 2.5 V, 3.3 V, and 5 V TTL/
LVTTL interfaces
• Supports LVDS, M-LVDS, LVDM interfaces
• 200 MHz vector rate
• Operates as a stand-alone card or with up to
seven additional synchronous slave boards (128
channels operating with the same timing set)
The GX5293 is a high performance, cost-effective
3U PXI dynamic digital I/O boards offering 16 TTL
or LVDS input or output channels with dynamic
direction control. The GX5293 also supports deep
pattern memory by offering 256 MB of on-board
vector memory with dynamic per pin direction
control and with test rates up to 200 MHz. The
single board design supports both master and slave
functionality without the use of add-on modules.
GX5293
High Speed Dynamic Digital I/O, 200 MHz
data rate
GX5292 / GX5292e
HIGH PERFORMANCE DYNAMIC DIGITAL I/O
• 32 input or output channels, dynamically configurable
on a per channel basis
• 256 MB of on-board vector memory
• Selectable inputs and programmable outputs support
all TTL/LVTTL families
• Supports LVDS, M-LVDS, LVDM interfaces
• 100 MHz vector rate
• Operates as a stand-alone card or with up to seven
additional synchronous slave boards
• PXI (GX5292) and PXI Express (GX5292e) configurations
The GX5292 and GX5292e are high-performance,
cost-effective 3U PXI dynamic digital I/O boards
offering 32 TTL or LVDS input or output channels with
dynamic direction control. Both modules offer identical
features and capabilities. However, the GX5292e
offers increased PXI bus performance via its PXI
Express interface. When compared to the GX5292,
the GX5292e offers at least a 2x improvement in data
bus transfer rates for a x1 PCI lane configuration
with much higher transfer rates possible for x4 lane
configurations.
GX5292e
GX5292
PXI Dynamic Digital I/O Card Features
Feature
GX5281
GX5282
GX5283
GX5292 / GX5292e
GX5293
Vector Rate
50 MHz
100 MHz
200 MHz
100 MHz
200 MHz
Channels
32
32
32
32
16
Logic Levels
TTL/LVTTL/CMOS/LVCMOS
1.4 to 3.6 prog. output level
TTL/LVTTL/CMOS/LVCMOS
LVDS/LVDM/M-LVDS
1.4 to 3.6 prog. output level
TTL/LVTTL/CMOS/LVCMOS
LVDS/LVDM/M-LVDS
1.4 to 3.6 prog. output level
TTL/LVTTL/CMOS/LVCMOS
LVDS/LVDM/M-LVDS
1.4 to 3.6 prog. output level
TTL/LVTTL/CMOS/LVCMOS
LVDS/LVDM/M-LVDS
1.4 to 3.6 prog. output level
Programmable Vector
Width / Depth
No
No
Yes
Yes
No
Vector Depth
32 Mb/channel
64 Mb/channel
128 Mb/channel to 4 Gb
(one channel)
64 Mb/channel to 2 Gb
(one channel)
128 Mb/channel
Dynamic Direction
Control
No
No
No
Yes
Yes
I/O Control
Per Byte
Per Byte
Per Byte
Per Channel
Per Channel
Toll Free: 888.837.8297
•
Phone: 949-263-2222
•
Fax: 949-263-1203
•
email: [email protected]
•
www.geotestinc.com
7
3U Digital I/O
GX5280 Series
High speed DYNAMIC DIGITAL I/O
•32 input or output channels
•Industry-leading 512 MB of on-board vector memory
(GX5283)
•Selectable inputs and programmable outputs support
all TTL/LVTTL families
•Supports LVDS, M-LVDS, LVDM interfaces (GX5282
and GX5283)
•Vector rates up to 200 MHz (GX5283)
•Operates as a stand-alone card or with up to seven
additional synchronous slave boards
The GX5280 Series offers high-performance, costeffective 3U PXI dynamic digital I/O with 32 TTL input or
output channels and 32 LVDS input or output channels.
The GX5280 Series offers an industry leading 512 MB
of on-board memory and supports vector rates up to
200 MHz. The single board design supports both master
and slave functionality and allows multiple boards to
operate using the same timing set.
GX5281
High Speed Dynamic Digital I/O, 50 MHz
data rate
GX5282
GX5283
High Speed Dynamic
Digital I/O, 100 MHz
data rate
High Speed Dynamic
Digital I/O, 200 MHz
data rate
GX5641 / GX5642
BI-DIRECTIONAL DIFFERENTIAL TTL/LVDS I/O CARDs
•64 bi-directional I/O channels
•Bi-directional TTL I/O and RS422 differential I/O
ports per channel (GX5641)
•Bi-directional TTL I/O and LVDS I/O ports per channel
(GX5642)
•128 digital inputs or outputs with direction control
•Channels can be programmed to operate in conversion
or static I/O modes through software control
•Default direction control per channel via 64 switches
•Each TTL and differential output port can be individually
enabled/disabled through software control
•Compatible with the NI PXI 7811R Intelligent DAQ
FPGA module
•Compatible with PXI Express hybrid peripheral slots
The GX5641/GX5642 are 3U PXI instrument cards that
can be used for general data acquisition, process control,
Automatic Test Equipment (ATE), Functional Test, and
factory automation applications. Each channel has two
ports (TTL and differential) and can be individually set to
operate in either conversion or static I/O modes. Both
the GX5641 and GX5642 can support 128 individual
digital inputs or outputs: 64 TTL and 64 differential, or
64 conversion channels.
GX5641 / GX5642
GX5733
128 Channel DIGITAL I/O CARD
•Three 32-bit LVTTL ports for a total of 96 LVTTL
input or output channels
•One 32-bit configurable port accepting one GX57xx
I/O module for customized input or output levels
•Available I/O modules include Digital Input Latch,
Digital Output Latch, Optically Coupled Digital Power
Output, Differential TTL (RS-422), LVDS, and input/
output modules with vector memory
•Compatible with PXI Express hybrid peripheral slots
8
The GX5733 is a 3U modular digital I/O card that offers up
to 128 I/O channels. Designed for ATE, data acquisition,
or process control systems where a large number of
discrete I/O channels are required, the GX5733 offers
the highest channel density and flexibility in the industry
for a single slot, 3U PXI board. 96 channels support
TTL levels and an additional 32 I/O channels can be
customized by installing one of Geotest’s GX57xx
series I/O modules.
GEOTEST
PXI CATALOG
6U Digital I/O
GX5055
High performance DYNAMIC DIGITAL I/O
• Cycle based, dynamic digital instrument with integral
timing generator
• High performance pin electronics with per pin
programmability
• Dual level drive / sense, and programmable load on
a per pin basis
• Adustable slew rate from .1 to 1 V/ns
• Wide drive / sense voltage range: -10 V to + 15 V
• Supports 6 data formats
• 50 MHz vector rate
• 32 bi-directional I/O pins (up to 18 cards may be
daisy-chained for a total of 576 pins)
• 10 MB of on-board memory
• External and programmable internal clock rates from
5 Hz to 50 MHz
The GX5055 represents a new level of performance and
capabilities for PXI-based digital instrumentation. Based
on the proven architecture of the GX5050, the GX5055
offers high performance pin electronics and an enhanced
timing generator in a compact, 6U PXI form factor. Each
card can function as a stand-alone digital subsystem or if
required, multiple cards can be interconnected, providing
a single domain and supporting up to 576 bi-directional
pins. Each digital pin can be individually programmed
for a drive hi, drive lo, sense hi, sense lo, and a load
value (with commutation voltage level) – offering the
user complete flexibility when creating test programs and
fixtures for multiple UUTs. Slew rate is also adjustable,
providing further flexibility when creating and verifying
test programs and fixtures.
GX5050
High speed DYNAMIC DIGITAL I/O
•32 bi-directional I/O pins (up to 16 cards may be
daisy-chained, providing a total of 512 pins)
•3 MB or 12 MB of total on-board memory
•External and programmable internal clock rates from
5 Hz to 50 MHz
•Dynamically controlled sequencer using opcodes and
conditional logic for branching, looping, subroutines,
as well as providing advanced features for UUT
synchronization
•Sequencer opcodes include conditional/unconditional
jump, loop, call, return, pause, and halt
•Multiple I/O options include TTL, PECL, LVDS, and
programmable levels
•Geotest graphical vector development environment
(DIOEasy) for generating, editing, capturing, and
comparing complex digital patterns
•Supports up to 50 MHz clock frequency per channel
for a total of 1.6 Gb of data per second
The GX5050 is a full-featured, high-speed, dynamic digital
I/O card that provides functionality and performance that
is comparable to high-speed digital subsystems found
in large functional test systems. The GX5050 requires
a single 6U PXI slot and operates independently of the
host computer when in the RUN mode.
Configurations & Options
•GX5050-256 – Dynamic Digital I/O Master/Slave, 32
channels, up to 50 MHz, w/ 2 MB of channel memory,
DIOEasy, and a mating cable—requires one GX59xx
I/O module
•GX5050-1 MB – Dynamic Digital I/O Master/Slave,
32 channels, up to 50 MHz, w/8 MB of channel
memory, DIOEasy, and a mating cable—requires
one GX59xx I/O module
•GX5910 – TTL I/O Module
•GX5930 – Programmable Level (0-9V) I/O Module
•GX5940 – PECL I/O Module
•GX5960 – LVDS I/O Module
GX5150 / GX5151
High speed DIGITAL I/O
•32 input or output pins
•Up to 128 Mb per pin (8 channel configuration with
4 Mb SIMMs)
•Programmable I/O width supports 32 / 16 / 8 channel
configurations
•Conditional Jump and Pause commands
•Test rates up to 50 MHz
•Supports up to 512 pins with one GX5150 and 15
GX5151 slave modules
•2-slot PXI board (GX5150)
•1-slot PXI board (GX5151)
Toll Free: 888.837.8297
•
The GX5150 Series offers high-speed, dynamic digital
test capabilities. The GX5150 master controller supports
32 I/O channels and operates at test rates up to 50
MHz with a vector depth of up to 128 Mb per pin. The
GX5151 slave is a single-slot 6U board and offers the
same timing characteristics and multiple I/O level
configurations when used in conjunction with the
GX5150. The GX5150 can control up to 15 GX5151
boards using the GX5150’s timing and sequencer.
Each GX5150 and GX5151 requires a GX59xx I/O
module and 2-9 GT500x memory modules. Memory
modules are available in 256 Kb, 1 Mb, 2 Mb, and 4 Mb
configurations, providing a total memory depth of up to
32 Mb per pin for a 32-channel configuration.
Phone: 949-263-2222
•
Fax: 949-263-1203
•
email: [email protected]
•
www.geotestinc.com
9
7
6U Digital I/O
GX5152 / GX5153
DIGITAL STIMULUS RESPONSE INSTRUMENT
•
•
•
•
100 MHz timing module
32 digital input or output channels
Up to 8 Mb / pin (32 channel configuration)
Programmable I/O width supports 32 / 16 / 8 channel
configurations
• Supports up to 15 slave cards (GX5153) for a total
of 512 pins
• Fully compatible with Summation SigmaSeries
DSR10 and DSR11
• 10 ns resolution edge placement
• 6U, 2 slot PXI board (GX5152)
• 6U, 1 slot PXI board (GX5153)
The GX5152 Series provides extensive high-speed
digital I/O capability including the ability to generate a
timing set or “major cycle” which is comprised of up to
256 unique output states. The GX5152 Digital Stimulus
Response (DSR) instrument functions as a master,
providing the timing set, 32 channels of digital input
or output, as well as synchronization to GX5153 slave
modules via a dedicated local bus and the PXI trigger
bus. The GX5152 requires a GX59xx I/O module and
2-5 GT500x memory modules. Memory modules are
available in 256 Kb, 1 Mb, and 2 Mb configurations,
providing a total memory depth of up to 8 Mb per pin
for a 32 channel configuration.
GX5731
224 Channel DIGITAL I/O CARD
•Four 32-bit TTL modules provide a total of 128 TTL
input or output channels
•Three 32-bit ports accept GX57xx I/O modules for
customized input or output levels (96 customizable
I/O channels)
•I/O modules with on-board memory and handshaking
capability
•I/O modules support Summation digital I/O product
(DIL, DOL, and DPO) features
I/O Module Options
•GX5701 – 32 channel digital input latch module with
programmable threshold, handshaking, and 16 KB of
vector memory
•GX5702 – 32 channel digital output latch module with
handshaking and 16 KB of vector memory
•GX5703 – 32 channel LVDS input latch module with
handshaking and 16 KB of vector memory
•GX5704 – Digital power output latch module, 32
optically isolated, OC outputs with handshaking and
16 KB of vector memory
The GX5731 is a 6U modular digital I/O card with 224 I/O
channels. Designed for ATE, data acquisition, or process
control systems where a large number of discrete I/O
channels are required, the GX5731 offers the highest
density in the industry for a single PXI plug-in board.
Of the 224 channels, 128 have TTL levels, with the
direction of each group of eight channels programmable
as an input or output. The remaining 96 channels can be
customized using Geotest’s GX57xx series I/O modules.
•GX5705 – 32 channel RS-232 I/O module
•GX5709 – 32 channel RS-422 I/O module
•GX5710 – 32 channel LVDS I/O module
•GX5711 – 16 channel LVDS to TTL
bi-directional converter
•GX5712 – 16 channel RS-422 to TTL
bi-directional converter
GX5732
224 Channel TTL DIGITAL I/O CARD
•Seven 32-bit ports for a total of 224 input or output
channels
•TTL Levels
•Four 8-bit, 50 MHz counters
10
6
The GX5732 is a 6U PXI static digital I/O card with 224
I/O channels. In addition, the GX5732 has four 8-bit,
bi-directional, 50 MHz counters. Eight I/O pins on the
counter port can be used as an input or output to any of
the counters. An additional 4 outputs can be used as
an output from any of the counters, or as a Terminal
Count (TC) for all counters. Six programmable inputs are
provided for counter control: clock, gate, or load. The
counters may be daisy chained to create two 16-bit
counters, or one 32-bit counter. The clock source can be
PCI clock, PXI clock, external clock, or another counter.
GEOTEST
PXI CATALOG
3U Analog
GX2472
DUAL CHANNEL, 70 MS/S DIGITIZER
• Two channel, 14 bit digitizer
• Differential or single ended inputs
• DC to >50 MHz analog bandwidth
• 1V to 20 Vpp full scale
• AC or DC coupling
• Excellent dynamic range and low distortion
The GX2472 is a high performance, dual differential
channel, 14-bit digitizer offering high dynamic range
and excellent SFDR. The module’s differential inputs,
coupled with its low distortion makes it an ideal
instrument for analyzing high performance or low
level analog signals. Each channel offers 3 selectable
low pass filters, a 14 bit, 70 MS/s ADC, and 512K of
memory. A 50 MHz or 70 MHz clock with a divider
provides a common acquisition clock source for both
channels.
GX1034
GX1034 STANDARDS MODULE
• 3U, single slot, precision standards module for PXI
systems
• Voltage, frequency, and resistance standards
• On-board EEROM ensures standards traceability
and accuracy
• Built in current source and DC measurement
resources for system self-test support
• Built-in self test
• Compatible with PXI Express hybrid slots
The GX1034 offers PXI system designers the capability to
develop a system re-certification strategy that employs only
internal system resources. By incorporating the GX1034
as part of a system configuration, it is possible to develop
a system accuracy verification strategy that can recertify a
system’s source and measure baseband instrumentation
– resulting in simplified support / maintenance logistics
and improved system availability. The GX1034’s standards
exhibit excellent long term stability with absolute accuracy
achieved by employing an on-board EEROM.
SMX2040 Series
61/2 DIGIT MULTIMETERS
•Flexible, full-featured auto-ranging DMMs
•DC/AC volts and current measurements
•2-wire and 4-wire ohms measurements
•True RMS AC measurements, 10 Hz to 100 kHz
•Measures 1 µV to 330 V
•Self-calibrating
•Up to 1,000 rps
•1 Hz to 300 kHz frequency measurements
•300 V isolation barrier
The SMX2040 plugs into any PXI or CompactPCI chassis
to provide a combination of resolution, accuracy, and speed
that surpasses rivals. With 61/2 digit resolution, 0.006%
basic DCV accuracy and 1,000 RPS, the SMX2040
provides measurements that are accurate, fast and
repeatable. The SMX2042 includes additional functions
for capacitance, frequency/period, pulse width, and event
measurements.
SMX2060 Series
71/2 DIGIT MULTIMETERS
•Flexible, full-featured auto-ranging DMMs
•DC/AC volts and current measurements
•2-wire and 4-wire ohms measurements
•True RMS AC measurements, 10 Hz to 100 kHz
•Measures 1 µV to 330 V
•Self-calibrating
•Up to 1,400 rps
•1 Hz to 300 kHz frequency measurements
•300 V isolation barrier
•Inductance, capacitance, and leakage measurements
Toll Free: 888.837.8297
•
The SMX2060 series is designed as a universal, multifunction sourcing DMM. Measurements commonly
associated with “high-end” system DMMs are standard
features with the SMX2060 family. The SMX2060 is a
full featured, 71/2 digit DMM offering outstanding accuracy and performance. The SMX2064 includes all of the
SMX2060’s basic DMM features as well as a DC voltage/
current source, an AC voltage source and leakage,
inductance, six wire guard, in-circuit capacitance, and
thermocouple measurement functions.
Phone: 949-263-2222
•
Fax: 949-263-1203
•
email: [email protected]
•
www.geotestinc.com
11
7
3U Analog
GTX2200 Series
TIME INTERVAL COUNTERS
•14 measurement functions
•DC to 225 MHz (GTX2210), DC to 1.3 GHz
(GTX2220), DC to 2.0 GHz (GTX2230)
•100 ps resolution without averaging (GTX2220 and
GTX2230 only)
•Accuracy: +/- [(time base error x frequency) + resolution]
•Fast measurement mode: 2300 readings/sec
•External reference clock input
•External arming signal input
•Self-calibration ensures highest accuracy
•Auto-adjust mode optimizes measurement stability
and accuracy
•Software selectable input impedance (1M Ω or 50 Ω)
and coupling (AC or DC) for each input channel
•Models also available in PCI format
•Compatible with PXI Express hybrid peripheral slots
GTX2220
GTX2230
1.3 GHz Universal Time
Interval Counter
2 GHz Universal Time
Interval Counter
The GTX2210 family of PXI universal time interval counters
offers many of the measurement and timing functions
of high-end stand-alone frequency counters, including
accumulate, auto ratio, frequency, fast frequency (GTX2220
and GTX2230 only), period, ratio, single period, test clock,
time interval, time interval delay, totalize, totalize gated,
totalize gated once, and width. The GTX2210 features a
10 MHz, TCXO time base with an initial accuracy of
100 PPM. The GTX2220 and GTX2230 offer a 10 MHz
TCXO time base with an intitial accuracy of 5 PPM. As an
option, both the GTX2220 and GTX2230 are available with
a 10 MHz OCXO time base for improved long-term stability.
225 MHz Universal Time Interval Counter
GX2002
RF POWER ANALYZER
•CW and pulse RF power measurements
•Frequency counter
•Pulse interval analyzer
•100 MHz to 3 GHz
•External input and output synchronization
•Compatible with PXI Express hybrid peripheral slots
The GX2002 PXI RF Power Analyzer module performs
multiple measurements on both CW and pulsed RF
waveforms including power, frequency, and pulse interval
measurements. Flexible triggering and a programmable
gate measurement window allow the module to acquire
and measure RF pulse power and the RF waveform’s
frequency. The GX2002 can analyze RF signals from
100 MHz to 3 GHz with an input range from –34 dBm
to +16 dBm. The RF input is processed in parallel using
a RF counter that measures frequency, a calibrated
envelope detector that measures CW or pulse power,
and time-capture circuitry that measures the pulse width
and pulse repetition interval. The GX2002 is ideally suited
for performing RF power and signal measurements on a
variety of modern day communication and radar products.
GX1648
ANALOG OUTPUT CARD
•64 individually-controlled analog outputs
•12-bit resolution
•Output range: -10 V to +10 V
•Output current: +/-10 mA per channel
•Update rate: 20 KHz
•Settling time: 50 µSec
•Simultaneous or independent updating of all channels
•Compatible with PXI Express hybrid peripheral slots
12
6
GTX2210
The GX1648 is a 3U PXI digital to analog output board
designed specifically for applications where multiple analog
outputs are required. The GX1648 offers precision signal
sourcing performance and quality at an economical price.
The GX1648 is organized into groups of eight channels.
Each group is programmed and triggered independently
of the others. All channels provide single-ended voltage
and are automatically set to zero volts DC after reset to
prevent inadvertent damage to external equipment.
GEOTEST
PXI CATALOG
3U Analog
GX1110
PXI ARBITRARY WAVEFORM FUNCTION GENERATOR
• Arbitrary Waveform Generator and Direct Digital
Synthesis modes
• 100 MS/s sample rate
• 12 –bit vertical resolution
•Programmable from 100 mV to 8 V p-p, full scale
•2 M sample memory
• PLL clock generator for AWG mode
• 3U, single slot module
The GX1110 is a high performance, single-channel
PCI arbitrary waveform generator that offers function
generator and arbitrary waveform generator functionality
within one instrument. Built-in waveforms are available
for use with both the DDS or AWG modes of operation
and include Sine, Triangle, Ramp, Noise, Gaussian
pulse and Sinx/x.
GX1200 Series
ARBITRARY WAVEFORM GENERATORS
•50 MS/sec (GX1200) and 100 MS/sec (GX1201)
sample rates
•Programmable 10-digit sample clock with a frequency
resolution of 1 µHz
•1 ppm clock accuracy and stability
•14-bit vertical resolution
•2 MS memory depth
•Multiple instrument synchronization
•Ultra-fast waveform downloads using DMA
•Extremely low phase noise carrier
The GX1200 and GX1201 are high performance, singlechannel PXI arbitrary waveform generators that combine
a function generator, arbitrary waveform synthesizer,
programmable sequencer, pulse generator, and modulation
generator in one instrument. The GX1200 Series delivers
all this at a lower cost than comparable bench-type or VXIbased instruments. With high sample rates of 50 MS/sec
(GX1200) and 100 MS/sec (GX1201), the GX1200 Series
is an ideal modulation source for troubleshooting encoding
schemes.
GX1200
50 MS/Sec Arbitrary Waveform Generator
GX1201
100 MS/Sec Arbitrary
Waveform Generator
GX1838 Series
PRECISION MULTI-CHANNEL DC SOURCE
•Eight discrete output channels
•Three programmable voltage rails
•Two output configurations: -10V to +32 (GX1838) or
-20V to +20V (GX1838-20)
•14-bit programming resolution
•500 mA maximum current output
•Accuracy enhanced by on-board EEPROM that contains
DAC’s calibration parameters
•Compatible with PXI Express hybrid peripheral slots
The GX1838 is a 3U PXI multi-channel programmable DC
Source providing multiple discrete outputs for avionics,
automotive, and industrial testing as well as other ATE
applications. The GX1838 provides eight output channels
that can be isolated, connected to any of the three voltage
rails, or connected to one of three external sources. Each
of the three voltage rails can be programmed to output
-10 VDC to +32 VDC or -20VDC to +20 VDC with 14bit resolution.
GX1838
Precision Multi-Channel DC Source
(-10V to +32V)
GX1838-20
Precision Multi-Channel
DC Source (-20V to +20V)
Toll Free: 888.837.8297
•
Phone: 949-263-2222
•
Fax: 949-263-1203
•
email: [email protected]
•
www.geotestinc.com
13
3U Analog
GX1222
WIDEBAND AMPLIFIER
•DC to 20 MHz Bandwidth
•40Vp-p maximum output voltage into open circuit
•20Vp-p maximum output voltage into 50 Ω load
•Isolated input & output
•Expands capabilities of the GX1200 Series Arbitrary
Waveform Generators
The GX1222 is a single-slot, PXI-based wideband power
amplifier used for signal amplification purposes. Offering
unprecedented signal purity, the GX1222 amplifies signals
from DC to over 20 MHz with a fixed gain of x10. Custom
gains are also available without jeopardizing signal purity
and amplifier performance. The GX1222 can amplify input
signals to an output of 40Vp-p into high impedance or
20Vp-p into 50 Ω, and can be used in conjunction with
Geotest’s GX1200 series Arbitrary Waveform Generators.
GX1164 Series
PROGRAMMABLE RESISTOR CARDs
•8 programmable resistor channels
•Configuration relays support normal and wiper mode
operation
•On-board EEPROM for personalized calibration data
•1 Ω to 64K Ω resistance, 1 Ω resolution (GX1164)
•2 Ω to 128K Ω resistance, 2 Ω resolution (GX1164-2)
•4 Ω to 256K Ω resistance, 4 Ω resolution (GX1164-4)
•8 Ω to 512K Ω resistance, 8 Ω resolution (GX1164-8)
•Compatible with PXI Express hybrid peripheral slots
The GX1164 is a 3U PXI programmable resistor card
with 8 programmable channels. Optionally, the card can
be configured for four channels, which will simulate
resistances from 1 Ω to 64K Ω with 1 Ω resolution
(GX1164 model). The GX1164 includes an on-board
EEPROM that contains calibration data. The EEPROM
can also be used to “personalize” the GX1164 using
custom resistance ranges and resolutions.
GX1164
1 Ω to 64K Ω programmable resistance,
1 Ω resolution
GX1164-2
2 Ω to 128K Ω programmable resistance, 2 Ω
resolution
GX1164-4
4 Ω to 256K Ω programmable resistance, 4 Ω
resolution
GX1164-8
8 Ω to 512K Ω programmable resistance, 8 Ω
resolution
GX7404
POWER INTERFACE & PROTOTYPE CARD
•Four fixed DC power outputs: +3.3 V, +5 V, +12 V,
and -12 V
•Software controlled on/off switching
•Output voltage and current readback
•External power inhibit line
•On-board prototyping area for custom circuitry
•Compatible with PXI Express hybrid peripheral slots
14
The GX7404 power interface card offers a low-cost
method to provide controlled power to a UUT or test
target interface circuitry. The GX7404 permits the +5V,
+3.3V, +12V, and -12V voltages present on the PXI
backplane to be accessed and controlled via a DB25
connector located on the front panel of the GX7404. The
GX7404 offers special features, including external output
inhibit, UUT discharge, and a prototype area. The external
inhibit is a TTL compatible input that disconnects all output
voltages supplied by the GX7404.
GEOTEST
PXI CATALOG
3U Switching
GX6115
HIGH CURRENT RELAY CARD
•15 individual high-current single-pole, double-throw
(SPDT) Form C relays
•7A @ 30 VDC contact rating per channel
•3 additional relay drivers for external relays or other
devices
•Available with 45 7A channels in a 6U form factor
•Compatible with PXI Express hybrid peripheral slots
The GX6115 is a 15 channel, high-current relay card that
plugs directly into any 3U PXI slot. The GX6115 offers
15 high current relays with a 7A @ 30 VDC current
rating for each channel. The GX6115 also provides three
transistor-driven channels for external relays; these
outputs may be used to drive external loads such as
heavier duty relays or lamps or other devices. A 50-pin
D type connector routes all signals to the front panel.
GX6125
General purpose SWITCHING CARD
•25 channels of single-pole, double-throw (SPDT)
Form C relays
•2 A contact rating per channel
•Available with 75 2A channels in a 6U form factor
•Compatible with PXI Express hybrid peripheral slots
The GX6125 is a high-density switching card with 25
SPDT Form C relays capable of switching 2 A at 220 VDC.
The GX6125 is suitable for all test applications requiring
general-purpose, low-level switching. The GX6125 has 25
SPDT relays and a 78-pin D type connector. Each of the
relays can be latched or unlatched under program control.
GX6138
HIGH DENSITY SWITCHING CARD
•38 channels of single-pole, single-throw (SPST)
Form A relays
•0.5 A contact rating per channel
•Available with 114 channels in a 6U form factor
•Compatible with PXI Express hybrid peripheral slots
The GX6138 is low-cost switching card with 38 individual
low level SPST Form A relays capable of switching 0.5
A at 200 VDC. The GX6138 is ideal for applications
requiring high-density switching. The GX6138 consists
of 38 individual relays and a 78-pin D type connector.
Each of the relays can be latched or unlatched under
program control.
GX6021
20-CHANNEL RF MULTIPLEXER
•High density PXI RF multiplexer
•Four groups of 1x4 multiplexer scanners
•Groups may be daisy-chained
•>500 MHz bandwidth within each group
•>300 MHz bandwidth between groups
•Available with 12 1x4 multiplexers in a 6U form factor
•Compatible with PXI Express hybrid peripheral slots
Toll Free: 888.837.8297
•
The GX6021 is a configurable RF multiplexer. Within each
multiplexer group, each channel can be connected to any
of the other four channels in its group. Additional relays
connect adjacent groups. Using these additional relays,
larger groups can be formed such as 2x1:9 or 1x1:19.
The GX6021 groups can be software configured to
provide switch paths that maintain >300 MHz bandwidth.
Phone: 949-263-2222
•
Fax: 949-263-1203
•
email: [email protected]
•
www.geotestinc.com
15
3U Switching
GX6377
MULTI-FUNCTION RELAY CARD
•Five 10 amp, single pole Form A relays
•Four 2 amp, single pole Form A relays
•Four 2 amp, single pole Form C relays
•Dual 16x2, configurable relay matrix
•Compatible with PXI Express hybrid peripheral slots
The GX6377 is a multi function switch card that provides
users with the ability to switch both high-current and
general-purpose signals using only one PXI switch card.
The card features multiple channels of high-current
switching capability for 10 amp and 2 amp applications
as well as two, 16x2 switch matrix groups, which can
also be configured as a 32x2 or 16x4 matrix.
GX6384 Series
HIGH DENSITY SWITCH MATRICES
•Supports up to 256 switch cross-points
•Available in two configurations: dual 32x2 & dual
32x4
•Can be configured in software as a 64x2 or 64x4
switch matrix
•User friendly 78 pin sub-D type interface connector
•Compatible with PXI Express hybrid peripheral slots
The GX6384 is a 3U PXI switch matrix that provides users
with the ability to switch and interface tester resources
to multiple UUT connections. The card is available in
two different configurations, supporting a dual 32x2 or
32x4 switch matrix configurations. Both versions of the
GX6384 can be software configured as single matrices, offering 64x2 or 64x4 configurations.
GX6384
Configurable, high-density switch matrix
with 128 cross-points
GX6384-2
Configurable, high-density
switch matrix with 256
cross-points
SMX4032
LOW THERMAL EMF SWITCH CARD
•Up to 4 differential 8:1 scan groups
•Software Configurable for:
2-wire measurements
4-wire measurements
6-wire measurements
Universal
•Fast switching and settling times
•Low-thermal EMF offset
•Low leakage
•Low capacitance
16
The SMX4032 is a high-density 32-channel relay
switching card that is designed for use in applications
requiring precision signal switching. With an on-board
micro-controller, the intelligent SMX4032 is particularly
suitable for demanding test applications. The very low
thermal-offset, leakage, and capacitance make the
SMX4032 ideal for switching precise low-level signals.
GEOTEST
PXI CATALOG
6U Switching
GX6062
RF SWITCHING CARD
•Multiple switching configurations
•Hi-density RF switching
•200 MHz bandwidth
•12 groups of 1x4 switches
The GX6062 is a high-density 6U, single-slot PXI RF
switching card that provides an overall bandwidth of 200
MHz and multiple switching configurations. Each 1x4
switch has a bandwidth of 300 MHz. The GX6062
has 12 groups of 1x4 differential, non-terminated RF
multiplexers. The 12 groups can be used to create
multiple configurations including: 6x1:9, 3x1:19, 2x1:29,
1x1:59, and more.
GX6264I/C
PXI Scanner / Multiplexer CARD
•High-density multiplexer configurable as 128 singleended or 64 differential channels
•Eight scan groups configurable as 16 single-ended
or eight differential channels each
•Available with commercial or industrial grade relays
•250VDC or 220VAC switching voltage per channel
(GX6264I)
•100VDC or 150VAC switching voltage per channel
(GX6264C)
•Fast switching time with 0.5A rating per channel
•Fully software programmable
The GX6264 is a 6U PXI scanner/multiplexer that plugs
directly into an PXI or CompactPCI backplane. The
GX6264 provides either differential or single-ended
capability and is configurable via software commands or
DIP switches. The GX6264 is available in two versions:
commercial and industrial. The commercial version
employs commercial grade DIP reed relays and is suitable
for most commercial applications. The industrial version
uses an industrial-grade relay and is suitable for adverse
and demanding applications. The switch module’s
architecture consists of eight scan groups, A through H,
which provide scanning/multiplexing of eight differential
or 16 single-ended channels. Mixed configurations of
single-ended and differential channels can be used
simultaneously. Typical configurations include: 1:128
single ended, 1:64 differential, 2x1:64 single ended,
and 2x1:32 differential.
GX6315
High current Relay Card
•45 individual high-current, single-pole, double-throw
(SPDT) Form C relays
•7A contact rating per channel
•Nine additional relay drivers for external relays or
other devices
Toll Free: 888.837.8297
•
The GX6315 is a 45 channel, high-current relay board
that plugs directly into any 6U PXI slot. The GX6315
also provides nine transistor-driven channels for external
relays. These outputs may be used to drive external
loads, such as heavier duty relays, lamps, solenoids, or
other devices. Each of the relays can be independently
latched or unlatched under program control.
Phone: 949-263-2222
•
Fax: 949-263-1203
•
email: [email protected]
•
www.geotestinc.com
17
6U Switching
GX6325
General purpose SWITCHING CARD
•75 channels of single pole double throw (SPDT)
Form C relays
•2A contact rating per channel
The GX6325 is 6U switching card with 75 SPDT Form C
relays capable of switching 2A at 220VDC. With the
highest density available in PXI, the GX6325 is suitable
for all test applications requiring general-purpose,
low-level switching. The GX6325 consists of three
groups: A, B, and C. Each group has 25 high-current
relays and a 78-pin, D-type connector. Each of the
relays can be independently latched or unlatched
under program control.
GX6338
high density SWITCHING CARD
•114 channels of single pole single throw (SPST)
Form A relays
•0.5 A contact rating per channel
The GX6338 is a low-cost 6U switching card with 114
individual low-level SPST Form A relays capable of
switching 0.5A at 200VDC. The GX6338 is ideal for
applications requiring high-density switching. The
GX6338 consists of three groups: A, B, and C. Each
group has 38 individual relays and a 78-pin, D type
connector. Each of the relays can be independently
latched or unlatched under program control.
GX6616
high density SWITCH MATRIX CARD
•Six switching groups allow multiple configurations
up to 2x96
•Fast switching time with 0.5 A contact rating
•Single-ended or differential switching capability
•Optional built-in test adapter simplifies maintenance
and support
18
The GX6616 is a 6U PXI switch matrix board that
provides either differential or single-ended multiplexing
capability, along with six 2x16 matrix groups that may be
used in various configurations. The GX6616 consists
of six switching groups, A through F, which provide
connections between two rows and 16 channels. Each
switching group can be connected either horizontally or
vertically to an adjacent group via on-board jumpers.
Single ended or differential configuration is controlled
via software commands. Typical configurations include:
6x2:16, 3x4:16, 3x2:26, and 1x2:96.
GEOTEST
PXI CATALOG
Emulators & JTAG / CPU Interfaces
NX5000 / NX5000-3U
3U / 6U PXI ROM EMULATOR
•Supports full-speed operation of the UUT with
no modifications
•No special fixturing required
•Requires only one generic pod
•Supports 8/16/32 bit ROMs
•New processors can be added with just a software
update
•No assembly language required for use of the basic
functions of the ROM emulation card
•Basic functions include Read, Write, RAM test, ROM
CHECKSUM, Fill, Copy, Move, etc.
•Basic diagnostics are available to troubleshoot a
dead kernel
ROM emulation is a powerful and versatile method of
microprocessor testing. A microprocessor-based board
can be tested by replacing the boot ROMs on the Unit
Under Test (UUT) with memory-emulation pods. Each
pod handles eight bits of the data bus. Processors
from 8 to 32 bits can be controlled with one to four
pods (even the most advanced CPUs such as the Intel
Pentium® generally use only an 8-bit boot path). The
emulator takes control of the UUT by resetting the
processor and, under the test program’s control (monitor
program), exercises all functions on the board. The
NX5000 supports 8 and 16-bit ROMs. The NX5100
expansion kit provides support for 32-bit boot ROMs.
NX5300
JTAG / BACKGROUND DEBUG MODE TEST SYSTEM
• Single slot, 3U format
• Supports troubleshooting of processor based boards
via a JTAG or On-chip Debug port
• No special fixturing required
• Supports on-board Flash ROM programming
• 16 channels of general purpose digital I/O
• High speed logic probe for nodal diagnostics
The NX5300 is a single slot 3U PXI device and
interfaces to the unit under test via an On-Chip Debug
(OCD) or JTAG port. The NX5300 is a high performance
JTAG based background debug mode (BDM) diagnostic
system designed for functional test, development,
programming and troubleshooting of microprocessor
and microcontroller based embedded processor
systems. Advanced capabilities include simultaneous
support of up to 255 devices on a single scan chain,
support of sixteen NX5300 systems controlled by
single host machine and configurable JTAG/BDM clock
rates up to 24 MHz. Each of the card's 16 channels
can measure logic levels, frequency, count events and
perform a CRC check at rates up to 100 MHz.
User Power Supply
GX7400A
Dual Output Power Supply
•Two programmable 150W output supplies
•Read-back voltage and current at output
•Over-voltage and over-current protection
•Over-temperature and short-circuit protection
•Remote inhibit via front panel connector
•Power supply outputs isolated from each other
•3-slot, 6U configuration
The GX7400 is a dual-output, programmable DC
power supply designed for use in 6U PXI systems.
The GX7400 occupies three slots and is controlled via
the PXI bus. AC power is provided via a front panel
receptacle. The power supplies are fully isolated and
can be externally connected in series to provide higher
voltage.
Power Supply Module Options
•GX7415 – 0-15V @10A programmable power
supply
•GX7430 – 0-30V @5A programmable power
supply module
•GX7460 – 0-60V @2.5A programmable power
supply module
Toll Free: 888.837.8297
•
Phone: 949-263-2222
•
Fax: 949-263-1203
•
email: [email protected]
•
www.geotestinc.com
19
Software
•Graphical vector development environment for all of
Geotest’s dynamic digital I/O products
•Supports creation/editing of vectors via a graphical
interface or embedded scripting environment
•Supports vectors up to 512-bits wide and 128 MS deep
•File compression algorithm reduces DIO file size
•Converts ASCII vector formats to/from DIO formats
for all Geotest digital I/O instruments
•GUI environment supports interactive control and
status of all Geotest dynamic digital instruments
and executing digital test vectors. DIOEasy toolbars
and menus provide quick access to vector editing and
viewing tools.
Description
Digital I/O (DIO) systems are very complex and typically
require a substantial amount of programming effort to
define data vectors. In order to simplify the process,
Geotest developed Windows-based DIOEasy—providing
users with a familiar interface for developing, debugging,
Vectors can be loaded to and from DIO instrument(s)
using the DIO Virtual Panel. After loading the vectors, the
user can arm and trigger the instrument for generation/
acquisition. Data captured from the boards can be saved
to a file and/or loaded to DIOEasy for viewing or for
comparison against a previously defined vector data file.
Features
DIOEasy offers two methods for creating and editing
digital test vectors:
•Graphical User Interface (GUI) Environment
•Scripting Environment
DIOEasy
Graphical
Editor
DIO
Panel
Scripting
Editor
Function
Library
ActiveX
Objects
DIO Driver
DIO Boards
Graphical User Interface
DIOEasy’s GUI offers interactive digital vector editing and viewing. Its
generic structure allows it to easily support all of Geotest’s dynamic digital
instrument hardware configurations. DIOEasy produces vector data files
that can be directly used by the digital instrument’s driver (GTDIO).
Similar to a spreadsheet application, each cell represents the state of a
single data bit in a given step. The data bits (channels) are represented
by trace lines in the rows of cells, and each step is a column of cells.
Scripting
DIOEasy allows you to create, design, and edit vectors using Microsoft
Visual Basic Script™ (VBScript)—a popular scripting language. Using
the capabilities of VBScript and DIO ActiveX objects, the user can write
complex programs that create and modify DIO vectors.
20
GEOTEST
PXI CATALOG
Software
•32-bit object-oriented programming framework for
Windows® 98/ME and 2000/XP
•Rapid Application Development (RAD) environment
enables short development cycles
•Instrumentation/Test System-like modular structure
for easy development and maintenance
•Application Builder creates royalty-free, run-time
executables (EXE files)
•Built-in Test Executive and Profile editor for full control
of test execution, sequence, and conditions; optional
touch panel UI; and user-group-based UI customization
•User-defined, plain language commands offer program
legibility for easier maintenance
•Automatic generation of HTML and text-based test
logs instantly display test results
•Configuration Management tools allow simplified
project management
•Connectivity with Microsoft® Source Safe enables
direct check in, out, add, and compare files
•Multithreading support allows simultaneous execution
of multiple code segments
•Visual Basic-like Form Editor generates graphical
user interfaces, menus, and controls
•Event-driven programming support facilitates more
efficient program execution
•Supports ActiveX, OCX, OLE, DDE, DLL, .NET
components/assemblies and C/C++ header files (for
automatic DLL functions and type declaration)
•Vendor-independent open architecture supports PXI,
PCI/cPCI, VXI, GPIB, TCP/IP, RS-232, ISA, and more
•Supports VXI Plug-and-Play, Function Panel (.fp)
drivers, Virtual Instruments (.vi/.llb), and IVI drivers
Description
ATEasy is a test executive and offers a rapid application development
framework for functional test, ATE, data acquisition, process control,
and instrumentation systems. ATEasy provides all the necessary tools
to develop and maintain software components, from instrument drivers
to complex test programs. With ATEasy, test applications are faster to
generate and easier to maintain.
ATEasy includes a complete test development suite which is specifically
designed for test applications. The ATEasy development environment
combines the ease of Microsoft Visual Basic and the flexibility of
Microsoft Visual C++ — a complete object-oriented, 32-bit Windows
programming environment.
Features
Test engineers build their test application from components modeled
after real-world test systems. These components include a System,
Drivers, Programs, Tests, Commands, and more. ATEasy provides a
streamlined, easy-to-follow framework and wide array of features that
enable the user to create reusable components. The result is a test
application that is faster to generate and easier to maintain.
Toll Free: 888.837.8297
•
Phone: 949-263-2222
•
Fax: 949-263-1203
•
email: [email protected]
•
www.geotestinc.com
21
1770 Kettering
Irvine California, 92614-5616
TF: 888.837.8297
Tel: 949.263.2222
Fax: 949.263.1203
E-Mail: [email protected]
www.geotestinc.com
Copyright © Geotest – Marvin Test Systems, Inc. All rights
reserved. Product and company names listed are trademarks
or trade names of their respective companies. Revision A.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
