CONTENTS

Mobile Video Studio

OBV-2800

OBV-2800-CCU

MRS-2800

Camera Control System

CCU-100

AD-2

CB-45

MS-2800A

MS-2800B

Portable Video Studio

HS-2800

HS-2200

HS-600

Digital Video Switcher

SE-2800

SE-2200

SE-1200MU

SE-700

SE-600

SE-500

Video Monitor

TLM-170P/ PM/ PR

TLM-170G/ GM/ GR

TLM-702HD

TLM-700HD

TLM-434H

TLM-430

10

4

5

6

7

8

Converter/ Distribution Amplifier

DAC-70

DAC-60

DAC-50S

DAC-9P

DAC-8P

DAC-7

VP-597/ VP-445

Accessory

RMK-2

MB-4/ 5/ 6

Digital Video Recorder

HRS-30

HDR-60

HDR-70

DN-600

DN-700

DN-60A

HDR-10

Character Generator

TC-200+CG-200

CG-500

CG-350

CG-250

CG-100

Teleprompter

TP-300

TP-500

TP-600

DVP-100

HC-300/ 500/ 600

12

16

18

13

14

HD/SD-SDI PTZ Camera

PTC-150

PTC-120

RMC-180

RMC-190

Camera Controller

MCU-100P

MCU-100S

MCU-200P

MCU-200S

AD-1P/S

Video Streaming Server

NVS-25

IP Video Decoder

NVD-20

Network Controllable Player

NVP-20

Wi-Fi Bridge Unit

NVW-150

NVW-250

Intercom/Tally System

ITC-100

ITC-200E

Chromakey

DVK-300HD

DVK-200

CKL-300

19

20

23

24

21

22

21

21

Virtual Studio System

TVS-1000

TVS-1200

RMC-220

TVS-AUX

Test & Measurement

VS-100

VS-150

VSM-100

VSM-200

Audio Delay/ Audio Mixer/

Audio Converter

AD-200

AD-100

DAC-80

BAC-03

AM-100

Power Center

PD-2A

PD-4A

PD-6

DDC-4012H

DDC-2512

All In One Cable/ Repeater

CB-22H/ 23H

CB-30/ 31

CB-46/ 47/ 48

VP-605H

VP-633

VP-634

VP-737

25

28

29

30

31

2

2

OBV-2800 MRS-2800 MS-2800A MS-2800B HS-2800 HS-2200 HS-600

3

3

Mobile Video Studio

M o b i l e V i d e o S t u d i o

LIVE IN SECONDS

HD/SD 12-Channel

Mobile Video Studio (OBV)

OBV-2800

OBV-2800 is a PPU (portable production unit), designed to fit into the back of a small van to provide complete mobile production facilities. It’s a mobile, transportable solution for broadcasters and professionals for both in-studio and onlocation productions.

Built around the latest HD / SD switcher, it supports up-to 12 channels of HD/SD-SDI,

HDMI or composite video signals. The system is integrated, compact and sturdy with a metal framework for great stability and protection yet provides room for future expansion.

With power-efficient modules, OBV-2800 can be powered by a DC 12V supply, is easy to install, and is cost effective.

OBV-2800-CCU MRS-2800 Model OBV-2800

4

Description OBV Rack System

8/12-CH HD/SD-SDI inputs

27RU Mobile Rack System (x 2)

Configuration

Digital Video Switcher

17.3" Rack Mount LCD

HD/SD SDI Recorder

Intercom/Tally system

SE-2800-8/12

TLM-170GR x 2

HDR-70 x 1

ITC-100 w/4 Belt pack

SDI Vector Scope

Audio Mixer (6-CH)

VSM-100

AD-200

Audio Delay Box AD-200

Power distributor (8-way) PD-2A

Return Video (8-CH CV) RP-45A

Camera Control System ----

Camera Power Distributor PD-3A

Title Creator ----

Highlight Replay Recorder ----

HD/SD SDI Amplifier VP-445 x 1

Rack System Integration 27RU Mobile Rack System x 2

Options

SDI Vector Scope ----

Return Video (8-CH CV) ----

Camera Power Distributor ----

Camera Power Regulator DDC-4012H (9-30V to DC12V)

Redundant Power (360W) PD-4A

Multi-Camera Control MCU-200P/S

Return Video LCD (CV)

SDI/CV/ITC/DC cable

CB-22H/23H Repeater

SDI/CV/ITC/Cat-5 cable

SDI/ITC cable

ITC/Tally cable

100m SDI Repeater

TLM-430 with Ball head

CB-22H/CB23H (30m/50m)

VP-605H

CB-30/31/38 (30/50/40m)

CB-46/47/48 (30/50/100m)

CB-3/CB-4 (20m/50m)

VP-633/VP-634

OBV Rack with Camera Control System

8/12-CH HD/SD-SDI inputs

27RU Mobile Rack System (x 2)

SE-2800-8/12

TLM-170GR x 2

HDR-70 x 1

ITC-100 w/4 Belt pack

VSM-100

AD-200

AD-200

PD-2A

----

CCU-100 + AD-2 + CB-45

PD-6

TC-200

HDR-10

VP-445 x 1

27RU Mobile Rack System x 2

----

----

----

DDC-4012H (9-30V to DC12V)

PD-4A

----

TLM-430 with Ball head

CB-22H/CB23H (30m/50m)

VP-605H

CB-30/31/38 (30/50/40m)

CB-46/47/48 (30/50/100m)

CB-3/CB-4 (20m/50m)

VP-633/VP-634

Mobile Rack System

8/12-CH HD/SD-SDI inputs

27RU Mobile Rack System

SE-2800-8/12

TLM-170GR x 1

HDR-70 x 1

ITC-100 w/4 Belt pack

----

----

AD-100 with RMK-1

PD-2A

----

----

----

----

----

VP-445 x 1

27RU Mobile Rack System

VSM-100

RP-45A

PD-6

DDC-4012H (9-30V to DC12V)

PD-4A

MCU-200P/S

TLM-430 with Ball head

CB-22H/CB23H (30m/50m)

VP-605H

CB-30/31/38 (30/50/40m)

CB-46/47/48 (30/50/100m)

CB-3/CB-4 (20m/50m)

VP-633/VP-634

4

Mobile Video Studio

Camera Control System

Camera Control Unit

CCU-100

Multi Transmission Adaptor Box

AD-2

All in One Cable for CCU-100

CB-45

Lookback Monitor

TLM-430

Multi

Transmission

Adaptor Box

AD-2

Camera

Remote

Control

RMC-240

Headset

HP-1

Camera

How AD-2 connects with other devices:

1. TLM-430

2. HP-1/XLR Headset

3 .RMC-240

4. Camera

All In One

Cable for

CCU-100

CB-45

The camera control system CCU-100, AD-2 and

CB-45 provide a robust 70M all-in-one cable link between a professional camera and a digital video switcher system.

The system simultaneously transports digital SDI and analog signals as well as camera control, look back, camera view finder data, Tally and intercom call signals between the camera and switcher system.

Close look of

A D - 2 M u l t i

Transmission

Adapter Box and CB-45 All in One Cable for CCU-100

5

5

Mobile Video Studio

HD/SD 12-Channel

Mobile Video Studio

MS-2800

MS-2800 is a light weight video studio that is ready to go.

It’s designed around the SE-2800 switcher to work in high and standard definition. It’s perfect for outdoor events, conferences, education, places of worship and many more applications. It’s ideal for users that require a flexible but affordable system, a true one box ‘live in seconds’ studio solution with easy setup and break down at any location.

Model MS-2800A MS-2800B

Description

Configuration

Digital Video Switcher

17.3" Rack Mount LCD

HD/SD SDI Recorder

Intercom/Tally system

SDI Vector Scope

Audio Mixer and Delay Box

Power distributor (8-way)

Return Video (8-CH CV)

Camera Power Distributor

HD/SD SDI Amplifier

Rack System Integration

Options

Camera Power Regulator

Multi-Camera Control

Return Video LCD (CV)

SDI/CV/ITC/DC cable

CB-22H/23H Repeater

SDI/CV/ITC/Cat-5 cable

SDI/ITC cable

ITC/Tally cable

100m SDI Repeater

6

6

Mobile Video Studio

8/12-CH HD/SD-SDI inputs

8RU Flight Case

SE-2800-8/12

TLM-170GM x 1

HDR-70 x 1

ITC-100 w/4 Belt pack

----

AD-200

PD-2A

----

----

----

8RU Flight Case

DDC-4012H (9-30V to DC12V)

MCU-100P/S

TLM-430 with Ball head

CB-22H/CB23H (30m/50m)

VP-605H

CB-30/31/38 (30/50/40m)

CB-46/47/48 (30/50/100m)

CB-3/CB-4 (20m/50m)

VP-633/VP-634

Mobile Video Studio

8/12-CH HD/SD-SDI inputs

8RU Flight Case

SE-2800-8/12

TLM-170GM x 1

HDR-70 x 1

ITC-100 w/4 Belt pack

VSM-100

AD-200

PD-2A

RP-45A

PD-3A

VP-445

8RU Flight Case

DDC-4012H (9-30V to DC12V)

MCU-100P/S

TLM-430 with Ball head

CB-22H/CB23H (30m/50m)

VP-605H

CB-30/31/38 (30/50/40m)

CB-46/47/48 (30/50/100m)

CB-3/CB-4 (20m/50m)

VP-633/VP-634

Portable Video Studio

P o r t a b l e V i d e o S t u d i o

STUDIO IN A BOX

HD 6-Channel

Portable Video Studio

HS-2200

Model HS-2800 HS-2200 HS-600

Built-in Monitor

Display

Video Standard HD & SD

Video Format 1080i 50/59.94/60Hz

576i 50Hz, 480i 59.94Hz

Input Routable /

Crosspoint

Video Input

Computer

Graphic Interface

Down-converted output

Video output

Fixed

Standard:

8x SDI, 2x HDMI, 4x CV

Max:

12x SDI, 3x HDMI, 6x CV

Max 3 via HDMI

2x SDI

2x SDI assignable:

PGM, PVW, AUX & Clean Out

1x HDMI assignable:

PGM & Multi-view

Audio input

Audio output

4x Balanced XLR

2x Balanced XLR

Embedded audio support

Input up to 16 channels,

Output 4 channels

Audio Delay

Calibration

A+V switching

DSK

Up to 8 frames

Yes

2x DSK support Lumakey & Linear key

(Key / Fill)

Picture in Picture 2

Logo Insertion 2 (or 1 logo + 1 clock)

Built-in Audio

Mixer

N/A

Built-in Intercom

& Tally

Dimension

(LxWxH)

Weight

17.3” HD TFT LED back-lit, 1600x900 pix

HD

1080i 50/59.94/60Hz

720p 50/59.94/60 Hz

576i 50Hz,

480i 59.94Hz

All 6, repeatable

SD only

NTSC, PAL

All 8, repeatable

6x HD-SDI, 2x HDMI

(on CH5 & 6)

2 via HDMI

N/A

6x CV

1x DVI-D

1x DVI-I (VGA, need cable adapter)

Max 2 via DVI-D, HDMI or VGA (need cable adapter for HDMI & VGA)

N/A

5x SDI Outputs assignable:

AUX 1-4, PGM, PVW, PGM Clean or Multiview

1x HDMI assignable:

PGM or Multi-view

4x Balanced XLR

2x Balanced XLR

Input up to 16 channels,

Output 4 channels

2xCV + 1xY/C or 1x CV + 1x YUV: PGM

2xCV: AUX 1

2xCV: AUX 2

1xDVI-D: Multi-view

Option: 2x DV & 2x SDI

2x Balanced XLR (Line / Mic)

2x Unbalanced RCA (Stereo pair)

2x Balanced XLR

2x Unbalanced RCA (Stereo pair)

Output only (optional DV & SDI)

N/A

Yes

1x DSK support Lumakey & Linear key

(Key / Fill)

2

2 (or 1 logo + 1 clock)

N/A

Up to 700ms or 17 frames

Yes

1x Lumakey

2

2

3 channels

8 channels (4 belt-packs incl.)

455 x 355 x 134 mm

19.6 Lbs (9 Kg), Reinforce Plastic Case

7

7

Digital Video Switcher

HD/SD 12-Channel Digital Video Switcher

SE-2800

Digital Video Switcher

HD 6-Channel Digital Video Switcher

SE-2200

Model SE-2800 SE-2200 SE-1200MU

8

Video Standard

Video Format

HD & SD

1080i 50/59.94/60Hz

576i 50Hz, 480i 59.94Hz

Video Processing

Input Routable / Crosspoint

Video Input

Mix HD & SD source

Computer Graphic Interface

Video output

SDI: 4:2:2

HDMI: YUV 4:2:2, RGB 4:4:4

Fixed

Standard: 8x SDI, 2x HDMI, 4x CV

Max: 12x SDI, 3x HDMI, 6x CV

Yes

Max 3 via HDMI

3x SDI assignable:

PGM, PVW, AUX & Clean Out

2x HDMI assignable:

PGM & Multi-view

Down-converted output Yes, 2x SDI (CH2 & CH3)

Built-in Multi-view monitoring out 2x HDMI

Audio input 4x Balanced XLR

Audio output

Embedded audio support

Audio Delay Calibration

A+V switching

Chromakey

DSK

Picture in Picture

Logo Insertion

Still Store

Effects

Transition Preview

Sync / Reference In/Out

Tally Output

PC Remote Control

Built-in Audio Mixer

Special Features

Chassis

Power

2x Balanced XLR

Input up to 16 channels, Output 4 channels

Up to 8 frames

Yes

N/A

2x DSK support Lumakey & Linear key

(Key / Fill)

2

2 (or 1 logo + 1 clock)

12

FTB, Cut, 8 Wipe with border

PiP & DSK

Built-in Genlock

Support external sync with loop thru

1x D-sub 25pin, dual color

Via Ethernet (free Window software) or RS-

422 / RS-232

N/A

2-CH SD downconvert output

2 units, rack-mount mainframe

DC 12V 48W

HD

1080i 50/59.94/60Hz

576i 50Hz, 480i 59.94Hz

720p 50/59.94/60 Hz

SDI: 4:2:2

HDMI: YUV 4:2:2, RGB 4:4:4

All 6, repeatable

6x HD-SDI, 2x HDMI (on CH5 & 6)

N/A

2 via HDMI

6x SDI Outputs assignable:

AUX 1-4, PGM, PVW, PGM Clean &

Multi-view

2x HDMI assignable:

PGM & Multi-view

N/A

2x HDMI

4x Balanced XLR

2x Balanced XLR

HD

1080i 50/59.94/60Hz

720p 50/59.94/60Hz

SDI: 4:2:2

HDMI: YUV 4:2:2, RGB 4:4:4

All 6, repeatable

4x HD-SDI

2x HDMI (RGB/YUV, 1080i/1080p/720p)

N/A

2 via HDMI

2x HD-SDI & 2x HDMI assignable:

PGM(w/DSK 1&2), PGM(w/DSK 1),

PGM Clean, PVW(w/o DSK),

Multi-view, Input 1-6

N/A

HDMI & Ethernet (MJPEG)

2x Balanced XLR

N/A

Input up to 16 channels, Output 4 channels Only embedded analog audio

N/A N/A

Yes

N/A

1x DSK support Lumakey & Linear key

(Key / Fill)

2

Yes

2 Keyers

2x DSK support Lumakey & Linear key

(Key / Fill)

1

2 (or 1 logo + 1 clock)

6

FTB, Cut, 8 Wipe with border

PiP & DSK

Built-in Genlock

N/A

24

FTB, Cut, 32 Wipe with border

Full transitions preview

N/A

1x D-sub 25pin, dual color

Via Ethernet (free Window software) or

RS-422 / RS-232

N/A

6x6 Matrix seamless switch

2 units, rack-mount mainframe

DC 12V 32W

1x D-sub 15pin, dual color

Via Ethernet (free Window software) or RS-422

N/A

Motion JPEG Multi-view streaming

1RU Rack-mount

DC 12V 30W

8

Model SE-700 SE-600 SE-500

Video Standard

Video Format

Video Processing

Input Routable / Crosspoint

Video Input

Mix HD & SD source

Computer Graphic Interface

Video output

HD

1080i 50/59.94/60Hz

720p 50/59.94/60Hz

SDI: 4:2:2

HDMI: YUV 4:2:2, RGB 4:4:4

All 4, repeatable

2xHD-SDI

2xHDMI

N/A

2 via HDMI

2x HD-SDI & 1x HDMI assignable:

PGM(w/DSK),PGM Clean,

PVW (w/o DSK),Multi-view, Input 1-4

Down-converted output N/A

Built-in Multi-view monitoring out HDMI

Audio input 2x Balanced XLR

Audio output

Embedded audio support

Audio Delay Calibration

A+V switching

Chromakey

DSK

Picture in Picture

Logo Insertion

Still Store

Effects

N/A

Only embedded analog audio

N/A

Yes

2 (M/E keyer + PIP)

1x DSK

1

N/A

24

FTB, Cut, 32 Wipe with border

Transition Preview

Sync / Reference In/Out

Tally Output

PC Remote Control

Built-in Audio Mixer

Special Features

Chassis

Power

Full transitions preview

N/A

1x D-sub 15pin, dual color

Via Ethernet (free Window software)

N/A

N/A

Unibody

DC 12V 23W

SD

NTSC, PAL

SD

NTSC, PAL

4:2:2 4:2:2

2

2

All 8, repeatable

6x CV, 1x DVI-D (or HDMI)

1x DVI-I (or VGA)

N/A

2x DVI-D

2x Balanced XLR (Line / Mic)

2x Unbalanced RCA (pair)

2x Balanced XLR

2x Unbalanced RCA (pair)

Output only (optional SDI & DV out)

Fixed

4x CV or 4x Y/C

2 built-in down-converter on DVI-D & DVI-I input

2 via DVI-D, HDMI or VGA

2xCV + 1xY/C or 1xCV + 1xYUV: PGM

2xCV: AUX 1

2xCV: AUX 2

2xDVI-D: Multi-view

Option: 2x DV & 2x SDI

N/A

N/A

2x CV & 1x Y/C or 1x CV & 1x YUV

1x CV Quad PVW

N/A

1x CV

2x ¼” Mic jack

2x Unbalanced RCA (pair)

2x Unbalanced RCA (pair)

Up to 700ms / 17 frames

Yes

N/A

1x Lumakey

N/A

N/A

N/A

N/A

N/A

1

FTB, Cut, Mosaic, Paint, Monochrome,

14 Wipe with border

Transition & Effect

Built-in Genlock

1

N/A

N/A

Quad, Split, 11 Wipe with border

Yes

Built-in Genlock

2x D-sub 15pin, dual color

Via RS-422

3 channels

3 Macro Memory Preset

Unibody

DC 12V 33W

1x D-sub 15pin, dual color

Via RS-232

3 channels

N/A

Unibody

DC 12V 18W

9

9

Video Monitor

Model

Wide view angle

FULL HD

1080p

LCD

TLM-170P/PM/PR

LCD

Life time

50000 hours

TLM-170G/GM/GR TLM-702HD

10

Screen

Chassis

Loop Through

17.3" LED Back-Lit

Tabletop (170P)

1RU Pull-Out (170PM)

7RU Rack Mount (170PR)

1920x1080 Resolution

Viewing Angle (H) +80/-80°

(V) +60/-80°

Luminance/Contrast 400cd/m2

600:1

Video Inputs 1x 3G/HD/SD-SDI

2x HDMI

1x HD/SD-YUV

2x Composite Video

1x 3G/HD/SD-SDI

1x Composite Video

Supported Input

Resolutions

Aspect Ratio

Tally LED

Audio In/Out

Special Features

Power

1080p(23.98/24/25/30/50/59.9

5/60Hz), 1080i(50/59.94/60Hz),

720p(50/59.94/60Hz), 480i (NTSC), 576i

(PAL)

16:9, 4:3

Live (Red)

Cued (Amber)

Embedded Audio on SDI and HDMI

3 x Mono RCA Inputs Stereo Speakers

3G-SDI Support, Picture-in-Picture, Blue

Only, Audio Level Indicator, Safe Frame,

Pixel Zoom up to 8x, Network IP Remote,

SDI Time Code Display

DC 12V, 30 watts

17.3" LED Back-Lit

Tabletop (170G)

1RU Pull-Out (170GM)

7RU Rack Mount (170GR)

1600x900

(H) +40/-45°

(V) +45/-45°

220cd/m2

500:1

1x 3G/HD/SD-SDI

2x HDMI

1x HD/SD-YUV

2x Composite Video

1x 3G/HD/SD-SDI

1x Composite Video

1080p(23.98/24/25/30/50/59.9

5/60Hz), 1080i(50/59.94/60Hz),

720p(50/59.94/60Hz), 480i (NTSC), 576i

(PAL)

16:9, 4:3

Live (Red)

Cued (Amber)

Embedded Audio on SDI and HDMI

3 x Mono RCA Inputs Stereo Speakers

3G-SDI Support, Picture-in-Picture, Blue

Only, Audio Level Indicator, Safe Frame,

Pixel Zoom up to 8x, Network IP Remote,

SDI Time Code Display

DC 12V, 18 watts

2x7" LED Back-Lit

3RU Rack Mount

800x480

(H) +70/-70°

(V) +50/-70°

300cdm2

500:1

2x HD/SD-SDI

2x HD/SD-YUV

2x HDMI

2x Composite Video

N/A

1080i(50/60Hz)

720p(50/60Hz)

480i(NTSC)

576i(PAL)

16:9, 15:9, 4:3

Live (Red)

Cued (Amber)

Embedded Audio on SDI and HDMI

Audio Level Indicator, 2x Stereo

Headphone Jack

Blue Only, Safe Frame, SDI Time Code

Display, Audio Level Indicator, Safe Frame

DC 12V, 30 watts

10

Video Monitor

Model

TLM-430

DN-60A

TLM-700HD

RMC-200

4.3” LOOK-BACK SYSTEM

TLM-43LB

TLM-430+RMC-200

This innovative solution provides an excellent clear shot view for the cameraman.

Datavideo TLM-43LB camera look-back system is a combination of Datavideo TLM-430 4.3” Look-back LCD monitor, tally and intercom system, RMC-200 camera remote controller and an optional DN-60A CF card recorder for Sony, Panasonic and Canon camcorders.

SETUP DIAGRAM

TLM-430 DN-60A

REC/PAUSE

SELECT CAM/

LOOK-BACK VIDEO

TLM-434H

1

CAMERA REMOTE

ZOOM/REC/PAUSE

RMC-200

TLM-430

Screen

Chassis

7" LED Back-Lit

Camera Mount

4x4.3" TFT LCD

2RU Rack Mount

4.3" TFT LCD

Camera Mount

Resolution

Viewing Angle

800x480

(H) +70/-70°

(V) +50/-70°

Luminance/Contrast 300cdm2

500:1

Loop Through N/A

Video Inputs

Supported Input

Resolutions

Aspect Ratio

Tally LED

Audio In/Out

Special Features

Power

480x272

(H) +80/-80°

(V) +80/-80°

320cd/m2

400:1

4x HD/SD-SDI

480x272

(H) +80/-80°

(V) +80/-80°

320cd/m2

400:1

N/A

1x HD/SD-SDI

1x HD/SD-YUV

1x HDMI

1x Composite Video

1080i(50/60Hz)

720p(50/60 Hz)

480i(NTSC)

576i(PAL)

16:9, 15:9, 4:3

Live (Red)

Cued (Amber)

Embedded Audio on SDI and HDMI

Audio Level Indicator,

1x Stereo Headphone Jack

Blue Only, Safe Frame, SDI Time Code

Display, Audio Level Indicator, Safe Frame,

Image Flip, Can powered by batteries (Not

Included)

DC 12V, 18 watts

4x HD/SD-SDI

4x HDMI

1080i(50/60Hz)

720p(50/60 Hz)

480i(NTSC)

576i(PAL)

16:9, 4:3

Live (Red)

Cued (Amber)

Embedded Audio on SDI and HDMI,

Audio Level Indicator,

4x Stereo Headphone Jack

Blue Only, Embedded Time Code Indicator,

Safe Frame

DC 12V, 15 watts

2x Composite Video

480i(NTSC)

576i(PAL)

16:9, 4:3

Live (Red)

Cued (Amber)

N/A

Can be powered by DC adaptor, Sony batteries or D-TAP. TLM-43LB Camera look back system (with RMC-200 and control cable)

DC 12V, 6 watts

11

11

Converter/ Distribution Amplifier

Up/ Down/ Cross Converter

DAC-70

■ 3G/HD/SD Up/Down/Cross convert

■ Audio/HDMI/SDI/VGA input

■ 3G/HD/SD SDI and HDMI output

■ Can be rackmounted using optional

RMK-2 2RU Rackmount Kit

■ Heavy duty design, robust metal casing

Model DAC-70

■ Low power consumption

(30 ~ 50% less than regular converters)

■ Low heat dissipation, ideal for long hour operation in normal ventilated environment

DAC-60 DAC-50S

Conversion

Video Inputs

Loop Through

Video Outputs

Audio Inputs

VGA/HDMI/SDI to HDMI/SDI

Multi-format Up/Down/Cross

Sel.:

1x VGA, 1x HDMI,

1x 3G/HD/SD-SDI

Yes

2x 3G/HD/SD-SDI with embedded Audio

2x RCA (Stereo Pair), 1x HD

3G/HD/SD SDI to VGA

1x 3G/HD/SD-SDI

Yes

1x VGA

2CH SDI Audio embedded

HD/SD SDI to Analog

1x HD/SD-SDI

N/A

YUV + Composite or Y/C +

2x Composite

2CH SDI Audio embedded

Audio Outputs

Supported Video

Input Format

Output Resolutions

Equalizer

Reclock

SDI Cable Drive

Power

Remarks

2CH HDMI Audio embedded

2CH SDI Audio embedded

800x600 (60Hz),1024x768(60Hz),

1280x1024(60Hz),1366x768(60Hz),

1400x1050(60Hz), 1600x1200(60Hz),

480i (NTSC), 576i (PAL),

720p (50/59.94/60Hz),1080i (50/59.94/60Hz),

1080p(23.98/24/25/29.97/30/50/59.94/60Hz)

Sel.:

480i, 576i, 720p (50/59.94/60Hz)

1080i (50/59.94/60Hz)

1080p (23.98/24/25/29.97/30/50/59.94/60Hz)

N/A

480i (NTSC), 576i (PAL), 720p

(50/59.94/60Hz),

1080i (50/59.94/60Hz),

1080p (23.98/24/25/29.97/

30/50/59.94/60Hz)

2x RCA (Stereo Pair)

720p (50/59.94Hz),

1080i(50/59.94Hz),

1080p(50/59.94Hz)

Sel.:

800x600 (60Hz), 1024x768 (60Hz)

1280x800 (60Hz), 1280x1024 (60Hz),

1366x768 (60Hz), 1400x1050 (60Hz),

1600x1200 (60Hz), 1920x1080 (60Hz),

1920x1200 (60Hz)

Sel.:

480i, 576i

Yes

Yes

Yes

DC 12V, 7.2 watts

N/A

Yes

Yes

DC 12V, 3.6 watts

Yes

Yes

Yes

DC 12V, 6.0 watts

- Heavy duty design, robust metal casing

- Low power consumption (30 ~ 50% less than regular converters)

- Low heat dissipation, ideal for long hour operation in normal ventilated environment

- Supports wide range of 3G video formats including 1080p 50/59.94/60Hz (DAC-8P/9P/60/70)

- Supports YUV and RGB color space (DAC-8P/9P/60/70)

- Can be rackmounted using optional RMK-2 2RU Rackmount Kit

- Can be used with DAC accessories: MB-4 DAC Series Battery Holder, and MB-5 DAC Series Tripod Mount

2x6 3G HD/SD-SDI Distribution Amplifier

VP-597

1-4 HD/SD-SDI Distribution Amplifier

VP-445

12

■ 2 x 3G/HD/SD-SDI inputs

■ 6 x 3G/HD/SD-SDI distribution outputs

■ Supports embedded Audio SDI

■ Supports video formats:

- 3G-SDI | HD-SDI: 1080p 50/59.94/60/ 23.98/24/25/30

- SD-SDI 1080i 50/59.4/60/525i /625i/720p/50/59.94/60

■ Two input video sources can be controlled by A/B switch or GPI remote

12

■ Four way HD/SD SDI Distribution Amplifier with

Embedded Audio

■ Supports multi – standard

Operation SD-SDI (SMPTE 259M and SMPTE

344M)

■ Supports HD-SDI (SMPTE 292M)

Converter/ Accessory

2RU Rackmount Kit

RMK-2

■ Rackmount Frame to hold up to 8 DAC Converters

■ Built in power distributor for up to 8 converters

■ Suitable for DAC-8P, DAC-9P, DAC-60, DAC-70,

DAC-80 and future DAC converters

Model DAC-9P DAC-8P DAC-7

Conversion

Loop Through

Video Inputs

Video Outputs

Audio Inputs

HDMI to 3G/HD/SD SDI

N/A

1x HDMI

2x 3G/HD/SD-SDI with embedded Audio

2CH HDMI Audio embedded

Audio Outputs

Supported Video

Input Format

2CH SDI Audio embedded

480i (NTSC),

576i (PAL),

720p (50/59.94/60Hz),

1080i (50/59.94/60Hz),

1080p (23.98/24/25/29.97/

30/50/59.94/60Hz)

Output Resolutions Automatically matches the SD, HD and

3G HDMI video input

3G/ HD/SD SDI to HDMI

1

1x 3G/HD/SD-SDI

1x HDMI with embedded Audio

2 x RCA (Stereo Pair)

2CH SDI Audio embedded

2CH HDMI Audio embedded

480i (NTSC),

576i (PAL),

720p (50/59.94/60Hz),

1080i (50/59.94/60Hz),

1080p (23.98/24/25/29.97/

30/50/59.94/60Hz)

Automatically matches the SD, HD and

3G SDI video input

SD Analog to SD-SDI

N/A

Sel.:

1x CV, 1x YUV,

1x S-Video

2x SD-SDI with embedded Audio

2x RCA (Stereo Pair)

2x XLR (Stereo Pair)

2CH SDI Audio embedded

480i(NTSC), 576i(PAL)

Automatically matches the NTSC, PAL video input.

Equalizer

Reclock

SDI Cable Drive

Power

Remarks

N/A

N/A

Yes

DC 12V, 5 watts

Yes

Yes

Yes

DC 12V, 4 watts

N/A

N/A

Yes

DC 12V, 2.4 watts

- Heavy duty design, robust metal casing

- Low power consumption (30 ~ 50% less than regular converters)

- Low heat dissipation, ideal for long hour operation in normal ventilated environment

- Support wide range of 3G video formats including 1080p 50/59.94/60Hz (DAC-8P/9P/60/70)

- Support YUV and RGB color space (DAC-8P/9P/60/70)

- Can be rackmounted using optional RMK-2 2RU Rackmount Kit

- Can be used with DAC accessories: MB-4 DAC Series Battery Holder, and MB-5 DAC Series Tripod Mount

DAC Series Battery Holder

MB-4

DAC Series Tripod Mount

MB-5

VS-100 Battery Mount Kit

MB-6

Battery

SONY

NP-F970

SONY

NP-F770

BATTERY COMPARISON TABLE

SONY

BP-U60

SONY

BP-U30

Panasonic

CGA-D540

Canon

BP-975

JVC

BN-VF823

Model

7.2V/5400mAh

DAC-7 12W 190min

DAC-8P 4W 580min

DAC-9P 5W 460min

DAC-50 18W 120min

DAC-60 6W 380min

DAC-70 7.2W 320min

VS-100 3.6W 640min

7.2V/3000mAh

100min

320min

250min

70min

210min

180min

360min

14.4V/5200mAh 14.4V/2600mAh 7.2V/5400mAh

190min

1120min

890min

240min

740min

620min

1240min

180min

560min

440min

120min

370min

310min

620min

190min

580min

460min

120min

385min

320min

640min

7.4V/7350mAh

270min

815min

650min

180min

540min

450min

900min

7.2V/2190mAh

70min

230min

180min

50min

150min

130min

380min

13

13

Digital Video Recorder

Hand Carry Recorder System

HRS-30

HRS-30 is a new portable recorder and player, which can be used on the field. A removable hard drive base recorder is integrated with one 10.1” monitor for mobile recording. HRS-30 and the HS-2800 switcher can be combined into one complete system for use on any field site.

The HRS-30 records from both High and Standard Definition video equipment via

HD/SD-SDI. The HRS-30 supports 1080i, 720p, 576i, 480i video formats and provides a choice of recording formats in MEPG-II Long-GOP or intra-frame (i-frame) with 4:2:2 color sampling. The recorded MXF/

OP1A file format is compatible with a wide range of NLE and play out systems. Storage by a removable hard drive and compatible with 2.5’’ HDD &

SSD drives.

Model HRS-30 HDR-60 HDR-70 DN-600 DN-700

14

Video Standard

Video Format

Supported Video

Input Signal

Monitoring/

Playback output

Analog Audio Input

& Audio Output

HD & SD

1080p 23.97/24Hz ,

1080i 50/59.94/60Hz

720p 50/59.94/60Hz ,

525i/ 625i

1x SDI

1x SDI (input loop thru)

1x HDMI, 1x SDI (Out)

N/A (input)

3.5Ø phone jack (output)

HD & SD

1080p 23.97/24Hz ,

1080i 50/59.94/60Hz ,

720p 50/59.94/60Hz ,

525i/ 625i

1x SDI

1x SDI (input loop thru)

1x HDMI, 1x SDI (Out)

2x Balanced mini

XLR (Stereo pair)

2x Balanced XLR

(Stereo pair)

SD & HD-ready (HDV)

SD: NTSC, PAL

DV/DVCPro25: 576i 50Hz, 480i 59.94/60Hz

HDV: 1080i 50/59.94/60Hz, 720p

50/59.94/60Hz

1x CV

1x DV / HDV (IEEE1394 6-pin)

1x CV

1x DV / HDV (In/Out share)

2x Balanced XLR (Stereo pair)

2x Unbalanced RCA (Stereo pair)

Embedded Audio SDI Input / Output (8CH )

HDMI Output (8CH)

Storage Medium Max capacity 750GB on HDD

SSD: 120GB / 256GB (recommend)

Estimated Record

Time (min per 10GB)

How to Retrieve

Recorded Content

Recorded File

Format

Video Recording

Bit Rate/ Color

Sampling

Audio Recording

Format

Time code in/out

External Sync/

Genlock

SD: 22 (50Mbps) ~ 75 (8Mbps)

HD: 10 (125Mbps) ~ 68 (10Mbps)

Removable Hard Drive / SSD, transfer data via USB 2.0

Storage File System NTFS

MXF OP1A, MOV

Both In & Out (8-CH on SDI & 4-CH on HDMI)

2.5” Hard Drive / SSD*, Max capacity 750GB

DV / HDV In/Out (2-CH)

2.5” Hard Drive / SSD*, Max capacity 750GB

SD: 22 (50Mbps) ~ 75 (8Mbps)

HD: 10 (125Mbps) ~ 68 (10Mbps)

Removable Hard Drive / SSD, transfer data via

USB2.0

SD / DV: 46

HDV: 50 (1080i) ~ 65 (720p)

- Removable Hard Drive/ SSD,

transfer data via USB2.0

- transfer via IEEE1394

(Firewire, in HDD mode)

NTFS (read/write on Window, read only on MAC) NTFS (read/write on Window & MAC)

FAT32 (read/write on Window & MAC)

MXF OP1A, MOV

SD / DV: AVI, MXF OP1A, MOV

HDV: M2T

SD / DV: 25Mbps, 4:2:0

DVCPro25: 25Mbps, 4:1:1

HDV: 25Mbps, 4:2:0

Uncompressed PCM

MPEG2 Long GOP HD:

1. 10Mbps 4:2:0 1440x1080/1280x720,

2. 25Mbps 4:2:0 1440x1080/1280x720,

3. 35Mbps 4:2:2 1920x1080/1280x720,

4. 50Mbps 4:2:2 1920x1080/1280x720,

5. 65Mbps 4:2:2 1920x1080/1280x720,

6. 120Mbps 4:2:2 1920x1080/1280x720,

MPEG2 Long GOP SD

1. 8Mbps 4:2:0 720x480/720x576 (to be F/W upgrade)

2. 15Mbps 4:2:2 720x480/720x576

3. 30Mbps 4:2:2 720x480/720x576

4. 50Mbps 4:2:2 720x480/720x576

MPEG2 I-Frame Only HD

1. 80Mbps 4:2:2 1920x1080/1280x720

2. 100Mbps 4:2:2 1920x1080/1280x720

3. 125Mbps 4:2:2 1920x1080/1280x720

MPEG2 I-Frame Only SD

1. 25Mbps 4:2:2 720x480/720x576

2. 50Mbps 4:2:2 720x480/720x576

Uncompressed PCM

Sampling rate 48KHz 24bit

Yes

Black Burst & Tri-level w/loop thru

Yes

Black Burst & Tri-level with loop thru

Power failure protection Content saved up to last second before power failure

Chassis Desktop Desktop 1RU 19” rack-mountable

MPEG-1 Layer 2, 384kbps

Sampling rate 48KHz (16bit),

32KHz (12bit)

Yes

N/A

Desktop 1RU 19" rack-mountable

* Check compatible storage on the Datavideo website

14

Digital Video Recorder

Highlight Replay Recorder

HDR-10

The HDR-10 is an Event/Replay recorder that can mark and record compelling scenes during a game or show, then replay it on your switcher.

This is a single channel recorder with a removable hard drive (compatible with 2.5" SSD drives), that can record from both High and Standard Definition video equipment via 3G/HD/SD-SDI and supports 1080p, 1080i, 720p,

576i, and 480i video formats.

The LISN (Local Interconnect Synchronous Network) connector allows you to connect the HDR-10 and an inline controller. It can also connect another HDR-10 to cascade up to 8 sets of HDR-10's at the same time.

Model DN-60A HDR-10

Video Standard

Video Format

SD & HD-ready (HDV)

DV/DVCPro25/DVCpro50: 576i 50Hz, 480i 59.94/60Hz

HDV: 1080i 50/59.94/60Hz, 720p 50/59.94/60Hz

Supported Video Input

Signal

Monitoring/ Playback output

Analog Audio Input &

Audio Output

Embedded Audio

Storage Medium

Estimated Record Time

(min per 10GB)

How to Retrieve

Recorded Content

Storage File System

1x DV / HDV (IEEE1394 6-pin)

1x DV / HDV (In/Out share)

N/A

DV / HDV In/Out (2-CH)

Compact Flash card*

SD / DV: 46

HDV: 50 (1080i) ~ 65 (720p)

Removable CF card, transfer via card reader

NTFS (read/write on Window & MAC)

FAT32 (read/write on Window & MAC)

Recorded File Format

Video Recording Bit

Rate/ Color Sampling

SD / DV: AVI, MXF OP1A, MOV

HDV: M2T

SD / DV: 25Mbps, 4:2:0

DVCPro25: 25Mbps, 4:1:1

DVCPro50: 25Mbps, 4:2:2

HDV: 25Mbps, 4:2:0

Audio Recording Format MPEG-1 Layer 2, 384kbps

Sampling rate 48KHz (16bit), 32KHz (12bit)

Time code in/out Via embedded DV/HDV only

External Sync/Genlock N/A

Power Failure Protection Content saved up to last second before power failure

Chassis Handheld, Camera-mountable via Ball-head

HD & SD

720p 50/59.94/60

1080i 50/59.94/60

1080p 23.976/24

1080p 50/59.94/60

480i/576i

1xSDI

2xSDI

N/A

SDI Input

Internal 4GB Buffer

N/A

Removable Hard Drive / SSD, transfer data via USB 2.0

NTFS (read only)

MOV

Uncompressed 10-bit

4:2:2

Uncompressed PCM

Via embedeed SDI only

LISN

(Local Interconnect Synchronous Network)

N/A

Desktop/Unibody

Rack-mountable with RMK-2 2U Rackmount Kit

15

15

Character Generator

Portable CG Solution

HD / SD Character Generator Kit

TC-200+CG-200

The combination of the TC-200 overlay unit and CG-200 brings broadcast-quality live titling to the laptop.

Users can now create beautiful motion graphics in realtime without the need for a dedicated workstation - it's a significant breakthrough.

■ Includes TC-200 (Title Creator) & CG-200 (Character

Generator Software)

■ Supports DSK function (via HDMI) or SDI overlay function

■ Support HD/SD SDI input and output in Overlay mode

■ Supports HD video with 1080i 50/59.94/60; 720p

50/59.94/60

■ Compatible with Windows 7/8

■ Supports all Windows fonts

■ Multi-language support

■ Supports animation including JPG, TAG, GIF, BMP, PNG

CG-200

HD/SD Character

Generator Software

TC-200

Title Creator

■ Title editing patterns include Slide, Reveal, etc.

■ Supports scrolling

■ Easy logo set up

■ TC-200 working voltage is 7-15V. It can be used with

7.2 V & 14.4 V batteries

Switcher

CG-250 (Optional)

Special Features of CG-250

■ A variety of CG templates and text font choices

■ Supports Live 3D graphic

■ Key frame control

■ Supports countdown clock and sport scoreboard

CG-250 Example

16

16

CG-200 Example

Character Generator

HD/SD Graphic & Character Generator

CG-500

The Windows based Datavideo CG-500 graphics, titling, and character generator software is a powerful multi-layer, real-time solution for live programming and post production. It is compatible with widely available professional video hardware and supports the flexible play-out of multiple playlists, or Datavideo's TC-200 device while titles are being created. CG-500 can be used for SD or HD news, reports, weather forecasts, and entertainment programming.

Hundreds of key frame based GPU effects, such as

Swirl, Explode, and Linear Light can be rendered in real-time. The software features innovative group and text playing by character, by line, and by text, with fully dynamic textures.

Applications

Model CG-500 CG-350 CG-250 CG-200 CG-100

SD resolution

HD resolution

Manual playout control

Playlists

Animated logo / sequence

Scheduling

Dynamic Data integration

Database integration

Live 3D graphics

Fast graphics rendering

Template-based

Media library

Keyframe control

Capture Video Frame

Recommended Video Card for both Internal/External key

Datavideo TC-200

Decklink 4K Extreme

Datavideo TC-200

Decklink 4K Extreme

Datavideo TC-200 Datavideo TC-200

Decklink SDI / Studio

17

17

Teleprompter

DV Prompter

TP-300

Protective Cases

HC-300/HC-500/

HC-600

A teleprompter allows a presenter to look into the camera lens and read a script from a reflected screen equipped with beam-splitter glass. Most teleprompters are for use in the studio but the Datavideo TP range can be used anywhere!

Convert Apple or Android smartphones and tablets into cost-effective and easy to use prompter solutions. Scripts can be easily loaded, character’s font, size, color and scrolling speed are all adjustable.

Wired and optional Bluetooth remotes allow users to control the speed to achieve natural results.

Model TP-300 TP-500 TP-600

The dv prompter application is available to download

Free from Apple™

App Store™ & Google

Play.

DVP-100

18

Product Name Tablet Prompter

(HD/SD Camcorders used)

Device Used

Camera-Mount

Interface

Smartphone/

Tablet Size

Apple iPads

Android Tablets

Prompter Frame

Min. Tablet Width: 105mm

Max. Tablet Width: 198mm

DSLR Prompter

Apple iPads

Android Tablets

Adjustable Camera Plate

Min. Tablet Width: 105mm

Max. Tablet Width: 198mm

ENG Prompter

Apple iPads

Android Tablets

Prompter Rail

Min. Tablet Width: 105mm

Max. Tablet Width: 198mm

Wireless Prompting System

Features

• Multiple prompter screens kept in perfect sync

• Remote control and script management over IP

(WiFi/Ethernet)

• IOS and Android Apps available

Multi-language support

Hood Dimension/

Prompter Size

Width: 250mm

Height: 210mm

Depth: 447mm

Device dependent including Arabic and Asian languages such as Chinese, Japanese, Korean, Hindi, Tamil and more

Width: 250mm

Height: 210mm

Depth: 447mm

Width: 250mm

Height: 210mm

Depth: 447mm

Remote Control Wired Remote (inclusive) with headset jack input for Apple iOS devices and some Android devices

*Optional Universal Bluetooth Wireless Remote (with USB cable adapter for charging purposes)

Net Weight 1.9 Kg 1.9 Kg 1.9 Kg

Yes,

10/100Mbps Ethernet Port

0.47 Kg

18

HD/SD-SDI PTZ Camera

HD/SD-SDI PTZ Camera

PTC-150

HD/SD-SDI PTZ Camera

PTC-120

Control Unit

RMC-180

Control Unit

RMC-190

Model

1-4 Camera Control

PTC-150 PTC-120

1-7 Camera Control

Video format

Image Sensor

Effective Pixels (approx.)

Min. Illumination

Electronic Shutter

Zoom Ratio

Gamma

Iris Control

Digital Noise Reductions

White Balance

AGC / Gain Control

Mirror / Flip Image

Focus Mode

Panning/Tilting Range

Panning/Tilting Speed

Preset

Field of View (Horzontal, Wide)

Image Compensation

Video Output

Tally LED

Remote Control Interface

Model

1080p 59.94 /50 /30 /29.97 /25 Hz

1080i 59.94 /50 Hz

720p 59.94 /50 Hz

480i, 576i (on CVBS)

1/2.8 type MOS

2 Megapixels

Color: 0.4 Lux, B/W: 0.03 Lux

1/50~1/2,000 sec

22x Optical zoom

Yes, 4 modes

Auto / Manual

Yes

AWB / AWC / Manual (Adjustable R and B signals)

Outdoor / Indoor / Fluorescent

Low1 / Low2 / Low / Mid1 / Mid / High1 / High / OFF

(Gain adjustable)

Mirror / Flip Image

Yes

Auto / Manual / One-Push / STOP-AF

Pan: 270° , Tilt: +90° to -20°

1~150°/Sec

50 Position

65.1°

Dehazing, Day & Night function

3G-SDI x 1

HDMI x 1

CVBS x 1

Dual color

RS-422, DVIP (RJ45)

RMC-180

1080p 60 /50 /30 /29.97 /25 Hz

1080i 60 /50 Hz

720p 60 /50 Hz

480i, 576i (on CVBS)

1/2.8 type MOS

2 Megapixels

5 Lux

1/1 ~ 1/10,000 sec

20x Optical zoom ; 12x Digital zoom

Yes, 4 modes

Auto

2D & 3D

Auto / Indoor / Outdoor / One-Push / Manual

Auto / Manual

Yes

Auto / Manual

Pan: 340° , Tilt: +90° to -30°

1~300°/sec

128 Position

63°

Backlight, Exposure

3G-SDI x 1

DVI-D x 1

Component x 1

CVBS x 1

N/A

RS-232 & RS-422

RMC-190

Maximum Camera Control

Preset Position

Control Protocol

Connection to Cameras

4

4 for each camera

Sony VISCA

Point to Point

7

128 for each camera

Sony VISCA

Daisy Chain

19

19

Camera Controller

Multi-camera Control Unit

MCU-100P MCU-100S

MCU-100 and MCU-200 are designed to control up to four camcorders in studio multicam configuration, giving the producer the ability to match and manage the settings of multiple cameras.

Small, compact and light weight, the handheld unit

MCU-100 and the rack-mounted MCU-200 control all major image settings, such as iris, master pedestal and gain. They are easy to use in a pressurized environment, giving the camera operator the freedom to concentrate on framing each shot.

■ Wide range of control functions include:

- Gain Up/Down

- Output Cam/Bar Selection (linked to Auto Knee)

- White Balance A/B/Preset, AWB/ABB Execution

- Shutter SS/Fix/Off Selection and Speed Setting

- Iris Auto/Manual Selection and Adjustment

Multi-camera Control Unit

MCU-200P/S

- Master Pedestal, Painting

- Camera Menu Operation, Recorder Operation

(Rec/Play/FF/Rew/Rec Check)

- User Buttons (3), Character On/Off)

■ Memory function for camcorder settings

■ USB interface for firmware update

■ Remote control distance up to 1000m

■ Bundled with four remote control cable adapters

■ Supported Panasonic camcorders:

AG-HPX255, AG-HPX600, AG-HPX370 / 371 /

372, AG-HPX300 / 301 / 302 /304 / AJ-HPX2700G

/ AJ-HPX3000 / AJ-HPX3700

■ MCU-100S Supports Sony HDCAM, Digital

BETACAM, and XDCAM camcorders.

20

Connecting the MCU-100S/100P/200

Connect AD-1 adapter to the camera’s CAM/BS port.

Connect an ethernet cable from the AD-1 to the MCU.

Parameters can viewed by connecting monitors to each AD-1 adaptor using a CVBS cable. MCU-100 and MCU-200 utilize locking power connectors.

20

Camera Remote Adaptor

AD-1P/S

(4 Included)

Video Streaming Server/ IP Video Decoder/ Network Controllable Media Player

H.264 Video Streaming Server

NVS-25

SDI SDI

NVS-25 is a small, easy-to-use video streaming and recording appliance designed for professional video producers who need to simultaneously stream a live event and record the master quality version for post-event editing. From any HDMI / SDI / CVBS input source such as a camera or switcher, NVS-25 generates an H.264-encoded stream compliant with RTSP / RTMP / HLS protocols. While encoding the video for live streaming, NVS-25 can simultaneously records a MP4 or .TS file to a USB storage device. NVS-25 is remotely controlled using Windows / Apple PC or mobile device with a web browser. Flexible mechanism design for desktop application or 1RU rack mount application.

■ Broadcast quality HD / SD H.264 network streaming

■ H.264 / AVC video CODEC, up to High Profile

Level 4.0

■ Input source: NVS-25 can accept SDI / HDMI /

CVBS source input.

■ Flexible source input: Analog audio input for 2 channels (This analog audio input supports audio source selection e.g. not only for CVBS analog audio, but also accept SDI or HDMI audio such as when you use PTC-150 to take video, the audio must come from somewhere). SDI and HDMI can also select embedded audio.

■ Network feature: Support DHCP Client, RTSP over TCP/UDP/

HTTP with MPEG TS. RTMP, HLS protocols. Unicast Only.

■ Flexible video scaler presets for streaming out

■ Supports 3 types of GOP structure: IBBP, IPPP and IBP.

■ Web UI for system configuration and FW upgrade.

■ Support De-interlace video streaming output.

■ Storage by USB device (Up to 1TB storage device).

IP Video Decoder

NVD-20

Network Controllable Media Player

NVP-20

A wired IP video decoder with HDMI, Composite and analogue audio outputs. The NVD-20 decodes all common IP streams including RTP/RTSP,

RTMP, UDP, TCP, HTTP and MPEG-TS and can output SD/HD video at resolutions up to 1080p60.

The NVD-20 is the perfect partner to the Datavideo

NVS-20 IP encoder allowing full HD point to point video links over Ethernet, WiFi or the Internet.

■ Operates on standard 10/100Mb Ethernet networks

■ Excellent image quality with very low delay

■ Unicast and multicast support

■ Supports RTSP over UDP (Unicast/Multicast),

RTSP over TCP, RTSP over HTTP, MPEG-TS over UDP, RTMP over TCP, UDP raw (Unicast/

Multicast), HLS over HTTP

■ Feature-rich WebUI for configuration and control

■ Built in video scaler

■ Supports Full HD video and audio

■ Supports HDMI and Composite video output

■ Supports simultaneous digital embedded and analogue audio output

■ Small form factor, rack mountable using RMK-1

■ 12V DC input

The Datavideo NVP-20 is a fully automated remote control H.264 video player. The NVP-20 can use any USB storage device as its media source; Video files can then be added to the media player by physically copying them to the USB device or can be transferred over the network using FTP.

Using the feature rich web interface, the user can create and load playlists as well as remotely controlling video playback. With the addition of a USB keyboard, the NVP-20’s on screen display means the unit can be used completely standalone without IP control.

Video playback can also be triggered via GPI.

■ Operates on standard 10/100Mb Ethernet networks

■ IP and GPI control

■ Support multiple playlists

■ Excellent image quality up to 1080p60

■ Supports mp4, H.264,.mkv,.mov,.TS

■ IP control supports play next clip, play all clips, loop play all clips, pause, resume and seek

■ Supports NTFS and FAT/FAT32 formatted USB storage

■ Feature-rich WebUI for configuration and control

■ Built-in video scaler

■ Supports Full HD video and audio

■ Supports HDMI and Composite video output

■ Supports simultaneous digital embedded and analogue audio output

■ Small form factor, rack mountable using RMK-1

■ 12V DC input

21

21

Wi-Fi Bridging Unit

High Power Wi-Fi Bridging Unit

NVW-150

NVW-150 is a miniature carrier class WiFi distribution system. Users can connect any network enabled devices via Ethernet to NVW-150 which can then transparently link to a second NVW-150 or NVW-250 with a range of over 250m with the supplied antenna.

■ Connect any network (IP) enabled devices through a long and high range WiFi link

■ Completely transparent, devices connected to either end of the

WiFi link will behave exactly as they would if they were connected directly with an Ethernet cable

■ Multiple units can be used together (Point to Multipoint)

■ Supports transmission speeds up to 450Mb/s

■ Supports transmission distances greater than 250m with the supplied antenna (further with optional external antennas).

■ Automatically adjusts transmission rates based on current conditions to maintain link stability

■ Supports narrow channel widths for increased range and interference immunity

■ Can be powered from any DC source (5-20V), 9-24V Passive POE supported

■ Wireless profit supports NA (5Ghz 802.11a/n)

■ No radio licences required

Dual Radio High Power Wi-Fi Bridging Unit

NVW-250

Housed in a rugged case, NVW-250 is a high-power dual radio WiFi distribution system and local WiFi access point. It transparently links with Datavideo NVW-150/250 units and delivers a range of over 500m with the supplied antennas (further with optional external antennas). It creates a local hotspot to connect devices via WiFi and Ethernet.

22

■ Dual radio design allows one radio to be used for the backhaul between bridging units and the other as a local access point.

■ Ideal for covering larger distances, directional antennas can be used to connect bridging units while the local access point still allows free Omni-directional roaming at each end.

■ Supports transmission distances greater than 500m with standard antennae / 10KM with external antennae

■ Wireless profit supports either NA (5Ghz 802.11a/n) or NG (2.4Ghz

802.11g/n). For increased devise compatibility, it is recommended to use NG for the local access point.

■ Dual V-mount battery slot for extended battery life

■ Regulated 12V 5A XLR power output for powering external devices

■ No radio licences required

22

REAR PANEL

LAN LAN

SIDE PANEL

LAN POWER

Intercom/ Tally System

Intercom System

ITC-100

Communication between the director, camera crew, lighting engineer and control room is essential to produce a polished end result. The ITC-100 Intercom system provides 8-way talkback and tally indicators.

The producer can talk to an individual channel or to all channels simultaneously.

High S/N ratio makes the communication crisp and clear.

The ITC-100 is a standard 19/1RU rack design, so it is easy to integrate into any rack system for using in the field or studio.

■ Standard 19/1RU rack design

■ Supports 8-Way talkback (standard package includes 4 sets of ITC-100SL with belt-pack accessories)

■ Additional external earphone and microphone interface

■ Dual color tally light indicator

■ Selectable channel talk, broadcast to all or mute

■ Communication distance up to 200m

■ Supplied complete with gooseneck mic and light

Intercom Expansion Unit

ITC-200E

The ITC-200E provides an additional 4 channels to existing

Datavideo ITC-100 Intercom systems. Connecting with the

ITC-100 gives up to 12 additional intercom channels.

Setup Diagram

ITC-100

A

B

C

D

ITC-200 E

SE-2800

INTERCOM

+TALLY

INTERCOM

+TALLY

23

23

Chromakeyer

Live HD/SD Chromakeyer

DVK-300HD

DVK-300HD is easy and intuitive to use, delivering great results even in the most challenging environments.

Most HD chromakey systems are either complex computer-based solutions or included in vision mixers with limited keying features. The DVK-300HD is ideal for users that simply need professional featured and affordable live keying in a portable device.

DVK-300HD can be used by a computer to connect directly or remotely over an IP network.

HDMI and SDI inputs make the DVK-300HD perfect in any live environment, it includes a range of resolutions like, traditional SD resolutions and up-to full HD 1080p.

Dual Color Chromakey Kit

CKL-300

RF-1025+LD-1

Highly

Retro-Reflective

Cloth

RF-1025

Dual Color

LED Light Ring

LD-1

Datavideo CKL-300 is a combination of a dual color (green & blue) LED ring, light controller and a unique 3 x 0.9m (w) x 2.5m

(h) retro-reflective backdrop cloth, which is embedded with tiny glass beads.

The LED light ring is mounted on the lens of the camera, and projects a highly directional green or blue light on the backdrop cloth. Thanks to the reflective beads, light is then projected back to the camera creating a perfect green or blue background, providing you with excellent keying results with minimal effort.

■ Light ring lens size 72 mm (stepping rings 52-82mm available from resellers)

Model DVK-300HD DVK-200

Video Standard

Video Format

Foreground Inputs

Background Inputs

Loop Through

Output

Keying Options

Key Mask/ Spill Correction/

Edge Correction

Color Processor

24

Noise Reduction

User Preset

GPI In/Out

Controlled Via

Chassis

3G/HD/SD

1080p (25/30/50/59.94/60 Hz)

1080i (50/59.94/60 Hz)

720p (50/59.94/60 Hz)

480i (NTSC), 576i (PAL)

Autodetect

1x 3G/HD/SD-SDI

1x HDMI (1.4)

1x 3G/HD/SD-SDI

1x DVI-I

N/A

2x 3G/HD/SD-SDI

1x HDMI

Chormakey Green / Blue, Lumakey

Yes

Foreground: Brightness, Contrast, Saturation, Ambient

Intensity

Yes

4

N/A

Ethernet

1RU 19" Rack-mount Design

SD

480i (NTSC), 576i (PAL) selectable

1x Composite Video

1x Y/C (S-Video)

1x YUV (Component)

1x DVI-I

1x Y/C (S-Video)

1x Composite Video

CV, YUV & Y/C only

2x Composite Video

1x Y/C (S-Video)

Chormakey Green / Blue, Lumakey

Yes

Foreground & Background: Brightness, Contrast,

Satuation, Tint

N/A

2

Yes

Front Panel, RS-232

2RU 1/2 Rack Design

24

Virtual Studio System

Trackless Virtual Studio System

TVS-1000

The TVS-1000 is a 5 in 1 design which consists of trackless virtual studio system, video switcher, character generator, video recorder and web streaming encoder. It's a versatile, easy to use and cost-effective solution. TVS-1000 is suitable for production companies, corporate producers, users in education, small studios and TV stations.

As a virtual studio solution, TVS-1000 supports pan, tilt and zoom camera movements for a dynamic effect. The builtin Virtual Set Maker allows users to fully customize their sets: background images can be inserted with ease, logos can be added to any surface and video can be run in the backdrop. In addition, professional studio templates can be downloaded on http://www.datavideovirtualset.com

Web

Streaming

Virtual

Studio

Switcher

TVS-1000

Recorder

CG

■ Five in One: Virtual Studio, Switcher, Charter Generator, Recorder and Web

Streaming

■ Use just one HDMI input: four virtual studio angle), each angle supports 3 phases (pan, tilt, zoom type movements)

■ Support additional TVS-AUX Card to have one more input

■ Mini phone jack audio input, audio embedded to PGM HDMI output.

■ 2 x DSK to add CG and animation to the scene

■ Edit the background: add graphics or videos in the background

■ Chroma Key function delivers perfect keying

■ 30 free set virtual set backgrounds are included

■ Free TVS-1000 control panel (RMC-220) is included

■ Virtual set maker software is included. Easy to create your own style virtual set

Applications

TV Station School Personal Studio

25

25

Virtual Studio System

TVS-1200 Functions

TVS-1200 Key Function

Two SDI camera inputs and two chromakeyers create more flexibly and creative video. TVS-1200 is perfect to use in talk show and broadcast market.

26

■ Two SDI inputs to create four virtual studio angels. Each angle support 3 phases (Pan, tilt, zoom type movement)

■ Two SDI outputs

■ Tally Signal and mini phone jack supported.

26

Virtual Studio System

TVS-1200/ TVS-1000 Functions

TVS series provides free virtual set maker software for you to create your own virtual set.

30 virtual set backgrounds

Included with TVS-1000/ TVS-1200 datavideovirtualset.com

Download professional virtual set backgrounds from the datavideovirtualset.com

TVS Main Unit with Control Panel RMC-220

RMC-220 TVS control panel provides users with easy control of the TVS Virtual Studio System by mimicking a switcher interface.

The RMC-220 has also been equipped with 10 function keys, which can directly trigger the assigned function by pressing the corresponding key.

TVS-AUX card (Optional)

The TVS-AUX capture card is specially designed for displaying media files via the

HDMI port. It supports files from popular applications such as PowerPoint and various media players. The TVS-AUX card can be used by the TVS-1000 and TVS-1200 systems.

Specification

Video Input

Video Output

Video Input Format

Audio Input

Tally

Downstream Key

Media

Virtual Studio

Still Picture

Still Text

Keyer

Recording

Live Streaming

Hard Disk Capacity

TVS-1000

HDMI x1

HDMI x 1

1080 30P/29.97P/25P

1080 60i/59.94i/50i

720 50P/59.94P

Mini Phone Jack x 1

HDMI audio embedded

NO

2

2(DDR)

30 sets

2

2

(20 sets included+10 sets free download)

Chromakey/ Luminance key

H.264/ MPEG-2

TS HTTP

TS RTP

TS UDP

TS RTSP

FLV HTTP

FLV RTMP

1TB

TVS-1200

SDI x 2

SDI x 2

1080 60P/59.94P/50P

1080 60i/59.94i/50i

720 60P/59.94P/50P

Mini Phone Jack x 1

SDI audio embedded

YES

2

2(DDR)

30 sets

2

2

(20 sets included+10 sets free download)

Chromakey/ Luminance key

H.264/ MPEG-2

TS HTTP

TS RTP

TS UDP

TS RTSP

FLV HTTP

FLV RTMP

1TB

TVS-AUX

HDMI x1

HDMI x 1

1080 30P/29.97P/25P

1080 60i/59.94i/50i

720 50P/59.94P

Mini Phone Jack x 1

HDMI audio embedded

NO

27

27

28

28

Test & Measurement Sampling Vector Scope Monitor

Sampling Vector Scope Monitor

VSM-100

Accurate video signal analysis and calibration has always been crucial to any live production.

Datavideo VSM-100 and VSM-200 waveform / vectorscope monitor series seamlessly integrate into a compact 19 rack system to ensure consistent and legal color and luminance video levels. At 2RU, they are perfect for use in a production van or any space-limited setup.

VSM-100 has a single waveform / vectorscope unit while

VSM-200 features dual scopes. Both models come with two

LCD screens, thus no external monitors are required; as such it’s highly cost effective.

■ VSM-100: one waveform / vectorscope unit with two 4.3inch HD monitor screens

■ VSM-200: two waveform / vectorscope unit with two 4.3inch HD monitor screens

■ Sampling Vectorscope

- HD/SD-SDI input

- HDMI and HD/SD-SDI output, SDI output can be assigned as video source loop out or vectorscope display

- Auto-detect NTSC, PAL and HD signals

- Support four analysis modes: Waveform, Vectorscope,

Parade (YCrCb & RGB) and Histogram

- Save and Recall traces for easy comparison of different video signals

- Video input thumbnail with selectable 16:9/4:3 aspect ratio

- Vectorscope reticle can be toggled between 75% and

100%

- Waveform detail can be zoomed 20%, 40%, 60% and

100% - Adjusting Horizontal Delay to view parts of the waveform

- Support embedded audio with on-screen audio level meter for up to 8 selecteable channels

■ Monitor screens

- Each monitor has one HDMI and one HD/SD-SDI input with loopthrough output

- Auto-detect NTSC, PAL and HD input signal

- Individual adjustments of Brightness, Contrast, Color

Saturation and Back Light Level for each monitor

- Support Blue Only function, Safe area marking and

Timecode display

- Support embedded audio on SDI, HDMI

- Audio monitoring via on-screen audio level indicator and front panel headphone jacks

-4:3 & 16:9 display mode switching

■ Standard 19-inch rack size, 2RU height, easy for system integration

VS-100 VS-150 VSM-100 VSM-200

Video Inputs

Video Outputs

Loop Through

Audio Inputs

Audio Outputs

Input Resolutions

Additional I/O

Waveform/ Vector Scope

1x HD/SD-SDI

1x HDMI

1x HD/SD-SDI

Waveform/ Vector Scope

1x HD/SD-SDI

1x HDMI

1x HD/SD-SDI

Waveform/ Vector Scope

1x HD/SD-SDI

1x HD/SD-SDI

N/A

Embedded Audio through SDI interface

Waveform/ Vector Scope

2x HD/SD-SDI

2x HD/SD-SDI

N/A

1x 2-Channel 1/8 Jack (Monitor any 2 of 8 audio channels.)

1080i (50, 59.97, 60Hz), 1080p (24, 25, 30Hz), 720p (25, 29.97, 30, 50, 59.97, 60Hz), 576i, 480i

• Screen #1: 1x HDMI Input

• Screen #2: 1x HDMI Input

• VS/WFM: 1x HDMI Output

• Screen #1: 1x HDMI Input

• Screen #2: 1x HDMI Input

• VS/WFM #1: 1x HDMI Out

• VS/WFM #2: 1x HDMI Out

Parade Waveform Monitor Histogram Vectorscope

Audio Delay/ Audio Mixer/ Audio Converter

Audio Delay Box with Level Adjustment

AD-200

Audio Delay Box

AD-100

Datavideo offers a solution - AD-200. This 2-piece audio system has a rack-mount design for installation in an OB Van or PPU.

The AD-200 features an audio mixer with level adjustment and audio delay capabilities. The matrix-type audio mapping function allows a combination of multiple audio input channels into one or more output channels. Up to 3 seconds of delay are available to synchronize audio with video.

AD-200 is user-friendly with a clear OLED display and supports

2 audio inputs for a microphone or line input.

Audio Isolation Transformer

DAC-80

AD-100 is an easy to use audio delay box, enabling synchronisation of audio and video.

The unit features RCA (phono) connector as well as XLR type connection. Built in a rugged metal housing for use in the field or studio.

■ RCA (phono) connector as well as XLR type connection.

■ Built in a rugged metal housing for use in the field or studio setup

■ Low power consumption

Balanced/ Unbalanced

Audio Converter

BAC-03

DAC-80 is designed to remove hum and buzz created by ground loops. Voltage differences between different pieces of equipment cause small AC power currents to flow within the shield of audio cables. Capacitance issues can also introduce small current flows within the cable shield. Both problems will create hum in audio signals. DAC-80 delivers the clean audio signal you need, yet remains transparent within the production chain.

Audio Mixer

AM-100

■ Stereo Balanced Audio In / Out via XLR

Sockets

■ Stereo Unbalanced Audio In / Out via

Phono Sockets

■ Robust Metal Construction

■ Supplied c/w Power Adapter

AM-100 is a 1RU 5-channel mixer designed for live video and TV environments. Channels 1 to 4 are designed for microphone or line inputs. The 5th channel is for secondary AUX XLR inputs.

AM-100 supports audio-followvideo switching. It is ideal for integration with a Datavideo video switcher.

■ Ultra-compact 4 input + 2 AUX mixer featuring low noise, highheadroom design

■ Four studio-grade Dynamic Range mic preamps with:

1.Ultra –wide 60dB gain range

2.130dB dynamic range

3.+22dBu line input handling

4.Extended low-frequency response

5.Distortion under 0.0007%

(20Hz~20KHz)

6.Phantom power for studio condenser mics

■ Six high-headroom line inputs

■ High resolution 8 segment stereo meters

■ Ear phone 6.3mm with knob x1

■ Tally In (D-Sub)

■ Level indictor

■ A+V switch

29

29

Power Center

Camera Power Center

PD-6

PD-2A 400 watts 1RU 19 rack Power Distribution

Center provides a steady power supply for studio equipment, such as the video switcher, monitors, recorders and intercom system.

It features auto-switchable inputs of AC 110V/220, a UPS interface and DC 12V ports.

PD-2A has 4 12V/3A terminals, two 12V/5A terminals, two 12V/10A terminals (shared) and XLR

DC outputs. It provides up to 400 Watts.

The PD-2A adds reliability to studio equipment and consolidates power supplies and cabling.

Datavideo PD-4A Power Distribution Center comes with two AC power supplies to provide instant failover redundancy. PD-4A provides multiple DC

12V outputs. The automatic port control sequencer intelligently initiates each output to ensure the power supply on start-up.

The PD-4A can also be powered from a regulated DC 12V power source.

It can run from a car or van’s power outlet with the use of a suitable regulator.

PD-6 is a 19-inch, rack mountable, universal AC to DC Power Distribution

Center, designed to supply steady and sequenced voltage for the production kit while on location or in your studio.

Perfect for use in conjunction with Datavideo studio equipment and the

CB-22H / CB-23H via a single power cable. Each of the eight outputs can be configured individually, DC48V, 24V, 14.4V & 12V, with a total power consumption of 360W.

PD-2A PD-4A PD-6

30

Product Name

AC input

DC Backup Input

DC Outputs

Max. Power Rating

DC Overload

AC Overload

LED Indicator

Studio Power Distributor

• 100~240 VAC (50Hz or 60Hz)

• AC input outlet: One AC input

with Power Switch

• One DC 12V/32A,

• supports non-regulated DC

12V output

8

12V±5%, 3A XLR DC Female Jack x 4

12V±5%, 5A XLR DC Female Jack x 2

12V±5%,10A XLR DC Female Jack x 2

400W

DC overload protection, auto-recovery fuses on each DC output terminal non-recovery fuse on the AC input outlet

8 DC output LED indicators

Redundant Power Centerributor

• 100~240 VAC (50Hz or 60Hz)

• AC input outlet: Two AC inputs & Two

Power Switches

• One DC 12V/25A,

• supports non-regulated DC 12V output

5

12V±5%, 5A XLR DC Female Jack x 4

12V±5%, 10A XLR DC Female Jack x 1

360W

DC overload protection, auto-recovery fuses on each DC output terminal

non-recovery fuse on the AC input outlet

Green LED: Unit under working condition

Red twinkle: AC Input failed

1~4 XLR DC outputs LED indicator

Selectable of Auto/AC input switch

Camera Power Distributor

• 100~240 VAC (50Hz or 60Hz)

• AC input outlet: One AC input with

Power Switch

N/A

8(x4 30W,x4 60W)

30W:12V(2.5A),14.4V(2A),24V(1.25A),48V(0.6A)

60W:12V(5A),14.4V(4A),24V(2.5A),48V(1.25A)

PIN1:GND PIN2:DC OUT PIN3/4:NC

360W

Protection type: Recovery automatically after fault condition is removed non-recovery fuse on the AC input outlet

LED Color Indicator: Red:48V,

Weak Red:24V, Green:14.4V, Blue:12V

N/A Power source Input

Select AUTO/AC

Selectable of Auto/AC input switch

DC to DC 12/7.2V 4A Converter

DDC-4012H

Input

DC to DC 12V/ 2.5A Converter

DDC-2512

48W

Output

Protection

Connector

Voltage Range

Efficiency(Typ.)

DC Voltage

Voltage Tolerance

Rated Current

Current Range

Rated Power

Ripple & Noise(Max)

Over Load

DDC-4012H

15V~50V DC

UP TO 85%

7.2V / 8.4V / 12V

±3%

4 A

0~4 A

48W

<400mV

105%~150% rated output power

DDC-2512

9V~30V DC

UP TO 85%

12V

±3%

2.5 A

0~2.5 A

30W

<400mV

105%~150% rated output power

Protection type: Recovery automatically after fault condition is removed

PIN1:GND , PIN2/3:NC , PIN4:DC IN

Protection type: Recovery automatically after fault

PIN1:GND , PIN2/3:NC , PIN4:DC IN

PIN1:GND , PIN4:NC, PIN2:DC IN PIN1:GND , PIN2/3:NC , PIN4:DC OUT

30W

Environment

Others

DC Input

4Pin XLR Male

DC Output

4Pin XLR Female

DC Output

5.5Mm DC Jack

Working Temp

Working Humidity

Storage Temp.humidy

Dimension

Weight

Cable

Slide Switch

LED Lamp

Center: DC OUT , Shell: GND

0°C to 40°C (32°F to 102°F)

10% to 90% (non condensing)

-40°C to +85°C, 10~95% RH

115 mm x 50 mm x 35 mm (L x W x H)

Approx. 0.3 kg/ 0.66 lbs

UL 2464 ,18AWG, L=1M

Selected 7.2V or 12V output

RED:DC out 12V, Green: DC out 7.2V

Center: DC OUT , Shell: GND

0°C to 40°C (32°F to 102°F)

10% to 90% (non condensing)

-40°C to +85°C, 10~95% RH

115 mm x 50 mm x 35 mm(L x W x H)

Approx. 0.3 kg/ 0.66 lbs

UL 2464 ,18AWG, L=1M

--

--

30

All In One Cable/ Repeater

HD/SD 30m/50m/100m All In One Cable for Portable Video Studio

CB-46/ 47/ 48

Model CB-22H/ 23H CB-30/ 31

5-Pin

XLR

BNC

SDI

BNC

SDI

5-Pin

XLR

CB-46/ 47/ 48

Interface

Length

Repeater

Applications

- 1 x 4-pin XLR power cable

- 1 x 5-pin XLR ITC/Tally cable

- 1 x 75Ω BNC for HD/SD SDI video

- 1 x 75Ω BNC for CV return video

CB-22H: 30m

CB-23H: 50m

VP-605H

- Intercom & Tally

- DC Power 12~48V

- Video (including HD-SDI)

- Return video for Look Back monitor

- Datavideo OBV or Mobile Studio

100m SDI Repeater

(Powered)

VP-633

100m SDI Repeater

(Unpowered)

VP-634

- 1 x 5-pin XLR ITC/Tally cable

- 1 x 75Ω BNC for HD/SD SDI video

- 1 x 75Ω BNC for CV return video

- 1 x CAT-5 cable for Camera control

CB-30: 30m

CB-31: 50m

VP-633 and VP-634

- EFP Multi-camera Operation

- Mobile Video Studio

VP-633/VP-634 SDI repeaters can significantly extend the maximum cable run of standard SDI cabling.

Up-to 4 SDI repeaters can be used in one chain, allowing runs of up to

1000m SDI video through good quality SDI cable.

Each run must contain a VP-633 as this has a power connection to supply power through the

SDI cables which then powers the subsequent

VP-634’s (which do not require additonal power).

For applications where runs of a few hundred meters HD-SDI video are required (concert hall, sports stadium etc.), the Datavideo VP-633 &

VP-634 are a very cost effective solution.

POWER

CAMERA

VP-634

100m SDI Repeater

VP-633

100m SDI Repeater

HS-2800

HD/SD 8/12-Channel Portable Video Studio

- 1 x 75Ω BNC for HD/SD SDI video

- 1 x 5-pin XLR ITC/Tally cable

CB-46: 30m

CB-47: 50m

CB-48: 100m

VP-633 and VP-634

- Intercom & Tally

- Video (including HD-SDI)

- Range of Datavideo Mobile or Portable

Video Studio

200M

400M

HD-SDI 100m Cable

HD-SDI 100m Cable

HD-SDI 100m Cable

HD-SDI 100m Cable

100M

300M

VP-634

100m SDI Repeater

VP-634

100m SDI Repeater

31

31

All In One Cable Extender

VP-605H

Create SDI cable runs up to 200m

The all-in-one signal repeater provides composite video, power, and intercom connections. It's perfect for use with the

CB-22H / CB-23H cables.

FRONT VIEW REAR VIEW

SDI OUT CV IN POWER IN ITC IN

Composite Signal Repeater

VP-737

VP-737 is designed to be a composite video signal repeater that separates into two units. One unit is installed near the video signal source for transmission, and the other is near the display as a receiver.

It is able to extend a composite signal up to 200 meters away over a Cat5e (or better) cable. With no software configuration requirements, the installation and setup is quick and hassle-free.

■ Wired composite video transmission as far as 200 meters

■ Completely adaptive - quick, easy installation and setup, no configuration required

■ Cat5e extension design make use of existing Cat5e or better wiring infrastructure

Model VP-605H VP-633/634

ITC OUT POWER

OUT

CV OUT SDI IN

VP-737

32

Video and Signal Input:

HD/SD-SDI、CV、Talkback, Tally, DC in

Output:

HD/SD-SDI、CV、Talkback, Tally, DC out

Input: HD-SDI/SD-SDI

Output: HD-SDI/SD-SDI

Standard

Video Format

Audio

Power

SD: SMPTE 259M

HD: SMPTE 292M

SD︰720x480i、720x576i

HD︰1280x720 50P/59.94P/60P

1920x1080 50i/59.94i/60i

1920x1080 24P/25P/30P

SDI Embedded Audio

DC 12V~25V

SD: SMPTE 259M

HD: SMPTE 292M

SD︰720x480i、720x576i

HD︰1280x720 50P/59.94P/60P

1920x1080 50i/59.94i/60i

1920x1080 24P/25P/30P

SDI Embedded Audio

DC 12V~25V (VP-633 only)

Transmitter

- CV Input (BNC)

- DC Input

- CAT 5 Output (RJ-45)

Receiver

- CV Output (BNC)

- CAT 5 Input (RJ-45)

SD: SMPTE 259M

625i PAL, 525i NTSC

N/A

DC 12V

32

Follow us on :

33

33

34

34 35

35

www.datavideo.com

Datavideo Corporation

7048 Elmer Avenue,Whittier, CA 90602, U.S.A.

Tel: +1-562-696 2324

Fax:+1-562-698 6930

E-mail:[email protected]

Datavideo Canada Branch Office

Tel: +1-514-924-6768

E-mail: [email protected]

Datavideo Brazil Branch Office

Tel: +55-11-95557-8200

E-mail: [email protected]

Datavideo Technologies Europe BV

Floridadreef 106

3565 AM Utrecht,

The Netherlands

Tel: +31-30-261-96-56

Fax:+31-30-261-96-57

E-mail:[email protected]

Datavideo Hong Kong Ltd

G/F.,26 Cross Lane

Wanchai, Hong Kong

Tel: +852-2833-1981

Fax:+852-2833-9916

E-mail:[email protected]

Datavideo UK Limited

Units1 & 2 Waterside Business Park

Hadfield, Glossop, Derbyshire

SK13 1BE, UK

Tel: +44-1457 851 000

Fax:+44-1457 850 964

E-mail:[email protected]

Datavideo Technologies (S) PTE Ltd

No. 178 Paya Lebar Road #06-03

Singapore 409030

Tel: +65-6749 6866

Fax:+65-6749 3266

E-mail:[email protected]

Datavideo France s.a.r.l.

Cité Descartes 1, rue Albert Einstein

Champs sur Marne 774477 –

Marne la Vallée cedex 2

Tel: +33-1-60370246

Fax:+33-1-60376732

E-mail:[email protected]

Datavideo India Noida

A-132, Sec-63,Noida-201307,

India

Tel: +91-0120-2427337

Fax:+91-0120-2427338

E-mail: [email protected]

Datavideo Technologies Co. Ltd

10F. No. 176, Jian 1st Rd.,Chung Ho

District, New Taipei City 235, Taiwan,

R.O.C.

Tel: +886-2-8227-2888

Fax:+886-2-8227-2777

E-mail:[email protected]

Datavideo Technologies China Co

101,NO.618,LiuYing Rd,Zhabei District,

Shanghai,China

Tel: +86 21-5603 6599

Fax:+86 21-5603 6770

E-mail:[email protected]

Datavideo India Kochi

1’st Floor, Chicago Plaza, Rajaji Road,

Off MG-Road, Kochi 682035 , India

Tel: +91 4844-025336

Fax:+91 4844-047696

E-mail: [email protected]

Datavideo Visual Technology(s) Pte Ltd

No. 178 Paya Lebar Road #06-07

Singapore 409030

Tel: +65-6749 6866

Fax:+65-6749 3266

E-mail:[email protected]

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
