CD Soundmachine
User Manual
Manual del usario
Manual do usuário
AZ1122
AZ1123
Meet Philips at the Internet
http://www.philips.com
W
CLASS 1
LASER PRODUCT
AZ 1122
AZ 1123
Printed in China
JH-0603
1
1
2
3
4
5
9
0
6 x R14 • UM-2 • C-CELLS
AC MAINS~
PHONES
110V127V
220V240V
6
7
8
!
@
#
2
3
4
5
6
PRO
REP ALL
SHUF
7
X
Es necesario que lea cuidadosamente su instructivo de manejo.
Mexico
ATENCIÓN
No abrir, riesgo de choque eléctrico
PRECAUCIÓN - ADVERTENCIA
Verifique que el voltaje de alimentación
sea el requerido para su aparato
Alimentación:
Consumo:
Importador:
Domicilio:
Descripción:
Modelo:
110–127/220–240 V; ~50–60 Hz
18 W
Philips Mexicana, S.A. de C.V.
Av. La palma No. 6
Col. San Fernando la Herradura, Huixquilucan
Radio MW/FM con reproductor de CD
AZ1123/78
Para evitar el riesgo de choque eléctrico, no quite la tapa.
En caso de requerir servicio, dirijase al personal calificado.
Localidad y Telefono:
Edo. de México C.P. 52784
Tel. 52 69 90 00
Philips Electronics Hong Kong Ltd.
China
______________________________________
Exportador:
País de Origen:
Nº de Serie:
LEA CUIDADOSAMENTE ESTE INSTRUCTIVO
ANTES DE USAR SU APARATO.
AVISO IMPORTANTE
Philips Mexicana, S.A. de C.V. no se hace responsable por daños o
desperfectos causados por:
– Maltrato, descuido o mal uso, presencia de insectos o roedores
(cucarachas, ratones etc.).
– Cuando el aparato no haya sido operarado de acuerdo con el
instructivo del uso, fuera de los valores nominales y tolerancias
de
las tensiones (voltaje), frecuencia (ciclaje) de alimentación
eléctrica y las características que deben reunir las instalaciones
auxiliares.
– Por fenómenos naturales tales como: temblores, inundaciones,
incendios, descargas eléctricas, rayos etc. o delitos causados por
terceros (choques asaltos, riñas, etc.).
English
Supplied Accessories
– AC power cord
Top/front panels (See 1)
1 Source selector: CD, FM, MW or OFF
– selects CD or radio (FM/MW) source of
sound
– power off switch
2 2; – starts or pauses CD playback
§∞
– selects the next/previous track
– fast searches forwards/backwards
(press and hold the button)
PROG – programs tracks and reviews the
program
9 – stops CD playback;
– erases a CD program
3 Display – shows the CD functions
4 REPEAT – repeats a track/
CD program/entire CD.
5 SHUFFLE – plays all tracks in random order
6 OPEN•CLOSE – opens/ closes the CD
door
7 TUNING – tunes to radio stations
Back/bottom panels (See 1)
8 VOLUME – adjusts volume level
9
0
!
@
#
Telescopic antenna – improves FM
reception
Battery door – open to insert 6 x 1.5V
R-14/ UM-2/ C-cells
p – 3.5 mm stereo headphone socket
Helpful hints: The speakers will be muted
when headphones are connected to the set.
AC MAINS~ – inlet for power cord
Voltage selector – (not for all versions)
adjust to match the local voltage 110/220V
before plugging in the set
Controls/Power Supply
CAUTION
Use of controls or adjustments or
performance of procedures other
than herein may result in unsafe
operation.
Power Supply
Whenever convenient, use the power supply
cord if you want to conserve battery life.
Make sure you remove the plug from the set
and wall outlet before inserting batteries.
2
1
Replace the battery door, making sure the batteries are firmly and correctly in place.The set
is now ready to operate.
Open the battery door and insert 6 batteries,
type R-14, UM-2 or C-cells, (preferably
alkaline) with the correct polarity as indicated
by the "+" and "–" symbols inside the compartment (See 1).
Batteries (not included)
•
•
•
Incorrect use of batteries can cause
electrolyte leakage and will corrode the
compartment or cause the batteries to burst:
Do not mix battery types: e.g. alkaline with carbon zinc. Only use batteries of the same type
for the set.
When inserting new batteries, do not try to mix
old batteries with the new ones.
Remove the batteries if the set is not to be
used for a long time.
•
Batteries contain chemical substances, so
they should be disposed of properly.
Power Supply
General Operation/Tuner
General operation
1
If your set is equipped with a voltage selector, adjust the selector so that it matches
with the local power supply.
Check if the power voltage, as shown on
the type plate located on the
bottom of the set, corresponds to your
local power supply. If it does not, consult your
dealer or service center.
1
Turn TUNING to tune to a station.
Adjust the Source selector to FM or
MW to select your desiredwaveband.
Using AC power
WARNING: Always check you have
completely switched off the set, before
you change or disconnect power supply.
2
Connect the power cord to the
AC MAINS~ inlet and the wall socket.The
set is now connected and ready for use.
2
Switching on and off and selecting the
function
To select your sound source, adjust the
Source selector to: CD, FM or MW.
3
To switch the set off completely, withdraw
the power cord from the wall socket.
1
4
Install the unit near the AC outlet and where
the AC power plug can be easily reached.
For MW, the set uses a built-in antenna.
Direct this antenna for best reception by
turning the whole set.
To improve radio reception
For FM, extend, incline and turn the telescopic antenna for best reception. Reduce its
length if the signal is too strong.
Helpful hints:
Radio reception
Adjust the sound with the VOLUME control.
Adjusting volume
To switch off the set, adjust the
Source selector to OFF position.
5
•
•
2
•
The type plate is located on the
bottom of the set.
Disconnect the power cord from the wall
socket to protect your set during heavy
thunderstorms.
–
Helpful hints:
To avoid unnecessary energy consumption,
always adjust the Source selector to OFF
after using the set.
CD Player
Playing a CD
1
Adjust the Source selector to CD.
•
1
Open the CD door.
This CD player plays Audio Discs including
CD-Recordables (CD-R) and CD-Rewritables
(CD-RW).
2
Insert a CD with the printed side facing up,
then press the CD door gently to close.
➜ Display shows --, and later the total
number of tracks. (See 2)
Finding a passage within a
track
During playback, press and hold ∞ or § .
➜ The CD is played at high speed and with
reduced volume.
When you recognize the passage you want,
release ∞ or § to resume normal playback.
Helpful hints:
When your searching reaches the end of the
last track, the CD goes to stop mode.
Programming track numbers
You may store up to 20 tracks in the desired
sequence. If you like, store any track more
than once.
1
In the stop position, press PROG to
activate programming.
➜ Display: PROG and 00 flash. (See 4)
2
3
Press 2; to start playback.
2
Press ∞ or § to select your desired track
number.
MP3, CD-ROM, CD-I, CDV,VCD, DVD or
computer CDs are not possible for playback.
4
To pause playback, press 2;.
➜ Display: 2 flashes. (See 3)
Press PROG to store the desired track
number.
➜ Display: PROG and 00 flash for you to
program the next track.
•
5
To resume, press 2; again.
3
Repeat steps 2 to 3 to select and store all
desired tracks in this way.
➜ If you attempt to store more than 20
tracks, no track can be selected and the
display shows flashing --.
–
6
To stop CD playback, press 9.
4
To play your program, press 2;.
–
5
IMPORTANT!
CDs encoded with copyright protection
technologies by some record companies may
be unplayable by this product.
7
Helpful hints:
CD play will also stop when:
– you open the CD door;
– you select FM,MW or OFF;
– the CD has reached the end.
Selecting a different track
• Press ∞/ § once or repeatedly until the
desired track number appears in the display.
• In the pause/stop position, press 2; to start
playback.
Helpful hints :
When playback of your program comes to
the stop position, your set will return to
normal playback. To re-enter program mode,
press PROG in the stop position.
CD Player
Reviewing the program
In the stop position, press PROG repeatedly
to see your stored tracks.
Erasing a program
You can erase the contents of the memory
by:
– in the stop position, press PROG to enter
program mode, and then press 9;
– selecting FM, MW or OFF;
– opening the CD door.
Different play modes:
REPEAT and SHUFFLE
(See 5, 6)
REPEAT
You can play the current track or the whole
disc repeatedly, and combine REPEAT modes
with PROGRAM.
REP – plays the current track continuously.
2
1
Press 2; to start playback if in the
stop/pause position.
To select play mode, press REPEAT once or
more.
➜ The display shows REP or REP ALL.
REP ALL – repeats the entire CD/program.
3
To return to normal playback, press
REPEAT repeatedly until the modes are no
longer displayed.
– You can also press 9 to cancel your play
mode.
In the stop position, press SHUFFLE to
switch on shuffle play.
➜ Display shows SHUF.
SHUFFLE
You can play all the tracks in random order.
1
To switch off shuffle play, press 9.
Helpful hints:
During the shuffle play, when REP function is
selected, it will play the current shuffled track
repeatedly, or when the REP ALL function is
selected, it will repeat the shuffle play of the
entire CD.
Shuffle play is not available in the program
mode.
2
–
–
•
•
•
•
To clean the CD, wipe in a straight line from
the center towards the edge using a soft,
lint-free cloth. Do not use cleaning agents as
they may damage the disc.
Always close the CD-tape door to avoid dust
on the lens.
Sudden changes in the surrounding
temperature can cause condensation on the
lens of your CD player. Playing a CD is then
not possible. Do not attempt to clean the
lens but leave the set in a warm environment
until the moisture evaporates.
The lens of the CD player should never be
touched!
If the CD player cannot read CDs correctly,
use a cleaning CD to clean the lens before
taking the set to repair.
•
•
•
•
•
•
•
•
The mechanical parts of the set contain
self-lubricating bearings and must not be oiled
or lubricated.
No naked flame sources, such as lighted candles, should be placed on the apparatus.
No objects filled with liquids, such as vases,
shall be placed on the apparatus.
Do not cover the ventilation openings with
items such as newspapers, table-cloths, curtains, etc.
Adequate ventilation with a minimum gap of
15cm (6 inches) between the ventilation
holes and surrounding surfaces is necessary
to prevent heat build-up.
The apparatus shall not be exposed to dripping or splashing.
Do not expose the set, batteries, CDs to
humidity, rain, sand or excessive heat caused
by heating equipment or direct sunlight.
Place the set on a flat, hard and stable surface
so that the system does not tilt.
Safety information
•
To clean the set, use a dry cloth. Do not use
any cleaning agents containing alcohol,
ammonia, benzene or abrasives as these may
harm the housing.
Maintenance & Safety (See 7)
•
Never write on a CD or attach any stickers
to it.
CD player and CD handling
•
Environmental information
All unnecessary packaging material has been omitted.The packaging can be easily separated
into three materials: cardboard, polystyrene and plastic.
Your set consists of materials which can be recycled if disassembled by a
specialized company. Please observe the local regulations regarding the
disposal of packaging, dead batteries and old equipment.
Troubleshooting
No CD inserted
Insert a CD
CD badly scratched or dirty
Replace/ clean CD, see Maintenance
Laser lens steamed up
Wait until lens has cleared
CD-R/CD-RW is blank or not finalized
Use a finalized CD-R/CD-RW or suitable CD
Audio disc only
CD damaged or dirty
Replace or clean CD
Program/Shuffle is active
Quit program/shuffle mode
Note: A CD badly scratch or dirty may result in
improper operation.
–
•
–
•
The CD skips tracks
Note:
Make sure the CD is not encoded with
Copyright protection technologies, as some
do not conform to the Compact Disc standard.
–
•
–
•
–
•
–
•
-- indication
Do not open the set as there is a risk of electric shock. Under no
circumstances should you try to repair the set yourself, as this will
invalidate the guarantee.
If a fault occurs, first check the points listed below before taking the set for repair.
If you are unable to remedy a problem by following these hints, consult your dealer or service centre.
WARNING:
Problem
– Possible cause
• Remedy
No hay sonido/energía
– Volume not adjusted
• Adjust the VOLUME
– Power cord not securely connected
• Connect the AC power cord properly
– Batteries dead/ incorrectly inserted
• Insert (fresh) batteries correctly
– Headphones connected to the set
• Disconnect headphones.
– CD contains non-audio files
• Press ∞ , § once or more to skip to a CD audio
track, instead of the data file.
Display does not function properly / No
reaction to operation of any of the
controls
– Electrostatic discharge
• Switch off and unplug the set. Reconnect after a
few seconds
Severe radio hum or noise
– Electrical interference: set too close to TV, VCR or
computer
• Increase the distance
Poor radio reception
– Weak radio signal
• FM: Adjust the FM telescopic aerial
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
