Glow-worm November 2009

Glow-worm November 2009

The Glow-worm Range

Choice • Technology • Performance appliances to suit any application

The Ultracom Range

Combi

Ultracom 24cxi, 30cxi,

38cxi, 24cx and 30cx

Open Vent

Ultracom 12hxi, 15hxi,

18hxi, 24hxi, 30hxi and

38hxi

System

Ultracom 18sxi and

30sxi

Why Choose the Ultracom?

Easy to install

Extensive flueing options, LPG compatible without conversion kit and the Ultracom can be installed and commissioned without removing the case.

Tried and tested technology

Based on 4th generation technology with proven stainless steel heat exchanger providing excellent performance

Inbuilt digital programmer

Advanced heating and hot water control and greater efficiencies with the advanced 7 day 2 channel inbuilt digital programmer

Easy to set up, easy to use

Orange back lit screen, large icons and simple push button controls means it takes just a couple of minutes to set the Ultracom

High Efficiency Condensing boiler

SEDBUK A with NOx Class 5

– The best possible

Available as a Combi,

Open Vent or Sealed

System solution

Reliable

 Stainless Steel heat exchanger gives excellent reliability

 Daily pump spin and three way valve exercise program to reduce risk of seizure.

 Mains water inlet and central heating filters prevent contamination of components by debris.

 Siphonic condensate trap reduces the risk of freezing in severe weather.

Easy to use and service

 Forward facing components for ease of access

 Dry pocket diverter valve enables removal without draining the appliance

 Easy access to DHW heat exchanger due to upward facing orientation

 The intuitive display is simple to use

Advanced control

Simple intuitive display

 Built-in 2 channel 7 day programmer provides control of both CH & DHW provision.

 Advance and copy/paste function ensures programmer is easy to use.

 Large digital display with simple icons.

 Back lit for increased visibility when installed in an airing cupboard.

Flue

Flue options

10 metres horizontal

10 metres vertical

40 metres twin flue

Both the horizontal and vertical flues use the same 100mm o/d flue system

The Flexicom Range

Flexible and Compact. The Flexicom High Efficiency appliance that fits inside a kitchen cupboard and has a direct rear flue.

Suitable for apartments to large detached, 2 bathroom houses

The Flexicom Range

Open Vent

Combi

Flexicom 12hx, 15hx,

18hx, 24hx, 30hx and

35hx

Flexicom 24cx, 30cx and 35cx

Flexicom 18sx and 30 sx

The Ultracom Range

Combi

Ultracom 24cxi, 30cxi,

38cxi, 24cx and 30cx

Open Vent

Ultracom 12hxi, 15hxi,

18hxi, 24hxi, 30hxi and

38hxi

System

Ultracom 18sxi and

30sxi

Why Flexicom?

• Amazingly flexible – with a direct rear flue option.

• Surprisingly compact – smallest installation footprint in its class.

• Easy to install – can be installed and commissioned without removing the case.

• Easy to use/service – forward facing components make accessibility for servicing easy.

• Reliable – high grade aluminium silicate heat exchanger provides greater tolerance to system debris.

The Flexicom Range

Flexicom cx high efficiency combination boiler

3 models

Flexicom 24cx

DHW output @35degC rise

10l/min

Flexicom 30cx •

12l/min

Flexicom 35cx •

14.4l/min

SEDBUK A rated

NOx class 5

The Flexicom Range

Flexicom sx high efficiency system boiler

• 2 models Flexicom 18sx

& 30sx

• CH output

• 10-18kW

• 10-30kW

• SEDBUK A rated

• NOx class 5

The Flexicom Range

Flexicom hx high efficiency heating only boiler

• 6 models Flexicom 12hx, 15hx,

18hx, 24hx, 30hx & Flexicom

35hx

• SEDBUK A rated

• NOx class 5

Surprisingly Compact

Product Dimensions

Flexicom cx & sx

Flexicom hx

Amazingly Flexible

Direct Rear Flue

Choice of direct rear or top outlet flue options.

Reduces height of installation footprint hence enables installation within kitchen cupboard.

Improves aesthetics of installation.

Telescopic as top outlet flue so no need to cut to length.

Rear flue compatible with PMK.

Amazingly Flexible

Extensive Flue Options

Shares the same flue system as all Glowworm range makes things simple.

The telescopic flue simplifies installation with no need to cut to length.

8m

8m

20m

Easy to Install

Easy to Install

Pre-fixing jig enables installation of system pipe work and rear flue prior to fitting boiler including built-in filling loop.

The Flexicom can be installed and commissioned without the need to remove the front case. Drop down electrical connection box enables simple installation of mains & controls cable.

Siphonic condensate trap for fast connection.

Telescopic flue means no need to cut to length.

Volt free controls mean no requirements for part P approval. (combi models only)

Easy to Install

Fixing Jig

Allows pre installation and system testing using optional manometer kit.

Built-in filling loop removes the need for extra external plumbing.

Copper tails clip distance from the wall for easy connection of system pipe work.

Valves hidden under boiler

– results in a tidy installation and better aesthetics.

One-piece construction ensures perfect alignment of hanging bracket and jig on uneven wall surfaces.

Easy to Install

Electrical Connections

Simple drop down connection box

– All connections in one place without having to enter the boiler.

One screw fix

– simple and quick access.

Connection plug with labelled terminals for fast connection of cables.

Suitable for use with 230v or volt free system controls so no requirement for

Part P. (Combi models only)

Easy to use/service

• Forward facing components for ease of access.

• Dry pocket diverter valve enables removal without draining the appliance.

• Easy access to DHW heat exchanger due to forward facing orientation.

• The intuitive display is simple to use.

• No overheat thermostat due to high water content heat exchanger enables simple reset by end user.

Easy to use/service

User Interface

LCD display

Mode button

Reset button

Adjustment buttons

Reliable

Cast Aluminium Heat Exchanger

Automotive grade aluminium silicate provides excellent corrosion resistance.

Large waterways increase tolerance to system debris.

Monobloc design reduces joints and opportunities for defects.

Excellent thermal conductivity of aluminium enables compact design.

Summary

The Glow-worm Flexicom Range

Amazingly flexible Direct rear flue option.

Surprisingly compact The smallest high efficiency installation footprint

in its class. It fits in most kitchen cupboards.

Easy to install Carefully designed from the outset to make installation as simple as possible.

Easy to use/service A high efficiency boiler with intuitive digital controls makes this boiler both user friendly and

cost effective for the home owner.

Reliable High grade aluminium silicate heat exchanger and

monobloc design give excellent corrosion resistance and tolerance to system debris.

Xtramax HE

High Efficiency Storage Combi

30/33kW output

SEDBUK A rated.

Stainless steel heat exchanger.

LCD interface.

42 litre DHW store.

890mm x 700mm x 480mm.

G31 compatible.(LPG)

The Ultrapower sxi Range

Ultrapower 100sxi

Ultrapower 170sxi

The Ultrapower sxi Range

Ultrapower sxi high efficiency system store

2 models Ultrapower 100sxi &

Ultrapower 170sxi

80 & 120 litre cylinders

100 & 170 litre output without any performance drop

Reheat time 10mins 100sxi &

17mins 170sxi

CH output 8.7-24.3kW

DHW output 8.7-31kW

• 12l/min @ Δ35 o

C (once cylinder depleted)

SEDBUK A rated

NOx class 5

Controls

Climastat

Climapro

Climapro RF

Intelligent room thermostat

Modulating or on/off

Low voltage connection

Intelligent programmable room thermostat

Modulating or on/off

7 day or 24 hour

Low voltage connection

Intelligent programmable room thermostat

Modulating or on/off

7 day or 24 hour

Wireless connection

Smart Wiring Centre

Enables intelligent room control and weather compensation on open vent and sealed systems

Has the ebus connection to allow Glow-worm controls Climastat &

Climapro to be used with Flexicom hx and sx

Room and weather compensation can now be achieved on Flexicom system and open vent boilers

Glow-worm Accessories

Plume Management Kit

Compatible with all

Glow-worm models

Designed to exhaust plume away from neighbours properties and public areas

Can be easily directed around obstacles

Help achieve minimum clearance without re-locating boiler

Condensate Pump

Compatible with all

Glow-worm models

Outdoor sensor

Aids siting flexibility by collecting condensate from boiler and pumps it into the waste system

Smallest available in the UK

4m vertical pump height & 6m discharge hose

Overflow safety switch

Add to a Glow-worm boiler to create a full weather compensation system

Small sensor attaches to the side of a house

Clearly Solar

The Glow-worm range of solar thermal solutions

Flurosorb

Pressurised flat plate collector

Flurocyl

Twin coil unvented cylinder

(for use with open vent and sealed systems)

Fluropro

Solar controller

Solar pump station

The new Glow-worm solar range is fully compatible with any open vent and system boiler (with new boiler or retro fit existing boiler)

Also compatible with space heating side of any combination boiler if required

Clearly Heat Recovery

Introducing Clearly Heat Recovery

2 models in range

HRD 275

– Output 275M³/h @ 160pa

HRD 350

– Output 350M³/h @ 170pa

High efficiency – Up to 85% of the heat contained in the extracted air is returned to the house

Aluminum heat exchanger – one of the most efficient on the market

Speed controlled fans - adjusted via the room controller to match homeowner airflow requirements

Supplied with 2m flying lead and 3 pin plug – simple and easy installation

Pull out high grade dust filters (fitted as standard) -

No tools necessary in replacement. Home owner can change them quickly and effortlessly

Clearly Heat Pumps

Introducing the Clearly Heat Pumps

Key Features:

Smallest and lightest range of heat pumps on the UK market

Compact outdoor type, single packaged unit

3 unit range 8, 10 & 14kW (230v)

Dimensions: 1100 x 352 x 900mm high (1,300mm for

14kW) Weight: 101 to 151kgs

Hard wired single zone programmer/controller supplied with the unit, can also be adapted to become a room thermostat

Soft start as standard

– reduces power surge on start up

Non-ozone depleting R410a refrigerant contained in a sealed refrigerant system

Integral hydraulic module including heat exchanger, pump, filter, expansion vessel, pressure gauge and pressure relief valve all supplied as part of a Clearly

Heat Pumps system

Training ?

And not forgetting……..

All Glow-worm products are supported by

Service

Local contact - Local service

Glow-worm Service Contacts

Glow-worm Service tel. 02890 231142 fax. 01773 828070

Ray Keen tel. 07803 079023

Chris White-Overton

/ Terry Bateson tel. 07966 219317

Phoenix Scheme Warranty Options

Standard Three Years

Option for additional Two Years

Glow-worm

Flexibility

Easy Installation

Reliability

Service Excellence

Extremely Competitive Prices

Thank You
