WHAT WE OFFER

ROBOTIC

TOTAL STATIONS

AND GPS.

INSPECTION

AND MEASURING

EQUIPMENT.

SAFETY AND

DETECTION.

LASER

SCANNERS.

ROTATING,

PIPE AND CROSS

LINE LASERS.

TRAINING

AND SUPPORT.

EQUIPMENT HIRE

Phoenix, part of the Brandon Hire Group has been hiring survey equipment for over 30 years and boasts one of the largest and most up-to-date equipment fleets in the country.

Great rates

Next day nationwide delivery

All equipment fully checked and certified

Low cost, long-term contracts available

On-site and phone support

Leasing scheme available (subject to approval)

2 Hire • Repair • Sales • Support • Training

SERVICE

& REPAIR

Each Phoenix Survey & Safety depot has purpose-built workshop facilities so equipment can be serviced and repaired. Our in-house workshops are capable of dealing with any make or type of instrument, restoring them to manufacturers’ specification; all issued with ISO 9001:2008 certification on completion. We will collect and deliver to your site or office and leave a replacement instrument, if necessary.

A TOTAL SERVICE:

-

Any make

-

Any model

-

Any survey or safety equipment

-

ISO 9001 certification supplied

-

Purpose built workshop in every depot

-

Replacement equipment available

-

Trained engineers in every depot

-

Collection and speedy return service available

FLEET MAINTENANCE SERVICE

Phoenix Survey & Safety offer a maintenance service governed by our database which enables the owner of the equipment to relax knowing that we will maintain, service and certify their entire fleet at predetermined intervals.

This can involve us securely storing customers’ equipment when not in use and issuing it as required, allowing the customer to easily track any equipment movement and current location.

Take the hassle out of owning a large number of instruments

Allocate unique reference numbers to your equipment

Record each instrument’s service history

Advise of the next service due date

Optimise fleet usage by keeping track of every instrument

Immediately advise the cause and result of any damage sustained on site

Organize and monitor replacement hire instruments where needed

Upon request, provide equipment reports tailored to your requirements

Phoenix Survey + Safety Equipment | phoenixse.com

3

CONTENTS

SERVICES

What We Offer

Equipment Hire

Service & Repair

Finance Options

Phoenix Online

SURVEY

Optical Levels

Digital Levels

Construction Lasers

- Interior/Exterior Lasers

- Advanced Laser

- Grade Levelling Lasers

Pipe Lasers

Machine Sensors

Machine Control

7-8

9

10-11

12-13

14-15

17

18-19

20-21

2

2

3

6

7

Crossline Lasers

- Alignment Lasers

Laser Equipment Accessories

- Laser Sensors

- Levelling Staves

- Equipment Tripods

Total Stations

- Total Station Training

- Theodolites

- Total Stations

- Advanced Total Stations

- Robotic Total Stations

- Imaging Stations

- Measuring Stations

- Total Station Accessories

- Laser Scanners

GPS Receivers

- GPS Equipment Training

- Site Receivers

- Network Receivers

- GNSS Receivers

- Data Collectors

- Software

22-23

24

25

26

27

28

29

30-33

34-35

36-37

38-39

40-41

42-44

46

48-49

50-51

50-53

55-57

58-59

4

Hire • Repair • Sales • Support • Training

SAFETY + DETECTION

Gas Detection 60-61

62-63 Confined Spaces

Cable Location

- Cable Locators

- Advanced Cable Locators

- Cable Location Accessories

Duct & Drain Inspection

Ground Penetrating Radar

Cable Avoidance Training

64-67

68-73

74

75

76

77

INSPECTION + MEASURING

Sound Monitoring 78

Airflow Anemometers

Rebar Detector

79

80

Wall/Stud Scanners 81-82

Cavity Inspection/Endoscopes 83-84

Moisture Meters

Thermal Imaging Cameras

Laser Measures

Measuring Wheels

Incline & Angle Measures

85-86

87-88

89-90

91-92

93

SUNDRIES

Marking

- Tape Measures

- Spray Paint

- Chalk & Roll Lines

- Paint-Stik Markers

- Survey Markers

- Survey Pins

- Nails

Site Sundries

- Survey Books & Pads

- Scale Rules

- Surveyors Rods & Rules

- Planwheels

- Crack Monitors

For full terms and conditions of hire and sale visit www.phoenixse.com

Phoenix Survey + Safety Equipment | phoenixse.com

94

95

95

95

95

95

95

96

96

96

96

96

5

6

EQUIPMENT

FINANCE

CONSERVE CASH RESERVES

Leasing allows resources to be saved for other purposes, such as new business opportunities, unexpected needs, business development or marketing. Money is kept ‘in the business’ rather than in depreciating assets. It may also be possible to tailor the timing of the payments to suit expected cash flow including seasonal cash flow circumstances.

BUDGET OUTGOINGS

Medium term planning: Payments will be known at the outset.

These can be monthly or quarterly. The finance will be secure for the term of the agreement; it cannot be recalled early like a bank overdraft. The payments are also fixed for the length of the term, which enables easier forecasting of cash flow.

TAX ADVANTAGES

Due to the nature of the tax advantages of leasing (i.e. the full rental costs being offset against profit), and taking into account the opportunity cost of investment, the lease will usually work out cheaper than if the asset were bought for cash.

MAINTAIN CREDIT LINES FOR

OTHER USES

Equipment can be acquired without impacting other credit lines, such as loans and overdrafts, making further borrowing easier.

CONTACT YOUR NEAREST DEPOT

FOR MORE INFORMATION OR

EMAIL: [email protected]

NO EXTRA SECURITY REQUIRED:

The equipment itself is normally the only security required on a finance agreement. If bank funding was used to buy the equipment instead, extra security would normally be required, or the rates would be substantially higher.

Finance offered subject to status, contact us for full terms and conditions.

Hire • Repair • Sales • Support • Training

PHOENIX ONLINE

OUR WEBSITE INCLUDES EVERYTHING YOU NEED TO KNOW

ABOUT OUR EXTENSIVE PRODUCT RANGE AND SERVICES

AVAILABLE TO HIRE AND BUY.

Check back regularly to make sure you’re up-to-date with the latest developments, offers and news.

ENQUIRIES TEAM:

Call us on 44 (0)1454 338985 or email on [email protected]

We supply goods and equipment worldwide, if you are outside of Great Britain and would like a product quotation including traceable delivery please contact our exports team:

+44 (0)1454 338985

NEDO F32

AUTOMATIC LEVEL

Working out of its manufacturing plant in Switzerland, Nedo is one of the pioneers in the surveying and measuring tool industry.

The tough F-32 level features first-class optics with 32x magnification, a top-quality air-damped compensator and a modern design, ideal for use under tough conditions.

SPECIFICATIONS

Accuracy (1km double run levelling)

TELESCOPE (ERECT)

Magnification

Minimum Focus

COMPENSATOR

Setting Accuracy

Working Range

Bubble Sensitivity

Circle Graduation

GENERAL

Weight

Manufacturers Warranty

1.5mm

32x

0.5m

0.3”

±15’

8’/2mm

1.26kg

2 Years

Phoenix Survey + Safety Equipment | phoenixse.com

7

TOPCON AT-B

AUTOMATIC LEVELS

The AT-B product line-up is streamlined to make users’ choices as simple as possible. The three models will satisfy all levels of requirements from surveying to engineering, from use in open field to underground.

The compensator of AT-B series incorporates four suspension wires made of extremely high-tensile metal that features minimal thermal expansion coefficient, providing unmatched durability and accuracy even in the harshest environmental conditions. A finely tuned magnetic damping system quickly levels and stabilizes the line of sight despite the fine vibrations present when working near heavy equipment or busy roadways.

The AT-B series can focus on objects at 20cm (7.9in.) in front of the telescope, while previous models provided 50cm or 1m (1.6ft. or 3.3ft.) minimum focusing distance. This feature dramatically facilitates work in confined spaces.

With an IPx6 rating, the instrument is protected against powerful water jets from all directions, meaning the AT-B series withstands a sudden shower or torrential rainfall. The advanced design not only prevents water penetration, but also deters clouding or condensation inside the telescope.

Since the introduction of the first auto level AT model in 1961, Topcon has been a world leader of auto level technology for over 50 years. The previous AT-G series were best-selling models for more than two decades and now the AT-B series sets a new standard for auto levels used in surveying, engineering and construction applications.

FEATURES:

Superior telescope design provides a clear, bright view

2-speed focus (AT-B2 model)

Rapid, accurate and stable automatic compensation

Ultra-short 20cm focusing

All-weather dependability

Endless fine horizontal adjustments

Horizontal circle is covered for protection against dirt and scratching

8

TELESCOPE

Magnification

Resolving Power

Field of view

(at 100m)

Minimum Focus

Focusing Knob

ACCURACY (1km double run levelling)

Without Micrometer

With Micrometer

COMPENSATOR

Type

Setting Accuracy

Working Range

GENERAL

Water Resistance

Weight

Manufacturers Warranty

SPECIFICATIONS

AT-B2

32x

3”

AT-B3

28x

3.5”

1°20’

(2.3m)

1°20’

(2.5m)

0.2m from end of telescope

0.3m from instrument centre

2-Speed 1-Speed

0.7mm

0.5mm

1.5mm

n/a

Pendulum compensator with magnetic damping system

0.3”

±15’

0.5”

IPX6 (IEC 60529:2001)

1.85kg

2 Years

1.7kg

Hire • Repair • Sales • Support • Training

AT-B4

24x

4”

2.0mm

TOPCON DL-500

DIGITAL LEVELS

QUICK, EASY

& RELIABLE

Topcon DL-500 series digital levels maximises work efficiency and minimises human errors, providing consistent measurement precision and speed regardless of the operator’s skill levels.

Incorporating cutting-edge Random-Bidirectional (RAB) coding technology and optimum digital processing algorithm, the DL-500 provides exceptional measurement accuracy, stability and speed, under a variety of environmental conditions. Even when the staff surface is partially shaded, or in dim lighting conditions as low as 20 lux, one single button triggers measurement and the

DL-500 instantly shows reliable results.

Pre-installed measurement programs assist various levelling tasks and accompanied calculations.

Internal memory stores the valuable data which can be directly transferred to a computer, eliminating human errors.

Rock-and-Read

DL-500 tracks the RAB Code staff waved back and forth, and automatically reads the correct height. The staff reading becomes the minimum when it stands vertically. The DL-500 automatically finds the least value of staff readings. This world first technology allows for error-free readings of waved staffs, while dramatically reducing the operator’s eyestrain.

After focusing on the staff, just press one button. The DL-500 will read the height and distance, and store the data. Digital technology eliminates misreading and reduces the operator’s eye fatigue.

TELESCOPE

COMPENSATOR

SPECIFICATIONS

Compensator Working Range

HEIGHT MEASUREMENT

DL-502 DL-503

32x 28x

Pendulum compensator with magnetic damping system

±15’

Accuracy (Standard deviation for 1km double run levelling)

Electronic Reading Invar Staff

Fiberglass staff

0.6mm

1.0mm

0.8mm

1.5mm

Optical Reading

Measuring Range

Accuracy

(D

≤10m / 10m<D≤50m / 50m<D)

Least Count

GENERAL

1.0mm

1.6 to 100m

2.0mm

Measuring Time Fine Tracking

Least Count

3 sec.

(single/continuous/average) 1 sec.

0.0001 / 0.001m

DISTANCE MEASUREMENT (D = Measuring distance)

±10mm / ±0.1% x D /

±0.2% x D

0.01 / 0.1m

User Interface

Data Storage (Internal Memory)

Interface

Water Resistance

128 x 32 LCD with backlight

2,000 Points /

Max. 20 Jobs

RS-232C

Power Supply

Operating Time

Weight (including battery)

IPX4 (IEC 60529:2001)

BDC46B

(Li-ion battery, 7.2V)

Approx. 16 hours

2.4KG

The DL-500 has an internal memory that stores up to 2000 measurements of data. The “DL TOOL” software transfers data to a computer in CSV format and is readily available from any

Topcon website.

DL-500 SERIES STAVES

Topcon has released a new range of invar, aluminium and wooden bar code staves suitable for use with the Topcon DL-500 digital level series. Designed specifically to be used with the DL-500, the new range of staves feature the

RAB (RAndom-Bidirectional) bar coding technology which enables the level to automatically detect whether it is in the normal position or inverted, as well as enable the ‘rock and read’ functionality.

The new invar staves’ graduations are engraved within the external coating by an interferometrically controlled laser beam, ensuring superior graduation accuracy and edge sharpness. Random graduation errors on the invar staves are less than ±0.005 mm.

Phoenix Survey + Safety Equipment | phoenixse.com

9

TOPCON RL-VH4

MULTI-PURPOSE LASER

TOPCON

GUARANTEE

A powerful red beam laser, offering advanced functions along with one of the most visible and accurate red beams available. The selflevelling RL-VH4 series has many advanced features.

Draw a line of laser light on any surface, to any length you need automatically from the target. Easily set wall studs and use the RC-40 remote to control the laser functions. If the laser is bumped or disturbed, it will automatically turn off saving costly errors and re-work.

Featuring a high waterproof rating, tough build, and levelling sensor supplied as standard, the RL-VH4 interior lasers also have the flexibility to be used for exterior levelling applications.

FEATURES:

SmartScan

®

beam, control with line drawing

Remote control capabilities

Horizontal and vertical orientation

Self-levelling

REMOTE CONTROL RC-40

The RC-40 Remote control gives you real control over your work by using radio communication giving you a 100m working range.

ITEM

Accuracy

Operating Range

Beam Type

Laserclass

Water - Dust Proof

Scanning Width

Batteries

Operating Time

Weight

Laser Detector

REMOTE CONTROL

Radius

Water - Dust Proof

Power

SPECIFICATIONS

RL-VH4

2mm @ 20m

300m

635nm Red

3R

IP54

180 degree

Rechargeable

45 hours

2.2kg

LS-80A

RC-40

100m+

IP66

2 x AA

10

Hire • Repair • Sales • Support • Training

PLS HVR 505

MULTI-PURPOSE LASER LEVELS

The PLS HVR 505 is a fully automatic, self-levelling rotating laser, which projects a solid visible light beam onto any surface for alignment purposes.

The robust 505 series features plumb points up and down, four different rotation speeds, a target scanning function and horizontal and vertical modes with a-dual slope ability on the X- and

Y- axis.

Two models are available, the 505R Redbeam or the ultra-bright 505G

Greenbeam. Manage the laser from a distance with the remote and use the included laser detector to capture the laser beam in bright sunlight. The 505 is an ideal solution for interior installations as well as horizontal and vertical layout outdoors.

ITEM

Detecting Range

Accuracy

Down Beam Accuracy

Up Beam Accuracy

SPECIFICATIONS

505R

150m

±3mm @ 30m

3mm @ 3m

3mm @ 3m

Self Levelling Range

Manual Slope

Scan Function

Rotating Speed (RPM)

Beam Type

Laserclass

Water - Dust Proof

Operating Time

505G

150m

±3mm @ 30m

±5°

2 axis, ±10%

6°, 20°, 50°, 90°

60, 120, 300, 600

635nm <1mW

Class II

532nm <5mW

Class IIIA

IP64 IP64

25 hours (rechargeable)

Phoenix Survey + Safety Equipment | phoenixse.com

The full accessory package includes the laser, remote control, carrying case, laser detector, battery charger, magnetic laser targets and the wall bracket. Add a tripod and staff and you’ve got a full interior and exterior levelling and alignment solution.

11

TOPCON RL-H4C

ADVANCED LASER LEVEL

TOPCON

GUARANTEE

Topcon’s RL-H4C laser combines precision, versatility and value in one job site tough package.

Fast and highly accurate self-levelling motors ensure you hit the target first time and its high-power 2.0mw (max) diode means you have an 800m diameter working radius. The RL-H4C features one of the highest water and dust proof ratings at IP66, but also has a 635nm visible beam which means it can also be used for interior alignment applications where required.

The slope function and long range make this laser perfect as a low cost indicate solution when combined with a Topcon LS-B10 machine sensor which will also fit inside the case.

The package comes with rechargeable batteries which can be removed without disturbing the laser set up allowing insertion of dry cell batteries to keep you working.

Topcon are so confident in the quality of their lasers they are the only manufacturer to offer a 5 YEAR warranty for every one at no extra cost.

SPECIFICATIONS

ITEM

Accuracy

Self Levelling Range

Operating Range

Slope Matching Range

Beam Type

RL-H4C

1.5mm per 30m

±5°

800m (diameter)

±5%

Red (visible diode)

Beam Power

Water - Dust Proof

Rotation Speed (RPM)

Power

Operating Time

Weight

2.0mW (max.)

IP66

600

Rechargeable battery

Approx. 60 hours

2.6KG

LASER RECEIVER

Digital Readout

On-grade precision

Audible on-grade alarm

Power

Auto shutoff

Stave bracket

LS-100D

+20mm to -50mm

+/- 0.5mm

Yes

AA Batteries

30min after last key/laser activity

Holder 6

FEATURES:

Simple, intuitive manual slope match capability

Automatic cross axis self-levelling

Fast, automatic self-levelling

Ruggedised construction with dual handles

IP66 water-resistant housing

NEW LS-100D Long-Distance laser sensor

Up to 60 hours of production from dry or rechargeable batteries

Automatic height of instrument alert (HI alert)

Focused beam provides long 800m operating radius

Machine control compatible

10 arc second accuracy

635nm visible red beam laser diode

Carry case also fits an LS-B10 machine mounted laser sensor

12

Hire • Repair • Sales • Support • Training

TOPCON RL-H4C

ADVANCED LASER LEVEL

HORIZONTAL, SLOPE

AND LONG RANGE

CAPABILITIES IN ONE

TOUGH PACKAGE

The RL-H4C Battery pack can be charged outside the unit allowing the laser to be put into a secure lock-up during overnight charging. The package comes with rechargeable batteries as standard which can be removed without disturbing the laser set up, dry cell batteries can then be used to keep you working whilst the batteries are being charged.

The new style Topcon carry case is rugged in design with strong catches and an easy-toclean interior.

The case will also take an LS-B10 Machine Sensor should you choose to pair one with the RL-H4C for a low cost indicate machine control solution.

TOPCON LS-100D

The Topcon LS-100D is the latest addition to Topcon’s line of compact digital laser sensors. The sensor digitally displays the offset value to on-grade, which is designed to make elevation and vertical alignment control easier and faster for any application.

Phoenix Survey + Safety Equipment | phoenixse.com

NEW

13

TOPCON RL-SV2S

DUAL GRADE LASER

TOPCON

GUARANTEE

The Topcon RL-SV2S Dual Gradient Laser is a ‘multi-task laser’ which is suitable for any job requiring a laser for horizontal, vertical, single or dual slope applications.

A full function backlit radio remote is supplied as standard with the same display and buttons as the laser giving you full control when away from the laser; change grade, select menu settings, check operational status and verify battery life, all without touching the laser.

Suitable for machine control usage, the RL-SV2S features electronic shutters to avoid interference to-and-from other lasers on site. Fast self-levelling motors get you to work quickly and the heavy-duty glass and rugged body holds up to everyday bangs and bumps. Featuring a 635nm visible beam, the laser can also be used for interior setting and alignment.

The RL-SV2S is a low cost solution to those who need easy and accurate results, but don’t necessarily need the extended range or grade range of the

RL-100 or RT-5SA series.

ITEM

Horizontal & Vertical

Accuracy

SPECIFICATIONS

RL-SV2S

10”

Self Levelling Range

Grade Settings

Operating Range

Laser Class / Type

Beam Power

Water - Dust Proof

Rotation Speed (RPM)

Power

Operating Time

Remote

±5°

Dual, ±15%

400m (radius)

Class 3R / Red 635nm Visible

2.4mW (max.)

IP66

300, 600

Rechargeable battery

90hrs (Alkaline), 55hrs (Ni-MH)

RC-60

DUAL SLOPE LASER

WITH MULTI-TASK

FUNCTIONALITY

LASER RECEIVER LS-80L

Grade Information Channels 11 (+high/low out of range)

On-Grade Precision

Audible On-Grade Alarm

Power

Battery Life

High precision: ±1mm

Normal precision: ±2mm

Yes

2 x AA Alkaline Batteries

Approx. 120 hours

Auto Shut-Off

Stave Bracket

30 minutes w/o beam detection

Holder 6

FEATURES:

Horizontal, vertical, single and dual slope functionality

±15% Dual Slope functionality

Electronic shutters avoiding site interference

Fast self-levelling motors

Machine Control functionality

Visible 635nm beam

High contrast large LCD display

Long range receiver

Radio operated remote control

LS-80L long range receiver

Remote control grade match function

14

Hire • Repair • Sales • Support • Training

TOPCON RL-200

GRADE LASERS

TOPCON

GUARANTEE

Choose from two models, RL-200 1S single slope, or RL-200 2S dual slope which both feature Topcon’s revolutionary encoding system providing the highest grade repeatability of any laser

(7 arc seconds).

The RL-200 2S provides dual slopes of +/-10% in single slope or an industry leading +/- 25% dual slope. The 2S features the same standard accessories as the 1S except for the addition of the RC-400 remote control that allows you to change grade, select menu settings, check operational status, and verify battery life from up to 300m away.

The illuminated displays on the laser and remote also show the masking of electronic shutters on up to three quadrants avoid interference with other lasers on site. You can see the chosen rotation speed, selectable remote control channels and a sensitivity selector for strong winds or calm conditions, and the Hi-Alert which indicates if the laser has been disturbed preventing inaccurate work. The RL-200 also come with Topcon’s exclusive

5 Year Guarantee, the best factory warranty in the industry.

FEATURES:

7 Arc Second Accuracy

Wide Grade Range (up to 25% slope) without Slope Blocks

Extra-Long Battery Life (100 hours)

Long Range - up to 1,100m

Graphical Display

Full Function Remote (RL-200 2S only)

ITEM

Repeatability

Horizontal Accuracy

Grade Range

Working Range

Rotation Speed

Wave Length

Laser Class

Operating Time

SPECIFICATIONS

RL-200 1S

7 arc seconds

±7 arc seconds

-5% to +25% (single)

RL-200 2S

±10%/-5% to +25% (dual)

1100 m

300/600/900 rpm

685 nm visible

Class 3R

100 hours (alkaline)

90 hours (NiMH rechargeable)

Environmental IP66

Dimensions (W x H x D) 253 mm x 218 mm x 174 mm

REMOTE CONTROL

Laser Class

Environmental

Power

Dimensions (W x H x D)

N/A RC-400

two-way 300 m

IPX6

3 x AA alkaline

60 mm x 155 mm x 35 mm

RECEIVER

Grade information channels

LS-80L (Dual Sided)

11 (+high/low out of range)

On-Grade precision High precision: ±1 mm, Normal precision: ±2 mm

Audible on-grade alarm Yes

Power 2 x AA Alkaline batteries

Battery life

Auto shut-off

Approx. 120 hrs

After 30 minutes w/o beam detection

Phoenix Survey + Safety Equipment | phoenixse.com

15

EQUIPMENT

TRAINING

CONFINED SPACES TRAINING

The course provides delegates with the basic skills and knowledge to manage and supervise work in confined spaces and to make them aware of the risks and the current legal obligations involved in such workplaces.

National Occupational Standards (NOS) have been agreed and set for all major occupations and if achieved, demonstrate an individual’s competency to a nationally agreed standard. These are used by

Industry Lead Bodies (ILB) such as Energy and Utility Skills, in conjunction with Trade bodies such as

Water UK, to devise training and assessment programmes.

Such programmes are then offered by nationally recognised awarding bodies such as City & Guilds.

These, in turn, give successful candidates certificates of competence which are recognised nationally.

HARNESS AND LANYARD AWARENESS

The course is intended for those who use safety harness and lanyards in the workplace.

Delegates will achieve an understanding of the requirements under the Work at Height Regulations 2005, including the safe selection, use and inspection of harnesses and lanyards.

GET THE TRAINING YOU NEED:

In today’s competitive market, proving the competency of a workforce is crucial for many reasons:

A requirement for pre-tendering

Compliance with ISO Quality systems and processes

Compliance with company Risk Assessments

Compliance with Health & Safety Legislation

Compliance with client requirements

CONTACT US NOW FOR DETAILS

ON AVAILABLE TRAINING PROGRAMS

16

Hire • Repair • Sales • Support • Training

TOPCON TP-L4

PIPE LASERS

TOPCON

GUARANTEE

The TP-L4 is the perfect utility laser, featuring a highly accurate and powerful beam, auto line centering and grade zeroing, all in a waterproof metal housing.

Accelerate production by making setup and alignment automatic using

Topcon’s patented SmartLine scanning technology. Simply press the

SmartLine button on the laser or remote and the laser automatically finds the target centre, letting your crew start another day’s production without delay (TP-L4A and TP-L4G models only).

A handy remote is included as standard and gives you complete laser control, without being in the hole. Easily control SmartLine™ auto alignment, manage the beam brightness or simply put the laser on standby to save battery power. The easier you can see the beam, the quicker and more accurate your work will be.

Topcon also offers two green beam models, with beams that are four times brighter than any red beam with vastly superior spot quality.

ITEM

Beam Type

Beam Colour

SmartLine™ Auto-Alignment

Auto Line Centering

Auto Grade Zeroing

Plumb Reference

Plumb Reference Type

SmartLine™ Range

Grade Range

Line Range

Horizontal Accuracy

Battery Life

Housing Construction

Laserclass

Waterproof Depth

Operating Temperature

SPECIFICATIONS

T-L4B TP-L4A

633nm

Red

No

Yes

Yes

Yes

LED

N/A

-15% ~ +40%

±15%

±10”

DB-53: 70 hours

BT-53Q: 48 hours

Cast aluminium

Yes

LED

150m

633nm

Red

Yes

Yes

Yes

Class 3R

At least 5m for 24 hours

-20°C ~ 50°C

Yes

Yes

Yes

LED

N/A

TP-L4BG

532nm

Green

No

DB-53: 45 hours

BT-53Q: 32 hours

TP-L4G

532nm

Green

Yes

Yes

Yes

Yes

LED

150m

FEATURES:

World’s most accurate levelling

& grade system

Waterproof depth at least 5m for 24 hours

Cable free operation

Convenient 6 hour quick charge

Built for tough “in trench” conditions

RC-200 remote gives complete control

5 year manufacturer’s warranty

Phoenix Survey + Safety Equipment | phoenixse.com

17

TOPCON LS

MACHINE SENSORS

Topcon offers a range of machine control sensors designed to improve the quality of finish grading whilst also increasing productivity.

There are two basic types of machine control systems. Indicate systems, also known as manual systems, allow the user to monitor visual grade information and adjust the elevation of the blade accordingly. An automatic machine control system enables the operator to monitor visual grade information with the option of automatically maintaining the blade on grade by sending the information directly to the hydraulic system of the equipment.

18

ITEM

Detective Range

Detective Angle

DETECTIVE PRECISION

Mode 1:

Mode 2:

Mode 3:

Mode 4:

Detectable Laser

Laser Detecting Range

Wireless Communication with

RD-100W

SPECIFICATIONS

LS-B10

120mm

270°

LS-B100

175mm

360°

LS-B110

250mm

±2mm

±6mm

±12mm

±30mm

±3mm

±6mm

±15mm

±30mm

Wave Length 633 to 785nm

(diameter) 800m (using RL-100 1S/2S)

No No No

Power

4 x C-size dry cells or

Battery pack BT-68Q (sold separately)

DC 10V to 30V External Power Supply

OPERATING TIME

Alkaline Dry Cells

Battery Pack BT-68Q

Operating Temperature

Water Proof

-

100 hours

-20°C to +50°C

100 hours

50 hours

80 hours

40 hours

IP66 (based on the standard IEC60529)

LS-B110W

Yes

N/A

40 hours

18 hours

ITEM

Wireless Communication

Power

Operating Time

RD-100W - Remote Display

20m

(May vary depending on obstacles between the two instruments as well as other communication)

3 x AA dry cells

40 hours

Hire • Repair • Sales • Support • Training

TOPCON LS

MACHINE SENSORS

TOPCON LS-B10 RECEIVER

The entry level LS-B10 receiver is a versatile, low cost, 270° indicate solution for grade checking and machine control applications.

The integrated magnetic mount allows the

LS-B10 to be easily installed on a wide variety of machines. Using a standard levelling staff and Topcon sensor bracket the sensor can also be for manual grade checking.

TOPCON LS-B100, B110 & B110W MACHINE SENSORS

The LS-B100 series provide tight accuracy and a large working range making them ideal for dozers, box blades, excavators and backhoes.

Unique features, such as on-grade matching and wireless capability, offer unmatched performance.

The LS-B100 offers pure height indication for low end applications, with a fast and easy setup this affordable depth control sensor can be mounted to your equipment and working within minutes. The next step up is the LS-B110 for stand-alone usage on excavators because of the height and plumb indication, this can be combined with a control box to automatically control the machine hydraulics.

The LS-B110W and RD-100W enable height and plumb indication to be wirelessly transmitted to a remote display.

MAGNETIC MOUNTING POLE

The magnetic excavator mount quickly and easily places the LS-B100 or LS-B110 onto excavators, you will be set up and ready to go in mere minutes.

Phoenix Survey + Safety Equipment | phoenixse.com

19

TOPCON X-32

GRADE CONTROL SYSTEM

Topcon’s X-32 systems represent a giant leap in excavator grade indication. Completely user friendly and user definable, they’re flexible enough to apply to even the most difficult jobs.

The X-32 featuring the Windows CE based GX-30 Graphical Display - fully upgradeable to Topcon’s 3D excavator control. The system includes four TS-i3 tilt sensors used to measure angles between the cab, boom, stick and bucket and a compass for real 2D applications. Add Topcon’s optional LS-B10W laser receiver and you have the industries most advanced laser indicate system.

With 2D, you’ll eliminate over-excavation and control material usage saving you time and money. That’s because 2D gets you to grade fast and keeps you there, even in deep, blind cut situations or when digging under water.

With these systems the operator can “see” bucket position at all times.

GRAPHICAL DISPLAY

Windows ® CE

LCD Touch Screen (GX-30)

USB or Sitelink3D™ file transfer

User friendly software interface

COMMUNICATION BOX

CAN bus communication (MC-i3)

Network modem

Sitelink3D™ ready

GNSS upgradeable

INTEGRATED COMPASS POLE

Environmentally sealed

Best industry accuracy

Iron-free design

CAN bus protocol

TILT SENSOR

Environmentally sealed

No moving parts

Single or dual axis sensors (TS-i3)

LED status indicator

20

Hire • Repair • Sales • Support • Training

TOPCON X-32

GRADE CONTROL SYSTEM

3DXI GPS+ EXCAVATOR CONTROL UPGRADE

The 2DXi can be upgraded to Topcon’s 3DXi which provides superior performance with all of the advantages of satellite positioning technology which enables the operator to “see” his machine’s exact position within the site.

3DXi also ties in with Topcon‘s 3DMC applications for dozer and motor grader, this allows for seamless dataflow between hardware and software.

LS-B110

LASER RECEIVERS

Fast to set up and easy to use, these affordable depth control sensors can be mounted to your equipment and working within minutes.

The LS-B110 enables you to offset the “on-grade” position with one touch. This gives you an even greater working range. When you put the LS-B110W on your dozer, then move it to your scraper and then to your excavator. This equipment does it on all your machines.

LS-B110

Slope and Plumb

Indicators

Accuracy Modus for grading and excavating accuracies

One touch “On Grade” matching

LS-B110W

Wireless Remote

Display

Best solution for larger machines where the

Sensor is out of view

One touch “On Grade” matching

Built-in Plumb and

Slope Indicator

Phoenix Survey + Safety Equipment | phoenixse.com

21

PLS

CROSSLINE LASERS

Lay out reference points faster than traditional methods using PLS crossline lasers, which project a perfectly aligned horizontal vertical beam onto any surface.

The tough and compact PLS-2 is a self-levelling professional line laser and is perfect for any application that requires a vertical plumb or horizontal level.

The more advanced PLS-180 features a high-power beam that is easy to work with even in bright sunlit areas; this high beam power also slightly increases the lasers working range.

Another advantage is that the PLS-180 projects a horizontal and vertical beam on a direct 90 degree angle from the very front of the laser, not a few feet forward as in most other lasers.

Powered by 3 x AA batteries, both lasers come with a versatile magnetic bracket which allows for easy set-up on site. The PLS-2 is supplied with a pouch to house the laser and bracket whereas the PLS-180 package includes a carry case, which has room for an optional

PLS SLD laser detector. When paired with the sensor the lasers range is doubled to 60m and can be used outside for general construction applications.

PLS

DOT LASERS

Determine your reference points much faster and easier with the powerful PLS-3 and PLS-5. These multi-purpose tools project crystal clear, highly visible laser points up to 30m and can be used to quickly level, plumb down or up from the floor to the ceiling.

The PLS 5 also features a pulsating beam, which can be used with the optional

PLS HVD laser sensor and bracket for external tasks. The detector captures the pulsing points outdoors in bright sunshine when the points can no longer be seen by the human eye, this allows the outdoor working range to be extended from around 25m (visible range to see the dot) to 75m in bright sunshine.

PLS

90º LASER

The self-levelling PLS-90° is a one man operation laser for setting straight lines and perfect right angles for both interior and exterior work.

With two vertical lines at right angle, a plumb beam, quick set up one-button operation and an extremely precise laser, the PLS-90° is perfect for measuring and alignment jobs in interior finishing, dry wall construction and general construction. On long distances in pulsed mode the optional sensor can be used.

The PLS 90° can be supplied with an optional exterior construction kit which includes a laser detector, reflector target and carry pole.

PLS

480 TOOL

Square and horizontal layout with plumb down and up.

Multi-functional, self-levelling, interior-exterior, square and horizontal laser lines. Ideal for foundations, walls on slab and more.

Working Range

Cross Line Accuracy

Plumb Down

Power Supply

SPECIFICATIONS

+/-200‘ (61 meters) (outdoor w/detector)

+/-1/8” @ 60’ (+/-3mm @ 18 meters)

+/-1/8” @ 20’ (+/-6mm @ 6 meters)

3AA batteries, alkaline or rechargeable

Operating Time

Dimensions

Weight

+/- 25 hrs. continuous use w/horizontal beam +/- 15 hrs. continuous use w/ square beam

5.6” x 4.6” x 2.9“

1.25lb. (.57kg)

22

Hire • Repair • Sales • Support • Training

PLS

360º LASER

The self-levelling PLS-360 projects a continuous 360 degree line of reference for horizontal alignment applications such as suspended ceilings, and with the addition of a laser sensor it can also be used for outside use.

Unlike rotating lasers with sensitive moving parts, this compact tool operates via one button and has no complicated features.

PLS FT

90º LASER

The PLS FT 90 is a one button operation cross line squaring tool designed for tile-floor layout.

Easily establish 90 degree square floor layout with bright laser lines from this durable cast aluminium laser tool.

PLS SLD

LASER DETECTOR

Use this exclusive PLS Detector to capture the lines of the PLS 180,

PLS 360, HVL100 and PLS 90. This detector cannot be used with rotating lasers or the PLS-5.

ITEM

Type

Levelling

Laser Class

Range Inside

PLS 2

Line Laser

Fully automatic self-levelling on pendulum principal

Laser Class 2 (IEC 60825-2001.11)

Up to 20m

PLS 180

Line Laser

Up to 30m

SPECIFICATIONS

PLS 90

Line Laser

PLS 360

Line Laser

Range Outside

Accuracy

Optical Angle

Compensation Range

Magnetic Dampening

Operating Hours

Up to 20m

±3mm @ 10m

> 160°

± 6°

Min. 60m - in pulsed mode with laser detector

±3mm @ 10m

> 180°

± 6°

Ready for use in less than a second

+25 hours +25 hours

±1mm @ 10m

90°

± 6°

+25 hours

±1mm @ 10m

360°

± 8°

+35 hours

Environmental Protection IP52

Laser Projection

Thread

Horizontal, vertical, cross, free turnable

1/4”

Tilt

Power Source

Optional Accessories -

Horizontal, vertical, cross, free turnable

1/4”

2 x Vertical in

90° with plumb down

1/4” + 5/8”

Turns off laser light if out of compensation range

3 x AA (1.5V)

PLS SLD detector

Reflector target

& pole, laser detector

& bracket

360° Round horizontal

1/4”

3 x D (1.5V)

PLS SLD detector

PLS 3

Dot Laser

PLS 5

Dot Laser

PLS FT 90

Line Laser

N/A (fixed base)

-

±3mm @ 10m

± 6°

-

±1mm @ 10m

± 8°

+30 hours +30 hours

Up to 20m

Up to 20m

±2mm @ 6m

-

-

-

+10 hours

-

3 axis up, down, front

5 axis up, down, front, left, right

2 axis, square

-

-

3 x AA (1.5V)

PLS HVD detector with pendulum target

-

Phoenix Survey + Safety Equipment | phoenixse.com

23

LASER EQUIPMENT ACCESSORIES

TOPCON

LASER SENSOR

TOPCON LS-80L LASER SENSOR

This rugged, accurate sensor has displays on both sides, is water and dust resistant and can be used with most conventional rotating lasers.

The LS-80L has segmented arrows giving millimetre settings of 5mm, 10mm and 15mm individual levels of grade, an auto shut off after

30 minutes and a fine accuracy of 1mm.

HOLDER 6 BRACKET

This handy tool also communicates with the laser, giving the operator low battery and height alert warnings reducing potential errors.

TOPCON

LASER SENSOR

The Holder 6 is the standard bracket designed for use with the Topcon LS-80 laser receivers and LS-B10 machine receiver for secure attachment to any standard levelling staff.

SECO

LASER SENSOR

TOPCON LS-100D SECO APACHE STORM

The Topcon LS-100D is the latest addition to Topcon’s line of compact digital laser sensors. The sensor digitally displays the offset value to on-grade, which is designed to make elevation and vertical alignment control easier and faster for any application.

The LS-100D features an extra-wide beam capture sensor that also rejects interference from strobe light exposures.

The large and bright LCD displays (front and back) feature 9 channels of grade information and display the distance to on-grade. By pressing the hold button, the display is locked meaning you can conveniently read the results.

WHICH LASER SENSOR IS RIGHT FOR YOU?

ITEM

Sensor Readout

Detection Accuracy (up to)

Audible On-Grade Alarm

Receiving Strip Height

Environmental

Power

Operating Time

Auto Power-Off

The dual sided Apache Storm ® features a digital readout which provides a numeric display on both sides which shows exactly how far the elevation is from grade, this offers a huge “ease of use” advantage over other sensors on the market.

Accurate measurements can be made without moving the staff clamp and a massive 12.7cm reception height allows quick acquisition of the laser beam. A patented anti-strobe sensor prevents construction lights from giving faulty signals and LEDs on the front show red for high and low and green for on-grade.

LS-80L

Front and rear

SPECIFICATIONS

LS-100D

Front/read and digital numeric readout

±1.0mm

±0.5mm

Yes Yes

4.8cm

IPX6

2 x AA alkaline AA Batteries

120 hours

30 minutes without beam detection 30min after last key/laser activity

APACHE STORM

Front and rear /

Digital numeric readout

±0.5mm

12.7cm

IP67

24

Hire • Repair • Sales • Support • Training

LASER EQUIPMENT ACCESSORIES

NEDO

LEVELLING STAVES

5 METRE FIVE SECTION LEVELLING STAFF

Constructed of high quality powder-coated aluminium, our staves feature robust locking mechanisms guaranteeing a safe locking of the individual telescopic sections. The sections are easy to withdraw and the entire staff can be taken apart for cleaning without tools.

FEATURES:

Durable, easily replaceable buttons

High precision scale on front and back

Ergonomically designed shape for a better grip

mm-graduation on back allowing overall height readings

Free carrying bag and snap-on bubble

5 METRE FIBREGLASS LEVELLING STAFF

Made of high impact fibreglass materials which are extremely durable and robust these staves also feature brass buttons and wear-resistant graduations on the front and back ensuring a long life.

FEATURES:

Extremely robust design

Durable buttons made of brass

High precision scale on front and back

Ergonomically designed shape for a better grip

mm-graduation on back allowing overall height readings

Non-conductive (under dry conditions)

Laser receiver brackets easily attachable

Free carrying bag and snap-on bubble

LASER LEVELLING STAFF

The laser levelling staff considerably simplifies levelling with a laser.

The zero mark at the centre of the staff can be adjusted to the line of collimation of the instrument, permitting differences in height to be determined immediately and with the correct plus or minus sign.

The universal sliding adapter allows easy attachment of all standard makes and models of laser sensor and bracket. Made of high grade aluminium, the laser staff can be extended and secured in any position with the clamping screw, with a length capacity of 1.31m to 2.42m.

CARRY POUCH

All Nedo Staves are supplied with a hard wearing carry pouch.

HIGH QUALITY

TOOLS...

...FOR THE

TRADE

PROFESSIONAL

Phoenix Survey + Safety Equipment | phoenixse.com

25

LASER EQUIPMENT ACCESSORIES

NEDO

UNIVERSAL INSTRUMENT TRIPODS

The impact of tripods on the accuracy of measuring results is often underestimated. The degree of accuracy and precision can only be achieved with a combination of high-quality tripods and high precision instruments.

Wood or Aluminium?

Surveyors prefer to use wooden tripods because of the superior material properties. In comparison to aluminium tripods, wooden tripods feature a better damping behaviour and are less affected by temperature changes. Aluminium tripods are mostly used on construction sites with lasers as they are lightweight and extremely hard-wearing.

ALUMINIUM TRIPODS

NEDO aluminium tripods are mostly used on construction sites as they are lightweight and extremely hard-wearing. The industry standard

5/8” thread and quick clamp system make this an excellent, versatile tripod suitable for everyday use with surveying instruments.

WOODEN TRIPODS

NEDO heavy duty wooden tripods are particularly hard-wearing and have a long service life. All wooden parts are sealed with a high-tech plastic material that gives complete moisture protection preventing swelling of the wood.

SHORT ALUMINIUM

NEDO short tripods are suitable for light to medium weight rotating lasers as well as dot and line lasers which are often used in interior finishing. A low weight of 3kg and a quick clamp system make for fast and easy set up.

LIGHT/MEDIUM

ELEVATING HEAD

The two metre light and medium tripods feature a quick clamp system and bubble for easy set-up and also have a reduction gear unit to prevent unintentional equipment descent. The light model is perfect for light rotating, line and dot lasers. The medium duty model is perfect for stable use with any standard rotating laser.

JUMBO TRIPOD

The sturdy design of the Jumbo Tripod allows vibration-free use of the machine control laser.

The large working height ensures that the laser beam does not lie in the shadow of construction vehicles or other obstacles. Thanks to the indirect gear, even heavy-duty lasers can be easily and conveniently set to the desired working height.

HEAVY DUTY

ELEVATING HEAD

With an elevating tripod, even heavy-duty instruments can easily be set to the desired height. The reduction gear unit prevents any unintentional equipment descent.

TRIPOD

Standard Aluminium

Heavy Duty Aluminium

Medium Duty Wooden

Heavy Duty Wooden

Short Aluminium

2m Light Duty Elevating Head

2m Medium Duty Elevating Head

3m Heavy Duty Elevating Head

4m Heavy Duty Elevating Head

Extra Heavy Duty Jumbo Tripod

Min - Max Height

(Approx)

1.08m - 1.72m

1.06m - 1.70m

1.02m - 1.65m

1.02m - 1.69m

0.78m - 1.18m

0.69m - 1.45m

0.85m - 1.90m

0.85m - 3.0m

1.77m - 4.0m

1.73m - 4.01m

Retracted

Length

SPECIFICATIONS

Adjustable

Column Range

Weight

1.14m

1.13m

1.09m

1.10m

0.82m

0.75m

0.95m

1.32m

1.87m

1.94m

n/a n/a n/a n/a n/a

485mm

595mm

600mm

600mm

908mm

5.00kg

6.40kg

5.40kg

7.60kg

4.00kg

3.50kg

5.60kg

8.75kg

11.20kg

17.20kg

Thread

5/8

5/8

5/8

5/8

5/8

5/8

5/8

5/8

5/8

5/8

Tripod Head

Flat, ø 140mm

Flat, ø 167mm

Flat, ø 140mm

Flat, ø 167mm

Flat, ø 140mm

Flat, ø 110mm

Flat, ø 110mm

Flat, ø 110mm

Flat, ø 110mm

Flat, ø 167mm

Tripod Reference

200 200

200 524

200 100

200 513

200 412

210 631

210 611

210 680

210 442

210 540

26

Hire • Repair • Sales • Support • Training

EQUIPMENT

TRAINING

TOTAL STATION USER TRAINING

Phoenix Survey & Safety Equipment is now offering a number of cost effective training options, tailored to suit your needs - whether you are after the basics or something more comprehensive.

With technology moving faster than ever, it’s important to keep ahead of the competition when it comes to saving time and costs and improving productivity. Phoenix offers a range of courses designed for total station and GPS users to help you get the most from your time on and off site.

Whether you’ve bought a new instrument or you have an old piece of equipment that you need a refresher on, Phoenix has a dedicated team that specialise in training and support to help you get the most out of your kit.

CONTACT US NOW FOR

DETAILS ON AVAILABLE

TRAINING PROGRAMS

TRAINING TAILORED FOR YOU:

In today’s competitive market, you can save time and money on-site with expert knowledge of how to get the most from your equipment.

Courses held Monday - Friday

One to one or group courses

Training can be held at your site or our facilities

Half or full days training to suit your needs

Post training phone and email support provided

Please note; full training is provided on equipment and related software only, a prior knowledge of surveying principles is required by any applicable trainee.

Phoenix Survey + Safety Equipment | phoenixse.com

27

TOPCON DT-200

SERIES THEODOLITE

Topcon has combined precise reliable measurement into a functional package that anyone on the construction site can easily use.

Compact and lightweight for easy portability, the DT-200 series are built to the highest waterproof standards and feature the same advanced technology as found in Topcon total stations, thus ensuring the highest accuracy and reliability.

TELESCOPE

Magnification

Resolving Power

SPECIFICATIONS

DT-202

30x

2.5”

Minimum Focus 90cm

ELECTRONIC ANGLE MEASUREMENT

Detecting

Horizontal:

2 side

DT-205

Minimum Reading

1” / 5”

0.2mgon / 1mgon

The DT-202 and 205 have a twosided detection system for horizontal angle readings and a tilt sensor for vertical angle correction assuring high measurement accuracy.

The DT-202 and 205 also feature an RS-232C serial port that allows data communication with data collectors or computers. The DT-

209P “quick centering” model features a shifting base tribrach for quick and easy setup over the required point.

HIGHLY ACCURATE,

SIMPLE TO USE

NEDO ET-5

THEODOLITE

Accuracy 2” (0.6mgon)

OPTICAL PLUMMET TELESCOPE

Magnification 3x

Field of View

Focusing

GENERAL

Display

0.5m - infinity

Data Output

Water & Dust Protection

Power Supply

Operating Time

2 side LCD

Yes (RS232C)

IP66

4 x AA

140 hours

5” (1.5mgon)

3x

3x

DT-209 / 209P

26x

3”

Horizontal:

1 side

10” / 20”

2mgon /

5mgon

9” (3.0mgon)

1 side LCD

No

170 hours

Manufactured by Nedo in

Germany, the ET-5 theodolite is precise, reliable and features easy and intuitive operation.

This sturdy builders’ theodolite has a built in digital display and automatic vertical compensator. An ET-5 Laser model is also available which features a laser plummet.

As an optional accessory a diagonal eyepiece can be provided for easy measuring of steep vertical angles.

FEATURES:

Bright optics with 30x magnification

2 large easy-to-read LCD illuminated displays

2 clearly arranged control panels

Automatic vertical compensator; working range ± 3’

Horizontal circle with right/left function

Horizontal circle can be set to zero in any position

Hold function for horizontal circle

Automatic switch-off after 30 minutes; can be deactivated

Optical plumb with 3x magnification

Robust tribrach with 5/8“ connecting thread

ITEM

Telescope Magnification

Telescope Minimum Focus

SPECIFICATIONS

Angle Measurement Detecting

ET-5

30x

135cm

Horizontal: 2 side

Angle Measurement Minimum Reading 1” / 5” 0.2mgon / 1mgon

Angular Accuracy

Compensator

Optical Plummet Magnification

Optical Plummet Accuracy

Readout

Power Supply

Operating Time

5”

± 3’, automatic vertical compensator

3x

±0.5mm / 1.5m

4 x AA or rechargeable

36 hours with batteries

18 hours with rechargeable

28

Hire • Repair • Sales • Support • Training

TOPCON GTS-250W SERIES

TOTAL STATION

The GTS-250W Series combines Topcon’s tradition of rugged field-ready quality and accuracy and places it in an economical, compact design perfect for everyday measuring and positioning applications such as topo and construction layout.

The entry-level value choice GTS-250W – built with

Topcon’s precision and durability. The GTS-250W provides the construction professional with a dedicated layout solution. Use the on-board software to layout points in the field, confident that with Topcon, you’ll be right on target.

Use any of Topcon’s field controllers running MAGNET™ software tailored to more advanced construction tasks.

The GTS-250W has a backlit 24 key alphanumeric keyboard.

This keyboard makes it easier and faster to key in codes and other alpha or numeric fields.

For contractors looking for a full tablet computer, connect the GTS-250W to Topcon’s Tesla, or use the FC-2600 with full alphanumeric keyboard, or our touch screen FC-250 cable-free. Bluetooth

®

provides you with flexibility to be up to 10 feet away from the GTS-250W.

FEATURES:

Rugged Waterproof Design

Bluetooth

®

Cable-Free Communication

High Accuracy and Long Range Measuring

Enhanced Absolute Encoder

Versatile Application Functions

Dual-Axis Tilt Sensor

TELESCOPE

Magnification

Resolving Power

ANGLE MEASUREMENT

SPECIFICATIONS

GTS-250W

30x

3.0”

GTS-252W

GTS-255W

TILT ANGLE COMPENSATOR

Compensation

Range

DISTANCE MEASUREMENT

Mini Prism

One Prism

Three Prism

Accuracy

Measuring Time

DATA MANAGEMENT

Display

Keyboard

Data Storage (Internal)

GENERAL

Battery Operation

Dust/Water Protection

Wireless Connection

Operating Temperature

Min. Resolution/Accuracy

2”

5”

Dual-axis liquid tilt sensor

±3’

900m (3,000 ft.)

2,000m (6,600 ft.)

2,700m (8,900 ft.)

2mm+2ppm (0.3-200m)

Fine: 1.2 sec. Coarse: 0.7 sec. Tracking: 0.4 sec.

Graphic LCD 160 x 64

24 Key alphanumeric

Up to 24,000 points

Up to 27 hours

IP54

Bluetooth

®

Class 1

-4°F to 122°F (-20°C to 50°C)

Phoenix Survey + Safety Equipment | phoenixse.com

29

TOPCON ES ADVANCED

TOTAL STATIONS

The ES (Easy Station) series is a completely new design of total station delivering the very latest technological advantages in a small, sleek design.

The ES has a non-prism operating distance of 500m with incredible accuracy and a pinpoint EDM beam spot to ensure precise measurement. The exclusive

LongLink™ function provides a 300m Bluetooth wireless communication range.

Operate a data collector, carry out accurate field coding or quickly make setting out decisions, all from the prism pole. LongLink™ technology brings a whole new level of capability to your manual field survey or engineering team, enhancing data collection and dramatically improving stakeout speed and accuracy.

The ES features an internal communication module allowing owners to receive on-screen notice of software updates and firmware enhancements which can be downloaded and installed over a WiFi connection. If the instrument is misplaced or stolen, the module also enables location of the instrument anywhere in the world and the sending of a coded signal to disable it.

Data transfer is easy via the USB port, using either a cable or memory stick and the enhanced batteries will last up to 36 hours on a single charge allowing you to work almost a full work week without recharging.

FEATURES:

TSshield™ Advanced Security

LongLink™ Communications

Fast and Powerful EDM

Advanced Angle Accuracy

Extended Battery Life

Backlit Graphical Display

Advanced Measurement,

Logging and Calculation functionality

Choice of angle accuracies

TELESCOPE

Magnification / Resolving Power

Field of View / Minimum Focus

ANGLE MEASUREMENT

Accuracy / Display Resolution

Dual-Axis Compensator

DISTANCE MEASUREMENT (P)

Prism EDM Range

Prism EDM Accuracy

Non-Prism Range

Non-Prism Accuracy

Measuring Time

INTERFACE AND DATA MANAGEMENT

Display / Keyboard

Control Panel Location

Data Storage

Interface

Bluetooth Modem (option)

GENERAL

Laser Pointer

Guide Lights

Optical Plummet

Laser plummet (option)

Environmental / Operating Temp.

Operating Time

BDC70 Battery

External Battery

30

ES-101

30x / 2.5”

SPECIFICATIONS

ES-102

1°30’ (26m/1,000m) / 1.3m

ES-103

1” / 0.5”, 1” 2” / 1”, 5” 3” / 1”, 5”

Dual-axis liquid tilt sensor, working range: ±6’ (±111mgon)

4,000m (ES-107 3,000m)

2mm+2ppm

500m

3mm+2ppm (0.3-200m)

Fine: 0.9s, Rapid: 0.7s, Tracking: 0.3s

Backlit graphic LCD / Alphanumeric keyboard, backlight

Dual Sided

Internal: approx. 10,000 points. Plug-in: USB flash (max. 8GB)

Serial RS-232C, USB2.0 (Type A, for USB flash memory)

Bluetooth Class 1, Ver.2.1+EDR, Operating range: up to 300m

ES-105

5” / 1”, 5”

Coaxial red laser using EDM beam

Green LED (524nm) and Red LED (626nm), Range: 1.3 to 150m

Magnification: 3x, Minimum focus: 0.3m from tribrach bottom

Class II red laser (635nm¬±10nm), Beam accuracy: <[email protected]

IP66 (IEC 60529:2001) / -20 to +50°C (-4 to +122°F)

Approx. 36 hours (single distance measurement every 30 seconds)

Optional: BDC60: approx. 44 hours, BDC61: approx. 89 hours

Hire • Repair • Sales • Support • Training

ES-107

30x / 3.5”

7” / 1”, 5”

Single

TOPCON OS ADVANCED

TOTAL STATIONS

The OS (On-Board Station) features all of the advanced benefits of the new ES series and more.

With a completely new design, the OS provides an on-board Windows based data collection interface, LongLink™ communication, TSshield™ telematics module, and a powerful EDM.

The OS features an internal communication module allowing owners to receive on-screen notice of software updates and firmware enhancements which can be downloaded and installed over a WiFi connection. If the instrument is misplaced or stolen, the module also enables location of the instrument anywhere in the world and the sending of a coded signal to disable it.

FEATURES:

MAGNET Field On-board

Easy, Advanced Graphical

Interface

TSshield™ Advanced Security

Module

LongLink™ Communications

Fast and Powerful

Reflectorless EDM

Advanced Angle Accuracy

Choice of angle accuracies

TELESCOPE

Magnification / Resolving Power

Field of View / Minimum Focus

ANGLE MEASUREMENT

Accuracy / Display Resolution

Dual-Axis Compensator

DISTANCE MEASUREMENT (P)

Prism EDM Range

OS-101

30x / 2.5”

1°30’ (26m/1,000m) / 1.3m

1” / 0.5”

SPECIFICATIONS

OS-103

3” / 1”

Dual-axis liquid tilt sensor, working range: ±6’

Prism EDM Accuracy

Non-Prism Range

Non-Prism Accuracy

Measuring Time

INTERFACE AND DATA MANAGEMENT

Operating System / Application

Display / Keyboard

Control Panel Location

Data Storage

Interface

Bluetooth Modem (option)

GENERAL

Laser Pointer

Guide Lights

Optical Plummet

Laser plummet (option)

4,000m

2mm+2ppm

500m

3mm+2ppm (0.3-200m)

Fine: 0.9s, Rapid: 0.7s, Tracking: 0.3s

Microsoft Windows CE 6.0 / MAGNET Field

3.5” semi- transflective TFT QVGA colour LCD & keypad

Dual sided (face 2 is touch screen)

750MB internal memory, Plug-in: USB flash (max. 8GB)

Serial RS-232C, USB2.0 (Type A, for USB flash memory)

Bluetooth Class 1, Operating range: up to 300m

Coaxial red laser using EDM beam

Green LED (524nm) and Red LED (626nm), 150m Range

Magnification: 3x, Minimum focus: 0.3m

Class II red laser (635nm), Accuracy: <[email protected]

Environmental / Operating Temp.

BDC70 Battery

Operating Time

IP65 / -20 to +50°C (-4 to +122°F)

Approx. 18 hours

Ext. Battery (optional) BDC60: Approx. 22 hours BDC61: Approx. 44 hours

OS-105

5” / 1”

Single

Phoenix Survey + Safety Equipment | phoenixse.com

31

TOPCON DS-200i SERIES

IMAGING ROBOTIC TOTAL STATION

Use the DS-200i when imaging is required to document field activity or use photo documentation to settle disputes.

The DS-200i is a mid-ranged professional motorized total station designed for the construction professional who is looking for productivity enhancement from servo motors and auto-tracking technology. The MAGNET ® on-board software intuitive interface assists with image capture and photo notes of field activity.

For even higher productivity levels, use a field controller with MAGNET Field software for robotic, one-operator control.

Work directly on the bright, color touch screen or with the alpha-numeric keyboard, to achieve higher levels of production with MAGNET Field on-board software. The DS-200i total station can be used on a wide variety of applications, from building layout to earthwork volumes and land surveying.

SPECIFICATIONS

TELESCOPE

Resolving Power

Magnification

2.5”

30x

ANGLE MEASUREMENT (Min. Resolution/Accuracy)

3 Models 1”, 3”, 5”

TILT ANGLE COMPENSATION

Compensation

Range

DISTANCE MEASUREMENT

Dual-axis compensator

±6’

Prism EDM Range

Prism EDM Accuracy

Non-Prism Range

Non-Prism Accuracy

Measuring Time

6,000 m

1.5mm+2ppm

1,000 m

2mm+2ppm (0.3 to 200m)

Fine: 0.9 sec

Rapid: 0.6 sec

Tracking: 0.4 sec

AUTO-TRACKING

360° Prism Range

Single Prism Range

CAMERA AND COMMUNICATIONS

5 MP Live video or photos

LongLinkTM rover communications*

USB 2.0 Slot (Host + Slave) RS-232C Serial

GENERAL

2 to 600 m

1.3 to 1,000 m

Display

Keyboard

Battery Operation

Dust/Water Protection

Color Touch TFT 240 x 320

QVGA Display (Dual Display on 1” model)

25 keys with illuminator

Up to 5 hours

IP65

Wireless Connection

Operating Temperature

UPGRADE OPTIONS

Hybrid Positioning

Bluetooth® Class 1

-20°C to 50°C

RC-5 LongLink/Quick lock

* The communication range may vary due to the condition of the area

32

Hire • Repair • Sales • Support • Training

TOPCON DS

TOTAL STATION

The DS series total station can be configured as a mid-range, on-board data collection, auto-pointing total station, and later upgraded to a fully robotic instrument. Further upgrades, such as

Hybrid Positioning can be added, making this the most versatile instrument on the market. Versatility to meet your needs.

FEATURES:

Auto-tracking firmware upgrade available

Ready for Hybrid Positioning

Xpointing Technology (Auto Collimating)

Magnet On-Board application software

Exclusive LongLink

TM

Communications 300m (984 ft)

TSshieldTM Advanced Security and Maintenance

Rugged Waterproof IP65 design

Xpointing Technology (Auto Collimating)

The Topcon DS unities Xpointing technology featuring a new intelligent algorithm that automatically aims to the prisms with precise corrected angle readings. Inexperienced users will find that the DS finds and centres on the prism quicker than by hand. The Xpointing technology works in dim or dark conditions where the prism is difficult to be found. Whatever the job requires the DS makes your job done easier and faster while still maintaining accuracy.

Magnet On Board Software

Powerful and intuitive field application software that enables users to collect survey mapping data and perform construction and road layout using the DS total station. Software package is graphical and intuitive to assist with even the most complex structures for stakeout or BIM.

Fast and Powerful EDM

The 1,000m (3,280 ft) Non-Prism is a phase shift EDM that has a smaller beam width then other non-prism instruments in this class.

Measurements can be as fast as .9 seconds in the fine mode. The Topcon algorithm reduces the noise associated with non prism measurements providing an accurate result to most surfaces over longer distance. This is true for darker surfaces and wet surfaces where other non-prism fail.

Our smaller beam width allows Topcon to get measurements to a fence as well as through the fence to a building behind. 5,000m is the distance to a prism.

Exclusive LongLink™ Communications 300m

When connected with external data collector the

Longlink™ communication provides the power at the remote rod position. The remote operator can record the data for codes and rod heights for as-builts eliminating most common errors. For stakeout the remote operator can view directions required to find the stake point. The system becomes an economical robotic system where the instrument man simple needs to follow, and aim on the remote prism. No need to focus on the prism, the DS with XPointing feature finds the center of the prism automatically.

TSshield™ Advanced Security and Maintenance

Every instrument has a telematics card installed that will communicate to the Topcon servers every day. Topcon can then review if the total station has any error codes from the day before, what firmware version is installed, as well as the total station location. From this information Topcon can send a message to the total station and advise the operator if a newer version is available. Topcon is providing 3 years worth of telematics at no charge to the customer for this data.

Rugged Waterproof IP65 design

Provides protection from the driving rain for all weather as well as dust.

Phoenix Survey + Safety Equipment | phoenixse.com

33

TOPCON PS

TOTAL STATIONS

The rugged, IP65 rated PS-Series Robotic Total Stations have the latest technology including TSshield™ for advanced security and maintenance, exclusive LongLink™ communications and the Topcon RC-5 with a quick-lock function, providing features that are not found in other systems.

The revolutionary PowerTrac engine dramatically increases power for prism tracking. Employing entirely new optics, laser system, and further advanced algorithms, PowerTrac provides the PS Series with unsurpassed ability to keep tracking a moving prism even under the toughest environmental conditions.

The 1000m Non-Prism EDM uses phase shift technology that has a smaller beam width than other nonprism instruments in this class. Measurements can be as fast as 0.9 seconds in fine mode. The Topcon algorithm reduces the noise associated with non-prism measurements providing an accurate result to most surfaces over a longer distance. This is true for darker and wet surfaces where other non-prisms fail. Our smaller beam width allows Topcon to get measurements up to a fence as well as through the fence to a building behind. The distance to a prism is 6000m - Almost twice the distance as the competition!

When connected with the external data collector, the Longlink™ communication provides license free communication. The Longlink communication is built in to the RC-5 which has the ability to send a signal to the total station to quickly re-acquire the prism.

Our advanced encoder technology provides the ‘best in class’ 1 second angle accuracy with technology allowing the instrument to calibrate its own angle measurement system automatically.

34

Hire • Repair • Sales • Support • Training

TOPCON PS

TOTAL STATIONS

SPECIFICATIONS

TELESCOPE

Resolving Power 2.5”

Magnification

ANGLE MEASUREMENT

30x

Min. Resolution/Accuracy

PS-101

PS-103

PS-105

1”

3”

5”

TILT ANGLE COMPENSATION

Compensation Dual-axis Compensator

Range ± 6’

DISTANCE MEASUREMENT

Prism EDM Range

Prism EDM Accuracy

Non-Prism Range

Non-Prism Accuracy

6,000m

1.5mm+2ppm

1,000m

Measuring Time

2mm+2ppm

Fine:

Rapid:

Tracking:

0.9 sec

0.6 sec

0.4 sec

COMMUNICATIONS

LongLink™ rover communications** (600m)

USB 2.0 Slot (Host + Slave)

RS-232C Serial

GENERAL

Display

Keyboard

Battery Operation

Dust/Water Protection

Colour Touch TFT 240 x 320 QVGA

Display (Dual Display)

25 keys with illuminator (single keyboard)

Up to 4 hours

IP65

Wireless Connection Bluetooth ® Class 1

Operating Temperature -20°C to +50° (-4°F to +122°F)

MAGNET SOFTWARE

Powerful and intuitive field application software that enables users to collect survey mapping data and perform construction and road layout.

Paired with the Tesla data collector, it provides the surveyor with a powerful tool.

Phoenix Survey + Safety Equipment | phoenixse.com

35

TOPCON IS3

IMAGING STATIONS

Imagine the power, accuracy and speed of the proven Topcon QS robotic series, then give it faster scanning capability and 2 cameras, and you have the IS-3. Advanced imaging and high accuracy surveying techniques are combined in a single innovative instrument.

Topcon’s IS combines our proven third generation robotic technology with dual digital Imaging cameras to provide a full colour, real-time image on a touch sensitive LCD display.

View your data in real time and utilise the iSCAN options for thorough data collection. Select one of these routines to automatically measure feature points, cross sections or regular grids of points.

Thanks to digital imaging using a coaxial 30x Through The

Lens (TTL) camera, you can be confident that the point you select on the screen and measure is the point you need!

Navigate your site with the wide-angle camera and zoom to pinpoint features which can be measured up to 2000m away.

This can be carried out on the IS-3, or remotely on our field controllers, using the new WT-100, controlling the instrument by live video feed up to 300m away!

The IS3 has multiple communication options including a 2.4

GHz Interference free spread spectrum Radio, optional RC-4 for IR remote control and communications, Bluetooth

®

, and

WiFi ™ connectivity with the new WT-100 for live video control.

36

The IS3 features iSCAN Intelligent Scanning

Technology with automatic feature detection and measurement saving you time in the field. A regular grid scan can be performed at up to 20 points per second giving affordable access to the laser scanning arena.

Topcon’s iCONTROL system gives you completely cable free instrument control via WiFi™ which is ideal for remote monitoring, hazardous area or difficult location working. iCONTROL can be used with PC Based ImageMaster or via the WT-100 and

Topcon Field Controller.

The IS3 also benefits from the iDRIVE touch screen interface allowing control the instrument simply by tapping on the touch screen interface. Save time by using iDRIVE to seamlessly switch from rover to reflectorless measurement without the user having to return to the instrument.

FEATURES:

10 Frames Per Second at the Detail Pole

Up to 20 PPS Scanning

Multi-purpose Robotic Instrument

Capture a 360˚ Photo Field Book

Twin Digital Cameras

Wide Angle Cameras with 30x Zoom TTL

Intelligent Image Scanning

XTRAC8 Auto-Tracking

2,000m Reflectorless Measurement

Long Range Live Video Instrument Control

Flexible Finance Options Available

Hire • Repair • Sales • Support • Training

TOPCON IS3

IMAGING STATIONS

ITEM

ANGLE MEASUREMENT

SPECIFICATIONS

IS-3 1” IS-3 3” IS-3 5”

Method

Minimum Reading

Accuracy

Tilt Correction

Absolute Reading

0,5”/1” - 0,1/0,5mgon 1”/5” - 0,2/1mgon

0,3 mgon / 1” 1 mgon / 3”

1”/5” - 0,2/1mgon

1.5mgon / 5”

Compensating Range

DISTANCE MEASUREMENT

Dual Axis

±6‘

Prism Mode

Range 1, 3, 9 Prism / Accuracy 3,000m, 4,000m, 5,000m / ± (2 mm + 2 ppm x D*) m.s.e.

Non-Prism Mode

Short Range / Accuracy

Long Range / Accuracy

Rapid scan

EDM Laser Class

AUTOMATIC TRACKING

1,5m - 250m / ± 3mm m.s.e.

5,0m - 2,000m / ± (10mm + 10ppm x D*) m.s.e.

Up to 20 Hz ±5 mm m.s.e.

Class 1 (IEC publication 825)

Tracking Speed

Tracking Range

15°/sec

1,000m (with standard prism)

Rotating Speed

IMAGING

Cameras

85°/sec

2 x 1.3 MP ccd, wide angle apparent resolution equivalence to 4.8 MP

Image Speed Up to 15 FPS

USER INTERFACE - FEATURE RECOGNITION SYSTEM

OS Microsoft Windows CE ® .NET 5.0

Processor

Screen

Interface

Memory

Intel PXA255 400 MHz

3.5” TFT Full colour touch-screen

RS-232C / Compact Flash / USB (Type A,Type B mini)

128MB RAM, 2MB Flash ROM, 1GB micro SD Card

A PICTURE SPEAKS A

THOUSAND WORDS

Standard Package

IS-3 1”, 3” or 5” instrument, Charging

Cradles, FC -250 Controller with

TopSURV, WT-100 System, A7R4 360° prism, Li-Ion Batteries, TopSURV on

Board for IS, ImageMaster (Remote

Control and Office Processing software),

Manuals & Utility software. Tripod,

Pole & Brackets.

IMAGEMASTER SOFTWARE

Seamlessly integrate digital imagery with 3D data measured using your chosen survey tool, be it Imaging

Station, Laser Scanner or Digital camera. Topcon bring you the software solution to manage 3D data measured using our Capture Reality range of products.

ImageMaster for IS is included with the Imaging Station specifically for allowing remote control collection and preparation of IS scan data for export to 3rd party software - control the Imaging Station via WiFi and conduct your survey from the comfort of your office or site vehicle. Simple output to DXF, PTS or text delivers a working dataset for modelling in your software of choice.

ImageMaster Pro gives full access to Topcon’s Capture Reality range and provides the tools to make Imaging effective in your workplace. Combine a GLS-1500 or IS and Digital camera with no limits, create 3D textured models or produce linework from stereopair photos. Draw elevations, compute volumes, create sections, measure areas; this software will meet most operators needs in a one-stop-shop.

Use Image Master for: mining, aerial photogrammetry, architecture archaeology, disaster monitoring/mapping, accident/crime investigation, 3D modelling and visualization and civil engineering and survey deliverables.

FEATURES:

Clear and easy user interface

Combine Survey data, Pointclouds and

Photogrammetric projects

Manage multiple models using multiple source data

Generate 3D models for measurement, mapping and interpretation

Produce models with accuracies up to 0.4 mm

Phoenix Survey + Safety Equipment | phoenixse.com

37

TOPCON

HYBRID POSITIONING TECHNOLOGY

Choice of GNSS Receiver

Hybrid Positioning™ simply requires an incoming position from a GNSS receiver. This receiver can be a local RTK base/rover combination, a MAGNET

Relay rover, or a Network RTK rover. Depending on the accuracy of the GNSS position, different levels of hybrid performance will be seen.

Faster Field Work

Hybrid Positioning™ systems will perform faster in the field compared to other robotic systems and with more versatility than an RTK-only system. The hybrid system combines both GNSS positioning and optical robotic measurements into one rover pole measurement point. It is impossible to achieve a robotic line of sight to all points.

Hybrid Positioning reduces the need for traversing and multiple tripod set ups.

Topcon’s commitment to automating data workflow and increasing your productivity can be seen in this latest technology.

Topcon’s slogan of “Your Productivity, Our Technology” is our commitment to providing industry-leading productivity systems based on software, hardware, and technology – all systems that improve the way you work. Topcon continues to enhance field measurement systems by providing unique technology combinations that make you more productive.

Hybrid Positioning™ technology is the ability to use both

GNSS positioning and optical positioning data at the same time, in ways that improve field measurement efficiency.

MAGNET™ Field software now has an available module for Hybrid Positioning. Topcon has revolutionized the industry by providing GNSS receivers that utilize the most advanced signal processing and robust performance in difficult environments. Additionally, Topcon’s optical total station technology of advanced tracking and powerful

EDM performance is industry leading. These two hardware solutions, plus MAGNET Field software, come together to make Hybrid Positioning technology.

GNSS positions are provided through any of Topcon’s GNSS receivers and combined in the field controller software,

MAGNET Field, to make the robotic total station a more productive solution. The GNSS positions assist the instrument to lock onto a prism faster, resection the robotic instrument location in real geodetic coordinates automatically with autolocalization, and provides a method of measurement even when the line of sight to the robotic instrument is blocked.

HYBRID LOCK

Turns the instrument toward the prism location

Regain prism tracking

Record more shots

The ultimate in prism reacquisition

HYBRID RESECTION

RTK coordinates for control

Safe robotic location setup

Geodetic coordinates

Fast job site setup

HYBRID SWITCH

User controlled

Fast switch between GNSS or Optical

No need for new setup

Easy one-touch switch

AUTO-LOCALIZATION

Automatic localization to geodetic coordinates

Bing ® Map background

Multi-point localization

Works with RTK positioning

38

Hire • Repair • Sales • Support • Training

TOPCON

MEASURING STATIONS

Featuring a wide array of innovative technologies, MS05A and MS1A offer superior performance in angle and distance measurement as well as reliable robotic functionality which has made them the unit of choice on the Crossrail project. The ‘Measuring Station’ ensures dramatic enhancement in precision and productivity in all applications such as surveying, engineering, construction, monitoring and 3D industrial measurement.

MS05A - ULTRA-PRECISION MEASURING STATION

The MS05A employs an Independent Angle Calibration System (IACS) technology for unparalleled measurement reliability. Combined with absolute encoders that incorporate advanced coding and digital-processing technologies, the MS05A provides the industry’s highest 0.5” (0.15mgon) angle measurement precision.

Using reflective sheet targets, the MS05A provides sub-millimetre accuracy in a range of up to 200m. With its 3.5km long-range capability and fast measurement speed, the MS05A also satisfies every requirement for the reference EDM that is employed for precise baseline calibration.

MS1A - LONG-RANGE VERSATILE MEASURING STATION

OVER 100 IN USE

ON THE CROSS

RAIL PROJECT

The MS1A is primarily designed for precise construction applications providing 1” (0.3mgon) angle accuracy and 1mm + 1ppm distance measurement precision. A 200m reflectorless measurement capability gives MS1A further versatility for applications where reflectors cannot be placed. The MS1A measures up to 300m with 50 x 50mm reflective sheet targets and the long-range capability reduces the need for changing instrument positions, resulting in higher work efficiency.

Monitoring - Effectively performs displacement and deformation monitoring using the state-of-the-art automated measurement capability.

Tunnels - Measures tunnel convergence and deformation more efficiently than ever and can be employed for automatic or unmanned monitoring of tunnels, either existing or under construction, to ensure safety and save labour.

-

Civil Engineering - Major Civil engineering tasks demand the highest accuracy and reliability possible. The MS05A/MS1A dramatically increases construction efficiency and accuracy with its superior measurement capability in combination with unique target systems.

Bridges - Precise measurements using reflective sheet targets and compact prisms enable high-quality bridge construction with short lead times.

Plant and Process Engineering - Position, geometry and dimensions of complex members of various plants can be measured with sub-millimeter to millimetre accuracy.

Nuclear - When absolute accuracy is required and no compromise is allowed, the MS05A provides a flexible solution for the precise measurement of dimensional stability and geometry of important structures.

FEATURES:

0.5” / 1” Angle Accuracy

High-Performance, versatile EDM

0.6 mm Distance Accuracy

Monitoring optimised Auto-pointing

Laser Option for Tunnelling

Windows CE Operating System

Accuracy

Minimum Display

SPECIFICATIONS

ANGLE MEASUREMENT MS05A

0.5” / 0.15 mgon

MS1A

1” / 0.3 mgon

0.1” / 0.02 mgon / 0.0005 mil

IACS

DISTANCE MEASUREMENT

Provided (Independent Angle Calibration System)

Accuracy

Reflective Sheet

Prism

Reflectorless

Minimum Display

Measuring Range

Reflective sheet

One prism

Mini prism

Reflectorless

Measuring Time

(0.5 + 1 ppm x D)mm

(0.8 + 1 ppm x D)mm

(1 + 1 ppm x D)mm

0.01 mm

1.3 to 200 m

1.3 to 3,500 m

1.3 to 800 m

0.3 to 100 m

Fine: 2.4 s, Rapid: 2.0 s

(1 + 1 ppm x D)mm

(1 + 1 ppm x D)mm

(3 + 1 ppm x D)mm

0.1 mm

1.3 to 300 m

1.3 to 3,500 m

1.3 to 1,000 m

0.3 to 200 m

Phoenix Survey + Safety Equipment | phoenixse.com

39

TOTAL STATION ACCESSORIES

TRIPODS

We offer an extensive range of accessories to suit all applications so if you can’t see what your looking for give us call.

HEAVY DUTY TRIPODS ALUMINIUM TRIPODS

In comparison to aluminium tripods, wooden tripods feature a better damping behaviour and are less affected by temperature changes. Made of straight-fibered ash and pine wood. All wooden parts are sealed with a high-tech material that gives complete moisture protection preventing swelling of the wood. The legs are extremely robust with a considerably long service life.

PRISM

TARGETS

PRISM C/W TARGET

BACKPLATE

Aluminium tripods are robust, very solid and hard wearing. The standard aluminium tripod is the typical model supplied with a prism, adapter and tribrach to make up a Prism

Station Outfit. The industry standard 5/8” thread and quick clamp system make this an excellent, versatile tripod suitable for every day use with surveying instruments.

Compatible with Topcon, Sokkia, Nikon and

Pentax this prism outfit combines zero offset prism, target plate and holder and can be used atop any standard pole with a 5/8” thread.

MINI PRISM C/W

GROUND SPIKE

The tough, weather resistant mini prism can be set to either 0 or 30mm offset and features a target plate and tilt for easy alignment. The mini prism can be attached to a detail pole if required and comes complete with ground spike and case.

NODAL PRISM

POLE SYSTEM

PRISM STATION

Compatible with Topcon, Sokkia, Nikon and

Pentax the Prism Station outfit combines zero offset prism, target plate, adapter and tribrach for quick setup on any standard flat head tripod. The prism head can also be removed for use with any 5/8” detail pole.

MINI PRISM C/W POLE

The SECO 25mm sliding prism system features a silver-coated prism and 0 offset.

The holder slides up and down the pole, the knobs lock in height and tilt and also double as vertical angle targets. Features an adjustable 40-minute circular vial and three sections each 60cm in length to achieve 1.8m with 10cm red or white coloured sections.

L-BAR MINI PRISM

This prism pole system is deal for precise layout as well as topos and all hand-held prism work. It is available with the most accurate offset position (-17.5mm - nodal) that places the optical centre of the prism over the plumb line axis which helps eliminate angular pointing errors at close range. Features 30cm sections, a 40-minute adjustable vial, a 5/8 adapter for attachment to standard prism poles and a carry case.

REFLECTIVE STICK-ON TARGETS

The 25mm ‘L-Bar’ Mini Prism is perfect for deformation or mining surveys, or places where a permanent mounting is needed.

This assembly is constructed of anodized aluminium and the prism is water and dust proof. It features a -25mm offset and comes with 10.3mm mounting hole.

Reflective targets work with most EDM’s for monitoring work where you have to leave targets in position over long periods of time. These self adhesive bright yellow targets can easily be seen in daylight and each target can give a measuring range of over 100m with millimetre accuracy. Greater distance can be achieved using multiples of 5 and 9 targets.

25MM PACK OF 10

25MM PACK OF 50

25MM PACK OF 100

50MM PACK OF 10

50MM PACK OF 50

50MM PACK OF 100

40

Hire • Repair • Sales • Support • Training

TOTAL STATION ACCESSORIES

PRISM

POLES & BIPODS

We offer an extensive range of accessories to suit all applications so if you can’t see what your looking for give us call.

STANDARD DETAIL POLE 45CM MINI DETAIL POLE

This 2.6m pole features the TLV™ locking mechanism. It’s constructed of sturdy aluminium tubing and a two-stage brass adjustable top-threaded tip. It’s finished with electrostatic powder paint coating on the outer pole and permanent silk-screened metric graduations on the inner pole.

CARBON FIBRE

ROBOTIC POLE

Constructed of sturdy aluminium with an electrostatic paint coating this mini stake out pole only weighs 0.68kg and has the industry standard 5/8” thread. The pole features a replaceable hardened steel point and anodised levelling vial.

SECO THUMB

RELEASE BIPOD

The ultra lightweight 2.65m carbon fibre pole is extremely strong and is used with robotic total stations. Features SECO’s

TLV locking system to guarantee no slipping or change in length of the pole which also has a 40-minute bubble vial.

POLE SUPPORT

The SECO Thumb Release™ Open

Clamp Bipod allows the user to simply clamp the pole into place without lifting and threading it through the bipod head.

Within seconds the operator can set up a free standing GPS antenna pole or prism pole.

The legs extend to 1.8m for use in uneven terrain and the bipod collapses to 109cm. A bipod leg clip is available for convenient transport or storage purposes.

The heavy duty support holder features a robust design, tough non slip clamp and high stability. This versatile support can be used to securely hold levelling staves, ranging poles as well as prism poles.

DATA

CABLES

When used in conjunction with Topcon Link software (which we are happy to provide free of charge) these cables allow you to easily transfer data to and from your total station and PC. There are two types available, which one you choose depends on whether you wish to use a USB or serial port on your PC or laptop to download the data.

USB DATA CABLE SERIAL DATA CABLE

All modern computers should have a USB port making them compatible with this cable. A disk containing the necessary cable software is provided as standard.

TRAVERSE KITS – PICK A COMBO TO SUIT YOU

Serial connections tend to be found on older machines. The serial port cable does not require any software drivers to be installed before use.

Standard Detail Outfit

Comprises of: Prism c/w Target & Holder, Detail Pole

Optional: Mini Prism

Half Traverse Kit

Comprises of: Aluminium Tripod, Prism Station

Optional: Prism c/w Target & Holder, Detail Pole, Mini Prism

Full Traverse Kit

Comprises of: 2 x Aluminium Tripod, 2 x Prism Station

Optional: Prism c/w Target & Holder, Detail Pole, Mini Prism

Phoenix Survey + Safety Equipment | phoenixse.com

41

TOPCON SCANMASTER

LASER SCANNING SOFTWARE

OFFICE SOFTWARE FOR 3D

POINT CLOUD DATA

Topcon’s ScanMaster software offers a complete, full featured

3D point cloud software package that includes all tools for processing, editing and delivering point cloud data from your Topcon GLS series laser scanner.

With ScanMaster’s operator-friendly interface, scanning professionals quickly become more proficient in their execution of laser scanning projects.

ScanMaster enables professionals to efficiently collect point cloud data, then process and create final deliverables that exceed client expectations. After field work is complete, ScanMaster supports viewing, smart processing and export of point cloud data leading to design, analysis and/or BIM applications. For those project stakeholders that have an interest in viewing point cloud data and conducting basic measurements, a free viewer mode is available.

RECOMMENDED SYSTEM REQUIREMENTS

Processor Speed Intel Core 2 Duo at 2.66Ghz

RAM

Operating System

Video Card

Wi-Fi

USB

2GB+ (preferably 16Gb)

32 or 64 Bit

NVidia or ATI discrete video card with

256mb+ of memory

802.11g

USB2.0

ENGINE

High performance point cloud engine radically improves performance, saving valuable time.

CLEANUP AND REGION SELECTION TOOLS

Intelligent filtering of isolated measurements from point clouds and region select tools automate the cleanup of noisy data.

VOLUMES

Flexible volume report calculation. Calculations based on mesh-to-mesh or mesh-to-plane surface comparison.

Also extract volume region by boundary area, volume region centroid.

EDGES

Automatically extract edge sets from scans.

Merge sets to quickly draft complex building shapes.

42

Hire • Repair • Sales • Support • Training

TOPCON GLS-2000

LASER SCANNER

Topcon’s GLS-2000 laser scanner allows you to quickly and accurately capture 3D data at any project site.

An industry leading laser scanner no serious practitioner should be without, the GLS-2000 can be utilised at any job site. Powered by user selectable dual laser capability, the operator is able to choose between a Class 3R and Class 1 laser according to the job site conditions.

With a scan range of over 350 metres the GLS-2000 is a versatile tool that lets you get laser scanning in many different work environments. The standalone capability of the scanner combined with its rugged design provides technology that will stand up to the most extreme work sites.

Intuitive and Efficient

Historically difficult to measure objects such as buildings, antennas and spans are recorded at the press of a button. The scanner is a quick, simple and effective way of capturing 3D data at high speed but without sacrificing the accuracy required for today’s demanding professionals.

The usability of the GLS-2000 provides one-touch operation for the nonspecialist but also satisfies the survey professional with occupation and backsight operation. On-board instrument height measurement and the dual digital cameras provide for ultimate productivity and practicality when dealing with point clouds.

The GLS-2000 laser scanner together with ScanMaster software provides the ultimate package for people who want the quick, easy and cost-effective route into laser scanning.

A Laser Scanner for all Users and Markets

The technology embodied in the GLS-2000 laser scanner provides the features that make it the ultimate tool for all users.

The class leading specifications of the scanner make it an ideal tool for the BIM environment. Scan to BIM and ‘as built’ projects will benefit from the precision and productivity provided by the GLS-2000.

SYSTEM PERFORMANCE

Maximum Range at Specified Reflectivity

Standard Mode

High Speed Mode

Low Power Mode

SPECIFICATIONS

350m at 90%

210m at 90%

210m at 90%

Single Point Accuracy

Distance

Angle

Dual Axis Compensator

Resolution

Accuracy

Range

Target Detection Accuracy

LASER SCANNING SYSTEM

Type

Laser Class

Scan Density (Resolution)

Spot Size

Maximum Sample Density

Field of view (per scan)

Colour Digital Imaging

SCANNING CONTROL

Control System

Display

Keyboard

Data Storage

PHYSICAL

Dimensions

Weight

3.5mm (1-150m), 1

6”

1”

4”

± 6’

3” at 50m

Pulsed Precise Scan Technology

3R (High Speed / Standard) 1M (Low Power)

4mm at 20m

1mm at 20m

Horizontal: 360º Vertical: 270º

5M pixel, Dual (170°/8.9°)

On-board

VGA Colour Touch Display

3 Key

SD Card

152 x 293 x 412mm

11kg

Phoenix Survey + Safety Equipment | phoenixse.com

43

FARO FOCUS

3D

X 130

LASER SCANNER

The new X-series laser scanner FARO Focus

3D

X

130 is a powerful high-speed 3D scanner for all kinds of applications.

The ultra-portable Focus

3D

X 130 enables fast, straightforward, and yet accurate measurements of façades, complex structures, production and supply facilities, accident sites and large-volume components. Combining the highestprecision scanning technology with authentic mobility and ease-of-use, the new device offers reliability, flexibility, and real-time views of recorded data. The 3D scan data can easily be imported into all commonly used software solutions for accident reconstruction, architecture, civil engineering, construction, forensics or industrial manufacturing.

With a battery runtime of 4.5 hours, the laser scanner has also a high level of flexibility and endurance. The Focus’ light weight, small size and SD-card makes the scanner truly mobile.

MID RANGE SCANNING

– UP TO 130M

Its range up to 130m allows the Focus

3D

X 130 for laser scanning in all kinds of applications in the architecture,

BIM, heritage, forensics, shipbuilding, construction, process industry, CGI, and many others.

XTRA POSITIONING

– INTEGRATED GPS RECEIVER

Effortlessly determine the position of the scanner. This helps to facilitate the registration process and provides the exact time and location of the users’ scans.

XTRA PORTABLE

The Focus

3D

X 130 has the size of only 24 x 20 x 10 cm and a weight of just 5.2kg. Waterproof Pelicase and a ergonomic backpack incl. tripod holder make the device truly portable.

WIRELESS LAN

WLAN remote control permits you to start, stop, and view scans at a distance.

SPECIFICATIONS

RANGING UNIT

Unambiguity interval

Range Focus

3D

X 130

Measurement speed (pts/sec)

Ranging error 1

COLOUR UNIT

>130m

0.6m - 130m indoor or outdoor with upright incidence to a

90% reflective surface

122,000 / 244,000 / 488,000 / 976,000

±2mm

Resolution

Dynamic colour feature

Parallax

Up to 70 megapixel colour

Automatic adaption of brightness

Co-axial design

DEFLECTION UNIT

Field of view (vertical/horizontal)

300° / 360°

Step size (vertical/horizontal)

0.009° (40,960 3D-Pixel on 360°) / 0,009° (40.960 3D-Pixel on 360°)

Max. vertical scan speed 5.820rpm or 97Hz

LASER (OPTICAL TRANSMITTER)

Laser class

Wavelength

Laser class 1

1550nm

Beam divergence

Beam diameter at exit

DATA HANDLING AND CONTROL

Typical 0.19mrad (0,011°) (1/e, halfangle)

Typical 2.25mm (1/e)

Data storage

Scanner control

New WLAN access:

SD, SDHC™, SDXC™; 32GB card included

Via touchscreen display and WLAN

Remote control, scan visualisation are possible on mobile devices with Flash ®

HANDLING

Dual axis compensator

Height sensor

Compass

GPS

2

Levels each scan: Accuracy 0.015°; Range ± 5°

Via an electronic barometer the height relative to a fixed point can be detected and added to a scan

The electronic compass gives the scan an orientation. A calibration feature is included

Integrated GPS receiver

44

Hire • Repair • Sales • Support • Training

TOPCON LN-100

ROBOTIC TOTAL STATION

Building Information Modelling (BIM)

Construction coordination is essential for any building project. Knowing what was done before and working from the same design plan is critical to maintain schedule and avoid costly collisions.

With Topcon’s BIM solutions you stay connected to the same design.

Topcon’s BIM solutions help perform fast layout of design points and quick quality control documentation. A project’s success is based on productivity, accuracy, and coordination.

Contribute precise as-built data back to the

BIM model as your work is done.

The world’s first 3D positioning system designed specifically for construction layout.

The first time you see it you know it’s unlike anything you’ve seen before.

Its clean, innovative design tells you right away that the LN-100 is a game changer. The LN-100 strips away complexity to deliver an easy-to-use tool dedicated to construction layout. The LN-100 utilizes Topcon’s timeproven laser and robotic total station technologies to create a totally new tool that’s easy to use, without sacrificing the accuracy and versatility demanded for all types of construction layout.

With the press of just one button, the LN-100 automatically self-levels and is ready for action. Fire-up its hand-held, touch-screen controller and you are ready to go to work.

With the wireless controller, you can call up simple point layout or large CAD drawings—right in the palm of your hand, anywhere on the site. Display the design point or line that needs to be staked out, touch it, and the LN-100 laser immediately points to the exact location. It can also lock onto a prism and guide you to the next design points. One-person layout has never been this easy.

From traditional utility layout, to foundations, electrical, plumbing, walls, ceilings, HVAC, and much more, layout anything on the job site up to 100m away. Never before has construction layout been so powerfully simple.

3D Layout Tool

The LN-100 is a compact, self levelling, easy-to-setup

3D layout tool designed for construction layout.

Use the LN-100 instead of theodolites tapes or other layout tools.

Compact, rugged and very light weight, the LN-100 is ideal for construction layout and as-builts.

SPECIFICATIONS

POSITIONING ACCURACY

Measurement Range

Positioning Accuracy

Vertical Coverage

Horizontal Rotation

Guide Light

0.9m – 100m

±3mm

±25° up to 22m range,

±10m height,

22 - 100m range

360º

Range : ~100m

V : ±12°, H : 8°

HARDWARE

Laser Plummet

Auto Levelling

Communication

LED Indicators

Working Duration

Integrated

Self-levelling (±3°)

LED indicators for levelling

Wireless 802.11n/b/g

Power, Battery Level, Communication and Self-levelling

5 Hours (1 battery)

PHYSICAL

Dust/Water Protection IP65

Dimensions 185 x 196 x 295mm

Weight (inc. batteries and antenna) ~ 4kg

Phoenix Survey + Safety Equipment | phoenixse.com

45

EQUIPMENT

FINANCE

CONSERVE CASH RESERVES

Leasing allows resources to be saved for other purposes, such as new business opportunities, unexpected needs, business development or marketing. Money is kept ‘in the business’ rather than in depreciating assets. It may also be possible to tailor the timing of the payments to suit expected cash flow including seasonal cash flow circumstances.

BUDGET OUTGOINGS

Medium term planning: Payments will be known at the outset.

These can be monthly or quarterly. The finance will be secure for the term of the agreement; it cannot be recalled early like a bank overdraft. The payments are also fixed for the length of the term, which enables easier forecasting of cash flow.

TAX ADVANTAGES

Due to the nature of the tax advantages of leasing (i.e. the full rental costs being offset against profit), and taking into account the opportunity cost of investment, the lease will usually work out cheaper than if the asset were bought for cash.

MAINTAIN CREDIT LINES FOR

OTHER USES

Equipment can be acquired without impacting other credit lines, such as loans and overdrafts, making further borrowing easier.

CONTACT YOUR NEAREST DEPOT

FOR MORE INFORMATION OR

EMAIL: [email protected]

NO EXTRA SECURITY REQUIRED:

The equipment itself is normally the only security required on a finance agreement. If bank funding was used to buy the equipment instead, extra security would normally be required, or the rates would be substantially higher.

Finance offered subject to status, contact us for full terms and conditions.

46

Hire • Repair • Sales • Support • Training

EQUIPMENT

TRAINING

GPS EQUIPMENT USER TRAINING

Phoenix Survey & Safety Equipment is now offering a number of cost effective training courses, tailored to suit your requirements - whether you’re after the basics or something more comprehensive.

With technology moving faster than ever, it’s important to keep ahead of the competition when it comes to saving time and costs and improving productivity. Phoenix offers a range of courses designed for total station and GPS users to help you get the most from your time on and off site.

Whether you’ve bought a new instrument or you have an old piece of equipment that you need a refresher on, Phoenix has a dedicated team that specialise in training, sales and customer support of the high-end equipment required by today’s survey, mapping and data collection professionals.

CONTACT US NOW FOR

DETAILS ON AVAILABLE

TRAINING PROGRAMS

TRAINING TAILORED FOR YOU:

In today’s competitive market, you can save time and money on-site with expert knowledge of how to get the most from your equipment.

Courses held Monday - Friday

One to one or group courses

Training can be held at your site or our facilities

Half or full days training to suit your needs

Post training phone and email support provided

Where required a training course can also cover post-survey office processing with software packages such as Magnet Office Topo or Topcon Tools. See pages 58-59 for more information on our survey software packages.

Phoenix Survey + Safety Equipment | phoenixse.com

47

TOPCON HiPER SR

SITE RECEIVER

Providing leading edge technology in a new smart, rugged design, the new

HiPER SR provides superior performance at an affordable price. The compact, integrated receiver design includes the

GNSS board, industry leading

Fence Antenna™, sealed long-life power supply, memory storage and Topcon’s innovative LongLink™ communication technology.

With the HiPER SR, you don’t have to sacrifice durability and performance to have a lightweight receiver. HiPER SR – a compact lightweight receiver that is built to take the most intense environmental conditions and job site punishment.

The design of the HiPER SR also provides a great deal of versatility, allowing the HiPER SR to be configured in a variety of ways depending on your project requirements. Use a pair of HiPER SR receivers for a low-cost, completely cable free base and rover RTK system.

Using Topcon’s LongLink™ RTK communication, HiPER SR makes the perfect affordable, small job site system. HiPER SR also makes a great low-cost static GNSS system that can be pre-programmed and operated in the field with just one button. You can also utilize the HiPER SR as a network RTK rover by adding network functionality and a cellular enabled controller.

FEATURES:

Compact, lightweight, rugged design

Completely integrated receiver, antenna, batteries, memory, and communications

Superior multi-constellation Vanguard

GNSS chipset

Integrated multi-channel LongLink™ communication technology

48

Hire • Repair • Sales • Support • Training

TOPCON HiPER SR

SITE RECEIVER

RUGGED AND LIGHTWEIGHT

The HiPER SR is both lightweight and rugged. It is guaranteed to survive a

2m on the pole drop to concrete. The magnesium metal housing is rugged and lightweight.

INTEGRATED DESIGN

HiPER SR brings an innovative combination of compact, lightweight design with advanced technology and performance. The integrated design includes GNSS receiver, power supply, memory, and communications module

– all in a rugged, environmentally sealed housing.

CABLE-FREE DESIGN

This completely integrated receiver operates cable free in the field, with no antennas, battery doors, or connectors to worry about. The mini USB port is completely waterproof.

VANGUARD TECHNOLOGY

The latest Topcon GNSS chipset and firmware provide Universal Channel

Tracking. The receiver firmware can read existing satellite signals, and new signals planned for the future.

SPECIFICATIONS

TRACKING CAPABILITIES

Number of Channels

Tracked Signals

Antenna Type

POSITIONING ACCURACY

*1

RTK L1+L2

Fast Static

Fast Static

DGPS

L1

L1+L2

SBAS

COMMUNICATION

RTK Broadcast

I/O Communications

DATA AND MEMORY

Memory

Real Time Data Output

ASCII Output

PHYSICAL

Dimensions

Weight

Operation Time

ENVIRONMENTAL

Operating temperature

Storage temperature

Humidity

Water / Dustproof

226 Channels

GPS, GLONASS, SBAS, QZSS, Galileo, and COMPASS*

Fence Antenna™ Technology

H: 10 mm + 1.0 ppm

H: 3 mm + 0.8 ppm

H: 3 mm + 0.5 ppm

H: .04 m

H: 1.0 m

V: 15 mm + 1.0 ppm

V: 4 mm + 1.0 ppm

V: 5 mm + 0.5 ppm

V: .06 m

V: 1.5 m

LongLink™ 300m+ Range, Up to 3 simultaneous rovers

Bluetooth ® , Serial, USB

4GB internal (Firmware limit of 2GB of static data)

TPS, RTCM SC104 v 2.x, 3.x; CMR/CMR+

NMEA 0183 version 2.x and 3.0

6 x 6 x 1.5 in (w x d x h) 150 x 150 x 64 mm

1.87lbs., 850g

Up to 20 hours

-20oC to +65oC with internal batteries

-40oC to +65oC with external power

-40oC to +70oC

100%, condensing

IP67

*Galileo and COMPASS support will be incorporated into HiPER SR when these constellations have matured and are ready for commercial use.

Phoenix Survey + Safety Equipment | phoenixse.com

49

TOPCON HiPER V

DUAL FREQUENCY GNSS RECEIVER

Compact, cable-free solution with

Vanguard Technology for all GNSS positioning applications.

In a continued commitment to improving the productivity of positioning professionals, Topcon enhances the HiPER family of products by adding

Vanguard Technology to the HiPER V. In the early

2000’s Topcon revolutionized GNSS receivers by integrating the design to be compact and light weight. Topcon continues the revolution with

Vanguard Technology™.

Topcon raises the standard once again by adding Vanguard Technology’s 226 channels and Fence

Antenna™ into a versatile, configurable receiver, HiPER V. The additional channels and precision antenna element make RTK positioning faster and more productive than any other receiver on the market.

DUAL-CONSTELLATION

SIGNAL TRACKING

Topcon’s industry leading GPS+GLONASS dual-frequency signal tracking offers better performance than GPS only receivers. Urban canyons or woodlands are difficult locations for GNSS positioning. But with Topcon’s dualconstellation solution you can work near tall obstructions and limited skyview.

INTERNAL RADIO CONFIGURATIONS

The HiPER V can be configured with the radio and cellular modem that best fits your needs.

You can choose from Digital UHF or Spread

Spectrum radio. Further, you can choose from

HSPA , CDMA, or no cellular module. With both a radio and cellular module housed internally, the HiPER V can be used as a base and rover one moment and then a network rover the next

(with a suitable SIM card and TopNET licence).

50

FEATURES:

Vanguard Technology

226 GNSS Channels

Integrated RTK and Static Receiver

Rugged, Magnesium Alloy Construction

Fence Antenna Advanced Performance

Base and rover or network rover options

Ideal for surveying and setting out

Hire • Repair • Sales • Support • Training

TOPCON HiPER V

DUAL FREQUENCY GNSS RECEIVER

TRACKING CAPABILITIES

Number of Channels

Tracked Signals

GPS

GLONASS

SBAS

POSITIONING ACCURACY

*1

Static

Kinematic

RTK

DGNS

L1+L2

LI only

L1+L2

L1+L2

WIRELESS COMMUNICATION

Bluetooth

®

Radio

*3

ENVIRONMENTAL

Dust/Water Protection

Shock

SPECIFICATIONS

226 Channels with Universal Tracking Technology

L1 CA, L1/L2 P-code, L2C

L1/L2 CA, L1/L2 P-code

WAAS, EGNOS, MSAS, QZSS

H: 3 mm + 0.5 ppm

H: 3 mm + 0.8 ppm

H: 10 mm + 1 ppm

L1+L2

<0.5 m

V: 5mm + 0.5ppm

V: 4 mm + 1 ppm

V: 15 mm + 1 ppm

V: 15 mm + 1 ppm

V2.1 + EDR, Class 2, 115,200bps

UHF, Spread Spectrum, Cellular (options)

Operating Temperature

IP67

2m (6.56 ft.) pole drop

HiPER V receiver with battery

-40°F to + 149°F (-40°C to + 65°C)

Battery

-4°F to +149°F (-20°C to + 65°C)

Radio/GSM modems

-4° to +131°F (-20° to + 55°C)

PHYSICAL

Enclosure

Size

Weight

Battery

POWER SUPPLY

Standard Battery

Operating Time

External Power Input Voltage

Magnesium alloy housing

7.24” D x 3.74“ H (184mm D x 95mm H)

HiPER V receiver 2.20 lb. to 2.82 lb. (1.00kg to 1.28kg)

6.9 oz. (195g)

Detachable, Li-ion rechargeable battery, 7.2V, 4.3Ah

>7.5 hours in static mode at 68°F (20°C) w/Bluetooth

®

connection

6.7 to 18V DC

1. Number of channels and tracked signals vary according to receiver configurations.

2. RMS Values. Accuracy depends on the number of satellites used, obstructions, satellite geometry (DOP), occupation time, multipath effects, atmospheric conditions, baseline length, survey procedures and data quality. 3. 10 Hz standard. Higher rates available as options.

TOPCON FIELD

CONTROLLERS

The Topcon HiPER V System can be supplied with a choice of advanced field controllers.

VISIT PAGE 57 FOR

MORE INFORMATION.

AFFORDABLE ADVANCED GNSS

Phoenix Survey + Safety Equipment | phoenixse.com

51

TOPCON GR-5

ADVANCED GNSS RECEIVER

The new GR-5 receiver is the next step in the continuing development of the latest, most advanced receiver technology available. Building from the tremendous success of the world’s first

G3 RTK receiver, the Topcon GR-3, the new GR-5 provides the latest technological advancements.

As with its predecessor the Topcon GR-5 combines all three of the original positioning systems – GPS, GLONASS, and

Galileo. Although the commercial use of Galileo is still in the future, Topcon continues its commitment to develop technology to utilise ALL signals from ALL satellites. Topcon is also committed to the precision signals from the developing

Chinese Compass system, Japan’s Quasi-Zenith Satellite

System (QZSS), and India’s IRNSS system. If there is an operational advantage of combining new systems and signals, you can count on Topcon to continue to lead the industry.

The most significant advancement comes with the GR-

5’s new, state-of-the-art Fence™ Antenna. With high performance tracking of low elevation satellites the

Fence™ Antenna provides unsurpassed sensitivity while simultaneously improving accuracy, providing signal tracking capabilities not found in any other RTK receiver.

Not only does the new Topcon Fence™ Antenna outperform other RTK receivers with enhanced sensitivity, but also provides sophisticated multi-path rejection algorithms that gives the GR-5 a level of tracking performance and accuracy in difficult environments beyond any other RTK GNSS receiver.

In side-by-side tests with other RTK GNSS receivers, the new Topcon GR-5 with Fence™ Antenna Technology outperformed the competition in tracking ability, acquisition speed, positional accuracy, repeatability, RTK radio range, and overall RTK performance. See for yourself - arrange a demo today!

52

Hire • Repair • Sales • Support • Training

TOPCON GR-5

ADVANCED GNSS RECEIVER

SPECIFICATIONS

TRACKING CAPABILITIES

Number of Channels

Tracked Signals

216 Universal Channels

GPS L1, L2, L2C, L5

GLONASS L1, L2, & L5 carrier

Gallieo GIOVE-A, GIOVE-B

SBAS

WAAS/EGNOS YES

Antenna Type

POSITIONING ACCURACY

Real time RTK accuracy

Post processed Static DGPS

COMMUNICATIONS

Optional Radio Type

Base Radio Output

Cellular Communications

Wireless Communications

DATA & MEMORY

Memory

Data Update/Output Rate

Real Time Data Output

ASCII Output

Control & Display Unit

ENVIRONMENTAL

Enclosure

Operating Temperature

Environmental Specification

Shock Rating

Humidity

Integrated Micro-Center on Flat Ground Plane

H: 10 mm + 1 ppm

H: +3.0 mm + 0.5 ppm

V: 15 mm + 1 ppm

V: +5.0 mm + 0.5 ppm

Integrated Tx/Rx UHF Digital TPS/Satel protocol

0.250 – 1.0 Watts, selectable

Integrated via SIM Card, GSM/GPRS

Integrated Bluetooth version 1.1 comp

Internal, Removable SD Memory Card

100 Hz

TPS, RTCM SC104, CMR, CMR+

NMEA 0183 version 3.0

Optional, External, Mobile Computer

Magnesium I-Beam Housing

–40°C to 50°C

IP66 waterproof/dustproof

2m pole drop, SAE J1455, Section 4.7 (4G RMS), MIL-STD

202G, Method 214A

100% non condensing

The new GR-5 design didn’t stop simply with new antenna and tracking technologies, the GR-5 also boasts numerous advancements such as an increased number of channels, extended battery life, expanded internal memory options, new internal modem design, internet-compatible firmware, and much, much more.

It all sums up to…

More Performance.

More Accuracy.

More Productivity.

FEATURES:

Unmatched Tracking Sensitivity

216 Universal Tracking Channels

GPS + GLONASS + Galileo Tracking

High Accuracy in Difficult Environments

100 Hz RTK position update

Multiple Radio & Cellular Modem combos

32 GB SDHC storage support

Hot Swappable Batteries

Interchangeable Base & Rover

Static, RTK and Network RTK Modes

Phoenix Survey + Safety Equipment | phoenixse.com

53

With the completion of the Ordnance Survey’s upgrade to the nationwide CORS (Continuously Operating Reference

Stations) network, Topcon is now working in partnership with the Ordnance Survey and using data from OS Net.

We can now offer users an RTK grade subscription service to allow positioning activities at centimetre level accuracy.

Note that we refer to it as a GNSS (Global Navigation Satellite System) rather than just GPS; thanks to the infrastructure of Topcon’s partners in conjunction with their own network; Topcon are able to provide both

GPS & GLONASS corrections throughout the United Kingdom and Ireland.

54

CORRECTION

SERVICE

TOPNET CORRECTION SERVICE

TopNET+ is Topcon’s dedicated GNSS network correction service, available to all subscribers using a GNSS receiver unit and a mobile data connection. With this service, users can carry out their usual surveying activities without the need for a GNSS base station, as network corrections are supplied to the rover using a low cost GPRS connection, offering real time positioning in the coordinate system of your choice.

SUBSCRIPTION PACKAGES

TopNET+ is available in a number of different subscription plans to suit all user requirements including DGPS and RTK. The limited service allows the user to receive network connections for up to 40 hours each month. The unlimited service offers users unrestricted access to network corrections. Discounts are available for TSA members.

CONTACT US NOW FOR MORE DETAILS ON

AVAILABLE NETWORK SUBSCRIPTIONS

Hire • Repair • Sales • Support • Training

TOTAL STATION & GPS ACCESSORIES

DATA

COLLECTORS

Topcon offer a range of technologically advanced data loggers with multiple software options to suit your job.

TOPCON FC-336 DATA COLLECTOR

Topcon’s FC-336 is a fully rugged handheld built to meet MIL-STD-810G with high-speed

3.5G WWAN wireless networking, designed for dependability under the most extreme conditions.

Integrated Sensors

Embedded 48 channel all-in-view tracking SIRF Star IV™ chipset provides position information by point positioning or by DGPS using SBAS corrections. The FC-336 incorporates a 5MP autofocus camera, electronic compass and an altimeter for GIS data collection applications.

Long Life Battery

The field-swappable 5600mAh Li-ion long life battery can be removed and replaced on the job site. An external battery charger is available as an optional accessory.

TOPCON FC-500 FIELD CONTROLLER

The Topcon FC-500 data controller is designed for the construction, mapping and survey professional operating Topcon MAGNET® or

Pocket 3D and works with all Topcon GNSS receivers and total stations.

The FC-500 has an optional 3.5G cellular modem that provides access to MAGNET Enterprise and Sitelink3D for sending and receiving data files and staying connected.

The FC-500 includes a capacitive touchscreen, similar to many of the smartphones used every day. The display surface is also extremely scratch-resistant, and much more pierce resistant to sharp objects compared with other resistive displays in other products.

With the FC-500’s internal “intelligent” batteries, there is no worry of ever overcharging. Typical battery life is tested to 20 hours with excellent performance under extreme conditions.

Recharging is fast and gets to a 50 percent charge in as little as an hour.

Phoenix Survey + Safety Equipment | phoenixse.com

55

TOTAL STATION & GPS ACCESSORIES

DATA

COLLECTORS

TOPCON TESLA LARGE SCREEN DATA COLLECTOR

Following the success of tablet devices, Topcon have developed the Tesla, a new large screen tablet data logger running the Windows Mobile

6.5.3 operating system. With an impressive array of features, the new unit operates with Topcon’s full suite of software, including Magnet, Pocket

3D, Layout and eGIS.

All three Topcon Tesla units – Standard, Geo and Geo G3 – come with Wi-Fi and Bluetooth wireless technology. The Geo and the Geo 3G add a 3.2 MP camera and GPS capability; the Geo 3G also has a 3G GSM modem. With a 5.7 inch, ultra-bright backlit LCD screen, the Topcon Tesla ensures that bigger is definitely better. It also features an extremely long battery life of up to 16 hours. In addition, the unit has hot-swappable battery capabilities, ensuring continuous use without losing data. The unit weighs just 862g and measures

136 mm wide, 220 mm long and 51 mm deep. The dustproof and waterproof instrument with its IP67 rating is impervious to harsh conditions, including water, sand, humidity, dust, vibration, altitude, shock and extreme temperature.

56

Hire • Repair • Sales • Support • Training

TOTAL STATION & GPS ACCESSORIES

FEATURE

Microprocessor / Speed 1GHz

Operating System

Memory

Interface

Bluetooth

®

Capable

Wireless LAN

Internal Modem

Radio

Microsoft Windows Mobile ® 6.5

512MB NAND Flash and 8GB iNAND

USB Type Mini-B, Micro SDHC

(Up to 32GB)

Bluetooth

®

(v2.0 +EDR Class 2)

Yes (802.11b/g)

FC-336

SPECIFICATIONS

FC-500

1GHz ARM Cortex A8 i.MX53

Microsoft® Windows

Embedded Handheld 6.5

512MB RAM 8GB flash storage

User Accessible Micro-USB

Yes

Yes (802.11b/g/n)

UMTS/HSPA+3GPP

Via RC-4 if required

TESLA

Marvel PXA320 / 806 MHz

Windows Mobile 6.5.3

256MB SDRAM 2GB Flash Memory

D-sub 9 pin, USB rev 1.1 (Mini-B / Type A),

SD/SDHC slot, 3.5 mm audio jack,

Yes

Yes (802.11 b/g)

Tri-band HSDPA / UMTS, Quad-band GSM

/ GPRS/EDGE

Via RC-4

LCD Display

Display (Sunlight

Readable)

Keyboard

Audio

GPS

Camera

Touchscreen (480x680)

3.5” VGA 600 Nits-Quadra-Clear ®

22 operation keys, numeric, directional function

Integrated Speaker and Microphone

SIRF Star IV™ chipset

5MP, auto focus

4.3” colour WVGA LCD TFT

800 x 480 pixel resolution

5.7” (145 mm) colour VGA LCD (640 x 480)

5.7 inch ultra-bright colour touch screen,

LED backlight

10 operation keys, directional function

Directional function, on-screen keyboard, shift and programmable keys

Integrated Speaker and Microphone

DGPS capable (Geo/Geo 3G models only)

5MP, autofocus camera with flash

IP68 (MIL-STD 810G) -30°C TO 60°C

Integrated Speaker and Microphone

DGPS capable (Geo/Geo 3G models only)

/ 3G GSM Modem

3.2MP auto focus (Geo/Geo 3G models only)

IP67 / –20°C to +50°C Environmental IP68 / -30°C to 60°C

Dimensions / Weight H178 x W89 x D30mm / 500g

Batteries / Approx. Operating

Time (main battery)

Removable Li-ion Rechargeable Battery, 3.72V,

5600mAh / 12 hours with Bluetooth

®

connection

H91 x W184 x D38mm / 590g to 1070g depending on model

Removable Li-ion battery pack proving up to 20 hours operating time

H220 x W136 x D51mm /0.86kg

Li-ion hot swappable batteries / 16 hours

Phoenix Survey + Safety Equipment | phoenixse.com

57

MAGNET

ENTERPRISE

Magnet Enterprise is a web-based solution to manage your field and office data in the cloud.

Track your assets and communicate with all those involved on projects. Login from any browser for live updates.

The power of cloud storage and exchanging of data is realised in increased productivity. Sharing the most up to date, recently collected, or recently drafted data is critical to avoid mistakes in the field or the office. Enterprise provides the manager with the ability to see all projects on-going and also a secure private backed up copy of historical data.

FEATURES & BENEFITS:

Secure Cloud Storage - 500MB standard, add more as needed

Projects allow for team-based collaboration

Exchange data between field and office in real time

Track unlimited projects (based on available storage)

Asset Manager tracks your entire inventory of instruments

Live Chat with multiple members simultaneously: offer instructions and guidance or support your field crew right from your desktop

View survey results of points and lines on top of Google

Map

®

imagery

Set automated e-mail alerts with critical information

Cloud Based storage

Real time data sharing

“MAGNET Chat”

Real time messaging between MAGNET users

Real time data analysis with Google Maps

Equipment management and security

58

Hire • Repair • Sales • Support • Training

MAGNET

OFFICE

Magnet Office is a stand-alone processing and CAD solution for surveying and grading applications.

Available in several packages to suit your exact needs.

Magnet Office Tools

is the in office raw data editor, processing, and post-processing software.

Magnet Office Topo

is a drafting package for surveying and simple project drafting, in addition to all the functionality of Office Tools.

Magnet Office Site

contains all the functionality of Office Topo, plus advanced design and drafting tools for construction contractors.

Magnet Office Site w/Resurfacing

has all of the functionality of Office Site, plus advanced tools for paving, milling and ridability construction.

FEATURES & BENEFITS:

Modular System – Purchase what you need, when you need it.

GNSS Post Processing

Advanced data processing

Data format conversion

Import/Export of multiple data types inc

.dxf, .dwg, .txt, .shp, .xml & many more

Export data to Google Earth for data visualisation

Direct connection to MAGNET Enterprise for data sharing

MAGNET

FIELD

Magnet Field is the user interface that enables field users to collect land positioning data and perform construction, road layout, and land surveying functions, using total stations, levels, and GNSS receivers.

Perform topography, and layout functions all within a live

Bing maps view. Collect data with your own code library that will show your features on the screen. MAGNET Field does not require an internet connection in the field but can become even more productive with a cellular enabled controller.

FEATURES & BENEFITS:

Modular System – Purchase what you need, when you need it.

Control all your Equipment from one Software package

Easy to use graphical interface

Stake Out

Survey

Volumetrics

Cogo – In field calculations for areas, curves, offsets,

Intersections etc

Bing Maps

Stream live map data to the field controller

Data types – Multiple Formats

Roads Option

Advanced road construction module

Add offset line work to designs in the field

Phoenix Survey + Safety Equipment | phoenixse.com

59

Crowcon Detection Instruments Ltd develop and manufacture a complete range of portable and fixed gas detection products you can trust to protect people and plant against gas hazards worldwide.

CROWCON

GASMAN

The Crowcon Gasman is designed for use in the toughest environments offering an unbeatable combination of loud and bright alarms in a compact and lightweight design.

FEATURES:

Choose between flammable, toxic and oxygen interchangeable sensors

Tough poly-carbonate housing with IP65 and IP67 compliant protection

One button operation and easy to read LCD display with back light

Striking red and blue visual and vibrating alarms with a 95dB audible alarm

Data and event logging with time weighted average alarms for toxic versions

Clear indication of operating status and 30 day advance calibration due warning

CROWCON

TETRA3

The Tetra 3 multi-gas monitor is a single button operation, small lightweight gas detector designed for use in demanding industrial environments.

FEATURES:

Detects the standard four gases

Single button operation for easy use in gloved hands

Rugged impact resistant design

Lithium-ion battery with over 16 hours continuous operation

Water and dust resistant to IP65 and IP67

Top mounted backlit display of all gas readings diagnostics and battery life

Audible alarm, vibrating alarm and bright red and blue visual alarm

CROWCON

TETRA

Tetra is an intrinsically safe multi-gas monitor for the detection of flammable, oxygen and toxic gases. Tetra is the only portable gas detector with embedded software designed to the exacting requirements of IEC 61508-3 guaranteeing reliable and dependable operation.

FEATURES:

Digital interchangeable i-module sensors for full flexibility

Simultaneous 4 gas display with automatic backlight

Dual colour red/blue visual alarms and vibrating alarm

90dBA audible alarm with selectable tones

Rugged and robust with IP65 ingress protection

Peak mode operation and TWA reading recall

Data and event logging with simple IR interface to PC

60

Hire • Repair • Sales • Support • Training

CROWCON

DETECTIVE+

The Detective+ is a transportable area monitor that can be used singly or linked together for the purpose of providing an effective warning of gas hazards.

Detective+ is rugged and robust, with a fixed or folding leg protective frame options.

Alarms can be transmitted between Detective+ units while an optional built in pump allows faster gas response and better sensor protection.

A high battery capacity provides remote sites with extended usage and optional infra-red sensors can be equipped which provide either CO2 detection, or allow higher flammable gas level monitoring and immunity to the poisoning effects which standard flammable gas sensors can suffer from.

FEATURES:

Up to 4 gases monitored in a rugged and sturdy protective frame

Wide range of sensor options including infra-red

Ultra-loud 104 dBA sounder and red LED cluster alarms

Raised detectors with IP65 specification provides excellent sensor protection

Built-in pump option to provide faster gas response

12 Detective+ units may be linked together, up to 100m from adjacent units

CROWCON

GAS PRO

The Gas-Pro has an easy to read top mount display and can detect up to 5 gases.

The optional internal pump, activated with the flow plate, takes the pain out of pre-entry testing and allows Gas-Pro to be worn either in pumped or diffusion modes.

FEATURES:

Large, easy to read top mount display for hands free observation

5 Gas Monitor - Up to 5 gases in a compact and rugged design

Single button operation with intuitive functionality

Li-ion battery provides over 19hrs use from a 5hr charge

Water and dust resistant to IP65 and IP67

Specific and unique Pre-Entry mode

Flexible options for bump testing and calibration

FIXED GAS MONITORS

We are also able to offer a full range of Fixed Gas Monitoring solutions for flammable, toxic and oxygen gases to suit all applications. Our comprehensive range offers compact and rugged designs with high reliability and the flexibility to adapt to specific use requirements.

GAS DETECTOR SERVICING & REPAIR

We have fully equipped service workshops each staffed by an experienced team of engineers who are able to service and repair the majority of gas detection products on the market today.

If you have a fleet of gas detectors contact us to find out more about our fleet maintenance contracts which take the hassle out of maintaining a large fleet of instruments ensuring they are properly maintained, calibrated and compliant at all times.

Phoenix Survey + Safety Equipment | phoenixse.com

61

FULL CONFINED SPACES

PACKAGE

The Full Confined Spaces Kit offers a complete solution for safe, easy access and egress into confined spaces such as manholes.

THE STANDARD KIT COMPRISES OF:

1 x DB-A2 Tripod c/w Mounting Bracket

1 x HRA Rescue/Retrieval Winch c/w SK200 Carabiner

1 x G2-AR Two Point Harness

1 x Drager CF Escape Breathing Apparatus

1 x Crowcon Tetra3 Four Gas Detector

ENERGY ABSORBING LANYARD

The IKAR Energy Absorbing

Lanyards are specially developed to be lightweight, easy to use items of a Personal

Fall Protection System.

62

Hire • Repair • Sales • Support • Training

FULL CONFINED SPACES

PACKAGE

2.

4.

1.

3.

1. IKAR DB-A2 TRIPOD

The IKAR DB-A2 Tripod has been specifically developed to create a stable, high attachment point for entry and egress of confined space work areas. Each leg has individual adjustment and a slip resistant foot to allow for uneven ground.

2. IKAR HRA RESCUE/RETRIEVAL WINCH

During normal use the IKAR HRA allows the user to move freely whilst the steel cable is kept under permanent tension.

In the event of a fall the locking system activates with the internal brake disk absorbing the energy. The rescue function then allows the casualty to be either lifted or lowered to safety.

3. IKAR FALL ARREST HARNESS

The IKAR Fall Arrest Harnesses are lightweight and multiadjustable to enable a range of users to work with the same harness. With both a rear and a front fall arrest attachment points, these harnesses can be used for both fall restraint and Fall Arrest.

4. CROWCON TETRA 3 FOUR GAS DETECTOR

The Tetra 3 multi-gas monitor detects the standard four gases (O2, CO, CH4, H2S) in a compact and user friendly design. The single button operation makes it easy to use with gloved hands and the top mounted backlit display shows all gas reading diagnostics and battery life.

5. DRAGER CF SERIES ESCAPE SET

The Drager CF constant flow emergency escape breathing apparatus allows safe and uncomplicated escape from hazardous environments with minimal user training.

Contained in a highly visible photo luminescent bag, the cylinder contents gauge is visible at all times allowing for quick inspection.

5.

Phoenix Survey + Safety Equipment | phoenixse.com

63

C-SCOPE XL2

CABLE LOCATORS

The new CXL2 and DXL2 Cable Avoidance Tools and SGA2 and SGV2 Signal

Generators from C.Scope have been designed to set a new benchmark in excavating safety as well as still delivering all the advantages and familiar operating practices associated with the original C.Scope product range. The new products are loaded with new features which enable operators to find more buried utilities by delivering improved levels of performance and helping to reduce the effects of human error.

The XL2 Cable Avoidance Tools are driven by powerful Digital Signal Processor Technology.

Advanced software programming enables the new products to provide outstanding detection performance even when locating in the most difficult areas.

64

Hire • Repair • Sales • Support • Training

C-SCOPE XL2

CABLE LOCATORS

FEATURES:

Power Mode

Radio Mode

Generator Mode

AllScan Mode

Accurate Depth Indication (DXL2 only)

Automatic Noise Rejection

Dynamic Swing Sensor

Automatic Daily Self Test

Optional Data Logging of all Locator activity

Optional Bluetooth™ for high accuracy GPS

High resolution Liquid Crystal Display

No Periodic Calibration required

Three year Warranty

FEATURE Frequency

Power

Radio

Generator

AllScan

Sondes

50-400Hz

10kHz-30kHz

33+131kHz

50Hz-33kHz

33kHz

SPECIFICATIONS

Sensitivity @ 1m (DEPTH) Detection Depth (MAX)

5mA

25µA

5µA

100µA

3m

2m

5m

3m

7m

DETECT AND TRACE

BURIED SERVICES SIMPLY,

QUICKLY AND RELIABLY

The XL2 Cable Avoidance Tools deliver improved signal detection sensitivity and better noise rejection so that they are now capable of detecting the smallest of signals, even in areas of high service density and electrical noise. The addition of the new simultaneous 33+131kHz frequency will assist in the detection of smaller buried cables such as telecoms, sheathed fibre-optics and streetlighting spurs.

Human error can be a contributory factor associated with cable strikes.

To address this issue, intelligent features such as an Automatic Daily

Self Test function and a dynamic

Swing Sensor help ensure that the best working practices are adhered to and are being applied on-site.

The Data Logging option can also provide an invaluable insight into working practices and help to identify key training requirements.

Phoenix Survey + Safety Equipment | phoenixse.com

65

C-SCOPE SG2

SIGNAL GENERATORS

C.Scope SGA2 / SGV2 Signal Generators are vital pieces of equipment used with C.Scope

Cable Avoidance Tools that significantly improve operator safety and enable better location of pipes and cables even in challenging environments.

The NEW 33kHz+131kHz combined signal further increases the number of buried services that can be energised and detected.

FEATURES:

One Watt adjustable Power Output

New 33+131kHz simultaneous Signal Output

Pulsed or Continuous Output Signal

Three Signal Application Techniques

Direct Connection

Wraparound

Induction

High resolution Liquid Crystal Display

(SGV2 only)

Accessory Tray

No Periodic Calibration required

Three year Warranty

66

Hire • Repair • Sales • Support • Training

C-SCOPE SG2

SIGNAL GENERATORS

Direct Connection allows specific pipes or cables to be individually traced, identified and their depths measured.

Induction method allows previously unknown metal pipes or cables to be detected and traced.

SIGNAL APPLICATION TECHNIQUES

The SGA2 / SGV2 offers three alternative ways to apply a Signal Generator signal:

Direct Connection

Direct Connection allows specific pipes or cables to be individually traced, identified and their depths measured.

The use of Signal Clamps, Signal Injectors and Direct

Connection leads make this mode the most effective method for pinpointing pipes and cables.

Wraparound

If it is difficult or inconvenient to use Direct Connection, then the Wraparound technique can be utilised to successfully energise a street or car park lighting cable.

Induction

Induction allows the Signal Generator to induce a detectable and traceable signal to previously unknown, undetected or inaccessible underground metal pipes or cables.

POWER

The SGA2 / SGV2 has a One Watt Power Output to provide long distance tracing. The SGV2 has a four position power level adjustment. The SGA2 can be toggled between a high

& low setting. So that the user can control how much power to use and when.

LOUDSPEAKER

The SG2 / SGV2 have a clear audible signal output to indicate when it is in operation. There is also the facility to mute the audio if required.

PULSED OR CONTINUOUS SIGNAL OUTPUT

The SGA2 / SGV2 offer the choice of a Pulsed or Continuous signal output enabling operators to switch to the Pulsed

Mode in high interference situations and keep on tracing.

SERVICING INFORMATION

In line with recommendations your cable avoidance equipment should be serviced every 12 months by an authorised specialist. Phoenix Surveying

& Safety Equipment are an official nationwide C-Scope Service Centre.

We are also able to service and repair most other recognised brands of cable location equipment. We will be happy to collect, service and return your equipment for a set fee.

For more information or to arrange an equipment service please contact your nearest depot or email [email protected]

Phoenix Survey + Safety Equipment | phoenixse.com

67

C-SCOPE MXL2 & MXT2

ADVANCED CABLE LOCATION PACKAGE

The new MXL2 and MXT2 from C.Scope have been designed to set a new benchmark in excavating safety as well as still delivering all the advantages and familiar operating practices associated with the original MXL and MXT.

The new products are loaded with new features which enable operators to find more buried utilities by delivering improved levels of performance and helping to reduce the effects of human error.

The MXL2 Pipe and Cable Locator is driven by powerful

Digital Signal Processor Technology. Advanced software programming enables the MXL2 to attain performance levels previously associated with high end pipe and cable surveying instruments. The MXL2 delivers improved signal detection sensitivity and better noise rejection so the Locator is now capable of detecting and tracing the smallest of signals, even in areas of high service density and electrical noise.

The multi frequency MXL2 also benefits from the addition of the new simultaneous 33+131kHz detection signal which enables a broader range of utilities including smaller buried pipes and cables such as telecoms, sheathed fibre optics and streetlighting spurs to be detected.

The NEW MXL2 and MXT2 are higher performance products designed to detect, trace and identify specific buried pipes and cables quickly, reliably and accurately.

FEATURE

Power

Radio

Transmitter

AllScan

Sondes

68

Frequency

50-400Hz

10kHz-30kHz

33+131kHz

8kHz

512 / 640Hz

50Hz-33kHz

33kHz

8kHz

512 / 640Hz

SPECIFICATIONS

Sensitivity @ 1m (DEPTH)

5mA

25µA

5µA

100µA

500µA

100µA

Detection Depth (MAX)

5m

5m

3m

3m

2m

5m

7m

7m

7m

Hire • Repair • Sales • Support • Training

C-SCOPE MXL2 & MXT2

ADVANCED CABLE LOCATION PACKAGE

MXL2 FEATURES:

Power Mode

Radio Mode

Transmitter Mode

Simultaneous 33+131kHz Signal detection for utility avoidance

8kHz Signal detection for tracing over longer distances

Ultra low 512/640Hz Signal detection for specialist tracing

All Scan Mode

Accurate Depth Indication

Signal Current Measurement

Automatic Noise Rejection

Dynamic Swing Sensor

Automatic Daily Self Test

- Optional Data Logging of all Locator activity

Optional Bluetooth™ for high accuracy GPS

High resolution Liquid Crystal Display

No periodic calibration required

Three year Warranty

MXT2 FEATURES:

One Watt 4-level adjustable Power Output

Three Signal Outputs

New simultaneous 33+131kHz Signal

8kHz Signal

512/640Hz Signal

Pulsed or Continuous Output Signal

Three Signal Application Techniques

Direct Connection

Wraparound

Induction

High resolution Liquid Crystal Display

Accessory Tray

No periodic calibration required

Three year Warranty

Power

Radio

Transmitter

AllScan

Depth

Signal Current

Frequencies

Visual Indication

Pulsed/Continuous

Max. Output

Yes

No

No

No

CXL2 CAT

Yes

Yes

33kHz

Yes

Yes

No

Yes

No

DXL2 CAT

Yes

Yes

33kHz

Yes

Yes

Yes

Yes

Yes

MXL2 LOCATOR

Yes

Yes

512/640Hz, 8kHz, 33kHz

Yes

SGA2 GENNY SGV2 GENNY MXT2 GENNY

33kHz

No

Yes

300mW

33kHz

Yes

Yes

300mW

512/640Hz, 8kHz,

33kHz

Yes

Yes

1W

Phoenix Survey + Safety Equipment | phoenixse.com

69

RADIODETECTION RD8000

ADVANCED CABLE LOCATORS

The RD8000 PDL and PXL deliver a highly controllable and reliable location product to service any industry.

The RD8000PXL is a high performance cable and pipe locator with a broad range of active, passive and sonde frequencies as well as a number of unique user features.

The RD8000PDL is Radiodetections most advanced cable and pipe locator delivering a broader range of frequencies and sophisticated fault-finding capabilities. It has all the features of the RD8000PXL and a larger range of active and passive frequencies (including CATV and CPS) plus Current

Direction (CD), and Fault Find (FF) modes.

TX SIGNAL TRANSMITTERS

70

The Tx-1 is a low power transmitter with a higher current and induction capability as well as Fault Find. All models feature a phase sensitive amplifier that delivers a groundimpedance compensated, constant current across its entire bandwidth in either direct connect, clamp or inductive mode.

© 2016 Radiodetection Ltd. All rights reserved.

Radiodetection RD8000 Pdl, Radiodetection RD8000 PXL, Radiodetection Tx-1.

Hire • Repair • Sales • Support • Training

RADIODETECTION RD8000

ADVANCED CABLE LOCATORS

FEATURE

RD8000 SPECIFICATIONS

RD8000PXL RD8000PDL

LOCATOR & RECEIVER SPECIFICATIONS

Sensitivity 6E-15 Tesla, 5µA at 1 meter (33kHz)

Peak Mode o o o o

Dynamic range 140dB rms/ √Hz

Null Mode

Peak/Null Mode - Simultaneous screen view enables identification of magnetic field distortion due to ground effects or nearby utilities

Single Mode o o o o

Selectivity

Depth accuracy

Maximum Depth*

120dB/Hz

Line: ± 5% tolerance 0.1m (4”) to

3m (10ft)

Sonde: ± 5% tolerance 0.1m (4”) to

7m (23ft)

Line 6m (20ft), Sonde 15m (50ft)

Fault Find CD & 8K

Current Direction (CD) - Current direction arrows allow identification of target utility, eliminating faulty trails on parallel conductors

Centros™ - Improves the accuracy and repeatability of measurements and delivers unprecedented responsiveness in the field

Compass - Visually follow the target cable or pipe orientation with the dynamic line indicator

SurveyCERT™ - Share RD8000 data with PC or PDA applications for reporting, audit and analysis

TruDepth™ - Indicates depth when the locator is oriented correctly above the target for the most accurate reading

Dynamic Overload Protection

Allows use of locator in areas where excessive signals are present.

StrikeAlert™- reduces the risk of accidents by detecting shallow power cables and alerting the operator with an audio warning

Passive Avoidance - Rapidly survey an area using power and radio signals simultaneously

Depth on Power eCAL™ - Validate your RD8000 against its original factory calibration using Centros™

Manager on your own PC

SideStep™ - Lets the operator adjust the transmitter frequency to avoid unwanted interference.

iLOC™ - Save time by remotely controlling the transmitter using an advanced long range

Bluetooth ® link.

o o o o o o o o o o o o o o o o o o o o

RD8000PXLB RD8000PDLB

Locate accuracy

CD Fault-Finding (CDFF)

Fault-Finding (FF)

Batteries

Battery life

Warranty

Dynamic overload protection

Compliance / Approvals

Environment

± 5%

5 CD pairs

Diagnose cable sheath faults from short circuit to 2M Ω using the

A-frame

Rx: 2 x D-cells (LR20)

Tx: 8 x D-cells (LR20)

Rx: 30 hours intermittent

Tx: use dependent on signal conditions typically 15 hours

36 Months upon registration

30dB (automatic)

FCC, RSS 310 RoHS, Weee, CE,

Bluetooth ®

IP54

Phoenix Survey + Safety Equipment | phoenixse.com

71

RADIODETECTION CAT4 & GENNY4

CABLE LOCATORS AND SIGNAL GENERATORS

Radiodetection’s range of Cable Avoidance Tools,

C.A.T4 and Genny4, build on over 30 years of

Cable Avoidance expertise to enable operators to find more buried utilities, faster.

The C.A.T4 Avoidance Mode™ lets the operator check an intended excavation area for Power, Radio and Genny4 signals, and pinpoint located utilities, in a single scan.

The bargraph ‘tidemark’ enables the user to quickly spot and zero-in on a buried conductor.

The Genny4 provides a simultaneous dual-frequency signal output. Alongside the familiar 33 kHz signal for general purpose locates, the Genny4 transmits a specialised Small

Diameter Locate frequency which facilitates location of utilities such as telecoms and street lighting, including spurs.

For difficult locates, the Signal Boost function enables the Genny4 signals to travel further and deeper, and couple onto utilities more easily.

C.A.T4’s Dynamic Overload Protection feature automatically filters out high levels of interference, allowing operators to continue working even in electrically noisy areas such as substations and under high-voltage cables – and requires no input from the operator.

Data Acquisition / Logging

On-board memory allows over a year’s worth of data2 to be stored on eC.A.T4 and gC.A.T4 series products. This data can be backed-up to a PC at any time, giving virtually unlimited record keeping for the life of the product. Retrieved data can be analysed, either locally or remotely, to aid in ensuring compliance and identifying training requirements.

Straightforward operation and introduction

C.A.T4 and Genny4 retain the familiar C.A.T operating interface first introduced by Radiodetection in the mid-1980s and have been designed to offer full reverse-compatibility.

For example, all Genny3 accessories are compatible with Genny4.

Radiodetection offers comprehensive training options for operators, managers and trainers to promote best working practises and supports management of those responsible for Cable Avoidance. Contact your local office or representative for more details.

Signal output power

Signal boost output power

Induction mode signal characteristic

Direct connection/clamp signal characteristic

Batteries

Warranty

GENNY4 SPECIFICATIONS

0.1W

1.0W

33 kHz

33 kHz & Small Diameter Locate frequency

Automatic impedance matching on connection

4 x LR20 (D) 1.5 V alkaline

12 months from purchase

© 2016 Radiodetection Ltd. All rights reserved. Radiodetection CAT4, Radiodetection Genny4.

72

Hire • Repair • Sales • Support • Training

RADIODETECTION CAT4 & GENNY4

CABLE LOCATORS AND SIGNAL GENERATORS

eCERT – REMOTE CALIBRATION VALIDATION

eCert remote calibration testing offers an innovative calibration option intended to form part of an annual service regime. Activated through the C.A.T Manager PC software, eCert provides a fast, thorough and convenient test of the key locating circuitry within C.A.T4, and validates the results against the original factory calibration using an internet connection to Radiodetection. Following an eCert test pass, a Radiodetection Calibration Certificate for that C.A.T4 can be printed or saved.

For a complete maintenance package, Radiodetection also offers exhaustive factory-backed service and recalibration options including full mechanical integrity inspection and function testing.

SMALL CABLE LOCATING

Simultaneous dual frequency and simple, intuitive, locating methods assist C.A.T4 and Genny4 users to locate Small Diameter cables such as telecom twisted pairs, CATV feeds, spurs and drop-offs which have historically been hard to find and a common strike risk.

SERVICE DUE INDICATOR AND CALSAFE™

Annual service and calibration is key to ensuring that C.A.T operators can work safely and with confidence in their equipment. To support this, eC.A.T4 and gC.A.T4 models provide a 31-day Service

Due countdown warning on start-up.

CALSafe – enabled units can be set to automatically deactivate on expiry of the defined calibration interval, to help ensure compliance with individual company policies. The interval required between services can be customised using the C.A.T Manager software to anything up to one year.

C.A.T4

MODEL COMPARISON

C.A.T4+ eC.A.T4

eC.A.T4+ gC.A.T4

gC.A.T4+

Avoidance Mode TM

Genny TM signal locate

Power signal locate

Radio signal locate

Small Diameter Locate frequency eCert TM

Dynamic Overload Protection

Depth

StrileAlert TM

Data acquisition

Service due indicator

SWING TM warning

CALSafe

TM

Bluetooth

®

(for future use)

GPS/GNSS

Standard Option

Phoenix Survey + Safety Equipment | phoenixse.com

73

CABLE LOCATION ACCESSORIES

Phoenix Surveying & Safety not only provide sales, hire, repair and training services for cable location solutions we also supply a comprehensive range accessories. If you cannot see what you need or have any questions please give us a call.

C-SCOPE CAT & GENNY KIT BAGS

A C-Scope Carry Bag will keep your cable locating equipment safe and also has the capacity to carry additional items such as site maps, marker paint or pegs. Choose between the

Professional Carry Bag that has specific compartments for each item or the Budget Carry Bag that is a loose holdall.

SIGNAL CLAMP

Apply a Signal Generator effectively to any cable by using the Signal Clamp. An practical way to allow individual cables to be traced, even amongst other cables.

SIGNAL INJECTOR

Apply the Signal Generator or MXT Transmitter signal to an electrical cable quickly and safely by using a standard wall socket as the point of connection with the C.Scope Signal Injector.

SPECIFICATIONS

Frequency

Max Cable/Pipe Diameter

33kHz and 8kHz

105mm

Lead Length

IP Rating

2m

68 (waterproof)

GENERAL PURPOSE SONDE

This general purpose sonde allows the route of non-metallic pipes such as sewers, drains and large plastic gas and water mains to be traced.

Ideal for finding the position of blockages in pipes and powerful enough to be detectable at 7metres depth with the MXL and 5metres with a Cable

Avoidance Tool.

Powered by 1 x AA battery the sonde can be attached to either drain rods or a flexi-rod for tracing and a spring coupling adapter can be used for greater manoeuvrability on bends and obstructions.

LIGHTWEIGHT PLASTIC PIPE TRACERS

The unique C-Scope Plastic Pipe Tracers are designed specifically to allow small diameter, non-metallic pipes to be traced. Developed as a result of requests from the British gas industry these pipe tracers are the smallest diameter product on the market and can be successfully inserted into pipes when nothing else fits.

Available in 20 metre or 50 metre lengths, the pipe tracer can be used for both ‘line’ tracing and ‘end’ tracing using the sonde housed at the very tip.

Frequency

Max Line Voltage

SPECIFICATIONS

33kHz

250 V rms

Max Power 100mW (nominal mains load)

Mains Power Frequency Range 45-65Hz

Frequency - Colour

SPECIFICATIONS

33kHz - Orange

8kHz - Green

Detection Depth

Dimensions

End Fitting

Battery Type

Battery Life

IP Rating

5m with standard CAT

7m with MXL Locator

39mm diameter, 121mm long

M10 threaded stud, supplied with connector for standard drain rods with 7 T.P.I. thread

1 x AA

Up to 15 hours

68 (waterproof)

Frequency

Cable Diameter

SPECIFICATIONS

33kHz

Line Detection Depth

Tip/End Detection Depth

2.5m with standard CAT

3.0m with MXL Locator

3.0m with standard CAT

4.0m with MXL Locator

6mm

74

Hire • Repair • Sales • Support • Training

HEAVY DUTY

PIPE TRACER

A flexitrace is a compact and labour saving solution for locating ducts and drains.

Attach a Signal Generator to both terminals of the flexitrace and the coil transmits a signal that allows it to be traced along its complete length with a cable avoidance tool. The end coil housing contains no batteries and is therefore very compact compared with traditional sondes.

Frequency

Line Detection Depth

Tip/End Detection Depth

Sonde Dimensions

Construction

SPECIFICATIONS

33kHz

3m

Available Cable Diameter and Lengths

3.0m with standard CAT

4.0m with MXL Locator

4.5mm x 25m / 50m

6.0mm x 30m / 50m / 80m

9mm diameter x 75mm

Glass Fibre Rod and copper conductors in a polypropylene sheath on a steel frame

COBRA

PIPE RODDING SYSTEM

The Maxi Cobra rodding system offers a faster and more economic solution than drain rods.

Using an adaptor this flexible solution can also be attached to a sonde for use in conjunction with a CAT & Genny tracing kit. Sizes range from 50m to 300m with a variety of adapters available allowing attachment of various accessories.

MINICAM SOLO PRO/PRO 360

DRAIN CAMERA

The Solo Pro records video and captures images for a cost effective one-man survey solution. Available in 40m, 60m and 100m coiler sizes this versatile system features a control unit with a high resolution TFT

Screen that can be easily removed for desktop use.

JPEG image capture is available or live MPEG4 video recording with 3 x Zoom function.

The MiniCam supports SD/SDHC card and

USB memory stick with an internal 16GB memory which is expandable to 128GB.

The internal Li-ion batteries allow for over

6 hours constant use and the user is able to charge the CCU directly from a vehicle

(12Vdc) or mains voltage (100V – 240vac).

The lightweight CCU and coiler are both environmentally protected to IP65 standard.

The Solo Pro 360 model offers the additional benefit of being able to pan and rotate the camera head inside the pipeline.

SPECIFICATIONS

CONTROL UNIT

Display

File Format

Power

Internal Storage

External Storage

CAMERA HEAD

Size

Construction

41 mm ø

Stainless Steel

Pipe Compatibility 50–225mm

Image 1/4” colour CCD DSP

Effective pixels

Resolution

512 x 582 (PAL)

470 HTVL (enhanced)

Sensitivity

Aperture / FOV

Sonde Options

COIL/ROD

Rod Lengths

Height / Weight

8” TFT LCD (800 x 600)

MPEG4 video / JPEG snapshots

Internal rechargeable Li-ion cells

Solid State memory (expandable to 128GB)

SD/SDHC card / USB2.0 memory stick

<1.0 lux

F2.5 / 75°

33khz, 512hz, 640hz

40m, 60m, 100m

620mm/15kg, 890mm/20kg, 960mm/30kg

Phoenix Survey + Safety Equipment | phoenixse.com

75

PEARPOINT P340+

FLEXIPROBE™ SYSTEM

P340+ flexiprobe™ pushrod inspection systems redefine convenience and control in pipeline inspection.

At the heart of the P340+ flexiprobe system is the weatherproof P340+ flexiprobe controller, which displays colour footage in digital quality on an ultrabright 8” TFT screen. USB flash drive and Compact

Flash storage options along with PC connectivity provide flexible data storage and comprehensive reporting capabilities.

The P340+ controller option features an internal lithiumion battery, providing convenient power for up to a full day’s typical usage, removing the inconvenience and set-up time of an external power lead.

P340 AND P340+ CONTROLLERS SPECIFICATIONS

Power requirements

P340 (+) controller input: 12-24VDC, 40W

External power supply (PSU) input: 100-240VAC, 50-60Hz, 1.2A

P340+ automotive battery charger input: 10-30VDC, 4.0A

Battery capacity (P340+) 14.8V, 6.6Ah (98Wh)

Battery run-time (P340+) Up to 1 days typical usage, 7hrs view only/4hrs continuous recording*

Display 8” Industrial TFT

Storage

Connectivity

High speed Compact Flash Card or USB flash drive

Environmental protection

USB, Analog video in/out (PAL/NTSC), Analog audio in/out

P340 (+) controller IP55 (covers closed) protection IP53 (covers open and socket panel closed)

P340 External PSU IP67 rated for outdoor use

P340+ External PSU option IP54 rated for indoor use

Dimensions 14” x 14” x 8” (360 x 360 x 200mm)

P340+ flexiprobe systems have been designed to deliver controllable and high quality video inspection for any situation, from residential work and commercial use through to specialist plant and municipal applications.

Fully sealed 1” (25mm) and 2” (50mm) cameras can be mounted on a range of rods: from the ultra-flexible 100’ (30m) Plumbers reel, designed for accessing tight corners, to the 500’ (150m)

P343 reel designed to push for long distances.

A range of compatible sondes, skids, brushes and accessories completes the package.

Dimensions

Weight

Power

Environmental

Temperature

CAMERA SPECIFICATIONS

P340+ 1”/25mm

P340+ 2”/50mm

Self- levelling

1” x 1.52”

25.4 x 38.7mm

0.1lbs/0.06kg

1.89” x 2.87”

48 x 72.8mm

0.8lbs /0.36kg

1.8W

3.8W

IP68 to 330’ (100m) /11bar

Storage:

-4°F to 176°F / -20°C to +80°C

Focus

Focal range

Lighting

Active pixels

(HxV)

Operating:

14°F to 122°F / -10°C to 50°C

Adjustable

10mm to

Ultra bright white LEDs

656 x 492 NTSC

768 x 576 PAL

768 x 492 NTSC

765 x 582 PAL

FINANCE PACKAGES AVAILABLE

Phoenix Survey & Safety in conjunction with our finance partner offer a range of leasing options to suit your business needs. Conserve cash reserves and acquire equipment that will allow you and your business to operate more efficiently with affordable repayments tailored to your cash flow circumstances. Visit page 6 for more information on the benefits of our finance packages.

RD1000+™

GROUND PENETRATING RADAR

The RD1000+™ is an exciting and powerful addition to the utility surveyor’s toolkit. Using radar technology, the RD1000+™ displays an image map of underground features in their topographical context making it ideal for locating and excavating utilities.

The advantage over a traditional, electromagnetic locator is that the RD1000+™ can see non-conductive materials including plastic pipes. Built from weatherproof materials, the RD1000+™ offers users a comfortable and easy-to-steer product that can operate in almost any terrain.

The RD1000+™ can be assembled on site in less than two minutes and can be dismantled with ease for compact storage and safe transportation. A high-contrast LCD displays the sub-surface map in real-time and offers features such as digital colour and gain enhancements that let the operator maximize locate quality and performance. Advanced digital filtering helps to eliminate unwanted signals and provide greater accuracy.

Unique to the RD1000+™, Locate Mode, is activated simply by reversing the cart and provides an accurate snapshot of underground conditions using a cursor to indicate the depth and location of a buried utility. The RD1000+™ also features onetouch image recording to help document findings, images are saved to Compact Flash cards which can also be used to update the RD1000+™ firmware when upgrades are made available.

© 2016 Radiodetection Ltd. All rights reserved. Pearpoint P340+ Flexiprobe™, RD1000+™ Ground Penetrating Radar.

76

Hire • Repair • Sales • Support • Training

© 2016 Radiodetection Ltd. All rights reserved. Pearpoint P340+ Flexiprobe™, RD1000+™ Ground Penetrating Radar.

EQUIPMENT

& SOFTWARE

TRAINING

TOTAL STATION, GPS & OFFICE

SOFTWARE USER TRAINING

Phoenix Survey & Safety Equipment offer a number of cost effective training courses, tailored to suit your requirements - whether you’re after the basics or something more comprehensive.

With technology moving faster than ever, it’s important to keep ahead of the competition when it comes to saving time, reducing costs and maximising productivity. Phoenix support a wide range of Topcon products designed to do just this both on and off site.

Whether you’ve recently purchased a new instrument or you have an older piece of equipment that you need a refresher on, Phoenix has a dedicated team that specialise in training and customer support.

CONTACT US NOW FOR DETAILS ON

TRAINING PROGRAMS AND BESPOKE

TRAINING TAILORED FOR YOU:

In today’s competitive market, you can save time and money on-site with expert knowledge of how to get the most from your equipment.

Courses held Monday – Friday

Course content pre agreed with you beforehand

Training can be held at your site or our facilities

Half or full days training to match your needs and budget

Products covered included levels, total stations, robotic total stations and GPS

Office software e.g. Magnet Office, also catered for (Import of data, volumes, DTMs, Sections, Plotting etc)

Surveying and setting out courses available

Both equipment usage and surveying techniques can be covered

One to one or group courses

Post training phone and email support provided

CONTACT US NOW FOR

DETAILS ON AVAILABLE

TRAINING PROGRAMS

Phoenix Survey + Safety Equipment | phoenixse.com

77

NM102

NOISE METER

The NM102 is a pocket-sized Sound Level Meter with more features than many higher price units.

Covering a wide measurement range (30 to 130 dBA) with automatic range selection, the meter is housed in a strong case shaped to reduce acoustic reflections. If you have any special measurement requirements, it is only a button push to select A or C Frequency Weighting or Fast/Slow Time Response.

Standard Accessories

SPECIFICATIONS

Wind shield, battery, soft carrying case

Optional Full Measurement Kit Sound level calibrator, wind shield, manual for meter and calibrator, batteries for meter and calibrator, soft carry case (for unit) hard carry case (for all items)

Display 4 Digit LCD with back light, update rate 0.5s

Indicators Low battery, frequency & time weighting, min/max

Resolution / Accuracy

Frequency Range

Level Range

Frequency Weighting

Microphone

Time Weighting

Dynamic Range

Battery / Battery Life

Dimensions

0.1dB / ±1.5 dB (ref 94 dB @ 1 kHz)

31.5 Hz to 8 kHz

30 to 130 dB(A), 35 to 130 dB(C)

A and C

1/2" electret condenser

Fast (125ms) and Slow (1s)

50 dB

One 9V battery (supplied) / About 50 hours (alkaline battery)

200 x 55 x 38, 170g (including battery)

CR:306

NOISE METER

The CR:306 is a general purpose digital sound level meter which meets the full requirements of

IEC 61672 to Class 2.

Ideal for basic noise surveys and can be used for measurements such as workplace spot checks, fire alarms and audible warning systems as well as the installation of sound systems. In applications where a Sound Level

Meter can be useful but a high specification instrument would be too costly, the CR:306 becomes a simple low cost solution for checking noise levels quickly and simply.

Standard Accessories

SPECIFICATIONS

24 month warranty, operating manual, a certificate of calibration, battery, calibration screwdriver, windshield

Optional Full Measurement Kit CR:514 Acoustic Calibrator, UA:239 Windshield, CP:65 Carrying Pouch. Certificates of calibration, operating manuals and batteries for both the Sound Level Meter and the Acoustic Calibrator

Applicable standards

Measurement Range

Range Information

IEC 61672:2002-1 Class 2, IEC 60651:1979 Type 2 I

35dB(A) to 130dB(A), 40dB(C) to 130dB(C)

L (Low) = 35dB(A) to 100dB(A), H (High) = 65dB(A) to 130dB(A)

Frequency Weighting

Time Weighting

Display Functions

Measurement Functions

Display Flags

Display

Outputs / Power

Microphone dB(A) & dB(C) to IEC 61672:2002-1 Class 2

Fast to IEC 61672:2002-1 Class 2

Normal (Sound Level), Maximum Hold

L

AF

, L

CF

, L

AFMax

, L

CFMax

Overload (Green Light), Under range (Red Light), Maximum Hold (HOLD), Low battery (LOWBAT)

3 ½ digit LCD with 0,1dB Resolution

AC Out Max output = 2V / 1 x 9V (6F22, PP3), External DC Power, 7V to 10V

½” pre-polarised electret condenser (Typically Type MK:268)

78

Hire • Repair • Sales • Support • Training

AIRFLOW

ANEMOMETERS

Airflow anemometers are ideal for anything from ventilation surveys, air conditioning, heating and environmental monitoring to worker safety on site including crane usage and working at height.

CHOOSE A

MODEL TO

SUIT YOU

Measures

Airflow Range

Airflow Resolution

Airflow Accuracy

Temp. Range

Temp. Resolution

Temp. Accuracy

Wind Chill Resolution

Wind Chill Accuracy

Digital Compass

Display

Measurement Scale

Max/Min Function

Display Hold

Battery / Battery Life

Dimensions / Weight

Warranty

ETI 8020

Air: temp, speed

0.4 to 20m per second

SPECIFICATIONS

ETI 8022

Air: temp, speed, volume

0.4 to 20m per second

0.1m/sec or 1ft/min

±2% of reading (air speed)

-9.9 to 49.9°C

0.1°C

±1°C n/a n/a n/a

LCD digital

MPH, KPH, knots, ft/min, m/s,

Beaufort scale

Yes

Yes

3 x 1.5 volt AAA / 180 hours

30 x 60 x 157mm / 180g

1 year

0.1m/sec or 1ft/min

±2% of reading (air speed)

-9.9 to 49.9°C

0.1°C

±1°C n/a n/a n/a

LCD digital with backlight

MPH, KPH, knots, ft/min, m/s,

Beaufort scale

Yes

Yes

3 x 1.5 volt AAA / 180 hours

30 x 60 x 157mm / 180g

1 year

WINDMATE 200 KESTREL 2000

Air: temp, chill, speed, direction Water + Air: temp, chill, speed

0.8 to 89 Mph, 1.0 to 144

Km/h, 0.6 to 78 kts

Not listed

0.4 to 40 m/s, 59 to 7877 ft/ min, 1.0 to 144.0 km/h, 0.8 to 89.0 mph, 0.6 to 78.0 kt, 0 to 12 B

0.1m/sec, 1ft/min, 0.1km/h,

0.1mph, 0.1kt, 1B

±3% of reading (air speed)

-20.0 to 158.0 °F

Not listed

±1°C / 1.8 °F

0.1°C / 0.1°F

±1°C / 1.8 °F

Yes - Wind direction to ±2˚

LCD digital with backlight

MPH, KPH, knots, ft/min, m/s,

Beaufort scale

±3% of reading (air speed)

-29.0 to 70.0 °C, -20.0 to

158.0 °F

0.1°C / 0.1°F

±1°C / 1.8 °F

0.1°C / 0.1°F

±1°C / 1.8 °F n/a

LCD digital with backlight

MPH, KPH, knots, ft/min, m/s,

Beaufort scale

Yes

No

Yes

Yes

1 x CR2032 / 400 hours approx 1 x CR2032 / 300 hours approx

19 x 44 x 140mm / 91g

2 year

122 x 42 x 18mm / 65g

2 year

INDUSTRIAL

THERMOMETERS

The Therma 1 and 3 digital thermometers are rugged and easy to use instruments that operate through the range of -100 to

1370°C with a 0.1°C or 1°C resolution.

Powered by three 1.5 volt AAA batteries that give a minimum of five years battery life, the therma series feature a large, easy to read LCD display.

Range 0.1°C

Range 1°C

Resolution

Accuracy

Battery

Battery Life

Sensor Type

Display

Dimensions

Weight

SPECIFICATIONS

THERMA 1/ELITE

-99.9 To 299.9°C

300 To 1372°C

0.1°C & 1°C

±0.4°C ±0.1%

3 X 1.5 Volt Aaa

10000 Hours/Min 5 Years

K Thermocouple

12 Mm LCD

25 X 56 X 128Mm

130 Grams

THERMA 3

N/A

-100 To 1372°C

1°C

±1°C ±0.1%

3 X 1.5 Volt Aaa

10000 Hours/Min 5 Years

K Thermocouple

12 Mm LCD

25 X 56 X 128Mm

130 Grams

Phoenix Survey + Safety Equipment | phoenixse.com

79

PROCEQ PROFOSCOPE

REBAR DETECTOR

Rebar location, cover measurement and rebar diameter measurement all provided by a single, fully integrated, cordless one-handed instrument.

Profoscope has a unique real-time rebar-visualization allowing the user to actually “see” the location of the rebar beneath the concrete surface. This is coupled with rebar-proximity indicators and optical and acoustical locating aids combine to make the task of locating rebars simple and efficient.

The Profoscope+ offers all the functions of the standard Profoscope model with the added capability of data recording that makes note taking an obsolete process. Data exchange can be done easily by connecting the Profoscope+ directly to the USB-port of the PC or by reading out the integrated Micro SD memory card. The included Windows based software ProfoLink allows the user to comfortably download, edit and present the data measured by the Profoscope+.

Standard Accessories

SPECIFICATIONS

Packaging with integrated start-up test kit, 2 x AA batteries, canvas bag, carrying strap, chalk and product documentation.

2GB MicroSD memory card (Profoscope+), USB-cable (Profoscope+), ProfoLink software CD (Profoscope+)

Self-adhesive protection covers x 3 for scanning face (391 10 121S), Calibration test block (390 00 270), Chalk x 10 (325 34 018S) Optional Accessories

Measuring Range / Accuracy

Short Measuring Range

Long Measuring Range

Data Logging

Power Supply

Battery Lifetime

Time Outs

(Range based on a single 14" size rebar with sufficient clearance to neighbouring rebars)

0-50mm / ±1mm, 51-80mm / ±1-3mm

80-185mm / ±3-4mm

Profoscope+ model only, via on-board SD Card or external connection to a device via USB connection

2 x 1.5v AA batteries

50 hours backlight off, 15 hours backlight on

Sleep mode after 30 seconds, auto shut down after 120 seconds

Water & Dust Protection IP54

Standards & Regulations Applied BS1881 part 204; DIN1045; SN 505 262; DGZfP B2

Typically Useful For General contractors, building inspectors, civil contractors, drilling specialists, electrical contractors, civil engineers, Educational institutes

Every Profoscope is supplied with a start-up test kit as standard. This kit allows the user to familiarise him/herself with the operation of the instrument in a comfortable, controlled environment to avoid wasting valuable time on site.

80

Hire • Repair • Sales • Support • Training

ZIRCON

STUD FINDERS & WALL SCANNERS

MULTISCANNER PRO SL

MultiScanner ® Pro SL quickly and easily locates studs, metal, and hot electrical wiring behind walls, floors, and ceilings. A 4-mode switch makes it easy to change functions, while the easy-to-read display screen, SpotLite

®

Pointing System, and audio tone all indicate the location of the target.

Locate the edges of wood or metal studs or find and trace live, unshielded electrical wire. The Pro SL will also locate non-ferrous metal, such as copper pipe, and ferrous metal, such as rebar.

MULTISCANNER i520 / i700

The i520 and i700 OneStep

®

MultiScanners

®

quickly and easily locate studs and joists behind walls, floors, and ceilings and also locate metal as well as live AC electrical wiring.

A 4-mode switch makes it easy to change functions, while the ultra-bright display screen, SpotLite

®

Pointing System, and audio tone all indicate the location of the target. A signal strength indicator helps to distinguish between shallow and deep targets. Auto correcting technology compensates for errors automatically such as when scanning begins over a stud and CenterVision

® technology will find the center of a stud in a single pass.

Stud Scan mode locates the edges of wood or metal studs whilst AC Scan finds and traces live, unshielded electrical wire. Metal scan mode locates nonferrous metal, such as copper pipe and ferrous metal, such as rebar.

The MultiScanner ® i700 has several unique features including an integrated, erasable marker for one-handed operation and a floating head design which keeps the scanning head flat on rough surfaces, even if the handle is rocked or tilted.

METALLISCANNER MT6

Locate embedded metal before your drill bit or saw blade does.

This powerful dedicated metal scanning tool can locate both ferrous and non-ferrous metal up to 152mm deep in any non-metallic construction material, including concrete, tile, and marble.

The MT6 automatically differentiates between magnetic metal (such as rebar) and non-magnetic metal (such as copper pipe) and will indicate the target depth and location. MT6 indicates when you are approaching a metal object with a large plus (+) sign on the display. When the plus becomes a minus (-), you have crossed over the target and are now moving away.

Phoenix Survey + Safety Equipment | phoenixse.com

81

ZIRCON

STUD FINDERS & WALL SCANNERS

ELECTRISCANNER V5

The ElectriScanner™ V5 locator finds and traces the path of live hidden wires. It pinpoints wires behind walls using a unique “dynamic calibration” which constantly re-adjusts and self-corrects during scanning, this allows the V5 to “learn the wall” and eliminate false positives to find live wires under almost any circumstance.

It will locate live wires (not shielded by metal) behind standard construction walls in residential, commercial, and industrial environments. Scan depth is typically

102mm although this can vary depending upon placement of wires, wire voltage, humidity, and the composition of the material you are scanning through.

Auto mode will detect a strong electrical signal and disregard weaker signals in order to home in on the strongest. In Manual mode it reports all results and will not disregard weaker signals (a low voltage wire, like a doorbell wire or landscape lighting wires). In Manual mode the tool will indicate the direction of the strongest signal nearby at any given time, even if it has encountered stronger signals before.

WHICH ZIRCON

SCANNER IS

RIGHT FOR YOU?

Finds Stud Edges

Finds Stud Centre with CentreVision™

Finds Studs up to 38mm

WireWarning ® Detection

Scans for Metal

Scans for Electrical

Over-the-stud Indication

ACT™ Auto Correcting

LCD Display Screen

SpotLite ® Pointing System

Signal Strength Indicator

Finds Studs in Lath & Plaster

Integrated Erasable Marker

MULTISCANNER

PRO SL

SPECIFICATIONS

MULTISCANNER

I520

o o o o o o o o o o o o o o o o o o o o

MULTISCANNER

I700

o o o o o o

METALLISCANNER

MT6

ELECTRISCANNER

V5

o o o o o o o o o

SHOP ONLINE AT WWW.PHOENIXSE.COM

Find the latest special offers, product updates and industry news as well as directions and maps to all of our branches at our website.

82

Hire • Repair • Sales • Support • Training

SEESNAKE MKII

CAVITY INSPECTION KIT

The SeeSnake Micro inspection camera MkII allows you to easily perform visual inspections in hard to reach areas. Its lightweight, handheld design allows for easy transport and an AV port which allows the image to be seen on any compatible monitor.

Standard Accessories

Display / Resolution

Camera Diameter

Cable Reach

Lighting

Waterproof

Power Source

SPECIFICATIONS

Waterproof Camera Head and Cable, Fully Adjustable LED Lighting,

Flexible 3ft Cable, Twist and Lock Attachments (Mirror, Hook &

Magnet), AV Port and lead, 4 x AA Batteries, Comfort Grip, High

Visibility 2.5 Inch Colour LCD, Protective Storage Case

2.5” Colour LCD / 160 x 234

17 mm (0.7”)

3ft (expandable to 30ft with optional extension lead)

2 Adjustable LEDs

Camera & Cable to 10ft (when properly assembled)

4 x AA Batteries (3 hours of continuous run-time)

HSW

RIGID ECONOSCOPE

The Henke Sass-Wolf (HSW) Econoscope is a high quality rigid endoscope with a miniature quartz halogen lamp built into the tip.

Operated from the rechargeable battery pack or directly from its charging unit, this tough unit is ideal for any application that requires a rigid endoscope with a 90˚ view. Shaft length is 315mm with a 9mm diameter.

Standard Accessories

Illumination

Field of view

SPECIFICATIONS

Battery & charger with cable and transformer for mains operation, spare lamp, scope protection sleeve for use in masonry, robust carrying case.

Quartz halogen 6v 4.5w

55˚ with fixed focus eyepiece - focusing from 7mm to infinity

LCD SC CARD

FLEXIBLE VIDEO ENDOSCOPE

This Palm sized LCD monitor style endoscope is equipped with a

LED light source, TFT Display, camera and recorder. The compact package allows work to be carried out without the need for separate laptops or other recording systems and can also output the image to a TV monitor.

The 5.5mm diameter can easily get through small cavity openings whilst the

4 white LED light intensity can be regulated by a dial on the unit. Videos are stored in MPEG4 format on an SD card for easy transfer. Oil and scratch resistant glass protects the camera and maintains the high image resolution.

Standard Accessories

Field of View / Depth of Field

Display / Resolution

Protection

Available Sizes

SPECIFICATIONS

45˚ Mirror attachment, mini USB cable, charging unit, 1GB memory card, AV leads, user instructions, aluminium carry case

67˚ / 1.5cm - 10cm

3.5” TFT LCD monitor / 640 x 480 - images, 320 x 240 - video (30fps)

IP57

5.5mm Shaft diameter. Available shaft lengths: 1m, 2m, 3m , 10m, 30m

Phoenix Survey + Safety Equipment | phoenixse.com

83

XL-VU

VIDEOPROBE

XL-VU VideoProbe is equipped to handle all of your remote visual inspection needs with superior All-Way ® Articulation, durability and probe options.

Save clear, accurate still images and motion video to the 1GB internal flash memory or removable USB. Easy-to-use controls and servo motor All-Way

®

Probe articulation make the XL-Vu very user friendly with a simple drop-down menu-driven operation menu navigated via the articulation joystick.

Choose from two power options - plug into a nearby AC outlet with the corded version or use a long running lithium ion battery. The XL-VU Video

Probe provides inspectors unparalleled access without a bulky base unit.

84

Standard Accessories

Optional Accessories

Probes

6.1mm Diameter Probe

3.9mm Diameter Probe

Insertion Tube Length

2.0, 3.0 or 4.5m

8.0m

Tip Optics

LCD Monitor

Joystick Control

Audio

Brightness Control

Illumination Type

Image Control

Image / Video Format

User Annotation

Memory

Data I/O Ports

Waterproof

Case Dimensions

SPECIFICATIONS

XL-VU system (corded version), Power cord (for corded version only), Operating manual, 4GB ThumbDrive

®

, Optical tip case, Standard shipping/storage case.

2 or 4 hour battery & AC battery charger (for battery version only), Mini magic clamp, Hand-set holder, Ball joint, Tube gripper.

1/6 inch colour SUPER HAD™ CCD camera, 440,000 pixels, titanium housing

1/10 inch colour SUPER HAD™ CCD camera, 290,000 pixels, titanium housing

Tip Articulation

Up/Down – 100° min, Left/Right – 100° min

Up/Down – 90° min, Left/Right – 90° min

Various tip options available with differing ranges of field of view/depth of view

Integrated 3.7" VGA colour LCD

360˚ All-Way

®

tip articulation, menu access and navigation,

Integrated 2.5mm headset/microphone jack

Auto and variable

White LED

Invert, 3 x Digital zoom

Bitmap (.BMP), JPEG (.JPG) / MPEG 4

Built-in full screen text overlay generator, User placement of graphic arrows

Internal 1GB Flash memory / external USB thumbdrive

1 x USB 2.0 port, VGA video out

Insertion tube and tip to 14.7 psi (1 bar, 10.2m of H2O, 33.5 ft of H2O)

62.5 x 21.8 x 50 cm (Full system weight 8kg approx)

Hire • Repair • Sales • Support • Training

The GE Protimeter Moisture Detection Range is at the forefront of its field and is widely used by professionals involved with the identification, management and remedy of dampness to identify the extent of the moisture penetration and diagnose the cause of the problem. All Protimeter Moisture Meters are supplied with a 24 month warranty for mechanical or manufacturing defects, this does not include wearing of parts or accessories.

Traceable calibration certificates are available as an extra where required.

PROTIMETER

MINI MOISTURE METER

The Protimeter Mini can be used for making rapid moisture assessments in a wide range of building materials including wood, masonry, drywall, plaster and concrete.

The measuring pins are small and sharp which means measurements can be taken at the surface with virtually no mark left behind. The numerical values represent the actual percent moisture content of wood (%MC). The Protimeter

Mini can be used to determine if the fabric of a building is in a dry, borderline or damp condition.

An external probe and lead is supplied as standard for taking readings in awkward positions. Optional accessories include a hammer electrode for determining moisture gradients in wood and deep wall probes which are useful accessories when investigating the cause of the moisture problems within buildings.

PROTIMETER

AQUANT MOISTURE METER

The Protimeter Aquant is used to assess and monitor the relative moisture level of building materials including plaster, drywall, masonry, concrete and fiberglass (GRP).

It is ideal for checking the relative moisture condition of building elements such as solid walls and floors prior to more rigorous and time-consuming investigative procedures that may be required. The Aquant can be used to detect the presence of moisture behind floor and wall coverings such as ceramic tile and vinyl floor coverings.

A digital display and colour-coded LED scale show the relative moisture level of the material under investigation. Relative moisture levels are measured by holding the aquant against a surface to allow the radio frequency to penetrate to a nominal depth of 10-20mm, meaning there are no needles to mark the surface.

PROTIMETER

SURVEYMASTER MOISTURE METER

The SurveyMaster moisture meter combines the functions of the Mini and Aquant models allowing the user to distinguish sub-surface from surface moisture, essential information when trying to establish the extent and cause of a dampness problem.

SurveyMaster is a moisture meter that displays the moisture level values on a digital display alongside a scale of colour-coded lights. The combined presentation of moisture measurement helps the user to map the extent of problems and monitor changes in condition precisely and reliably.

Phoenix Survey + Safety Equipment | phoenixse.com

85

PROTIMETER

HYGROMASTER MOISTURE METER

The HygroMaster is a hand-held instrument for taking spot measurements and for logging humidity and temperature values. Quick measurements of relative humidity, dew point, mixing ratio and ambient temperature are shown on a split display at the touch of a button. Surface temperature measurements can also be measured with an optional surface temperature sensor.

A data-logging mode can measure temperature trend analysis if the instrument is left in place for a period of time, the memory contents can then be downloaded to a PC using optional software and displayed in tabular and graphical form.

Two types of humidity probes are offered for use with the HygroMaster, the Hygrostick and the HumiStick.

The HygroStick in optimised for measuring humidity in the 30-100% RH range and may be used with

Protimeter humidity sleeves for measuring the relative humidity of solid walls and floors. The HumiStick is a fast responding sensor with a range of 1-100% RH making it more suitable for general air quality applications such as dehumidifiers and HVAC systems.

Standard Package

Optional Accessories

Floor Kits

ACCESSORIES

Hand-held Hygromaster, Hygrostick™ humidity sensor, velcro pouch with belt loop and instructions.

Surface temperature sensor (BLD7710-080), Five pack Hygrostick (BLD4750C), Software and cable (BLD5810), Hygrostick

(POL4750), Hygrostick/Quikstick™ extension lead (BLD5802), NIST traceable calibration certificates available (BLDCERT),

Surface humidity box (BLD4711), Data cable and software (BLD7712).

Hygromaster is available in kit form for the flooring industry complying with national standards: Hygromaster standard kit (see above), Extension lead (BLD5802), 20 pack humidity sleeves (BLD4750HS-020). Optional Surface humidity box (BLD4711).

PROTIMETER

MOISTURE MEASUREMENT SYSTEM

The Protimeter Moisture Measurement System (MMS) is a complete moisture measurement device for use in many different building related industries.

The MMS combines pin type and non-invasive modes of measurement together with a thermo-hygrometer in one state-of-the-art instrument. The standard kit is supplied in a nylon carry case with all the necessary accessories for a complete moisture survey.

Quick measurements of relative humidity, dew point, mixing ratio and ambient temperature are shown at the touch of a button. Surface temperature measurements can also be measured with the supplied surface temperature.

Standard Accessories

Optional Accessories

ACCESSORIES

Instrument with grains/lb automatic calculation, Data download software with cable, Hygrostick (BLD5800LH) or Quickstick

(BLD5800HS), Surface temperature sensor, 5 in (127 mm) deep wall probes, Pin moisture probe, Hygrostick/Quickstick extension lead, Wood calibration chart, Calibration check device, Spare pins, Instructions and nylon zipper pouch.

Hammer Electrode (BLD5055) - Measures moisture to a depth of 1.38 in (35 mm) - Weight 1.5 kg, Humidity Sleeves (BLD4750HS)

20, 50 and 100 packs available for measurement of RH% in concrete slabs, Hygrostick (BLD4750C) - Five pack standard, traceable calibration certificate (part number BLDCERT) available.

PROTIMETER

BUILDING DAMPNESS GUIDE BOOK

The Protimeter book on dampness diagnosis, treatment and available measurement techniques.

The ‘Dampness in Buildings’ book explains the nature of dampness in buildings, how to diagnose a dampness problem as well as how to deal with the issue. It covers such areas as rising damp, condensation, bridging and rainwater ingress and penetration.

86

Hire • Repair • Sales • Support • Training

FLIR Systems are the industry leader in thermal imaging cameras with a wide range of models catering for all users from novices to experienced thermal imaging professionals.

BUILDING SURVEYS:

Water damage

Windows (air leakage, energy)

Radiators and pipes

Underfloor heating

Poor insulation

Air leakage

ELECTRICAL

& MECHANICAL:

Safety inspections

Spot loose connections

Insulation failure

HVAC problems

Verify after repair

Component failure

The building sector offers the largest single potential for improving energy efficiency and infrared thermography is the easiest and quickest method to detect energy waste, moisture and electrical issues in buildings. An infrared camera shows exactly where the problems are and helps focus the inspectors’ attention allowing proper diagnosis of areas with energy loss. An infrared camera is also a powerful maintenance tool, as in many instances equipment failure is preceded by a period of increasing heat.

FLIR QuickReport Software

FLIR QuickReport software is included with each camera and allows users to organise and analyse the radiometric images and present them in a report with image descriptions and text and voice comments in just three easy steps. The cameras are also compatible with the more powerful FLIR Reporter which is extended software for creating a higher level of compelling and professional reports.

FLIR i SERIES

THERMAL IMAGING CAMERAS

The FLIR i series is the smallest, lightest and most affordable thermal imaging camera on the market.

Designed for entry-level users, it requires no former experience and has a ‘fixed’ focus lens. It really is a matter of “point-shoot-detect” to obtain high-quality thermal images.

Images are stored with a unique ID in radiometric JPEG format, containing all temperature data within each captured picture. These are stored on an on-board miniSD card and can be easily transferred to a PC via USB.

THE STANDARD PACKAGE INCLUDES:

FLIR i3, FLIR i5 or FLIR i7 thermal imaging camera, FLIR QuickReport CD, Printed

Getting Started Guide, User documentation CD-ROM, Calibration certificate,

Hand strap, Battery (inside camera), Power supply/charger with EU, UK, US and Australian plugs, USB cable, miniSD card (512 MB), with SD card adaptor.

MODEL

Field of View

IR Screen Resolution

Thermal Sensitivity

Measurement Modes

Min Focus Distance / Type

Display

Object Temperature Range

Accuracy

Image Storage

Image File Format

Battery Type / Operating Time

Charging System

Operating Temperature Range

Water and Dust Protection

i3

12.5˚ x 12.5˚

i5

17˚ x 17˚

SPECIFICATIONS i7

25˚ x 25˚

60 x 60 pixels 80 x 80 pixels 120 x 120 pixels

0.15˚C 0.10˚C

Center spot Center spot

0.6m / Fixed focus

2.8” colour LCD

0.10˚C

Center spot, box with max/min temp, isotherms above/below selected temperature interval

-20˚C to +250˚C

±2˚C or ±2% of reading

Mini SD Card

JPEG (Images contain thermal measurement data for post processing)

Li-Ion rechargeable / 5 hours, display shows current battery status

In camera, AC adapter; 3 hours to 90% capacity

0˚C to +50˚C

IP43

Phoenix Survey + Safety Equipment | phoenixse.com

87

FLIR EBX SERIES

THERMAL IMAGING CAMERAS

With up to 7800 pixels at 320 × 240 resolution - FLIR E-Series gives you the best point and shoot thermal imaging resolution at its pricepoint. Real-time imaging at 60Hz lets you capture moving components and dynamic events that 9Hz cameras miss. A built-in 3 megapixel digital camera produces clear visible light reference pictures.

The touchscreen gives you easy access to all the analytics tools you need. Fine-tune the temperature range and image and choose the right colour palette to enhance your findings. Thermal Fusion merges visual and infrared images to offer better analysis and Picture-in-Picture (PiP) gives clear location referencing. The Relative Humidity Alarm alerts you to the areas where there is a risk of condensation. An

Insulation Alarm shows the insulation performance of the building structure. Text annotations can be made from a pre-defined list using the touch screen or a headset can be connected to make voice annotations.

EBx models feature Wi-Fi connectivity (excludes E30Bx) to mobile devices like a smart phone or tablet PC.

Work in electrical or building inspections is made easier with the ability to use Bluetooth to transfer data acquired by an Extech clampmeter or moisture meter into the camera.

MODEL

IR Screen Resolution

Spatial Resolution

Thermal Sensitivity

Zoom

Field of View / Focus

Minimum Focus Distance

Display

Picture in Picture

Thermal Fusion

Object Temperature Range

Spotmeter Analysis

Area

Difference Temperature

Voice Annotations

Text Annotations

External Sensors

BLUETOOTH

®

, WiFi

Image Storage Type

Camera

Instant Report

Measurement Accuracy

Laser Pointer

E30BX

160 x 120 pixels

2.72 mrad

0.1˚C

N/A

25˚ x 19˚ / Manual

0.4m

N/A

N/A

SPECIFICATIONS

E40BX

160 x 120 pixels

-20˚C to + 120˚C / 0˚C to +250˚C -20˚C to + 120˚C / 0˚C to +650˚C

1 3

1 box with min/max/average

N/A

N/A

N/A

2.72 mrad

0.045˚C

1-2x continuous digital zoom

Built-in 3.5” LCD touch screen, 320 x 240 pixels

IR area on visual image

N/A

3 boxes with min/max/average

Image File Format JPEG (Images contain thermal measurement data for post processing)

Battery Type / Operating Time Lithium-Ion (field replaceable) / 4 hours continuous use

Charging System In camera, AC adapter, 2-bay charger or 12V from a vehicle

Operating Temperature Range -15˚C to +50˚C

Water and Dust Protection IP 54 (IEC 60529)

E50BX

240 x 180 pixels

1.82 mrad

0.045˚C

1-4x continuous digital zoom

Scalable IR area on visual image

Yes

3

E60BX

320 x 240 pixels

1.36 mrad

0.045˚C

1-4x continuous digital zoom

Scalable IR area on visual image

3

Delta temperature between measurement functions or reference temperature

60 seconds via BLUETOOTH

®

Text from predefined list or soft keyboard on touch screen

N/A

N/A

IR images

Possible to connect, via BLUETOOTH

Yes

® , Extech Moisture meter MO297 or Extech clamp meter EX845

IR / visual images; simultaneous storage of standard visual and IR images

Built-in 3.1 Megapixel digital camera

N/A N/A N/A Yes

±2˚C or ±2% of reading

Laser position displayed on the IR image. Semiconductor AlGalnP diode laser, Class 2

Yes

THE STANDARD PACKAGE INCLUDES:

FLIR E30bx,FLIR E40bx, FLIR E50bx or FLIR E60bx: Hard transport case, Thermal imaging camera with lens, Battery, Hand strap,

Calibration certificate, FLIR Tools software CD-ROM, Memory card, Lens cap, Power supply incl. multiplugs, Printed Getting Started

Guide, Printed Important Information Guide, USB cable, User documentation CD-ROM, Video cable, Warranty extension card or

Registration card.

88

Hire • Repair • Sales • Support • Training

DISTO™

LASER MEASURES

The DISTO™ range has been at the forefront of professional laser distance measures for years with their innovative technology and unrivalled presence at the top of the professional laser measure market.

DISTO™ D110

The new Leica DISTO™ D110 is the first laser distance meter with

Bluetooth

®

Smart that fits to a pocket.

Its handy design with a pocket clip and simple functions make it a perfect tool for anyone who wants to take effortless measurements. Whether you need a quick material estimation or you work on a home improvement project, the Leica

DISTO™ D110 with integrated Bluetooth

®

Smart and the free Leica DISTO™ sketch app offers you endless possibilities to create sketches, generate floor plans, document your measurements with pictures using a smartphone or a tablet.

DISTO™ D210

The compact and handy entry-level model has many interesting functions and is still simple to use.

Addition and subtraction, area and volume calculations for rapid and reliable site measurement. The last 10 results are stored. Leica DISTO™ D210 – leave the measuring tape behind. Featured with: Power Range Technology™, IP54 dust and water splash protection, illuminated 3-line display, automatic multifunctional end-piece.

DISTO™ D510

The new Leica DISTO™ D510 stands for easy and effortless outdoor distance measurement.

The unique combination of digital Pointfinder and 360° tilt sensor allows measurements which are not possible with conventional distance meters.

In addition, with Bluetooth

®

Smart and attractive free apps, you are prepared for the future. Featured with: Pointfinder with 4x zoom, IP65 water jet protection and dust-tight, 360° tilt sensor, Smart Horizontal Mode™, Height tracking, Bluetooth

®

Smart, Free App – Leica DISTO™ sketch.

DISTO™ D810

The Leica DISTO™ D810 touch is the first laser distance meter worldwide with a touch screen.

This allows for quick and intuitive operation. Another revolutionary feature allows for measurements with pictures. Due to the integrated camera it is also possible to take pictures and download them with the USB-interface to a computer. The high functionality is perfectly completed by the smart free app “Leica DISTO™ sketch”.

Featured with: Touchscreen, Pointfinder with 4x zoom, Overview camera, Measure with a picture, Precise 360° tilt sensor, Smart Horizontal Mode™, Height tracking,

Bluetooth

®

Smart, Li-Ion battery.

DISTO™ X310

The new Leica DISTO™ X310 is the only laser distance meter to be dust-tight and protected against water jets – to IP65.

In addition, it passes drop tests of up to 2m height. Thanks to the integrated tilt sensor, it can take indirect distance and height measurements absolutely precisely.

Leica DISTO™ X310 – guarantees reliable measurements, even under the harshest conditions. Featured with: IP65 water jet protection and dust-tight, 360° tilt sensor,

Smart Horizontal Mode™, height tracking, Power Range Technology™, illuminated

4-line display, automatic multifunctional end-piece.

Phoenix Survey + Safety Equipment | phoenixse.com

89

WHICH DISTO™

IS RIGHT FOR YOU?

FUNCTION

Application

Distance measurements, including area, volume and continuous measurement

SPECIFICATIONS

D110

Mainly Indoor o o o

Addition and subtraction of distances, areas and volumes

Indirect height and distance measurement to inaccessible places

Automatic calculation of room dimensions e.g. wall and ceiling areas

Measurement of tilts

Measure horizontal distances, even past obstacles

Determine the area of a multi-cornered room

Check a right angled room corner

Target far-off objects in very bright conditions using the digital Pointfinder

Measurement of roof slopes and facade areas

Measure heights without a reflection point

Measure the roof slope or pitched objects from remote distance

Determine spot heights and ground profiles

Extremely robust, dust tight and protected against jets of water

Data transmission by BLUETOOTH ® Technology

Free Data Transfer Software - plug-in for convenient planning and drawing with your software

TECHNICAL DATA

Range

Accuracy

Measuring Units

Tilt Sensor

Measuring Range

Accuracy to Laser Beam

Accuracy to Housing

0.05 - 60m

± 1.5mm

m, ft, in

D210

0.05 - 100m

± 1.5mm

m, ft, in

±45˚

±0.3˚

±0.3˚ o o o o o o o o

10

0.0˚, 0.00%

1

20

Tilt Sensor Units

Store Constant Values

Recall Last Values

4 x Zoom Digital Pointfinder

Time Delay Release (Timer)

Display Illumination

Measurements Per Battery Set

Batteries

Tripod Thread

Water & Dust Protection o o

Up to 5,000

2 x AAA

1/4

IP54 o o

Up to 5,000

2 x AAA

1/4

IP54 o o o o

Up to 5,000

2 x AAA

1/4

IP54

D510

o o o o o o o o

D810

In and Outdoor o o o o o

0.05 - 100m

± 1.0mm

m, ft, in

±45˚

±0.3˚

±0.3˚

0.0˚, 0.00%

1

20

0.05 - 70m

± 1.5mm

m, ft, in

10 o

Up to 5,000

2 x AAA

1/4

IP65

0.05 - 200m

± 1.0mm

m, ft, in, yd

±45˚

±0.3˚

±0.3˚

0.0˚, 0.00%, mm/m, in/ft

1

20 o o o

Up to 5,000

2 x AA

1/4

IP54

X310

o o o o o o o o o o

DISTO™ TRI-100 Tripod Laser Glasses Corner Targets Target Plates

90

Hire • Repair • Sales • Support • Training

TRUMETER 5000

MEASURING WHEEL

Professional and robust road measuring wheel with built in stand and brake.

The wheel is available in metric or imperial versions and is ideal for any distance measuring application.

FEATURES:

Large easy to read display

Pointer indicates start position

Robust construction

3 Year Warranty

Fold away stand

Folding, locking handle for easy carriage

Adds forward subtracts in reverse

Measures up to 99999.9metres, yards or

99999’11feet and inches

Accuracy ± 1%

Shipping weight 3Kgs

ROTOSURE RES1000

MEASURING WHEEL

The Rotosure RES1000 Econo is a low price precision made measuring wheel suitable for a wide range of applications in the construction and surveying industries.

A fully moulded ergonomic handle gives easy grip ensuring perfect handling when measuring on uneven surfaces. The crystal clear counter mounted over the centre of the wheel ensures perfect balance and easy reading.

The RES1000 works efficiently on most surfaces smooth and uneven over long or short distances and is used in road marking, construction, paving, fencing, pool construction, garden layouts, field layouts, factory layouts, property assessments.

FEATURES:

Folds in Half

Push Button Release Clip

Push Button Zero Reset

Kick Down Side Stand

Debris Removing Scraper

Follows Fine Edges

Runs in Straight Line

Balanced In Line Movement

Better Traction

Wheel Runs on Sealed Roller Bearings

Optional Carry Bag

See next page for technical specifications

ROTOSURE RD1000

DELUXE MEASURING WHEEL

The RD1000 has all the features of the popular RES1000 with added benefits including a built in brake which makes measuring even more accurate and reliable, a built in heavy duty carry handle which means a bag is not essential for carrying or transport and a heavy duty shaft which makes the wheel extremely robust.

The RD1000 works efficiently on most surfaces smooth and uneven over long or short distances and is used in road marking, construction, paving, fencing, pool construction, garden layouts, field layouts, factory layouts, property assessments.

FEATURES:

Robust Measuring Wheel

Trigger Brake in Handle

Heavy Duty Shaft

Folds in Half

Push Button Release Clip

Push Button Zero Reset

Kick Down Side Stand

Debris Removing Scraper

Built in Carry Handle

Wrist Strap

Follows Fine Edges

Runs in Straight Line

Balanced In Line Movement

Better Traction

Wheel Runs on Sealed Roller Bearings

Optional Carry Bag

Phoenix Survey + Safety Equipment | phoenixse.com

91

LAND

MEASURING WHEEL

Made of stainless steel and using a precision

22 inch measuring wheel the 4x4 Land

Measuring Wheel is suitable for the roughest terrain and strong enough to stand up to the toughest jobs.

An ergonomic t-bar hand grip gives the user easy control and makes measurement error free giving a balanced feel while measuring. The land measuring wheel can be compressed for easy transport and is supplied with a carry bag as standard.

FEATURES:

Adjustable Height Telescopic Handle

24 Inch Precision Wheel

Push Button Zero Reset

Kick Down Side Stand

Debris Removing Scraper

Follows Fine Edges

T Bar Handle for Ease of Use

Balanced In Line Movement

Large Display Counter

Stainless Steel Body

RAIL

MEASURING WHEEL

Manufactured here in the UK the

Avancer Rail Wheel is suitable for all rail measuring applications.

It is available with single reading models metric or imperial readings and with or without de-clutch as well as dual reading models with or without de clutch. A carry bag and certificate of conformity are supplied as standard.

FEATURES:

Heavy Duty Rail Track Measurer

99.5% Accuracy

Stainless Steel Construction

Metric or Imperial Counter

Complete with Carry Bag

Certificate of Conformity

De clutch available for measuring

ROLO-SURE 50

INDOOR MEASURING WHEEL

The Rolo-Sure 50 was designed for measuring around the office home or Factory over short distances.

Ideal for positioning furniture, machines and measuring along walls, floors for quick reference measurement such as quoting on carpets, tiles, curtains and many more. The Rolo-Sure will measure an arch or curved surface more quickly than any tape measure.

FEATURES:

Telescopic Handle Folds to One Third

Measures Walls and Windows

Push Button Zero Reset

Follows Fine Edges

Runs in Straight Line

Balanced In Line Movement

Carry bags are available for all models and come as standard with the

Land and Rail Wheels

MODEL

Accuracy

Measuring Distance

Increments

Wheel Circumference

Wheel Diameter

Weight

Carry Bag

TRUMETER 5000

± 1%

999.9m

0.01m

1m

32cm

3kgs

Optional

RES1000

99.5%

999.9m

0.01m

1m

32cm

1.6kgs

Optional

SPECIFICATIONS

RD1000

99.5%

999.9m

0.01m

1m

32cm

2.01kgs

Optional

ROLO-SURE

99.5%

999.9m

0.01m

0.16m

5cm

0.7kgs

Optional

LAND WHEEL

99.5%

999.9m

0.01m

1.79m

57cm

6kgs

Included

RAIL WHEEL

99.5%

9999.9M

0.1m

0.5m

15.9cm

6kgs

Included

92

Hire • Repair • Sales • Support • Training

TRADE

LEVELS

Combining exceptional accuracy with remarkable durability, the trade level has an extra heavy duty girder profile with one horizontal, one plumb and one angle setting vial. The angle setting vial rotates through 360° with graduations in 5° increments. Other features include an accuracy of ±1.0mm /m = 0.057° in standard position, UV and anti-static resistant vials that are fluorescent for dark or dim conditions.

Vials are also guaranteed for 30 years against leakage. Available sizes are 300mm, 600mm, 1000mm and 1200mm spirit levels.

DIGITAL

INCLINOMETERS

Inclines, gradients and angles can be easily determined with high accuracy using a digital inclinometer level. Measured values are displayed alternatively in degrees or percent. An audible signal at 0° and 90° facilitates adjustment and therefore, visual contact with the display is not necessary. A measured value can be retained on the display when activating the hold function. The Digital Inclinometer level is easy to operate, rugged and splash-proof. 600mm and 800mm lengths available.

WINKELFIX

ANGLE FINDER

With the Winkelfix, measurements of angles are easily performed quickly and precisely. Simply place the

Winkelfix in position and the angle can be rapidly read off from the analogue display.

Two integral spirit levels ensure accurate horizontal and vertical positioning. Choose from two models, the Winkelfix mini has a shank length of 430mm and the Winkelfix features a 600mm shank length. Both models a have measuring range of 0° to 180°.

WINKELTRONIC

ANGLE FINDERS

The Winkeltronic is a digital angle measuring device used to precisely measure and transfer angles. The measured angles are then read off from the large display. Two integral spirit levels ensure true horizontal and vertical positioning.

The hold function keeps values in the display and the display can be set to zero at any given shank position.

WinkelTronic Easy

The Winkeltronic easy is a smaller more compact model, its light weight and its large display make the Winkeltronic Easy an ideal helper on the construction site, especially in interior outfitting.

MODEL

Shank Lengths

Resolution

SPECIFICATIONS

WINKELTRONIC WINKELTRONIC EASY

450mm / 600mm 400mm

0.1˚

Measuring Range 0˚ to 352˚

Carry Pouch Optional

0.1˚

0˚ to 200˚

Optional

MESSFIX

HEIGHT MEASURE

The Messfix is a telescopic rule designed to measure the widths of openings. Simply place the Messfix in position, pull out the extensions and read off the measurement from the analogue display. A two-way spirit level attached to the outer tube facilitates taking vertical and horizontal measurements. The built-in metal measuring tape and the heavy-duty rewind mechanism are made to withstand severe stresses and to guarantee accurate measurements at all times.

Thanks to its ease of use, reliability and sturdiness, the Messfix has become indispensable in most skilled trades, such as window frame making and interior outfitting. 5m and 8m lengths available.

Phoenix Survey + Safety Equipment | phoenixse.com

93

SURVEY & CONSTRUCTION SUNDRIES

MEASURING TAPES

We offer a massive range of measuring tapes to suit all applications so if you can’t see what your looking for give us call.

5M

8M

PHOENIX POCKET TAPES

The Phoenix pocket tapes feature an ergonomically designed ABS case and shock proof rubber outer that provides maximum hand comfort, grip and durability.

25mm/1” width blade

Magnetic end hook

Metric and Imperial units

Shock resistant rubber housing

5m & 8m available

*Appearance may vary from picture

5M

8M

FISCO BIG-T POCKET TAPES

The Big-T is one of the most advanced pocket tapes in the world.

Rubber protection at all impact points

Patented internal shock absorber

Unique snap-in & quick release belt holster

Cursor shows precise reading

Clear view end hook - read right to the tip

Brake gives superior control

Integrated buffer to protect tip from damage

5m & 8m available

30M

50M

100M

FISCO PACER STEEL TAPES

The Fisco Pacer is a heavy duty high specification tape designed for the professional user.

Impact resistant frame with ground spike

Tufcote polyester coated steel tape

Low friction bearing for smooth rewind

Long winding lever and easy grip handle

Corrosion resistant end piece

Low friction mouthpiece insert

30m, 50m and 100m metric available

30M

50M

FISCO SURVEYOR TAPES

One of the most advanced, ergonomically designed long tapes with a long list of great features.

Heavy duty hi-spec frame for professionals

13mm Tufcote nylon coated steel tape

Right & left handed flip out handle

Button press blade lock and quick release

Ground spike for anchoring

Corrosion resistant triple action end hook

Blade drum offers balanced rewind speed

94

100M

RICHTER H/DUTY 100M TAPE

The Richter 100m steel tape has a heavy duty and durable design that is built to last. A metripolysan nylon coating is bonded to the steel tape surface which resists abrasion and makes the tape extremely strong. The tape conforms to EC Class II standard or accuracy.

13mm wide blade

Heavy duty extra tough design

Anti sun glare blade surface

30M

50M

100M

FIBREGLASS LONG

RANGE TAPES

This rugged, heavy duty fibreglass long range tape measure is designed for the professional user.

13mm wide blade

Blade guidance wheels

Convenient retractable handle

Low cost professional tape

Hire • Repair • Sales • Support • Training

SURVEY & CONSTRUCTION SUNDRIES

MARKING OUT

HULTAFORS

CLP30 CHALK LINE

The Innovative 30m chalk line with a 1mm single twisted cotton line and a lockable handle, the CLP30 is ideal for the professional user. The CLP30 comes with a geared winding mechanism for quick rewinding.

FISCO 100M ROLL LINE

Professional high quality ranging line with hard wearing frame and a tough braided line which can be locked at any length. Rotating handle for fast rewind.

BOX OF 12

PAINT-STIK MARKERS

Paint Stiks are solidified paints in stick form, you can apply them to virtually any surface including wet or oily surfaces. Available in yellow and white.

PERMANENT

SURVEY MARKERS

Feno permanent survey markers have high resistance to uprooting thanks to three steel prongs which can be deployed in the ground.

The anchorage retains its mechanical shape for 30 years and the head is extremely hard wearing. Please call for more information.

SET OF 10

SURVEY PINS

These hardened steel survey pins are used for marking out. The pins are 440mm x 4m with a

35mm ringed top. Supplied in sets of 10 with a steel carrying ring.

2M POLE

2M JOINTED

RANGE POLES

Our range poles are constructed from a high strength aluminium core with plastic tubing solidly moulded on top to resist the harshest of weather conditions. A two section jointed option is available which allows you to break the pole down for easy storage.

25 X 5MM

32 X 6MM

50 X 7MM

PK SURVEY NAILS

Parker Kalon masonry nails have zinc plating for corrosion resistance and a ribbed shaft ensuring a secure, strong grip into most materials. 100 nails per box.

14MM

22MM

32MM

42MM

54MM

64MM

72MM

82MM

HILTI-TYPE NAILS

Hilti-type masonry nails come complete with a steel support washer and can be driven into hard surfaces by hand or with a nail gun.

100 nails per box.

Phoenix Survey + Safety Equipment | phoenixse.com

95

SURVEY & CONSTRUCTION SUNDRIES

CHARTWELL

SURVEY BOOKS & PADS

Produced to the highest specification, these survey books contain 50% rag bond paper which has high cotton linters content giving excellent tear resistance and strength when wet. It retains this strength and writing surface when dried after being subjected to adverse site or weather conditions.

2426 CHARTWELL COLLIMATION / H.P.C. BOOK

2142 CHARTWELL DIMENSION BOOK

2126 CHARTWELL FIELD BOOK

RULES

150MM

300MM

SCALE RULES

The Verulam range of scale rules are unequalled for clarity and legibility, accuracy and design. The material used is chosen for its toughness and stability. Available in metric and imperial dividings, with 300mm (12”) and 150mm (6”) lengths.

150mm Scales:

1:1, 1:100x1:20,

1:200, 1:5,

1:50x1:1250,

1:2500

300mm Scales:

1:1, 1:100x1:20,

1:200, 1:5,

1:50x1:1250,

1:2500

WOODEN

SURVEYORS ROD

A professional six-fold wooden rule ideal for measuring in restricted access areas or when working single handedly.

The surveyors rod remains rigid when extended. Made from top quality hardwood these professional wooden rules have precise graduations inscribed into the tough surface.

SCALEX

PLANWHEEL

300MM

TRIANGULAR

SCALE RULE

A colour-coded triangular scale rule.

The base material of the rule is tough and stable and the dividings are clear and accurate. Available in 300mm.

300mm Scales:

1:1, 1:10 x 1:2, 1:20, 1:5, 1:50 x

1:100, 1:200, 1:500, 1:1000 x 1:1250,

1:2500

WOODEN BENCH RULE

A professional grade rule which can be permanently fixed to a bench top.

Ideal for estimators, craftsmen and anyone selling materials by length.

Made from top quality hardwood these professional wooden rules have precise graduations inscribed into the tough surface.

The PlanWheel SA2 is the perfect tool for taking accurate scaled measurements from blueprints, maps and plans. Just select the built-in scale factor to match the plan and roll the PlanWheel.

SCALEX SA2

The Scalex SA2 has 111 built-in and thousands of available user-defined Metric & Imperial scale factors measuring in inches, feet, yards, miles, centimetres, metres and kilometres. Calculate auto-scale factor from reduced enlarged or odd-scale drawings and square and cubic dimensions for regular areas and volumes. Buttons on probe tip let you count items or add fixed lengths as you scale. Create, store and retrieve 2 user-defined scale factors. When user the SA2 a clear audible tone indicates wheel movement and a plus/minus (+/-) mode allows user to simply back-up to deduct an over-rolled measurement.

Accuracy is ±0.25% with a resolution of 1.0mm.

CRACK MONITOR

TELL TALES

96

A simple yet accurate device for monitoring crack movement. This inexpensive system consists of two acrylic plates which move independently of each other, one has cross hairs and the other a correlating grid. Attached using screws, an adhesive or even a combination of both, the cross hairs will move across the grid indicating crack movement.

Hire • Repair • Sales • Support • Training

1 X CRACK MONITOR

5 X CRACK MONITOR

10 X CRACK MONITOR

For full standard terms and conditions please visit www.phoenixse.com

INDEX

Airflow Anemometers

Angle Measures

Cable Location

- Cable Avoidance Tools

- Cable Location Accessories

- Cable Avoidance Training

Cavity Endoscopes

Chalk & Roll Lines

Cobra Rodding

Confined Spaces

79

93

64-73

74

77

74

95

75

62-63

- Confined Spaces Training

Crack Monitors

Data Cables (EDM)

Detail Poles

Digital Levels

Drain Inspection Cameras

Gas Detection

GPS Receivers

- Data Collectors

- Software

16

96

41

41

9

75

60-61

55-57

58-59

Ground Penetrating Radar 76

Height Measure 93

Inclinometers 93

Laser Measures (DISTO)

Laser Scanners

89-90

42-44

Levelling Lasers

- Interior Lasers

- Exterior Lasers

- Grade Lasers

- Laser Sensors

- Machine Sensors

Machine Control

Measuring Wheels

Moisture Meters

10-11

10-11

15

24

18-19

20-21

91-92

85-86

Nails 95

Optical Levels

Paint Stiks

7-8

95

Pipe Lasers 17

Planwheels 96

Prism Targets

Rebar Detector

Reflective Targets

Scale Rules

Sound Monitoring

Spray Paint 95

Staves 25

Survey Books & Pads 96

40

40

40

96

78

Survey Markers

Survey Pins

Surveyors Rods & Rules

Survey Software

Tape Measures

95

95

96

58-59

94

Theodolites 28

Thermometers 79

Thermal Imaging Cameras

Total Stations

- Basic Total Stations

- Robotic Total Station

- Imaging Stations

- Measuring Stations

- Data Collectors

- Total Station Accessories

87-88

29

34-35

36-37

38-39

55-57

40-41

- Software

- Total Station Training

Tripods

- Laser Tripods

- Total Station Tripods

Wall / Stud Scanners

58-59

27

26

40

81-82

For full standard terms and conditions please visit www.phoenixse.com

Phoenix Survey + Safety Equipment | phoenixse.com

97

WE ARE

BRANDON

HIRE.

For more than 40 years, tool and equipment hire has been the core of our business.

This means we understand what’s important to our customers – a simple and safe service, that’s local, reliable and offers real value.

WHAT WE DO.

TOOL HIRE.

PLUMBING

& PIPE HIRE.

LIFTING HIRE.

SURVEY & SAFETY

EQUIPMENT HIRE.

EVENT EQUIPMENT

& TOILET HIRE.

POWERED ACCESS.

SMALL PLANT HIRE.

TRAINING.

98 www.brandonhire.co.uk

NATIONAL NETWORK,

LOCAL SERVICE.

Call your local branch:

0870 514 3391

Brandon Hire

72-75 Feeder Road

St. Philips, Bristol BS2 0TQ

T: 01179 719 119

F: 01179 720 116

E: [email protected]

Search Brandon Hire

www.brandonhire.co.uk

99

NOTES

100

Hire • Repair • Sales • Support • Training

Business Reply

Licence Number

RTJX–SKLH–SYAY

FOLD HERE

Brandon Hire

72-75 Feeder Road

Bristol

BS2 0TQ

BRANDON HIRE GROUP ACCOUNT APPLICATION FORM

Please complete in black ink using block capitals.

A) YOUR COMPANY.

FIRST NAME:

(REQUIRED)

SURNAME:

(REQUIRED)

D) SPECIAL INSTRUCTIONS.

WILL YOU USUALLY SUPPLY AN ORDER NUMBER WHEN HIRING?

YES NO

HAVE YOU ANY SPECIAL INSTRUCTIONS, OF WHICH WE

SHOULD BE AWARE, WHEN HIRING TO YOUR COMPANY?

COMPANY NAME / SOLE TRADER:

(IN FULL)

TELEPHONE NO:

(REQUIRED)

COMPANY ADDRESS:

(TO WHICH STATEMENTS SHOULD BE SENT)

E) ANTICIPATED ANNUAL SPEND.

£0 -

£50

£50 -

£500

£500 -

£5,000

£5,000 plus

POST CODE:

MOBILE NO:

FAX:

EMAIL:

F) BANK DETAILS.

NAME OF BANK

ACCOUNT NO:

(LAST BOX TO BE USED FOR GIRO BANK, 9 DIGIT ACCOUNTS)

SORT CODE:

LANDSCAPING

MANUFACTURING /

AGRICULTURAL

PLUMBER /

ELECTRICIAN / M&E

BRANCH ADDRESS:

B) BUSINESS TYPE.

CONSTRUCTION /

CONTRACTOR

RETAIL /

TRANSPORT

CATERING /

HOTELS

OTHER

SELF

BUILD

PAINTING /

DECORATING

NOTE: We reserve the right to conduct a “credit check” on limited companies prior to opening an account on your behalf. If you are NOT a limited company, please

SIGN HERE to give your permission for us to carry out a credit check.

SIGNATURE:

PRINT NAME:

DOB:

C) IS YOUR COMPANY LIMITED?

YES NO

YES

If yes please attach a copy of your company’s letterhead with registration number and go to section D.

COMPANY REGISTRATION NUMBER:

NO

If NO, please complete the section below.

HOW MANY YEARS HAVE YOU BEEN TRADING AT THIS ADDRESS?

If less than 3 years, what was your previous address?

ADDRESS:

G) GUARANTEE.

Please read and sign the following declaration

“I (the undersigned) agree that all transactions of hire or sale entered into by my company (known as “The Customer”) shall be subject to Brandon Hire Group’s

‘Standard Terms and Conditions’, published on Brandon Hire Group’s website at www.brandontoolhire.co.uk, operative at the time of any contract of hire or sale. I will make full settlement of all monies due within one month from the date of Brandon Hire Group’s invoice and answered all questions on this application form truly and fully. I hereby, personally guarantee payment in respect of all sums due from my company (“The Customer”) to Brandon Hire Group, together with all ancillary costs incurred. I have retained a copy of this form for my records.”

SIGNATURE OF DIRECTOR/PROPRIETOR: DATE:

FULL NAME:

(PLEASE PRINT)

POSITION:

(WITHIN COMPANY)

NAME OF PARTNER(S)

Data Protection. The information you provide will be held in accordance with the data protection Act 1988 and will be used by Phoenix and its trading divisions. We may contact you from time to time about other products and services available from us and may release your company details to other selected companies whose products we believe will be of interest to you. If you do not want to receive such offers please write to us at: Phoenix, 72-75

Feeder Road, St Philips, Bristol, BS2 0TQ.

BRANCH

USE ONLY.

BRANCH NO.

AREA BRANCH NAME AUTH BY STAFF MEMBER DATE

BIC

TRADE TERMS

Keeping you informed. We would like to keep you informed by letter, phone, email about products, services and additional benefits that we believe may be of interest to you. Please tick the box if you do not wish to receive product updates.

MOISTEN HERE

GRADIENT CHART

1 : 10 = 10.000

1 : 11 = 9.091

1 : 12 = 8.333

1 : 13 = 7.692

1 : 14 = 7.143

1 : 15 = 6.667

1 : 16 = 6.286

1 : 17 = 5.882

1 : 18 = 5.556

1 : 19 = 5.263

1 : 20 = 5.000

1 : 21 = 4.762

1 : 22 = 4.545

1 : 23 = 4.348

1 : 24 = 4.167

1 : 25 = 4.000

1 : 26 = 3.846

1 : 27 = 3.704

1 : 28 = 3.572

1 : 29 = 3.448

1 : 30 = 3.333

1 : 31 = 3.226

1 : 32 = 3.125

1 : 33 = 3.030

1 : 34 = 2.941

1 : 35 = 2.847

1 : 36 = 2.778

1 : 37 = 2.703

1 : 38 = 2.632

1 : 39 = 2.564

1 : 40 = 2.500

1 : 41 = 2.438

1 : 42 = 2.381

1 : 43 = 2.325

1 : 44 = 2.273

1 : 45 = 2.222

1 : 46 = 2.174

1 : 47 = 2.128

1 : 48 = 2.083

1 : 49 = 2.041

1 : 50 = 2.000

1 : 51 = 1.961

1 : 52 = 1.923

1 : 53 = 1.887

1 : 54 = 1.852

1 : 55 = 1.818

1 : 56 = 1.786

1 : 57 = 1.755

1 : 58 = 1.724

1 : 59 = 1.695

1 : 60 = 1.667

1 : 61 = 1.639

1 : 62 = 1.613

1 : 63 = 1.587

1 : 64 = 1.563

1 : 65 = 1.539

1 : 66 = 1.515

1 : 67 = 1.493

1 : 68 = 1.471

1 : 69 = 1.449

1 : 70 = 1.429

1 : 71 = 1.408

1 : 72 = 1.389

1 : 73 = 1.370

1 : 74 = 1.351

1 : 75 = 1.333

1 : 76 = 1.316

1 : 77 = 1.299

1 : 78 = 1.282

1 : 79 = 1.266

1 : 80 = 1.250

1 : 81 = 1.235

1 : 82 = 1.219

1 : 83 = 1.205

1 : 84 = 1.190

1 : 85 = 1.176

1 : 86 = 1.163

1 : 87 = 1.149

1 : 88 = 1.136

1 : 89 = 1.124

1 : 90 = 1.111

1 : 91 = 1.099

1 : 92 = 1.087

1 : 93 = 1.075

1 : 94 = 1.064

1 : 95 = 1.053

1 : 96 = 1.042

1 : 97 = 1.031

1 : 98 = 1.020

1 : 99 = 1.010

1 : 100 = 1.000

1 : 105 = 0.952

1 : 110 = 0.909

1 : 115 = 0.870

1 : 120 = 0.833

1 : 125 = 0.800

1 : 130 = 0.769

1 : 135 = 0.741

1 : 140 = 0.714

1 : 145 = 0.690

1 : 150 = 0.667

1 : 155 = 0.645

1 : 160 = 0.625

1 : 165 = 0.606

1 : 170 = 0.588

1 : 175 = 0.571

1 : 180 = 0.556

1 : 185 = 0.541

1 : 190 = 0.526

1 : 195 = 0.513

1 : 200 = 0.500

1 : 205 = 0.488

1 : 210 = 0.476

1 : 215 = 0.465

1 : 220 = 0.455

1 : 225 = 0.444

1 : 230 = 0.435

1 : 235 = 0.426

1 : 240 = 0.417

1 : 245 = 0.408

1 : 250 = 0.400

1 : 255 = 0.392

1 : 260 = 0.385

1 : 265 = 0.377

1 : 270 = 0.370

1 : 275 = 0.364

1 : 280 = 0.357

1 : 285 = 0.351

1 : 290 = 0.345

1 : 295 = 0.339

1 : 300 = 0.333

1 : 310 = 0.323

1 : 320 = 0.313

1 : 330 = 0.303

1 : 340 = 0.294

1 : 350 = 0.286

1 : 360 = 0.278

1 : 370 = 0.270

1 : 380 = 0.263

1 : 390 = 0.256

1 : 400 = 0.250

1 : 410 = 0.244

1 : 420 = 0.238

1 : 430 = 0.233

1 : 440 = 0.227

1 : 450 = 0.222

1 : 460 = 0.217

1 : 470 = 0.213

1 : 480 = 0.208

1 : 490 = 0.204

1 : 500 = 0.200

1 : 525 = 0.190

1 : 550 = 0.182

1 : 575 = 0.174

1 : 600 = 0.167

1 : 625 = 0.160

1 : 650 = 0.154

1 : 675 = 0.148

1 : 700 = 0.143

1 : 725 = 0.138

1 : 750 = 0.133

1 : 775 = 0.129

1 : 800 = 0.125

1 : 825 = 0.121

1 : 850 = 0.118

1 : 875 = 0.114

1 : 900 = 0.111

1 : 925 = 0.106

1 : 950 = 0.105

1 : 975 = 0.103

1 : 1000 = 0.100

1 : 1050 = 0.095

Formula: Difference in height x 100’ = Percentage grade

Distance

Example: 1 in 19.5 = 1 x 100’ = 05.128%

19.5

Phoenix Survey + Safety Equipment | phoenixse.com

103

BRANCHES

BRISTOL

Unit 4

Armstrong Court

Armstrong way

Yate, Bristol

BS37 5NG

Tel: 01454 312560

Fax: 01454 273118

EXETER

4 Leigham Business Units

Silverton Road

Matford Park

Exeter

EX2 8HY

LONDON

Unit 9 Derby Road

Metropolitan Estate

Off Long Drive

Greenford

UB6 8UP

Tel: 01392 824163

Fax: 01392 824325

Tel: 0208 578 3377

Fax: 0208 578 6846

BODMIN

Unit 15

Woods Browning

Industrial Estate

Bodmin

PL31 1DQ

Tel: 01208 261340

Fax: 01208 78553

BIRMINGHAM

1 Howard Street

Constitution Hill

Birmingham

B19 3HJ

Tel: 0121 212 6555

Fax: 0121 212 6556

GLASGOW

Unit 1, Claremont Centre

Cornwall Street South

Kinning Park, Glasgow

G41 1AA

BRIGHTON & HOVE

Units B4 - B5

Portland Business Park

Portland Road

Hove BN3 5RY

Tel: 01414 197921

Fax: 01414 279009

Tel: 01273 427900

Fax: 01273 427901

ALTRINCHAM

Unit 4b

Stag Industrial Estate

Atlantic Street

Altrincham WA14 5DW

Tel: 01619 268010

Fax: 01619 261811

READING

4 Richfield Avenue

Reading

RG1 8EQ

Tel: 01189 707280

Fax: 01189 707281

CARDIFF

Norwich Road

Cardiff

CF23 9AB

Tel: 02920 470776

Fax: 02920 470779

BOURNEMOUTH

51-57 Alma Road

Bournemouth

BH9 1AB

Tel: 01202 541720

Fax: 01202 533871

PHOENIX SURVEY

& SAFETY EQUIPMENT

Registered Office: 72-75 Feeder Road,

St Philips, Bristol BS2 0TQ

Registered England 1336159

phoenixse.com

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
