helix board 12
Summit Digital Mixer
Intuitive 16-Channel 8-Bus Digital Mixing Console
Low-noise
preamplifiers
GUI accessed
through color
touch screen
Fully-automated
100 mm faders
L
█
12 mono mic/line with grouped phantom power, 4
mono line input channels
█
Professional quality digital EFX processor
assignable to AUX channels
█
Internal digital sampling rate up to 96 kHz in
24-bit resolution
█
Dynamic processor assignable to input
channels, ‘multi’ outputs
█
Compact design achieved through 16 faders
encompassing two layers (Channel, AUX/Group)
█
Save and instantly recall up to 99 scenes at the
touch of a button
█
16 ultra-smooth 100 mm automated faders
arranged in a familiar analog mixer arrangement
█
Stereo headphone mix with independent level
control
█
Eight balanced 1/4” phone jack ‘multi’ outputs
█
█
High quality GUI interface onboard accessed
through a full-color touch-screen
Processing accomplished through a high
quality 40-bit fixed point digital signal processor
█
█
Up to 8 AUX and 8 Group buses assignable to
‘multi’ outputs
Optional FireWire & USB 2.0 expansion card
(16-in, 16-out) for multi-track recording
█
FireWire & USB 2.0 card compatible with
Windows XP/Vista and Mac OSX operating
systems
█
4-band semi-parametric EQs assignable to input
channels, multi outputs and main outputs
█
Digital AES/EBU I/O onboard
R
L: Level controls
arranged in 2
layers
R: Stereo
headphone
output with level
control
Digital AES/EBU
input and output
DIGITAL INTERFACES
483 x 88 x 286 mm (19" x 3." x 11.2")
kg (11 lbs)
Phonic’s Firefly 808 and Firefly 808 Universal rack-mountable
pre -amplif ied units with digital inter face are easy-to use,
professional quality recording interfaces for songwriters to
record guitars, keyboards, vocals and more to the computer
through FireWire and USB 2.0 (USB 2.0 on Universal model
only). Featured are 8 analog (XLR and 1/4") inputs and 8 analog
(1/4") outputs, as well as S/PDIF, AES/EBU, MIDI and ADAT
inputs and outputs – all of which are streamed to and from the
computer in real time through the FireWire or USB 2.0 connection
in superb 24-bit / 192kHz audio. Compatible with most popular of
Digital Audio Workstation software, these powerful units provide
recording musicians and engineers alike the kind of sophisticated
- yet easy to-use - recording device they so desperately desire.
█
█
█
█
█
█
24-bit resolution, up to 192 kHz sampling rate
Headphone output and main output with volume control
for monitoring purposes
S/PDIF I/O, AES/EBU I/O, MIDI I/O and word clock I/O
Stand-alone mixer functionality for field and studio use
without computer
Compatible with Mac OSX and Windows XP / Vista
Steinberg Cubase LE 4 DAW software included
Included
Compatible
FIREFLY 808
Studio Recording Preamp with 192 kHz FireWire Interface
█
█
█
█
█
█
█
█
█
FireWire (IEEE 1394) audio interface
18 simultaneous inputs and outputs
8 microphone preamps with trim control and individual phantom
power switches
8 analog line Inputs including 2 Instrument Inputs
8 channels of optical ADAT I/O (4 ch. via 96k dual SMUX)
Channel meters on channel 1 to 8 for input or output
Synchronization, sampling rate, digital I/O and MIDI in/out indicators
Dual FireWire ports for daisy chaining and direct connection to Mac
or PC
Instrument input, pad switch, balanced TRS send jacks on Inputs 1
and 2
FIREFLY 808 UNIVERSAL
Studio Recording Preamp with 192 kHz USB 2.0/FireWire Interface
█
█
█
█
█
█
█
█
█
FireWire (IEEE 1394) and USB 2.0 audio interface
18 simultaneous inputs and outputs
8 microphone preamps with trim control and individual phantom
power switches
8 analog line Inputs including 2 Instrument Inputs
8 channels of optical ADAT I/O (4 ch. via 96k dual SMUX)
Channel meters on channel 1 to 8 for input or output
Synchronization, sampling rate, digital I/O and MIDI in/out indicators
Dual FireWire ports for daisy chaining and direct connection to Mac
or PC
Instrument input, pad switch, balanced TRS send jacks on Inputs 1
and 2
FIREFLY 808 / FIREFLY 808 UNIVERSAL
DIGITAL INTERFACES
FIREFLY 302
PLUS
Portable 5 x 6 FireWire Audio Interface
5 x 6 24-bit/192kHz I/O
2 x 2 analog operation (RCA)
Digital S/PDIF (coaxial) I/O (PCM)
Front-panel microphone in (XLR) with: 48V phantom
power
Headphone output with dedicated level control
Near-zero latency ASIO software monitoring
1 x 1 16-channels MIDI I/O
Power indicator LED
Powered via FireWire bus or included DC power supply
Dual FireWire (6 and 4 pin ports) with bus-power
Sig and Clip LEDs for input and output
Mac and Windows XP / Vista compatible
█
█
█
█
█
█
█
█
█
█
█
█
155 x 196 x 51 mm (6.1" x 7.7" x 2")
0.9kg (1.98 Ibs)
FIREFLY 302 USB
Portable 5 x 6 USB2.0 Audio Interface
5 x 6 24-bit/192kHz USB Stream I/O
2 x 2 analog operation (RCA)
Front-panel microphone in (XLR) with 48V
phantom power
Headphone output with dedicated level control
Near-zero latency ASIO software monitoring
Power indicator LED
Powered via included DC power adaptor
An easy-to-read LED sig and clip indicators for
input and output
Mac and Windows XP / Vista compatible
█
█
█
█
█
█
█
█
155 x 196 x 51 mm (6.1" x 7.7" x 2")
0.9kg (1.98 Ibs)
█
Firefly 302 Plus
Firefly 302 USB
Firefly 808
2
2
8
8
1/4"
2
2
-
-
RCA
√
√
8
8
Mic
√
√
√
√
S/PDIF
√
√
√
√
MIDI
√
√
√
√
Phones
-
-
√
√
ADAT
-
-
√
√
AES/EBU
2
2
5
5
1/4"
2
2
2
2
RCA
√
√
√
√
S/PDIF
√
√
√
√
MIDI
FireWire
5
-
8
8
Inputs
2
-
8
8
Outputs
USB 2.0
-
5
-
8
Inputs
-
2
-
8
Outputs
universal
universal
individual
individual
Level Meter
-
-
16 x 10-pt
16 x 10-pt
Indicators
mic, clip
mic, clip
Inputs
Outputs
44.1, 48, 88.2, 96, 176.4, 192
Sampling Rates (kHz)
Phantom Power
FIREFLY 302 PLUS / FIREFLY 302 USB
Firefly 808 Universal
level, sync, clock, digital in/out
HELIX BOARD
USB 2.0 + FireWire Mixers
LOW NOISE
PREAMPLIFIERS
FIREWIRE/USB
INTERFACE
3-BAND
EQUALIZER
DIGITAL EFFECTS
PRE/POST
SWITCH
Features Overview
The following is an explanation of a few of the features you
will find on each and every Helix Board. Though the Helix
Boards do feature a number of common features, such as
those described on this page, they all incorporate their
own unique characteristics as well.
real situations where digital effects can enhance your
performance. When it all comes down to it, that’s what
makes a digital effect processor more than just another
useless feature.
LOW NOISE PREAMPLIFIERS
We know a lot of engineers like to use the Helix Board
for live performances, and there are also those who want
to use the board in the studio. That being the case, the
pre/post switch is a feature that really separates the big
players from the wannabes. Conveniently placed on
every single input channel, users can switch the signal
sent to their computer between that of a pre-fader signal
and that of a post-fader signal. For people recording live
performances, a pre-fader signal will allow you to adjust
EQ and level settings for the live audio without affecting
the recorded signal. If you’re using the Helix Board in
the studio, setting this switch to ‘post’ will give you total
control over EQ and level settings for signals sent through
the FireWire interface.
The lack of noise in our preamps can pass muster with
even the toughest of critics. Phonic have had upwards of
30 years experience in manufacturing preamps, and the
results are nothing short of spectacular.
RACK EARS
Sounds pretty basic, right? Rack-ears are a must-have for
any mixer. Can you even imagine the headache if we didn’t
provide them along with the mixer? Lucky for you, we do.
FIREWIRE INTERFACE
This is really why we’re all here, isn’t it? The FireWire
interface on all Helix Board units allows for a 96 kHz /
24-bit audio signal to be sent to the computer for recording,
mixing, editing, and tweaking. A signal containing all of
the Helix Board’s input channels, as well as an additional
stereo channel, will be sent at lightning quick speeds to
the computer, and right into your Digital Audio Workstation
software.
FIREWIRE RETURN
Users are given a stereo return signal through the FireWire
interface, perfect for monitoring the recorded audio. Send
the FireWire return signal to the Main, AUX or Control
Room mixes with the touch of a button.
3-BAND EQUALIZER
Don’t underestimate the appeal of a good EQ. The Helix
Boards provide a 3-band EQ on all channels, with high and
low frequency points set at 12 kHz and 80 Hz respectively.
The Helix Board ‘12’ models offer a mid control set at 2.5
kHz, whereas all other models offer a swept mid on mono
channels, adjustable between 100 Hz and 8 kHz. A total of
12 dB of boost or cut is available through these controls.
Add a little bass to your kick drum or more intensity to
your guitar.
DIGITAL EFFECTS
A hundred digital ef fects standard sounds good on
paper, but how do they stand up in real-life, studio and
live situations? That’s just the thing; all of our digital
effects were designed by real musicians, to be used in
PRE/POST SWITCH
DRIVERS & SOFTWARE
PC users will naturally need to use drivers for use with
the Helix Boards FireWire and Universal. A driver CD
will be packaged along with the unit. Updated drivers
will be made available through the Phonic we bsite
periodically. New drivers often provide fixes on minor
bugs or enable the unit to be used with newly developed
software. The control panel software (part of the driver)
allows users to adjust sampling rates, buffer lengths,
choose synchronization settings, rename input and output
channels, and a good number of other features.
Mac users do not need to install drivers and can just
plug the Helix Board in to get a multi-track signal to their
computer. The Helix Board’s sampling rate and other
properties are adjusted through the MIDI audio setup page
on the Mac. The Helix Board is compatible with Garage
Band and the latest versions of Logic Pro and Logic
Express.
STEINBERG CUBASE LE 4
Phonic offers a ‘Light Edition’ of Steinberg’s popular
Cubase digital audio workstation software packaged along
with all of its Helix Board mixers. Along with Cubase
LE, Helix Board users can make high quality multi-track
recordings of their audio, edit their recordings as needed
– adding effects, equalization and other necessities – and
export the final mixdown of their tracks.
DIGITAL INTERFACES
HELIX BOARD SERIES
Get a quality front-end for your computer. Helix Board mixers are Phonic's newest, digitally-enabled mixers that sound great and work
hard both in and out of the studio. Connect a Helix Board mixer to your computer's USB 2.0 or FireWire port to get live, CD-quality
sound. Low-latency playback lets you record directly to your computer and monitor in real-time. Helix Board mixers assure perfect
audio quality when multi-track recording by allowing you to monitor previously recorded audio files through your headphones while
recording another track. Combine the digital audio capabilities of these mixers with audio workstation software, and there's no limit to
what you can do.
NON-POWERED MIXERS
HELIX BOARD 24 UNIVERSAL
HelixBoard24FireWire M KII
24-Input 4-Subgroup Mixer with USB 2.0/FireWire Interface
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
445 x 212 x 432 mm (17.5" x 8.3" 17")
9.8 kg (21.6 Ibs)
HELIX BOARD 24 FIREWIRE MKII
24-Input 4-Subgroup Mixer with DFX & FireWire Interface
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
24-input analog mixer with extremely low noise circuitry
96kHz FireWire interface for streaming 18 independent channels of
audio to computer with near-zero latency
Pre/post internal setting for swapping streaming input channels to
computer from pre low cut, EQ to post EQ, post fader
2 channels of monitoring from computer via FireWire interface, can
be assigned to control room monitors, main mix and aux1
DFX, our 40-bit high definition algorithm digital multi-effect processor
with 100 programs plus tap delay and foot switch jacks
16 Mic/Line channels with inserts
3-band EQ with swept mid-range
75 Hz low-cut filter on each channel
AUX 1 & 2 with Pre/Post switch
Six AUX send mixing bus
Four stereo AUX returns, three with effect to monitor
+48V phantom power on Mic channels
Four true subgroups with main L and R routing switches
Direct outputs for multi-track recording
Control Room and Phones outputs with multi-input source matrix
Mono out with variable low pass filter from 60 Hz to 160 Hz for
subwoofer
Dual-position I/O pod
Built-in switching power supply with universal connector, 100-240
VAC, 50/60 Hz
S/PDIF digital audio output
Included
Compatible
96kHz USB 2.0 / FireWire interface for streaming 18 independent
channels of audio to computer with zero latency
Pre/post setting for swapping input channels sent to the computer
from pre-low cut, -EQ to post-EQ, post-fader
2 channels of monitoring from computer via USB 2.0 / FireWire
interface, can be assigned to control room monitors, main mix and
AUX 1
DFX, our 32/40-bit high definition algorithm digital multi-effect
processor with 100 programs plus tap delay and foot switch jacks
Channel 17/18 routed to computer can be selected from Main mix,
Group 1/2 and AUX 3/4
16 Mic/Line channels with inserts
3-band EQ with swept mid-range
75 Hz low-cut filter on each channel
AUX 1 & 2 with Pre/Post switch
Six AUX send mixing bus
Four stereo AUX returns, three with effect to monitor
+48V phantom power on Mic channels
Four true Subgroups with Main L and R routing switches
Direct outputs for multi-track recording
Control Room and Phones outputs with multi-input source matrix
Mono out with variable low pass filter from 60 Hz to 160 Hz for
subwoofer
Dual-position I/O pod
Built-in switching power supply with universal connector, 100-240
VAC, 50/60 Hz
Rack-mounting kit included
S/PDIF digital audio output
Compatible with Mac OSX and Windows XP / Vista
Steinberg Cubase LE 4 included
HELIX BOARD 18 UNIVERSAL
18-Input Mixer with USB 2.0/FireWire Interface
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
Pre/post setting for swapping USB 2.0/FireWire input channels sent
to computer from pre-low cut, -EQ to post-EQ, post-fader
18-input small-format analog mixer with extremely low noise circuitry
96kHz USB 2.0/FireWire interface for streaming 16 independent
channels of audio to computer with zero latency
2 channels of monitoring from computer via USB 2.0 / FireWire
interface, can be assigned to control room monitors, Main mix and
AUX 1
Channel 15/16 routed to computer can be selected from main mix,
group 1/2 and AUX 2/3
DFX, our 32/40-bit high definition algorithm digital multi-effect
processor with 100 programs plus tap delay, foot switch jacks and
volume controls for sending processed signal to aux send 1 & 2
Six Mic/Line channels with inserts
8 extremely low noise mic preamps
Four stereo Line channels
3-band EQ with swept mid-range
75 Hz low-cut filter on mono channels
Three AUX sends, one with Pre/Post switch
Two stereo AUX returns, one with effect to monitor level control
+48V phantom power on Mic channels
Solo feature on each input and output
Two true subgroups with Main L and R routing switches
Built-in switching power supply with universal connector, 100-240
VAC, 50/60 Hz
Rack-mounting kit included
S/PDIF digital audio output
Compatible with Mac OSX and Windows XP / Vista
Steinberg Cubase LE 4 included
HELIX BOARD 24 UNIVERSAL / HELIX BOARD 24 FIREWIRE MKII / HELIX BOARD 18 UNIVERSAL
HELIX BOARD 18 FIREWIRE MKII
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
12-Input Mixer with USB 2.0 & FireWire Interface
18-input small-format analog mixer with extremely low noise circuitry
96kHz FireWire interface for streaming 16 independent channels of
audio to computer with near-zero latency
2 channels of monitoring from computer via FireWire interface,
assignable to control room monitors, main mix and AUX 1
Pre/post switch for swapping streaming input channels to computer
from pre low cut, EQ to post EQ, post fader
Channel 15/16 routed to Computer can be selected from main mix,
group 1/2 and aux 2/3
DFX, our 40-bit high definition algorithm digital multi-effect processor
with 100 programs plus tap delay, test tones and foot switch jacks
Six Mic/Line channels with inserts
8 extremely low noise mic preamps
Four stereo Line channels
3-band EQ with swept mid-range
75 Hz low-cut filter on mono channels
Three AUX sends, one with Pre/Post switch
Two stereo AUX returns with effect to monitor level control
+48V phantom power on Mic channels
Solo feature on each input and output
Two true subgroups with main L and R routing switches
Built-in switching power supply with universal connector, 100-240
VAC, 50/60 Hz
S/PDIF digital audio output
HELIX BOARD 12
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
HELIX BOARD 12 FIREWIRE MKII
PLUS
12-Input Mixer with DFX & USB 2.0 Interface
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
12-Input Mixer with DFX & FireWire Interface
12-input small-format analog mixer with extremely low noise circuitry
Pre/post switch for streaming input channels to computer from pre
low cut, EQ or from post EQ, post channel fader
192 kHz USB 2.0 interface for streaming 10 independent channels of
audio to computer with near-zero latency
DFX, our 40-bit digital multi-effect processor with 100 programs plus
tap delay and foot switch jacks
Two channels of monitoring from computer via USB interface
Four mono Mic/Line channels
Two stereo channels, two stereo AUX Returns, two AUX sends
3-band EQ on each channel
75 Hz low-cut filter on mono channel
Inserts on channel 1 & 2
+48V phantom power on Mic channels
Stereo AUX Send 1 cue for monitoring individual channel
Master AUX section with EFX to Monitor
Extra ALT 3-4 stereo bus
Control room/Phones source matrix
Balanced master output with 60 mm fader control
High-volume headphone output
Inputs
Outputs
FireWire
USB
Sampling Rate
Channel EQ
12-input small-format analog mixer with extremely low noise circuitry
Pre/post switch for streaming input channels to computer from pre
low cut, EQ or from post EQ, post channel fader
96 kHz USB 2.0 & FireWire interface for streaming 10 independent
channels of audio to computer with near-zero latency
DFX, our 40-bit digital multi-effect processor with 100 programs plus
tap delay and foot switch jacks
Two channels of monitoring from computer via USB or FireWire
interface
Four mono Mic/Line channels
Two stereo channels, two stereo AUX Returns, two AUX sends
3-band EQ on each channel
75 Hz low-cut filter on mono channel
Inserts on channel 1 & 2
+48V phantom power on Mic channels
Stereo AUX Send 1 cue for monitoring individual channel
Master AUX section with EFX to Monitor
Extra ALT 3-4 stereo bus
Control room/Phones source matrix
Balanced master output with 60 mm fader control
High-volume headphone output
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
12-input small-format analog mixer with extremely low noise circuitry
Pre/post switch for streaming input channels to computer from pre
low cut, EQ or from post EQ, post channel fader.
DFX, our 40-bit digital multi-effect processor with 100 programs plus
tap delay and foot switch jacks
96 kHz FireWire interface for streaming 10 independent channels of
audio to computer with near-zero latency
Two channels of monitoring from computer via FireWire interface
Four mono Mic/Line channels
Two stereo channels, two stereo AUX Returns, two AUX sends
3-band EQ on each channel
75 Hz low-cut filter on mono channel
Inserts on channel 1 & 2
+48V phantom power on Mic channels
Stereo AUX Send 1 cue for monitoring individual channel
Master AUX section with EFX to Monitor
Extra ALT 3-4 stereo bus
Control room/Phones source matrix
Balanced master output with 60 mm fader control
High-volume headphone output
HB12FW MKII
HB18FW MKII
HB24FW MKII
HB12 Plus
HB12 U
HB18U
12
18
24
12
12
18
24
4
8
16
4
4
8
16
Mic
4
8
16
4
4
8
16
Line
HB24U
4
4
4
4
4
4
4
Stereo*
√
√
√
√
√
√
Stereo RCA
8
10
17
8
8
10
17
-
2
3
-
-
2
3
XLR
√
√
√
√
√
√
√
Stereo RCA
-
√
√
-
-
√
√
S/PDIF
16
18
-
10
16
18
Input Channels
Output Channels
2
2
2
-
2
2
2
-
-
-
10
10
16
16
Input Channels
-
-
-
2
2
2
2
Output Channels
24-bit / 96 kHz
24-bit / 96 kHz
24-bit / 96 kHz
24-bit / 192 kHz
24-bit / 96 kHz
24-bit / 96 kHz
24-bit / 96 kHz
3-band
3-band
3-band with swept mid
3-band with swept mid
Master EQ
-
Stereo 10-band
-
-
-
Stereo 10-band
-
10-pt
13-pt
12-pt
10-pt
10-pt
13-pt
12-pt
*AUX inputs included
1/4" TRS
10
Level Meter
DFX
Total*
√
3-band
NON-POWERED MIXERS
█
DIGITAL INTERFACES
HELIX BOARD 12 UNIVERSAL
18-Input 2-Subgroup Mixer with DFX & FireWire Interface
100+ effects, tap delay and test tones
Included
HELIX BOARD 18 FIREWIRE MKII / HELIX BOARD 12 UNIVERSAL / HELIX BOARD 12 PLUS / HELIX BOARD 12 FIREWIRE MKII
Compatible
NON-POWERED MIXERS
SONIC STATION SERIES
Sonic Station mixers are bursting with inputs! Every channel has a Mic preamp and balanced line input. The 3-band EQ with
swept-mid (4-band EQ on stereo channels), insert points for connection to external processors, 6 AUX send mixing bus (2 AUX
sends with pre/post buttons), and 8-28 direct outputs for multi-track recording allow users incredible flexibility with mix control
and signal routing. But that's not all. The built-in 32/40-bit digital effect processor has 16 awesome programs, main parameter
control, foot switch control and tap delay. And if you get any "sub" Sonic noise in your Mics just hit the low cut filter to get rid
of breath pops, stage rumble and wind noise. Top it off with a subwoofer output, four true subgroups and phantom power, and
you've got a perfect mixer for live events or studio mixing.
SONIC STATION 16
24-Input 4-Bus Mixing Console with Dual-Position I/O Pod and DFX
DFX, our 32/40-bit digital multi-effect processor with 16 programs
plus one main parameter control, tap control and foot switch jack
16 Mic/Line channels with inserts
3-band EQ with swept mid-range
75 Hz low-cut filter on each channel
Four true subgroups with main L and R routing switches
Direct outputs for multi-track recording
Control Room and Phones outputs with multi-input source matrix
Mono out with variable low pass filter from 60 Hz to 160 Hz for
subwoofer
█ Dual-position I/O pod
█ Rec out with trim control for record level matching
█ Built-in switching power supply with universal connector, 100-240
VAC, 50/60 Hz
█
█
█
█
█
█
█
█
440 x 210 x 475 mm (17.3" x 8.26" x 18.7")
9.5 kg (20.9 Ibs)
SONIC STATION 22
30-Input 4-Bus Mixing Console with DFX
22 channel 4-bus mixing console, 20 mic preamps
Dual effect engines with 16 EFX plus one main parameter control, Effect
2 with tap delay and foot switch jacks
█ Direct out with pre-EQ switch for multi-track recording
█ Rec out with independent trim control
█ Talkback mic built-in
█ 4 stereo AUX return, each with to aux 1~4 (effect to monitor)
█ Group 1-4 and AUX 1-4, Main fader and control room volume control can
be swapped for monitor console use
█ Variable LPF on mono output for subwoofer
█ Seven 12-segment level meters for main, group or AUX
█ 3-band with swept mid-range ch EQ on mono channel
█ 6 AUX mixing bus, two pairs with pre/post switch
█ On, Peak/Solo and Signal indicators on each input channel
█ Pad/Line in switch on mono channels
█ Two stereo channels with XLR mic in, 1/4" and RCA line inputs
█ 12V gooseneck lamp socket
█ Main stereo and mono out with XLR jacks and inserts
█
█
859 x 102.79 x 547.42 mm (33.8" x 4.05" x 21.6")
15.5 kg (34.1 Ibs)
SONIC STATION 32
40-Input 4-Bus Mixing Console with DFX
█
█
█
█
█
█
█
█
█
█
█
1155.5 x 102.79 x 547.42 mm (45.5" x 4.05" x 21.6")
18 kg (39.7 Ibs)
█
█
█
█
* See Appendix I on page 32 for full specifications
█
█
█
Pad switch on mono channels
Two stereo channels with XLR mic in, 1/4" and RCA line inputs
12V gooseneck lamp socket for dark working environments
Main stereo and mono out with XLR jacks and inserts
30 Mic preamps
Dual digital effect engines, each with 16 programs plus one main
parameter control, tap delay and foot switch jacks
28 direct outputs with pre-fader switch for multi-track recording
Rec out with independent trim control
Talkback Mic built-in
Four stereo AUX returns, each with switches to route signal to AUX 1-4
(effect to monitor)
Groups 1-4 and AUX 1-4 can be swapped for monitor console use
Talkback mic built-in
Variable LPF on mono output for subwoofer
Six 12-segment level meters for main, group or AUX
Independent solo level control
3-band channel EQ with swept mid-range on mono channels, 4-band
EQ on stereo channels
Six AUX mixing bus, two pairs with pre/post switch
ON, SIGNAL and PEAK/SOLO LED indicators on each input channel
SONIC STATION 16 / SONIC STATION 22 / SONIC STATION 32
NON-POWERED MIXERS
PM 801
Single Rack Unit 8-Channel Mixer with Tone Control
█
█
█
█
█
█
█
ZX4
ZX2
PLUS
4 Zone Mixer
█
█
█
█
█
█
█
█
PLUS
2 Zone Mixer
Three stereo RCA line inputs with individual trim controls
Paging microphone input and 1/4" TRS emergency input for
emergency message broadcasting
Three stereo and one mono zone output with independent
source select switches and level controls
Microphone ducking depth and EQ controls
Utility output provides audio to general utility areas (foyers,
restrooms, etc.)
Utility output source selectable
Stereo/Mono switch on zone 1 and 2
Remote level controls can be wired to the four zones for
applications requiring remote adjustment of audio levels
█
█
█
█
█
█
█
█
█
█
Optional Paging Controls
Inputs
Outputs
Level Controls
Horizontal installation
8 balanced Mic/Line inputs
Ultra low noise pre-amp circuitry offering up to 62 dB gain (Mic
In)
EQ and Direct Out features
Mute control, Clip Indicator, and Tone control on each channel
Pre-fader Out and AUX Bus In for connecting additional units to
maximize the application flexibility
+48V phantom power on every channel
Built-in power supply - no wall wart!
Three stereo RCA line inputs with individual trim controls
Paging microphone input and 1/4" TRS emergency input for
emergency message broadcasting
Two stereo zone outputs with independent source select
switches and level controls
Subwoofer output on each zone
High and low EQ controls on each zone
Microphone ducking depth and EQ controls
Utility output provides audio to general utility areas (foyers,
restrooms, etc.)
Utility output source selectable
Stereo/Mono switch on zone 1 and 2
Remote level controls can be wired to the two zones for
applications requiring remote adjustment of audio levels
ZX2 Plus
ZX4 Plus
1
1
PM801
8
3 x stereo
3 x stereo
1 x mono
√
√
-
Emergency Audio
Zones
2
4
-
√
-
Utility
7
8
1
1/4" Jacks
√
√
√
2-band
-
-
Microphone EQ
2-band
2-band
Tone controls
Mic Depth Control
√
√
-
Source Selection
√
√
-
Source Link
√
√
-
1 unit
1 unit
1 unit
2.5 kg (5.5 lbs)
2.5 kg (5.5 lbs)
2.3 kg (5.3 lbs)
Weight
Stereo RCA
√
Zone EQ
Size (rack spaces)
Microphone
Vertical installation
PM 801 / ZX2 PLUS / ZX4 PLUS
NON-POWERED MIXERS
IMPACT SERIES
The Impact mixers are easy-to-use mixing consoles that provide
all the features you need for any project studio or live sound
reinforcement. Models vary between 10 and 26 ultra-quiet Mic
preamps with high headroom and phantom power, as well as two
stereo line channels on every mixer. All mono channels feature
inserts, for inclusion of external processors, and low-cut switches,
for removing unwanted ground noise. A 3-band EQ with swept-mid
is included on mono channels, and a 4-band EQ on stereo channels,
giving you greater control over your audio. Four AUX sends and two
stereo AUX returns can be used to connect a variety of outboard
signal processors or to create special mixes to send to your monitor
speakers. Impact mixers also feature an onboard 32-bit stereo digital
effects processor with 100 preset programs plus one main parameter
control, tap control and foot switch jacks. Output is achieved through
XLR or 1/4" phone jacks, with an additional mono output topped with
an adjustable LPF - ideal for use with subwoofers. The addition of
mini stereo input/outputs makes these mixers perfect for anyone
connecting MP3, MD, computer audio or recording devices. The
Impact mixers are ideal for houses of worship, small to medium-sized
halls and project studios.
IMPACT 8.4X
IMPACT 16.4X
IMPACT 12.4X
IMPACT 24.4X
12- Channel Mic/Line Mixer with DFX
16 - Channel Mic/Line Mixer with DFX
█
█
█
█
█
█
█
█
█
█
█
█
█
█
Total Inputs
Outputs
Audiophile quality & ultra low noise
Multiple low-noise mic preamps
Mono channels have 3-band EQ with swept mid-range, 75Hz
(18 dB/octave) low-cut filter, inserts and phantom power
Two stereo channels with 4-band EQ
4 AUX sends, AUX 1 & 2 with XLR and 1/4” phone output jacks
32/40 bit digital stereo multi-effect processor with 100
programs, tap control and foot switch jacks
2 stereo AUX returns with effect to monitor
Low cut on each mono channel
PAD control on all mono channels
Main Stereo and Mono output with XLR and 1/4” phone jacks
Mono output with variable low pass filter for subwoofer
Tape input can be routed to AUX 1 and AUX 2
Mini stereo I/O for MD, MP3 player/recorder
Built-in switching power supply with universal connector,
100-240VAC 50/60Hz
Impact 12.4X
Impact 16.4X
Impact 24.4X
12
16
20
28
8
12
16
24
Mic
8
12
16
24
Line
4
4
4
4
Stereo*
√
√
√
√
Stereo RCA
√
√
√
√
Mini Stereo
3
3
3
3
1/4" TRS
√
√
√
√
XLR
√
√
√
√
Phones
√
√
√
√
Stereo RCA
√
√
√
√
Mini Stereo
3-band with swept mid
2 x 12-pt
Level Meter
100 programs
DFX
Weight
28- Channel Mic/Line Mixer with DFX
Impact 8.4X
Channel EQ
Dimensions
(W x H x D)
20- Channel Mic/Line Mixer with DFX
510 x 112 x 437 mm
( 20" x 4.4" x 17.2" )
642 x 112 x 437 mm
( 25.3" x 4.4" x 17.2")
774 x 112 x 437 mm
( 30.5" x 4.4" x 17.2" )
1038 x 112 x 437 mm
( 40.9" x 4.4" x 17.2" )
7.2 kg (15.9 lbs)
8.7 kg (19.1 lbs)
10.5 kg (23.1 lbs)
13.5 kg (29.7 lbs)
*AUX inputs included
10
IMPACT 8.4X / IMPACT 12.4X / IMPACT 16.4X / IMPACT 24.4X
156 x 51 x 244 mm
(6.1” x 2” x 8.8”)
1.1 kg (2.4 Ibs)
MU 502
█
█
█
█
█
█
█
190 x 56 x 233 mm
(7.5” x 2.2” x 9.2”)
1.5 kg (3.3 lbs)
MU 802
5-Input Compact Mixer
█
8-Input Compact Mixer
Two low-noise microphone inputs and five line inputs
2-band EQ, low cut filter and insert on mono input channel
Stereo RCA 2-Track and Record I/O
Global +48V phantom power
Dual 4-segment master level meter
Peak LED on mono input channel
Headphones output with volume control
Balanced master output
█
█
█
█
█
█
█
█
█
█
█
Two balanced Mic/Line inputs and two stereo Line inputs
3-band EQ on every channel
Mini stereo I/O and stereo RCA I/O
Post-fader EFX send on every input
One stereo AUX return
Global +48V phantom power
Stereo EFX Send cue for monitoring individual channel in
stereo image
Mono/Stereo switch on main mix for checking mono
system playback
Peak and VU Metering
Separate Mix, CTRL RM and Headphones outputs
Balanced master output with 60 mm fader control
190 x 56 x 233 mm
(7.5" x 2.2" x 9.2")
1.5 kg (3.3 Ibs)
MU 1002X
10-Input Compact Mixer with DFX
█
█
█
█
█
█
█
█
█
█
█
█
NON-POWERED MIXERS
MU SERIES
Two balanced Mic/Line channels each with Peak indicators
Four stereo Line channels each with +4/-10 level matching
DFX, our 32-bit DSP processing multi-effect processor with
16 programs plus one main parameter control and tap control
3-band EQ on Mic/Line input channel
75 Hz low-cut filter on mono channels
EFX send on every channel
Mini stereo I/O and stereo RCA I/O
+48V phantom power on Mic channels
Stereo EFX send cue for monitoring individual channel
Mono button on master output allows users to select a stereo
or dual mono output
Headphone output with separate rotary level control
Balanced master output with 60 mm fader control
275 x 60 x 271 mm
(10.8” x 2.4” x 10.7”)
2.2 kg (4.85 lbs)
MU 1202
12-Input Compact Mixer
█
█
█
█
█
█
█
█
█
█
█
█
Four balanced Mic/Line channels and two stereo Line
channels
3-band EQ on each channel
75 Hz low-cut filter on mono channels
Two AUX sends per channel
Two stereo AUX returns
Stereo RCA 2-Track and Record I/O
+48V phantom power on Mic channels
Stereo AUX send 1 cue for monitoring individual channel
Rec out with trim control for record level matching
Control room/Phones source matrix
High-volume headphone output
Balanced 1/4” TRS outputs
* See Appendix II on page 32 for full specifications
MU 502 / MU 802 / MU 1002X / MU 1202
11
NON-POWERED MIXERS
* See Appendix II on page 32 for full specifications
MU 'X' models come with
our own 32/40-bit DSP
multi-effect p rocessor
with 1 00 p reset p rograms a s well a s tap
delay and numerous test
tones.
300 x 89 x 340 mm
(11.8" x 3.5" x 13.4")
4.2 kg (9.25 lbs)
245 x 86 x 271 mm
(9.7” x 3.4” x 10.7”)
2.6 kg (5.73 lbs)
MU 1202X
MU 1722X
12-Input Compact Mixer with DFX
█
█
█
█
█
█
█
█
█
█
█
█
█
█
17-Input 2-Bus Compact Mixer with DFX
Four balanced Mic/Line channels with inserts
Two stereo Line channels
DFX, our 32-bit digital multi-effect processor with 16 programs plus
one main parameter control, tap control and foot switch jack
3-band EQ on each channel
75 Hz low-cut filter on mono channels
Extra ALT 3-4 stereo bus
Two AUX sends per channel
Two stereo AUX returns
Stereo RCA 2-Track and Record I/O
+48V phantom power on Mic channels
Stereo AUX send 1 cue for monitoring individual channel
Master AUX section with EFX to Monitor
Control room/Phones source matrix
Balanced master output with 60 mm fader control
█
█
█
█
█
█
█
█
█
█
Five balanced Mic/Line channels with inserts and three stereo Line
input channels
DFX, our 32-bit digital multi-effect processor with 16 programs plus
one main parameter control, tap control and foot switch jack
3-band EQ with swept mid-range
75 Hz low-cut filter on mono channels
Two AUX sends, one with Pre/Post switch
Three stereo AUX returns, two with effect to monitor level control
+48V phantom power for mic inputs
Mini stereo I/O and stereo RCA I/O
Solo feature on each input and output
Two true subgroups with main L and R routing switches
407 x 89 x 357 mm
(16" x 3.5" x 14")
4.8 kg (10.6 Ibs)
MU 1822X
18-Input 2-Bus Compact Mixer with Graphic EQ and DFX
█
█
█
█
█
█
█
█
█
█
█
█
█
12
Six Mic/Line channels with inserts
8 Mic preamps in total
Four stereo Line channels
DFX, our 32-bit digital multi-effect processor with 16 programs plus
one main parameter control, tap control and foot switch jack
3-band EQ with swept mid-range
75 Hz low-cut filter on mono channels
Three AUX sends, one with Pre/Post switch
Two stereo AUX returns with effect to monitor level control
Mini stereo I/O and stereo RCA I/O, rec out with trim control for level
matching
+48V phantom power on mic channels
Solo feature on each input and output
Stereo 7-band graphic EQ, assignable to main mix or AUX 1 send
Two true subgroups with main L and R routing switches
418 x 140 x 438 mm
(16.5" x 5.5" x 17.2")
5.9 kg (13 Ibs)
MU 2442X
24-Input 4-Bus Rack Mixer with DFX
█
█
█
█
█
█
█
█
█
█
█
█
Eight Mic/Line channels with inserts
10 Mic preamps in total
Four stereo Line channels
DFX, our 32-bit digital multi-effect processor with 16 programs plus
one main parameter control, tap control and foot switch jack
3-band EQ with swept mid-range
75 Hz low-cut filter on mono channels
Three AUX sends, one with Pre/Post switch
Two stereo AUX returns with effect to monitor level control
Mini stereo I/O and stereo RCA I/O, rec out with trim control for level
matching
+48V phantom power on mic channels
Solo feature on each input and output
Two true subgroups with main L and R routing switches
MU 1202X / MU 1722X / MU 1822X / MU 2442X
AUDIO TESTING
PAA3
Handheld Audio Analyzer with USB 2.0 Interface
The PAA3 is a highly accurate handheld audio analyzer that gives sound engineers a
rich array of sound analysis tools. Features include 31-band real time spectrum analysis,
RT60, SPL and line meter, internal generator, EQ setting program, microphone calibration
and speaker phase checking abilities. All functions and menus can be accessed through
a central jog dial, leaving your other hand free to adjust audio settings. Easily upload
information and settings to your computer via the built-in USB
interface. The large LCD screen has a visible backlight to help you
see in dark environments. With a battery life of 7 hours, the PAA3 is a
multifunctional tool for every serious audio engineer.
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
SPL meter calibration through sound level calibrator
4 standard response time
3 power modes: (1) Power Save (2) On (3) Off
Audio test signals and desktop control software on CD-ROM
Sound Pressure Level Meter from 30 dB~130 dB
Line signal measurement display in dBu, dBV,
or Volts (AC)
3 level range selection for dB SPL and
line signal
Maximum level display
Peak hold display
Adapter operation available
7 hours continuous operation
with 4 AA batteries
31-band Real Time Spectrum
Analyzer
RT60 measurement
Built-in calibrated measurement
microphone
Phase checker
31-band EQ setting value display
(Boost/Cut)
Memory and average calculation function
USB 2.0 and XLR input and output sockets
Noise generator with pink noise,
1 kHz and polarity test signal, balanced output
144.95 x 82.95 x 39.42 mm
(5.7" x 3.26" x 1.55")
354 g (0.78 lbs)
PAA3
Inputs/Outputs
Display
Measurement Range
√
Built-in Omni-directional Mic
√
XLR Jacks (input and output)
√
USB Interface
160 x 160
30 to 130 dB SPL
SPL (Mic Input)
-50 to +40 dBu
dBu (Line Input)
-52 to +38 dBV
Settings
Voltage (Line Input)
A, C or Flat
Weighting
ON/OFF
Peak Hold
RESET
Maximum Level Display
35ms, 125ms, 250ms, 1sec
Noise Generators
Other Functions
Power Source
Battery Life
PAA3
dBV (Line Input)
5 mV to 80 V
Response Time
√
Pink noise
√
1 kHz Signal
√
Polarity Signal
√
31-band RTA
√
Average Calculation
√
Phase Checker
√
Reverb Time Analyzer (RT60)
√
Memory
√
EQ Setting Value Display
4 x AA batteries
Up to 7 hours
13
AUDIO TESTING
174.5 x 40 x 105.5 mm
(6.89” x 1.57” x 4.17”)
465 g (1 lbs)
PAA6
2-Channel Audio Analyzer with Color Touch LCD
The PAA6 is the latest and the greatest in Phonic's popular handheld audio analyzer series.
All functions and menus are easily accessed through a 480 x 272 color touch-screen display.
The PAA6 incorporates significantly improved versions of real time spectrum analyzer,
RT60, tone generator, LEQ, EQ setting and Phase checking from the PAA3. Moreover, the
PAA6 audio tester provides engineers with an even wider array of essential sound analysis
tools than ever before - now adding FFT, THD+N, Polarity and Scope functions to the
mix, as well as two built-in mics that can take highly accurate measurements from multiple
positions in any given room. A USB 2.0 connector and SD card slot have been included
to assist in transferring information to and from your computer. This feature-rich, portable
audio tester is sure to satisfy even the most discerning professional audio engineer.
█
█
█
█
█
Powerful dual channel palm-size audio analyzer
480 x 272 color LCD touch screen
Two built-in measurement condenser mics
Tone generator includes pink noise, white noise, sine wave,
sweep, polarity, triangle and square
Useful functions include RTA, LEQ, RT-60, FFT, THD+N,
Polarity, Phase, Scope and Meter (dB SPL, dBu, dBV, Volt)
Microphone
Display
Inputs / Outputs
Interface
Display
Input Methods
Test Units
RTA
FFT
RT-60
THD+N
Meter
Phase
Oscillator Scope
Polarity
LEQ
14
█
█
█
█
Elegant graphical user interface
Long-lasting rechargeable lithiumion battery system
USB 2.0 port and SD card slot
included for storing and retrieving
data
30 to 130 dB SPL meter
Built-in condenser mic x2
480 x 272, 16-bit, full color touch screen
XLR input x2 (Balanced/Unbalanced), XLR output x1 (Servo Balanced)
USB High Speed 2.0 Interface
480 x 272, 16-bit, full color touch screen
Microphone / Line Inputs
dB SPL, dBu, dBV, Volt (for most functions)
Frequency
20 Hz ~ 20 KHz, All Frequencies
EQ Setting
EQ Cut or Boost
Subtract / Sum
CH1+CH2, CH1-CH2, CH2-CH1
Peak Hold
Off, 0.5 ms, 1 Sec, 2 Sec, 4 Sec, Continue
Frequency Detect
On, Off
Dynamic Range
30 ~130 dB. 60dB display range, eg. 70~130, 60~120, 50~110
dB-scale setting
+/- 5dB steps on Y-Axis
Octave
1/1, 1/3, 2/3, 1/6
Weighting
A. B. C. Flat
Frequency Range
13 selectable bandwidths
Subtract / Sum
CH1+CH2. CH1-CH2. CH2-CH1
Peak Hold
Off, 0.5 ms, 1 Sec, 2 Sec, 4 Sec, Continue
Frequency Detect
On , Off
Octave
1/1, 1/3, 2/3, 1/6
Weighting
A, B, C, Flat
Trigger
Internal , External
Weighting
A. B. C. Flat. 1 Octave
Unit
dB SPL, dBu, dBV, Volt
Level Range
30~130 dB SPL, -85~25 dBu, -87.2~22.8 dBV, 0.0436mV~13.8V
Max
Peak Hold
Phase Degree
Phase Correlation (out of phase or in phase)
Trigger
CH1, CH2, CH1+CH2
Mode
Auto , Normal
Polarity checker
Negative, Positive
Weighting
A, B, C, Flat
Selectable Frequency
31.5Hz, 63Hz, 125Hz, 250Hz, 500Hz, 1KHz, 2KHz, 4KHz, 8KHz, 16KHz
PAA6
POWERED MIXERS
POWERPOD SERIES
Built to meet remarkably high standards, the Powerpod powered mixers from Phonic
feature super-smooth controls, low noise, brawny amplification, and sturdy constructions
for maximum reliability. The series begins with the entry level Powerpod 410 and advances
to the more sophisticated Powerpods K-12 Plus and K-16 Plus, giving musicians more
flexibility, functions and power to cater to larger audiences. Phonic has designed the entire
Powerpod series with varying input numbers, different signal routing capabilities, and
various amplification levels - ensuring there is a perfect Powerpod for everyone, depending
on venue size, the size of the audience and the different needs of Musicians and engineers.
POWERPOD 410
100W 4-Channel Powered Mixer with Variable Delay
█
█
█
█
█
100W output power
4 Mic/line channels
Variable digital delay with time and repeat control
Amplifier power assignable with additional 1/4" stereo
jack
2-band EQ on mono channels
POWERPOD 620
PLUS
200W 6-Channel Powered Mixer with DFX
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
100W + 100W / 4 ohms stereo power amplifier for Main
L/R or Main/Monitor (Bridge mono, 200W / 8 ohms)
32/40 bit digital multi-effect processor with 100 programs
plus foot switch jack
Six balanced Mic inputs
8 Line inputs
Two Super Hi-Z inputs optimized for direct instrument
input
2-band channel EQ
7-band graphic EQ
Pad control on channels 1~4
AUX input
Stereo RCA I/O
+48V phantom power
Built-in limiters
Monitor and effect sends on each input channel
Drive level / Effect out master control to the input of builtin effect processor
Wooden box with vinyl coating plus steel corner
protection
POWERPOD 740
PLUS
440W 7-Channel Powered Mixer with DFX
█
█
█
█
█
█
█
█
█
█
█
█
█
█
220W + 220W / 4 ohm stereo power amplifier for Main
L/R or Main/Monitor (Bridge mono, 440W / 8 ohm)
32/40 bit digital multi-effect processor with 100 programs
plus foot switch jack
Seven balanced Mic inputs
10 Line inputs
Two super Hi-Z inputs optimized for direct instrument
input
3-band channel EQ
Dual 7-band graphic equalizers with In/Out switches for
Main L/R or Main/Monitor
Pad control on channels 1-4
One AUX input
Monitor and effect sends on each input channel
+48V phantom power
Two built-in limiters
Rec out with trim control for record level matching
Mains power switchable between 115 VAC and 230 VAC
* See Appendix IV on page 33 for full specifications
POWERPOD 410 / POWERPOD 620 PLUS / POWERPOD 740 PLUS
15
POWERED MIXERS
POWERPOD 780
PLUS
600W 7-Channel Powered Mixer with DFX
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
300W + 300W / 4 ohm stereo power amplifier for Main L/R or Main/Monitor
32/40-bit digital multi-effect processor with 100 programs plus foot switch jacks
Seven balanced Mic inputs
10 Line inputs
Two super Hi-Z inputs optimized for direct instrument input
3-band channel EQ
Dual 7-band graphic equalizers with In/Out switches for Main L/R or Main/Monitor
Rumble filters for Mic inputs
Pad control on channels 1-4
One AUX input
Monitor and effect sends on each input channel
+48V phantom power
Two built-in limiters
Rec out with trim control for record level matching
Mains power switchable between 115 VAC and 230 VAC
POWERPOD 820
200W 5-Channel Powered Mixer with DFX
█
█
█
█
█
█
█
█
POWERPOD 865
2 x 100 Watt power amplifiers
6 input channel mixer
+48V phantom power for condenser mics
8-preset DSP effects with enhanced 32-bit processing and two main trim (parameter)
controls
Super Hi-Z inputs and stereo line inputs
Level meters for main outputs with built-in output limiter indicator
Headphone output with volume control
Rugged light weight plastic enclosure
PLUS
600W 8-Channel Molded Powered Mixer with Graphic EQ and DFX
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
Dual position 45 degree angular molded cabinet
300W + 300W / 4 ohms stereo power amplifier for Main L/R or Main/
Monitor (Bridge mono, 600W / 8 ohms)
DFX, our 32/40-bit digital multi-effects processor with 100 preset
programs plus tap delay and test-tones
Wireless Mic module slot
8 balanced Mic inputs
10 Line inputs
Two super Hi-Z inputs optimized for direct instrument input
3-band channel EQ (two channels with swept mid-range)
Dual 7-band graphic equalizers with feedback detection system
Pad control on channels 1-6
Monitor and effect sends on each input channel
Stereo AUX input
+48V phantom power
Vocal eliminator for karaoke application
sPs for smoother high frequencies and enhanced low-end output
Two built-in limiters
Two Speakon-type connectors and five 1/4" phone jacks for speaker
connection
Compatible with the Phonic S3 tripod speaker stand
* See Appendix IV on page 33 for
full specifications
16
POWERPOD 885
PLUS
800W 8-Channel Molded Powered Mixer with Graphic EQ and DFX
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
Dual 45 degree angular molded cabinet
400W + 400W / 4 ohms stereo power amplifier for Main L/R or Main/
Monitor (Bridge mono, 800W / 8 ohms)
Dual DFX, our 32/40-bit digital multi-effects processor with 100
preset programs plus tap delay and test tones
Wireless Mic module slot
8 balanced Mic inputs
10 Line inputs
Two super Hi-Z inputs optimized for direct instrument inputs
3-band channel EQ (two channels with sweepable mid-range)
Dual 7-band graphic equalizers with feedback detection system
Pad control on channels 1-6
Monitor and effect sends on each input channel
Stereo AUX input
+48V phantom power
Vocal eliminator for karaoke application
sPs for smoother high frequencies and enhanced low-end output on
speakers
Two built-in limiters
Rec out with trim control for record level matching
Two Speakon-type connectors and five 1/4" phone jacks for speaker
connection
Compatible with the Phonic S3 tripod speaker stand
POWERPOD 780 PLUS / POWERPOD 820 / POWERPOD 865 PLUS / POWERPOD 885 PLUS
POWERED MIXERS
POWERPOD 1062
PLUS
750W 9-Channel Powered Mixer with DFX
█
█
█
█
█
█
█
█
█
█
█
█
█
█
375W+375W / 4 ohms stereo power amplifier for Main L/R or Mono/Monitor (Bridge mono,
750W / 8 ohms)
DFX, our 32/40-bit digital multi-effect processor with 100 programs plus tap delay and
test tones
9 balanced Mic inputs
12 Line inputs
Two super Hi-Z inputs optimized for direct instrument inputs
3-band channel EQ
Dual 8-band graphic equalizers with in/out switches for Main L/R and Monitor or Main L/R
Rumble filters for channels 1-6
Pad control on channels 1-6
Monitor and effect sends on each input channel
+48V phantom power
Two built-in limiters
Rec out with trim control for record level matching
Mains power switchable between 115 VAC and 230 VAC
POWERPOD 1082
PLUS
800W 10-Channel Powered Mixer with DFX
█
█
█
█
█
█
█
█
█
█
█
█
█
█
400W / 4 ohms stereo power amplifier for Main L/R or Mono/Monitor (Bridge mono,
800W / 8 Ohms)
DFX, our 32/40-bit digital multi-effect processor with 100 programs plus tap delay and
test tones
9 balanced Mic inputs
12 Line inputs
Two super Hi-Z inputs optimized for direct instrument inputs
3-band channel EQ
Dual multi-band graphic equalizers with in/out switches for Main L/R and Monitor or Main
L/R
Rumble filters for Mic inputs
Pad control on channels 1-6
Monitor and effect sends on each input channel
+48V phantom power
Two built-in limiters
Rec out with trim control for record level matching
Mains power switchable between 115 VAC and 230 VAC
POWERPOD 1860
PLUS
800W 12-Channel Powered Mixer with Graphic EQ and DFX
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
* See Appendix IV on page 33 for
full specifications
█
400W + 400W / 4 ohms stereo power amplifier (bridgeable and patchable)
DFX, our 32/40-bit digital multi-effect processor with 100 programs plus tap
control, test tone generator and foot switch on/off jack
8 balanced Mic inputs with inserts
Total of 12 Line inputs
Two stereo Line input channels capable of accepting RCA/Phone inputs
3-band channel EQ
Stereo 7-band graphic EQ
Four AUX sends (AUX 1/2 are pre-fader and EFX 1/2 are post-fader)
Two stereo AUX returns, each can be routed to AUX 1 & 2 sends (effect to monitor)
Stereo RCA I/O for CD/TAPE external sources
Grouped +48V real phantom power for broader application
Mono output for extra zone filling or as subwoofer processing source
PFL on each input and AFL on each output
Standby switch to mute Ch1 ~ Ch12 for playing music between sets
Zone 2 output for side fill or another PA system
Headphone/control room output with rotary level control
One professional Speakon-type jack and two 1/4” jacks per channel for speaker
connection
Rugged metal main chassis with integrated handle
Less weight achieved by high-efficiency switching power supply
Molded protective cover prevents scratching or damage to mixer
Mains power switchable between 115 VAC and 230 VAC
POWERPOD 1062 PLUS / POWERPOD 1082 PLUS / POWERPOD 1860 PLUS
17
POWERED MIXERS
POWERPOD K-12
PLUS
1000W 12-Channel Powered Mixer with Graphic EQ and Dual DFX
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
500W + 500W / 4 ohms stereo power amplifier (bridgeable and patchable)
Dual DFX, our 24/32-bit digital multi-effects processor with 100 programs with
tap delay and test-tones
8 balanced Mic inputs (8 with inserts)
12 Line inputs
Two stereo input channels with 1/4" and RCA inputs
3-band channel EQ with swept mid-range
Stereo 7-band graphic EQ
Four AUX sends (AUX 2 can be set to pre- or post-fader)
Two stereo returns - each can be routed to AUX 1 & 2 sends (effect to monitor)
+48V individual phantom power switches
Mono output with variable low pass filter from 60 Hz up to 160 Hz
PFL on each input and AFL on each output
Standby switch for playing music between sets
Zone 2 output for side fill or another PA system
Headphone output with separate rotary level control
One Speakon-type connector and two 1/4" phone jacks per channel for speaker
connection
Molded protective cover prevents scratching or damage to mixer
Rugged metal main chassis with integrated handle
Low weight achieved by high-efficiency switching power supply
POWERPOD K-16
PLUS
1000W 16-Channel Powered Mixer with Graphic EQ and Dual DFX
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
* See Appendix IV on page 33 for
full specifications
█
█
█
█
█
500W + 500W / 4 ohms stereo power amplifier (bridgeable and patchable)
Dual DFX, our 24/32-bit digital multi-effects processor with 100 programs, tap
delay and test-tones
14 balanced Mic inputs (12 with inserts)
16 Line inputs
Two stereo Line input channels
3-band channel EQ with swept mid-range
Stereo 7-band graphic EQ with feedback detection system
Four AUX sends (AUX 2 can be set to pre- or post-fader)
Two stereo returns - each can be routed to AUX 1 & 2 sends (effect to monitor)
+48V individual phantom power switches
Vocal eliminator for karaoke application
sPs for smoother high frequencies and enhanced low-end output on speakers
Mono output with variable low pass filter from 60 Hz up to 160 Hz
PFL on each input and AFL on each output
Standby switch for playing music between sets
Zone 2 output for side fill or another PA system
Headphone output with separate rotary level control
One Speakon-type connector and two 1/4" phone jacks per channel for speaker
connection
Molded protective cover prevents scratching or damage to mixer
Rugged metal main chassis with integrated handle
KA920
460W Karaoke Powered Mixer
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
18
2 x 460W @ 4 ohms
2 x 300W @ 8 ohms
32/40-Bit DSP reverb and professional digital echo for
superior vocal enhancement
+/- 8-Step Digital Key Controller changes the key of the
music without changing the tempo
On-board video switching with four sets of A/V Inputs, two
audio outputs and two video outputs
Gain and Echo Send control on each microphone input
Ch 1-4 Mic inputs each with individual 3-band EQ
One AUX output and one stereo AUX input
3-band EQ on music input
Balance control on master Music and Mic sections
High, Mid, Low controls on Music source input
Individual Master Microphone and Music volume controls
Multi-functional remote control
Switching-mode power supply
3 RU rack mountable
POWERPOD K-12 PLUS / POWERPOD K-16 PLUS / KA920
AMPLIFIERS
ICON SERIES
Icon Series power amplifiers are designed with the needs of
sound contractors in mind. The binding post outputs allow
for connection to standard low impedance speakers. Barrier
strip outputs enable 25V, 70V and 100V Line operation.
Each amplifier channel has a separate toroidal secondary
transformer that provides full electrical isolation and ensures
maximum audio separation. Features like power up muting,
full short-circuit temperature, DC offset protection and a
built-in 45 Hz subsonic filter, combine to make the Icon
Series an attractive, cost effective solution for any audio
installation.
█
█
█
█
█
Barrier strip connection determines output
mode: 25V, 70V, 100V and low impedance
outputs available simultaneously
Rear panel detented gain controls
Stereo, bridge, and parallel operating modes
XLR inputs and outputs for easy signal pass
through in multi-amp setups
Built-in 45 Hz subsonic filter prevents speaker
transformer saturation with minimal effect on
program material
ICON 300
300W Contractor Amp
█
█
█
132 x 480 x 428 mm (5.2" x 18.9" x 16.9")
20.2 kg (44.5 lbs)
█
█
Output power: 2 x 150W @ 70V or 100V
Automatic dual-speed, high-efficiency cooling fan
XLR and barrier strip inputs
Full short-circuit, temperature and DC offset protection
Toroidal output transformers provide full electrical isolation and
meet worldwide safety standards
ICON 700
700W Contractor Amp
█
█
█
132 x 480 x 428 mm (5.2" x 18.9" x 16.9")
24.3 kg (53.5 lbs)
Output Power
Constant Voltage Output
█
█
Output power: 2 x 350W @ 70V or 100V
Automatic dual-speed, high-efficiency cooling fan
XLR and barrier strip inputs
Full short-circuit, temperature and DC offset protection
Toroidal output transformers provide full electrical isolation and
meet worldwide safety standards
ICON 300
ICON 700
300W + 300W
550W + 550W
200W + 200W
400W + 400W
4Ω stereo
540W
1100W
4Ω bridge
150W + 150W
350W + 350W
100V or 70V
120W + 120W
280W + 280W
25V
50Hz-50KHz
Frequency Response
Inputs
Barrier Strip
√
√
√
√
XLR
Outputs
√
√
Barrier Strip
Protection
√
√
Thermal
√
√
Short Circuit
√
√
DC Offset
2
2
20.2Kg(44.5lbs)
24.3Kg(53.5lbs)
Size (Rack Space Units)
Weight
ICON 300 / ICON 700
2Ω stereo
19
AMPLIFIERS
XP SERIES
Built around robust and advanced toroidal
transfor mer s, Phonic X P Ser ies power
amplifiers deliver clean power on demand.
The advanced protection circuitry guards
against short circuit and open circuit, and
also protects against ultrasonic and RF
interference. A dual mono, high current power
supply increases reliability and performance,
and the variable speed fans ef fectively
cool the amp with rear to front air flow and
protect against overheating. Phonic's XP
Power Amplifiers are specially designed for
professionals who value high power, audio
clarity, reliability and lasting performance.
█
█
█
█
█
█
█
High continuous current output from robust toroidal
transformer
Switchable input peak limiter and selectable high pass
filter (30Hz, 50Hz) to reduce distortion and protect
speakers
Bridge mono and parallel mode LEDs
Fast Recovery design for lower distortion if clipping
occurs
Active balanced inputs for low noise
Front mounted detented gain controls for easy access
Signal level at - 40, -20, -10, protect and clip LED
indicators to monitor performance
XP 1000
1120W Power Amp
█
█
Output Power: 560W @ 2 ohms stereo, 440W @ 4 ohms stereo
Requires two standard rack units for mounting
1920W Power Amp
█
█
Output Power: 960W @ 2 ohms stereo, 660W @ 4 ohms stereo
Requires two standard rack units for mounting
XP 3000
2800W Power Amp
█
█
Output Power: 1400W @ 2 ohms stereo, 1100W @ 4 ohms stereo
Requires three standard rack units for mounting
█
█
█
█
█
Ground Lift switch to prevent humming
Ventilation through variable speed fans
Selectable stereo, parallel & bridge mono amp
modes
Speakon-type connectors and binding post
speaker outputs
XLR & 1/4" TRS connectors for maximum input
flexibility
Advance protection circuitry guards against:
short circuit, open circuit, thermal, ultrasonic,
and RF protection, stable into mismatched loads,
on/off muting, DC fault output crowbar
XP 5000
5000W Power Amp
█
█
█
XP 2000
█
█
█
Output Power: 2500W @ 2 ohms stereo, 1800W @ 4 ohms stereo
High-current toroidal transformers for greater two-ohm power and low noise
Independent user-defeatable clip limiters reduce distortion
XLR, 1/4” and barrier strip inputs all included
Requires three standard rack units for mounting
XP 5100
5000W Power Amp with Subwoofer
█
█
█
█
█
█
Output Power: 2500W @ 2 ohms stereo, 1800W @ 4 ohms stereo
Two low pass filters with selectable frequencies at 60, 90 or 120 Hz for
subwoofer use
High-current toroidal transformers for greater two-ohm power and low noise
Independent user-defeatable clip limiters reduce distortion
XLR, 1/4” and barrier strip inputs all included
Requires three standard rack units for mounting
XP 3100
2800W Power Amp with Subwoofer
█
█
█
█
Output Power: 1400W @ 2 ohms stereo, 1100W @ 4 ohms stereo
XLR & 1/4" TRS connectors for maximum input flexibility
Two low pass filters with selectable frequencies at 60, 90 or 120 Hz
for subwoofer use
Requires three standard rack units for mounting
* See Appendix VII on page 34 for full specifications
20
XP 1000 / XP 2000 / XP 3000 / XP 3100 / XP 5000 / XP 5100
AMPLIFIERS
MAX SERIES
All 5 of the Phonic MAX series power amplifiers provide
a range of different power options and are big on added
features. Input to the MAX amps is achieved via the XLR
and 1/4” jacks, and output is achieved through either the
professional standard speakon connectors or traditional
binding posts. Common to all models are such features as
ground switches, user defeatable clip limiters, selectable
high pass filters, as well as the ability to choose stereo,
parallel or bridge operating modes. All of this, plus the
high efficiency circuitry design and ultra-cool operation
makes the MAX series amplifiers ideal for real world, large
scale application.
MAX 250
MAX 500
160W Power Amp
█
█
█
█
█
█
█
█
█
█
240W Power Amp
Output power: 80W @ 4 ohms stereo, 60W @ 8 ohms stereo
Studio quality performance with very low noise and wide dynamic
range
Class H high efficiency circuitry design
Ultra-low total harmonic distortion
High damping factor provides exceptional loudspeaker motion control
Detented level controls for precise repeatability
Signal and CLIP indicators to monitor performance
Short circuit, thermal, subsonic, RF protection, output DC offset,
over-heat protection and power on/off muting
Convection cooling system dissipates heat through the heat sink and
chassis for noise-free operation
One rack unit
█
█
█
█
█
█
█
█
█
█
█
MAX 860
PLUS
600W Power Amp
█
█
█
█
█
█
█
█
Output power: 300W @ 4 ohms stereo, 200W @ 8 ohms stereo
High-current toroidal transformers for greater power and low noise
Balanced XLR input jacks
Binding post and Speakon-type outputs
Front mounted gain controls for easy access
Signal and Peak LED indicators to monitor performance
Short circuit, thermal, subsonic, RF protection, output DC offset
Power on/off muting
Output power: 120W @ 4 ohms stereo, 90W @ 8 ohms stereo
Studio quality performance with very low noise and wide dynamic
range
Class H high efficiency circuitry design
Ultra-low total harmonic distortion
High damping factor provides exceptional loudspeaker motion control
Detented level controls for precise repeatability
Signal and CLIP indicators to monitor performance
Protect indicator
Short circuit, thermal, subsonic, RF protection, output DC offset,
over-heat protection and power on/off muting
Convection cooling system dissipates heat through the heat sink and
chassis for noise-free operation
One rack unit
MAX 1500
PLUS
900W Power Amp
█
█
█
█
█
█
█
█
Output power: 450W @ 4 ohms stereo, 280W @ 8 ohms stereo
High-current toroidal transformers for greater power and low noise
Balanced XLR input jacks
Binding post and Speakon-type outputs
Front mounted gain controls for easy access
Signal and Peak LED indicators to monitor performance
Short circuit, thermal, subsonic, RF protection, output DC offset
Power on/off muting
MAX 2500
PLUS
1500W Power Amp
█
█
█
█
█
█
█
█
Output power: 750W @ 4 ohms stereo, 500W @ 8 ohms stereo
High-current toroidal transformers for greater power and low noise
Balanced XLR input jacks
Binding post and Speakon-type outputs
Front mounted gain controls for easy access
Signal and Peak LED indicators to monitor performance
Short circuit, thermal, subsonic, RF protection, output DC offset
Power on/off muting
* See Appendix VIII on page 34 for full specifications
MAX 250 / MAX 500 / MAX 860 PLUS / MAX 1500 PLUS / MAX 2500 PLUS
21
SPEAKERS
NEXUS SERIES
The Nexus Active Speakers are the sucessors to the Phonic
Performer series - the world's first wireless professional audio
speakers. The Nexus Speakers are able to wirelessly communicate
with your mixer through Phonic's WM series of wireless transmitters
and receivers. For a completely wireless set up, they can also be
used with Phonic's versatile UM wireless microphones.
645 x 495 x 440 mm ( 25.4" x 19.5" x 17.3")
24 kg ( 52.9 lbs)
* See Appendix IX on page 35 for full specifications
NEXUS A915SB
450W Active 15" Subwoofer
█
█
█
█
█
█
█
Built-in 450 Watt (RMS) amplifier
Balanced XLR input and output
Built-in protection circuitry
Lightweight cabinet with dynamic sound
128 dB Max SPL (1 Watt @ 1 meter)
22k ohm input impedance
35mm pole mounting point
NEXUS A935SB
900W Active 15" Subwoofer with Powered Output
█
█
█
█
█
█
█
█
Built-in 700 Watt (RMS) amp for the subwoofer and 2 x 100
Watts (RMS) for external full range speakers
Balanced XLR input and output
Two 1/4" phone jack outputs for powering passive full-range
speakers with 100 Watts (per channel)
Built-in protection circuitry
Lightweight cabinet with dynamic sound
126.5 dB Max SPL (1 Watt @ 1 meter)
22k ohm input impedance
35mm pole mounting point
Optional Accessories:
For more information, see page 27.
22
Wireless microphone systems (UM31, UM41, UM51)
UM31: Wireless Handheld System
UM41: Wireless Lavaliere System
UM51: Wireless Head-set System
NEXUS A915SB / NEXUS A935SB
SPEAKERS
CENTER SERIES
The Phonic Center loudspeakers provide high power handling, low
distortion, and consistent polar response in compact, scratch-proof
enclosures. The Center speakers come in 2-way and subwoofer
models, and feature 10” to 18” low-frequency drivers matched with 1”
compression drivers (with exception to subwoofer models). The Phonic
Center speakers have a number of sound reinforcement applications:
as main front-of-house loudspeakers in small venues, as floor monitors
for musicians (Center 12M), for bass enhancement (‘SB’ models),
or as side-fill loudspeakers in larger systems. Most models can be
suspended from ceilings and angled for better coverage, or mounted
onto stands, poles and trusses. With the versatility of the range, the setup possibilities are virtually endless with the Phonic Center series.
█
█
█
█
CENTER 10
10" 2-Way Stage Speaker
█
█
█
█
█
█
Frequency response: 60Hz-20kHz
Coverage pattern: 90 degrees x 60
degrees nominal
Power rating: 200W RMS, 400W
Program
10" Differential drive woofer
1" compression driver
Forged eyebolts for fixed installation
Constructed from A-grade MDF and finished with antiscratch paint
Extremely high power handling in a light weight, compact
enclosure
Integrated passive crossover offered on all 2-way models
Incredible fidelity and outstanding high and low frequency
performance
CENTER 12
CENTER 15
12" 2-Way Stage Speaker
█
█
█
█
█
█
15" 2-Way Stage Speaker
Frequency response: 55Hz-18kHz
Coverage pattern: 90 degrees x 60
degrees nominal
Power rating: 300W RMS, 600W
Program
12" Differential drive woofer
1" compression driver
Forged eyebolts for fixed installation
█
█
█
█
█
█
Frequency response: 50Hz-18kHz
Coverage pattern: 90 degrees x 60
degrees nominal
Power rating: 400W RMS, 800W
Program
15" Differential drive woofer
1" compression driver
Forged eyebolts for fixed installation
CENTER 215
Dual 15" 2-Way Stage Speaker
█
█
█
█
█
█
CENTER 12M
CENTER 215SB
12" 2-Way Stage / Floor Monitor Speaker
█
█
█
█
█
Dual 15", 2-way, speaker cabinet system
Frequency response: 45Hz-18kHz
Coverage pattern: 90 degrees x 60 degrees nominal
Power rating: 800W RMS, 1600W program
Dual 15" Differential drive speakers
1" compression driver for mids and highs
Dual 15" Subwoofer
Frequency response: 55Hz-18kHz
Coverage pattern: 90 degrees x 60 degrees nominal
Power rating: 300W RMS, 600W Program
12" Differential drive woofer
1" compression driver
█
█
█
█
█
Frequency Response : 40Hz - 250Hz
Power Rating (Continuous/Program): 600W/1200W
Sensitivity (1w @ 1m): 96dB SPL
Dual 15" Differential drive woofer
Nominal Impedance: 4 ohms parallel
CENTER 18SB
CENTER 218SB
18" Subwoofer
█
█
█
█
Dual 18” Subwoofer
Frequency response: 35Hz-200Hz
Power rating: 500W RMS, 1000W program
Rugged, plywood construction and internal bracing
reduces acoustic losses
Top-mounted pole receptacle for easy expansion
█
█
█
█
█
Frequency Response : 40Hz - 350Hz
Power Rating (Continuous/Program):
1000W/2000W
Sensitivity (1w @ 1m): 100dB SPL
Dual 18" Differential drive woofer
Nominal Impedance: 4 ohms parallel
* See Appendix VI on page 34 for full specifications
CENTER 10 / CENTER 12 / CENTER 12M / CENTER 15 / CENTER 215 / CENTER 18SB / CENTER 215SB / CENTER 218SB
23
SPEAKERS
IMPRESSION
IMPRESSION 215
PLUS
█
█
█
█
█
█
█
█
Power handling (Continuous/Program/Peak):
300 / 600 / 1200 Watts
High sound pressure level: 100 dB SPL @ 1 W / 1 M
Frequency response: 40 Hz ~ 20 kHz
1.75" (44mm) diaphragm tweeter
Constant directivity horn with 90 x 60 degrees of
coverage
HF driver protection system
Durable die-cast handles
Trapezoidal enclosure
Professional speaker
connectors and 1/4"
phone jacks
(IN and LINK OUT)
█
█
█
█
█
█
Power handling: 300 Watts (RMS) / 600 Watts (Program)
@ 8 ohms
Versatile use as a floor monitor or mounted as a raised
sound reinforcement speaker
High sound pressure level: 97 dB SPL @ 1 W / 1 M
Frequency response: 48 Hz ~ 20 kHz
1.75" (44 mm) diaphragm tweeter
Constant directivity horn with 90 x 60 degrees of coverage
█ HF driver protection system
█ Trapezoidal enclosure for array system
█ One 35 mm socket at bottom for stand or pole
mounting
█ Speakon-type connectors and 1/4" phone jacks
(In and Link Out)
█ Solid steel grille protection
IMPRESSION 12
15" Subwoofer
█
█
█
█
█
█
Power handling: 500 Watts (RMS),
1000 Watts (Program) @ 4 ohms
High sound pressure level:
98 dB SPL @ 1 W / 1 M
Frequency response: 38 Hz ~ 250 Hz
Durable die-cast handles
One 35 mm socket on top for pole
mounting
Speakon-type connectors and 1/4"
phone jacks (In and Link Out)
Solid steel grille protection
█
IMPRESSION 18SB
█
█
█
█
█
█
█
SEM 710
█
█
█
█
█
█
█
PLUS
Double duty: use as a floor monitor or mounted as
a raised sound reinforcement speaker
Power handling: 150 Watts (RMS); 300 Watts
(Program)
Frequency response: 65 Hz ~ 20 KHz
High sound pressure level, 96 dB SPL @ 1W / 1M
10" heavy-duty woofer and piezo tweeter
8 ohm nominal load
Built-in handle
35 mm stand adapter built-in
Dual 1/4" phone jacks
SEM 715
PLUS
15" 2-way Stage/Floor Speaker
█
█
█
█
█
█
█
█
█
24
█
█
█
█
█
█
Power handling: 250 Watts (RMS) / 500 Watts
(Program) @ 8 ohms
Versatile use as a floor monitor or mounted as a
raised sound reinforcement speaker
High sound pressure level: 96 dB SPL @ 1 W / 1 M
Frequency response: 55 Hz ~ 20 kHz
1.75" (44 mm) diaphragm tweeter
Constant directivity horn with 60 x 90 degrees of
coverage
HF driver protection system
Trapezoidal enclosure for array system
One 35 mm socket at bottom for stand or pole
mounting
Professional speaker connectors and 1/4" phone
jacks (In and Link Out)
Solid steel grille protection
SERIES
10" 2-way Stage/Floor Speaker
█
█
Power handling : 700 Watts (RMS) / 1400 Watts
(Program) @ 4 ohms
High sound pressure level: 99 dB SPL @ 1 W / 1 M
Frequency response: 33 Hz ~ 250 Hz
Durable die-cast handles
One 35 mm socket on top for pole mounting
Speakon-type connectors and 1/4" phone jacks
(In and Link Out)
Solid steel grille protection
PLUS
█
█
PLUS
18" Subwoofer
█
SEM
PLUS
12'' 2-Way Stage / Floor Monitor Speaker
PLUS
█
PLUS
15'' 2-Way Stage / Floor Monitor Speaker
IMPRESSION
15SB
█
* See Appendix X on page
35 for full specifications
IMPRESSION 15
PLUS
Dual 15” 2-Way Stage Speaker
█
SERIES
Double duty: use as a floor monitor or mounted as
a raised sound reinforcement speaker
Power handling: 230 Watts (RMS); 460 Watts
(Program)
Frequency response: 50 Hz ~ 20 KHz
High sound pressure level, 98 dB SPL @ 1W / 1M
15" heavy-duty woofer and piezo tweeter
8 ohm nominal load
Built-in handle
35 mm stand adapter built-in
Dual 1/4" phone jacks
* See Appendix XI on page 35
for full specifications
SEM 712
PLUS
12" 2-way Stage/Floor Speaker
█
█
█
█
█
█
█
█
█
Double duty: use as a floor monitor or mounted as a
raised sound reinforcement speaker
Power handling: 175 Watts (RMS); 350 Watts
(Program)
Frequency response: 60 Hz ~ 20 KHz
High sound pressure level, 95 dB SPL @ 1W / 1M
12" heavy-duty woofer and piezo tweeter
8 ohm nominal load
Built-in handle
35 mm stand adapter built-in
Dual 1/4" phone jacks
SE 725
PLUS
Dual 15" Passive Speaker
█
█
█
█
█
█
█
Power handling: 400 Watts (RMS); 800 Watts
(Program) at 4 ohms
Two 15" woofers matched with a 1" piezo tweeter
High sound pressure level
Wide frequency response: 40 Hz - 20 kHz
1/4" phone jack inputs
High sound pressure level: 100 dB SPL @ 1 W / 1 M
Carpeted trapezoidal box
IMPRESSION 12 PLUS / IMPRESSION 15 PLUS / IMPRESSION 215 PLUS / IMPRESSION 15SB PLUS / IMPRESSION 18SB PLUS /
SEM 710 PLUS / SEM 712 PLUS / SEM 715 PLUS / SE 725 PLUS
SPEAKERS
STUDIO MONITORS
Phonic Active Studio Monitors produce extremely accurate, crystal clear sound.
Featuring a bi-amplified design with outputs starting at 70 Watts (program) and
140 Watts (peak). They also feature bi-colored On/Clip Indicators, built-in overload
protection circuits, and incredibly flat frequency response. Use these speakers in
acoustically perfect or challenging environments for consistent performance and
quality every time.
* See Appendix III on page 32 for full specifications
P5A
210W 2-Way High Resolution Active Speaker
█
█
█
█
█
█
█
█
█
█
█
█
Bi-amplified design with 140W for the low
frequencies and 70W for the highs
Flat response from 70 Hz to 20 kHz
Extremely wide sweet spot and good imaging
Built-in speaker response controls
5" Woofer, 1" silk-dome tweeter
Built-in adjustable high match, low match
Room Compensation
Magnetically shielded
Overload protection
Front bi-color (On/Clip) indicator
XLR and 1/4" inputs
High grade MDF wooden cabinet
P6A
P8A
210W 2-Way High Resolution Active Speaker
█
█
█
█
█
█
█
█
█
█
█
█
320W 2-Way High Resolution Active Speaker
Bi-amplified design with 140W for the low
frequencies and 70W for the highs
Flat response from 55 Hz to 20 kHz
Extremely wide sweet spot and good imaging
Built-in speaker response controls
6 1/4" Woofer, 1" silk-dome tweeter
Built-in adjustable high match, low match
Room Compensation
Magnetically shielded
Overload protection
Front bi-color (On/Clip) indicator
XLR and 1/4" inputs
High grade MDF wooden cabinet
█
█
█
█
█
█
█
█
█
█
█
█
█
Bi-amplified design with 212W for the low
frequencies and 106W for the highs
Flat response from 45 Hz to 22 kHz
Extremely wide sweet spot and good imaging
Built-in speaker response controls
8 3/4" Woofer, 1" silk-dome tweeter
Built-in adjustable high match, low match
Room compensation circuitry
Strong bass
Magnetically shielded
Overload protection
Front bi-color (On/Clip) indicator
XLR and 1/4" inputs
High grade MDF wooden cabinet
CONTRACTOR SPEAKERS
SE 206
5 1/4" 2-Way Molded Speaker
█
█
█
█
█
Extended bass response
Lightweight plastic enclosure
Internal threaded inserts
U-mount bracket included
Optional universal swivel mounting bracket
SE 207
6 1/2" 2-Way Molded Speaker
█
█
█
█
█
Power Capacity: 50 Watts
Sensitivity: 90 dB SPL @ 1W / 1M
Frequency Response: 70 Hz ~ 20 kHz
1" Tweeter and 6 1/2" Woofer
U-mount Bracket included
VERSATAP 30
4" 2-way Speaker with Transformer
█
█
█
█
█
█
█
█
Power Capacity: 30W @ 8 Ohm
Frequency Response: 120 Hz - 20 kHz
Sensitivity: 84 dB SPL @ 1W/1M, 1 kHz
4" poly carbon woofer and 1" soft dome
Transformer with 4 taps positions (2, 4, 8, 16W)
and 30W (8 Ohm) bypass
Moisture resistant aluminum enclosure available
in black or white
Lightweight and compact
U-mount bracket included
P5A / P6A / P8A / SE 206 / SEp 206 / SE 207 / SEp 207 / VERSATAP 30 / VERSATAP 50
SEp 206
Powered 5 1/4" Molded Speaker
█
█
█
█
█
Built-in 20W power amplifier
One XLR (female) input jack
Frequency Response: 80 Hz ~ 16 kHz
1" Tweeter and 5 1/4" Woofer
U-mount Bracket included
SEp 207
Powered 6 1/2" Molded Speaker
█
█
█
█
█
Built-in 20W power amplifier
One XLR (female) input jack
Frequency Response: 70 Hz ~ 20 kHz
1" Tweeter and 6 1/2" Woofer
U-mount Bracket included
VERSATAP 50
6 1/2" Molded Speaker with Transformer
█
█
█
█
█
█
█
Power Capacity: 50W @ 8 Ohm
Frequency Response: 75 Hz - 20 kHz
Sensitivity: 90 dB SPL @ 1W/1M, 1 kHz
6.5" poly carbon woofer and 1" soft dome
Transformer with 4 taps positions
(2.5, 5, 10, 20W) and 50W (8 Ohm) bypass
Moisture resistant lightweight plastic enclosure
U-mount bracket included
25
SPEAKERS
CEILING SPEAKERS
WIRELESS GEAR
█
Iron-molded circular construct with fire-proof coating
█
Coaxial driver reduces size and improves sound quality
█
Mount speakers with C-type iron rings and lightweight
V-type steel brackets; fasten with auto-lock nails
█
Built-in transformer
Speaker
Diameter
IW5006
IW6510
5"*3/4" coaxial
driver
6.5"*1" coaxial
driver
IW4030
IW8030
IW8030LP
IW1060
IW506
IW656
IW810
4"*1.5" driver
8"*1" coaxial
driver
8"*1" coaxial
driver
10" subwoofer
driver
5" driver
6.5" driver
8" driver
70V
70V
70V
Operating Mode
100V
100V
100V
Power Handling
1.5W, 3W, 6W
1.5W, 3W, 6W
20W.30W
Frequency
Response
65 Hz - 18 kHz
60 Hz - 18 kHz
80 Hz - 20 kHz
50 Hz - 20 kHz
50 Hz - 20 kHz
S.P.Lat Rated
Input(1m)
92dB
90dB
90dB
91dB
Beam width
(at 1 kHz)
130°
140°
130°
180mm
230mm
Height
123.5mm
Weight
1.05kg
Dimensions
(outer diameter)
100V
100V
100V
1.5W,3W,6W
1.5W,3W,6W
3W,6W
45 Hz - 150Hz
150 Hz - 12 kHz
130 Hz - 13
kHz
80 Hz - 12
kHz
91dB
94dB
91dB
91dB
90dB
110°
110°
N/A
N/A
N/A
N/A
181mm
270mm
270mm
320mm
153mm
183mm
220mm
123.5mm
176mm
255mm
190mm
303mm
75mm
72mm
66mm
1.5kg
2.1kg
5kg
5kg
7kg
0.87kg
1.1kg
1.1kg
3.7W, 7.5W, 15W, 3.7W, 7.5W, 15W,
15W, 30W, 60W
30W
30W
WIRELESS
Universal System For All Active Speakers
WM-SYS3
W5
Single Channel Wireless System For Active Speakers
█
█
█
2.4GHz Wireless Digital Audio System
WM60 single channel transmitter
WM400-L receiver
M6, M8, M10 screws & velcro strip for attaching to speakers
█
█
█
█
█
WM-SYS4
█
Starter kit includes one transmitter and 2 receivers
High Audio Quality through 2.4 GHz Uncompressed PCM Transmission
Varied inputs and outputs, including USB 2.0, S/PDIF and RCA
1100mAH Li-ion battery embedded into receiver with a life up to 4 hours
Supports multiport link: one transmitter can link to between 1 and 5
receivers
Transfers audio up to 100 meters
Dual Channel Wireless System For Active Speakers
█
█
█
█
WM70 dual channel transmitter
WM400-L left channel receiver
WM400-R right channel receiver
M6, M8, M10 screws & velcro strip for attaching to speakers
Transmitters
Receivers
WM60
█
█
█
█
WM70
█
█
█
█
█
26
WM40-L
WM40-R
Single Channel Wireless
Transmitter
16 selectable UHF preset channels
XLR and 1/4” phone jack inputs
Transmits over 70 meters (230 feet)
█
█
█
WM400-R
Dual Channel Wireless Transmitter
16 selectable UHF preset channels
Volume controls to avoid clipping
Combo inputs accepting 1/4” and
XLR Mono/Stereo select switch
Transmits over 70 meters (230 feet)
WM400-L
Single Channel Receiver
16 selectable UHF preset channels
For use with the Phonic Nexus
active speakers
WM400-L
WM400-R
█
█
█
█
Single Channel Receiver
16 selectable UHF preset channels
XLR output
For use with any active speaker
CEILING SPEAKERS / WM-SYS3 / WM-SYS4 / WM60 / WM70 / WM40 / WM400
WIRELESS GEAR
MICROPHONES
N ow Phonic provides user s with a c omplete wireless microphone range
c ompatible with their most popular ranges of pro audio gear. The U M 3 0,
U M 40 and U M 5 0 W ireless Microphone sets are all c ompatible with the
incredibly popular Sound Ambassador Mobile Sound Systems. The
U M 31, U M 41 a n d U M 51, o n t h e o t h e r h a n d , a r e c o m p a t i b l e w i t h t h e
popular RoadG ear sets, Ac tive W ireless Nexus Speaker s and Power pod
8 6 5 Plus and 8 8 5 Plus M olded Powered Mixer s, making them incredible
ver satile as well as simple to use.
UM30
Wireless UHF Handheld System
█
UM-R10
HT-100
Sound
Ambassador
█
HT-100 Handheld Transmitter
UM-R10 Wireless Receiver Module
UM40
Wireless UHF Lavaliere System
█
BT-200
ML-10
UM-R10
█
█
BT-200 Bodypack Transmitter
ML-10 Lavaliere Mic
UM-R10 Wireless Receiver Module
UM50
Wireless UHF Head-set System
For Sound Ambassador,
see page 28
█
█
BT-200
MH-20
UM-R10
█
BT-200 Bodypack Transmitter
MH-20 Headset Mic
UM-R10 Wireless Receiver Module
UM31
Powerpod 865 Plus
Powerpod 885 Plus
Wireless UHF Handheld System
HT-100
UM-R11
█
█
HT-100 Handheld Transmitter
UM-R11 Wireless Receiver Module
UM41
RoadGear
Wireless UHF Lavaliere System
█
█
BT-200
ML-10
UM-R11
█
BT-200 Bodypack Transmitter
ML-10 Lavaliere Mic
UM-R11 Wireless Receiver Module
Nexus
UM51
Wireless UHF Head-set System
█
█
For RoadGear, see page 29
For Nexus, see page 22
UM30 / UM40 / UM50 / UM31 / UM41 / UM51
BT-200
MH-20
UM-R11
█
BT-200 Bodypack Transmitter
MH-20 Headset Mic
UM-R11 Wireless Receiver Module
27
MOBILE PA
SOUND AMBASSADOR
SOUND AMBASSADOR 35 DELUXE
35 Watt Mobile Sound System
█
█
█
█
█
█
█
█
█
█
█
█
331 x 230 x 244 mm ( 13" x 9" x 9.6")
7 kg (15 lbs)
█
█
█
All-in-one compact mobile wireless sound system
6.5” full range speaker and 35 watts power amplifier built-in
Optional UHF wireless microphones
Optional anti-shock CD player with MP3 playback
Built-in DC charging circuit
12 VDC supply from built-in, maintenance-free lead acid type rechargeable
batteries, 2.7Ah
DC inlet for external power supply
Two expansion slots for the addition of UHF PLL synthesized diversity
wireless receiver modules
Built-in diversity receiving antennas
One 1/4" phone jack for wired microphone input
1/4" phone jack for line-level input and output
Built-in limiter and protection circuitry to minimize distortion and overload
Individual volume control for wired and wireless microphones
Echo effect with level and time/repeat controls
Compatible with the Phonic S3 tripod speaker stand
SOUND AMBASSADOR 75 DELUXE
75 Watt Mobile Sound System
█
█
█
█
█
█
█
█
█
█
█
█
█
This picture is for reference only and features optional
components. Your Sound Ambassador 75 Deluxe may
differ to what is shown here.
█
Optional Accessories:
█
█
612 x 300 x 350 mm ( 24" x 11.8" x 13.8")
19.5 kg (43 lbs)
Portable sound system with wheels and retractable handle
Optional wireless microphones (UHF) and anti-shock CD player with MP3
playback
100 - 240VAC switching power supply
10" 2-way speaker system (75 Watts @ 4 ohms)
Built-in DC charging circuit
24 VDC supply from two built-in, maintenance-free lead acid type
rechargeable batteries
One XLR and one 1/4" phone jack for wired microphone input
1/4" phone jack and mini-stereo jacks for line-level input and output
Built-in limiter and protection circuitry to minimize distortion and overload
Individual volume control for wired and wireless microphones
Master volume control
Switched and unswitched speaker output jacks
Tripod stand adapter included
Compatible with the Phonic S1 and S2 speaker mounts
█
█
UM30: Wireless UHF Handheld Microphone System
UM40: Wireless UHF Lavaliere Microphone System
UM50: Wireless UHF Headset Microphone System
CD Player with MP3 Playback
For more information, see page 26 and 27.
SOUND AMBASSADOR 40A
Active Expansion Speaker for the Sound Ambassador 35 Deluxe
█
█
█
█
█
6.5” full range speaker and 35 watt power amp built-in
2.7Ah acid-lead battery built-in, operates on DC or AC power
Echo effect and tone control for sweetening your voice
25mm diameter tripod stand adapter included
Speaker output jack for external passive speaker
(Sound Ambassador 40P)
SOUND AMBASSADOR 80A
Active Expansion Speaker for the Sound Ambassador 75 Deluxe
█
█
█
█
█
█
SOUND AMBASSADOR 40P
Passive Expansion Speaker for the Sound Ambassador 35 Deluxe
█
█
█
█
Passive speaker for the extension of SA35D
6.5” full range speaker and 35 watts program power handling
Sensitivity 92dB SPL @1W/1M
25mm diameter tripod stand adapter included
█
█
█
SOUND AMBASSADOR 80P
Passive Expansion Speaker for the Sound Ambassador 75 Deluxe
█
█
* See Appendix V on page 33 for full specifications
█
█
█
█
28
10" 2-way speaker system with 75 watt power amplifier
Frequency response: 50Hz to 18kHz
100-240VAC switching power supply
Built-in DC charging circuit
24 VDC supply from two built-in, maintenance-free lead acid type
rechargeable batteries
24-32VDC inlet for external power supply
Two 1/4" phone jacks for input & output
Built-in limiter and protection circuitry to minimize distortion and overload
Tripod stand adapter included
10" 2-way speaker system
Power handling: 75 watts
Frequency response: 50Hz to 18kHz
Sensitivity: 96dB SPL @ 1m
Two 1/4" phone jack for input & output
Tripod stand adapter included
SA35D / SA75D / SA40A / SA40P / SA80A / SA80P
PLUS
SERIES
MOBILE PA
ROADGEAR
The RoadGear Series is a totally hassle-free, mobile sound solution. The RoadGear 160 Plus
and 260 Plus are self-sufficient systems housing 2-way 8" speakers, a 5- or 8-channel powered
mixer, a dynamic microphone (two with the 260) and all the necessary cables. The roadworthy, high-impact modular polymer construction in a wheelbase, luggage-style cabinet makes
RoadGear the ideal mobile sound solution for live performers, schools, churches, conferences,
special events, and anywhere that calls for a quick, five minute setup.
ROADGEAR 160
PLUS
160 Watt Mobile Sound System
█
█
█
█
█
█
█
█
█
█
█
█
█
Luxury luggage-style molded cabinet with wheels
160W (80W per channel) stereo power amplifier
5-Channel powered mixer (three Mic/Line, one stereo) with phantom power
Speaker system with 1" compression driver and 8" woofers
Echo effect with delay and repeat controls
2-band EQ on each input channel
System bass/treble control
One stereo input channel and one stereo AUX return
Speaker output with send and return
One dynamic microphone with mic clip, cable and carry bag
Two 30 ft speaker cables
Storage compartments for microphones, cables and accessories
Operates on AC or DC power
ROADGEAR 260
PLUS
260 Watt Mobile Sound System
█
█
█
█
█
█
█
█
█
█
█
█
█
818 x 635 x 352 mm ( 32.2" x 25" x 13.86")
28 kg ( 62 lbs)
Luxury luggage-style molded cabinet with wheels
260W (130W per channel) stereo power amplifier
8-Channel powered mixer (four Mic/Line, two stereo) with phantom power
Speaker system with 1" compression driver and 8"woofer
DFX, our 24-bit digital multi-effect processor with 16 programs and foot
switch jack
2-band EQ on each input channel
3-band system equalizer
One stereo input channel and one stereo AUX return
Speaker output with send and return
Two dynamic microphones with mic clips, cables and carry bags
Two 30 ft speaker cables
Storage compartments for microphones, cables and accessories
Operates on AC or DC power
Optional Accessories:
█ Wireless UHF handheld, lavaliere and head-set microphones
(UM31, UM41, UM51, respectively)
█ Speaker stands and mounts (MK1-RG, MK2-RG, SK1, SK2)
█ RoadGear travel bag (TB-RG)
For more information, see page 26 and 27.
RoadGear 160 Plus
Speakers
Output Power
Speaker Outputs
System EQ
Minimum Impedance (Power Amp)
Tweeter
130W + 130W
8Ω
2 kHz
XLR
3
4
3
4
1/4"
2
3
1/4" Stereo
1
1
Stereo RCA
2
4
1/4"
Treble or Bass
3-band
8Ω
4Ω
L & R or MAIN & MONITOR
Amp Mode
DFX
Woofer
1" Driver
80W + 80W
Low/High Crossover Point
Inputs
RoadGear 260 Plus
8"
Echo
16 & Tap Delay
√
Phantom Power
Wireless microphone expansion slots
2
Included Accessories
1
2
Mic
√
√
Cables & Dust Cover
ROADGEAR 160 PLUS / ROADGEAR 260 PLUS
2
29
SIGNAL PROCESSORS
SIGNAL PROCESSORS
GEQ1500
482 x 183 x 44 mm
(19" x 7.2" x 1.7")
2.29 kg (5.05 lbs)
GEQ3100
482 x 183 x 88 mm
(19" x 7.2" x 3.6")
4.4 kg (9.7 lbs)
DYN2000
482 x 183 x 44 mm
(19" x 7.2" x 1.7")
2.29 kg (5.05 lbs)
iA231F
485.5 x 88 x 182 mm
(19" x 3.5" x 7.2")
3.2 kg (7.1 lbs)
GEQ1500
15-band Graphic Equalizer
█
█
█
█
█
█
█
█
Two 15-band, 2/3-octave Constant Q frequency bands
Switchable boost/cut ranges of ±6 or ±12 dB
12 dB per octave 50Hz low-cut filter
Front-panel bypass switch
±12 dB input gain range
4-segment LED ladders for monitoring output levels
XLR and TRS Inputs and Outputs
Internal Toroidal Transformer
DYN2000
Dual Channel Compressor and Limiter
█
█
█
█
█
█
█
█
█
█
█
█
30
Stereo or Dual Mono operation of gating, compression and peak
limiting
Expander/Gate Circuit with variable release time and +15dBu
maximum threshold
Hard Knee Selection allows selection between compression curve
and the classic Hard Knee curve
Low Frequency Shelf (via Contour button) in the Sidechain Path
function
Limiting - provides control of maximum peak levels at output
regardless of other controls
Peak Limiter comes after the compression, gating and other circuitry
including the output gain
Absolute limit for peak excursions before they reach the output
True RMS Level Detection senses the power in the program, in a
similar way as human hearing does, giving results superior to peak or
average detection
Bypass Buttons on both channels - comparing the processed and
unprocessed signals
LED Display for Gain Reduction and output
Balanced XLR and 1/4” TRS Input and Output Jacks
Separate Sidechain Inserts enable an outboard processor or signal
to control compression or gating
GEQ3100
31-band Graphic Equalizer
█
█
█
█
█
█
█
█
Two 31-band, 1/3-octave Constant Q frequency bands
Switchable boost/cut ranges of ±6 or ±12 dB
12 dB per octave 50Hz low-cut filter
Front-panel bypass switch
±12 dB input gain range
4-segment LED ladders for monitoring output levels
XLR and TRS Inputs and Outputs
Internal Toroidal Transformer
iA231F
Dual Channel Digital 31-Band Graphic Equalizer
█
█
█
█
█
█
█
█
█
█
█
█
█
█
30 mm VR Sliders for precise adjustment
Feedback Detection System instantly reveals critical frequencies
Additional HPF filter removes unwanted frequencies
Switchable boost/cut range between 6 dB and 12 dB
EQ IN/OUT switch
I/O Level meter switch
Dedicated mono subwoofer output with adjustable crossover frequency
+15 dB to -oo input gain range for easy level matching
8-segment LED meter with clip warning for input
Illuminated faders
Relay-controlled bypass
Channel-link function
Balanced inputs and outputs with 1/4" TRS and XLR connectors
Built-in limiter control from -20 dB to +20 dB (OFF)
GEQ1500 / GEQ3100 / DYN2000 / iA231F
SIGNAL PROCESSORS
i7100
51.3 x 482 x 207.6 mm
(2.02" x 18.98" x 8.17")
2.2Kg (4.8lbs)
i7300
51.3 x 482 x 207.6 mm
(2.02" x 18.98" x 8.17")
2.5 kg (5.5 lbs)
i7600
483 x 44 x 206 mm
(19" x 1.75" x 8")
2.5 kg (5.5 lbs)
PPC8000
44.44 × 48.2 × 152 mm
(2.75" × 19" × 6")
2.4kg (5.29 lbs)
PPC9000
44.44 × 48.2 × 152 mm
(2.75" × 19" × 6")
2.4kg (5.29 lbs)
PCR2213
482 × 44.5 × 167 mm
(19" × 1.75" × 6.57")
3.21kg (7.1 lbs)
i7100
Digital Feedback Eliminator
█
█
█
█
█
24 fully programmable parametric filters can be set manually
Auto Mode constantly monitors the mix and automatically resets the filters
Manual Mode provides each channel with up to 12 fully parametric filters
Single-Shot, Auto, and Manual modes can be assigned to each individual
filter
Most recent changes are automatically stored and kept, even after the power
is off
i7300
Digital Multi Reverb
█
█
█
█
█
█
█
█
█
█
█
24-bit A/D and D/A converters with 256/512 times over sampling for high
headroom and resolution
Internal 32-bit processor with 44.1 kHz sampling rate
True stereo performance and variable stereo image parameters
100 factory programs and 100 user programs
Dual 10-segment LED level meters
Balanced XLR and 1/4" TRS inputs and outputs
Operating levels of +4 dBu and -10 dBV independently selectable for input
and output
Foot switch connector for hands-free program selection and bypass
MIDI capability allowing real-time program selection and dump
Dedicated rotary controls and illuminated buttons for quick and easy
operation
Large LCD display
i7600
Dual 30-Band 1/3 Octave Digital Graphic Equalizer with RTA
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
█
Dual-channel 29-band real-time spectrum analyzer (RTA)
24-bit A/D and D/A converters with 256/512 times over sampling for high
headroom and resolution
Internal 32-bit/44.1 KHz processor
Provides 12 dB of boost or cut
Channel-link function
Stores up to 60 programs: 30 factory-set, 30 user-defined
Selectable unit of measurement for RTA line signal: dBu or dBV
Six view range options for band-level measurement
Six response time options
Peak-hold options: permanent and none
Three weighting options: A weighting, C weighting, and flat
Pink noise generator outputs balanced test signals at 0 dB
Bypass function
Variable low-pass filter (LPF) and high-pass filter (HPF)
Balanced XLR and 1/4" TRS inputs and outputs
Operating levels of +4 dBu and -10 dBV independently selectable for input
and output
780 bright LED indicators
Rack mountable in one rack-space chassis
i7100 / i7300 / i7600 / PPC8000 / PPC9000 / PCR2213
PPC8000
Power Conditioner with Light Modules
█
█
█
█
█
█
█
8 switched outlets on the rear of the unit
Single, unswitched outlet on the front
Two swiveling light fixtures with dimmer switch for rack illumination
RFI / EMI filtering
Circuit Breaker with 15 amp rating
Heavy-duty 14-gauge AC power cord
Triple-mode Varistor spike and surge protection
PPC9000
Power Conditioner with Light Modules
█
█
█
█
█
█
█
█
8 switched outlets on the rear of the unit
Single, unswitched outlet on the front
Two swiveling light fixtures with dimmer switch for rack illumination
RFI / EMI filtering
Circuit Breaker with 15 amp rating
Heavy-duty 14-gauge AC power cord
Triple-mode Varistor spike and surge protection
20-segment, line Voltage meter reading from 90 to 128 VAC
PCR2213
Active Crossover
█
█
█
█
█
█
█
█
█
█
█
█
Stereo 2-way or mono 3-way operation
24 dB/octave Linkwitz-Riley filters with zero phase error at
crossover frequencies
Perfect flat summed amplitude response at all crossover
frequencies
Independent limiters on all outputs with pre-defined time
parameters
Latching mute push Buttons on all outputs, vital during setting up
and troubleshooting
LED indication on all important switching functions for easy status
identification
Crossover frequencies continuously variable from 80 - 8000 Hz
Time/phase alignment via polarity switches and 4 ms time delay
controls
Switchable horn EQ curve to compensate the HF roll-off
RF and Subsonic input filters
High precision components and potentiometers ensure excellent
quality and accuracy of settings
Balanced XLR inputs and outputs
31
APPENDIX
Appendix I: Sonic Station Mixers
Sonic Station 16
Sonic Station 22
Sonic Station 32
24
30
40
16
20
30
Mic
16
18
28
Line
Total Inputs
Outputs
4
6
6
Stereo*
-
1
1
Talkback Mic
√
-
-
Mini Stereo
1
3
3
Stereo RCA
1/4" TRS
5
12
12
3
3
3
XLR
8
18
28
Direct Outs
√
-
-
Mini Stereo
√
√
√
Stereo RCA
√
√
√
Inserts
3-band with swept mid
Channel EQ
Level Meter
DFX
2 x 12-pt
7 x 12-pt
One 16-EFX
Dual DFX
BNC
Lamp Jack
Dimensions
(H x W x D)
440 x 210 x 475 mm
(17.3" x 8.26" x 18.7" )
859 x 102.79 x 547.42 mm
( 33.8" x 4.05" x 21.6" )
1155.5 x 102.79 x 547.42 mm
( 45.5" x 4.05" x 21.6" )
9.5 kg ( 20.9 lbs )
15.5 kg ( 34.1 lbs )
18 kg ( 39.7 lbs )
Weight
*AUX inputs included
Appendix II: MU Mixers
Inputs
Outputs
MU 502
MU 802
MU 1202
MU 1002X
MU 1202X
MU 1722X
MU 1822X
5
8
12
10
12
17
18
MU 2442X
24
1
2
4
2
4
4
8
10
Mic
2
2
4
2
4
5
6
8
Line
Mini Stereo
-
√
-
√
-
√
√
√
4
6
8
8
4
12
12
16
Stereo*
3
5
5
5
7
5
5
6
1/4" TRS
-
-
-
√
-
2
2
2
XLR
-
√
-
√
-
√
√
√
Mini Stereo
Stereo RCA
√
√
√
√
√
√
√
√
Channel EQ
2-band
3-band
3-band
3-band
3-band
3-band
3-band
3-band
Level Meter
2 x 4-pt
2 x 5-pt
2 x 9-pt
2 x 5-pt
2 x 9-pt
2 x 12-pt
2 x 12-pt
2 x 12-pt
-
-
-
16
16
16
16
16
DFX
Dimensions
(H x W x D)
156 x 51 x 244
mm (6.1" x 2" x
8.8")
190 x 56 x 233 275 x 60 x 271 190 x 56 x 233
mm (7.5" x 2.2" mm (10.8" x 2.4" mm (7.5" x 2.2"
x 9.2")
x 10.7")
x 9.2")
245 x 86 x 271 300 x 89 x 340 407 x 89 x 357 418 x 140 x 438
mm (9.7" x 3.4" mm (11.8" x 3.5" mm (16" x 3.5" x mm (16.5" x 5.5"
x 10.7")
x 13.4")
14")
x 17.6")
Weight
1.1 kg (2.4 lbs)
1.5 kg (3.3 lbs)
2.6 kg (5.73 lbs) 4.2 kg (9.25 lbs) 4.8 kg (10.6 lbs)
2.2 kg (4.85 lbs) 1.5 kg (3.3 lbs)
5.9 kg (13 lbs)
*AUX inputs included
Appendix III: Studio Monitors
P5A
P6A
P8A
1
1
1
XLR
1
1
1
1/4" Phone Jack
Amplifier Low
140W
140W
212W
Amplifier High
70W
70W
106W
Woofer Size
5"
6 1/4"
8 3/4"
Tweeter Size
1"
1"
1"
Connectors
8Ω
Nominal Impedance
32
Total
Dimensions
(H x W x D)
295 x 196 x 295 mm
(11.6" x 7.7" x 11.6" )
351 x 221 x 300 mm
( 13.8" x 8.7" x 11.8" )
429 x 269 x 231 mm
( 16.9" x 10.6" x 9" )
Net Weight
5.6 kg ( 12.9 lbs)
8.2 kg ( 18 lbs)
10 kg ( 22 lbs)
Appendix IV: Powerpod Mixers
POWERPOD
620 PLUS
POWERPOD
740 PLUS
POWERPOD
780 PLUS
4
6
7
4
4
7
4
2
2
POWERPOD 410
Inputs
Outputs
POWERPOD
820
POWERPOD
1062 PLUS
POWERPOD
1082 PLUS
7
8
10
10
7
4
9
9
Mic
2
4
4
4
Line (Hi-Z)
Line (Super Hi-Z)
Total
-
2
2
2
-
2
2
-
-
4
4
4
5
5
Stereo*
√
√
√
√
√
√
√
Stereo RCA
1
3
3
3
4
4
4
1/4" TRS
√
√
√
√
√
√
√
Stereo RCA
1/4" Phone Jack
Speaker Outputs
2
5
5
5
4
5
5
Power Amplifier
100W + 100W
100W + 100W
220W + 220W
300W + 300W
100W + 100W
375W + 375W
400W + 400W
4Ω stereo
-
200W
440W
600W
-
750W
800W
8Ω bridge
2 x 7-band
Channel EQ
2-band
3-band
System EQ
-
7-band stereo
-
2 x 8-band
Level Meter
-
2 x 5-pt
2 x 10-pt
5-pt
5-pt
Variable Digital Delay
100+
16
100+
100+
3.2 kg
(7 lbs)
21.5 kg
(47.4 lbs)
22.5 kg
(49.6 lbs)
DFX
Weight
7.4 kg
(16.3 lbs)
12 kg
(26.46 lbs)
15.5 kg
(34.18 lbs)
15.5 kg
(34.18 lbs)
*AUX inputs included
POWERPOD
1860 PLUS
POWERPOD
K-12 PLUS
16
10
Total Inputs
Outputs
POWERPOD
K-16 PLUS
POWERPOD
865 PLUS
POWERPOD
885 PLUS
16
20
12
12
10
12
8
8
Mic
8
8
12
6
6
Line
4
4
4
6
6
Stereo*
2
2
2
√
√
Stereo RCA
Total
6
10
10
7
7
1/4" TRS
√
√
√
√
√
Stereo RCA
4
4
4
5
5
Speakon
2
2
2
2
2
1/4" Phone Jack
400W + 400W
500W + 500W
500W + 500W
300W + 300W
400W + 400W
4Ω stereo
800W
1000W
1000W
600W
800W
8Ω bridge
Wireless Module Slot
-
-
-
√
√
Vocal Elimination
-
-
√
√
√
Feedback Detection
-
√
√
√
√
sPs
-
-
√
√
Speaker Outputs
Power Amplifier
3-band
Channel EQ
√
3-band with swept mids
3-band
System EQ
7-band stereo
3-band
Level Meter
2 x 13-pt
3 x 5-pt
100+
DFX
Dimensions
(H x W x D)
Weight
2 x 100+
100+
483x142.6x466.2 mm
(19" x 5.6" x 18.4")
583x142.6x466.2 mm
(23" x 5.6" x 18.4")
583x142.6x466.2 mm
(23" x 5.6" x 18.4")
475x306x324 mm
(18.7" x 12" x 12.8")
475x306x324 mm
(18.7" x 12" x 12.8")
14.3 kg (31.5 lbs)
14.5 kg ( 31.94 lbs )
19.5 kg ( 42.95 lbs )
11 kg ( 24.2 lbs )
12 kg ( 26.4 lbs )
*AUX inputs included
Appendix V: Sound Ambassador Series
Sound Ambassador Sound Ambassador Sound Ambassador Sound Ambassador Sound Ambassador Sound Ambassador
35 Deluxe
75 Deluxe
40A
40P
80A
80P
Output RMS
Power Handling
(Program)
Frequency Response
35W
75W
35W
-
75W
-
-
-
-
40W
-
150W
60 Hz - 18 kHz
50 Hz - 20 kHz
60 Hz - 18 kHz
60 Hz - 18 kHz
18 Hz - 20 kHz
50 Hz - 18 kHz
Woofer
6.5"
10"
6.5"
6.5"
10"
10"
Tweeter
1"
1"
1"
1"
1"
1"
√
2
√
√
√
√
1/4"
√
√
-
-
-
-
XLR
Mini-stereo
Inputs
Outputs
-
√
-
-
-
-
√
√
√
√
√
√
Line Out
-
2
-
-
√
-
Speaker Out
Mini-stereo
-
√
-
-
-
-
Channel Tone Control
√
√
-
-
-
-
Internal Battery
√
2
√
-
√
-
Optional Accessories
√
√
-
-
-
-
Wireless Mic
√
√
-
-
-
-
CD Player
Dimensions
331 x 230 x 244 mm
( 13" x 9" x 9.6" )
Net Weight
7 kg ( 15.4 lbs )
612 x 300 x 350 mm 336 x 220 x 216 mm
( 24" x 11.8" x 13.8" ) ( 13.2" x 8.7" x 8.5" )
19.5 kg ( 43 lbs )
6.5 kg ( 14.3 lbs )
336 x 220 x 216 mm 612 x 300 x 350 mm 612 x 300 x 350 mm
( 13.2" x 8.7" x 8.5" ) ( 24" x 11.8" x 13.8" ) ( 24" x 11.8" x 13.8" )
4 kg ( 8.8 lbs )
18 kg ( 39.7 lbs)
12 kg ( 26.5 lbs )
33
Appendix VI: Center Series Speakers
Power Handing(RMS)
Frequency Response (Hz)
Center 10
Center 12(M)
Center 15
Center 215
Center 18SB
Center 215SB
200W
300W
400W
600W
500W
600W
Center 218SB
800W
60Hz - 20kHz
55Hz - 18kHz
50Hz - 18kHz
45Hz - 18kHz
35Hz - 200Hz
40Hz -250Hz
40Hz -350Hz
100dB
Sensitivity: 1W,1M
93dB
95dB
96dB
98dB
95dB
96dB
Nominal Impedance
8 ohm
8 ohm
8 ohm
4 ohm
8 ohm
4 ohm
4 ohm
Maximum SPL
122dB
125dB
126dB
129dB
130dB
129dB
131dB
Coverange H° x V°
90 x 50
90 x 50
80 x 50
90 x 60
-
-
-
Crossover modes
Passive
Passive
Passive
Passive
-
-
-
Connectors
2
2
2
2
2
2
2
Speakon
Handles
2
2 ( 12M only one )
2
2
2
2
4
Die-cast
Bottom
Bottom
Bottom
-
Top
-
-
Stand Socket ( 35mm)
Dimensions(HxWxD )
520x330x330mm
610x380x380mm
740x450x450mm 1160x500x500mm 690x560x600mm 500x982x510mm 1080x574x780mm
610x350x350mm(12M)
Appendix VII : XP Amplifiers
Continuous Power Output
XP 1000
XP 2000
XP 3000
560W + 560W
960W + 960W
1400W + 1400W
1120W
1920W
2800W
2800W
5000W
5000W
√
√
√
√
√
√
√
√
√
√
√
√
1/4"
­
­
­
­
√
√
Barrier Strip
√
√
√
√
√
√
Binding Posts
√
√
√
√
√
√
Speakon®-type
XLR
Inputs
Outputs
Subwoofer Output
XP 3100
XP 5000
XP 5100
1400W + 1400W 2500W + 2500W 2500W + 2500W
­
­
­
√
­
√
-
-
-
√
-
√
2Ω stereo
4Ω bridge
XLR
20 Hz - 20 kHz, 0/-1 dB; -3 dB points: 5 Hz - 100 kHz
Frequency Response
40 x (32 dB)
Gain
High Pass Filter (30Hz, 50Hz)
√
√
√
√
√
√
Low Pass Filter (60Hz, 90Hz, 120Hz)
-
-
-
√
-
√
>500
20 kΩ balanced, 10 kΩ unbalanced
Input Impedance
Damping Factor @ 8 Ω
>2000
>500
>500
>500
>500
Size (rack space units)
2
3
3
3
3
3
28.2 kg (62 lbs)
28.2 kg (62 lbs)
17.5 kg (38.5 lbs) 21.8 kg (48 lbs) 24.2 kg (53.3 lbs) 24.2 kg (53.3 lbs)
Weight
Appendix VIII: MAX Amplifiers
Continuous Power Output
Inputs
Outputs
MAX 250
MAX 500
MAX 860 PLUS
MAX 1500 PLUS
80W + 80W
120W + 120W
300W + 300W
450W + 450W
750W + 750W
60W + 60W
90W + 90W
200W + 200W
280W + 280W
500W + 500W
8Ω stereo
-
-
600W
900W
1500W
8Ω bridge
√
√
√
√
√
XLR
√
√
√
√
√
1/4" Jacks
-
-
√
√
√
Speakon®-type
√
√
√
√
√
Binding Posts
Frequency Response
20 Hz - 20 kHz, +0/-1 dB
Input Impedance
20 kΩ balanced, 10 kΩ unbalanced
Protection
Gain
Size (Rack Units)
Net Weight
34
MAX 2500 PLUS
Short circuit, thermal, subsonic, RF protection, output DC offset, power on/off muting
41 x (30 dB)
41 x (30 dB)
32 x (30 dB)
40 x (30 dB)
1
1
2
2
50 x (30 dB)
2
6.7 kg (14.8 lbs)
7.85 kg (17.3 lbs)
14.6 kg (32.2 lbs)
15.5 kg (34.2 lbs)
18 kg (39.7 lbs)
4Ω stereo
Appendix IX: Nexus Series Speakers
Nexus A915SB
Nexus A935SB
400W + 50W
250W + 100W x 2
Output RMS
38 Hz - 150 Hz
38 Hz - 150 Hz
Woofer
15"
15"
Tweeter
-
-
Inputs
-
√
XLR
√
√
1/4" Phone Jacks
Frequency Response
Output
XLR
√
√
-
2 x Powered
1/4" Phone Jacks
20k Ω balanced ; 10k Ω unbalanced
Impedance
­5 0 - 0 dB on input
Sensitivity
98 dB
123 dB
< 30 kg (66 lbs)
< 30 kg (66 lbs)
Max SPL @ 1M
Net Weight
Appendix X: Impression Plus Speakers
Impression 12 Plus
Impression 15 Plus
Impresion 215 Plus
Impression 15SB Plus
250W
300W
600W
500W
700W
RMS
500W
600W
1200W
1000W
1400W
Program
Power Handling
Impression 18SB Plus
Woofer
12"
15"
2 x 15"
15"
18"
Tweeter
1 3/4"
1 3/4"
1 3/4"
-
-
2
2
2
2
2
1/4" Phone Jacks
2
2
2
2
2
Speakon
Sensitivity @ 1 W / 1 M
96 dB
97 dB
100 dB
97 dB
99 dB
Frequency Response
55 Hz - 20 kHz
48 Hz - 20 kHz
40 Hz - 20 kHz
38 Hz - 250 Hz
33 Hz - 250 Hz
90 x 60°
90 x 60°
90 x 60°
-
-
8Ω
8Ω
4Ω
4Ω
4Ω
600 x 38 x 340 mm
(23.6" x 15" x 13.4")
660 x 465 x 370 mm
(26" x 18.3" x 14.6")
42.7" x 19.1" x 18.7"
(1085 x 485 x 475 mm)
632 x 464 x 445 mm
(24.9" x 18.3" x 13.2")
860 x 680 x 465 mm
(33.9" x 26.8" x 18.3")
16.2 kg (35.7 lbs)
19.7 kg (43.4 lbs)
38.5 kg (84.8 lbs)
26.5 kg (58.4 lbs)
45.2 kg (101 lbs)
Input Connectors
Dispersion Angle
Nominal Impedance
Dimensions
(H x W x D)
Weight
Appendix XI: SEM Plus Speakers
Power Capacity
SE M 710 Plus
SE M 71 2 Plus
SE M 715 Plus
SE 72 5 Plus
15 0W
175 W
23 0W
4 0 0W
RMS
3 0 0W
3 5 0W
4 6 0W
8 0 0W
Pro gram
Woofer
10 "
12 "
15"
2 x 15"
Twee ter
Piezo
Piezo
Piezo
Piezo
2
2
2
1
9 6 dB
9 5 dB
9 8 dB
10 0 dB
Conne c tor s
Sensitivity @ 1 W / 1 M
Ma x SPL
Fr e quency Re sponse
-
-
-
-
6 5 Hz - 20 kHz
6 0 Hz - 20 k Hz
5 0 Hz - 20 k Hz
4 0 Hz - 20 k Hz
Built- in Cr ossover
√
√
√
√
D isper sion Angle
90 x 40°
90 x 40°
90 x 40°
90 x 40°
8Ω
8Ω
8Ω
4Ω
D imensions
(H x W x D)
491 x 3 51 x 3 41 mm
(19. 3 " x 13. 8 " x 13.4")
5 4 0 x 376 x 3 5 6 mm
(21. 3 " x 14. 8 " x 14")
679 x 476 x 3 8 8 mm
(26.7 x 18 .7 " x 15. 3 ")
10 8 5 x 476 x 3 8 8 mm
(42 .7 " x 18 .7 " x 15. 3 ")
Ne t Weight
11 kg (24.7 lbs)
13 kg (28 .6 lbs)
19 kg (4 0. 5 lbs)
32 . 5 kg ( 71. 8 lbs)
Nominal Impedance
1/4" Phone Jac k
35
INDEX
Center 10.....................................................23, Appendix VI
PM801 …………….............…......…..............................…....9
Center 12.....................................................23, Appendix VI
Powerpod 410……….................................…15, Appendix IV
Center 12M..................................................23, Appendix VI
Powerpod 620 Plus…................................…15, Appendix IV
Center 15.....................................................23, Appendix VI
Powerpod 740 Plus…................................…15, Appendix IV
Center 215...................................................23, Appendix VI
Powerpod 780 Plus…...................................16, Appendix IV
Center 18SB................................................23, Appendix VI
Powerpod 820…...........................................16, Appendix IV
Center 215SB..............................................23, Appendix VI
Powerpod 865 Plus…...............................…16, Appendix IV
Center 218SB..............................................23, Appendix VI
Powerpod 885 Plus......................................16, Appendix IV
DYN2000………..........................................................……30
Powerpod 1082 Plus.....................................17, Appendix IV
Firefly 302 Plus…….......................................………………..3
Powerpod 1062 Plus….................................17, Appendix IV
Firefly 302 USB………...................................………………..3
Powerpod 1860 Plus.…................................17, Appendix IV
Firefly 808………………..................................….…………...2
Powerpod K-12 Plus................................…..18, Appendix IV
Firefly 808 Universal…...................................….…………...2
Powerpod K-16 Plus…..................................18, Appendix IV
GEQ1500………………......................................................30
PPC 8000…..........................................................…...……31
GEQ3100…………………...................................................30
PPC 9000…..............................…......….........................…31
Helix Board 12 Plus…................................................……...7
RoadGear 160 Plus……...................................…………….29
Helix Board 12 FireWire MKII….................................……...7
RoadGear 260 Plus……………...................................…….29
Helix Board 12 Universal…........................................……...7
SE206………….…...................................................……….25
Helix Board 18 FireWire MKII…….................................…...7
SE207…………...................................................…………..25
Helix Board 18 Universal……........................................…...6
SE725 Plus...................................…………..24, Appendix XI
Helix Board 24 FireWire MKII…….................................…...6
SEp206………….....................................................……….25
Helix Board 24 Universal……........................................…...6
SEp207…………................................................…….....….25
i7100…………..............……….......…............................…...31
SEM 710 Plus..........................................….24, Appendix XI
i7300……….........……...............…...............................…...31
SEM 712 Plus..........................................….24, Appendix XI
i7600…………………….......................................................31
SEM 715 Plus..........................................….24, Appendix XI
iA231F…………………….................................................…30
Sonic Station 16……........................................8, Appendix I
ICON 300……................................................................….19
Sonic Station 22……….................................…8, Appendix I
ICON 700……................................................................….19
Sonic Station 32………….................................8, Appendix I
Impact 8.4X.......................................................................10
Sound Ambassador 35 Deluxe…...............…28, Appendix V
Impact 12.4X.....................................................................10
Sound Ambassador 75 Deluxe…..................28, Appendix V
Impact 16.4X.....................................................................10
Sound Ambassador 40A…............................28, Appendix V
Impact 24.4X.....................................................................10
Sound Ambassador 40P…............................28, Appendix V
Impression 12 Plus........................................24, Appendix X
Sound Ambassador 80A…............................28, Appendix V
Impression 15 Plus.......................................24, Appendix X
Sound Ambassador 80P…............................28, Appendix V
Impression 15SB Plus...................................24, Appendix X
Summit................................................................................1
Impression 18SB Plus...................................24, Appendix X
UM 30……................................................................……..27
Impression 215 Plus...................................24, Appendix X
UM 31……..........................................................…......…..27
KA920……………..….........................................................18
UM 40……................................................................……..27
MAX 250……..........................................…21, Appendix VIII
UM 41…….................................................................……..27
MAX 500……..........................................…21, Appendix VIII
UM 50……................................................................……..27
MAX 860 Plus.........................................…21, Appendix VIII
UM 51…….................................................................……..27
MAX 1500 Plus.......................................…21, Appendix VIII
Versatap 30……......………….....................................…….25
MAX 2500 Plus.......................................…21, Appendix VIII
Versatap 50…………...........……................................…….25
MU 502........................................…..........…...11, Appendix II
W5......................................................................................26
MU 802................................................……...11, Appendix II
WM-40…...........................................................................26
MU 1002X............................................……...11, Appendix II
WM-60…...........................................................................26
MU 1202...............................................……...11, Appendix II
WM-70…...........................................................................26
MU 1202X............................................……...12, Appendix II
WM-400….........................................................................26
MU 1722X............................................……...12, Appendix II
WM-SYS3…......................................................................26
MU 1822X............................................……...12, Appendix II
WM-SYS4…......................................................................26
MU 2442X…….....................................……...12, Appendix II
XP 1000…..........................................……20, Appendix VII
Nexus A915SB………….....….......….............22, Appendix IX
XP 2000…….........................................……20, Appendix VII
Nexus A935SB............................................22, Appendix IX
XP 3000……............................................…20, Appendix VII
P5A……………………….........................…….25,Appendix III
XP 3100…….........................................……20, Appendix VII
P6A……………………....................................25,Appendix III
XP 5000…….........................................……20, Appendix VII
P8A……………………....................................25,Appendix III
XP 5100…….........................................……20, Appendix VII
PAA3…………………….....…...............................……..……13
ZX2 Plus…………….......................................…..….………..9
PA A6…………………….....…...............................……..……14
ZX4 Plus……………………..........................................……..9
PCR2213………...............…...............................……..……31
36
QUESTIONS ?
Email: [email protected]
WANT TO BUY ?
Find a local Phonic reseller at http://www.phonic.com/where/?ssolang=en
or email: [email protected]
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
