English
Congratulations on your purchase and
welcome to Philips!
To fully benefit from the support that
Philips offers, register your product at
www.philips.com/welcome.
Supplied Accessories
– AC power cord
17:20
Page 9
Controls/Power Supply
Back/bottom panel (See 1
and 2)
9 Source selector: CD, FM, AM, OFF
– selects CD or radio source of sound
– power off switch
0 Telescopic antenna
- improves FM reception.
! AC MAINS~ - inlet for power cord.
Top/front panels (See 1)
1 VOLUME – adjusts volume level.
2 SHUFFLE – plays all tracks in random order
3 REPEAT – repeats a track/
CD program/entire CD.
4 2 ; – starts or pause CD playback
§ ∞ – selects the next/previous track
– searches forwards/backwards (press and
hold the button) within the current track
9 – stops CD playback;
– erases a CD program
5 PROG
– programs tracks and reviews the program
6 LIFT TO OPEN
– opens/closes the CD door.
7 TUNING – tunes to radio stations
8 Display – shows the CD functions
@ DBB – turns the bass enhancement on/off.
# LINE-IN – inlet for external audio source.
$ Battery door
– Press on the arrow and push to insert 6 x
1.5V R-14/ UM-2/ C-cells.
CAUTION
– Use of controls or adjustments or
performance of procedures other than
those specified herein may result in
hazardous radiation exposure.
– (Invisible) Laser Radiation when
open. DO NOT STARE INTO BEAM.
– Use of controls or adjustments or
performance of procedures other than
herein may result in unsafe operation.
– Visible and invisible laser radiation. If the cover is open, do not look
at the beam.
– High voltage! Do not open.You
run the risk of getting an electric
shock.The machine does not contain
any user-serviceable parts.
– Modification of the product
could result in hazardous radiation
of EMC or other unsafe operation.
AZ102C/S/N_37_UM_V2.0_EN
2010.4.16
17:20
Power Supply
Power Supply
Whenever convenient, use the power supply
cord if you want to conserve battery life.
Make sure you remove the plug from the set
and wall outlet before inserting batteries.
General Operation
4
Install the unit near the AC outlet and where
the AC power plug can be easily reached.
•
Disconnect the power cord from the wall
socket to protect your set during heavy
thunderstorms. Children could seriously injure
themselves as the free end of the cable may
still be live if only the connector is removed
from the MAINS socket at the back of the
unit.
Batteries (not included)
1
2
•
•
•
•
•
Open the battery door and insert 6 batteries,
type R-14, UM-2 or C-cells, (preferably
alkaline) with the correct polarity as indicated
by the "+" and "–" symbols inside the
compartment.
Replace the battery door, making sure the
batteries are firmly and correctly in place.The
set is now ready to operate.
Batteries contain chemical substances, so
they should be disposed of properly.
Incorrect use of batteries can cause electrolyte
leakage and will corrode the compartment or
cause the batteries to burst:
Do not mix battery types: e.g. alkaline with
carbon zinc. Only use batteries of the same type
for the set.
When inserting new batteries, do not try to mix
old batteries with the new ones.
Remove the batteries if the set is not to be used
for a long time.
Perchlorate Material-special handling may apply.
See
www.dtsc.ca.gov/hazardouswaste/perchlorate.
Using AC power
WARNING: Always check you have
completely switched off the set, before
you change or disconnect power supply.
1
Check if the power voltage, as shown on
the type plate located on the bottom
of the set, corresponds to your local power
supply. If it does not, consult your dealer or
service center.
2
Connect the power cord to the AC
MAINS~ inlet and the wall socket.The set is
now connected and ready for use.
3
To switch the set off completely, withdraw the
power cord from the wall socket.
Page 10
The type plate is located on the bottom
of the set.
Helpful hints:
–
To avoid unnecessary energy consumption,
always adjust the Source selector to OFF
after using the set.
General operation
1
Switching on and off and selecting the
function
To select your sound source, adjust the
Source selector to: CD, FM or AM.
2
To switch off the set, adjust the Source
selector to OFF position.
3
To switch to LINE IN mode, connect an
external audio source to the LINE-IN inlet.
Helpful hints:
•
The set switches to LINE IN mode
automatically when an external audio source
is connected, no matter the set is in CD, FM
or AM mode.
•
The LINE-IN inlet is not for earphones.
Adjusting volume and sound
Adjust the sound with the VOLUME and
DBB controls.
AZ102C/S/N_37_UM_V2.0_EN
2010.4.16
17:20
Page 11
Tuner
CD Player
Radio reception
1
Adjust the Source selector to FM or
AM.
2
Turn TUNING to tune to a station.
Playing a CD
•
This CD player plays Audio Discs including
CD-Recordables (CD-R) and CD-Rewritables
(CD-RW).
•
MP3, CD-ROM, CD-I, CDV,VCD, DVD or
computer CDs are not possible for playback.
Helpful hints:
To improve radio reception
•
For FM, extend, incline and turn the
telescopic antenna for best reception. Reduce
its length if the signal is too strong.
•
For AM, the set uses a built-in antenna. Direct
this antenna for best reception by turning the
whole set.
IMPORTANT!
CDs encoded with copyright protection
technologies by some record companies may
be unplayable by this product.
1
Adjust the Source selector to CD.
2
Open the CD door, and insert a CD with
the printed side facing up, then press the CD
door gently to close.
➜ Display shows --, and later the total
number of tracks. (See 3)
3
4
Press 2; to start playback.
To pause playback, press 2;.
➜ Display: 2 flashes. (See 4)
5
To resume, press 2; again.
6
To stop CD playback, press 9.
Helpful hints:
CD play will also stop when:
–
you open the CD door;
– you select FM, AM or OFF sound source;
– the CD has reached the end.
AZ102C/S/N_37_UM_V2.0_EN
2010.4.16
17:20
Page 12
CD Player
Selecting a different track
• Press ∞/ § once or repeatedly until the
desired track number appears in the display.
• In the pause/stop position, press 2; to start
playback.
Finding a passage within a
track
1
2
During playback, press and hold ∞ or § .
➜ The CD is played at high speed and with
reduced volume.
When you recognize the passage you want,
release ∞ or § to resume normal playback.
Helpful hints :
– When playback of your program comes
to the stop position, your set will return
to normal playback.To re-enter program
mode, press PROG in the stop position.
Reviewing the program
In the stop position, press PROG repeatedly
to see your stored tracks.
Erasing a program
You can erase the contents of the memory
by:
Helpful hints:
– in the stop position, press PROG to enter
program mode, and then press 9.
– When your searching reaches the end of the
– selecting FM, AM or OFF;
last track, the CD goes to stop mode.
Programming track
numbers
You may store up to 20 tracks in the desired
sequence. If you like, store any track more
than once.
1
In the stop position, press PROG to
activate programming.
➜ Display: PROG and 00 flash. (See 5)
2
Press ∞ or § to select your desired track
number.
3
Press PROG to store the desired track
number.
➜ Display: PROG and 00 flash for you to
program the next track..
4
Repeat steps 2 to 3 to select and store all
desired tracks in this way.
➜ If you attempt to store more than 20
tracks, no track can be selected and the
display shows --.
5
To play your program, press 2/;.
– opening the CD door;
AZ102C/S/N_37_UM_V2.0_EN
2010.4.16
CD Player
Different play modes:
REPEAT. and SHUFFLE
(See 6, 7)
REPEAT
You can play the current track or the whole
disc repeatedly, and combine REPEAT
modes with PROG (PROGRAM).
REP – plays the current track continuously.
REP ALL – repeats the entire CD/program
1
2
3
To select play mode, press REPEAT once or
more.
➜ The display shows REP icon or REP
ALL icon.
Press 2; to start playback if in the stop/pause
position.
To return to normal playback, press REPEAT
repeatedly until the modes are no longer
displayed.
– You can also press 9 to cancel your play
mode.
SHUFFLE
You can play all the tracks in random order.
1
2
In the stop position, press SHUFFLE to
switch on shuffle play.
➜ Display shows SHUFFLE icon.
To switch off shuffle play, press 9.
Helpful hints:
– During the shuffle play, when REP function is
selected, it will play the current shuffled track
repeatedly, or when the REP ALL function is
selected, it will repeat the shuffle play of the
entire CD.
17:20
Page 13
AZ102C/S/N_37_UM_V2.0_EN
2010.4.16
Maintenance & Safety
17:20
Page 14
(See 8)
CD player and CD handling
•
If the CD player cannot read CDs correctly,
use a cleaning CD to clean the lens before
taking the set to repair.
•
The lens of the CD player should never be
touched!
•
Sudden changes in the surrounding
temperature can cause condensation on the
lens of your CD player. Playing a CD is then
not possible. Do not attempt to clean the
lens but leave the set in a warm environment
until the moisture evaporates.
Safety information
•
Place the set on a flat, hard and stable surface
so that the system does not tilt.
•
Where the MAINS plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable.
•
Do not expose the set, batteries, CDs to
humidity, rain, sand or excessive heat caused
by heating equipment or direct sunlight.
•
The apparatus shall not be exposed to dripping or splashing.
•
Adequate ventilation with a minimum gap of
15cm (6 inches) between the ventilation
holes and surrounding surfaces is necessary
to prevent heat build-up.
•
Always close the CD door to avoid dust on
the lens.
•
To clean the CD, wipe in a straight line from
the center towards the edge using a soft,
lint-free cloth. Do not use cleaning agents as
they may damage the disc.
•
Do not cover the ventilation openings with
items such as newspapers, table-cloths, curtains, etc.
Never write on a CD or attach any stickers
to it.
•
No objects filled with liquids, such as vases,
shall be placed on the apparatus.
•
No naked flame sources, such as lighted candles, should be placed on the apparatus.
•
The mechanical parts of the set contain selflubricating bearings and must not be oiled or
lubricated.
•
To clean the set, use a dry cloth. Do not use
any cleaning agents containing alcohol, ammonia, benzene or abrasives as these may harm
the housing.
•
Batteries (battery pack or batteries installed)
shall not be exposed to excessive heat such
as sunshine, fire or the like.
•
AZ102C/S/N_37_UM_V2.0_EN
2010.4.16
17:20
Page 15
Troubleshooting
If a fault occurs, first check the points listed below before taking the set for repair.
If you are unable to remedy a problem by following these hints, consult your dealer or service centre.
WARNING: Do not open the set as there is a risk of electric shock. Under no
circumstances should you try to repair the set yourself, as this will
invalidate the guarantee.
Problem
--, Er or 01 indication
– Possible cause
• Remedy
–
•
–
•
–
•
–
•
No sound /power
–
•
–
•
–
•
–
•
Volume not adjusted
Adjust the VOLUME
Power cord not securely connected
Connect the AC power cord properly
Batteries dead/ incorrectly inserted
Insert (fresh) batteries correctly
CD contains non-audio files
Press ∞ , § once or more to skip to a CD audio
track, instead of the data file.
Display does not function properly / No
reaction to operation of any of the
controls
– Electrostatic discharge
• Switch off and unplug the set. Reconnect after a
few seconds
No CD inserted
Insert a CD
CD badly scratched or dirty
Replace/ clean CD, see Maintenance
Laser lens steamed up
Wait until lens has cleared
CD-R/CD-RW is blank or not finalized
Use a finalized CD-R/CD-RW or suitable CD
Audio disc only
Note:
Make sure the CD is not encoded with copyright protection technologies, as some do not
conform to the Compact Disc standard.
The CD skips tracks
–
•
–
•
CD damaged or dirty
Replace or clean CD
Program/shuffle is active
Quit program/shuffle mode
Note: A CD badly scratch or dirty may result in
improper operation.
AZ102C/S/N_37_UM_V2.0_EN
2010.4.16
17:20
Page 16
Environmental information
All unnecessary packaging material has been omitted.The packaging can be easily separated
into three materials: cardboard, polystyrene and plastic.
Your set consists of materials which can be recycled if disassembled by a
specialized company. Please observe the local regulations regarding the
disposal of packaging, dead batteries and old equipment.
Your product is designed and manufactured with high quality materials and components,
which can be recycled and reused.
Never dispose of your product with other household waste. Please inform yourself about
the local rules on the separate collection of electrical and electronic products and batteries.
The correct disposal of these products helps prevent potentially negative consequences on
the environment and human health.
Your product contains batteries, which cannot be disposed of with normal household
waste. Please inform yourself about the local rules on separate collection of batteries.The
correct disposal of batteries helps prevent potentially negative consequences on the environment and human health.
Please visit www.recycle.philips.com for additional information on a recycling center in your
area.
Removal of the built-in battery invalidates the warranty and may destroy the product.
Specifications
Power consumption...............................................≤ 15W
Dimensions.......................290 x 143 x 240 (mm)
Weight ..........................................................................1,62 kg
AZ102C/S/N_37_UM_V2.0_EN
2010.4.16
17:20
Page 17
Philips Consumer Lifestyle
A division of Philips Electronics North America Corporation
P.O. Box 10313
Stamford, CT 06904
Phone: 1-888-PHILIPS (744-5477)
Meet Philips at the Internet
http://www.philips.com/welcome
W
AZ102C
AZ102S
AZ102N
CLASS 1
LASER PRODUCT
Printed in China
AZ102C/S/N_37_UM_V2.0
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
