BICYCLE
WARNING
THIS MANUAL CONTAINS IMPORTANT SAFETY,
PERFORMANCE AND SERVICE INFORMATION.
Read it before you take the first ride on your new
bicycle, and keep it for reference.
CONGRATULATIONS ON YOUR PURCHASE OF A
CANNONDALE BICYCLE.
our products:
1. We think riding a bike is fun! Which means all of us at Cannondale are lucky enough to
do what we enjoy. You’ll see that dedication to our craft in every bicycle we make.
2. Our dedication to craft includes dreaming up new ways to pioneer improvements for the
industry – things like System Integration and the BB30 Standard. Later, other manufacturers
often “borrow” our ideas, but that’s okay. After all, more people on bikes is good for everyone.
3. Because bike riding is so much fun, we encourage you to partake whenever the whim
strikes you: Going to the grocery store, going to work, going to school, or wherever you
go. Bikes are serious transportation, in addition to being outrageously good fun.
4. To keep your bike in top condition and to minimize risk, please read this manual before
your first ride and refer to this manual whenever you have questions about its operation.
5. We encourage you to visit your local Independent Bike Dealer. Many of us had our first jobs in
bike shops, and your local Cannondale dealer is an important source of information for you.
Use of this manual
Other Manuals & Instructions
Many of the components on your bike were not
made by Cannondale. When available from the
manufacturer, Cannondale packages these manuals
and/or instructions with our bikes for delivery to you.
We strongly recommend that you read and follow
all the manufacturer’s specific instructions included
with your bike.
Cannondale Bicycle Owner’s Manual
This manual contains important information
affecting your safety and the proper use of bicycles.
It is a very important manual for every bike we make.
It is organized into two parts:
Authorized Cannondale Retailers
Your local Authorized Cannondale Retailer is your
primary contact for service and adjustment of your
bicycle, instruction in its use, and any warranty
questions.
PART I
Is a generic guide to the proper function and use
of bicycles. This generic information is used by
many bike companies. Most aspects of bicycles are
common or “generic.” PART I of this manual is the
10th edition of the generic manual.
Your new bike is to be delivered by a Authorized
Cannondale Retailer to you in a completely
assembled and properly adjusted condition,
complete with all required safety equipment,
Owner’s Manuals, any Cannondale Owner’s Manual
Supplements, and the available manufacturer’s
instructions (shipped by Cannondale) for parts and
components for your bike.
PART II
Contains information specific to Cannondale bicycles
and topics we feel you need to know and understand
about our bikes.
To find the Cannondale retailer closest to you, call
1-800-THE-BIKE-USA, or use our website dealer
locator at www.cannondale.com.
A manual alone cannot teach you how to ride, and a
manual the size of an encyclopedia could not cover
every combination of bicycle, rider and conditions.
Thus, as a reasonable person would expect, the
Cannondale manuals and supplements focus on the
bicycle, not teaching you to ride.
Use Only Genuine Replacement Parts
It is important to your safety and the performance
of your Cannondale bicycle that you use only
genuine Cannondale replacement parts in Headshok
and Lefty forks, Cannondale swingarms and rear
suspension assemblies, derailleur hangers and other
frame hardware.
This manual is not intended as a comprehensive use,
service, repair or maintenance manual. It contains
no assembly instructions. This manual is not a
service manual for any parts of your bike. Please see
your dealer for all service, repairs or maintenance.
Your dealer may also be able to refer you to classes or
books on bicycle use, and maintenance.
These parts are described in Owners Manual
Supplements. This note does not apply to widely
used generic bicycle components such as derailleurs.
Owner’s Manual Supplements
Cannondale Owner’s Manual Supplements are
“supplements” to this manual providing important
additional model specific safety, maintenance, and
technical information. Cannondale Owner’s Manual
Supplements are not replacements for this or any
other manual for your bike.
You can download Adobe Acrobat PDF versions of
any Cannondale Owner’s Manual or Owner’s Manual
Supplements or Tech Notes from our website. Go to:
http://www.cannondale.com.
1
131264 (01/14)
