Linksys NMH300 Specification

Key Features
Key Features:
Drive Bay Cover:
Protects the two drive bays, pre-installed
with one SATA hard drive - add another
for more protection or increased storage.
NMH405
NMH410
LCD Display:
Full-color LCD screen lets you initiate
backups, see alerts, check on hard drive
usage, view the status of the Media Hub,
and more.
Navigation Pad:
Navigate easily through the LCD menus.
• Automated Backup: Finds and saves your files periodically.
• Expandability: Increased storage capacity when additional SATA
hard drives are purchased. Up to 2TB capacity achievable.
• PC/Mac Interface: Easy to use at home or on the go.
• Intelligent Aggregation: Finds and backs up files across your
network.
• HD Streaming: Delivers up to 3 high-def video streams simultaneously.
• Built-in Media Reader: Reads your memory cards for direct storage
(NMH400 Series only).
• Full-color LCD: At-a-glance view of your storage space (NMH400
Series only).
Protect your memories. Share your moments.
Power Button on LED:
The Power LED flashes blue when the
Media Hub boots up, installs a disk, or
shuts down.
Memory Card Slots:
Insert CompactFlash, Secure Digital (SD),
MMC, xD or MS card to access files.
USB Port:
Expand your storage or import more media content
without a computer.
NMH300
NMH305
Drive Bay Cover:
Protects the two drive bays, pre-installed
with one SATA hard drive - add another
for more protection or increased storage.
Disk1/Disk2:
LED flashes when disk is ready for use.
Back Up Buttons (Windows XP or Vista
only):
Initiate backup jobs.
Power Button on LED:
The Power LED flashes blue when the
Media Hub boots up, installs a disk, or
shuts down.
USB Port:
Expand your storage or import more
media content without a computer.
Learn more inside.
NMH300 - Media Hub
NMH305 - Media Hub
NMH405 - Media Hub
with LCD
NMH410 - Media Hub
with LCD
Ports
One Power, One Gigabit
Ethernet (10/100/1000),
Two USB 2.0
Ports
One Power, One Gigabit
Ethernet (10/100/1000),
Two USB 2.0
Ports
One Power, One Gigabit
Ethernet (10/100/1000),
Two USB 2.0
Buttons
One Backup, One Reset,
One Power
Buttons
Five Navigation, One Reset,
One Power
Buttons
Five Navigation, One Reset,
One Power
LED
One Power, Two Disk
LED
One Power
LED
One Power
Drive Bays
NMH300 - 2 (none occupied)
NMH305 - 2 (one occupied)
LCD Display
One 1.8”, 176 x 220,
64K Colors
LCD Display
One 1.8”, 176 x 220,
64K Colors
Drive Bays
2 (one occupied)
Drive Bays
2 (one occupied)
Storage
One 500GB Drive Installed
Storage
One 1TB Drive Installed
Dimensions
4.37” x 7.8” x 6.61”
(WxHxD)
Dimensions
4.37” x 7.8” x 6.61”
(WxHxD)
Storage
NMH300 - None installed
NMH305 - One 500GB Drive
Installed
Dimensions
4.37” x 7.8” x 6.61”
(WxHxD)
FREE SETUP
SUPPORT
Our highly trained,
award-winning support
technicians will walk you
through every step.
Phone number inside package.
You will not be charged by Cisco for this
service if you call within 30 days of purchase.
Air Vent:
Allows air to circulate
and cool the Media Hub.
Ethernet Ports:
For connection to an
Ethernet network device.
LED flashes with network
activity and connections.
USB Port:
Connects to USB
storage device.
For more information please visit: www.linksysbycisco.com/mediahub
Security Slot:
Attach lock to
help protect
Media Hub
from theft.
1- A period of Remote Access is included from date of activation. Fees may apply thereafter and
are subject to change. Go to www.linksysbycisco.com for further information and details of terms
and conditions applicable to the Remote Access service.
Power Port:
Connects to
power adapter.
3 - Viewing media on a TV requires a UPnP-compatible digital media player.
Meet the Linksys by Cisco Media Hub.
Protect, organize, share and access your irreplaceable files,
throughout your home and wherever you go.1
2- Maximum performance derived from IEEE Standard 802.11 specifications. Actual performance
can vary, including lower wireless network capacity, data throughput rate, range and coverage.
Performance depends on many factors, conditions and variables, including distance from the
access point, volume of network traffic, building materials and construction, operating system
used, mix of wireless products used, interference and other adverse conditions.
Specifications are subject to change without notice. Linksys, Cisco and the Cisco Logo are
registered trademarks or trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and
certain other countries. Other brands and products are the trademarks or registered trademarks
of their respective holders. Copyright © 2009 Cisco Systems, Inc. All rights reserved.
Automatic Backup and Storage
So How Does It Work?
Media Hub makes it easy.
Back up all your important files, across computers in your home, as
often as you choose, so you can feel safe.
1
Connect to your network.
It’s easy to get started and easy to use. Just plug your Media
Hub into your router or modem/router. It’ll find your networked
devices by itself, so there’s nothing else to hook up.
2
Safely store your files.
The Media Hub looks through your network, finds and backs up
your important files. Define how often you want to back up. You
can easily add additional storage for up to 2 Terabytes by adding
another drive to the bay, or connect an external hard drive via USB.
Don’t be fooled by its size
The Media Hub has the capacity to store hundreds of hours of video
and hundreds of thousands of photos and songs depending on your
configuration. Just choose the one that fits your needs, and you can
expand later if needed.
4.37”
It’s so much more than storage.
PC
Media Hub
Your Photos
Safely store hundreds of thousands of photos.
Easily find and view your photos by creating albums or searching
by date, name or most recent.
Wireless Router
Share with friends and family.
Share in slideshow mode and through remote access with any
computer with an Internet connection.1
7.8”
Remote
Access
Load and store at home or on the go.
Away from home? Find a computer and an Internet connection,
and you can upload your photos to your Media Hub just by logging
onto your unique page.1
Laptop
3
Your Music
Get organized.
No more searching all your computers to find just the right track.
The Media Hub finds the music on your network, organizes it by
album or artist, and saves it along with the album art. You can even
see the Media Hub in your iTunes® application.
So anyone in the family can listen to any of your music, all across
the house—on computers, wireless-enabled stereos, or the Linksys
by Cisco Wireless Home Audio system.
Access your music anywhere.1
At a party, at the office—just about anywhere with an Internet
connection. Just log in and start playing.
Your Movies
Stream your photos, movies, and music.
The Media Hub lets you stream or download to all your networked
devices. So you can watch different movies and slideshows in
different rooms of the house on your computer or TV.3
Anywhere Access
Easy web-based interface.
The Media Hub provides an easy, web-based interface for uploading
or downloading data on the go.
All you have to do is visit your personal Media Hub Web page to
access all your files. Or give access to friends and family anywhere
in the world.1
Stream photos and videos to your computer.
Stream through your wireless or wired connection.
On your computer.
The Media Hub can deliver 3 video streams at once. So, show home
movies in the living room, Kung Fu in the kid’s room and comedy for
the teens.
On your TV.
Get out from behind
your desk and get the
family together. The
Media Hub uses your
home router or modem/
router to send movie
files wirelessly2 to your
Xbox 360 or Playstation 3
and on to your TV.3
Laptop
Stream photos and videos to your TV.
Stream photos and videos through a media extender
like a Playstation 3 or Xbox 360.3
Stream music throughout your home.
Stream music through your wireless-enabled stereo
or Wireless Home Audio device.
4
Access your files anywhere.1
The easy-to-use interface is also available online. Just visit
www.ciscomediahub.com and enter your unique login.
Upload and download files all across the world or give the URL
to friends and family so they can see your latest photos or share
your playlists.1
