Webroot SecureAnywhere DNS Protection Admin Guide

Webroot SecureAnywhere DNS Protection Admin Guide
What Is DNS? .................................................................................................................................................................................. 2
Why Is DNS-Based Web Security Needed? ................................................................................................................................... 2
What Is Webroot SecureAnywhere DNS Protection? ...................................................................................................................... 3
Can I Use This For Content Filtering? ........................................................................................................................................... 4
Webroot’s Differentiators ................................................................................................................................................................. 5
SecureAnywhere DNS Protection Is Powered by BrightCloud Threat Intelligence ............................................................................ 5
Single Management Console for Endpoint and SecureAnywhere DNS Protection ............................................................................ 5
FAQs ............................................................................................................................................................................................... 5
Setting Up Webroot SecureAnywhere DNS Protection ........................................................................................................................ 6
Determining the External IP Address ............................................................................................................................................ 6
Setup Information ....................................................................................................................................................................... 6
Defining Policies ............................................................................................................................................................................ 12
Web Overrides ............................................................................................................................................................................... 13
Block / Allow List ...................................................................................................................................................................... 14
Block Page Settings .................................................................................................................................................................. 14
Testing DNS Functionality .............................................................................................................................................................. 15
Installing Certificates ..................................................................................................................................................................... 15
Configuring the Network ................................................................................................................................................................ 16
Testing DNS Filtering ..................................................................................................................................................................... 17
Block Page Returned ................................................................................................................................................................. 17
Browser Test ............................................................................................................................................................................ 17
Appendix ....................................................................................................................................................................................... 19
Setting Up Your Router to Use Webroot SecureAnywhere DNS Protection ..................................................................................... 19
Linksys ..................................................................................................................................................................................... 19
NETGEAR .................................................................................................................................................................................. 19
D-Link ...................................................................................................................................................................................... 19
Asus......................................................................................................................................................................................... 20
TP-Link .................................................................................................................................................................................... 20
Cisco ........................................................................................................................................................................................ 20
Belkin ....................................................................................................................................................................................... 20
Page 1 | © 2017 Webroot Inc. All rights reserved. | Proprietary and Confidential Information
March 31, 2017
Domain Name System (DNS) is the Internet's equivalent of a phone book. It holds domain names, such as google.com, and when queried,
provides information that includes a corresponding IP address. This allows your computer to find the desired site.
Generic DNS servers simply answer DNS requests, but have no way to differentiate between good and bad websites.
Page 2 | © 2017 Webroot Inc. All rights reserved. | Proprietary and Confidential Information
March 31, 2017
Webroot SecureAnywhere DNS Protection is a cloud based security solution that proactively prevents communication between your
network and web-based threats.
Customers who direct their DNS traffic to Webroot SecureAnywhere DNS Protection servers integrated with Webroot BrightCloud Threat
Intelligence can monitor all DNS requests from clients to block responses for sites associated with Malware, Phishing, and Botnets, while
allowing requests for safe sites to proceed. When a request for malicious site is made, the response is blocked.
Page 3 | © 2017 Webroot Inc. All rights reserved. | Proprietary and Confidential Information
March 31, 2017
In addition to protecting against dangerous and fraud-based websites, SecureAnywhere DNS Protection service can also be used for
policy management using web filtering categories such as Adult, Dating. Customers have the option to manage 80 plus categories using
Webroot recommended templated policies or by creating custom policies to suit an organization’s needs.
SecureAnywhere DNS Protection also maintains granular reporting on DNS requests along with category and blocking information for 90
days.
Page 4 | © 2017 Webroot Inc. All rights reserved. | Proprietary and Confidential Information
March 31, 2017

Network level protection at the DNS layer.

Trusted by leading Network and Security Vendors such as F5, Cisco, HP, and their customers.

Largest and most accurate in terms of coverage and efficacy.

Simplicity and ease of use.

Single view of their deployments across multiple sites.

Easy to use template based reporting.

Manage both WSA-B and Webroot SecureAnywhere DNS Protection all from one GSM Portal—Single Pane of Glass!
Is this part of WSA Business?
SecureAnywhere DNS Protection is planned to be sold as an add-on to WSAB, as well as a stand-alone.
What is the primary purpose of SecureAnywhere DNS Protection?
SecureAnywhere DNS Protection protects networks from malicious domains and inappropriate websites by filtering DNS requests, helping
users be secure in a connected world.
What reporting capabilities are available?
A full audit trail of all DNS requests from each site is available for up to 90 days. This includes reporting on the different policy categories
as well as what has been blocked and allowed.
Page 5 | © 2017 Webroot Inc. All rights reserved. | Proprietary and Confidential Information
March 31, 2017
The following describes how to set up Webroot SecureAnywhere DNS Protection.

On the networks that will be using DNS Protection, identify the public IPv4 address used for internet access (WAN IP). An internet
search of My IP generally reveals the appropriate IP address.

These addresses will need to be entered in order for DNS Protection to answer DNS requests, and for logging and filtering to be
provided.

If the network is using a dynamically provided address, the IP address may change if you reboot your router or if your ISP, such as
Comcast, Century Link, etc., makes changes. If this happens, you must look up the newly assigned address and update the entry.

IPv6 is not yet supported.
To set up SecureAnywhere DNS Protection:
1. Go to the GSM console:
https://my.webrootanywhere.com/
2. Log in, using the credentials provided.
Page 6 | © 2017 Webroot Inc. All rights reserved. | Proprietary and Confidential Information
March 31, 2017
3. Webroot SecureAnywhere DNS Protection can be enabled on a per site basis by clicking the Manage button on the far right of the
Sites tab.
The Summary panel displays.
Page 7 | © 2017 Webroot Inc. All rights reserved. | Proprietary and Confidential Information
March 31, 2017
4. Select the DNS tab.
5. Enable/disable Webroot SecureAnywhere DNS Protection by selecting the Enable SecureAnywhere DNS checkbox.
Page 8 | © 2017 Webroot Inc. All rights reserved. | Proprietary and Confidential Information
March 31, 2017
The DNS tab expands.
6. In the IP Address column, add or remove IP addresses, as needed.
Page 9 | © 2017 Webroot Inc. All rights reserved. | Proprietary and Confidential Information
March 31, 2017
7. From the SecureAnywhere DNS Policy drop-down menu, select a policy for that particular IP address.
A default policy is automatically applied to the IP when created. You will also have the ability to choose a separate policy, if the
default is not desired. The service is pre-loaded with two template policies:
SecureAnywhere DNS High Protection – The High Protection policy builds on Medium Policy, but also adds additional filters,
blocking categories such as gambling and hacking. Access to Security, Parental Controls and Questionable (Cheating, Cult, etc.)
sites is restricted.
SecureAnywhere DNS Medium Protection – The Medium Protection Policy includes all Security Risks and adds filtering for
categories that may not be appropriate for the workplace. Access to Security and Parental Controls (Adult, Nude, Porn, etc.)
sites is restricted.
Page 10 | © 2017 Webroot Inc. All rights reserved. | Proprietary and Confidential Information
March 31, 2017
8. When you’re done, click the Save Changes button to apply the policy.
Page 11 | © 2017 Webroot Inc. All rights reserved. | Proprietary and Confidential Information
March 31, 2017
Policies for DNS Protection are managed under the Global Settings tab of the GSM console. Here you will find that policies are broken out
into two tabs:

Endpoint

DNS
As with Endpoint policies, functional static policies are provided.

The Medium Protection Policy includes all Security Risks and adds filtering for categories that may not be appropriate for the
workplace.

The High Protection policy builds on Medium Policy, but also adds additional filters, blocking categories such as gambling and
hacking.

To create custom polices, click the Add button, and create a new policy, or click the Copy button to create a new policy from an
existing one.
Page 12 | © 2017 Webroot Inc. All rights reserved. | Proprietary and Confidential Information
March 31, 2017
Web Overrides and the Block Page configuration are managed under the Web Overrides tab. These are broken out into two sub tabs.

Block / Allow List

Block Page Settings
Page 13 | © 2017 Webroot Inc. All rights reserved. | Proprietary and Confidential Information
March 31, 2017
Under the Block / Allow List tab, custom entries can be added to augment the DNS Protection policies. This is done by adding the specific
domain or subdomain, assigning an action, and then associating it with a specific site or to all sites by using the GSM Global Overrides
selection.
Note that this entry is specific to the domain or subdomain entered. For example, allowing webroot.com does not cover
news.webroot.com. In order to control access to news.webroot.com, a separate entry is required.

The Block Page can be customized for each GSM console; allowing the user to be provided with more information alongside the
standard Webroot messaging to include a logo as well as custom text.

The image size is restricted to 1 MB.

The Content field can be used for custom text such as telephone numbers, websites, and links. For example, you could enter
information such as Please contact your network administrator if you have any questions, and then include the contact method of
your choice.
Page 14 | © 2017 Webroot Inc. All rights reserved. | Proprietary and Confidential Information
March 31, 2017
Once the IP addresses and the policies have been configured, it needs to be confirmed that the servers are responding with appropriate
information. This can be done from an endpoint on the network to be protected.
To test DNS functionality:
1. Open a command prompt.
2. Run NSLookup.
3. Set the server to 45.54.55.54.
4. Check several sites to confirm valid responses.
A successful test looks like the following:
Certificates need to be installed to avoid browser errors when https websites are blocked. Although skipping this step will not stop
filtering, it does avoid certificate errors when an https site is redirected. Certificates can be downloaded from behind a registered IP
address: http://45.54.55.55/download
The certificate needs to be installed to Trusted Root Certification Authorities. This can be done on individual systems or, depending on
your environment, pushed out automatically.
To install a certificate:
1. Click Start, click Start Search.
2. In the Search field, type mmc, and then press Enter.
3. From the File menu, select Add/Remove Snap-in.
4. Under Available snap-ins, click Certificates, and then click Add.
5. Under This snap-in will always manage certificates for, click Computer account, and then click Next.
6. Click Local computer, then click Finish then OK.
7. In the console tree, double-click Certificates.
8. Right-click Trusted Root Certification Authorities.
9. Click Import to import the certificates and follow the steps in the Certificate Import Wizard to add the P7B certificate.
Page 15 | © 2017 Webroot Inc. All rights reserved. | Proprietary and Confidential Information
March 31, 2017
Set the DNS forwarders, in the case of AD, or appropriate router to forward DNS requests to the Webroot SecureAnywhere DNS Protections
servers.
To configure a DNS server to use forwarders using the Windows interface:
1. Open DNS Manager.
2. In the console tree, click the applicable DNS server.
3. On the Action menu, click Properties.
4. On the Forwarders tab, under DNS domain, select a domain name.
5. Under Selected domain's forwarder IP address list, type the IP address of a forwarder, and then click Add.
For more information, you can view the full article here.
DNS1: 45.54.55.54
DNS2: 45.54.55.55
Page 16 | © 2017 Webroot Inc. All rights reserved. | Proprietary and Confidential Information
March 31, 2017
Testing can be done via NSlookup from a system behind a protected IP address. By asking the server to lookup a known blocked page,
instead of receiving the actual IP address, the block page IP will be provided. Alternately, the cache can be flushed from both the server
and the workstation, and then the blocked website can be loaded in a browser.

Flush existing DNS cache – command prompt: ipconfig /flushdns.

Using a web browser, confirm the internet is available by browsing to an unfiltered site.

Test the filtering by opening a blocked https site such as https://www.webroot.com when running a policy with the Business /
Government / Services selected.
In this instance, your custom Block Page should display without certificate errors. If you see a certificate error, review the Installing
Certificates section of this document.
Page 17 | © 2017 Webroot Inc. All rights reserved. | Proprietary and Confidential Information
March 31, 2017

SecureAnywhere DNS Protection provides Dashboard, On-Demand, and Scheduled Reporting. This can be accessed by navigating to
Reports Tab. For more information, see Generating On-Demand Reports.
Page 18 | © 2017 Webroot Inc. All rights reserved. | Proprietary and Confidential Information
March 31, 2017
Changing the DNS server settings on your router isn't that difficult, but every manufacturer uses their own custom interface, meaning the
process can be very different depending on the router you own.
1. Sign in to your Linksys router's web-based administration, usually http://192.168.1.1.
2. From the top menu, tap or click Setup.
3. From the Setup submenu, tap or click Basic Setup.
4. In the Static DNS 1, enter the primary DNS server you'd like to use.
5. In the Static DNS 2 field, enter the secondary DNS server you'd like to use.
6. The Static DNS 3 field can be left blank, or you can add a primary DNS server from another provider.
7. At the bottom of the screen, tap or click the Save Settings button.
8. On the next screen, tap or click the Continue button.
1. Sign in to your NETGEAR router manager page, most often via http://192.168.1.1 or http://192.168.0.1.
2. NETGEAR has two major interfaces with different ways of performing the next step:
If you have a Basic and Advanced tab along the top, select the Basic tab followed by selecting the Internet option on the left.
If you don't have those two tabs along the top, select Basic Settings.
3. Under the Domain Name Server (DNS) Address section, select Use These DNS Servers.
4. In the Primary DNS field, enter the primary DNS server you'd like to use.
5. In the Secondary DNS field, use the secondary DNS server you'd like to use.
6. If your NETGEAR router gives you a Third DNS field, you can leave it blank or choose a primary DNS server from another provider.
7. Tap or click Apply to save the DNS server changes you just entered.
8. Follow any additional prompts about restarting your router. If you don't get any additional prompts, your changes should be now be
live.
1. Sign in to your D-Link router using http://192.168.1.1.
2. On the left side of the page, select the Internet option.
3. From the top of the page, select the Setup menu.
4. Find the Dynamic IP (DHCP) Internet Connection Type section, and in the Primary DNS Address field, enter the primary DNS server
you want to use.
5. In the Secondary DNS Address field, enter the secondary DNS server you want to use.
6. At the top of the page, click the Save Settings button.
7. The DNS server settings should have changed instantly, but you may be told to reboot the router to complete the changes.
Page 19 | © 2017 Webroot Inc. All rights reserved. | Proprietary and Confidential Information
March 31, 2017
1. Sign in to your ASUS router's admin page with this address: http://192.168.1.1.
2. From the menu to the left, click or tap WAN.
3. At the top of the page, to the right, click the Internet Connection tab.
4. In the DNS Server1 field, under the WAN DNS Setting section, enter the primary DNS server you want to use.
5. In the DNS Server2 field, enter the secondary DNS server you want to use
6. Click the Apply button at the bottom of the page to save the changes.
1. Sign in to your TP-LINK router's configuration page, usually via the http://192.168.1.1 address, but sometimes via
http//192.168.0.1.
2. From the menu on the left, select the DHCP option.
3. Tap or click the DHCP submenu option called DHCP Settings.
4. In the Primary DNS field, enter the primary DNS server you'd like to use.
5. In the Secondary DNS field, enter the secondary DNS server you'd like to use.
6. Click the Save button at the bottom of the page to save the changes.
1. Sign in to your Cisco router from either http://192.168.1.1 or http://192.168.1.254, depending on your router model.
2. Click or tap the Setup option from the menu at the very top of the page.
3. Click the LAN Setup tab from the menu that's just below the Setup option.
4. In the LAN 1 Static DNS 1 field, enter the primary DNS server you'd like to use.
5. In the LAN 1 Static DNS 2 field, select the secondary DNS server you'd like to use.
6. Some Cisco routers may have a LAN 1 Static DNS 3 field, which you can leave blank, or enter yet another DNS server.
7. Save the changes clicking the Save Settings button at the bottom of page.
1. Sign in to your Belkin router through the address http://192.168.2.1.
2. Select DNS under the Internet WAN section from the menu on the left.
3. In the DNS Address field, enter the primary DNS server you'd like to use.
4. In the Secondary DNS Address field, use the secondary DNS server you'd like to use.
5. Click or tap the Apply Changes button to save the changes.
6. You may be told to restart your router for the changes to take effect. If told to do so, simply follow the on-screen prompts.
Page 20 | © 2017 Webroot Inc. All rights reserved. | Proprietary and Confidential Information
March 31, 2017
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertising
