Thank you for buying a Samsung Camera.
This manual will help you learn to capture
images, share or print your photos, and edit
photos with the accompanying software.
Please read this manual thoroughly.
User Manual
Instructions
Getting to Know your camera
Use this camera in the following order.
Thank you for buying a Samsung Digital Camera.
Setting up the applica- To use this camera with a PC, install
the application software ¿rst. After
tion software
this has been done, the stored images in the camera can be moved
to the PC and can be edited by an
image editing program. (p.104-106)
Take a picture
Insert the USB cable
Check the camera's
power
Take a picture. (p.21)
Insert the supplied USB cable
into the PC’s USB port and the
camera’s USB connection
terminal. (p.107)
Check the camera’s power. If the
power is turned off, preset the
camera button to turn it on.
Open Windows’s EXPLORER
Check [Removable Disk] and search for [Removable Disk].
(p.108)
Prior to using this camera, please read the user manual
thoroughly.
If you require After Sales service, please bring the camera and the
cause of the camera malfunction (such as battery, Memory card
etc.) to the A/S centre.
Please check that the camera is operating properly prior to when
you intend to use it (e.g. for a trip or an important event) to avoid
disappointment. Samsung takes no responsibility for any loss or
damage that may result from camera malfunction.
Keep this manual in a safe place.
If you use a card reader to copy the images on the memory card to
your PC, the images could be damaged. When transferring the
images taken with the camera to your PC, be sure to use the
supplied USB cable to connect the camera to your PC. Please note
that the manufacturer holds no responsibility for loss or damage of
images on the memory card due to the use of a card reader.
The contents and illustrations of this manual are subject to change
without prior notice for upgrading the camera functions.
Ä Microsoft, Windows and Windows logo are registered trademarks
of Microsoft Corporation incorporated in the United States and/or
other countries.
Ä Apple, Mac and QuickTime logo are registered trademarks of
Apple computer.
Ä Adobe and Reader are either trademarks or registered
trademarks in the United States and/or other countries.
Ä All brand and product names appearing in this manual are
registered trademarks of their respective companies.
001
Danger
Warning
DANGER indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
Do not attempt to modify this camera in any way. To do so may
result in ¿re, injury, electric shock or severe damage to you or your
camera. internal inspection, maintenance and repairs should only
be carried out by your dealer or Samsung Camera Service centre.
Please do not use this product in close proximity to Àammable or
explosive gases, as this could increase the risk of explosion.
Should any form of liquid or a foreign object enter the camera, do
not use it. Switch off the camera, and then disconnect the power
source. You must contact your dealer or Samsung Camera Service
centre. Do not continue to use the camera as this may cause a ¿re
or electric shock.
Do not insert or drop metallic or inÀammable foreign objects into
the camera through access points e.g. the memory card slot and
battery chamber. This may cause a ¿re or electric shock.
Do not operate this camera with wet hands. This could pose a risk
of electric shock.
Do not use the Àash in close proximity to people or animals.
Positioning the Àash too close to your subject’s eyes may cause
eyesight damage.
For safety reasons keep this product and accessories out of reach
of children or animals to prevent accidents e.g.:
- Swallowing battery or small camera accessories. If an accident
should occur, please consult a doctor immediately.
- There is the possibility of injury from the camera’s moving parts.
Battery and camera may become hot during prolonged use and it
may result in camera malfunction. Should this be the case, allow
the camera to sit idle for a few minutes to allow it time to cool.
Do not leave this camera in places subject to extremely high temperatures, such as a sealed vehicle, direct sunlight or other places
of extremes in temperature. Exposure to extreme
temperatures may adversely affect the camera’s internal
components and could cause a ¿re.
When in use, do not cover the camera or Charger. This may cause
heat to build up and distort the camera body or cause a ¿re. Always
use the camera and its accessories in a well-ventilated area.
002
Caution
CAUTION indicates a potentially hazardous situation which, if not
avoided, may result in a minor or moderate injury.
Leaking, overheating, or damaged battery could result in ¿re or injury.
- Use battery with the correct speci¿cation for the camera.
- Do not short circuit, heat or dispose of battery in ¿re.
- Do not insert the battery with the polarities reversed.
Remove the battery when not planning to use the camera for a
long period of time. Otherwise the battery may leak corrosive
electrolyte and permanently damage the camera’s components.
Do not ¿re the Àash while it is in contact with hands or objects. Do
not touch the Àash after using it continuously. It may cause burns.
Do not move the camera while it is switched on, if you are using
the AC adapter. After use, always switch off the camera before
unplugging the cable from the wall socket. Then make sure that
any connector cords or cables to other devices are disconnected
before moving the camera. Failure to do so may damage the cords
or cables and cause a ¿re or electric shock.
Take care not to touch the lens or lens cover to avoid taking an
unclear image and possibly causing camera malfunction.
Avoid obstructing the lens or the Àash when you capture an image.
When using this camera in low temperatures, you may experience
the following. These are not camera malfunctions and usually
recover at normal temperature.
- It takes longer to turn on the LCD monitor and the colour may
differ from the subject.
- When changing the composition, there may be an after image on
the LCD monitor.
Credit cards may be demagnetized if left near case. Avoid leaving
magnetic strip cards near the case.
Never connect the 20 pin connector to the USB port of a PC. This
carries a high risk of computer malfunction.
Contents
