SP-M200S SP-M220S SP-M250S

LCD Projector

Owner’s Instructions

The color and the appearance of the product may differ from the illustrations in this manual. The specifications are subject to change without prior notice to improve performance.

Table Of Contents

MAJOR SAFETY PRECAUTIONS

Before You Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

INSTALLATION AND CONNECTION

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Installing the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Leveling with Adjustable Feet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Zoom and Focus Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Screen Size and Projection Distance . . . . . . . . . . . . . . . . . . . . . . . . . 2-5

Lamp Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6

Rear Side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7

Supported Display Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8

Connecting the Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9

Connecting with a PC and Setting up the PC . . . . . . . . . . . . . . . . . . 2-10

Connecting a PC using an HDMI/DVI cable . . . . . . . . . . . . . . . . . . . . 2-11

Connecting an HDMI-Compatible Device . . . . . . . . . . . . . . . . . . . . . . 2-12

Connecting an AV device using a D-Sub cable . . . . . . . . . . . . . . . . . 2-13

Connecting an AV device with Component output . . . . . . . . . . . . . . 2-14

Connecting using a Video cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15

Connecting an External Speaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16

Kensington Lock slot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17

USING

Product Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Front, Upper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

LED Indications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

Using the Screen Adjustment Menu (OSD: On Screen Display) . . . . 3-5

TROUBLESHOOTING

Before Requesting Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

MORE INFORMATION

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

RS232C Command Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2

Contact SAMSUNG WORLDWIDE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3

Correct Disposal - Europe only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4

1 Major Safety Precautions

1-1 Before You Start

Icons used in this manual

ICON NAME

Caution

MEANING

Indicates cases where the function may not work or the setting may be canceled.

Note Indicates a hint or tip to operate a function.

Using this Manual

• Make yourself fully aware of the safety precautions before using this product.

• If a problem occurs, refer to the 'Troubleshooting' section.

Copyright Notice

The contents of this manual are subject to change without prior notice for performance improvement.

Copyright © 2010 Samsung Electronics Co., Ltd. All rights reserved.

The copyright of this manual is reserved by Samsung Electronics, Co., Ltd.

The contents of this manual may not be partially or in whole reproduced, distributed or used in any form without the written permission of Samsung Electronics, Co., Ltd.

1-2 Care and Maintenance

Cleaning the Surface and the Lens

Clean the projector using a soft dry cloth.

• Avoid cleaning the product with a flammable substance such as benzene or thinner.

• Avoid scratching the lens with your fingernails or a sharp object.

This may result in scratches or damage to the product.

• Avoid cleaning the product with a wet cloth or by directly spraying water onto the product.

If water enters the product, it may result in fire, electric shock, or a problem with the product.

• A white stain may appear on the surface of the projector if water gets on it.

The appearance and the color may differ depending on the model.

Cleaning Inside the Projector

For cleaning the interior of the projector, contact an authorized

Samsung Service Center.

• Contact a Service Center if dust or other substances are inside the projector.

1-3 Safety Precautions

Icons used for safety precautions

ICON NAME

Warning

Caution

MEANING

Failing to follow the precautions marked with this sign may result in a serious injury or even a fatality.

Failing to follow the precautions marked with this sign may result in a personal injury or property damage.

Meaning of Signs

Do not perform.

Do not disassemble.

Do not touch.

Must be followed.

The power plug must be unplugged from the wall outlet.

Must be grounded to prevent electric shock.

Power Related

The following images are for your reference and may differ depending on models and countries.

The appearance and the color may differ depending on models.

Warning

Plug the power plug in firmly.

• Otherwise, it may result in fire.

Avoid using a damaged power cord or plug or a loose power outlet.

• Otherwise, it may result in electric shock or fire.

Avoid plugging in or unplugging the power supply with wet hands.

• Otherwise, it may result in electric shock.

Avoid connecting multiple electric appliances to a single wall outlet.

• Otherwise, it may result in fire due to overheating of the wall outlet.

Avoid bending or twisting the power cord excessively and avoid placing heavy objects on the cord.

• Otherwise, it may result in electric shock or fire due to a damaged power cord.

To move the product, turn the power off and unplug the power cord and any other wires connected to the product.

• Otherwise, it may result in electric shock or fire due to the damaged power cord.

Major Safety Precautions 1-3

Make sure to connect the power cord to a grounded wall outlet (for insulation class 1 equipment only).

• Otherwise, it may result in electric shock or injury.

Caution

When unplugging the power plug from the wall outlet, make sure to hold the power plug by the plug and not by the cord.

• Failing to do so may result in electric shock or fire.

Unplug the power plug before cleaning the product.

• There is a danger of electric shock or fire.

Connect the power plug to a wall outlet that can be easily reached.

• When a problem occurs with the product, you must unplug the power plug to cut the power off completely.

You cannot cut the power off completely using only the power button on the product.

Installation Related

Warning

Avoid installing the product in a location exposed to direct sunlight and installing the product near a heat source such as a fire or heater.

• This may shorten the product life cycle or cause fire.

When installing the product in a cabinet or shelf, take care so that the front end of the product is completely supported by the cabinet or shelf.

• Failing to do so may result in the product falling and resulting in damage to the product or injury.

• Make sure to use a cabinet or shelf suitable to the size of the product.

Keep the power cord away from heaters.

• The coating of the power cord may melt and cause electric shock or fire.

1-3

Do not turn the product on or off by plugging or unplugging the power plug. (Do not use the power plug as a power switch.)

Keep the power cord away from sources of heat.

Avoid installing the product in a badly-ventilated location such as inside a bookshelf or closet.

• Otherwise, it may result in fire due to internal overheating.

When installing the product on a console or shelf, make sure that the front of the product does not protrude out of the console or shelf.

• Otherwise, this may cause the product to fall off and result in a malfunction or injury.

When thunder or lighting occurs, unplug the power cord.

• Failing to do so may result in electric shock or fire.

Major Safety Precautions

Do not install the product in a location exposed to dust, moisture (sauna), oil, smoke or water (rain drops) and do not install it in a vehicle.

• This may result in electric shock or fire.

Caution

Take care not to block the vent with a table cloth or curtain.

• Otherwise, it may result in fire due to internal overheating.

When putting the product down, place it gently.

• Failing to do so may result in a problem with the product or injury.

Usage Related

Avoid inserting metal objects such as a chopsticks, coins or hairpins, or inflammable objects into the product (the vents, ports, etc).

• If water or an alien substance enters the product, turn the power off, unplug the power cord and contact a service center.

• Otherwise, it may result in a problem with the product, electric shock or fire.

Do not disassemble, or attempt to fix or modify the product.

• When the product requires repairs, contact a Service Center.

Avoid using or placing inflammable spray or objects near the product.

• This may result in an explosion or fire.

Avoid placing a liquid container such as a vase, flowerpot, beverage, cosmetics or drugs, or a metal object over the product.

• If water or an alien substance enters the product, turn the power off, unplug the power cord and contact a service center.

• Otherwise, it may result in a problem with the product, electric shock or fire.

Major Safety Precautions

Do not install the product in areas with heavy dust.

Do not let the product drop while moving it.

• This may result in a problem with the product or injury.

Do not install the product at a height where children may reach it.

• If a child touches the product, the product may fall and this may result in injury.

Do not let children place objects such as toys or cookies on the product.

• If a child tries to reach for any of these objects, the product may fall and cause harm.

Do not look directly at the light of the lamp nor project the picture into someone's eyes.

• This is dangerous, especially for children.

When you remove batteries from the remote, be careful that they are not swallowed by children. Keep batteries out of the reach of children.

• If swallowed, see a doctor immediately.

1-3

1-3

Caution

If the product generates a strange noise, a burning smell, or smoke, unplug the power plug immediately and contact a service center.

• Failing to do so may result in electric shock or fire.

If the power plug pin or jack is exposed to dust, water or alien substances, clean it thoroughly.

• There is a danger of electric shock or fire.

When cleaning the product, disconnect the power cord and clean the product with a soft dry cloth.

• Avoid using chemicals such as wax, benzene, alcohol, thinner, mosquitorepellent, fragrance, lubrication or cleansing agent when cleaning the product.

This may result in the exterior being deformed or the print being removed.

When not using the product for a long time, such as leaving your home, unplug the power cord from the wall outlet.

• Otherwise, it may cause dust accumulation and result in fire caused by overheating or a short circuit or result in an electric shock.

If the product is installed in a location where the operating conditions vary considerably, a serious quality problem may occur due to the surrounding environment.

In this case, install the product only after consulting our Call Center.

• Places exposed to microscopic dust, chemicals, too high or low temperature, high humidity, such as airports or stations where the product is continuously used for a long time etc..

If you drop the product or the case is damaged, turn the power off and unplug the power cord. Contact a service center.

• Failing to do so may result in fire or electric shock.

Make sure to place your remote control on a table or desk.

• If you step on the remote control, you may fall and hurt yourself or the product may be damaged.

If water or a foreign substance enters the product, turn the product off, unplug the power cord from a wall outlet, and contact a Service Center.

Do not use the product while it indicates a malfunction, such as no sound or no picture.

• Turn the product off immediately, unplug the power cord from a wall outlet, and contact a Service Center.

When a gas leak occurs, do not touch the product or the power plug and ventilate immediately.

• A spark may result in an explosion or fire.

• During a thunder or lighting storm, do not touch the power cord or antenna cable

Do not touch the lens on the product.

• This may cause damage to the lens.

Do not touch any outer part of the product with tools such as a knife or a hammer.

To clean dirt or stains on the front projection lens, use spray or a wet cloth dampened with neutral detergent and water.

Ask a Service Center to clean the interior of the projector at least once per year.

Major Safety Precautions

To avoid burning yourself, do not touch the vents or lamp cover while operating or right after turning off the product.

Do not open any cover on the product.

• This would prove hazardous because of high-voltage current inside the product.

Be careful not to touch the ventilation hole while the projector is on as hot air comes out.

Do not place objects vulnerable to heat near the projector.

Take care not to lose the lens cover of the product.

• The lens could get damaged.

Do not clean the product using water spray or a wet cloth. Avoid using any chemicals such as detergents, industrial or automotive polish, abrasive, wax, benzene, alcohol on any plastic part of the product such as projector case, since this may cause damage.

Do not use any undesignated battery.

The ventilation hole is hot for some time though the projector is turned off. Keep you hands or body off the ventilation hole.

Be careful to keep your body away from the projector lamp. The lamp is hot.

(Children and those who have sensitive skin should be more careful.)

The lens cover protects the lens and should be used when the projector is turned off.

• To hide the screen while the projector is turned on, use the BLANK feature.

Major Safety Precautions 1-3

2 Installation and Connection

2-1 Package Contents

• Unpack the product and check if all of the contents listed below have been included.

• Store the packaging box in case you need to move the product at a later date.

Projector

CONTENTS

Quick Installation Guide Warranty Card / Registration

Card (Not available in all locations)

User Manual

Remote Control / 1 Battery

( Not available in all locations)

Cleaning Cloth D-Sub Cable

Power Cord

Lens cover

4 Screws

(For bracket of ceiling mount.)

Projector case

A ceiling mount is not included and must be purchased separately. Use the included screws to attach the projector to the ceiling mount bracket.

2-1 Installation and Connection

2-2 Installing the Projector

Install the projector so that the beam from the projector is perpendicular to the screen.

• Place the projector so that the lens aims at the center of the screen. If the screen is not vertical, the picture on the screen may not appear rectangular.

• Do not install the screen in bright surroundings. If the surroundings are too bright, the picture on the screen will be washed out and not display clearly.

• When using the projector in bright surroundings, use curtains to block the light.

• You can install the projector in the following locations relative to the screen: Front-Floor / Front-Ceiling / Rear-Floor /

Rear-Ceiling. To view the installation position settings, see below.

To adjust the picture when you install the projector behind the screen

Installing behind a semi-transparent screen.

When you install the projector behind a semi-transparent screen, you can use the menu to adjust the picture so that it displays correctly, depending on where you've located the projector, rearfloor (or low) or rear-ceiling.

1.

For rear-floor, press :

Menu > Setup > Install > Rear-Floor

2.

For rear-ceiling, press :

Menu > Setup > Install > Rear-Ceiling

To adjust the picture when you install the projector in the front of the screen

Installing the projector in front of the screen.

When you install the projector in front of a screen, you can use the menu to adjust the picture so that it displays correctly, depending on where you’ve located the projector, front-floor (or low) or front-ceiling.

1.

For front-floor, press :

Menu > Setup > Install > Front-Floor

2.

For front-ceiling, press :

Menu > Setup > Install > Front-Ceiling

Installation and Connection 2-2

2-3 Leveling with Adjustable Feet

Press the PUSH buttons, as shown, to adjust the legs and level the projector.

The projector can be adjusted to a height of up to 30 mm (about 1.8 inches) from the reference point.

If <Auto Keystone> is set to <On>, <V-Keystone> is adjusted automatically.

If fine tuning is required after auto-adjustment, use <V-Keystone>.

2-3 Installation and Connection

2-4 Zoom and Focus Adjustment

Zoom Knob : You can adjust the size of the image within the zoom range by manipulating the Zoom Knob.

Focus Ring : Focus the picture on the screen using the Focus

Ring.

The size of your screen determines the distance you set your projector from the screen.

If you do not install your projector at the projection distance specified in the Screen Size and Projection Distance table in

Section 2-5, you will not be able to adjust the focus correctly.

Installation and Connection 2-4

2-5 Screen Size and Projection Distance

A. Screen / Z. Throw Distance / Y’. Distance from Lens Center to Image Bottom

Install the projector on a flat, even surface and level the projector using the adjustable feet to obtain optimal picture quality. If images are not clear, adjust them using the Zoom Knob or Focus Ring, or move the projector forward and backward.

M (DIAGONAL)

INCHES / CM

30 / 76.20

40 / 101.60

50 / 127.00

60 / 152.40

70 / 177.80

80 / 203.20

90 / 228.60

100 / 254.00

110 / 279.40

120 / 304.80

130 / 330.20

140 / 355.60

150 / 381.00

160 / 406.40

170 / 431.80

180 / 457.20

190 / 482.60

200 / 508.00

210 / 533.40

220 / 558.80

230 / 584.20

240 / 609.60

250 / 635.00

SCREEN SIZE

X (HORIZONTAL)

INCHES / CM

24 / 61.00

32 / 81.30

40 / 101.60

48 / 121.90

56 / 142.20

64 / 162.60

72 / 182.90

80 / 203.20

88 / 223.50

96 / 243.80

104 / 264.20

112 / 284.50

120 / 304.80

128 / 325.10

136 / 345.40

144 / 365.80

152 / 386.10

160 / 406.40

168 / 426.70

176 / 447.00

184 / 467.40

192 / 487.70

200 / 508.00

Y (VERTICAL)

INCHES / CM

18 / 45.70

24 / 61.00

30 / 76.20

36 / 91.40

42 / 106.70

48 / 121.90

54 / 137.20

60 / 152.40

66 / 167.60

72 / 182.90

78 / 198.10

84 / 213.40

90 / 228.60

96 / 243.80

102 / 259.10

108 / 274.30

114 / 289.60

120 / 304.80

126 / 320.00

132 / 335.30

138 / 350.50

144 / 365.80

150 / 381.00

THROW DISTANCE

Z (WIDE)

INCHES / CM

35 / 87.80

46 / 117.00

58 / 146.30

69 /175.60

81 / 204.80

92 / 234.10

104 / 263.30

115 / 292.60

127 / 321.90

138 / 351.10

150 / 380.40

161/ 409.70

173 / 438.90

184 / 468.20

196 / 497.40

207/ 526.70

219 / 556.00

230 / 585.20

242 / 614.50

253 / 643.70

265 / 673.00

276 / 702.30

288 / 731.50

Z (TELE)

INCHES / CM

41 / 104.20

55 / 139.00

68 / 173.70

82 / 208.50

96 / 243.20

109 / 278.00

123 / 312.70

137 / 347.50

150 / 382.20

164 / 417.00

178 / 451.70

192 / 486.50

205 / 521.20

219 / 556.00

233 / 590.70

246 / 625.40

260 / 660.20

274/ 694.90

287 / 729.70

301 / 764.40

315 / 799.20

328 / 833.90

342 / 868.70

OFFSET

Y'

INCHES / CM

2.178 / 5.50

2.904 / 7.40

3.630 / 9.20

4.356 / 11.10

5.082 / 12.90

5.808 / 14.80

6.534/ 16.60

7.260 / 18.40

7.986 / 20.30

8.712 / 22.10

9.438 / 24.00

10.164 / 25.80

10.890 / 27.70

11.616 / 29.50

12.342 / 31.30

13.068 / 33.20

13.794 / 35.00

14.520 / 36.90

15.246 / 38.70

15.972 / 40.60

16.698 / 42.40

17.424 / 44.30

18.150 / 46.10

2-5 Installation and Connection

SCREEN SIZE

X (HORIZONTAL)

THROW DISTANCE

Z (TELE) Z (WIDE) M (DIAGONAL)

INCHES / CM

260 / 660.40

270 / 685.80

280 / 711.20

290 / 736.60

300 / 762.00

310 / 787.40

320 / 812.80

330 / 838.20

340 / 863.60

350 / 889.00

360 / 914.40

370 / 939.80

380 / 965.20

390 / 990.60

400 / 1016.00

INCHES / CM

208 / 528.30

216 / 548.60

224 / 569.00

232 / 589.30

240 / 609.60

248 / 629.90

256 / 650.20

264 / 670.50

272 / 690.90

280 / 711.20

288 / 731.50

296 / 751.80

304 / 772.20

312 / 792.50

320 / 812.80

Y (VERTICAL)

INCHES / CM

156 / 396.20

162 / 411.50

168 / 426.70

174 / 442.00

180 / 457.20

186 / 472.40

192 / 487.70

198 / 502.90

204 / 518.20

210 / 533.40

216 / 548.60

222 / 563.90

228 / 579.10

234 / 594.40

240 / 609.60

INCHES / CM

356 / 903.40

369 / 938.20

383 / 972.90

397 / 1007.70

410 / 1042.40

424 / 1077.20

438 / 1111.90

451 / 1146.70

465 / 1181.40

479 / 1216.20

492 / 1250.90

506 / 1285.60

520 / 1320.40

534 / 1355.10

547 / 1389.90

This projector is designed to show images optimally on a 80 ~ 120 inch sized screen.

INCHES / CM

300 / 760.80

311 / 790.00

323 / 819.30

334 / 848.60

346 / 877.80

357 / 907.10

369 / 936.30

380 / 965.60

392 / 994.90

403 / 1024.10

415 / 1053.40

426 / 1082.60

438 / 1111.90

449 / 1141.20

461 / 1170.40

OFFSET

Y'

INCHES / CM

18.876 / 47.90

19.602 / 49.80

20.328 / 51.60

21.054 / 53.50

21.780 / 55.30

22.506 / 57.20

23.232 / 59.00

23.958 / 60.90

24.684 / 62.70

25.410 / 64.50

26.136 / 66.40

26.862 / 68.20

27.588 / 70.10

28.314 / 71.90

29.040 / 73.80

Installation and Connection 2-5

2-6 Lamp Replacement

Cautions on Lamp Replacement

• The projector lamp is an expendable item. For best operating performance, replace the lamp according to the usage time.

You can view the lamp usage time in the Information Display (INFO button).

• Replace the lamp with the one specified below only.

- Lamp Model Name : DPL3321U (SP-M200S, SP-M220S, SP-M250S)

- For inquiries on lamp purchase, please see 'Contact SAMSUNG WORLDWIDE' in section 5-3.

• Check that the power cord is unplugged before replacing the lamp.

• Because the lamp is a high temperature and high voltage product, wait at least one hour from the time you disconnect the power cord before replacing the lamp.

• The projector lamp is on the top of the projector.

• Do not leave the old lamp near flammable items or in reach of children. There is a danger of fire, burns, or injury.

• Remove dirt or foreign material around or inside the lamp unit using a proper vacuum device.

• When handling the lamp, avoid touching any part of it except for the handles. If you handle the lamp incorrectly, you can shorten the lamp’s lifetime and affect picture quality.

• When you change the lamp, put the projector on a flat surface.

• The projector has been designed so that the projector does not work if the lamp cover is not completely assembled after a lamp replacement. If the projector does not work properly, please check the operating status of the indicator LED.

Lamp contains Mercury. Dispose According to Local, State or Federal Laws.

Lamp Replacement Procedure

Because the lamp is a high temperature and high voltage product, wait at least one hour from the time that the power cord is disconnected before replacing it.

The projector lamp is on the top of the projector.

1.

Remove the screw shown in the figure below, and then open the cover.

2.

Wtih the cover open, remove the three (3) screws on the top of the projector as shown in the figure below.

2-6 Installation and Connection

3.

To remove the lamp, hold and then pull the lamp handle as shown in the figure below.

Install a new lamp in the reverse order of removal.

Replacing and Cleaning the Filter

Precautions when replacing the projector filter:

• The filter is on the side of the projector.

• Turn off the power of the projector, and then disconnect the power cord after the projector has cooled sufficiently.

Otherwise, its parts may be damaged due to internal heat.

• When you replace the filter, you may release some dust.

• For inquiries on replacement filter purchase, please see 'Contact SAMSUNG WORLDWIDE' in Chapter 5.

To replace or clean the filter, follow these steps:

1.

Turn off the power of the projector, and then disconnect the power cord after the projector has cooled sufficiently.

2.

Open the filter cover.

3.

Replace or clean the filter.

• When cleaning the filter, use a small vacuum cleaner designed for computers and small electronics products, or wash it under running water.

• After washing the filter under running water, make sure to dry it completely. The moisture may cause the filter to corrode.

• If dust cannot be separated from the filter or the filter is torn, it must be replaced.

• After cleaning or replacing the filter, run <Reset> > <Reset Filter Time> in the <Setup> menu.

Ventilation openings

For the location of the ventilation openings, see the picture below:

• Do not block the ventilation openings. Blocking the ventilation openings can cause your projector to overheat and may cause it to fail.

Installation and Connection 2-6

Air outtake vent

Air intake vent

2-6 Installation and Connection

2-7 Rear Side

1. Kensington Lock slot

2. PC IN port

3. VIDEO IN port

4. [AUDIO IN] L-AUDIO-R port

5. HDMI/DVI IN port

6. Remote Control Signal Receiver

7. Power Input port

8. AUDIO OUT/ port

9. RS232C port

Installation and Connection 2-7

FORMAT

VESA

VESA

VESA

VESA

VESA

VESA

VESA

VESA

VESA

VESA

VESA

VESA

VESA

VESA

VESA

VESA

VESA

VESA

VESA

VESA

VESA

VESA

VESA

MAC

VESA

IBM

IBM

IBM

VESA

MAC

VESA

VESA

VESA

2-8 Supported Display Modes

PC Timing (D-Sub/HDMI)

RESOLUTION

1024 x 768

1024 x 768

1024 x 768

1152 x 864

1152 x 864

1152 x 864

1152 x 864

1280 x 720

1280 x 720

1280 x 720

1280 x 720

1280 x 768

720 x 576

800 x 600

800 x 600

800 x 600

800 x 600

800 x 600

832 x 624

1024 x 768

640 x 350

640 x 480

720 x 400

640 x 480

640 x 480

640 x 480

640 x 480

640 x 480

1280 x 768

1280 x 800

1280 x 800

1280 x 960

1280 x 960

75Hz

60Hz

70Hz

72Hz

75Hz

60Hz

70Hz

72Hz

75Hz

60Hz

70Hz

72Hz

75Hz

60Hz

75Hz

60Hz

70Hz

60Hz

56Hz

60Hz

70Hz

72Hz

75Hz

75Hz

60Hz

70Hz

60Hz

70Hz

60Hz

67Hz

70Hz

72Hz

75Hz

VERTICAL

FREQUENCY

(HZ)

75.000

59.855

70.000

72.000

74.777

59.870

70.069

72.000

75.029

59.959

70.000

72.000

59.950

56.250

60.317

70.000

72.188

75.000

74.551

60.004

70.086

59.940

70.087

59.940

66.667

70.000

72.809

75.000

74.893

59.810

74.934

60.000

70.000

HORIZONTAL

FREQUENCY

(KHZ)

67.500

44.772

52.500

54.072

56.456

47.776

56.476

57.672

60.023

53.783

63.000

64.872

35.910

35.156

37.879

43.750

48.077

46.875

49.726

48.363

31.469

31.469

31.469

31.469

35.000

35.000

37.861

37.500

60.289

49.702

62.795

60.000

69.930

PIXEL

FREQUENCY

(MHZ)

108.000

74.500

89.040

91.706

95.750

79.500

75.000

78.434

78.750

81.750

96.768

99.643

32.750

36.000

40.000

45.500

50.000

49.500

57.284

65.000

25.175

25.175

28.322

25.175

30.240

28.560

31.500

31.500

102.250

83.500

106.500

108.000

120.839

2-8 Installation and Connection

FORMAT

VESA

VESA

VESA

VESA

VESA

VESA

VESA

VESA

VESA

VESA

RESOLUTION

1280 x 960

1280 x 960

1280 x 1024

1280 x 1024

1280 x 1024

1280 x 1024

1400 x 1050

1440 x 900

1440 x 900

1600 x 1200

72Hz

75Hz

60Hz

70Hz

72Hz

75Hz

60Hz

60Hz

75Hz

60Hz

HORIZONTAL

FREQUENCY

(KHZ)

72.072

75.231

63.981

74.620

76.824

79.976

65.317

55.935

70.635

75.000

VERTICAL

FREQUENCY

(HZ)

72.000

74.857

60.020

70.000

72.000

75.025

59.978

59.887

74.984

60.000

All resolutions higher or lower than 800x600 are converted to 800x600 by the Scaler chip inside the projector. If the resolution of the signal out put by the PC matches the real resolution (800x600) of the projector, the screen quality is optimal.

PIXEL

FREQUENCY

(MHZ)

124.540

130.000

108.000

128.943

132.752

135.000

121.750

106.500

136.750

162.000

AV Timing (D-Sub)

FORMAT

BT.601 SMPTE 267M

BT.1358 SMPTE 293M

BT.601

BT.1358

SMPTE 296M

BT.709 SMPTE 274M

480i

480p

576i

576p

720p

720p

1080i

1080i

RESOLUTION

59.94Hz

59.94Hz

50Hz

50Hz

59.94Hz/60Hz

50Hz

59.94Hz/60Hz

50Hz

SCAN

Interlaced

Progressive

Interlaced

Progressive

Progressive

Progressive

Interlaced

Interlaced

AV Timing (HDMI)

EIA-861

EIA-861

EIA-861

EIA-861

EIA-861

EIA-861

EIA-861

FORMAT

Format1

Format1

Format2,3

Format2,3

Format4

Format4

Format5

RESOLUTION

640 x 480

640 x 480

720 x 480

720 x 480

1280 x 720

1280 x 720

1920 x 1080

SCAN

Progressive

Progressive

Progressive

Progressive

Progressive

Progressive

Interlaced

HORIZONTAL

FREQUENCY

(KHZ)

59.940

60.000

59.940

60.000

59.939

60.000

59.939

VERTICAL

FREQUENCY

(HZ)

31.469

31.500

31.469

31.500

44.955

45.000

33.716

PIXEL

FREQUENCY

(MHZ)

25.175

25.200

27.000

27.027

74.175

74.250

74.175

Installation and Connection 2-8

FORMAT RESOLUTION

EIA-861

EIA-861

EIA-861

EIA-861

Format5

Format17,18

Format19

Format20

1920 x 1080

720 x 576

1280 x 720

1920 x 1080

SCAN

Interlaced

Progressive

Progressive

Interlaced

HORIZONTAL

FREQUENCY

(KHZ)

60.000

50.000

50.000

50.000

VERTICAL

FREQUENCY

(HZ)

33.750

31.250

37.500

28.125

PIXEL

FREQUENCY

(MHZ)

74.250

27.000

74.250

74.250

AV Timing (VIDEO)

NTSC, NTSC 4.43, PAL, PAL60, PAL-N, PAL-M, SECAM

Your projector supports the standard video formats listed above through its video inputs. No adjustments are necessary.

2-8 Installation and Connection

2-9 Connecting the Power

1.

Plug the power cord into the power terminal on the rear side of the projector.

Installation and Connection 2-9

2-10 Connecting with a PC and Setting up the PC

2-10-1. Setting up the PC Environment

Check the following items before connecting your PC to your projector.

1.

Click the right mouse button on the Windows desktop, and then click [Properties].

The <Display Properties> dialog appears.

2.

Click the [Settings] tab, and then set the <Screen resolution>. The optimal resolution for the projector is 800 x 600. For other resolutions supported by the projector, see the PC Timing Display Mode table in section 2-8.

You do not have to change the <Color quality> setup.

3.

Press the [Advanced] button. Another property window appears.

4.

Click the [Monitor] tab and set the <Screen refresh rate>. For the refresh rate that matches the resolution you’ve chosen, see the refresh rate (60 Hz, 70 Hz, etc.) next to your selected resolution in the PC Timing Display Mode table in section 2-8.

Setting the refresh rate sets both the vertical and horizontal frequencies.

2-10 Installation and Connection

5.

Click the [OK] button to close the window, and then click the [OK] button on the <Display Properties> window to close that window.

6.

Shut down the PC and connect it to the projector.

The setup process might vary depending on your type of computer or version of Windows.

(For example, [Properties] appears instead of [Properties (R)] as shown in 1.)

This projector supports 32 bit color quality (per pixel) when it is used as a PC monitor.

Projected images may differ from the images on your monitor depending on the monitor manufacturer or Windows version.

When connecting the projector to a PC, make sure that the PC setup complies with the display settings supported by this projector. If it does not, you may have signal problems.

2-10-2. Connecting with a PC

Make sure that your PC and projector are turned off.

1.

Connect the [PC IN] port on the rear side of the projector to the PC video out (D-sub) port of the PC using a PC video cable.

2.

Plug in the power cords of the projector and the PC.

This product supports plug and play. If you use Windows XP, you do not need to set up the driver on your PC.

Using the Projector

1.

Turn on the projector, and then press the [SOURCE] button to select <PC>.

If the <PC> Mode is not available, make sure the PC video cable is properly connected.

2.

Turn on the PC, and then set the PC Environment (screen resolution, etc.) if necessary.

3.

Adjust the screen.

Installation and Connection 2-10

2-11 Connecting a PC using an HDMI/DVI cable

Make sure that your PC and projector are turned off.

1.

Connect the [HDMI/DVI IN] terminal of the projector to the HDMI or DVI terminal of your PC using a HDMI/HDMI or HDMI/DVI cable (Not supplied).

- If you are connecting to the HDMI terminal of your PC, use an HDMI/HDMI cable (Not supplied).

- For the supported resolutions and refresh rates, see PC Timing (D-Sub/HDMI) in Section 2-8, "Supported Display Modes".

2-11 Installation and Connection

2-12 Connecting an HDMI-Compatible Device

Make sure that the AV device and your projector are turned off.

1.

Connect the [HDMI/DVI IN] terminal at the back of the projector to the HDMI or HDMI/DVI output terminal of the digital output device using an HDMI/DVI or HDMI/HDMI cable.

- If you are connecting to the HDMI output terminal on the digital output device, use an HDMI/HDMI cable.

- For supported input signal formats, resolutions, and frequencies, see AV Timing(HDMI) in Section 2-8, "Supported Display

Modes".

2.

If you connected using a HDMI/DVI cable, connect the [ AUDIO IN (L-AUDIO-R) ] terminal on the projector to the Audio out terminal on your digital output device using an audio cable (Not supplied).

- If you connected with a HDMI/HDMI cable, you do not need an audio cable.

Installation and Connection 2-12

2-13 Connecting an AV device using a D-Sub cable

Make sure that the AV device and your projector are turned off.

1.

Connect the [PC IN] terminal at the back of the projector to the D-Sub terminal of your AV device using a D-Sub cable.

- For supported input signal formats, resolutions, and frequencies, see AV Timing (D-Sub) in Section 2-8, "Supported Display

Modes".

2.

Connect the [ AUDIO IN (L-AUDIO-R) ] terminal at the back of the projector to the Audio out terminal of your AV device using an audio cable (Not supplied).

2-13 Installation and Connection

2-14 Connecting an AV device with Component output

Make sure that the AV device and your projector are turned off.

1.

Connect the [PC IN] terminal on the back of the projector to the Component terminal on your AV device using a D-Sub to

Component cable (Not supplied). This cable has a D-Sub connector on one end and three RCA jacks on the other.

- For supported input signal formats, resolutions, and frequencies, see AV Timing (D-Sub) in Section 2-8, "Supported Display

Modes".

2.

Connect the [ AUDIO IN (L-AUDIO-R) ] terminal on the back of the projector and the Audio out terminal on your AV device using an audio cable (Not supplied).

Installation and Connection 2-14

2-15 Connecting using a Video cable

Make sure that the AV device and your projector are turned off.

1.

Connect the AV device to the

[VIDEO]

port using a VIDEO cable (not supplied).

- For supported input signal formats, see AV Timing (VIDEO) in section 2-8, "Supported Display Modes".

2.

Connect the [ AUDIO IN (L-AUDIO-R) ] terminal on the back of the projector and the Audio out terminal on your AV device using an audio cable (Not supplied).

2-15 Installation and Connection

2-16 Connecting an External Speaker

You can hear sound through an external speaker instead of the internal speakers built into the projector.

1.

Obtain an audio cable (Not supplied) suitable for your external speaker.

2.

Connect the [AUDIO OUT/ ] terminal of the projector to the external speaker using an audio cable.

- When using an external speaker, the internal speaker does not operate but you can adjust the volume of the external speaker using the Volume button or the remote control of the projector.

- The [AUDIO OUT/ ] terminal can output all audio signals.

Installation and Connection 2-16

2-17 Kensington Lock slot

The Kensington Lock slot allows you to lock your projector, providing a sense of security when you use it in a public place.

Because the shape and usage of the lock may differ depending on the model and the manufacturer, see the User Manual supplied with the locking device for more information.

Locking the product

1.

Loop the Kensington lock cable around an immovable part of desk or heavy object as directed in the Kensington lock user manual.

2.

Insert the locking part of the locking device into the Kensington lock hole in the projector.

3.

Insert the Kensington lock key into the locking mechanism and turn it in the locking direction.

You can purchase a locking device from an electronics store or an online shop.

2-17 Installation and Connection

3 Using

3-1 Product Features

1.

An optical engine adopting new LCD technology

• 800x600 resolution.

• 3P-LCD panel.

• SP-M200S : Provides a bright, 2000 lumen screen.

SP-M220S : Provides a bright, 2200 lumen screen.

SP-M250S : Provides a bright, 2500 lumen screen.

2.

Minimized fan noise

• Minimizes fan noise through optimized internal air flow and the fan installation structure.

3.

Multiple input terminals

• Increases the connectivity to peripheral devices such as D-Sub 15P, Video, HDMI(DVI PC signal, supported), etc.

4.

Audio Output

• Equipped with an internal 7W (mono) speaker.

5.

User adjustments

• Allows adjustment of each input port.

• Equipped with an internal Test Pattern that can be used to install and adjust the projector.

• Compact size, lightweight, and portable.

Using 3-1

3-2 Front, Upper

2. Move

NAME

1.Indicators

/ Select /

DESCRIPTION

- STAND BY (Blue LED)

- LAMP (Blue LED)

- STATUS (Green/Red/Yellow LED)

Refer to the LED Indications.

/ : Use to move or to select an item within a menu.

3. MENU button

4. SOURCE button

6. Zoom Knob

7. Focus Ring

8. Lens

9. Remote Control Signal

Receiver

10. Hole for attaching lens cap string

-

: Use to adjust the volume.

Use to display the Menu Screen.

Use to select the external device signal.

Use to turn the projector on or off.

-

Use to enlarge or reduce image size.

-

Use for Focus Adjustment.

3-2 Using

3-3 Remote Control

Using your projector with another remote control device nearby may result in improper functioning due to remote control code (frequency) interference.

1. POWER ( ) Button

Use this button to turn the product on and off.

2. AUTO

Button

Adjusts the Picture automatically. (Available in <PC> Mode Only)

3. MENU ( ) Button

Use to display the Menu Screen.

4. Move

(

)/ (

) Buttons

Use to move to or select each menu item.

5. V. KEYSTONE

Button ( )

Use to correct the screen shape when the screen is displayed as a trapezoid.

6. INSTALL

Button

Use to adjust the image so that it is appropriate for the projector's installation location (In front of the screen and hangng from the ceiling, behind the screen and hanging from the ceiling, etc.)

7. BLANK

Button

Use to turn off the screen and sound temporarily. The video and audio will come back on when any button other than the [POWER] button is pressed.

8. P.SIZE

Button

Use to adjust the size of picture screen.

9. QUICK

Button

Use to return to the last menu used quickly.

10. MUTE ( ) Button

Press to mute the sound temporarily. Press the MUTE button again or the

VOL button ( ) when the sound is muted to hear sound again.

11. RETURN (

) Button

Returns to the previous menu.

12. EXIT

( ) Button

Use to make the Menu Screen disappear.

13. VOL ( ) Button

Use to control the volume.

14. INFO

Button

Use to check source signals, picture setup, PC screen adjustment, and lamp lifespan.

15. SOURCE

Button

Use to check or select the connection status of external devices.

16. P.MODE

Button

Use to select Picture Mode.

17. STILL

Button

Use to see still images.

Make sure to place your remote control on a table or desk.

If you step on the remote control, you may fall and hurt yourself or damage the remote.

You can use the remote control up to a distance of about 32.8 feet (10 m) from the product.

Using 3-3

3-4 LED Indications

LED Indications

:Light is On :Light is Blinking :Light is Off

STATUS LAMP STAND BY STATUS

If you press the [POWER] button on the remote control or projector, the screen appears within 30 seconds.

The projector is operating normally.

The projector is preparing an operation after the [POWER] button on the projector or the remote control has been pressed.

The [POWER] button has been pressed to turn off the projector, and the cooling system is in operation to cool off the inside of the projector. (Operates for about 3 seconds.)

The cooling fan inside the projector is not operating normally. Refer to Action 1 in Clearing Indicator Problems below.

The lamp cover protecting the lamp unit is not closed properly. Refer to Action 2 in Clearing Indicator Problems below.

The projector has changed to Cooling mode because its internal temperature has increased beyond the maintenance limit.

Refer to Action 3 in Clearing Indicator Problems below.

The projector has turned itself off automatically because its internal temperature has increased beyond the maintenance limit. Refer to Action 4 in Clearing

Indicator Problems below.

A problem has occurred with the operation of the lamp. Refer to Action 5 below.

3-4 Using

Clearing Indicator Problems

CLASSIFICA

TION

Action 1

Action 2

Action 3

Action 4

Action 5

STATE MEASURES

The cooling fan system is not operating normally.

The lamp cover protecting the lamp unit is not properly closed or the sensor system is not operating normally.

The projector has changed to the Cooling mode because the internal temperature of the projector has increased beyond the maintenance limit.

The internal temperature of the projector has risen higher than the limit, and the projector has turned off automatically.

The lamp has malfunctioned after power turns off abnormally or after the projector is powered on right after turning off.

If the symptom remains even after disconnecting and then reconnecting the power cord and turning the projector on again, contact your product provider or our service center.

Check if the screws on the side of the projector are securely tightened. If they are and the indicators are still lit, contact your product distributor or a service center.

If the internal temperature of the projector has increased beyond the maintenance limit, the projector changes to the Cooling mode before turning off automatically.

In Cooling mode, the fan speed is increased and the projector’s lamp is changed to <ECO> mode.

Check whether the ventilation hole of the projector is blocked.

Check the air filter and clean if blocked.

Check whether the surrounding temperature of the projector is higher than the standard temperature range of the projector.

Cool the projector sufficiently and operate it again.

Check whether the ventilation hole of the projector is blocked.

Check the air filter and clean if blocked.

Check whether the surrounding temperature of the projector is higher than the standard temperature range of the projector.

Cool the projector sufficiently and operate it again.

If the same problem occurs continually, contact your product distributor or service center.

Turn the power off, wait for a sufficient amount of cooling time and then turn the power on to operate. If the same problem occurs continually, contact a Samsung service center.

This Projector uses a cooling fan system to keep the unit from overheating. Operation of the cooling fan may produce noise,

This does not affect product performance and is part of normal operation.

Using 3-4

3-5 Using the Screen Adjustment Menu (OSD: On Screen Display)

The Screen Adjustment Menu (OSD: On Screen Display) Structure

To access the Menu, press the Menu button on the product or on the remote. To move in the menu, press the arrow buttons.

Menu selections with an arrow on the far right have sub-menus. Press the right arrow button to access the sub-menu. Directions for navigating and selecting items in a menu are at the bottom of each menu screen.

MENU SUB-MENU

Input


Setup

Option

Source List

Mode

Overscan

Install

Test Pattern

Language

Sleep Timer

Edit Name

Size

Film Mode

Lamp Mode

Video Type

Menu Option

Security

Position

PC

Auto Keystone

Caption

Sound

Panel Lock

Digital NR

Zoom

V-Keystone

Reset

Filter Check

Time

Information

Black Level

Background

Auto Power On

3-5-1. Input

MENU

Source List

Edit Name

DESCRIPTION

You can select a device connected to the projector to display.

• <PC>-<AV>-<HDMI>

You can edit the names of devices connected to the projector.

• <VCR>-<DVD>-<Cable STB>-<Satellite STB>-<PVR STB>-<AV Receiver>-<Game>-

<Camcorder>-<PC>-<DVI Devices>-<TV>-<IPTV>-<Blu-ray>-<HD DVD>-<DMA>

3-5-2. Picture

3-5 Using

Using

MENU

Mode

Size

DESCRIPTION

Select a screen mode to match the environment, the kind of images you are projecting, or select a customized mode you have created based on your requirements.

<Mode>

• <Dynamic> : Selects the picture for increased definition in a bright room.

• <Standard> : Selects the picture for the optimum display in a normal environment.

• <Presentation> : This mode is suitable for presentations.

• <Text> : This mode is suitable for text work.

• <Movie> : This mode is suitable for viewing a movie.

• <Game> : This picture mode is optimized for playing games.

In <Game> mode, the text in still pictures will appear unnatural.

• <User> : This is a customized mode you create using the <Mode>→<Save> function.

<Presentation> and <Text> modes are only enabled if the input signal is a PC Timing (D-Sub/

HDMI) signal.

Each mode has separate controls for <Contrast>, <Brightness>, <Sharpness>, <Color>, etc.

When you access a mode and change (for example) the <Contrast>, you are changing the contrast for that mode only.

<Contrast> : Used to adjust the contrast between the object and the background.

<Brightness> : Used to adjust the brightness of the entire picture.

<Sharpness> : Used to adjust the sharpness of the picture.

When the input signal is a PC Timing (D-Sub/HDMI) signal, the <Sharpness> cannot be adjusted.

<Color> : Used to adjust color lighter or darker.

When the input signal is a PC Timing (D-Sub/HDMI) signal, the <Color> cannot be adjusted.

<Tint> : Used to obtain more natural color by enhancing the amount of green or red in images.

When the input signal is a PC Timing (D-Sub/HDMI) signal or PAL and SECAM signal in the

[AV] modes, the <Tint> cannot be adjusted.

<Color Tone > : The tone of the color can be changed.

• Factory defaults: < COOL2 >, < COOL1 >, < WARM1 >, < WARM2 >

• You can select the color temperature for the items below according to your preferences.

<R-Gain>, <G-Gain>, <B-Gain> : Adjusts the color temperature of the White level.

<R-Offset>, <G-Offset>, <B-Offset> : Adjusts the color temperature of the Black level.

• <Color Tone >-<R-Gain>-<G-Gain>-<B-Gain>-<R-Offset>-<G-Offset>-<B-Offset>

<Gamma> : Changes the brightness characteristic for each color tone of an image.

• The larger (+) the value, the greater the contrast of the bright and dark parts.

The smaller (-) the value, the darker the dark parts.

• Adjustable range: -3 to +3

<Save> : You can save the status of a screen you adjusted according to your preferences using the

<Mode>→<User> OSD.

<Reset> : Restores the mode settings to the factory defaults.

Using this function, you select a screen size.

When the input signal is a PC Timing (D-Sub/HDMI) signal, <Zoom1>/<Zoom2> is not supported.

• <Normal>-<Zoom1>-<Zoom2>-<16 : 9>

3-5

3-5

MENU

Position

Digital NR

Black Level

Overscan

Film Mode

PC

Zoom

DESCRIPTION

Using this function, you can adjust the screen position if it is not aligned.

To adjust, select the direction you want to move the screen, and then press the arrow button pointing in that direction repeatedly.

If dotted lines appear in an image or the screen shakes, enabling Digital NR (Noise Reduction) can improve the quality of the picture.

When the input signal is a PC Timing (D-Sub/HDMI) signal, <Digital NR> does not operate.

If the black level is unsuitable for the input signal, the dark parts of an image may look unclear or dim.

Using this function, you can select a black level that can improve the visibility of the dark parts.

The <Black level> can only be set for the 480i and 576i RGB signals in the [AV], and AV Timing

(D-Sub) modes.

For [AV], and the 480i and 576i signals of AV Timing (D-Sub).

• <0 IRE> : Sets the black level to <0 IRE>.

• <7.5 IRE> : Sets the black level to <7.5 IRE>.

For the RGB signal of <HDMI> mode.

• <Normal> : Used in a normal environment.

• <Low> : Used when the dark parts of an image are too bright.

Using this function, you can cut off edge of the a picture when unnecessary information or images appear on the edge of the picture.

Overscan is not supported in [AV] modes.

Overscan is supported only when the input signal is an AV Timing (D-Sub) or AV Timing

(HDMI) signal.

If <Overscan> is turned off, unnecessary extra parts at the edges of an image may be shown.

In this case, turn <Overscan> on.

Using this function, you can set the display mode so that it is optimized for playing movies.

• <Off>-<Auto>

<Film Mode> is only be supported for the [AV], 480i, and 576i of AV Timing (D-Sub) signals.

For PC signals, the four PC functions eliminate or reduce noise that causes unstable screen quality, such as screen shaking. If the noise is not removed using Fine Adjustment, adjust the frequency to the maximum and then perform Fine Adjustment again.

These functions are only enabled for the PC Timing (D-Sub/HDMI) input of the D-Sub terminal.

Refer to PC Timing (D-Sub/HDMI).

• <Auto Adjustment> : Used to adjust the frequency and phase of PC screen automatically.

• <Coarse> : Used to adjust the frequency when vertical lines appear on the PC screen.

• <Fine> : Used to fine tune the PC screen.

• <Reset> : Using this function, you can reset the PC menu settings to the factory default settings.

You can magnify the screen to a size you want.

• <x1> - <x2> - <x4> - <x8>

This function is only enabled when the input signal is a PC Timing (D-Sub/HDMI) signal.

Using

3-5-3. Setup

Using

MENU

Install

Lamp Mode

Auto Keystone

V-Keystone

Background

Test Pattern

DESCRIPTION

To tailor the picture to the installation location, (for example, behind a semi-transparent screen, hanging from the ceiling), you can invert the projected images vertically / horizontally.

• <Front-Floor> : Normal Image

• <Front-Ceiling> : Horizontal/Vertical Reversed Image

• <Rear-Floor> : Horizontally Reversed Image

• <Rear-Ceiling> : Vertically Reversed Image

Using this function, you can set the image brightness by adjusting the amount of light generated by the lamp.

• <Eco> : This mode is optimized for screens smaller than 100 inches.

This mode decreases the lamp brightness and power consumption in order to extend the lamp lifetime and reduce noise and power consumption.

• <Bright> : This mode maximizes the lamp brightness when the ambient illumination is bright. As the brightness of the lamp increases, the lamp life time may be reduced and the noise and power consumption may increase.

If video scenes are distorted or tilted, you can compensate for this by setting the <Auto Keystone> function to <On> so that the <V-Keystone> function automatically starts.

• <Off>-<On>

If video scenes are distorted or tilted, you can compensate for this using the vertical Keystone function.

The sound output of your projector is temporarily stopped while the keystone is being changed.

Keystone does not compensate for distortion in the On Screen Display (OSD) menu.

You can selec t an image or screen which will appear when there is no signal from the external device connected to the projector.

• <Logo>-<Blue>-<Black>

A default test pattern built into the projector. You can use it as a reference picture to optimize the installation of the projector and to optimize images.

• <Crosshatch> : You can check whether the picture is distorted or not.

• <Screen Size> : You can reference and display picture format sizes such as 1.33 : 1 or 1.78 : 1.

3-5

3-5

MENU

Video Type

Caption

Reset

DESCRIPTION

If the screen quality is abnormal as a result of the projector not identifying the input signal type automatically in <PC> or <HDMI> mode, Video Type lets you manually set the input signal.

• In <PC> mode, the menu is only enabled for AV Timing (D-Sub) input signals. For separate H/V sync, it is only enabled for a 1280 x 720p 59.94Hz/60Hz signal.

• <Auto>-<RGB(PC)>-<RGB(AV)>-<YPbPr(AV)>

• In <HDMI> mode, <Video Type> is only enabled for the 640x480p 59.94Hz/60 Hz and 1280x720p

59.94Hz/60 Hz signals.

• <Auto>-<PC>-<AV>

Usage

Color,

Sharpness,

Tint kšˆ‰“Œ‹

PC menu l•ˆ‰“Œ‹ yniOwjP yniOh}P

€w‰w™Oh}P wj

~Œ•GŠ–••ŒŠ›•ŽG›ŒGyniG–œ›—œ›G–GˆG wjG›–G›ŒGkTzœ‰G›Œ™”•ˆ“G

~Œ•GŠ–••ŒŠ›•ŽG›ŒGyniG–œ›—œ›G–G

ˆ•Gh}G‹ŒŠŒGOz{iSGk}kSGŒ›ŠˎPG›–G›ŒG kTzœ‰G›Œ™”•ˆ“G

~Œ•GŠ–••ŒŠ›•ŽG›ŒG€w‰w™G–œ›—œ›G–G

ˆ•Gh}G‹ŒŠŒGOz{iSGk}kSGŒ›ŠˎPG›–G›ŒG kTzœ‰G›Œ™”•ˆ“G

~Œ•GŠ–••ŒŠ›•ŽGˆGwjG›–G›ŒGoktpG

›Œ™”•ˆ“G l•ˆ‰“Œ‹ l•ˆ‰“Œ‹ kšˆ‰“Œ‹ kšˆ‰“Œ‹ kšˆ‰“Œ‹ kšˆ‰“Œ‹ zoom l•ˆ‰“Œ‹ kšˆ‰“Œ‹ kšˆ‰“Œ‹ l•ˆ‰“Œ‹ h}

~Œ•GŠ–••ŒŠ›•ŽGˆ•Gh}G‹ŒŠŒGOz{iSG k}kSGŒ›ŠˎPG›–G›ŒGoktpG›Œ™”•ˆ“G l•ˆ‰“Œ‹ kšˆ‰“Œ‹ kšˆ‰“Œ‹ hœ›– hœ›–GšŒ››•Žš T T T

The <Caption> function is supp orted when the external analog signal from the Video input contains subtitles.

• <Caption> : <Off>-<On>

• <Mode> : <Caption>-<Text>

• <Channel> : <1>-<2>

• <Field> : <1>-<2>

The <Caption> function will not operate in <PC> (including components) or <HDMI> mode.

Depending on the external signal, a change to the channel or <Field> settings may be required.

Each <Channel> and <Field> contains different information. <Field><2> carries additional information to supplement information contained in <Field><1>.

(e.g. If English subtitles are provided on <Channel><1>, Spanish subtitles will be provided on

<Channel><2>.)

Using this function, you can reset various settings to the factory default settings.

• <Factory Default> : Changes the settings to the factory defaults.

• <Reset Filter Time> : Resets the filter time.

Using

3-5-4. Option

MENU

Language

Menu Option

Sound

Filter Check Time

Auto Power On

Sleep Timer

Security

Panel Lock

Information

DESCRIPTION

Using this function, you can select the language used for the menu screen.

• <Position> : You can move Menu Position up/down/left/right.

• <Transparency> : You can set the translucency of the menu.

• <High>-<Medium>-<Low>-<Opaque>

• <Display Time> : You can set the display time of the menu.

• <5 sec>-<10 sec>-<30 sec>-<60 sec>-<90 sec>-<120 sec>-<Stay On>

The projector comes with an internal 7W (mono) speaker. Use the equalizer settings below to adjust the sound.

• <100Hz>-<300Hz>-<1kHz>-<3kHz>-<10kHz>

Sets the check period for the filter. (Unit: hours)

• <Off>-<100>-<200>-<400>-<800>

If the filter usage time is larger than the filter check period, the filter check message is displayed for 1 minute whenever the projector is turned on.

Filter check message: "<Check the filter, and if necessary, clean or replace it.>".

With Auto Power On, if power is supplied to the projector, it turns on automatically without your pressing the Power button.

• <Off>-<On>

With Sleep Timer on, if there is no input signal for the specified time, the projector turns off automatically.

(There must be no button input from the remote control or the top of the projector for the specified time)

• <Off>-<10 min>-<20 min>-<30 min>

To deter theft, you can set a password that users must enter when the projector powers on. When you set a password, the projector will not work without it.

• <Power On Protection>

• <Off> : Enter your current password and set the protection function to off.

• <On> : Enter a new password and set the protection function to on.

• <Change Password> : Change your current password.

Use the displayed number keys to enter or change the password.

You can disable the buttons on the projector body so that the proj ector can only be ope rated by the remote control.

• <Off> - <On>

You can check external source signals, picture setup, and PC picture adjustment.

Using 3-5

4 Troubleshooting

4-1 Before Requesting Service

Please check the following before requesting After-Sales service. If the problem continues, please contact your nearest

Samsung Electronics Service Center.

Installation and

Connection

Menu and

Remote

Control

Symptoms

No Power.

I want to install my projector on the ceiling.

External Source can not be selected.

Remote control does not work.

I cannot select a menu.

Troubleshooting

Check the power cable connections.

The ceiling installation bracket is sold separately. Contact your local product distributor.

Be su re that the video cable or cables are properly connected to the correct jack or jacks on both ends. I f the device is not connected properly, it can not be selected.

Be sure that the proper external source is selected.

Check the battery in the remote. If there is something wrong with it, replace it with a new battery of the recommended size.

Be sure to aim the remote at sensor on the back of the unit and at a distance of no more than approximately 32.8 feet(10 m).

Remove any obstacles between your remote control and the product.

Direct light from 3-way light bulbs or other lighting devices on the remote sensor of the projector may affect the sensitivity and cause the remote control to malfunction.

Check if the remote control battery compartment is empty.

Check whether the LED indicator on the top of the projector is turned on.

Check if the menu is displayed in gray. Gray-colored menu items are unavailable.

4-1 Troubleshooting

Screen and

External

Source

Symptoms

Cannot see picture images.

Poor color.

Images are not clear.

Strange noise.

An operating LED is lit.

Lines appear on screen.

No external device screen is displayed.

Only a blue screen appears.

Screen appears in black and white or in an odd color, or the screen is too dark or bright.

Troubleshooting

Be sure that the power cord of the projector is connected.

Be sure that the proper input source is selected.

Check that the connectors are properly connected to the ports at the back of the projector.

Check the Remote Control batteries.

Be sure that the <Color> and<Brightness> settings are not at their lower limit.

Adjust the <Tint> and <Contrast>.

Adjust the focus.

Check if the projector is too far from or too near to the screen.

If a strange sound continues, contact your Service Center.

Refer to Corrective Actions According to LED Indications.

On-screen noise may occur when using your PC. Adjust the frequency (refresh rate) of the screen.

Check the operating status for the external device and check whether the adjustable menu items, such as <Brightness> and

<Contrast> have been changed correctly in the <Mode> command screen of the Projector menu.

Be sure to properly connect the external devices. Check the connection cables again.

As mentioned above, check the adjustable items such as

<Brightness>, <Contrast>, or <Color> in the menu.

If you want to restore various settings to their factory defaults, run <Factory Default> from the menu.

Troubleshooting 4-1

5 More Information

5-1 Specifications

Panel

Aspect ratio

Power

Lamp

Dimension

Weight

Key Features

Input signal

Speaker

User Environment

Noise

MODEL

Size

Resolution

SP-M200S

0.55 inches 3P LCD

SVGA (800 x 600)

4:3

260 W

SP-M220S

280 W

SP-M250S

Power Consumption 300 W

Power Consumption

Life Time

Brightness

Contrast

Projection Range

Keystone

200 W 210W

3,000 Hours (Eco : 5,000 Hours )

279 x 229 x 79 mm / 10.98 x 9.02 x 3.11 inches

230W

2.5 Kg / 5.5 lbs

2,000 ANSI

500:1

2,200 ANSI 2,500 ANSI

2000:1 (Only in Dynamic of picture mode)

1 m ~ 14 m / 39.37 inches ~ 551.18 inches

Zoom Adjustment

Focus Adjustment

Screen Size (Diagonal)

Vertical( ± 20 ° )

Manual

Manual

Diagonal 30 inches ~ 400 inches

Lens

Zoom Ratio

D-Sub 15p

HDMI

RCA x 1

F=1.58 ~ 1.70, f=16.4 mm ~ 19.7 mm

1:1.2

Analog RGB, analog YPbPr

Digital RGB, digital YPbPr

Composite video

7 W (Mono)

Temperature and Humidity Operating : Temperature 41 °F ~ 95 °F (5 °C ~ 35 °C),

Humidity 20 % ~ 80 % (Non-condensing)

Storage : Temperature 14 °F ~ 140 °F (-10 °C ~ 60 °C),

Humidity 10 % ~ 90 % (Non-condensing)

Eco : 31dB, Bright : 36dB

This Class B equipment is designed for home and office use. The equipment has been registered regarding EMI for residential use. It may be used in all areas. Class A is for office use. Class A is for business while class B emits less electromagnetic waves than class A.

5-1 More Information

The LCD panel used in the LCD projector consists of hundreds of thousands of fine pixels. Like other video display devices, the LCD panel may contain bad pixels which do not operate. When shipping a product, the conditions for identifying bad pixels and the number of bad pixels that a LCD panel is allowed to contain are strictly managed in accordance with the relevant specified standards by the LCD panel manufacturer and our company. Though a screen may have some dead pixels, this does not affect the overall screen quality and the lifetime of the product.

More Information 5-1

5-2 RS232C Command Table

Communication Format (Complies with the RS232C Standard)

• Baud rate : 9,600 bps

• parity : None

• Data bits : 8, stop bit : 1

• Flow Control : None

Serial Communication Protocol

1.

Command Packet Structure [7bytes]

0x08 0x22 cmd1 cmd2 cmd3 value

• A command packet consists of 7 bytes in total.

• The two bytes 0x08 and 0x22 signify that the packet is for serial communication.

• The following 4 bytes represent a pre-defined command that can be defined by the user.

• The last byte is the checksum which checks the validity of the current packet.

CS

• Header [2 Byte]: Pre-defined values fixed to 0x08 and 0x22.

• Cmd1 [1 Byte]: The first value of the code defined in the command list (Hexadecimal)

• Cmd2 [1 Byte]: The second value of the code defined in the command list (Hexadecimal)

• Cmd3 [1 Byte]: The third value of the code defined in the command list (Hexadecimal)

• Value [1 Byte]: Input parameter for the command (Default: 0) (Hexadecimal)

• CS [1 Byte]: Checksum (the 2’s complement of the sum of all the values except for the CS value.)

2.

Response Packet Structure [3 Bytes]

1.

Success

2.

Fail

0x03 0x0C 0xF1

0x03 0x0C 0xFF

• When the received packet from an external device has a valid value, a Success packet is sent. Otherwise, a Fail packet is sent.

• A Fail packet is sent if:

• The received packet length is not equal to 7 bytes.

• The 2 byte packet header value is not equal to 0x08, 0x22.

• The check sum is incorrect.

• Failure detection by an external device

• An external device classifies the packet as Fail if it does not receive a Success packet within 100ms.

5-2 More Information

Command Table

General

Input

Power

Mute

Blank

Still

CONTROL ITEM

Volume

Power

Direct Volume

Continuous Up

Down

On

Off

On

Off

On

Off

(0~9)

CMD1

Display OSD

/ Power On

OK

Cancel

Direct Power

Off

0x00

0x01

0x02

0x03

0x04

0x05 Power On

Protection

Source List 0x0A AV

PC

HDMI

AV

PC

HDMI

CMD2

0x00

CMD3

0x00

0x00

0x00

0x00

0x00

0x00

0x00

0x00

0x01

0x02

0x00

0x00

0x00

0x00

0x01

0x03

0x04

0

0

0

0

1

0

0

0

1

0

1

(0~9)

0

VALUE

1

2

3

(0~100)

More Information 5-2

Picture Mode

Contrast

Brightness

Sharpness

Color

Tint (G/R)

Color Tone

WB

CONTROL ITEM

Dynamic

Standard

Presentation

Text

Movie

Game

User

0~100

0~100

0~100

0~100

G50 / R50

Cool2

Cool1

Warm1

Warm2

R offset

G offset

B offset

R gain

G gain

B gain

CMD1

0x0B

CMD2

0X00

CMD3

0x00

0X02

0X03

0X04

0X05

0x06

0x0A

0x0B

0x00

0x00

0x00

0x00

0x00

0x00

0x00

0x01

0x02

0x03

0x04

0x05

VALUE

3

4

1

2

(0~100)

(0~100)

(0~100)

(0~100)

2

3

0

1

4

5

6

(0~100)

(0~100)

(0~100)

(0~100)

(0~100)

(0~100)

(0~100)

5-2 More Information


CONTROL ITEM

Gamma

Save

-3~3

Display OSD

OK

Cancel

Direct Save

Reset

Size

Digital NR

Black Level

Overscan

Film Mode

PC

Normal

Zoom1

Zoom2

16:9

Off

On

0 IRE/NOR-

MAL

7.5 IRE/LOW

Off

On

Off

Auto

Auto adjustment

Coarse fine

Reset

UP

DOWN

Up

DOWN

Display OSD

OK

Cancel

Direct Reset

Zoom x1 x2 x4 x8

LEFT

RIGHT

Up

Down

CMD1

0x0B

CMD2

0x0C

0x0D

0x0E

0x0F

0x10

0x11

0x12

0x13

0x14

0x15

0x16

0x17

0x18

0x19

CMD3

0x00

0x00

0x00

0x00

0x00

0x00

0x00

0x00

0x00

0x00

0x00

0x00

0x00

0x00

0

1

0

1

0

1

VALUE

0

1

3

0

1

2

(0~6)

0

0

1

2

3

0

1

2

3

0

3

1

2

3

0

1

2

1

0

0

1

0

More Information 5-2


CONTROL ITEM

Horizontal

Position

Continuous

Vertical Position

Continuous

LEFT

RIGHT

DOWN

Up

CMD1

0x0B

CMD2

0x1A

CMD3

0x00

0x1B 0x00 0

1

0

1

VALUE

5-2 More Information

Setup

More Information

CONTROL ITEM CMD1 CMD2 CMD3 VALUE

Install

Lamp Mode

Keystone

Background Logo

Blue

Black

Test Pattern

Video Type

Reset

Front-Floor 0x0C

Front-Ceiling

ECO

Bright

0x00 0x00

Rear-Floor 2

Rear-Ceiling 3

0x01 0x00

0

1

0

2

V-Keystone

Auto Keystone

-50~50

Off

On

0x02 0x00

0x02

0x03 0x00

1

0

(0~100)

0

Crosshatch

Screen size

Pattern Off

Auto

RGB(PC)

RGB(AV)

YPbPr(AV)

PC

AV

Factory

Default

Display OSD

Ok

Cancel

0x04

0x05

0x06

0x00

0x00

0x00

1

2

0

1

2

0

1

2

3

4

5

0

1

2

3

Reset Filter

Time

Direct Factory Default

Display OSD

Ok

Cancel

0x01 0

1

2

3

Caption Caption

Direct Reset

Filter Time

Off 0x07 0x00

Mode

Channel

On

Caption

Text

1

0x01

0x02

0

1

0

Field

2

1

2

0x03

1

0

1

0

1

5-2

Option

CONTROL ITEM

Language English

Deutsch

Nederlands

Español

Français

Italiano

Svenska

Português

Русский

中国语

한국어

Türkçe

ไทย

Menu Option Position

Transparency

Display Time 5 sec

10 sec

30 sec

60 sec

90 sec

120 sec

Stay On

LEFT

RIGHT

UP

DOWN

High

Medium

Low

Opaque

CMD1

0x0D

CMD2

0x00

CMD3

0x00

0x01

0x02

0x03

0x00

0x00

0x00

6

7

4

5

8

9

2

3

0

1

10

4

5

2

3

6

0

1

2

3

0

1

2

3

0

1

11

12

VALUE

5-2 More Information

Option Sound

CONTROL ITEM

100Hz

300Hz

1KHz

3KHz

10KHz

Filter Check

Time

Off

100

200

400

Auto Power

ON

800

Off

On

Sleep Timer Off

10 min

20 min

30 min

Information

Panel Lock Off

On

Up

Down

Up

Down

Up

Down

Up

Down

Up

Down

CMD1

0x0D

CMD2

0x04

CMD3

0x01

0x05

0x06

0x07

0x08

0x0A

0x02

0x03

0x04

0x05

0x00

0x00

0x00

0x00

0x00

4

0

2

3

0

1

0

1

0

1

0

1

0

1

0

1

0

1

3

0

1

2

1

0

VALUE

More Information 5-2

5-3 Contact SAMSUNG WORLDWIDE

• If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center.

U.S.A

CANADA

MEXICO

NORTH AMERICA

1-800-SAMSUNG(726-7864)

1-800-SAMSUNG(726-7864)

01-800-SAMSUNG(726-7864) http://www.samsung.com

http://www.samsung.com

http://www.samsung.com

ARGENTINA

BRAZIL

CHILE

COLOMBIA

COSTA RICA

ECUADOR

EL SALVADOR

GUATEMALA

HONDURAS

JAMAICA

NICARAGUA

PANAMA

PUERTO RICO

REP. DOMINICA

TRINIDAD & TOBAGO

VENEZUELA

AUSTRIA

BELGIUM

CZECH

LATIN AMERICA

0800-333-3733

0800-124-421

4004-0000 http://www.samsung.com

http://www.samsung.com

800-SAMSUNG(726-7864) http://www.samsung.com

01-8000112112 http://www.samsung.com

0-800-507-7267

1-800-10-7267 http://www.samsung.com

http://www.samsung.com

800-6225

1-800-299-0013 http://www.samsung.com

http://www.samsung.com

800-7919267 http://www.samsung.com

1-800-234-7267 http://www.samsung.com

00-1800-5077267

800-7267

1-800-682-3180

1-800-751-2676

1-800-SAMSUNG(726-7864)

0-800-100-5303 http://www.samsung.com

http://www.samsung.com

http://www.samsung.com

http://www.samsung.com

http://www.samsung.com

http://www.samsung.com

EUROPE

0810 - SAMSUNG(7267864,€ 0.07/min) http://www.samsung.com

02-201-24-18

800 - SAMSUNG (800-726786) http://www.samsung.com/be (Dutch) http://www.samsung.com/be_fr

(French) http://www.samsung.com

DENMARK

EIRE

ESTONIA

FINLAND

FRANCE

5-3

70 70 19 70

0818 717100

800-7267

030 - 6227 515

01 48 63 00 00 http://www.samsung.com

http://www.samsung.com

http://www.samsung.com

http://www.samsung.com

http://www.samsung.com

More Information

ARMENIA

AZERBAIJAN

BELARUS

GEORGIA

KAZAKHSTAN

KYRGYZSTAN

MOLDOVA

RUSSIA

TADJIKISTAN

UKRAINE

UZBEKISTAN

AUSTRALIA

CHINA

HONG KONG

GERMANY

HUNGARY

ITALIA

LATVIA

LITHUANIA

LUXEMBURG

NETHERLANDS

NORWAY

POLAND

PORTUGAL

SLOVAKIA

SPAIN

SWEDEN

SWITZERLAND

U.K

More Information

EUROPE

01805 - SAMSUNG (726-7864,€ 0,14/

Min)

06-80-SAMSUNG(726-7864) http://www.samsung.com

800-SAMSUNG(726-7864)

8000-7267

8-800-77777

261 03 710 http://www.samsung.com

http://www.samsung.com

http://www.samsung.com

http://www.samsung.com

http://www.samsung.com

http://www.samsung.com

0900 - SAMSUNG (0900-7267864) (€

0,10/Min)

815-56 480

0 801 1SAMSUNG (172678)

022 - 607 - 93 - 33

80820 - SAMSUNG (726-7864) http://www.samsung.com

http://www.samsung.com

0800-SAMSUNG(726-7864)

902 - 1 - SAMSUNG (902 172 678)

0771 726 7864 (SAMSUNG)

0848-SAMSUNG(7267864, CHF 0.08/ min) http://www.samsung.com

http://www.samsung.com

http://www.samsung.com

http://www.samsung.com

http://www.samsung.com/ch http://www.samsung.com/ch_fr (French)

0845 SAMSUNG (7267864) http://www.samsung.com

CIS

0-800-05-555

088-55-55-555

810-800-500-55-500

8-800-555-555

8-10-800-500-55-500

00-800-500-55-500

00-800-500-55-500

8-800-555-55-55

8-10-800-500-55-500

0-800-502-000

8-10-800-500-55-500 http://www.samsung.com

http://www.samsung.com

http://www.samsung.com

http://www.samsung.com/ua http://www.samsung.com/ua_ru http://www.samsung.com

ASIA PACIFIC

1300 362 603

400-810-5858

010-6475 1880

(852) 3698 - 4698 http://www.samsung.com

http://www.samsung.com

http://www.samsung.com/hk http://www.samsung.com/hk_en/

5-3

INDIA

INDONESIA

JAPAN

MALAYSIA

NEW ZEALAND

PHILIPPINES

SINGAPORE

TAIWAN

THAILAND

VIETNAM

BAHRAIN

JORDAN

SOUTH AFRICA

TURKEY

U.A.E

ASIA PACIFIC

3030 8282

1800 110011

1800 3000 8282

1800 266 8282

0800-112-8888

021-5699-7777

0120-327-527

1800-88-9999

0800 SAMSUNG (0800 726 786)

1-800-10-SAMSUNG(726-7864)

1-800-3-SAMSUNG(726-7864)

1-800-8-SAMSUNG(726-7864)

02-5805777

1800-SAMSUNG(726-7864)

0800-329-999

1800-29-3232

02-689-3232

1 800 588 889

MIDDLE EAST & AFRICA

8000-4726

800-22273

0860-SAMSUNG(726-7864)

444 77 11

800-SAMSUNG(726-7864) http://www.samsung.com

http://www.samsung.com

http://www.samsung.com

http://www.samsung.com

http://www.samsung.com

http://www.samsung.com

http://www.samsung.com

http://www.samsung.com

http://www.samsung.com

http://www.samsung.com

http://www.samsung.com

http://www.samsung.com

http://www.samsung.com

5-3 More Information

5-4 Correct Disposal - Europe only

Correct Disposal of This Product (Waste Electrical & Electronic Equipment) - Europe only

(Applicable in the European Union and other European countries with separate collection systems)

This marking on the product, accessories or literature indicates that the product and its electronic accessories

(e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources.

Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take these items for environmentally safe recycling.

Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic accessories should not be mixed with other commercial wastes for disposal.

Correct disposal of batteries in this product - Europe only

(Applicable in the European Union and other European countries with separate battery return systems.)

This marking on the battery, manual or packaging indicates that the batteries in this product should not be disposed of with other household waste at the end of their working life. Where marked, the chemical symbols Hg,

Cd or Pb indicate that the battery contains mercury, cadmium or lead above the reference levels in EC Directive

2006/66. If batteries are not properly disposed of, these substances can cause harm to human health or the environment.

To protect natural resources and to promote material reuse, please separate batteries from other types of waste and recycle them through your local, free battery return system.

More Information 5-4

5-4 More Information

advertisement

Was this manual useful for you? Yes No
Thank you for your participation!
