I S TREAM HD

Wireless 300N Media Adapter

USER MANUAL

MODEL 525282

INT-525282-UM-0212-01

TABLE OF CONTENTS

INTRODUCTION .......................................................................................... 3

What Is the iStream HD Adapter? ............................................................... 3

Package Contents ..................................................................................... 3

HARDWARE OVERVIEW ................................................................................ 4

Device Status LEDs ................................................................................... 5

RJ45 Network Port .................................................................................... 6

WPS Push-Button ..................................................................................... 6

Power On / Off Switch ............................................................................... 6

Power Outlet Connector ............................................................................. 6

INSTALLATION ............................................................................................ 7

Installation Using WPS .............................................................................. 7

Manual Installation ................................................................................... 9

ADVANCED CONFIGURATION MENU ............................................................. 13

Setting Up Your Computer’s Network Adapter ............................................. 13

Accessing the Advanced Configuration Menu .............................................. 17

Advanced Configuration Menu Options ....................................................... 19

TROUBLESHOOTING .................................................................................. 24

ADDENDUM .............................................................................................. 27

PlayStation3 Network Setup ..................................................................... 27

Xbox 360 Network Setup ......................................................................... 27

Wii Network Setup .................................................................................. 28

SPECIFICATIONS ...................................................................................... 29

SAFETY AND REGULATORY NOTICES ............................................................ 30

WARRANTY INFORMATION ......................................................................... 31

- 2 -

INTRODUCTION

What Is the iStream HD Adapter?

Thank you for purchasing the Intellinet Network Solutions iStream HD™ Wireless

Media Adapter. The iStream HD is the ideal solution for connecting your Web TV

(IPTV), gaming console or other Ethernet-ready media device to your wireless home network. The iStream HD eliminates the need to locate your gaming system or other entertainment devices near an Internet connection, and because it uses a

Cat5e / Cat6 cable to connect to your device, there’s no need to use up one of your valuable USB ports. Setup is incredibly easy, and the iStream HD works with all gaming systems, as well as all IPTVs, DVRs, Blu-ray players and other such devices with an Ethernet port.

The iStream HD allows you to enjoy a completely lag-free online gaming experience from your Xbox 360, PS2, PS3 or Wii system, or watch streaming video in full HD (10 80p with 5.1 stereo surround) on such services as Netflix, Hulu or

YouTube via your Web-ready HDTV, Blu-ray player or other media device. Even better, the iStream HD is quick and easy to set up.

Package Contents

- iStream HD Wireless Media Adapter

- Ethernet Cat5 RJ45 cable

- Quick installation guide

- Installation CD with user manual (this document)

- 3 -

HARDWARE OVERVIEW

- 4 -

e Status

The iStre interface if the LED eam adapt e. See cha

Ds do not

they have ter allows pter “Con

light up t e been dis

disabling figuration there is no sabled. s complete

” for detail o need to ls. So, may be because

Signal:

D indicates on. connectio

Steady o

Flashing

The qual downs an represen

slowly: Lo ity of the nd lag. If nts a probl ow signal

wireless s you want lem.

50%).

reception signal is s

to stream

. t the conn r play onl subject to ine games is

Flashing

The sign with you intermitt al quality r wireless tent at bes

iStream i al receptio w. The iStr sn’t conne

If there i pter canno s any com ny wireles on at all, y commun it will be nicate

WLAN:

When th operating adapter

Power:

The Pow reset, th

This LED g normally

WPS:

If this LE network

LAN: is LED flas is connect y. The LED er LED is e Power L on during

LED starts

normal o

flashing b

ED is lit, it

via WPS (

D must ligh of a Web etwork. t means th

(Wi-Fi Pro eans that hat the iSt tected Se n the iStre

V, Blu-ray player or h, regardl tream ada tup. Read ess radio ess of wh

of the iSt ether or n ream ada not the iSt apter is co d more on pter is con console. nected to pter is tream to a wirele

this below ess work port

- 5 -

RJ45 Network Port

The iStream adapter is equipped with a high-speed network port, which is designed to connect your Internet-ready TV, Blu-ray player or gaming console to the iStream adapter. You can use the included network cable for that purpose. Of course, should you require a longer connection between the iStream adapter and your device, it is no problem to use any standard Ethernet network cable that meets or exceeds the Cat5 specification. If you are not sure about this, don’t worry. Any standard network cable purchased from various retailers or online shops will work just fine.

WPS Push-Button

Wi-Fi Protected Setup (WPS) is a computing standard that attempts to allow easy establishment of secure wireless home-network connections. Created by the Wi-Fi

Alliance and introduced in 2007, the goal of the protocol is to allow home users who know little of wireless security and may be intimidated by the available security options to set up the encryption method WPA2, as well as making it easy to add new devices to an existing network without entering long passphrases.

So, what does this all mean for you? If your wireless router is a newer device, there is a good chance that it is equipped with a WPS push-button, in which case you are in luck, because adding the iStream adapter to your network will just be a matter of a couple of minutes. If the router is a little bit older and does not support WPS, it will take a little bit longer.

Power On / Off Switch

When it’s not in use, you can power down the iStream adapter to save energy.

Since the connection to your wireless network is re-established in less than a minute after startup, there are no downsides to powering down the iStream adapter when it is not used.

Power Outlet Connector

The iStream adapter plugs directly into a power wall outlet. It supports 110V 60

Hz for U.S. and 230V 50 Hz for European power outlets. The plug type will vary, depending on your location. The illustration above depicts the U.S. version of the iStream adapter.

- 6 -

The iStre involves method) eam Media and it is

the befor

uses a m only a ma manual m e-mention more tradit atter of co method, p up process your route

while the tional setu onvenience provided y

can be in ned WPS, stalled in one of tw

second (w s. Both wa hy you wo r supports

The first w the manu ays lead to ould use W way o the sam

WPS over t al e result, the

N-connec pushing

1

2

3 wireless ro

Pl

M ons. ug the iSt ake sure t

“O

Co ne on. uipped wi onnect the apter into ower swit ith a WPS e iStream

button (s

HD to you the wall o tch is set t outlet. to the onnect the etwork po e patch ca rt on the able (red) to the RJ4 iStream H

45 r. th

Bl de

Co

No k port of y u-ray play evice. e other en

ote: That network ca or other E hould be t ng consol able to ready urned off.

e,

.

3 sometimes ur network s referred k literally

Ethe

to as just by

1

2

y device on, WII, eb-ready yer, etc.)

- 7 -

4

5

6

7

On bu of outer. wo minute st f the WPS ress the W ep 4. uter, locat e picture il n an Intell s to comp

On fo nce steps llowing th

• The W

• The s

• The W

• After will g

• About ess the WP llustrates the locatio linet wirel n on the iS

5 after fin ess dapter for

WPS LED w

WPS that t been

4 and 5 a

a few sec o out. t 10 to 15 happen.

WPS LED w ignal LED will come will stay o conds, bot

5 seconds

LEDs will the wireles

successfu briefly. come bac e on. ully establi n. h the Sign h the Sign k on, and ished.

stay on, our networ al and g in ad sh

Th re de he final ste eady devic evice to bo formation dapter sho hould have ower on y ould be lit e network a few minu d obtain it

N LED on t rnetm HD

the device net access he k the iStream

now and k or Intern utes for th ts network e

.

Ethernet

(Xbox, P

TV, Blu-r nds. You laystation,

4 have

5

6

vice

WII, ready etc.)

7

- 8 -

Manua l Install lation

eed to inst g items be

1. Yo as tall the iSt efore you c u need to

the SSID

know the

). tream HD can begin

adapter m

.

your wire

you will n also refer red to

2. If y kn wh your wirel ow what t

Hin hen you co

3. A d tha

Int he same p ork is prot that passw password y your wire you need less netwo ption key, on your la e first tim d to ptop or ta e. ablet

1

2

Plu

Ma po po desktop or at has a st plorer). ug the iStr ake sure th sition.

ote: Your int. running M ser installe adapter in ower switc computer should be icrosoft W all outlet. ch is set to x, Safari,

”

Mac OS or

Chrome o r Linux, or

Co net nnect the twork cab

iStream H the compu r compute allow it to r’s LAN us

finish boo ncluded

- 9 -

3

4

Lau it t fai htt

A p as unch your to http://i ls, you ca tp://192.1

r Web brow streamset n also ent

168.2.254

wser and tup. In ca ter

. direct se this

Yo password window w

the passw ey in user name “ad

with the first page of the wi reless con

“1234”

Th e page sh e network you wish network do ca se, you can ireless net

to connec tworks cu ct to, and es not show am HD ada rrently in

then click ou need to k “Next.” gnal strengt pter to a dif th may be o select u may use am adapter wir er. a longer ne r in order to e between iStream HD the Ethern et device e

- 10 -

5

If y pre wir ess netwo with the sc reless netw reen belo e. ured by an w. Enter t n encrypti the passw on key, y word (pass ou will be or your me passwor rd that you a ny compute p assword en member th at the pass s network. I If the pter will no ect o ot

6

Ne the rocess. wn the fin al confirm Apply” to finish

7

Th

Sig e iStream HD will r gnal LED w estart now indicating e new sett e wireless tings. Onc connectio ce complet on. ted, the

- 11 -

8

Re mputer’s L net ray move the twork por y player, I

Eth

Ne sta

If a con ady device ext, power

network

LAN port a art up com all goes w nnected to cable from e. ect to the gaming co eady TV o device wil work or In l now be ternet. er to

Ethernet vice

WII, ready

TV, Blu-r ray player, etc.)

- 12 -

ADVA CONFIG

This chap

Wireless pter expla

Media Ad ains the ad dapter.

ENU

ion menu of your iS need to acc ess these f disable t the LEDs. A upgrade is s with the a dapter.

Addition ally, access nfiguration requires ad wish to upgr rade the vanced sett ings, or f you experi ience er system, the concep resses, and settings of your net twork adapt ter.

P

puter’s rk Adapt

The iStre access th in your c instructio address eam HD o he advanc computer ons that c on the ne not expla perates on has to be ained in th

in the sam ame with twork ada n the IP a me range

your com his user m uration in ddress 19 terface, th

Windows

1. Open s 7: the Netwo haring Ce nter.

92.168.2.2

he IP addr

;

informati our compu

e.g., 192 puter to k adapter

0. Refer t o the w to chang ny operati m that is

2. Click o

3. Right-

- 13 -

“Properti es.”

4. Select “Internet Protocol Version 4” from the list and click “Properties.”

5. Enter the information as shown below, and then click “OK” to save the settings.

Windows XP:

1. Double-click the “Network Connections” icon in the control panel.

2. Right-click the connection (e.g., Local Area Connection) and select “Properties.”

3. Select “Internet Protocol (TCP/IP)” from the list and click “Properties.”

- 14 -

4. Enter the information as shown below, and then click “OK” to save the settings.

Mac OS X:

1. Open the “System Preferences” page.

2. In the Internet & Network section, click the Network icon.

3. Select either Built-in Ethernet or Airport, depending on how you connect to the

iStream adapter, then click “Configure… .”

- 15 -

4. Set the value for Configure IPv4 to “Manually” and enter 192.168.2.50 in the

IP Address field. Click “Apply Now” (not shown in screen shot) to save the

settings.

- 16 -

Accessing the Advanced Configuration Menu

Open a Web browser and go to the page http://istreamsetup. In case this link does not work, try http://192.168.2.254.

A password request window will open up. The default user name is “admin”; the default password is “1234.” It is recommended to change the password in the advanced settings.

MSIE

Firefox

- 17 -

Next, you’ll be looking at the main screen of the iStream HD interface.

This page provides information about the operational status of the device. It shows to which wireless network the iStream HD adapter is currently connected to, which firmware or runtime code is installed and other information.

The page also allows checking to see if a new firmware version is available for your iStream HD adapter. Simply click on the “check for new version” link to do that. Note that your computer must be connected to the Internet for this function to work properly.

- 18 -

Advanced Configuration Menu Options

The Quick Setup pages allow connecting the iStream HD to a wireless network.

Refer to chapter “Installation -> Manual Installation” for details.

Item

Fragment Threshold

RTS Threshold

Channel Width

WMM

Description

The fragmentation threshold is used to set the maximum size of a packet that a client will send. The smaller the maximum sizes, the better the reliability of the wireless connection — but the performance is likely to decrease. Leave this value as 2346 unless you have a very poor wireless signal. Lowering the value can help improve the connection in such cases.

In case you experience poor wireless performance, you can try using values between 1200 and 500, and below 500 in severe cases. The default value is 2347, and that should normally not be modified.

Select the wireless channel width. 40MHz provides better network speed for 802.11n wireless clients. “Auto 20/40 MHz” is the recommended value.

Enable or disable Wireless Multi-Media. When enabled, this device will give priority to multimedia-related network applications so they will have better performance. It is recommended to leave this option enabled.

If you wish to deactivate the LEDs of the iStream HD, you can do so here. You have the choice of either turning off all LEDs or all but the Power LED.

- 19 -

Password settings:

By default, accessing the iStream HD advanced configuration does not require a password. To prevent someone from overwriting some settings, you can enter a new password here.

Current Password: Enter the current password (default = 1234) here.

New Password: Type in the new password.

Re-Enter password: Type in the new password again.

Management IP:

The default IP address for the iStream HD is 192.168.2.254.

The IP address of the adapter does not necessarily need to be in range of the wireless network. The IP address range has no impact on the function of the device. However, if you wish to adjust the IP address to make accessing the configuration interface easier — e.g., because your wireless network range is

192.168.0.xxx — then you can make changes to the address here.

Click “Apply” to save the settings.

- 20 -

The Restore to Factory Default function should be used if you wish to overwrite the entire configuration with the original factory default values. This is recommended after you upgrade the firmware.

Click the “Reset” button to start the process and confirm your decision by clicking

“OK” when you see this dialog:

From time to time there may be new firmware available for the iStream HD.

In order to install new firmware, proceed as follows:

1. Click “Browse…” to locate the firmware (.BIN file).

2. Click “Apply.”

3. Confirm the message “Do you wish to begin the firmware upgrade?”

4. Confirm the second message shown below:

5. The upgrade will begin now. During the process the iStream HD will display

several messages for you.

- 21 -

After the upgrade you should reset the iStream HD to factory default values (see above).

In the event that the iStream HD seems to be performing poorly, a reboot of the adapter may help resolve the problem. The System Restart function is designed to let you do exactly that without physically touching the device.

Click “Apply” to restart the iStream media adapter.

Click “OK” to continue.

- 22 -

FACTORY RESET

The iStream HD Wireless Media Adapter can be reset to the original factory default settings two ways.

Option 1: Factory reset via advanced configuration menu.

See chapter “Advanced configuration menu options” for details.

Option 2: Hardware reset

The iStream HD adapter must be powered on. Push the WPS button for 15 seconds, and then release it. The iStream HD will reboot and will have reverted to the original factory default settings.

Factory default values:

IP address: 192.168.2.254

Administrator user name: admin

Administrator password: 1234

Wireless: disconnected

- 23 -

TROUBLESHOOTING

Symptom

The Power LED is not lit.

The LAN LED does not light up.

The WPS LED does not light up.

The WLAN LED is not lit.

The Signal LED is off.

The hardware reset is not working.

My router has a WPS button, but the WPS setup does not work as described in this manual.

I don’t know the password of my wireless network and cannot connect the iStream HD adapter to my network.

My TV, Blu-ray player or gaming console does not have a network port. How do I connect the iStream HD?

How to address

Make sure that the power switch on the iStream HD is set to the

“On” position. In addition, check and make sure that the power outlet provides power.

Check the network connection between the iStream HD and the

Ethernet port of the device you’re connecting. The network cable must be inserted properly and the Ethernet device must be turned on. Try using a different network cable, if available.

The WPS LED lights only if an existing wireless connection was established by means of WPS. If you created the connection manually, or if no wireless connection has been set up, the WPS

LED will stay off.

The WLAN LED should always light, whether a wireless connection has been established or not. It essentially indicates that the wireless module has started successfully. If the LED is off, yet you have a working wireless connection, the LED may simply have failed. If you cannot connect to any wireless network, the iStream adapter needs to be replaced through your dealer (place of purchase).

Whenever the iStream HD is connected to a wireless network, or is in the process of connecting, the Signal LED will light. If the Signal LED is off, it means that the iStream HD has not been configured to access any network.

The WPS button needs to be pressed firmly for 15 seconds while the iStream HD is powered on. If it still does not work, it either means that the WPS button is malfunctioning or that you are doing it wrong.

WPS may be disabled in the router settings, or you have not pressed the WPS button on the iStream HD within 120 seconds of pushing the button on the router.

Refer to the section “Manual Installation.”

If the wireless network is password-protected, then you can either connect the iStream HD via WPS (should your wireless router support it) or manually by entering the wireless passphrase. If you have forgotten the password, there is no way of connecting the iStream HD to your wireless network. Your only way out is to set up your wireless network with a new password.

You can’t — with one exception: the Nintendo Wii. iStream HD is designed for devices with integrated Ethernet

RJ45 network ports. The Nintendo Wii does not have an RJ45 port; therefore, connecting the Wii console to the iStream HD requires the use of the Wii LAN adapter (sold separately).

NOTE: Non-Nintendo–manufactured USB LAN adapters will not work with the Wii console system. The Wii LAN adapter plugs into the Wii console's USB port and allows the connection of a device to the Wii console via an Ethernet cable.

See the Nintendo website (www.nintendo.com) for details.

- 24 -

Symptom

Can I use the iStream HD as a wireless adapter for my computer?

The signal LED flashes rapidly and there is no wireless connection for my

Web-ready TV or gaming console.

The Signal LED flashes slowly and the network connection for my Webready TV or gaming system seems slow.

Netflix movies take a long time to start playing.

The iStream HD adapter is supposed to stream HD video contents, yet I only receive standard-definition contents from Netflix.

My Internet service is fast enough, yet I still experience a lot of buffering and I only receive standarddefinition video when using

Netflix or other forms of online video streaming, such as YouTube.

How to address

Indeed you can. Simply set up the iStream HD as usual and connect it to the computer’s network port when finished. iStream HD now acts as a wireless adapter for your computer.

The flashing LED means that the signal strength is too weak to create a reliable wireless connection. Try re-locating or repositioning the iStream adapter. As long as the LED keeps flashing at a rapid pace, you won’t be able to use the iStream

HD adapter in any reasonable fashion.

The wireless signal strength is not optimal. Depending on the content you are transmitting over the wireless connection, occasional slow-downs can indeed occur. To improve the performance try re-locating or re-positioning the iStream HD adapter.

That is called buffering. Depending on your Internet connection speed (main factor) and the wireless connection speed of the iStream adapter (contributing factor), the buffering can take more than a minute. What happens here is that a good chunk of the movie is pre-loaded before the playback starts, so that the movie will not pause during playback.

Rule of thumb: The slower your Internet connection speed, the longer the buffering will take. If you want instant streaming of standard definition content, your Internet download speed must be at least 2 Mbps. If you expect instant-on HD contents, speeds greater than 5 Mbps are recommended.

Netflix analyzes the connection speed between the client (your

Xbox, PlayStation, IPTV, etc.) and the Netflix server. Depending on the result of that test you will get video that is optimized for your connection speed. In order to receive Netflix HD 1080p video, your Internet connection needs to be providing a steady, low-latency connection of more than 5 Mbps.

These symptoms clearly show that connection speed between the Netflix client — for example, your Internet-ready TV — and the Netflix online service is not fast enough. There are many possible reasons for this.

1. If you are experiencing these problems mostly in the evenings and on weekends, this points to your Internet connection as the cause for the problem. While your service provider can tell you how much bandwidth is available for your service package, this bandwidth can fluctuate greatly, depending on the time of day and the service provider’s total available bandwidth for all of its clients.

There are also websites available online that you can visit that will test and measure the bandwidth that is available on your existing home network. If you perform a test on your computer and are receiving less bandwidth than expected, contact your

Internet service provider to troubleshoot the issue. One popular site is speedtest.net.

For example, if you test your connection speed in the evening and you are getting something like this …

- 25 -

… and when you repeat the test in the morning you’re getting something like this …

I experience more lag when playing online games compared to before, when my gaming console was connected with a network cable.

I am setting up my gaming console for wireless access, but it does not work. I cannot connect to the network.

How can I use the iStream with my Nintendo Wii?

.

… it means that the bottleneck is your Internet connection, and not your local wireless network. Contact your Internet service provider to troubleshoot the issue.

2. If the problems occur all the time, and your Internet connection speed is fast for computers and other devices connected directly to the wireless router, the problem can indeed be related to the iStream HD adapter and its connection speed to the wireless network. A good way to test this is to first measure your Internet speed with a computer that is connected to the router. Then connect the computer to the LAN port of the iStream adapter and repeat the test. It would be normal that the results are not quite as high, but if you experience a significant decrease, then the wireless connection between the iStream adapter and your wireless network is not optimal. Try re-locating or re-positioning the iStream HD.

3. Someone may be freeloading. Ensure that your connection is secure. You may be unknowingly sharing your connection with others nearby if using an unsecured wireless network setup.

It is not out of the ordinary for ping times to increase ever so slightly when you switch from a wired to a wireless connection.

The effects become more pronounced if the wireless connection is poor. Typically, though, online gaming will not be affected in a negative way. If you require best possible ping times and lowest possible lag without any compromises, then a wireless connection for your gaming console may not be the right choice for you. A 500 Mbps Powerline AV starter kit may serve you better in this case.

You need to set up your gaming console for regular Ethernet cable-based access, not wireless. iStream HD is a wireless device; however, as far as your gaming console is concerned, it is connected with a regular network cable. iStream is

“transparent” in the network and your gaming console does not even know it is there.

You need to connect a Wii LAN adapter to your Wii in order to connect the iStream adapter. See Addendum.

- 26 -

ADDENDUM

PlayStation3 Network Setup

1. Connect an Ethernet cable from the iStream network port to the PS3 system.

2. Select (Settings) > (Network Settings).

3. Select [Internet Connection Settings].

Select [Yes] when a confirmation screen is displayed stating that you will be disconnected from the Internet.

4. Select [Custom].

5. Select “Wired Connection” as the connection method.

6. Select “Auto-Detect.”

7. Addition settings you may need to confirm:

- IP address settings: set to “Automatic.”

- DHCP host name: set to “Do Not Set.”

- DNS settings: set to “Automatic.”

- MTU should be set to “Automatic.”

- Proxy server needs to be set to “Do Not Use.”

- UPnP should be enabled.

Xbox 360 Network Setup

1. Press the Guide button on your controller (Xbox button in the center of your controller).

2. Go to Settings, and then select “System Settings.”

3. Select “Network Settings.”

4. Select “Wired Network” if you are prompted to do so.

- 27 -

5. Select “Test Xbox LIVE Connection.”

Wii Network Setup

1. Install a Wii LAN adapter (for instructions, click here )

2. From the Wii Main Menu, select the Wii icon from the bottom left.

3. Select "Wii Settings" to access the "Wii System Settings" menu.

4. Using the arrow on the right side of the screen, scroll to page 2 and select "Internet."

5. Next, select "Connection Settings."

6. Select "Connection 1: None" NOTE: If you do not have an empty connection slot, you will need to clear one. For instructions, click here .

7. Select "Wired Connection."

8. Select "OK" on the next screen. At this point your Wii will attempt to make a connection with the iStream HD.

If the connection test succeeds, then your Wii is now connected to the Internet.

If the connection test fails, and you receive an error code, please click here for help.

If you encounter any other problems while connecting your Wii to the Internet, please contact Nintendo customer service for assistance.

- 28 -

SPECIFICATIONS

• IEEE 802.11b (11 Mbps Wireless LAN)

• IEEE 802.11g (54 Mbps Wireless LAN)

• IEEE 802.11e (QoS Enhancement WMM)

• IEEE 802.11n (300 Mbps Wireless LAN)

General

• LAN port: RJ45 10/100 Mbps data port

• LAN port with Auto MDI/MDI-X

• Flash: 2 MB

• Memory: 16 MB SDRAM

• Certifications: FCC Class B, CE, RoHS

Wireless

• Wireless frequency range: 2.400 – 2.483 GHz

• Modulation technologies

- 802.11b: Direct Sequence Spread Spectrum (DSSS): DBPSK, DQPSK, CCK

- 802.11g: Orthogonal Frequency Division Multiplexing (OFDM): BPSK, QPSK, 16QAM, 64QAM

- 802.11n: Orthogonal Frequency Division Multiplexing (OFDM): BPSK, QPSK, 16QAM, 64QAM

• Data rates

- IEEE 802.11b (11 Mbps, 5.5 Mbps, 2 Mbps, 1 Mbps)

- IEEE 802.11g (54 Mbps, 48 Mbps, 36 Mbps, 24 Mbps, 18 Mbps, 12 Mbps, 9 Mbps, 6 Mbps)

- IEEE 802.11n (MCS0-15: up to 300 Mbps)

• Output power

- OFDM: 13 dBm +/- 1.5 dBm (300 Mbps, 20 mW max.)

- OFDM: 14 dBm +/- 1.5 dBm (54 Mbps, 25 mW max.)

- CCK: 17 dBm +/- 1 dBm (11 Mbps, 63 mW max.)

• Receiver sensitivity

- 11n (300 Mbps) MCS0-15: 20 MHz: -67 dBm; 40MHz: -63 dB (+/- 2 dBm)

- 11g (54 Mbps) OFDM: -70 dBm (+/- 2 dBm)

- 11b (11 Mbps) CCK: -85 dBm (+/- 2 dBm)

• Wireless security

- WEP encryption (64/128 bit)

- WPA TKIP

- WPA2 AES

- WPA2 mixed

• Antennas

- 2 internal printed antennas with 3 dBi gain each

- 2T2R MIMO mode (2 transmitters, 2 receivers)

Power

• Internal power adapter: 5 V DC, 1.0 A

• Power consumption: 4 Watts max.

Environmental

• Dimensions: 46.5 (W) x 73 (H) x 41 (D) mm (1.8 x 2.9 x 1.6 in.)

• Weight: 0.45 kg (1.0 lb.)

• Operating temperature: 0 – 40°C (32 – 104°F)

• Operating humidity: 10 – 90% RH, non-condensing

• Storage temperature: -20 – 60°C (4 – 149°F)

Package Contents

• iStream HD Wireless Media Adapter

• Quick install guide

• User manual

• Ethernet Cat5 RJ45 cable: 1.0 m (3 ft.)
