Table of Contents
CHAPTER 1 INTRODUCTION ................................................................................... 2
1.1
PACKAGE CONTENTS ............................................................................................. 2
1.2
KNOW YOUR ZVC7610.......................................................................................... 3
1.3
FEATURES AND BENEFITS ...................................................................................... 4
1.4
SYSTEM REQUIREMENTS ........................................................................................ 5
CHP ATER 2 HARDWARE INSTALLATION ............................................................ 6
2.1
CAMERA STAND INSTALLATION ............................................................................... 6
2.2
CONNECTING ZVC7610 TO YOUR NETWORK ........................................................... 7
2.3
ZVC7610 APPLICATION EXAMPLE .......................................................................... 8
CHAPTER 3 ACCESS YOUR ZVC7610................................................................... 9
3.1
USE IP FINDER ...................................................................................................... 9
3.2
LOGIN TO YOUR ZVC7610 ................................................................................... 10
3.3
IP ADDRESS CONFIGURATION ............................................................................... 12
CHAPTER 4 ZVC7610 CONFIGURATION ............................................................ 13
4.1
USING THE WEB BROWSER .................................................................................. 13
4.2
USING SMART WIZARD ......................................................................................... 14
4.3
BASIC SETUP ...................................................................................................... 16
4.4
NETWORK SETTINGS ............................................................................................ 17
4.5
VIDEO SETUP ...................................................................................................... 20
4.6
EVENT SERVER CONFIGURATION .......................................................................... 22
4.7
MOTION DETECT .................................................................................................. 23
4.8
EVENT CONFIG .................................................................................................... 24
4.9
TOOLS ................................................................................................................ 26
4.10 INFORMATION ...................................................................................................... 27
CHAPTER 5 APPENDIX ............................................................................................ 28
A.1 SPECIFICATION .................................................................................................... 28
A.2 GLOSSARY OF TERMS .......................................................................................... 29
-1-
Chapter 1
Introduction
Thank you for purchasing ZVC7610, a powerful and high-quality image IP camera.
ZVC7610 can be installed as a standalone system within your application environment
easily and quickly, and supports remote management function so that you can access and
control it using a Web browser on your computer.
1.1 Package Contents
Check the items contained in the package carefully before installation.
One ZVC7610
One AC Power Adapter
One Camera Stand.
One RJ-45 Ethernet Cable
One Installation CD w/ User Manual
One Quick Installation Guide.
NOTE: Contact your local authorized reseller or the store purchased from for any items
damaged and/or missing.
-2-
1.2 Know Your ZVC7610
Power LED indicates
ZVC7610 is power ON
with the steady amber
light.
Link LED indicates
ZVC7610 network
connectivity with the
flashing green light.
Lens Assembly
Front View
Screw Hole is
used to connect
your ZVC7610 to
the camera stand.
Power Connector
Connects the AC
Power Adapter
Reset Button will reset the
ZVC7610. Press and hold
the button for 5 seconds to
the factory default settings.
Rear View
-3-
Ethernet Cable Connector is
used to connect the RJ-45
Ethernet cable which supports
the NWay protocol for the
ZVC7610 to detect the network
speed automatically.
1.3 Features and Benefits
Surveillance Supported
ZVC7610 supports “nightshot mode” to deliver clearer images in the dark environment.
Enable motion detection and setup automated email alerts and upload FTP for security.
Remote Control Support
Use your standard web browser or the bundled software “Ultra View”, an administrator
can easily change the configuration of ZVC7610 over the network. In addition,
ZVC7610 can be upgraded remotely when a new firmware is available. Normal users
can also monitor the image and take snapshots via the network.
External Devices Support
You can connect the ZVC7610 to a variety of external devices with the auxiliary
Input/Output connectors, such as external speaker and other USB devices.
Multiple Platforms Support
ZVC7610 supports multiple network protocols – TCP/IP, SMTP, HTTP, and other
Internet related protocols. You can use it in a mixed operating system environment,
such as Windows 2000 and Windows XP.
Multiple Applications Support
Through the remote access technology, you can monitor various objects and places for
different purposes with ZVC7610. For example, babies at home, patients in the hospital,
offices, banks, and many more. ZVC7610 can capture images and video clips, and you
can save and restore them any time.
-4-
1.4 System Requirements
Networking
LAN: 10Base-T Ethernet / 100Base-TX Fast Ethernet
Accessing the Camera using Web Browser
Platform: Windows 2000/XP/Vista, Macintosh OSX
CPU: Intel Pentium III 350MHz or above
RAM: 128MB or above
VGA Resolution: 800x600 or above
Web browser support: Internet Explorer 6.0 or above, Mozilla Firefox 2.00 or above,
Apple Safari 2 or above
Accessing the Camera using Ultra View
Platform: W indows 2000/XP/Vista
Hardware Requirements
One ZVC7610:
Intel P-III 800MHz / 512MB RAM or above
Two to Four ZVC7610:
Intel P-4 1.3GHz / 512MB RAM or above
Five to Eight ZVC7610:
Intel P-4 2.4GHz / 1GB RAM or above
Nine to Sixteen ZVC7610:
Intel P-4 3.4GHz / 2GB RAM or above
VGA Resolution: 1024x768 or above
NOTE: If you connect multiple ZVC7610 to monitor different places in the same time, we
recommended you to use a higher performance computer for better result.
-5-
Chapter 2
Hardware Installation
2.1 Camera Stand Installation
ZVC7610 comes with a Camera Stand which uses a swivel ball screw head to lock the
screw-holes at the back of the unit. When the stand is attached to your ZVC7610, you can
place it anywhere by mounting it through the three screw-holes at the bottom of the
Camera Stand.
Camera Stand
-6-
2.2 Connecting ZVC7610 to Your Network
Use the provided RJ-45 Ethernet cable to connect the ZVC7610 to your network. The
ZVC7610 will power ON automatically after you connect the AC Power Adapter to the
power connector. You may verify the power status from the Power LED on the front panel.
Once you completed the connection, Link LED will start flash in green, ZVC7610 is at
standby mode, and it is ready to use.
RJ-45 Ethernet Cable Connector
-7-
2.3 ZVC7610 Application Example
ZVC7610 can be applied in multiple applications, including but not limited to the followings:
Monitor different places and objects via Internet or Intranet locally and remotely.
Capture images and video clips remotely.
Upload images and email messages with the images.
The following diagram explains one of the most typical applications for the ZVC7610. It
also provides a basic example of the ZVC7610 installation.
*ZVC7610 must
enclose by a
waterproof housing
when installing in an
outdoor environment
Home Applications
-8-
Chapter 3
Access your ZVC7610
3.1 Use IP Finder
ZVC7610 comes with an easy to use utility, IP Finder, in the Installation CD. It allows you
to find the ZVC7610 on your network easily.
1. Insert the Installation CD to CD-ROM drive and initiate the Auto-Run program
2. Double-click the IP Finder to launch the utility. The control panel will appear as
below.
Display all connected
ZVC7610(s)
Click Search to find the IP address of the connected ZVC7610(s)
Click Change IP to modify the IP address of the selected ZVC7610
Click Exit to close the utility
3. Once you have the IP address of the ZVC7610(s), you may use your web browser
or Ultra View to access it.
-9-
3.2 Login to your ZVC7610
1. Open your web browser and enter the ZVC7610 IP address on the address bar.
a. Default IP address: http://192.168.0.30 then press [Enter]
2. The login window will appear, enter the username and password then press OK to
access to the main screen of the ZVC7610 Web Configuration.
a. Default Username: admin (all lowercases)
b. Default Password: admin (all lowercases)
Enter the IP address
of the camera here.
Enter the User name
and Password.
NOTE: If this is the first time you access the ZVC7610, you will be asked to install a new
plug-in. Permission request depends on the Internet security settings of your
browser. Please click Yes to proceed.
- 10 -
After you login into the ZVC7610 Web Configuration main screen, the following screen will
appear.
Nightmode
Zoom In
Live View/Setup
Camera Information
Function
Live View Image
The Web Configuration provides you with many useful information and functions, including:
Camera Information – Display the location of your ZVC7610 with the current date &
time. This information can be modified in the Web Configuration.
Live View Image – Displays a real-time image of the connected ZVC7610.
Live View/Setup Switch – Click Setup to configure the ZVC7610. See Chapter 4 for
more details.
Function Button – Use these buttons to control the video functions.
Manual Record allows you to record and save a video clip
Snapshot allows you to capture and save an image
Browse allows you to save the video clips and image to a designated folder
Zoom In Button – Click the button to zoom in / out the live view image by 1x, 2x, and
3x
Nightmode Button – Click the button to enable the “Nightshot mode” to deliver clearer
images in the dark environment. However, this will also reduce the frame rate of the
video setting.
- 11 -
3.3 IP Address Configuration
You have to check the IP address of your computer if you failed to access the ZVC7610.
When connecting the ZVC7610 directly to your computer, you have to set up your
computer IP address within the same subnet in order for them to communicate correctly.
1. On your computer, click Start > Control Panel to open the Control Panel window
2. Double-click Network Connection to open the Network Connection window
3. Right-click Local Area Connection and click Properties, then select the General tab
4. Select Internet Protocol [TCP/IP] and click Properties to bring up the Internet
Protocol [TCP/IP] Properties window
5. Configure a fixed IP address that is within the same subnet of the ZVC7610. Select
Use the following IP address option and enter an IP address and Subnet Mask into
the empty field, for example: IP Address is 192.168.0.x where x is between 0~254
except 30 and Subnet Mask is 255.255.255.0.
6. Click OK after you finish.
- 12 -
Chapter 4
ZVC7610 Configuration
4.1 Using the Web Browser
To configure the ZVC7610 with your web browser, click Setup on the main page. The Web
Configuration will start from the Basic page.
The Web Configuration contains settings that are required for the ZVC7610 in the left
menu bar, Smart Wizard, Basic, Network, Video, Event Server, Motion detect, Event
Config, Tools, and Information.
- 13 -
4.2 Using Smart Wizard
ZVC7610 Smart Wizard lets you configure the camera easily and quickly. The wizard will
guide you through the necessary settings in detailed instructions of each step.
To start the wizard, click Smart Wizard in the left menu bar.
Step 1. Camera Settings
Enter the name and
location for ZVC7610
Enter and confirm
administrator password
Step 2. IP Settings
* Select the IP setting
according to your
network: DHCP,
Static IP, or PPPoE.
- 14 -
Step 3. Email Settings
* Enter the required
information for email
with image.
Step 4. Confirm Settings
The last step shows the configuration of your ZVC7610. After all settings are confirmed,
click Apply to finish the wizard and it will reboot the ZVC7610 automatically. Click <Prev
to go back and make necessary changes, or click Cancel to undo/discard all changes.
- 15 -
4.3 Basic Setup
The Basic menu contains three sub-menus, Camera Name, Location, Date & Time, and
User management.
Basic >> System
Basic
- Camera Name: Enter a description for your ZVC7610
- Location: Enter a description of your ZVC7610 location
Indication LED
It allows you to set LED illumination as your desired. There are two options: Normal
and OFF.
Basic >> Date & Time
Date & Time
- TimeZone: Select the proper time zone for the region from the drop-down menu.
- Synchronize with PC: Select this option to synchronize the ZVC7610 date & time
with the connected computer.
- Synchronize with NTP Server: Select this option to synchronize the time with the
NTP Server. You have to enter an IP address of the server then select the update
interval.
- Manual: Select this option to enter the ZVC7610 date and time manually.
Basic >> User
Administrator
To prevent unauthorized access to your ZVC7610 Web Configuration, we strongly
recommended you to change the default administrator password. Enter the
administrator password twice to set and confirm it.
General User
- Username: Enter and add more users to allow access to your ZVC7610 in a regular
basis
- Password: Enter the password for the new user(s)
Click Add/Modify to add the new user to the camera after you are finished. To modify
the user’s information, select the username from the UserList and click Add/Modify.
- UserList: Display all existing users of the ZVC7610. To delete a user, select the
username you want to delete and click Delete.
Guest
- User Name: Enter the guest’s name to access your ZVC7610
- Password: Enter the password for the new guest.
- UserList: Display the existing guests of your ZVC7610. To delete a guest, select the
name and click Delete.
NOTE: “General User” can access and use the Function buttons
“Guest’ can view live view images from the Web Configuration only
“Administrator” has full control of the Web Configuration
- 16 -
4.4 Network Settings
The Network menu contains three sub-menus, such as IP Setting, DDNS Setting, and IP
Filter.
- 17 -
Network >> Network
IP Setting allows you to select an IP address mode to set up the configuration
accordingly.
- DHCP: Select this option when your network uses the DHCP server. When ZVC7610
starts up, it will get from the DHCP server automatically.
- Static IP: Select this option and enter an IP address manually. You can use IP Finder
to obtain the setting values.
IP
Subnet Mask
Enter IP Address of ZVC7610
Default IP Address: 192.168.0.30
Enter Subnet Mask of ZVC7610
Default Subnet Mask: 255.255.255.0
Default
Gateway
Enter Default Gateway of ZVC7610
Default address: 192.168.0.1
Primary/
Secondary
DNS
DNS (Domain Name System) translates
domain names into IP addresses. Enter the
Primary and Secondary DNS that provided
by ISP.
- PPPoE: Select this option when you use a direct connection via the ADSL modem.
Enter your PPPoE Account User Name and Password. ZVC7610 will get the IP
address from your ISP when starting up.
NOTE: When setting up the IP Setting with PPPoE account, ZVC7610 gets the IP address
from your ISP during start up and will send a notification email to you automatically.
Therefore, you have to setup email/DDNS in advanced when using PPPoE as your
connection type.
- 18 -
DDNS Setting allows you to assign a fixed host and domain name to a dynamic
Internet IP address. Select Enable to use this feature. Then select the Provider from
the drop-down list. Enter the required information to the Host Name, User Name, and
Password boxes. You must sign-up for a DDNS service with a DDNS provider in
advanced.
UPnP
ZVC7610 supports UPnP (Universal Plug and Play) which enables device-to-device
interoperability from a set of computer network protocols. It also supports port auto
mapping function so that you can access the ZVC7610 even it is behind an NAT router
or a firewall. Select Enable to enable this feature.
Ports Number
- HTTP Port: Default HTTP port is 80
NOTE: We suggested to use port 1024 ~ 65535 if ZVC7610 is behind an NAT router or a
firewall.
Network >> IP Filter
The IP Filter setting allows the administrator limits users within a range of IP address to
access the ZVC7610.
Start/End IP Address
Assign a range of IP address that is NOT allowed to access the ZVC7610. Enter the
Start IP address and End IP address. Click Add to save the setting. You can repeat
this step to assign more than one range of IP address.
For example, when you enter 192.168.0.50 for the Start IP Address and 192.168.0.80
for the End IP Address, all computers whose IP address set within 192.168.0.50 ~
192.168.0.80 will NOT be able to access the ZVC7610.
Deny IP List
It displays all of the IP addresses that are NOT allow to access the ZVC7610. Click
Delete to clear range of IP address or a single IP address.
- 19 -
4.5 Video Setup
Video menu contains three sub-menus that provide video settings for the ZVC7610.
- 20 -
Video >> Camera
Image Setting
- Brightness: Adjust the brightness level from 0 ~ 100
- Contrast: Adjust the contrast level from 0 ~ 100
- Saturation: Adjust the colors level from 0 ~ 100
Click Default to restore the default settings of the three options above.
- Mirror: Select Horizontal to mirror the image horizontally. Select Vertical to mirror
the image vertically
- Light Frequency: Select the proper frequency according to the location of ZVC7610:
50Hz, 60Hz, or Outdoor
Overlay Setting
- Includes Date & Time: Select this option to display the date & time stamp on the live
view image
- Enable Opaque: Select this option to set a black background to the displayed date &
time stamp
Video >> Video
MJPEG
- Video Resolution: Select the desired video resolution in three different formats: VGA,
QVGA and QQVGA. The highest setting (VGA) gives you better video quality while it
uses more resources within your network.
- Video Quality: Select the desired image quality in five different levels: Lowest, Low,
Medium, High, and Highest.
- Frame Rate: Select Auto or a proper setting depending on your network status.
- 21 -
4.6 Event Server Configuration
The Event Server menu contains three sub-menus that allow you to upload images to FTP,
and send emails with images.
After you complete the required settings for FTP, or Email, click Test to test the
configuration to see if it is correct or not. After test is successful, click Apply.
Event Server Setting>> FTP
FTP
- Host Address: Enter the IP address of the target FTP server
- Port Number: Enter the port number for the FTP server
- User Name: Enter the user name to login to the FTP server
- Password: Enter the password to login to the FTP server
- Directory Path: Enter the destination folder for uploading the images, for example:
/Test/
- Passive Mode: Select Enable to enable the passive mode
- 22 -
Event Server Setting >> Email
Email
- SMTP Server Address: Enter the mail server address, for example: mymail.com
- Sender Email Address: Enter the email address of the user who will send the email,
for example: [email protected]
- Sender User Name: Enter the sender email address username to login the mail
server
- Sender Password: Enter the sender email address password to login the mail server
- Receiver #1 Email Address: Enter the first email address of the receiver who will
receive the email
- Receiver #2 Email Address: Enter the second email address of the receiver who will
receive the email
4.7 Motion Detect
The Motion Detect menu contains the command and option that allow you to enable and
setup the motion detection feature of the ZVC7610. It provides up to two detecting areas.
To enable the detecting areas, select Window 1 or 2 from the drop-down list, and select
Enable. When the detecting area(s) is enabled, you can use the mouse to move the
detecting area(s) and change the area coverage.
- Name: Assign a name of the detecting area(s)
- Threshold: Move the slide bar to adjust the level for detecting motion and record
video
- 23 -
4.8 Event Configuration
The Event Configuration menu contains four sub-menus that provide commands to the
configure event profiles.
Event Configuration >> General Setting
- Snapshot/Recording Filename Prefix: You can assign a given prefix to each new
captured file. Leave this option blank to use the default setting.
Event Configuration >> Arrange Schedule Profile
This sub-menu displays the scheduled profile(s). To customize the profile, click Add and
enter a description for the profile in the prompt dialog window. Click OK to add it to the
Schedule Profiles list. Click Delete to delete the selected profile from the list.
- 24 -
- Profile Name: Display profile name(s) that you added to the Schedule Profiles list
- Weekdays: Select the day(s), Monday to Friday, which you want to assign in the
schedule profile separately. Assigned weekday(s) will display in green color
- Time List: Display the period of time that you have assigned within the selected
weekday(s). Click Add this to all weekdays to assign the same period of time to
every weekday(s). Click Delete this from all weekdays to remove the selected
period from every weekday(s).
- Start/End Time: Enter the start and end time and then click Add to assign a time
period within in the selected weekday.
Event Configuration >> Motion Detect Trigger
Select Enable option to enable the trigger function of the ZVC7610 to send captured
images of the detecting area(s) to an FTP server, email receiver, Network Storage server,
or any connected USB device.
- Schedule Profile: Select a Schedule Profile from the drop-down list.
- Action: Select a destination for the captured images to be sent to: Send Email or
FTP Upload.
Event Configuration >> Schedule Trigger
You can configure the schedule for trigger function of the ZVC7610 separately with Email,
or FTP. Select Enable option on each item, then select a Schedule Profile from the dropdown list and set the Interval time.
- 25 -
4.9 Tools
The Tools menu provides commands that allow you to restart and/or reset the ZVC7610.
You can also backup, restore your configuration, and upgrade firmware for the ZVC7610.
Factory Reset
Click Reset to restore all factory default settings for the ZVC7610.
System Reboot
Click Reboot to restart the ZVC7610. It will power OFF the under then power ON
automatically. ZVC7610 configuration will be retained after System Reboot.
Configuration
You can save your ZVC7610 configuration as a backup file on your computer. You can
restore it by retrieving the backup file.
-
Backup: Click Get the backup file to save the current configuration of the ZVC7610
to your computer.
- Restore: Click Browse to locate the backup file and click Restore the configuration
of the ZVC7610.
Update Firmware
It displays the current firmware version. You can upgrade it once you obtained a latest
version of firmware.
- Select the firmware: Click Browse to locate the updated firmware file and click
Update.
NOTE: ZVC7610 must be power ON during firmware upgrade. Otherwise, the original
firmware may corrupt due to the failure of firmware upgrade.
- 26 -
4.10 Information
The Information menu displays the current configuration and events log of the ZVC7610.
Device Info
Display the Basic, Video, and Network settings of the ZVC7610.
System Log
This table displays all events log recorded by the system.
- 27 -
C HAPTER 5
A PPENDIX
A.1 Specification
Image Sensor
Sensor
Resolution
1/4” color CMOS
640x480
Video
Compression
Video resolution
MJPEG
VGA/QVGA/QQVGA; 30fps max.
System Hardware
Processor
RAM
ROM
Power
ARM9 base
16MB SDRAM
4MB NOR Flash
DC 5V
Communication
LAN
Protocol support
User Interface
LAN
Reset
Software
OS Support
Browser
Software
10/100Mbps Fast Ethernet
Auto-sensed, Auto-MDIX
TCP/IP, UDP, ICMP, DHCP, NTP,
DNS, DDNS, SMTP, FTP, PPPoE, UPnP
One RJ-45 port
One Reset button
Link LED (green)
Windows 2000/XP/Vista, Macintosh OSX
Internet Explorer 6.0 or above, Mozilla Firefox 2.00 or above,
Apple Safari 2 or above
Ultra View for playback/
Recording/configuration features
Operating Environment
Temperature
Operation: 5°C ~ 45°C
Storage: -15°C ~ 60°C
Humidity
Operation: 20~85% non-condensing
Storage: 0% ~ 90% non-condensing
- 28 -
A.2 Glossary of Terms
NUMBERS
10BASE-T
100BASE-TX
A
ADPCM
AMR
Applet
ASCII
ARP
AVI
B
BOOTP
C
Communication
Connection
D
DHCP
10BASE-T is Ethernet over UTP Category III, IV, or V unshielded
twisted-pair media.
The two-pair twisted-media implementation of 100BASE-T is
called 100BASE-TX.
Adaptive Differential Pulse Code Modulation, a new technology
improved from PCM, which encodes analog sounds to digital
form.
AMR (Adaptive Multi-Rate) is an audio data compression scheme
optimized for speech coding, which is adopted as the standard
speech codec by 3GPP.
Applets are small Java programs that can be embedded in an
HTML page. The rule at the moment is that an applet can only
make an Internet connection to the computer form that the applet
was sent.
American Standard Code For Information Interchange, it is the
standard method for encoding characters as 8-bit sequences of
binary numbers, allowing a maximum of 256 characters.
Address Resolution Protocol. ARP is a protocol that resides at the
TCP/IP Internet layer that delivers data on the same network by
translating an IP address to a physical address.
Audio Video Interleave, it is a Windows platform audio and video
file type, a common format for small movies and videos.
Bootstrap Protocol is an Internet protocol that can automatically
configure a network device in a diskless workstation to give its
own IP address.
Communication has four components: sender, receiver, message,
and medium. In networks, devices and application tasks and
processes communicate messages to each other over media.
They represent the sender and receivers. The data they send is
the message. The cabling or transmission method they use is the
medium.
In networking, two devices establish a connection to communicate
with each other.
Developed by Microsoft, DHCP (Dynamic Host Configuration
Protocol) is a protocol for assigning dynamic IP addresses to
devices on a network. With dynamic addressing, a device can
have a different IP address every time it connects to the network.
In some systems, the device's IP address can even change while
it is still connected. It also supports a mix of static and dynamic IP
addresses. This simplifies the task for network administrators
because the software keeps track of IP addresses rather than
requiring an administrator to manage the task. A new computer
- 29 -
DNS
E
Enterprise network
Ethernet
F
Fast Ethernet
Firewall
G
Gateway
Group
H
HEX
can be added to a network without the hassle of manually
assigning it a unique IP address. DHCP allows the specification
for the service provided by a router, gateway, or other network
device that automatically assigns an IP address to any device that
requests one.
Domain Name System is an Internet service that translates
domain names into IP addresses. Since domain names are
alphabetic, they're easier to remember. The Internet however, is
really based on IP addresses every time you use a domain name
the DNS will translate the name into the corresponding IP
address. For example, the domain name
www.network_camera.com might translate to 192.167.222.8.
An enterprise network consists of collections of networks
connected to each other over a geographically dispersed area.
The enterprise network serves the needs of a widely distributed
company and operates the company’s mission-critical
applications.
The most popular LAN communication technology. There are a
variety of types of Ethernet, including 10Mbps (traditional
Ethernet), 100Mbps (Fast Ethernet), and 1,000Mbps (Gigabit
Ethernet). Most Ethernet networks use Category 5 cabling to carry
information, in the form of electrical signals, between devices.
Ethernet is an implementation of CSMA/CD that operates in a bus
or star topology.
Fast Ethernet, also called 100BASE-T, operates at 10 or
100Mbps per second over UTP, STP, or fiber-optic media.
Firewall is considered the first line of defense in protecting private
information. For better security, data can be encrypted. A system
designed to prevent unauthorized access to or from a private
network. Firewalls are frequently used to prevent unauthorized
Internet users from accessing private networks connected to the
Internet, especially Intranets all messages entering or leaving the
intranet pass through the firewall, which examines each message
and blocks those that do not meet the specified security criteria.
A gateway links computers that use different data formats
together.
Groups consist of several user machines that have similar
characteristics such as being in the same department.
Short for hexadecimal refers to the base-16 number system,
which consists of 16 unique symbols: the numbers 0 to 9 and the
letters A to F. For example, the decimal number 15 is represented
as F in the hexadecimal numbering system. The hexadecimal
system is useful because it can represent every byte (8 bits) as
two consecutive hexadecimal digits. It is easier for humans to
read hexadecimal numbers than binary numbers.
- 30 -
I
Intranet
Internet
Internet address
IP
IP address
ISP
J
JAVA
L
LAN
M
MJPEG
MPEG4
This is a private network, inside an organization or company that
uses the same software you will find on the public Internet. The
only difference is that an Intranet is used for internal usage only.
The Internet is a globally linked system of computers that are
logically connected based on the Internet Protocol (IP). The
Internet provides different ways to access private and public
information worldwide.
To participate in Internet communications and on Internet
Protocol-based networks, a node must have an Internet address
that identifies it to the other nodes. All Internet addresses are IP
addresses
Internet Protocol is the standard that describes the layout of the
basic unit of information on the Internet (the packet) and also
details the numerical addressing format used to route the
information. Your Internet service provider controls the IP address
of any device it connects to the Internet. The IP addresses in your
network must conform to IP addressing rules. In smaller LANs,
most people will allow the DHCP function of a router or gateway
to assign the IP addresses on internal networks.
IP address is a 32-binary digit number that identifies each sender
or receiver of information that is sent in packets across the
Internet. For example 80.80.80.69 is an IP address. When you
“call” that number, using any connection methods, you get
connected to the computer that “owns” that IP address.
ISP (Internet Service Provider) is a company that maintains a
network that is linked to the Internet by way of a dedicated
communication line. An ISP offers the use of its dedicated
communication lines to companies or individuals who can’t afford
the high monthly cost for a direct connection.
Java is a programming language that is specially designed for
writing programs that can be safely downloaded to your computer
through the Internet without the fear of viruses. It is an objectoriented multi-thread programming best for creating applets and
applications for the Internet, Intranet and other complex,
distributed network.
Local Area Network a computer network that spans a relatively
small area sharing common resources. Most LANs are confined to
a single building or group of buildings.
MJPEG (Motion JPEG) composes a moving image by storing
each frame of a moving picture sequence in JPEG compression,
and then decompressing and displaying each frame at rapid
speed to show the moving picture.
MPEG4 is designed to enable transmission and reception of highquality audio and video over the Internet and next-generation
mobile telephones.
- 31 -
N
NAT
Network
NWay Protocol
P
PCM
PING
PPPoE
Protocol
Network Address Translator generally applied by a router that
makes many different IP addresses on an internal network appear
to the Internet as a single address. For routing messages properly
within your network, each device requires a unique IP address.
But the addresses may not be valid outside your network. NAT
solves the problem. When devices within your network request
information from the Internet, the requests are forwarded to the
Internet under the router's IP address. NAT distributes the
responses to the proper IP addresses within your network.
A network consists of a collection of two or more devices, people,
or components that communicate with each other over physical or
virtual media. The most common types of network are:
LAN – (local area network): Computers are in close distance to
one another. They are usually in the same office space, room, or
building.
WAN – (wide area network): The computers are in different
geographic locations and are connected by telephone lines or
radio waves.
A network protocol that can automatically negotiate the highest
possible transmission speed between two devices.
PCM (Pulse Code Modulation) is a technique for converting
analog audio signals into digital form for transmission.
Packet Internet Groper, a utility used to determine whether a
specific IP address is accessible. It functions by sending a packet
to the specified address and waits for a reply. It is primarily used
to troubleshoot Internet connections.
Point-to-Point Protocol over Ethernet. PPPoE is a specification for
connecting the users on an Ethernet to the Internet through a
common broadband medium, such as DSL or cable modem. All
the users over the Ethernet share a common connection.
Communication on the network is governed by sets of rules called
protocols. Protocols provide the guidelines devices use to
communicate with each other, and thus they have different
functions. Some protocols are responsible for formatting and
presenting and presenting data that will be transferred from file
server memory to the file server’s net work adapter Others are
responsible for filtering information between networks and
forwarding data to its destination. Still other protocols dictate how
data is transferred across the medium, and how servers respond
to workstation requests and vice versa. Common network
protocols responsible for the presentation and formatting of data
for a network operating system are the Internetwork Packet
Exchange (IPX) protocol or the Internet Protocol (IP). Protocols
that dictate the format of data for transferors the medium include
token-passing and Carrier Sense Multiple Access with Collision
Detection (CSMA/CD), implemented as token-ring, ARCNET,
FDDI, or Ethernet. The Router Information Protocol (RIP),a part of
- 32 -
the Transmission Control Protocol/Internet Protocol (TCP/IP)
suite, forwards packets from one network to another using the
same network protocol.
R
RJ-45
Router
RTP
RTSP
S
Server
SIP
SMTP
SNMP
Station
Subnet mask
T
(TCP/IP)
Transceiver
U
UDP
RJ-45 connector is used for Ethernet cable connections.
A router is the network software or hardware entity charged with
routing packets between networks.
RTP (Real-time Transport Protocol) is a data transfer protocol
defined to deliver live media to the clients at the same time,
which defines the transmission of video and audio files in real time
for Internet applications.
RTSP (Real-time Streaming Protocol) is the standard used to
transmit stored media to the client(s) at the same time, which
provides client controls for random access to the content stream.
It is a simple computer that provides resources, such as files or
other information.
SIP (Session Initiated Protocol) is a standard protocol that
delivers the real-time communication for Voice over IP (VoIP),
which establishes sessions for features such as audio and video
conferencing.
The Simple Mail Transfer Protocol is used for Internet mail.
Simple Network Management Protocol. SNMP was designed to
provide a common foundation for managing network devices.
In LANs, a station consists of a device that can communicate data
on the network. In FDDI, a station includes both physical nodes
and addressable logical devices. Workstations, single-attach
stations, dual-attach stations, and concentrators are FDDI
stations.
In TCP/IP, the bits used to create the subnet are called the subnet
mask.
Transmission Control Protocol/Internet Protocol is a widely used
transport protocol that connects diverse computers of various
transmission methods. It was developed y the Department of
Defense to connect different computer types and led to the
development of the Internet.
A transceiver joins two network segments together. Transceivers
can also be used to join a segment that uses one medium to a
segment that uses a different medium. On a 10BASE-5 network,
the transceiver connects the network adapter or other network
device to the medium. Transceivers also can be used on
10BASE-2 or 10BASE-T networks to attach devices with AUI
ports.
The User Datagram Protocol is a connectionless protocol that
resides above IP in the TCP/IP suite
- 33 -
User Name
Utility
UTP
W
WAN
WEP
Windows
WPA
WPA2
The USERNAME is the unique name assigned to each person
who has access to the LAN.
It is a program that performs a specific task.
Unshielded twisted-pair. UTP is a form of cable used by all access
methods. It consists of several pairs of wires enclosed in an
unshielded sheath.
Wide-Area Network. A wide-area network consists of groups of
interconnected computers that are separated by a wide distance
and communicate with each other via common carrier
telecommunication techniques.
WEP is widely used as the basic security protocol in Wi-Fi
networks, which secures data transmissions using 64-bit or 128bit encryption.
Windows is a graphical user interface for workstations that use
DOS.
WPA (Wi-Fi Protected Access ) is used to improve the security of
Wi-Fi networks, replacing the current WEP standard. It uses its
own encryption, Temporal Key Integrity Protocol (TKIP), to secure
data during transmission.
Wi-Fi Protected Access 2, the latest security specification that
provides greater data protection and network access control for
Wi-Fi networks. WPA2 uses the government-grade AES
encryption algorithm and IEEE 802.1X-based authentication,
which are required to secure large corporate networks.
- 34 -
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
