Manual
Content
1. Features
2. Specifications
3. Parts and accessories
4. The device at a glance
5. Installing a SATA hard disk drive
6. Installing the software
7. The backup software
7.1 Start
7.2 Quick Launch
7.3 File Backup
7.4 File manager
7.5 Setup
7.5.1 Files Backup
7.5.2 Others
Dear customer!
Congratulations for purchasing this premium quality
SHARKOON product.
For a long life time and to take full advantage of this product we
recommend that you read this manual completely.
Have a good time with our product!
SHARKOON Technologies GmbH
QUICKSTORE PORTABLE USB3.0
1. Features
•
•
•
•
•
Suitable for 2.5" SATA hard disk drives (9.5 mm height)
Tool free assembly
“One Click Backup” function (only Windows)
Backup software included
No drivers needed for Windows, Mac and Linux
3.Parts and accessories
A
B
C
D
2. Specifications
•
•
•
•
•
External interface: Internal interface: Data transfer rate: Dimensions: Weight: Mini USB3.0 (compatible to USB2.0
and USB1.x)
SATA (Version I and II)
max. 5 Gbit/s
135 x 85 x 14 mm (L x W x H)
~51 g
•
•
•
•
QuickStore Portable USB3.0 (A)
USB3.0 cable (B)
Quick start manual (C)
Tools CD incl. backup software and extensive manual (PDF / D)
Note:
If you are missing any of the items listed above, please contact
our customer service via e-mail at [email protected] or call
+ 49 (0) 6403 – 775 6100.
QUICKSTORE PORTABLE USB3.0
4. The device at a glance
A
5. Installing a SATA hard disk drive
A – QuickStore Portable in
respective version (black,
mirrored, blue, red or silver)
B
A
B –
Backup button:
pressing this button starts
a backup process with the
pre-defined settings (see
chapter 7)
1. Open the case cover lock (fig. 1).
fig. 1
2. Remove the case cover from the case body (fig. 2).
A – Case cover lock
A
A – Case cover
fig. 2
3. Slide a 2.5" SATA HDD into the HDD mounting bay (fig. 3).
A
B
A
B
–
–
SATA connector (data and
power)
HDD mounting bay
(for one 2.5"-SATA HDD)
fig. 3
QUICKSTORE PORTABLE USB3.0
4. Place the case cover back onto the case body (fig. 4).
6. Installing the software
1. Insert the included Driver&Tools CD into your CD/DVD drive.
2. Choose your CD/DVD drive (e.g. D:\).
3. Open the folder “Sharkoon“.
4. Start “Setup.exe”.The installation wizard will guide you through
the installation procedure.
fig. 4
5. After the installation is completed the following icon will appear
on your desktop:
5. Close the lock (fig. 5).
fig. 5
6. 7. Use the included USB3.0 cable to connect the device's Mini
USB3.0 connector to a USB3.0 connector of your PC/laptop.
Note:
Brand new HDDs built into the case must be partitioned and
formatted. Proceed as described below (e.g. Windows XP):
Start / Settings / Control Panel / Administrative Tools / Computer
Management / Disk Management. Click the respective HDD with
the right mouse button and choose partition/format.
6. Double-click (left mouse button) this desktop icon to launch the
software, the main interface will open up and another program
icon will appear in your task bar.
The QuickStore Portable will automatically be recognized by the
operating system and all required drivers will be installed. The
device is now ready.
QUICKSTORE PORTABLE USB3.0
7. The backup software
3. “Help” starts the help program of the backup software (fig. 7)
where all functions of the backup software will be explained in
detail.
7.1 Start
1. Click the icon in your task bar with the right mouse button
once. The following context menu will open up:
2. “About…” displays information about the software (fig. 6).
4. “Exit PC Clone EX“ quits the program (the icon will be removed
from your task bar).
5. fig. 7
“Show PC Clone EX” re-opens the program interface after you
have minimized it (see below).
Alternatively you may re-open the program interface by doubleclicking (left mouse button) the icon.
fig. 6
QUICKSTORE PORTABLE USB3.0
7.2Quick Launch
A
B
7.3 File Backup
C
D
E F G
B
A
H
C
G
A –
B –
C –
D –
E –
F –
G –
H –
Quick Launch (7.2)
File Backup (7.3)
File Manager (7.4)
Setup (7.5)
Shows you information about the software (see
above 7.1).
Starts the help program of the backup software (see
above 7.1)
Minimize the program window. To completely quit
the program see above 7.1.
Start the data backup by clicking this button.
A –
B –
C –
D –
D
All folders of your system are displayed here.
Choose the folders that shall be copied during a
backup, by ticking the respective checkbox(es).
Select the external target device from the dropdown
menu.
Start the backup by clicking the button.
Restore already existing backup files from the
external (backup) drive, by clicking this button.
Note:
The backup files are copied to the (hidden) folder “Fnet” on the
target device. This folder must not be deleted!
QUICKSTORE PORTABLE USB3.0
7.4 File manager
7.5 Setup
7.5.1Files Backup
A
B
E
F
C
D
The File Manager makes it easy to govern your local folders/files
and supports similar functions as known from the Windows
Explorer. A –
B –
C –
D –
E –
F –
Select between the windows "Files Backup" (7.5.1) and
"Others" (7.5.2).
Decide what shall happen after the backup has been completed: “Show complete message” will show a
summary of the backup; “Return program” returns to the
program; “Power off” will shut down your system.
Choose whether all or only changed files shall be secured.
Determine a hot key to start the backup.
Select which system folders shall be included into the
backup.
Determine whether the Files Backup folder shall be hidden
and if the quick file backup shall be double confirmed or
not.
QUICKSTORE PORTABLE USB3.0
7.5.2Others
Warning:
For potential loss of data, especially due to inappropriate handling, SHARKOON
assumes no liability.
All named products and descriptions are trademarks and/or registered
trademarks of the respective manufacturers and are accepted as protected.
As a continuing policy of product improvement at SHARKOON, the design
and specifications are subject to change without prior notice. National product
specifications may vary.
The legal rights of the enclosed software belong to the respective owner. Please
observe the license terms of the manufacturer before using the software.
All rights reserved especially (also in extracts) for translation, reprinting,
reproduction by copying or other technical means. Infringements will lead to
compensation.
All rights reserved especially in case of assignation of patent or utility patent.
Means of delivery and technical modifications reserved.
A
B
Disposal of your old product
Your product is designed and manufactured with high quality materials and
components, which can be recycled and reused.
A –
B –
Decide if the program shall be started during system
boot-up.
Activating this check box will also activate the backup
button on the enclosure enabling you to commence a
backup process by simply pressing the respective button
(see above 4.). Deactivating will prevent unintentional
backup procedures.
When this crossed-out wheeled bin symbol is attached to a product, it means
the product is covered by the European Directive 2002/96/EC.
Please be informed about the local separate collection system for electrical and
electronic products.
Please act according to your local rules and do not dispose of your old
products with your normal household waste. The correct disposal of your old
product will help prevent potential negative consequences to the environment
and human health.
© SHARKOON Technologies 2010
