Soft Serve / Yoghurt Freezer

Soft Serve / Yoghurt Freezer

SOFT SERVE / YOGHURT

Soft Serve / Yoghurt Freezer

Taylormate

MODEL

142

SPECIFICATIONS

1 Flavour, Console type

1 Phase, 220/50hz

Freezing Cylinder 1.4 Lt

Mix Reservoir 7.6 Lt

Compressor BTU p/hr 3000

Beater Motor HP 0.5

PRODUCTION DIMS-mm / WEIGHT

12.4 liter p/hr W406 x D622 x H736

Weight = 88Kg

Soft Serve / Yoghurt Freezer

Taylormate

MODEL

152

SPECIFICATIONS

1 Flavour, Console type

1 Phase, 220/50hz

Freezing Cylinder 1.4 Lt

Mix Reservoir 7.6 Lt

Compressor BTU p/hr 3000

Beater Motor HP 0.5

PRODUCTION DIMS-mm / WEIGHT

13.6 liter p/hr W418 x D699 x H711

Weight =103kg

Soft Serve / Yoghurt Freezer

Taylormate

MODEL

161

SPECIFICATIONS

2 Flavour + Mix, Gravity Feed

Console Type

1 Phase, 220/50hz

Freezing Cylinder 2 x 1.4 Lt

Mix Reservoir 7.6 Lt

Compressor BTU p/hr 8000

Beater Motor HP 0.5

PRODUCTION DIMS-mm / WEIGHT

13.6 liter p/hr

Each side

W737 x D610 x H787

Weight = 137kg

Soft Serve / Yoghurt Freezer

Taylormate

MODEL

150

SPECIFICATIONS

1 Flavour, Floor Standing

1 Phase, 220/50hz

Freezing Cylinder 1.4 Lt

Mix Reservoir 7.6 Lt

Compressor BTU p/hr 3000

Beater Motor HP 0.5

PRODUCTION DIMS-mm / WEIGHT

13.6 liter p/hr W357 x D610 x H1308

Weight = 154kg

Soft Serve / Yoghurt Freezer

Taylormate

MODEL

161Fs

SPECIFICATIONS

2 Flavour + Mix, Gravity Feed 13.6 liter p/hr

Floor Standing Each Side

1 Phase, 220/50hz

Freezing Cylinder 2 x 1.4 Lt

Mix Reservoir 7.6 Lt

Compressor BTU p/hr 8000

Beater Motor HP 0.5

PRODUCTION DIMS-mm / WEIGHT

W519 x D610 x H1365

Weight = 185kg

1

SOFT SERVE / YOGHURT

Soft Serve / Yoghurt Freezer

Crown Series

MODEL

C707

SPECIFICATIONS

1 Flavour, Gravity Feed

Console Type

3 Phase, 380/220/50hz

Freezing Cylinder 3.2 Lt

Mix Reservoir 18.9 Lt

Compressor BTU p/hr 9,500

Beater Motor HP 1.5

PRODUCTION DIMS-mm / WEIGHT

38 liter p/hr W464 x D864 x H860

Weight = 170kg

C707Fs

1 Flavour, Gravity Feed

Floor Standing

3 Phase, 380/220/50hz

Freezing Cylinder 3.2 Lt

Mix Reservoir 18.9 Lt

Compressor BTU p/hr 9,500

Beater Motor HP 1.5

38 liter p/hr W464 x D864 x H1510

Weight = 245kg

Features

Offer all the popular soft serve variations from low or non-fat ice creams to custards, yoghurts and sorbet. Serve two separate soft serve flavours, or an equal combination of both in a twist.

Soft Serve / Yoghurt Freezer

Crown Series

MODEL

C713

SPECIFICATIONS

2 Flavour + Mix, Gravity Feed 38 liter p/hr

Floor Standing Each Side

3 Phase, 380/220/50hz

Freezing Cylinder 3.2 Lt

Mix Reservoir 18.9 Lt

Compressor BTU p/hr 9,500

Beater Motor HP 1.5

PRODUCTION DIMS-mm / WEIGHT

W646 x D919 x H1525

Net Weight = 314kg

C712

2 Flavour + Mix, Pump Feed

Floor Standing

53 liter p/hr

Each Side

W646 x D919 x H1525

Net Weight = 341kg

Soft Serve / Yoghurt Freezer

Crown Series

MODEL

C706

SPECIFICATIONS

1 Flavour, Pump Feed

Console Type

3 Phase, 380/220/50hz

Freezing Cylinder 3.2 Lt

Mix Reservoir 18.9 Lt

Compressor BTU p/hr 9,500

Beater Motor HP 1.5

PRODUCTION DIMS-mm / WEIGHT

53 liter p/hr W464 x D864 x H860

Weight = 123kg

C706Fs

1 Flavour, Pump Feed

Floor Standing

3 Phase, 380/220/50hz

Freezing Cylinder 3.2 Lt

Mix Reservoir 18.9 Lt

Compressor BTU p/hr 9,500

Beater Motor HP 1.5

53 liter p/hr W464 x D864 x H1510

Weight = 288kg

Soft Serve / Yoghurt Freezer

Crown Series

MODEL

C723

SPECIFICATIONS

2 Flavour, Console Type

Freezing Cylinder 2.7 Lt

Mix Hopper 13.2 Lt

Compressor BTU p/hr 9,500

Beater Motor HP 1.0

PRODUCTION DIMS-mm / WEIGHT

53 liter p/hr

Each Side

W591 x D960 x H903

Net Weight = 293kg

2

SOFT SERVE / YOGHURT

Soft Serve / Yoghurt Freezer

Crown Series

MODEL

C709

SPECIFICATIONS

1 Flavour, Console Type

Gravity Feed, Heat Treat

3 Phase, 380/220/50hz

Freezing Cylinder 3.2 Lt

Mix Reservoir 18.9 Lt

Compressor BTU p/hr 9,500

Beater Motor HP 1.5

PRODUCTION DIMS-mm / WEIGHT

38 liter p/hr W464 x D864 x H860

Weight = 170kg

C709Fs

1 Flavour, Floor Standing

Gravity Feed, Heat Treat

3 Phase, 380/220/50hz

Freezing Cylinder 3.2 Lt

Mix Reservoir 18.9 Lt

Compressor BTU p/hr 9,500

Beater Motor HP 1.5

38 liter p/hr W464 x D864 x H1510

Weight = 245kg

Soft Serve / Yoghurt Freezer

MODEL

C702

SPECIFICATIONS

1 Flavour, Console Type

Gravity Feed, Heat Treat

Freezing Cylinder 3.8 Lt

Mix Reservoir 18.9 Lt

PRODUCTION DIMS-mm / WEIGHT

38 liter p/hr W468 x D811 x H924

Weight = 142kg

Soft Serve / Yoghurt Freezer

Crown Series

MODEL

C708

SPECIFICATIONS

1 Flavour, Console Type

Gravity Feed, Heat Treat

3 Phase, 380/220/50hz

Freezing Cylinder 3.2 Lt

Mix Reservoir 18.9 Lt

Compressor BTU p/hr 9,500

Beater Motor HP 1.5

PRODUCTION DIMS-mm / WEIGHT

53 liter p/hr W464 x D864 x H860

Weight = 170kg

C708Fs

1 Flavour, Floor Standing

Gravity Feed, Heat Treat

3 Phase, 380/220/50hz

Freezing Cylinder 3.2 Lt

Mix Reservoir 18.9 Lt

Compressor BTU p/hr 9,500

Beater Motor HP 1.5

53 liter p/hr W464 x D864 x H1510

Weight = 245kg

Soft Serve / Yoghurt Freezer

MODEL

C741

SPECIFICATIONS

1 Flavour, Floor Standing

Gravity Feed, Heat Treat

Freezing Cylinder 6.6 Lt

Mix Reservoir 18.9 Lt

PRODUCTION DIMS-mm / WEIGHT

38 liter p/hr W468 x D762 x H1521

Weight = 198.2kg

3

SOFT SERVE / YOGHURT

Soft Serve / Yoghurt Freezer

MODEL

336

SPECIFICATIONS

2 Flavour

Floor Standing

Freezing Cylinder 2.7 Lt

Mix Reservoir 7.6 Lt

Compressor BTU p/hr 9,500

Beater Motor HP 1.5

PRODUCTION DIMS-mm / WEIGHT

13.6 liter p/hr

Each Side

W519 x D843 x H1524

Weight = 170kg

Soft Serve / Yoghurt Freezer

MODEL

794

SPECIFICATIONS

2 Flavour, Console Type

Freezing Cylinder 3.2 Lt

Mix Reservoir 13.2 Lt

Compressor BTU p/hr 9,500

Beater Motor HP 1.5

PRODUCTION DIMS-mm / WEIGHT

53 liter p/hr

Each side

W519 x D843 x H1511

Weight = 312.9kg

Combination Freezer

Crown Series

PRODUCTION DIMS-mm / WEIGHT MODEL

C606

SPECIFICATIONS

SOFT SERVE

1 Flavour, Pump Feed

Heat Treat, Floor Standing

3 Phase, 380/220/50hz

Freezing Cylinder 3.2 Lt

Mix Reservoir 18.9 Lt

Compressor BTU p/hr 9,500

Beater Motor HP 1.5

53 liter p/hr W641 x D987 x H1535

Net Weight = 370kg

MODEL

C606

SPECIFICATIONS

MILK SHAKE

4 Flavour, Heat Treat, Pump

Freezing Cylinder 6.6 Lt

Mix Reservoir 18.9 Lt

Compressor BTU p/hr 11000

Beater Motor HP 1.0

PRODUCTION DIMS-mm / WEIGHT

113 liter p/hr

Features

The Heat Treatment system provides a daily heating and cooling cycle to safely maintain dairy products up to two weeks before a complete disassembly and cleaning is required. Heat treatment freezers address food safety, product waste, maintenance and repair cost concerns.

4

Gelato Freezer

Taylor by Frigomat

MODEL

104

SPECIFICATIONS

1 Flavour, Console type

1 Phase, 220/50hz

Freezing Cylinder 2.9 Lt

Compressor BTU p/hr 2500

Beater Motor HP 1.0

PRODUCTION DIMS-mm / WEIGHT

15 liter p/hr W411 x D681 x H542

Net Weight = 74.8kg

Gelato Freezer

Taylor by Frigomat

MODEL

C124

SPECIFICATIONS

Vertical Batch Freezer

1 Phase, 220/50hz

Max. Loading p/Cycle = 5kg

Kw. = 0,7

Compressor BTU p/hr 2500

Beater Motor HP 1.0

PRODUCTION DIMS-mm / WEIGHT

5 kg p/hr W465 x D430 x H320

Net Weight = 45kg

C125

Max. Loading p/Cycle =2.2kg

Kw. = 1

10 kg p/hr W465 x D430 x H320

Net Weight = 45kg

GELATO

Gelato Freezer

Taylor by Frigomat

MODEL

C122

SPECIFICATIONS

1 Flavour, Console type

1 Phase, 220/50hz

Freezing Cylinder 8 Lt

Loading p/Cycle = 1 - 3kg

Compressor BTU p/hr 11,500

Beater Motor HP 1.5

Kw. = 1,8

PRODUCTION DIMS-mm / WEIGHT

15kg p/hr W430 x D850 x H690

Net Weight = 143kg

Gelato Freezer

Taylor by Frigomat

MODEL

C119

SPECIFICATIONS

1 Flavour, Console type

3 Phase, 220/50hz

Freezing Cylinder 8 Lt

Loading p/Cycle = 2 - 4kg

Compressor BTU p/hr 15,500

Beater Motor HP 2

Kw. = 2,9

PRODUCTION DIMS-mm / WEIGHT

25kg p/hr W440 x D838 x H1260

Net Weight = 169kg

5

Gelato Freezer

Taylor by Frigomat

MODEL

C118

SPECIFICATIONS

1 Flavour, Console type

3 Phase, 220/50hz

Freezing Cylinder 11,7 Lt

Loading p/Cycle = 2 - 7kg

Compressor BTU p/hr 16,500

Beater Motor HP 2.5 to 4.0

Kw. = 3,8

PRODUCTION DIMS-mm / WEIGHT

35kg p/hr W520 x D1010 x H1420

Net Weight = 275kg

Gelato Freezer

Taylor by Frigomat

MODEL

C117

SPECIFICATIONS

1 Flavour, Console type

3 Phase, 220/50hz

Freezing Cylinder 17,6 Lt

Loading p/Cycle = 3 - 10kg

Compressor BTU p/hr 29,500

Beater Motor HP 3.9 to 7.2

Kw. = 4,9

PRODUCTION DIMS-mm / WEIGHT

60kg p/hr W520 x D1103 x H1420

Net Weight = 316kg

GELATO

Gelato Freezer

Taylor by Frigomat

MODEL

C116

SPECIFICATIONS

1 Flavour, Console type

3 Phase, 220/50hz

Freezing Cylinder 26,5 Lt

Loading p/Cycle = 4 - 15kg

Compressor BTU p/hr 38,000

Beater Motor HP 5.7 to 10

Kw. = 8,4

PRODUCTION DIMS-mm / WEIGHT

90kg p/hr W520 x D1114 x H1420

Net Weight = 355kg

Gelato Freezer

Taylor by Frigomat

MODEL

220

SPECIFICATIONS

1 Flavour, Floor Standing

3 Phase, 380/220/50hz

Freezing Cylinder 18.9 Lt

Mix Reservoir 9.5 Lt

Compressor BTU p/hr 15000

Beater Motor HP 1.5

PRODUCTION DIMS-mm / WEIGHT

50kg p/hr W468 x D1029 x H1435

Net Weight = 227kg

6

SLUSH / SMOOTHIE / SHAKE

Slush / Smoothie / Shake Freezer

MODEL

430

SPECIFICATIONS

1 Flavour, Console type

1 Phase, 220/50hz

Freezing Cylinder 3.8 Lt

Mix Reservoir 13.2 Lt

Compressor BTU p/hr 4000

Beater Motor HP 0.25

PRODUCTION DIMS-mm / WEIGHT

38 liter p/hr W418 x D703 x H699

Net Weight = 80kg

Slush / Smoothie / Shake Freezer

MODEL

432

SPECIFICATIONS

2 Flavour, Console type

1 Phase, 220/50hz

Freezing Cylinder 3.8 Lt

Mix Reservoir 11.4 Lt

Compressor BTU p/hr 6000

Beater Motor HP 0.25

PRODUCTION DIMS-mm / WEIGHT

38 liter p/hr

Each Side

W475 x D699 x H929

Net Weight = 138kg

Milkshake / Smoothie Freezer

MODEL

62

SPECIFICATIONS

4 Flavour, Console type

1 Phase, 220/50hz

Freezing Cylinder 6.6 Lt

Mix Reservoir 18.9 Lt

Compressor BTU p/hr 11000

Beater Motor HP 1.0

PRODUCTION DIMS-mm / WEIGHT

85 liter p/hr W570 x D794 x H886

Net Weight = 157kg

Milkshake / Smoothie Freezer

MODEL

441

SPECIFICATIONS

1 Flavour, Floor Standing

3 Phase, 380/220/50hz

Freezing Cylinder 6.6 Lt

Mix Reservoir 18.9 Lt

Compressor BTU p/hr 11000

Beater Motor HP 1.0

PRODUCTION DIMS-mm / WEIGHT

94 liter p/hr W468 x D762 x H1521

Net Weight = 188kg

Standard Version

Milkshake / Smoothie Freezer

MODEL

60

SPECIFICATIONS

4 Flavour, Gravity Feed

3 Phase, 380/220/50hz

Freezing Cylinder 6.6 Lt

Mix Reservoir 18.9 Lt

Compressor BTU p/hr 11000

Beater Motor HP 1.0

PRODUCTION DIMS-mm / WEIGHT

94 liter p/hr W468 x D813 x H1521

Net Weight = 236kg

Milkshake / Smoothie Freezer

MODEL

PH61

SPECIFICATIONS

4 Flavour,Heat Treat, Pump

3 Phase, 380/220/50hz

Freezing Cylinder 6.6 Lt

Mix Reservoir 18.9 Lt

Compressor BTU p/hr 11000

Beater Motor HP 1.0

PRODUCTION DIMS-mm / WEIGHT

113 liter p/hr W468 x D813 x H1521

Net Weight = 261kg

7

BLENDERS / CREAM WHIPPERS

Chrunchiecreme - Flavorburst

MODEL

CC8

SPECIFICATIONS

8 Flavour Blending

1 Phase, 220/50hz

PRODUCTION DIMS-mm / WEIGHT

Ref Taylor Spec Radius = 280mm

Height = 483mm

Net Weight = 12kg

Flavorburst Blender

MODEL

FB80

SPECIFICATIONS

8 Flavour Syrup Injection

1 Phase, 220/50hz

PRODUCTION DIMS-mm / WEIGHT

1000 portion per bag

W241 x D617 x H481

Net Weight = 34kg

Razzle Blender

MODEL

BC10

SPECIFICATIONS

Counter Top Unit

1 Phase, 220/50hz

PRODUCTION DIMS-mm / WEIGHT

W254 x D230 x H610

Net Weight = 8kg

Cream Whipper

Taylor by Frigomat

MODEL

C003

SPECIFICATIONS

1 Flavour, Console type

1 Phase, 220/50hz

Tank Cap. 2.5 Lt

PRODUCTION DIMS-mm / WEIGHT

50kg p/hr W230 x D560 x H450

Net Weight = 30kg

8

THE ART OF COOKING

Model L828

Model L810

Model L812

Model L820

Grills

Programmable Controls

Microprocessor controls are programmable for simplified operator operation. Offers flexibility for future menu items and product specification changes at the restaurant level.

External USB Port

External USB port allows user access to upload new menu and promotional items. Menu changes can be sent electronically to other store locations saving time and eliminating operator error.

Upper Platens

Upper platen will close automatically to the preset gap setting with the touch of one button. Air cylinder system provides quiet, simple, trouble-free operation of the upper platen. As a safety feature, platen will automatically open at loss of power, or if an obstruction is detected.

Precise Automatic Gapping

Solid platform with 3-point reference plane and fixed (home) reference point. Once programmed, the upper platen automatically achieves accurate and consistent gaps, every time. Precise, repeatable gapping assures product safety and better quality finished product.

Cooking Zones

One zone has three independent heating elements, and two in the upper platen to assure even temperatures and quick recovery.

Side-To-Side Release Material

Protects entire upper platen cooking surface and makes cleaning easy.

Improved installation and removal process away from hot surfaces.

Patty Cook Position Placement Guide

Lower cooking surface is etched for a permanent patty placement guide for two-sided cooking.

Model L822

9

BLAST FREEZERS

Refrigerator for Ice-Cream Makers

KAGL6B

KAGL6B Refrigerator for Ice-Cream Makers offers a world of ice - cream with made in Sagi quality, a guarantee of perfect product storage.

! One - piece AISI 304 stainless steel and 75 mm insulation thickness, for excellent energy savings

! Reversible door equipped with a self-closing system activated when opened to less than 90°.

Quick opening system to reduce door opening waiting time

! Refrigeration chamber with rounded corners and condensation drainage hole in the bottom for maximum hygiene

! Lock with key and door lighting as standard

! 20 - position rack bars with 60 mm spacing interval in AISI 304

! Electronic circuit board with HACCP alarms and Hyper Cold function for rapid chamber cooling

! Automatic hot gas defrosting with automatic condensation evaporation

! Fan - assisted refrigeration system with evaporator outside storage chamber for increased storage capacity.

Combined Freezer & Blast Chiller/Freezer

IMFEB

The IMFEB model has been studied to respond to the growing need for improving laboratory space management without jeopardising performance and quality.

! One - piece structure in AISI 304 stainless steel throughout with two separate compartments, managed by two independent motors: freezer storage compartment and blast chiller/freezer compartment. Insulation thickness 75 mm

! AISI 304 stainless steel, easily removable racks: 11 position storage freezer compartment with 60 mm spacing interval. 10 - position blast chiller/freezer compartment with 30 mm spacing interval

! Control panel for each compartment equipped with a HACCP - Top circuit board with LCD display for immediate, intuitive navigation, with a multi-language library and the possibility of selecting from preset programmes and/or memorize user programmes (blast chiller/freezer compartment), memorization-display of HACCP alarms

! Blast chiller/freezer compartment: manual air defrosting. Automatic passage to storage phase after blast freezing cycle. Storage freezer compartment: automatic electric defrosting.

Blast chiller/freezer

The range of made in Sagi blast chillers for ice-cream has been designed to ensure high quality ice-cream at each use.

After a whipping phase, the free water present in the freshly produced ice-cream, transforms into large ice crystals which would cause a loss of creaminess, taste and ice - cream volume.

To prevent this from happening, our blast chillers allow the formation of tiny microcrystals which maintain unaltered ice-cream quality.

DMG51C/M

745mm x 700mm x 1000/870mm

DMG51ME

745mm x 700mm x 870mm

DMG101L

800mm x 830mm x 1750mm

DMG82

750mm x 840mm x 2130mm

DMG102

820mm x 1036mm x 2130mm

10

REFRIGERATION

Underbar Refrigerator

QUB8S/C

Doors

Height (with castors)

Width

Depth

Temperature Range

Refrigerant

Internal Volume (Litres)

3.5

900mm

2380mm

650mm/750mm

2° to 6°C

R134A

840

QUB6S/C

Doors

Height (with castors)

Width

Depth

Temperature Range

Refrigerant

Internal Volume (Litres)

2.5

900mm

1780mm

650mm/750mm

2° to 6°C

R134A

580

Underbar Refrigerator

QUB4S/C

Doors

Height (with castors)

Width

Depth

Temperature Range

Refrigerant

Internal Volume (Litres)

1.5

900mm

1180mm

650mm/750mm

2° to 6°C

R134A

319

Underbar 2.5 Door Pizza Top

QUB6PZTS/C

Doors

Height (with castors)

Width

Depth

Temperature Range

Refrigerant

Internal Volume (Litres)

2.5

900mm

1780mm

650mm/750mm

2° to 6°C

R134A

580

11

REFRIGERATION

Back Bar Cooler

BBC 1 - 1 Door

Modular Back Bar Cooling systems designed for both small or large establishments. It has an advanced refrigeration system with built-in defrost and evaporation.

These units are supplied standard with adjustable shelves, electronic controls and internal lightning. Back Coolers are supplied in various finishes and is available in both hinged and sliding glass doors.

Back Bar Cooler

BBC 2 Hinged Door

Back Bar Cooler

BBC 3 - 3 Door

Back Bar Cooler

BBC 2 Sliding Door

Back Bar Cooler

BBC 3 - 2 Door

12

REFRIGERATION

Baby

Counter Top Ice Cream Freezer

! Temperature range: -15/-18°C

! 505mm x 680mm x 400mm

! Weight: kg 20

! Refrigerant gas: R 404a 0,120 kg.

! Power: 230V 50Hz 0,40 Kw

! EN 60 335-2-24

! Refrigerant ECO R 404a.

! Power supply V230-1-50 (other upon request)

! CFC free insulation

! ABS body

! Copper evaporator

! Low noise level

! Low energy consumption

! Easy maintenance

! Easy cleaning

! CE Norm

Piccolo

Counter Top Ice Cream Freezer

! Temperature range: -15/-18°C

! 505mm x 680mm x 400mm

! Weight: kg 20

! Refrigerant gas: R 404a 0,120 kg.

! Power: 230V 50Hz 0,40 Kw

! EN 60 335-2-24

! Refrigerant ECO R 404a.

! Power supply V230-1-50 (other upon request)

! CFC free insulation

! ABS body

! Copper evaporator

! Low noise level

! Low energy consumption

! Easy maintenance

! Easy cleaning

! CE Norm

Gelatissimo F9

Counter Top Ice Cream Freezer

! Temperature range: -15/-18°C

! 1255mm x 525mm x 360mm

! Weight kg: 35

! Refrigerant gas: R 404a 0,250 kg.

! Power: 230V 50Hz 0,50 Kw

! CE EN 60 335-2-24

! Refrigerant ECO R 404a.

! Power supply V230-1-50 (other upon request)

! CFC free insulation

! ABS body

! Copper evaporator

! Low noise level

! Low energy consumption

! Easy maintenance

! Easy cleaning

! CE Norm

13

THE PERFECT FRYING SOLUTION

Countertop Deep Fryer

The large output, ventless, hoodless, odorless, relentless, countertop deep fryer.

Increase your sales & profits with an expanded menu that will attract new customers with the easy-to-use perfect frying solution from perfect fry.

14

COLD BEVERAGE DISPENSERS

The Bubbler™ Standard Units

Unit

Bowls

Electrical

Refrigeration

Machine Dimensions

(H x W x D)

Cup Height

Listings

D15

1 X 18L bowls

D25: 115V / 60Hz / 5.5A

D255: 230V / 50Hz / 2.7A

D256: 230V / 60Hz / 2.7A

1/6 hp

69cm x 25cm x 38cm

20cm

UL, CUL, CE, NSF 20 (dairy)

D25

2 X 18L bowls

D25: 115V / 60Hz / 5.5A

D255: 230V / 50Hz / 2.7A

D256: 230V / 60Hz / 2.7A

1/6 hp

69cm x 44cm x 38cm

20cm

UL, CUL, CE, NSF

D25

D35

3 x 18L bowls

D35: 115V / 60Hz / 8.5A

D355: 230V / 50Hz / 4A

D356: 230V / 60Hz / 4A

1/6 hp

69cm x 65cm x 38cm

20cm

UL, CUL, CE, NSF

Unit

Bowls

Electrical

Suggested Uses

! Juice drinks

! Iced Coffee

! Tamarindo

! Chai

! Iced Cappuccino

Refrigeration

Machine Dimensions

(H x W x D)

Cup Height

Listings

! Cocktails

! Iced Tea

! Lemonade

! Horchata

The Bubbler™ Mini Units

E27/E29

2 x 9L bowls

E27 / E29: 115V / 60Hz / 3.3A

E275 / E295: 230V / 50Hz / 1.7A

E276 / E296: 230V / 60Hz / 1.7A

1/6 hp

65cm x 29cm x 38cm

20cm

UL, CUL, CE, NSF

E47/E49

4 x 9L bowls

E47 / E49: 115V / 60Hz / 5.5A

E475 / E495: 230V / 50Hz / 2.7A

E476 / E496: 230V / 60Hz / 2.7A

1/5 hp

65cm x 52cm x 38cm

20cm

UL, CUL, CE, NSF

E27/E29

E47/E49

D15

15

ESPRESSO MACHINES

VBM Lollo

Brewing Groups

Brew Head Style

Boiler

Thermosyphon System

Coffee Preinfusion

Steam Wands

Steam Valve Control

Length mm

Depth mm

Height mm

Heating Element Watts

Voltage

Amps

VBM Lollo 3 Group

3 Group

3

E64

16 litre

Heat Exchange

Static

360°

Multi Directional Locking Lever

930

560

500

5500W

240 V

25 amp

VBM Lollo 2 Group

VBM Lollo

Brewing Groups

Brew Head Style

Boiler

Thermosyphon System

Coffee Preinfusion

Steam Wands

Steam Valve Control

Length mm

Depth mm

Height mm

Heating Element Watts

Voltage

Amps

2 Group

2

E64

11 litre

Heat Exchange

Static

360°

Multi Directional Locking Lever

680

560

500

4500W

240 V

20 amp

16

VBM Replica 2 Group

ESPRESSO MACHINES

VBM Replica

VBM Replica

Boiler

Thermosyphon system

Coffee Preinfusion

Stainless Steel Wands

Steam Valve Control

Length mm

Depth mm

Height mm

1 Group

5 litre heat exchange static & electronic

360°

1/4 turn

530

535

500

Weight kg

Heating Element Wattage

Voltage

Boiler Contamination

Protection

Group Head Temperature

Control

Element Protection

60

1800

240V

Non return steam valve and anti-vacuum valve

Injector and

Hx restrictors

Element time out protection and over temperature thermo switch

Boiler Water Level Control

Probe System

Probe system

2 Group

11 litre heat exchange static & electronic

360°

1/4 turn

720

535

500

80

3500

240V

Non return steam valve and anti-vacuum valve

Injector and

Hx restrictors

Element time out protection and over temperature thermo switch

Probe system

3 Group

16 litre heat exchange static & electronic

360°

1/4 turn

890

535

500

100

4500

240V

Non return steam valve and anti-vacuum valve

Injector and

Hx restrictors

Element time out protection and over temperature thermo switch

Probe system

4 Group

25 litre heat exchange static & electronic

360°

1/4 turn

1230

525

500

120

5000

240V

Non return steam valve and anti-vacuum valve

Injector and

Hx restrictors

Element time out protection and over temperature thermo switch

Probe system

VBM Replica 3 Group

17

Easy Juicer™

Citrus Juicer

Ideal for oranges, lemons and limes.

Lets you quickly prepare the

freshest possible

lemonade, limeade, tropical drinks and other seasonal specialties.

FOOD PREPARATION

Easy Frykutter™

Vegetable Cutter

Cut potatoes for French fries and cut carrots and celery sticks. Chop onions, peppers, carrots and tomatoes. Wedge tomatoes for salads and potatoes for steak fries using the wedger kit. Great for wedging fruits too!

Easy Chopper II™

Use for fast, easy chopping, cutting and dicing of onions, tomatoes, potatoes, celery, peppers and other firm vegetables. Great for wedging citrus and other fruits, using the wedger kit.

Easy Chopper 1/4™

For salsa, pizza toppings, drink garnishes and more. Chops, slices and dices onions, tomatoes, potatoes, celery, peppers and other firm veggies. Great for wedging citrus and other fruits too, when using the wedger kit.

18

FOOD PREPARATION

Easy Tomato Slicer™

This is a must have if you like to keep fresh tomatoes on hand for your burgers, sandwiches, salads, salad bars and condiment trays. It’s great for slicing strawberries and mushrooms too.

Spiral Fry™

Potato Cutter

Hot, crispy spiral, ribbon, wavy or chip twister fries make a savory, healthful, h i g h - v a l u e p r e s e n t a t i o n t h a t customers love. Spiral Fry affords you the highest profit on every serving, and pays for itself in no time. It’s perfect for creating signature-item appetizers, and is a great choice for the bar and lounge too.

Easy Cheeser™

Cheese Cutter

The Easy Cheeser is perfect for salad bars, deli trays, party packs, in-store sampling, hors d’oeuvres and specialty trays. Great for butter too!

Makes individual pats and servingsize squares.

Easy Cheese Blocker™

Cheese Cutter

Use with the Nemco Easy Cheeser cutter for a total cheese prep center.

19

Easy Grill Scraper™

The Easy Grill Scraper features an ergonomic handle that channels all the pressure into the blade. That way, your staff can achieve the same desired results with much less effort, and get backto the more fun—and more productive—chores of preparing and cooking a whole lot faster.

Easy Flowering™

Onion Cutter

Create the perfect signature item onion appetizer. Or dip the ends of a flowered raw onion in food coloring to create magnificent onion garnish. Use with colossal and smaller sized onions.

FOOD PREPARATION

Easy Slicer™

Vegetable Slicer

Easy Slicer is the one slicer you need to make fast, easy work of most fruits and vegetables. Unique, adjustable, stainless steel blade provides a full range of slicing options. Fixed blade units also available. Optional shredding plates fit all units.

Butter Spreader™

This is the easiest and most efficient way to spread butter! Roller design promotes even, consistent application on all sorts of menu items, for economical portion.

Easy Chicken Slicer™

Cut your labor, not your hands, with the new

Easy Chicken Slicer. Compared to the conventional knife-in-hand alternative, the

Easy Chicken Slicer performs with superior s p e e d , co n si ste n c y a n d , a b o v e a l l , safety—with virtually no training required!

Cleanup is a breeze. Sharpened blades are also available for cutting other foods.

20

Easy Pineapple Corer/Peeler™

Take all the labor out of prepping a pineapple. Nemco’s latest countertop innovation completely removes the core and peel with one simple pull of its easyaction, top-down lever. Saves time, effort and food waste. locking mechanism keeps the handle/blade in the up position while loading a pineapple. Tough aluminum and stainless steel construction and easy disassembly for cleaning extend the life of the unit for great return on investment.

Easy Onion Slicer II™

Ideal for onions, celery, potatoes, pickles, firm tomatoes, oranges, lemons and limes.

FOOD PREPARATION

CanPRO™

Compact Can Opener

By cutting along the seam, on the outside of the rim,

®

Nemco’s new CanPRO recently emerged as a completely revolutionary way to open cans more easily and safely. Brilliantly conceptualized and carefully developed to include several new design improvements for durability, such as a gearless drive, the CanPRO is now saving time, and elbows, in thousands of commercial kitchens worldwide.

Easy Wedger™

& Easy Apple Corer

Easy Wedger is ideal for beverage operations. Use it for fresh lemon, lime and orange garnishes. Works great at the salad bar too. Try it with tomatoes, pickles, potatoes, cucumbers and zucchini.

21

FOOD PREPARATION

ShripPRO 2000™

Keep pace with the demand of your hungriest shrimp lovers! In just one hour, the ShrimpPro instantly and consistently deveins, cuts, butterflies or splits up to

6,000 shrimp! Operators can hand-feed or attach the feeder tray for higher volumes.

Either way, the ShrimpPro does all the work with virtually no risk of injury. Compact, portable design saves space and makes for easy storage.

Easy Lettucekutter™

Ideal for chopping iceberg and other lettuces, as well as slicing melons for fruit trays. Also slices lettuce for tacos and sandwiches. 55650-CS can be used to slice cooked chicken

for wraps and salads.

Roma Slicer™

This is the must-have tool for operations looking to capitalize on the increasing demand for

Caprese salads, personal pizzas, specialty sandwiches and other menu items featuring the smaller, richer, more authentic Roma. Great for slicing other soft produce too – like strawberries, mushrooms and more.

Available in:

1/4 Inch Slice

3/16 Inch Slice

22

HOT DOG EQUIPMENT

Roller Grill - 10 Hot Dogs

Model 8010

Roller Grill - 18 Hot Dogs

Model 8018 with self-serve guard Model 8018GD

Roller Grill - 27 Hot Dogs

Model 8027SX

Roller Grill - 45 Hot Dogs

Model 8045N with self-serve guard Model 8045NGD

Roller Grill - 36 Hot Dogs

Model 8036SX

23

HOT DOG EQUIPMENT

Moist Heat Bun/Food Warmer

Model 8027BW

Bun/Food Warmer

Model 8024BW

No Moist Heat

Bun/Food Warmer

Model 8048BW

No Moist Heat

Stainless Steel Bun Box

Model 8045W-SBB

24

FOOD WARMING

Model 6000A-1

Adjustable height

Freestanding Infrared Bulb Warmers

Model 6000A-2

Adjustable height

Bulb Warmer Suggested Uses

Keep plated foods at proper serving temperatures, including pies, breads, and other baked goods. Also great for hot appetizers and side dishes, such as chicken fingers, French fries, poppers and fried shrimp.

Counter-top Infrared Bulb Warmer

Model 6008-4

Clamp-on Infrared Bulb Warmer

Model 6004-4

Adjustable Gooseneck

Ceiling Mount Infrared Bulb Warmer

Model 6002

25

FOOD WARMING

Carving Station Infrared Bulb Warmer

Model 6015 polyethylene base

The perfect choice for serving moist, juicy slices of roast beef, prime rib, turkey, ham, leg of lamb and other large cuts at buffets and server stations.

Infrared Strip Heater on Base

Model 6152-24 with pan and screen set Model 66089

Infrared Strip Heater Suggested Uses

Hold foods at proper temperatures until you are ready to serve. A favorite for French fries, rice dishes, baked potatoes, fried chicken, pizza and large pans of food. Also works well as a plate or cup warmer.

Infrared Strip Heater

Model 6150-24 with hanging brackets

Infrared Strip Heater

Model 6150-24 with wire leg kit Model 66099

26

FOOD WARMING

Super Shot Countertop Steamer

Model 6600

Primed for virtually any cold foods you want to zap into a hot, fresh, plate-ready state—instantly! Ideal for buns, rolls, breads and other baked goods, and just perfect for tortillas.

Great for melting cheese or reheating precooked seafood, meats, pasta, fruits, veggies and more!

Countertop Warmer

Model 6100A

Countertop Warmers Suggested Uses

Attractive enough for serving lines, round warmers keep soups, gravies, BBQ sauce, hot dressings and dessert toppings warm and appetizing. Great for the back bar too.

Countertop Warmer

Model 6120A

Mini Steam Table

Model 6060A

Use one Nemco Mini Steam Table in place of several individual units to keep soups, sauces, gravies, stews and other like foods at the perfect temperature. Adapter plates provide maximum versatility on serving lines, allowing complete meal presentations, such as ribs with dipping sauce, mashed potatoes and gravy, plus many other side dishes.

Fresh-O-Matic by Nemco

Model 6625

The Fresh-O-Matic by Nemco can heat, refresh and serve hundreds of piping hot foods, from blueberry muffins, to beef stew, to Mexican burritos, to lobster dinners. You name it. If it’s leftover or frozen, it can taste like it’s freshly cooked once again.

27

Soup Merchandisers

Model 6510A-2D7

Turn your customers on to the idea of a hearty bowl of soup with these inviting soup warmer merchandisers. A unique heating element design maintains an even holding temperature and prevents hot spots. Twin warmers have separate thermostats for better temperature control. Plus, the header comes with interchangeable tab cards bearing the names of nearly 50 popular soups.

MERCHANDISERS

Model 6510-T4

Model 6510A-S7

28

DRINK MIXERS

Double Spindle Drink Mixer

WDM240

! Two high-performance 1 peak HP motors

! 3 speeds: 16,000, 22,000, 25,000 RPM, and Pulse

! Pulse switch pulses on selected speed

! No-tilt feature – Insert cup under spindle without the need to tilt

! Fully automatic START/STOP operation

! Heavy-duty die-cast housing

! Easily replaceable commercial motors

! 120 VAC, 60 Hz

UPC – 040072022371

Ship Weight – 28.6 lbs.

Cubic Feet – 2.540

Master Pack – 1

Single Spindle Drink Mixer

WDM120

! High-performance 1 peak HP motor

! 3 speeds: 16,000, 22,000, 25,000 RPM, and Pulse

! Pulse switch pulses on selected speed

! No-tilt feature – Insert cup under spindle without the need to tilt

! Fully automatic START/STOP operation

! Heavy-duty die-cast housing

! Easily replaceable commercial motor

! 120 VAC, 60 Hz

UPC – 040072015663

Ship Weight – 18.8 lbs.

Cubic Feet – 1.434

Master Pack – 1

Triple Spindle Drink Mixer

WDM360

! Three high-performance 1 peak HP motors

! 3 speeds: 16,000, 22,000, 25,000 RPM, and Pulse

! Pulse switch pulses on selected speed

! No-tilt feature – Insert cup under spindle without the need to tilt

! Fully automatic START/STOP operation

! Heavy-duty die-cast housing

! Easily replaceable commercial motors

! 120 VAC, 60 Hz

UPC – 040072015670

Ship Weight – 40.2 lbs.

Cubic Feet – 2.864

Master Pack – 1

Stainless Steel Malt Cup

CAC20

! 0.83 Lt

! Drink Mixer accessory

29

Medium-Duty Quik Stik Plus

®

WSB40E

! 254 mm fixed shaft, 24-liter capacity

! 1⁄2 HP heavy-duty motor

! 350-watt, 2-speed control

! 20,000 RPM on High

! Rubberized comfort grip

! All-purpose stainless steel blade

! 230 VAC, 50/60 Hz, 1.5 amps

! CE, RoHS*

Light-Duty Quik Stik

®

WSB33E

! 178mm fixed shaft, 12-liter capacity

! High efficiency 100-watt, 2-speed motor

! 20,000 RPM on High

! Lightweight and compact

! All-purpose stainless steel blade

! 230 VAC, 50/60 Hz, 0.4 amps

! CE, RoHS

254mm Stainless Steel Whisk Attachment

WSB2W

! Fits entire Big Stix® Heavy-Duty Immersion Blender line

! User-replaceable couplings with kit (CAC104)

BLENDERS

WSB65E

Heavy-Duty Big Stix

®

! HP heavy-duty motor

! 650-watt variable speed motor — 18,000 RPM on High

! Continuous On feature

! User-replaceable couplings with kit (CAC104)

! All-purpose stainless steel blade

! Rubberized comfort grip and second handle for safe and controlled operation

! Completely sealed stainless steel shaft is easily removable and dishwasher safe

! Universal power packs fit all shafts

! 230 VAC, 50/60 Hz, 2.8 amps

! CE, RoHS1

WSB70E

WSB50E

305mm Removable shaft

40 Lt capacity

WSB55E

355mm Removable shaft

60 Lt

WSB60E

406mm Removable shaft

100 Lt

WSB65E

457mm Removable shaft

140 Lt

WSB70E

533mm Removable shaft

200 Lt

With 254mm Stainless Steel Whisk Attachment

WSBPPWE

! 1 HP, 650-watt variable speed motor — 1600 RPM on High

! All the same features as Big Stix®

! User-replaceable couplings with kit (CAC104)

30

BLENDERS

MX1000XTEE MX1000XTPEE

Hi-Power Blenders

MX1000XTEE / MX1000XTPEE

! Heavy-duty 3.5 peak HP motor

! 45,000 RPM bare motor speed, 1500 watts

! Simple High, Low, Off and Pulse paddle switches

! One-piece dishwasher-safe removable jar pad

! MX1000XTEE — 2-liter BPA-free copolyestercontainer

! MX1000XTPEE — 1.5-liter stackable BPA-free copolyester container

MX1000XTSEE, MX1000XTPSEE

Sound Enclosure Included

! 240 VAC, 50Hz, 6.25 amps

! CE, RoHS (other configurations may be available

Hi-Power Programmable Blenders

With Sound Enclosure

MX1500XTEE / MX1500XTPEE

! Heavy-duty 3.5 peak HP motor, 1500 watts

! Easy-to-clean electronic membrane keypad

! LCD display with blue backlight for easy viewing and program selection

! 4 reprogrammable beverage stations

! Daily and total drink counter display

! Adjustable speed controls

! MX1500XTEE — 2-liter BPA-free copolyester container

! MX1500XTPEE — 1.5-liter stackable BPA-free copolyester container

! 240 VAC, 50 Hz, 6.25 amps

! CE, RoHS

! (other configurations may be available) MX1500XTPEE

Hi-Power Blenders

MX1050XTEE / MX1050XTPEE

! Heavy-duty 3.5 peak HP motor

! 45,000 RPM bare motor speed, 1500 watts

! Easy-to-clean electronic membrane keypad with simple On/Off, High, Low, Stop and Pulse controls

! One-piece dishwasher-safe removable jar pad

! MX1050XTEE — 2-liter

BPA-free copolyester container

! MX1050XTPEE — 1.5-liter

! stackable BPA-free copolyester container

! MX1050XTSEE, MX1050XTPSEE –

Sound Enclosure Included

! 240 VAC, 50Hz, 6.25 amps

! CE, RoHS

(other configurations may be available)

MX1500XTEE

31

GRILLS & TOASTERS

Tostato Supremo™

Large Italian-Style Panini Grill

WFG250E

! Flat cast-iron plates

! 368mm x 279mm cooking surface, great for grilled paninis, hamburgers, chicken, vegetables and more

! Brushed stainless steel body and removable drip tray

! Hinged, auto-balancing top plate to accommodate foods up to 76mm thick

! Adjustable thermostat to 299°C

! Adjustable back feet for easy grease drainage

! Indicator lights — Power and Ready

! Heat-resistant handles

! 230 VAC, 2520 watts, 10.4 amps

! CE, RoHS

Panini Ottimo™

Double Italian-Style Panini Grill

WPG300

! Flat ribbed-iron plates

! 431,8mm x 235mm cooking surface, great for grilled panini sandwiches, hamburgers, chicken, vegetables and more

! Brushed stainless steel body construction and removable drip tray

! Hinged, auto-balancing top plate to suit foods up to

76mm thick

! Adjustable thermostat to 570°F

! Adjustable back feet for easy grease drainage

! Dual Power ON and Ready indicator lights

! Heat-resistant handles

! 230 VAC, 2100 watts, 8.7 amps

! CE, RoHS

Tostato Perfetto™

Compact Italian-Style Panini Grill

WFG150E

! Flat cast-iron plates

! 247mm x 235mm cooking surface, great for grilled paninis, hamburgers, chicken, vegetables and more

! Brushed stainless steel body and removable drip tray

! Hinged, auto-balancing top plate to accommodate foods up to 76mm thick

! Adjustable thermostat to 299°C

! Indicator lights — Power and Ready

! Heat-resistant handles

! 230 VAC, 2100 watts, 8.7 amps

! CE, RoHS

32

GRILLS & TOASTERS

Panini Supremo™

Large Italian-Style Panini Grill

WPG250E

! Ribbed cast-iron plates for even heat distribution and quick cooking time

! 368mm x 279mm cooking surface, great for grilled paninis, hamburgers, chicken, vegetables and more

! Brushed stainless steel body and removable drip tray

! Hinged, auto-balancing top plate to accommodate foods up to 76mm thick

! Adjustable thermostat to 299°C

! Adjustable back feet for easy grease drainage

! Indicator lights — Power and Ready

! Heat-resistant handles

! 230 VAC, 2520 watts, 10.4 amps

! CE, RoHS

Heavy-Duty Combination Toaster

WCT815E

! Uniformly toasts regular bread, Texas toast, frozen waffles and many other foods

! Two 28mm regular toast slots and two 38mm extra-wide slots for bagels

! Bagel slots toast on cut side of bagel only

! Easily replaceable industrial heating plates

! 380 slices per hour

! 240 VAC, 2025 watts, 8.8 amps

! Electronic browning controls and carriage control lift levers

! Dishwasher-safe crumb tray

! CE, RoHS

Panini Perfetto™

Compact Italian-Style Panini Grill

WPG150E

! Ribbed cast-iron plates for even heat distribution and quick cooking time

! 248mm x 235mm cooking surface, great for grilled

! paninis, hamburgers, chicken, vegetables and more

! Brushed stainless steel body and removable drip tray

! Hinged, auto-balancing top plate to accommodate foods up to 3" thick

! Adjustable thermostat to 299°C

! Indicator lights — Power and Ready

! Heat-resistant handles

! 230 VAC, 2100 watts, 8.7 amps

! CE, RoHS

33

SPECIALITY PRODUCTS

Commercial Belgian Waffle Maker

WW150E

! Heavy-duty die-cast housing

! Rotary feature for even baking and browning

! Audio beep signals when waffle is ready

! LED indicators — Power and Ready to Bake

! Delivers up to 25 (30mm thick) Belgian waffles per hour

! Triple-coated, nonstick plates allow for easy removal of waffle and quick cleanup

! 230 VAC, 50 Hz, 1200 watts, 5.2 amps

! CE, RoHS

Commercial Belgian Waffle Maker

WW250

! Heavy-duty die-cast housing

! Rotary feature for even baking and browning

! Audio beep signals when waffle is ready

! LED indicators — Power and Ready to Bake

! Delivers up to 60 (30 mm thick) Belgian waffles per hour

! Triple-coated, nonstick plates allow for easy removal of waffle and quick cleanup

! 230 VAC, 50 Hz, 1200 watts, 5.2 amps

! CE, RoHS

Commercial Ice Crusher

IC70E

! Heavy-duty stainless steel crushing blades, powered by

½ HP motor

! Brushed stainless steel exterior

! Large chute and funnel for easy feeding

! Container holds up to 12 cups of crushed ice

! 230 VAC, 50 Hz, 350 watts, 1.5 amps

! CE, RoHS

34

DISPOSABLES DISPENSING

One-Size-Fits-All EZ-Fit

®

Cup Dispenser C2410C

146mm (Counter hole diameter) x 590mm (Tube Length)

Aprrox. Cup Size 236 - 1360ml

! Includes a gasket pack to handle wide range of cup sizes

! Easily change cup sizes without having to change dispenser

! Dispenses paper, plastic, and foam cups one-at-a-time

Lid Organisers

L2100

279 x 318 x 419 mm

L2150

273 x 216 x 419 mm

! Keep lids organized and easily accessible to customers

! Countertop design allows you to move organizer to accommodate changing needs

Lid Towers

L2203

3 Lid compartments, 1 Straw compartment

622 x 140 x 330 mm

L2204

4 Lid compartments, 1 Straw compartment

762 x 140 x 330 mm

! High capacity lid and straw organization

! Countertop design allows you to move organizer and accommodate changing needs

Condiment & Straw Organizer

L2900

241 x 208 x 637 mm

35

®

Safe-T-Ice Tote

S1600 - Original 22.7 Lt

S1600 - Shorty™ 18.9 Lt

! Dedicated container for safe ice transport

! HACCP Hanger™ reduces back strain and injuries

! Tri-grip™ design for easier, more controlled handling

®

Safe-T-Scoop & Guardian System™

For Ice Machines

Included mounting tools: (1) mounting bracket, (2) wire hanging brackets and (2) suction cups

SI9000 - Scoop Guardian™ System 1.9-2.5 Lt

1 x Saf-T-Scoop

®

1 x Guardian holder with removable drainage cap

1 x Set mounting tools

Scoop only

FOOD SAFETY TOOLS

For Bar and Beverage Stations

Included mounting tools: (1) mounting bracket, (2) wire hanging brackets and (2) suction cups

S15000 - Scoop Guardian™ System 177-295 ml

1 X Saf-T-Scoop®,

1 X Guardian holder with removable drainage cap

1 X Set mounting tools

Scoop only

SI7000 - Scoop Guardian™ System 355-473 ml

1 X Saf-T-Scoop®,

1 X Guardian holder with removable drainage cap

1 X Set mounting tools

Scoop only

Klever Kutter™ Carton Opener

KK401 - Red

! No need to change blades

! Prevents costly injuries to employees

! Prevents damage to products

36

Kleen-Cup

®

KLC28C

! Effectively cleans and sanitizes mixer spindles

! Prevents flavor transfer and cross-contamination

! Replaceable brushes

FOOD SAFETY TOOLS

®

Safe-T-Knife Station

STK1008

! Sanitary, safe and secure storage for kitchen knives

! Protects knives from contamination and accidents

! Easy to assemble and clean

Allergen Saf-T-Zone™ System

The Allergen Saf-T-Zone™ System is the first product of its kind, designed to help foodservice operators create special food allergen meal prep procedures.

! Purple color alerts staff to follow special food allergy procedures

! Includes commercial-grade cutting board, tongs, turner and Chef ’s knife

! Durable purple case is easy to find in the kitchen and securely protects tools and board

ASZ121812SYS

1 x 254 mm stainless steel chef knife with purple handle

1 x 305 mm stainless steel tongs with purple handle

1 x 330 mm stainless steel turner with purple handle

(Thermometer not included)

ASZTHERM

Professional digital thermometer with protective sheath

ASZTHERMW

Professional digital thermometer with protective sheath, dishwasher safe

37

FOOD SAFETY TOOLS

®

Saf-T-Grip Cutting Boards

CBG912

229 x 305 x 9.5 mm

Blue, Brown, Green, Red, White and Yellow

! Integrated anti-slip grips securely hold board in place

! Food Safety Hook for sanitary transport and storage

! Durable co-polymer material will not warp

CBG6938

152 x 229 x 9.5 mm

Black, green, red, white and yellow

! Durable co-polymer construction provides superior heat, chemical and warp resistance

! Material won’t dull knives and resists unsanitary cut-grooving

! Smaller size is ideal for tight spaces

®

Saf-T-Grip 4-Board System

CBGW912QS

229 x 305 x 9.5 mm

4 x white boards with green, yellow, red and white grips

CBGW152012QS

381 x 508 x 13 mm

4 x white boards with green, yellow, red and white grips

! Reduce cross-contamination with color-coded cutting boards

while allowing you the tradition of a white cutting board

CBGW912

229 x 305 x 9.5 mm

White boards with blue, green, yellow and red grips preventing cross contamination

! All the same great features of Saf-T-Grip

®

38

BAR & FOOD MANAGEMENT

BD4005E

! Patented, domed lid rotates back for easy access and increased capacity when closed

! Use standard size trays to keep food chilled or deep trays for extra capacity

! Integrated snap-on caddies store straws, stirrers & picks

BD4005S

1 X 2 qt. deep tray

4 X 1 pt. standard trays;

2 X snap-on caddies, handles

BD4005E

1 X 2 qt. deep tray

4 X 1 pt. standard trays;

2 X end caps

1 X snap-on caddy

BD4023S

2 X 3 pt. deep trays

3 X 1 pt. standard trays

2 X snap-on caddies, handles

BD4006S

6 X 1 pt. standard trays; 2 X snap-on caddies, handles

BD4003

3 X 2 qt. deep trays; 2 X handles

BD4004

4 X 3 pt. deep trays; 2 X handles

BD4014

4 X 1.5 pt. standard trays; 2 X handles

BD2001

! Patented, domed lid design in a smaller size; notched lid option

®

BD2001

1 x 1.9 Lt deep tray

BD2002

1 x 0.95 Lt standard tray

BD2003

2 x 0.47 Lt standard trays

BD2004NL

2 x 0.71 Lt deep trays (notched domed lid)

BD2002CAR

1 x 0.95 Lt standard tray with caddy

BD2004CAL

2 x 0.7 Lt trays with left hand caddy

39

BDS4266

BAR & FOOD MANAGEMENT

®

Dome Stacker

! Patented, domed lid design in a smaller size; notched lid option

®

4 x 1 0.47 Lt standard trays and bonus 2 x 1.9 Lt trays

4 x 0.71 Lt deep trays, notched lids and bonus 2 x 0.95 Lt trays

®

4 x 0.71 Lt deep trays, 4 x 0.47 Lt standard trays, 2 x notched lids and 2 x standard lids

12 x 0.47 Lt standard trays

3 x 1.9 Lt deep trays and 6 x 0.47 Lt standard trays, Chillable

BDS2483NL BDS2203

40

SPECIALISED FABRICATION

FSE-FL

Fries Station

FSE-FL / FSS-FL

! Fully 304 stainless steel construction

! Easy-to-remove & clean parts

! Highly durable & reliable ceramic heating elements

! Special design bottom heater for dump pan heating

! Divider could optionally to segregate different product placed in the dump pan.

! Raised edge around dump basket and prepack area for easier cleaning

! Poly carbonate shield for pre-pack to keep packed fries fresh & warm

! Low wattage rating & less energy consumption

Burger Chute

HBC-36-2T

! Full stainless steel construction for ease of cleaning

! Pass-through design

! Angled thermo-perspex flip doors provide easy & clear viewing of the product as well as maximum heat retention which give food safety & hygiene

! Individual control section giving the flexibility to adjust according to your needs

! Dual heat technology with individual heater controls intensity adjustable radiant heater on top side and digital temperature controlled foil heater on bottom side

! Easily removable of parts for cleaning

! Easily accessible electrical panel for service & maintenance

Heated Counter Warmer

HCW3T

! Full stainless steel construction for ease of cleaning

! Pass-through design

! Angled thermo-perspex flip doors provide easy & clear viewing of the product as well as maximum heat retention which give food safety & hygiene

! Individual control section giving the flexibility to adjust according to your needs

! “Dry heat” – top tier will give the heat require to hold your fried product crispy fresh & “Humidified Heat” – bottom tier will provide the humidity required to keep your product warmly moist and fresh

! Automatic water refills thru the use of level sensor with manual by-pass

! Digital temperature display & thermostat control water in the well

Options & Accessories

! Aluminium perforated bun pan

! S/S tong holder

FSS-FL

41

SPECIALISED FABRICATION

Holding Cabinet

HCPT

! Full stainless steel construction for ease of cleaning

! Self-contained detachable heating module

! Powerfully and efficient heating system to provide right temperature required to hold product

! Uniform temperature of +/-3°C

! Digital temperature controller

! Rigid structure frame body

! Oversize base for protecting cabinet body

! Self-closing doors with magnetic door gaskets provide maximum heat retention and sealing

! Removable tray racks

Options & Accessories

! Aluminium perforated bun pan

Breading Table

BTS

! Full stainless steel construction for ease of cleaning

! Optional high backsplash application and integrated bin skirting to keep flour spillage to minimum

! Patented front loading design for ease of exchanging breading bin

! “Slide-In” design for ease of operator fatigue

! Reduce lifting height by 22%

! Improve productivity

Options & Accessories

! Rubber plug

! S/S breading bin

! Plastic breading bin

! S/S vegetable round insert c/w cover

! S/S egg dip basket

Marinator

M

! Full stainless steel construction for ease of cleaning

! Leak proof drum

! Easy to operate control

! Adjustable timer & auto shut off

! Special design drum capable of marinating up to

80Ibs of product each time

! Easy removal of marinated product manually

! Heavy duty swivel caster with brakes

Options & Accessories

! Non perforated 9” poly lug

! Perforated 9” poly lug

! Gasket cover

42

TOASTERS AND OVENS

Vertical Bun Toaster

CBT-15

! 2 Openings: 55.4 cm Wide x 35.1 cm Deep

! Great For HIGH Volume Bun/Roll Contact Toasting

! 2 Sided Heat Platen For Toasting Crowns and Heels

! Spring Loaded Pressure Plate (no adjustment knobs)

! Dual, Drive Systems

! Adjustable Conveyor Speed

! Adjustable Thermostatic Heat Control

Conveyor Toaster

JT1

! 36.5 cm Wide x 35.3 cm High x 41.3 cm Deep

! 120 Volts – Plugs in Anywhere

! Up to 350 Slices or Bun Halves/hr*

! Cool Touch Exterior

! Safe For Self Serve Operation

! 26.6 cm Wide Conveyor

Junior Bagel Toaster

JT1-B

! 36.5cm Wide x 33.3cm High x 41.3cm Deep

! 120 Volts – Plugs in Anywhere

! Up to 500 Bagel Halves/hr*

! Cool Touch Exterior

! Safe For Self Serve Operation

! 26.6 cm Wide Conveyor

Conveyor Bagel Toaster

JT2-B

! Durable, Rugged Construction

! Forced Convection Toasting

! 26.6 cm Conveyor Belt

! Inexpensive To Operate

! Energy Efficient CAL-ROD Heaters

! 50% Power Saving Feature

! 24 Hrs/Day, 7 Days/Week Service

43

TOASTERS AND OVENS

Conveyor Toaster

JT2

! 35.9 cm Wide x 35.3 cm High x 46.4 cm Deep

! 26.6 cm Wide Conveyor

! 208, 220 and 240 Volts:

! Up to 800 Slices or Bun Halves/hr

! Also Available At 120 Volts:

! Up to 450 Slices or Bun Halves/hr

! Cool Touch Exterior

! Safe For Self Serve Operation

Conveyor Toaster

JT3

! 36.5 cm Wide x 33.3 cm High x 46.4 cm Deep

! Basic, simple operation

! Durable, Rugged Construction

! Forced Convection Toasting

! Independent Heat Controls

! Inexpensive To Operate

! Energy Efficient Quartz Heaters

! 75% Power Saving Feature

! 24 Hrs/Day, 7 Days/Week Service

Broiler / Cheese Melter

JW30

! Great For Broiling and Finishing Menu Items

! Broil Steaks In Approximately 10 Minutes

! Melt Cheese and Finish Nachos in 1-2 minutes

! Great For Cheese Fries, Potato Skins, Fish, Garlic Bread and Much More

! Capacity: 3 -25 cm Plates or 2 -30 cm Platters

! Opening: 52.75cm Wide, 35.5cm Deep, 18.4cm High

Finishing / Broiler Oven

JW1

! 33 cm Wide x 15.6 cm High x 26.6 cm Deep

! 120 Volts – Plugs in Anywhere

! 15 Minute Timer

! Top Heat Only

! Automatic Standby Feature

! Five Shelf Position

! Electric Infrared Quartz

! Forced Convection

! Energy Saving Features

! Wall Mounting Available

44

BLENDERS

Model

Description

Power

Color

Control

Speed

Container Size

Container Material

Voltage

Dimensions

Net weight

BL330

1 HP Blender

600 Watts

Silver (BL330S)

Red (BL330R)

2 Speed Toggle

(high/low)

21,500 - 25,500

1.3 Kg

BPA Free Tritan

Copolyester

120/60/1

220/50/1 (use BL332)

203mm W x 178 mm x 394 mm H

3.2 Kg

Model

Description

Power

Control

Speed

Container Size

Container Material

Voltage

Dimensions

Net weight

B2400

2 HP Variable Speed Blender

1500 Watts

On/Off and High/Low

Toggle Control

21,500 - 25,500

1.3 Kg

BPA Free Tritan

Copolyester

Available in 120V/60Hz and 220V/50-60HZ (B2502)

197mm W x 229 mm x 514 mm H

7 Kg

Model

Description

Power

Color

Control

Speed

Container Size

Container Material

Voltage

Dimensions

Net weight

BL360

1 HP Blender

600 Watts

Silver (BL360S)

Red (BL360R)

2 Speed Toggle

(high/low)

21,500 - 25,500

1 Kg

Stainless Steel

120/60/1

220/50/1 (use BL362)

133mm W x 178 mm x 394 mm H

3.1 Kg

Model

Description

Power

Dimensions

Control

Container Size

Voltage

Net weight

B2500

2 HP 2 Speed Blender

1500 Watts

197mm W x 229 mm x 514 mm H

On/Off and High/low

Toggle Control

1.8 Kg

Available in 120V/60Hz and 220V/50-60HZ (B2502)

7 Kg

Model

Description

Power

Color

Control

Speed

Container Size

Container Material

Voltage

Dimensions

Net weight

BL390

1 HP Blender

600 Watts

Silver (BL390S)

Red (BL390R)

2 Speed Toggle

(high/low)

21,500 - 25,500

Combo Pack - 1.3 / 1 Kg

Tritan Copolyester +

Stainless Steel

120/60/1

220/50/1 (use BL392)

Same as BL330 & BL360

Same as BL330 & BL360

45

PRO KITCHEN EQUIPMENT

High Performance Butane Stove

90019

! For Indoor Commercial Use

! High Impact Carrying Case

! Automatic Piezo Electronic Ignition

! In Line Regulator with Pressure Sensing Shut Off

! Heat Transfer Plate Maintains High Heat Output

! Boil to Simmer Heat Range

! Use Only Butane Marked BF1010

High Performance Butane Stove

90011

! For Indoor Commercial Use

! High-Impact Carrying Case

! Automatic Piezo Electronic Ignition

! In Line Regulator with Pressure

Sensing Shut Off

! Heat Transfer Plate Maintains High

Heat Output

! Boil to Simmer Heat Range

! Use Only Butane Marked BF1010

Knife Sharpener

90015GDCM01

! Reversible Carbide Blades

Premium Griddle Scraper

90002

! Engineered to Maximize Production and

Minimize Fatigue

Meat Tenderiser

90009

! Make the Toughest Cut of Meat into a Juicy,

Flavorful Masterpiece

! 48 Stainless Steel Razor Sharp Blades

Penetrate Any Cut of Meat with Ease

! Tenderizing Meat, Poultry or Fish Prior to

Marinating will Allow Spices & Flavors to be

Absorbed Quickly & Deeply

! Easy to Use – No Assembly Required

46

Char Broiler Brush

90051

! Commercial Grade Stainless Steel Bristles &

Scraper

! Dual-Handle Provides Leverage to Remove

Tough Residue Easily

PRO KITCHEN EQUIPMENT

19 Lt Salad Dryer

90005

! Built-In Brake Extends Life of Gears

! Sanitary Sealed Gearbox

! Convenient Side Handles

! Large 19 Lt Capacity Accommodates

Approximately 5-6 Heads of Lettuce

Barbecue Grilling Claws

40209CM

! The Quick and Easy Way to Shred Pork, Beef

& Chicken

! Firmly Holds Meats While Lifting or Carving

! Soft Comfortable Rubber Grip for Easy

Handling

19 Lt Salad Dryer

90008

! Convenient Side Handles for Safe & Easy

Transport

! Heavy Duty, Durable & Safe

! Large 19 Lt Capacity Accommodates

Approximately 5-6 Heads of Lettuce

9 Lt Salad Dryer

90012

! Built-In Brake Extends Life of Gears

! Sanitary Sealed Gearbox

! Convenient Side Handles

! 9 Lt Capacity Accommodates Approximately

2-3 Heads of Lettuce

47

Hand Held Grill Brush

90044

! Durable Handle

! Stainless Steel Bristles

! Stainless Steel Scraper Blade

PRO KITCHEN EQUIPMENT

Panini Grill Brush

90052

! 1m Handle

! 196mm Double-Sided Head

! Long Stainless Steel Bristles

Griddle Scraper

90018

! Durable Handle

! Stainless Steel Bristles

! Stainless Steel Scraper Blade

Classic Pizza Oven Brush

90041

! 1m Handle

! 254mm Head

! Brass Bristles

! Stainless Steel Scraper Blade

! Double Crimped Collar

Classic

Broiler Brush

90042

! 762mm Handle

! 203mm Head

! Stainless Steel Bristles

! Stainless Steel Scraper Blade

! Double Crimped Collar

48

PRO KITCHEN EQUIPMENT

1 Lt

Butter Roller

90021

! Spreads Butter Quickly and

Evenly

! Prevents Messy Spills and

Flareups Around the Grill or

Griddle

! Easy to Clean

! Sturdy Stainless Steel

Construction

Whipped Cream

Dispensers

90068 / 90069

! Easy to Operate

! Eco-Friendly

! Economically Priced with

Professional Results

0.5 Lt

Pro Chopper

90017

! Easily Cut, Dice, Chop and

Mince

! Great for Salad, Herbs,

Veggies,Dough and More

! Use in a Bowl or on a Cutting

Board

! Double Stainless Blades

! Natural Rocking Motion Makes

! Chopping Quick and Easy

! Commercial Dishwasher Safe

1 Lt

Premium Whipped

Cream Dispensers

90062 / 90063

! Easy to Operate

! Dishwasher Safe

! For Professional Use Only

! Limited Lifetime Warranty

0.5 Lt

Citrus Wedger

90023

! Makes Perfectly Wedged Lemons and Limes for Drinks and

Garnishes

! Produces 8 or 16 Wedges at a Time

! Safer to Use — Eliminates Knife Accidents

! Saves Time with One Easy Motion

! Non-Skid Rubber Feet Keeps Wedger in Place

49

INSULATED FOOD STORAGE BOXES

GN 1/1 Premium

Freezer Box

CBT-15

GN Premium - More space and special recessed grips inside make changing of hot or heavy GN-containers easier. Special space for labels.

10023

Outside Dimensions: 600mm x 400mm x 180mm

Inside Dimensions: 538 mm x 337mm x 117mm

10033

Outside Dimensions: 600mm x 400mm x 230mm

Inside Dimensions: 538mm x 337mm x 167mm

10043

Outside Dimensions: 600mm x 400mm x 280mm

Inside Dimensions: 538mm x 337mm x 217mm

10053

Outside Dimensions: 600mm x 400mm x 320mm

Inside Dimensions: 538mm x 337mm x 257mm

10083

Cooling top

Space-saving insulation box. Hinged side walls and

2-piece lid. Handy and easy to fold-up, stackable.

Insulation from -30° up to + 90°C.

12643

Outside Dimensions: 685mm x 485mm x 260mm

Inside Dimensions: 625mm x 425mm x 200mm

12673

Outside Dimensions: 685mm x 485mm x 360mm

Inside Dimensions: 625mm x 425mm x 300mm

Freely expandable

Drinks to Go

10163

Safe transportation and insulation of drinks, yoghurt, fruit and more.

Click-to-connect system expandable from three to twelve beverage holders for various sized plastic cups. Insert for GN and

PIZZA Box.

Outside Dimensions: 335mm x

117mm x 135mm

Inside Dimensions: 3 x Ø 69mm -

88mm

Simply click-to-connect

50

INSULATED FOOD STORAGE BOXES

Frontloader

10400

For safe transportation and insulation of hot, cold and fresh food. It is sturdy, solid and extremely light.

Outside Dimensions: 645mm x 445mm x 625mm

Inside Dimensions: 530mm x 335mm x 525mm

Guide Rails - Distance: 12 - 32 mm

Faltbox

10340

Space-saving insulation box. Hinged side walls and 2-piece lid. Handy and easy to fold-up, stackable. Insulation from -30° up to + 90°C.

Outside Dimensions: 600mm x 400mm x 250mm

Inside Dimensions: 550mm x 350mm x 200mm

Frontloader

10450

For safe transportation and insulation of hot, cold and fresh food. It is sturdy, solid and extremely light.

Outside Dimensions: 645mm x 445mm x 475mm

Inside Dimensions: 530mm x 335mm x 370mm

Guide Rails - Distance: 8 - 32 mm

Boxer

10383

Box for best logistical solutions! Optimized packing size (1/4 Euro-pallet), stackable with most common stacking containers (E2- or bakery baskets), suitable for GN size containers.

Outside Dimensions: 595mm x 395mm x 290mm

Inside Dimensions: 540mm x 340mm x 230mm

51

INSULATED FOOD STORAGE BOXES

Ice Box

13433

For safe transportation and insulation of hot, cold and fresh food. It is sturdy, solid and extremely light.

Outside Dimensions: 600mm x 400mm x 260mm

Inside Dimensions: 3 x (360mm x 165mm x 150mm)

Shopping Box

20955

Blue

Outside Dimensions: 325mm x 265mm x 325mm

Inside Dimensions: 275mm x 215mm x 260mm

20957

Red

Outside Dimensions: 325mm x 265mm x 325mm

Inside Dimensions: 275mm x 215mm x 260mm

For safe transportation and insulation of hot, cold and fresh food. It is sturdy, solid and extremely light.

Ideal for leisure, camping or shopping.

Practical plastic strap.

20953

Black

Outside Dimensions: 325mm x 265mm x 325mm

Inside Dimensions: 275mm x 215mm x 260mm

20954

Green

Outside Dimensions: 325mm x 265mm x 325mm

Inside Dimensions: 275mm x 215mm x 260mm

Extension Frame

13473

52

12350

12350 + 12153

INSULATED FOOD STORAGE BOXES

Pizza Frontloader

12350

Comfortable front loading pizza box for hot, big size pizza, fresh salads or cold beverages. Including 1 x removable EPP-shelf to separate insulated areas for delivery of hot and cold food. Solid plastic hinges.

Easy to open and to close, lockable door. Large interchangeable advertising space on four sides.

Weight without signboards 4,6 kg.

Outside Dimensions: 600mm x 580mm x 570mm

Inside Dimensions: 490mm x 490mm x 415mm

12350 + 12153

As an option: use a Pizza Box to separate “hot & cold“

Outside Dimensions: 480mm x 480mm x 265mm

Inside Dimensions: 420mm x 420mm x 197mm

Pizza Box

12013

For safe transportation and insulation of Pizza or other foods. It is sturdy, solid and extremely light.

Outside Dimensions: 490mm x 490mm x 540mm

Inside Dimensions: 420mm x 420mm x 470mm

Pizza Frontloader

12300

Comfortable front loading pizza box for hot pizza, fresh salads or cold beverages. Including 1 x removable EPP-shelf separates insulated areas for delivery of hot and cold food. Solid plastic hinges.

Lockable front flap. Large advertising space on front flap and sides. Weighs only 3,6 kg.

Outside Dimensions: 490mm x 490mm x 540mm

Inside Dimensions: 420mm x 420mm x 470mm

53

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
