E-Series Widescreen
Multifunction Display
Installation instructions
E90W, E120W and E140W models
Trademarks and registered trademarks
Autohelm, HSB, RayTech Navigator, Sail Pilot, SeaTalk and Sportpilot are UK registered trademarks of Raymarine UK Limited.
Pathfinder and Raymarine are UK registered trademarks of Raymarine Holdings Limited. 33STV, 45STV, 60STV, AST, Autoadapt,
Auto GST, AutoSeastate, AutoTrim, Bidata, G Series, HDFI, LifeTag, Marine Intelligence, Maxiview, On Board, Raychart, Raynav,
Raypilot, RayTalk, Raystar, ST40, ST60+, Seaclutter, Smart Route, Tridata, UniControl, Hybridtouch, and Waypoint Navigation are
trademarks of Raymarine UK Limited.
All other product names are trademarks or registered trademarks of their respective owners.
Fair Use Statement
You may print no more than three copies of this manual for your own use. You may not make any further copies or distribute or use the
manual in any other way including without limitation exploiting the manual commercially or giving or selling copies to third parties.
Copyright ©2009 Raymarine UK Ltd. All rights reserved.
ENGLISH
Document number: 87116-1
Date: 09-2009
Contents
Chapter 1 Important information............................. 7
TFT LCD Displays .......................................................... 8
Water ingress ................................................................. 8
Disclaimers .................................................................... 9
CompactFlash cards ....................................................... 9
EMC installation guidelines ............................................. 9
Suppression ferrites ........................................................ 10
Connections to other equipment ...................................... 10
Declaration of conformity................................................. 10
Product disposal ............................................................. 10
Warranty registration....................................................... 10
IMO and SOLAS............................................................. 11
Technical accuracy ......................................................... 11
3.1 General cabling guidance .......................................... 22
3.2 Connections overview ............................................... 23
3.3 Power connection ..................................................... 23
3.4 SeaTalkhs network ..................................................... 26
3.5 NMEA 0183 connection ............................................. 34
3.6 SeaTalk connection ................................................... 35
3.7 Alarm connection ...................................................... 36
3.8 GPS connection ........................................................ 37
3.9 AIS connection.......................................................... 38
3.10 Fastheading connection........................................... 39
3.11 SeaTalkng connections ............................................. 40
3.12 NMEA 2000 connection ........................................... 41
3.13 Video and alarm audio connection............................ 42
Chapter 2 Planning the installation ........................ 13
Chapter 4 Location and mounting .......................... 45
2.1 Handbook information ............................................... 14
2.2 Installation checklist .................................................. 14
2.3 E-Series Widescreen system ..................................... 15
2.4 System protocols ...................................................... 17
2.5 Data master.............................................................. 18
2.6 Pack contents ........................................................... 19
2.7 Tools ........................................................................ 20
4.1 Selecting a location ................................................... 46
4.2 Flush mounting ......................................................... 48
4.3 Bracket (trunnion) mounting....................................... 49
4.4 Front bezel ............................................................... 51
Chapter 3 Cables and connections......................... 21
Chapter 5 System checks ........................................ 53
5.1 Initial power on test ................................................... 54
5.2 Designating the data master ...................................... 55
5.3 GPS check ............................................................... 55
5
5.4 Radar check ............................................................. 56
5.5 Sonar check ............................................................. 58
5.6 Language selection ................................................... 59
5.7 Setting up Autopilot, AIS and Navtex .......................... 59
5.8 System setup menu .................................................. 60
Chapter 6 Troubleshooting...................................... 67
6.1 Troubleshooting ........................................................ 68
6.2 Power up troubleshooting .......................................... 69
6.3 Radar troubleshooting ............................................... 70
6.4 GPS troubleshooting ................................................. 71
6.5 Sonar troubleshooting ............................................... 72
6.6 System data troubleshooting...................................... 73
6.7 Video troubleshooting................................................ 74
6.8 Touchscreen troubleshooting ..................................... 75
6.9 SeaTalkhs LED indications.......................................... 75
6.10 Miscellaneous troubleshooting ................................. 76
9.2 SeaTalkng accessories ............................................... 86
9.3 SeaTalkhs accessories ............................................... 87
9.4 Spares and accessories ............................................ 89
Appendix A Multifunction display system
integration................................................... 93
Appendix B NMEA 0183 sentences ........................ 95
Appendix C NMEA 2000 sentences ........................ 97
Appendix D Connectors and pinouts ..................... 99
Chapter 7 Technical support ................................... 77
7.1 Raymarine technical support...................................... 78
7.2 3rd party support....................................................... 79
Chapter 8 Technical specification........................... 81
8.1 Technical specification............................................... 82
Chapter 9 Options and accessories ....................... 85
9.1 SeaTalk accessories.................................................. 86
6
E-Series Widescreen installation
Chapter 1: Important information
Warning: Product installation and
operation
This product must be installed and operated in
accordance with the Raymarine instructions provided.
Failure to do so could result in personal injury, damage
to your boat and/or poor product performance.
Warning: Potential ignition source
This product is NOT approved for use in
hazardous/flammable atmospheres. Do NOT install in
a hazardous/flammable atmosphere (such as in an
engine room or near fuel tanks).
Warning: High voltages
This product contains high voltages. Do NOT remove
any covers or otherwise attempt to access internal
components, unless specifically instructed in this
document.
Warning: Product grounding
Before applying power to this product, ensure it has
been correctly grounded, in accordance with the
instructions in this guide.
Warning: Switch off power supply
Ensure the boat’s power supply is switched OFF
before starting to install this product. Do NOT connect
or disconnect equipment with the power switched on,
unless instructed in this document.
Warning: Radar scanner safety
Before rotating the radar scanner, ensure all personnel
are clear.
Warning: Radar transmission safety
The radar scanner transmits electromagnetic energy.
Ensure all personnel are clear of the scanner when
the radar is transmitting.
Warning: Sonar operation
• NEVER operate the sounder with the boat out of
the water.
• NEVER touch the transducer face when the sounder
is powered on.
• SWITCH OFF the sounder if divers are likely to be
within 25 ft (5 m) of the transducer.
Warning: Touchscreen display
When exposed to prolonged periods of direct sunlight,
the touchscreen display can get very hot. In such
conditions, avoid using the touchscreen display and
use the unit’s physical keys and buttons instead.
Important information
7
Caution: Power supply protection
Caution: Use the sun covers
When installing this product ensure the power
source is adequately protected by means of a
suitably-rated fuse or automatic circuit breaker.
To protect your product against the damaging
effects of ultra violet light, always fit the sun
covers when the product is not in use.
Caution: Care of chart cards
Caution: Cleaning
To avoid irreparable damage to and/or loss of data
from chart cards:
When cleaning this product:
• Ensure that chart cards are fitted the correct way
around. DO NOT try to force a card into position.
• DO NOT save data (waypoints, routes, and
so on) to a chart card, as the charts may be
overwritten.
• Do NOT wipe the display screen with a dry cloth,
as this could scratch the screen coating.
• Do NOT use abrasive, or acid or ammonia based
products.
• Do NOT use a jet wash.
• DO NOT use a metallic instrument such as a
screwdriver or pliers to remove a chart card.
• Safe removal. Use the Remove Card menu
option before removing the chart card.
Caution: Ensure chart card door is
securely closed
To prevent water ingress and consequent damage
to the display, ensure that the chart card door is
firmly closed. This can be confirmed by an audible
click.
TFT LCD Displays
The colors of the display may seem to vary when viewed against
a colored background or in colored light. This is a perfectly normal
effect that can be seen with all color Liquid Crystal Displays (LCDs).
In common with all Thin Film Transistor (TFT) LCD units, the screen
may exhibit a few (less than 7) wrongly illuminated pixels. These
may appear as black pixels in a light area of the screen or as colored
pixels in black areas.
Water ingress
Water ingress disclaimer
8
E-Series Widescreen installation
Although the waterproof rating capacity of Raymarine products
exceeds that called for by the IPX6 standard, water intrusion
and subsequent equipment failure may occur if any Raymarine
equipment is subjected to commercial high pressure washing.
Raymarine will not warrant equipment subjected to high pressure
washing.
CompactFlash cards
Disclaimers
Use branded chart cards
This product (including the electronic charts) is intended to be used
only as an aid to navigation. It is designed to facilitate use of official
government charts, not replace them. Only official government
charts and notices to mariners contain all the current information
needed for safe navigation, and the captain is responsible for their
prudent use. It is the user’s responsibility to use official government
charts, notices to mariners, caution and proper navigational skill
when operating this or any other Raymarine product. This product
supports electronic charts provided by third party data suppliers
which may be embedded or stored on memory card. Use of such
charts is subject to the supplier’s End-User Licence Agreement
included in the documentation for this product or supplied with the
memory card (as applicable).
Raymarine does not warrant that this product is error-free or that it
is compatible with products manufactured by any person or entity
other than Raymarine.
This product uses digital chart data, and electronic information from
the Global Positioning System (GPS) which may contain errors.
Raymarine does not warrant the accuracy of such information and
you are advised that errors in such information may cause the
product to malfunction. Raymarine is not responsible for damages
or injuries caused by your use or inability to use the product, by the
interaction of the product with products manufactured by others, or
by errors in chart data or information utilized by the product and
supplied by third parties.
Important information
Jeppesen and Navionics chart cards
The Display is pre-loaded with Jeppesen electronic charts for
your region. If you wish to use different chart data, you can insert
Jeppesen or Navionics chart cards into the CompactFlash card slot
on the unit.
When archiving data, Raymarine recommends the use of quality
branded CF memory cards. Some brands of CF memory card may
not work in your unit. Please contact customer support for a list of
recommended CF cards.
EMC installation guidelines
Raymarine equipment and accessories conform to the appropriate
Electromagnetic Compatibility (EMC) regulations, to minimize
electromagnetic interference between equipment and minimize the
effect such interference could have on the performance of your
system
Correct installation is required to ensure that EMC performance is
not compromised.
For optimum EMC performance we recommend that wherever
possible:
• Raymarine equipment and cables connected to it are:
– At least 1 m (3 ft) from any equipment transmitting or cables
carrying radio signals e.g. VHF radios, cables and antennas.
In the case of SSB radios, the distance should be increased
to 7 ft (2 m).
9
– More than 2 m (7 ft) from the path of a radar beam. A radar
beam can normally be assumed to spread 20 degrees above
and below the radiating element.
• The product is supplied from a separate battery from that used
for engine start. This is important to prevent erratic behavior
and data loss which can occur if the engine start does not have
a separate battery.
• Raymarine specified cables are used.
• Cables are not cut or extended, unless doing so is detailed in
the installation manual.
Note: Where constraints on the installation prevent any of
the above recommendations, always ensure the maximum
possible separation between different items of electrical
equipment, to provide the best conditions for EMC performance
throughout the installation
If your Raymarine equipment is to be connected to other equipment
using a cable not supplied by Raymarine, a suppression ferrite
MUST always be attached to the cable near the Raymarine unit.
Declaration of conformity
Raymarine Ltd. declares that the E-Series Widescreen Multifunction
Displays are in compliance with the essential requirements of EMC
directive 2004/108/EC.
The original Declaration of Conformity certificate may be viewed on
the relevant product page at www.raymarine.com
Product disposal
Dispose of this product in accordance with the WEEE Directive.
Suppression ferrites
Raymarine cables may be fitted with suppression ferrites. These
are important for correct EMC performance. If a ferrite has to be
removed for any purpose (e.g. installation or maintenance), it must
be replaced in the original position before the product is used.
The Waste Electrical and Electronic Equipment (WEEE)
Directive requires the recycling of waste electrical and electronic
equipment. Whilst the WEEE Directive does not apply to some
Raymarine products, we support its policy and ask you to be aware
of how to dispose of this product.
Use only ferrites of the correct type, supplied by Raymarine
authorized dealers.
Warranty registration
Connections to other equipment
Requirement for ferrites on non-Raymarine cables
10
To register your E-Series Widescreen multifunction display
ownership, please take a few minutes to fill out the warranty
registration card found in the box, or visit www.raymarine.com and
register on-line.
E-Series Widescreen installation
It is important that you register your product to receive full warranty
benefits. Your unit package includes a bar code label indicating the
serial number of the unit. You should stick this label to the warranty
registration card.
IMO and SOLAS
The equipment described within this document is intended for use
on leisure marine boats and workboats not covered by International
Maritime Organization (IMO) and Safety of Life at Sea (SOLAS)
Carriage Regulations.
Technical accuracy
To the best of our knowledge, the information in this document was
correct at the time it was produced. However, Raymarine cannot
accept liability for any inaccuracies or omissions it may contain. In
addition, our policy of continuous product improvement may change
specifications without notice. As a result, Raymarine cannot accept
liability for any differences between the product and this document.
Important information
11
12
E-Series Widescreen installation
Chapter 2: Planning the installation
Chapter contents
•
2.1 Handbook information on page 14
•
2.2 Installation checklist on page 14
•
2.3 E-Series Widescreen system on page 15
•
2.4 System protocols on page 17
•
2.5 Data master on page 18
•
2.6 Pack contents on page 19
•
2.7 Tools on page 20
Planning the installation
13
2.1 Handbook information
2.2 Installation checklist
This handbook contains important information regarding the
E-Series Widescreen range of multifunction displays.
Installation includes the following activities:
Installation Task
The handbook is for use with the following models:
• E90W Widescreen Multifunction Display
1
Plan your system
• E120W Widescreen Multifunction Display
2
Obtain all required equipment and tools
• E140W Widescreen Multifunction Display
3
Site all equipment
4
Route all cables.
5
Drill cable and mounting holes.
6
Make all connections into equipment.
7
Secure all equipment in place.
8
Power on test the system.
E-Series handbooks
The E-Series Widescreen Multifunction Display has the following
handbooks available:
All documents are available to download as PDFs from
www.raymarine.com
E-Series handbooks
Description
Part number
Installation and commissioning
instructions
87116
Operating instructions (quick
reference)
86137
User reference handbook
81320
Additional handbooks
Description
Part number
SeaTalkng reference manual
81300
14
E-Series Widescreen installation
2.3 E-Series Widescreen system
The E-Series Widescreen display can be connected to a variety of equipment as part of your marine electronics system..
Basic system example
RS125 GPS
E-Series Widescreen display
Digital sounder
(DSM)
SeaTalkhs switch
Digital Radome
SeaTalkhs
SeaTalk
SeaTalkhs
SeaTalkhs
Autopilot
Autopilot Controller
(ST6002)
NMEA0183
D11713-1
Planning the installation
15
Expanded system example
Autopilot
Digital Devices
Digital Radar
Antenna
Sirius Weather
(SR100)
Instrument
AIS 500
Digital Sounder
(DSM)
AIS
500
CANCEL
ENTER
CANCEL
MENU
SeaTalkng
ENTER
MENU
SeaTalkng
SeaTalkng
SeaTalkng backbone
G-Series Monitor
RS125 GPS
Engine
Devicenet Spur
SeaTalkhs switch
E-Series Widescreen display
Video
E-Series Widescreen display
(data master)
SeaTalkhs
SeaTalkhs
Alarm
D11683-1
Note: The system allows up to 5 E-Series Widescreen displays to be connected on a SeaTalkhs network.
16
E-Series Widescreen installation
2.4 System protocols
Your Multifunction Display can connect to various instruments and
displays to share information and so improve the functionality of
the system. These connections may be made using a number of
different protocols. Fast and accurate data collection and transfer is
achieved by using a combination of the following data protocols:
• SeaTalkhs
SeaTalkng utilizes a single backbone cable to which compatible
instruments connect using a spur. Data and power are carried within
the backbone. Devices that have a low draw can be powered from
the network, although high current equipment will need to have a
separate power connection.
SeaTalkng is a proprietary extension to NMEA 2000 and the proven
CAN bus technology. Compatible NMEA 2000 and SeaTalk /
SeaTalk2 devices can also be connected using the appropriate
interfaces or adaptor cables as required.
• SeaTalkng
• NMEA 2000
• SeaTalk
• NMEA 0183
Note: You may find that your system does not use all of the
connection types or instrumentation described in this section.
NMEA 2000
NMEA 2000 offers significant improvements over NMEA 0183, most
notably in speed and connectivity. Up to 50 units can simultaneously
transmit and receive on a single physical bus at any one time,
with each node being physically addressable. The standard
was specifically intended to allow for a whole network of marine
electronics from any manufacturer to communicate on a common
bus via standardized message types and formats.
SeaTalkhs
SeaTalk
SeaTalkhs is an ethernet based marine network. This high speed
protocol allows compatible equipment to communicate rapidly and
share large amounts of data.
SeaTalk is a protocol which enables compatible instruments to
connect to each other and share data.
Information shared using the SeaTalkhs network includes:
• Shared cartography (between compatible displays.
• Digital radar data.
• Sonar data.
The SeaTalk cable system is used to connect compatible
instruments and equipment. The cable carries power and data and
enables connection without the need for a central processor.
Additional instruments and functions can be added to a SeaTalk
system, simply by plugging them into the network. SeaTalk
equipment can also communicate with other non-SeaTalk equipment
via the NMEA 0183 standard, provided a suitable interface is used.
Seatalkng
NMEA 0183
SeaTalkng (New Generation) is an enhanced protocol for connection
of compatible marine instruments and equipment. It replaces the
older SeaTalk and SeaTalk2 protocols.
The NMEA 0183 Data Interface Standard was developed by
the National Marine Electronics Association of America. It is an
Planning the installation
17
international standard to enable equipment from many different
manufacturers to be connected together and share information.
2.5 Data master
The NMEA 0183 standard carries similar information to SeaTalk.
However it has the important difference that one cable will only
carry information in one direction. For this reason NMEA 0183 is
generally used to connect a data receiver and a transmitter together,
e.g. a compass sensor transmitting heading to a radar display. This
information is passed in ‘sentences’, each of which has a three
letter sentence identifier. It is therefore important when checking
compatibility between items that the same sentence identifiers are
used some examples of which are:
Any system containing more than one networked multifunction
display must have a designated data master.
• VTG - carries Course and Speed Over Ground data.
• GLL - carries latitude and longitude.
• DBT - carries water depth.
• MWV - carries relative wind angle and wind speed data.
The data master is the display which serves as a primary source
of data for all displays, it also handles all external sources of
information. For example the displays may require heading
information from the autopilot and GPS systems, usually received
through a SeaTalkng or NMEA connection. The data master is the
display to which the SeaTalk, NMEA and any other data connections
are made, it then bridges the data to the SeaTalkhs network and
any compatible repeat displays. Information shared by the data
master includes:
• Cartography
• Routes and waypoints
• Radar
NMEA baud rates
• Sonar
The NMEA 0183 standard operates at a number of different
speeds, depending upon the particular requirement or equipment
capabilities. Typical examples are:
• Data received from the autopilot, instruments, the engine and
other external sources.
• 4800 baud rate. Used for general purpose communications,
including FastHeading data.
Your system may be wired for redundancy with data connections
made to repeat displays. However these connections will only
become active in the event of a fault and/or reassignment of the
data master.
• 9600 baud rate. Used for Navtex.
• 38400 baud rate. Used for AIS and other high speed applications.
18
E-Series Widescreen installation
2.6 Pack contents
Number
Description
All models contain the following items:
1
Gasket
2
E-Series Widescreen Multifunction Display
3
Bezel
4
Suncover
5
1.5 m (4.9 ft) Power and data cable
6
Screw pack
7
Document pack, includes:
• Multilingual CD
• Installation and commissioning instructions
• Cutting template
• Jeppesen EULA
1
8
4
Micro-fiber dry cleaning cloth
2
Unpack the display unit carefully to prevent damage. Save the
carton and packing in case the unit has to be returned for service.
3
5
6
7
8
D11684-1
Planning the installation
19
2.7 Tools
Tools required for installation
Power
drill
Jig
saw
Adhesive tape
drill bit,
bracket mounting
Screwdriver
File
35 mm (1.3/8 in)
5 mm (3/16 in) drill bit,
hole cutter, bracket mounting
panel mounting
D11580-1
20
E-Series Widescreen installation
Chapter 3: Cables and connections
Chapter contents
•
3.1 General cabling guidance on page 22
•
3.2 Connections overview on page 23
•
3.3 Power connection on page 23
•
3.4 SeaTalkhs network on page 26
•
3.5 NMEA 0183 connection on page 34
•
3.6 SeaTalk connection on page 35
•
3.7 Alarm connection on page 36
•
3.8 GPS connection on page 37
•
3.9 AIS connection on page 38
•
3.10 Fastheading connection on page 39
•
3.11 SeaTalkng connections on page 40
•
3.12 NMEA 2000 connection on page 41
•
3.13 Video and alarm audio connection on page 42
Cables and connections
21
3.1 General cabling guidance
Always route data cables as far away as possible from:
• other equipment and cables,
Cable types and length
• high current carrying ac and dc power lines,
It is important to use cables of the appropriate type and length
• Unless otherwise stated use only standard cables of the correct
type, supplied by Raymarine.
• Ensure that any non-Raymarine cables are of the correct quality
and gauge. For example, longer power cable runs may require
larger wire gauges to minimize voltage drop along the run.
• antennae.
Strain relief
Ensure adequate strain relief is provided. Protect connectors from
strain and ensure they will not pull out under extreme sea conditions.
Routing cables
Circuit isolation
Cables must be routed correctly, to maximize performance and
prolong cable life.
Appropriate circuit isolation is required for installations using both
AC and DC current:
• Do NOT bend cables excessively. Wherever possible, ensure a
minimum bend radius of 100 mm.
• Always use isolating transformers or a separate power-inverter
to run PC’s, processors, displays and other sensitive electronic
instruments or devices.
• Always use an isolating transformer with Weather FAX audio
cables.
Minimum bend
200 mm (8 in)
diameter
Minimum bend of cable
100 mm (4 in) radius
• Always use an RS232/NMEA converter with optical isolation on
the signal lines.
• Always make sure that PC’s or other sensitive electronic devices
have a dedicated power circuit.
• Protect all cables from physical damage and exposure to heat.
Use trunking or conduit where possible. Do NOT run cables
through bilges or doorways, or close to moving or hot objects.
• Secure cables in place using tie-wraps or lacing twine. Coil any
extra cable and tie it out of the way.
Cable shielding
Ensure that all data cables are properly shielded that the cable
shielding is intact (e.g. hasn’t been scraped off by being squeezed
through a tight area).
• Where a cable passes through an exposed bulkhead or deckhead,
use a suitable watertight feed-through.
• Do NOT run cables near to engines or fluorescent lights.
22
E-Series Widescreen installation
3.3 Power connection
3.2 Connections overview
Cable connectors are on the rear of the display.
Widescreen display
19 way multi-cable
7Afuse
1
2
3
4
D11688-1
Data and video
1. SeaTalkng
2. Power, data and 1 x video in
3. SeaTalkhs
4. Additional 3 x Video in, 1 x video out and alarm audio line out
Red
Black
12 V / 24 V
supply
D11210-2
Power distribution
Raymarine recommend that all power connections are made via a
distribution panel.
• All equipment must be powered from a breaker or switch, with
appropriate circuit protection.
• All equipment should where possible be wired to individual
breakers.
Cables and connections
23
Warning: Product grounding
connected via a single, appropriately-rated conductor, to the boat’s
common ground.
Before applying power to this product, ensure it has
been correctly grounded, in accordance with the
instructions in this guide.
The preferred minimum requirement for the path to ground (bonded
or non-bonded) is via a flat tinned copper braid, with a 30 A rating
(1/4 inch) or greater. If this is not possible, an equivalent stranded
wire conductor may be used, rated as follows:
Grounding
• for runs of <1 m (3 ft), use 6 mm2 (#10 AWG) (6 mm) or greater.
The following requirements apply when grounding Raymarine
equipment which does not have a dedicated drain wire or shield:
• for runs of >1 m (3 ft), use 8 mm2 (#8 AWG) or greater.
In any grounding system, always keep the length of connecting
braid or wires as short as possible.
Common ground point
The negative wire must be connected to a bonded common ground
point, i. e. with the ground point connected to battery negative, and
situated as close as possible to the battery negative terminal.
Important: Do NOT connect this product to a positively-grounded
power system.
References
• ISO 10133/13297
• BMEA code of practice
• NMEA 0400
1
2
3
1. Power cable to display
2. Bonded common ground connection
3. Battery
D11705-1
Power cable
The display is supplied with a combined power and data multi cable,
this can be extended if required.
Power cable supplied
Cable
Part number
Notes
1.5 m (4.9 ft) Power and
data cable
R62131
Supplied with unit
Implementation
If several items require grounding, they may be first be connected
to a single local point (e.g. within a switch panel), with this point
24
Cable extension
The following restrictions apply to any extension to the power cable:
E-Series Widescreen installation
• Cable must be of a suitable gauge for the circuit load.
Sharing a breaker
• Each unit should have its own dedicated power cable wired back
to the distribution panel.
Where more than 1 piece of equipment shares a breaker you must
provide protection for the individual circuits. E.g. by connecting an
in-line fuse for each power circuit.
Total length (max)
Supply voltage
Cable gauge
(AWG)
0–5 m (0–16.4 ft)
12 V
18
24 V
20
12 V
14
24 V
18
12 V
12
24 V
16
12 V
12
24 V
14
5–10 m (16.4–32.8 ft)
10–15 m (32.8–49.2 ft)
15–20 m (49.2–65.5 ft)
+VE bar
-VE bar
Where possible, connect individual items of
equipment to individual circuit breakers.
Where this not possible, use individual in-line
fuses to provide the necessary protection.
Circuit breaker
Fuse
Fuse
D11637-1
Note: These distances are for a 2 wire power cable run from the battery to
the display (approximately the distance from the battery to the display). To
calculate the round trip length, double the figure stated here.
Breakers, fuses and circuit protection
The power cable includes an in-line fuse. It is recommended that
you fit an additional thermal breaker or fuse at the distribution panel.
Display
Fuse
• C90W / E90W
7 A in-line fuse fitted within power
cable.
• C120W / E120W
• C140W /E140W
Cables and connections
25
3.4 SeaTalkhs network
The SeaTalkhs network allows you to connect compatible displays and other digital devices.
SeaTalkhs can be used with E-Series Widescreen to:
• Create a network of up to 5 E-Series Widescreen displays.
• Connect a digital radar scanner.
• Connect a digital sounder (DSM).
Note: A network containing more than a single connection will
require a SeaTalkhs switch. This is a hub used for connection
of multiple devices.
26
E-Series Widescreen installation
Typical SeaTalkhs network
1
2
4
SeaTalkhs
5
3
SeaTalkhs
SeaTalkhs
SeaTalkhs
D11689-1
1. Data master display
2. Repeat display
3. SeaTalkhs switch
4. Digital radar scanner
5. Digital sounder, e.g. DSM400
Radar connection
The display is compatible with Raymarine digital radar scanners.
The scanner is connected using a SeaTalkhs cable.
Cables and connections
The digital radar is usually connected via a SeaTalkhs switch. On
smaller systems (with only one display and no other digital devices)
the radar may be connected using a crossover coupler.
27
Radar connected using SeaTalkhs switch
2. Digital radar scanner
3. SeaTalkhs switch
4. VCM100 power converter (This is only required with open array
type scanners.)
5. Connection to power supply
Radar connected directly to the display
1
2
Note: The connector on the free end of the radar cable does not
have a locking / weather tight mechanism. The use of a crossover
coupler is important to create a weather proof connection.
3
4
5
D11686-1
1. Display
28
E-Series Widescreen installation
1
2
3
4
D11685-1
1. Digital radar scanner
2. Display
3. Crossover coupler
4. Connection to power supply
Cables and connections
29
Digital radar cable extension
If required you can use a Raymarine digital radar extension cable.
1
2
D11687-1
1. Extension cable
2. Digital scanner cable
Note: The extension cable connects to the radar scanner.
Digital radar cables
You will need at least 2 cables to connect the digital radar scanner.
One cable connects the scanner to a SeaTalkhs switch (or crossover
coupler). The second cable then connects into the display.
30
Note: The maximum cable length including all extensions is 25 m
(82 ft).
E-Series Widescreen installation
Radar scanner to SeaTalkhs switch (or crossover coupler)
SeaTalkhs switch (or crossover coupler) to display unit
Digital scanner cables
SeaTalkhs network cables
SeaTalkhs
Connect the Radar scanner to the
switch (or crossover coupler) and
power supply. These cables contain both power and data wires.
Cable
Part number
5 m (16.4 ft) Digital cable
A55076
10 m (32.8 ft) Digital
cable
A55077
15 m (49.2 ft) Digital
cable
25 m (82.0 ft) Digital
cable
Notes
Connect from the SeaTalkhs switch or the crossover coupler into the rear of the
display.
Cable
Part number
1.5 m (4.9 ft) SeaTalkhs
network cable
E55049
5 m (16.4 ft) SeaTalkhs
network cable
E55050
10 m (32.8 ft) SeaTalkhs
network cable
E55051
A55078
20 m (65.6 ft) SeaTalkhs
network cable
E55052
A55079
Your radar scanner may
include the 10 m cable
(depending upon the
model purchased)
Notes
SeaTalkhs hardware
Extension cables
Use of one of these cables to extend the radar connection to the SeaTalkhs switch
(or crossover coupler) and power supply. These cables contain both power and
data wires.
Cable
Part number
2.5 m (8.2 ft) extension
cable
A92141
5 m (16.4 ft) extension
cable
A55080
10 m (32.8 ft) extension
cable
A55081
Cables and connections
Notes
To connect the digital radar to the C-Series display you will need
to include one of the following
Cable
SeaTalkhs
switch
SeaTalkhs coupler
Part number
Notes
E55058
8 way hub for network
connection of multiple
SeaTalkhs devices.
E55060
Couple for connection
of a single SeaTalkhs
device.
31
Sonar connection
The sonar connection is required for fishfinder applications. The
display is connected to a sonar module (DSM) using a SeaTalkhs
cable. You will also require a compatible transducer connected to
the DSM unit.
The E-Series Widescreen display can be used with the following
DSM units:
• DSM400
• DSM300
• DSM30
The display can support 1 DSM module.
Sonar connected directly to the display
1
On smaller systems (with only one display and no other digital
devices) the DSM may be connected directly to the display without
using a SeaTalkhs switch.
Note: You must ensure that the cable ends connected into the
display and DSM have a locking / weather tight mechanism.
Typical DSM system
2
1
2
SeaTalk hs
3
3
SeaTalk hs
D11680-1
1. Display
2. SeaTalkhs switch
3. DSM unit, e.g. DSM400
32
4
SeaTalkhs
D11681-1
E-Series Widescreen installation
1. DSM unit, e.g. DSM400
Cable
Part number
Notes
2. Display
1.5 m (4.9 ft) SeaTalkhs
network cable.
A62245
Cable has waterproof
connectors at both ends.
10 m (32.8 ft) SeaTalkhs
network cable
A62246
Cable has waterproof
connectors at both ends.
3.
SeaTalkhs
switch
4. Transducer
Sonar cable
Connect the DSM unit directly to your display, or connect via the
SeaTalkhs switch.
SeaTalkhs network cables
Connect from the SeaTalkhs switch into the rear of the display.
Cable
Part number
1.5 m (4.9 ft) SeaTalkhs
network cable
E55049
5 m (16.4 ft) SeaTalkhs
network cable
E55050
10 m (32.8 ft) SeaTalkhs
network cable
E55051
20 m (65.6 ft) SeaTalkhs
network cable
E55052
Notes
Fully waterproof SeaTalkhs network cables
Connect directly from DSM to the rear of the display.
Cables and connections
33
3.5 NMEA 0183 connection
The display has 3 NMEA ports available:
Connections to NMEA 0183 devices are made using the supplied
Power and data cable.
• Port 1: Input and output, 4800 / 9600 baud rate.
• Port 2: Input and output, up to 38400 baud rate.
• Port 3: Input only, 4800 baud rate.
NMEA 0183 cable
You can extend the NMEA 0183 wires within the supplied power
and data cable.
Widescreen display
Data cable extension
The following restrictions apply to any extension to the NMEA 0183 data wires.
Total length (max)
Cable
Up to 5 m
High quality data cable:
• 2 x twisted pair with overall shield.
White
IN
+ve
Green Yellow Brown
IN
OUT OUT
-ve
+ve
-ve
Orange/
Green
IN
-ve
Orange/
White
IN
+ve
OUT
+ve
OUT
-ve
IN
+ve
NMEA
DEVICE
4800/9600 baud
IN
-ve
OUT
+ve
Orange/
Brown
OUT
-ve
Orange/
Yellow
OUT
+ve
OUT
-ve
IN
+ve
Blue/
Green
IN
-ve
• 50 to 75 pF/m capacitance core to
core.
Blue/
White
IN
+ve
IN
-ve
NMEA
DEVICE
4800/9600/38400 baud
OUT
+ve
OUT
-ve
NMEA
DEVICE
4800 baud
(transmit to
display
only)
D11200-2
34
E-Series Widescreen installation
3.6 SeaTalk connection
SeaTalk cable
Connections to SeaTalk equipment are made using the supplied
multi-cable.
For SeaTalk cables and extensions, use Raymarine SeaTalk cable
accessories.
Note: Power to SeaTalk instruments is not provided by the
display.
Widescreen display
19 way multi-cable
Power, data and video
White/Red
Red
White/Black
Black
White/Yellow
Yellow
SeaTalk devices
Red
Black
Cables and connections
5 A fused,
12 V dc supply
D11215-2
35
3.7 Alarm connection
Typical alarm connection
An alarm buzzer can be connected using the power / data cable
provided with the display.
Widescreen display
19 way multi-cable
Power, data and video
Grey
Black
Red
Black
Black
-ve supply
(from battery/
breaker)
Alarm
D11216-2
Note: The alarm output is rated for 100 mA maximum load
36
E-Series Widescreen installation
3.8 GPS connection
High alarm loads and third party alarms
You can use the alarm output to switch a relay. This may be useful
for connecting high loads such as third party alarm sounders or
inductive loads to the display. If you are in any doubt as to how to
make such connections please consult an authorized installer.
The E-Series Widescreen multifunction display has a positive
switched alarm output. The following circuit shows the arrangement
for connection of a relay switch.
Depending upon your GPS type it may be either connected via
SeaTalk or NMEA 0183.
See also
• For SeaTalk connection refer to: 3.6 SeaTalk connection.
• For NMEA 0183 connection refer to: 3.5 NMEA 0183 connection.
Alarm output configured to switch a relay
Alarm out
(+ve)
Battery+
Relay
Suppression
diode
0v return
Battery--
D11591-1
High current load
Note: When connecting the output to a relay or other inductive
device you should fit a spike suppression diode e.g. 1N4001.
Cables and connections
37
3.9 AIS connection
Connection using NMEA 0183
A compatible AIS can be connected using SeaTalkng or NMEA 0183.
1
2
3
Connection using SeaTalkng
SeaTalkng
1
2
NMEA0183 (4800)
VHF
AIS
500
D11678-1
1. Widescreen display
2. AIS500 transceiver
4
NMEA0183 (38400)
D11221-2
1. VHF antenna
2. VHF radio
3. AIS unit
4. Display
38
E-Series Widescreen installation
3.10 Fastheading connection
Note: The connection can be made into any NMEA 0183 port.
If you wish to use MARPA (radar target acquisition) functions
on a system without a SeaTalkng autopilot then you will require
a dedicated Fastheading connection. The connection uses
NMEA 0183 and can be made to either a compatible Raymarine
autopilot or a dedicated Fastheading sensor. If your system includes
a Raymarine SPX course computer connected using SeaTalkng then
you will not need the separate Fastheading connection.
4. Autopilot controller
Typical Fastheading from NMEA 0183 compatible autopilot
5. Fluxgate compass
1
3
4
1. Display
2. Autopilot course computer
3. Autopilot connected via NMEA 0183 (Fastheading and other
relevant data)
2
NMEA0183
5
D11220-2
Cables and connections
39
3.11 SeaTalkng connections
The display can connect as part of a SeaTalkng network.
Typical SeaTalkng system
ST70
Instrument
The display can use SeaTalkng to communicate with:
• SeaTalkng instruments (e.g. ST70)
CANCEL
ST70
Pilot Controller
ENTER
CANCEL
MENU
Transducer
Pod
Wind
Transducer
ENTER
MENU
• SeaTalkng autopilots (e.g. ST70 with SmartPilot SPX course
computer)
Widescreen Display
Autopilot
(Course
Computer)
Power Supply
12 V dc + Data
12 V / 24 V dc
SeaTalkng backbone
Transducer
Pod
Transducer
Pod
Depth
Transducer
Speed
Transducer
D11195-2
40
E-Series Widescreen installation
3.12 NMEA 2000 connection
SeaTalkng cabling
SeaTalkng cables
Connection / Cable
Notes
Backbone cables (various lengths)
The main cable carrying data. Spurs
from the backbone are used to
connect SeaTalkng devices.
T-piece connectors
Used to make junctions in the
backbone to which devices can then
be connected.
Terminators
Required at either end of the
backbone.
Spur cables
Used to connect devices. Devices
may be daisy chained or connected
directly to the T-pieces.
Seatalkng power
The SeaTalkng bus requires a 12 V power supply. This may be
provided from:
The display can receive data from NMEA 2000 devices (e.g. data
from compatible engines). The NMEA 2000 connection is made
using SeaTalkng and appropriate adaptor cables.
You can EITHER:
• Use your SeaTalkng backbone and connect each NMEA 2000
device on a spur, OR
• connect the display on a spur into an existing NMEA 2000
backbone.
Important: You cannot have 2 backbones connected together.
Connecting NMEA 2000 equipment to the SeaTalkng backbone
1
4
12V
NMEA2000
• Raymarine equipment with a regulated 12 V supply. (e.g. a
SmartPilot SPX course computer)
3
• Other suitable 12 V supply.
SeaTalkng
Note: SeaTalkng does NOT supply power to multifunction displays
and other equipment with a dedicated power supply input.
2
D11711-1
1. 12 V supply into backbone
2. SeaTalkng backbone
Cables and connections
41
3.13 Video and alarm audio connection
3. SeaTalkng to DeviceNet adaptor cable
4. NMEA 2000 equipment
Connecting the display to an existing NMEA 2000 (DeviceNet)
backbone
The display supports connection of up to 4 video devices and
an external monitor. It also provides an alarm audio output for
connection to the ship’s audio system.
1
2
4
3
D11198-2
1. Display
2. SeaTalkng to DeviceNet adaptor cable
3. DeviceNetng backbone
4. NMEA 2000 equipment
42
E-Series Widescreen installation
Video and alarm audio connection
4. Video connection (x 4)
5. VGA connection to external monitor
6. Audio out (line level to appropriate amplifier)
Video connection colors
1
2
1
Black
2
Yellow
3
Green
4
Blue
3
Video and alarm audio cables
4
These are the cables which provide connections for video devices,
an external monitor and an alarm audio signal.
1
2
3
4
5
6
D11682-1
1. Display
2. Power and data cable
3. Audio/Video cable
Cables and connections
43
Video and audio cables
Cable
Part number
Notes
1.5 m (4.9 ft) Power and
data cable
R62131
Supplied with the
display.
Provides 1 x video input
5 m (16.4 ft) Video/Alarm
audio cable
A62158
Available as an
accessory.
This cable provides:
• 3 x video input BNC
connectors
• 1 x VGA video output
connector
• 1 x RCA phono
jack plug (for alarm
signalling only)
Note: 5 m (16.4
ft) length is for the
VGA flying lead only.
All other connectors
are on leads of 0.5 m
(1.6 ft) length.
44
E-Series Widescreen installation
Chapter 4: Location and mounting
Chapter contents
•
4.1 Selecting a location on page 46
•
4.2 Flush mounting on page 48
•
4.3 Bracket (trunnion) mounting on page 49
•
4.4 Front bezel on page 51
Location and mounting
45
4.1 Selecting a location
Warning: Potential ignition source
This product is NOT approved for use in
hazardous/flammable atmospheres. Do NOT install in
a hazardous/flammable atmosphere (such as in an
engine room or near fuel tanks).
General location requirements
– Use cable supports to prevent stress on connectors.
• Water ingress
The display is suitable for mounting both above and below decks.
It is waterproof to IPX6 standard. Although the unit is waterproof,
it is good practice to locate it in a protected area away from
prolonged and direct exposure to rain and salt spray.
• Electrical interference
Select a location that is far enough away from devices that
may cause interference, such as motors, generators and radio
transmitters/receivers.
Key factors which can affect product performance are:
• Magnetic compass
Select a location that is at least 3 ft (1 m) away from a magnetic
compass.
• Ventilation
To ensure adequate airflow:
• Power supply
Select a location that is as close as possible to the boat’s DC
power source. This will help to keep cable runs to a minimum
When selecting a location for your display it is important to consider
a number of factors.
– Ensure that equipment is mounted in a compartment of suitable
size.
– Ensure that ventilation holes are not obstructed. Allow
adequate separation of equipment.
Any specific requirements for each system component are
provided later in this chapter.
• Mounting surface.
Ensure equipment is adequately supported on a secure surface.
Do not mount units or cut holes in places which may damage the
structure of the vessel.
• Cable entry
Ensure the unit is mounted in a location which allows proper
routing and connection of cables:
– Minimum bend radius of 100 mm (3.94 in) unless otherwise
stated.
46
Adequate space for cooling fins
Ensure adequate space around the cooling fins, in particular you
must avoid contact with any metal object or surface.
Both the cooling fins on the rear of the display and the screws
securing them MUST NOT be in contact with any metal objects
including any metallic part of the vessel structure. Failure to adhere
to this could result in unwanted current flow and in turn damage
to the vessel structure through the process of galvanic corrosion.
If this is a concern then the method of mounting must ensure
electrical isolation.
Viewing angle considerations
As display contrast, color and night mode performance are all
affected by the viewing angle, Raymarine recommends you
temporarily power up the display when planning the installation, to
enable you to best judge which location gives the optimum viewing
angle.
E-Series Widescreen installation
Widescreen display dimensions
Viewing angle
C
80°
80°
E
B
80°
D
A
60° E90W / E120W
70° E140W
A
B
C
D
E
C/E90W
316 mm
(12.4 “)
197 mm
(7.8 “)
113 mm
(4.4 “)
156 mm
(6.1 “)
211 mm
(8.3 “)
C/E120W
380 mm
(15 “)
245 mm
(9.6 “)
113 mm
(4.4 “)
156 mm
(6.1 “)
260 mm
(10.2 “)
C/E140W
423 mm
(16.7 “)
277 mm
(10.9 “)
113 mm
(4.4 “)
156 mm
(6.1 “)
291 mm
(11.5 “)
D11691-1
Note: The angles are provided for a contrast ratio of equal to
or greater than 10.
D11190-2
Location and mounting
47
4.2 Flush mounting
The standard method for mounting the display is a flush or panel
mounting arrangement.
Before mounting the unit, ensure that you have:
• Selected a suitable location
• Identified the cable connections and route that the cables will take
• Detached the front bezel
D11193-2
1. Check the selected location for the unit. A clear, flat area with
suitable clearance behind the panel, is required.
2. Fix the appropriate cutting template supplied with the product, to
the selected location, using masking or self-adhesive tape.
3. Using a suitable hole saw (the size is indicated on the template),
make a pilot hole in each corner of the cut-out area.
4. Using a suitable saw, cut along the inside edge of the cut-out line.
48
E-Series Widescreen installation
5. Ensure that the unit fits into the removed area and then file
around the cut edge until smooth.
6. Drill four 4.5 mm (3/16 in) holes as indicated on the template
to accept the securing bolts.
7. Place the gasket onto the display unit and press firmly onto the
flange.
8. Connect the power, data and other cables to the unit.
9. Slide the unit into place and secure using bolts provided.
Once you have secured the display in place, proceed and attach
the front bezel.
Location and mounting
4.3 Bracket (trunnion) mounting
The display can be mounted on an optional bracket.
REQUIRES THE OPTIONAL MOUNTING BRACKET ACCESSORY.
Before mounting the unit ensure that you have:
• Selected a suitable location
• Identified the cable connections and route that the cables will take
• Attached the front bezel
49
Note: Bracket (trunnion) mounting kit is available as an optional
accessory.
1. Mark the location of the mounting bracket screw holes on the
chosen mounting surface.
2. Drill pilot holes for the screws using a suitable drill, taking care
that there are no cables or anything that may be damaged
behind the surface.
3. Use the screws supplied to attach the mounting bracket securely.
4. Attach the display unit to the mounting bracket.
Once you have secured the display in place, proceed and make
the required cable connections.
D11191-2
50
E-Series Widescreen installation
4.4 Front bezel
Attaching the front bezel
Before fitting the bezel you must have mounted the unit in its
required location.
1. Carefully lift one edge of the screen protection film, so that it is
accessible for removing when unit installation is complete.
2. Place the bezel over the front of the display, ensuring that the
clips along the bottom edge of the bezel are latched into position.
D11196-2
3. Ensure that the control buttons pass through their respective
openings.
4. Apply firm but even pressure to the bezel along the:
i. Outer edges - work from the sides upwards and then along
the top edge, to ensure that it clips securely into position.
ii. Inner edges - particularly along the chart card door edge, to
ensure that the bezel sits flat.
5. Check that all control buttons are free to operate. Use your
thumb or forefinger in a circular motion to do this.
Location and mounting
51
Removing the front bezel
3. Unclip the right hand edge.
The bezel should now come away from the display easily.
2
3
1
D11197-2
Important: Use care when removing the bezel. Do not use any
tools to lever the bezel, doing so may cause damage.
1. Unclip the lower edge of the bezel. Starting at the lower-center
edge and working towards the outer edges,
2. Unclip the left hand edge working from the bottom corner
upwards.
52
E-Series Widescreen installation
Chapter 5: System checks
Chapter contents
•
5.1 Initial power on test on page 54
•
5.2 Designating the data master on page 55
•
5.3 GPS check on page 55
•
5.4 Radar check on page 56
•
5.5 Sonar check on page 58
•
5.6 Language selection on page 59
•
5.7 Setting up Autopilot, AIS and Navtex on page 59
•
5.8 System setup menu on page 60
System checks
53
5.1 Initial power on test
1
Touchscreen overview
2
The touchscreen provides a quick way of performing many common
functions.
3
Some of the functions you can operate with the touchscreen include:
• Accessing applications.
• Adding and editing applications pages.
1. Rotary Control. Use this to select menu options and adjust the
value of various items.
• Placing and editing waypoints.
2. Trackpad. Use this to select menu items, options and move
the cursor.
• Building routes and auto-routes.
3. OK button. Use this to confirm a selection or entry.
• Panning the chart display.
• Placing and moving the cursor.
• Placing and moving VRMs and EBLs.
Note: Raymarine strongly recommends that you familiarize
yourself with touch operations while your vessel is anchored
or moored. You may find it helpful to use the simulator mode
(accessible from Menu > System Setup Menu) in these
situations.
Powering the display on
1. Press and hold the POWER button until the Raymarine logo
appears.
2. Press OK to acknowledge the warning window.
Note: To disable the audible “beep” that you hear when you touch
the screen, go to Menu > Display Setup > Touch beep.
UniControl
The UniControl provides a number of key functions in a single
control.
54
E-Series Widescreen installation
5.2 Designating the data master
5.3 GPS check
The following task must be performed on the multifunction display
that you want to designate as the data master:
Checking GPS operation
1.
2.
3.
4.
5.
Press the MENU button.
Select the System Setup menu item.
Select the System Integration menu item.
Select the Data Master > ON option.
Press the OK button.
You can check that the GPS is functioning correctly using the chart
application.
1. Select the Chart page.
2. Check the screen.
With the chart displayed, you should see:
Your boat position (indicates a GPS fix). Your current position
is represented by a boat symbol or solid circle. Your position is
also displayed in the data bar under VES POS.
Note: A solid circle on the chart indicates that neither heading
nor Course Over Ground (COG) data is available.
System checks
55
5.4 Radar check
Typical HD digital radar screen
Warning: Radar scanner safety
Before rotating the radar scanner, ensure all personnel
are clear.
Warning: Radar transmission safety
The radar scanner transmits electromagnetic energy.
Ensure all personnel are clear of the scanner when
the radar is transmitting.
Checking the radar
1. Select a Radar page.
The Radar scanners will now initialize in standby mode, this
process will take approximately 70 seconds.
2. Press the POWER button.
3. Press the Radar Tx/Stdby softkey and set to Tx.
The scanners should now be transmitting and receiving.
4. Check that the radar screen is operating correctly.
Note: The example above is representative of the enhanced
output provided by a HD digital radar scanner.
Points to check:
• Radar sweep with echo responses are shown on screen.
• Radar status icon rotating in top right hand corner.
Check and adjust bearing alignment
Bearing alignment
The radar bearing alignment ensures that radar objects appear at
the correct bearing relative to your boat’s bow. You should check
the bearing alignment for any new installation.
56
E-Series Widescreen installation
Example misaligned radar
2. Note the position of the object on the radar display. If the target
is not under the ships heading marker (SHM), there is an
alignment error and you will need to carry out bearing alignment
adjustment.
Adjusting the bearing alignment
Once you have checked the bearing alignment you can proceed and
make any required adjustments.
With the radar page displayed:
1. Select the RADAR SETUP > BEARING ALIGNMENT menu.
2. Press the BEARING ALIGNMENT softkey.
3. Use the rotary control to place the selected target under the
Ship’s Heading Marker.
4. Press OK when complete.
Adjusting radar offset (parking)
This setting is applicable to open array scanners. It is used to
ensure the scanner parks in the correct position when rotation stops.
Before you proceed, ensure that:
• The radar page is selected
• The radar scanner is initialized standby mode
Target object dead ahead
(bearing alignment will be required)
Radar target not aligned
D11590-1
Checking the bearing alignment
1. With your vessel under way: Align the bow with a stationary
object identified on the radar display An object between 1 & 2
NM distant is ideal.
System checks
1. Press the RADAR SETUP > SCANNER SETUP.
2. Select the PARKING OFFSET option, then adjust the offset
angle required to park the radar so that the antenna comes to
rest facing forward (you should see the Raymarine logo wording
from the front of the vessel) when you place it in either standby
or switch it off.
3. Press OK when complete.
57
5.5 Sonar check
Warning: Sonar operation
• NEVER operate the sounder with the boat out of
the water.
• NEVER touch the transducer face when the sounder
is powered on.
• SWITCH OFF the sounder if divers are likely to be
within 25 ft (5 m) of the transducer.
Select the fishfinder transducer
You must set up the system for the transducer connected to your
DSM. Use the fishfinder setup menus to select the appropriate
transducer.
Selecting the fishfinder transducer
From the main fishfinder screen:
1.
2.
3.
4.
2. Check the fishfinder display.
With the fishfinder active you should see:
• Depth reading (indicates the transducer is working). The
depth is shown in large white numbers at the bottom left of
the screen.
Press the MENU button.
Select Fishfinder Setup from the list of options.
Select Transducer Settings from the list of menu options:
Use the Select Transducer option and select the appropriate
transducer from those available.
Checking the sonar
Sonar checks are made using the fishfinder application.
1. Select the fishfinder page.
58
E-Series Widescreen installation
5.6 Language selection
5.7 Setting up Autopilot, AIS and Navtex
The system can operate in the following languages:
Some setting up is required to enable integration of Autopilot, AIS
and Navtex equipment connected as part of your system.
English (US)
English (UK)
Chinese
Danish
Dutch
Finnish
French
German
Greek
Italian
Japanese
Korean
Norwegian
Portuguese
Russian
Spanish
Swedish
Turkish
1. Press the MENU button to open the setup menu.
2. Select the System Setup > Language menu.
3. Select from the languages available.
System checks
1. Check the system integration settings.
i. Access the Menu > System Setup > System Integration
menu
ii. Autopilot control. This option should be Enabled if you wish
to control a compatible autopilot using the display.
iii. NMEA port settings. These should be set appropriately for
the connected devices.
iv. Bridge NMEA heading. This should be set ON only if the
display is used as a source of heading data for other devices
connected on SeaTalk or SeaTalkng.
2. Check the display presentation settings.
The AIS presentation layer must be turned ON in order to display
targets.
i. Select the 2D Chart Layers from the chart window
ii. Select AIS Targets On or Off as appropriate.
Further changes to the system set up can be made as required,
however most other equipment will operate to a default level without
further configuration.
59
5.8 System setup menu
The following table describes the various options in the System Setup menu for your multifunction display.
Menu item
Description
Options
Position Mode
Determines how positioning data is displayed — as
Latitude/Longitude coordinates, or Loran TDs.
• Lat/Long (default)
When the Position Mode (see above) is set to TDs, you can
specify the chain identifier, slave, and ASF values.
Chain
TD Setup
• TDs
• Various options, depending on cartography.
Slave 1/2
• Various options, depending on cartography.
ASF 1/2
• –09.9 to +09.9
Simulator
Enables or disables simulator mode, which allows you to practice
operating your multifunction display without data from a GPS
antenna, fishfinder (DSM sonar), or any other external unit.
• OFF (default)
• ON
• DEMO
Bearing Mode
MOB Data Type
60
Determines how all bearing and heading data is displayed in.
This does not affect how the chart or radar displays are drawn.
Determines whether positional data or dead reckoning is
displayed. Assuming that your vessel and the Man Over Board
(MOB) are subject to the same tide and wind effects, the dead
reckoning setting normally gives a more accurate course.
• True (default)
• Magnetic
• Dead Reckoning (default)
• Position
E-Series Widescreen installation
Menu item
Description
Options
Variation Source
This setting compensates for the naturally occuring offset
of the earth’s magnetic field. When set to Auto, the system
automatically compensates, and displays the compensation
value in brackets. To enter your own compensation value, use
the Manual option, then specify the value using the Manual
Variation setting (see below).
• Auto (compensation value displayed in
brackets) (default)
Manual Variation
When the Variation Source menu item is set to Manual (see
above), you use the Manual Variation setting to specify the
compensation value that you want to use. This value is also
transmitted to any other connected SeaTalk instruments.
• Manual
• 0 degrees East (default)
• Range: 0 to 30 degrees East or West
•
Language
Determines the language that will be used for all on-screen text,
labels, menus and options.
Extended Character Set
Determines whether additional accented characters are made
available when you are entering text.
• OFF (default)
Resets the chosen ground trip distance counter to zero.
• Ground Trip 1 Reset
Ground Trip Reset
• ON
• Ground Trip 2 Reset
• Ground Trip 3 Reset
• Ground Trip 4 Reset
Settings Reset
Resets all system setup menus, including page sets and the
databar, to the factory default settings. Waypoints, routes and
tracks are NOT deleted.
Reset Defaults confirmation
• YES
• NO
System checks
61
Menu item
Description
Options
Settings and Data Reset
Resets all system setup menus, including page sets and the
databar, to the factory default settings. Waypoints, routes and
tracks ARE deleted.
Factory Reset confirmation
Note: For systems using multiple multifunction displays
(networked displays), the complete system database is
deleted on the data master (primary display). Only the
waypoints, routes and tracks will be deleted from any
additional multifunction displays.
Date/Time Setup
These options enable you to customize the date and time format
to your requirements. You can also specify a local time offset
from Universal Time Constant (UTC), to compensate for any
time zone difference.
• YES
• NO
Date Format
• mm/dd/yy
• dd/mm/yy
Time Format
• 12hr
• 24hr
Local Time Offset
• –013.0 to +013.0
62
E-Series Widescreen installation
Menu item
Description
Options
Units Setup
Enables you to specify the units used for the following key
measurements:
Distance Units
• Distance
• Speed
• Depth
• Temperature
• Pressure
• Volume
Note: If the Distance unit is set to Nautical Miles or Statute
Miles, and the data displayed is less than 1 unit, the system
displays the units in Feet. If the Distance unit is set to
Kilometers, the system displays the units in Meters.
• Nautical Miles (default)
• Statute Miles
• Kilometers
Speed Units
• Knots (default)
• mph (miles per hour)
• kph (kilometers per hour)
Depth Units
• Meters
• Feet (default)
• Fathoms
Temperature Units
• Fahrenheit (default)
• Celsius
Pressure Units
• Bar
• PSI (default)
• Kilopascals
Volume Units
• US Gallons
• Imp (Imperial) Gallons (default)
System checks
63
Menu item
Description
Options
• Liters
System Integration
Determines the connection settings for external equipment. The
following items are available in the sub-menu:
• Autopilot Control — If set to Enabled, this option allows you
to control certain aspects of a connected pilot control head,
such as sending commands to engage and disengage the
autopilot. If set to Disabled, you will not be able to control
the autopilot from your multifunction display, and all functions
must be controlled from the pilot control head itself.
• DSC Message — If set to ON, details of distress DSC
messages from a connected DSC VHF radio will be displayed
on your multifunction display. If set to OFF, the messages will
NOT be displayed on your multifunction display.
• SeaTalk Alarms — If set to ON, all system alarms generated
by any connected SeaTalk units will be displayed on your
multifunction display. If set to OFF, the alarms will NOT be
displayed on your multifunction display.
• Preferred GPS Source — Your multifunction display
supports GPS receivers connected by SeaTalk1, SeaTalkng, or
NMEA2000. Select the preferred source.
• Data Master — If you have more than one multifunction
display on the same network, one of them must be set as the
data master. When this option is set to ON, the multifunction
display you are currently using will be set as the data master.
• Bridge NMEA Heading — If set to ON, NMEA heading data
will be bridged onto the SeaTalk data bus, and will be sent to
all NMEA-connected devices. If set to OFF, NMEA heading
data will NOT be bridged onto the SeaTalk bus. An example
of a use for this setting is when using MARPA with an external
fast heading sensor, in which case you should set this option
64
Autopilot Control
• Disabled (default)
• Enabled
DSC Message
• OFF (default)
• ON
SeaTalk Alarms
• ON (default)
• OFF
Preferred GPS Source
• SeaTalkng / NMEA2000 (default)
• SeaTalk1
• NMEA0183
Data Master
• ON (default)
• OFF
Bridge NMEA Heading
• OFF (default)
• ON
SeaTalk2 Keyboard
E-Series Widescreen installation
Menu item
Description
to OFF to ensure that all NMEA-connected units receive
heading data from the external heading sensor.
Options
• OFF (default)
• SeaTalk2 Keyboard — Set to ONE or ALL if you have a
SeaTalk2 keyboard connected. Otherwise, set to OFF.
• ALL
• NMEA Output Setup — allows you to enable or disable the
individual NMEA output “sentences” for each NMEA port.
NMEA Output Setup
• NMEA Port Setting — Allows you to specify the appropriate
port speed for the equipment connected to each NMEA port.
When the Navtex 4800 or Navtex 9600 option is selected,
you will be able to view the Navtex message list. Use the AIS
38400 option for AIS receivers.
• ONE
• APB
• BWC
• BWR
• DBT
• DPT
• GGA
• GLL
• MTW
• MWV
• RMA
• RMB
• RMC
• RSD
• RTE
• TTM
• VHW
• VLW
• WPL
System checks
65
Menu item
Description
Options
• VTG
• ZDA
NMEA Port Setting
• NMEA 4800 (default)
• Navtex 4800
• Navtex 9600
• AIS 38400
Waypoint Password Setup
This menu allows you to enable password protection for
waypoints, and to change the password.
Enable Password
• OFF (default)
• ON
Change Password
• Displays Edit Waypoint Password dialog.
66
E-Series Widescreen installation
Chapter 6: Troubleshooting
Chapter contents
•
6.1 Troubleshooting on page 68
•
6.2 Power up troubleshooting on page 69
•
6.3 Radar troubleshooting on page 70
•
6.4 GPS troubleshooting on page 71
•
6.5 Sonar troubleshooting on page 72
•
6.6 System data troubleshooting on page 73
•
6.7 Video troubleshooting on page 74
•
6.8 Touchscreen troubleshooting on page 75
•
6.9 SeaTalkhs LED indications on page 75
•
6.10 Miscellaneous troubleshooting on page 76
Troubleshooting
67
6.1 Troubleshooting
The troubleshooting information provides possible causes and
corrective action required for common problems associated with
marine electronics installations.
All Raymarine products are, prior to packing and shipping, subjected
to comprehensive test and quality assurance programs. However,
if you experience problems with the operation of your E-Series
Widescreen multifunction display, this section will help you to
diagnose and correct problems in order to restore normal operation.
If after referring to this section you are still having problems with your
unit, please contact Raymarine Technical Support for further advice.
68
E-Series Widescreen installation
6.2 Power up troubleshooting
Problems at power up and their possible causes and solutions are described here.
Problem
Possible causes
Possible solutions
The display does not start up.
Problem with power to the unit.
Check relevant fuses and breakers.
Check that the power supply cable is sound and that all connections are
tight and free from corrosion.
Check that the power source is of the correct voltage and sufficient current.
Troubleshooting
69
6.3 Radar troubleshooting
Problems with the radar and their possible causes and solutions are described here.
Problem
Possible causes
Possible solutions
No Data or No scanner message
Radar scanner power supply
Check that the scanner power supply cable is sound and that all connections
are tight and free from corrosion.
Check relevant fuses and breakers.
Check power source is of the correct voltage and sufficient current (using
voltage booster if appropriate).
SeaTalkhs network problem
Check that the Scanner is correctly connected to the display via a crossover
coupler or SeaTalkhs switch.
Check the status of the SeaTalkhs Switch.
Check that SeaTalkhs cables are free from damage.
Software mismatch between equipment
may prevent communication.
Contact Raymarine technical support.
Switch at scanner pedestal in OFF position
Ensure scanner pedestal switch is in ON position.
Radar will not initialize (Voltage control
module (VCM) stuck in “sleep mode”
Intermittent or poor power connection
Check power connection at VCM. (Voltage at input = 12 / 24 V, Voltage
at output = 40 V)
The bearing of a target on the radar screen
is incorrect.
The radar bearing alignment requires
correcting.
Check and adjust radar bearing alignment.
70
E-Series Widescreen installation
6.4 GPS troubleshooting
Problems with the GPS and their possible causes and solutions are described here.
Problem
Possible causes
Possible solutions
“No Fix” GPS status icon is displayed.
Geographic location or prevailing
conditions preventing satellite fix.
Check periodically to see if a fix is obtained in better conditions or another
geographic location.
External GPS connection fault.
Ensure that GPS connections and cabling are correct and fault free..
External GPS antenna in poor position.
For example:
Ensure GPS antenna has a clear view of the sky.
• Below decks
• Close proximity to transmitting
equipment such as VHF radio
GPS installation problem.
Refer to manufacturers handbook for installation details.
Note: A GPS Status screen is available within the Setup menu. This provides satellite signal strength and other relevant information.
Troubleshooting
71
6.5 Sonar troubleshooting
Problems with the sonar and their possible causes and solutions are described here.
Problem
Possible causes
Possible solutions
No data source for the fishfinder.
DSM power supply fault.
Check the DSM power supply and cables.
Other DSM fault.
Refer to the instructions supplied with the DSM unit.
SeaTalkhs
Check that the DSM is correctly connected to the display or SeaTalkhs switch.
network problem.
Check the status of the SeaTalkhs Switch.
Check that SeaTalkhs cables are free from damage.
Problematic depth readings or sonar
image.
72
Software mismatch between equipment
may prevent communication.
Contact Raymarine technical support.
Gain or Frequency settings may be
inappropriate for present conditions.
Check the fishfinder presets, gain and frequency settings.
DSM cable fault.
Ensure that the power, transducer and all other cables to the DSM unit are
properly connected and free from damage.
Other DSM fault.
Refer to the instructions supplied with the DSM unit.
E-Series Widescreen installation
6.6 System data troubleshooting
Aspects of the installation can cause problems with the data shared between connected equipment. Such problems, their possible
causes and solutions are described here.
Problem
Possible causes
Possible solutions
Instrument, engine or other system data is
unavailable at all displays.
Data is not being received at the display.
Check the data bus (e.g. SeaTalkng) wiring and connection to the display.
Check the overall integrity of the data bus (e.g. SeaTalkng) wiring.
If available refer to the reference guide for the data bus. (e.g. SeaTalkng
reference manual)
Data source (e.g ST70 instrument or
engine interface) is not operating.
Check the source of the missing data (e.g. ST70 instrument or engine
interface).
Check the power to the SeaTalk bus.
Refer to the manufacturer’s handbook for the equipment in question.
Instrument or other system data is missing
from some but not all displays.
Software mismatch between equipment
may prevent communication.
Contact Raymarine technical support.
SeaTalkhs network problem
Check that all required equipment is connected to the SeaTalkhs switch.
Check the status of the SeaTalkhs Switch.
Check that SeaTalkhs cables are free from damage.
Software mismatch between equipment
may prevent communication.
Troubleshooting
Contact Raymarine technical support
73
6.7 Video troubleshooting
Problems with the video inputs and their possible causes and solutions are described here.
Problem
Possible causes
Possible solutions
No signal message on screen (video
image not displayed)
Cable or connection fault
Check that the connections are sound and free from corrosion.
Only 1 video connection available
Video inputs 2, 3 and 4 are on a separate
audio / video cable
Ensure that you have the separate audio/video cable and that it is correctly
connected.
74
E-Series Widescreen installation
6.8 Touchscreen troubleshooting
Problems with the touchscreen and their possible causes and solutions are described here.
Problem
Possible causes
Possible solutions
Touchscreen does not operate as
expected
Touch lock is enabled
Use the Trackpad to turn off the touch lock on the home screen.
Screen is not being operated with bare
fingers, for example gloves are being worn
Bare fingers must make contact with the screen for correct operation.
Alternatively you may use conductive gloves.
Touchscreen requires calibration
Use the setup menus to calibrate the touchscreen.
Saltwater deposits on the screen
Carefully clean and dry the screen in accordance with the instructions
provided.
6.9 SeaTalkhs LED indications
LED indications associated with the SeaTalkhs switch are described
here.
LED state
Possible causes
For all connected channels: 1 steady
and 1 flashing green LED.
No problem detected (Steady LED
indicates network connection Flashing
LED indicates network traffic) .
No LEDs are illuminated.
No power to the SeaTalkhs switch.
Some LEDs are not illuminated.
• Cable / connection faults on the
channels with non-illuminated
LEDs.
• Equipment connected to
non-illuminated LEDs may be
faulty.
Troubleshooting
75
6.10 Miscellaneous troubleshooting
Miscellaneous problems and their possible causes and solutions are described here.
Problem
Possible causes
Possible solutions
Display behaves erratically:
Intermittent problem with power to the
display.
Check relevant fuses and breakers.
• Frequent unexpected resets.
• System crashes or other erratic
behavior.
Check that the power supply cable is sound and that all connections are
tight and free from corrosion.
Check that the power source is of the correct voltage and sufficient current.
Buttons trapped by front bezel.
Ensure that the front bezel is fitted correctly and that all buttons are free
to operate correctly.
Software mismatch on system (upgrade
required).
Go to www.raymarine.com and click on support for the latest software
downloads.
Corrupt data / other unknown issue.
Perform a factory reset. This option can be found within Menu > System
Setup > Settings and Data Reset .
Important: This will result in the loss of any settings and data (such as
waypoints) stored on the display. Please save any important data to a
CF card before resetting.
76
E-Series Widescreen installation
Chapter 7: Technical support
Chapter contents
•
7.1 Raymarine technical support on page 78
•
7.2 3rd party support on page 79
Technical support
77
7.1 Raymarine technical support
Viewing product information
Raymarine provides a comprehensive customer support service, on
the world wide web, through our worldwide dealer network and by
telephone help line. If you are unable to resolve a problem, please
use any of these facilities to obtain additional help.
1.
2.
3.
4.
Open the system Setup menu.
Select System Diagnostics.
Select Software Services.
Select the Software Services menu:
Web support
Please visit the customer support area of our website at:
www.raymarine.com
This contains Frequently Asked Questions, servicing information,
e-mail access to the Raymarine Technical Support Department and
details of worldwide Raymarine agents.
Telephone support
In the USA call:
+1 603 881 5200 extension 2444
In the UK, Europe, the Middle East, or Far East call:
+44 (0)23 9271 4713
Product information
If you need to request service, please have the following information
to hand:
• Product name.
• Product identity.
• Serial number.
• Software application version.
You can obtain this product information using the menus within your
product.
78
E-Series Widescreen installation
7.2 3rd party support
Contact and support details for 3rd party suppliers can be found on
the appropriate websites.
Jeppesen
www.jeppesen.com
Navionics
www.navionics.com
Sirius marine weather
www.sirius.com/marineweather
Sirius audio
www.sirius.com
Technical support
79
80
E-Series Widescreen installation
Chapter 8: Technical specification
Chapter contents
•
8.1 Technical specification on page 82
Technical specification
81
8.1 Technical specification
Nominal supply voltage
12 or 24 V dc
Operating voltage range
10.7 to 32 V dc
Fuse / Breakers
In-line fuse (fitted within power cable)
Environmental
Installation environment
• Operating temperature: -10 ºC to
+50 ºC (14 ºF to 122 ºF)
• Storage temperature: -20 ºC to
+65 ºC (-4 ºF to 149 ºF)
• Relative humidity: max 95%
• 7 A. (Standard 20 mm glass fuse)
• Water proof to IPX6
Weight
• E90W: 3.7 kg (8.2 lb)
• E120W: 4.4 kg (9.7 lb)
• E140W: 5.4 kg (11.9 lb)
Current
4 A peak operating current
Power consumption
Typical power consumption at full
brightness:
• E90W: 23 W
• E120W: 35 W
• E140W: 37 W
LEN
(Refer to Seatalkng reference manual
for further information.
1
Display screen
TFT LCD display, 24bit color (16.7 M
colors)
Resolution
• E90W: 9 in display, 800 x 480
pixels
• E120W: 12 in display, 1280 x 800
pixels
• E140W: 14 in display, 1280 x 800
pixels
Brightness
• E90W: 800 cd/m2
• E120W / E140W: 1000 cd/m2
82
E-Series Widescreen installation
Data connections.
• 3 x NMEA 0183 ports:
Electronic charts
– NMEA port 1: I/O 4800/9600
baud
• Jeppesen (embedded cartography
appropriate to purchase region;
North America, Europe or Rest of
World, as appropriate)
– NMEA port 2: I/O
4800/9600/38400 baud
Compatible chart cards
(CompactFlash)
– NMEA port 3: Input only, 4800
baud
• Jeppesen C-MAP 4D
• 1 x SeaTalk port
• Navionics Silver, Gold, Gold+,
Platinum and Platinum+
• 1 x SeaTalkhsport. 100 Mbits/s.
RJ45 type connection
• 1 x SeaTalkng connection
Audio alarm output
• 1 x Alarm output. Provides supply
battery voltage @100 mA peak
load.
Embedded electronic charts
Conformance
• Europe: 2004/108/EC
• Australia and New Zealand: C-Tick,
Compliance Level 2
• 1x Alarm repeat. Line level output,
1V rms line level into 600R load.
Video input
4 x NTSC/PAL video inputs to ITU-R
BT.601 standard.
Video output
1 x VGA output at either 720p (1280 x
720) or native display resolution.
Technical specification
83
84
E-Series Widescreen installation
Chapter 9: Options and accessories
Chapter contents
•
9.1 SeaTalk accessories on page 86
•
9.2 SeaTalkng accessories on page 86
•
9.3 SeaTalkhs accessories on page 87
•
9.4 Spares and accessories on page 89
Options and accessories
85
9.1 SeaTalk accessories
9.2 SeaTalkng accessories
SeaTalk cables and accessories for use with compatible products.
SeaTalkng cables and accessories for use with compatible products.
Description
Part No
NMEA / SeaTalk
converter
E85001
3 m (9.8 ft) SeaTalk
extension cable
D285
• 2 x 5 m (16.4 ft)
Backbone cable
5 m (16.4 ft) SeaTalk
extension cable
D286
•
9 m (29.5 ft) SeaTalk
extension cable
D287
• 4 x T-piece
12 m (39.4 ft) SeaTalk
extension cable
E25051
20 m (65.6 ft) SeaTalk
extension cable
D288
86
Notes
Description
Part No
Notes
Backbone Kit
A25062
Includes:
•
1 x 20 m (65.6 ft)
Backbone cable
2 x Backbone
terminator
• 1 x Power cable
SeaTalkng 0.4 m (1.3 ft)
spur
A06038
SeaTalkng 1 m (3.3 ft)
spur
A06039
SeaTalkng 3 m (9.8 ft)
spur
A06040
SeaTalkng 5 m (16.4 ft)
spur
A06041
SeaTalkng 0.4 m (1.3 ft)
backbone
A06033
SeaTalkng 1 m (3.3 ft)
backbone
A06034
E-Series Widescreen installation
9.3 SeaTalkhs accessories
Description
Part No
SeaTalkng
A06035
3 m (9.8 ft)
Notes
Digital radar scanner cables
Scanner cables
backbone
SeaTalkng 5 m (16.4 ft)
backbone
A06036
SeaTalkng 20 m (65.6 ft)
backbone
A06037
SeaTalkng - bare ends 1
m (3.3 ft) spur
A06043
SeaTalkng - bare ends 3
m (9.8 ft) spur
A06044
SeaTalkng — SeaTalk2
0.4 m (1.3 ft) spur
Connect the Radar scanner to either the SeaTalkhs switch or the crossover coupler.
Cable
Part number
5 m (16.4 ft) Digital cable
A55076
10 m (32.8 ft) Digital
cable
A55077
A06048
15 m (49.2 ft) Digital
cable
A55078
SeaTalkng Power cable
A06049
25 m (82.0 ft) Digital
cable
A55079
SeaTalkng Terminator
A06031
SeaTalkng T-Piece
A06028
SeaTalkng E-Piece
A06064
SeaTalkng Blanking plug
A06032
Options and accessories
Notes
Your radar scanner may
include the 10 m cable
(depending upon the
model purchased)
Scanner extension cables
Use of one of these cables to extend the connection between the radar scanner
and the SeaTalkhs switch or crossover coupler.
Cable
Part number
2.5 m (8.2 ft) extension
cable
A92141
5 m (16.4 ft) extension
cable
A55080
10 m (32.8 ft) extension
cable
A55081
Notes
87
SeaTalkhs network cables
SeaTalkhs hardware
Cable
SeaTalkhs network cables
SeaTalkhs
Standard network cables connect compatible equipment to the
crossover coupler), they have a waterproof connector at one end.
Cable
Part number
1.5 m (4.9 ft) SeaTalkhs
network cable
E55049
5 m (16.4 ft) SeaTalkhs
network cable
E55050
10 m (32.8 ft) SeaTalkhs
network cable
E55051
20 m (65.6 ft) SeaTalkhs
network cable
E55052
switch (or
Notes
SeaTalkhs
switch
SeaTalkhs coupler
Part number
Notes
E55058
8 way hub for network
connection of multiple
SeaTalkhs devices.
E55060
Couple for connection
of a single SeaTalkhs
device.
Fully waterproof SeaTalkhs network cables
Connect directly from display to display.
Cable
Part number
Notes
1.5 m (4.9 ft) Dual end
SeaTalkhs network cable.
A62245
Cable has waterproof
connectors at both ends.
15 m (49.2 ft) Dual end
SeaTalkhs network cable
A62246
Cable has waterproof
connectors at both ends.
88
E-Series Widescreen installation
9.4 Spares and accessories
Options and accessories for the E-Series Widescreen Multifunction
displays.
Optional accessories
Description
Part No
Trunnion (bracket)
mount kit (C90W /
E90W)
A62132
Trunnion (bracket)
mount kit (C120W /
E120W)
A62133
Notes
Description
Part No
Trunnion (bracket)
mount kit (C140W /
E140W)
A62134
5 m (16.4 ft) Audio/Video
cable
A62158
Notes
Available as an
accessory.
This cable provides:
• 3 x video input BNC
connectors
• 1 x VGA video output
connector
• 1 x RCA phono
jack plug (for alarm
signalling only)
Note: 5 m (16.4
ft) length is for the
VGA flying lead only.
All other connectors
are on leads of 0.5 m
(1.6 ft) length.
Spare / replacement parts
Options and accessories
Description
Part No
Trunnion knob
R08001
Suncover (C90W /
E90W)
R62122
Notes
89
Description
Part No
Suncover (C120W /
E90W)
Notes
Description
Part No
R62123
Seal Set (C120W /
E120W)
R62187
Suncover (C140W /
E90W)
R62124
Seal Set (C140W /
E140W)
R62188
Flushmount Gasket (C
and E-Widescreen — all
models)
R62128
Front panel (C90W /
E90W)
R62191
Flushmount Screw Kit
(C and E-Widescreen —
all models)
R62312
Front panel (C120W /
E120W)
R62192
R62193
Bezel (E90W)
R62151
Front panel (C140W
E140W)
Bezel (E120W)
R62152
Chartreader assembly
R62209
Bezel (E140W)
R62153
Lower keyboard assy
(C90W / E90W)
R62211
1.5 m (4.9 ft) Power and
data cable — straight
R62131
Lower keyboard assy
(C120W / E120W)
R62212
1.5 m (4.9 ft) Power and
data cable — 90 degree
R62227
Lower keyboard assy
(C140W / E140W)
R62213
Side keyboard assy
R62214
E90W Bonded
Touchscreen Assembly
R62249
E120W Bonded
Touchscreen Assembly
R62250
E140W Bonded
Touchscreen Assembly
R62251
Service spares
Service spares are available to service dealers only.
Description
Part No
Chart door
R62184
Seal Set (C90W / E90W)
R62186
90
Notes
Notes
E-Series Widescreen installation
Description
Part No
Rotary encoder PCB
assembly
R62252
I/O PCB Assembly
R62253
CPU PCB Assembly
R62254
Keymat Set
R62270
SSD PCB Assembly —
US version
R62255
SSD PCB Assembly —
EU version
R62298
SSD PCB Assembly —
ROW version
R62299
UniControl
R62313
Options and accessories
Notes
91
92
E-Series Widescreen installation
Appendix A Multifunction display
system integration
display, and the type of connectivity (in terms of protocols and
physical interfaces) that they use to exchange data with the display:
You can connect a number of external devices to your multifunction
display, providing additional features and functions.
The following diagram illustrates the various external devices that
can be connected to your multifunction display:
Device Type
Suitable Devices
Connectivity
Radar
Up to two radar scanners
may be connected
to your multifunction
display, but only one
may be operated at any
one time.
SeaTalkhs
Instruments
Video/Camera
Autopilot
• 4 kilowatt Digital
Radome Scanner.
External GPS
• 4 kilowatt HD Digital
Radome Scanner.
E-Series display
DSC VHF
• 4 kilowatt HD Digital
Open Array Scanner.
Digital OpenArray radar scanner
• 4 kilowatt SuperHD
Digital Open Array
Scanner.
11.18.02
RAY240
OK
MENU
CH
16/9
HI/LO
WX
SCAN
WATCH
SQ
or
• 12 kilowatt SuperHD
Digital Open Array
Scanner.
Digital Radome scanner
AIS receiver
SeaTalkhs
Fishfinder
DSM 30, 300, or 400 switch
Additional
E-Series display(s)
Note: Please
ensure your radar
scanner is using
the latest software
version.
Weather receiver
D11692_1
Personal
Computer
Fishfinder
Your multifunction display uses a number of protocols to transfer
data between the various devices in your networked system. The
following table details which devices may be connected to your
Multifunction display system integration
• ONE DSM 30, OR
SeaTalkhs
• ONE DSM 300, OR
• ONE DSM 400
93
Device Type
Suitable Devices
Connectivity
Device Type
Suitable Devices
Connectivity
Cartography — included
Embedded (internal)
Jeppesen cartography
Internal storage
AIS
• AIS 250
NMEA 0183, SeaTalkng
Cartography — optional
External CompactFlash
chart cards:
CompactFlash card slot
• AIS 500
• Third-party AIS Class
A or Class B receiver
/ transceiver
• Jeppesen C-Map 4D
• Navionics Silver
Navtex
Navtex Receiver
NMEA 0183
• Navionics Gold
Fast Heading Sensor
Fast Heading Sensor
NMEA 0183
• Navionics Gold+
GPS — external
Raystar125 GPS or
third-party external GPS
receiver
SeaTalk, SeaTalkng, or
NMEA 0183
Instruments
All current Raymarine
instruments
SeaTalk, SeaTalkng, or
NMEA 0183
Autopilot — Raymarine
All current Raymarine
autopilots
SeaTalk, SeaTalkng
Autopilot — third party
Third-party autopilots
NMEA 0183 (waypoint
and bearing information)
VHF radio
Raymarine DSC VHF
radios
NMEA 0183, SeaTalk
Additional Multifunction
Display(s)
E90W, E120W, E140W,
SeaTalk, SeaTalkhs,
SeaTalkng
Video/camera
Composite PAL or NTSC
video source
BNC connector
• Navionics Platinum
• Navionics Platinum+
• Navionics Fish’N Chip
• Navionics Hotmaps
Refer to the
Raymarine website
(www.raymarine.com)
for the latest list of
supported chart cards.
Sirius Weather/Audio
• SR100 Sirius
Weather Receiver
SeaTalkhs
Weather sensor
Airmar Weather Station
SeaTalk2, SeaTalkng, or
NMEA 2000
94
E-Series Widescreen installation
Appendix B NMEA 0183 sentences
The display supports the following NMEA 0183 sentences. These
are applicable to NMEA 0183 and SeaTalk protocols.
Transmit
RMC
Recommended minimum specific
GPS transit data
VTG
Course over ground and ground speed
ZDA
Time and date
APB
Autopilot b
MWV
Wind speed and angle
BWC
Bearing and distance to waypoint
RTE
Routes sentence
Bearing and distance to waypoint
rhumb line
WPL
Waypoint location sentence
BWR
DBT
Depth below transducer
DPT
Depth
AAM
Waypoint arrival alarm sentence
MTW
Water temperature
DBT
Depth below transducer sentence
DPT
Depth sentence
RMB
Recommended minimum navigation
information
DTM
Datum reference sentence
RSD
Radar system data
TTM
Tracked target message
APB
Autopilot b sentence
VHW
Water speed and heading
BWC
Bearing and distance to waypoint
sentence
VLW
Distance travelled through the water
GGA
Global positioning system fix data
BWR
Bearing and distance to waypoint
rhumb line sentence
GLL
Geographic position latitude longitude
DSC
Digital selective calling information
sentence
DSE
Distress sentence expansion
GGA
Global positioning system fix data
sentence
GSA
GPS DOP and active satellites
GSV
GPS satellites in view
RMA
Recommended minimum specific
loran c data
NMEA 0183 sentences
Receive
95
Geographic position loran c sentence
GLC
XTE
Cross track error measured sentence
ZDA
Time and date sentence
GLL
Geographic position latitude longitude
sentence
MDA
Meteorological composite sentence
GSA
GPS DOP and active satellites
sentence
GBS
GPS satellite fault detection data
sentence
GSV
GPS satellites in view sentence
RTE
Routes sentence
Heading deviation and variation
sentence
WPL
Waypoint location sentence
HDG
HDT
Heading true sentence
HDM
Heading magnetic sentence
MSK
MSK receiver interface sentence
MSS
MSK receive r signal status sentence
MTW
Water temperature sentence
WMV
Wind speed and angle sentence
RMA
Recommended minimum specific
loran c data sentence
RMB
Recommended minimum navigation
information sentence
RMC
Recommended minimum specific
GPS transit data sentence
VHW
Water speed and heading sentence
VLW
Distance travelled through the water
sentence
VTG
Course over ground and ground speed
sentence
96
E-Series Widescreen installation
Appendix C NMEA 2000 sentences
The display supports the following NMEA 2000 sentences. These are applicable to NMEA 2000, SeaTalkng and SeaTalk 2 protocols.
Message number
Message description
59392
ISO Acknowledgment
59904
ISO Request
60928
ISO Address Claim
●
●
●
126208
NMEA - Acknowledge group function
●
●
●
126464
PGN List
●
●
●
126992
System time
●
●
●
126996
Product information
●
●
●
127237
Heading/Track Control
127245
Rudder
●
●
●
127250
Vessel heading
●
●
●
127488
Engine parameters rapid update
●
127489
Dynamic engine parameters
●
127493
Dynamic transmission
●
127498
Static engine parameters
●
127505
Fluid level
●
128259
Speed
●
●
●
128267
Water depth
●
●
●
128275
Distance log
●
●
●
129025
Position rapid update
●
●
●
NMEA 2000 sentences
Transmit
Receive
Bridge
●
●
●
●
●
97
Message number
Message description
Transmit
Receive
Bridge
129026
COG SOG rapid update
●
●
●
129029
GNSS position data
●
●
●
129033
Time and date
●
●
●
129038
AIS Class A Position Report
●
129039
AIS Class B Position Report
●
129040
AIS Class B Extended Position Report
●
129044
Datum
●
●
●
129283
Cross track error
●
●
●
129284
Navigation data
●
●
●
129291
Set and drift rapid update
●
●
●
129301
Time to or from mark
●
129539
NMEA 2000 GNSS DOPs message
●
129540
GNSS Sats in view
129545
NMEA 2000 GNSS RAIM output message
●
129550
GNSS differential correction receiver interface
●
129551
GNSS differential correction receiver signal
●
129793
AIS UTC and Date Report
●
129794
AIS Class A Static and Voyage Related Data
●
129801
AIS Addressed Safety Related Message
●
129802
AIS Safety Related Broadcast Message
●
130306
Wind data
98
●
●
●
●
●
●
E-Series Widescreen installation
Message number
Message description
Transmit
Receive
Bridge
130310
Environmental parameters
●
●
●
130311
Environmental parameters message
●
130576
Small craft status
●
130577
Direction data
130578
Vessel speed components
Appendix D Connectors and pinouts
Power, data and video connector
1
2
3
5
4
●
●
Item
Remarks
Current source to network
No current sourced for external
devices.
Current sink from network
• PSU: Main Power input.
• NMEA: No power required for
interface.
9
11
●
6
8
7
●
12
18
13
10
19
14
15
• ST1: <50mA (Interface drive only).
16
17
• Video: No power required for
interface.
Item
Remarks
Identification
PWR/NMEA/ST/Video
Connector type
19 pin twist-lock
Connectors and pinouts
Power, data and video cable cores and colors
Grouping
Signal
Pin
Cable
AWG
Color
BATT+
18
32/0.2
18
Red
BATT-
19
32/0.2
18
Black
SCREEN
17
not used
99
Signal
Pin
Cable
AWG
NMEA1
TX+
6
7/0.15
26
NMEA1
TX-
9
7/0.15
26
NMEA1
RX+
4
7/0.15
26
NMEA1
RX-
8
7/0.15
26
NMEA2
TX+
1
7/0.15
26
NMEA2
TX-
3
7/0.15
26
NMEA2
RX+
7
7/0.15
26
Grouping
Twisted
pair
Twisted
pair
Color
Signal
Pin
Cable
AWG
Yello
ST1
BATT-
14
7/0.15
26
Brown
VIDEO
15
RG179
75R coax
(or equivalent)
VIDEO
RTN
13
Screen
White
Green
Twisted
pair
Orange /
Yellow
Orange /
Brown
Twisted
pair
White /
Black
Details for the connector providing video and alarm audio
connectivity.
2
1
Orange /
White
3
4
5
6
7
11
10
9
NMEA2
RX-
11
NMEA3
RX+
5
7/0.15
26
NMEA3
RX-
2
7/0.15
26
Blue /
Green
Pin
Signal
1
VIDEO IN A
ST1
BATT+
10
7/0.15
26
White /
Red
2
VIDEO IN B
ST1 DATA
12
7/0.15
26
White /
Yellow
3
VIDEO IN C
4
VIDEO IN B RETURN
5
VIDEO IN A RETURN
HONK
100
16
7/0.15
7/0.15
26
Orange /
Green
Twisted
pair
Color
Video and alarm-audio connector
8
26
Grouping
12
13
14
15
16
17
20
18
19
Blue /
White
Grey
E-Series Widescreen installation
Pin
Signal
6
VIDEO IN C RETURN
7
AUDIO OUT +
8
VIDEO OUT H-SYNC
9
VIDEO OUT V-SYNC
10
AUDIO OUT –
11
Item
Remarks
Identification
STHS
Connector type
RJ45 (with suitable waterproofing)
Current source to network
No current sourced for external devices
Current sink from network
No power required for interface
VIDEO OUT RED
Pin
Signal
12
VIDEO OUT H-SYNC GROUND
1
Tx+
13
VIDEO OUT RED GROUND
2
Tx-
14
VIDEO OUT V-SYNC GROUND
3
Rx+
15
SHIELD
4
Not connected
16
VIDEO OUT GREEN
5
Not connected
17
SHIELD
6
Rx-
18
VIDEO OUT GREEN GROUND
7
Not connected
19
VIDEO OUT BLUE
8
Not connected
20
VIDEO OUT BLUE GROUND
Note: Use only Raymarine cables when connecting to SeaTalkhs
SeaTalkhs connector
1
8
Connectors and pinouts
101
SeaTalkng connector
5
1
6
4
2
3
Item
Remarks
Identification
ST2/NMEA2000
Connector type
STNG
Current source to network
No current sourced for external devices
Current sink from network
<160mA (Interface drive only)
Pin
Signal
1
+12V
2
0V
3
Screen
4
CanH
5
CanL
6
SeaTalk (not connected on C / E-Series
Widescreen)
Note: Use only Raymarine cables when connecting to SeaTalkng
102
E-Series Widescreen installation
