1. General Information

1.1 Product Description

The Renogy Solar Suitcases combine highly efficient Renogy Solar Panels and a fully adjustable

10 Amp PWM Solar Charge Controller with LCD to create an easy-to-use, ‘plug and play’ system.

This system is specifically designed for mobile off-grid applications, where space and weight limitations are abundant. The Solar Suitcase 100W supports 12V deep cycle battery varieties such as sealed lead acid, gel, and flooded. With built-in tilting stands, these panels can be adjusted at different angles to maximize the power output throughout the seasons.

The alligator clips included in this package make it easy to connect the panel to a battery in seconds. If one ever needs to connect a battery with a different type of end terminal, the alligator clips are attached via an Anderson plug connector (50A SB housing).

Scan the QR Code to visit the download page.

Or visit: http://goo.gl/NrqNn5

2

2. Emergency 30

2.1 Components

The Emergency 30 Watt kit comes with:

1. Renogy 30W monocrystalline Solar Panel

2. 15 AH Battery

3.

Tray Cable 5’

4. 500 Watt Inverter

2.2 Renogy 30 Watt Solar Panel

Key Features

The Renogy 30 Watt monocrystalline solar panel has a high PTC Rating and high module conversion efficiency. This solar panel guarantees no hot spots and every panel is 100%

EL Tested.

Application

Off-grid rooftop/ground mounted

Residential/Rural

12V Battery charging

3

Electrical Characteristics

Description

Maximum Power

Open Circuit Voltage (Voc)

Short Circuit Current (Isc)

Maximum Power Voltage (Vmp)

Maximum Power Current (Imp)

Cell Type

Cell Efficiency

Maximum System Voltage

Mechanical Characteristics

Solar Cell

Number of Cells

Dimensions

Weight

Front Glass

Frame

Description

Junction Box

Output Cables

Connectors

Fire Rating

Temperature Characteristics

Description

Nominal Operating Cell Temperature

Operating Module Temperature

2.3 UPG Sealed Lead-Acid Battery

Specification

Nominal Voltage

Description

Parameter (30W)

30W

21.6V

1.85

17.5V

1.71A

Monocrystalline

19.0%

600 VDC

Parameter (30W)

Monocrystalline 125

12 (4x3)

13.5 x 23.8 x 1 in.

7.7 lbs

.13 in tempered glass

Anodized aluminum alloy

IP65 Rated

31.5 inches

Alligator Connectors

Class C

Parameter (30W)

116 °F±4

-40°F to 176°F

Parameter (30W)

12V (6 Cells)

4

Nominal Capacity

20-hr (0.75A)

10-hr (1.395A)

5-hr (2.55A)

1-hr (9.0A)

Approximate Weight

Internal Resistance

Shelf Life

Temperature Dependency of Capacity

15.0 AH

13.95 AH

12.75 AH

9.0 AH

9.2 lbs.

18mΩ

3 Months – 91%

6 Months – 82%

12 Months – 64%

104°F – 102%

77°F – 100%

32°F – 85%

5°F – 65%

13.6-13.8 Float Use

2.4 Renogy 500 Watt Inverter

A power inverter, or inverter, is an electrical device that changes direct current (DC) to alternating current (AC); the converted AC can be at any required voltage and frequency with the use of appropriate transformers, switching, and control circuits.

DC In

AC Out

Fig. 1 Simple diagram on how the inverter works

The AC output of these

RENOGY

Inverters it’s a Pure Sine Wave. This type of waveform is typically found in a house AC power outlet as shown in

Fig. 2

.

5

Fig. 2 Pure Sine Waveform

Safety Instructions

Warning!

Please read the instruction manual carefully before attempting to carry out any installation and wiring. Contact Technical support for any questions concerning the installation.

This equipment should be installed, adjusted, and serviced by qualified electrical maintenance personnel familiar with the construction and operation of the equipment and the hazards involved. Failure to observe this precaution may result in bodily injury.

Do not connect the unit to the AC distribution wiring, such as main circuit breaker box.

Keep the unit away from water. Do not allow water to drip or splash onto the inverter. Do not insert or pull out any AC plug with wet hands.

Keep the unit in cool environments. Ambient air temperature should be between 14 °F and 122 °F (-10 °C and 50 °C). Keep from direct sunlight and away from heating vents.

6

Keep the unit way from flammable materials or in any location where may accumulate flammable fumes or gases, such as the battery compartment of a car, boat, RV or truck.

With the heavy use, the unit will become warm and possibly hot. Keep the unit away from any heat sensitive materials.

Make sure the opening to the fan and vent holes are not blocked.

Do not open the unit. High voltages are inside when the device is powered.

Use proper size wiring. High power inverters can draw many amps from the DC source and can melt wires if not fused and sized properly.

Make sure a proper connection is made between the inverter and the battery (ie s). Reverse polarity connection may melt or blow the inverter’s fuses. Turn off the unit when not in use.

Before cleaning the equipment, switch the power off, clean dry cloth. Do not use wet cloth or cleanser to clean it.

Wiring Instructions

Step 1: Select the right input voltage

Input voltage can be 12V/24V/48V subjecting to the products. It is recommended that the inverter be powered by a battery or battery bank, as the current draw from the inverter can get really high.

Step 2: Connecting inverter to battery

Set the switch to OFF position

(inverter and appliances). Connect the battery cables to their respective colors on the inverter i.e. black cable goes to the black terminal on the

7

inverter, and the red cable goes to the red terminal on the inverter.

Please refer to

Fig. 3

. Each end of the battery tray cables should have an

“Oring

” type of connector. These connectors make it easy to achieve a secure and strong connection. Once the cables are connected and bolted down to the inverter, connect the black cable to the negative post of the battery (-). Then connect the red cable to the positive post of the battery (+). If connecting to a battery bank, make sure that the black cable connects to the negative

Fig. 3 wiring diagram battery post (-) at the end of the bank (opposite to the positive battery post as shown on

Fig. 3

). It is recommended that a fuse be placed on the hot line

(positive) between the battery and inverter. Please refer to Section 5 for the proper wire gauge size and the fuse ratings for each inverter.

The battery negative terminal and the chassis ground of the

Ground! inverter should be connected to a system ground. This a safety measurement to prevent electric shock!

Step 3: Connecting electrical appliances to inverter

Make sure the power load is within the rated power of the inverter.

Caution!

The start power of the appliances should not exceed the peak power of the inverter.

Once the devices are connected to the AC outlet, they are ready to be powered.

When the inverter is not being use, it is recommended to turn off the inverter

(switch in OFF position).

Step 4 (optional): Connecting remote ON/OFF switch to inverter

The 1000-2000W inverters have a built-in RJ11 connector for remote ON/OFF switch. This allows to easily shut-off the inverter from a remote location.

Fig. 4 remote switch in OFF position

Make sure that, both, main inverter and remote switch are in the OFF position

(

Fig.4

). Then connect, the remote into the RJ11 port on the inverter.

8

Flip the switch, and the inverter should power up, and the remote LED with lit solid green (

Fig.5

).

Fig. 5 remote switch in ON position

Wire and In-Line Fuse Size

Warning!

Make sure the correct wire gauge size is used. Inverters draw a large amounts of amps, and if the wire is not sized properly, the wires can melt and catch on fire. Please refer to Table 1 for the recommended wire sizing.

12V Power inverters tend to draw large amount of current based on the appliance load. The reason behind this, is because the voltage ratio (AC/DC) is as follows:

120Vac / 10Vdc = 10

This means that a 500W load on the AC side (connected on the AC power outlet of the inverter) is going to draw from the battery

500 / 10 = 50 Amps

This current draw can be achieved with multiple devices connected to the inverter or running single appliances such as microwaves, toasters, blenders, etc. For this reason, it is required that the inverter is properly fused, and that the correct wire gauge size is used.

Model

RNG-500INV-P

RNG-1000INV-P

RNG-1500INV-P

RNG-2000INV-P

Fuse Size

75A

150A

200A

300A

Table 1. Fuse and wire size

Gauge Size

#6

#4

#2

#00 (2/0)

9

Indicators

The LED indicators on the inverter are essential to differentiate between working mode and alarm/warning states. Tables 2 and Table 3 describe these indicators.

Fig. 6 RNG-500INV-P AC side

Working Mode

During normal operation the inverter

“Working” indicator will be on.

Model LED Name Color

RNG-500INV-P

RNG-1XXXINV-P

Work

Inv

Solid green

Solid green

Table 2. Working Mode LEDs description

Alarm/Warning

Whenever the inverter is malfunctioning, the “Alarm/Warning” LED will turn on.

This can be caused by low input voltage, over-voltage, short circuit, overload, or thermal protection.

Model LED Name Color

RNG-500INV-P

RNG-XXXXINV-P

Fault

Char

Flashing red

Solid red

Table 3. Alarm/Warning LEDs description

Do not ignore these warning indicators. Please refer to Section 7

& 8 for troubleshooting the inverter.

Warning!

10

Protection Function

Low voltage input protection

A buzzer will alarm when the battery voltage is low. This indicates that your battery (ies) need to be recharged. When the input voltage is below 10V +/- 0.5V

(for 12V input inverter) or 20V +/-1.0V (for 24V input inverter), the AC output will be automatically shut off. At this point, the buzzer alarm will turn on, and the

“Fault/char” LED will turn red at the same time.

Over voltage input protection

When the input voltage reaches 15V +/- 0.5V (for 12V input inverter) or 30V+/-

1.0V (for 24V input inverter), the AC output will automatically shut off. At this point, the buzzer alarm will turn on, and the “Fault/char” LED will turn red at the same time.

Short circuit protection

In case of a short circuit, the AC output will shut off automatically, and the

“Fault/char” LED will turn red.

Overload protection

When overload happens, the AC output will shut off automatically, and the

“Fault/char” LED will turn red.

Reverse polarity input protection

If the battery terminals are reversed by accident, the inverter is equipped with fuses to prevent internal damage to the inverter and to protect any electronic device connected to the unit. The fuses are located externally for inverters sizes

1000W and up.

Inverter thermal protection

When the inner temperature exceeds 167 °F (75 °C), the AC output will shut off automatically, and the “Fault/char” LED will turn red. At this point the inverter needs to cool down for at least 15 minutes until it can be used again.

Load thermal protection

As the load increases the chassis will start to get warm, if the temperature of the chassis exceeds 122 °F (50 °C), the inner fan will automatically turn on to cool down the inverter.

Troubleshooting

TV Interference

The inverter may cause minimal interference with a television. It is recommended that the inverter is place far away from the television and/or the antenna.

Inverter has no response

(a) Poor connection between batteries and inverter, reconnect them.

(b) If polarities where reversed by accident, probably a fuse or multiple fuses are blown. Disconnect the inverter from the battery and replace the blown fuse(s) with a new one of the same size, when done, reconnect the battery and power the inverter.

11

Output voltage very low

(a) Power overload. Load power exceeds rated power, shut off some of the devices connected to the inverter and restart the inverter by turning it off and back on.

(b) Input voltage too low. Make sure input voltage is within the rated range.

Low voltage alarm

(a) Battery has insufficient power (low voltage). The battery might be overdischarged, and is necessary to recharge the battery for the inverter to continue to work properly.

(b) Poor connection. Check terminals on the inverter and battery post for loose connections. If the terminals are dirty, clean them with a dry cloth.

Inverter has no output

(a) Battery voltage might be too low, recharge the battery (s) or replace them.

(b) Load power too high. If the load exceeds the rated power of the inverter, the output will be automatically shut off. In this case, please turn off some of the devices connected to the inverter. This will reduce the load drawn from the inverter. Restart the inverter.

(c) Inverter thermal protection. The inverter might be too hot to operate, if the inverter exceeds 167 °F (75 °C) the output power will automatically shut off. Cool the inverter and place it in a place with good ventilation. Wait at least 15 minutes before resuming its use.

(c) Reverse polarity. If accidentally the polarity for the input voltage is reversed, a fuse or multiple fuses might blow up. This prevents from damaging the internals of the inverter or any device connected to the unit.

Disconnect the inverter from the battery and replace the blown fuse(s) with a new one of the same size, when done, reconnect the battery and power the inverter.

12

3. Emergency 60

Anderson Powerpole

Connector

(50A SB housing)

15 ft. Tray

Cable

Tilting Stands

3.1 Components

The Emergency 60 Watt kit comes with:

1. Renogy 100W Foldable Solar Suitcase

2. 60 AH Battery

3. Tray Cable 5

4. 1000 Watt Inverter

3.2 Renogy 60 Watt Foldable

Junction box

10A PWM LCD

Charge Controller

Aluminum frame with corner protection

Battery Alligator

Clips

Latch

Handle

Latch

Anderson Powerpole Connector

(50A SB housing)

Fuse Holder with

7.5A mini fuse

13

Also included but not depicted:

Storage Case

Installation

1. Unclip the two latches on the side of the unit and unfold the two panels outward.

Extend the stands to support the solar panels.

2. The controller is mounted on metal plate. The plate is attached to the back of the panel with Velcro. The hinges attached to the metal plate allow the user to swivel the charge controller to get a better look at the LCD display. The Velcro allows the reattachment of the charge controller back under the panel.

14

3. Fully extend battery leads. Connect the red alligator clip to the positive (+) battery terminal and the black alligator clip to the negative (-) battery terminal on a 12V battery.

Ensure that the connections are secure.

Black Red

Note: The kit should be connected to a battery generating at least 9V to start the charge controller. If the 12V battery is fully discharged, charge it for a short period of time by other means to reach 9V.

4. When you connect the kit to the battery, the charge controller will display a boot up message as follows:

15

WELCOME

VERSION 1.23

5. Adjusting Battery Size and Type: Press

to navigate to the menu options.

to enter to the options, press or

1.Monitoring .

2.Device Set

3.Parameter Set

4.Load Set

When the inverse cursor rests on 5. Rated Value , press parameter interface. Once again, press or

to enter into the nominal

to move between the adjustable parameters. Pressing pressing

will move the inverse cursor to the right. While

will move it to the left. If the inverse cursor is at the very beginning, press to jump back to the main menu screen. When the inverse cursor rests at some parameter, the contents of the parameter can be modified. To modify a parameter, press to increase the current parameter, or press to reduce it.

16

In this screen the battery type and capacity can be modified. The battery capacity ranges from 1-999 AH.

After the last digit of the battery capacity, Press battery.

or to select the type of

Seal = Sealed Lead Acid (AGM), Gel = Gel Battery, Flood = Flooded (wet cell) battery

Settings can be saved by pressing until the last adjustable parameter is reached, in this case will be the Battery Type. Press or

Cancel. The inverse cursor will rest on the selected option.

to choose between Save or

Press to confirm the selection. If the Save option is chosen, then the parameters will be saved. If Cancel was chosen, then parameters won’t be saved, and the screen will jump back to the main menu interface. When saving, the controller will check and confirm valid parameters. If the parameters are correctly set, and success message will appear as shown below:

17

After successfully saving the parameters, press to exit to the main menu. The controller should now have the correct parameters for the battery selected. If there is a need to use different charging parameters, the controller is fully adjustable. Please refer to the charge controller manual.

6. Find a clear sunlit area, free from overhanging tree branches, obstructions or shading.

The panel should be facing south, and the tilting angle should be adjusted as follows:

Summer

𝜃 = 𝐿𝑎𝑡𝑖𝑡𝑢𝑑𝑒 – 15°

Fall and Spring

𝜃 = 𝑎𝑡 𝑙𝑎𝑡𝑖𝑡𝑢𝑑𝑒

Winter

𝜃 = 𝐿𝑎𝑡𝑖𝑡𝑢𝑑𝑒 + 15° 𝜃

Note: To maximize the output, adjust the position of the kit regularly to track the sun movement throughout the day

7. Remote Temperature Sensor (optional): The charge controller (ViewStar) has a builtin temperature sensor. This is used for temperature compensation of the charging parameters. During a hot summer day, the local temperature on the controller might register a higher temperature than that from the battery if the battery is under shade.

2ERJ-3.81

Port

18

For this reason, the controller also has a 2ERJ-3.81 port for a Remote Temperature

Sensor (Model: TS-R). The RTS can be placed next to the battery (ies). This optional accessory can be purchased separately.

Charge Controller LEDs

Charging LED

Indicator

Fault

LED Indicator

Charging Indicator

The green LED indicator will turn on whenever sunlight is available for battery charging.

Under normal charging conditions, the green charging LED will stay on at all times.

Color

Green

Table 1 Charging LED indicators

Fault Indicator

Indication

On solid

Operating State

Charging

When the following cases occur the fault indicator will be flashing red:

Solar module

Over-current

Error while trying to measure the voltage

Reverse-protection MOS-I short

19

MOS-C short

MOS-I or MOS-C disconnection

MOS break in control section

Battery

Over-voltage

Error while trying to measure the voltage

The temperature is above range (battery too hot)

Load

Over load

Short

Discharging MOS Short

Error while trying to measure the voltage

Device

Controller is operating too hot

For trouble shooting please refer to the charge controller manual (Chapter 5).

Color

Red

Indication

Flashing

Operating State

PV: Over-current, Measure error,

MOS-I Short, MOS-C Short or MOS

Break

BATT: Over-voltage, Measure error or Running too hot

LOAD: Over load, Short,

Discharging MOS short, or

Measure error

DEVICE: Running too hot

Table 2 Fault indicators

Frequently Asked Questions

Q. What type of batteries can be used with this kit?

A. Any sealed lead acid, gel, or flooded 12V battery (typically used in caravans, motorhomes, boats etc.) is appropriate for use with this kit.

Q. Can this kit charge a 24V battery?

20

A. No, because this kit is designed to charge a 12V battery. Technically, it’s possible to change solar panel connections to enable the kit to work in 24V mode; however, a qualified, knowledgeable individual should only do this.

Note: unauthorized modification to 24V will void the warranty.

Q. Can the kit charge two or more 12V batteries connected in parallel?

A. Yes, it’s possible if the batteries have the same type and capacity and are wired in parallel as a single 12V battery bank.

Q. Is there any risk that the solar kit will over charge my battery?

A. One of the functions of the solar charge controller is to ensure that your battery is not over charged; therefore there is no risk of overcharge.

Q. Can I extend the battery leads?

A. Yes, it’s possible – please choose the same size of cable for extension. However, there longer the extension, the greater the line loss. Bigger gauge will be required for longer runs.

Q. Do I need to clean the solar panels?

A. Yes, it is recommended for better performance. Dust and dirt should first be swept off the panel surface using a soft brush. When the sweeping is complete, use a wet cloth to wipe the panel surface to remove remaining dirt and grime.

Q. Can rain damage the solar kit?

A. The solar panels are fully waterproof (IP66 class), the controller is not. We recommend protecting the kit from rain, since water into controller may damage the internal circuitry.

Trouble Shooting

Check all connections to ensure they are secure and clean

Check polarity of the battery connection and make sure the battery generates at least 9V

Ensure the solar panels are exposed to sufficient light – ideally position them to face the sun directly

21

For more information refer to the Troubleshooting section of the Solar Controller

Manual (skip anything which relates to load work in the controller manual as the load terminals of the controller are not used)

Specifications

Solar Panels

Description Parameter (60W) Parameter (100W)

Maximum Power

Open Circuit Voltage (Voc)

Short Circuit Current (Isc)

Maximum Power Voltage (Vmp)

Maximum Power Current (Imp)

Cell Type

Operating Temperature

Folded Size

Net Weight

60W

21.6V

3.62

18.0V

100W

21.6V

6.17A

17.5V

3.34A

Monocrystalline

5.71A

Monocrystalline

−40°F to +185°F −40°F to +185°F

13.60 x 25.40 x 2.80 “ 19.88 x 27.17 x 2.36 “

21.20 lbs. 24.69 lbs.

Table 3 Solar panels specifications

Specifications under standard test conditions (STC): 1000W/m

2

, AM 1.5, 25 °C. Specifications are stated for the solar panels only without the effect of the charge controller.

Charge Controller

Description Parameter

Nominal System Voltage

Rated Charge Current

Rated Discharge Current

Maximum Battery Voltage

Max. Solar Input Voltage*

Max. PV Input Power

Self-consumption**

Charge Circuit Voltage Drop

Discharge Circuit Voltage Drop

Communication

Remote Temperature Sensor

Ground

Battery Type

12VDC/24VDC Auto recognition

10A, 30A

10A, 30A

32V

48VDC

120W (12V)

≤18mA

≤ 0.24V

≤ 0.15V

TTL232 / 8 pin RJ45

2ERJ-3.81

VSxxxx24N: Negative ground

Gel, Sealed (AGM), and Flooded

Table 4 Electrical Parameters

*Array voltage should never exceed maximum PV input voltage. Refer to the solar module documentation to

determine the highest expected array V oc

(Open Circuit Voltage) as defined by the lowest expected ambient temperature for the system location.

Charging Parameters

22

High Volt Disconnect

Charging Limit Voltage

Over Voltage Reconnect

Equalization Voltage

Control Parameter

Battery type Gel Sealed Flooded

Default

16.0V; x2/24V 16.0V; x2/24V 16.0V; x2/24V

Max 17.0V; x2/24V 17.0V; x2/24V 17.0V; x2/24V

Min

15.0V; x2/24V 15.0V; x2/24V 15.0V; x2/24V

Default

15.5V; x2/24V 15.5V; x2/24V 15.5V; x2/24V

Max 16.0V; x2/24V 16.0V; x2/24V 16.0V; x2/24V

Min

14.0V; x2/24V 14.0V; x2/24V 14.0V; x2/24V

Default 15.0V; x2/24V 15.0V; x2/24V 15.0V; x2/24V

Max 16.0V; x2/24V 16.0V; x2/24V 16.0V; x2/24V

14.0V; x2/24V 14.0V; x2/24V 14.0V; x2/24V

Min

Default

Max

N/A

N/A

14.6V; x2/24V 14.8V; x2/24V

15.2V; x2/24V 15.2V; x2/24V

Min

N/A 14.2V; x2/24V 14.2V; x2/24V

Table 5 Battery Parameters

Boost Voltage

Float Voltage

Boost Return Voltage

Low Voltage Reconnect

Under Voltage Recover

Under Voltage Warning

Default

14.2V; x2/24V 14.4V; x2/24V 14.6V; x2/24V

Max

15V; x2/24V 15V; x2/24V 15V; x2/24V

Min 13.8V; x2/24V 13.8V; x2/24V 13.8V; x2/24V

Default

13.8V; x2/24V 13.8V; x2/24V 13.8V; x2/24V

Max

14.2V; x2/24V 14.2V; x2/24V 14.2V; x2/24V

Min 13.2V; x2/24V 13.2V; x2/24V 13.2V; x2/24V

Default

13.2V; x2/24V 13.2V; x2/24V 13.2V; x2/24V

Max

13.5V; x2/24V 13.5V; x2/24V 13.5V; x2/24V

Min 12.7V; x2/24V 12.7V; x2/24V 12.7V; x2/24V

Default

13.2V; x2/24V 13.2V; x2/24V 13.2V; x2/24V

Max

13.5V; x2/24V 13.5V; x2/24V 13.5V; x2/24V

Min 12.7V; x2/24V 12.7V; x2/24V 12.7V; x2/24V

Default

12.2V; x2/24V 12.2V; x2/24V 12.2V; x2/24V

Max

12.6V; x2/24V 12.6V; x2/24V 12.6V; x2/24V

Min 11.8V; x2/24V 11.8V; x2/24V 11.8V; x2/24V

Default

12.0V; x2/24V 12.0V; x2/24V 12.0V; x2/24V

Max

Min

12.4V; x2/24V 12.4V; x2/24V

11.6V; x2/24V 11.6V; x2/24V

12.4V; x2/24V

11.6V; x2/24V

23

Low Voltage Disconnect

Discharging Limit Voltage

Equalize Duration

Boost Duration

Table 5 Continued

Threshold Voltage

Default

11.1V; x2/24V 11.1V; x2/24V 11.1V; x2/24V

Max 11.8V; x2/24V 11.8V; x2/24V 11.8V; x2/24V

Min

10.5V; x2/24V 10.5V; x2/24V 10.5V; x2/24V

Default

10.8V; x2/24V 10.8V; x2/24V 10.8V; x2/24V

Max 11V; x2/24V 11V; x2/24V 11V; x2/24V

10.5V; x2/24V 10.5V; x2/24V 10.5V; x2/24V

Min

N/A

N/A

N/A

2 hours

2 hours

2 hours

2 hours

2 hours

Description

NTTV (Night Time Threshold Voltage)

DTTV (Day Time Threshold Voltage)

Default

Max

Min

Default

Max

Min

Parameter

5V; x2/24V

10V; x2/24V

1V; x2/24V

6V; x2/24V

10V; x2/24V

1V; x2/24V

Table 6 Threshold Voltages

Temperature Compensation

Temperature Compensation Coefficient

(TEMPCO)*

Description

Default

Max

Min

Table 7 Temperature Compensation

*Compensation of equalize, boost, float and low voltage disconnect voltage

Parameter

-3mV/°C/2V (25°C ref)

0mV/°C/2V

-9mV/°C/2V

Environmental Parameters

Environmental

Working Temperature Range

Storage Temperature Range

Enclosure

Table 8 Environmental Parameters

Mechanical Parameters

Parameter

-35 °C to +55 °C (-31 °F to +131 °F)

-35 °C to +80 °C (-31 °F to +176 °F)

IP30

Mechanical Parameter

24

Terminal

Weight

Table 9 Mechanical Parameters

VS1024N: 4 mm

2

(up to #12 AWG)

VS3024N: 16 mm

2

(up to #6 AWG)

VS1024N: 0.44 lbs.

VS3024N: 1.54 lbs.

Warranty

By acquiring the products of RNG Group Inc. ("Renogy"), you have purchased quality. As a sign of confidence in this quality, we are pleased to grant you the following warranties and guarantees for our photovoltaic products.

LIMITED WARRATNY:

Renogy warrants this product will be free from defects in material and manufacturer for the following periods from the date of purchase:

Five (5) years on the solar panel

Two (2) years on charge controller

One (1) year on the rest of the kit components

This warranty extends only to the original purchaser. The Customer’s sole and exclusive remedy and the entire liability of Renogy, its suppliers and affiliates for breach of the warranty is, either to replace the Product or component parts or to refund the purchase price of the Product. This warranty does not cover labor. Repaired or replaced products are warranted for the remainder of the original warranty period only. No employee, agent, dealer or other person is authorized to give any warranties on behalf of Renogy not expressly set forth in this limited warranty.

The warranty does not cover failures result from incorrect handling, product modifications, installation, conversion or additions, supplements, operation, natural elements, excessive or deficient energy supply, chemicals, the effect of solid bodies or deliberate damage. If Renogy determines that the problem with the Product is not due to a manufacturing defect in Renogy’s workmanship or materials, or otherwise does not qualify for warranty repair, then the Customer will be responsible for the costs of all necessary repairs and expenses incurred by Renogy.

The warranty shall be asserted with Renogy in writing enclosing a copy of the invoice and a description of the defect/loss of performance within the warranty period. Renogy shall accept no returns of modules without the previous written request for this. Within five (5) business days of the date of notification, Renogy will provide the Customer with an RMA number and the location to which the Customer must return the defective

Product. Any Product returned for warranty service shall be shipped at the expense and risk of the Customer. The Customer must return the entire Product (or, if authorized by

Renogy, the defective component parts), within fifteen (15) days after issuance of the

25

RMA number. Renogy will be under no obligation to accept any returned Product that does not have a valid RMA number. All parts that Renogy replaces shall become

Renogy’s property on the date Renogy ships the repaired Product or part back to the

Customer. Renogy will use all reasonable efforts within thirty (30) days of receipt of the defective Product to repair or replace such Product. If a warranty claim is invalid for any reason, the Customer will be charged at Renogy’s then-current rates for services performed and will be charged for all necessary repairs and expense incurred by

Renogy. If Renogy determines that a warranty claim is valid, it will ship the repaired or replaced Product to Customer at Renogy’s cost.

RENOGY MAKES NO OTHER WARRANTIES OR CONDITIONS, EXPRESS OR IMPLIED,

INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OR CONDITION OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE OR ANY IMPLIED

WARRANTY OR CONDITION ARISING OUT OF A COURSE OF DEALING, CUSTOMER OR

USAGE OF TRADE.

LIMITATION OF LIABILITY

UNDER NO CIRCUMSTANCES WILL RENOGY OR ITS AFFILIATES OR SUPPLIERS BE LIABLE

OR RESPONSIBLE FOR ANY LOSS OF USE, INTERRUPTION OF BUSINESS, LOST PROFITS,

LOST DATA, OR INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES OF

ANY KIND REGARDLESS OF THE FORM OF ACTION, WHETHER IN CONTRACT, TORT

(INCLUDING NEGLIGENCE), STRICT LIABILITY OR OTHERWISE, EVEN IF RENOGY OR ITS

AFFILIATE OR SUPPLIER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

Some states do not allow the exclusion or limitation of incidental or consequential damages, so these limitations may not apply to you. Neither Renogy nor its affiliates or suppliers will be held liable or responsible for any damage or loss to any items or products connected to, powered by or otherwise attached to the Product. The total cumulative liability to Customer, from all causes of action and all theories of liability, will be limited to and will not exceed the purchase price of the Product paid by Customer.

This warranty gives you specific legal rights and you may also have other legal rights that vary from state to state.

3.3 UPG Sealed Lead-Acid Battery 35Ah

Specification

Nominal Voltage

Nominal Capacity

20-hr (1.75A)

10-hr (3.26A)

5-hr (5.95A)

1-hr (21.00A)

Description Parameter (30W)

12V

35.0 Ah

32.55 Ah

29.75 Ah

21.0 Ah

26

Approximate Weight

Internal Resistance

Shelf Life

Temperature Dependency of Capacity

Float Use

22.5 lbs.

12mΩ

3 Months – 91%

6 Months – 82%

12 Months – 64%

104°F – 102%

77°F – 100%

32°F – 85%

5°F – 65%

13.6-13.8

3.4 Renogy 1000 Watt Inverter

See section 2.3 Renogy 500 Watt Inverter for specifications.

4. Emergency 100

4.1 Components

The Emergency 100 Watt kit comes with:

1. Renogy 100W Foldable Solar Suitcase

2. 85 AH Battery

3.

Tray Cable 5’

4. 2000 Watt Inverter

4.2 Renogy 100 Watt Foldable

See section 3.2 Renogy 100 Watt Foldable for specifications.

27

4.3 UPG Sealed Lead-Acid Battery 50Ah

Specification

Description

Nominal Voltage

Nominal Capacity

20-hr (2.50A)

10-hr (4.65A)

5-hr (8.50A)

1-hr (30.00A)

Approximate Weight

Internal Resistance

Shelf Life

Temperature Dependency of Capacity

Float Use

4.4 Renogy 2000 Watt Inverter

Parameter (30W)

12V

50.0 Ah

46.5 Ah

42.5 Ah

30.0 Ah

30.2 lbs.

11mΩ

3 Months – 91%

6 Months – 82%

12 Months – 64%

104°F – 102%

77°F – 100%

32°F – 85%

5°F – 65%

13.6-13.8

See section 2.3 Renogy 500 Watt Inverter for specifications.

28

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
