ENGLISH
SAFETY INSTRUCTIONS
1. Read Instructions - All the safety and operating instructions should
be read before the product is operated.
2. Retain instructions - The safety and operating instructions should
be retained for future reference.
3. Heed Warnings - All warnings on the product and in the operating
instructions should be adhered to.
4. Follow Instructions - All operating and use instructions should be
followed.
5. Cleaning - Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for
cleaning.
6. Attachments - Do not use attachments not recommended by the
product manufacturer as they may cause hazards.
7. Water and Moisture - Do not use this product near water - for
example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in
a wet basement, or near a swimming pool; and the like.
8. Accessories - Do not place this product on an unstable cart, stand,
tripod, bracket, or table. The product may fall, causing serious injury
to a child or adult, and serious damage to the product. Use only with
a cart, stand, tripod, bracket, or table recommended by the
manufacturer, or sold with the product. Any mounting of the product
should follow the manufacturer’s instructions, and should use a
mounting accessory recommended by the
manufacturer.
9. A product and cart combination should be
moved with care. Quick stops, excessive
force, and uneven surfaces may cause the
product and cart combination to overturn.
10. Ventilation - Slots and openings in the
cabinet are provided for ventilation and to
ensure reliable operation of the product PORTABLE CART WARNING
and to protect it from overheating, and
these openings must not be blocked or covered. The openings
should never be blocked by placing the product on a bed, sofa, rug,
or other similar surface. This product should not be placed in a
built-in installation such as a bookcase or rack unless proper
ventilation is provided or the manufacturer’s instructions have been
adhered to.
11. Power Sources - This product should be operated only from the
type of power source indicated on the marking label. If you are not
sure of the type of power supply to your home, consult your product
dealer or local power company. For products intended to operate
from battery power, or other sources, refer to the operating
instructions.
12. Grounding or Polarization - This product may be equipped with a
polarized alternating-current line plug (a plug having one blade
wider than the other). This plug will fit into the power outlet only one
way. This is a safety feature. If you are unable to insert the plug
fully into the outlet, try reversing the plug. If the plug should still fail
to fit, contact your electrician to replae your obsolete outlet. Do not
defeat the safety purpose of the polarized plug.
Alternate Warnings - This product is equipped with a three-wire
grounding-type plug, a plug having a third(grounding) pin. This plug
will only fit into a grounding-type power outlet. this is a safety
feature. If you are unable to insert the plug into the outlet, contact
your electrician to replace your obsolete outlet. Do not defeat the
safety purpose of the gronding-type plug.
13. Power-Cord Protection - Power-supply cords should be routed so
that they are not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to cords at plugs,
convenience receptacles, and the point where they exit from the
product.
14. Outdoor Antenna Grounding - If an outside antenna or cable
system is connected to the product, be sure the antenna or cable
system is grounded so as to provide some protection against
voltage surges and built-up static charges. Article 810 of the
National Electrical Code, ANSI/NFPA 70, provides information with
regard to proper grounding of the mast and supporting structure,
grounding of the lead-in wire to an antenna discharge unit, size of
grounding conductors, location of antenna-discharge unit,
connection to grounding electrodes, and requirements for the
grounding electrode. See Figure 1.
Figure 1
Example of antenna grounding as per
National Electrical Code, ANSI/NFPA 70
15. Lightning - For added protection for this product during a lightning
storm, or when it is left unattended and unused for long periods of
time, unplug it from the wall outlet and disconnect the antenna or
cable system. This will prevent damage to the product due to
lightning and power-line surges.
16. Power Lines - An outside antenna system should not be located in
the vicinity of overhead power lines or other electric light or power
circuits, or where it can fall into such power lines or circuits. When
installing an outside antenna system, extreme care should be taken
to keep from touching such power lines or circuits as contact with
them might be fatal.
17. Overloading - Do not overload wall outlets, extension cords, or
integral convenience receptacles as this can result in a risk of fire
or electric shock.
18. Object and Liquid Entry - Never push objects of any kind into this
product through openings as they may touch dangerous voltage
points or short-out parts that could result in a fire or electric shock.
Never spill liquid of any kind on the product.
19. Servicing - Do not attempt to service this product yourself as
opening or removing covers may expose you to dangerous voltage
or other hazards. Refer all servicing to qualified service personnel.
20. Damage Requiring Service - Unplug this product form the wall
outlet and refer servicing to qualified service personnel under the
following conditions:
a) When the power-supply cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the
product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following the
operating instructions. Adjust only those controls that are
covered by the operating instructions as an improper
adjustment of other controls may result in damage and will
often require extensive work by a qualified technician to
restore the product to its normal operation.
e) If the product has been dropped or damaged in any way, and
f) When the product exhibits a distinct change in performance this indicates a need for service.
21. Replacement Parts - When replacement parts are required, be
sure the service technician has used replacement parts specified
by the manufacturer or have the same characteristics as the
original part. Unauthorized substitutions may result in fire, electric
shock, or other hazards.
22. Safety Check - Upon completion of any service or repairs to this
product, ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
23. Wall or Ceiling Mounting - The product should be mounted to a
wall or ceiling only as recommended by the manufacturer.
24. Heat - The product should be situated away from heat sources
such as radiators, heat registers, stoves, or other products
(including amplifiers) that produce heat.
2
Introduction
This symbol is intended to alert the user to the presence
of uninsulated "dangerous voltage" within the product's
enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
CAUTION
: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK). NO USERSERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
WARNING
This symbol is intended to alert the user to the presence
of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
Caution regarding installation
Note : For heat dispersal, do not install this unit in a confined space such as a bookcase or similar enclosure.
Do not block ventilation openings or stack other equipment on the top.
Note to CATV System Installer :
This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper
grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point
of cable entry as practical.
FCC INFORMATION
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Caution : Any changes or modifications in construction of this device which are not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
FOR YOUR SAFETY
U.S.A
CANADA
Units shipped to the U.S.A and CANADA are designed for operation on 120 V AC only.
Safety precaution with use of a polarized AC plug.
However, some products may be supplied with a nonpolarized plug.
120 V
CAUTION : To prevent electric shock, match wide blade of plug to wide slot, fully insert.
Pour éviter chocs électriques, introduire la lame la plus large de la fiche dans la borne
ATTENTION : correspondante
de la prise et pousser jusqu’ au fond.
CAUTION
• Leave a space around the unit for sufficient ventilation.
• Avoid installation in extremely hot or cold locations, or in an area that is exposed to direct sunlight or heating equipment.
• Keep the unit free from moisture, water, and dust.
• Do not let foreign objects in the unit.
• The ventilation should not be impeded by covering the ventilation openings with items, such as newspapers, table-cloths, curtains, etc.
• No naked flame sources, such as lighted candles, should be placed on the unit.
• Please be care the environmental aspects of battery disposal.
• The unit shall not be exposed to dripping or splashing for use.
• No objects filled with liquids, such as vases, shall be placed on the unit.
• Do not let insecticides, benzene, and thinner come in contact with the set.
• Never disassemble or modify the unit in any way.
■Notes on the AC power cord and the wall outlet.
• The unit is not disconnected from the AC power source(mains) as long as it is connected to the wall outlet, even if the unit has been turned off.
• When disconnecting the power cord from the wall outlet, always pull the plug, not the power cord.
• Disconnect the plug from the wall outlet when not using the unit for long periods of time.
• The wall outlet shall be installed near the unit and shall be easily accessible.
3
ENGLISH
READ THIS BEFORE OPERATING YOUR UNIT
ENGLISH
CONTENTS
• SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
• Introduction
READ THIS BEFORE OPERATING YOUR UNIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
• System Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
• Front Panel Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
• Universal Remote Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
OPERATING COMPONENTS WITH REMOTE CONTROL . . . . . . . . . . . . . . . . . . . . . . 19
REMOTE CONTROL OPERATION RANGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
LOADING BATTERIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
USING FUNCTIONS OF REMOTE CONTROL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
• ROOM 2 Remote Controls
REMOTE CONTROL OPERATION RANGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
LOADING BATTERY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
• Operations
LISTENING TO A PROGRAM SOURCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
SURROUND SOUND . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
ENJOYING SURROUND SOUND . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
LISTENING TO RADIO BROADCASTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
LISTENING TO XM SATELLITE RADIO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
(XM Satellite Radio (only for North America))
RECORDING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
DIGITAL AUDIO RECORDING WITH MD RECORDER . . . . . . . . . . . . . . . . . . . . . . . . . 44
OTHER FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
ROOM 2 SOURCE PLAYBACK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
• OSD Menu Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
SETTING THE SYSTEM SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
SETTING THE INPUT SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
SETTING THE SPEAKER / ROOM EQ SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
SETTING THE CH LEVEL SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
SETTING THE SOUND PARAMETER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
SETTING THE ROOM 2 SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
• Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
• Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
• Setup Code Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
4
• Please be certain that this unit is unplugged from the AC outlet before making any connections.
• Since different components often have different terminal names, carefully read the operating instructions of the
component connected.
• Be sure to observe the color coding when connecting audio, video and speaker cords.
• Make connections firmly and correctly. If not, it can cause loss of sound, noise or damage to the receiver.
1. CONNECTING ANTENNAS
GND
GND
AM
LOOP
AM
LOOP
• A 75Ω outdoor FM antenna may be used to further improve the reception. Disconnect the
indoor antenna before replacing it with the outdoor one.
• Change the position of the FM indoor antenna
until you get the best reception of your favorite
FM stations.
GND
• Place the AM loop antenna as far as possible
from the receiver, TV set, speaker cords and
the AC input cord and set it to a direction for the
best reception.
• If the reception is poor with the AM loop antenna, an AM outdoor antenna can be used in
place of the AM loop antenna.
AM
LOOP
5
ENGLISH
System Connections
2. CONNECTING VIDEO COMPONENTS
ENGLISH
• The jacks of VIDEO 1 may also be connected
to a DVD recorder or other digital video
recording component.
For details, refer to the operating instructions
of the component to be connected.
• The jacks of VIDEO 2/VIDEO 3/VIDEO 4 can
also be connected to an additional video
component such as a cable TV tuner, an LD
player or satellite system.
• Connect the jacks of VIDEO 3/VIDEO 4 to the
video component in the same way.
Note:
• When Sherwood DVD player such as V-768,
etc. is connected to the DIGI-LINK jack for
system control, you should connect the DVD
player to the " VIDEO 2" jacks of this unit.
Because, if the PLAY button, etc. is pressed on
the DVD player, the VIDEO 2 is automatically
selected as an input source on this unit. Then
playback, etc. starts.
HDMI (High Definition Multimedia Interface) connection : (*1)
• You can connect the source component (DVD player, etc.) to the display component (TV, projector, etc.) through this
receiver with using a commercially available HDMI cord.
• The HDMI connection can carry uncompressed digital video signals and digital audio signals.
• This receiver can output digital video and digital audio signals from the MONITOR HDMI OUT of this receiver without
passing through any circuits as they were input into the HDMI IN.
• If you connect the HDMI INs to your video components, it is easier to do so following the default settings.
• If your HDMI connection is different from the default setting, you should assign the HDMI INs you used with the "When
selecting the VIDEO ASSIGN 1" procedure on page 52.
• The default settings are as follows :
HDMI 1 : VIDEO 1, HDMI 2 : VIDEO 2
• HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI licensing
LLC.
Note :
• Depending on the connected component, unreliable signal transfer may happen. (For details, refer to the operating
instructions of your component.)
Component video input default settings: (*2)
• If you connect the COMPONENT VIDEO INs to your video components, it is easier to do so following the default settings.
• If your component video connections are different from the default setting , you should assign the COMPONENT VIDEO
INs you used with the “When selecting the VIDEO ASSIGN 2” procedure on page 53.
• The default settings are as follows:
COMPONENT IN 1 : VIDEO 1, COMPONENT IN 2 : VIDEO 2, COMPONENT IN 3 : VIDEO 3.
6
• There are three types of video jacks (COMPONENT, S-VIDEO, (composite) VIDEO) for connecting video
components.
Connect them to the corresponding video jacks according to their capability.
• For your reference, the excellence in picture quality is as follows : “COMPONENT” >“S-VIDEO”> “(composite)
VIDEO” .
• When making COMPONENT VIDEO connections, connect “Y” to “Y”, “PB/CB” to “CB”(or “B-Y”, “PB”) and “PR/CR”
to “CR”(or “R-Y”, “PR” ).
• When recording video program sources through VIDEO 1 OUT jacks or viewing ROOM 2 source through
ROOM 2 OUT jack, you must use the same type of video jacks that you did connect to video playback
components such as DVD player, LD player, etc.
• This unit is equipped with a function that up-converts composite video or S-Video signals to component video
signals or down-converts S-Video signals to composite video signals and outputs them from the MONITOR
OUTs. Because of this, you need not connect all the types of MONITOR OUT jacks to the MONITOR TV.
• After connecting the video components, you should set the video mode correctly, reffering to the following table.
(For details, refer to "When selecting the VIDEO MODE" on page 53.)
Relationship between the video input signal and the video output signal
Video input signals
Video Mode
COMPONENT
S-VIDEO
(COMPOSITE) VIDEO
Setting
×
×
◯
Auto
×
◯
×◯◯
×
◯
×
◯
◯
◯
Component *1
×
×
◯
Composite*2
◯
◯
×
Auto
Component
S-Video
S-Video
◯
×
◯
Auto
Component
Composite video
Composite video
Component*4
MONITOR OUTs
COMPONENT
Component
Component
S-Video*2
S-Video
Composite video
S-VIDEO
S-Video
(COMPOSITE) VIDEO
Composite video*3
×
×
S-Video
S-Video
Composite video
Composite video
◯
×
×
Auto
×
◯
◯
Auto
×
◯
×
Auto
S-Video
S-Video
S-Video
×
×
◯
Auto
Composite video
Composite video
Composite video
S-Video
×
×
S-Video
Composite video*3
*1 : Component video signal can be output from the MONITOR COMPONENT OUT jacks only.
*2 : The video signal set in the VIDEO MODE menu can be output from all the types of MONITOR OUT jacks.
*3 : The OSD menu and the momentary OSD cannot be displayed via MONITOR COMPOSITE jack.
*4 : If the OSD menu operation is performed, the picture is automatically turned off and only the OSD menu is
displayed via MONITOR COMPONENT OUT jacks.
Note :
• When outputting the component video signal from the MONITOR COMPONENT OUT jacks as it was input, the
momentary OSD cannot be displayed.
3. CONNECTING AUDIO COMPONENTS
• The TAPE IN/OUT jacks can be connected to audio recording equipment such as a tape deck, an MD recorder,
etc.
7
ENGLISH
Continued
ENGLISH
4. CONNECTING EXTERNAL INS
• Use these jacks to connect the corresponding outputs
of a DVD player or external decorder, etc. that has 6,
7 or 8 channel analog audio outputs.
• In case of 6 or 7 channel outputs, do not connect both
of the SURROUND BACK L and R inputs or the
SURROUND BACK R input of this unit. (For details,
refer to the operating instructions of the component to
be connected.)
5. CONNECTING DIGITAL INS AND OUT
• The OPTICAL and the COAXIAL DIGITAL OUTs of
the components that are connected to this unit can
be connected to these DIGITAL INs.
• A digital input should be connected to the
components such as a CD player, LD player, DVD
player, etc. capable of outputting DTS Digital
Surround, Dolby Digital or PCM format digital
signals, etc.
• If the component with OPTICAL IN jack is
connected to the OPTICAL OUT jack of this unit,
you can record the high quality sound of CDs, etc.
without degradation.
• For details, refer to the operating instructions of the
component connected.
• When making the COAXIAL DIGITAL connection,
be sure to use a 75 Ω COAXIAL cord, not a
conventional AUDIO cord.
• All of the commercially available optical fiber cords
cannot be used for the equipment. If there is an
optical fiber cord which cannot be connected to your equipment, consult your dealer or nearest service
organization.
Note:
• Be sure to make either a OPTICAL or a COAXIAL DIGITAL connection on each component. (You don’t need to
do both.)
Digital input default settings
• If you connect the DIGITAL INs to your components, it is easier to do so following the default settings.
• If your DIGITAL connections are different from default settings, you should assign the DIGITAL INs you used
with the “When selecting the DIGITAL AUDIO” procedure on page 52.
• The default settings are as follows :
OPTICAL IN 1 : VIDEO 1, OPTICAL IN 2 : VIDEO 2, OPTICAL IN 3 : VIDEO 3, OPTICAL IN 4 : VIDEO 4,
(Front) OPTICAL IN 5 : VIDEO 5, COAXIAL IN 1 : CD, COAXIAL IN 2 : AUX.
8
6. CONNECTING PRE OUTS
ENGLISH
• Use these jacks when adding additional
power amplifiers.
• Connect the PRE OUT jacks to the powered
speakers or the power amplifiers connected
to speakers respectively.
• When using only one surround back speaker,
connect the SURROUND BACK LEFT jack to
the power amplifier.
• To emphasize the deep bass sounds,
connect a powered subwoofer.
Notes :
• After installing the speakers, first adjust the
speaker settings according to your
environment and speaker layout (For details,
“SETTING THE SPEAKER/ROOM EQ
SETUP” on page 55.)
• According to speaker settings, some
channels of PRE OUTs cannot output audio
signals.
7. CONNECTING SYSTEM CONTROL
• Connect this jack to the DIGI-LINK jack of the
external Sherwood component that uses the
DIGI-LINK II or III remote control system.
8. CONNECTING DC TRIGGER OUT
• Connect a component to DC TRIGGER OUT
jack that allows DC 12V to turn on when a
specific input source is selected.
• For details, refer to the operating instructions
of the components to be connected.
• To link DC TRIGGER OUT with a specific
input source, refer to "When selecting the DC
TRIGGER" on page 54.
Note:
• This output voltage (12V d.c., 100mA) is for (status) control only, it is not sufficient for drive capability.
• When making DC TRIGGER connection, you should use the stereo mini cord, not a mono mini cord.
9
ENGLISH
9. CONNECTING SPEAKERS
• Be sure to connect speakers firmly and correctly according to the channel(left and right) and the polarity
(+ and -). If the connections are faulty, no sound will be heard from the speakers, and if the polarity of the
speaker connection is incorrect, the sound will be unnatural and lack bass.
• For installing the speakers, refer to “Speaker placement” on page 11.
• After installing the speakers, first adjust the speaker settings according to your environment and speaker
layout. (For details, refer to “SETTING THE SPEAKER/ROOM EQ SETUP” on page 55.)
Front speakers A and B
• This unit allows you to connect two different sets of front speakers and to select either FRONT A or/and B
speakers according to your taste.
• However, if you have only a set of front speakers, connect them to either FRONT A or B speaker
terminals.
Surround back speakers
• When using only one surround back speaker, you should connect it to SURROUND BACK/ROOM 2
LEFT channel.
• If you assign the power amplifier for the surround back/room 2 channels to the ROOM 2, this unit can
drive the speakers in another room (ROOM 2).
(For details, refer to “CONNECTING ROOM 2 OUTS” on page 12 and “When selecting the AMP ASSIGN”
on page 49.)
Caution :
• For safe amplifier operation, in case of using either front A or front B speakers, use all the speakers with
impedance of over 6 ohms. However, in case of using both front A and front B speakers, use only these
speakers with impedance of over 12 ohms and other speakers with impedance of over 6 ohms.
• Do not let the bare speaker wires touch each other or any metal part of this unit. This could damage this
unit and/or the speakers.
10
Speaker placement
ENGLISH
Ideal speaker placement varies depending on the
size of your room and the wall coverings, etc. The
typical example of speaker placement and
recommendations are as follows :
■Front left and right speakers and center speaker
• Place the front speakers with their front surfaces as
flush with TV or monitor screen as possible.
• Place the center speaker between the front left and
right speakers and no further from the listening
position than the front speakers.
• Place each speaker so that sound is aimed at the
location of the listener’s ears when at the main
listening position.
■Surround left and right speakers
• Place the surround speakers approximately 1 meter
(40 inches) above the ear level of a seated listener
on the direct left and right of them or slightly behind.
■Surround back left and right speakers
• Place the surround back speakers at the back facing
the front at a narrower distance than front speakers.
• When using a single surround back speaker, place it
at the rear center facing the front at a slightly higher
position (0 to 20 cm ) than the surround speakers.
• We recommend installing the surround back
speaker(s) at a slightly downward facing angle. This
effectively prevents the surround back channel
signals from reflecting off the TV or screen at the
front center, resulting in interference and making the
sense of movement from the front to the back less
sharp.
1. TV or Screen
2. Front left speaker
3. Subwoofer
4. Center speaker
5. Front right speaker
6. Surround left speaker
7. Surround right speaker
8. Surround back left speaker
9. Surround back right speaker
10. Surround center speaker
11. Listening position
■Subwoofer
• The subwoofer reproduces powerful deep bass
sounds.
Place a subwoofer anywhere in the front as desired.
■Notes :
•When using a conventional TV, to avoid interference with the TV picture, use only magnetically shielded front
left and right and center speakers.
•To obtain the best surround effects, the speakers except the subwoofer should be full range speakers.
11
ENGLISH
10. CONNECTING ROOM 2 OUTS
• ROOM 2 playback feature allows you to play a different program source in another room as well as one source
in the main room at the same time.
• For ROOM 2 playback, connect the ROOM 2 OUT jacks to the amplifier, TV, etc. installed in another room, or
connect the SURROUND BACK/ROOM 2 speaker terminals to the speakers.
• When connecting the SURROUND BACK/ROOM 2 speaker terminals, you should assign the power amplifier
for surround back/room 2 channels to the ROOM 2.
(For details, refer to "When selecting the AMP ASSIGN" on page 49.)
Notes :
• To minimize hum or noise, use high quality connection cords.
• You cannot use the digital audio signal for ROOM 2 playback.
11. CONNECTING PC FOR UPGRADES
• This receiver incorporates RS-232C terminal that may be
used in the future to update the operating software so that it
will be able to support new digital audio formats, external
control by using an external device and the like.
• Connect RS-232C terminal to your PC.
Notes:
• Be sure to set the UPGRADE switch to "SVC" (service) before
updating.
• This switch should be set to "OPR" (operation) during normal
operation except for upgrades. If not, this unit wil not operate
normally.
• Programming for upgrades and external control requires specialized programming knowledge and for that
reason we recommend that it only be done by qualified installers. For more information on future upgrades and
external control, visit the Sherwood web site at www.sherwoodamerica.com or contact your dealer.
• Do not disconnect the connection cable while updating the operating software, etc.
Should this happen, it may be result in malfunction or cause damage to the unit.
12
• The multi-room system kit(sold separately ) is essential for operation from a remote location .
For information on the multi-room system kit, contact the Xantech corporation at 1-800-843-5465 or
www.xantech.com.
• IR IN jack allows you to control this receiver from another room with the remote control unit.
• To control this receiver from another room with the remote control unit, connect the IR IN jack to the output of
the connecting block.
• If this receiver is located inside a cabinet or other enclosure where the infrared beams from the remote control
unit cannot enter, then operation with the remote control unit will not be possible. In such a case, connect the IR
IN jack to the output of the connecting block.
Note:
• Remote operation may become unreliable if the IR receiver is exposed to strong light such as direct sunlight or
inverted fluorescent.
13. CONNECTING XM DT (only for North America)
• Connect the XM DT terminal to the XM
Connect-and-Play antenna (sold
separately).
• Position the XM Connect-and-Play
antenna near a south-facing window to
receive the best signal.
When making connections, also refer to
the operating instructions of the XM
Connect-and-Play antenna.
• For the best reception, check the signal
strength of the XM radio signal with using
signal strength display mode, then adjust the position of the XM antenna until "SIGNAL : GOOD" is displayed.
(For details, refer to "Displaying XM information" on page 42.)
• To listen to XM Satellite Radio, refer to "XM Satellite Radio (only for North America)" on page 40.
13
ENGLISH
12. CONNECTING MULTI-ROOM SYSTEM KIT
ENGLISH
14. SWITCHED AC OUTLETS
• These outlets are switched on (power-on mode) and
off (standby mode) according to power control as
follows (Maximum total capacity is 120 W (1A)).
Standby mode - Switched AC outlet off
Power - on mode - Switched AC outet on
15. AC INPUT
• Plug the supplied AC input cord into this AC inlet and
then into the wall AC outlet.
Note:
• Do not use an AC input cord other than the one supplied
with this unit. The AC input cord supplied is designed for
use with this unit and should not be used with any other
device.
14
ENGLISH
Front Panel Controls
1. POWER switch
2. POWER ON/STANDBY button/indicator
3. VIDEO INPUT SELECTOR button
4. AUDIO INPUT SELECTOR button
5. EXTERNAL IN button
6. BAND button
7. MASTER VOLUME CONTROL knob
8. HEADPHONE jack
9. SPEAKER button
10. PURE AUDIO button
11. SURROUND MODE button
12. STEREO button
13. OSD SETUP button
14. CHANNEL LEVEL button
15. CONTROL UP (▲)/DOWN (▼) buttons
16. ROOM 2 button
17. MEMORY/ENTER button
18. TUNING UP(+)/DOWN(-) buttons
19. PRESET UP(+)/DOWN(-) buttons
20. DIGITAL/ANALOG MODE button
21. MULTI CONTROL knob
22. REMOTE SENSOR
23. PURE AUDIO indicator
24. FLUORESCENT DISPLAY
For details, see below.
25. SETUP MIC jack
For details, see next page.
26. AUX IN jack
For details, see next page.
27. VIDEO 5 INPUT jacks
For details, see next page.
FLUORESCENT DISPLAY
1. Dolby surround mode indicators
2. Auto surround indicator
3. Speaker (/channel output : outer box) indicators
4. Input signal indicators
5. REMASTERING indicator
6. Front A/B speaker indicators
7. ROOM 2 amp indicators
8. ROOM-EQ indicator
9. Input, frequency, surround mode, operating
information, etc.
10. DIGITAL INPUT indicator
11. TONE indicator
12. SLEEP indicator
13. CINEMA EQ indicator
14. STEREO indicator
15. MEMORY indicator
16. TUNED indicator
17. MUTE indicator
18. Preset number, volume level, sleep time display
15
ENGLISH
SETUP MIC JACK
• To use Auto Setup function, connect the supplied
microphone to the SETUP MIC jack.(For details, refer to
"When selecting the AUTO SETUP" on page 55.)
Notes:
• Because the microphone for Auto Setup is designed for
use with this receiver, do not use a microphone other
than the one supplied with this receiver.
• After you have completed the auto setup procedure,
disconnect the microphone.
AUX IN JACK
• The AUX IN jack can be connected to an
additional audio component such as an
MP3 player, etc.
Note :
• When connecting this jack to an MP3
player, etc., you should use the stereo
mini cord, not a mono mini cord.
VIDEO 5 INPUT JACKS
When not using
the VIDEO 5 INPUT
jacks, cover these
jacks with the
supplied cap.
• The VIDEO 5 input jacks may be also connected
to an additional video component such as a
camcorder, a video game player, etc.
• If the OPTICAL IN 5 is connected to the
component connected to VIDEO 5, it is easier to
do so following the default settings.(For details,
refer to “Digital input default settings” on page 8.)
• If the OPTICAL IN 5 connection is different from
the default settings, you should assign the
DIGITAL INs you used with the “When selecting
the DIGITAL AUDIO" procedure on page 52.
• If you connect the COMPONENT VIDEO INs on
the rear panel to your video component, you
should assign the COMPONENT VIDEO INs you
used with the "When selecting the VIDEO
ASSIGN" procedure on page 52.
16
This universal remote control can operate not only this receiver but also most popular brands of audio and video
components such as CD players, tape decks, TVs, cable boxes, VCRs, satellite receivers, DVD players, etc.
• To operate 7 components other than this receiver , you should enter the setup code for each component.
(For details, refer to “USING FUNCTIONS OF REMOTE CONTROL” on page 20.)
DIGI LINK system remote controls
This remote control can also operate Sherwood compatible components bearing the DIGI LINK(II or III) logo.
• For DIGI LINK system remote control operation, first make the DIGI LINK connections between Sherwood
components.
• The numbered buttons on the remote control have different functions in different device modes. For details,
refer to "FUNCTION TABLE of the NUMBERED BUTTONS" on the next page.
17
ENGLISH
Universal Remote Controls
ENGLISH
FUNCTION TABLE of the NUMBERED BUTTONS.
Notes :
• Some functions for each component may not be available or may work differently.
• Depending on other kinds of components that are available for each DEVICE button, some functions may not be
available or may work differently, too.
• For details about functions, refer to the operating instructions of each component.
18
1
2
3
4
REMOTE CONTROL OPERATION RANGE
Enter the setup code for each
component other than this receiver.
For detalis, refer to “Entering a setup
code” on page 20.
• Use the remote control within a range of
about 7 meters (23 feet) and angles of up
to 30 degrees aiming at the remote sensor.
Turn on the component you want to
operate.
Select the DEVICE button on the
remote control corresponding to the
component you wish to operate.
Aim the remote control at the
REMOTE SENSOR of the component
you wish to control and press the
button corresponding to the operation
you want.
• When operating a Sherwood CD player or tape
deck using digi link system remote control, aim
the remote control at the REMOTE SENSOR
of this receiver.
However, to operate a Sherwood DVD player,
aim at the REMOTE SENSOR of the
corresponding component.
LOADING BATTERIES
•When the remote control does not operate, the old batteries should be replaced. In this case, load new batteries
within several minutes after removing old batteries.
•If the betteries are removed or have been exhausted for a longer period of time, memorized contents will be
cleared. Should this happen, you should memorize them again.
1
Remove the cover.
2
Load four alkaline batteries (“AAA”
size, 1.5V) matching the polarity.
+
+
+
• Remove the batteries when they are not used
for a long time.
• Do not use the rechargeable batteries (Ni-Cd
type).
• Be sure to use alkaline batteries.
19
ENGLISH
OPERATING COMPONENTS WITH REMOTE CONTROL
ENGLISH
USING FUNCTIONS OF REMOTE CONTROL
• This remote control can control up to 8 different components.
• Before operating audio and video components other than this receiver with using this remote control, the setup
code for each component should be entered.
• For system remote control operation, “000” was stored previously in the memory of the device button “CD” for
Sherwood CD player, “DVD” for Sherwood DVD player, “AUX” for Sherwood tape deck and “TV” for Sherwood TV
respectively as its factory setup code. So, you don’t need to enter its code for each Sherwood component except in
such a case that its code does not work.
Entering a setup code
• Setup code entry is the easiest way to program
this remote control for operating audio and
video components.
1
3
4
While “LEARN” is displayed, press the
CURSOR UP(▲)/DOWN(▼) buttons to
select the setup code mode (“CODE”),
then press the ENTER.
Turn on the component you want to
operate
Press and hold down both the ENTER
button and the desired one of the
DEVICE buttons for more than 2
seconds.
• Then “LEARN” is displayed on the LCD screen
for several seconds.
• Each time the CURSOR UP(▲)/DOWN(▼) buttons
are pressed, the mode changes as follows :
LEARN DELETE MACRO
CODE PUNCH
Notes:
• The AUDIO button is unavailable for the audio
components other than this receiver.
• During setting operation, to exit from the setting
mode, press any of the DEVICE buttons.
5
2
Find the setup codes according to the
type and the brand name of your
component, referring to “Setup Code
Table” on page 71.
• Then “PRESET” and 3 digit number are displayed.
• If “PRESET”, etc. go off, start again from the above
step ③.
While “PRESET”, etc. are displayed, enter a 3 digit code and press the ENTER button,
aiming the remote sensor on the component.
Example: When entering "001".
• Then “OK” is displayed on the LCD screen.
• To be sure that the setup code is correct, press the
POWER ON (or STANDBY) button.
• If the setup code is correct, your component will be
turned off.
• When your component is not turned off, repeat the
above steps ② to ⑤, trying entering each code for
your component until you find one that works.
• If “NG” is displayed, retry entering the correct
setup code while “PRESET” and 3 digit number
are displayed.
20
Operate the component using the corresponding function buttons.
• If any of buttons fails to operate as they should , start from the step ① again to enter the correct setup code.
Notes:
• Manufacturers may use different setup codes for the same product category. For that reason, it is important
that you check to see if the code you have entered operates as many controls as possible. If only a few
functions operate, check to see if another code will work with more buttons.
• When operating a Sherwood CD player or tape deck using the system remote control, aim the remote control
at the REMOTE SENSOR on this receiver.
However, in case of Sherwood DVD player and MD recorder, aim it at the REMOTE SENSOR on the
corresponding component.
Repeat the above steps ① to ⑥ for each of your other components.
7
Searching a setup code
2
• In addition to enter a setup code using “Setup
Code Table” on page 71, it is also possible to
search through all the codes that are stored in
the library of this remote control.
1
3
Turn on the component you want to
operate.
While “PRESET” is displayed, search a
setup code, aiming the remote control
at the remote sensor on the
component.
4
• Each time the CURSOR UP(▲)/DOWN(▼)
buttons are pressed, the setup code is selected
one by one.
• If the selected code is correct, your component
will be turned off.
• When your component is not turned off, repeat
this step until you find one that works.
5
Perform the steps ③ and ④ in
“Entering a setup code” procedure on
page 20 to select the setup code mode
(“CODE”).
While “PRESET” is displayed, press the
ENTER button to store the setup code.
• Then “OK” is displayed on the LCD screen.
Operate the component using the
corresponding function buttons.
6
• If any of buttons fails to operate as they
should, start from the step ① again to find the
correct setup code.
21
Repeat the above steps ① to ⑤ for
each of your other components.
ENGLISH
6
ENGLISH
Programing the commands from other
remote controls (LEARNING mode)
2
• If the setup codes are not available for your
component or you want to program a missing or
special function into one button of a device, the
learning function enables this remote control to
learn the commands from other remote controls.
1
Press and hold down the ENTER
button and the desired one of the
DEVICE buttons for more than 2
seconds.
Place this remote control and other
remote control facing each other at a
distance of 5 to 15 cm (2 to 6 inches )
apart.
• Then “LEARN” is displayed on the LCD screen
for several seconds
Note :
• During setting operation, to exit from the setting
mode, press any of the DIVICE buttons.
3
While “LEARN” is displayed, press the
ENTER button.
4
While “SEL” is flickering, on this remote
control, press the button corresponding
to the function to be learned.
Example: If the function to be learned is playback,
press the PLAY(▶) button.
• Then “SEL” is flickering.
• If “SEL” goes off, start again from the above
step ②.
5
• Then “READY” is displayed.
Note:
• You cannot program a function into some
buttons such as DEVICE, MACRO and LIGHT
buttons.
While “SEL” is flickering, repeat the
above steps ④ and ⑤ to program all
the commands you want to the buttons
on this remote control under the same
device mode.
To exit from the setting mode, press any of the
DEVICE buttons.
While “READY” is displayed, on the
other remote control, press the button
of the function to be learned.
6
• If the command has been learned successfully,
“OK” is displayed and then “SEL” is flickering.
• If “ERROR” is displayed and then “SEL” is
flickering, it means that for some reason the
command was not learned. In this case, repeat
the above steps ④ and ⑤.
Notes :
• If an incorrect signal has been sent or, in some
cases, the command from other remote control
simply cannot be learned.
• In some “ERROR” cases, the remote controls
just need to be moved closer together or
farther apart.
22
7
Repeat the above steps ① to ⑥ to
program the commands from a different
remote control.
8
Operate the newly programmed buttons
to make sure the learning function was
performed properly.
1
2
Perform the steps ③ and ④ in
“Entering a setup code” procedure on
page 20 to select the delecting mode
(“DELETE”).
While “BTTN” is displayed, press the
CURSOR UP(▲)/DOWN(▼) buttons to
select the one command deleting mode
(BTTN), then press the ENTER button.
• Then “BTTN” is displayed on the LCD screen
for several seconds.
3
While “SEL” is flickering, press the
button for the command you want to
erase.
• Each time the CURSOR UP(▲)/DOWN(▼)
buttons are pressed, “BTTN” or “LEARN”(all
command deleting mode) is selected.
• Then “SEL” is flickering.
• If “SEL” goes off, start again from the above
step ①.
Example: When the button for the command to be
erased is PLAY button.
4
While “SEL” is flickering, repeat the
above step ③ to erase other
commands.
• “OK” is displayed and then “SEL” is flickering.
Erasing all the commands
programmed under a device mode
1
2
Perform the steps ③ and ④ in
“Entering a setup code” procedure on
page 20 to select the deleting mode
(“DELETE”).
While “BTTN” is displayed, press the
CURSOR UP(▲)/DOWN(▼) buttons to
select the all command deleting mode
(“LEARN”), then press the ENTER
button.
• Then “BTTN” is displayed on the LCD screen
for several seconds.
3
While “SURE?” is displayed, press the
ENTER button
• Then “SURE?” is displayed .
• If “SURE?” goes off, start again from the
above step ①.
4
•Then all the commands programmed are erased.
23
To erase all the commands
programmed under other device mode,
repeat the above steps ① to ③ .
ENGLISH
Erasing the programmed command
from one button
ENGLISH
Programming a macro function
2
• The macro function enables you to program a
series of button operations(up to 15) on this
remote control into a single button.
• You can store up to three separate macro
command sequences into “M1”, “M2” and “M3”
buttons.
1
Perform the steps ③ and ④ in
“Entering a setup code” procedure on
page 20 to select the macro mode
(“MACRO”).
• Then “M1” is displayed on the LCD screen for
several seconds.
• During macro setting operation, pressing any of
the DEVICE buttons cannot exit from the macro
mode.
3
While “M1” is displayed, press the
CURSOR UP(▲)/DOWN(▼) buttons to
select the MACRO button to be
programmed into, then press the ENTER
button.
• Each time the CURSOR UP(▲)/DOWN(▼) buttons
are pressed, “M1”, “M2” or “M3” is selected.
• Then “SEL” is flickering.
• If “SEL” goes off, start again from the above
step ①.
While “SEL” is flickering, press the
operation buttons you want to program
in order.
4
Example: When playing a DVD on the DVD player
connected to VIDEO 2 jacks of this
receiver.
1. Press “AUDIO” button to control this receiver.
2. Press “POWER ON” button to turn this
receiver on.
3. Press “VIDEO 2(7)” button to select the
desired input source.
4. Press “DVD” button to control the DVD player.
5. Press “POWER ON” button to turn the DVD
player on.
6. Press “PLAY (▶)” button to start playback.
Press any of the MACRO buttons
(M1~M3) to complete the programming.
• Then “OK” is displayed.
To erase a macro program
• When erasing a macro program, perform the
above steps ①, ② and ④, but ignore the step ③.
To change a macro program
• When a new macro program is stored into a
MACRO button with performing the above steps
① to ④, the previous macro program is erased
from the memory of the MACRO button.
• Each time the operation buttons are pressed,
the programmed order is displayed.
Operating a macro function
Notes:
• The codes programmed into a MACRO button will
be transmitted at an interval of 0.5 seconds.
However, some components may not be able to
complete one operation in 0.5 seconds and may
miss the next code.
In this case, the macro function cannot control the
corresponding components correctly.
• Be sure to use the remote control within the
remote control operation range of the
components.
• Depending on the operation status of the
components, etc., the macro function cannot
control the corresponding components correctly.
• Aim the remote control at the REMOTE
SENSORs of the components to be controlled
and press the MACRO button you want.
Example: When pressing “M1” button.
24
2
• The punch-through function allows the volume
controls, channel controls or transport controls
to link to a different device while a device is
controlled with this remote control as a master
device.
• For example, since this receiver will likely be
used as the sound system while watching TV,
you may want to use volume controls to operate
this receiver although this remote control is set
to control the TV.
1
Perform the steps ③ and ④ in
“Entering a setup code” procedure on
page 20 to select a master device and
the punch -through mode (“PUNCH”).
• Each time the CURSOR UP(▲)/DOWN(▼)
buttons are pressed, the mode changes as
follows:
→ VOL : The volume punch -through mode
allows the “VOLUME ▲/▼” and
“MUTE” buttons to operate a different
device.
• Then “VOL” is displayed on the LCD screen for
several seconds.
3
While “VOL” is displayed, press the
CURSOR UP(▲)/DOWN(▼) buttons to
select the desired punch-through mode
, then press the ENTER button.
While the device is displayed, press the
CURSOR UP(▲)/DOWN(▼) buttons to
select the desired punch-through
device, then press the ENTER button.
DELETE : All punch-through deleting
mode.
PLAY : The transport punch-through mode
allows the “◀◀”, “●”, “▶▶”, “ ◀◀”, “ ”,
“▶▶ ”, “◀/ ” and “▶” buttons to
operate a different device.
→ CH : The channel punch-through mode
allows the “CHANNEL ∧/∨” and “CH.
LEVEL” buttons to operate a different
device.
• Each time the CURSOR UP(▲)/DOWN(▼)
buttons are pressed, depending on the selected
punch-through mode, punch-through devices
and the one punch-through deleting mode
(“DELETE”) are selected as follows :
• Then the device to which you can link the
selected punch-through mode is displayed.
4
• In case of the volume punch-through,
→ AUDIO
DELETE TV ←
• In case of the transport punch-through,
→ CD
DELETE DVD VCR AUX ←
• In case of the channel punch-through,
→ TV
DELETE SAT CABLE VCR ←
5
• Then “OK” is displayed and the current punchthrough mode is displayed.
25
While the punch-through mode is
displayed, repeat the above steps ②
and ③ to program other punch-through
function under the same master device
mode.
To program punch-through functions
under other master device mode,
repeat the above steps ① to ④.
ENGLISH
Programming a punch-through function
ENGLISH
Operating a punch-through function
• Then the punch-through device is displayed on
the LCD screen.
• While this remote control is set to control a
master device, aim the remote control at the
REMOTE SENSOR of the punch-through
device and press the desired button of the
programmed punch-through controls.
Example: When pressing “PLAY (▶)” button.
Erasing the programmed puch-through
function
1
2
Perform the steps ③ and ④ in
“Entering a setup code” procedure on
page 20 to select a master device and
the punch-through mode (“PUNCH”).
While “VOL” is displayed, press the
CURSOR UP(▲)/DOWN(▼) buttons to
select the punch-through mode to be
erased, then press the ENTER button.
• Then “VOL” is displayed on the LCD screen for
several seconds.
3
While the device is displayed, press
the CURSOR UP(▲)/DOWN(▼)
buttons to select the one punchthrough deleting mode(“DELETE”),
then press the ENTER button.
• Each time the CURSOR UP(▲)/DOWN(▼)
buttons are pressed, the mode changes as
follows:
→ VOL
DELETE PLAY CH ←
• Then the device is displayed .
4
• Each time the CURSOR UP(▲)/DOWN(▼)
buttons are pressed, depending on the
selected punch-through mode, the punchthrough devices and the deleting mode
(“DELETE”) are selected.
• Then “OK” is displayed and the current punchthrough mode is displayed .
5
26
While the punch-through mode is
displayed, repeat the above steps ②
and ③ to erase other punch-through
function under the same master device
mode.
To erase punch-through functions
under other master device mode,
repeat the above steps ① to ④.
1
2
Perform the steps ③ and ④ in
“Entering a setup code” procedure on
page 20 to select a master device and
the punch-through mode (“PUNCH”).
While “VOL” is displayed, press the
CURSOR UP(▲)/DOWN(▼) buttons to
select the all punch-through deleting
mode (“DELETE”).
• Then “VOL” is displayed on the LCD screen for
several seconds.
3
While “DELETE” is displayed, to erase
all the punch-through functions
programmed under the master device
mode, press ENTER button.
• Each time the CURSOR UP(▲)/DOWN(▼)
buttons are pressed, the mode changes as
follows:
→ VOL
DELETE PLAY CH ←
• Then “DELETE” is displayed .
4
• Then “OK” is displayed and “DELETE” is
displayed.
• To exit from the deleting mode, press any of the
DEVICE buttons.
27
To erase all the punch-through
functions programmed under other
master device mode , repeat the above
steps ① to ③.
ENGLISH
Erasing all the punch-through functions
programmed under a master device mode
ENGLISH
ROOM 2 Remote Controls
This remote control unit is an additional remote control unit for the ROOM 2 source playback only.
• You can use the ROOM 2 functions with this remote control unit more conveniently in another room than with
the universal remote control unit.
• For details on ROOM 2 operation, refer to "ROOM 2 SOURCE PLAYBACK" on page 46.
REMOTE CONTROL OPERATION RANGE
• Aim the ROOM 2 remote control(or the
universal remote control) at the IR receiver
installed in another room.(For details, refer to
“CONNECTING MULTI-ROOM SYSTEM KIT”
on page 13.)
• When you operate the ROOM 2 function in the
main room, aim the universal remote control
(or the ROOM 2 remote control) at the remote
sensor of this receiver.
LOADING BATTERY
1
Remove the cover.
2
Load the battery(CR2025) matching
the polarity.
• Remove the battery when it is not used for a long
time.
28
Notes:
• Before operating this receiver with the supplied remote control, refer to "Universal Remote Controls" on page 17
for details about operation.
• Before operating this receiver, first set this unit as desired for optimum performance, doing the OSD menu
setting procedures. (For details, refer to "OSD Menu Settings" on page 47.)
LISTENING TO A PROGRAM SOURCE
Select the desired input source.
3
Before operation
• Enter the standby mode.
• The POWER ON/STANDBY button
lights up in amber. This means that
the receiver is not disconnected from
the AC mains and a small amount of
current is retained to support the
operation readiness.
• To switch the power off, push the
POWER switch again.
Then the power is cut off and the POWER ON /
STANDBY button goes off.
• Each time the "AUDIO" button on the front panel
is pressed, the input source changes as follows:
→ CD → AUX → TAPE
In the standby mode, turn the power on.
1
• Each time the "VIDEO" button on the front panel
is pressed, the input source changes as follows:
→ VIDEO 1 → VIDEO 2 → - - - → VIDEO 5
• Each time the "BAND" button is pressed, the
band changes as follows:
→ FM STEREO → FM MONO → AM → XM
• Each time the POWER ON/STANDBY button on
the front panel is pressed, the receiver is turned on
to enter the operating mode (the POWER ON/
STANDBY button lights up in blue) or off to enter
the standby mode(the POWER ON/STANDBY
button lights up in amber).
• On the remote control, press the POWER ON
button to enter the operating mode or press the
STANDBY button to enter the standby mode.
• In the standby mode, if the INPUT SELECTOR
button is pressed, the receiver is turned on
automatically and the desired input is selected.
2
When selecting the EXTERNAL IN as desired,
Switch the desired front
speakers on.
• Depending on the power amplifier setting for the
surround back channels and the surround back
speaker setting, "EXT. IN" is displayed and 8(/7/6)
separate analog signals from the component
connected to this input pass through the tone and
volume circuits only and can be heard from your
speakers.
• Press the EXTERNAL IN button or select the
desired input source to cancel the external in
function.
• These analog signals can be heard only, not
recorded.
• Each time this button is pressed, the speaker
mode changes as follows and the sound can
be heard from the speakers connected to the
selected front speaker terminals:
• When using the headphones for private listening, select the
Off mode to switch off the front speakers and all the others.
29
ENGLISH
Operations
ENGLISH
When CD, AUX, VIDEO 1~ 5 is selected as an input source
4
Select the digital or the analog input connected as desired.
• Each time this button is pressed, the
corresponding input is selected as follows:
■Notes:
• When TUNER, TAPE or EXTERNAL IN is selected as an input source, the digital input cannot be selected.
• When the selected digital input is not connected, the “DIG.” indicator flickers and the analog input is
automatically selected.
• The selected digital or analog input is automatically assigned to the corresponding input source on the
INPUT SETUP menu. (For details, refer to "SETTING THE INPUT SETUP" on page 52.)
• The sound from the component connected to the selected digital input can be heard regardless of the
selected input source.
5
Operate the selected component for
playback.
Adjust the (overall) volume.
6
• When playing back the program sources with
surround sound, refer to “ENJOYING
SURROUND SOUND” on page 34.
Listening with headphones
Muting the sound
• "MUTE" flickers.
• To resume the previous sound level, press it again.
30
• Ensure that the SPEAKER button is set to off.
• Depending on the signal format which is being
input, you can listen in different Dolby
Headphone modes, stereo mode, etc. (For
details, refer to "Listening in a Dolby Headphone
mode" on page 35).
• When the EXTERNAL IN is selected as an input
source, only front left and front right channel
signals can be reproduced through the
headphones.
• The PURE AUDIO indicator lights up,
the fluorescent display goes off and all the videorelated circuits are turned off, meaning no video
signal transfer.
• When the pure audio is activated, the optimum
surround mode (or stereo mode, etc.) will be
automatically selected depending on the signal
format being input.
• Press this button again to cancel the pure audio
function.
31
ENGLISH
Achieving higher purity of sound quality
SURROUND SOUND
ENGLISH
• This receiver incorporates a sophisticated Digital Signal Processor that allows you to create optimum sound quality and sound
atmosphere in your personal Home Theater.
Surround modes
■DTS Digital Surround
• DTS Neo : 6 Cinema
This mode is optimum for playing movies. Decoding is
performed with emphasis on separation performance to
achieve the same atmosphere with 2-channel sources as with
6.1-channel sources.
DTS Digital Surround(also called simply DTS) is a multi-channel
digital signal format which can handle higher data rates. Discs
bearing the “
” include the recording of up to
5.1 channels of digital signals, which can be generally thought
to provide better sound quality due to the lower audio
compression required.
It also provides wide dynamic range and separation, resulting
in magnificent sound.
■DTS - ES Extended Surround™
(
• DTS Neo : 6 Music
This mode is suited mainly for playing music. The front left
and front right signals bypass the decoder and are played
directly so there is no loss of sound quality, and the effect of
the surround signals from the center, surround left, surround
right and surround back channels adds a natural sense of
expansion to the sound field.
)
This is a new multi channel digital signal format which greatly
improves the 360- degree surround impression and space
expression thanks to further expanded surround signals,
offering high compatibility with the conventional DTS format.
In addition to the 5.1 channels, DTS-ES Extended Surround
also offers the surround back (sometimes also referred to as
“surround center”) channel for surround playback with a total
of 6.1 channels. DTS-ES Extended Surround includes two
signal formats with different surround signal recording
methods as follows:
■DTS 96/24
Conventional surround formats used sampling frequencies of
48 or 44.1 kHz, so 20 kHz was about the maximum playback
signal frequency. With DTS 96/24, the sampling frequency is
increased to 96 or 88.2 kHz to achieve a wide frequency
range of over 40 kHz. In addition, this format has a resolution
of 24 bits, resulting in the same frequency band and dynamic
range as 96kHz / 24 bit PCM signals.
As with conventional DTS surround, DTS 96/24 is compatible
with a maximum of 5.1 channels. DTS 96/24 is fully
compatible with the conventional DTS surround format, so
DTS 96/24 sources can be played using a conventional DTS
5.1 channel decoder.
• DTS-ES™ Discrete 6.1
Because the signals for 6.1 channels (including the surround back
channel) are fully independent, it is possible to achieve a sense
that the acoustic image are moving about freely among the
background sounds surrounding the listener from 360 degrees.
Though maximum performance is achieved when sound
tracks recorded with this system are played using a DTS -ES
decoder, when played with a conventional DTS decoder, the
surround back channel signals are automatically downmixed
to the surround left and surround right channels so that none
of the signal components are lost.
“DTS”, “DTS-ES”, “Neo:6” and “DTS 96/24” are trademarks
of Digital Theater Systems, Inc.
■Dolby Digital
Dolby Digital is the multi- channel digital signal format
developed by Dolby Laboratories. Discs bearing the
“
” includes the recording of up to 5.1 channels of
• DTS - ES™ Matrix 6.1
With this format, the additional surround back channel
signals undergo matrix encoding and are input to the
surround left and surround right channels beforehand. During
playback, they are decoded to the surround left, surround
right and surround back channels.
Because the bit stream format is 100% compatible with
conventional DTS signals, the effect of the DTS-ES Matrix 6.1
format can be achieved even with DTS 5.1- channel signal
sources. Of course, it is possible to play DTS-ES Matrix 6.1 channel signal sources with a DTS 5.1 - channel decoder.
When DTS-ES Discrete 6.1 or Matrix 6.1 sources are decoded
with a DTS - ES decoder, the format is automatically detected
upon decoding and the optimum surround mode is selected.
However, some DTS - ES Matrix 6.1 sources may be detected
as DTS sources. In this case, the DTS - ES Matrix mode
should be selected manually to play these sources.
digital signals, which can reproduce much better sound
quality, spatial expansion and dynamic range characteristics
than the previous Dolby Surround effect.
■Dolby Digital EX
This mode creates the back (sometimes also referred to as
“surround center”) signals from the surround left and right
signals in Dolby Digital 5.1 channel source using a matrix
decoder and provides 6.1 channel surround playback. For the
best results, this mode should be selected during playback of
sources(bearing the “
”) recorded in Dolby Digital
EX. With this additional channel, you can experience more
dynamic and realistic moving sound especially.
When Dolby Digital EX sources are decoded with a Dolby
Digital EX decoder, the format is automatically detected upon
decoding and the Dolby Digital EX mode is selected.
However, some Dolby Digital EX sources may be detected as
Dolby Digital sources. In this case, the Dolby Digital EX mode
should be selected manually to play these sources.
DTS Neo : 6™ surround
This mode applies conventional 2-channel signals such as
digital PCM or analog stereo signals to the high precision digital
matrix decoder used for DTS-ES Matrix 6.1 to achieve 6.1channel surround playback. DTS Neo : 6 surround includes two
modes for selecting the optimum decoding for the signal source.
32
■Dolby Pro Logic IIx surround
• Dolby Virtual Speaker Wide
The width of the front sound image seems to extend beyond
the front speakers.
• Dolby Pro Logic IIx Movie
When enjoying movies, this mode allows you to further
enhance the cinematic quality by adding processing that
emphasizes the sounds of the action special effects.
■Dolby Headphone
The Dolby Headphone function simulates 5.1 channel
surround sound , which allows you to enjoy 5.1 channel
surround sound through 2 channel headphones, just like
listening from 5.1 channel speakers.
This mode is effective not only for 5.1 channel sources but
also for stereo ( 2 channel ) sources.
• Dolby Pro Logic IIx Music
When listening to music, this mode allows you to further
enhance the sound quality by adding processing that
emphasizes the musical effects.
Manufactured under license from Dolby Laboratories.
“Dolby”, “Pro Logic” and the double-D symbol are trademarks
of Dolby Laboratories.
• Dolby Pro Logic IIx Game
When playing games, this mode allows you to further
enhance the dynamic surround effects by adding processing
that emphasizes the surrounded and exciting sound.
• The following modes apply conventional 2-channel signals
such as digital PCM or analog stereo signals to high
performance Digital Signal Processor to recreate sound
fields artificially. Select one of the 3 provided surround
modes according to the program source you want to play.
■Dolby Pro Logic II surround
This mode applies conventional 2-channel signals such as
digital PCM or analog stereo signals as well as Dolby
Surround signals, etc. to surround processing to offer
improvements over conventional Dolby Pro Logic circuits.
Dolby Pro Logic II surround includes Dolby Pro Logic II Movie,
Dolby Pro Logic II Music and Dolby Pro Logic II Game like
Dolby Pro Logic IIx surround.
■Theater
This mode provides the effect of being in a movie theater
when watching a play.
■Hall
This mode provides the ambience of a concert hall for
classical music sources such as orchestral, chamber music or
an instrumental solo.
■Dolby Virtual Speaker
This mode creates a virtual surround sound field using as few
as two front speakers, allowing you to experience listening
from 5.1 channel speakers.
This mode is effective not only for 5.1 channel sources but
also for stereo(2 channel) sources.
Dolby VIrtual Speaker includes two listening mode as follows:
■Stadium
This mode provides the expansive sound field to achieve the
true stadium effect when watching baseball or soccer games.
• When using the EXTERNAL INs to play back the sound from the additional multi-channel decoder for surround sound, you can
enjoy the corresponding surround sound, too.( For details, refer to the operating instructions of the component to be
connected.)
For your reference, the sound from each channel can be reproduced according to the surround modes as follows:
Modes
Channels
FRONT L/R
CENTER
SURROUND L/R
SURROUND BACK L/R
SUBWOOFER
—
DTS, DTS 96/24
DTS ES DISCRETE/MATRIX
—(*)
DTS NEO: 6 CINEMA/MUSIC
—
DOLBY DIGITAL
DOLBY DIGITAL EX
DOLBY PRO LOGIC IIx MOVIE/MUSIC/GAME
DOLBY PRO LOGIC II MOVIE/MUSIC/GAME
—
DOLBY VIRTUAL SPEAKER
—
—(*)
Other Surrounds
STEREO
—(*)
—
—
—
—(*)
EXTERNAL IN
(*): Depending on the subwoofer setting, the sound from the subwoofer channel may be reproduced.
• Depending on the speaker settings and the number of the encoded channels, etc., the sound from the corresponding channels
cannot be reproduced.(For details, refer to "SETTING THE SPEAKER / ROOM EQ SETUP" on page 55.)
33
ENGLISH
• Dolby Virtual Speaker Reference
The width of the front sound image is defined by the actual
distance between front speakers.
Dolby Pro Logic IIx decodes all stereo (2 channel ) and 5.1
channel sources and extends to 7.1channel surround
playback. It delivers the most natural, full range and
immersing 7.1 channel listening experience. Dolby Pro Logic
IIx surround includes three modes as follows :
ENGLISH
ENJOYING SURROUND SOUND
Notes:
• Before surround playback, first perform the speaker setup procedure, etc. on the OSD menu for optimum performance.
(For details, refer to "SETTING THE SPEAKER/ROOM EQ SETUP" on page 55.)
• When playing digital signals from the Dolby Digital program source or selecting the surround mode such as Dolby Pro Logic II
/Dolby Pro Logic IIx Music, Dolby Headphone, Dolby Virtual Speaker modes, you can adjust their parameters for optimum
surround effect. (For details, refer to "SETTING THE SOUND PARAMETER" on page 64.)
• When the EXTERNAL IN is selected as an input source, the surround modes cannot be selected.
Depending on how to select a surround mode, select the auto surround mode or the manual surround mode.
• Each time this button is pressed, the mode changes as
follows :
Auto surround mode : The optimum surround mode will be
("AUTO" lights up.)
automatically selected depending on the signal
format being input.
Manual surround mode : You can select the desired of different
('AUTO" goes off.)
surround modes selectable for the signal
being input with using the MULTI
CONTROL knob or the SURROUND MODE
UP/DOWN ( ›/‹ ) buttons.
■Notes :
• When the SPEAKER button is set to off, the auto surround mode is invalid.
• Even when the auto surround mode is selected and the same type of digital signal format is being input,
the optimum surround mode may vary depending on whether the speaker type is set to "NONE" or not.
• When the auto surround mode is selected and the PCM (2 channel) digital signal or the analog stereo
signal is being input, only the stereo mode will be selected.
• When the auto surround mode is selected, the surround modes other than the optimum surround mode
cannot be selected.
■When selecting the manual surround mode with pressing the SURROUND MODE button on the front
panel.
Select the desired surround mode.
• Each time the MULTI CONTROL knob is rotated or
the SURROUND MODE UP / DOWN ( >/< ) buttons
are pressed, the surround mode changes depending
on the input signal format as follows :
Signal format being input
Dolby Digital EX 6.1 channel sources,
Dolby Digital 5.1 channel sources
Dolby Digital 2 channel sources
DTS ES Discrete/Matrix 6.1 channel
sources
DTS sources
DTS 96/24 sources
96 kHz PCM (2 channel) sources
PCM (2 channel) sources,
Analog stereo sources
Selectable surround mode
<DOLBY DIGITAL EX, DOLBY D + PLIIx MUSIC>, (DOLBY D + PLIIx MOVIE),
DOLBY DIGITAL, DOLBY VS REFERENCE, DOLBY VS WIDE
<DOLBY PLIIx MOVIE, DOLBY PLIIx MUSIC, DOLBY PLIIx GAME>, [DOLBY PLII MOVIE,
DOLBY PLII MUSIC, DOLBY PLII GAME], DOLBY VS REFERENCE, DOLBY VS WIDE
<corresponding DTS ES mode, DTS + PLIIx MUSIC>, (DTS + PLIIx MOVIE), DTS,
DOLBY VS REFERENCE, DOLBY VS WIDE
DTS, DOLBY VS REFERENCE, DOLBY VS WIDE, <DTS + NEO:6, DTS + PLIIx MUSIC>,
(DTS + PLIIx MOVIE)
DTS 96/24, DOLBY VS REFERENCE, DOLBY VS WIDE
<DOLBY PLIIx MOVIE, DOLBY PLIIx MUSIC, DOLBY PLIIx GAME>, [DOLBY PLII MOVIE,
DOLBY PLII MUSIC, DOLBY PLII GAME], NEO:6 CINEMA, NEO:6 MUSIC,
THEATER, HALL, STADIUM
<DOLBY PLIIx MOVIE, DOLBY PLIIx MUSIC, DOLBY PLIIx GAME>, [DOLBY PLII MOVIE,
DOLBY PLII MUSIC, DOLBY PLII GAME], DOLBY VS REFERENCE, DOLBY VS WIDE,
NEO:6 CINEMA, NEO:6 MUSIC, THEATER, HALL, STADIUM
• Depending on surround back speaker setting, some surround modes can be selected or not as follows:
< >: Possible only when surround back speaker is not set to "NONE".
[ ] : Possible only when surround back speaker is set to "NONE".
( ): Possible only when surround back speaker is set to " 2CH".
34
Continued
• Depending on the signal format which is being input, either the
stereo mode or the 2CH downmix mode is selected.
• To cancel either the stereo mode or the 2CH downmix mode,
select the surround mode with using the MULTI CONTROL knob
on the front panel or the SURROUND MODE UP/DOWN ( >/< )
buttons on the remote control.
2CH downmix mode
• This mode allows the multi-channel signals encoded in DTS or Dolby Digital format to be mixed down into 2 front
channels and to be reproduced through only two front speakers or through headphones.
• When the SPEAKER button is set to off to listen with headphones, if the STEREO button is pressed while playing
the multi-channel digital signals from DTS or Dolby Digital sources, it will enter the 2CH downmix mode
automatically.
• To cancel the 2CH downmix mode, select the desired Dolby Headphone mode with using the MULTI CONTROL
knob on the front panel or the SURROUND MODE UP/DOWN ( >/< ) buttons on the remote control.
Listening in a Dolby Headphone mode
• The Dolby Headphone function simulates 5.1 channel surround sound, which allows you to enjoy 5.1 channel
surround sound through 2 channel headphones, just like listening from 5.1 channel speakers.
Notes :
• Only when the SPEAKER button is set to off, the Dolby Headphone mode can be selected.
• When playing the 96 kHz PCM(2 channel) digital signals, only the stereo mode can be selected.
• While listening with headphones, select the desired Dolby Headphone mode.
• Each time the MULTI CONTROL knob is rotated or the SURROUND
MODE UP/DOWN ( >/< ) buttons are pressed, the mode changes as
follows :
: This simulates the soundfield as if you were in a relatively
small room with less reverberations.
: This simulates the soundfield as if you were in a typical
listening room with moderate reverberations.
: This simulates the soundfield as if you were in a large space
like theater.
Adjusting each channel level with test tone
• The volume level of each channel can be adjusted easily with the test tone function.
Note : When the SPEAKER button is set to off, the test tone function does not work.
• The test tone will be heard from the speaker of each
Enter the test tone mode.
channel for 2 seconds as follows:
1
Front Left
Subwoofer
Front Right
Surround Left
Surround Back
Surround Right
Surr.Back Left
Surr.Back Right
• When the speaker setting is "NONE" or "NO", the test tone
of the corresponding channel is not available.
• ( ) : Possible depending on whether the surround
back channel is set to "2 CH" or "1 CH".
2
At each channel, adjust the level as
desired until the sound level of each
speaker is heard to be equally loud.
Cancel the test tone function.
3
• You can select the desired channel with pressing the
CONTROL UP/DOWN (▲/▼) buttons or the CURSOR
UP/DOWN (▲/▼) buttons.
35
ENGLISH
To cancel the surround mode for stereo operation
ENGLISH
Adjusting the current channel level
• After adjusting each channel level with test tone, adjust the channel levels either according to the
program sources or to suit your tastes.
• You can adjust the current channel levels as desired. These adjusted levels are just memorized into
user’s memory ("CALIBRATE"), not into preset memory("REFERENCE 1", "REFERENCE 2").
1
Press the CHANNEL LEVEL button.
• Then the memory mode ("CALIBRATE" or
"REFERENCE 1") is displayed for several
seconds.
• When the memory mode or channel level
disappears, press this button again.
Select the desired channel.
2
• Each time these buttons are pressed, the corresponding
channel is selected as follows:
DTS LFE or Dolby Digital LFE
( ): Possible depending on whether the surround back channel is set to "2
CH" or "1 CH".
< >: Possible only when the digital signals from Dolby Digital or DTS
program sources that include LFE signal are input.
• Depending on the speaker settings("NONE" or "NO" , etc.) and surround mode, etc., some channels
cannot be selected.
• When the SPEAKER button is set to off, only the Front Left and Front Right channels can be selected.
Adjust the level of the selected channel as desired.
3
4
• The LFE level can be adjusted within the range of
-10~0 dB and other channel levels within the
range of -15~+15 dB.
• In general, we recommend the LFE level to be
adjusted to 0 dB.(However, the recommended
LFE level for some early DTS software is -10 dB.)
If the recommended levels seem too high, lower
the setting as necessary.
Repeat the above steps ② and ③ to adjust each channel level.
36
Memorizing the adjusted channel levels
1
2
After performing the steps ①~④ in "Adjusting the current channel level" procedure on page 36,
press the (MEMORY/) ENTER button.
• The "1" of "REFERENCE 1" indication flickers for
several seconds.
Select the desired one of REFERENCE 1
and REFERENCE 2.
Confirm your selection.
3
• The adjusted channel levels have now been
memorized into the selected memory.
• If the preset memory disappears, perform the
above step ① again.
Recalling the memorized channel levels
Press the CHANNEL LEVEL button.
1
2
Select the desired one of REFERENCE 1
and REFERENCE 2.
• Then the channel levels memorized into the
selected preset memory are recalled.
• "REFERENCE 1" (or "CALIBRATE") is
displayed for several seconds.
• If the channel level mode display disappears,
press this button again.
37
ENGLISH
• You can memorize the adjusted channel levels into preset memory("REFERENCE 1", "REFERENCE 2")
and recall the memorized whenever you want.
ENGLISH
LISTENING TO RADIO BROADCASTS
Auto tuning
Select the desired band.
1
• Each time this button is pressed, the band
changes as follows :
→ FM STEREO → FM MONO → AM → XM
• When FM stereo broadcasts are poor because of
weak broadcast signals, select the FM mono
mode ("STEREO" goes off) to reduce the noise,
then FM broadcasts are reproduced in monaural
sound.
• To listen to XM Satellite Radio, select XM mode.
(For details, refer to "XM Satellite Radio (only for
North America)" on page 40.)
Press the TUNING UP(+)/DOWN(-) buttons for more than 0.5 second.
2
• The tuner will now search until a station of
sufficient strength has been found. The display
shows the tuned frequency and "TUNED".
• If the station found is not the desired one, simply
repeat this operation.
• Weak stations are skipped during auto tuning.
Manual tuning
Auto presetting
• Manual tuning is useful when you already
know the frequency of the desired station.
• After selecting the desired band, press the
TUNING UP(+) / DOWN(-) buttons repeatedly
until the right frequency has been reached.
• Auto presetting function automatically searches
for FM stations only and store them in the
memory.
• While listening to radio broadcasts, press and hold
down the MEMORY/ENTER button for more than
2 seconds.
• Then "AUTO MEMORY" flickers
and this receiver starts auto
presetting.
• Up to 30 FM stations can be
stored.
Notes:
• FM stations of weak strength
cannot be memorized.
• To memorize AM stations or weak stations,
preform "Manual presetting" procedure with using
"Manual tuning" operation.
• In the XM mode, auto presetting doesn't work.
38
Press the MEMORY/ENTER button.
Manual presetting
2
1
ENGLISH
• You can store up to 30 preferred stations in the
memory.
Tune in the desired station with auto or
manual tuning.
• "MEMORY" is flickering for several seconds.
3
Select the desired preset number (1~30)
and press the MEMORY/ENTER button.
4
Repeat the above steps ① to ③ to
memorize other stations.
MEMORY BACKUP FUNCTION
The following items, set before the receiver is
turned off, are memorized.
• INPUT SELECTOR settings
• Surround mode settings
• Preset stations,etc.
• The station has now been stored in the memory.
• A stored frequency is erased from the memory by
storing another frequency in its place.
• If "MEMORY" goes off, start again from the above
step ②.
Tuning to preset stations
Scanning preset stations in sequence
• After selecting the tuner as an input source, select
the desired preset number.
• The receiver will start scanning the stations in the
preset sequence and each station is received for 5
seconds.
• At the desired station, press this button again to
stop scanning.
39
XM Satellite Radio (only for North America)
ENGLISH
• This receiver is the XM ReadyⓇ receiver. You can receive XM Satellite RadioⓇ by connecting to the XM
Connect-and-PlayTM (sold separately) and subscribing the XM service.
What's XM Satellite Radio?
XM offers 170 digital channels with 69 commercial-free music channels.
XM, the nation's leading satellite radio service, launched nationwide on November 12, 2001.
Note :
"XM ReadyⓇ Products" : An XM Ready product is a product that has incorporated minimal technology to
support the XM Service via an external/receiver chipset such as XMDirectⓇ or XM Connect-and-PlayTM
antenna, which are sold separately. XM Ready products do not have the full XM receiver functionality into the
main product configuration but require the addition of an off-board receiver accessory to make a complete XM
Radio System.
A warning against reverse engineering
It is prohibited to copy, decompile, disassemble, reverse engineer, or manipulate any technology incorporated
in receivers compatible with the XM Satellite Radio system.
XM $12.95 monthly service subscription sold separately. XM Passport system required to receive XM service
sold separately. Installation costs and other fees and taxes, including a one-time activation fee may apply.
Subscription fee is consumer only. All fees and programming subject to change. Channels with frequent explicit
language are indicated with an XL. Channel blocking is available for XM radio receivers by calling 1-800XMRADIO. Subscriptions subject to Customer Agreement available at xmradio.com. XM service only available
in the 48 contiguous United States. XM Ready is trademarks of XM Satellite Radio Inc. ⓒ2006 XM Satellite
Radio Inc. All rights reserved.
LISTENING TO XM SATELLITE RADIO
2
Signing up for XM Satellite Radio
Press the TUNING UP(+)/DOWN(-)
buttons repeatedly to select XM CH 000.
• Before using XM Satellite Radio, you must first
sign up for an account. You will need a major
credit card and your XM Satellite Radio ID,
which you can get from this receiver as
explained below.
1
Press the BAND button repeatedly to
select XM mode.
• Then your XM Satellite Radio ID is displayed.
3
• Then XM CH ~ is displayed.
40
To sign up, access the website at
"http://activate.xmradio.com" or call
"1-800-967-2346".
Channel search
• The channel changes continuously when you
press and hold the TUNING button.
Direct search
• Direct search is useful when you already know
the channel number.
1
2
In the XM mode, select the direct
search mode.
While displaying "DIRECT SEARCH",
select the desired channel number with
pressing the NUMERIC (0 ~ 9) buttons.
Examples :
For "3" :
For "27" :
For "124" :
• When "DIRECT SEARCH" disappears, repeat
again from the above step ①.
• Each time this button is pressed, the search mode
changes as follows:
→DIRECT SEARCH→ CATegory search → OFF
Note:
• When using channel search or preset search, press
this button to select the search off.
Category search
2
• Category search allows you to select the desired
channel by the selected category.
1
While displaying "CAT : ~ ", select the
desired category, then press the
ENTER button.
In the XM mode, select the category
search mode.
• Each time these buttons are pressed, one of
different categories is selected.
• When "CAT : ~ " disappears, repeat again from
the above step ①.
• "CAT : ~ " is displayed.
41
ENGLISH
• In the XM mode, press the TUNING UP (+)/DOWN (-) buttons repeatedly to select the desired channel.
Continued
Select the desired channel in the selected category.
ENGLISH
3
Presetting channels
Preset search
• You can store up to 30 preferred channels in
the memory.
1
2
• In the XM mode, select the desired preset channel.
Select the desired channel with
preforming channel search, direct
search or category search.
To memorize the channels, perform the
steps ② to ④ in "Manual presetting"
procedure on page 39.
Displaying XM information
• Each time the DISPLAY button is pressed, the
display mode changes as follows:
→ Channel → Artist → Song → Category
name
name
title
• You can display XM information such as channel
name, artist name, song title and signal strength.
• In the XM mode,
OFF
←
(Surround mode
display)
Signal
strength
←
Note:
• If the information on artist name, song title or
category is not available, it will not be displayed
correctly.
Signal strength display mode
• If the reception is poor, you can check the signal
strength of the XM radio signal and adjust the
position of the XM antenna until "SIGNAL :
GOOD" is displayed.
Error message and status
• If an operation takes longer than usual or an error occurs, one of the following messages may be displayed.
Message
CHECK ANTENNA
UPDATING
NO SIGNAL
LOADING
OFF AIR
Status
The XM antenna is not connected correctly. Check the antenna.
The XM user encryption code is being updated. Please wait.
The signal is too weak. Check the antenna connection and reposition it for the
best reception.
This receiver is tuning or decoding audio or text data. Please wait.
The selected XM channel is not currently broadcasting. Select another channel.
42
• The analog signals from the EXTERNAL INs as well as the digital signals from the coaxial or optical digital input can be heard
but cannot be recorded.
• When recording the analog signals from CD, AUX, VIDEO 1~5, be sure to select the analog input.
(For details, refer to "When CD, AUX, VIDEO 1~5 is selected as an input source" on page 30.)
• The volume and tone (bass, treble) settings have no effect on the recording signals.
Recording with TAPE
1
Start recording on the TAPE.
Select the desired input as a recording
source except for TAPE.
2
Start play on the desired input.
3
Start recording on the VIDEO 1.
Dubbing from video components onto
VIDEO 1
1
2
Select the desired of VIDEO 2 ~ 5 as a
recording source except VIDEO 1.
Start play on the desired input.
3
• The audio and video signals from the desired
input will be dubbed onto the VIDEO 1 and you
can enjoy them on the TV set and from the
speakers.
Dubbing the audio and video signals
separately onto VIDEO 1
2
Example: When dubbing the VIDEO 2 video signal and
the CD audio signal separately onto VIDEO 1.
1
Select VIDEO 2 as a video recording
source.
43
Select CD as an audio recording
source.
ENGLISH
RECORDING
Start recording on the VIDEO 1.
4
ENGLISH
3
Start play on the VIDEO 2 and the CD
respectively.
• The audio signal from the CD and the video
signal from the VIDEO 2 will be dubbed and
you can enjoy them on the TV set and from the
speakers.
Note : Be sure to observe the order of the
above steps ① and ②.
DIGITAL AUDIO RECORDING WITH MD RECORDER
• Only when the OPTICAL DIGITAL OUT of this receiver is connected to the OPTICAL DIGITAL IN of the MD recorder or CD
recorder, you can enjoy high-quality sound of digital recording without converting the original signals. Refer to "CONNECTING
VIDEO COMPONENTS", "CONNECTING AUDIO COMPONENTS" and "CONNECTING DIGITAL INS and OUT" on pages
6~8 and the operating instructions of the MD recorder or CD recorder.
Notes:
• Digital recording is available for the digital audio program sources such as CDs, MDs, some DVDs, etc.
• In most DVDs as well as some CDs, etc., digital recording may not be available depending on the signal format.
• There are some restrictions on recording digital signals. When making digital recordings, refer to the operating instructions of
your digital recording equipment to know what restrictions are imposed.
1
Select the desired of CD, AUX, VIDEO
1~5 as a recording source.
2
For digital recording, select the digital
input as recording signal input.
Note :
• When the digital signals are not input from the
selected digital input, there will be no recording.
(For details, refer to "When CD, AUX, VIDEO 1~ 5
is selected as an input source" on page 30 or
"When selecting the DIGITAL AUDIO" on page
52.)
3
Start play on the desired input.
Start recording on the component
connected to the OPTICAL DIGITAL
OUT.
4
44
Operating the sleep timer
Adjusting the brightness of the
fluorescent displays
• The sleep timer allows the system to continue
to operate for a specified period of time before
automatically shutting off.
• To set the receiver to automatically turn off
after the specified period of time.
• Each time this button is pressed, the
brightness of all fluorescent displays of
Sherwood components connected by the DIGI
LINK III changes together as follows:
• Each time this button is pressed, the sleep time
changes as follows:
→ ON → dimmer → OFF
→ 10 → 20 → 30 → --- → 90 → OFF
Unit : minutes
• In the display OFF mode, pressing any button
will cancel the display OFF mode for several
seconds to display the operation status.
• While operating the sleep timer, "
" lights up.
• When the sleep time is selected, all display
panels of Sherwood components connected by
the DIGI LINK III are dimly lit.
Displaying the audio information
• You can check the audio information of the input source other than tuner on your monitor TV.
• During playback,
• Depending on whether the input signal is digital or
analog signal, the corresponding information is
displayed for several seconds.
Example : When playing the digital signals from the
Dolby Digital source.
45
ENGLISH
OTHER FUNCTIONS
ENGLISH
ROOM 2 SOURCE PLAYBACK
• This function allows enjoying one source in the main room and playing another in a different room at the same time.
• When you connect the multi-room system kit to the IR IN jack of this receiver, you can control this receiver with not only the
universal remote control unit but also the ROOM 2 remote control unit in a different room, too. (For details, refer to
"CONNECTING MULTI-ROOM SYSTEM KIT" on page 13 and "ROOM 2 Remote Controls" on page 28.)
Notes:
• The analog signals from the EXTERNAL INs and the digital signals cannot be output to the different room, meaning no
playback in a different room.
• You cannot play the ROOM 2 source in any surround mode.
■When using the buttons on the front panel.
■When using the buttons on the remote control unit.
Press the ROOM 2 button.
1
1
Press the ROOM 2 button to enter the
ROOM 2 mode.
• ROOM 2 ~ is displayed for several seconds.
• When the ROOM 2 setting mode disappears,
press the ROOM 2 button again.
• ROOM 2 ~ is displayed for several seconds.
• Each time this button is pressed, the ROOM 2 mode
changes as follows :
ON : To turn on the ROOM 2
function. ("
" lights up.)
OFF : To turn it off. ("
" or "
"
goes off depending on the AMP ASSIGN setting.)
Note :
• When the ROOM 2 mode is set to OFF, you cannot
adjust the ROOM 2 volume.
2
• Each time these buttons are pressed,
the mode changes as follows :
ROOM 2 ~
: To turn on or
(ROOM 2 mode) off the ROOM 2
function.
INPUT ~
: To select the desired
(ROOM 2 input)
ROOM 2 source.
Select the desired input as a ROOM 2 source.
2
VOLUME ~
: To adjust the volume on the power
(ROOM 2 volume) amplifier assigned to ROOM 2.
Note : When the ROOM 2 mode is set to OFF,
the ROOM 2 input and the ROOM 2 volume
cannot be selected
• Each time the INPUT button
on the universal remote
control unit is pressed, the
ROOM 2 input can be
selected among MAIN
source, TUNER, CD, AUX,
TAPE, VIDEO 1 ~ VIDEO 5.
3
Adjust the ROOM 2 volume.
3
• You can adjust the volume on the power amplifier
assigned to ROOM 2 when the SURROUND BACK/
ROOM 2 speaker terminals are connected to the
speakers in a different room. (For details, refer to "When
selecting the AMP ASSIGN" on page 49.)
• The MUTE button on the ROOM 2 remote control unit can
be available only when the ROOM 2 function is operating.
4
Select the desired mode while displaying
the ROOM 2 setting mode.
■When selecting the ROOM 2 mode.
ON : To turn on the ROOM 2 function.
("
" lights up.)
OFF : To turn it off. ("
" or "
" goes off
depending on the AMP ASSIGN setting.)
■When selecting the ROOM 2 input.
• You can select the desired among MAIN source,
TUNER, CD, AUX, TAPE, VIDEO 1 ~ VIDEO 5 as a
ROOM 2 source.
■When selecting the ROOM 2 volume.
• You can adjust the volume on the power amplifier
assigned to ROOM 2 when the SURROUND BACK/
ROOM 2 speaker terminals are connected to the
speakers in a different room. (For details, refer to "When
selecting the AMP ASSIGN" on page 49.)
4
Start play on the component related to the
ROOM 2 source.
Set the selected mode as
desired.
Start play on the component related to the
ROOM 2 source.
Notes:
• When the EXTERNAL IN is selected as a main input, if the MAIN source is selected as a ROOM 2 input, no audio signals
can be heard in the different room (ROOM 2).
• Even when this receiver enters the standby mode, in such a case that "
" lights up still and the POWER
ON/STANDBY button lights up in blue as it does in the operating mode, meaning only the ROOM 2 circuitry operates, the
ROOM 2 source can be played independently.
• When you do not use the ROOM 2 function, turn off the ROOM 2 function to save electricity.
46
• The OSD (On-Screen Display) menu is a setting menu that is displayed on the monitor TV and allows you to perform
the setup procedures easily. In most situations, you will only need to set this once during the installation and layout of
your home theater, and it rarely needs to be changed later.
The OSD menu consists of 6 main menus ; system setup, input setup, speaker / room EQ setup, CH level setup,
sound parameter and room 2 setup. These menus are then divided up into various sub-menus.
■Notes:
• The OSD menu and the momentary OSD cannot be diplayed via MONITOR HDMI OUT connector.
• Depending on the VIDEO MODE setting and the video connections between this receiver and the video
component, the OSD menu and the momentary OSD cannot be displayed via MONITOR COMPOSITE OUT jack,
or the picture is automatically turned off and only the OSD menu can be displayed via MONITOR COMPONENT
OUT jacks.
(For details, refer to "Relationship between the video input signal and the video output signal" on page 7.)
■Navigating through the OSD menu
• The explanations here assume you are using the buttons on the remote control when performing the OSD menu
operation. However, you can use the buttons on the front panel as well.
The buttons on the front panel correspond to those on the remote control as shown below.
Turn the menu screen on.
1
• The main menu will be shown.
• To turn the menu screen off, press this button again.
2
Select the desired menu using the
CURSOR UP(▲)/DOWN(▼) buttons.
47
ENGLISH
OSD Menu Settings
Confirm your selection.
ENGLISH
3
When selecting the SYSTEM SETUP
When selecting the INPUT SETUP
When selecting the SPEAKER /ROOM EQ SETUP
When selecting the CH LEVEL SETUP
When selecting the SOUND PARAMETER
When selecting the ROOM 2 SETUP
• For the setting details, see page in ⇨.
• Adjust the setting(s) in each setting category to your preference.
• When the OSD button is pressed on a sub-menu, the menu screen will be turned off.
48
• AMP ASSIGN : To assign the surround back channel's power
amplifier to ROOM 2 for ROOM 2 playbak.
• SUBWOOFER MODE : To select the desired subwoofer mode.
• TONE CONTROL : To adjust the tone (bass and treble) as
desired.
• CINEMA EQ : To select the desired cinema EQ mode.
• BACKGROUND : To select the desired background color of the
OSD menu.
• MOMENTARY OSD : To turn on or off the OSD that shows the
status corresponding to each operation
momentarily.
• OSD POSITION ADJUST : To adjust the positon of the
momentary OSD and the OSD menu.
When selecting the items other than OSD POSITION ADJUST
1
2
Press the CURSOR UP(▲)/DOWN(▼) buttons to select the desired item.
Press the CURSOR LEFT(◀)/RIGHT(▶) buttons to set the selected item as desired.
When selecting the AMP ASSIGN
• You should assign the power amplifier for the surround back/room 2 channels to ROOM 2 when the
SURROUND BACK/ROOM 2 speaker terminals are connected to the speakers installed in another room
for ROOM 2 playback. In this case, you need not use the power amplifier to drive the speakers
additionally. (For details on ROOM 2 connection, refer to "CONNECTING ROOM 2 OUTS" on page 12.)
SURR BACK : To use power amplifier for the surround back channels. ("
ROOM 2 : To use it for ROOM 2 playback. ("
" lights up.)
49
" goes off.)
ENGLISH
SETTING THE SYSTEM SETUP
Continued
ENGLISH
When selecting the SUBWOOFER MODE
• "SW PLUS+" mode is valid only when "FRONT" and "CENTER" are set to "LARGE" and "SUBWOOFER"
is set to "YES" on the SPEAKER/ROOM EQ SETUP menu. (For details, refer to "SETTING THE
SPEAKER/ ROOM EQ SETUP" on page 55.)
NORMAL : When the low frequency signals of channels set to "LARGE" are reproduced from those
channels only.
In this mode, the low frequency signals that are reproduced from the subwoofer channel
is only the low frequency signals of LFE (from the multi-channel sources that contains
LFE (Low Frequency Effects) channel, also called the ".1" channel) and the channels set to
"SMALL".
SW PLUS+ : When the low frequency signals of channels set to "LARGE" are reproduced
simultaneously from those channels and the subwoofer channel.
In this mode, the low frequency range expands more uniformly through the room, but
depending on the size and shape of the room, interference may result in a decrease of the
actual volume of the low frequency range.
When selecting the TONE CONTROL
OFF : To listen to a program source without the tone effect. ("TONE" goes off.)
ON : To adjust the tone for your taste. ("TONE" lights up.)
■When the TONE CONTROL is set to ON to adjust the tone (bass and treble)
1. Press the ENTER button to enter the tone adjustment mode.
2. Press the CURSOR UP(▲)/DOWN(▼) buttons to select the desired tone mode.
3. Press the CURSOR LEFT(◀)/RIGHT(▶) buttons to adjust the selected tone as desired.
• The tone level can be adjusted within the range of
-10 ~ +10 dB.
• In general, we recommend the bass and treble to
be adjusted to 0 dB (flat level).
• Extreme settings at high volume may damage
your speakers.
• To complete tone adjustment, repeat the above
steps 2 and 3.
50
When selecting the CINEMA EQ
ON : To compensate for edgy or shrill movie sound tracks. ("CINEMA-EQ" lights up.)
■Note : When the EXTERNAL IN is selected as an input source, the CINEMA EQ is automatically set to OFF.
When selecting the BACKGROUND
BLACK : To display the black as the color background of the OSD menu.
BLUE : To display the blue.
■Note : Only when no video signals are input into this unit, the selected background color will be displayed.
When selecting the MOMENTARY OSD
ON : To turn on the OSD function that shows the status corresponding to each operation on this unit
momentarily.
OFF : To turn it off.
■Note : When outputting the component video signal from the MONITOR COMPONENT OUT jacks as it was
input, the momentary OSD cannot be displayed.
When selecting the OSD POSITION ADJUST
• You can adjust the position of the momentary OSD and the OSD menu that are displayed on the
monitor TV.
1
2
Press the CURSOR UP(▲)/DOWN(▼) buttons to select the OSD POSITION ADJUST,
then press the ENTER button.
Press the CURSOR UP(▲)/DOWN(▼)/LEFT(◀)/RIGHT(▶) buttons to adjust the position of
the momentary OSD and the OSD menu as desired.
51
ENGLISH
OFF : To turn off the cinema EQ function. ("CINEMA-EQ" goes off.)
SETTING THE INPUT SETUP
ENGLISH
• This menu allows you to make the various settings
depending on how to use the input sources connected to
this receiver.
When selecting the items other than NAME
1
2
3
Press the CURSOR UP(▲)/DOWN(▼) buttons to select the desired input source, then press
the ENTER button.
Example: When selecting the VIDEO 1
Press the CURSOR UP(▲)/DOWN(▼) buttons to select the desired item.
■Note :
• Depending on the input source, some items other than
DC TRIGGER cannot be selected.
Press the CURSOR LEFT(◀)/RIGHT(▶) buttons to set the selected item as desired.
When selecting the DIGITAL AUDIO
• You should assign the connected DIGITAL INs to the desired of CD, AUX and VIDEO 1 ~ VIDEO 5.
(For details, refer to "CONNECTING DIGITAL INS and OUT" on page 8.)
• You can select the desired of OPT 1 ~ OPT 5, COAX1 ~ COAX 2 and ANAlog.
■Note :
• In such a case that a DIGITAL IN is assigned to two input sources or more, when these input sources are
selected, the digital audio signals can be heard from the same DIGITAL IN.
When selecting the VIDEO ASSIGN 1
• You should assign the connected HDMI INs to the desired of VIDEO 1 ~ VIDEO 5.
(For details, refer to "CONNECTING VIDEO COMPONENTS" on pages 6 ~ 7.)
• You can select HDMI 1 or HDMI 2.
■Note :
• In such a case that a HDMI IN is assigned to two input sources or more, when these input sources are
selected, the uncompressed digital video signals and audio signals can be output from the MONITOR HDMI
OUT of this receiver without passing through any circuits as they were input into the same HDMI IN.
52
Continued
• You should assign the connected COMPONENT VIDEO INs to the desired of VIDEO 1 ~ 5.
(For details, refer to "CONNECTING VIDEO COMPONENTS" on pages 6 ~ 7.)
• You can select the desired of COMP 1 ~ 3.
■Note :
• In such a case that a COMPONENT VIDEO IN is assigned to two input sources or more, when these input
sources are selected, the component video signals can be viewed from the same COMPONENT VIDEO IN.
When selecting the VIDEO MODE
• You can select the video input signal to be output from the MONITOR OUTs.
AUTO : When there are mutiple video input signals, the video input signals are detected and the video input signal to be
output from the MONITOR OUTs is selected automatically in the following order : component video, S-video,
composite video.
COMPOSITE : The signal that is input into the (COMPOSITE) VIDEO jack is always played. The composite video input
signal is up-converted and output from the S-VIDEO and COMPONENT MONITOR OUT jacks.
S-VIDEO : The signal that is input into the S-VIDEO jack is always played. The S-video input signal is converted and
output from the (COMPOSITE) VIDEO and COMPONENT MONITOR OUT jacks.
COMPONENT : The signals that are input into the COMPONENT jacks are always played.
Because video conversion is not performed, no video signals are output from the MONITOR
OUT jacks when there are no video signals that are input into the COMPONENT jacks.
• For details, refer to "Relationship between the video input signal and the video output signal" on page 7.
When selecting the AUTO SURROUND
• Depending on how to select a surround mode, you can select the auto surround mode or the manual
surround mode.
ON
: The optimum surround mode will be automatically selected depending on the signal
(Auto surround mode)
format being input.
OFF
(Manual surround mode)
: You can select the disired of different surround modes selectable for the signal being
input with using the MULTI CONTROL knob or the SURROUND MODE UP/DOWN
( >/< ) buttons. (For details, refer to "When selecting the manual surround mode with
pressing the SURROUND MODE button on the front panel" on page 34.)
■Notes :
• When the SPEAKER button is set to off, the auto surround mode is invalid.
• Even when the auto surround mode is selected and the same type of digital signal format is being input,
the optimum surround mode may vary depending on whether the speaker type is set to "NONE" or not.
• When the auto surround mode is selected and the PCM (2 channel) digital signal or the analog stereo
signal is being input, only the stereo mode will be selected.
• When the auto surround mode is selected, the surround modes other than the optimum surround mode
cannot be selected.
When selecting the REMASTER
• The remastering processes the input signal digitally and converts its digital sampling frequency to twice
the current frequency (88.2/96 kHz) for a more detailed sound reproduction.
ON : To process the input signal digitally and to convert its sampling frequency to 88.2/96 kHz for a more
detailed sound reproduction.
OFF : To turn off the remastering function.
■Note :
• The remastering function have no effect on the input digital signal from the 88.2/96 kHz source or higher
as well as the digital signal that is output from the OPTICAL DIGITAL OUT of this receiver.
When selecting the AV SYNC
• There may be a slight time delay between the video and audio signals in case that some video playback
equipments may process the video signals later than the audio signals due to signal processing
procedure, etc.. Should this happen, you can adjust the time delay of audio signals to synchronize the
sound with the picture.
• The time delay can be adjusted within the range of 0 ~ 200 msec.
53
ENGLISH
When selecting the VIDEO ASSIGN 2
ENGLISH
When selecting the DC TRIGGER
• To turn on the component connected to the DC TRIGGER OUT jack when this input source is selected,
you should set the DC TRIGGER to ON for this input source.
OFF : To turn off the DC trigger function.
ON: To turn it on.
• For details, refer to "CONNECTING DC TRIGGER OUT" on page 9.
When selecting the NAME
• You can give names to the input sources other than tuner.
• Up to 7 characters can be entered for each name.
1
2
Press the CURSOR UP(▲)/DOWN(▼) buttons to select the desired input source, then
press the ENTER button.
Example: When selecting the VIDEO 1
Press the CURSOR UP(▲)/DOWN(▼) buttons to select the NAME, then press the ENTER button.
• The first digit flickers.
3
Press the CURSOR LEFT(◀)/ RIGHT(▶)
buttons to select the desired digit.
4
Press the CURSOR UP(▲)/DOWN(▼)
buttons to enter the desired character on
the flickering digit.
• You can enter the desired among blank, A ~ Z,
a ~ z, 0 ~ 9, (, ), , +, , , -, ., /.
• Then the selected digit will flicker.
5
Repeat the above steps ③ and ④ to enter the desired characters on the rest of the digits.
6
Confirm your entry.
• The name is stored in the memory.
■To resume its factory input source name.
• Make a blank on each digit and press the ENTER
button.
54
• After you have installed this receiver and connected all the components, you should adjust the speaker settings for the
optimum sound acoustics according to your environment and speaker layout.
• Even when you change speakers, speaker positions, or the layout of your listening environment, you should adjust the
speaker settings, too.
• When performing the AUTO SETUP procedure, you need not perform the SPEAKER CONFIGURATION, SPEAKER
DISTANCE, SPEAKER CROSSOVER and CH LEVEL SETUP procedures.
• AUTO SETUP : To set the speaker setup and channel level setup
automatically.
• SPEAKER CONFIGURATION : To select the sizes of the speakers that
are connected.
• SPEAKER DISTANCE: To enter the distance between the listening
position and each speaker to set the delay time
automatically for optimum surround playback.
• SPEAKER CROSSOVER : To select the desired crossover frequency.
• ROOM EQ : To turn on or off the room EQ.
When selecting the AUTO SETUP
• Auto Setup lets you avoid troublesome listening-based speaker setup and achieve good surround sound.
Auto Setup has the feature that provides the optimum listening environment at two main listening
positions in your room, where there are often multiple listeners viewing programs together.
You should connect the supplied microphone to the SETUP MIC jack so that this receiver can analyze the
information from a series of test tones emitted from speakers at two main listening positions and can
adjust the size, distance, sound level, crossover frequency and frequency response of each speaker
automatically.
For optimum effectiveness, move the microphone from first position to second position within the listening
area surrounded by the speakers while performing the auto setup.
About the first listening position
The first listening position is the point where a listener sits most often or the listening position when only
one person is listening. Measurements start from this point.
• If you want to personalize your speaker setup and channel level setup by making the settings manually,
perform the "When selecting the SPEAKER CONFIGURATION" on page 57, "When selecting the
SPEAKER DISTANCE" on page 59, "When selecting the SPEAKER CROSSOVER" on page 60,
"Adjusting each channel level with test tone" on page 35 and "Adjusting the current channel level" on
page 36.
• After the auto setup has been completed, set the room EQ mode as desired. (For details, refer to "When
selecting the ROOM EQ" on page 61.)
Preparations
1. Check that the speakers are securely connected
to this receiver.
• If your subwoofer has adjustable volume and
crossover frequency, set the volume halfway
and set the crossover frequency to the
maximum or the low pass filter off.
2. Connect the supplied microphone to the SETUP
MIC jack on the front panel.(For details, refer to
"SETUP MIC JACK" on page 16.)
■Notes :
• Because the microphone for Auto Setup is
designed for use with this receiver, to use the auto
setup function, do not use a microphone other than
the one supplied with this receiver.
• After you have completed the auto setup
procedure, disconnect the microphone.
Place the microphone on a flat level surface at the first main listening position.
1
• If possible, use a tripod, etc. to attach the microphone at the same height as your ears would be when
you are seated in your listening position.
• Ensure there are no obstacles between the speakers and the microphone.
55
ENGLISH
SETTING THE SPEAKER / ROOM EQ SETUP
Continued
ENGLISH
2
Press the CURSOR UP(▲)/DOWN(▼) buttons to select the AUTO SETUP, then press the
ENTER button.
3
Press the CURSOR UP(▲)/DOWN(▼) buttons to select the START, then press the ENTER
button
When measurements at first position have been completed.
• Loud test tones are output from each speaker and then if measurements at the first position have been completed,
"SECOND POSITION" message will be displayed.
Place the microphone on a flat level at the second main listening position.
4
• For optimum effectiveness, place the microphone at the second main position within the listening area surrounded by
the speakers.
5
Press the CURSOR UP(▲)/DOWN(▼) buttons to select "CONTINUE", then press the ENTER
button
When the auto setup has been completed.
• Loud test tones are output again successively and then if a series of auto setup procedure has been completed,
"COMPLETE" will be displayed.
• To stop the auto setup procedure while performing it, (press the CURSOR UP(▲)/DOWN(▼) buttons to select
"CANCEL THE AUTO SETUP"), then press the ENTER button.
In such a case that the auto setup procedure is stopped before "COMPLETE", the results of each adjustment may
not be memorized.
• If there may be a problem with front speakers or microphone connection, error message will be displayed. In this case,
turn off the power, check the connection and then retry the auto setup procedure.
■Notes :
• Before starting auto setup, be sure not to set the SPEAKER button to off.
• Because the test tones are loud, ensure there no infants or small children in the room.
• For best results, ensure the room is as quiet as possible during the auto setup procedure.
If there is too much ambient noise, the results may not be satisfactory.
56
Continued
6
• Then the results are memorized and the
SPEAKER/ROOM EQ SETUP menu is displayed.
• Check the results on each setup menu(SPEKER
CONFIGURATION menu below, SPEAKER
DISTANCE menu on page 59, SPEAKER
CROSSOVER menu on page 60 and CH LEVEL
SETUP menu for "CALIBRATE" mode on page 62).
• If the results are not satisfactory, you can retry the
auto setup procedure or personalize your speaker
setup and channel level setup by making the
settings manually. (For details, refer to "When
selecting the SPEAKER CONFIGURATION" below,
"When selecting the SPEAKER DISTANCE" on
page 59, "When selecting the SPEAKER
CROSSOVER" on page 60, "Adjusting each
channel level with test tone" on page 35 and
"Adjusting the current channel level" on page 36.)
When selecting the SPEAKER CONFIGURATION
1
2
Press the CURSOR UP(▲)/DOWN(▼) buttons to select the SPEAKER CONFIGURATION,
then press the ENTER button.
Press the CURSOR UP(▲)/DOWN(▼) buttons to select the desired speaker.
57
ENGLISH
To check the results, press the ENTER button.
Continued
ENGLISH
3
Press the CURSOR LEFT(◀)/ RIGHT(▶) buttons to set the selected speaker as desired.
• Depending on your speaker type, you can select one of these
following speaker types.
LARGE: Select this when connecting speakers that can fully
reproduce sounds below crossover frequency.
SMALL: Select this when connecting speakers that can not fully
reproduce sounds below crossover frequency. When this is
selected, sounds below crossover frequency are sent to the
subwoofer or speakers which are set to LARGE(when not
using a subwoofer)
NONE: Select this when no speakers are connected. When this is
selected, sounds are sent to the speakers which are not set to
NONE.
2CH/1CH: Select the desired depending on the number of surround
back speakers.
YES/NO: Select the desired depending on whether a subwoofer is
connected or not.
Notes :
• When speakers are set to "SMALL", you should set their crossover frequency correctly according to their
frequency characteristics. (For details, refer to "When selecting the SPEAKER CROSSOVER" on page 60.)
• When the "FRONT" is set to "SMALL", "CENTER", "SURROUND", "SURR BACK" cannot be set to
"LARGE" and "SUBWOOFER" is automatically set to "YES".
• When the "SURROUND" is set to "SMALL", "SURR BACK" cannot be set to "LARGE".
• When the power amplifier for surround back/room 2 channels is assigned to "ROOM 2", the "SURR BACK"
cannot be selected. (For details, refer to "When selecting the AMP ASSIGN" on page 49.)
When setting the speaker size by performing the auto setup.
If the speakers may not be detected properly because of incorrect connection, measurement environment,
or other factors, the speakers are set as follows :
• When a pair of speakers such as front, surround or surround back speakers are detected differently (i.e,
one is detected as "LARGE", the other as "SMALL"), both are automatically set to "SMALL".
• When only one surround speaker is detected, both are automatically set to "NONE".
• When only the surround back right speaker is detected, both are automatically set to "NONE".
In this case, connect that speaker to the SURROUND BACK/ROOM 2 LEFT speaker terminals and retry
the auto setup, then it will be automatically set to "1CH".
4
Repeat the above steps ② and ③ until the speakers are all set to the desired mode.
About the speaker size
• Select "LARGE" or "SMALL" not according to the actual size of the speaker but according to the speaker's
capacity for playing low frequency (bass sound below frequency set on the SPEAKER CROSSOVER
menu) signals.
• If you do not know, try comparing the sound at both settings (setting the volume to a level low enough so
as not to damage the speakers) to determine the proper setting.
• When setting the speaker size by performing the auto setup, depending on whether the measured
crossover frequency of each speaker is lower or higher than 80 Hz, its size is automatically set to "LARGE"
or "SMALL". (For details, refer to "When selecting the SPEAKER CROSSOVER" on page 60.)
58
When selecting the SPEAKER DISTANCE
2
ENGLISH
1
Press the CURSOR UP(▲)/DOWN(▼) buttons to select the SPEAKER DISTANCE, then
press the ENTER button.
Press the CURSOR UP(▲)/DOWN(▼) buttons to select the desired item.
Note :
• You cannot select the subwoofer and the speakers
set to "NONE".
3
Press the CURSOR LEFT(◀)/RIGHT(▶) buttons to set the selected item as desired.
When selecting the desired unit
• You can select either METERS or FEET.
• Once a unit is selected, the distances are
automatically changed in the selected unit.
When setting the distance
• You can set the distance within the range of 0.1 ~
9.0 meters in 0.1 meter intervals (or 0.5 ~ 30 feet in
0.5 feet intervals).
4
Repeat the above steps ② and ③ until the distances are all set as desired.
About the speaker distance
When enjoying multi-channel surround playback with Dolby Digital and DTS sources, etc., it is ideal that the
center, surround and surround back speakers should be the same distance from the main listening position
as the front speakers. By entering the distance between the listening position and each speaker, the delay
times of center, surround and surround back speakers are automatically adjusted to create an ideal listening
environment virtually as if the center, surround and surround back speakers were at their ideal locations
respectively.
59
When selecting the SPEAKER CROSSOVER
ENGLISH
• When speakers are set to "SMALL", be sure to set their crossover frequency correctly according to
their frequency characteristics.
1
2
Press the CURSOR UP(▲)/DOWN(▼) buttons to select the SPEAKER CROSSOVER, then
press the ENTER button.
Press the CURSOR UP(▲)/DOWN(▼) buttons to select the desired speaker.
Note :
• You cannot select the subwoofer and the speakers
set to "NONE".
3
Press the CURSOR LEFT(◀)/RIGHT(▶) buttons to set the crossover frequency as desired.
• You can adjust the crossover frequency within
the range of 40 ~ 200 Hz in 10 Hz intervals.
4
Repeat the above steps ② and ③ until the crossover frequencies are all set as desired.
About the crossover frequency
• When speakers are set to "SMALL", low frequencies in those channels that are below the crossover
frequency are to output from subwoofer or front speakers which are set to LARGE(when not using a
subwoofer).
• Refer to the operating instructions of the speakers to be connected. If the frequency range of your speaker
is 100 Hz~20 kHz, the crossover frequency should be set to 100 Hz(or slightly higher).
60
• The room EQ is a kind of room equalizer for your speakers. According to the acoustic characteristics of
your room measured by the auto setup, the room EQ automatically adjusts the frequency response of
your speakers.
• If you use different brands or sizes of speakers for some channels or have a room with unique acoustic
characteristics, such as walls, furniture, and the dimensions or the shape of the room, we recommend
using the room EQ.
■Note :
• To use the room EQ, first you should finish measuring the acoustic characteristics of your room
performing the auto setup.
(For details, refer to "When selecting the AUTO SETUP" on page 55.)
1
2
Press the CURSOR UP(▲)/DOWN(▼) buttons to select the ROOM EQ.
Press the CURSOR LEFT(◀)/RIGHT(▶) buttons to select the desired room EQ mode.
ON : When turning on the room EQ.
OFF : When turning it off.
61
ENGLISH
When selecting the ROOM EQ
SETTING THE CH LEVEL SETUP
ENGLISH
Memory mode
■Note :
• Depending on the speaker settings("NONE" or "NO", etc.), some channels cannot be selected.
Adjusting the current channel level
• You can adjust the current channel levels as desired. These adjusted levels are just memorized into
user’s memory("CALIBRATE"), not into preset memory("REFERENCE 1", "REFERENCE 2").
• After adjusting each channel level with test tone, adjust the channel levels either according to the
program sources or to suit your tastes.(For details, refer to "Adjusting each channel level with test tone"
on page 35.)
1
Press the CURSOR UP(▲)/DOWN(▼) buttons to select the desired channel.
■When adjusting the LFE LEVEL
1. Press the CURSOR UP(▲)/DOWN(▼)buttons to select the LFE LEVEL SETUP, then press the ENTER
button.
2. Press the CURSOR UP(▲)/DOWN(▼) buttons to select the desired program source.
2
3
Press the CURSOR LEFT(◀)/RIGHT(▶) buttons to adjust the level of the selected channel or
program source's LFE as desired.
• The LFE level can be adjusted within the range of
-10 ~ 0 dB and other channel levels within the
range of -15 ~ +15 dB
• In general, we recommend the LFE level to be
adjusted to 0 dB.(However, the recommended LFE
level for some early DTS software is -10 dB.) If the
recommended levels seem too high, lower setting
as necessary.
Repeat the above steps ① and ② to adjust each channel level.
62
Memorizing the adjusted channel levels
1
After performing the steps ①~③ in "Adjusting the current channel level" procedure on page
62, press the CURSOR UP(▲)/DOWN(▼) buttons to select a channel (, not the MODE
(memory mode) and the LFE LEVEL SETUP), then press the ENTER button.
• The "REFERENCE 1" indication flickers.
2
Press the CURSOR LEFT(◀)/RIGHT(▶) buttons to select the desired preset memory,
then press the ENTER button.
• Each time the CURSOR LEFT(◀) or RIGHT(▶)
button is pressed, "REFERENCE 1" or
"REFERENCE 2" is selected.
• The adjusted channel levels have now been
memorized into the selected memory.
Recalling the memorized channel levels
1
Press the CURSOR UP(▲)/DOWN(▼) buttons to select the MODE(memory mode).
• "CALIBRATE" may be displayed instead of
"REFERENCE 1" or "REFERENCE 2".
2
Press the CURSOR LEFT(◀)/ RIGHT(▶) buttons to select the desired one of REFERENCE 1
and REFERENCE 2.
• Then the channel levels memorized into the
selected preset memory are recalled.
63
ENGLISH
• You can memorize the adjusted channel levels into preset memory("REFERENCE 1", "REFERENCE 2")
and recall the memorized whenever you want.
SETTING THE SOUND PARAMETER
ENGLISH
• NIGHT MODE : To adjust the dynamic range compression that
makes faint sound easier to hear at low volume
levels.
• DOLBY PLII MUSIC : To adjust the various surround
parameters for optimum surround effect.
• DOLBY HEADPHONE : To select the desired listening mode for
each Dolby Headphone mode.
• DOLBY VIRTUAL SPEAKER : To select the speaker layout to be
used actually for each Dolby
Virtual Speaker mode.
When selecting the NIGHT MODE
• This function compresses the dynamic range of previously specified parts of the Dolby Digital sound
track (with extremely high volume) to minimize the difference in volume between the specified and nonspecified parts.
This makes it easy to hear all of the sound track when watching movies at night at low levels.
Notes:
• The night mode setting is valid only when the digital signals from the Dolby Digital program source are
being input.
• In some Dolby Digital softwares, the night mode setting may not be valid.
1
2
Press the CURSOR UP(▲)/DOWN(▼) buttons to select the NIGHT MODE, then press the
ENTER button.
Press the CURSOR LEFT(◀)/ RIGHT(▶) buttons to adjust the dynamic range compression as
desired.
0.0 (MIN)
0.1
Lower compression
0.2
:
:
:
0.9
Higher compression
1.0 (MAX)
64
• You can adjust the various surround parameters for optimum surround effect.
Note:
• The parameter settings are valid only when listening in either Dolby Pro Logic II Music mode or the
Dolby Pro Logic IIx Music mode.
1
2
3
Press the CURSOR UP(▲)/DOWN(▼) buttons to select the DOLBY PLII MUSIC, then press
the ENTER button.
Press the CURSOR UP(▲)/DOWN(▼) buttons to select the desired parameter.
Press the CURSOR LEFT(◀)/ RIGHT(▶) buttons to adjust the selected parameter as desired.
When selecting the PANORAMA mode
This mode extends the front stereo image to include
the surround speakers for an exciting "wraparound"
effect with side wall imaging. Select "OFF" or
"ON"(default value:OFF).
When selecting the CENTER WIDTH control
This adjusts the center image so it may be heard only
from the center speaker, only from the left/right
speakers as a phantom image, or from all three front
speakers to varying degrees.
The control can be set in 8 steps from 0 to 7(default
value : 3).
When selecting the DIMENSION control
This gradually adjusts the soundfield either towards
the front or towards the rear. The control can be set in
7 steps from -3 to +3(default value : 0).
4
Repeat the above steps ② and ③ to adjust other parameters.
65
ENGLISH
When selecting the DOLBY PLII MUSIC
ENGLISH
When selecting the DOLBY HEADPHONE
• You can select the desired listening mode for each Dolby Headphone mode.
Note:
• The listening mode setting is valid only when playing analog stereo, PCM 2 channel or Dolby Digital 2
channel source.
1
2
3
Press the CURSOR UP(▲)/DOWN(▼) buttons to select the DOLBY HEADPHONE, then
press the ENTER button.
Press the CURSOR UP(▲)/DOWN(▼) buttons to select the desired Dolby Headphone mode.
Press the CURSOR LEFT(◀)/ RIGHT(▶) buttons to select the desired listening mode.
MOVIE : This provides the surround effect suitable
for movie sources.
MUSIC 1 : This provides the surround effect suitable
for music sources.
MUSIC 2 : This provides less surround effect
compared to MUSIC 1 mode.
4
Repeat the above steps ② and ③ to select the desired listening modes for other Dolby
Headphone modes.
66
• You can select the speaker layout to be used actually for each Dolby Virtual Speaker mode.
Note:
• The speaker layout settings are valid only when listening in a Dolby Virtual Speaker mode.
1
2
3
Press the CURSOR UP(▲)/DOWN(▼) buttons to select the DOLBY VIRTUAL SPEAKER,
then press the ENTER button.
Press the CURSOR UP(▲)/DOWN(▼) buttons to select the desired Dolby Virtual Speaker mode.
Press the CURSOR LEFT(◀)/RIGHT(▶) buttons to select the desired speaker layout.
When selecting the Dolby Virtual Speaker Reference
mode
2 SPK : When using 2 front speakers only.
3 SPK : When using 2 front and center speakers.
When selecting the Dolby Virtual Speaker Wide mode
2 SPK : When using 2 front speakers only.
3 SPK : When using 2 front and center speakers.
4 SPK : When using 2 front and 2 surround speakers.
5 SPK : When using 2 front, center and 2 surround speakers.
Note:
• When the speakers are set to "NONE", the corresponding speaker layouts cannot be selected.
4
Repeat the above steps ② and ③ to select the desired speaker layout for another Dolby
Virtual Speaker mode.
67
ENGLISH
When selecting the DOLBY VIRTUAL SPEAKER
SETTING THE ROOM 2 SETUP
ENGLISH
• The ROOM 2 function allows enjoying one source in the main room while playing another in a different
room at the same time.
• ROOM 2 : To turn on or off the ROOM 2 function.
• INPUT : To select the desired ROOM 2 source.
• VOLUME : To adjust the volume on the power
amplifier assigned to ROOM 2.
Notes:
• The analog signals from the EXTERNAL INs and the digital signals cannot be output to the different
room, meaning no playback in a different room.
• You cannot play the ROOM 2 source in any surround mode.
1
Press the CURSOR UP(▲)/DOWN(▼) buttons to select the desired item.
Note:
• The VOLUME cannot be adjusted when the AMP
ASSIGN is assigned to SURR BACK.
(For details, refer to "When selecting the AMP
ASSIGN" on page 49.)
2
Press the CURSOR LEFT(◀)/RIGHT(▶) buttons to set the selected item as desired.
When selecting the ROOM 2
OFF : To turn off the ROOM 2 function.
↕
ON : To turn it on.
Notes:
• When the ROOM 2 is set to OFF, the INPUT and the VOLUME cannot be selected.
• When you do not use the ROOM 2 function, set the ROOM 2 to OFF to save electricity.
When selecting the INPUT
• You can select the desired among MAIN source, TUNER, CD, AUX, TAPE, VIDEO 1 ~ VIDEO 5 as a
ROOM 2 source.
Note:
• When the EXTERNAL IN is selected as a main input, if the MAIN source is selected as a ROOM 2 input,
no audio signals can be heard in the different room (ROOM 2).
When selecting the VOLUME
• You can adjust the volume on the power amplifier assigned to ROOM 2 when the SURROUND BACK/
ROOM 2 speaker terminals are connected to the speakers in a different room.
Note:
• You can adjust the VOLUME only when the power amplifier for surround back/room 2 channels is
assigned to "ROOM 2". (For details, refer to "When selecting the AMP ASSIGN" on page 49.)
68
If a fault occurs, run through the table below before taking your receiver for repair.
If the fault persists, attempt to solve it by switching the receiver off and on again. If this fails to resolve the situation, consult your
dealer. Under no circumstances should you attempt to repair the receiver yourself. This could void the warranty.
PROBLEM
POSSIBLE CAUSE
REMEDY
No power
• The AC input cord is disconnected.
• Poor connection at AC wall outlet or the outlet is
dead or off.
• Connect cord securely.
• Check the outlet using a lamp or another
appliance.
No sound
• The speaker wires are disconnected.
• The master volume is adjusted too low.
• The MUTE button is pressed to ON.
• Incorrect selection of input source.
• Incorrect connections between the components.
• Check the speaker connections.
• Adjust the master volume.
• Press the MUTE button to cancel the muting effect.
• Select the desired input source correctly.
• Make connections correctly.
No sound from the surround
speakers
• Surround mode is switched off(stereo mode).
• Master volume and surround level are too low.
• Monaural source is used.
• Surround speaker setting is "NONE".
• Select a surround mode.
• Adjust master volume and surround level.
• Select a stereo or surround source.
• Select the desired surround speaker setting.
No sound from the center
speaker
• Dolby Virtual Speaker, stereo mode, etc is
selected.
• Center speaker setting is "NONE".
• Master volume and center level are too low.
• Select the desired surround mode.
• The input signal format or the current surround
mode cannot support the 7.1(or 6.1) surround.
• Master volume and surround back level are too low.
• Surround back speaker setting is "NONE".
• Under the proper situations, perform the 7.1(or
6.1) surround playback.(For details, refer to
"ENJOYING SURROUND SOUND" on page 34.)
• Assign the power amplifier to the surround back
channels.(For details, refer to "When selecting
the AMP ASSIGN"on page 49.)
• Adjust master volume and surround back level.
• Select the desired surround back speaker setting.
Stations cannot be received
• No antenna is connected.
• The desired station frequency is not tuned in.
• Antenna is in wrong position.
• Connect an antenna.
• Tune in the desired station frequency.
• Move antenna and retry tuning.
Preset stations cannot be
received
• An incorrect station frequency has been memorized.
• The memorized stations are cleared.
• Memorize the correct station frequency.
• Memorize the stations again.
Poor FM reception
• No antenna is connected.
• The antenna is not positioned for the best reception.
• Connect an antenna.
• Change the position of the antenna.
Continuous hissing noise during
FM reception, especially when a
stereo broadcast is received.
• Weak signals.
• Change the position of the antenna.
• Install an outdoor FM antenna.
Continuous or intermittent hissing
noise during AM reception,
especially at night.
• Noise is caused by motors, fluorescent lamps or
lightning, etc.
• Keep the receiver away from noise sources.
Remote control unit does not
operate.
• Batteries are not loaded or exhausted.
• The remote sensor is obstructed.
• Replace the batteries.
• Remove the obstacle.
Other Sherwood components do
not react to remote control
commands.
• DIGI LINK connections are not made properly.
• Make proper DIGI LINK connections.
OSD function is not available.
• Video connections between this unit and the
monitor TV are not made correctly.
• Make proper video connections.
No sound from the surround back
speakers
• The power amplifier for the surround back/room 2
channels is assigned to the ROOM 2.
• Select the desired center speaker setting.
• Adjust master volume and center level.
• Install an outdoor AM antenna.
69
ENGLISH
Troubleshooting Guide
ENGLISH
Specifications
AMPLIFIER SECTION
• Power output, stereo mode, 8 ,Ω THD 0.08 %, 20 Hz~20 kHz .................................................................. ............. 2×100 W
• Total harmonic distortion, 8 Ω, 95 W, 1 kHz ............................................................................... ................................... 0.05%
• Intermodulation distortion
60 Hz : 7 kHz= 4 : 1 SMPTE, 8 Ω, 95 W ........................................................................................ ............................. 0.1%
• Input sensitivity/impedance
Line (CD, TAPE, VIDEO) .............................................................................................................................. 200 mV/47kΩ
• Signal to noise ratio, IHF "A" weighted
Line (CD, TAPE, VIDEO) ........................................................................................................................................... 96 dB
• Frequency response
Line (CD, TAPE, VIDEO), 20 Hz~100 kHz ............................................................................................................. 0, -3 dB
• Output level
TAPE OUT, 2.2 kΩ ............................................................................................................... .................................... 200 mV
PRE OUT (Front, Center, Surround, Surround back, Subwoofer), 1 kΩ .............................................................. ........ 1.0 V
• Bass/Treble control, 100 Hz/10 kHz ............................................................................................................................. ±10 dB
• Surround mode, only channel driven
Front power output, 8 Ω, 1 kHz, THD 0.08 % ................................................................................... ............ 115W / 115W
Center power output, 8 ,Ω 1 kHz, THD 0.08 % .................................................................................. ........................ 115W
Surround power output, 8 ,Ω 1 kHz, THD 0.08 % ................................................................................ ......... 115W / 115W
Surround back / ROOM 2 power output, 8 ,Ω 1 kHz, THD 0.08 % ............................................................... 115W / 115W
DIGITAL AUDIO SECTION
• Sampling frequency .................................................................................................................................. 32, 44.1, 48, 96 kHz
• Digital input level
Coaxial, 75Ω ................................................................................................................... ...................................... 0.5 Vp-p
Optical, 660 nm ............................................................................................................................................ -15~-21 dBm
VIDEO SECTION
• Video format .................................................................................................................................................................... NTSC
• Input sensitivity(=Output level), 75 Ω
Video (Composite(normal)) ....................................................................................................................................... 1 Vp-p
S-Video (luminance signal) ..................................................................................................................................... 1 Vp-p
(chrominance signal) .......................................................................................................................... 0.286 Vp-p
Component video (R-Y signal) .............................................................................................................................. 0.5 Vp-p
(B-Y signal) ............................................................................................................................ 0.5 Vp-p
(Y signal) ................................................................................................................................. 1.0 Vp-p
• HDMI connector ............................................................................................................................................................. 19 pin
FM TUNER SECTION
• Tuning frequency range .................................................................................................................................... 87.5~108 MHz
• Usable sensitivity, THD 3%, S/N 30 dB ...................................................................................................................... 12.8 dBf
• 50 dB quieting sensitivity, mono/stereo ........................................................................................................... 20.2 / 45.3 dBf
• Signal to noise ratio, 65 dBf, mono/stereo ................................................................................................................ 70 / 65 dB
• Total harmonic distortion, 65 dBf,1 kHz, mono/stereo ............................................................................................ 0.5 / 0.8 %
• Frequency response, 30 Hz~15 kHz ............................................................................................................................. ±3 dB
• Stereo separation, 1 kHz ................................................................................................................................................ 32 dB
• Capture ratio ................................................................................................................................................................. 4.0 dB
• IF rejection ratio .............................................................................................................................................................. 60 dB
AM TUNER SECTION
• Tuning frequency range ................................................................................................................................... 520~1710 kHz
• Usable sensitivity ...................................................................................................................................................... 500 µV/m
• Signal to noise ratio ........................................................................................................................................................ 40 dB
• Selectivity ........................................................................................................................................................................ 25 dB
GENERAL
• Power supply ..................................................................................................................................................... 120 V ~ 60 Hz
• Power consumption ............................................................................................................................................................. 6 A
• Switched AC outlets ....................................................................................................................... TOTAL 120 W (1 A) max.
• Dimensions (W×H×D, including protruding parts) .............................. 440×171×421 mm(17-3/8×6-3/4×16-1/2 inches)
• Weight (Net) ................................................................................................................................................... 15.5 kg (34.1 Ibs)
Note: Design and specifications are subject to change without notice for improvements.
70
Setup Code Table
AOC
Admiral
Aiko
Akai
Alaron
Ambassador
America Action
Ampro
Anam
Audiovox
Baysonic
Belcor
Bell & Howell
Bradford
Brockwood
Broksonic
CXC
Candle
Carnivale
Carver
Celebrity
Cineral
Citizen
Concerto
Contec
Craig
Crosley
Crown
Curtis Mathes
Daewoo
Daytron
Denon
Dumont
Dwin
Electroband
Emerson
Envision
Fisher
Fujitsu
Funai
Futuretech
GE
Gibralter
005
041
014
005
026
024
027
043
027
030
027
003
019
027
003
028
027
005
005
010
050
030
012
011
027
027
010
027
007
012
022
030
003
016
002
044
050
019
003
005
019
026
027
027
007
004
002
003
031
047
027
048
014
Goldstar
Gradiente
Grunpy
Hallmark
Harley Davidson
Harman/Kardon
Havard
Hitachi
Infinity
Inteq
JBL
JCB
JVC
KEC
KTV
Kenwood
LG
LXI
Logik
Luxman
MGA
MTC
Magnavox
Magestic
Marantz
Matsushita
Magatron
Memorex
049
034
001
031
011
014
005
006
010
005
032
003
011
019
016
038
006
006
008
011
040
014
014
030
001
041
006
034
035
Midland
Minutz
Mitsubishi
Motorola
Multitech
NAD
NEC
NTC
Nikko
Onwa
Optimus
Optonica
Orion
Panasonic
Penney
003
036
028
026
031
006
026
023
008
015
005
030
038
003
027
024
041
040
029
034
029
025
035
025
Pilco
Philips
71
005
009
027
025
026
010
027
016
010
002
010
050
009
027
027
005
011
007
001
011
017
012
010
001
010
042
025
019
001
007
004
041
041
027
020
005
014
005
027
019
041
028
008
007
004
010
010
025
011
026
003
011
018
ENGLISH
TV
011
046
005
003
003
010
006
019
020
005
005
005
025
003
026
003
011
016
042
031
017
025
002
008
006
015
017
025
003
025
003
022
011
025
014
042
021
031
042
020
003
031
022
025
005
011
026
008
011
005
012
006
016
005
015
003
025
040
ENGLISH
Pilot
Pioneer
Portland
Prism
Proscan
Proton
Pulsar
Quasar
RCA
Radio Shack
Realistic
Runco
SSS
Sampo
Samsung
Samsux
Sansei
Sansui
Sanyo
Scimitsu
Scotch
Scott
Sears
Semivox
Semp
Sharp
Sherwood
Shogun
Signature
Sony
Soundesign
Squareview
Starlite
Supreme
Sylvania
Symphonic
TMK
Tandy
Technics
Technoi Ace
Techwood
Teknika
Telefunken
Toshiba
Totevision
Vector Research
Victor
Vidikron
005
022
003
008
007
025
002
008
007
037
007
003
019
011
002
027
005
012
006
030
031
019
003
025
028
007
011
027
020
041
000
003
001
050
027
023
027
050
010
023
025
041
008
026
008
010
011
011
019
006
005
009
010
003
006
006
014
032
003
042
008
038
019
011
021
006
005
003
006
005
White Westinghouse
Yamaha
Zenith
021
041
039
021
006
027
003
040
027
013
015
005
025
005
025
003
025
025
019
021
006
003
003
020
011
026
025
Admiral
Adventura
Aiko
Aiwa
Akai
America Action
America High
Asha
Audiovox
Beaumark
Bell & Howell
Brocksonic
Broksonic
CCE
Calix
Canon
Carver
Cineral
Citizen
Colt
Craig
Curtis Mathes
Cybernex
Daewoo
Denon
Dynatech
Electrohome
Electrophonic
Emerex
Emerson
045
026
026
005
011
024
Fisher
Fuji
Funai
GE
Garrard
Go Video
GoldStar
Gradiente
HI-Q
Harley Davidson
Harman/Kardon
Harwood
042
011
027
001
017
006
020
012
012
014
003
025
010
026
031
005
002
003
021
011
034
003
031
027
000
025
005
026
025
004
023
005
023
017
021
020
015
005
004
081
025
005
015
005
013
023
010
008
000
005
005
002
005
001
012
004
000
013
000
052
005
000
012
000
016
015
021
005
001
035
025
004
001
014
021
001
023
026
015
028
024
020
025
017
003
000
018
009
004
027
023
003
VCR
033
027
010
006
025
Vidtech
Wards
026
72
000
018
025
025
012
004
025
006
006
021
Minolta
Mitsubishi
Motorola
Multitech
NEC
Nikko
Noblex
Olympus
Opimus
Orion
Panasonic
Penny
Pentax
Philco
Philips
Pilot
Pioneer
Profitronic
Proscan
Protec
Pulsar
Quarter
Quartz
Quasar
RCA
Radio Shack
Radix
Randex
011
000
008
014
026
005
015
014
004
005
000
015
004
023
023
023
025
004
023
004
005
004
004
000
008
027
004
000
017
005
023
004
005
031
020
004
004
008
004
004
005
014
023
013
015
007
011
011
004
013
000
005
005
Realistic
008
026
Runco
STS
Samsung
Sanky
Sansui
Sanyo
Scott
Sears
026
025
026
005
006
Semp
Sharp
Shintom
Shogun
Singer
Sony
Syvania
Symphonic
TMK
Tatung
Teac
Technics
Teknika
Thomas
Toshiba
Totevision
Unitech
Vector
Vector Research
Video Concepts
Videosonic
Wards
009
000
007
016
000
019
028
005
017
029
027
021
007
011
012
031
023
032
014
027
015
014
009
026
006
027
032
021
028
005
017
028
029
030
001
022
023
029
008
031
006
016
White WestingHouse
XR-100
Yamaha
Zenith
Ameira High
Brocksonic
Colt
Cutis Mathes
Daewoo
Emerson
Funai
GE
021
016
028
004
029
027
031
023
008
Hitachi
HQ
Lloyds
MGA
Megavox
019
73
004 005 027
011
007
008
023 010 033
027 007
000 014 021
012 023 017
020 010 018
004 005 012
011
010
027
015
023
015
004 002 000
004 016 000
000
023
026
000 026
004 028
004 005 000
000
010 009
005 023
023
010
006
010
023
013 004 027
000 008 015
021 025
004 000 015
006
007 000 021
004 (TV use 008)
001
015
004 (TV use 008)
025
001
000
004 (TV use 008)
027 (TV use 041)
004 (TV use 008)
000
000
023
016 (TV use 010)
000
012
000
026
011
009
000
024
017
ENGLISH
Headquarter
Hitachi
Hughes Net.Sys
JVC
Jensen
KEC
KLH
Kenwood
Kodak
LXI
Lloyd’s
Logik
MEI
MGA
MGN Technology
MTC
Magnasonic
Magnavox
Magnin
Marantz
Marta
Matsushita
Memorex
008
017
016
023
003
009
012
019
003
013 (TV use 012)
023
000
004 (TV use 008)
ENGLISH
Magnin
Memorex
Mitsubishi
Orion
Panasonic
Penney
Quasar
RCA
Sansui
Sanyo
Sear
Sharp
Sony
Symphonic
Zenith
023
005 028 (TV use 025)
027 (TV use 041)
001
004 (TV use 008) 028 (TV use 042)
004 (TV use 008) 023
028 (TV use 042)
004 (TV use 008) 028 (TV use 042)
013 (TV use 012) 004 (TV use 008)
027 (TV use 041)
000
023
000 005
027 (TV use 041)
002 (TV use 000)
000
000
CBL
ABC
Allegro
Archer
Bell&Howell
Century
Citizen
Comtronics
Contec
Easten
Emerson
Everquest
Focus
Garrard
Gemini
General Instrument
GoldStar
Goodmind
Hamlin
Hitachi
Hytex
Jasco
Jerrold
DVD
Harman/Kardon
JVC
Kenwood
Megavox
Mitsubishi
Onkyo
Panasonic
Philips
Pioneer
Proscan
RCA
Samsung
Sherwood
Sony
Technics
Theta Digital
Toshiba
Yamaha
Zenith
009
008
005
011
016
011
013
011
003
002
002
017
001
020
004
013
014
011
013
011
006
014
012
021
Movie Time
NSC
Oak
Optimus
Panasonic
Philips
Pioneer
Popular Mechanics
RCA
Radio Shack
Recoton
Regal
Regency
Rembrandt
Sherwood
SL Marx
Smasung
Scientific Atlanta
Signal
Signature
Sprucer
Starcom
026
000
022
018
023
019
025
007
010
74
002
007
018
018
009
018
018
014
011
001
026
010
022
018
010
033
017
026
012
006
007
010
002
006
015
015
011
031
016
018
017
022
031
010
022
012
001
006
000
014
017
003
010
006
031
002
003
006
021
026
009
008
030
276
040
006
034
020
004
013
018
007
034
021
033
032
026
028
030
027
021
014
031
025
021
020
014
023
014
010
009
010
010
010
015
014
007
010
018
007
153
015
024
022
014
AUX-LD
026
Denon
Mitsubishi
NAD
Pioneer
Sony
008
008
001
009
009
General Instrument
HTS
Hitachi
Hughes Net.Sys
JVC
Jerrold
Megavox
Memorex
Next Level
Panasonic
Philips
Primestar
RCA
Radio Shack
Realistic
Sherwood
Sony
Star Choice
Toshiba
Uniden
Zenith
016
009
011
007
009
016
006
006
006
017
006
016
003
018
014
000
004
018
010
006
013
AUX-TAPE
Aiwa
Carver
Harman/Kardon
JVC
Kenwood
Megavox
Marantz
Onkyo
Opimus
Panasonic
Pioneer
Sansui
Sony
Technics
Victor
Wards
Yamaha
015
018
015
005
005
015
002
005
004
004
016
022
008
004
004
012
002
038
002
004
021
038
024
002
010
034
004
024
025
020
020
011
014
026
009
AUX-AMP
012
Aiwa
Carver
Curtis Mathes
Denon
Harman/Kardon
Linn
Megavox
Marantz
Panasonic
Philips
Pioneer
Sony
Technics
Wards
Yamaha
014
AUX-TAPE/MD
Sherwood
018
019
SAT
AlphaStar
Chaparral
Echostar
Expreevu
007
007
007
007
017
ENGLISH
Stargate
Starquest
TV86
Teleview
