Portable Digital Mixer
Digital Portable Mixer
DMX-P01
Digital audio mixing - stepping into ENG and EFP
E
ffective audio quality is now more important than ever for Electronic News Gathering (ENG) and Electronic Field Production (EFP) applications
because, even with high-quality video, lackluster audio performance will result in a mediocre production.
Introducing the DMX-P01 Digital Portable Mixer, Sony’s answer to these high-quality audio requirements. Not only does the DMX-P01 offer
outstanding audio quality, it is also one of the most user-friendly mixers in the ENG and EFP markets.
With full 24-bit processing and a sampling rate of either 48kHz or 96kHz, the DMX-P01 provides sound quality comparable to high-end production
mixers. Its front panel is human engineered to allow fast, easy, and accurate setting adjustments - essential when working in the field. It also
includes other useful features, such as panel-lock and parameter-lock functions, selectable meter scales, camera-audio return-level check,
memory function, digital cascade capability, and digital outputs.
All of this functionality and versatility is packaged into one sleek, compact, and lightweight body that can be used effortlessly in field productions.
Make the DMX-P01 your first step into the world of portable digital-audio mixing in the field.
◗◗◗Digital Benefits of the DMX-P01
Excellent Sound Quality/Full Digital
Processing
In order to provide outstanding sound quality for ENG and
EFP applications, the DMX-P01 offers full digital-audio
processing. Its 24-bit A/D and D/A converters provide a
high level of linearity for analog inputs and outputs.
Internally, the unit utilizes 32-bit digital processing for
maximum throughput. In addition, the DMX-P01 has a
sampling rate that is selectable from either 48kHz or
96kHz.
High-Quality Digital Limiters/Compressors
By using digital limiters and compressors, the DMX-P01
can provide extremely high-quality sound in one small
package. Limiters are available at the input, and both
limiters and compressors are available at the output for
maximum flexibility.
Full Parameter Controls From The Front
Panel
The DMX-P01 puts all of its controls at your fingertips,
with a cleanly organized and logical layout on the unit’s
front panel. The DMX-P01 processes audio digitally, so
parameters that are used less frequently are stored
internally and accessed only when needed. Using the
front-panel controls and easy-to-read LCD allows full
control of every parameter without the need to remove
the unit from its audio-organizer case. The LCD panel is
also equipped with a backlight, so the unit can be used
in low-light conditions too.
Panel-Lock and Parameter-Lock Features
One major concern for audio engineers in the field is the
accidental bumping of controls, which can inadvertently
change the sound settings. The DMX-P01 safeguards
against this with its panel-lock feature, which can be set
to secure all of the control settings, or selected individual
control settings. With the lock engaged, physical contact
with the controls will not alter their settings. In addition,
a Parameter-Lock feature also prevents inadvertent
parameter changes.
Flexible Meter Scales
Because the DMX-P01 is a digital mixer, the meter
calibrations can be easily changed from one type to
another without the need to replace the entire meter.
LEFT PANEL
Six easy-to-change meter scale sheets are supplied:
VU, PPM1 (BBC-type), PPM2 (DIN-type), PPM3 (NORDICtype), PPM4 (IEC-type1), and dBFS. Simply insert the
desired scale sheet and select the appropriate meter type
from the setup menu. The DMX-P01 will display the
audio level according to the scale selected.
Camera-Audio Return-Level Check
The DMX-P01 enables users to visually verify that the
mixer’s audio level matches the level recorded to the
camcorder tape. This is done using the camera return-level
mode, available in the setup menu. Simply send a
reference tone signal to the camcorder and the level
difference between the mixer output and camcorder
return signal will be displayed. Then adjust the marker to
the central position, and the level adjustment is complete.
Memory Function
The DMX-P01 processes audio digitally, so users can
effortlessly store and recall parameters from the setup
menu. There are two memory functions: “Power-On
Memory Recall,” and “Scene Memory Recall.”
Power-On Memory Recall - When the DMX-P01 is powered
on, the system is capable of recalling parameters in three
different ways: with the default factory settings, with the
same settings as the last time the unit was used, or with
the parameters of one specific scene memory.
Scene Memory Recall - This feature allows users to recall
up to ten different user-defined parameter settings or the
factory default settings.
In situations where a single unit is required to serve
multiple users or multiple shooting scenarios, these
features can prove invaluable.
Digital Cascade
For applications requiring additional inputs, DMX-P01
mixers can be cascaded using a digital connection
between mixers. The benefit of cascading mixers digitally
is that sound quality is not degraded, as it would be when
cascading analog mixers.
Digital Output
The DMX-P01 is equipped with a digital output, which
can be used to send audio to digital peripheral equipment
such as DAT recorders. AES/EBU and S/PDIF (IEC 60958)
coaxial interfaces are available for master outputs.
RIGHT PANEL
◗◗◗Features
Inputs
• 4 microphone/line inputs with XLR type balanced connectors
• +48 V power for each microphone input
• Digital cascade input with phono connector
• Microphone/line gain-level control
• Level control knobs with stereo-link facility
• Selectable sampling rate (48 kHz or 96 kHz) for A/D
converters
Outputs
• 2 balanced outputs with XLR-type connectors
• Digital AES/EBU output (stereo) with XLR-type
connector
• Coaxial output connector for mix-bus output
(for cascade) or S/PDIF digital output (selectable)
• Stereo tape output with unbalanced 3.5 mm TRS jack
• Switchable output mode: stereo or monaural
• Selectable output-level control for L/R master outputs
and camera send
• Selectable sampling rate (48 kHz or 96 kHz) for D/A
converters
Panning
• Variable pan controls
Low Cut Filters
• Adjustable cut-off frequencies for 2 user settings (A/B)
• Quick parameter-recall switch with OFF/A/B positions
Limiters/Compressors
• Digital limiters on both inputs and outputs
• Digital compressors on outputs
• Precise parameter control on threshold and ratio value,
attack and release time
• Link function (ON/OFF switchable)
• LED indicators for output limiter/compressor operation
Link/M-S Operation
• Links input levels, LCFs, and PAN controls for channels
1/2 and 3/4
• Links output levels for master left/right outputs
• Decodes M-S microphone inputs, and links the input
levels of channels 1/2 and 3/4
• Phase reverse on channels 2 and 4 (M-S decode)
LCD Panel
• Various level-meter displays: VU, PPM1 (BBC-type),
PPM2 (DIN-type), PPM3 (NORDIC-type), PPM4
(IEC-type1), dBFS
• Displays setup menus and allows various parameter
settings
• Ten user-scene memory settings (each including level
meter, LCF, limiter/compressor, and link status)
• Six scale sheets supplied for different level-meter
calibrations
• Back light
• Heated LCD* for low-temperature conditions
Monitoring
• 2 outputs: 1/4-inch phone jack and 3.5-mm mini jack
• Six monitoring modes: left output, right output, stereo
output, left/right-mixed monaural, M/S decode and
camera return
• Level-control knob
Camera-Audio Send/Return-Level Control
• Stereo return from a camcorder via 12-pin balanced
connector
• Precise level control on LCD with auto-evaluation
function for return level
• Monitoring capability with headphones
Oscillator/Talkback (selectable)
• Oscillator: 1-kHz pilot-tone signal into all outputs
• Talkback: slate into all outputs
• Momentary and alternative modes for both oscillator
and talkback
Power
• External DC 10 to 15 V input with 4-pin XLR connector
• External DC 10 to 15 V input with jack connector
• DC 10 to 15 V output* with 4-pin Hirose connector for
a wireless microphone receiver
• 8 internal AA-size (LR6) batteries for approximately 5
hours of continuous operation
• Spare battery-compartment for quick battery change
*When operated on alkaline batteries, power is not supplied to
the wireless microphone receiver nor is the LCD panel heated.
◗◗◗System Example
Boom Mic
DMX-P01
Headphones
2-Ch Portable
Receiver
Bodypack
Transmitters
Portable DAT Recorder
Camcorder
◗◗◗Specifications
Inputs
Channel inputs (analog)
Cascade input (digital)
Outputs
Master outputs (analog)
4 ch, XLR-3-31 (x 4), electrically balanced, microphone
power; +48 V (on/off)
Mic level; -70 to -30 dBu (max. -10 dBu), 2.2 kΩ or more
Line level; -30 to +10 dBu (max. +30 dBu), 10 kΩ or more
2 busses (L/R), coaxial, 75 Ω
2 ch (L/R), -60/-20/+4 dBu (max. +24 dBu), XLR-3-32 (x 2),
balanced, 600 Ω load or more
Master outputs (digital)
2 ch (L/R), AES/EBU, XLR-3-32 (x 1), 110 Ω load
2 ch (L/R), IEC 60958 coaxial (x 1), 75 Ω load
Tape outputs (analog)
2 ch (L/R), -10 dBu (max. +10 dBu), 3.5 mm dia. TRS jack,
unbalanced, 10 kΩ load or more
Camera send/return (analog) 2 ch (L/R), 12-pin, female, balanced,
Send level; -60/-20/+4 dBu (max. +24 dBu), 600 Ω load or more
Return level; 0 dBu (max. +20 dBu), 10 kΩ
A/D converter
24 bits
D/A converter
24 bits
Sampling frequency
48 kHz or 96 kHz
Internal signal processing
32 bits
Low cut filter
70 to 400 Hz (at 96 kHz sampling frequency), 12 dB/octave
50 to 400 Hz (at 48 kHz sampling frequency), 12 dB/octave
Input limiter
Threshold: 0 to +20 dB (in 2 dB steps)
Output limiter/compressor
Threshold: -20 to +10 dB (in 2 dB steps)
Ratio: 2:1, 4:1, 6:1, or 10:1
Attack time: 0.5 ms, 10 ms, or 100 ms
Release time: 0.1 s, 1.0 s, or 2.0 s
Frequency response
20 Hz to 40 kHz +0.5/-3.0 dB (at 96 kHz sampling frequency)
20 Hz to 20 kHz +0.5/-1.0 dB (at 48 kHz sampling frequency)
Total harmonic distortion
0.05% or less
Equivalent input noise
-130 dBu, 150 Ω terminated, IHF-A (mic input, typical)
Crosstalk
-90 dB (1kHz) or less
Delay time
1 ms or less at 96 kHz sampling frequency, including A/D D/A
conversions
2 ms or less at 48 kHz sampling frequency, including A/D D/A
conversions
Level meter calibration
VU, BBC-type DIN-type, NORDIC-type, IEC-type1,
dBFS (selectable)
Headphone output
1/4-inch TRS jack (x 1) and 3.5-mm dia. TRS jack (x 1),
300 mW, 32 Ω load or more
Operating voltage
Internal
DC 12 V (eight AA-size (LR6) alkaline batteries)
External
DC 10 to 15 V via XLR 4-pin connector and DC jack
Battery life
Approximately 5 hours
(with Sony AA-size alkaline (when the sampling frequency is 48 kHz and the LCD backlight
batteries (LR6SG) at 25 ºC) and +48 V microphone power are not used.)
Power supply
DC 10 to 15 V via 4-pin Hirose connector, female
(to wireless microphone)
Operating temperature
0 to +45 ºC (+32 to +113 ºF)
Storage temperature
-20 to +60 ºC (-4 to +140 ºF)
Dimensions (W x H x D)
266 x 68 x 206 mm (10 1/2 x 2 3/4 x 8 1/8 inches)
Weight
Approx. 2.2 kg (4 Ib 13 oz)
Supplied accessories
Spare battery-compartment (x 1), 12-pin male connector (x 1),
meter scale sheets (x 1 set), cascading belt (x 1),
operating instructions (x 1), rubber foot (x 1 set)
®
Sony Electronics Inc.
1 Sony Drive
Park Ridge, NJ 07656
www.sony.com/proaudio
A-1101-A
MK10015V3IW03JUN
◗◗◗Block Diagram
LEVEL
METER
+48V
24bit
96k/48kHz
Mic
CH1
ATT
Line
+48V
M-S
Line
M-S
Mic
INPUT
LIMITER
LIM
ADC
CHANNEL
VOL
Line
Trim
+10 to -30 dBu
-30 to -70 dBu
OFF
MASTER
VOL
LIM
STEREO
/MONO
ATT
OUTPUT L
ATT
OUTPUT R
MIC
DAC
1kHz
LIM
OUTPUT
COMP/
LIMITER
S/PDIF
CASCADE
24bit
96k/48kHz
+4/-20/-60dBu
CAMERA
DO
COAXIAL
LINK/M-S
LCF
ATT
PAN
AES/EBU
TAPE OUT
-10dBu
1kHz
OFF
LIM
INPUT
LIMITER
OFF A B
Trim
+10 to -30 dBu
-30 to -70 dBu
+48V
CHANNEL
VOL
LCF
ADC
ATT
PAN
24bit
96k/48kHz
DO
PEAK
LED
MIC
24bit
96k/48kHz
Mic
CHANNEL
LEVEL VOL
METER
OFF A B
Trim
+10 to -30 dBu
-30 to -70 dBu
+48V
CH4
INPUT
LIMITER
LIM
ADC
Line
CH3
LINK/M-S
LCF
ATT
PAN
LIM
INPUT
LIMITER
OFF A B
Trim
+10 to -30 dBu
-30 to -70 dBu
Mic
CH2
CHANNEL
VOL
LCF
ADC
LEVEL
METER
PAN
PHONES
HEADPHONE
SELECT
/M-S DECORD
HEADPHONE
AMP
DAC
PHONES
OFF A B
DC OUT
CPU
CASCADE
IN
DC IN
XLR Type
DI
INT SYNC / DI SYNC
DC IN JACK
OSC
1kHz
LCD HEATER
96kHz
SAMPLING-RATE SELECT
SLATE
MIC
8 x LR6
(AA SIZE)
INT/EXT
SW
48kHz
AGC/ADC
POWER SW
© 2003 Sony Corporation. All rights reserved.
Reproduction in whole or in part without written permission is prohibited.
Features and specifications are subject to change without notice.
All non-metric weights and measurements are approximate.
Sony is a trademark of Sony.
Printed in USA (7/03)
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
