LG | SMC-EZ1016DT | User guide | LG SMC-EZ1016DT network switch

USER GUIDE
SMC-EZ1016DT
SMC-EZ1024DT
EZ SwitchTM 10/100 16/24-port
Unmanaged Fast Ethernet Switch
Copyright
Information furnished by LG-Ericsson USA, Inc. is believed to be accurate and reliable.
However, no responsibility is assumed by LG-Ericsson USA, Inc. for its use, nor for any
infringements of patents or other rights of third parties, which may result from its use. No
license is granted by implication or otherwise under any patent or patent rights of LG-Ericsson USA, Inc. LG-Ericsson USA, Inc.reserves the right to change specifications at any
time without notice.
© Copyright 2011. LG-Ericsson USA, Inc. All rights reserved. LG-Ericsson is a registered
trademark. Other products and company names are trademarks and registered trademarks of their respective holders.
Technical Support
To Contact LG-Ericsson Technical Support
Phone: 877.828.2673
Email: support@lgericssonus.com
Online: http://www.lgericssonus.com
Warranty and Product Registration
To register LG-Ericsson products and to review the detailed warranty statement,
please refer to the LG-Ericsson Website at http://www.lgericssonus.com
COMPLIANCES
FCC - Class A
Federal Communication Commission Interference Statement
This Equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful
interference to radio communications.
Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to
correct the interference at his own expense.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received; including interference that may cause
undesired operation.
EC Conformance Declaration - Class A
SMC contact for these products in Europe is:
SMC Networks Europe,
Edificio Conata II,
Calle Fructuós Gelabert 6-8, 2o, 4a,
08970 - Sant Joan Despí,
Barcelona, Spain.
This information technology equipment complies with the
requirements of the Council Directive 2004/108/EC on the
Approximation of the laws of the Member States relating to
Electromagnetic Compatibility and 2006/95/EC for electrical
equipment used within certain voltage limits and the Amendment
Directive 2006/95/EC. For the evaluation of the compliance with
these Directives, the following standards were applied:
v
RFI Emission:
•
•
•
Limit class A according to EN 55022:2006 (EMC)
Limit class A for harmonic current emission according to EN
61000-3-2/2000+A2:2005
Limitation of voltage fluctuation and flicker in low-voltage
supply system according to EN
61000-3-3/1995+A1:2001+A2:2005
Immunity:
•
•
•
•
•
•
•
•
LVD:
•
Product family standard according to EN
55024:1998+A1:2001+A2:2003
Electrostatic Discharge according to EN 61000-4-2:2001
ED.1.2
(Contact Discharge: ±4 kV, Air Discharge: ±8 kV)
Radio-frequency electromagnetic field according to EN
61000-4-3:2006 ED.3.0
(80 - 1000 MHz with 1 kHz AM 80% Modulation: 3 V/m)
Electrical fast transient/burst according to EN
61000-4-4:2004 ED.2.0(AC/DC power supply: ±1 kV,
Data/Signal lines: ±0.5 kV)
Surge immunity test according to EN 61000-4-5:2005 ED.2.0
(AC/DC Line to Line: ±1 kV, AC/DC Line to Earth: ±2 kV)
Immunity to conducted disturbances, Induced by
radio-frequency fields:
EN 61000-4-6:2006 ED.2.2 (0.15 - 80 MHz with 1 kHz AM
80% Modulation: 3 V/m)
Power frequency magnetic field immunity test according to
EN 61000-4-8:2001 ED.1.1 (1 A/m at frequency 50 Hz)
Voltage dips, short interruptions and voltage variations
immunity test according to EN 61000-4-11:2004
ED.2.0(>95% Reduction @10 ms, 30% Reduction @500 ms,
>95% Reduction @5000 ms)
EN 60950-1:2006
vi
VCCI - Class A
この装置は、情報処理装置等電波障害自主規制協議会(VCCI)の基準に基づくク
ラスA情報技術装置です。この装置を家庭環境で使用すると電波妨害を引き起こ
すことがあります。この場合には使用者が適切な対策を講ずるよう要求されることが
あります。
Please read the following safety information
carefully before installing the Switch:
WARNING: Installation and removal of the unit must be carried out
by qualified personnel only.
•
•
•
•
•
•
This guide is intended for use by network administrators who
are responsible for setting up and installing network
equipment; consequently it assumes a basic working
knowledge of LANs (Local Area Networks).
The unit must be connected to an earthed (grounded) outlet
to comply with international safety standards.
Do not connect the unit to an A.C. outlet (power supply)
without an earth (ground) connection.
The appliance coupler (the connector to the unit and not the
wall plug) must have a configuration for mating with an EN
60320/IEC 320 appliance inlet.
The socket outlet must be near to the unit and easily
accessible. You can only remove power from the unit by
disconnecting the power cord from the outlet.
This unit operates under SELV (Safety Extra Low Voltage)
conditions according to IEC 60950. The conditions are only
maintained if the equipment to which it is connected also
operates under SELV conditions.
vii
France and Peru only
This unit cannot be powered from IT. supplies. If your supplies are of
IT type, this unit must be powered by 230 V (2P+T) via an isolation
transformer ratio 1:1, with the secondary connection point labelled
Neutral, connected directly to earth (ground). †Impédance à la terre
Power Cord Set
U.S.A. and
Canada
Denmark
Switzerland
U.K.
Europe
The cord set must be UL-approved and CSA
certified.
The minimum specifications for the flexible
cord are: - No. 18 AWG - not longer than 2
meters, or 16 AWG. - Type SV or SJ 3-conductor
The cord set must have a rated current
capacity of at least 10A.
The attachment plug must be an
earth-grounding type with NEMA 5-15P (15 A,
125 V) or NEMA 6-15P (15 A, 250 V)
configuration.
The supply plug must comply with Section
107-2-D1, Standard DK2-1a or DK2-5a.
The supply plug must comply with SEV/ASE
1011.
The supply plug must comply with BS1363
(3-pin 13 A) and be fit-ted with a 5 A fuse
which complies with BS1362.
The mains cord must be <HAR> or <BASEC>
marked and be of type HO3VVF3GO.75
(minimum).
The supply plug must comply with CEE7/7
(.SCHUKO.).
The mains cord must be <HAR> or <BASEC>
marked and be of type HO3VVF3GO.75
(minimum).
IEC-320 receptacle.
viii
Veuillez lire à fond l’information de la sécurité
suivante avant d’installer le Switch:
AVERTISSEMENT: L.installation et la dépose de ce groupe doivent
être confiés à un personnel qualifié.
•
•
•
•
•
Ne branchez pas votre appareil sur une prise secteur
(alimentation électrique) lorsqu’il n’y a pas de connexion de
mise à la terre (mise à la masse).
Vous devez raccorder ce groupe à une sortie mise à la terre
(mise à la masse) afin de respecter les normes
internationales de écurité.
Le coupleur d.appareil (le connecteur du groupe et non pas la
prise murale) doit respecter une configuration qui permet un
branchement sur une entrée d.appareil EN 60320/IEC 320.
La prise secteur doit se trouver à proximité de l.appareil et
son accès doit être facile. Vous ne pouvez mettre l.appareil
hors circuit qu.en débranchant son cordon électrique au
niveau de cette prise.
L.appareil fonctionne à une tension extrêmement basse de
sécurité qui est conforme à la norme IEC 60950. Ces
conditions ne sont maintenues que si l.équipement auquel il
est raccordé fonctionne dans les mêmes conditions.
France et Pérou uniquement:
Ce groupe ne peut pas être alimenté par un dispositif à impédance à
la terre. Si vos alimentations sont du type impédance à la terre, ce
groupe doit être alimenté par une tension de 230 V (2 P+T) par le
biais d.un transformateur d.isolement à rapport 1:1, avec un point
secondaire
de connexion portant l.appellation Neutre et avec raccordement
direct à la terre (masse).
ix
Cordon électrique - Il doit être agréé dans le pays
d.utilisation
Etats-Unis et
Le cordon doit avoir reçu l′homologation
Can-ada:
des UL et un certificat de CSA.
Les spe’cifications minimales pour la corde
flexible sont AWG No. 18, ou AWG No. 16
pour une longueur infe’rieure a‘ 2 me’tres:
- type SV ou SJ
- 3 conducteurs
Le cordon doit être en mesure d.acheminer
un courant nominal d.au moins 10 A.
La prise femelle de branchement doit être
du type à mise à la terre (mise à la masse)
et respecter la configuration NEMA 5-15P
(15 A, 125 V) ou NEMA 6-15P (15 A, 250
V).
Danemark:
La prise mâle d.alimentation doit
respecterla la section 107-2 D1 de norme
DK2 1a ou DK2 5a.
Cordon électrique - Il doit être agréé dans le pays d.utilisation
Suisse:
La prise mâle d.alimentation doit respecter
la norme SEV/ASE 1011.
Europe
La prise secteur doit être conforme aux
normes CEE 7/7 (.SCHU- KO. LE cordon
secteur doit porter la mention <HAR> ou
<BASEC> et doit être de type
HO3VVF3GO.75 (minimum).
x
Bitte unbedingt vor dem Einbauen des RPU die
folgenden Sicherheitsanweisungen durchlesen:
WARNUNG: Die Installation und der Ausbau des Geräts darf nur
durch Fachpersonal erfolgen.
• Diese Anleitung ist fr die Benutzung durch
Netzwerkadministratoren
vorgesehen, die fr die Installation und das einstellen von
Netzwerkkomponenten verantwortlich sind; sie setzt Erfahrung
bei der Arbeit mit LANs (Local Area Networks) voraus.
• Das Gerät sollte nicht an eine ungeerdete
Wechselstromsteckdose
angeschlossen werden.
• Das Gerät muß an eine geerdete Steckdose angeschlossen
werden,
welche die internationalen Sicherheitsnormen erfüllt.
• Der Gerätestecker (der Anschluß an das Gerät, nicht der
Wandsteckdosenstecker) muß einen gemäß EN 60320/IEC 320
konfigurierten Geräteeingang haben.
• Die Netzsteckdose muß in der Nähe des Geräts und leicht
zugänglich sein. Die Stromversorgung des Geräts kann nur durch
Herausziehen des Gerätenetzkabels aus der Netzsteckdose
unterbrochen werden.
• Der Betrieb dieses Geräts erfolgt unter den SELV-Bedingungen
(Sicherheitskleinstspannung) gemäß IEC 60950. Diese
Bedingungen sind nur gegeben, wenn auch die an das Gerät
angeschlossenen Geräte unter SELV-Bedingungen betrieben
werden
Stromkabel.
Dies muss von dem Land, in dem es benutzt wird geprüft werden:
Dieser Stromstecker muß die SEV/ASE
Schweiz
1011Bestimmungen ein- halten.
Das Netzkabel muß vom Typ HO3VVF3GO.75
(Mindestan-forderung) sein und die Aufschrift
Europe
<HAR> oder BASEC> tragen Der Netzstecker muß
die Norm CEE 7/7 erfüllen (.SCHUKO.).
xi
Warnings and Cautionary Messages
Warning: This product does not contain any serviceable user parts.
Warning: Installation and removal of the unit must be carried out
by qualified personnel only.
Warning: When connecting this device to a power outlet, connect
the field ground lead on the tri-pole power plug to a valid earth
ground line to prevent electrical hazards.
Caution: Wear an anti-static wrist strap or take other suitable
measures to prevent electrostatic discharge when handling this
equipment.
Caution: Do not plug a phone jack connector in the RJ-45 port. This
may damage this device. Les raccordeurs ne sont pas utilisé pour le
système téléphonique!
Caution: Use only twisted-pair cables with RJ-45 connectors that
conform to FCC standards.
Warnings (in German)
Achtung: Dieses Produkt enthält keine Teile, die eine Wartung vom
Benutzer benötigen.
Achtung: Installation und Deinstallation des Gerätes müssen von
qualifiziertem Servicepersonal durchgeführt werden.
Achtung: Wenn das Gerät an eine Steckdose angeschlossen wird,
muß der Masseanschluß n Netzstecker mit Schutzerde verbunden
werden, um elektrische Gefahren zu vermeiden.
Warnings (in Korean)
A 급기기 (업무용 정보통신기기)
이 기기는 업무용으로 전자파 등록을 한 기기 이오니 판매자 또는
사용자는 이 점을 주의 하시기 바라며, 만약 잘못 판매 또는 구입하였을
때에는 가정용으로 교환하시기 바랍니다.
xii
Environmental Statement
The manufacturer of this product endeavors to sustain an
environmentally-friendly policy throughout the entire production
process. This is achieved though the following means:
• Adherence to national legislation and regulations on
environmental production standards.
• Conservation of operational resources.
• Waste reduction and safe disposal of all harmful un-recyclable
by-products.
• Recycling of all reusable waste content.
• Design of products to maximize recyclables at the end of the
product’s life span.
• Continual monitoring of safety standards.
End of Product Life Span
This product is manufactured in such a way as to allow for the
recovery and disposal of all included electrical components once the
product has reached the end of its life.
Manufacturing Materials
There are no hazardous nor ozone-depleting materials in this
product.
Documentation
All printed documentation for this product uses biodegradable paper
that originates from sustained and managed forests. The inks used
in the printing process are non-toxic.
Purpose
This guide details the hardware features of the switch, including Its
physical and performance-related characteristics, and how to install
the switch.
Audience
The guide is intended for use by network administrators who are
responsible for installing and setting up network equipment;
consequently, it assumes a basic working knowledge of LANs
(Local Area Networks). Diese Anleitung ist für die Benutzung durch
Netzwerkadministratoren vorgesehen, die für die Installation und
das einstellen von Netzwerkkomponenten verantwortlich sind; sie
setzt Erfahrung bei der Arbeit mit LANs (Local Area Networks)
voraus.
xiii
TABLE OF CONTENTS
INTRODUCTION.................................. 2
Green Saving Switches…………………………………………….2
Features and Benefits ....................................... 2
Front Panel LEDs .............................................. 4
Front Panel ...................................................... 4
Rear Panel ....................................................... 4
INSTALLING THE SWITCH .................... 5
Package Contents ............................................. 5
Selecting a Site ................................................ 5
Instructions ..................................................... 6
TROUBLESHOOTING ........................... 7
Diagnosing Switch Indicators ............................. 7
CABLES ............................................. 8
Cable Specifications .......................................... 8
10BASE-T/100BASE-TX Pin Assignments ............. 8
PRODUCT SPECIFICATIONS ................. 9
INTRODUCTION
The EZ Switch™ 10/100 SMC-EZ1016DT and SMC-EZ1024DT are
16/24-port Fast Ethernet switches. The 10BASE-T/100BASE-TX
ports deliver dedicated 10/100 Mbps links to each attached LAN
segment – all with conventional cabling and adapters.
Auto-negotiation is used to select the optimal communication mode
for each connection. Auto-sensing is used to select the optimal
transmission speed for each connection. With store-and-forward
switching and flow control, maximum data integrity is always
maintained, even under heavy loading. Easy installation and
reliability make this plug-and-play switch an ideal choice for smooth
Fast Ethernet integration.
Green Saving Switches
The Green Saving technologies are intelligent, innovative algorithms
that detect link status and distance to best save power while
maintaining performance and stability.
l
Power saving by Auto-Detection of the number of active
ports:
The SMC-EZ1016DT/SMC-EZ1024DT switches will auto-detect
the link status and automatically cut off power at a given port
during periods of idle (when a port is unconnected or a PC is
turned off). After it detects an incoming signal, it wakes up from
power saving mode and operates in normal mode.
l
Power saving by Cable length Auto-Detection:
The SMC-EZ1016DT/SMC-EZ1024DT switches can actively
detect the presence of a shorter cable and determines the
appropriate power level based on cable length so there’ll be
less power consumption when the link distance is shorter.
2
Features and Benefits
•
Save up to 59% of power usage with the
SMC-EZ1016DT/SMC-EZ1024DT switches
- If PCs connected to the switches are turned off, the
switches can save up to 59% for the power used. And
even under full traffic load, the switches can still save up to
21% power consumption.
- If cable length is less than 20 meters, each switch can save
up to 12% for the power used.
•
Auto-negotiation of half or full duplex, and auto-sensing of
transmission speed, on all ports
•
Auto configuration for MDI/MDI-X cable connection allows
connections to servers, workstations, hubs or switches to be
made with straight-through cabling
•
ANSI/IEEE 802.3u compliance ensures compatibility with
standards-based hubs, switches and cards from any vendor
•
Store-and-forward switching ensures error-free transmission
•
Half- and full-duplex flow control prevents packets from
being dropped under heavy loading
•
Plug-and-play
•
“At-a-glance” LEDs for port and system status monitoring
•
Desktop and rack mountable
3
Front Panel LEDs
The front panel of the switch provides a link status LED for each
RJ-45 port. In addition, the front panel also contains status LEDs for
“at-a-glance” system monitoring. The following table details the
functions of the various indicators:
Port and Switch Status LEDs
LED
Condition
Status
Power
On Green
The switch is receiving power.
On
The port has established a valid
network connection.
Traffic is passing through the
port.
The port has not established any
network connection.
Ports
Link/Act
Flashing
Off
Front Panel
SMC-EZ1024DT
SMC-EZ1016DT
Rear Panel
The AC power connector is located on the rear panel of the switch.
4
INSTALLING THE SWITCH
Before installing the switch, verify that you have all the items listed
under “Package Contents.” Note that the switch can be installed on
any suitably large flat surface or in a standard EIA 19-inch rack.
Package Contents
The EZ Switch 10/100 includes:
•
•
•
•
•
EZ Switch 10/100 (SMC-EZ1016DT or SMC-EZ1024DT)
Four rubber foot pads
Rack-mount bracket kit
Appropriate AC power cord
This User Manual
Selecting a Site
Be sure to follow the site selection guidelines below when choosing a
location:
•
•
•
Select a suitable location for the switch:
o It should be accessible for installing, cabling and
maintaining the switch.
o The temperature and humidity should be within the
ranges listed in the specifications.
o The status LEDs should be clearly visible.
o There should be adequate space (approximately two
inches) on all sides for proper air flow.
Make sure twisted-pair cable is always routed away from
power lines, fluorescent lighting fixtures and other sources of
electrical interference such as radios, transmitters, etc.
Make sure that a properly grounded power outlet is within
2.44 meters (8 feet) of the switch and is powered from an
independent circuit breaker. As with any equipment, using a
filter or surge suppressor is recommended.
5
Instructions
1. Positioning the Switch: For desktop or shelf mounting, attach
the four adhesive foot pads to the bottom of the switch. For rack
mounting, install into a standard EIA 19-inch rack using the
included brackets.
2. Applying Power: Plug one end of the power cord into the socket
on the switch’s rear panel, and the other end into an appropriate
electrical outlet. Check the Power LED to be sure power is on.
Note: It is not necessary to power off the switch before connecting
or disconnecting any UTP cables, as these actions will not disrupt the
operation of other devices attached to the switch.
3. Connecting PCs: Connect each PC to an RJ-45 port on the
switch using Category 5 or 5e shielded or unshielded twisted-pair
(UTP or STP) cable, maximum length 100 meters (328 ft). The EZ
Switch 10/100 will support up to 16 or 24 PCs. All ports on the
switch support automatic MDI/MDI-X operation, so you can use
straight-through cables for all network connections to PCs or
servers, or to other switches or hubs.
Note: If an attached device does not support auto-negotiation, the
data rate will be sensed automatically and the communication mode
will default to half duplex.
4. Cascading Switches and Other Network Devices: All the
ports on the switch support automatic MDI/MDI-X configuration
for cable connections. This allows you to use straight-through
cable to connect to other switches or hubs from any port on the
switch. No crossover cables or other device settings are needed.
See the Cable Specifications.
Caution: Do not plug a phone jack connector into any RJ-45 port.
This switch, instead, use only twisted-pair cables with RJ-45
connectors that conform with FCC standards.
6
TROUBLESHOOTING
Diagnosing Switch Indicators
1. Symptom
Power LED does not light after power on.
Probable Causes
o AC power cord may be defective.
Possible Solutions
o Check for loose connections.
o Check the power outlet by using it for another device.
o Replace the AC power cord.
2. Symptom
Link LED does not light after connection is made.
Probable Causes
o Switch port, network card or cable may be defective.
Possible Solutions
o Check that the switch and attached device are both
powered on.
o Be sure the network cable is connected to both
devices.
o Verify that Category 5 or better cable is used for
10/100 Mbps connections and that the length of any
cable does not exceed 100 meters (328 feet).
o Check the network card and cable connections for
defects.
o Replace the defective card or cable if necessary.
7
CABLES
Cable Specifications
Cable
10BASE-T
100BASE-TX
Cable Types and Specifications
Type
Max. Length
2-pair Cat. 3 or better
100 m (328 ft)
100-ohm UTP
2-pair Cat. 5 or better
100 m (328 ft)
100-ohm UTP
Connector
RJ-45
RJ-45
10BASE-T/100BASE-TX Pin Assignments
Caution: DO NOT plug a phone jack
connector into any RJ-45 port. Use only
twisted-pair cables with RJ-45
connectors that conform with FCC
standards.
Use unshielded twisted-pair (UTP) or shielded twisted-pair (STP)
cable for RJ-45 connections: 100-ohm Category 3 or better cable for
10 Mbps connections or 100-ohm Category 5 or better cable for 100
Mbps connections. Also be sure that the length of any twisted-pair
connection does not exceed 100 meters (328 feet).
Because all ports on this switch support automatic MDI/MDI-X
operation, you can use straight-through cables for all network
connections to PCs or servers, or to other switches or hubs. In
straight-through cable, pins 1, 2, 3, and 6, at one end of the cable,
are connected straight through to pins 1, 2, 3 and 6 at the other end
of the cable.
The table below shows the 10BASE-T/100BASE-TX MDI-X and MDI
port pinouts.
Pin
MDI-X Signal Name
MDI Signal Name
1
Receive Data plus (RD+)
Transmit Data plus (TD+)
2
Receive Data minus (RD-)
Transmit Data minus (TD-)
3
Transmit Data plus (TD+)
Receive Data plus (RD+)
6
Transmit Data minus (TD-)
Receive Data minus (RD-)
4,5,7,8
Not used at 10/100 Mbps
Not used at 10/100 Mbps
8
PRODUCT SPECIFICATIONS
EZ Switch 10/100
Standards
Conformance
Communication Rate
Communication Mode
Media Supported
Number of Ports
Indicator Panel
Dimensions
Weight
MAC Address Table
Memory Buffer
Power Consumption
Power Requirement
Temperature
Humidity
EMC/Safety
Compliances
Immunity
Emissions
IEEE 802.3-2002
Ethernet, Fast Ethernet
Full-duplex flow control
10 and 100Mbps
Full or half duplex at 10/100 Mbps
10BASE-T: 100-ohm Category 3 or better
twisted-pair
100BASE-TX: 100-ohm Category 5 or
better twisted pair
SMC-EZ1016DT: 16 RJ-45 10/100
BASE-T ports
SMC-EZ1024DT: 24 RJ-45 10/100
BASE-T ports
Power
Ports: Link/Act
SMC-EZ1016DT:21.6x13.3x4.2cm(8.5x5
.2x1.7in)
SMC-EZ1024DT:26.7x16.1x4.2cm(10.5x
6.3x1.7in)
SMC-EZ1016DT: 870g (1.9 lbs)
SMC-EZ1024DT: 1376g (3 lbs)
8 K entries
SMC-EZ1016DT: 160Kbytes
SMC-EZ1024DT: 160Kbytes
SMC-EZ1016DT: 6.831 Watts
SMC-EZ1024DT: 8.514 Watts
Input Voltage: 100 - 240 VAC@50-60 Hz
Operating: 0 ~ 40 ºC / 32 ~ 104 ºF
10% to 90% non-condensing
CE Mark
EN 61000-4-2/3/4/5/6/8/11
FCC Class A,VCCI Class A
9
Warranty Information
and Product Registration
To register LG-Ericsson products and to review the detailed
warranty statement, please refer to the LG-Ericsson Website at
http://www.lgericssonus.com
Technical Support
To Contact LG-Ericsson Technical Support
Phone: 877.828.2673
Email: support@lgericssonus.com
Online: http://www.lgericssonus.com
Copyright
Information furnished by LG-Ericsson USA, Inc. is believed to be accurate and reliable.
However, no responsibility is assumed by LG-Ericsson USA, Inc. for its use, nor for any
infringements of patents or other rights of third parties, which may result from its
use. No license is granted by implication or otherwise under any patent or
patent rights of LG-Ericsson USA, Inc. LG-Ericsson USA, Inc. reserves the
right to change specifications at any time without notice.
© Copyright 2011. LG-Ericsson USA, Inc. All rights reserved.
LG-Ericsson is a registered trademark. Other products and company
names are trademarks and registered trademarks of their respective
holders.
Model Number
SMC6128L2
SMC-EZ1016DT
SMC-EZ1024DT
EZ SwitchTM 10/100 16/24-port
Unmanaged Fast Ethernet Switch
