HP

2500C/C+/CM

Professional Series Color Printer

NETWORK GUIDE

Acknowledgments

HP ColorSmart II, HP PhotoREt II and HP ZoomSmart Scaling

Technology are trademarks of Hewlett-Packard Company.

Microsoft is a U.S. registered trademark of Microsoft Corporation.

Windows is a trademark of Microsoft Corporation.

Adobe is a U.S. registered trademark of Adobe Systems Incorporated.

PostScript 3 is a trademark of Adobe Systems Incorporated.

NetWare and Novell are registered trademarks of Novell Corporation.

Notice

The information contained in this document is subject to change without notice.

Hewlett-Packard makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.

Hewlett-Packard shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.

No part of this document may be photocopied, reproduced, or translated to another language without the prior written consent of

Hewlett-Packard Company.

Edition 2 – June 1999

© Copyright 1999 by Hewlett-Packard Company

450 Alexandra Road

Singapore 119960

Singapore

HP

2500C/C+/CM

Contents

1.

Network Printing Overview

2. Year 2000 Compliance

2.1 Year 2000-compliant Versions of HP JetDirect Software

2.2

Disclaimer Statement

3. Supported Network Printer Connections

3.1 Printing through an HP JetDirect Print Server

3.1.1

Overview

3.1.2 Supported Network Configurations for

Client-Server Printing

3.1.3

Supported Network Configurations for

Peer-to-Peer Printing

3.2

Printing through a PC

3.2.1

Supported Network Configurations for

Printing through a PC

4.

Installing the Print Server

4.1

Installing the HP JetDirect Print Server Card

5.

Customizing the Printer Software

6. Configuring to Print on the Network

6.1 Configuring the PC as a Server to Print Through the HP JetDirect Port

6.1.1 Option 1 - Using the HP JetDirect Installation Utility

6.1.2

Option 2 - Using the HP 2500C Printer Software

6.2

Configuring the PC (Client) to Connect to the Print Server via a Server

6.2.1

Option 1 - Using the HP 2500C Series Printer Software

6.2.2

Option 2 - Using the Add Printer Wizard (for PCL 3 drivers only)

6.2.3

Option 3 - Other Methods for Configuring the PC (Client)

(For PCL 3 drivers installed in the server and the port has been configured for sharing)

6.3 Configuring the PC (Peer-to-Peer) to Print Directly to the Printer

6.3.1 Option 1 - Using the HP JetDirect Installation Utility

6.3.2 Option 2 - Using the HP 2500C Series Printer Software

6.4

Configuring the JetDirect Print Server Port to Connect to the NetWare 4.11 Bindery Network

6.5

Configuring the JetDirect Print Server Port to Connect to Netware 4.11 NDS Network

6.6

Configuring the PC as a Server to Share the Printer

6.6.1

Using the HP 2500C Series Printer Software to Share the Printer

6.7 Installing Alternate Drivers

6.8 Installing PostScript Driver

7.

Troubleshooting

8.

Improving Printing Performance over the Network

12

12

12

13

14

15

16

17

17

18

19

4

5

5

1

1

2

3

4

4

4

6

7

7

8

11

11

11

12

9

9

9

10

HP

2500C/C+/CM

Network Printing Overview

1.

A network is a system of computers and other equipment set up for sharing files, data and other resources such as printers and scanners.

A LAN, or a local area network, in its smallest form may consist of two computers that can communicate with each other. A larger LAN may connect members of a workgroup, such as an accounting department where users have similar requirements for sharing data and resources.

The HP 2500C/C+/CM Professional Series Color Printer may be shared on a network. It can be connected directly to a network using an HP JetDirect print server, or it can be attached to a PC that is connected to a network.

HP

2500C/C+/CM

Year 2000 Compliance

2. For the entire HP JetDirect solution to be Year 2000-compliant, the

HP JetDirect product must work in a fully Year 2000-compliant environment. The network operating system (NOS) for the HP JetDirect product must be Year 2000-compliant. Please contact the NOS manufacturer directly to verify Year 2000 readiness.

The HP JetDirect product is Year 2000-compliant if the hardware, firmware and software are Year 2000-compliant.

Hardware

Firmware

Software

All HP JetDirect hardware is Year 2000-compliant.

All HP JetDirect firmware is Year 2000-compliant.

Most HP JetDirect software is Year 2000-compliant.

Some versions of HP JetDirect software may need to be upgraded by the customer to be Year 2000-compliant

(see

Table 1 for the list of Year 2000-compliant software).

1

2

2.1 Year 2000-compliant Versions of HP JetDirect Software

Year 2000-compliant versions of HP JetDirect software (listed in

Table 1) are available for download, at no charge, from http://www.hp.com/support/net_printing. Any version of software not listed in Table 1 has not been certified as compliant.

Table 1.

Year 2000-compliant JetDirect Software

HP JetAdmin and HP JetPrint for Novell NetWare (DOS client) version A.01.09

and A.01.15

HP JetAdmin for HP-UX 9.04 (for HP 9000 S700 and S800) version D.04.10 and

D.04.12

HP JetAdmin for HP-UX 9.10 (for HP 9000 S300 and S400) version D.01.08

HP JetAdmin for HP-UX 10.01, 10.10, 10.20, 11.0 version D.04.10 and greater

HP JetAdmin for OS/2 Warp version A.02.04, A.03.00 and greater

HP JetAdmin for Solaris 2.3, 2.4, 2.5, 2.5.1, 2.6 version D.04.10 and greater

HP JetAdmin for Sun OS 4.1.3, 4.1.4 version D.04.10 and greater

HP JetAdmin for Windows 3.1/Windows for Workgroups 3.11 version 2.2, 2.33, 2.4

and greater

HP JetAdmin for Windows 95 version 2.2, 2.33, 2.4 and greater

HP JetAdmin for Windows NT version 2.33, 2.4 and greater

HP JetDirect Download Manager version A.02.17 and greater

HP Network Printer Installer version 1.0 and greater

HP Utilities for Mac OS version 3.0 and greater

HP Web JetAdmin version 4.0 and greater

Install and Setup Utilities for IBM LAN Server and Microsoft LAN Manager version

A.00.05

Setup and Monitor Utility for Windows for Workgroups 3.11 version A.00.03

HP recommends its customers verify the version of HP JetDirect software on their system. Instructions on how to determine the version of HP JetDirect software can be found at http://hpcc923.external.hp.com/cposupport/networking/support_doc/ bpj05564.html.

2.2 Disclaimer Statement

HP has made every effort to ensure the accuracy of our product testing. However, because each customer’s environment is different from HP’s laboratory test environment, it is the customer’s responsibility to validate the Year 2000 readiness of these products in their own environment. Therefore, information about the Year 2000 status of HP products is provided “as is” without warranties of any kind. HP makes no representation or warranty respecting the accuracy or reliability of information about non-HP products. Such information was provided by the manufacturers of those products and customers are urged to contact the manufacturer directly to verify Year 2000 readiness.

3

4

HP

2500C/C+/CM

Supported Network Printer Connections

3. The HP 2500C/C+/CM Professional Series Color Printer supports the following network printer connections:

3.1 Printing through an HP JetDirect Print Server

3.1.1

Overview

In this configuration, the printer is connected to the network via an HP

JetDirect print server. This configuration provides better performance as well as flexibility in preparing a location for the printer. The HP

2500CM Professional Series Color Printer comes with an internal

HP JetDirect Print Server. It is therefore recommended that the printer be shared on a network through the print server.

There are two basic network configurations using the HP JetDirect print server: Client-Server printing and Peer-to-Peer printing.

Client-Server printing is typically used in medium to large networks where dedicated computer servers are used to manage printing needs of many users. Client-server networks use network operating systems

(NOS) such as Novell NetWare and Microsoft Windows NT Server 4.0.

Peer-to-Peer printing is more suitable for smaller networks. On peerto-peer networks, users configure their Windows 95, Windows 98 or

Windows NT 4.0 systems to print directly to the printer.

3.1.2 Supported Network Configurations for Client-Server Printing

Server Client Configurations

Windows NT 4.0

Windows 95/98 Windows for

Workgroups 3.11

Yes Yes

Not recommended Yes

Yes

Yes

Windows NT 4.0

Windows 95/98

Novell NetWare

4.11 (Bindery)

Novell NetWare

4.11 (NDS)

Yes

Yes

Yes

Yes

Yes

Yes

3.1.3 Supported Network Configurations for Peer-to-Peer Printing

Windows 95

Windows 98

Windows NT 4.0

See page 14 for more information.

Note: To take full advantage of network printer management features provided by the

HP 2500C/C+/CM color printer, please use HP Web JetAdmin 5.0 or later and the latest printer firmware.

For HP Web JetAdmin and other HP network printing software, visit our website at www.hp.com/support/net_printing.

To obtain the latest printer firmware for the HP 2500C Professional Series printer, please visit our web site at www.hp.com/go/hp2500.

3.2 Printing through a PC

In this configuration, the printer is connected directly to the parallel port of a selected computer (or server) on the network and is shared out to the other computers (or client). The server could be a Novell NetWare 4.11

server or a computer running Windows for Workgroups 3.11, Windows 95,

98 or NT 4.0. Sharing the printer in this configuration is a low cost, easy way to share a printer because it requires no additional hardware or software.

The HP 2500C Professional Series printer can be shared over a network with this configuration. However, it is recommended only for a small workgroup where there is a small number of users or usage is low as the shared computer will be slowed down when many users print to its shared printer.

5

6

3.2.1 Supported Network Configurations for Printing through a PC

Novell NetWare 4.11

Windows NT 4.0

Windows 95/98

Windows For

Workgroups 3.11

Client Configurations

Windows NT 4.0

Windows 95/98 Windows for

Workgroups 3.11

Yes

Yes

Yes

Yes

Yes

Yes

No Yes Yes

No No Yes

1

2

3

4

JETDIRECT

10/100 Base-Tx

(RJ-45)

(RJ-45)

10/100 Base-Tx

JETDIRECT

JETDIRECT

10/100 Base-Tx

(RJ-45)

(RJ-45)

10/100 Base-Tx

JETDIRECT

HP

2500C/C+/CM

Installing the Print Server

4. The HP 2500CM Professional Series Color Printer comes with an internal MIO JetDirect Print Server preinstalled. However, if you have purchased the HP 2500C Professional Series Printer, you may purchase the internal JetDirect Print Server.

For the list of HP MIO JetDirect Print Servers, please refer to our web site at www.hp.com/go/jetdirect.

4.1 Installing the HP JetDirect Print Server Card

Step 1 - Verify that the Printer Works

1. Turn on the printer.

2. Press [MENU] repeatedly until SELF TEST MENU appears.

3. Press [ITEM] repeatedly until PRINT DIAGNOSTIC PAGE appears.

4. Press [SELECT] to print the Diagnostic Page.

Step 2 - Install the HP JetDirect Print Server Card into the Printer

Note: The HP JetDirect card contains electronic components that can be damaged by static electricity through electrostatic discharge (ESD). To prevent

ESD, maintain frequent contact with any bare sheet metal surface on the printer. A grounding wrist strap (or similar device) is useful for this purpose.

Handle the card carefully at all times. Avoid touching electronic components or circuit paths.

1. Turn off the printer and unplug the power cord.

2. Unscrew and remove the metal plate on the left side of the printer.

3. Insert the card. Align the card with the guide rails in the printer.

4. Press the card into the slot until the card is firmly seated.

5. Tighten each thumbscrew a little at a time, alternating between each side until both screws are secure.

6. Connect the network cable to the card.

7. Connect the power cord and turn on the printer.

7

8

HP

2500C/C+/CM

Customizing the Printer Software

5. You may choose to customize the printer software so that certain items or features such as status and bi-directional printing will be disabled the next time you install the printer software. This feature is useful if you want to install a customized configuration on several computers in a network.

To do this:

1.

Insert the Starter CD into your CD-ROM drive. If the installation program does not run automatically, access File Manager or

Explorer and run INSTALL.EXE on the CD-ROM.

2.

Click on Printer Driver followed by Download.

During download, you will be asked if you wish to customize the printer software. If you choose not to, you may run the

Installer Configuration Utility later by double-clicking on the

HPINSCFG.EXE icon in the driver directory of the Starter CD.

3.

Choose the options you wish to install.

4.

Click OK.

5.

The printer software will be installed according to this configuration the next time you install from the downloaded files.

HP

2500C/C+/CM

Configuring To Print On The Network

6.

There are several options to use the HP 2500C series of professional printers in a network environment. You can choose to use the JetDirect port (the card comes standard with the HP

2500CM printer) or merely configure to connect direct to the printer. This chapter describes the procedures for setting up the server or client configurations and also sharing the printer on the network.

6.1 Configuring the PC as a Server to Print Through the HP JetDirect Port

This procedure takes you through setting up the PC as a server to print through the HP

JetDirect port, which is connected to the print server. To allow other PCs to connect to this configured server PC to print, using the HP JetDirect port, you will need to share this

PC (refer to section 6.6.1, Step 2 - Share the Printer on the Network).

JetDirect

MIO Card

Printer

PC Server

There are two methods to you can use to configure the PC.

Note:: Your may encounter problems printing with IPX/SPX in Windows NT 4.0. Large print jobs may stop mid-page and continuously re-spool. We recommend that you use TCP/IP instead or ensure that your system is upgraded to MS NT 4.0 Service Pack 4.

6.1.1 Option 1 - Using the HP JetDirect Installation Utility

Step 1 - Install HP JetAdmin

1.

Insert the HP JetDirect CD-ROM into your CD-ROM drive. If the installation program does not run automatically, access the Explorer.

2.

Select the option to install JetAdmin and follow the instructions on the screen.

Before you proceed to Step 2, please ensure that the HP 2500C Printer Software is

installed. Otherwise, refer to section 6.1.2, Option 2, Step 1 - Install HP 2500C Series

Printer Software for the procedure.

Step 2 - Associate Printer Software with the JetDirect Port

This step takes you through the process of linking the PC local or existing connected port to the JetDirect printer.

1. Select HP 2500C/CM Printer in the Printers folder. The printer name will defer, depending on if you are installing the PCL 3 or PostScript printer software.

9

10

2. Click the right mouse button and select Properties.

3.

Select the Details tab, click Add Port, and click OK.

4. Select a new port to assign it to the JetDirect printer and click OK.

Ensure that the printer has been set up as shared. Please refer to section 6.6.1, Step 2 - Share

the Printer on the Network, for the procedure, if the printer is not set up as shared.

The Installation Option screen appears for you to select the print features.

6.1.2 Option 2 - Using the HP 2500C Printer Software

Step 1 - Install HP 2500C Series Printer Software

1.

If you are running Windows NT 4.0, log on to the computer as the system administrator.

2.

Insert the Starter CD into the CD-ROM drive to install the PCL 3 printer software.

If the installation program does not run automatically, access the File Manager or

Explorer and run INSTALL.EXE from the CD-ROM. The Starter CD allows you to either install or download the printer driver onto the network drive. Choose

Download if you wish to customize your printer software for future quick installation. The next screen appears to prompt you to select the port.

3.

Windows 95/98/NT 4.0: Select Local/Existing (this selection assumes that the port is a local (LPT) or defined print server port).

Note: The other two port options that are available for selection are:

Network (Client):If you wish to connect a PC (client) to the shared or server PC in the network.

Network (Server/Peer-to-Peer): If you wish to connect a PC to print directly to the printer server port without sharing through a server PC.

Windows for Workgroups 3.11:

3a. Click Connect when prompted to select a printer port.

3b. Type in the path that the printer has been mapped to and select the shared printer.

3c. Select the LPT port that you have just mapped and click OK.

If you wish to install the PostScript printer software, refer to the section on Installing

PostScript Driver for the procedure.

If you wish to install the PCL 5 printer software, refer to the PCL 5 Supplementary Network

Guide.

6.2 Configuring the PC (Client) to Connect to the Print Server via a Server

JetDirect

MIO Card

Printer

PC (Client)

PC Server

There are three methods to set up the PC as a client to a configured print server on the network.

6.2.1 Option 1 - Using the HP 2500C Series Printer Software

1.

Refer to the section 6.1.2, Step 1 - Install HP 2500C Series Printer Software, for the

procedure on installing the printer software. Instead of selecting

Local/Existing, select Network (Client).

2.

Type in the name of the shared printer, like, \\Computer\Name\PrinterName, in the

Select Network Port field. If you do not know the computer name or printer name, browse the network to help you find the printer. The Installation Option screen appears.

6.2.2 Option 2 - Using the Add Printer Wizard (for PCL 3 drivers only)

You may use the Microsoft Windows Add Printer Wizard to install the printer software.

1. Click on Start and select Settings, followed by Printers.

2. Double-click Add Printer.

3. For Windows 95/98, select Network Printer.

For Windows NT 4.0, select Network Printer Server, when prompted.

4. Type in the network part or queue name of the shared printer, for example,

\\ComputerName\PrinterName. If you do not know the name, you can click on

Have Disk…, when prompted to select printer model.

5. Click on Browse… and locate the hp2500c.inf file. This file contains the printer name for you to select. The file is located in the Starter CD or on your network server if the

System Administrator had copied the files onto the server.

6. The Installation Option screen appears. Follow the instructions on the screen to complete the PC configuration process.

11

12

6.2.3 Option 3 - Other Methods for Configuring the PC (Client) (For PCL 3 drivers installed in the server and the port has been configured for sharing)

If the printer software is installed in the server computer and the port has been shared out, the printer software can be installed onto the client computer by doing one of the following:

• • Sending a print job to the printer by dragging the document onto the network printer icon.

• • Dragging a network printer icon into the Printers folder.

• • Double-clicking a network printer icon.

• • Right-clicking a network printer icon and selecting Install.

6.3 Configuring the PC (Peer-to-Peer) to Print Directly to the Printer

PC (Peer-to-Peer)

JetDirect

MIO Card

Printer

There are two methods to set up the printer for this configuration.

6.3.1 Option 1 - Using the HP JetDirect Installation Utility

Please refer to the same option in section 6.1.1 for the procedure

6.3.2 Option 2 - Using the HP 2500C Series Printer Software

To set up the PC to print directly to the printer, you need to complete the following steps:

Step 1 - Install HP 2500C Series Printer Software

1.

Please refer to section 6.1.2, Option 2 - Install HP 2500C Series Printer Software,

for the procedure. When it comes to port selection, do the following:

Select Network (Server/Peer-to-Peer), instead of Local/Existing, to associate the printer software with the JetDirect port. This selection applies when the port you intend to use is not defined. Select the desired port from the list, or you may enter the port name.

2. Click OK. The Setup Printer wizard appears to guide you through the setting up process.

6.4 Configuring the JetDirect Print Server Port to Connect to the NetWare 4.11 Bindery

Network

This procedure allows you set up the HP JetDirect port on the NetWare 4.11 Bindery Network.

Step 1 - Install HP JetAdmin

1.

Insert the HP JetDirect CD-ROM into the CD-ROM drive. If the installation program does not run automatically, access the File Manager or Explorer and run SETUP.EXE that is on the CD-ROM.

2. Select the option to install JetAdmin and follow the instructions on the screen.

Step 2 - Configure the JetDirect Print Server

1.

Log onto the network with Supervisor privileges at any user workstation that has the HP JetAdmin installed.

2. Click Start, Programs, HP JetAdmin Utlities, and HP JetAdmin, to run HP

JetAdmin.

3. The following message may appear: "JetAdmin could not find any configured devices on your network. Do you want to configure one now?". Click Yes and proceed to 5. If this message is not displayed, go to 4.

4.

On the HP JetAdmin Utility screen, press [F5] to refresh the list of printers. All configured print servers are displayed.

5. Select Device, New. On the New Device screen, highlight the LAN hardware address of your print server. (The 12-character hardware address is on the HP JetDirect configuration page.)

6. Click Configure. A General screen appears.

7. Type the name of the print server and a description (optional): then click Next. A

NetWare configuration screen appears.

8. Click Operating Mode and select Queue Server Mode.

9.

Click Queues and then click Change.

10. Select your NetWare server from the list and click Create.

11. Type a name for this printer queue in the Create Queue screen and click OK.

12. Click Yes to add the queue to the list of serviced queues.

13. The configured queues appears under Serviced Queues, click OK.

14. Follow the instructions to complete configuration.

Step 3 - Copy Printer Software to a Network Drive for Client Installation

Please refer to section 6.2 for the procedure on installing the HP 2500C Series Printer

Software.

13

14

6.5 Configuring the JetDirect Print Server Port to Connect to Netware 4.11 NDS Network

This procedure allows you set up usage of the HP JetDirect port to share the printer.

Step 1 - Install HP JetAdmin

1.

Insert the HP JetDirect CD-ROM into the CD-ROM drive. If the installation program does not run automatically, access the File Manager or Explorer and run SETUP.EXE that is on the CD-ROM.

2. Select the option to install JetAdmin and follow the instructions on the screen.

Step 2 - Configure the JetDirect Print Server

1.

Log onto the network with Supervisor privileges at any user workstation that has the HP JetAdmin installed.

2. Click Start, Programs, HP JetAdmin Utlities, and HP JetAdmin, to run HP

JetAdmin.

3. The following message may appear: "JetAdmin could not find any configured devices on your network. Do you want to configure one now?". Click Yes and proceed to 5. If this message is not displayed, go to 4.

4.

On the HP JetAdmin Utility screen, press [F5] to refresh the list of printers. All configured print servers are displayed.

5. Select Device, New. On the New Device screen, highlight the LAN hardware address of your print server. (The 12-character hardware address is on the HP JetDirect configuration page.)

6. Click Configure. A General screen appears.

7. Type the name of the print server and a description (optional): then click Next. A

NetWare configuration screen appears.

8. Click Operating Mode and select Queue Server Mode.

9.

Click Network Directory Services. Use the arrow key to select the name of the NDS tree (where objects are located) in the Tree Name Box.

10. Click Browse and expand the NDS tree. Then identify and select an appropriate context and click OK.

11. Click Queues and then click Change.

12. Select the appropriate queue and click Yes to add the queue to the list of serviced queues.

13. Your configured queues are displayed under Serviced Queues, click OK, then Next.

14. If a TCP/IP screen appears, click Next.

15. Follow the instructions to complete configuration.

Step 3 - Copy Printer Software to a Network Drive for Client Installation

Please refer to Section 6.2 for the procedure on installing the HP 2500C Series

Printer Software.

6.6 Configuring the PC as a Server to Share the Printer

PC

JetDirect

MIO Card

Printer

PC

PC Server

There are two ways to install and configure the PC to share the printer on the network

Before you proceed with the installation, ensure the following conditions:

• The server computer which the printer will be connected to, has been set up correctly in the network. Refer to the documentation that comes with your network operating system for more information.

• Networking software and protocol must be present on both the server and client computers.

• The server computer must be turned on when trying to connect.

• For Windows for Workgroups 3.11, the Print Manager must be enabled. To do this, doubleclick the Printers icon in the Control Panel and choose Use Print Manager.

• For Windows 95/98/NT 4.0, File and Printer Sharing of the server computer must be enabled.

Note: If the server is running Novell Netware 3.12 or 4.11, please refer to the documentation that comes with Novell on how to set up a local printer.

15

16

6.6.1 Using the HP 2500C Series Printer Software to Share the Printer

Step 1 - Install HP 2500C Series Printer Software

Please refer to section 6.1.2, Step 2 - Install HP 2500C Series Printer Software

for the procedure.

Step 2 - Share the Printer on the Network

For Windows 95/98/NT 4.0:

1.

Right-click on the HP 2500C Series Printer icon in the Printers folder, followed by

Properties, to access the printer properties.

2. Select the Sharing tab in Properties to share the printer. Proceed to 3 if you do not see the Sharing tab, otherwise, move on to 5.

3.

To enable the file and printer share, double-click the Network icon in the Control

Panel. Click File and Printer Sharing and make sure that both the check boxes are selected.

4.

Click OK and restart Windows.

5. In the Sharing tab, select Shared As and specify a shared name for this printer, for example, HP 2500C.

6. Click OK.

For Windows for Workgroups 3.11:

1. Double-click the Printers icon in the Control Panel.

2. Select HP 2500C Series Printer and make sure that the Use Print Manager option is checked.

3. Choose Cancel or Close to exit the Printers Control Panel.

4. Double-click the Print manager icon in the Main group and select the printer.

5. Select Share Printer As... from the Printer menu. . Proceed to 6 if you do not see the

Sharing tab, otherwise, move on to 8.

6.

If the Share As… option is disabled, you have not enabled the printer sharing. To do this, double-click the Windows Setup icon in the Main program group, choose

Change Network Settings in the Options menu and enable printer sharing.

7. Click OK and restart Windows.

8. Specify a shared name for this printer, for example, HP 2500C.

9. Check the Re-share At Startup option if you wish to share the printer permanently.

10. Click OK.

11. Proceed to install the printer software on the client computer.

6.7 Installing Alternate Drivers

If your server is running Windows NT 4.0 and you wish to install

Windows 95 or 98 drivers to client computers over the network, you may do so if you have installed an alternate driver in your server.

To install an alternate driver in your server:

1. Insert the Starter CD into the CD-ROM drive.

2. Click the Start button on the taskbar.

3. Select Settings, followed by Printers to open the Printers folder.

Right-click on the HP 2500C Series Printer icon and select

Sharing.

4. Select Shared and type in a Share Name of your choice.

5. Select Windows 95 under Alternate Drivers.

6. When prompted to insert disk, click OK.

7. In the Copy Files From: box, type d:\ drivers\nt295\ where d:\ is your CD-ROM drive. You may also click Browse and point to the directory to be installed from.

8. Click OK and follow the instructions on screen to complete installation.

6.8 Installing PostScript Driver

Option 1

1.

Insert the HP 2500C/C+/CM Adobe PostScript 3 CD-ROM into your

CD-ROM drive and run INSTALL.EXE.

2.

Follow the instructions on the screen and select HP 2500C Series

PS3 Printer in the PPD description.

3.

Follow the instructions to complete the installation and verify your setup with the self-test page (for Windows 95, 98 and NT only).

Option 2

1.

Copy the entire contents of the HP 2500C/C+/CM Adobe PostScript

3 CD-ROM to a folder in your server.

2.

Assign (Map) a drive letter to your network folder.

3.

Run INSTALL.EXE.

4.

Follow the instructions on the screen and select HP 2500C Series

PS3 Printer in the PPD description.

5.

Follow the instructions to complete the installation and verify your setup with the self-test page (for Windows 95, 98 and NT only).

17

18

Option 3

1.

Copy the folders and files of the specific Operating System and language required from the HP 2500C/C+/CM Adobe PostScript 3

CD-ROM to a folder in your server.

2.

Run SETUP.EXE.

3.

Follow the instructions on the screen and select HP 2500C Series

PS3 Printer in the PPD description.

4.

Follow the instructions to complete the installation and verify your setup with the self-test page (for Windows 95, 98 and NT only).

HP

2500C/C+/CM

Troubleshooting

7. If you encounter any problems or difficulty printing over a network, please refer to the following documentation:

Troubleshooting tab on the HP 2500C Toolbox.

HP JetDirect Hardware Manual.

HP JetDirect Software Manual.

Your NOS and OS Manual.

HP

2500C/C+/CM

Improving Printing Performance over the Network

8. Color output from applications requires a lot of processing to become printer ready data. Therefore, when networking color inkjet printers, the demands on a print server’s system resources are higher than other network printers.

To optimize printing performance over the network, the following is recommended:

1.

Set Print Queue to Accept only RAW Data in a NT4.0 Client-

Server Environment

A print queue can be configured to accept only RAW Data. By doing so, the work of creating RAW data is moved from the print server CPU to the client PC. This will reduce the load on the print server CPU.

To enable this option:

1.

Click Start and select Settings followed by Printers.

2.

Right-click on the HP 2500C series printer icon and select

Properties.

3. Click on the General tab.

4.

Click on Print Processor.

5.

Check always spool RAW datatype checkbox and click OK.

2.

Free Up Hard Disk Space

It is recommended that the print server has 200MB of free disk space for every 10 queues.

3.

Set Port Monitor

It is recommended that you use HP JetDirect port software that comes with HP JetAdmin (3.4 or later) or HP Standard port software that comes with HP Web JetAdmin instead of Microsoft’s LPR port software.

Also, for optimal printing and spooling of 11” x 17” or A3-size jobs, the

TCP/IP Idle Time Out value of the MIO card should be set to at least

360 seconds. To do this:

1.

Click Start and select Settings followed by Printers.

2.

Right-click on the HP 2500C series printer icon and select Modify.

3. Click Next.

4.

Set the TCP/IP Idle Timeout to at least 360.

5.

Click Next and Finish.

4. Reduce the Complexity of the File

Reduce the complexity of the file such as reducing the number of colors.

19

5.

Send the Print File through a Different Application

It has been found that some applications handle complex print files more efficiently than others. Try opening your file with another application and send it to print.

6.

Use the HP ZoomSmart Feature

If you have the intention of printing a larger version of your print job, e.g., from A4 or Letter size to A3 or 11” x 17”, it is recommended that the

ZoomSmart feature be used to enlarge the image instead of enlarging it through an application. The spool file generated with ZoomSmart is about 30% smaller.

20

©Copyright 1999

Hewlett-Packard Company

450 Alexandra Road

Singapore 119960

Singapore.

http://www.hp.com/go/hp2500

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
