Preface
Copyright
©2011 Vivitek Corporation.
is a trademark of Vivitek Corporation. Other
trademarks are the properties of their respective owners. Values, weights and dimensions
are approximate. Specifications are subject to change without prior notice.
Disclaimer
The information in this document is subject to change without notice. The manufacturer
makes no representations or warranties with respect to the contents hereof and specifically
disclaims any implied warranties of merchantability or fitness for any particular purpose.
The manufacturer reserves the right to revise this publication and to make changes from
time to time in the content hereof without obligation of the manufacturer to notify any
person of such revision or changes.
Trademark Recognition
HDMI, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC in the United States and other countries.
All other product names used in this manual are the properties of their respective owners
and are acknowledged.
ii
Important Safety Information
Important:
It is strongly recommended that you read this section carefully before using the
Qumi. These safety and usage instructions will ensure that you enjoy the Qumi.
Keep this manual for future reference.
Symbols Used
Warning symbols that are used on the projector and in this manual are to alert you of potential
hazardous situations.
The following styles are used in this manual to alert you to important information.
Note:
Provides additional information on the topic at hand.
Important:
Provides additional information that should not be overlooked.
Caution:
Alerts you to situations that may damage the unit.
Warning:
Alerts you to situations that may damage the unit, create a hazardous environment,
or cause personal injury.
Throughout this manual, component parts and items in the OSD (On-Screen Display)
menus are denoted in bold, for example:
“Press the Menu button on the remote control to open the Main menu.”
General Safety Information
• Do not open the unit case. There are no user-serviceable parts in the unit. For
servicing, contact qualified service personnel.
• Follow all warnings and cautions in this manual and on the unit case.
• The projection light source is extremely bright by design. To avoid damage to eyes,
do not look into the lens when the LED illumination is on.
• Do not place the unit on an unstable surface or stand.
• Avoid using the system near water, in direct sunlight, or near a heating device.
• Do not place heavy objects on the unit.
iii
Qumi Installation Notice
• Allow at least a 20-inch (50cm) clearance around the exhaust vent.
Minimum 4 inches (100mm)
Minimum 20 inches (500mm)
• Make sure that the intake vents do not recycle hot air from the exhaust vent.
• When operating the Qumi in an enclosed space, make sure that the surrounding air
temperature within the enclosure does not exceed operating temperature while the
Qumi is running, and the air intake and exhaust vents are unobstructed.
•
does not recycle exhaust air, as this may cause the device to shutdown even if the
enclosure temperature is with the acceptable operating temperature range.
Caution:
Avoid using the Qumi in dusty environments.
iv
Power Safety
• Only use the supplied adapter.
• Do not place anything on the cord. Place the cord where it will not be in the way of
foot traffic.
• Remove the battery from the remote control when storing or not in use for a prolonged period.
Cleaning the Qumi
• Unplug the cord before cleaning. See Cleaning the Qumi on page 36.
Note:
The Qumi will be warm after usage. Allow the Qumi to cool down before storing.
Regulatory Warnings
Before installing and using the Qumi, read the regulatory notices in the Regulatory
Compliance on page 45.
Symbol Explanations
DISPOSAL: Do not use household or municipal waste collection services
for disposal of electrical and electronic equipment. EU countries require the
use of separate recycling collection services.
Main Features
• Lightweight unit, easy to pack away and transport.
• Compatible with all major video standards including NTSC, PAL, and SECAM.
• A high brightness rating allows for presentations in daylight or in lit rooms.
• Supports data resolution up to UXGA at 16.7 million colors to deliver crisp, clear images.
• Flexible setup allows for front, rear, ceiling and rear ceiling projection.
• Line-of-vision projections remain square, with advanced keystone correction for angled projections.
• Input source automatically detected.
About this manual
This manual is intended for end users and describes how to install and operate the Qumi.
Wherever possible, relevant information—such as an illustration and its description—has
been kept on one page. This printer-friendly format is both for your convenience and to
help save paper, thereby protecting the environment. It is suggested that you only print
sections that are relevant to your needs.
v
Table of Contents
Preface��������������������������������������������������������������������������������������������������������������������� ii
Chapter 1 At a Glance������������������������������������������������������������1
Overview������������������������������������������������������������������������������������������������������������������ 1
Accessories������������������������������������������������������������������������������������������������������������� 3
Remote Control������������������������������������������������������������������������������������������������������� 4
Qumi and Remote Control Buttons����������������������������������������������������������������������� 4
Media Player Screen����������������������������������������������������������������������������������������������� 4
Chapter 2 Getting Started������������������������������������������������������5
What You Need�������������������������������������������������������������������������������������������������������� 5
Setting Up Qumi������������������������������������������������������������������������������������������������������ 6
Setting Up the Remote����������������������������������������������������������������������������������������� 12
Chapter 3 Qumi Media Suite������������������������������������������������13
Overview���������������������������������������������������������������������������������������������������������������� 13
Movies�������������������������������������������������������������������������������������������������������������������� 14
Photos�������������������������������������������������������������������������������������������������������������������� 15
Music���������������������������������������������������������������������������������������������������������������������� 16
Office Viewer��������������������������������������������������������������������������������������������������������� 18
Settings������������������������������������������������������������������������������������������������������������������ 19
Chapter 4 On-Screen Display (OSD) Settings�������������������20
OSD Menu Controls���������������������������������������������������������������������������������������������� 20
Setting the OSD Language���������������������������������������������������������������������������������� 21
OSD Menu Overview��������������������������������������������������������������������������������������������� 22
OSD Sub-Menu Overview������������������������������������������������������������������������������������� 23
Image Menu ���������������������������������������������������������������������������������������������������������� 24
Computer Menu���������������������������������������������������������������������������������������������������� 26
Video/Audio Menu������������������������������������������������������������������������������������������������� 27
Installation I Menu ����������������������������������������������������������������������������������������������� 29
Installation II Menu ���������������������������������������������������������������������������������������������� 31
Chapter 5 Taking Care of Your Qumi����������������������������������36
Cleaning the Qumi������������������������������������������������������������������������������������������������ 36
Cleaning the Lens������������������������������������������������������������������������������������������������� 36
Troubleshooting���������������������������������������������������������������������������������������������������� 37
Vivitek Support Site���������������������������������������������������������������������������������������������� 40
Specifications������������������������������������������������������������������������������������������������������� 41
Projection Distance vs. Projection Size������������������������������������������������������������� 42
Projection Distance and Size Table��������������������������������������������������������������������� 42
Timing Mode Table������������������������������������������������������������������������������������������������ 43
Qumi Dimensions������������������������������������������������������������������������������������������������� 44
Regulatory Compliance���������������������������������������������������������������������������������������� 45
Safety Certifications��������������������������������������������������������������������������������������������� 45
Disposal and Recycling��������������������������������������������������������������������������������������� 45
vi
Chapter 1 At a Glance
Overview
Front/Top/Right View
Keypad
See Keypad - On-Screen
Display (OSD) buttons
Cooling Vent
Cooling Vent
Do not cover
Do not cover
Lens
Focus ring
Projection Lens
Focus the projected image
Keypad
Menu
Open and exit the OSD
buttons
Up Cursor
Navigate and change
settings in the OSD
Enter Cursor
Change settings in the OSD
Left Cursor
Right Cursor
Navigate and change
settings in the OSD
Navigate and change
settings in the OSD
Down Cursor
Navigate and change
settings in the OSD
1
Rear/Top/Left View
DC IN
Connect the supplied power
adapter
Power Switch
AUDIO OUT
Turn on/off the Qumi
Connect an audio cable to
speakers or headphones
UNIVERSAL I/O
AV IN
Connect a RGB or component
cable from a device
Connect the AV IN cable
from a video device
MINI HDMI
USB
Connect a MINI HDMI cable
from a HDMI device
Connect an USB drive or
device
IR Receiver
microSD
Insert a microSD card
Receive IR signal from the
remote control
Bottom View
Docking Connector
Rubber Foot Pad
Dock to optional battery pack
Stability and maintain cooling
ventilation
Cooling Vent
Tripod Connecting Slot
Do not cover
Tripod not included
2
Accessories
Along with the Qumi, the following accessories are included:
Remote Control
(With one 3V CR2025 battery)
Mini to Standard HDMI Cable
Mini to Mini HDMI Cable
VGA Cable
Regional Power Cord and Power Adapter
Documentation Kit (Warranty Card)
Carrying Case
Cable Cores (x2)*
Contact your dealer immediately if any items are missing, appear damaged, or if the unit does
not work. It is recommended that you keep the original packing material should you ever need
to return the equipment for warranty service.
Note:
Accessories will vary from model to model.
* To ensure a high quality performance from your project and to prevent
electromagnetic interference (EMI), equip the VGA or HDMI video source cable with
the included cable cores.
3
Remote Control
Up Cursor
Navigate and change settings
in the OSD
Right Cursor
Navigate and change settings
in the OSD
Enter
Change settings in the OSD
Exit
Left Cursor
Close the OSD
Navigate and change settings
in the OSD
Down Cursor
Navigate and change settings
in the OSD
Menu
Open and exit the OSD
Mute
Source
Mute the built-in speaker
Change the input source
Important:
1. Be sure nothing obstructs the path between the remote control and the Qumi.
If the path between the remote control and the Qumi is obstructed, the signal can
2. The buttons and keys on the Qumi have the same layout and similar functions as
the corresponding buttons on the remote control. This user’s manual describes the
functions based on the remote control.
Qumi and Remote Control Buttons
The Qumi can be used with the remote control or the keypad that is located on top of the
projector. All operations can be carried out with the remote control and a combination of
keys from the keypad.
The remote control is not only used to navigate the cursor in the menus, but can also be
used to control the media functions (music and video playback). For more details about
how to control the media functions with the remote control, please refer to 13.
Media Player Screen
The media player screen is the main interface for the Qumi Q2 Series. If a USB or
MicroSD card is plugged in when powering on the Qumi, the media player screen appears.
In the media player screen, you can choose the type of media to display by selecting:
• Movie – A movie player that displays multiple movie formats.
• Photo – A photo viewer that contains slide show functionality.
• Music – A music player that supports many types of audio files.
• Office viewer – A document viewer that displays documents.
• Settings – The settings of the Qumi can be adjusted in this menu.
4
Chapter 2 Getting Started
What You Need
Many types of external devices and peripherals can be connected to the Qumi. External
or portable music players can be connected to play music. DVD, VCD and VHS players
can be connected to play movies. Camcorders and digital cameras can also be used to
play videos and display photos. Computers, as well as peripherals such as MicroSD
cards and USB flash drives, can be connected to the Qumi to display documents and
other types of content.
These devices can be connected to the Qumi by using an appropriate cable. Make sure
that the connecting device has an appropriate output connector.
Connect AC power adapter
Connect video or
Apple® devices
Insert microSD card
Connect audio
Insert USB device
Connect HDMI
peripherals
Warning:
Connect personal
computers or Apple® devices
As a safety precaution, disconnect all power to the Qumi and connecting devices before making
connections.
5
Setting Up Qumi
Connecting Apple Devices
Connect an Apple® device to the Qumi by using the following:
Apple® Connection Kit
VGA to Apple® Video Adapter (Optional)
NOTE:
Connectors for Apple products sold separately.
Connecting Peripherals by HDMI
Connect HDMI-compatible peripherals to the Qumi using the Mini to Standard HDMI cable.
6
Connecting Personal Computers
Connect a personal computer to the Qumi by using the VGA cable.
Note:
The personal computer must have a VGA output port to use the VGA cable to
connect to the Qumi.
Inserting a microSD Card or USB Drive
Connect a USB drive or microSD card to the Qumi by inserting the storage device(s) into
the appropriate port.
Connecting Video
Connect video devices to the Qumi by using the audio/video cable (optional accessory).
NOTE:
Some cables sold separately.
7
Connecting Audio
Connect earphones or mini speakers to the Qumi by inserting into the Audio Out port.
Starting and Shutting down the Qumi
1. Connect the AC power adapter to
the Qumi. Connect the other end
of the AC power adapter to a wall
outlet.
Note:
Adapter models may vary
between regions.
2. Then slide the
POWER switch
to turn on the Qumi.
The Qumi splash screen displays
and connected devices are
detected.
See Setting an Access Password
(Security Lock) on page 10 if
security lock is enabled.
8
3. If more than one input device is
connected, press the SOURCE
button on the remote control and
use the ▲ or ▼ buttons to select
the applicable device or press ▲
and ▼ or ◄ and ► at the same
time on the keypad on the Qumi.
• VGA: Analog RGB
• Component: DVD input YCbCr /
YPbPr, or HDTV input YPbPr
• Composite Video: Traditional
composite video
• HDMI: HDMI / DVI
• USB: microSD card / USB disc
4. Slide the
POWER switch to
turn off the Qumi.
Adjusting the Image
If the projected image is not clear, the image can be
adjusted by moving the focus ring up or down until
the image is clear.
9
Setting an Access Password (Security Lock)
To prevent unauthorized use of the Qumi, you can create a password. When the access
password function is enabled, the password must be entered after the Qumi has been
turned on.
Creating a password can be done by performing the following steps:
1. Press the MENU button on the
remote control or press MENU and
on the keypad simultaneously
to open the On-Screen Display
(OSD) menu.
2. Move the cursor to the Installation
I tab and scroll down to select
Advanced.
3. Press the ▲ or ▼ button to select
Security Lock.
4. Press the ◄ or ► button to
enable or disable the security lock
function.
A password dialog box
automatically appears.
5. You can use the ▲▼◄► buttons
located either on top of the Qumi
or on the remote control to enter
the password. Any combination
of the navigation buttons can be
used (five must be chosen).
Press the navigation buttons in
any order to set the password.
Then press the MENU button to
exit the dialog box.
10
6.
appears when you power on the
Qumi when the Security Lock is
enabled.
Enter the password that was
created in step 5.
Important:
Keep the password in a safe place. Without the password, you will not be able to
use the Qumi. If you lose the password, contact your reseller for information on
resetting the password.
Using a Tripod
The Qumi can be used with a tripod by connecting
the tripod to the bottom of the Qumi. Many typical
tripods can be connected.
• Type: Mini tripod
• Slot size: 1/4 - 20
11
Setting Up the Remote
The remote control comes with one (1) 3V lithium
battery (CR2025). The battery is pre-installed in the
remote control.
To begin using the remote control, remove the plastic
tab (A) from the battery compartment.
Replacing the Remote Control Batteries
1. Remove the battery 2. Remove the old battery 3. Install the cover.
compartment cover
by sliding the cover
towards the arrow (A).
Then pull out the cover
towards the arrow (B).
and insert the new
battery with the positive
side facing up.
Caution:
1. Only use a 3V lithium battery (CR2025).
2. Dispose of used batteries according to local ordinance regulations.
3. Remove the battery when not using the Qumi for prolonged periods.
Operating Range
The remote control uses infrared (IR) transmission to control the Qumi. It is not necessary
to point the remote directly at the Qumi.
The remote control functions properly within a radius of approximately 23 feet (7 meters)
and 15 degrees above or below the Qumi level (if the remote is not held perpendicular to
the sides or rear of the Qumi).
If the Qumi is unresponsive to the remote control, move closer towards the Qumi.
12
Chapter 3 Qumi Media Suite
Overview
microSD card or USB drive. Music, movies, pictures and documents can be displayed.
The media suite menu contains five (5) applications that can be accessed:
• Movie – An easy to use movie player that displays multiple movie formats.
• Photo – A photo viewer that contains slide show functionality.
• Music – A music player that supports many types of audio files.
• Office viewer – A document viewer that displays documents.
• Settings – The settings of the Qumi can be adjusted in this menu.
13
Movies
Supported Formats
The following video formats are supported:
•
AAC-LC
• MPEG-4 video up to 2.5 Mbps, 640 by 480 pixels at 30 frames per second; Simple
• Motion JPEG (M-JPEG) up to 35 Mbps, 1280 by 720 pixels, 30 frames per second,
Watching Your Movie
To open a list of movies, perform the following:
1. Press the ◄ or ► key to select the Movie icon in the media suite menu.
2. Press
3.
4. Press
While a movie is playing, the control interface can be hidden. To hide the control interface,
press the ▲ key. Press the ▲ key again to show the control interface.
The control interface will automatically disappear if there is no user input for five (5) seconds.
Control Interface
The following playback functions are controlled by the remote control, which are shown in
the table below:
ACTION
DESCRIPTION
Pause/Resume
Press
Forward speed
Press the ◄ or ► key to change the speed (2X, 4X, 8X,
16X, 32X)
to pause or resume a movie
14
Photos
Supported Formats
• BMP (up to 4000 x 3000 pixels)
• PNG (up to 4000 x 3000 pixels)
• JPG (up to 4000 x 3000 pixels)
Viewing Your Photo
When a USB flash drive and/or a microSD card is inserted, the storage card folder icon
To open a photo in photo viewer, perform the following:
1. Press the ◄ or ► key to select the Photo icon in the media suite menu.
2. Press
3. Select the folder containing the desired photo.
4. Press
to display the desired photo.
To view the details of the photos, navigate to a photo. The details of the photo will appear
on the bottom of the screen.
To view photos in full screen mode, perform the following:
1. Navigate to a photo.
2. Press
to view the photo in full screen mode.
To utilize the Zoom-In tool, press
. (2X, 4X, 8X, 16X).
In order to zoom out to the default size of the image, press the Exit key.
While a photo is displayed, the control interface can be hidden. To hide the control
interface, press the ▲ key. Press the ▲ key again to show the control interface.
Control Interface
The photo viewer contains the following controls:
ICON
DESCRIPTION
Return to the previous menu
Sets the Slide Show interval
View photos in Slide Show mode
Rotate the photo in a counter-clockwise position
Rotate the photo in a clockwise position
15
Music
Supported Formats:
• MP3 (up to 256Kbps bit-rate)
• WMA, MID, MIDI, MP1, MP2, OGG, AAC, AMR, WAV, AC3, M4A, AWB, APE
Playing your Track
To open the music list, perform the following:
1. Press the ◄ or ► key to select the Music icon in the media suite menu.
2. Press
3. Select the folder containing the desired song.
4. Press
to play the desired song.
A song can be played or paused by selecting the Pause/Play button in the music
player interface.
When the cursor is selecting the progress bar, a song can be paused or can be
played by pressing
.
Control Interface
The music player interface contains the following controls:
16
The music player provides controls to navigate through a song playlist. The following table
provides a description the controls.
ICON
/
DESCRIPTION
/
Toggle speaker output to Left/Right/Stereo
/
Return to previous/Forward to next track
/
Pause/Play track
Stop playback
Return to the previous menu
The order of songs and playback mode can be adjusted. The following table provides a
description of the playback modes.
ICON
DESCRIPTION
Songs in the playlist will play in a continuous
order
All songs in the playlist will repeat
Only the current song playing will repeat
All songs in the playlist will be shuffled during
playback
The music player contains many preset equalizer settings that can be applied. The
following table provides a description of the different equalizer settings.
ICON
DESCRIPTION
Normal
Classical
Jazz
Pop
Rock
Bass
17
Office Viewer
Supported Formats
The document viewer in the Qumi Media Suite can open the following types of documents:
• Microsoft® Word (97-2007, .doc/.docx)
• Microsoft® PowerPoint (97-2007, .ppt/.pptx)
• Microsoft® Excel (97-2007, .xls/.xlsx)
• Adobe® PDF (.pdf)
• Text (.txt)
Selecting Your Document
To open a file in document viewer, perform the following:
1. Press the ◄ or ► key to select the office viewer icon in the media suite menu.
2. Press
to open the file directory.
3. Select the folder containing the desired file.
4. Press
to display the desired file.
Once a file is open, press
to zoom in for a larger view of the file. Files can be zoomed
in 2X, 4X, 8X and 16X views. Use the navigation keys to move the view of the file.
To proceed to the next page or return to a previous page, press the ▲ or ▼ keys.
Note:
You cannot move to the previous or next page if the view is zoomed in.
Control Interface
The office viewer does not contain a dedicated control interface.
18
Settings
System Options
menu provides details about the software version.
The Information
Play Mode
The play mode menu displays settings for both video and music player options. The
following settings are available:
• Repeat None – The videos or music tracks will not repeat after it is completed.
•
• Repeat One – A selected video or music track will continuously repeat after it is
completed.
•
the playlist have been completed.
Note:
The Qumi media suite will always output 1280x800 resolution to the system,
therefore the OSD will be displayed in this resolution as its received signal.This
does not indicate the actual resolution of the actual multimedia files.
USB Options
The USB Mass Storage option allows you to connect a personal computer with a
supported USB flash device to transfer files between the Qumi and personal computer.
Note:
The Qumi media suite only supports input from USB drives and MicroSD memory
devices.
19
Chapter 4 On-Screen Display (OSD) Settings
OSD Menu Controls
The Qumi has an On-Screen Display (OSD) settings menu that allows you to make
adjustments and changes to settings, such as display and audio. There are five (5)
menus within the OSD menu:
• Image – Various aspects of the image quality
• Computer – Settings for personal computers
• Video/Audio – Many settings for video and audio
• Installation I – Default language and other settings
• Installation II – Factory reset and other settings
If the interface is set on AV-IN, MINI HDMI or Universal I/O, the OSD menu can be
accessed by pressing the MENU button on the remote control or keypad.
If the interface is set on the Qumi Media Suite menu, the OSD menu can be accessed by
pressing the MENU button on the remote control or by simultaneously pressing MENU
and
on the keypad.
Note:
If the OSD menu is inactive for 15 seconds, the OSD menu will close.
Navigating the OSD
The remote control cursor buttons or the buttons on the top of the Qumi can be used to
navigate and make changes to the OSD settings.
1. Enter the OSD menu.
2. Press the ◄ or ► button
to move through the 5
menus.
3. Press the ▲ or ▼ button
to move the cursor up
and down within in a
menu.
4. Press ◄ or ► to change
settings.
5. Press MENU button or
Exit on the remote
control to close the OSD
or close a submenu.
Note:
example, the Horizontal/Vertical Position items in the Computer menu can only
.
20
Setting the OSD Language
The language that is displayed in the OSD can be changed. To change the language in
the OSD, perform the following steps:
1. Enter the OSD menu. Press the ◄ or ► button to select the Installation I menu.
2. Press the ▲ or ▼ button until the cursor highlights the Language setting.
3. Press the ◄ or ► button until the language you want is shown in the cursor.
4. Press the EXIT button or MENU button twice to close the OSD.
21
OSD Menu Overview
Use the following illustration to quickly find a setting or determine the range for a setting.
22
OSD Sub-Menu Overview
23
Image Menu
To access the Image menu and adjust the settings, perform the following steps:
1. Enter the OSD menu.
2. Press the ◄ or ► button to select the Image menu.
3. Press the ▲ or ▼ button to move the cursor up or down in the Image menu.
4. Press the ◄ or ► button to change values for each applicable setting.
ITEM
DESCRIPTION
Display Mode
Press the ◄ or ► button to set the Display Mode.
Brilliant Color
Press the ◄ or ► button to adjust the Brilliant Color value.
Brightness
Press the ◄ or ► button to adjust the display brightness.
Contrast
Press the ◄ or ► button to adjust the display contrast.
Sharpness
Press the ◄ or ► button to adjust the display sharpness level.
Gamma
Press the ◄ or ► button to adjust the gamma correction of the
display.
Advanced
to enter the Advanced menu. See Advanced Feature
Press
on page 25.
Reset
Press
to reset all settings to default values.
Note:
The settings for BrilliantColor, Brightness, Contrast, Sharpness, Gamma and
Advanced modes are only adjustable when the Display Mode is set to User.
24
Advanced Feature
To access the Advanced menu and adjust the settings, perform the following steps:
1. Enter the OSD menu.
2. Press the ◄ or ► button to select the Image menu.
3. Press the ▼ or ▲ button to move to the Advanced menu and then press
.
4. Press the ▼ or ▲ button to move the cursor up or down in the Advanced menu.
ITEM
DESCRIPTION
Color Space
Press the ◄ or ► button to adjust the color space.
Color Temperature
Press the ◄ or ► button to adjust the color temperature.
25
Computer Menu
To access the Computer menu and adjust the settings, perform the following steps:
1. Enter the OSD menu.
2. Press the ◄ or ► button to select the Computer menu.
3. Press the ▲ or ▼ button to move the cursor up or down in the Computer menu.
4. Press the ◄ or ► button to change values for each applicable setting.
ITEM
DESCRIPTION
Horizontal Position
Press the ◄ or ► button to adjust the display position to left or
right.
Vertical Position
Press the ◄ or ► button to adjust the display position to up or
down.
Frequency
Press the ◄ or ► button to adjust the A/D sampling clock.
Tracking
Press the ◄ or ► button to adjust the A/D sampling dot.
Auto Image
Press
to automatically adjustment for phase, tracking, size
and position.
Note:
Items in the Computer menu can only be modified when the Qumi is connected to
a PC through a VGA cable. Settings that are not enabled or that cannot be modified
are gray in color.
26
Video/Audio Menu
To access the Video/Audio menu and adjust the settings, perform the following steps:
1. Enter the OSD menu.
2. Press the ◄ or ► button to select the Video/Audio menu.
3. Press the ▲ or ▼ button to move the cursor up and down in the Video/Audio menu.
4. Press the ◄ or ► button to change values for each applicable setting.
ITEM
DESCRIPTION
Video AGC
Press the ◄ or ► button to enable or disable the Automatic Gain
Control for video source.
Video Saturation
Press the ◄ or ► button to adjust the video saturation.
Video Tint
Press the ◄ or ► button to adjust the video tint/hue.
Video Overscan
Press the ◄ or ► button to enable or disable video over scan.
Closed Captioning
Press the ◄ or ► button to enable or disable Closed Captioning.
Audio
Press
to enter the Audio menu. See Audio on page 28.
Reset
Press
to reset all settings to default values.
Note:
Video AGC, Video Saturation, Video Tint and Closed Caption settings are
adjustable only when the source is from composite video. The Video Overscan
settings are adjustable only when the source is from composite, component and
HDMI video.
27
Audio
To adjust the audio settings, press
to enter the Audio sub menu.
ITEM
DESCRIPTION
Volume
Press the ◄ or ► button to adjust the audio volume.
Mute
Press the ◄ or ► button to turn on or off the speaker.
Audio Input
Press the ◄ or ► button to select audio input.
28
Installation I Menu
To access the Installation I menu and adjust the settings, perform the following steps:
1. Enter the OSD menu.
2. Press the ◄ or ► button to select the Installation I menu.
3. Press the ▲ or ▼ button to move the cursor up or down in the Installation I menu.
4. Press the ◄ or ► button to change values for each applicable setting.
ITEM
DESCRIPTION
Language
Press the ◄ or ► button to select a different localization menu.
Blank Screen
Press the ◄ or ► button to select different color to blank the
screen.
Projection
Press the ◄ or ► button to choose from four projection methods:
Front, Rear, Ceiling-Front, Ceiling-Rear.
Aspect Ratio
Press the ◄ or ► button to adjust the video aspect ratio.
Keystone
Press the ◄ or ► button to adjust the display keystone.
Digital Zoom
Press the ◄ or ► button to adjust the Digital Zoom menu.
Advanced
Press
30.
Reset
Press
to reset all settings to default values
(expect Language and Security Lock).
to enter the Advanced menu. See Advanced on page
29
Advanced
to enter the Advanced sub menu.
To adjust the advanced settings, press
ITEM
DESCRIPTION
Security Lock
Press the ◄ or ► button to enable or disable security lock
function.
Keypad Lock
Press the ◄ or ► button to enable or disable keypad lock
function.
Presentation Timer
Press
to enter the Presentation menu.
Presentation Timer
To adjust the presentation timer settings, press
menu.
ITEM
to enter the Presentation Timer sub
DESCRIPTION
Timer
Press the ◄ or ► button to enable or disable presentation timer
function.
Timer Period
Press the ◄ or ► button to adjust the display timer period.
Timer Reset
Press
to reset presentation timer counter.
30
Installation II Menu
To access the Installation II menu and adjust the settings, perform the following steps:
1. Enter the OSD menu.
2. Press the ◄ or ► button to select the Installation II menu.
3. Press the ▲ or ▼ button to move the cursor up or down in the Installation II menu.
ITEM
DESCRIPTION
Auto Source
Press the ◄ or ► button to enable or disable automatic source
detection.
LED Mode
Press the ◄ or ► button to select the LED mode for higher
brightness or lower brightness to save LED life.
Advanced
Press
to enter the Advanced menu. See Advanced Feature
on page 32.
Factory Reset
Press
Status
Press
to enter the Status menu. See page 35 for more
information on Status.
to reset all items to factory preset values.
31
Advanced Feature
To access the Advanced menu and adjust the settings, perform the following steps:
1. Enter the OSD menu.
2. Press the ◄ or ► button to select the Installation II menu.
3. Press the ▲ or ▼ button to select the Advanced menu and then press
.
4. Press the ▲ or ▼ button to move the cursor up or down in the Advanced menu.
5. Press the ◄ or ► button to change values for each applicable setting.
ITEM
DESCRIPTION
OSD Menu Setting
Press
to enter the OSD setting menu. See page 33 for
more information on OSD Menu Setting.
Peripheral Test
Press
to enter the Peripheral Test menu. See page 33 for
more information on Peripheral Test.
3D
Press
to enter the 3D menu. See 3D on page 34.
Note:
3D functionality works when the input source supports 120Hz.
32
OSD Menu Setting
ITEM
DESCRIPTION
Menu Position
Press the ◄ or ► button to select different OSD location.
Translucent Menu
Press the ◄ or ► button to select OSD background translucent
level.
Menu Display
Press the ◄ or ► button to select OSD timeout delay.
Peripheral Test
ITEM
Remote Control
Test
Color Test
Button Test
DESCRIPTION
Press
to test the IR remote controller for diagnostic.
Press
to select different colors on screen.
Press
to test the button on keypad.
33
3D
ITEM
DESCRIPTION
3D
Press the ◄ or ► to select Off, DLP-Link or IR.
3D Sync Invert
Press the ◄ or ► to turn 3D Sync Invert On or Off.
Factory Reset
To reset all of the menu items to the factory default values (except Language and Security
Lock), perform the following steps:
1. Press the ▲ or ▼ button to move the cursor up or down in the Installation II menu.
2. Select the Factory Reset sub menu.
3. Press
.
34
Status
To see the status of the Qumi, perform the following steps:
1. Press the ▲ or ▼ button to move the cursor up or down in the Installation II menu.
2. Select the Installation II sub menu
3. Press
to enter the Status sub menu.
ITEM
DESCRIPTION
Active Source
Displays the activated source.
Video Information
Displays resolution/video information for RGB source and color
standard for Video source.
LED Hours
LED use information is displayed (in hours). Eco and Normal
counters are separated.
35
Chapter 5 Taking Care of Your Qumi
Cleaning the Qumi
Cleaning the Qumi to remove dust and grime will help provide trouble-free operation.
Warning:
1. The Qumi should be turned off and unplugged before cleaning. Failure to do so
may result in injury or damage to the system.
2. Use only a dampened cloth when cleaning. Do not allow water to enter the
ventilation openings on the Qumi.
3. If a small amount of water gets into the interior of the Qumi while cleaning,
unplug the Qumi and set in a well ventilated area for several hours before using.
4. If a large amount of water gets into the interior of the Qumi when cleaning,
unplug the Qumi and have it serviced.
Cleaning the Lens
Optical lens cleaning solutions can be purchased from most camera and other retail
stores. To clean the Qumi lens, perform the following steps:
1. Apply a small amount of the optic lens cleaning solution to a clean and soft cloth. (Do
not apply the cleaning solution directly to the lens.)
2. Gently wipe the lens in a circular motion.
Caution:
1. Do not use abrasive cleaners or solvents.
2. To prevent discoloration or fading, do not allow the cleaning solution to contact
the Qumi case.
36
Troubleshooting
Common Problems and Solutions
These guidelines provide tips to deal with problems you may encounter while using the
Qumi. If the problem remains unresolved, contact your dealer for assistance.
The problem sometimes can be as simple as a wire that is not completely connected.
•
• Make sure that the Qumi is turned on.
• Make sure all connections are securely connected.
• Make sure the connected device is turned on; also make sure that the
device is not in suspend or sleep mode.
• Make sure the connected device is properly configured for an external
display (as needed)
Tips for Troubleshooting
help solve the problem more quickly.
For example, if you replace batteries and the problem remains, put the original batteries
back and move to the next step.
Keep a record of the steps you take when troubleshooting. The information may be useful
for reference when calling technical support or for bringing the Qumi to service personnel.
LED Error Messages
ERROR CODE MESSAGES
Over temperature error (Inlet air )
LED over temperature (Red)
LED over temperature (Green)
LED over temperature (Blue)
Fan 1 (Blower) error
Fan 2 (System) error
Red LED Thermistor error
Green LED Thermistor error
Blue LED Thermistor error
LEFT KEY
BLUE BLINK
3
3
3
3
6
6
8
8
8
RIGHT KEY
BLUE BLINK
OFF
1
2
3
1
2
1
2
3
In the event of an LED error, disconnect the AC power cord and wait for one (1) minute
before restarting the Qumi.
If there is any other situation that isn’t listed in the chart above, please contact your service
center.
37
Image Problems
Problem: No image appears on the screen
1. Verify that the settings on your personal computer are properly configured.
2. Turn off all of the equipment and power up the equipment again in the correct order.
Problem: The image is blurred
1. Adjust the Focus on the Qumi.
2. Make sure the Qumi-to-screen distance is within the specified range.
3. Clean the Qumi lens with optical lens cleaning cloth if it is dirty.
Problem: The image is wider at the top or bottom (trapezoid effect)
1. Position the Qumi so that it is perpendicular to the screen as much as possible.
2. Adjust the Keystone settings in the OSD to correct the problem.
Problem: The image is reversed
Check the orientation of the Projection setting in the Installation I menu in the OSD.
Problem: The image is streaked
1. Set the Frequency and Tracking settings on the Computer menu in the OSD to the
default settings.
2. Connect the Qumi to another computer to make sure that the problem is not caused
by a computer’s video card.
Problem: The image is flat with no contrast
Adjust the Contrast setting in the Image menu in the OSD.
Problem: The color of the projected image does not match the source image
Adjust the Color Temperature and Gamma settings in the Image menu in the OSD.
Remote Control Problems
Problem: The Qumi does not respond to the remote control
1. Aim the remote control towards remote sensor on the Qumi.
2. Make sure the path between remote and sensor is not obstructed.
3. Turn off any fluorescent lights in the room.
4. Check to see if the battery polarity is correct.
5. Replace the batteries.
6. Turn off other Infrared-enabled devices in the vicinity.
7. Have the remote control serviced.
38
Audio Problems
Problem: There is no sound
1. Adjust the volume of the audio source.
2. Check the audio cable connection.
3. Test the output of the audio source with other speakers.
4. Have the Qumi serviced.
Problem: The sound is distorted
1. Check the audio cable connection.
2. Test the output of the audio source with other speakers.
3. Have the Qumi serviced.
FAQs
1. Does Qumi work with a personal computer, notebook or netbook?
Yes. Use the provided VGA cable or HDMI cable. The Qumi can connect to a PC,
notebook or netbook if they have an appropriate HDMI or VGA port. To play audio,
a separate 3.5mm stereo mini-jack audio cable is required to connect to the Qumi’s
audio port.
2. Is it possible to connect the Qumi to a game console, such as a Microsoft®
Xbox or Sony® PS3?
Yes. The Qumi can be used to display content from an Xbox or PS3 console. This can
be done by connecting the HDMI cable from the game console to the Qumi.
3. Can the Qumi project content from a television?
Watching television content can be done by connecting a cable box, digital set-topbox or satellite receiver because televisions are only able to produce images on its
own screen. For example, if a cable box is used, it can be connected by an HDMI
cable to the Qumi.
4. How can an iPad® connect to the Qumi?
An Apple® iPad to VGA converter cable is required. To connect it to the Qumi, connect
the cable from the iPad to the converter. The VGA converter can then be connected
to the Qumi. The output of the iPad will be properly resized to fit the Qumi’s native
resolution and full screen view.
39
5. How are images from a digital camera or a USB storage device displayed?
Images and other content can be displayed by connecting the following devices to the
Qumi:
•
• Digital camera
• Smart phone
• microSD card
• Multimedia storage viewer
Once the devices are connected, images can be displayed by using the Qumi Media
Suite.
6. Which cable is required to video devices to the Qumi?
Video devices can be connected to the Qumi by using an Audio/Video or HDMI cable
if the devices contain the appropriate ports. To play audio, a separate stereo mini-jack
adapter cable (3.5mm mini plug and two RCA plugs). An RCA cable connected can
also be connected to the Qumi.
7. What type of video formats does the Qumi support?
H.264, MPEG-4, VC-1, WMV9, DivX(Xvid), Real Video, AVS and MJPEG.
8. What type of audio formats does the Qumi support?
MP3 and WMA.
9. What type of document formats does the QUMI support?
Microsoft®
Adobe®
®
®
, PowerPoint®),
10.What type of photo formats does the QUMI support?
JPEG, PNG and BMP.
11. How long will the LED light source in the Qumi last and can it be replaced?
The Qumi does not use a typical projector lamp. It uses a set of Light Emitting
Diodes (LED) to illuminate and project images. LED's have a greater lifespan
than conventional lamps; the Qumi is estimated to last 20,000 to 30,000 hours.
The lifespan of the LED depends on factors such as brightness, usage and
environmental conditions; however, LED brightness can decrease over time.
Please note that the LED modules are not replaceable.
Vivitek Support Site
Please visit www.vivitekcorp.com for more information, support and product registration.
40
Model
Qumi Q2
Brightness
Up to 300 Lumens
Native Resolution
HD 720p (1280x800)
Max. Resolution
UXGA (1600 x 1200)
Contrast Ratio
2,500:1 (Full On/Full Off)
Lamp Life and Type
≈30,000 Hours, LED
Display Type
HD Pico DLP® Technology by Texas Instruments
Throw Ratio
1.55:1 (Distance/Width)
Image Size (Diagonal)
30" to 90" (0.8 to 2.3 m)
Projection Distance
3.28' to 9.84' (1 to 3m)
Projection Lens
TBD
Zoom Ratio
Fixed Lens
Aspect Ratio
16:10 Native, 4:3 & 16:9 Compatible
Offset
102.5%
Keystone Correction
± 15° Vertical
Color Spectrum
1.07 Billion
Horizontal Scan Rate
15, 30 to 90 KHz
Vertical Scan Rate
43 to 85 Hz
Speaker
1W Mono
Projection Method
Table Top, Tripod (¼ - 20) or Ceiling (Front or Rear)
Uniformity
85%
File Compatibility
JPEG, Office Viewer (Doc, XLS, PDF)
Computer Compatibility
UXGA, WXGA, SXGA+, SXGA, XGA, SVGA, VGA Resized;
VESA Standards; PC and Macintosh Compatible
Video Compatibility
SDTV (480i), EDTV (480p), HDTV (720p, 1080i/p),
NTSC/NTSC 4.43, PAL B/G/H/I/M/N 60, SECAM
I/O Connection Ports
Mini-HDMI, Universal I/O (24-Pin Connector for
VGA/Component Input), AV Mini-Jack, Mini-Jack Audio-Out,
USB, MicroSD
Weight
21.7 oz (1.4 lbs)
Dimensions (W x H x D)
6.3” x 1.3” x 4.0” (162 x 32 x 102 mm)
Noise Level
28dB/32dB (Standard / Boost Mode)
Power
Supply: AC 100-240V, 50/60Hz
Consumption: 85W (Boost Mode), <0.5W (Standby)
Operating Temperature
41 to 104°F (5 to 40°C)
Safety Certification
FCC-B, UL, CCC, CE, C-Tick, KC, CB, SASO, NOM, PCT,
RoHS, PSB, ICES-003(Canada)
Note:
.
41
Projection Distance vs. Projection Size
Projection Distance and Size Table
IMAGE DIAGONAL IMAGE WIDTH
(MM/INCHES)
(MM/INCHES)
IMAGE HIGH
(MM/INCHES)
PROJECTION
DISTANCE
(MM/INCHES)
OFFSET-A
(MM/INCHES)
762/30
646/25.43
404/15.91
1000/39.37
10/0.40
1016/40
862/33.94
538/21.18
1340/52.76
13/0.51
1143/45
969/38.15
606/23.86
1500/59.06
15/0.59
1270/50
1077/42.40
673/26.50
1670/65.75
17/0.66
1524/60
1292/50.87
808/31.81
2000/78.74
20/0.79
1778/70
1508/59.37
942/37.09
2340/92.13
24/0.92
2032/80
1723/67.83
1077/42.40
2670/105.12
27/1.06
2286/90
1939/76.34
1212/47.72
3000/118.11
30/1.18
42
Timing Mode Table
H-SYNC V-SYNC COMPOSITE /
COMPONENT RGB DVI/HDMI
(KHZ)
(HZ)
S-VIDEO
SIGNAL
RESOLUTION
NTSC
—
—
15.734
60.0
15.625
50.0
720 x 400
37.9
85.0
640 x 480
31.5
60.0
640 x 480
37.9
72.0
640 x 480
37.5
75.0
640 x 480
43.3
85.0
800 x 600
35.2
56.0
800 x 600
37.9
60.0
800 x 600
48.1
72.0
800 x 600
46.9
75.0
PAL/SECAM
VESA
Apple® Mac
SDTV
EDTV
HDTV
800 x 600
53.7
85.0
1024 x 768
48.4
60.0
1024 x 768
56.5
70.0
1024 x 768
60.0
75.0
1024 x 768
68.7
85.0
1280 x 800
49.7
59.8
1280 x 800
62.8
74.9
1280 x 800
71.6
84.8
1280 x 1024
63.98
60.0
1280 x 1024
79.98
75.0
1280 x 1024
91.10
85.0
1280 x 960
60.0
60.0
1280 x 960
85.9
85.0
1400 x 1050
65.3
60.0
1440 x 900
70.6
75.0
1440 x 900
55.6
60.0
1600 x 1200
75.0
60.0
640 x 480
35.0
66.68
832 x 624
49.725
74.55
1024 x 768
60.24
75.0
1152 x 870
68.68
75.06
480i
15.734
60.0
576i
15.625
50.0
480p
31.469
60.0
576p
31.25
50.0
720p
37.5
50.0
720p
45.0
60.0
1080i
33.8
60.0
1080i
28.1
50.0
1080p
67.5
60.0
1080p
56.3
50.0
O
O
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
O: Frequency supported
—: Frequency not supported
*: Displayable level
43
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
O
O
O
O
O
O
O
O
O
O
—
—
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
—
—
—
—
—
—
—
—
—
—
—
—
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
—
O
O
O
O
O
O
O
O
O
O
O
O
O
O
Qumi Dimensions
44
Regulatory Compliance
FCC Warning
This equipment has been tested and found to comply with the limits for a Class B digital
device pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be required to correct the
interference at his/her own expense.
Changes or modifications not expressly approved by the parties responsible for
compliance could void the user’s authority to operate the equipment.
Canada
This class B digital apparatus complies with Canadian ICES-003.
Safety Certifications
FCC-B, UL, CCC, CE, C-Tick, KC, CB, SASO, NOM, PCT, RoHS, PSB,
ICES-003 (Canada)
Disposal and Recycling
This product may contain other electronic waste that can be hazardous if not disposed of
properly. Recycle or dispose in accordance with local, state, or federal Laws. For more
information, contact the Electronic Industries Alliance at www.eiae.org.
45
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
