Urushi
ray
Variant
name
ST18i, ST18a
White paper
March2011
June
z2011
White paper | Xperia™ ray
Purpose of this document
Sony Ericsson product White papers are intended to give an overview of a product and provide details in
relevant areas of technology.
Document history
Version
June 2011
First released version
Version 1
Sony Ericsson Developer World
For the latest Sony Ericsson technical documentation and development tools, go to
www.sonyericsson.com/developer.
This document is published by Sony Ericsson
Mobile Communications AB, without any
warranty*. Improvements and changes to this
text necessitated by typographical errors,
inaccuracies of current information or
improvements to programs and/or equipment
may be made by Sony Ericsson Mobile
Communications AB at any time and without
notice. Such changes will, however, be
incorporated into new editions of this document.
Printed versions are to be regarded as temporary
reference copies only.
This White paper is published by:
Sony Ericsson Mobile Communications AB,
SE-221 88 Lund, Sweden
www.sonyericsson.com
© Sony Ericsson Mobile Communications AB,
2009-2011. All rights reserved. You are hereby
granted a license to download and/or print a
copy of this document.
Any rights not expressly granted herein are
reserved.
*All implied warranties, including without
limitation the implied warranties of
merchantability or fitness for a particular
purpose, are excluded. In no event shall
Sony Ericsson or its licensors be liable for
incidental or consequential damages of any
nature, including but not limited to lost profits or
commercial loss, arising out of the use of the
information in this document.
Frist released version (June 2011)
Publication number: 1253-2401.1
2
June 2011
White paper | Xperia™ ray
Table of contents
Product overview ........................................................................................................4
Xperia™ ray ...........................................................................................................4
Sony Ericsson signature features ..........................................................................5
Facts – dimensions, weight, performance and networks ......................................6
Application overview list ........................................................................................8
Categorised feature list ..........................................................................................9
Technologies in detail ...............................................................................................11
Device-to-device communications (local) ...........................................................11
Bluetooth wireless technology ..........................................................................11
Wi-Fi® ...............................................................................................................12
DLNA™ (Digital Living Home Alliance)..............................................................13
Messaging ...........................................................................................................14
MMS (Multimedia Messaging Service)..............................................................14
Email .................................................................................................................14
Positioning – location based services .................................................................15
Provisioning (OMA CP) ........................................................................................15
Multimedia (audio, image and video) ...................................................................16
Synchronisation (OMA DS, EAS, Google Sync™) ...............................................17
Web browser .......................................................................................................17
Trademarks and acknowledgements ..................................................................18
3
June 2011
White paper | Xperia™ ray
Product overview
Xperia™ ray
Sleek and irresistibly elegant with a clear vibrant display, the Xperia™ ray combines compactness with
high functionality and style. Here’s a summary of the main features:
•Elegant smartphone with aluminium frame, mineral glass – and only 9.4mm thin
•Great stills and videos even in low light with Exmor R™ for mobile
•Reality Display with Mobile BRAVIA® Engine
•Fast, powerful smartphone with all the apps you need
9.4mm thin
Just 9.4mm thin and 100g light, the Xperia™ ray can fit neatly into the palm of your hand, or slide
comfortably into a small shirt or jeans pocket. Its flat aluminum frame adds further grace and style. But it’s
got more than just good looks. The Xperia™ ray combines the best of Android with the latest goodies
from Sony Ericsson.
Vibrant visuals
The Xperia™ ray delivers HD video and 8.1 megapixel photo capturing. Capture exceptionally clear
photos and videos even by candlelight with Exmor R for mobile, a back-illuminated CMOS sensor that
uses light more efficiently than conventional front-illuminated pixel technologies. Mobile BRAVIA ENGINE
further enhances the visual experience, combining magically with the scratch-resistant mineral glass and
3.3 inch Reality Display. The black screen finish cuts down on light lost through reflection, resulting in a
clearer image. And if that’s not enough, you get to browse the web in FWVGA resolution.
Power to go
The Xperia™ ray’s durable 1500mAh battery combines with the pre-installed power save mode
application to give you up to five times more staying power. So you can chat, watch videos and enjoy your
music for as long as you want.
Grow with Android Market
With the Android Market application installed as standard on your Xperia™ ray, you can easily download
everything from games to everyday tools and entertainment apps. With more than 200,000 apps available,
there are thousands of ways to personalise your life.
4
June 2011
White paper | Xperia™ ray
Sony Ericsson signature features
The Xperia™ ray comes with a range of Sony Ericsson features as standard. Below is a summary of the
key signature features.
Sony Ericsson Timescape™
The place to meet your friends
The Timescape™ application manages all your communication with one person in one place. You can
effortlessly browse by category your Facebook™, Twitter™, email and text communications, as well as
view your photos. Now everything is all together and in chronological order, so you don't have to open different applications to see what's going on.
Sony Ericsson infinite button
Everything you want – from everywhere
Tap the infinite button in the Timescape™ application and smart filter each category of communication by
person. For example, when viewing a text message from a friend in Timescape™, tap the infinite button to
view a list of all chat messages with that friend.
Sony Ericsson Sync™
Your mobile life on the web
Synchronise your phone data using Sony Ericsson Sync so that you always have a backup. While you’re
at it, match your phone contacts with your Facebook™ contacts. All your synchronised phone data is right
at your fingertips and in your account on www.sonyericsson.com.
Sony Ericsson Local connectivity
More control over your media
Using Sony Ericsson Local connectivity, you can exercise more control over how media files get transferred and stored. For example, you can select MTP mode to transfer files if you want to limit the risk of
data corruption or select MSC mode if you want to have more control over the data storage.
Sony Ericsson Home screen application
The place you call Home
Customise your Home screen with widgets, shortcuts, folders, themes, wallpaper and other items.
Where’s best for you? Email top right? Music player bottom left? You decide. With four extensions to your
Home screen, you’ve got plenty of space to put things where you want. Just remember to flick left or right
to find them.
Note: Some of the services mentioned above may not be available in all markets.
5
June 2011
White paper | Xperia™ ray
Facts – dimensions, weight, performance and
networks
Operating system
Google™ Android™ 2.3 (Gingerbread)
Processor
1 GHz Qualcomm Snapdragon™ MSM8255
Size
111x 53x9.4 mm
Weight
100 grams
Available colours
Black
Gold
Pink
White
Main screen
Colours
16,777,216 colour TFT
Resolution
854x480 pixels
Size (diagonal)
3.3 inches
Scratch resistant
Shatter proof sheet on scratch-resistant glass
Input mechanisms
Text input
On-screen QWERTY keyboard, 12 key input
Touch screen
Capacitive (multi-touch)
Touch gesture
Yes - multi-touch
Memory
Internal phone storage
1 GB (up to 300 MB of user accessible memory)
RAM
512 MB
Expansion slot
microSD™, up to 32 GB
Camera
Camera resolution
8.1 megapixel
Front-facing camera
Yes
Digital zoom
16x
Video recording
Yes - HD 720p
Sensors
Accelerometer
Yes
Proximity sensor
Yes
Ambient light sensor
Yes
Magnetometer
Yes
6
June 2011
White paper | Xperia™ ray
Networks
ST18i
UMTS HSPA 900 (Band VIII), 2100 (Band I)
GSM GPRS/EDGE 850, 900, 1800, 1900
ST18a
UMTS HSPA 800(Band VI), 850 (Band V), 1900 (Band II),
2100 (Band I)
GSM GPRS/EDGE 850, 900, 1800, 1900
Data transfer speeds
GSM GPRS
Up to 86 kbps
GSM EDGE
Up to 237 kbps
UMTS HSPA cat 6 (upload)
Up to 5.8 Mbps
UMTS HSPA cat 8 (download)
Up to 7.2 Mbps
Talk time (GSM)
Up to 6 hours 50 mins*
Standby time (GSM)
Up to 430 hours*
Talk time (UMTS)
Up to 7 hours*
Standby time (UMTS)
Up to 440 hours*
Music listening time
Up to 36 hours
Video playback time
Up to 6 hours 45 mins
Battery
1500 mAh
*Values are according to GSM Association Battery Life Measurement Technique.
Note: Battery performance may vary depending on network conditions and configurations, and phone
usage.
7
June 2011
White paper | Xperia™ ray
Application overview list
Sony Ericsson signature applications
Sony Ericsson Home sceen application
Sony Ericsson Music Player
Sony Ericsson Timescape™
Sony Ericsson services
PlayNow™ service*
TrackID™ application
Sony Ericsson Sync™
Other applications
Facebook™ *
Microsoft® Exchange ActiveSync®
Wisepilot™ turn-by-turn navigation (free trial version)*
*This service is not available in all markets.
8
June 2011
White paper | Xperia™ ray
Categorised feature list
Camera
Music
Internet
8.1 megapixel camera
16x digital zoom
Aperture f/2.4
Auto focus
Face detection
Face recognition
Photo light
Front-facing camera (VGA)
Geo tagging
HD video recording (720p)
Image stabiliser
Scene detection
Self-timer
Send to web
Smile detection
Sony Exmor R™ CMOS sensor
Touch capture
Touch focus
Video light
Video recording
Video stabiliser
Album art
Bluetooth™ stereo (A2DP)
Music tones (MP3/AAC)
PlayNow™ service**
SensMe™
Sony Ericsson Music Player
TrackID™ music recognition
application**
xLOUD™ Experience
Android Market*
Bookmarks
Google™ search**
Google Voice Search**
NeoReader™ barcode scanner
Pan & zoom
Web browser (WebKit)
Communication
Messaging
Design
Call list
Conference calls
Facebook™ application
Google Talk™
Noise Shield
Polyphonic ringtones
Sony Ericsson Timescape™
Speakerphone
Twitter™ (Timescape™ integration)
Vibrating alert
Video chat ready
Conversations
Email
Google Mail™
Instant messaging
Picture messaging (MMS)
Predictive text input
Text messaging (SMS)
Auto rotate
Keyboard (on-screen, 12 key)
Keyboard (on-screen, QWERTY)
Picture wallpaper
Reality display with Sony Mobile
BRAVIA® Engine
Touch screen
Wallpaper animation
9
June 2011
White paper | Xperia™ ray
Entertainment
Organiser
Connectivity
3D games
Media browser
Motion gaming
Radio (FM radio with RDS)
Video streaming
YouTube™ *
Alarm clock
Calculator
Calendar
Document editors
Document readers
E-Manual
Flight mode
Google Calendar™
Google Gallery 3D™*
Infinite button
Phone book
Setup Wizard
Widget manager
3.5 mm audio jack
aGPS
Bluetooth™ technology
DLNA Certified™
Google Latitude™
Google Maps™ with Street View
Media Transfer Protocol support
Micro USB support
Modem
Native USB tethering
Synchronisation via Facebook™
Synchronisation via Google™
Sync*
Synchronisation via Sony Ericsson Sync
Synchronisation with computer
Synchronisation via Exchange
ActiveSync®
USB High speed 2.0 support
USB mass storage
Wi-Fi®
Wi-Fi® Hotspot functionallity
Wisepilot™ turn-by-turn navigation*
* Applications from the Android Market™ vary widely in size, from less than 100 KB for small utilities to 3-4
MB for full games, music player applications, or other major offerings. The average size, if a representative
selection of useful and fun applications is selected, is about 1 MB. This means that, on average, more than
100 applications can be downloaded and used on your device without negatively impacting performance.
With the ready availability of the Android Market™ application in the phone, it is also very easy to delete
and later reinstall infrequently used applications.
** This service is not available in all markets.
10
June 2011
White paper | Xperia™ ray
Technologies in detail
NOTE: The information outlined below is general and levels of compliance to standards and specifications
may vary between products and markets. For more information, contact Sony Ericsson Developer World
or your Sony Ericsson contact person where applicable.
Device-to-device communications (local)
Bluetooth wireless technology
Bluetooth™ profiles supported
Advanced Audio Distribution Profile v1.2
Audio/Video Remote Control Profile v1.0
Handsfree Profile v1.5
Headset Profile v1.1
Object Push Profile v1.1
Phonebook Access Profile v1.0
Core version and supported
core features
Advanced Audio 2.1+EDR
Connectable devices
Products supporting at least one of the profiles above.
More information:
www.sonyericsson.com/developer
www.bluetooth.com
11
June 2011
White paper | Xperia™ ray
Wi-Fi®
Supported standards
IEEE 802.11b/g/n and Wi-Fi®.
Connectable devices
Wi-Fi® access points
Frequency band
2.4 GHz
Data transfer rate
Up to 72 Mbit/s
Security
WEP 64 bit
WEP 128 bit
TKIP
CCMP (AES)
Open Authentication
Shared Authentication
EAP-TLS
EAP-TTLS/MSCHAPv2
PEAPv0/EAP-MSCHAPv2
PEAPv1/EAP-GTC
WPA Personal and WPA2 Personal
WPA Enterprise and WPA2 Enterprise
Encryption
WEP, TKIP and AES
Power save
WMM-UAPSD
QoS, WMM
12
June 2011
White paper | Xperia™ ray
DLNA™ (Digital Living Home Alliance)
Supported Device Classes
M-DMS – Mobile Digital Media Server
Media Types: Images
Summary: The digital media server exposes the media
files in your phone to a Wi-Fi® network. The media files
can then be accessed from other DLNA clients.
Supported Bearers
Wi-Fi®
DRM Support
The Sony Ericsson DLNA implementation does not support DRM-protected content.
13
June 2011
White paper | Xperia™ ray
Messaging
MMS (Multimedia Messaging Service)
MMS 1.0 is supported.
Email
Bearer type (IP)
GPRS, EGPRS, UMTS
Character sets
BIG5 Traditional Chinese
GB2312 Simplified Chinese
ISO-2022-JP Japanese
ISO-8859-1
ISO-8859-2 Eastern Europe
ISO-8859-5 Cyrillic
ISO-8859-7 Greek
ISO-8859-9 Turkish
ISO 8859-11
KOI8-R Cyrillic
Shift_JIS Japanese
USASCII
UTF-16
UTF-8
Windows® 874
Windows® 1251 Cyrillic
Windows® 1252
Windows® 1254 Turkish
Windows® 1258 Vietnamese
Protocols
POP3 and IMAP4
Push email
Microsoft® Exchange ActiveSync® (EAS)
Secure email
SSL/TLS, both port methods (POPS/IMAPS) and STARTTLS
HTML mail
Yes (read only)
More information:
www.sonyericsson.com/developer
www.openmobilealliance.org
14
June 2011
White paper | Xperia™ ray
Positioning – location based services
Supported standards:
OMA Secure User Plane Location (SUPL) v1.0
3GPP™ Control Plane location (incl. Emergency location)
Qualcomm® GPSOneXtra
Provisioning (OMA CP)
OMA CP version 1.1
15
June 2011
White paper | Xperia™ ray
Multimedia (audio, image and video)
Audio Playback
Decoder format
Audio decoding MPEG-1/2/2.5,
audio layer 3
AAC, AAC+, eAAC+
AMR-NB, AMR-WB
General MIDI (GM)
Linear PCM 16bit
OTA
Ogg vorbis
Supported in file format
MP3 (.mp3) , 3GPP (.3gp); MP4
(.mp4, .m4a)
3GPP (.3gp) MP4 (.mp4)
3GPP (.3gp) MP4 (.mp4)
SMF (.mid)
WAV (.wav)
OTA (.ota)
Ogg vorbis (.ogg)
Audio Recording
Encoder format
AMR-NB, AMR-WB
Supported in file format
3GPP (.3gp), MP4 (.mp4),
AMR(.amr)
3GPP (.3gp), MP4 (.mp4)
AMR-NB, AMR-WB, AAC-LC
stereo, sample rate 48 kHz bit
rate 128 kbps
Decoder format
1, 4, 8, 16, 24 and 32 bpp and
RLE encoded formats
Single and multi frame, bitmap
mask support (GIF87a format
and GIF89a format)
Joint Photographic Experts
Group
Portable Network Graphics Bitmap mask support
Wireless Bitmap
Supported in file format
BMP (.bmp)
Image Capture
Encoder format
Joint Photographic Experts
Group
Supported in file format
JPEG (.jpg)
Video Playback
Decoder format
MPEG-4 Visual Simple Profile,
Advanced Simple Profile Level 6
H.264 High Profile Level 3.1
H.263 Profile 0, Profile 3 Level
70
Supported in file format
3GPP (.3gp); MP4 (.mp4)
3GPP (.3gp); MP4 (.mp4)
3GPP (.3gp)
Video Recording
Encoder format
- Video H.263 Profile 0, H.264
Baseline Profile
- Audio: AAC-LC stereo, sample
rate 48 kHz bit rate 128 kbps,
AMR-NB
Supported in file format
3GPP (.3gp), MP4 (.mp4)
Audio/Video Streaming
Streaming transport
RTSP according to 3GPP™
HTTP streaming
DRM
DRM (Digital Rights Management) — features the rights and
copy protection of downloaded
content.
OMA DRM 1.0
Image Playback
16
GIF (.gif)
JPEG (.jpg)
PNG (.png)
WBMP (.wbmp)
June 2011
White paper | Xperia™ ray
Synchronisation (OMA DS, EAS, Google Sync™)
OMA Data Synchronisation protocol versions 1.1.2 and 1.2.
OMA Data Formats: vCard 2.1, vCalendar 1.0.
Microsoft® Exchange ActiveSync® protocol version 2.5
Microsoft® Exchange ActiveSync® protocol version 12
Google Sync™
Related information: www.sonyericsson.com/developer
Web browser
Browser version
Android 2.3 Browser (Based on WebKit)
Navigation/rendering
Pan & Zoom
Landscape/portrait rendering
Full page PC rendering
Adobe™ Flash™ 10.1
Search
Internet Search
Browser compliancy
HTML version 4.0
HTML version 5.0
XHTML Basic version 1.0
XHTML 1.1
CSS 2.0
CSS 2.1
CSS 3.0
JavaScript 1.7/ECMA-script 262 3rd edition
DOM 2.0
DOM 3.0
Supported Device API
Geo-location API
Protocol compliancy
HTTP/1.1
TLS 1.0 and SSL 3.0
Gzip
OMA Download 1.0
Related information:
www.sonyericsson.com/developer
17
June 2011
White paper | Xperia™ ray
Trademarks and acknowledgements
The Liquid Identity and Liquid Energy logos, PlayNow, TrackID, Xperia and Timescape are trademarks or
registered trademarks of Sony Ericsson Mobile Communications AB. Sony, "make.believe", Exmor R,
xLOUD and Sony Mobile BRAVIA engine are trademarks or registered trademarks of Sony Corporation.
Ericsson is a trademark of Telefonaktiebolaget LM Ericsson.
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by
Sony Ericsson is under licence. TrackID is powered by Gracenote Mobile MusicID. Gracenote and
Gracenote Mobile MusicID are trademarks or registered trademarks of Gracenote, Inc.
Google, Google Calendar, Google Gallery 3D, Google Latitude, Google Maps, Google Places, Google
Talk, Google Search, Google Sync, Google Mail, Picasa, YouTube, Google Voice, Android and Android
Market are trademarks or registered trademarks of Google, Inc. Facebook is a trademark or registered
trademark of Facebook, Inc. Twitter is a trademark or a registered trademark of Twitter, Inc.
Wi-Fi is a trademark or registered trademark of the Wi-Fi Alliance. DLNA is a trademark or registered
trademark of the Digital Living Network Alliance. MicroSD is a trademark or registered trademark of
SanDisk Corporation. XHTML is a registered trademark of the W3C.
Microsoft, Windows, Exchange ActiveSync are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
Adobe Flash is a trademark or registered trademark of Adobe Systems Incorporated in the United States
and/or other countries. 3GPP™ is a trademark of ETSI.
Qualcom is a trademark or registered trademark of Qualcomm, Inc.
All other trademarks and copyrights are the property of their respective owners.
18
June 2011
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
