User Software Install

User Software Install

Fiery X3e

USER SOFTWARE INSTALLATION GUIDE

About the

Documentation

This manual is part of a set of Fiery X3e ™ documentation that includes the following manuals for users and system administrators:

• The

Quick Start Guide

summarizes the steps for configuring the Fiery X3e and printing. It also describes how to access the online documentation.

• The

User Software Installation Guide

describes how to install software from the

User Software CD to enable users to print to the Fiery X3e, and also describes setting up printing connections to the Fiery X3e.

• The

Configuration Guide

explains basic configuration and administration of the

Fiery X3e for the supported platforms and network environments. It also includes guidelines for setting up UNIX, Windows NT 4.0/2000, and Novell NetWare servers to provide printing services to users.

• The

Printing Guide

describes the printing features of the Fiery X3e for users who send jobs from their computers.

• The

Color Guide

provides information on managing the color output of the

Fiery X3e. It explains how to calibrate your copier and take advantage of the

ColorWise ® color management system, as well as features in ColorWise Pro Tools ™ .

• The

Fiery Color Reference

addresses concepts and issues associated with managing color output of the Fiery X3e and outlines key workflow scenarios. In addition, it offers information on printing color documents from popular Microsoft Windows and Apple Mac OS applications.

• The

Job Management Guide

explains the functions of the job management utilities, including Command WorkStation ™ and DocBuilder Pro ™ , and how you can use them to monitor and control jobs on the Fiery X3e. This manual is intended for an operator or administrator, or a user with the necessary access privileges, who monitors and manages job flow, performs color calibration, and troubleshoots problems that may arise.

Release Notes

provide last-minute product information and workarounds for some of the problems you may encounter.

Copyright © 2002 Electronics For Imaging, Inc. All rights reserved.

This publication is protected by copyright, and all rights are reserved. No part of it may be reproduced or transmitted in any form or by any means for any purpose without express prior written consent from Electronics For Imaging, Inc., except as expressly permitted herein. Information in this document is subject to change without notice and does not represent a commitment on the part of Electronics For Imaging, Inc.

The software described in this publication is furnished under license and may only be used or copied in accordance with the terms of such license.

This product may be covered by one of more of the following U.S. Patents: 4,500,919, 4,837,722, 5,212,546, 5,343,311, 5,424,754, 5,467,446, 5,506,946,

5,517,334, 5,537,516, 5,543,940, 5,553,200, 5,615,314, 5,619,624, 5,625,712, 5,666,436, 5,760,913, 5,818,645, 5,835,788, 5,867,179, 5,959,867,

5,970,174, 5,982,937, 5,995,724, 6,002,795, 6,025,922, 6,041,200, 6,065,041, 6,112,665, 6,122,407, 6,134,018, 6,141,120, 6,166,821, 6,185,335,

6,201,614, 6,215,562, 6,219,659, 6,222,641, 6,224,048, 6,225,974, 6,226,419, 6,238,105, 6,239,895, 6,256,108, 6,269,190, 6,289,122, 6,292,270,

6,310,697, 6,327,047, 6,327,050, 6,327,052, RE36,947, D406,117, D416,550, D417,864, D419,185, D426,206, D439,851, D444,793

Trademarks

ColorWise, EDOX, EFI, Fiery, the Fiery logo, Fiery Driven and RIP-While-Print are registered trademarks of Electronics For Imaging, Inc. in the U.S. Patent and Trademark Office and/or certain other foreign jurisdictions.

The eBeam logo, the Electronics For Imaging logo, the Fiery Driven logo, the PrintMe logo, the Splash logo, AutoCal, ColorCal, Command WorkStation,

DocBuilder, DocBuilder Pro, DocStream, eBeam, EFI Color Profiler, EFI Production System, EFI ScanBuilder, Fiery X2, Fiery X2e, Fiery X2-W, Fiery X3e, Fiery

X4, Fiery ZX, Fiery Z4, Fiery Z5, Fiery Z9, Fiery Z16, Fiery Z18, Fiery Document WorkStation, Fiery Downloader, Fiery Driver, Fiery FreeForm, Fiery Link,

Fiery Prints, Fiery Print Calibrator, Fiery Production System, Fiery Scan, Fiery ScanBuilder, Fiery Spark, Fiery Spooler, Fiery WebInstaller, Fiery WebScan, Fiery

WebSpooler, Fiery WebStatus, Fiery WebTools, NetWise, PrintMe, PrintMe Networks, Print Me. Everywhere You Go, RIPChips, Splash, Velocity, Velocity

Balance, Velocity Build, Velocity Design, Velocity Estimate, Velocity Scan, and VisualCal are trademarks of Electronics For Imaging, Inc.

All other terms and product names may be trademarks or registered trademarks of their respective owners, and are hereby acknowledged.

Legal Notices

APPLE COMPUTER, INC. (“APPLE”) MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION THE

IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, REGARDING THE APPLE SOFTWARE.

APPLE DOES NOT WARRANT, GUARANTEE, OR MAKE ANY REPRESENTATIONS REGARDING THE USE OR THE RESULTS OF THE USE

OF THE APPLE SOFTWARE IN TERMS OF ITS CORRECTNESS, ACCURACY, RELIABILITY, CURRENTNESS, OR OTHERWISE. THE ENTIRE

RISK AS TO THE RESULTS AND PERFORMANCE OF THE APPLE SOFTWARE IS ASSUMED BY YOU. THE EXCLUSION OF IMPLIED

WARRANTIES IS NOT PERMITTED BY SOME STATES. THE ABOVE EXCLUSION MAY NOT APPLY TO YOU.

IN NO EVENT WILL APPLE, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE TO YOU FOR ANY CONSEQUENTIAL,

INCIDENTAL OR INDIRECT DAMAGES (INCLUDING DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, LOSS OF

BUSINESS INFORMATION, AND THE LIKE) ARISING OUT OF THE USE OR INABILITY TO USE THE APPLE SOFTWARE EVEN IF APPLE

HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. BECAUSE SOME STATES DO NOT ALLOW THE EXCLUSION OR

LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATIONS MAY NOT APPLY TO YOU.

Apple’s liability to you for actual damages from any cause whatsoever, and regardless of the form of the action (whether in contract, tort [including negligence], product liability or otherwise), will be limited to $50.

Restricted Rights Legends

For defense agencies: Restricted Rights Legend. Use, reproduction, or disclosure is subject to restrictions set forth in subparagraph (c)(1)(ii) of the Rights in

Technical Data and Computer Software clause at 252.227.7013.

For civilian agencies: Restricted Rights Legend. Use, reproduction, or disclosure is subject to restrictions set forth in subparagraph (a) through (d) of the commercial Computer Software Restricted Rights clause at 52.227-19 and the limitations set forth in Electronics For Imaging’s standard commercial agreement for this software. Unpublished rights reserved under the copyright laws of the United States.

Part Number:

45029763

FCC Information

WARNING: FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly approved by the manufacturer could void the user’s authority to operate this equipment.

Class A Compliance

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, and uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause interference in which case the user will be required to correct the interference at his own expense.

Industry Canada Class A Notice

This Class A digital apparatus complies with Canadian ICES-003.

Avis de Conformation Classe A de l’Industrie Canada

Cet appareil numérique de la Classe A est conforme à la norme NMB-003 du Canada.

CE Marking (Declaration of Conformity)

This product complies with the following EU directives: 89/336/EEC, 73/23/EEC, and 93/68/EEC directives. This declaration is valid for the area of the

European Union.

RFI Compliance Notice

This equipment has been tested concerning compliance with the relevant RFI protection requirements both individually and on system level (to simulate normal operation conditions). However, it is possible that these RFI Requirements are not met under certain unfavorable conditions in other installations. It is the user who is responsible for compliance of his particular installation.

Dieses Gerät wurde sowohl einzeln als auch in einer Anlage, die einen normalen Anwendungsfall nachbildet, auf die Einhaltung der Funkentstörbestimmungen geprüft. Es ist jedoch möglich, dass die Funkentstörbestimmungen unter ungünstigen Umständen bei anderen Gerätekombinationen nicht eingehalten werden.

Für die Einhaltung der Funkentstörbestimmungen einer gesamten Anlage, in der dieses Gerät betrieben wird, ist der Betreiber verantwortlich.

Compliance with applicable regulations depends on the use of shielded cables. It is the user who is responsible for procuring the appropriate cables.

Die Einhaltung zutreffender Bestimmungen hängt davon ab, dass geschirmte Ausführungen benützt werden. Für die Beschaffung richtiger Ausführungen ist der

Betreiber verantwortlich.

Software License Agreement

YOU SHOULD CAREFULLY READ THE FOLLOWING TERMS AND CONDITIONS BEFORE USING THIS SOFTWARE. IF YOU DO NOT

AGREE TO THE TERMS AND CONDITIONS OF THIS AGREEMENT, DO NOT USE THE SOFTWARE. INSTALLING OR USING THE

SOFTWARE INDICATES THAT YOU AGREE TO AND ACCEPT THE TERMS OF THIS AGREEMENT. IF YOU DO NOT AGREE TO ACCEPT

THE TERMS OF THIS AGREEMENT YOU MAY RETURN THE UNUSED SOFTWARE FOR A FULL REFUND TO THE PLACE OF PURCHASE.

License

EFI grants you a non-exclusive license to use the software (“Software”) and accompanying documentation (“Documentation”) included with the Product. The

Software is licensed, not sold. You may use the Software solely for your own customary business or personal purposes. You may not rent, lease, sublicense or lend the Software. You may, however, permanently transfer all of your rights under this Agreement to another person or legal entity provided that: (1) you transfer to the person or entity all of the Software and Documentation (including all copies, updates, upgrades, prior versions, component parts, the media and printed materials, and this Agreement); (2) you retain no copies of the Software and Documentation, including copies stored on a computer; and (3) the recipient agrees to the terms and conditions of this Agreement.

You may not make or have made, or permit to be made, any copies of the Software or portions thereof, except as necessary for backup or archive purposes in support of your use of the Software as permitted hereunder. You may not copy the Documentation. You may not attempt to alter, disassemble, decompiler, decrypt or reverse engineer the Software.

Proprietary Rights

You acknowledge that the Software is proprietary to EFI and its suppliers and that title and other intellectual property rights therein remain with EFI and its suppliers. Except as stated above, this Agreement does not grant you any right to patents, copyrights, trade secrets, trademarks (whether registered or unregistered), or any other rights, franchises or licenses in respect of the Software. You may not adopt or use any trademark or trade name which is likely to be similar to or confusing with that of EFI or any of its suppliers or take any other action which impairs or reduces the trademark rights of EFI or its suppliers.

Confidentiality

You agree to hold the Software in confidence, disclosing the Software only to authorized users having a need to use the Software as permitted by this Agreement and to take all reasonable precautions to prevent disclosure to other parties.

Remedies and Termination

Unauthorized use, copying or disclosure of the Software, or any breach of this Agreement will result in automatic termination of this license and will make available to EFI other legal remedies. In the event of termination, you must destroy all copies of the Software and all of its component parts. All provisions of this Agreement relating to disclaimers of warranties, limitation of liability, remedies, damages, and EFI’s proprietary rights shall survive termination.

Limited Warranty and Disclaimer

EFI warrants to the original purchaser (“Customer”) for thirty (30) days from the date of original purchase from EFI or its authorized retailer that the Software will perform in substantial conformance to the Documentation when the Product is used as authorized by EFI’s specifications. EFI warrants the media containing the Software against failure during the above warranty period. EFI makes no warranty or representation that the Software will meet your specific requirements, that the operation of the Software will be uninterrupted or error free, or that all defects in the Software will be corrected. EFI makes no warranty, implied or otherwise, regarding the performance or reliability of any third party products (software or hardware) not provided by EFI. THE INSTALLATION OF ANY

THIRD PARTY PRODUCTS OTHER THAN AS AUTHORIZED BY EFI WILL VOID THIS WARRANTY. IN ADDITION, USE, MODIFICATION,

AND/OR REPAIR OF THE PRODUCT OTHER THAN AS AUTHORIZED BY EFI WILL VOID THIS WARRANTY.

EXCEPT FOR THE ABOVE EXPRESS LIMITED WARRANTY, EFI MAKES AND YOU RECEIVE NO WARRANTIES OR CONDITIONS ON THE

SOFTWARE, EXPRESS, IMPLIED, STATUTORY, OR IN ANY OTHER PROVISION OF THIS AGREEMENT OR COMMUNICATION WITH YOU,

AND EFI SPECIFICALLY DISCLAIMS ANY IMPLIED WARRANTY OR CONDITION OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR

PURPOSE OR NONINFRINGEMENT OF THIRD PARTY RIGHTS.

Limitation of Liability

TO THE MAXIMUM EXTENT PERMITTED BY LAW, EFI AND ITS SUPPLIERS SHALL NOT BE LIABLE FOR ANY DAMAGES, INCLUDING

LOSS OF DATA, LOST PROFITS, COST OF COVER OR OTHER SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES

ARISING FROM THE SALE, INSTALLATION, MAINTENANCE, USE, PERFORMANCE OR FAILURE OF THE SOFTWARE, HOWEVER CAUSED

AND ON ANY THEORY OF LIABILITY. THIS LIMITATION WILL APPLY EVEN IF EFI HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH

DAMAGE. YOU ACKNOWLEDGE THAT THE PRICE OF THE PRODUCT REFLECTS THIS ALLOCATION OF RISK. BECAUSE SOME

JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES,

THE ABOVE LIMITATION MAY NOT APPLY TO YOU.

Export Controls

You agree that you will not export or re-export the Software in any form in violation of any applicable laws or regulations of the United States or the country in which you obtained them.

U.S. Government Restricted Rights:

The Software and Documentation are provided with RESTRICTED RIGHTS. Use, duplication, or disclosure by the United States Government is subject to restrictions as set forth in subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause at DFARS 252.227-7013 or subparagraphs (c)(1) and (2) of the Commercial Computer Software Restricted Rights at 48 CFR 52.227-19, as applicable.

General

The laws of the State of California govern this Agreement. You agree that this Agreement shall not be subject to the United Nations Convention on Contracts for the International Sale of Goods (1980). This Agreement is the entire agreement held between us and supersedes any other communications or advertising with respect to the Software. If any provision of this Agreement is held invalid, the remainder of this Agreement shall continue in full force and effect.

If you have any questions, please see EFI’s web site at www.efi.com.

Electronics For Imaging

303 Velocity Way

Foster City, CA 94404

Contents

About the Documentation

Introduction

About this manual

Specifications

User software

Fiery WebTools

System requirements

Chapter 1: Installing User Software on a Windows Computer

Setting up PostScript or PCL printing with Windows 9x/Me

Installing the PostScript or PCL printer driver for Windows 9x/Me

Configuring installed options

Completing the Windows 9x/Me printer connection

Setting up PostScript or PCL printing with Windows NT 4.0

Installing the PostScript or PCL printer driver for Windows NT 4.0

Configuring installed options

Completing the Windows NT 4.0 printer connection

Setting up PostScript or PCL printing with Windows 2000/XP

Installing the PostScript or PCL printer driver for Windows 2000/XP

Configuring installed options

Completing the Windows 2000/XP printer connection

Installing EFI Fiery Mail Port

Installing Fiery utilities

Adobe Acrobat

Using Fiery utilities for the first time

Configuring the connection for Fiery utilities

Configuring the connection for Command WorkStation

1-32

1-32

1-36

1-40

1-50

1-55

1-57

1-57

1-58

1-60

1-17

1-17

1-20

1-25

1-1

1-2

1-3

1-6

xiii

xv

xi xi

xvi

viii Contents

Installing color files from the User Software CD

Installing the ICM profiles on a Windows computer

Loading the monitor settings file

Loading the ICM copier device profile

Installing the printer description files for Windows

Chapter 2: Installing User Software on a Mac OS Computer

Setting up the Fiery X3e as a PostScript printer

Setting up the Fiery X3e in the Chooser

Installing Fiery X3e software and fonts

Installing MRJ on your computer

Configuring a connection for ColorWise Pro Tools

Configuring a connection for Fiery Spooler

Configuring a connection for Fiery Downloader

Fonts

Installing color files from the User Software CD

Loading ICC profiles

Loading the monitor settings file

Loading the ICC copier profile

Chapter 3: Downloading Installers with Fiery WebTools

Setting up Fiery WebTools

Using the Fiery WebTools Installer

2-1

2-2

2-4

2-5

2-6

2-9

2-11

2-12

2-13

2-14

2-16

2-17

1-64

1-65

1-65

1-67

1-68

3-1

3-2

ix Contents

Chapter 4: Troubleshooting

On a Windows computer

Setting up printing on Windows NT 4.0 or Windows 2000/XP computers

Reinstalling the Adobe PostScript Printer Driver on Windows 9x/Me

Problems with the Fiery utilities on Windows computers

On a Mac OS computer

Setting up the Fiery X3e in the Chooser

Index

4-1

4-1

4-1

4-2

4-2

4-2

xi About this manual

Introduction

This manual describes how to install user software for the Fiery X3e, and how to set up printing from Microsoft Windows and Apple Mac OS computers. For information about setting up network servers and clients to use the Fiery X3e, see the

Configuration Guide

. For general information on using the color copier, your computer, application software, or network, see the manuals that accompany those products.

The name “Aero” is used in illustrations to represent the Fiery X3e. The Fiery X3e includes support for Fiery WebTools ™ and software for Command WorkStation, which enables an operator to manage all jobs sent to the Fiery X3e. Although it may not be the case at all sites, the documentation for this product assumes the presence of an operator who controls and manages jobs sent by users from remote workstations.

N

OTE

:

The term “Windows 9x” is used in this manual to represent Windows 98. The term “Windows” is used to refer to Windows 98, Windows Me, Windows NT 4.0,

Windows 2000, and Windows XP wherever appropriate.

About this manual

This manual covers the following topics:

• Installing printer files on Windows and Mac OS computers

• Setting up printing connections on Windows and Mac OS computers

• Installing Fiery ® utilities/other user software on Windows and Mac OS computers

Specifications

• Intel Mobile Pentium III 700 MHz CPU

• 128MB RAM

• 10GB hard disk drive

• Supports AppleTalk, TCP/IP, and IPX/SPX protocols simultaneously

• Supports Port 9100

• Supports twisted pair (Fast Ethernet 100BaseTX or Ethernet 10BaseT)

xii Introduction

• Supports parallel port

• Supports Adobe PostScript 3

• Supports PCL 5c printing (for Windows computers)

• Includes 136 fonts (126 Adobe Type 1 PostScript and 10 TrueType)

In addition, two Adobe Multiple Master fonts are included and are used for font substitution in PDF files.

• Includes 45 scalable PCL fonts

• Built-in ColorWise color management and NetWise ™ networking management

• Fiery WebTools, including WebSetup ™ (Windows only), Status ™ , WebSpooler ™ ,

WebLink ™ , Installer ™ , WebDownloader ™ , and WebScan ™

• Fiery utilities, including Fiery Downloader ™ , Fiery Remote Scan ™ , Fiery Mail

Port ™ , and Fiery Spooler ™ (Mac OS only)

• ColorWise Pro Tools

• Command WorkStation (Windows only) software

• Supports DocBuilder Pro (available as an option)

• Supports Fiery FreeForm ™

• Supports EFI Densitometer ™ ED-100 (available as an option)

• Supports Internet Printing Protocol (IPP) for Windows 98, Windows Me, and

Windows 2000/XP

• Supports E-mail printing

• Supports PrintMe ™ (available as an option)

xiii User software

User software

Fiery X3e user software is provided on the User Software CD.

Adobe PostScript

Printer Driver

PostScript Printer

Description (PPD) file

PostScript fonts

(Mac OS only)

Enables you to print to the Fiery X3e from

Windows 9x/Me, Windows NT 4.0, and Mac OS computers; also supports Fiery X3e and PostScript 3 features. Windows 2000/XP users should use the

Microsoft PostScript Printer Driver provided with those operating systems.

For use with the PostScript printer driver that allows the Fiery X3e to appear in the Print and Page Setup dialog boxes of popular applications. The Fiery X3e

PPDs provide information about the Fiery X3e and your particular copier model to the application and printer driver you are using.

PostScript screen and printer fonts that correspond to the PostScript printer fonts installed on the

Fiery X3e. For a complete list of PostScript fonts installed on the Fiery X3e, see Appendix B of the

Printing Guide

.

PCL Printer Driver

PCL PDD file

Enables you to print to the Fiery X3e from Windows computers; supports Fiery X3e PCL print features.

For use with the PCL printer driver that enables the

Fiery X3e to appear in Print and Page Setup dialog boxes in popular applications. The Fiery X3e PDDs provide information about the Fiery X3e and your particular copier model to the application and printer driver you are using.

xiv Introduction

Fiery Downloader

Fiery Spooler

(Mac OS only)

ColorWise Pro Tools

Fiery Remote Scan

Command WorkStation

(Windows only)

EFI Fiery Mail Port

(Windows only)

Color management files

Enables you to print PostScript files, PCL files,

Encapsulated PostScript (EPS) files, TIFF version 6.0 files, and Portable Document Format (PDF) versions

1.2 and 1.3 files directly to the Fiery X3e without opening the application in which they were created.

You can also use it to manage the printer fonts installed on the Fiery X3e.

Enables you to view the order and priority of print jobs, customize printer settings for jobs, delete jobs, and move jobs between queues. You can also use it to view job accounting information.

ICC-open color management and calibration tools; enables you to edit and download ICC profiles.

Standalone application and plug-in modules for supported TWAIN-compliant application software that enable you to scan images from the copier directly into the application. Enables you to scan to E-mail,

Mailbox, Disk, FTP, Internet Fax, and the Hold queue.

To use Fiery Remote Scan, see the

Printing Guide

.

Enables the operator to control the Fiery X3e functions from Windows 9x/Me and Windows NT/2000/XP computers. To use Command WorkStation, see the

Job

Management Guide

.

Enables you to send jobs to the Fiery X3e in the form of e-mail attachments by adding the EFI Fiery Mail

Port software as a printer port.

ICM (Windows) and ColorSync (Mac OS) color management files that enable you to maintain consistent color from your original artwork to the colors displayed on your monitor and then to the printed output.

xv Fiery WebTools

Color reference files

Calibration files

MRJ (Mac OS only)

Reference pages that you can print to view the range of colors available on your Fiery X3e. For the most predictable color results, refer to these pages when defining colors in applications. For more information on color management, see the

Color Guide

.

Includes measurement files and targets that you can use with ColorWise Pro Tools.

Mac OS Runtime for Java (MRJ) is required by all

Java-based Fiery utilities. If MRJ is not detected when you install these utilities, the MRJ installer is automatically launched.

N

OTE

:

You can install PostScript and PCL printer drivers and printer description files from the User Software CD or from the Fiery X3e with the Installer WebTool.

For instructions, see

“Using the Fiery WebTools Installer” on page 2.

Fiery WebTools

Fiery WebTools allow you to manage your Fiery X3e remotely from the Internet or from your company’s intranet. You access Fiery WebTools from the Fiery WebTools home page.

N

OTE

:

To find out which Fiery WebTools are supported, see

“Specifications” on page xi.

Fiery WebTools

Status

WebSpooler

WebLink

Summary For more information

Shows you the jobs currently processing and printing.

Allows you to view, manipulate, reorder, reprint, and delete jobs currently spooling, processing, or printing on the

Fiery X3e. It also allows you to view, print, and delete the Job Log.

Provides a link to another web page, provided you have a valid Internet connection.

See the

Printing Guide

.

See the

Job Management

Guide

.

See the

Printing Guide

and the

Configuration Guide

.

xvi Introduction

Fiery WebTools Summary

Installer Allows you to download the Fiery Link installer and Fiery X3e printer file installers directly from the server.

WebDownloader Allows you to download PostScript,

PCL,EPS, and PDF files to the

Fiery X3e.

WebSetup

(Windows only)

Allows you to modify the Fiery X3e configuration (Setup) remotely. This function requires the Administrator password, if one has been set.

WebScan Allows you to view and print images that have been scanned to the copier.

For more information

See

Chapter 3

.

See the

Printing Guide

.

See the

Configuration Guide

.

See the

Printing Guide

.

System requirements

System requirements are described in detail in the printed

Quick Start Guide

provided in your media pack.

1

1-1 Setting up PostScript or PCL printing with Windows 9x/Me

Chapter 1:

Installing

User Software on a Windows

Computer

This chapter describes the procedures for installing software and setting up printing from a computer using a supported version of Windows. For the Windows versions supported, see the

Quick Start Guide

.

The general steps for installing the software are as follows:

• Install the PostScript printer driver or PCL printer driver and corresponding printer driver files and set up the printer driver to communicate with the Fiery X3e.

• Install Fiery utilities and user software—EFI Fiery Mail Port, Fiery Remote Scan,

Fiery Downloader, ColorWise Pro Tools, and Command WorkStation.

• Configure the connection for Fiery utilities and user software.

• Copy additional files from the User Software CD as required.

In addition to using the User Software CD, you can download printer drivers from the

Fiery X3e with the Installer WebTool (if the administrator has enabled Internet access to the Fiery X3e). For instructions, see

“Using the Fiery WebTools Installer” on page 3-2. Once you download the printer files, the installation process is identical to

installing from the User Software CD.

Setting up PostScript or PCL printing with

Windows 9x/Me

To set up the Fiery X3e as a PostScript or PCL printer, you must install the PostScript or PCL printer driver for Windows 9x/Me and the corresponding printer description files. You must also configure either a local connection for printing directly or a network connection for printing over the network.

If you are printing using SMB (Server Message Block), you can connect to the

Fiery X3e and install the printer drivers in a single procedure. For more information, see

“Setting up SMB printing with Windows 9x/Me” on page 1-14.

N

OTE

:

The procedures for setting up printing with the PostScript and PCL printer drivers are similar. The following illustrations show the PostScript drivers. Any differences are noted.

1

1-2 Installing User Software on a Windows Computer

Installing the PostScript or PCL printer driver for Windows 9x/Me

The following procedure describes installing the printer driver from the User

Software CD or from the Installer WebTool. Subsequent procedures describe configuring installable options and setting up the printer connection.

N

OTE

:

The following procedures display Windows 98 illustrations; Windows Me differences are noted.

T

O INSTALL THE

P

OST

S

CRIPT OR

PCL

PRINTER DRIVER

FOR

W

INDOWS

9

X

/M

E

1.

Click Start, choose Settings, and then choose Printers.

2.

In the Printers window, double-click the Add Printer icon and click Next.

3.

Specify printing using a Local printer and click Next.

This procedure describes the installation of a local printer. You can modify the connection later, according to your network type.

4.

In the dialog box displaying lists of manufacturers and printers, click Have Disk.

The Install From Disk dialog box prompts you for the disk.

5.

If you are installing from the CD, type the name of the CD-ROM drive (for example,

D:\), and click Browse. Browse to English\Prntdrvr\Ps_drvr\Win_9x_ME.

If you are installing from the files you downloaded using the Installer WebTool, browse to prntdrvr\Prntdrvr\Ps_drvr\Win_9x_ME.

6.

Make sure “Oemsetup.inf” is selected and click OK.

The path is copied to the Install From Disk dialog box.

7.

Verify the path is correct and click OK.

1

1-3 Setting up PostScript or PCL printing with Windows 9x/Me

8.

Select the Fiery X3e printer driver appropriate for your printer and click Next.

9.

Select the LPT1 port and click Next.

You will configure the port later, according to your network type.

10.

Enter a name for the Fiery X3e.

11.

To make the Fiery X3e the default printer, select Yes; if not, select No and click Next.

12.

Select No to printing the test page and click Finish.

The necessary PostScript or PCL files are installed to your computer.

Configuring installed options

After you have completed the printer driver installation, you must configure the

Fiery X3e for the options installed on the copier. This allows the Fiery X3e to take advantage of the copier options. You can configure the options manually. Or, for

TCP/IP network connections, you can use the Two-Way Communication feature to configure the options automatically.

1

1-4 Installing User Software on a Windows Computer

Configuring installed options manually

The following procedure describes how to manually configure the Fiery X3e for the options installed on the copier.

T

O CONFIGURE OPTIONS MANUALLY FOR

W

INDOWS

9

X

/M

E

1.

Click Start, choose Settings, and then choose Printers.

2.

Click the Fiery X3e icon and choose Properties from the File menu.

3.

Click the Configuration tab.

4.

Select an installed option from the Available Options list.

5.

Click Add to move the option to the Installed Options list.

Engine Configuration

—Copier, Printer

Engine Type

—31 ppm Color Engine, 20 ppm Color Engine

N

OTE

:

The Engine Type option is not available with the PCL printer driver.

Optional Trays

—Not Installed, Universal Cassette (Tray 3), Universal Cassettes

(Tray 3, 4), LCC (Tray 3)

1

1-5 Setting up PostScript or PCL printing with Windows 9x/Me

Duplex Option

—Not Installed, Installed

Finisher Option

—Not Installed, Single Staple Finisher, Folding Finisher

Engine Storage Option

—Not Installed, Extension Memory, Hard Disk Drive,

Extension Memory and Hard Disk Drive

6.

Click Apply, and then click OK.

Configuring installed options and updating print options settings automatically

If you have a TCP/IP-enabled network, you can automatically update your printer driver to reflect the options currently installed on the copier. When the printer driver is first installed, the options have default settings that were set up in Fiery X3e Setup or

ColorWise Pro Tools. When you update the printer driver with the Two-Way

Communication feature, you allow the Fiery X3e to complete the actual setting.

The Two-Way Communication feature also updates Expert Color Settings options to reflect the current color settings on the Fiery X3e. To access the Expert Color Settings options, click the Expert Settings tab in the ColorWise print option bar of the Fiery printing tab of your printer driver. For more information, see the

Color Guide

.

T

O CONFIGURE INSTALLED OPTIONS AND UPDATE PRINT OPTIONS

SETTINGS AUTOMATICALLY FOR

W

INDOWS

9

X

/M

E

1.

Click Start, choose Settings, and then choose Printers.

2.

In the Printers window, select the icon for the Fiery X3e PostScript or PCL printer driver.

3.

Choose Properties from the File menu.

4.

Click the Configuration tab.

1

1-6 Installing User Software on a Windows Computer

5.

Select Two-Way Communication.

6.

Type the Fiery X3e IP address or DNS name.

7.

To display the printer’s current default settings when opened, select Update Fiery

Driver When Opened.

8.

Click Update, and then click OK.

Completing the Windows 9x/Me printer connection

To print from Windows 9x/Me, you should already have set up network servers, if any, and set up the Fiery X3e to accept print jobs from your computer.

To complete the Windows 9x/Me connection, you must configure a connection on each Windows computer for the network.

Completing the Windows 9x/Me parallel port connection

Preparing a parallel port connection for Windows 9x/Me requires specific BIOS settings on your computer, and specific port and printer settings for Windows 9x/Me.

In addition, the administrator may need to change the parallel port timeout in Fiery

Setup if you choose to spool files to the Fiery X3e, rather than print directly.

1

1-7 Setting up PostScript or PCL printing with Windows 9x/Me

T

O PREPARE THE

F

IERY

X3

E AND YOUR COMPUTER

FOR PARALLEL PORT PRINTING

1.

Connect the Fiery X3e to the parallel port on your computer.

For instructions, see the

Configuration Guide

.

2.

In Network Setup>Port Setup>Parallel Port Setup on the Fiery X3e Control Panel, set

Enable Parallel Port to Yes.

For more information about Fiery X3e Setup, see the

Configuration Guide

.

3.

If you want to spool files to the Fiery X3e, set Port Timeout in Seconds to 10.

If you want to print directly to the Fiery X3e, set Port Timeout in Seconds to 5.

4.

In your computer’s BIOS settings, set Parallel Port Mode to ECP.

To access the BIOS settings, restart the computer and press the key indicated on your monitor as soon as the computer starts up. You may have to scroll through several menus to reach the parallel port settings. After setting the Parallel Port Mode to ECP, save your changed setting and exit.

T

O PREPARE THE PRINTER FOR PARALLEL PORT PRINTING

1.

Click Start, choose Settings, and then choose Printers.

2.

Click the Fiery X3e printer icon and choose Properties from the File menu.

3.

Click the Details tab, and in the “Print to the following port” menu, select

LPT 1: (ECP Printer Port).

N

OTE

:

Check this selection carefully. It may read LPT 1: (Printer Port), which is

not

equivalent to LPT 1: (ECP Printer Port).

If this box does

not

read LPT 1: (ECP Printer Port), change the port setting now, as described in “To prepare the port for parallel port printing” on

page 1-9 , and then

return to this procedure. You may need your Windows System CD.

4.

If you changed the selection in the “Print to the following port” menu, click Apply.

A Warning dialog box may appear, stating that fonts you downloaded to the previously selected port may be lost; click OK.

1

1-8 Installing User Software on a Windows Computer

5.

Click Spool Settings.

6.

Select either “Spool print jobs so program finishes printing faster” or “Print directly to the printer.”

The selection you make depends on the port timeout you set in

step 3

on

page 1-7

:

• If you set the Port Timeout in Seconds to 10, you can select either option; however, spooling is faster.

• If you set the Port Timeout in Seconds to 5, select “Print directly to the printer.”

7.

Select “Disable bi-directional support for this printer” and click OK.

8.

Click Apply.

You are now ready to print from your applications to the Fiery X3e with the parallel port. To confirm the connection, print a test page.

9.

Click the General tab.

10.

Click Print Test Page and click OK.

11.

In the Job Notes field, type user and job identification information, and click OK.

If the test page prints successfully, you are ready to print from the computer.

Perform the following procedure in Windows 9x/Me only if the LPT1 port is not currently set to ECP Printer Port.

1

1-9 Setting up PostScript or PCL printing with Windows 9x/Me

T

O PREPARE THE PORT FOR PARALLEL PORT PRINTING

IN

W

INDOWS

9

X

/M

E

1.

Click Start, choose Settings, and then choose Control Panel.

2.

Double-click System.

The System Properties dialog box appears.

3.

Click the Device Manager tab.

4.

Double-click Ports.

5.

Double-click the port with LPT1 in its name.

6.

In the (LPT1) Properties dialog box, click the Driver tab and then click Update Driver.

The Update Device Driver Wizard dialog box appears.

1

1-10 Installing User Software on a Windows Computer

7.

Click Next.

8.

Select “Display a list of all the drivers in a specific location, so you can select the driver you want,” and then click Next.

9.

Select “Show all hardware.”

10.

From the Manufacturers list, select “(Standard port types).” From the Models list, select “ECP Printer Port” (

not

Printer Port). Click Next.

1

1-11 Setting up PostScript or PCL printing with Windows 9x/Me

11.

Click Yes in the Update Driver Warning dialog box.

12.

Click Next.

13.

Click Finish, then close the Printer Port Properties and System Properties dialog boxes.

You must restart your computer in order to activate the new settings. After

Windows 9x/Me restarts, complete the procedure described in

“To prepare the printer for parallel port printing” on page 1-7.

Completing the Windows 9x/Me IPX/SPX or IPX (Novell) connection

If you are printing through a Novell server, the Novell network and file server should be set up before you begin. The file server should be configured with a print server and print connection for the Fiery X3e. For details, see your NetWare documentation and the

Configuration Guide

.

To print from Windows 9x/Me computers over IPX (Novell), you must first set up

IPX/SPX protocols, and then configure the Fiery X3e by choosing the IPX frame type and entering the settings for the port you use.

T

O SELECT A FRAME TYPE FOR

IPX/SPX

PRINTING

FOR

W

INDOWS

9

X

/M

E

1.

Click Start, choose Settings, and then choose Control Panel.

2.

Double-click the Network icon.

Make sure that IPX/SPX-compatible Protocol is listed in the installed network components pane.

For instructions, see your Windows 9x/Me documentation or contact Microsoft

Technical Support.

1

1-12 Installing User Software on a Windows Computer

3.

Double-click the IPX/SPX-compatible Protocol icon.

4.

Click the Advanced tab.

5.

Select Frame Type in the Property list.

6.

In the Value menu, choose the Frame Type that corresponds to the one set in Fiery X3e

Network Setup.

If necessary, print the Configuration page from the Fiery X3e Control Panel to determine which frame type(s) are configured.

1

1-13 Setting up PostScript or PCL printing with Windows 9x/Me

N

OTE

:

Do not select Auto. Doing so may not select the frame type specified on the Fiery X3e.

7.

Click OK and close the Network Control Panel.

8.

When prompted to restart your computer, click Yes.

T

O SET UP A PORT FOR

IPX (N

OVELL

)

PRINTING WITH

W

INDOWS

9

X

/M

E

1.

Click Start, choose Settings, and then choose Printers.

2.

Click the Fiery X3e printer icon and choose Properties from the File menu.

3.

Click the Details tab and click Add Port.

A list of connection options appears.

4.

In the Add Port dialog box, specify the network path or click Browse for a display of your network environment.

5.

If you are using a NetWare file server, double-click the icon for the NetWare file server to use for printing to the Fiery X3e.

1

1-14 Installing User Software on a Windows Computer

6.

Click the printer icon for the NetWare print queue you want to use, and then click OK.

7.

In the Add Port dialog box, verify that the network path is updated and click OK.

Your print jobs are transmitted to the specified print queue on the Novell file server.

The Fiery X3e polls the file server, and if jobs are present, they are transmitted to the Fiery X3e.

8.

To confirm the connection, click the General tab, click Apply, and then click Print

Test Page.

After the test page prints successfully, you are ready to print from the computer.

Setting up SMB printing with Windows 9x/Me

SMB printing (also known as Windows or WINS printing) allows you to install the

PostScript or PCL printer driver and printer description files on your computer from the Fiery X3e using Point and Print, and print to a particular connection (Hold, Print, or Direct). To set up SMB printing, you must have the TCP/IP protocol and Client for

Microsoft Networks installed.

Each connection (Hold, Print, or Direct) requires a new printer driver and printer description file. Repeat the procedure

“To set up SMB printing on Windows 9x/Me”

for each connection. If you install more than one printer, give each a descriptive name during printer driver installation, such as

Aero-Print

or

Aero-Hold

, so you can easily identify printers.

B

EFORE YOU BEGIN

• Configure the Fiery X3e for SMB printing in Run Setup>Network Setup>Service

Setup > Windows Setup.

SMB printing is referred to as Windows Printing in Setup, on the Control Panel Map, and on the Configuration page.

1

1-15 Setting up PostScript or PCL printing with Windows 9x/Me

T

O SET UP

SMB

PRINTING ON

W

INDOWS

9

X

/M

E

1.

Double-click the Network Neighborhood icon to display your network environment.

2.

Browse for the printer you want to print to.

Browse for the name entered in Network Setup> Service Setup> Windows

Setup>Server Name. For this information, see the Configuration page.

N

OTE

:

You can also locate the printer using the Find feature on your Windows computer. Click Start, choose Find, and then choose Computer. Enter the name of the printer, and click Find Now.

If you are not able to locate your Fiery X3e, contact your network administrator.

3.

Double-click the name of the printer to display enabled print connections.

N

OTE

:

For a description of each print connection, see the

Configuration Guide

.

4.

Double-click the name of the connection you want to print to.

5.

Select Yes to install the PostScript or PCL printer driver and printer description file for the selected connection.

The Add Printer Wizard dialog box appears.

6.

Specify whether you print from MS-DOS based programs and click Next.

If you choose Yes, you must capture a printer port before proceeding with the installation. For details, see your Windows documentation.

1

1-16 Installing User Software on a Windows Computer

7.

Type a name for the Fiery X3e in the Printer name field and choose whether to make it the default printer. Click Next.

8.

If you want to print a test page, choose Yes and click Finish.

The necessary files are installed to your computer.

If the test page prints successfully, you are ready to print from the computer.

Setting up IPP printing with Windows 9x/Me

With Internet Printing Protocol (IPP), print jobs are sent to the Fiery X3e over the Internet.

IPP printing is supported on Windows 2000/XP but can be enabled on

Windows 9x/Me computers by installing the “wpnpins.exe” client file (available on the

Windows Me CD or the Windows 2000 Server CD). For more information about obtaining and installing this client, contact the Microsoft Corporation or Microsoft

Technical Support.

N

OTE

:

The IPP setup procedures are performed after installing the appropriate printer drivers. See

“To install the PostScript or PCL printer driver for Windows 9x/Me” on page 1-2.

B

EFORE YOU BEGIN

1.

Prepare the Fiery X3e for TCP/IP printing.

2.

Make sure the Fiery X3e is configured for IPP printing.

For more information, see the

Configuration Guide

.

3.

Specify the printing destination on your computer.

T

O SET UP

IPP

PRINTING WITH

W

INDOWS

9

X

/M

E

1.

Click Start, choose Settings, and then choose Printers.

2.

In the Printers windows, right-click the icon for the Fiery X3e PostScript printer driver and choose Properties.

3.

Click the Details tab and click Add Port.

The Add Port dialog box appears.

1

1-17 Setting up PostScript or PCL printing with Windows NT 4.0

4.

Enter the network path for the printer.

5.

Click OK.

Setting up PostScript or PCL printing with Windows NT 4.0

To set up the Fiery X3e as a PostScript or PCL printer, you must install the PostScript or PCL printer driver for Windows NT 4.0 and the corresponding printer description files. You must also configure the print connection between the computer and the

Fiery X3e. If you are printing over a network, you must configure a network connection. If you are printing directly to the printer, you must configure a parallel port connection.

N

OTE

:

The procedures for setting up printing with the PostScript and PCL printer drivers are similar. The following illustrations show the PostScript driver. Any differences are noted.

Installing the PostScript or PCL printer driver for Windows NT 4.0

The following procedures describe the installation of a local printer. Adding a printer to a local system requires that you log in to your local Windows NT 4.0 computer

(not the network server domain) and that you are a member of the Administrators group. The procedure for adding a network printer is similar to adding a port. See

“Completing the Windows NT 4.0 TCP/IP and LPR connection” on page 1-26.

T

O INSTALL THE

P

OST

S

CRIPT OR

PCL

PRINTER DRIVER

FOR

W

INDOWS

NT 4.0

1.

If you are installing from the User Software CD, insert it into the CD-ROM drive.

2.

Click Start, choose Settings, and then choose Printers.

3.

Double-click Add Printer.

4.

To install a printer locally, select My Computer and click Next.

My Computer is available if you logged in to a computer on which you have

Administrator privileges. If it is not available, you can add a network printer.

The procedure is similar to adding a port (see

page 1-26

).

1

1-18 Installing User Software on a Windows Computer

5.

Select LPT1: and click Next.

This is a general installation that works for the parallel port connection. You can add a network port later, according to your network type.

6.

In the dialog box displaying lists of manufacturers and printers, click Have Disk.

The Install From Disk dialog box prompts you for the disk.

7.

If you are installing from the CD, type the name of the CD-ROM drive (for example,

D:\) and click Browse.

If you are installing from files you downloaded using the Installer WebTool, type the name of your hard disk drive (for example, C:\) and click Browse.

8.

If you are installing from the CD, browse to the English\Prntdrvr\Ps_drvr\Win_NT4x folder and click Open.

If you are installing from files you downloaded using the Installer WebTool, browse to the prntdrvr\Prntdrvr\Ps_drvr\Win_NT4x folder and click Open.

Make sure “Oemsetup.inf ” or “Oemsetup” is selected.

The path is copied to the Install From Disk dialog box.

1

1-19 Setting up PostScript or PCL printing with Windows NT 4.0

9.

Verify that the path is correct and click OK.

10.

In the Printers list, select the Fiery X3e printer driver and click Next.

11.

Type a name for the Fiery X3e in the Printer name field and indicate whether you want to make it the default printer. Click Next.

12.

Indicate whether you want the printer installed as a shared printer, and click Next.

If you select Shared, enter a Share Name for the printer and select the operating systems used by client computers. For information on shared printers, see the

Configuration Guide

.

13.

Click No to postpone printing a test page and click Finish.

When installation is complete, the Printers window is displayed with an icon for the newly installed printer.

1

1-20 Installing User Software on a Windows Computer

Configuring installed options

After you have completed the printer driver installation, you must configure the

Fiery X3e to reflect the options installed on the copier. This allows the Fiery X3e to take advantage of the copier options. You can configure the options manually; or for

TCP/IP network connections, you can use the Two-Way Communication feature to configure the options automatically.

Configuring installed options manually

The following procedure describes how to manually configure the Fiery X3e for the options installed on the copier.

T

O CONFIGURE INSTALLABLE OPTIONS FROM THE

P

OST

S

CRIPT PRINTER DRIVER

FOR

W

INDOWS

NT 4.0

1.

Click Start, choose Settings, and then choose Printers.

2.

Right-click the Fiery X3e icon and choose Properties from the File menu.

3.

Click the Device Settings tab and scroll to Installable Options.

1

1-21 Setting up PostScript or PCL printing with Windows NT 4.0

4.

Select an Installable Option and choose a setting.

N

OTE

:

Windows NT systems display installable options as a menu. You must select the installable option to activate the menu.

Engine Configuration

—Copier, Printer

Engine Type

—31 ppm Color Engine, 20 ppm Color Engine

Optional Trays

—Not Installed, Universal Cassette (Tray 3), Universal Cassettes

(Tray 3, 4), LCC (Tray 3)

Duplex Option

—Not Installed, Installed

Finisher Option

—Not Installed, Single Staple Finisher, Folding Finisher

Engine Storage Option

—Not Installed, Extension Memory, Hard Disk Drive,

Extension Memory and Hard Disk Drive

5.

Click OK to activate the current settings.

T

O CONFIGURE INSTALLABLE OPTIONS ON THE

F

IERY

X3

E

FROM THE

PCL

PRINTER DRIVER

1.

Click Start, choose Settings, and then choose Printers.

2.

Right-click the Fiery X3e icon, and choose Document Defaults from the File menu.

1

1-22 Installing User Software on a Windows Computer

3.

Click the Configuration tab and specify the options installed on the Fiery X3e.

4.

Select an installed option from the Available Options list, and click Add to move the option to the Installed Options list.

Engine Configuration

—Copier, Printer

Optional Trays

—Not Installed, Universal Cassette (Tray 3), Universal Cassettes

(Tray 3, 4), LCC (Tray 3)

Duplex Option

—Not Installed, Installed

Finisher Option

—Not Installed, Single Staple Finisher, Folding Finisher

Engine Storage Option

—Not Installed, Extension Memory, Hard Disk Drive,

Extension Memory and Hard Disk Drive

5.

Click OK.

You are ready to connect to your network type (see

“Completing the Windows NT 4.0 printer connection” on page 1-25).

1

1-23 Setting up PostScript or PCL printing with Windows NT 4.0

Configuring installed options and updating print options settings automatically

If you have a TCP/IP-enabled network, you can automatically update your printer driver to reflect the options currently installed on the Fiery X3e. When the printer driver is first installed, the installable options have default settings that were set up in

Fiery X3e Setup or ColorWise Pro Tools. When you update the printer driver with the

Two-Way Communication feature, you allow the Fiery X3e to complete the actual setting.

The Two-Way Communication feature also updates Expert Color Settings options to reflect the current color settings on the Fiery X3e. To access Expert Color Settings options, click the Expert Settings tab in the ColorWise print option bar of the Fiery printing tab of your printer driver. For more information, see the

Color Guide

.

T

O SET UP

T

WO

-W

AY

C

OMMUNICATION FOR

P

OST

S

CRIPT OR

PCL

PRINTER DRIVERS FOR

W

INDOWS

NT 4.0

1.

Click Start, choose Settings, and then choose Printers.

2.

In the Printers window, select the icon for the Fiery X3e PostScript or PCL printer driver.

3.

Choose Properties from the File menu.

4.

Click the Configuration tab.

N

OTE

:

The following illustration shows the PostScript printer driver. The PCL printer driver is similar except for the tabs and the title bar.

1

1-24 Installing User Software on a Windows Computer

5.

Select Two-Way Communication.

6.

Enter the Fiery X3e IP address or DNS name.

7.

If you want your printer driver to display the current settings when opened, select

Update Fiery Driver When Opened.

8.

Click Update.

9.

Click OK.

1

1-25 Setting up PostScript or PCL printing with Windows NT 4.0

Completing the Windows NT 4.0 printer connection

To print from Windows NT 4.0, you must:

• Set up network servers, if any.

• Set up the Fiery X3e to accept print jobs from your computer.

• Configure a port on each Windows NT 4.0 computer for the network type.

To do this

Configure the parallel connection

Configure the TCP/IP (LPR port) connection

Configure the IPX (Novell) connection

See

“Completing the Windows NT 4.0 parallel port connection” in this section.

“Completing the Windows NT 4.0 TCP/IP and LPR connection” on page 1-26.

“Completing the Windows NT 4.0 IPX

(Novell) connection” on page 1-28.

Completing the Windows NT 4.0 parallel port connection

The parallel port cable connects the Fiery X3e to a single computer. Once you have installed the Windows NT 4.0 PostScript printer driver and the Fiery X3e printer description files, complete the setup for parallel port printing.

T

O SET UP PARALLEL PRINTING FOR

W

INDOWS

NT 4.0

1.

Click Start, choose Settings, and then choose Printers.

2.

Double-click the Fiery X3e icon and choose Properties from the Printer menu.

In the Ports tab, confirm that LPT1 (Local Port) is checked.

The Fiery X3e is ready to accept parallel print jobs from your computer, using the

Windows NT 4.0 PostScript printer driver and the Fiery X3e printer description file.

3.

Click the General tab and click Print Test Page.

1

1-26 Installing User Software on a Windows Computer

4.

To share the printer on the network, click the Sharing tab.

Select whether to share the printer, and specify the operating systems used by network clients.

5.

Click OK to exit the Printer Properties dialog box.

Completing the Windows NT 4.0 TCP/IP and LPR connection

After installing the PostScript or PCL printer driver and printer driver files, complete the setup for the TCP/IP and LPR connection by performing the following steps:

• Prepare the Fiery X3e to accept print jobs using TCP/IP and LPR protocols.

For details, see the

Configuration Guide

.

• Enable LPD from the Fiery X3e Control Panel. For details, see the

Configuration

Guide

.

• Configure the computer for the TCP/IP connection.

Before you continue, contact the system administrator for the IP address assigned to the Fiery X3e, as well as the subnet mask and the gateway address, if they are used.

The TCP/IP protocol should already be installed on your Windows NT computer.

T

O SET UP

TCP/IP

AND

LPR

PRINTING FOR

W

INDOWS

NT 4.0

1.

Open the Properties dialog box for the Fiery X3e and click the Ports tab.

2.

Click Add Port.

The available port types are displayed.

1

1-27 Setting up PostScript or PCL printing with Windows NT 4.0

3.

Select LPR Port and click New Port.

If the LPR port is not listed, install the TCP/IP network protocol and

Microsoft TCP/IP printing software. See your Windows documentation.

4.

Type the IP address of the Fiery X3e.

If your network uses Domain Name Services (DNS), enter the DNS name assigned to the Fiery X3e instead of the IP address.

5.

Type one of the following printer names, depending on the Fiery X3e connection you want to print to.

print hold

6.

Click OK.

The computer checks the address or DNS name you entered and notifies you if it cannot resolve the address.

7.

Click Close in the Printer Ports dialog box.

The new port configuration is reflected in the Ports tab. You must close the Printer

Properties dialog box to verify the connection.

8.

Click OK to close the Printer Properties dialog box.

9.

Reopen the Printer Properties dialog box.

10.

Click the General tab and click Print Test Page.

When you print, your PostScript or PCL files are transmitted over the LPR Port connection to the Fiery X3e.

11.

Click OK to close the Printer Properties dialog box.

1

1-28 Installing User Software on a Windows Computer

Completing the Windows NT 4.0 IPX (Novell) connection

Complete the setup for the IPX (Novell) connection as follows:

• Configure the Novell network and file server for handling Fiery X3e print jobs. The file server should be configured with a print server and print connection for the

Fiery X3e. For details, see your NetWare documentation.

• Prepare the Fiery X3e for IPX printing.

• Set up the IPX connection on the computer.

NetWare protocols (NWLink IPX/SPX Compatible Transport) and NetWare client services should already be installed on the Windows NT 4.0 computer.

T

O SET UP

IPX (N

OVELL

)

PRINTING FOR

W

INDOWS

NT 4.0

1.

Double-click Network Neighborhood.

2.

Double-click NetWare or Compatible Network.

A list of NetWare servers appears.

3.

Double-click the NetWare Tree or File Server on which the network administrator defined a print connection for the Fiery X3e.

You may have to log in to the file server to see the print connections.

4.

Double-click the print connection defined for the Fiery X3e.

1

1-29 Setting up PostScript or PCL printing with Windows NT 4.0

5.

If the NetWare server does not have a suitable driver for the Fiery X3e, you may be asked if you want to set up the printer on your computer. Click Yes.

6.

Click OK to install the Fiery X3e PostScript printer driver.

7.

Follow steps 6 to

13

of the procedure on

page 1-18 .

When installation is complete, a new printer window appears, with the name of the print queue on the NetWare server.

8.

Choose Properties from the File menu and click the Ports tab.

Verify that the connection to the NetWare queue is listed and selected as a port for the Fiery X3e.

9.

Click the General tab and click Print Test Page.

10.

In the printer Job Notes window, type user and job identification information and click OK.

The Test Page remains listed in the queue window until it is printed.

The Fiery X3e polls the NetWare server for print jobs in the print connection defined for the Fiery X3e. When you print, your PostScript files are spooled to that connection and transmitted over the queue “port” to the Fiery X3e.

1

1-30 Installing User Software on a Windows Computer

Setting up SMB printing on Windows NT 4.0

SMB printing (also known as Windows printing) allows you to install the PostScript or

PCL printer driver and printer description files, and print from your computer to a particular print connection (Hold, Print, or Direct) on the Fiery X3e. These instructions assume you have installed the TCP/IP protocol and Client for Microsoft

Networks.

Each connection (Hold, Print, or Direct) requires a new printer driver and printer description file. To set up printing to a second or third print connection, repeat the procedure

“To set up SMB printing on Windows NT 4.0” on page 1-31. If you install

more than one printer, give each a descriptive name during printer driver installation, such as Aero-Print or Aero-Hold , so you can easily identify printers.

N

OTE

:

To change printer defaults and configure installable options from Windows

NT 4.0, you must log on as Administrator and use the password specified in Fiery X3e

Setup. If you log on as a User, you can install the printer driver through Point and

Print, but you cannot modify printer defaults and configure installable options.

B

EFORE YOU BEGIN

• Configure the Fiery X3e for SMB printing in Run Setup>Network Setup>Service

Setup> Windows Setup.

SMB printing is referred to as Windows Printing in Setup, on the Control Panel Map, and on the Configuration page. For more information, see the

Configuration Guide

.

1

1-31 Setting up PostScript or PCL printing with Windows NT 4.0

T

O SET UP

SMB

PRINTING ON

W

INDOWS

NT 4.0

1.

Double-click Network Neighborhood.

2.

Browse for the printer you want to print to.

The printer name you are browsing for is the name entered in Network

Setup>Service Setup >Windows Setup>Server Name. For this information, see the

Configuration page.

The amount of network traffic determines the amount of time required for the

Browse function.

N

OTE

:

You can also locate the printer with the Find feature on your Windows computer. Click Start, choose Find, and then choose Computer. Enter the name of the printer, and click Find Now.

If you are not able to locate your Fiery X3e, contact your network administrator.

3.

Double-click the name of the Fiery X3e to display enabled print connections.

1

1-32 Installing User Software on a Windows Computer

4.

Double-click the name of the connection you want to print to.

The Printers dialog box appears, asking whether you want to set up the printer.

5.

Select Yes to complete the installation for the selected connection.

Windows NT 4.0 downloads the printer driver and printer description files from the

Fiery X3e to your computer and installation is complete.

Setting up PostScript or PCL printing with

Windows 2000/XP

To set up the Fiery X3e as a PostScript or PCL printer, you must install the PostScript or PCL printer driver for Windows 2000/XP and the corresponding printer description files. You must also configure the print connection between the computer and the Fiery X3e. If you are printing over a network, you must configure a network connection. If you are printing directly to the printer, you must configure a parallel port connection.

N

OTE

:

The procedures for configuring the options for the PostScript and PCL printer drivers are similar. The following illustrations show the PostScript driver. Differences are noted.

Installing the PostScript or PCL printer driver for Windows 2000/XP

The following procedure describes installing the printer driver from the User

Software CD or from the Installer WebTool. Subsequent procedures describe setting up the print connection.

1

1-33 Setting up PostScript or PCL printing with Windows 2000/XP

T

O INSTALL THE

P

OST

S

CRIPT OR

PCL

PRINTER DRIVER

FOR

W

INDOWS

2000/XP

1.

On Windows 2000, click Start, choose Settings, and then choose Printers to display the

Printers window.

On Windows XP, click Start and choose Printer and Faxes.

2.

On Windows 2000, double-click the Add Printer icon and click Next.

On Windows XP, click Add Printer.

3.

Specify printing using a Local printer and click Next.

This procedure describes the installation of a local printer. You can modify the connection later, according to your network type.

4.

Select LPT1: and click Next.

5.

In the dialog box displaying lists of manufacturers and printers, click Have Disk.

The Install From Disk dialog box prompts you for the disk.

1

1-34 Installing User Software on a Windows Computer

6.

Type the name of the CD-ROM drive (for example, D:\) and click Browse. Browse to the

English\Prntdrvr\Ps_drvr\Win_2000 or English\Prntdrvr\Ps_drvr\Win_XP folder.

If you are installing from the files you downloaded using the Installer, browse to prntdrvr\Prntdrvr\Ps_drvr\Win_2000 or prntdrvr\Prntdrvr\Ps_drvr\Win_XP and click

Open.

Make sure “Oemsetup.inf ” or “Oemsetup” is selected and click Open.

7.

Verify the path is correct and click OK.

The path is copied to the Install From Disk dialog box.

8.

In the Printers box, select the Fiery X3e printer driver appropriate for your printer and click Next.

1

1-35 Setting up PostScript or PCL printing with Windows 2000/XP

9.

Type a name for the Fiery X3e in the Printer name field.

This name will be used in the Printers window and the queues window.

10.

Follow the instructions in the remaining dialog boxes.

When asked whether to print a test page, select No.

The necessary files are installed to your hard disk.

N

OTE

:

The Digital Signature Not Found dialog box indicates that the printer driver for

Windows 2000 does not have a Microsoft digital signature. However, printing to the

Fiery X3e is processed correctly, so click Yes to continue with installation.

1

1-36 Installing User Software on a Windows Computer

11.

If this is the first printer driver you are installing on the computer, you may be prompted to install files from the Windows 2000 CD. Insert the CD-ROM, browse to the win2000\english\i386 folder, and then click OK.

When installation is complete, the Printers window appears with an icon for the newly installed printer. You must now configure the options installed on your copier.

Configuring installed options

After you have completed the printer driver installation, you must configure the

Fiery X3e to reflect the options installed on the copier. This allows the Fiery X3e to take advantage of the copier options. You can configure the options manually; or for

TCP/IP network connections, you can use the Two-Way Communication feature to configure the options automatically.

Configuring installed options manually

The following procedure describes how to manually configure the Fiery X3e for the options installed on the copier.

T

O CONFIGURE INSTALLABLE OPTIONS ON THE

F

IERY

X3

E FROM THE

P

OST

S

CRIPT

PRINTER DRIVER FOR

W

INDOWS

2000/XP

1.

On Windows 2000, click Start, choose Settings, and then choose Printers.

On Windows XP, click Start, and choose Printers and Faxes.

2.

Right-click the Fiery X3e icon and choose Properties.

3.

Click the Configuration tab.

4.

Select an installed option from the Available Options list.

1

1-37 Setting up PostScript or PCL printing with Windows 2000/XP

5.

Click Add to move the option to the Installed Options list.

.

Engine Configuration

—Copier, Printer

Engine Type

—31 ppm Color Engine, 20 ppm Color Engine

Optional Trays

—Not Installed, Universal Cassette (Tray 3), Universal Cassettes

(Tray 3, 4), LCC (Tray 3)

Duplex Option

—Not Installed, Installed

Finisher Option

—Not Installed, Single Staple Finisher, Folding Finisher

Engine Storage Option

—Not Installed, Extension Memory, Hard Disk Drive,

Extension Memory and Hard Disk Drive

6.

Click OK to activate the current settings.

T

O CONFIGURE INSTALLABLE OPTIONS ON THE

F

IERY

X3

E

FROM THE

PCL

PRINTER DRIVER

1.

Click Start, choose Settings, and then choose Printers.

2.

Right-click the Fiery X3e icon, and choose Printing Preferences.

1

1-38 Installing User Software on a Windows Computer

3.

Click the Configuration tab and specify the options installed on the Fiery X3e.

4.

Select an installed option from the Available Options list, and click Add to move the option to the Installed Options list.

Engine Configuration

—Copier, Printer

Optional Trays

—Not Installed, Universal Cassette (Tray 3), Universal Cassettes

(Tray 3, 4), LCC (Tray 3)

Duplex Option

—Not Installed, Installed

Finisher Option

—Not Installed, Single Staple Finisher, Folding Finisher

Engine Storage Option

—Not Installed, Extension Memory, Hard Disk Drive,

Extension Memory and Hard Disk Drive

5.

Click Apply, then click OK.

You are ready to connect to your network type (see the next section “Completing the

Windows 2000/XP printer connection” ).

1

1-39 Setting up PostScript or PCL printing with Windows 2000/XP

Configuring installed options and updating print options settings automatically

If you have a TCP/IP-enabled network, you can automatically update your printer driver to reflect the options currently installed on the Fiery X3e. When the printer driver is first installed, the installable options have default settings that were set up in

Fiery X3e Setup or ColorWise Pro Tools. When you update the printer driver with the

Two-Way Communication feature, you allow the Fiery X3e to complete the actual setting.

The Two-Way Communication feature also updates Expert Color Settings options to reflect the current color settings on the Fiery X3e. To access the Expert Color Settings options, click the Expert Settings tab in the ColorWise print option bar of the Fiery printing tab of your printer driver. For more information, see the

Color Guide

.

S

ETTING UP

T

WO

-W

AY

C

OMMUNICATION FOR

P

OST

S

CRIPT

OR

PCL

PRINTER DRIVERS FOR

W

INDOWS

2000/XP

N

OTE

:

The procedures for the PostScript and PCL printer drivers on Windows 2000 and XP are similar. The following procedure displays Windows 2000 illustrations using the PostScript printer driver. Differences are noted in the text.

1.

On Windows 2000, click Start, choose Settings, and then choose Printers.

On Windows XP, click Start, and choose Printers and Faxes.

2.

In the Printers window, select the icon for the Fiery X3e PostScript printer driver.

3.

For the PostScript printer driver, choose Properties from the File menu.

For the PCL printer driver, choose Printing Preferences from the File menu.

4.

Click the Configuration tab.

5.

Enter the Fiery X3e IP address or DNS name.

6.

If you want your printer driver to display the current settings when opened, select the

Update Fiery Driver When Opened option.

7.

Click Update.

8.

Click OK.

1

1-40 Installing User Software on a Windows Computer

Completing the Windows 2000/XP printer connection

To print from Windows 2000/XP, you must:

• Set up network servers, if any.

• Set up the Fiery X3e to accept print jobs from your computer.

• Configure a port on each Windows 2000/XP computer for the network type.

To do this

Configure the parallel connection

Configure the TCP/IP (LPR port) connection

Configure the IPX (Novell) connection

See

“Completing the Windows 2000/XP parallel port connection” in this section.

“Completing the Windows 2000/XP TCP/IP and Port 9100 or LPR connection” on page 1-41.

“Completing the Windows 2000/XP IPX

(Novell) connection” on page 1-44.

N

OTE

:

The procedures for completing the printer connection for Windows 2000 and

Windows XP are similar. Windows 2000 illustrations are used in the following procedure, with relevant Windows XP differences noted.

Completing the Windows 2000/XP parallel port connection

The parallel port cable connects the Fiery X3e to a single computer. Once you have installed the Windows 2000/XP PostScript printer driver and the Fiery X3e printer description files, complete the setup for parallel port printing.

T

O SET UP PARALLEL PRINTING FOR

W

INDOWS

2000/XP

1.

Click Start, choose Settings, and then choose Printers.

2.

Double-click the Fiery X3e icon and choose Properties from the Printer menu.

In the Ports tab, confirm that LPT1 (Local Port) is selected.

The Fiery X3e is ready to accept parallel print jobs from your computer, using the

Windows 2000/XP PostScript printer driver and the Fiery X3e printer description file.

1

1-41 Setting up PostScript or PCL printing with Windows 2000/XP

3.

Click the General tab and click Print Test Page.

4.

To share the printer on the network, click the Sharing tab.

Select whether to share the printer, and specify the operating systems used by network clients.

5.

Click OK to exit the Printer Properties dialog box.

Completing the Windows 2000/XP TCP/IP and Port 9100 or LPR connection

Once you have installed the PostScript and printer driver files, complete the setup for the TCP/IP and LPR connection as follows:

• Prepare the Fiery X3e to accept print jobs using TCP/IP and LPR protocols.

For details, see the

Configuration Guide

.

• Enable LPD or Port 9100 from the Fiery X3e Control Panel.

For details, see the

Configuration Guide

.

• Configure the computer for the TCP/IP connection.

Before you continue, contact the system administrator for the IP address assigned to the Fiery X3e, as well as the subnet mask and the gateway address, if they are used.

The TCP/IP protocol should already be installed on the Windows 2000/XP workstation.

N

OTE

:

You can also set up the LPR connection by installing Print Services for UNIX, which is supplied as an add-on Windows component with your Windows 2000/XP

CD. For more information, see your Windows documentation.

T

O SET UP

TCP/IP

AND

P

ORT

9100

OR

LPR

CONNECTION

FOR

W

INDOWS

2000/XP

1.

Open the Properties dialog box for the Fiery X3e and click the Ports tab.

2.

Click Add Port.

3.

Select Standard TCP/IP Port for Available port types and click New Port.

4.

Click Next.

The Add Standard TCP/IP Printer Port Wizard dialog box appears.

1

1-42 Installing User Software on a Windows Computer

5.

Type the IP address of the Fiery X3e.

6.

Click Next.

7.

Make sure that Generic Network Card is selected as Standard for Device Type and click Next.

8.

Click Finish to close the Add Standard TCP/IP Printer Port Wizard dialog box and click

Close in the Printer Ports dialog box.

9.

Click Configure Port in the Properties dialog box.

The Configure Standard TCP/IP Port Monitor dialog box appears.

10.

If you have LPD printing enabled at the Fiery X3e Control Panel, select LPR for

Protocol and LPR Byte Counting Enabled under LPR Settings.

N

OTE

:

You can also proceed without selecting LPR Byte Counting Enabled under

LPR settings.

1

1-43 Setting up PostScript or PCL printing with Windows 2000/XP

11.

If you have Port 9100 printing enabled at the Fiery X3e Control Panel, select Raw.

The port number 9100 automatically appears under Raw Settings. You can print to the printer connection selected for Port 9100 printing at the Fiery X3e Control Panel.

12.

Enter the name of the print connection.

For LPR, use print or hold

.

For Port 9100, manually enter the following port numbers for each print connection under Raw Settings: direct:

9100

(default) or

9101 print: 9100 (default) or 9102 hold:

9103

N

OTE

:

Type the number

exactly

as shown.

13.

Click OK to close the Configure Standard TCP/IP Port Monitor dialog box.

1

1-44 Installing User Software on a Windows Computer

Completing the Windows 2000/XP IPX (Novell) connection

Complete the setup for the IPX (Novell) connection as follows:

• Configure the Novell network and file server for handling Fiery X3e print jobs. The file server should be configured with a print server and print connection for the

Fiery X3e. For details, see your NetWare documentation.

• Prepare the Fiery X3e for IPX printing.

• Set up the IPX connection on the computer.

NetWare protocols (NWLink IPX/SPX Compatible Transport) and NetWare client services should already be installed on the Windows 2000/XP computer.

T

O SET UP

IPX (N

OVELL

)

PRINTING FOR

W

INDOWS

2000/XP

1.

On Windows 2000, double-click My Network Places.

On Windows XP, click Start, and then click My Network Places.

2.

Double-click NetWare or Compatible Network.

A list of NetWare servers appears.

3.

Double-click the NetWare Tree or File Server on which the network administrator defined a print connection for the Fiery X3e.

You may have to log in to the file server to see the print connections.

4.

Double-click the print connection defined for the Fiery X3e.

1

1-45 Setting up PostScript or PCL printing with Windows 2000/XP

5.

If the NetWare server does not have a suitable driver for the Fiery X3e, you may be asked if you want to set up the printer on your computer. Click Yes.

6.

Click OK to install the Fiery X3e PostScript printer driver.

7.

Follow the procedure that starts with

step 6 on page 1-18 .

When installation is complete, a new printer window appears, with the name of the print queue on the NetWare server.

8.

Choose Properties from the File menu and click the Ports tab.

Verify that the connection to the NetWare queue is listed and selected as a port for the Fiery X3e.

9.

Click the General tab and click Print Test Page.

10.

In the printer Job Notes field, type user and job identification information and click OK.

The Test Page remains listed in the queue window until it is printed.

The Fiery X3e polls the NetWare server for print jobs in the print connection defined for the Fiery X3e. When you print, your PostScript files are spooled to that connection and transmitted over the queue “port” to the Fiery X3e.

1

1-46 Installing User Software on a Windows Computer

Setting up SMB printing on Windows 2000/XP

SMB printing (also known as Windows printing) allows you to install the printer driver and associated files, and print from your computer to a particular print connection (Hold, Print, or Direct) on the Fiery X3e. These instructions assume you have installed the TCP/IP protocol and Client for Microsoft Networks.

Each connection (Hold, Print, or Direct) requires a new printer driver and printer description file. To set up printing to a second or third print connection, repeat the procedure,

“To set up SMB printing on Windows 2000/XP” . If you install more than

one printer, give each a descriptive name during printer driver installation, such as

Aero-Print

or

Aero-Hold

, so you can easily identify printers.

N

OTE

:

With Windows 2000/XP, the printer driver must be installed from the User

Software CD. You cannot use Point and Print to install the driver and configure the printing connection to the Fiery X3e in a single procedure.

B

EFORE YOU BEGIN

• Configure the Fiery X3e for SMB printing in Network Setup>Service

Setup>Windows Setup.

SMB printing is referred to as Windows Printing in Setup, on the Control Panel Map, and on the Configuration page. For more information, see the

Configuration Guide

.

T

O SET UP

SMB

PRINTING ON

W

INDOWS

2000/XP

1.

Open My Network Places.

2.

Browse for the printer you want to print to.

The printer name you are browsing for is the name entered in Network Setup>

Service Setup>Windows Setup > Server Name. For this information, see the

Configuration page.

The amount of network traffic determines the amount of time required for the

Browse function.

N

OTE

:

You can also locate the printer using the Search feature on your Windows computer. Right-click My Network Places and click Search for Computers. Type the name of the printer and click Search Now.

1

1-47 Setting up PostScript or PCL printing with Windows 2000/XP

If you are not able to locate your Fiery X3e, contact your network administrator.

3.

Double-click the name of the Fiery X3e to display enabled print connections.

You must now create a printer port and install the printer driver from the User

Software CD.

N

OTE

:

You cannot use Point and Print to install the driver and configure the printing connection to the Fiery X3e in a single procedure.

4.

On Windows 2000, click Start, choose Settings, and then choose Printers.

On Windows XP, click Start and choose Printers and Faxes.

5.

Double-click Add Printer and click Next.

6.

Click Local Printer and click Next.

7.

Click Create a New Port, and choose Local Port from the menu. Click Next.

8.

In the Port Name dialog box, type the name of the Fiery X3e, followed by the printing connection, and click OK.

Enter the port name as follows: \\Aero\print where Aero is the name of the Fiery X3e and print

is the printing connection.

9.

In the dialog box displaying lists of manufacturers and printers, click Have Disk.

You will now install the printer driver from the User Software CD.

10.

Type the name of the CD-ROM drive and browse to the

English\Prntdrvr\Ps_drvr\Win_2000 or English\Prntdrvr\Ps_drvr\Win_XP folder.

11.

Make sure “Oemsetup.inf” or “Oemsetup” is selected and click Open.

12.

Verify the path is correct in the Install From Disk dialog box and click OK.

13.

Follow the on-screen instructions.

For more information, see

“To install the PostScript or PCL printer driver for

Windows 2000/XP” on page 1-33.

1

1-48 Installing User Software on a Windows Computer

Setting up IPP printing with Windows 2000/XP

With Internet Printing Protocol (IPP), print jobs are sent to the Fiery X3e over the Internet.

IPP printing is supported directly for Windows 2000/XP computers. IPP printing is not supported on Windows NT 4.0.

N

OTE

:

The IPP setup procedures are performed after installing the appropriate printer drivers (see

“To install the PostScript or PCL printer driver for Windows 2000/XP” on page 1-33).

B

EFORE YOU BEGIN

1.

Prepare the Fiery X3e for TCP/IP printing.

2.

Make sure the Fiery X3e is configured for IPP printing. For more information, see the

Configuration Guide

.

3.

Specify the printing destination on your computer.

T

O SET UP

IPP

PRINTING WITH

W

INDOWS

2000/XP

1.

On Windows 2000, click Start, choose Settings, and then choose Printers.

On Windows XP, click Start and choose Printers and Faxes.

2.

On Windows 2000, double-click the Add Printer icon and click Next.

On Windows XP, click Add Printer.

3.

Select Network printer and click Next.

1

1-49 Setting up PostScript or PCL printing with Windows 2000/XP

4.

Select “Connect to a printer on the Internet or on your intranet.” Type an IP address or computer name in the URL field.

The URL for the printer is the IP address or DNS name followed by “ipp” and the connection you want to print to ( print

, hold

, or direct

). Insert slashes between the different elements.

5.

Click Next.

The Connect to Printer dialog box appears.

6.

Click OK.

The Add Printer Wizard dialog box appears.

7.

If you are installing the PostScript printer for Windows 2000/XP for the first time, follow the procedure described on

page 1-33 .

If you have already installed the printer driver on your computer, choose the appropriate names from the Manufacturers and Printers lists and click OK.

8.

Indicate whether you want to make the Fiery X3e the default printer and click Next.

9.

Click Finish.

1

1-50 Installing User Software on a Windows Computer

Installing EFI Fiery Mail Port

The E-Mail Service provides a method to print and control the Fiery X3e remotely.

Jobs are sent to the Fiery X3e in the form of e-mail attachments. You can set up e-mail printing on Windows computers by adding the EFI Fiery Mail Port software as a printer port.

To set up the Fiery X3e for e-mail printing, see the

Configuration Guide

. After Setup has been performed, install the software from the User Software CD onto your

Windows computer, and then add a port.

N

OTE

:

Procedures are given for Windows 9x/Me and Windows NT 4.0. Procedures for

Windows 2000/XP are similar to those for Windows NT 4.0.

T

O INSTALL THE E

-

MAIL PORT MONITOR ON

W

INDOWS COMPUTERS

1.

Open the EFI Fiery Mail Port folder on the User Software CD.

2.

Double-click the Setup icon and follow the on-screen instructions.

When installation is complete, you are ready to configure the connection for the e-mail port monitor.

T

O CONFIGURE THE CONNECTION FOR

EFI F

IERY

M

AIL

P

ORT ON

W

INDOWS

9

X

/M

E

1.

Click Start, choose Settings, and then choose Printers.

2.

In the Printers window, right-click the icon for the Fiery X3e printer driver.

For instructions on installing the printer driver, see

“Installing the PostScript or PCL printer driver for Windows 9x/Me” on page 1-2.

3.

Choose Properties, and click the Details tab.

1

1-51 Installing EFI Fiery Mail Port

4.

Click Add Port.

5.

Click Other and select EFI Fiery Mail from the list of ports.

6.

Click OK.

7.

Enter the basic information required to set up the e-mail port.

Fiery’s E-mail Address

—Enter the e-mail address of the Fiery X3e.

Outgoing Mail Server

—Enter the name or IP address of the SMTP server for the port monitor to use.

8.

Click Advanced.

1

1-52 Installing User Software on a Windows Computer

The E-Mail Port Configuration dialog box appears.

9.

Enter the following information.

For Fiery Server:

E-mail Address

—The e-mail address of the Fiery X3e.

Queue

—The print connection on the Fiery X3e that you want.

For Outgoing Mail Server (SMTP):

Server Name

—The SMTP server to use.

From Address

—The “from” address to insert in the e-mail.

For Options:

Break apart messages larger than

—The maximum size of a single e-mail message is displayed. If a job exceeds this size, it is split into multiple messages, each not exceeding this size.

Status messages from Fiery X3e

—When enabled, the Status option requests the

Fiery X3e to send status reports of the job via e-mail.

1

1-53 Installing EFI Fiery Mail Port

10.

Click OK.

The name assigned to the EFI Fiery Mail Port appears in the Details tab of the

Fiery X3e printer driver.

11.

Click Apply, and then click OK.

The connection for the EFI Fiery Mail Port has now been configured.

T

O CONFIGURE THE CONNECTION FOR THE

EFI F

IERY

M

AIL PORT

ON

W

INDOWS

NT 4.0

1.

Click Start, choose Settings, and then choose Printers.

2.

In the Printers window, double-click the Add Printer icon and click Next.

3.

Specify printing using a Local printer and click Next.

4.

In the window displaying a list of ports, click Add Port.

The Printer Ports dialog box is displayed, with the EFI Fiery Mail port listed as one of the available ports.

1

1-54 Installing User Software on a Windows Computer

5.

Select EFI Fiery Mail and click New Port.

The Add Port dialog box appears.

6.

Enter the basic information required to set up the e-mail port.

Fiery’s E-mail Address

—Enter the e-mail address of the Fiery X3e.

Outgoing Mail Server

—Enter the name or IP address of the SMTP server for the port monitor to use.

7.

Click Advanced.

The E-Mail Port Configuration dialog box appears.

1

1-55 Installing Fiery utilities

8.

Enter the following information.

For Fiery Server:

E-mail Address

—The e-mail address of the Fiery X3e.

Queue

—The print connection on the Fiery X3e that you want.

For Outgoing Mail Server (SMTP):

Server Name

—The SMTP server to use.

From Address

—The “from” address to insert in the e-mail.

For Options:

Break apart messages larger than

—The maximum size of a single e-mail message is displayed. If a job exceeds this size, it is split into multiple messages, each not exceeding this size.

Status messages from Fiery X3e

—When enabled, the Status option requests the

Fiery X3e to send status reports of the job via e-mail.

9.

Click OK.

The Add Printer Wizard dialog box appears.

10.

Click Next and follow the instructions for installing the printer driver for your

Windows computer.

Installing Fiery utilities

From the User Software CD, you can install the following Fiery utilities and user software:

• ColorWise Pro Tools

• Fiery Downloader

• Fiery Remote Scan (TWAIN Fiery Scan Module and Application)

1

1-56 Installing User Software on a Windows Computer

• EFI Fiery Mail Port (see “Installing EFI Fiery Mail Port” on page 1-50)

• Command WorkStation

• DocBuilder Pro (available as an option)

Do not attempt to install DocBuilder Pro from the User Software CD (by starting the setup.exe from the DBPro folder); it is automatically installed when you install

Command WorkStation. Installing DocBuilder Pro from the User Software CD can cause unpredictable results. In order to use DocBuilder Pro, you must install Acrobat v4.0.5 and the DocBuilder Pro dongle from the DocBuilder Pro option kit. To install

Acrobat, see

“Adobe Acrobat” on page 1-57.

The Fiery utilities must be separately installed on each user’s computer. The installation of each utility is similar. Before you begin each installation, determine where you want to install each item on your hard disk. Otherwise, the software is placed by default in the Fiery folder inside the Programs folder except for the Fiery

Remote Scan TWAIN plug-in module. The Command WorkStation installer also installs the Java files necessary to use Fiery Setup from Command WorkStation.

To install the software on a Windows 2000 computer, you must have Service Pack 2 installed on your computer. If not, a warning message alerts you to install Service

Pack 2.

The TWAIN Fiery Remote Scan Module installer automatically creates a folder named

Twain_32 in the Windows folder on your hard disk, and then installs the Fiery Remote

Scan plug-in module into the folder.

N

OTE

:

Before installing the TWAIN Fiery Remote Scan module, make sure the

TWAIN plug-ins (installed with TWAIN-compliant application software) are located in the correct Plugins subfolder. If the TWAIN plug-ins have been deleted, you must reinstall the TWAIN-compliant application software in order to use Fiery Remote

Scan.

You access the Fiery Remote Scan plug-in from the TWAIN-compliant software using the TWAIN module. For details, see the

Printing Guide

.

1

1-57 Installing Fiery utilities

T

O INSTALL

F

IERY UTILITIES

1.

Open the appropriate folder for the software you want to install.

2.

Double-click the Setup.exe icon.

3.

Follow the instructions in the Setup dialog boxes to complete installation.

Adobe Acrobat

In Command WorkStation, the DocBuilder Pro feature (available as an option) works with Adobe Acrobat v4.0.5. If you purchase the DocBuilder Pro option, the Acrobat software is included on the Adobe Acrobat for DocBuilder Pro CD.

If Adobe Acrobat version 5.0 is already installed on your computer, version 4.0.5 will be installed in a separate folder. You do not need to uninstall version 5.0 to use

DocBuilder Pro, but you must install version 4.0.5.

N

OTE

:

If Adobe Acrobat is installed after Command WorkStation, you may be required to restart Command WorkStation in order to use DocBuilder Pro.

For more information about Adobe Acrobat for Windows, see the Readme.pdf file on the Adobe Acrobat for DocBuilder Pro CD.

T

O INSTALL

A

CROBAT

1.

Insert the Adobe Acrobat CD in the CD-ROM drive.

The Adobe Acrobat Welcome screen appears.

2.

Click Next and follow the on-screen instructions.

Using Fiery utilities for the first time

Before you can use the newly installed software, you must configure the connection to the Fiery X3e. Configuration of the Fiery utilities is similar.

1

1-58 Installing User Software on a Windows Computer

Configuring the connection for Fiery utilities

The first time you start one of the Fiery utilities, you must configure the connection to the Fiery X3e. Similar configuration is used for all Fiery utilities, so any change in one configuration affects all the other connections. Configuration for most Fiery utilities is described in the following procedure.

For configuration of specific Fiery utilities, see “Configuring the connection for

Command WorkStation” on page 1-60

B

EFORE YOU BEGIN

• Print the Configuration page from the Fiery X3e Control Panel.

This page contains information you need when configuring the connection, such as the IP address. For TCP/IP installations, you can use the DNS name of the Fiery X3e instead of the IP address. Make sure the Fiery X3e is already registered in a Domain

Name Server (DNS) on your network. For more information, see your Windows system documentation.

T

O CONFIGURE THE CONNECTION FOR

F

IERY UTILITIES

1.

Start the utility for which you want to configure a connection.

For Fiery Remote Scan, start the supported TWAIN-compliant software.

For details, see the

Printing Guide

.

2.

If the No Servers Configured dialog box appears, click OK.

If the Choose Printer Device dialog box appears, click Add.

3.

Enter the appropriate information for the Fiery X3e.

Nickname

—Enter a name for the Fiery X3e. This name does not have to match the actual Server Name of the Fiery X3e.

N

OTE

:

The nickname cannot contain any of the following seven characters:

[ ] _ " ' <space> <tab>

Protocol

—Choose the type of network protocol you are using from the menu.

N

OTE

:

Fiery utilities are not supported over IPX/SPX. Command WorkStation is supported on Windows computers over TCP/IP.

Device name of the

Fiery X3e (31C-M)

1

1-59 Installing Fiery utilities

Server Name

—Enter the IP address (or DNS name) of the Fiery X3e.

New Device

—Enter the name of the device the Fiery X3e is connected to:

31C-M

.

N

OTE

:

Type 31C-M exactly as shown because this term is case-sensitive.

4.

When you have entered all the information, click Add.

5.

With the device name (31C-M) selected in the Devices list, click OK.

The Fiery X3e appears in the list of available servers. The first line of the entry displays the nickname you gave the server, followed by the protocol you chose. The second line displays the device name.

6.

With the device name selected in the list of Available Servers, click Select to begin using the utility.

Modifying the configuration

Edit the configuration whenever there is any change to your Fiery X3e server or network, such as a server name or IP address. If you change Fiery X3e Setup information, do so before reconfiguring the connection.

T

O MODIFY THE CONFIGURATION

1.

To edit information for a Fiery X3e in the list of available servers, select the Fiery X3e by its nickname and click Modify.

2.

Make the necessary changes in the Modify Server Settings dialog box and click OK.

1

1-60 Installing User Software on a Windows Computer

3.

To add a new Fiery X3e to the list of available servers, click Add. Configure the Add

New Server dialog box as outlined in steps 3 through

5

in the previous procedure.

4.

To remove a Fiery X3e, select the Fiery X3e by its nickname and click Remove.

N

OTE

:

The nickname cannot be modified.

Configuring the connection for Command WorkStation

The first time you start Command WorkStation, you are prompted to configure the connection to the Fiery X3e.

T

O CONFIGURE THE CONNECTION FOR

C

OMMAND

W

ORK

S

TATION

1.

Print a Configuration page.

The information on this page helps you locate the Fiery X3e, if it is not on the same local subnet as your computer.

2.

Start Command WorkStation.

The Available Servers dialog box appears. All servers found in the local subnet are displayed.

1

1-61 Installing Fiery utilities

3.

If no Fiery X3e servers were found, click the Manual tab to search by DNS name or IP address. Click Add to add the server to the Available Servers list.

4.

Click the Auto Search tab and then click Advanced to search by either a range of IP addresses or the IP address and subnet mask.

5.

Click Search.

All available servers appear in the Available Servers list.

1

1-62 Installing User Software on a Windows Computer

6.

Select the Fiery X3e server you want to use and click Add.

The selected Fiery X3e server appears in the Login Server dialog box.

7.

Click the server name.

The Log In dialog box appears.

8.

Select Administrator, Operator, or Guest and click Log In.

Your computer is connected to the server.

1

1-63 Installing Fiery utilities

Modifying the configuration

Edit the configuration whenever there is any change to your Fiery X3e server or network, such as a server name or IP address. If you change Fiery X3e Setup information, do so before reconfiguring the connection.

T

O MODIFY THE CONFIGURATION

1.

Start Command WorkStation.

The Login Server window appears.

2.

Select the Fiery X3e server for which you want to modify the configuration, and click Remove.

The Available Servers dialog box appears.

3.

To add the modified Fiery X3e server, follows steps 3

through

6 of the procedure,

“To configure the connection for Command WorkStation” on page 1-60.

To modify the connection to the Fiery X3e, you must remove the server from the

Login Server list and follow the procedure for configuring the connection.

1

1-64 Installing User Software on a Windows Computer

Installing color files from the User Software CD

You can copy additional color files from the User Software CD to your hard disk.

Many of the files are PostScript files that you can download and print using

Fiery Downloader.

Icm folder ICM monitor settings file and a device profile specially designed for use with the Fiery X3e and particular copier models. For instructions on installing, see

“Installing the ICM profiles on a

Windows computer” on page 1-65.

Cmyk.ps, an 11-page, letter-size PostScript file to use for reference when defining CMYK colors in applications.

Clrfiles folder

(inside the

English folder)

Pantone.ps, a 19-page, letter-size PostScript file that indicates the closest equivalent of PANTONE coated colors that the

Fiery X3e and your copier model can produce. The method used to print the Pantone.ps file differs depending on the Spot Color

Matching setting. For more information, see the

Printing Guide

and the

Color Guide

.

Rgb_01.doc, a file you can print from Microsoft Word 97 or later to view available RGB colors.

Rgb_02.ppt, a file you can print from PowerPoint 6.0 or later to view available RGB colors.

Calibrat folder

(inside the

English\Clrfiles folder)

Four PostScript files of color patches for obtaining measurements: Custom21.ps, Custom34.ps, Stand21.ps, and

Stand34.ps. The numbers in the file names refer to the number of patches on the page. The Custom files allow you to download measurement patches that incorporate the copier’s current calibration set. The Standard files allow you to download standard measurement patches that bypass the copier’s current calibration set. For information on using these files, see the

Color Guide

.

N

OTE

:

These files are provided for expert users and should not be used for day-to-day calibration.

1

1-65 Installing color files from the User Software CD

Installing the ICM profiles on a Windows computer

The ICM profiles included in the Icm folder on the User Software CD are for use with ColorWise Pro Tools. You can also use the ICM profiles with applications that support ICC standards, such as Photoshop. For most ICC-aware applications, the files must be installed in a folder named Color in the System folder. For use with

ColorWise Pro Tools, you can copy the files to a folder of your choice.

You can upload additional ICC profiles with the Profile Manager in ColorWise

ProTools. For more information on uploading and using ICC profiles with ColorWise

Pro Tools, see the

Color Guide

.

T

O INSTALL THE

ICM

PROFILES ON A

W

INDOWS COMPUTER

1.

On the User Software CD, open the Icm folder.

2.

If you are using Windows 9x/Me, copy the profiles to the Windows\System\Color folder on your hard disk.

If you are using Windows NT or Windows 2000, copy the profiles to the

Winnt\System32\Color folder on your hard disk.

N

OTE

:

If a folder named “Color” does not exist in the System32 folder, create one and install the profiles into it.

If you are using Windows XP, right-click the profile you want and click Install Profile.

N

OTE

:

The profiles are installed automatically to the

Windows\System32\spool\drivers\color folder on your hard disk.

Loading the monitor settings file

The Efirgb.icm monitor settings file can be used in Photoshop, or other applications that support ICM profiles, to define a source color space for printing to the Fiery X3e.

These instructions assume you have installed the ICM profiles included on the

User Software CD. For more information, see the preceding section.

N

OTE

:

The internal name of an ICC profile may vary slightly from its file name.

N

OTE

:

If you use Fiery Remote Scan, install the monitor settings profile.

1

1-66 Installing User Software on a Windows Computer

T

O LOAD THE

RGB W

ORKING

S

PACE PROFILE FOR

P

HOTOSHOP

5.

X

1.

Start Photoshop.

2.

Choose Color Settings from the File menu and choose RGB Setup from the Color

Settings submenu.

3.

In the RGB Setup dialog box, click Load.

4.

For Windows 9x/Me, browse to the Windows\System\Color folder, select Efirgb.icm, and then click Load.

For Windows NT 4.0 or Windows 2000, browse to the Winnt\System32\Color folder, select Efirgb.icm, and then click Load.

For Windows XP, browse to the Windows\System32\spool\driver\color folder, select

Efirgb.icm, and then click Load.

The Efirgb v1f file is displayed in the RGB menu of the RGB Setup dialog box.

5.

Click OK.

For more information about ICM profiles, see your Photoshop documentation.

1

1-67 Installing color files from the User Software CD

Loading the ICM copier device profile

This ICM profile defines the target color space for printing to the copier.

These instructions assume you have installed the ICM profiles included on the

User Software CD. For more information, see

“Installing the ICM profiles on a

Windows computer” on page 1-65.

N

OTE

:

The internal name of an ICC profile may vary slightly from its file name.

T

O LOAD THE

ICM

COPIER DEVICE PROFILE IN

P

HOTOSHOP

5.

X

1.

Start Photoshop.

2.

Choose Color Settings from the File menu and choose CMYK Setup from the Color

Settings submenu.

3.

In the CMYK Setup dialog box, choose ICC as the CMYK color model.

4.

Select the profile that corresponds to the Fiery X3e from the Profile menu.

N

OTE

:

Three profiles are provided: Fiery X3e 31C-M, Fiery X3e 31C-M 100GCR, and Fiery X3e 31C-M HiGCR. For more information on using profiles, see the

Color

Guide

.

5.

Click OK.

For more information about ICC profiles, see your Photoshop documentation.

1

1-68 Installing User Software on a Windows Computer

Loading monitor settings files and ICM device profiles in Photoshop 6.x

Once you have installed the Efirgb.icm monitor settings file and the ICM device profile for the Fiery X3e, they can be loaded at the same time in Photoshop 6.x.

T

O LOAD THE MONITOR SETTINGS FILE AND

ICM

DEVICE PROFILE

IN

P

HOTOSHOP

6.

X

1.

Start Photoshop.

2.

Choose Color Settings from the Edit menu and select Advanced Mode in the Color

Settings dialog box.

3.

Choose EFI RGB from the RGB menu.

4.

Choose the profile that corresponds to the Fiery X3e from the CMYK menu.

N

OTE

:

Three profiles are provided: Fiery X3e 31C-M, Fiery X3e 31C-M 100GCR, and Fiery X3e 31C-M HiGCR. For more information on using profiles, see the

Color Guide

.

Installing the printer description files for Windows

The User Software CD contains printer description files for popular Windows applications. Adobe Pagemaker 5.0, 6.x, and 7.0 do not support automatic installation of printer description files from the Printers or Printers and Faxes Control Panel. To make the Fiery X3e available in the Print and Page Setup dialog boxes of this application, copy printer description files to the appropriate location.

1

1-69 Installing color files from the User Software CD

T

O COPY THE PRINTER DESCRIPTION FILES

1.

On the User Software CD, open the English\Prntdrvr\Ps_drvr folder. Select the folder that corresponds to the system you are using.

For Windows 9x/Me, select English\Prntdrvr\Ps_drvr\Win_9x_ME.

For Windows NT 4.0, select English\Prntdrvr\Ps_drvr\Win_NT4x.

For Windows 2000, select English\Prntdrvr\Ps_drvr\Win_2000.

For Windows XP, select English\Prntdrvr\Ps_drvr\Win_XP.

2.

Copy the printer description file for your Fiery X3e to the appropriate location.

If you use Copy this file

PageMaker 5.0 or later 1Ef3m2a22.ppd

Ef3m2o22.ppd

To this location

For PageMaker 5.0,

\ALDUS\USENGLSH\PPD4

For PageMaker 6.0,

\PM6\RSRC\USENGLSH\PPD4

For PageMaker 6.5,

\PM65\RSRC\USENGLSH\PPD4

For PageMaker 7.0,

\PM7\RSRC\USENGLSH\PPD4

2

2-1 Setting up the Fiery X3e as a PostScript printer

Chapter 2:

Installing

User Software on a Mac OS

Computer

The general steps for installing the Fiery X3e user software and setting up printing on a

Mac OS computer are as follows:

• Install the PostScript printer driver and printer description file.

• Set up the Fiery X3e in the Chooser.

• Install the Fiery utilities (Fiery Remote Scan, ColorWise Pro Tools, Fiery

Downloader, and Fiery Spooler).

• Configure the connection for Fiery utilities.

• Install the printer and screen fonts.

• Install the ColorSync profiles.

• Install additional color reference and application-specific files.

In addition to using the User Software CD, you can download printer drivers from the

Fiery X3e with the Installer WebTool (if the site administrator has enabled Internet access to the Fiery X3e). For instructions, see

page 3-2 .

Once you download the printer files, the installation process is identical to installing from the User Software CD.

Setting up the Fiery X3e as a PostScript printer

To set up the Fiery X3e as a PostScript printer, you must install the PostScript printer driver and the printer description file that corresponds to your copier. The PostScript printer driver and printer description files are provided on the User Software CD.

Printer drivers provide a way to communicate information on print jobs between your applications, the Fiery X3e, and any other PostScript printer connected to your computer.

When you install printer files from the User Software CD or printer files downloaded using the Installer WebTool, use the following procedures.

2

2-2 Installing User Software on a Mac OS Computer

T

O INSTALL THE

A

DOBE

PS

PRINTER DRIVER

AND PRINTER DESCRIPTION FILE

1.

Quit all open applications.

After you have completed installation, restart your computer.

2.

On the User Software CD, open the English: Printer Driver folder.

If you are installing from files you downloaded using the Installer WebTool, open the

Printer Driver folder on your hard disk.

3.

Double-click the AdobePS Installer icon.

4.

Follow the on-screen instructions.

The AdobePS Installer installs the Adobe PostScript printer driver, and the printer description file that corresponds to the Fiery X3e.

N

OTE

:

If you operate the Fiery X3e in a copy shop, quick print shop, or service bureau, provide your customers with copies of the printer driver, printer description file, or

ICC profiles you use for printing images, as well as any relevant documentation. This ensures that jobs they create and print to files are properly formatted for printing to the Fiery X3e.

Setting up the Fiery X3e in the Chooser

After you install the Adobe PostScript printer driver and printer description file (see

page 2-1 ), you must set up the Fiery X3e in the Chooser in order to take full advantage

of its features. This section describes how to set up the Fiery X3e with the AdobePS printer driver.

T

O SET UP THE

F

IERY

X3

E IN THE

C

HOOSER

1.

Select Chooser from the Apple menu.

Make sure AppleTalk is set to Active.

2.

Select the correct AppleTalk Zone, if necessary.

2

2-3 Setting up the Fiery X3e as a PostScript printer

3.

Click the AdobePS icon.

The Fiery X3e appears in the Select a PostScript Printer list in the form of

<server name>_<print connection>.

N

OTE

:

Only the print connections (Direct, Hold, and Print) that have been enabled in Setup appear in the Chooser.

4.

Select a Fiery X3e connection from the “Select a PostScript Printer” list and click Create.

Select the correct printer description file for your printer.

N

OTE

:

You must set up each print connection separately. Repeat this step for all enabled connections.

5.

In the Installable Options dialog box, select the appropriate settings from the menus and click OK.

2

2-4 Installing User Software on a Mac OS Computer

Engine Type

—31 ppm Color Engine, 20 ppm Color Engine

Optional Trays

—Not Installed, Universal Cassette (Tray 3), Universal Cassettes

(Tray 3, 4), LCC (Tray 3)

Duplex Option

—Not Installed, Installed

Finisher Option

—Not Installed, Single Staple Finisher, Folding Finisher

Engine Storage Option

—Not Installed, Extension Memory, Hard Disk Drive,

Extension Memory and Hard Disk Drive

6.

Close the Chooser.

Installing Fiery X3e software and fonts

The Mac OS installers function essentially the same for each type of software. Before you begin each installation, determine where you want to install each item on your hard disk. Otherwise, the software is placed by default as follows:

• ColorSync profiles—ColorSync Profiles folder.

If you are using ColorSync 2.5, install the profiles into the ColorSync Profiles folder inside the System folder. If you are using an earlier version of ColorSync, install the profiles to the ColorSync Profiles folder inside the System:Preferences folder. The printer profile can be moved to a folder of your choice.

• Fiery Spooler, Fiery Downloader, Fiery Remote Scan, and ColorWise Pro Tools—

”Fiery” folder.

• Fonts—System folder:Fonts folder.

For instructions on installing Fonts, see “Fonts” on page 2-12.

2

2-5 Installing Fiery X3e software and fonts

T

O INSTALL

M

AC

OS

SOFTWARE

1.

Insert the User Software CD in the CD drive and double-click the Installer icon of the item you want to install, then follow the instructions in the installer dialog boxes.

2.

If prompted, click Quit to close the software installer.

In order to use ColorWise Pro Tools, Fiery Link, or Fiery Spooler, you must have

Mac OS Runtime for Java (MRJ) installed on your computer.

If you do not have the appropriate MRJ installed, the installer automatically initiates the MRJ installation process.

3.

To Install MRJ, follow the instructions in the installer dialog boxes.

Installing MRJ on your computer

In order to use ColorWise Pro Tools, Fiery Link, or Fiery Spooler, you must have

Mac OS Runtime for Java (MRJ) installed on your computer.

If you do not have MRJ installed, the ColorWise Pro Tools, Fiery Link, or Fiery

Spooler installer automatically initiates the MRJ installation process.

N

OTE

:

The respective installer prompts the MRJ installation from the User Software

CD. MRJ 2.2.4 is provided on the User Software CD.

TO INSTALL

M

AC

OS R

UNTIME FOR

J

AVA

1.

Open the MRJ folder on the User Software CD and double-click Installer.

2.

Read the Apple Computer Inc. License Agreement and click Agree to install the software.

3.

Click Install.

Some files are installed.

4.

Click Quit.

You are now ready to configure the ColorWise Pro Tools, Fiery Spooler, and Fiery Link connections to the Fiery X3e.

2

2-6 Installing User Software on a Mac OS Computer

We recommend that you use the version of MRJ provided on the User Software CD with the Fiery X3e software.

If you have a newer version of MRJ (such as 2.2.5) already installed on your computer and experience some difficulty using the Fiery X3e software, either remove or relocate the MRJ files currently installed and reinstall the version of MRJ provided on the User

Software CD, using the following procedure.

T

O UNINSTALL

M

AC

OS R

UNTIME FOR

J

AVA

1.

Locate the System Folder on your hard disk.

2.

Inside the Extensions folder, locate MRJ Libraries and remove it or move it to another folder.

N

OTE

:

If you find the “MRJ Enabler” file under Extensions, remove it or move it to another folder.

3.

On Mac OS 8.6, locate the Apple Extras folder on your hard disk. On Mac 9.x, locate the

Apple Extras folder inside the Applications folder on your hard disk.

4.

Inside the Apple Extras folder, locate Mac OS Runtime for Java, and remove it or move it to another folder.

5.

Restart your computer.

Configuring a connection for ColorWise Pro Tools

The first time you use ColorWise Pro Tools, you are prompted to configure a connection to the Fiery X3e.

N

OTE

:

ColorWise Pro Tools are supported only over TCP/IP networks.

B

EFORE YOU BEGIN

• Print the Configuration page from the Control Panel and note the IP address of the Fiery X3e.

2

2-7 Installing Fiery X3e software and fonts

T

O CONFIGURE A CONNECTION FOR

C

OLOR

W

ISE

P

RO

T

OOLS

1.

Start the utility by double-clicking its icon.

The Choose Printer Device dialog box appears.

2.

If you have previously configured a connection to the Fiery X3e, you are ready to use

ColorWise Pro Tools. If you have not configured a connection, click Add.

3.

Enter the appropriate information for the Fiery X3e.

Nickname

—Enter a name for the Fiery X3e. It does not have to match the actual server name of the Fiery X3e.

N

OTE

:

The nickname cannot contain any of the following seven characters:

[ ] _ " ' <space> <tab>

Protocol

—TCP/IP is the only supported network protocol, so no selection is necessary.

Server Name

—Enter the IP address (or DNS or hosts name) of the Fiery X3e.

Device name of the Fiery X3e

2

2-8 Installing User Software on a Mac OS Computer

New Device

—Enter the name of the device the Fiery X3e is connected to: 31C-M .

This device name appears in the Printer Setup section of the Configuration page.

N

OTE

:

The device name is case sensitive; enter it

exactly

as it appears here.

4.

When you have added all the information, click Add.

5.

With the device name selected in the Devices list, click OK.

The Fiery X3e appears in the list of available servers. The first line of the entry displays the nickname you gave the server, followed by the protocol. The second line displays the device name.

6.

With the device name selected in the list of Available Servers, click Select to begin using ColorWise Pro Tools.

Modifying the configuration

Edit the configuration whenever there is any change in your original configuration, such as a change of IP address. Change the specific Fiery X3e Setup information before using the following procedure to configure the connection.

T

O MODIFY THE CONFIGURATION

1.

To edit information for a Fiery X3e in the list of available servers, select the Fiery X3e by its nickname and click Modify. Edit information in the Modify Server Settings dialog box as necessary, and click OK.

2.

To add a new Fiery X3e to the list of available servers, click Add. Configure the Add

New Server dialog box as outlined in steps 3 through

5

in the preceding procedure.

3.

To remove a Fiery X3e from the list of available servers, select the Fiery X3e by its nickname and click Remove.

Fiery X3e name and device name (31C-M)

2

2-9 Installing Fiery X3e software and fonts

Configuring a connection for Fiery Spooler

Before you begin, print a Configuration page from the Control Panel and note the

IP address of the Fiery X3e.

T

O CONFIGURE THE CONNECTION FOR

F

IERY

S

POOLER

1.

Start the utility by double-clicking its icon.

The Chooser dialog box appears.

2.

Click Option.

3.

Click Add.

4.

Enter the appropriate information for the Fiery X3e.

Name

—Enter the IP address (or DNS name) of the Fiery X3e.

New Device

—Enter the name of the device that the Fiery X3e is connected to: 31C-M.

This device name appears in the Printer Setup section of the Configuration page.

N

OTE

:

Type 31C-M exactly as shown; this term is case-sensitive.

5.

When you have entered all the information, click Add.

6.

With the device name selected, click OK.

The Fiery X3e appears in a list of configured servers.

7.

Click OK in the Configure dialog box.

2

2-10 Installing User Software on a Mac OS Computer

The Fiery X3e appears in a list of available servers.

Fiery X3e name and device name

8.

With the Fiery X3e selected in the list of available servers, click OK to begin using

Fiery Spooler.

Modifying the configuration

Edit the configuration whenever there is any change to your Fiery X3e or network, such as an IP address or device change. Change the specific Fiery X3e Setup information before configuring the connection.

T

O MODIFY THE CONFIGURATION

1.

In the Chooser dialog box, click Option.

2.

To edit information for a Fiery X3e, select the Fiery X3e by its IP address or DNS name and click Modify. Edit information in the Settings dialog box as necessary, and click

OK.

3.

To add a new Fiery X3e, click Add. Configure the Settings dialog box as outlined in

steps 4 through 6

in the preceding procedure.

4.

To remove a Fiery X3e, select the Fiery X3e by its IP address or DNS name, and click

Remove.

The list of available servers reflects the modifications you have made.

2

2-11 Installing Fiery X3e software and fonts

Configuring a connection for Fiery Downloader

When you start Fiery Downloader, you must specify the connection to the Fiery X3e.

B

EFORE YOU BEGIN

• Print the Configuration page from the Control Panel and note the AppleTalk zone of the Fiery X3e.

T

O SPECIFY A

F

IERY

X3

E CONNECTION

1.

Double-click the Fiery Downloader icon.

2.

Select the AppleTalk zone in which the Fiery X3e is located from the AppleTalk

Zones list.

The available servers appear in the Servers list.

Fiery X3e name and device name

(31C-M)

3.

Select the Fiery X3e in the Servers list.

2

2-12 Installing User Software on a Mac OS Computer

4.

Click Connect.

The Fiery Downloader dialog box appears.

For information on how to use Fiery Downloader, see the

Printing Guide

.

Fonts

The Fonts installer on the User Software CD includes screen and printer fonts that correspond to the 136 built-in PostScript printer fonts on the Fiery X3e. The Font installer copies both types of fonts to the System:Fonts folder on your hard disk. To be available to applications, the screen fonts must remain in the System:Fonts folder. You can copy the printer fonts to a folder of your choice.

N

OTE

:

In the System:Fonts folder, when displayed by Kind, screen fonts appear as type

“Font Suitcase” and PostScript printer fonts appear as type “PostScript font”.

2

2-13 Installing color files from the User Software CD

T

O INSTALL SCREEN AND PRINTER FONTS

1.

On the User Software CD, double-click the Fonts icon to start the Fonts installer.

2.

Click Install and restart your computer.

By default, the fonts are installed to the System folder:Fonts folder on your hard disk.

If you have any applications open, you must quit and restart them before the newly installed screen fonts are available.

Installing color files from the User Software CD

You can copy additional color files from the User Software CD to your hard disk.

Many of the files are PostScript files you can download and print using

Fiery Downloader.

The User Software CD contains the following color files:

ICC profiles

(inside the

ColorSync folder)

Color Files folder (inside the English folder)

Install the ICC profiles into the ColorSync Profiles folder inside the System folder.

CMYK Color Reference.ps, an 11-page, letter-size PostScript file to use for reference when defining CMYK colors in applications.

PANTONE Book.ps, a 19-page, letter-size PostScript file that indicates the closest equivalent of PANTONE coated colors that the Fiery X3e and your particular copier model can produce.

The method used to print the PANTONE Book.ps file differs depending on the Spot Color Matching setting. For more information, see the

Printing Guide

and the

Color Guide

.

RGB page 01, a file you can print from Microsoft Word 97 or later to view available RGB colors.

RGB page 02, a file you can print from PowerPoint 6.0 or later to view available RGB colors.

2

2-14 Installing User Software on a Mac OS Computer

Calibration folder

Four measurements files of color patches: custom21.ps, custom34.ps, standard21.ps and standard34.ps. The numbers in

(inside Color

Files folder) the file names refer to the number of patches on the page. The

Custom files are provided to allow you to download measurement patches that incorporate the copier’s current calibration set. The Standard files are provided to allow you to download standard measurement patches that bypass the copier’s current calibration set. For information on using these files, see the

Color Guide

.

These files are provided for expert users and should not be used for day-to-day calibration.

Loading ICC profiles

The ICC profiles installed are used with ColorWise Pro Tools and applications that support ICC standards.

These instructions assume that you have already installed the ICC profiles included on the User Software CD inside the ColorSync folder. For more information, see

“Installing color files from the User Software CD” on page 2-13.

N

OTE

:

The internal name of an ICC profile may vary slightly from its file name.

The following procedure describes installing the ICC profiles with ColorSync 4.0.

For more information about ColorSync, see your application’s documentation.

2

2-15 Installing color files from the User Software CD

T

O SET THE

C

OLOR

S

YNC SYSTEM PROFILE

1.

Choose Control Panels:ColorSync from the Apple Menu.

2.

Select EFIRGB ICC v1f from the System Profile list.

When selected as the ColorSync system profile, EFIRGB ICC v1f sets the optimal source color space for printing to the Fiery X3e. The color space set by the

EFIRGB ICC v1f profile is the same as that set by the EFIRGB setting of the RGB

Source Profile print option.

N

OTE

:

The RGB Source Profile print option setting overrides the ColorSync system profile setting.

3.

Close the ColorSync dialog box.

For more information about ICC profiles, see your Photoshop documentation.

2

2-16 Installing User Software on a Mac OS Computer

Loading the monitor settings file

The EFIRGB ICC monitor settings file can be used in Photoshop or other applications that support ICC profiles to define a source color space for printing to the Fiery X3e.

T

O LOAD THE MONITOR SETTINGS FILE IN

P

HOTOSHOP

5.

X

1.

Start Photoshop.

2.

Choose Color Settings from the File menu, and choose RGB Setup from the Color

Settings submenu.

3.

In the RGB Setup dialog box, click Load.

4.

Browse to the System: Preferences: ColorSync Profiles folder, select the EFIRGB ICC file, and then click Open.

N

OTE

:

If you are using ColorSync 2.5, the ColorSync profile is located in System

Folder:ColorSync Profiles.

The EFIRGB v1f file appears as the selection.

5.

Click OK.

2

2-17 Installing color files from the User Software CD

Loading the ICC copier profile

The ICC copier profile enables RGB-to-CMYK conversions that are specific to the kind of copier you are using.

T

O LOAD THE

ICC

COPIER PROFILE IN

P

HOTOSHOP

5.

X

1.

Start Photoshop.

2.

Choose Color Settings from the File menu and choose CMYK Setup from the Color

Settings submenu.

3.

In the CMYK Setup dialog box, choose ICC as the CMYK color model.

4.

Select the profile that corresponds to the Fiery X3e from the Profile menu.

N

OTE

:

Three profiles are provided: Fiery X3e 31C-M ICC, Fiery X3e 31C-M

100GCR ICC, and Fiery X3e 31C-M HiGCR ICC. For more information on using profiles, see the

Color Guide

.

5.

Click OK.

For more information about ICC profiles, see your Photoshop documentation.

Loading monitor settings and the ICC device profile in Photoshop 6.x/7.x

In Photoshop 6.x and 7.x, you can load the monitor settings file and the ICC device profile at the same time.

T

O LOAD THE MONITOR SETTINGS FILE AND THE

ICC

DEVICE PROFILE

IN

P

HOTOSHOP

6.

X

/7.

X

1.

Start Photoshop.

2.

Choose Color Settings from the Edit menu and then choose Advanced Mode.

3.

Choose EFI RGB from the RGB menu.

2

2-18 Installing User Software on a Mac OS Computer

4.

Choose the profile that corresponds to the Fiery X3e from the CMYK menu.

N

OTE

:

Three profiles are provided: Fiery X3e 31C-M ICC, Fiery X3e 31C-M

100GCR ICC, and Fiery X3e 31C-M HiGCR ICC. For more information on using profiles, see the

Color Guide

.

5.

Click OK.

For more information, see your Photoshop documentation.

3

3-1 Setting up Fiery WebTools

Chapter 3:

Downloading

Installers with

Fiery WebTools

Fiery WebTools allow you to manage your Fiery X3e remotely from the Internet or from your company’s intranet. The Fiery X3e has its own home page, from which you can select a variety of functions.

For more information on using Fiery WebTools, see the

Printing Guide

.

Setting up Fiery WebTools

In order for network users to access and use Fiery WebTools, you must set specific

Fiery X3e options in Network Setup and Printer Setup. You also must prepare each user’s computer to communicate with the Fiery X3e over the Internet or intranet.

For more information about Network Setup and Printer Setup, see the

Configuration Guide

.

T

O SET UP CLIENT WORKSTATIONS TO USE

F

IERY

W

EB

T

OOLS

1.

Enable TCP/IP networking.

2.

Make sure the workstation has a valid, unique IP address.

3.

Make sure a supported Internet browser is installed on the computer.

For more information on supported browsers, see the

Quick Start Guide

.

4.

Make sure Java is enabled in your Internet browser.

For more information on setting up the Fiery X3e and the network, see the

Configuration Guide

.

3

3-2 Downloading Installers with Fiery WebTools

Using the Fiery WebTools Installer

The Installer WebTool allows you to download installers for printer drivers directly from the Fiery X3e to your computer.

T

O DOWNLOAD PRINTER DRIVER FILES WITH THE

I

NSTALLER

W

EB

T

OOL

1.

Start your Internet or intranet browser and enter the DNS name or IP address of the Fiery X3e.

2.

Click the WebTools button.

3.

Select a login level, enter a password if required, and click OK.

No password is required to log in as Guest. If the Administrator has configured Guest access, any user has full access to the Installer WebTool while logged in as Guest.

4.

Click Installer.

5.

Under the name of your operating system, click the name of the item you want to install.

3

3-3 Setting up Fiery WebTools

6.

For installation of printer drivers, continue with the following instructions.

A dialog box appears, prompting you to save the file to the location you choose.

For Windows computers, a dialog box appears, offering you the choice of running the program across the Internet or intranet or saving it to disk.

For Mac OS computers, a folder named Printer Driver is downloaded to the desktop in a BinHex-encoded, compressed format. If your Internet browser is equipped with an expander utility, such as StuffIt Expander, the folder decodes and decompresses automatically.

7.

For Windows computers, browse to the location where you want to save the

Prntdrve.exe file and click Save.

For Mac OS computers, if the Printer Driver folder did not automatically decode and decompress, start the utility that performs that function.

8.

For Windows computers, double-click the Prntdrve.exe file, browse to the location where you want to install the folder, and click Next.

The folder is installed to the location you specified.

9.

Install the appropriate printer driver for your operating system.

For instructions on installing the printer driver for

Windows 9x/Me

Windows NT 4.0

Windows 2000/XP

Mac OS

See

“To install the PostScript or PCL printer driver for

Windows 9x/Me” on page 1-2

“To install the PostScript or PCL printer driver for

Windows NT 4.0” on page 1-17

“To install the PostScript or PCL printer driver for

Windows 2000/XP” on page 1-33

“Setting up the Fiery X3e as a PostScript printer” on page 2-1

4

4-1 On a Windows computer

Chapter 4:

Troubleshooting

This chapter provides troubleshooting tips.

On a Windows computer

Setting up printing on Windows NT 4.0

or Windows 2000/XP computers

If you have problems installing the Fiery X3e with Windows NT 4.0 or

Windows 2000/XP, try installing another PostScript printer (such as the Apple

LaserWriter IIg), and then install the Fiery X3e. Installing another printer ensures that all files are properly installed and available. For instructions, see your Windows documentation.

For information about problems you may encounter using the PostScript Printer

Driver for Windows NT 4.0, see the Adobe README file (readmeNT) included in

English\Prntdrvr\Ps_drvr\Win_NT4x on the User Software CD. For

Windows 2000/XP, see your Windows 2000/XP documentation.

Reinstalling the Adobe PostScript Printer Driver on

Windows 9x/Me

If you are reinstalling the Adobe PostScript Printer Driver, delete any previous versions and related files before installation.

For additional information about problems you may encounter using the Adobe

Printer Driver for Windows 9x/Me, see the Adobe README file (readme9x.wri) included in English\Prntdrvr\Ps_drvr\Win_9x_ME on the User Software CD.

4

4-2 Troubleshooting

Problems with the Fiery utilities on Windows computers

If you are experiencing problems with connections for the Fiery utilities, try the following:

1.

Make sure the TCP/IP networking protocol is enabled.

2.

Make sure the connection is configured correctly for your site.

To check the current configuration, start a Fiery utility and choose Open from the File menu. Select the Fiery X3e and click Modify to see current settings. If the settings are incorrect, you can change them in this dialog box.

On a Mac OS computer

Setting up the Fiery X3e in the Chooser

If Auto-setup does not work and you are prompted to select the printer description file, select the appropriate Fiery X3e file in your System:Extensions:Printer Descriptions folder, “Fiery X3e 31C-M” or “Fiery X3e 31C-M eu”.

Installing screen fonts

If you experience problems installing the PostScript screen fonts from the User

Software CD to the System folder:Fonts folder, try the following:

1.

Quit all applications and close all windows.

2.

Create a new folder and name it “Uninstalled Fonts.”

This folder must be located outside of the System folder.

3.

Move fonts you are not using from the System folder:Fonts folder to the Uninstalled

Fonts folder.

4

4-3 On a Mac OS computer

4.

Install the fonts from the User Software CD to a folder called CD fonts. Copy the fonts to the System folder:Fonts folder.

5.

Create aliases to the System folder:Fonts folder and the Uninstalled Fonts folder.

6.

Place both aliases on your desktop.

7.

When necessary, use the aliases to open both folders and move fonts between them.

If you have any applications running, you must quit and restart them in order to view and use the newly installed fonts.

Or, you can try combining fonts from multiple suitcases into a single suitcase.

A

Adobe Acrobat

for DocBuilder Pro 1-57 installation 1-57

Adobe PageMaker for Windows

see

PageMaker for Windows

Adobe PostScript 3 fonts xii

Adobe PostScript printer driver,

see

PostScript printer driver

AppleTalk

connecting to Mac OS 2-2

C

cable, color server xi

Calibrat folder, for Windows users 1-64

Calibration folder, for Macintosh users 2-14

Chooser

selecting the server in 2-2

setting up color server in 4-2

Clrfiles folder 1-64

CMYK Color Reference.ps 2-13

Cmyk_ref.ps 1-64

Color Files folder 2-14

Color Files folder, for Macintosh users 2-13

color management files xii, xiv

color reference files xv, 2-13

for Macintosh users 2-13

for Windows users 1-64

color server, specifications xi, xii

ColorSync and ICM color management files xiv

ColorSync Profiles 2-4

ColorWise color management files xii

ColorWise Pro Tools 1-55

configuring the connection to the Fiery

(Mac OS) 2-6

(Windows) 1-57

installing for Mac OS 2-4

installing for Windows 1-55

Command WorkStation xi

configuring the connection 1-60

installing for Windows 1-56

Configuration page 1-15, 1-31, 1-46, 1-58

connecting

Windows 2000/XP with TCP/IP 1-41

Windows 9x/Me with parallel port 1-6

Windows NT 4.0 with parallel port 1-25, 1-40

Windows NT 4.0 with TCP/IP 1-26

connection on Windows, configuring 1-58 to 1-60

Custom21.ps (Mac OS) 2-14

Custom21.ps (Windows) 1-64

Custom34.ps (Mac OS) 2-14

Custom34.ps (Windows) 1-64

D

device name 1-59, 2-8, 2-9

Windows 2000/XP with TCP/IP 1-27

Windows NT 4.0 with TCP/IP 1-27

DNS name 1-27, 1-58, 2-9

DocBuilder Pro xii

Domain Name Server,

see

DNS

E

Efirgb.icc monitor settings file for

Mac OS 2-15

Efirgb.icm monitor settings file for

Windows 1-65

E-mail printing, installing 1-50, 1-56

EPS files xiv

Ethernet 100BaseTX cable xi

Ethernet, SNAP frame type xi

F

Fast Ethernet 100BaseTX cable xi

Fast Ethernet 10BaseT cable xi

I-2 Index

Fiery Downloader 1-55

EPS files xiv

installing for Windows 1-55

overview xiv

PDF files xiv

Fiery Spooler xiv

configuring the connection on

Mac OS 2-9 to 2-10

modifying the configuration

(Mac OS) 2-10

overview xiv

Fiery utilities

configuring the connection on

Windows 1-58 to 1-60

installing for Mac OS 2-4

installing for Windows 1-55

problems on Windows 4-2

Fiery WebTools

Installer xv, xvi, 3-2 to 3-3

setting up 3-1

Status xv

WebDownloader xvi

WebLink xv

WebScan xvi

WebSetup xvi

WebSpooler xv

fonts

Adobe PostScript 3 xii

installer for Mac OS 2-12 installing 2-12, 4-2

Multiple Master xii

printer fonts 2-12 to 2-13 screen fonts 2-12 to 2-13

substituting in PDF files xii

TrueType xii

Fonts folder 4-3

Frame Type option 1-12

I

ICC device profile 2-17 loading in Photoshop 4.0

(Mac OS) 2-17 loading in Photoshop 6.x (Mac

OS) 2-17

ICC monitor settings profile, specifying in

Photoshop (Mac OS) 2-16

ICM and ColorSync color management files xiv

Icm folder (Windows) 1-64

Installable Options

specifying, from Mac OS printer driver 2-3

specifying, from Windows 2000/XP printer driver 1-36

specifying, from Windows 9x/Me printer driver 1-4

specifying, from Windows NT printer driver 1-20

Installer WebTool,

see

Fiery WebTools installers

Mac OS 2-4

Windows 1-55

installing

Adobe Acrobat 1-57

Adobe PostScript printer,

Windows 2000/XP 1-33 to 1-38

Adobe PostScript printer, Windows 9x/

Me 1-2

Adobe PostScript printer,

Windows NT 4.0 1-17 to 1-19

Command WorkStation 1-56

Mac OS software 2-5

PCL printer driver, Windows 9x/Me 1-1 to 1-3

PostScript printer driver for Mac OS 2-2

screen and printer fonts 2-12 to 2-13

software for Mac OS 2-4

software for Windows 1-55

internal name, for Windows NT 4.0 with

TCP/IP 1-27

IP address 1-59

I-3 Index

IPP printing setup

on Windows 2000/XP 1-48 to 1-49

on Windows 98 1-16 to 1-17 on Windows Me 1-16 to 1-17

IPX

printing for Windows 2000/XP 1-44 to

1-45

printing for Windows NT 4.0 1-29

Windows 2000/XP 1-44

Windows NT 4.0 1-28

IPX/SPX

Windows 2000/XP 1-44

Windows NT 1-28

J

Java 1-56, 3-1

M

Mac OS

copying color files 2-13

fonts 2-12 to 2-13

Installer WebTool 2-1 installing Fiery utilities 2-1, 2-4

installing software 2-5

troubleshooting 4-2

monitor settings file, Mac OS 2-16

N

NetWare client setup

Windows 9x/Me 1-13, 1-28, 1-44

Windows 2000/XP 1-44

Windows NT 1-28

O

Oemsetup.inf file 1-2, 1-18, 1-34

P

PageMaker for Windows 1-69

PANTONE Book.ps 2-13

PANTONE.ps 1-64

parallel port

Windows 9x/Me 1-7 to 1-11

PCL printer driver

Windows 9x/Me 1-1 to 1-3

PDF files xii, xiv

Photoshop 5.0

loading the ICC device settings profile

(Mac OS) 2-17

loading the ICC monitor settings file

(Mac OS) 2-16

loading the ICM device profile

(Windows) 1-67

loading the RGB working space profile

(Windows) 1-66

Photoshop 6.x

loading the ICC device settings profile

(Mac OS) 2-17 loading the ICC monitor settings file

(Mac OS) 2-17

loading the ICM device profile

(Windows) 1-68 loading the ICM monitor settings file

(Windows) 1-68

PostScript

printing from Mac OS 2-1 to 2-13

printing from Windows 1-1, 1-32

screen fonts xiii

PostScript Level 3 xii

PostScript Printer Description file,

see

PPD

PostScript printer driver

for Mac OS 2-2

installing using WebTools 3-2 to 3-3

Windows 2000/XP 1-33 to 1-38

Windows 9x/Me

PostScript printer driver 1-2

Windows NT 4.0 1-17 to 1-19

PostScript printing

Windows 9x/Me 1-1

PowerPoint, RGB color reference file 2-13

PPD

copying files for Windows applications 1-69

overview xiii

selecting the PPD in the Chooser 4-2

I-4 Index

Windows 9x/Me 1-3

Windows 2000/XP 1-34

Windows NT 4.0 1-18

Printer Driver, installable options

Windows 2000/XP 1-36

Windows 9x/Me 1-4

printer drivers,

see

PostScript printer drivers printing

Windows 2000/XP 1-40

Windows NT 4.0 1-25

see also

PostScript printing

Prntdrve.exe file 3-3

R

RGB page 01 2-13

RGB page 02 2-13

Rgb_01.doc 1-64

Rgb_02.ppt 1-64

S

screen fonts 2-12, 4-2

SMB printing setup

on Windows 2000/XP 1-46 to 1-47

on Windows 9x/Me 1-14 to 1-16

on Windows NT 4.0 1-30 to 1-32

specifications, color server xi, xii

Spooler,

see

Fiery Spooler

Stand21.ps (Mac OS) 2-14

Stand21.ps (Windows) 1-64

Stand34.ps (Mac OS) 2-14

Stand34.ps (Windows) 1-64

Status WebTool,

see

Fiery WebTools

T

thinnet cable xi

troubleshooting

Mac OS computers 4-2

Windows computers 4-1

U

Uninstalled Fonts folder 4-2

unshielded twisted pair (UTP) cable xi

User Software CD

contents (Mac OS) 2-1

contents (Windows) 1-55

installing from, for Mac OS 2-2, 2-13

troubleshooting fonts 4-2

W

WebDownloader WebTool,

see

Fiery

WebTools

WebScan xvi

WebSetup WebTool,

see

Fiery WebTools

Windows

copying color files 1-64

installing Fiery utilities 1-55

troubleshooting 4-1

Windows 9x/Me

parallel port 1-7 to 1-11

PCL printer driver 1-1 to 1-3 setting up PostScript printing 1-1

SMB printing 1-14 to 1-16

troubleshooting 4-1

Windows 2000/XP

IPX 1-44 to 1-45

IPX/SPX 1-44

PostScript printer driver 1-33 to 1-38

printing requirements 1-40

setting up PostScript printing 1-32

troubleshooting 4-1

Windows NT 4.0

IPX 1-29

IPX/SPX 1-28

PostScript printer driver 1-17 to 1-19

printing requirements 1-25

troubleshooting 4-1

WINS Name Server 1-15, 1-31, 1-46

Word, RGB color reference file 2-13
