Insteon Hub

Owner’s Manual

Contents

Getting Started

Insteon Hub

Device Overview

Installation

Download the App

Create an Account

4

Optional Wall Mounting

5

Insteon App

Insteon App on iOS

Insteon App on Android

Insteon App on Windows

Hardware Reset

Diagnostics

Network Reset

Factory Reset

Appendix

Specifications

Troubleshooting

Certifications and Warnings

Product Warranty

7

12

17

22

23

24

28

30

33

34

3

Device Overview

Status LED Linking

Unlinking/Network Issue

Insteon Hub

Installation

Connect your Hub to the internet and a power outlet using the cables provided. Avoid switched outlets or filtered power strips.

Ethernet Port

Factory Reset Power

X

Ethernet

Cable

Power

Cable

Download the App

From your mobile device, download and install Insteon for Hub from your device’s app store.

insteon for hub

Create an Account

Launch the App and follow the on-screen instructions to create an account and setup the Insteon Hub.

INSTEON

INSTEON for Hub

Sign In

Create an Account

You’re done setting up your Insteon Hub; now start adding devices.

4

1

Print out this page and use it as a template to drill mounting holes.

Optional Wall Mounting

2

Hang the Hub on two screws by aligning the hanger slots and sliding down.

15/32”

12mm

2 1/32”

52mm

Screw head should be about 5/16”

(8mm) in diameter

2 1/32”

52mm

15/32”

12mm

5

Use the Insteon App to configure and control your Insteon Hub. Everything from adding a device to controlling your thermostat is handled through the app.

6

Insteon App on iOS

The Insteon app on iOS uses a right-hand drawer to navigate between Check-In,

Favorites, Rooms, Scenes, Thermostats and

Settings. You can also add and edit devices, rooms and scenes from the drawer.

Check-In

An at-a-glance overview of all of your Insteon sensors. Sensors are white when red when triggered and white when not.

2:10 PM

Check-In

Back Door Front Door

Garage Door Garage Motion Kitchen Sink

Smoke Sensor

Favorites

A customizable screen where you can place your most used devices, scenes and sensors.

2:10 PM

Favorites

All Devices Bathroom Bedroom

Check-In Favorites Garage

Kitchen Living Room Outside

7

Rooms

Lets you group devices into rooms for easier navigation.

2:10 PM

Rooms

Bathroom Bedroom Kitchen

Living Room Garage Outside

Insteon App on iOS

Scenes

Automatically displays all of the scenes that have been created.

2:10 PM

Scenes

Good Morning Movie Time All Off

Thermostat

Displays your Insteon or Nest Thermostat.

For homes with multiple thermostats, you can configure the default from settings.

2:10 PM

Living Room

Thermostat

Off

74

º

Cooling to Heat to 65 º 72 º

Heat Cool

Auto

Settings

Your one-stop-shop for Hub and Insteon account settings and configuration. You can also find in-app help here.

2:10 PM

Settings Done

Devices 8

Scenes

Rooms

Schedules

House

1

Home

House Management

Account

1 [email protected]

3

6

About INSTEON App

Get Latest Configuration

8

Controlling a Device

Floor Lamp

2:10 PM

Living Room

On

Off

Insteon App on iOS

2:10 PM

Living Room

Living Room

Floor Lamp

On

Off

On

Tap to turn the device on or off

Off

Tap for additional control and to edit the device.

Additional Device Control

42%

2:10 PM

Living Room

Floor Lamp

2:10 PM

Living Room

Floor Lamp

42%

2:10 PM

Living Room

Tap On

Floor Lamp

Tap Off

42%

Turn a device on or off, regardless of brightness

2:10 PM

2:10 PM

Living Room

Living Room

Floor Lamp

Floor Lamp

42%

Tap the arrows to adjust in

10%-ish increments

9

Monitoring a Sensor

Insteon App on iOS

2:10 PM

Living Room

Motion Sensor

Motion Detected

Indicates that your sensor is not triggered

Indicates that your sensor has been triggered

Indicates that the Hub has lost contact with your sensor

If a newly added sensor shows yellow, try activating it.

Controlling a Camera

2:10 PM

Garage

Garage Lights Garage Door Camera

2:10 PM

Garage

Tap the arrows to pan and tilt your camera

Garage Lights Garage Door Camera

10

Controlling a Scene

Bedtime

2:10 PM

Scenes

On

Off

Insteon App on iOS

2:10 PM

Scenes

Bedtime

2:10 PM

Scenes

Bedtime

On

Off

On

Tap to turn the scene on or off

Off

Tap for additional control and to edit the scene.

Additional Scene Control

2:10 PM

Scene

Bedtime

On

Off

2:10 PM

Scene

Bedtime

On

Off

Tap to turn the scene on or off

11

Insteon App on Android

Favorites

Bathroom Bedroom Garage

2:10 PM

Kitchen Living Room Outside

Favorites Rooms Scenes Check-In

72º

Temp Settings

The Insteon app on Android uses tabs to navigate between Check-In, Favorites, Rooms,

Scenes, Thermostats and Settings. You can add and edit devices, rooms and scenes from the settings button.

Check-In

An at-a-glance overview of all of your

Insteon sensors. Sensors are red when triggered and white when not.

2:10 PM

Check-In

Back Door Backyard

Motion

Front Door

Garage Door Garage Motion Kitchen Sink

Smoke Sensor

Favorites Rooms Scenes Check-In

72º

Temp Settings

Favorites

A customizable screen where you can place your most used devices, scenes and sensors.

Favorites

Bathroom Bedroom Garage

2:10 PM

Kitchen Living Room Outside

Favorites Rooms Scenes Check-In

72º

Temp Settings

12

Insteon App on Android

Rooms

Lets you group devices into rooms for easier navigation. Also the location for All Devices which displays every device added to your house

2:10 PM

Rooms

All Devices Bathroom Bedroom

Check-In Favorites Garage

Kitchen Living Room Outside

Favorites Rooms Scenes Check-In

72º

Temp Settings

Scenes

Automatically displays all of the scenes that have been created.

Scenes

Good Morning Movie Time All Off

2:10 PM

Favorites Rooms Scenes Check-In

72º

Temp Settings

Thermostat

Displays your Insteon or Nest Thermostat.

For homes with multiple thermostats, you can configure the default from settings.

Living Room

Thermostat

2:10 PM

72

º

Cooling to Heat to 70 º 78 º

Off Heat Cool Auto Fan

ALWAYS

Favorites Rooms Scenes Check-In

72º

Temp Settings

Settings

Your one-stop-shop for Hub and Insteon account settings and configuration. You can also find in-app help here.

2:10 PM

Settings

Devices

Scenes

Rooms

Schedules

House

House Management

Account

Home

1 [email protected]

8

3

6

1

About INSTEON App

Favorites Rooms Scenes Check-In Temp Settings

13

Controlling a Device

Insteon App on Android

2:10 PM

Living Room

Favorites

Floor Lamp

2:10 PM

Favorites Rooms Scenes Check-In

72º

Temp Settings

Living Room

Floor Lamp

On

Off

On

Tap to turn the device on or off

Off

Tap for additional control and to edit the device.

Additional Device Control

Favorites

Floor Lamp

42%

2:10 PM

Favorites Rooms Scenes Check-In

72º

Temp Settings

2:10 PM

Living Room

Floor Lamp

42%

2:10 PM

Living Room

Tap On

Floor Lamp

Tap Off

42%

Turn a device on or off, regardless of brightness

2:10 PM

2:10 PM

Floor Lamp

Floor Lamp

42%

Tap the arrows to adjust in

10%-ish increments

14

Monitoring a Sensor

Insteon App on Android

Check-In

Motion Sensor

2:10 PM

Motion Detected

Favorites Rooms Scenes Check-In

72º

Temp Settings

Indicates that your sensor is not triggered

Indicates that your sensor has been triggered

Indicates that the Hub has lost contact with your sensor

If a newly added sensor shows yellow, try activating it.

Controlling a Camera

Favorites

2:10 PM

Favorites

2:10 PM

Overhead Motion Sensor Garage Door

Favorites Rooms Scenes Check-In

72º

Temp Settings

Use the arrows to pan and tilt your camera

Overhead Motion Sensor Garage Door

Favorites Rooms Scenes Check-In

72º

Temp Settings

15

Controlling a Scene

Insteon App on Android

Scenes

2:10 PM

Living Room

Bedtime

Bedtime

Bedtime

On

Off

2:10 PM

Floor Lamp

On

Off

On

Off

Rooms Scenes Check-In

72º

Temp Settings

Tap for additional control and to edit the scene.

Additional Scene Control

Scenes

Bedtime

On

2:10 PM

Off

Favorites Rooms Scenes Check-In

72º

Temp Settings

Scenes

Bedtime

On

2:10 PM

Off

Tap to turn the scene on or off

Favorites Rooms Scenes Check-In

72º

Temp Settings

16

Insteon App on Windows

The Insteon app on Windows Phone uses a six-screen carousel to switch between Quick View, Favorites,

Rooms, Scenes, Thermostats and Settings.

Quick View

An at-a-glance overview of all of your

Insteon sensors. Sensors are green when closed and red when triggered.

Favorites

A customizable screen where you can place your most used devices, scenes and sensors.

17

Rooms

Insteon App on Windows

Lets you group devices into rooms. Also the location for All Devices which displays every device added to your house.

Scenes

Automatically displays all of the scenes that have been created.

Thermostats

Displays your Insteon Thermostat. For homes with multiple thermostats, you can configure the default from settings.

Settings

Your one-stop-shop for Hub and Insteon account settings and configuration. You can also find in-app help here.

18

Controlling a Device

Insteon App on Windows

Tap the arrows to adjust in 10% increments

Slide to quickly adjust the brightness

Turn a device on or off, regardless of brightness

Monitoring a Sensor

Indicates that your sensor is OK

Indicates that your sensor has been triggered

Indicates that the Hub has lost contact with your sensor

If a newly added sensor shows yellow, try activating it.

19

Controlling a Scene

Insteon App on Windows

Tap to turn the scene on or off

Tap to edit the scene

Controlling a Camera

Use the arrows to pan and tilt your camera

20

A network reset will restore the default network configuration to the Hub.

A factory reset will erase all links stored in the device’s database as well as any customized properties.

21

1

You can enter an audio diagnostic mode that will report a connection issue in six potential areas. Once in the diagnostic mode, your Hub will beep through a series of tests.

Diagnostics

Tap the set button twice, wait one second and then tap the set button again once.

2x 1x

Single Beep: Test Passed

Double-Beep: Test Failed

Test 1

Insteon Hub Modem active

Test 2

Internet Time Server reachable

Test 3

Hub has a valid IP Address

Test 4

Connected to Insteon Servers

Test 5

Active remote connection to

Insteon’s Servers

Test 6

Successful remote connection to Insteon’s Servers at power up

22

1

Tap the set button three times. The

Hub will triple-beep.

3x

Network Reset

2

After a few seconds the Hub will singlebeep.

Your Hub has been restored to default network settings.

23

Factory Reset

1

Prior to performing a factory reset, you must delete all devices and scenes or factory reset all of your devices and delete your user account from Insteon.

Navigate to settings

2:10 PM

Settings Done

Devices

Scenes

Rooms

Schedules

House

1

Home

House Management

Account

1 [email protected]

8

3

6

About INSTEON App

Get Latest Configuration

2

From Settings, tap Account

Back

2:10 PM

Account Settings

User Email

Password

Default text/SMS [email protected]

••••••••••••••••

None _

Remember Me

Delete Account

3

Tap Delete Account. This cannot be undone and will erase your home from Insteon Connect.

Back

2:10 PM

Account Settings

User Email [email protected]

Password ••••••••••••••••

None _

Remember Me account. Failure to do so will result in degrated network performance.

Delete Account

Cancel OK

Disconnect power from the Hub

24

5

Press and hold the set button while reconnecting power. The

Hub will emit a long beep.

Factory Reset

6

When the long beep ends, release the set button. The

Hub will double-beep. After 30 seconds, your Hub will beep again.

LONG

7

Unplug and then reconnect your

Hub to power.

Your Hub has been restored to factory settings.

25

26

Insteon Glossary

Controller The Insteon transmitter

Responder The Insteon receiver

Blinking LED turning on and off repeatedly

Dual-Band An Insteon device that can send and receive both Insteon powerline signals and Insteon radio frequency signals

Ramp Rate The speed at which the load fades on or off

On-Level The preset brightness level a device will return to when turned on

Insteon A dual-band, mesh networking technology developed by Smarthome/Insteon. The world’s most reliable, expandable and simple home automation and control technology.

Link A one way association between a controller and responder

Linking A method for associating Insteon controller buttons with groups of Insteon responders such that the responders instantly return to a memorized state when the button is pushed. Links can be made manually with the set button or using software.

Unlinking The process by which an Insteon device can remove stored links. Just as with linking, unlinking is a one-way process and should be performed in both directions for devices that are both controllers and responders of each other, as in a 3-way switch scenario.

Multi-Linking /

Unlinking

A special mode that allows more than one link to be either created or removed simultaneously, without laborious set button presses. When in linking or unlinking mode, an Insteon device will continue to link to other devices until the set button is tapped or four minutes have elapsed, whichever occurs first.

Factory Reset A process that erases all stored links and reconfigures the device to factory defaults.

Load The device that you are controlling (e.g. a light bulb, ceiling fan, etc.)

On/Off A device that can control its connected load to turn on and off but cannot dim. Usually a relay-based device.

Retry A 2nd (or subsequent) attempt by a controller to send an Insteon signal, usually after an acknowledge is not received from the responder in the expected time-slot.

Scene Multiple devices respond to memorized states. For example, a dinner time scene turns on the dining table light, dims the kitchen lights to 10%, backyard lights turn off and the thermostat adjusts to 72º.

Set Button A button on an Insteon device that is used for setting or changing its properties

Simulcast A method for increasing the reliability of message delivery in a network. When a node in a network sends a message, every other node that hears the message retransmits it at precisely the same time based on a global clock, provided that the message has not already been retransmitted some maximum number of times. Message propagation is more robust because each node adds its energy to the signal, much like voices in a choir. Simulcasting is much simpler than message routing because there are no routing tables to maintain and nodes can join the network without any installation procedure.

27

Specifications

General

Available Colors White

Brand: Insteon

FCC ID SBP22452

Industry Canada 5202A-22452

Manufacturer Product No.: 2245-222

Patent No.: Protected under US and Foreign Patents (see www.insteon.com/ patents)

UPC: 813922013498

Warranty: 2 years, limited

Operation

Audio Alert Beeper

Local Control No

Setup Memory Non-volatile EEPROM

Status LED Red/Green LED

Insteon Features

Insteon Device Category 0x03

Insteon Device Subcategory 0x33

Insteon ID 1

Insteon Links 992

Insteon Messages Repeated Yes

Insteon Minimum Receive Level 40 mV

Insteon Minimum Transmit Level 3.2 Vpp into 5 Ohms

Insteon Powerline Device Yes

Insteon Powerline Frequency 131.65 KHz

Insteon RF Device Yes

Maximum Controlled Scenes 256

Maximum Scene Memberships 992

28

Multi-Link Support Yes

Multi-Unlink Support Yes

RF Beacon Yes

Radio Frequency 915 MHz

Radio Frequency Range Up to 250 feet

Mechanical

Beep on Button Press No

Dimensions 1.5” H x 3.75” W x 3.75” D

38mm H x 95mm W x 95mm D

Enclosure Material UV stabilized plastic

Mounting Tabletop or Wall Mount

Operating Environment Indoors

Operating Humidity Range 0-90% relative humidity

Operating Temperature Range 32º to 104º F

0º to 40º C

Factory Reset Button Yes

Storage Temperature Range -4º to 158º F

-20º to 70º C

Weight 5.2 oz

Electrical

Power Consumption 2 Watts

Supply Voltage 120-277 Volts AC, 50/60 Hertz, single phase

Surge Resistance Surges over 1000 volts

Power Connector IEC C8

Certification FCC ID Part 15B & 15C

IC RSS-210

Intertek ETL

29

Troubleshooting

Initial Setup and Configuration

Unable to create an Insteon account

There is most likely an internet connection issue between your mobile device and the Insteon Hub

Try this:

• Make sure your internet connection is working by trying to browse a website on your mobile device

• Look for any typos in your email address that might prevent the account from creating; if you are missing the “@” symbol or “.com,” add them. Insteon requires a full, valid email address.

Insteon App is unable to find your Insteon Hub

A number of factors can impact the initial setup but most of them are internet connection related.

Try this:

• Check all of the cables going into the Hub and make sure they are firmly seated. Trace the ethernet cable from the Hub back to the router and make sure it is connected properly there, too.

• Look for signs of life from the Insteon Hub. Even if not properly connected, you should see a green LED glow on the front of the Hub. If the LED doesn’t illuminate, check the power outlet. There should also be a blinking green and solid orange light on the Hub’s ethernet port. If both ethernet LEDs are off, try a different port on your router.

• Try power cycling your Hub by unplugging and then reconnecting it to power.

• For the initial connection, your mobile device must be connected to the WiFi network being generated by the same router to which the Hub is connected. While some routers create a “guest” network, you most often need to be connected to the main WiFi network being created by your router for the initial setup to work correctly.

• You can check to see if the Insteon Hub was able to properly “phone home” to Insteon. This will at least tell you that the Hub is up and running, even if a network configuration problem is preventing you from connecting to the Hub. On your mobile device or computer, open a browser and visit connect.insteon.com/ getinfo.asp. Any detected Insteon Hubs will be displayed on this page.

• Try a network reset (see Network Reset).

• If the problem persists, contact Insteon Support 866-243-8022

Insteon App is unable to connect to your Insteon Hub

A number of factors can impede connection to the Insteon Hub but most of them are internet connection related.

Try this:

• Check all of the cables going into the Hub and make sure they are firmly seated. Trace the ethernet cable from the Hub back to the router and make sure it is connected properly there, too.

• Look for signs of life from the Insteon Hub. Even if not properly connected, you should see a green LED glow on the front of the Hub. If the LED doesn’t illuminate, check the power outlet. There should also be a blinking green and solid orange light on the Hub’s ethernet port. If both ethernet LEDs are off, try a different port on your router.

• Ensure that your home internet connection is functioning by visiting a website from your computer’s internet browser.

• Restart your Hub by unplugging and then reconnecting it to power.

30

Troubleshooting

General Issues

Unable to add a new device using the Insteon App

Inability to add a new device is usually centered around issues with the Insteon network.

Try this:

• Relocate the new device closer to the Insteon Hub and try again. If this works, you may need a Range

Extender or an additional Dual-Band Insteon device to increase the reach of your Insteon Network.

• Log out of the Insteon App and sign back in. From the Insteon App, navigate to Settings and tap Log Out at the bottom of the screen.

Unable to delete a device using the Insteon App

Deleting a device from the Insteon App may encounter issues if that device is no longer present or connected in your home.

Try this:

• Ensure that the device to be deleted is plugged in or otherwise powered. If it is a battery powered device, press and hold the set button until the Status LED begins blinking and then try deleting from the App.

• If the device to be deleted has stopped functioning, you can force the Insteon App to delete the device but only after attempts to delete the device are unsuccessful by the app. You will be presented with an option to Force Remove the unresponsive device.

• Log out of the Insteon App and sign back in. From the Insteon App, navigate to Settings and tap Log Out at the bottom of the screen.

Unable to add a new WiFi Camera using the Insteon App

There are several points to check when a WiFi Camera cannot be added using the Insteon App.

Try this:

• Ensure that your router is functioning properly and that the Ethernet cable connecting the WiFi Camera is firmly connected to both the camera and your router.

• Confirm that the WiFi camera has power.

• Log out of the Insteon App and sign back in. From the Insteon App, navigate to Settings and tap Log Out at the bottom of the screen.

Unable to receive alerts via email or SMS

With iOS version 1.9.25 and Android version 1.7.4, SMS alerts are no longer supported in favor of push notifications. The Insteon Connect cloud service may require updating if an alert setting was not properly saved.

Try this:

• Check your email for an email from Insteon Connect. After initially configuring alerts, a confirmation link needs to be clicked to confirm that you wish to enable alerts for the specified email address. This email may

31

Troubleshooting

General Issues have been inadvertently routed to your spam folder or deleted.

• Disable and then re-enable alerts for the device that is not transmitting alerts.

• Ensure that a recipient email address is entered for the alert.

• Ensure that the Insteon for Hub app has permission to send push notifications. From the home screen of your iPhone, iPad or iPod touch, navigate to Settings. Scroll to the bottom of the list and locate Insteon.

In the “Allow Insteon to Access” section, tap Notifications. Flip the switch to green to enable push notifications. You will still need to configure push notifications on a per-device basis from within the Insteon app.

Unable to disable alerts via email

The Insteon Connect cloud service may require updating if an alert setting was not properly saved.

Try this:

• Log out of the Insteon App and sign back in.

• Delete the device for which alerts cannot be disabled and then re-add the device and enable alerts.

Schedules do not appear to run at the correct time

It is possible that the Hub’s clock is incorrect and requires resetting.

Try this:

• From the Insteon App, navigate to Settings > House and check Hub Local Time. If this time is incorrect or if the Hub Location is incorrect, tap Hub Location and locate your Insteon Hub on the map. This will automatically update your Hub’s internal clock.

• If updating the Hub time does not correct the schedule run time, try a Network Reset.

Check for firmware updates for your Insteon Hub

Your Hub will update its firmware automatically but you can manually check for updates.

Try this:

• From the Insteon App, navigate to Settings > House and tap Check for Updates.

32

Certifications and Warnings

Read and understand these instructions before installing and retain them for future reference.

This product is not designed or approved for use on powerlines other than 120-277VAC, 50Hz or 60Hz, single phase. Attempting to use this product on unapproved powerlines may have hazardous consequences.

• Use only indoors or in outdoor rated box

• This product may feel warm during operation. The amount of heat generated is within approved limits and poses no hazards. To minimize heat buildup, ensure the area surrounding this product is as clear of clutter as possible.

• Each Insteon product is assigned a unique Insteon I.D., which is printed on the product’s label.

• Changes or modifications to the hardware not expressly approved by Insteon may void the user’s authority to operate the equipment in a licensed manor.

• For pluggable equipment, the socket-outlet shall be installed near the equipment and shall be easily accessible.

This device complies with FCC Rules and Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

Le present appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorise aux deux conditions suivantes: (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radiolectrique subi, mme si le brouillage est susceptible d’en compromettre le fonctionnement.

33

Product Warranty

Limited Warranty

Seller warrants to the original consumer purchaser of this product that, for a period of two years from the date of purchase, this product will be free from defects in material and workmanship and will perform in substantial conformity to the description of the product in this Owner’s Manual. This warranty shall not apply to defects or errors caused by misuse or neglect. If the product is found to be defective in material or workmanship, or if the product does not perform as warranted above during the warranty period, Seller will either repair it, replace it, or refund the purchase price, at its option, upon receipt of the product at the address below, postage prepaid, with proof of the date of purchase and an explanation of the defect or error. The repair, replacement, or refund that is provided for above shall be the full extent of Seller’s liability with respect to this product. For repair or replacement during the warranty period, call 866-243-8022 with the Model # and Revision # of the device to receive an RMA# and send the product, along with all other required materials to:

Insteon

ATTN: Receiving

16542 Millikan Ave.

Irvine, CA 92606-5027

Limitations

The above warranty is in lieu of and Seller disclaims all other warranties, whether oral or written, express or implied, including any warranty or merchantability or fitness for a particular purpose. Any implied warranty, including any warranty of merchantability or fitness for a particular purpose, which may not be disclaimed or supplanted as provided above shall be limited to the two-year of the express warranty above. No other representation or claim of any nature by any person shall be binding upon Seller or modify the terms of the above warranty and disclaimer.

Home automation devices have the risk of failure to operate, incorrect operation, or electrical or mechanical tampering. For optimal use, manually verify the device state. Any home automation device should be viewed as a convenience, but not as a sole method for controlling your home.

In no event shall Seller be liable for special, incidental, consequential, or other damages resulting from possession or use of this device, including without limitation damage to property and, to the extent permitted by law, personal injury, even if Seller knew or should have known of the possibility of such damages. Some states do not allow limitations on how long an implied warranty lasts and/or the exclusion or limitation of damages, in which case the above limitations and/or exclusions may not apply to you. You may also have other legal rights that may vary from state to state.

Protected under U.S. and foreign patents (see www.insteon.com/patents)

©2015 Insteon Rev 06.22.15

34

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
