Panasonic C-HDM-106 Installation guide

Panasonic C-HDM-106 Installation guide
9.67
4
7.00
7
18.74
TOP VIEW
ITEM QTY. PART NUMBER
NO.
7
DESCRIPTION
1
10-003201
BRACKET HDM BASE FORD VAN
2
1
10-002267
BRACKET, LATCH, UNIVERSAL MOUNTING
3
1
30-002625
COLLAR, SPIDER ASSY
4
1
HS93061-5
EQUIPMENT BRACKET, TRACK MOUNT, 5" LONG
5
1
GSM01260
ASSY SUPPORT ARM 12.5-19"
6
1
C-HK-102
HARDWARE KIT
4
GSM31006
WASHER, 5/16" FLAT, SAE ZP
4
GSM31027
WASHER, 5/16" LOCK, ZP
4
GSM33011
SCREW, 5/16-18 X 3/4"
1
C-HK-105
HK KIT HDM SUPPORT
1
GSM33000
SCREW 1/4-20 X 1/2 HHCS, BLK, ZP, GRD 5
4
GSM33001
SCREW 1/4-20 x 3/4" HHCS ZP
4
GSM31026
WASHER 1/4 LOCK ZP
5
GSM31005
WASHER, 1/4 FLAT ZP, BLACK
4
GSM30005
NUT 1/4-20 HEX BLK, ZINC, GRD 5
3.
1
GSM33011
SCREW, 5/16-18 X 3/4"
4.
1
GSM31027
WASHER, 5/16" LOCK, ZP
1
GSM31006
WASHER, 5/16" FLAT, SAE ZP
1
C-HK-108
FORD VAN HDM BASE HARDWARE KIT
1
GSM32012
CARRIAGE BOLT 5/16-18 X 1 1/2
1
GSM31018
WASHER 5/16 X 1 1/4 FENDER ZP
1
GSM31006
WASHER, 5/16" FLAT, SAE ZP
1
GSM30024
NUT 5/16-18 HEX FLANGE SERRATED ZP
8
3
REAR VIEW
1
7
3
5
6
8
INSTALLATION INSTRUCTIONS
1.
2.
5.
6.
7.
REMOVE THE INBOARD FRONT & REAR
PASSENGER SEAT BOLTS. LIFT THE SEAT, PLACE
HDM BASE BETWEEN SEAT BRACKETS AND
VEHICLE FLOOR, AND ALIGN SLOTS TO SEAT BOLT
MOUNTING POINTS.
REINSTALL AND TIGHTEN ALL SEATBOLTS TO
VEHICLE MANUFACTURER'S TORQUE
SPECIFICATION. (USE CAUTION WHEN
THREADING THE BOLTS TO AVOID STRIPPING THE
THREADS.)
INSTALL SPIDER COLLAR ON THE HDM POLE (NOT
SHOWN)AS A SNUG FIT.
FIX HDM POLE ONTO THE BASE BRACKET USING
HARDWARE FROM C-HK-102 HARDWARE KIT.
INSTALL SUPPORT ARM AS SHOWN USING
HARDWARE SUPPLIED WITH C-HK-105 KIT.
*OPTIONAL DRILLING REQ'D*
FIX HS 93061-3 SUPPORT BRACKET ONTO SPIDER
COLLAR, AND AGAINST THE SEAT BASE. ATTACH
TO COLLAR AND SEAT BASE WITH HARDWARE
FROM C-HK-105 HARDWARE KIT.
THROUGH BOLT THE CARRIAGE BOLT ENSURING
NO WIRES OR CABLES ARE DAMAGED WHILST
DRILLING.
1
2
7
HAVIS, INC.
TITLE:
75 JACKSONVILLE RD,
WARMINSTER, PA. 18974
1-800-524-9900
97-13 FORD E SERIES VAN SIDE
MOUNT HDM BASE
DO NOT SCALE DRAWING
SIZE
A
DWG. NO.
C-HDM-106-INST
WEIGHT (LB): 7.24
SCALE: 1:8
REV
A
SHEET 1 OF 1
