Getting Started
∙ NVIDIA® SLITM Technology
Industry leading NVIDIA SLI technology offers amazing performance scaling by implementing
AFR(Alternate frame Rendering) for the world's premier gaming solution under Windows 7 with solid,
state-of-the-art drivers.
∙ Microsoft® DirectX 11 Support
DirectX 11 GPU with ShaderModel 5.0 support designed for ultrahigh performance in the new API's key
graphics feature, GPU-accelerated tessellation.
∙ Microsoft Windows 7 Support
Windows 7 is a new generation operating system that will mark a dramatic improvement in the way the OS
takes advantage of the graphics processing unit (GPU) to provide a more compelling user experience. By
taking advantage of the GPU for both graphics and computing, Windows 7 will not only make today's PCs
more visual and interactive but also ensure that they have the speed and responsiveness customers want.
Quick Installation
Follow the instructions below to install the VGA card:
1. Remove the computer case.
2. Locate the expansion slot on your mainboard.
Warning: Inserting the VGA card into a wrong
slot may damage your card (refer to your
mainboard manual for further Information).
3. Put the card directly over the expansion slot and
press one end of the card into the slot first.
Gently but firmly press the other end until the card is
fully seated in the slot.
4. Secure the card with a bracket screw.
5. Attach the power cable of the power supply with
recommended wattage to the VGA card, if necessary.
∙ Two Dual-link DVI with 2560X1600 maximum resolution
Able to drive industry's largest and highest resolution flat-panel displays up to 2560x1600 and with support
for High-bandwidth Digital Content Protection (HDCP).
6. Install all other cards and devices and connect all the
cables, and then re-install the computer case.
∙ HDMI with 4096X 2160 maximum resolution
Support for HDMI includes GPU-accelerated Blu-ray 3D support (Blu-ray 3D playback requires the
purchase of a compatible software player from CyberLink, ArcSoft, Corel, or Sonic), x.v.Color, HDMI Deep
Color, and 7.1 digital surround sound. Upgrade your GPU to full 3D capability with NVIDIA 3DTV Play
software, enabling 3D gaming, picture viewing, and 3D web video streaming. See www for
more details.
7. Connect the monitor. Now, you are ready to install
the driver and software on your computer.
∙ NVIDIA® PhysX® - Technology
Full support for NVIDIA PhysX technology,enabling a totally new class of physical gaming interaction for a
more dynamic and realistic experience with GeForce.
N670GTX series
∙ PCI Express 3.0 Support
Designed for the new PCI Express 3.0 bus architecture offering the highest data transfer speeds for the
most bandwidth-hungry games and 3D applications, while maintaining backwards compatibility with
existing PCI Express motherboards for the broadest support.
∙ NVIDIA® CUDATM Technology
CUDA technology unlocks the power of the GPU's processing cores to accelerate the most demanding
system tasks - such as video transcoding - delivering up to 7x performance over traditional CPUs.
Installing the VGA card...
Attaching the power cable...
Connecting the monitor...
∙ Support for four concurrent displays, including:
- Two dual-link DVI
- HDMI support
- DisplayPort 1.2
∙ NVIDIA® TXAA Technology
∙ NVIDIA® FXAA Technology
Part NO: G52-V2842X1
Power Connector
Fan Connector
NVIDIA GeForce GTX670 series
2048MB GDDR5 memory
1024MB GDDR5 memory
(optionally supported)
PCI Express Interface
SLI Interface
Display Port
Enabling HDMI Output
MSI Live Update 5 offers users with brand-new update service experience, which can significantly save your
time while searching files. Live Update 5 is capable to automatically analyze and list drivers, BIOS, and
utilities you need. With the easy-to-use updating approaches, you can increase the performance of your
system easily and quickly. Follow the instructions below, with a few mouse clicks, you can acquire the
related files for the system updating.
Follow the steps below to enable HDMI Output function:
1. Find the DVI-to-HDMI adapter, if provided.
The adapter may not come with the package, consult your
dealer to purchase the adapter, if needed.
3. Ensure that the adapter is firmly installed.
2. Click the Utility tab on the setup screen.
3. Click the MSI Live Update 5.
Follow the on-screen nstructions to
complete the installation.
To install the driver of the VGA card to your
computer, please follow the steps below:
4. Launch MSI Live Update utility to proceed
the updating function.
1. Turn on the computer.
2. Insert the driver disk into the optical device drive.
The AUTORUN program will start the Setup
program, and show the setup screen as shown
on the right.
DVI-D Port / DVI-I Port
- HDMI supported
- HDCP supported
- Dual dual-link DVI output
3. Click the Driver tag, and follow the on-screen
instructions to complete the installation.
DO NOT touch the cooling
system since it may produce a
certain heat while processing
For further information, please visit MSI website at
Optionally Supported
2. Attach the DVI-to-HDMI adapter to the DVI connector.
1. Insert the driver disk into the optical
device drive, and start the Setup program.
The VGA card shown here is for reference only, and may vary from the actual card.
Quick Installation
Do not force the GPU cooler
against the fragile GPU to avoid
damage to the GPU.
4. Once the installation is completed, restart the
computer as instructed.
Under the European Union ("EU") Directive on Waste Electrical and Electronic
Equipment, Directive 2002/96/EC, which takes effect on August 13, 2005,
products of "electrical and electronic equipment" cannot be discarded as
municipal waste anymore and manufacturers of covered electronic equipment
will be obligated to take back such products at the end of their useful life.
* All trademarks used in this manual are the sole property of their respective owners.
Tip: If, on your computer, the AUTORUN program does not execute automatically, please 1) enable the
optical device drive auto-detect function from the Control Panel; or 2) find and run the setup.exe file manually
from the driver disk.
Getting Started
Please check out the following items to make sure that you get the complete product:
∙ VGA card
∙ Driver disk, documentation, and accessories, if provided.
Consult the dealer immediately if the package is not completed.
System Requirements
To install the VGA card, your computer system needs to meet the following requirements:
∙ PCI Express® - compliant motherboard with one dual-width x16 graphics slot.
∙ Two 6-pin PCI Express supplementary power connector
∙ Minimum 500W or greater system power supply(with a minimum 12V current rating of 38A)
** Minimum system power requirement based on a PC configured with an Intel Core i7 3.2GHz processor.
∙ 300MB of available hard disk space
∙ 2GB system memory (4 GB recommended)
∙ Microsoft Windows 7, Windows Vista or Windows XP Operating System(32 or 64-bit)
∙ CD-ROM/ DVD-ROM drive
Card Features
∙ NVIDIA® 3D VisionTM Ready
GeForce GPU support for NVIDIA 3D Vision, bringing a fully immersive stereoscopic 3D experience to the
PC. A combination of high-tech wireless glasses and advanced software, 3D Vision transforms hdundreds
of PC games into full stereoscopic 3D. In addition, you can watch 3D movies and 3D digital photographs
in eye popping, crystal-clear quality.
∙ NVIDIA 3D VisionTM Surround Ready
Expand your games across three displays in full stereoscopic 3D for the ultimate "inside the game"
experience with the power of NVIDIA 3D Vision and SLI technologies. NVIDIA 3D Vision Surround also
supports triple screen gaming with non-stereo displays.
**NVIDIA 3D Version and 3D Version surround requires 3D Vision glasses, and 3D Vision-ready displays.
See for more information.
∙ OpenGL® 4.2 Optimization and Support
Ensures top-notch compatibility and performance for OpenGL applications.
∙ OpenCL Support
Full support for OpenCL GPU computing API.
∙ NVIDIA® Adaptive Vertical Sync
