INTRODUCTION

I

NTRODUCTION

The OkiLAN 6020e Plus Pocket Print Server enables Ethernet network users to connect to a printer with a bidirectional parallel port. It can be made to work with any Centronics or IEEE-1284 parallel interface printer that includes a resident emulation such as

PCL versions 4 through 6, Adobe PostScript ® , IBM ProPrinter ® or

Epson ® emulations.

The print server supports 10/100-megabit networks and most popular network operating systems and printers, except for the

OKIPAGE 8z and other GDI-based printers.

The print server kit includes the following:

• OkiLAN 6020e Plus hardware

• Power adapter with line cord

• Installation User’s Guide

• Utilities CD

• Product registration card

OKILAN 6020E PLUS INSTALLATION GUIDE 1

INSTALLING THE PRINT SERVER

I

NSTALLING THE

P

RINT

S

ERVER

1.

Turn off printer power.

2.

Attach the print server to the parallel connector on your printer (

1

).

1

3.

Secure the print server with the wire clips on the printer’s conncector.

4.

Plug the power adapter cord into the power jack on the print server. Then plug the power adapter into a

120 VAC outlet

2

OKILAN 6020E PLUS INSTALLATION GUIDE

.

INSTALLING THE PRINT SERVER

5.

NOTE

Some countries may require a different adapter for local voltages, such as 240 VAC.

Attach the 10/100Base-T UTP cable to the receptacle on the back of the print server.

6.

Attach the other end of the cable to the network.

P

OWERING

O

N THE

P

RINT

S

ERVER

Switch your printer power on. The print server runs through a set of power-up diagnostics for a few seconds. If the print server is operating properly, the green 100 Base-T light (

1

) blinks momentarily and then goes out (refer to the next page for light status descriptions). If the green light blinks continuously in a regular pattern, there is a problem. If this is the case, first verify that you have a good Ethernet connection, and then try turning the unit off and then on again. If the problem persists, refer to the

Troubleshooting section on page 12 in this Guide. When the green

OKILAN 6020E PLUS INSTALLATION GUIDE 3

INSTALLING THE PRINT SERVER light goes out, the yellow Link light (

2

) on the print server blinks in a random pattern.

1

2

3

LED I

NDICATORS

The back of the print server provides indicator lights for easy monitoring. The table on the next page defines the function of each indicator.

P

RINTING A

C

ONFIGURATION

S

HEET

To print configuration information, press the

Test

button on the back of the print server. You can also print configuration information using the utility program provided on the CD.

NOTE:

By default, the configuration sheet prints in ASCII text.

If you want the configuration sheet to print in PostScript or PCL, select this option (if the emulation is supported in the printer) when you run the network configuration utility program. The selected language must match the printer’s configured language to print correctly.

The content of the configuration sheet will vary depending on your printer and system setup.

4

OKILAN 6020E PLUS INSTALLATION GUIDE

HARDWARE TROUBLESHOOTING

H

ARDWARE

T

ROUBLESHOOTING

S

TATUS

I

NDICATOR

The back of the print server provides lights for easy monitoring.The following table defines the function of each light.

LABEL

Power

100

Base-T

Link

100

Base-T

+Link

100

Base-T

+Link

COLOR

Orange

Green

Yellow

Yellow,

Green

Yellow,

Green

STATE

ON

OFF

ON

OFF

ON

OFF

Blinking

Blinking

Alternately

Blinking

Simultaneously

STATUS

The unit is receiving power.

The unit is not receiving power.

The unit is transmitting at 100 megabits per second.

The unit is transmitting at 10 megabits per second

There is an Ethernet link

There is no Ethernet link.

There is network activity.

A fatal error or exception has occurred.

The firmware is being updated.

OKILAN 6020E PLUS INSTALLATION GUIDE 5

6

MANAGEMENT METHODS

M

ANAGEMENT

M

ETHODS

There are a variety of ways to configure and monitor the printer server using one or more of the following utilities:

E

XTEND

V

IEW

U

TILITY

• Used for advanced configuration of the print server, and allows you to configure for Netware, TCP/IP,

AppleTalk settings.

• Uses a 32-bit graphical user interface.

• Works with Windows PCs running TCP/IP or IPX/SPX protocols.

• Included on the print server installation CD.

• After installation, this utility can be run from the

START menu.

• Used for Windows configuration.

E

XTEND

V

IEW

W

EB

U

TILITY

• Allows you to configure the print server with a standard web browser like Netscape Navigator or

Microsoft Internet Explorer.

• Requires a Java Virtual Machine in Netscape or

Internet Explorer.

XA

DMIN

32 U

TILITY

• Used for advanced configuration of the print server, and allows you to configure for NetWare, TCP/IP,

AppleTalk settings.

• Uses a 32-bit graphical user interface.

• Works with Windows PCs running TCP/IP or IPX/SPX protocols.

• Included on the print server installation CD.

• After installation, this utility can be run from the

START menu.

• The default password is ACCESS.

• Used for reloading of firmware.

OKILAN 6020E PLUS INSTALLATION GUIDE

MANAGEMENT METHODS

NOTE

The XAdmin32 Utility is not required if ExtendView is installed.

W

EB

XA

DMIN

U

TILITY

• Allows you to configure the print server with a standard web browser like Netscape Navigator or Microsoft Internet

Explorer.

• No additional software is needed on the system.

• Can be used on any system that supports web browser capabilities.

• Type the IP address into your web browser address bar to connect.

• The default password is “OkiLAN”.

HP J

ET

A

DMIN

U

TILITY

An HP Windows-based utility (the OkiLAN print server works transparently with JetAdmin).

NOTE

The HP JetAdmin Utility is no longer available for download from the HP web site.

HP W

EB

J

ET

A

DMIN

U

TILITY

• A web browser-based HP utility (works with standard web browsers like Netscape Navigator or Microsoft Internet

Explorer).

• Can be downloaded from the HP web site <http:// www.hp.com>.

C

OMMAND

C

ONSOLE

• A command-line-oriented console.

• Contains features not available through ExtendView,

XAdmin32, or WebXAdmin.

• The default password is ACCESS.

• Can be accessed via XConfig NetWare Utility, or WebXAdmin.

• Type HELP for a list of console commands.

OKILAN 6020E PLUS INSTALLATION GUIDE 7

MANAGEMENT METHODS

NOTE

In all cases, when you are connected, press RETURN or

ENTER to get the "#" prompt, enter the password

ACCESS (it will not echo) and type anything in response to the "Enter Username>" prompt. When the "Local>" prompt appears, the console is ready to accept commands.

8

OKILAN 6020E PLUS INSTALLATION GUIDE

MICROSOFT WINDOWS NETWORK CONFIGURATION

M

ICROSOFT

W

INDOWS

N

ETWORK

C

ONFIGURATION

The following configuration procedures are designed for Windows

95/98/ME/2000/NT/XP/2003 Server operating systems.

1.

2.

Insert the CD supplied with your print server, and then click on Install Software.

Select TCP/IP Management Utilities, and then click on Next.

3.

4.

5.

6.

7.

8.

9.

Select ExtendView, and then click on Install.

Start the ExtendView utility by clicking on Start, Programs,

Okidata, and then ExtendView.

When you get the Welcome screen, click on Next, choose any name for your View Name, select Automatically create a view with default settings, and then click on Finish.

Double-click on the print server that you want to print to in the list.

If you are using TCP/IP (recommended for Windows printing) and you do not have a DHCP server (see note below), you will need to manually assign a valid IP Address (if you are not sure what IP address is valid, ask your network administrator), and click on OK.

NOTE

If you are using DHCP on your network, the print server may have acquired valid IP settings at this point and no further configuration is necessary. This might work well if your DHCP server allows the print server to keep this address permanently, but in most cases, you will want to use a static address outside the range reserved for DHCP (see your DHCP server documentation for details).

When you configure your printer port, the print server will go to a static IP address. To assign a static IP address, right-click on the print server in the menu, and then select Configuration. On the

TCP/IP tab, under IP Address Resolution, select Set Permanent, and assign a valid static IP address for your network. Click on OK to save the new settings.

Install the ExtendConnect IP Port Monitor by inserting the CD supplied with your print server and clicking on Install

Software.

Select ExtendNet Connect Windows Printing, click on Next, click on ExtendNet Connect for TCP/IP, and then click on

OKILAN 6020E PLUS INSTALLATION GUIDE 9

MICROSOFT WINDOWS NETWORK CONFIGURATION

Install. Follow the on-screen instructions to complete this installation.

10.

Install the printer driver software according to the documentation for the printer.

11.

Click the Windows Start button, select Settings, and then Printers (Start, then Printers and Faxes if you are using Windows XP).

12.

Right-click on the printer you wish to associate with the network port, and then select Properties.

13.

If you are using Windows NT/2000/XP, go to the

Ports tab. If you are using Windows 95/98/ME, go to the Details tab, and then click on Add Port.

14.

If you are using Windows NT/2000/XP, highlight

Wireless ExtendNet Connect IP Monitor, and then click on New Port.

15.

If you are running Windows 95/98/ME, select Other, highlight Wireless ExtendNet Connect IP Monitor, and then click on OK. The search will begin for available print servers.

16.

Highlight the print server you would like to create the port for, and then click on ADD.

17.

Make sure the port you created is chosen, and then click on Apply. You are now ready to print.

10

OKILAN 6020E PLUS INSTALLATION GUIDE

APPLETALK NETWORK CONFIGURATION

A

PPLE

T

ALK

N

ETWORK

C

ONFIGURATION

The print server supports the AppleTalk protocol running over

Ethernet (also known as EtherTalk). This capability allows

Macintosh computers to print jobs to a printer simultaneously with jobs from Windows, UNIX, NetWare, and other computers.

Print server AppleTalk capabilities allow a printer to appear as a shareable printer node on an AppleTalk Phase 2 network. The print server broadcasts information to Macintoshes on the network, and automatically appears in the Print Center or Chooser of each

Macintosh. Application programs (such as Microsoft Word, Excel,

PageMaker, etc.) can print without modification or special software on the Macintosh.

M

ACINTOSH

C

ONFIGURATION

(OS 8.

X AND

9.

X

)

1.

2.

3.

Identify the printer to which the print server is connected, and install the printer driver.

Verify that Ethernet is enabled from the Network Control

Panel or AppleTalk Control Panel.

At a Macintosh workstation, from the Apple menu, open the

Chooser.

4.

5.

6.

7.

If the Chooser window displays an AppleTalk zone list, select the necessary zone.

Click on the icon for the printer driver you are going to use.

If you have a Postscript printer, you can use the LaserWriter driver.

Select the print server name (the default is

TWC_xxxxxx_P1_AT, where "xxxxxx" are the last six digits of the Ethernet address.).

Close the Chooser. You can now print to the printer using any standard Macintosh application program.

M

ACINTOSH

C

ONFIGURATION

(OS 10.

X

)

1.

If you have not done so already, set the name of your computer by going to the Applications folder, selecting

System Preferences, and then Sharing. Type in the computer name in the Network Identity section (you can also set the IP address here if you want).

OKILAN 6020E PLUS INSTALLATION GUIDE 11

APPLETALK NETWORK CONFIGURATION

2.

3.

4.

5.

6.

NOTE

The Applications folder can generally be reached by double-clicking on the Macintosh HD icon on the desktop.

Turn on Ethernet and AppleTalk by clicking on the

Applications folder and clicking on Network. Next to

Configure: select Built-in Ethernet (you can leave the

Location: setting as Automatic).

Click on the AppleTalk tab; ensure the box next to

Make AppleTalk Active is checked. If necessary, select the appropriate AppleTalk Zone (you can leave the Configure: setting as Automatic).

Now go to the Applications folder, open the Utilities folder, and select Print Center. The Printer List will appear (it will be empty if you have no printers configured). Click on Add Printer..., and then select

AppleTalk instead of Directory Services.

All of the available AppleTalk printers on the network should appear. Click on the one you wish to add, and then click Add. The printer will now appear in the

Printer List.

To print from an application program, go to File and then Print, select the desired printer, and then click on Print.

12

OKILAN 6020E PLUS INSTALLATION GUIDE

TROUBLESHOOTING

T

ROUBLESHOOTING

This section describes procedures for troubleshooting problems you may encounter with the print server, and is divided into the following sections:

• Installation Problems

• Intermittent Problems

• Protocol-Specific Troubleshooting

P

RINTING

P

ROBLEMS

If you cannot print to the print server after you install it, check the following:

• Make sure that the printer is powered on and is on-line, and that all cables are securely plugged in.

If the printer starts up but you cannot print, the problem could be one of the following:

• There is a problem with the interface between the print server and the printer.

• There is a problem with the network connection or cabling.

• There is a queue setup problem, a print server setup problem, or other protocol-related problem.

C

HECKING THE INTERFACE BETWEEN THE PRINT SERVER AND THE PRINTER

:

1.

First make sure that the print server is securely plugged in to the printer.

2.

Wait about two minutes after the printer is powered ON, and then run a print server self-test by pushing the button on the back of the print server for less than five seconds.

3.

NOTE

Pushing the button for more than five seconds will reset the print server to factory defaults.

If the self-test does not print, then there is possibly a hardware problem. Double-check the connections. If you still cannot print, then make sure that your printer is capable of printing text, PCL or PostScript (the self-test will not work unless one of these is possible).

OKILAN 6020E PLUS INSTALLATION GUIDE 13

TROUBLESHOOTING

4.

If the self-test prints but you cannot print or you get distorted printouts, make sure that the printer is set for the correct Page Description Language. Also, verify that you have set up the drivers correctly on the workstation.

C

HECKING THE NETWORK CONNECTION AND CABLING

If the self-test page prints but you cannot print documents, first check the network connection and cabling.

• If the appropriate lights are not on, there is probably a bad 10baseT or 100baseTX cable, or the hub port is bad. If possible, try a different cable and hub port, or try connecting a different device to the cable.

• If you are using a hub, verify that the hub port is good by trying the print server on a different port.

• If you have a bridge or router located between the print server and the host computer, make sure that the device is set up to allow the print server to send and receive data from the host. For example, a bridge can be set up to only allow certain types of

Ethernet addresses to pass through (a process known as filtering); therefore, such a bridge must be configured to allow print server addresses. Likewise, a router can be set up to pass only certain protocols, so be sure that the desired protocol can be passed through to the print server. In the case of routers, also make sure that the protocol is routable (LAT,

NetBEUI, and DLC/LLC are not routable).

• If the job exits in the queue but does not print, ensure that you are not trying to print a text job to a

PostScript printer. If you have a printer that is capable of automatic language switching, ensure that the printer is not forced into PostScript mode.

• Make sure that you are not trying to perform an illegal operation, such as attempting to print a legalsize form when the printer only supports 8.5" x 11" paper.

14

OKILAN 6020E PLUS INSTALLATION GUIDE

TROUBLESHOOTING

I

NTERMITTENT

P

ROBLEMS

If the print server and the printer start up, but you intermittently have problems printing, check the following:

• Excessive NetWare polling can be a big cause of intermittent problems. Make sure that you have only enabled the

NetWare file servers that you need for printing (do a SHOW

NETWARE command from the print server console to see the enabled file servers).

• If you can print small jobs OK but large graphics jobs are distorted or incomplete, make sure that you have adequate memory in your printer.

TCP/IP T

ROUBLESHOOTING

If you are using TCP/IP and cannot print to the print server, and you have checked the hardware and network as described in the previous steps, then check the following (it is always a good idea to try creating a another print queue to eliminate the possibility of setup errors):

• The problem may be the result of mismatched or duplicate IP addresses. Verify that the IP address is correctly loaded into the print server (via the self-test page or through the remote console) and make sure that no other nodes on the network have this address (DUPLICATE IP ADDRESSES ARE THE

BIGGEST CAUSE OF TCP/IP PRINTING PROBLEMS). If the address is not correct, then check whether the loading procedure was properly executed.

• Also verify that the host computer and the print server are either on the same subnet (for example, if the print server has a subnet mask of 255.255.255.0, the host must have the same subnet mask) or that the router is properly configured to pass data between the two devices.

• If the wrong IP address is loaded, check your network for file servers that have DHCP, BOOTP, or rarp enabled, and make sure that these file servers are not set up to load IP addresses into the print server.

OKILAN 6020E PLUS INSTALLATION GUIDE 15

TROUBLESHOOTING

A

PPLE

T

ALK

T

ROUBLESHOOTING

If you cannot print from an AppleTalk for Macintosh computer, you have checked the hardware and network as described in the previous steps, then check the following:

• Make sure that you are running Phase 2 AppleTalk and that you have selected the correct network interface from the Network Control Panel on the

Macintosh.

• Verify that you have selected the correct AppleTalk zone. The print server gets its zone information from router broadcasts, and may not be in the zone you expect and will not show up in the Chooser. In this case, you may need to force the zone name with the

SET APPLETALK ZONE command.

• Verify that you have a PostScript printer, because

AppleTalk requires PostScript. If you have a printer with automatic language switching, the printer may need to be manually forced into PostScript mode via the printer front panel.

W

INDOWS

T

ROUBLESHOOTING

If you are having trouble printing with Windows, check the following (also refer to the TCP/IP Troubleshooting section):

• Make sure that you can ping the print server using the DOS command PING ipaddress, where ipaddress is the IP address of the print server. If you cannot ping the print server, you will not be able to print.

• If you are getting distorted printouts, try printing using the generic/text printer driver.

16

OKILAN 6020E PLUS INSTALLATION GUIDE

SAFETY AND REGULATORY NOTICES

S

AFETY AND

R

EGULATORY

N

OTICES

FCC R

ADIO

F

REQUENCY

I

NTERFERENCE

S

TATEMENT

This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio or television reception. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause interference to radio and television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver,

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

W

ARNING

The connection of a non-shielded equipment interface cable to this equipment will invalidate the FCC Certification of this device and may cause interference levels which exceed the limits established by the FCC for this equipment. It is the responsibility of the user to obtain and use a shielded equipment interface cable with this device.

If this equipment has more than one interface connector, do not leave cables connected to unused interfaces. Changes or modifications not expressly approved by the manufacturer could void the user's authority to operate the equipment.

OKILAN 6020E PLUS INSTALLATION GUIDE 17

SAFETY AND REGULATORY NOTICES

I

NDUSTRY

C

ANADA

R

ADIO

I

NTERFERENCE

S

TATEMENTS

This Class B digital apparatus meets all requirements of the

Canadian Interference-Causing Equipment Standards

(ICES-003).

Cet appereil numerique do la classe B respecte toutes les exigences du Reglement sur le materiel brouilleur NMB-003 du Canada.

Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

The term "IC" before the radio certification number only signifies that Industry of Canada technical specifications were met.

F

OR

E

UROPEAN

U

SERS

This product is in conformity with the protection requirements of EU Council Directive 89/336/EEC on the approximation of the laws of the Member States relating to electromagnetic compatibility. TROY Group cannot be responsible for any failure to satisfy the protection requirements resulting from a non-recommended modification of the product.

This product has been tested and found to comply with the limits for Class B Information Technology Equipment. The limits for Class B equipment were derived for typical residential environments to provide reasonable protection against interference with licensed communications devices.

18

OKILAN 6020E PLUS INSTALLATION GUIDE

SAFETY AND REGULATORY NOTICES

D

ECLARATION OF

C

ONFORMITY

(FCC)

Per CFR, Title 47, Part 2:

We: Oki Data Americas, Inc.

Located at: 2000 Bishops Gate Boulevard

Mt. Laurel, New Jersey 08054 declare under sole responsibility that the product:

Trade Name: Oki

Type of Product: Print Server

Model: OkiLAN 6020e Plus complies with CFR, Title 47, Part 15 of the FCC rules as a Class B digital device. Each product marketed, is identical to the representative unit tested and found to be compliant with the standards. Records maintained continue to reflect the equipment being produced can be expected to be within the variation accepted, due to quantity production and testing on a statistical basis as required by 47CFR §2.909.

D

ECLARATION OF

C

ONFORMITY

(EU)

We: Oki Data Americas, Inc.

Located at: 2000 Bishops Gate Boulevard

Mt. Laurel, New Jersey 08054 declare under sole responsibility that the product:

Trade Name: Oki

Type of Product: Print Server

Model: OkiLAN 6020e Plus is in conformity with the provisions of:

Council Directive 1989/336/ECC (May 3, 1989), Electromagnetic

Compatibility.

Standards used in the assessment:

ETSI EN 55022

ETSI EN 61000-3-2

ETSI EN 55024

ETSI EN 61000-3-3

OKILAN 6020E PLUS INSTALLATION GUIDE 19

Oki Data Americas, Inc., 2000 Bishops Gate Blvd., Mt. Laurel, NJ 08054-4620

Tel: (856) 235-2600 FAX: (856) 222-5320 http://www.okidata.com

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
