Off Road Range

HMC13530 - 2012 Off Road Range Brochure_V8.indd 1 6/02/12 3:46 PM

2 | Honda Off Road Range

HMC13530 - 2012 Off Road Range Brochure_V8.indd 2 6/02/12 3:46 PM

HMC13530 - 2012 Off Road Range Brochure_V8.indd 3 hondamotorcycles.com.au | 3

6/02/12 3:46 PM

Off Road

The Undisputed

Open-Class

Champion

CRF450R

Since its introduction, the CRF450R has served as the standard by which all other bikes are judged in the big-bore class of motocross machines. In 2012, Honda raises the bar once again with a host of improvements that will help the CRF450R stay at the head of the pack.

Features

• Advanced liquid-cooled 4-stroke 4-valve SOHC engine producing power across a broad rpm-band for smooth, easy operation

• High fuel efficiency allows use of compact and lightweight fuel tank and battery-less fuel injection is tuned for strong performance and reduced noise levels.

• Exhaust and muffler design achieves low weight, optimal pipe length for the engine and contributes to mass centralisation

• New Pro-Link linkage for enhanced traction and improved suspension control as well as new optimised suspension settings front and rear for even greater stability on rough terrain.

• Next generation twin-spar aluminium frame is lightweight and provides optimal rigidity for better handling and new stiffer fork springs for a higher spring impact rate, giving enhanced chassis balance and stability when approaching and landing from jumps.

• Unique lightweight and compact Honda Progressive Steering

Damper (HPSD), developed by Team Honda, improves cornering ability and reduces rider fatigue. More aggressive steering characteristics are augmented while straight-line stability is assisted. The damper’s progressive damping action smoothly increases with handlebar deflection, while producing very natural steering characteristics and feel.

• Brake pedal and shift lever are made of lightweight aluminium and designed to complement the riding position. Brake pedal features optimised ratio to match integrated rear-brake master cylinder design.

4 | Honda Off Road Range

HMC13530 - 2012 Off Road Range Brochure_V8.indd 4 6/02/12 3:46 PM

HMC13530 - 2012 Off Road Range Brochure_V8.indd 5 specifications

CRF450R

Engine Type

449.7cc liquid-cooled 4-stroke

4-valve SOHC

Bore and Stroke 96 x 62.1mm

Compression Ratio 12:0

Valve Train Unicam; 4-valve

Carburation PGM-FI electronic fuel injection

Ignition Full transistor

Transmission 5-speed, constant mesh manual

Starter Kick

Dimensions

2,188mm x 827mm x 1,271mm

Final Drive #520 roller chain

Front Suspension 48mm inverted KYB leading-axle twin chamber cartridge-type telescopic fork with 18-step adjustable compression and 16-step rebound damping; 310mm stroke

Rear Suspension

Pro-Link with KYB damper, adjustable low-speed (18-step) and high-speed (2.25-turns) compression and 20-step rebound damping; 315mm travel

Front Brake 240mm x3mm hydraulic disc with dual-piston calliper and sintered metal pads

Rear Brake 240mm x 4mm hydraulic disc with single-piston calliper and sintered metal pads

Front Tyre 80/100 – 21 inch

Rear Tyre 120/80 – 19 inch

Wheelbase 1,492mm

Rake (Caster Angle)

27°5’

Trail 116mm

Seat Height 952mm

Ground Clearance

329mm

Fuel Capacity 5.7 litres

Kerb Weight 108.9kg

Warranty Period

No Warranty hondamotorcycles.com.au | 5

6/02/12 3:46 PM

Off Road

Raising the

Bar – Again.

CRF250R

Superb handling and excellent power stand as the hallmarks of the

CRF250R, and the revised 2012 model ups the ante in the 250 class.

With a revamped engine, revised suspension settings the new

CRF250R motocross machine has a wider powerband and additional low-end and mid-range torque among other upgrades for 2012.

Features

• An all-new cylinder head with revised port shapes, new camshaft and new exhaust valves shape for enhanced drivability at low and medium rpm.

• New narrower throttle body enhancing bottom to mid range power and torque feel with improved throttle control.

• Third generation Unicam engine with lightweight battery-less fuel injection for reliable, controllable power.

• PGM-FI system monitors throttle position, intake air and coolant temperatures and manifold pressure to accurately map fuel charge and ignition spark, significantly improving partial-throttle response and helping to ensure excellent rideability

• New suspension settings front and rear ensure stable running on rough terrain, boosting rider confidence while new Pro-Link rear suspension linkage for enhanced traction and improved chassis control.

• Mass-centralised chassis gives fine control at any speed, particularly during mid-air manoeuvres and new front axle collars add rigidity to the front end, increasing steering precision.

• New longer and wider footpegs for enhanced control, with new bolt for lighter weight. Revised kickstart arm ensures easy starting.

• Rider ergonomics are optimized by adapting the handlebar, seat and footpeg height to place the rider’s legs at the narrowest part of the frame for improved comfort and handling feel.

6 | Honda Off Road Range

HMC13530 - 2012 Off Road Range Brochure_V8.indd 6 6/02/12 3:46 PM

HMC13530 - 2012 Off Road Range Brochure_V8.indd 7 specifications

CRF250R

Engine Type

249cc liquid-cooled single-cylinder

4-stroke

Bore and Stroke 76.8 x 53.8mm

Compression Ratio 13.2:1

Valve Train Unicam; 4-valve

Carburation PGM-FI electronic fuel injection

Ignition

Full transistor with digital ignition

Transmission 5-speed constant mesh

Starter Kick

Dimensions

2181mm x 827mm x 1271mm

Final Drive #520 roller chain

Front Suspension 48mm inverted Showa leadingaxle twin chamber cartridge-type telescopic fork with 16-step adjustable compression and rebound damping; 310mm stroke

Rear Suspension

Pro-Link with single Showa damper, adjustable low-speed

(13-step) and highspeed (3.5-turn) compression and 17-step rebound damping; 313mm travel

Front Brake 240mm hydraulic disc with dualpiston calliper and sintered metal pads

Rear Brake 240mm hydraulic disc with singlepiston calliper and sintered metal pads

Front Tyre

80/100 – 21 inch

Rear Tyre 100/90 – 19 inch

Wheelbase 1,489mm

Rake (Caster Angle)

27°23’

Trail 118mm

Seat Height 951mm

Ground Clearance

322mm

Fuel Capacity 5.7 litres

Kerb Weight 101.8kg

Warranty Period No Warranty hondamotorcycles.com.au | 7

6/02/12 3:46 PM

Off Road

The Honda CRF150R and CRF150RB (Big Wheel) motocross bikes offer a new level of competition!

*Overseas models shown

CRF150R/150RB

*

In keeping with the revolutionary CRF450R and CRF250R,

Honda’s 150cc 4-stroke machines are destined to redefine the small displacement motocross category. What you will find inside the bikes’ lightweight, high-tensile steel frame is a compact yet powerful 4-stroke 149cc liquid-cooled four-valve Unicam engine that produces impressive power across a wide rpm range for easy-to-control operation.

Minimisation of weight is a huge factor. It is evidenced in its handlebar-mounted hotstart system, low-carbon steel crankshaft, forged slipper piston and rings, aluminium swingarm, vertically split crankcases with built-in oil pump and exhaust system that uses a lightweight stainless exhaust header and repackable aluminium muffler.

The 32mm Keihin FCR Carburetor offers very little throttle effort, smooth operation, crisp throttle response and excellent rideability.

The bikes’ adjustable Showa cartridge front fork features a friction-reducing design to improve compression and rebound control. While the Pro-Link rear-suspension system features a fully adjustable Showa shock for superb compliance and control.

Lightweight front and rear disc brakes with high-performance pads offer powerful and precise braking.

8 | Honda Off Road Range

HMC13530 - 2012 Off Road Range Brochure_V8.indd 8 specifications

CRF150R/150RB

Engine Type

149.7cc liquid-cooled single-cylinder

4-stroke

Bore and Stroke 66 x 43.7mm

Compression Ratio 11.7:1

Valve Train Unicam valve train

Carburation Keihin 32mm flat slide with Throttle

Position Sensor (TPS)

Ignition Solid state CD with electronic advance

Transmission Close ratio 5-speed

Starter Kick

Dimensions

1,832mm x 770mm x 1,133mm

*1,900mm x 770mm x 1,171mm

Final Drive

#420 O-ring-sealed chain

Front Suspension 37mm fully adjustable leading axle inverted Showa cartridge fork *37mm fully adjustable leading axle inverted

Showa cartridge fork; 275mm stroke

Rear Suspension

Pro-Link fully adjustable Showa single shock; 272mm stroke

*Pro-Link fully adjustable Showa single shock; 282mm travel

Front Brake

220mm hydraulic disc with singlepiston calliper and sintered metal pads

Rear Brake 190mm hydraulic disc with single piston calliper and sintered metal pads

Front Tyre 70/100 – 17 inch

*70/100 – 19 inch

Rear Tyre 90/100 - 14 inch

*90/100 - 16 inch

Wheelbase 1,260mm / *1,285mm

Rake (Caster Angle) 27.2° / *27° 48’

Trail 78mm / *96mm

Seat Height 832mm / *866mm

Ground Clearance 301mm / *336mm

Fuel Capacity 4.3 litres

Kerb Weight 83kg / *85kg

Warranty Period No Warranty

*CRF150RB Specifications

6/02/12 3:47 PM

Off Road

One hell of a bike, one heavenly ride. With numerous magazine accolades and roaring approval from riders coast to coast, the electricstart CRF450X is the favourite big-bore off road machine for racers and weekend warriors alike.

*Overseas model shown

CRF450X

The CRF450X off road warrior was spawned by the creative minds at Honda to be the best open-class off road machine in the world and it has not failed to meet every expectation. With mechanical genetics based on the powerplant and chassis from the R-model, virtually every piece has been re-engineered to fulfill a completely different mission. Unique features include an electric-start system for easy starting in all conditions, a fuel-tank capacity of 7.2 litres, a powerful 35w halogen headlight that offers a wide range of illumination and all plastic body components designed for slimmer, more aggressive styling and lighter weight. Its powerful 4-stroke

449cc liquid-cooled four-valve Unicam engine is designed to produce power across a wide rpm range for off road riding.

On top of that, the CRF450X’s 40mm Keihin FCR-type carburetor features four rollers on the flat slide, resulting in smooth operation, crisp throttle response and excellent rideability. Additional special features such as a convenient sidestand integrated into the left footpeg bracket that can be easily removed for competition events and an 18-inch rear wheel for greater flat-tyre protection make this amazing bike even more attractive to the rider.

specifications

CRF450X

Engine Type

449cc liquid-cooled 4-stroke 4-valve

SOHC single

Bore and Stroke 96 x 62.1mm

Compression Ratio 12.0:1

Valve Train Unicam; 4-valve

Carburation 40mm Keihin FCR flat-slide carburetor with Throttle Position Sensor (TPS)

Ignition CDI with electronic advance and lighting coil

Transmission 5-speed

Starter Electric and kick

Dimensions

2,179mm x 521mm x 1,273mm

Final Drive #520 T-ring-sealed chain

Front Suspension 47mm Showa inverted leading-axle twin chamber cartridge-type telescopic fork with 16-step adjustable compression and rebound damping; 315mm stroke

Rear Suspension

Pro-Link with Showa damper, adjustable low-speed (13-step) and high-speed (3.5-turn) compression and 17-step rebound damping;

313mm travel

Front Brake 240mm hydraulic disc with dual-piston calliper and sintered metal pads

Rear Brake 240mm hydraulic disc with singlepiston calliper and sintered metal pads

Front Tyre

80/100 – 21 inch

Rear Tyre 110/100 – 18 inch

Wheelbase 1,480mm

Rake (Caster Angle)

27°3’

Trail 114.7mm

Seat Height 963mm

Ground Clearance

345mm

Fuel Capacity 7.2 litres

Kerb Weight 122kg

Warranty Period

3 months – parts only

HMC13530 - 2012 Off Road Range Brochure_V8.indd 9 6/02/12 3:47 PM

Off Road

A serious, purpose-built, off road bike that exceeds the capabilities of the competition in all conditions.

*Overseas model shown

CRF250X

The high-spirited CRF250X combines light weight, strong, versatile power, confidently responsive handling and unrivalled fun in one of the finest dirt bikes to be found in the world of off-road riding.

Acclaimed by the motorcycle press, enthusiasts and serious offroad riders everywhere, it features the easy dependability of pushbutton electric starting, enduro-style lights to extend your fun after the sun goes down, and the strong, versatile performance of a motocross champion that anybody can enjoy. The CRF250X comes with new Honda Racing-inspired graphics.

Whether you are battling for a position right up front ahead of hard-core competition or just looking for pure high-flying, roostthrowing, dirt riding enjoyment, the dynamic CRF250X’s winning combination of easy-handling excitement and solid dependability will deliver more fun than you’ve ever had in the dirt.

10 | Honda Off Road Range

HMC13530 - 2012 Off Road Range Brochure_V8.indd 10 specifications

CRF250X

Engine Type

249cc liquid-cooled, 4-stroke,

4-valve SOHC single

Bore and Stroke 78 x 52.2mm

Compression Ratio 12.9:1

Valve Train Unicam; 4-valve

Carburation 37mm Keihin FCR flat-slide carburetor with Throttle Position

Sensor (TPS)

Ignition

CDI with electronic advance and lighting coil

Transmission

5-speed

Starter Electric and kick

Dimensions 2,174mm x 827mm x 1,261mm

Final Drive #520 T-ring-sealed chain

Front Suspension 47mm inverted Showa leading axle twin-chamber cartridge type telescopic fork with 16-step adjustable compression and rebound damping; 315mm stroke

Rear Suspension Pro-Link with single Showa damper, adjustable low-speed (13-step) and high-speed (3.5 turn) compression and 17-step rebound damping;

312mm travel

Front Brake 240mm hydraulic disc with dual-piston calliper and sintered metal pads

Rear Brake 240mm hydraulic disc with singlepiston calliper and sintered metal pads

Front Tyre 80/100 – 21 inch

Rear Tyre 100/100 – 18 inch

Wheelbase 1481mm

Rake (Caster Angle) 27°54’

Trail 118mm

Seat Height 958mm

Ground Clearance 346mm

Fuel Capacity 7.3 litres

Kerb Weight

114.8kg

Warranty Period 3 months – parts only

6/02/12 3:47 PM

Off Road

Honda’s all-new CRF250L offers flexibility like no other Honda machine

*Overseas model shown. Headlight standard on Australian model.

CRF250L

Honda’s all-new CRF250L will offer convenient every-day riding along with enjoyable weekend off-road riding in one easy to handle package.

With a liquid-cooled, 4 stroke, DOHC, single cylinder engine, the

CRF250L will have more than enough power and agility to tackle any kind of riding conditions.

Wrapped in styling that predicts the look of the next-generation

CRF machines, the CRF250L boasts slim yet tough characteristics unique to Honda’s off-road bikes.

Designed with user friendliness in mind, the new CRF250L will offer specifications and equipment such as a bright headlight, twin trip meter, fuel gauge and a clock, along with a range of optional parts and accessories to cater for all requirements.

The CRF250L will offer flexibility like no other Honda machine; useability, capability and affordability will be wrapped up in one on/off-road power package. specifications

CRF250L

Engine Type 249.6cc liquid-cooled 4-stroke

DOHC 4-valve single cylinder

Bore and Stroke 76mm x 56mm

Valve Train DOHC 4-valve

Carburation

PGM-FI electronic fuel injection

Ignition CDI with electronic advance

Transmission 6-speed constant mesh transmission

Starter Electric

Dimensions 2,195mm x 819mm x 1,195mm

Final Drive 520 o-ring chain

Front Suspension 43mm inverted fork

Rear Suspension Pro-link single shock

Front Brake Hydraulic disc

Rear Brake Hydraulic disc

Front Tyre 3.00 x 21 inch

Rear Tyre

120/80 x 18 inch

Wheelbase 1,445mm

Seat Height 882mm

Ground Clearance 258mm

Fuel Capacity

7.7 litres

Kerb Weight 147kg

Warranty Period TBA hondamotorcycles.com.au | 11

6/02/12 3:47 PM HMC13530 - 2012 Off Road Range Brochure_V8.indd 11

Off Road

Discover the world of off road riding. The CRF230F is the ideal bike for recreational riders.

*Overseas model shown. Headlight standard on Australian model.

CRF230F

With electric starting, long-travel suspension and dependable power, the CRF230F is the perfect bike to discover the world of off road riding.

The popular CRF230F features an ever faithful 223cc air-cooled

4-stroke single-cylinder engine that delivers smooth, even power and torque across a wide rpm range making it the perfect enduro for teens and the young at heart. The rider focused features don’t stop there. The convenience of electric start, plus a smooth shifting 6-speed gearbox, an easy-to-use heavy duty clutch and a 26mm carburetor offering superb throttle response mean the

CRF230F is a bike built for fun.

With its low and slim motocross style seat, powerful 240mm front disc brake, box section aluminium swingarm and Pro-Link rear suspension, the CRF230F also offers sure and easy handling.

It’s lightweight high-tensile steel frame wrapped in CRF Honda

Racing-inspired bodywork, translates to hard edged looks – an important factor for those who like to be the leader of the pack.

Described by fans as being “very forgiving”, torquey with loads of low down power and extremely manoeuvrable, the CRF230F is sure to please everyone in the family.

12 | Honda Off Road Range

HMC13530 - 2012 Off Road Range Brochure_V8.indd 12 specifications

CRF230F

Engine Type

223cc air-cooled, single-cylinder

4-stroke

Bore and Stroke 65.5 x 66.2mm

Compression Ratio 9.0:1

Valve Train SOHC; 2-valve

Carburation 28mm piston-valve

Ignition

CDI

Transmission

6-speed

Starter Electric

Dimensions 2,059mm x 812mm x 1,190mm

Final Drive #520 O-ring-sealed chain

Front Suspension 37mm leading axle Showa fork;

216mm stroke

Rear Suspension

Pro-Link Showa single shock with spring pre-load adjustability;

230mm travel

Front Brake

240mm hydraulic disc with dualpiston calliper and sintered metal pads

Rear Brake

110mm leading drum

Front Tyre 80/100 – 21 inch

Rear Tyre 100/100 – 18 inch

Wheelbase 1,372mm

Rake (Caster Angle) 26°45’

Trail 111mm

Seat Height 872mm

Ground Clearance 305mm

Fuel Capacity 8.2 litres

(including 1.5 litre reserve)

Kerb Weight 113.8kg

Warranty Period 6 months hondamotorcycles.com.au | 12

6/02/12 3:48 PM

Off Road

Ever wonder what’s over the next hill? The road registerable CRF230L – small in size, big on fun.

Compact, lightweight and designed to go anywhere.

CRF230L

Thanks to its modest size and weight, the CRF230L is able to fulfill an amazing variety of roles for novice motorcyclists through to seasoned riding veterans. On sealed roads or dirt roads, the allnew CRF230L is ready to handle all kinds of conditions.

Built around a rock-solid 223cc air-cooled including a two-valve head and a compression ratio of 9.0:1, the net result is a wide power range that offers plenty of grunt. With supple long-travel suspension, lower seat height and a six-speed transmission, it is fuel efficient and easy to handle.

HMC13530 - 2012 Off Road Range Brochure_V8.indd 13

*Overseas model shown

specifications

CRF230L

Engine Type

223cc 4-stroke, single-cylinder, air-cooled SOHC

Bore and Stroke 65.5 x 66.2mm

Compression Ratio

9.0:1

Valve Train SOHC; 2-valve

Carburation 30mm

Ignition CDI battery

Transmission

6-speed

Starter Electric

Dimensions 2,080mm x 825mm x 1,110mm

Final Drive #520 O-ring-sealed chain

Front Suspension 37mm leading axle Showa fork;

205mm stroke

Rear Suspension Pro-Link Showa single shock with spring pre-load adjustability;

155mm travel

Front Brake 240mm hydraulic disc with dualpiston calliper and sintered metal pads

Rear Brake

220mm hydraulic disc with single piston calliper and sintered metal pads

Front Tyre 2.75 – 21 inch

Rear Tyre 120/80 – 18 inch

Wheelbase 1,340mm

Rake (Caster Angle)

26°50’

Trail 103mm

Seat Height 810mm

Ground Clearance 245mm

Fuel Capacity

8.7 litres

(including 2.7 litre reserve)

Kerb Weight 121kg

Warranty Period 12 months

6/02/12 3:48 PM

Off Road

Great handling and ultra reliability make the rider friendly CRF150F a popular choice for those with some experience already under their belt.

CRF150F

With its modest 825mm seat height, ultra-reliable 149cc singlecylinder air-cooled 4-stroke engine and great-handling chassis, the CRF150F redefines off road fun for young adults, as well as mum and dad. Ideal for the young rider with some experience.

The CRF150F is extremely rider-friendly thanks to a responsive

24mm carburetor that offers excellent throttle response.

Its ultra-reliable CD ignition never needs maintenance and with an electric starter for convenient starting in all conditions you never need to worry about getting stuck when away from home.

Additional features include a maintenance-free battery, snailtype chain adjusters for easy maintenance, ultra durable body components, an 7.2 litre fuel tank engine for long range, highimpact plastic skid-plate for undercarriage protection, washable, reusable foam air filter and more.

When it comes to fun bikes, kids know what they want and what they want is a Honda. Geared to increase the fun factor while reinforcing safety at all times.

14 | Honda Off Road Range

HMC13530 - 2012 Off Road Range Brochure_V8.indd 14 specifications

CRF150F

Engine Type

149cc air-cooled single-cylinder

4-stroke

Bore and Stroke 57.3 x 57.8mm

Compression Ratio 9.5:1

Valve Train SOHC; 2-valve

Carburation 22mm piston-valve

Ignition DC-CDI

Transmission 5-speed

Starter Electric

Dimensions

1,945mm x 799mm x 1,111mm

Final Drive

#520 O-ring-sealed chain

Front Suspension

35mm leading axle Showa fork;

207mm stroke

Rear Suspension Pro-Link Showa single shock;

227mm travel

Front Brake 240mm hydraulic disc with dual-piston calliper and sintered metal pads

Rear Brake 110mm leading drum

Front Tyre 70/100 – 19 inch

Rear Tyre 90/100 – 16 inch

Wheelbase 1,328mm

Rake (Caster Angle) 26°02’

Trail 88mm

Seat Height 826mm

Ground Clearance 257mm

Fuel Capacity 8.2 litres

(including 1.5 litre reserve)

Kerb Weight 107.2kg

Warranty Period 6 months

6/02/12 3:48 PM

Off Road

The CRF100F exceeds expectations. When first entering the world of riding, it’s vital to inspire fun and confidence in the rider.

CRF100F

For the 12+ kids, the CRF100F has proudly won an outstanding reputation for versatile riding enjoyment, rugged construction and smooth, unruffled performance that inspires fun and confidence.

Its quiet, powerful and quick-starting air-cooled 4-stroke engine combines with long-legged front and rear suspensions to deliver just the right combination of lively performance and easy handling for long days and many years of off road riding fun.

Like its smaller brothers in the CRF range, all of Honda’s ‘fun bikes’ feature chrome, steel-spoked wheels combined with Honda

Racing styling and graphics reminiscent of the bigger CRFs.

specifications

CRF100F

Engine Type

99cc air-cooled single-cylinder

4-stroke

Bore and Stroke 53 x 45mm

Compression Ratio 9.4:1

Valve Train SOHC; 2-valve

Carburation 20mm piston-valve

Ignition CDI

Transmission 5-speed

Starter

Kick

Dimensions

1,869mm x 816mm x 1,102mm

Final Drive

#428 chain

Front Suspension

27mm leading axle Showa fork;

132mm stroke

Rear Suspension Pro-Link Showa single shock;

140mm travel

Front Brake 95mm leading drum

Rear Brake 95mm leading drum

Front Tyre 2.50 – 19 inch

Rear Tyre 3.00 – 16 inch

Wheelbase 1,264mm

Rake (Caster Angle) 29°52’

Trail 103mm

Seat Height 775mm

Ground Clearance 253mm

Fuel Capacity 5.6 litres

(including 1.1 litre reserve)

Kerb Weight 79kg

Warranty Period 6 months hondamotorcycles.com.au | 15

6/02/12 3:48 PM HMC13530 - 2012 Off Road Range Brochure_V8.indd 15

Off Road

Legendary toughness packed into a compact machine. The CRF80F is the next logical step up for young riders who are ready for more power.

CRF80F

Legendary for its built-in toughness and exciting performance, the CRF80F is a favourite among young riders who are ready to move up in power. The CRF80F is built with an easy to use smooth clutch and 5-speed gearbox to offer the perfect introduction to gear changing. Also powered by a rugged and reliable Honda 4-stroke engine and built with a compliant suspension system to stand up to all the dirty business a kid can throw at it.

The CRF80F quickly proves itself to be a fast friend for kids who dig the dirt.

16 | Honda Off Road Range

HMC13530 - 2012 Off Road Range Brochure_V8.indd 16 specifications

CRF80F

Engine Type

79.7cc air-cooled single-cylinder

4-stroke

Bore and Stroke 47.5 x 45mm

Compression Ratio 9.7:1

Valve Train SOHC; 2-valve

Carburation 18mm piston-valve

Ignition CDI

Transmission 5-speed

Starter

Kick

Dimensions

1,743mm x 778mm x 1,030mm

Final Drive

#420 chain

Front Suspension

27mm leading axle Showa fork;

126mm stroke

Rear Suspension Pro-Link Showa single shock;

110mm travel

Front Brake 95mm leading drum

Rear Brake 95mm leading drum

Front Tyre 2.50 – 16 inch

Rear Tyre 3.60 – 14 inch

Wheelbase 1,208mm

Rake (Caster Angle) 27°34’

Trail 68mm

Seat Height 727mm

Ground Clearance 206mm

Fuel Capacity 5.6 litres

(including 1.1 litre reserve)

Kerb Weight 74kg

Warranty Period 6 months

6/02/12 3:48 PM

Off Road

Compact, rugged and packed with a punch,

Honda’s fun bikes continue to please even the smallest critics.

CRF70F

Just like a true motocross champion, the CRF70F is bred from its legendary bigger brothers to provide years of fun for the

10 and under crowd. The exciting little CRF70F is a compact fun bike with the look and feel of a true motocross champion.

Featuring a low seat, easy-handling front fork and monoshock rear suspension to eat up the bumps and powered by a rugged, yet reassuring 4-stroke engine with an easy shifting semiautomatic transmission, the CRF70F really catches the hearts and minds of young riders.

The brakes are compact, lightweight and feature a unique design for both front and rear. Knobby tyres also offer excellent grip and long life which makes it the ideal choice for 8 to 10 year olds who are wanting to take up the trails for the first time.

specifications

CRF70F

Engine Type

71.8cc air-cooled single-cylinder

4-stroke

Bore and Stroke 47 x 41.4mm

Compression Ratio 9.0:1

Valve Train SOHC; 2-valve

Carburation 13mm piston-valve

Ignition CDI

Transmission 3-speed with automatic clutch

Starter

Kick

Dimensions

1,543mm x 694mm x 877mm

Final Drive

#420 chain

Front Suspension

27mm telescopic fork;

90mm stroke

Rear Suspension Single shock; 88mm travel

Front Brake 95mm leading drum

Rear Brake 95mm leading drum

Front Tyre 2.50 – 14 inch

Rear Tyre 3.00 – 12 inch

Wheelbase

1,055mm

Rake (Caster Angle)

26°

Trail

55mm

Seat Height 648mm

Ground Clearance 163mm

Fuel Capacity 6.2 litres

(including 2.1 litre reserve)

Kerb Weight 63kg

Warranty Period 6 months hondamotorcycles.com.au | 17

6/02/12 3:48 PM HMC13530 - 2012 Off Road Range Brochure_V8.indd 17

Off Road

Built tough for tough little tackers. A fun bike for kids and adults alike.

Rugged, dependable, safety first.

CRF50F

The CRF50F continues to be one the of best selling bikes in the country due to its incredible construction. With its single-shock rear suspension, inverted fork and bullet proof 49cc 4-stroke engine it can tough it out. This legendary fun bike has a narrow

109mm wide CR-type seat, slim fuel tank and extra-low 549mm seat height to provide excellent comfort and mobility for young riders.

Its high-tensile steel frame and swingarm also offer excellent balance of strength and compliance, all important features when dealing with whatever the kids might throw at it! Of course, the CRF50F also appeals to those adults who want to get in on the Fast 50’s craze at fun bike 4-stroke competitions across the country.

specifications

CRF50F

Engine Type

49cc air-cooled single-cylinder

4-stroke

Bore and Stroke 39 x 41.4mm

Compression Ratio 10:1

Valve Train SOHC; 2-valve

Carburation 13mm piston-valve

Ignition CDI

Transmission 3-speed with automatic clutch

Starter

Kick

Dimensions

1,302mm x 581mm x 774mm

Final Drive

#420 chain

Front Suspension

Inverted telescopic fork;

87mm stroke

Rear Suspension Single shock; 70mm travel

Front Brake 80mm leading drum

Rear Brake 80mm leading drum

Front Tyre 2.50 – 10 inch

Rear Tyre 2.50 – 10 inch

Wheelbase

911mm

Rake (Caster Angle)

25°

Trail

32mm

Seat Height 548mm

Ground Clearance 146mm

Fuel Capacity 2.6 litres

(including 0.7 litre reserve)

Kerb Weight 50kg

Warranty Period 6 months

18 | Honda Off Road Range

HMC13530 - 2012 Off Road Range Brochure_V8.indd 18 6/02/12 3:49 PM

Off Road

The TRX700XX redefines the Sport category of

ATVs with a whole new level of confidence, comfort and high performance.

TRX700XX

Unique Features: • All-new 686cc SOHC liquid-cooled fuelinjected 4-valve single-cylinder 4-stroke engine. • Doublewishbone, Independent Rear Suspension (IRS) with tuned swaybar. • Centred chain final drive system. • In-gear starting in

Forward or easy-to-use Reverse. • Piggyback rear shocks with adjustable pre-load. • Dual-spring front shocks with adjustable pre-load. • 11-inch-diameter rear rims with removable mud scrapers. • Radical new-style bodywork.

HMC13530 - 2012 Off Road Range Brochure_V8.indd 19

*Overseas model shown

specifications

TRX700XX

Engine Type

686cc liquid-cooled SOHC dry-sump single-cylinder 4-stroke

Bore and Stroke 102 x 84mm

Compression Ratio 10:1

Carburation Keihin PGM-FI with a 44mm throttle body fuel injection system

Ignition Full transistorised

Transmission 5-speed with reverse

Starter Electric

Dimensions 1,815mm x 1,165mm x 1,135mm

Final Drive O-ring-sealed chain

Front Suspension Independent double-wishbone with piggy-back reservoir shocks;

267mm travel

Rear Suspension Independent double-wisbone with piggy-back reservoir shocks;

235mm travel

Front Brake

Dual hydraulic 174mm discs

Rear Brake

Single hydraulic 200mm disc

Front Tyre

21 x 7R – 10 inch

Rear Tyre

22 x 9R – 11 inch

Wheelbase 1,260mm

Seat Height 830mm

Ground Clearance 260mm

Fuel Capacity 11.4 litres

Kerb Weight 229kg hondamotorcycles.com.au | 19

6/02/12 3:49 PM

Off Road

Honda’s race-ready

TRX450ER — has won in virtually every ATV racing discipline.

TRX450ER

Unique Features: • Powerful 4-stroke 450cc liquid-cooled

4-valve Unicam engine is based on the award-winning CRF450R motocross and CRF450X off road engines. • Lightweight, compact, internal auto decompressor provides superb coldstarting and hot-starting operation. • Cylinder-head cover is made of magnesium to reduce engine weight. • Press-fitted steel spark-plug pipe fits between forked exhaust rocker arms, further contributing to compact cylinder-head design. • 40mm Keihin

FCR-type carburetor features four rollers on the flat slide, resulting in very light throttle effort and smooth operation. • Vertically split crankcases feature a built-in oil pump, reducing weight compared to a conventional design. • Exhaust system uses a lightweight stainless steel header and muffler. • Independent doublewishbone, double A-arm front suspension with fully adjustable

Showa shocks. • Dual 174mm front disc brakes with dual-piston callipers and high-pressure front brake lines provide excellent stopping power. • Lightweight aluminium wheels reduce unsprung weight for outstanding handling.

specifications

TRX450ER

Engine Type

449.4cm

3

liquid-cooled singlecylinder 4-stroke

Bore and Stroke 96 x 62.1mm

Compression Ratio 12:1

Carburation Keihin 40mm flat slide with Throttle

Position Sensor (TPS)

Ignition AC-CDI with electronic advance

Transmission 5-speed

Starter Electric

Dimensions 1862mm x 1177mm x 1100mm

Final Drive O-ring-sealed chain

Front Suspension Independent double-wishbone with Showa shocks, featuring adjustable spring pre-load rebound and compression damping;

215mm travel

Rear Suspension Pro-Link with single Showa shock featuring adjustable spring preload, rebound and compression damping; 237mm travel

Front Brake Dual hydraulic 174mm discs with dual-piston calliper

Rear Brake Single hydraulic / mechanical

190mm disc with single-piston calliper

Front Tyre 21 x 7R – 10 knobby radial

Rear Tyre 20 x 10 – 9 knobby radial

Wheelbase

1275mm

Seat Height

833mm

Ground Clearance

111mm

Fuel Capacity 10.3 litres

(including 3 litre reserve)

Kerb Weight 178kg

20 | Honda Off Road Range

HMC13530 - 2012 Off Road Range Brochure_V8.indd 20 6/02/12 3:49 PM

Off Road

With aggressive styling and the convenience of a reverse gear, the sport model TRX400EX.

TRX400EX

Unique Features: • 397cc dry-sump air-cooled 4-stroke.

• One-piece cast-aluminium swingarm. • Triple disc brakes provide superb stopping power. • Radial 4-valve Combustion

Chamber (RFVC) for maximum combustion efficiency and horsepower. • Stainless steel dual exhaust head pipes resist corrosion. • Heavy-duty clutch has 2mm-thick plates designed to stand up to sport-ATV demands. • High-efficiency oil cooler supplements the large-capacity oil tank for maximum engine cooling. • All Pro-Link components are made of aluminium to further reduce vehicle weight.

• Independent double-wishbone front suspension offers

208mm of travel from twin Showa shock absorbers with fiveposition adjustable spring pre-load. • Lightweight aluminium wheels reduce unsprung weight for even better handling.

• Radial tyres with knobby pattern provide superb traction and cornering ability. • Easy-to-use eccentric chain adjuster.

specifications

TRX400EX

Engine Type

397cc RFVC air-cooled dry sump single-cylinder 4-stroke

Bore and Stroke 85 x 70mm

Carburation 38mm piston-valve with accelerator pump

Ignition AC-CDI with electronic advance

Transmission 5-speed with reverse

Starter Electric

Dimensions 1,822mm x 1,155mm x 1,118mm

Final Drive O-ring-sealed chain

Front Suspension Independent double-wishbone with

Showa shocks, 5-position spring pre-load adjustability; 209mm travel

Rear Suspension

Pro-Link fully adjustable single

Showa shock; 230mm travel

Front Brake Dual hydraulic 174mm discs with dual-piston calliper

Rear Brake Single hydraulic 220mm disc with single-piston calliper

Front Tyre 22 x 7 – 10 knobby radial

Rear Tyre 20 x 10 – 9 knobby radial

Wheelbase

1,217mm

Seat Height

836mm

Ground Clearance

105mm

Fuel Capacity

9.7 litres

(including 1.6 litre reserve)

Kerb Weight 186kg

Warranty Period 12 months hondamotorcycles.com.au | 21

6/02/12 3:49 PM HMC13530 - 2012 Off Road Range Brochure_V8.indd 21

Off Road

Honda’s sporty, fun-to-ride

TRX250EX offers TRX450R race-inspired styling, front and rear suspension built to take on anything the track can throw at it, as well as Honda’s revolutionary innovation – the SportClutch.

TRX250X

Unique Features: • TRX450R-inspired bodywork. • Hand-operated

Honda SportClutch that enables the rider to experience manual clutch actuation with the advantage of no stalling. • Lightweight

OHV air-cooled 229cc engine is longitudinally mounted to allow direct drive-shaft alignment to rear wheels. • Closed crankcase vent system. • Automatic cam-chain tensioner. • Electric starter.

• Maintenance-free shaft drive. • Steel swingarm and single rear shock absorber provides 145mm of travel. • Dual hydraulic 174mm front disc brakes and fully sealed rear mechanical drum brake.

22 | Honda Off Road Range

HMC13530 - 2012 Off Road Range Brochure_V8.indd 22 specifications

TRX250X

Engine Type

229cc air-cooled OHV longitudinally mounted singlecylinder 4-stroke

Bore and Stroke

68.5 x 62.2mm

Carburation 20mm piston-valve

Ignition AC-CDI with electronic advance

Transmission 5-speed with reverse

Starter Electric

Dimensions 1,739mm x 1,062mm x 1,082mm

Final Drive Direct rear driveshaft

Front Suspension Independent double-wishbone;

150mm travel

Rear Suspension

Swing arm with single shock;

145mm travel

Front Brake Dual hydraulic 174mm discs

Rear Brake Sealed mechanical drum

Front Tyre 22 x 7 – 10 knobby

Rear Tyre 22 x 10 – 9 knobby

Wheelbase 1,124mm

Seat Height

797mm

Ground Clearance

146mm

Fuel Capacity

9.5 litres

(including 2.6 litre reserve)

Kerb Weight 171kg

6/02/12 3:50 PM

Off Road

With TRX450ER-inspired styling, an electric starter, a refined suspension system and a bulletproof

86cc SOHC 4-stroke engine, the TRX90X is a great place for young riders to start.

TRX90X

Unique Features: • Honda’s 86cc SOHC 4-stroke engine offers smooth power delivery and legendary reliability. • Convenient electric starter for ease of starting in all conditions. • Maintenancefree CD ignition system never needs attention. • Honda’s durable automatic clutch makes takeoffs and shifting a breeze.

• Independent front suspension features a pair of rugged shock absorbers. • Versatile four-speed transmission. • Uniquely designed centre mud guards keep mud and debris away from the rider’s feet.

HMC13530 - 2012 Off Road Range Brochure_V8.indd 23 specifications

TRX90X

Engine Type

86cc air-cooled 4-stroke OHC single cylinder

Bore and Stroke 47 x 49.5mm

Carburation 16mm piston-valve

Ignition DC-CDI

Transmission 4-speed

Starter Electric

Dimensions 1,489mm x 895mm x 928mm

Final Drive O-ring-sealed chain

Front Suspension

Independent suspension;

65mm travel

Rear Suspension Swingarm with single shock;

65mm travel

Front Brake Dual sealed drum

Rear Brake Sealed mechanical drum

Front Tyre 20 x 7 – 8

Rear Tyre 19 x 8 – 8

Wheelbase 983mm

Seat Height 660mm

Ground Clearance 100mm

Fuel Capacity 6.3 litres

(including 1 litre reserve)

Kerb Weight 119kg

Warranty Period 12 months hondamotorcycles.com.au | 23

6/02/12 3:50 PM

PARTS AND ACCESSORIES

Your purchase of a Honda motorcycle guarantees you servicing and comprehensive parts backup from one of the biggest motorcycle dealer networks in Australia. And with a range of flexible finance packages available, Honda MPE Financial Services can help you own the Honda motorcycle of your dreams sooner.

Engineered for your Honda. Only one brand of oils and chemicals guarantees performance in

Honda engines. Starting with the development by R&D in Japan nobody else crafts these products to the industry’s most demanding standards… Honda quality!

Renowned for quality and reliability, Honda Genuine Parts are made to ensure optimum performance on all levels. By insisting on Honda Genuine Parts you’re guaranteed the best parts money can buy. Don’t settle for anything else, always demand Honda Genuine Parts.

At Honda, our goal is to create the best motorcycles in the world and is matched by an equally strong commitment to responsible and safe riding. Remember, always wear a helmet, eye protection and protective clothing when you ride. Always obey the road laws and always use common sense. Never ride under the influence of alcohol or drugs and never use the street as a racetrack. Respect your own limitations. Respect the rights of others on the road. And respect the overall motorcycling experience, there’s nothing else like it!

Honda recommends that all riders take a training course and read their owner’s manual thoroughly. For safety or training information, call your local Honda Australia Rider Training centre:

Melbourne (03) 9270 1377, Sydney (02) 9144 5725, Brisbane (07) 3344 5164.

Website: www.hart.honda.com.au

Honda Motorcycles are all about freedom, performance, adventure and superior quality. When it comes to making sure you can enjoy your new Honda you can rely on the Honda Australia Extended Warranty and Honda Insurances to provide you with the peace of mind that your riding pleasure and security will be maintained. For full terms and conditions, please see your local Dealer.

In the interests of product development, Honda reserves the right to alter specifications and features without notice. Availability of stock depicted in this brochure and colours may vary from time to time. For complete details see your local Honda Motorcycle Dealer. Colours, specifications and model availability as at 06/02/2012. HondaRent is powered by BOQ Credit Pty Ltd ABN 92 080 151 266 (trading as Honda MPE Financial Services) in conjunction with

Honda Australia Motorcycles and Power Equipment Pty Ltd ABN 96 006 662 862 (trading as Honda MPE). HondaRent is available to approved personal customers. Credit fees and charges may apply. Terms and conditions apply.

HMC13530 - 2012 Off Road Range Brochure_V8.indd 24

HMC13530

6/02/12 3:50 PM

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
